INSTRUCTION MANUAL
DVD Home Theatre System
DC-TS750
REMOTE CONTROLLER RB-TS750ST
TABLE OF CONTENTS
PRECAUTIONS .................................................................................. |
1 |
VARIOUS DISC PLAYING FUNCTIONS ....................................... |
14 |
CONTROLS ........................................................................................ |
2 |
MP3 CD OPERATION .................................................................... |
17 |
REMOTE CONTROL .......................................................................... |
3 |
INITIAL SETTINGS ........................................................................ |
18 |
BASIC CONNECTIONS ..................................................................... |
4 |
LANGUAGE CODE LIST ............................................................... |
20 |
ADDITIONAL CONNECTIONS EXAMPLES ...................................... |
7 |
LISTENING TO OTHER SOURCES ................................................ |
21 |
SYSTEM CONNECTIONS EXAMPLES ............................................ |
8 |
LISTENING TO THE RADIO ............................................................ |
21 |
BEFORE OPERATION ..................................................................... |
10 |
TIMER OPERATION ........................................................................ |
22 |
ADJUSTING THE CLOCK ............................................................... |
10 |
MAINTENANCE ............................................................................... |
23 |
VARIOUS ADJUSTING ..................................................................... |
11 |
TROUBLESHOOTING GUIDE ......................................................... |
23 |
PLAYABLE DISCS ............................................................................ |
12 |
SPECIFICATIONS ............................................................................ |
24 |
DISC PLAY ....................................................................................... |
13 |
|
|
PRECAUTIONS
ANT |
|
VIDEO OUT SELECT |
|
|
|
|
|
|
SPEAKERS |
|
|
RGB |
S-VIDEO |
FRONT/CENTER/SURROUND: 8Ω |
AM |
|
SUBWOOFER: 4Ω |
||
|
|
|
||
AV EURO / TV(AUDIO)IN |
|
|
||
LOOP |
|
|
||
|
(RGB OUT) |
MONITOR OUT |
|
|
|
VIDEO (AUDIO) IN |
|
|
|
EXT.ANT
FM75Ω
R |
L VIDEO |
S-VIDEO |
R |
L CENTER R |
L SUB WOOFER |
|
|
|
FRONT |
SURROUND |
|
CAUTION
THIS PRODUCT CONTAINS A LOW POWER LASER DEVICE, TO ENSURE CONTINUED SAFETY DO NOT REMOVE ANY COVERS OR ATTEMPT TO GAIN ACCESS TO THE INSIDE OF THE PRODUCT.
REFER ALL SERVICING TO QUALIFIED PERSONNEL.
-The apparatus shall not be exposed to dripping or splashing.
-No objects filled with liquids, such as vases, shall be placed on the apparatus.
-Do not use where there are extremes of temperature (below 5°C or exceeding 35°C) or where direct sunlight may strike it.
-Because of the DVD player’s extremely low noise and wide dynamic range, there might be a tendency to set the volume on the amplifier unnecessarily high. Doing so may produce an excessively large output from the amplifier which could damage your speakers.
-Sudden changes in the ambient temperature may cause condensation to form on the optical lens inside the unit. If this happens, take out the disc, leave the unit for about 1 hour, and then proceed to operate.
-When carrying the unit, be sure to remove any disc which may be inside and turn the power off. Wait at least 10 seconds, then unplug the mains lead from the AC outlet. Carrying the unit with a disc inside may damage the disc and/or the unit.
-Do not install this equipment in a confined space, such as a book case or built in cabinet.
-Placing the unit in a well ventilated area is strongly recommended. Do not place any object on the top of the unit.
Do not block ventilation holes.
The cabinet of the unit warms up when it is used for a long time, but it is not a malfunction.
Important Information:
To connect this unit to a TV, TV must have a Video input socket or an
EURO-AV/SCART socket. You cannot use an RF input socket or aerial terminal to connect this unit.
This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision
Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.
IMPORTANT
If the plug supplied with this equipment is not suitable for the socket outlets in your home it should be cut off and replaced with the correct type.
Disposal of Plug
If the non rewireable plug is to be cut off, the removed plug should be disposed of carefully as there is a shock hazard should the plug be inserted into a live socket.
