Operating
Instructions
PowerJet
2500
RS
HIGH
PRESSURE
CLEANER
Contents
Introduction..........................................................................3
Environmental protection..................................................3
Scope of product...................................................................3
Description of symbols..................................................3
Specifications........................................................................3
Safety rules.................................................................................4
Hazard symbols and meanings................................................4
Unpacking...................................................................................6
Carton contents.........................................................................6
Assembly....................................................................................7
Attaching the handle.................................................................7
Checking the engine oil..............................................................7
Filling the fuel tank.................................................................8
Connecting hose and water supply to pump...........................8
Inlet water supply requirements................................................9
Operating checklist...................................................................9
Starting the machine.......................................................................10
Stopping the machine.....................................................................10
Nozzle installation selection...........................................................10
Selecting the proper nozzle............................................................11
Cleaning & applying chemicals...........................................12
Pressure washer rinsing.................................................................13
Cleaning horizontal surfaces..........................................................13
Cleaning vertical surfaces..............................................................13
Removing paint...............................................................................13
Cleaning radiator fins.....................................................................14
General maintenance.....................................................................14
Engine maintenance......................................................................16
Pump maintenance........................................................................16
Service Chart..................................................................................17
Storage...........................................................................................17
Protecting the pump.......................................................................17
Troubleshooting..................................................................18
Warranty..........................................................................................21
POWERJET HIGH PRESSURE CLEANER
2.
Read this manual carefully and become familiar with
your pressure washer. Know the applications, the
limitations and any hazards involved.
Every effort has been made to ensure that information
in this manual is accurate and current. However we
reserve the right to change, alter or otherwise improve
the product and this document at any time without
prior notice.
Pressure: 2500 PSI (max.)
Flow Rate: 8.8 L/min (max.)
Engine: 5.5 HP OHV 4 Stroke
Fuel Tank Capacity: 3.6L
Displacement: 163cc
Fuel Type: Unleaded petrol
Engine Oil Type: SAE30 4 Stroke
Detergent: Use detergent approved for
pressure washers
Water Supply Temp: Not to exceed 40
o
C
Operation Noise Level: 70dBA
Net Weight: 40kg
Specifications
Introduction
Your new POWERJET High Pressure Cleaner will
more than satisfy your expectations. It has been
manufactured under stringent quality standards to
meet superior performance criteria.You will find your
new tool easy and safe to operate, and, with proper
care, it will give you many years of dependable service.
CAUTION:
Carefully read through this entire Instruction Manual
before using your new POWERJET High Pressure
Cleaner. Take special care to heed the Cautions and
Warnings.
Your High Pressure Cleaner has many features that
will make your job faster and easier. Safety, performance, and dependability have been given top priority
in the development of this tool, making it easy to
maintain and operate.
IMPORTANT:
Your POWERJET 2500RS is shipped without engine
oil. Please ensure you fill the machine with oil as
per the instructions on page 7 before use.
Environmental
Protection
Recycle unwanted materials instead of disposing of
them as waste. All tools, hoses and packaging should
be sorted, taken to the local recycling centre and
disposed of in an environmentally safe way.
Scope Of Product
This product is suited for home and domestic cleaning
jobs around the house and garden, like decks,
driveways and vehicles.
Description Of Symbols
The rating plate on your tool may show symbols.
These represent important information about the
product or instructions on its use.
Wear hearing protection.
Wear eye protection.
Wear breathing protection.
Conforms to relevant standards
for electromagnetic compatibility.
POWERJET HIGH PRESSURE CLEANER
3.
Z1085
!
!
DANGER! Running engine gives off carbon
monoxide, an odourless, colourless, poison
gas.
Some chemicals or detergents may be
harmful if inhaled or ingested, causing
severe nausea, fainting or poisoning.
Breathing carbon monoxide will cause
nausea, fainting or death.
• Operate pressure washer ONLY outdoors.
• Use a respirator or mask whenever there is a
chance that vapours may be inhaled.
• Read all instructions with mask so you are certain
the mask will provide the necessary protection
against inhaling harmful vapours.
WARNING! Spray contact with electrical
wiring can result in electrocution.
• Keep water spray away from electric wiring
or fatal electric shock may result.
WARNING! Use of pressure washer can
create puddles and slippery surfaces.
High pressure spray could cause you to
fall if you are too close to the cleaning
surface.
