350 S. St. Charles St. Jasper, In. 47546
Ph. 812.482.2932 Fax 812.634.6632
www.ridetech.com
Part # 11050701
58-64 Chevy Impala Rear HQ Series Shock Kit
Components:
2 24179999 7” Stroke HQ Series shock
2 90002024 Master Series 1.7” eyelet
4 90001994 .625” bearing
8 90001995 Bearing snap ring
2 90002060 Extended T-bar (installed in shock body)
2 90001980 Snap ring for T-bar
4 90002067 Aluminum spacer for .625” bearing
Hardware:
4 99371004 3/8” x 1 ¼” USS bolt Shock to frame
4 99372002 3/8” USS Nylok nut Shock to frame
8 99373003 3/8” SAE flat washer Shock to frame
2 99502002 ½” SAE Nylok Nut Shock to lower stud
2 99503001 ½” SAE flat washer Shock to lower stud
350 S. St. Charles St. Jasper, In. 47546
Ph. 812.482.2932 Fax 812.634.6632
www.ridetech.com
1. Attach shock T-Bar to frame using 3/8” x
1 ¼” bolts, Nylok nuts and flat washers.
2. Attach the bottom of the shock to factory
shock stud using the ½” Nylok nut & flat
washer supplied. Install one aluminum
spacer on each side of the bearing.