Replacing Fuse
The detachable fuse cover must be replaced after changing the fuse. Only a 3A fuse should be used and should comply with BS1362 and should carry the ASTA mark
.
The wires in the mains lead are coloured in accordance with the following code;
Blue |
Neutral |
Brown |
Live |
The wires in the mains lead must be connected to the terminals in the plug as follows;
Wire colour |
Plug terminal marking |
Blue |
N or Black or Blue |
Brown |
L or Red or Brown |
Do not connect either wire to the earth terminal.
If the mains plug contains a fuse this should be 3A, if a plug without a fuse is used the distribution board fuse should not be greater than 5A.
The unit is not disconnected from the mains unless it is unplugged from the AC outlet.
1
CONTROLS
Front panel
1 |
2 |
3 |
1.Disc tray
2.Remote sensor (IR)
3.Display
4.Power button/Standby indicator (z/ON, STANDBY)
5.Headphones socket (PHONES)
10 |
9 |
8 |
7 |
6 |
5 |
4 |
6.Volume control (VOLUME)
7.Function button (FUNCTION)
8.Play button (a)
9.Stop button (n)
10.Open/Close button (q)
Display
1 |
|
|
2 |
|
|
3 |
4 |
5 |
|
|
|
6 |
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
DOLBY PL DTS |
T |
|
|
PROG. ALL 1 A-B |
||||||||||||||||||||
DOLBY DIGITAL |
|
|
kHz |
|
|
REP. |
|
|
|
7 |
||||||||||||||
|
|
|
|
|
|
|
|
|
|
C |
|
|
MHz |
|
SLEEP |
|
|
|||||||
|
|
|
|
|
ST MONO |
|
|
RDS |
|
ON OFF |
||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
18 |
|
|
|
16 15 |
13 |
|
|
12 |
10 |
|
8 |
|
|
|||||||||||
17 |
14 |
|
|
|
11 |
9 |
|
|
|
|
||||||||||||||
1.Dolby Pro Logic indicator (DOLBY PL)
2.DTS indicator (DTS)
3.Title and Track indicator (T)
4.Message or number indicators
(Title, chapter, track, playing time or other information)
5.Programme indicator (PROG.)
6.Repeat mode indicators (ALL, 1, A-B, REP.)
7.Timer indicator (0)
8.Timer off indicator (OFF)
9.Timer on indicator (ON)
10.Sleep indicator (SLEEP)
11.Kilohertz indicator (kHz)/Megahertz indicator (MHz)
12.RDS indicator (RDS)
13.Chapter indicator (C)
14.Pause indicator (k)
15.FM mono indicator (MONO)
16.FM stereo indicator (ST)
17.Play indicator (a)
18.Dolby Digital indicator (DOLBY DIGITAL)
|
ACCESSORIES |
RB-TS750ST remote control |
Front left speaker lead (Black and Blue) |
R6 (HP 7) battery x 2 |
Centre speaker lead (Black and Green) |
AM loop aerial |
Surround right speaker lead (Black and Orange) |
FM aerial wire |
Surround left speaker lead (Black and Gray) |
Video lead |
Subwoofer lead (Black and Brown) |
Front right speaker lead (Black and Red) |
Screw kit |
2
REMOTE CONTROL
Note: |
|
|
|
|
|
|
In this instruction manual, any operation of |
|
|
|
|
|
|
pressing any button while pressing the SHIFT |
|
1 |
|
7 |
|
|
button is as shown below. |
|
30 |
8 |
|||
Example: “Press the SHIFT + 1 ANGLE |
|
|
|
|||
buttons.” |
|
|
2 |
|
|
|
|
|
|
|
|
|
|
Controls |
z |
|
3 |
|
9 |
10 |
1. Power button ( |
/ON) |
|
6 |
|
|
|
2. Number and other function buttons |
|
|
|
|
||
Number buttons (1 - 9, 0) |
|
|
|
|
|
|
Angle button (ANGLE) |
|
5 |
|
|
|
|
Angle replay button (A.REPLAY) |
|
|
|
|
||
|
|
|
|
|
||
Zoom button (ZOOM) |
|
|
|
|
|
|
Audio button (AUDIO) |
|
4 |
29 |
|
11 |
|
Sleep button (SLEEP) |
|
|
||||
|
|
|
||||
Timer button (TIMER) |
|
|
28 |
12 |
|
|
Adjust button (ADJUST) |
|
|
|
|||
|
|
27 |
|
13 |