• Keep spray tip between 8 to 24 inches away from
cleaning surface.
• Operate this unit on a stable surface.
• The cleaning area should have adequate slopes
and drainage to reduce the possibility of a fall due
to slippery surfaces.
• Be extremely careful if you must use the pressure
washer from a ladder, scaffolding or any other
relatively unstable location.
• Firmly grasp spray gun with both hands when
using high pressure spray to avoid injury if gun
recoils.
!
Hazard Symbols
and Meanings
!
Safety Rules
This is the safety alert symbol. It is used to
alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol
to avoid possible injury or death.
The safety alert symbol (
!
) is used with a signal
word (DANGER, CAUTION, WARNING), a pictorial
and / or a safety message to alert you to hazards.
DANGER indicates a hazard which, if not avoided,
will result in serious injury or even death. WARNING
indicates a hazard which, if not avoided, could result
in serious injury or death. CAUTION indicates a hazard
hich, if not avoided, might result in minor or moderate
injury. CAUTION, when used without the alert symbol,
indicates a situation that could result in equipment
damage. Follow safety messages to avoid or reduce
the risk of injury or death.
WARNING: The engine exhaust from this
product contains chemicals known to cause
cancer, birth defects or other reproductive harm.
POWERJET HIGH PRESSURE CLEANER
4.
WARNING! Fuel and its vapors are
extremely flammable and explosive.
Fire or explosion can cause severe burns
or death.
WHEN ADDING FUEL
• Turn pressure washer OFF and let it cool at least
2 minutes before removing gas cap.
• Fill fuel tank outdoors.
• DO NOT overfill tank. Allow space for fuel
expansion.
• Keep fuel away from sparks, open flames, pilot
lights, heat, and other ignition sources.
• DO NOT light a cigarette or smoke.
WHEN OPERATING EQUIPMENT
• DO NOT tip engine or equipment at angle which
causes fuel to spill.
• DO NOT spray flammable liquids.
WHEN TRANSPORTING OR REPAIRING
EQUIPMENT
• Transport / repair with fuel tank EMPTY or with
fuel shutoff valve OFF.
WHEN STORING FUEL OR EQUIPMENT WITH
FUEL IN TANK
• Store away from furnaces, stoves, water heaters,
clothes dryers or other appliances that have a pilot
light or other ignition source because they can
ignite fuel vapours.
!
WARNING! The high pressure stream of
water that this equipment produces can
pierce skin and its underlying tissues,
leading to serious injury and possible
amputation.
• NEVER aim spray gun at people, animals or plants.
• DO NOT allow CHILDREN to operate pressure
washer.
• NEVER repair high-pressure hose. Replace it with
an equivalent rated hose.
• Keep high pressure hose connected to pump and
spray gun while system is pressurised.
WARNING! Starter and other rotating parts
can entangle hands, hair, clothing, or
accessories.
• DO NOT wear loose clothing, jewellery or anything
that may be caught in the starter or other rotating
parts.
• Tie up long hair and remove jewellery.
WARNING! High pressure spray can cause
paint chips or other particles to become
airborne.
• Always wear eye protection when using this equipment or in vicinity of where equipment is in use.
WARNING! Unintentional sparking can
result in fire or electric shock.
WHEN ADJUSTING OR MAKING REPAIRS
TO YOUR PRESSURE WASHER
• Disconnect spark plug wire from spark plug and
place wire where it cannot contact spark plug.
!
!
!
!
WARNING! Running engines produce heat
and hot exhaust gases.
Temperature of muffler and nearby areas
can reach or exceed 150°F (65°C).
Fire or severe burns can occur.
• DO NOT touch hot surfaces.
• Stay clear of exhaust gases.
• Allow equipment to cool before touching.
• Do not allow high pressure hose or inlet hose to
come in contact with hot muffler.
!
POWERJET HIGH PRESSURE CLEANER
5.
CAUTION: Excessively high or low
operating speeds increase risk of injury
and damage to pressure washer.
• DO NOT tamper with governed speed.
• DO NOT operate pressure washer above rated
pressure.
CAUTION: A pressure washer produces
a high pressure spray which increases
risk of injury and damage to unit.
• DO NOT secure spray gun in open position.
• DO NOT leave spray gun unattended while
machine is running.
• NEVER use a spray gun which does not have a
trigger lock or trigger guard in place and in working
order.
