Samsung MX-JS9500 User Manual

PREMIUM HI-FI Component System

user manual

MX-JS9500

imagine the possibilities

Thank you for purchasing this Samsung
product.
To receive more complete service,
please register your product at

www.samsung.com/register

This Nanum Gothic Eco font is provided by NAVER.

[MX-JS9500-ZA]AH68-02851A-00ENG.indd 1 2015-04-14 오후 1:37:22

Safety Information

2 English

Warning

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK).
NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK. DO NOT OPEN.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH THE

WIDE BLADE OF THE PLUG TO THE WIDE SLOT IN THE WALL

OUTLET. INSERT THE PLUG FULLY.

This symbol indicates "dangerous
voltage" inside the product that presents
a risk of electric shock or personal
injury.

This symbol indicates important
instructions accompanying the product.

WARNING

•

To reduce the risk of fire or electric shock, do
not expose this appliance to rain or moisture.

•

This product contains chemicals known to
the State of California to cause cancer and
reproductive toxicity.

CLASS 1 LASER PRODUCT

This Compact Disc player is classified as a
CLASS 1 LASER product. Use of controls,
adjustments or performance of procedures
other than those specified herein may result in
hazardous radiation exposure.

Complies with 21CFR 1040.10 except for
deviations pursuant to Laser Notice No. 50,
dated June 24, 2007.

DANGER :

•

VISIBLE AND INVISIBLE LASER RADIATION
WHEN OPEN. AVOID DIRECT EXPOSURE TO
BEAM. (FDA 21 CFR)

CAUTION :

•

CLASS 3B VISIBLE AND INVISIBLE LASER
RADIATION WHEN OPEN. AVOID EXPOSURE
TO THE BEAM. (IEC 60825-1)

•

THIS PRODUCT UTILIZES A LASER. USE
OF CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIATION
EXPOSURE. DO NOT OPEN COVER AND DO
NOT REPAIR YOURSELF. REFER SERVICING
TO QUALIFIED PERSONNEL.

CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
PRODUCTO LÁSER CLASE 1

[MX-JS9500-ZA]AH68-02851A-00ENG.indd 2 2015-04-14 오후 1:37:22

01 Safety Information

3 English

FCC NOTES (for U.S.A)

This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable
protection against harmful interference in
a residential installation. This equipment
generates, uses and can radiate radio
frequency energy and, if not installed and used
in accordance with the instructions, may cause
harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on.
If interference is present, the user is
encouraged to try to correct the interference
by one or more of the following measures:

•

Reorienting or relocating the receiving
antenna.

•

Increasing the separation between the
equipment and receiver.

•

Connecting this equipment to an outlet that
is on a different circuit than the radio or TV.

•

Consulting the dealer or an experienced
radio/TV technician for help.

This class B digital product meets all
requirements of the Canadian Interference ­Causing Equipment Regulations.

Important Safety Instructions

Read these operating instructions carefully
before using the unit. Follow all the safety
instructions listed below. Keep these operating
instructions handy for future reference.

1. Read these instructions.

2. Keep these Instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings.

Install in accordance with the
manufacturer's instructions.

8. Do not install near any heat sources such

as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that
produce heat.

9. Do not defeat the safety purpose of

the polarized or groundingtype plug. A
polarized plug has two blades with one
wider than the other. A grounding type
plug has two blades and a third grounding
prong. The wide blade or the third
prong are provided for your safety. If the
provided plug does not fit into your outlet,
consult an electrician for replacement of
the obsolete outlet.

10. Protect the power cord from being walked

on or pinched particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.

11. Only use attachment/accessories specified

by the manufacturer.

12. Use only with the cart,

stand, tripod, bracket,
or table specified by the
manufacturer, or sold
with the apparatus.
When a cart is used, use
caution when moving the cart/apparatus
combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning

storms or when unused for long periods
of time.

14. Refer all servicing to qualified service

personnel. Servicing is required when the
apparatus has been damaged in any way,
such as when the power-supply cord or
plug is damaged, liquid has been spilled
or objects have fallen into the apparatus,
the apparatus has been exposed to rain or
moisture, does not operate normally, or
has been dropped.

[MX-JS9500-ZA]AH68-02851A-00ENG.indd 3 2015-04-14 오후 1:37:23

Safety Information

4 English

Precautions

•

Ensure that the AC power supply in your
house complies with the identification sticker
located on the back of your product.