||
Set/Clear button (SET/CLEAR) |
|
|
14 |
|||
Clock button (CLOCK) |
|
|
26 |
15 |
||
3. TV control buttons |
|
|
|
|||
Note: |
|
|
|
25 |
16 |
|
- Only SANYO TVs can be operated |
|
|
24 |
|
17 |
|
using this remote control. |
|
|
18 |
|||
- There may be some older TV models |
|
|
2223 |
19 |
||
that cannot be operated with this remote |
|
|
21 |
20 |
|
|
control. If this is the case, use the original |
|
REMOTE CONTROLLER RB-TS750ST |
REMOTE CONTROLLER RB-TS750ST |
|
|
|
remote control supplied with the TV. |
|
|
|
|||
|
|
|
|
|
||
Power button (TV POWER) |
|
|
|
|
|
|
TV/Video select button (TV/VIDEO) |
|
|
|
|
|
|
Channel scanning buttons (TV CH) |
|
|
|
|
|
|
4. Tuner controls |
|
6. |
Shift button (SHIFT) |
21. Last memory button (L.MEMO) |
|
|
Radio data system mode button (RDS) |
7. |
Open/Close button (OPEN/CLOSE) |
22. Picture mode/Search mode button |
|
||
Tuner function/Band select button (TUNE/ |
8. |
Return button (RETURN) |
(PICTURE MODE/SEARCH MODE) |
|
||
BAND) |
|
9. |
Clear/Trim button (CLEAR/TRIM) |
23. Forward slow button (F.SLOW |
) |
|
Tuning/Programme type select buttons |
10. |
Test tone button (TEST) |
24. Reverse slow button (R.SLOW |
) |
|
|
(TUNE/PTY) |
|
11. |
Menu button (MENU) |
25. Fast forward/Fast reverse buttons (d, c) |
||
Preset tuning/Programme type check |
12. |
Directional arrow buttons (4, a, 5, b) |
26. Pause/Step button (k) |
|
|
|
buttons (PRESET/PTY CHK) |
13. |
On-screen display button (ON SCREEN) |
27. Title button (TITLE) |
|
|
|
5. Amplifier controls |
14. |
Play button (a) |
28. Enter button (ENTER) |
|
|
|
Surround button (SURROUND) |
15. |
Stop button (n) |
29. Setup button (SETUP) |
|
|
|
Muting button (MUTE) |
16. |
Skip/Next/Previous buttons (f, e) |
30. Programme button (PROGRAM) |
|
|
|
Bass button (BASS) |
17. |
Subtitle on/off button (S.T.ON/OFF) |
|
|
|
|
Sound preset button (SOUND) |
18. |
Subtitle change button (S.T.CH) |
|
|
|
|
Function button (FUNCTION) |
19. |
Repeat button (REPEAT) |
|
|
|
|
Volume buttons (VOLUME) |
20. |
A-B repeat button (A-B REP) |
|
|
|
|
Inserting batteries |
Remote control range |
Install two “R6 (HP 7)” batteries.
Remote sensor
|
|
|
|
|
Within |
|
|
|
|
|
|
|
|
approx. |
|
|
|
|
° |
° |
||||||
|
|
|
|
|
6 meters |
|||
|
|
|
|
|
|
|
30 |
30 |
Note:
Remove the batteries if the remote control is not to be used for a month or more. Batteries left in the unit may leak and cause damage.
3
BASIC CONNECTIONS
After all connections have been made, connect the mains lead to an AC outlet .
Note:
-Do not connect the mains lead to an AC outlet until all connections have been made.
-The system is not completely disconnected from the mains when the z/ON button is set to the zposition.
Speaker connections
To achieve proper stereo reproduction, connect the speaker wires without shorting to adjacent wires as shown in figure.
Speaker wire colour |
Use |
Black and Red |
Front right speaker |
Black and Blue |
Front left speaker |
Black and Green |
Centre speaker |
Black and Orange |
Surround right speaker |
Black and Gray |
Surround left speaker |
Black and Brown |
Subwoofer |
Note:
The SPEAKERS sockets are designed for use only with the supplied speakers. Do not use with other speakers. Connecting other speaker may damage the speaker and/or the unit.
