PRECAUTIONS

Thank you for purchasing this HI-FI product. Taking time to read these operating instructions carefully before use will acquaint you fully with all its features and help ensure optimum performance.

In order to simplify the explanation illustrations may sometimes differ from the originals.

Do not remove the case and bottom panel

Any inspections or adjustments inside the unit may lead to malfunctions and electric shocks. Do not touch any of the inside parts.

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER(OR BACK)

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lighting flash with arrowhead symbol, within an equilateral, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

WARMING: To prevent fire or shock hazard, do not expose this appliance to rain or moisture

Power plug

When disconnecting the power cord from the power outlet, always take hold of the plug, and not the wire, and pull free. Never connect or disconnect the power plug with wet hands since you may receive an electric shock.

Remember to disconnect the power plug from the power outlet when you do not intend to use the unit for a prolonged period of time.

1

Do not block the ventilation holes

Do not block the ventilation holes on the top of the unit by placing records or other objects over them. This will increase the inside temperature may lead to a failure or malfunction.

Installation precautions

Do not install the unit in any of the following locations since this may result in deterioration in performance of malfunction:

*Locations exposed to direct sunlight or near objects radiating heat such as heating appliances.

*Locations exposed to moisture or humidity.

*Locations with poor ventilation exposed to dust and dirt.

*Locations which are unstable and not perfectly flat or which are susceptible to vibration.

Do not wipe with thinners

Wipe the panels and case from time to time with a soft cloth. Using any kind of thinner, alcohol or volatile liquid will mar the surface, cause blotching on the exterior and erase the markings and should therefore be avoided. Do not use insecticide sprays in the vicinity.

Dripping warning: The product shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the product.

Pyramid Car Audio PR530A User Manual

CONNECTIONS

Connection precautions

When connecting, either disconnect the power plug from the power outlet or turn off the unit’s power using the POWER switch.

Check the left and right channels and connect properly (Left to L and Right to R).

Insert the plugs securely. Improper connection can lead to the generation of noise.

Compact disc player

Connect the CD terminals to the OUTPUT terminals on the compact disc player using the pin-plug cord.









TAPE



EQ

PHONO

CD

AUX

VIDEO TUNER PLAY

REC

PLAY

REC

L

R

LINE

PLAY(OUT) (IN) REC









TAPE



EQ

PHONO

CD

AUX

VIDEO TUNER PLAY

REC

PLAY

REC

L

R

OUTPUT

CD/AUX terminals

These terminals have an electrical performance which is equivalent to that of the CD terminals and the TUNER terminals which means that they can be used as the audio output terminals for a video disc player or TV tuner. Connect these terminals to the OUTPUT terminals on the component using the pin-plug cord.

TAPE Deck

Recording connections: Connect the TAPE REC terminals to the input (LINE IN) terminals on the tape deck using the pin-plug cord.

Playback connections: Connect the TAPE PLAY terminals to the output (LINE OUT) terminals on the cassette deck using the pin-plug cord.

PROCESSOR terminals

These terminals are used to connect a graphic equalizer or sound processor. They also come in handy for connecting an AV (audio/video) selector unit.

Use pin-plug cords to connect the REC terminals to the INPUT terminals on the selected component and also to connect the PLAY terminals to its OUTPUT terminals.







TAPE



EQ

PHONO

CD

AUX

VIDEO TUNER PLAY

REC

PLAY

REC

L

R

LINE

PLAY(OUT) (IN) REC

2