•

Install your product horizontally, on a suitable
base (furniture), with enough space around
it for ventilation (3 - 4 inches/7.5 - 10 cm).

•

Do not place the product on amplifiers or
other equipment which may become hot.
Make sure the ventilation slots are not
covered.

•

Do not stack anything on top of the product.

•

Before moving the product, ensure the Disc
Insert tray is empty.

•

To turn off the product completely, disconnect
the AC plug from the wall outlet. Disconnect
the AC plug from the wall outlet if you will
leave the device unused for a long period of
time.

•

During thunderstorms, disconnect the AC
plug from the wall outlet. Voltage spikes due
to lightning could damage the product.

•

Do not expose the product to direct sunlight
or other heat sources. This could cause the
product to overheat and malfunction.

•

Protect the product from moisture, excess
heat, and equipment creating strong
magnetic or electric fields (i.e. speakers.).

•

Disconnect the power cable from the AC
supply if the product malfunctions.

•

Your product is not intended for industrial
use. It is for personal use only.

•

Condensation may occur if your product or
disc has been stored in cold temperatures. If
transporting the product during the winter,
wait approximately 2 hours until the product
has reached room temperature before using.

•

The batteries used with this product
contain chemicals that are harmful to the
environment. Do not dispose of batteries in
the general household trash.

•

Always check the volume level of your Hi-Fi
Component System before playing to ensure
that you do not startle others with a sudden
burst of loud music.

•

Place the loudspeakers at a reasonable
distance on either side of the system to
ensure good stereo sound.

•

Direct the loudspeakers towards the listening
area.

•

Do not expose this apparatus to dripping or
splashing. Do not place objects filled with
liquids, such as vases, on the apparatus.

•

To turn this apparatus off completely, you
must disconnect it from the wall outlet.
Consequently, the wall outlet and power
plug must be readily accessible at all times.

•

Use only a properly grounded plug and
receptacle.

-An improper ground may cause electric
shock or equipment damage. (Class 1
Equipment only.)

Disc Storage & Management

•

Holding Discs

-Fingerprints or scratches on
a disc may reduce sound
and picture quality or cause
skipping.

-Avoid touching the surface of a disc where
data has been recorded.

-Hold the disc by the edges so that
fingerprints will not get on the surface.

-Do not stick paper or tape on the disc.

•

Cleaning Discs

-If you get fingerprints or dirt
on a disc, clean it with a mild
detergent diluted in water and
wipe with a soft cloth.

-When cleaning, wipe gently from the
inside to the outside of the disc.

•

Disc Storage

`Do not keep in direct sunlight.
`Keep in a cool ventilated area.
`Keep in a clean protection jacket and

store vertically.

[MX-JS9500-ZA]AH68-02851A-00ENG.indd 4 2015-04-14 오후 1:37:23

Contents

Contents

5 English

Safety InformatIon

2

Warning

4

Precautions

4

Disc Storage & Management

GettInG Started

7

Front Panel

8

Rear Panel

9

Remote Control

10

Accessories

10

Connecting the Speakers

10

Cautions on Moving the Speakers

11

Moving the Speaker Set

11

Moving a Speaker

functIonS

12

Using The Samsung Audio Remote App

12

Install Samsung Audio Remote App

12

Launching the Samsung Audio Remote
App

12

The Display function

12

Changing Display mode

12

The DEMO function

13

Playing a CD

13

Loading a Compact Disc

13

CD/MP3/CD-R Playback

13

Selecting a Track

14

Searching for a Specific Music Passage
on a CD

14

Repeat One or All Tracks on a CD

14

Playing USB Devices

14

USB Device Playback

14

To Select a File from a USB Device

15

To repeat one or all files

15

To Use High Speed Search

15

To Delete a File

15

To Move to the Next/Previous Folder
and Next/Previous File

16

To safely remove a USB device

16

Read Before Connecting USB Storage
Devices

16

Searching for a Track Quickly

16

Using the MY LIST Function

17

Viewing or Editing MY LIST Tracks

17

Bluetooth

17

What is Bluetooth?