If using other speakers, check their impedance/input power. FRONT/CENTER/SURROUND: 8 Ω or more/40 W or more SUBWOOFER: 4 Ω or more/80 W or more
Front right speaker |
Front left speaker |
Centre speaker |
Black |
Red |
Black |
Red |
Black |
Red |
Black |
Red |
Black |
Blue |
Black |
Green |
|
JCX-TS750 |
|
|
|
|
|
|
|
ANT |
|
|
|
VIDEO OUT SELECT |
|
|
||
|
|
|
|
|
SPEAKERS |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
RGB |
S-VIDEO |
FRONT/CENTER/SURROUND: 8Ω |
||
AM |
|
|
|
SUBWOOFER: 4Ω |
||||
|
|
|
|
|
|
|||
AV EURO / TV(AUDIO)IN |
|
|
|
|
|
|
||
LOOP |
|
|
|
|
|
|
||
|
(RGB OUT) |
MONITOR OUT |
|
|
|
|
|
|
|
|
|
|
|
|
|
||
VIDEO (AUDIO) IN |
|
|
|
|
|
|
|
|
EXT.ANT |
|
|
|
|
|
|
|
|
FM75Ω |
|
|
|
|
|
|
|
|
R |
L |
VIDEO |
S-VIDEO |
R |
L |
CENTER R |
L SUB WOOFER |
|
|
|
|
|
|
FRONT |
|
SURROUND |
|
Black |
Orange |
Black |
Gray |
Black |
Red |
Black |
Red |
Surround right speaker |
Surround left speaker |
||
Black |
Brown |
Black |
Red |
|
INPUT |
Subwoofer |
|
4
Speaker placement
Front right speaker |
|
|
|
Centre speaker |
Surround right speaker |
The supplied speakers have built-in magnetic stray |
|
field compensation. They may be placed close to a |
|||
|
|||
Front left speaker |
|
TV without affecting the colour purity. |
|
|
The five speakers are all the same and can be used |
||
|
|
for front left, centre, front right, surround left and |
|
|
|
surround right speakers. |
Subwoofer
Surround left speaker
Centre speaker
Front left speaker |
Front right speaker |
Subwoofer |
|
30° |
30° |
Surround left |
120° |
Surround right |
speaker |
|
speaker |
The front, centre, and surround speakers should be placed at approximately the same distance from the listening position.
Place the front left and right speakers either side of the TV. Place the centre speaker directly above the TV.
Place the surround speakers either sides of the listening position, or slightly to the rear, approximately 60 cm ~ 1 meter higher than ear level.
The subwoofer can be placed near the front speaker and not too far from the TV.
Note:
-The angles in the diagramme are approximate.
-Please refer to “Setting audio” on page 19.
Example: To hang the speaker on a wall |
Example: To mount the speaker with a stand |
Stand (not supplied)
Approx. 3 mm
Screw (supplied)
Built-in special nut, 3/16 inch diameter
Round head screw (not supplied)
Note: Take care when installing the speakers. They may cause damage or serious injury should they fall from their mountings.
5
Aerial connections
FM external aerial
AM loop aerial
ANT |
AM |
LOOP |
EXT.ANT
FM75Ω
Aerial wire
JCX-TS750 |
|
|
|
ANT |
|
|
|
AM |
AV EURO / TV(AUDIO)IN |
|
|
LOOP |
|
||
|
(RGB OUT) |
MONITOR OUT |
|
VIDEO (AUDIO) IN |
|
|
|
EXT.ANT |
|
|
|
FM75Ω |
|
|
|
R |
L |
VIDEO |
S-VIDEO |
In areas close to a transmitter the simple indoor aerial is sufficient to receive broadcasts. Extend the aerial wire as straight as possible and, while listening to the sound from the system, secure it in a position which yields minimal distortion and noise.
In fringe areas or where reception is distorted or noisy, an FM external aerial (not supplied) should be connected instead of the simple indoor aerial. Consult your dealer.
AM loop aerial
Assemble the loop aerial.