• Always be certain spray gun, nozzles and
accessories are correctly attached.
CAUTION: High pressure spray may
damage fragile items including glass.
• DO NOT point spray gun at glass when in jet
spray mode.
• NEVER aim spray gun at plants.
CAUTION: Improper treatment of pressure
washer can damage it and shorten its life.
• NEVER operate units with broken or missing parts,
or without protective housing or covers.
• DO NOT by-pass any safety device on this
machine.
• Before starting pressure washer in cold weather,
check all parts of the equipment to be sure ice
has not formed there.
• NEVER move machine by pulling on high pressure
hose. Use handle provided on unit.
!
• Check fuel system for leaks or signs of deterioration,
such as chafed or spongy hose, loose or missing
clamps, or damaged tank or cap. Correct all defects
before operating pressure washer.
!
!
!
Unpacking
Due to modern mass production techniques, it is
unlikely that your POWERJET Power Washer is faulty
or that a part is missing. If you find anything wrong,
do not operate the tool until the parts have been
replaced or the fault has been rectified. Failure to do
so could result in serious personal injury.
IMPORTANT: Read entire opeating manual before
you attempt to assemble or operate your new pressure
washer.
Removing Pressure Washer from Carton
• Remove high pressure hose, handle, and parts
included with pressure washer.
• Slice two corners from end of carton from top to
bottom so it can be folded down flat, remove all
packing material.
• Remove pressure washer from carton.
Carton Contents
• Main Unit
• High Pressure Hose
• Spray Gun
• Nozzle Extension with Quick Connect Fitting
• Handle
• Wheel / Axle Kit
• Parts Bag with fittings
Parts Bag includes the following:
• 4 x multi-coloured Quick Connect Spray Tips
• Owner’s Manual
POWERJET HIGH PRESSURE CLEANER
6.
Assembly
To prepare your pressure washer for operation, you
will need to perform the following:
1. Attach handle to main unit
2. Attach axle / wheels
3. Add oil to engine
4. Add fuel to fuel tank
5. Connect high pressure hose to spray gun and
pump
6. Connect water supply to pump
7. Connect nozzle extension to spray gun
8. Select and install desired quick connect spray tip.
Attaching the Handle
1. Place handle assembly onto handle supports
connected to main unit. Ensure holes in handle
tube align with the locking pins in the frame and
the spring-loaded locking pins are engaged with
the handle.
NOTE: It may be necessary to move the handle
supports from side to side in order to align the handle
so it will slide over the handle supports.
2. Insert multi-coloured spray tips in spaces provided
in handle.
B
A
CAUTION! Any attempt to crank or start the
engine before it has been properly filled with the
recommended oil will result in equipment failure.
Damage to equipment resulting from failure to follow
this instruction will void warranty.
Checking
the Engine Oil
IMPORTANT: All washers are shipped without engine
oil.
USE A QUALITY SAE30 GRADE OIL.
1. Place unit on a level surface
2. Remove oil filler cap / dipstick (A) and wipe it
clean.
3. Insert oil filler cap / dipstick into filler neck, but DO
NOT screw it in.
4. Remove dipstick. Proper oil level is at mid-point
of dipstick (A). Add oil if necessary to bring oil
level to top of threads (B). Oil capacity = 600ml.
5. Install and tighten cap.
NOTE: Check oil often during engine break-in.
!
POWERJET HIGH PRESSURE CLEANER
7.
Filling the Fuel Tank
CAUTION: Risk of fire. Handle fuel carefully.
Do not add fuel when product is operating. Stop
engine and allow engine to cool for two minutes before
refueling. Hot surfaces can cause burns and ignite
spilled fuel. Do not touch muffler.
• Fill fuel tank outdoors away from flames and open
sparks.
• Do not smoke when filling fuel tank.
• Do not overfill fuel tank. (There should be no fuel
in filler neck.)
• Avoid spilling fuel. Wipe clean after refueling.
• Move from refueling area before starting.
• Prevent fires by keeping engine clean of
accumulation, grease, trash and debris.
IMPORTANT: Do not permit
dirt or other foreign matter
to enter the fuel system. This
will cause hard starting, poor
performance and engine
damage. Always use clean
fuel storage containers and
funnels.
