PLEASE READ THIS MANUAL CAREFULLY BEFORE OPERATION
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER
[OR BACK]
THIS PRODUCT MUST BE EARTHED
NO USER-SERVICEABLE PARTS INSIDE,
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
Features:
• LED Screen
• Touch Button to control the Echo, Light, Bass, and EQ
• Instantly Stream Music from your iPhone, Android, MP3 Player, Tablet, PC, etc
• High Performance, High-Quality Speaker
• 60 Watts of Peak Music Power Output
• Includes Multi-color DJ LED Light
• USB/Micro SD Port/BT/FM/Aux Input
• Digital Display
• ON/OFF Switch to Control LED Lights
• Built-in Rechargeable Battery
• Master Volume, Mic Volume,
• (2) 1/4’’ -inch (6.35mm) Microphone/ Guitar Instrument Inputs
• Aux (3.5mm) Input Jack
• Convenient Integrated Carry Handle
• Rugged & Durable Molded Cabinet Design
• Perfect for Karaoke, Parties, Conferences, Indoors/Outdoors, and More
Wireless BT Streaming:
• Instantly Stream Music from Your BT Devices
• Works with All Your Favorite BT Devices
(iPhone, Android, Smartphone, iPad, Tablet, PC, etc.)
• Wireless BT Version: 5.0
• Wireless BT Range: >10m
• Wireless BT Network Name: Pyle
What's in the Box:
• Speaker box
• Remote Control
• Manual
Tweeter Specs:
• Size: 1.5'' -inch
• Material: Mylar
• Sensitivity: 94dB/1m. w
• Voice Coil: Piezoelectric
• Frequency Response: 2k-16KHZ
Subwoofer Specs:
• Size: 6.5'' -inch
• Material: Stamped Steel Basket
• Impendence: 4 Ohm
• Magnet: 10 oz.
• Voice Coil: 25mm, 1'' -inch
• Sensitivity: 88dB
• Frequency Response: 63Hz-7.5kHz
Technical Specs:
• Max Power Output: 300W (2x150 Watt)
• Amplier Class D
• Lithium Battery 11.1V / 3600mAh
• Battery Life: 3- 4 hours
• LF: 2 x 6.5" -inches
• Impendence: 4 Ohm
• Digital Audio File Compatibility: MP3, WMA, WAV
• Maximum SD/USB Flash Memory Support: 64GB
• Power: 100-240V 50/60HZ
• Dimensions (L x W x H): 21.95’’ x 9.56’’ x 9.9’’ -inches
www.PyleUSA.com
2
www.PyleUSA.com
3
OPERATION
1. Prior to switching ON, turn volume down to minimum.
2. Connect the audio source to the appropriate input socket.
3. Connect to the mains supply.
4. Set the volume with the applicable control.
Controls and Connections
INSTRUCTIONS
• Do not overload the box to avoid damage to the speakers.
• Do not place an open re (candle, etc.) on top or next to the box - FIRE HAZARD
• Only connect to an earthed mains outlet of AC 100-240V-50/60Hz.
• For indoor use only. If the box is used outdoors, you need to make sure that
no humidity can enter the box.
• When not in use, unplug the unit from the mains.
• Unplug the unit from the mains prior to checking or replacing the fuse.
• Make sure that the box is placed on a stable, strong surface.
• The boxes can be hung. Use only strong and approved mounting material.
During the mounting, make sure that nobody is standing below the
mounting area.
• Do not place liquids on the box and protect it against humidity.
Humidity can shorten the life time considerably.
• Only use suitable means of transportation if you want to move the box –
BEWARE OF YOUR BACK!!
• Always unplug the unit during a thunderstorm or when it is not in use.
• If the unit has not been used for a long period of time, condensation can occur
inside the housing. Please let the unit reach room temperature prior to use.
1. MIC 1 Input
2. MIC 2 Input
3. Line Input
4. USB Input
5. Micro SD Card Input
6. Main power switch
7. LED Light switch
8. Mic input volume control
9. Master volume control
10. ECHO - for mic in port
11.E CHO + for mic inport
www.PyleUSA.com
4
12. Wireless BT mode
13. LED Color Control
14. MIC Input to your USB driver or MicroSD card
15. MODE: USB/MicroSD/BT/FM/LINE
16. BASS Control
17. Previous Song
18. Next Song
19. Repeat one/repeat all/Random
20. Play/Pause
21. EQ mode
22. LED Display screen
• Never try to repair the unit yourself.
lt does not contain any user serviceable parts.
• Run the mains lead in such a way that nobody can fall over it and nothing
can be put in it.
• Set the unit to the lowest volume prior to switching it on.
• Keep the unit out of the reach of children.
www.PyleUSA.com
5