2
1
Unwind the aerial wires, then connect them to the AM LOOP terminals.
Place the loop aerial in a position which yields the best AM reception, or attach it to a wall or other surface.
1
3
2
Screws (not supplied)
Note:
To minimize noise, the speaker, mains and any other leads should not come close to the indoor or external aerial lead and AM loop aerial. Do not place the aerial leads close to the system.
Connecting to a TV with the video lead
Connect the video lead between the MONITOR OUT VIDEO socket of the unit and the video input socket of the TV.
JCX-TS750
TV
Video lead
ANT |
|
VIDEO OUT SELECT |
|
|
|
|
|
|
SPEAKERS |
|
|
RGB |
S-VIDEO |
FRONT/CENTER/SURROUND: 8Ω |
AM |
|
SUBWOOFER: 4Ω |
||
|
|
|
||
AV EURO / TV(AUDIO)IN |
|
|
||
LOOP |
|
|
||
|
(RGB OUT) |
MONITOR OUT |
|
|
|
VIDEO (AUDIO) IN |
|
|
|
EXT.ANT
FM75Ω
R |
L VIDEO |
S-VIDEO |
R |
L CENTER R |
L SUB WOOFER |
|
|
|
FRONT |
SURROUND |
|
VIDEO INPUT
Notes on connections
-Please refer to the instruction manuals for the components that you are connecting (TV, VCR, etc.).
-When you connect the unit to your TV and other equipment, be sure to turn off the power and disconnect all of the equipments from the AC outlet until all the connections have been made.
-Do not connect the MONITOR OUT (S-VIDEO/VIDEO) and AV EURO/TV (AUDIO) IN (RGB OUT) sockets of the unit to a VCR directly. The playback picture will be distorted because DVD discs are copy protected.
-Please consult your local audio/video dealer for more details.
6
ADDITIONAL CONNECTIONS EXAMPLES
Connecting to a TV with an S-video lead
Please follow these steps before turning on the power.
1.If your TV has an S-video input socket, connect the unit as shown in figure. (The MONITOR OUT VIDEO socket connection is not necessary.) You can enjoy clearer picture playback.
2.Set the VIDEO OUT SELECT switch to S-VIDEO.
Connecting to a TV with an EURO-AV/SCART lead
Please follow the steps below before turning on the power.
1.If your TV has an EURO-AV/SCART socket, connect the unit as shown. (Do not connect the video lead to the MONITOR OUT VIDEO socket.) You can enjoy high quality picture playback.
2.Set the VIDEO OUT SELECT switch to RGB.
TV
JCX-TS750 |
2 |
ANT |
|
VIDEO OUT SELECT |
|
|
|
|
|
|
|
SPEAKERS |
|
|
|
RGB |
S-VIDEO |
FRONT/CENTER/SURROUND: 8Ω |
S-VIDEO |
AM |
|
SUBWOOFER: 4Ω |
|||
AV EURO / TV(AUDIO)IN |
|
||||
LOOP |
|
|
INPUT |
||
|
(RGB OUT) |
MONITOR OUT |
|
|
|
|
VIDEO (AUDIO) IN |
|
|
|
|
EXT.ANT |
|
|
|
FM75Ω |
|
|
|
R |
L VIDEO S-VIDEO |
R |
L CENTER R L SUB WOOFER |
|
|
FRONT |
SURROUND |
S-Video lead (not supplied) |
|
1 |
|
JCX-TS750 |
|
2 |
TV |
ANT |
|
VIDEO OUT SELECT |
|
|
|
|
|
|
|
SPEAKERS |
|
|
|
RGB |
S-VIDEO |
FRONT/CENTER/SURROUND: 8Ω |
|
AM |
|
SUBWOOFER: 4Ω |
EURO-AV/SCART |
||
AV EURO / TV(AUDIO)IN |
|
||||
|
|
|
|
|
|
LOOP |
(RGB OUT) |
MONITOR OUT |
|
|
(RGB input facility) |
|
|
|
|||
|
|
|
|
||
|
VIDEO (AUDIO) IN |
|
|
|
|
EXT.ANT
FM75Ω
R |
L VIDEO |
S-VIDEO |
R |
L CENTER R |
L SUB |
|
|
|
FRONT |
SURROUND |
|
TV or Audio equipment connections
Connect an audio lead between the VIDEO (AUDIO) IN socket of the unit and the audio output socket of the TV or audio equipment.