Use clean, fresh, lead-free
gasoline. Do not use stale
gasoline or gasoline that has
been stored for a long
time. Stale gasoline does not vaporise properly,
causing hard starts. Use of Fuel Set gasoline stabilizer
is highly recommended . Use of leaded gasoline or
gasohol is NOT recommended.
!
3.
Inlet
Screen
2.
Connect high
pressure hose here
Connect Hose & Water
Supply To Pump
IMPORTANT: To avoid pump damage, you must
assemble the nozzle extension to the spray gun and
attach all hoses before you start the engine.
1. Uncoil high pressure hose and attach the end of
the hose to base of spray gun (Fig. 2). Thread
hose fitting on in clockwise direction and tighten
moderately.
3. Similarly, attach other end of high pressure hose
to high pressure outlet on pump.
4. Before connecting garden hose to water inlet,
inspect inlet screen (Fig. 3). Clean screen if it
contains debris, replace if damaged. DO NOT RUN
PRESSURE WASHER IF SCREEN IS DAMAGED.
5. Run water through garden hose for 30 seconds to
clean out any debris. Turn off water.
IMPORTANT: DO NOT siphon standing water for the
water supply. Use ONLY cold water (less than 40°C).
6. Connect garden hose (not to exceed 50 feet in
length) to water inlet (Fig. 3).
POWERJET HIGH PRESSURE CLEANER
8.
CAUTION! There MUST be at least ten feet
of unrestricted garden hose between the
pressure washer inlet and any flow shut off device,
such as a ‘Y’ shut-off connector or other convenience-type water shut-off valve. Damage to
equipment resulting from failure to follow this instruction
will void warranty.
7. Turn ON water and squeeze trigger on spray gun
to purge pump system of air and impurities.
!
5. Adding on extension to the supply hose will
reduce water flow rates. Check for adequate
water flow rate each time an extension is added.
Water flow rates can be increased by using the
largest possible internal diameter supply hose.
IMPORTANT: Inlet water temperature must not be
more than 40°C or damage to the pump may result.
Washer Rated Flow L/min Supply
L/min Required
PJ2000RS 6.4 10
PJ2500RS 8.8 12
Inlet Water Supply
Requirements
1. Inlet water supply must be a minimum of 20
PSI (1.4 bar). Attempting to operate the washer
with less than adequate water supply will cause
rapid wear of packings, valves and bearings that
will dramatically shorten pump life. Symptoms of
inadequate water supply are pump shuddering and
flattening of the supply hose.
2. Inlet water flow must be at least 125% of pump
rated flow (see the following table). Check volume
by timing how long it takes to fill a 20 litre container.
For example, a flow rate of 10 L /min would fill a
20 litre container in 2 minutes.
3. Water supply hose should be a good grade of
garden hose with a minimum inner diameter of
12mm, and no longer than 15.24m. If a longer
supply hose must be used, check to be certain
flow is at least equal to the ‘L/min Supply Required’
value for your washer (See the following table).
4. If a non-pressurised (static draw) water supply
is used, check to be certain flow is at least 125%
of pump rated flow (see the following table).
In static draw situations, water flow rate (L/min)
can be increased by elevating the water supply
tank or changing to a larger inside diameter water
supply hose.
Operating Checklist
IMPORTANT: Before starting the engine review the
unit’s assembly to confirm you have performed all of
the following:
1. Make sure handle is in place and secure.
2. Check that oil has been added to proper level in
engine crankcase and the pump.
3. Add proper fuel to fuel tank.
4. Check for properly attached hose connections.
5. Check to make sure there are no kinks, cuts, or
damage to high pressure hose.
6. Provide a proper water supply (not to exceed 40°C)
at an adequate flow.
7. Be sure to read all safety rules and how to use
your pressure washer in the following sections
before use.
If you have any problems operating your machine,
please call the Technical Helpline on 0800 387 678.
POWERJET HIGH PRESSURE CLEANER
9.
!
!
POWERJET HIGH PRESSURE CLEANER
Starting the Machine
WARNING! High pressure spray, improperly
used could damage the equipment you
wish to clean or the surrounding environment.
Practice on scrap materials, gradually increasing
pressure applied to the object by adjusting the nozzle
or moving the nozzle closer to the object until it is
cleaned without being damaged.
The manufacturer does not warranty damage caused
by the consumer's failure to adjust or operate the
machine in accordance with the instructions provided
in the owners manual supplied with the machine.
Follow these instructions to operate the machine:
1. Use the operation checklist to help avoid personal
injury and damage to the machine.
