Page 1
Page 2
Please read all instructions before use for the best performance
of this product. Save these instructions for future reference.
Box Contents
MUTE
VOL+
VOL-
OPT COAX
BT
USB
LINE
MOVIE MUSIC
DIALOG
Bookshelf Speaker Remote Cont rol Quick Start
RCA to RCA
audio cable
Stereo RCA to
3.5mm audio c able
Digital Opt ical cable Power Adapter
LED Indicators and Button Introduction
Infrared receiver
LED I ndicators
Active Speaker
www.PyleUSA.com2
Standby BT Opt ical
Line in Coaxial USB
RCA to RCA
audio cable
Page 3
03
0201
07
EQ
04
05
06
VOLUME
0
-2
+2
-4
-6 +6
TREB
0
-2
+2
-4
-6 +6
BASS
Model: PBKSRB40
Power Consumption: 60W
OPT
L R
+4
+4
SPEAKER OUT
08
COAX
09
LINE IN
USB
10
11
DC IN
12
19-21v
Active Speaker
SPEAKER IN
13
Passive Speaker
Know Your Remote
01. Power switch
02. Input selection
Press in to navigate between audio sources:
BT -> Optical -> Coaxial -> LINE IN -> USB
03. Sound effects
Press in to navigate between audio sources:
Music -> Dialogue -> Movie
04. Volume control
05. Treble control
06. Bass control
07. Optical input port
08. Coaxial input port
09. Line in input port
10. USB input port
11. Left speaker audio output
12. Power port
13. Left speaker audio in
VOL+
VOL-
OPT COAX
BT
USB
MOVIE MUSIC
MUTE
LINE
DIALOG
VOL+
COAX
USB
MOVIE
DIALOG
Power button
Volume up
Previous track
Play/pause
Coaxial mode
USB mode
Movie mode
Dialogue mode
MUTE
VOL-
OPT
BT
LINE
MUSIC
Mute/Unmute
Volume down
Next track
Optical mode
BT mode
Line mode
Music mode
www.PyleUSA.com 3
Page 4
Connection Diagram
TV
a
d
BT signal
up to 30 f eet
BT Devic e
VOLUME
0
-2
-4
-6 +6
TREB
0
-2
-4
-6 +6
BASS
Model: PBKSRB40
Power Consumption: 60W
OPT
+2
+4
+2
+4
EQ
L R
LINE IN
USB
SPEAKER OUT
COAX
DC IN
19-24v
e
f
SPEAKER IN
b
c
Active Speaker Passive Speaker
USB
a
Coaxial cable (not supplied)
c
(not supplied)
USB
e
Stereo RCA to 3 .5mm audio cable
RCA to RCA audio cable
f Power Adapter
(supplied)
g
Digital Opt ical cable
b
d
BT
(supplied)
g
www.PyleUSA.com4
(supplied)
(supplied)
Page 5
Connecting with a TV
Active Speaker
Coaxial cable
C
(not supplied)
A
Method 1. Connecting using an Optical cable.
Select Optical mode and set the TV’s audio output to “PCM”.
(More information on PCM page)
B
Method 2. Connecting using a RCA to 3.5mm cable.
Select RCA mode.
Method 3. Connecting using an Coaxial cable.
C
Select Coaxial mode and set the TV’s audio output to “PCM”.
(More information on PCM page)
Opti cal digital
A
B
(supplied)
cable
RCA to 3.5mm
(supplied)
cable
TV
Setting “PCM” on your TV
When all cables are connected properly, and LED indicator
lights properly, if there is no sound from tv or Soundbar, please
set your tv as below:
www.PyleUSA.com 5
Page 6
1. Press "Menu" on the TV’s remote control.
2. Press the arrow keys on the remote to scroll to "Audio Settings."
3. Press "OK" on the remote control.
4. Scroll to "Advanced Audio" and press "OK". Some televisions
may not have an"Advanced Audio" menu and may list various
audio settings instead.
5. Scroll to "Audio Output Mode" or "Digital Audio Output Mode"
and press "OK".
6. Scroll until "PCM" is displayed as the current audio output.
7. Press "OK" to save the settings.
Connecting a Wireless BT Device
BT
or
BT signal
up to 30 f eet
a. Press the “BT” button on the remote or press the “ ” button
on back panel of the active speaker, the LED indicator blinks blue.
b. Turn on Wireless BT on the BT device.
c. Select “PyleUSA” and connect it. When your BT device is
connected, the LED indicator blinks blue slowly.
d. Play music les from the device, connected via BT, through the
bookshelf speaker.
www.PyleUSA.com6
Page 7
Troubleshooting
No sound
• Check if the power indicator light is ON.
• Try to turn up the volume using either the master volume control
or remote control.
• Ensure the audio cables are rmly connected and the input is
set correctly on the speakers.
• Check if there is signal output from the audio source.
Cannot connect via Wireless BT
• Make sure the speaker is switched to BT input, in other audio
input mode BT can not be paired or connected. Disconnect from
any BT device by press and hold the volume dial in BT mode,
then try again.
• Eective BT transmission range is 10 meters, make sure operation
is within the range.
• Try another BT device for connection.
The PBKSRB40 Bookshelf Speaker does not turn on
Check if mains power is connected or if the wall outlet is switched on.
Specications
Power output:
Signal to noise ratio dB(A):
Input sensitivity:
Frequency response:
Bass unit:
Tweeter unit:
L/R: 30W + 30W
L/R: ≥85dB (A)
LINE IN: R/L: 650±50mV
Coaxial: R/ L: 500±50mV
OPT: R/L: 500±50mFFS
BT: R /L: 700±50mFFS
40HZ-18KHZ
4 inch ( 116mm)
Φ13mm silk dome t weeter
www.PyleUSA.com 7
Page 8
Questions? Comments?
We are here to help!
Phone: (1) 718-535-1800
Email: support@pyleusa.com