|
|
|
|
1 |
|
|
EURO-AV/SCART lead (not supplied) |
||||
|
|
|
|
TV or Audio equipment |
|
|
|
|
|
(such as MD deck etc.) |
|
JCX-TS750 |
|
|
|
|
|
ANT |
|
VIDEO OUT SELECT |
|
L |
|
|
|
|
|
SPEAKERS |
|
|
|
RGB |
S-VIDEO |
FRONT/CENTER/SURROUND: |
|
AM |
|
SUBWOOFER: 4Ω |
AUDIO |
||
|
|
|
|||
LOOP |
AV EURO / TV(AUDIO)IN |
|
|
OUTPUT |
|
|
(RGB OUT) |
MONITOR OUT |
|
|
|
|
VIDEO (AUDIO) IN |
|
|
|
R |
EXT.ANT |
|
|
|
|
|
|
|
|
|
|
|
FM75Ω |
|
|
|
|
|
VIDEO |
S-VIDEO |
R |
L |
SUB WOOFER |
|
|
|
FRONT |
SURROUND |
Audio lead (not supplied)
Headphones
Connect stereo headphones (not supplied) to the PHONES socket for monitoring or for private listening. The speakers are automatically disconnected when headphones are connected.
Manufactured under license from Dolby Laboratories.
“Dolby”, “Pro Logic” and the double-D symbol are trademarks of Dolby Laboratories.
DVD disc with DTS may not work correctly. You can see the picture on the TV screen, but there is no sound.
“DTS” and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc.
7
SYSTEM CONNECTIONS EXAMPLES
JCX-TS750, TV and Audio equipment
TV |
Aerial |
EURO-AV/SCART
(RGB input facility) AERIAL IN
Aerial lead (not supplied)
EURO-AV/SCART lead (not supplied)
JCX-TS750
ANT |
|
VIDEO OUT SELECT |
|
|
|
|
|
|
SPEAKERS |
|
|
RGB |
S-VIDEO |
FRONT/CENTER/SURROUND: 8Ω |
AM |
|
SUBWOOFER: 4Ω |
||
|
|
|
||
AV EURO / TV(AUDIO)IN |
|
|
||
LOOP |
|
|
||
|
(RGB OUT) |
MONITOR OUT |
|
|
|
VIDEO (AUDIO) IN |
|
|
|
EXT.ANT
FM75Ω
R |
L VIDEO |
S-VIDEO |
R |
L CENTER R |
L SUB WOOFER |
|
|
|
FRONT |
SURROUND |
|
Audio equipment (such as MD deck etc.)
AUDIO OUT
L
R
Audio lead (not supplied)
JCX-TS750, TV and VCR
Aerial |
TV |
EURO-AV/SCART
(Audio monitor out) AERIAL IN
Aerial lead (not supplied)
EURO-AV/SCART lead (not supplied)
|
|
|
|
|
|
Aerial lead (not supplied) |
|||
|
VCR |
|
JCX-TS750 |
|
|
EURO-AV/SCART lead (not supplied) |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
ANT |
|
|
|
VIDEO OUT SELECT |
|
|
|
AUDIO OUT |
IN |
|
|
|
|
|
||
|
|
|
|
|
RGB |
S-VIDEO |
SUBWOOF |
||
AV |
|
|
|
|
|
|
|
|
FRONT/CE |
|
|
AM |
AV EURO / TV(AUDIO)IN |
|
|
|
|
||
|
|
|
LOOP |
|
|
|
|
||
|
L |
AERIAL |
|
(RGB OUT) |
MONITOR OUT |
|
|
|
|
|
VIDEO (AUDIO) IN |
|
|
|
|
|
|||
|
R |
OUT |
EXT.ANT |
|
|
|
|
|
|
|
FM75Ω |
|
|
|
|
|
|
||
|
R |
L |
VIDEO |
S-VIDEO |
R |
L CENTER R |
|||
|
|
|
|
|
|
|
|
FRONT |
SURRO |
Audio lead (not supplied)
8
Loading...