18

To connect the Hi-Fi Component to a
Bluetooth device

18

To disconnect a Bluetooth device from
the Hi-Fi Component

19

To disconnect the Hi-Fi Component
from the Bluetooth device

19

Using Bluetooth Power On

19

TV SoundConnect

19

To connect the Hi-Fi Component to a
SoundConnect Compatible Samsung TV

20

To disconnect the TV from the Hi-Fi
Component

20

To disconnect the Hi-Fi Component
from the TV

20

Using My Karaoke

21

Auto Change Function

[MX-JS9500-ZA]AH68-02851A-00ENG.indd 5 2015-04-14 오후 1:37:24

6 English

21

Listening to the Radio

21

To Store the Stations You Want

22

Selecting a Stored Station

22

Timer Function

22

Setting the Clock

22

Setting the Timer

23

Cancelling the Timer

24

Setting the Sleep Function

24

The Recording Function

24

Basic Recording

26

Recording Speed

26

Special Sound Effects

26

Selecting PRESET EQ Mode

26

Selecting USER EQ Mode

27

FOOTBALL MODE function

27

GIGA PARTY Function

27

BEAT WAVING Function

27

DJ BEAT Function

28

+PANNING Function

28

NON-STOP MUSIC RELAY Function

28

TEMPO Function

28

PARTY BEAT Function

29

Software Update

29

Disc and Format Compatibility

30

Supported Audio Formats

appendIx

31

Troubleshooting

31

Important Note About Service

32

Specifications

[MX-JS9500-ZA]AH68-02851A-00ENG.indd 6 2015-04-14 오후 1:37:24

02 Getting Started

Getting Started

Front Panel

1

Display Panel

2

PARTY BEAT Pads

3

PARTY SOUND ◀ / ▶ button
PARTY BEAT button

4

MIC 1/2 jacks
MIC VOL JOG

5

TEMPO button
AUTO CHANGE button
NON-STOP MUSIC RELAY button
BEAT WAVING button

6

SEARCH button
FOLDER -/+ button
MEMORY button
DELETE button
ENTER button

7

AUX 1/2 Source buttons
TUNER Source button
DJ BEAT button for DJ sound effect
+PANNING button for DJ sound effect
Remote control sensor
DISC tray
BACKWARD SEARCH/SKIP button

7

STOP button
CD Source button
PLAY/PAUSE button
FORWARD SEARCH/SKIP button
OPEN/CLOSE button for Disc

8

VOLUME/SEARCH JOG

9

MY LIST button
USB 1/2 Source buttons
USB REC button
USB 1 jack for Playback only.
USB 2 jack for Playing and USB

Recording

0

Bluetooth Source button
TV SOUNDCONNECT Source button
POWER button

•

Press this button to switch your
product on or off.

!

Equalizer Jogs for adjusting 5-Band EQ
80Hz / 200Hz / 800Hz / 2kHz / 8kHz

@

PRESET EQ button
USER EQ button

GIGA PARTY button

FOOTBALL MODE button
DISPLAY/DEMO button

1

3

4
5

9

76 8

!

0

2

@

2

7 English

[MX-JS9500-ZA]AH68-02851A-00ENG.indd 7 2015-04-14 오후 1:37:35

Getting Started

Rear Panel

1

POWER

•

Insert only the provided power cable.

2

FM Antenna Terminals

1. Connect the FM antenna to the FM

antenna connector terminal.

2. Slowly move the antenna wire until

you find a location where reception
is good, then fasten it to a wall or
other rigid surface.

3

AUX IN 2 Terminals

1. Use an Audio Cable (not supplied)

to connect AUX IN 2 on the main
unit to Audio Out on an external
analog output device.

•

Be sure to match connector colors.

•

If the external analog output device
has only one Audio Out jack, connect
either left or right.

•

Press the AUX 1/2 button to select
AUX 2.

•

If the product is in AUX mode for
more than eight hours and no
buttons on the front panel or remote
are pushed, the system will turn off.

4

AUX IN 1 Terminals

1. Use to connect an external device

such as an MP3 player.

•

Connect AUX IN 1 on the rear panel
of the main unit to the Audio Out of
an external device/MP3 player.

•

Press the AUX 1/2 button to select
AUX1.

5

LED Terminals for Speaker Beat Waving.

6

ONLY FOR SERVICE

•

This jack is for testing only. Please do
not use.