2. Prime the pump and purge air from the system
by squeezing the gun trigger before starting the
machine, with the unit attached to a pressure
main. Let the water flow from the wand until air
is purged from system.
3. If engine is equipped with fuel valve, turn valve
to ON.
4. Close choke lever located on engine carburetor
as per engine manufacturer instructions.
5. Turn engine switch to ON.
6. If engine is equipped with throttle lever, position
lever to HALF THROTTLE.
7. For easier starting, squeeze the trigger on the
spray gun allowing water to flow through the gun.
This will relieve pressure in the pump allowing
the motor to turn freely. Failure to follow this
instruction may damage the pump or the recoil
starter and this damage will not be covered under
warranty.
8. Pull lightly on the starter grip until resistance is
felt, then pull briskly. Repeat this step as
necessary until engine starts.
!
CAUTION! Always begin high pressure
washing with nozzle at least four feet from
object being cleaned. Gradually move nozzle closer
to object until it is cleaned without damage.
Stopping the Machine
1. Run only clean water through the entire
chemical/detergent system.
2. If engine is equipped with throttle lever, position
lever to IDLE.
3. Turn engine switch to OFF.
4. If engine is equipped with a fuel valve, turn valve
to CLOSED position.
5. Turn water supply to OFF.
6. Open gun to relieve pressure, and drain as much
water as possible.
7. Remove inlet garden hose.
8. For safety and your liability protection, remove
high pressure hose and store gun/wand in a secure
place with this owners manual to eliminate the
possibility of unauthorized and untrained personnel
from operating the machine.
10 .
9. As engine begins to warm up, gradually move the
choke lever to OPEN.
10 If engine is equipped with throttle lever, position
lever to FULL THROTTLE.
11. You are now ready to start cleaning with your
pressure washer.
Nozzle Installation
Selection
INSTALLING NOZZLE
CAUTION! To avoid injury from escaping
fluids under pressure, relieve the pressure
in the system by stopping the washer and depress-
POWERJET HIGH PRESSURE CLEANER
11.
2. Push ring forward and lock nozzle in place.
Be sure nozzle is fastened to wand.
1. Retract locking ring (A) of quick-connect fitting
and insert male quick-connect fitting of nozzle (B).
Selecting the
Proper Nozzle
Pressure and volume are partially determined by the
size of the orifice in the nozzle. Standard numbers
are on the nozzles to indicate spray pattern and orifice
size. For example, a nozzle stamped 50 has a 5°
spray pattern and a 3.0 orifice.
0° NOZZLE - Red
This nozzle is a blasting
nozzle, delivering a
concentrated stream of
water.
IMPORTANT: Care must
be used to avoid gouging
wood or damaging fragile surfaces.
Recommended uses are as follows:
• Removing stains from concrete, masonry,
aluminum and steel.
• Remove weeds from sidewalk cracks.
• Remove caked-on mud from equipment.
• Clean lawn mower underdeck.
15° NOZZLE - Yellow
This nozzle provides a
chiseling effect suitable
for surface preparation.
The spray should be
directed at a 45° angle
to the surface.
Recommended uses:
• Removing peeling paint.
• Removing mildew stains.
25° NOZZLE - Green
This is a flushing nozzle.
It produces a brush effect
with a wider spray pattern
and less concentrated
spray pressure than a 5°
nozzle.
Recommended uses:
• Wet sweeping leaves from walks and drives.
• Cleaning stable floors.
• Cleaning swimming pool bottoms.
• Cleaning barbecue grill.
40° NOZZLE - White
This nozzle is a general
purpose nozzle with a wide
angle spray pattern. It is
recommended for rinsing
and light cleaning.
Recommended uses:
• Cleaning windows and aluminum siding.
• Vehicles (normal road dirt).
• Cleaning sidewalks, drives and patios.
ing gun trigger. Lock trigger before changing or
adjusting nozzle. Be sure nozzle is tightly attached
before operating to help prevent nozzle release.
!
!
5.
OPTIONAL
Cleaning & Applying
Chemicals
CAUTION! You must attach all hoses before
you start the engine. Starting the engine
without all the hoses connected and without the water
turned ON will damage the pump. Damage to equipment resulting from failure to follow this instruction
will void warranty.
IMPORTANT: Use soaps designed specifically for
pressure washers. Household detergents could
damage the pump.