7

Cooling fan

•

The fan operates while the unit is
powered on.
If you set the unit to the minimum
volume, the fan won't operate.
Secure a minimum 6 inches (15 cm)
of clear space on all sides of the fan
when installing the main unit.

8

4.2 CH Speaker Terminals

1. To achieve the correct sound quality,

when you connect the speakers,
match the color of the speaker plugs
to the color of the speaker jacks. See
below.

•

LEFT channel (marked

, White/

Purple).

•

RIGHT channel (marked

, Red/

Purple).

•

MID / TW channel (marked , WHITE)

•

MID / TW channel (marked

, RED)

•

Don't force the Purple SUBWOOFER
connector into the White or Red
speaker jack.

8 English

MID / TW

MID / TW

2134 5 6 87

[MX-JS9500-ZA]AH68-02851A-00ENG.indd 8 2015-04-14 오후 1:37:37

02 Getting Started

Installing Batteries In The Remote Control

•

Place batteries in the remote control so they
match the polarity of the illustrations in the
battery compartment. : (+) to (+) and (–) to (–).

•

Do not dispose of batteries in a fire.

•

Do not short circuit, disassemble, or overheat
the batteries.

•

There is a danger of explosion if the battery
is replaced with the wrong battery type.
Replace only with the same or equivalent
type.

•

The remote control can be used up to
approximately 23 feet (7 meters) in a
straight line from the system.

Remote Control

Power

Bluetooth

TUNING MODE

PLAY/PAUSE

TIMER SET

MY KARAOKE

CD

USB

TUNER/AUX

NON-STOP MUSIC RELAY

PRESET EQ

STOP

FOOTBALL

VOLUME -

MY LIST

TIMER ON/OFF

DISPLAY

MIC VOLUME (-, +)

DELETE

BEAT WAVING

TV SoundConnect

REC SPEED

MO/ST, TEMPO

+PANNING

REPEAT

AUTO CHANGE

VOLUME +

SEARCH

SLEEP (Set a sleep time to shut off the
product.)

,,.

FORWARD, BACKWARD SEARCH

USB REC

DJ BEAT

GIGA PARTY

MUTE (Turn off the sound temporarily.
Press again to turn the sound back on.)

SKIP/TUNING

FOLDER (-, +), EFFECT (-, +)

MEMORY

USER EQ

9 English

[MX-JS9500-ZA]AH68-02851A-00ENG.indd 9 2015-04-14 오후 1:37:37

Getting Started

Accessories

Check for the supplied accessories below.

User Manual

(AH68-02851A)

Remote Control / Batteries

(AH59-02694A/4301-000116)

Power Cable

(3903-000467)

FM Antenna

(AH42-00021A)

•

Figures and illustrations in this user's manual are provided for reference only and may differ
from actual product appearance.

Connecting the Speakers

Recommended speaker setup.

|IMPORTANT

|

✎The product may not operate properly if it is

subject to shaking or external shocks or if the
speakers are not installed as recommended.

✎Do not stretch the speaker wires or place a

heavy object on them.

✎When using the main unit and speakers, place

them on an even (not slanted), firm surface.

Cautions on Moving the Speakers

•

Before moving the main unit and speakers, make sure to disconnect all speaker cables between
the main unit and the speakers.

10 English

[MX-JS9500-ZA]AH68-02851A-00ENG.indd 10 2015-04-14 오후 1:37:39

02 Getting Started

11 English

Moving the Speaker Set

You can move the speakers to and install them in a desired location.

Moving a Speaker

1. Unlock the wheels by pulling up the lock

latch in the direction of the arrow.

•

To lock the wheels, pull down the latch.

2. Hold the speaker by the handles located on

either side of the speaker's top, and then roll
the speaker to its new location.

|CAUTION

|

✎Before using the speakers, make sure you have installed them on an

even surface and have locked their wheels.

✎Whenever you move a speaker for installation, repair, or cleaning,

move it in a straight line (back and forth). Moving it in a zigzag
fashion may damage the floor.

✎Be careful not to tip a speaker over when moving it on an uneven

surface.

✎Do not place a speaker on a slant or on a slanted surface. otherwise

it can move even if its wheels are locked.

< Locked > < Unlocked >

[MX-JS9500-ZA]AH68-02851A-00ENG.indd 11 2015-04-14 오후 1:37:39