To apply detergent follow these steps:
1. Review spray tip use.
2. Prepare detergent solution as required by
manufacturer.
3. Place chemical injection siphon/filter into detergent
container.
4. Make sure black spray tip is installed.
NOTE: Detergent cannot be applied with the high
pressure spray tips (White, Green, Yellow, or Red).
5. Make sure garden hose is connected to water inlet.
Check that high pressure hose is connected to
spraygun and pump; start engine.
6. Apply detergent to a dry surface, starting at lower
portion of area to be washed and work upward,
using long, even, overlapping strokes. DO NOT
allow detergent to dry on (prevents streaking).
7. Allow detergent to soak in between 3-5 minutes
before washing and rinsing. Reapply as needed
to prevent surface from drying.
CAUTION! Keep the chemical injection tube
from coming in contact with the hot
muffler.
When inserting the filter into a detergent
solution bottle, route the tube so as to keep it from
inadvertently contacting the hot muffler.
POWERJET HIGH PRESSURE CLEANER
12 .
DETERGENT
INJECTOR NOZZLE
- Black (Brass)
This nozzle must be used
with and is included in the
detergent injector kit.
This nozzle will allow a soft
spray to soak on a surface
with a liquid detergent.
For applying cleaning solution.
Recommended uses:
• Removing mildew and oxidation stain from houses
• Cleaning effervescent brick.
Pressure Washer
Rinsing
After you have applied detergent, scour the surface
and rinse it clean as follows:
1. Apply safety latch to spray gun.
2. Remove black chemical spray tip from nozzle
extension.
3. Select and install desired high pressure spray tip
following instructions in ‘Selecting the Proper
Nozzle’.
4. Apply high pressure spray to small area and check
surface for damage. If no damage is found, you
can assume it is okay to continue cleaning.
5. Start at top of area to be rinsed, working down with
same overlapping strokes as you used for cleaning.
!
Cleaning Horizontal
Surfaces
1. Move nozzle wand from side to side. Direct spray
at an angle to force debris ahead and away from
the cleared area (Fig. 6).
6.
7.
2. Depending on the material to be removed and
nozzle pressure, hold nozzle end 8 to 10 inches
(20 to 25cm) from the surface and use slow,
overlapping strokes.
3.
If debris is easy to remove, move nozzle back to
cover more area for faster cleaning.
Cleaning Vertical
Surfaces
IMPORTANT: Remember that the washer can deliver
a high pressure spray that can break glass and gouge
soft wood and other materials.
When cleaning building interiors or exteriors without
detergents, work from top to bottom. This will help
eliminate streaks. In interiors, start with the ceiling
first, then the walls and the floor last.
!
!
CAUTION! Clean around windows carefully.
If glass panes are not well-caulked and puttied,
the high pressure spray could break the glass.
CAUTION: Never spray directly overhead.
Always spray ahead to avoid dripping or falling
debris.
Removing Paint
IMPORTANT: Remember that high pressure spray
can gouge soft woods and other materials, as well as
loosen grout.
1. Direct spray at a 45° angle about 4 to 12 inches
(10 to 30cm) from surface.
2. Spray in a back and forth motion, try to get beneath
the loose and bubbled paint.
3. Do not be concerned with the paint that remains.
It should be sufficiently bonded so as not to cause
repainting problems.
POWERJET HIGH PRESSURE CLEANER
13 .
CAUTION! Never allow the pump to run for
more than a 2 minute period without opening
the gun. This will cause pump damage due to
excessive water temperature and void the warranty.
4. Some remaining paint may curl up at the edges.
These edges should be scraped with a steel brush
or scraper just before painting.
1. Use clean water without detergent.
IMPORTANT: Spray straight into the radiator to
prevent bending fins.
2. If possible, direct spray in the direction opposite
to normal air flow through the radiator.
8.
Before Each Use:
1. Check engine oil level.
2. Check water inlet screen for damage.
3. Check high pressure hose for leaks.
4. Check detergent siphoning tube and filter for
damage.
6. Check spray gun, nozzle extension, and spray
tips for leaks.
7. Rinse out garden hose to flush out debris.
Check and Clean Inlet Screen
Examine the screen on the water inlet. Clean it if the
screen is clogged or replace it if screen is damaged.
Check High Pressure Hose
The high pressure hose can develop leaks from wear,
kinking, or abuse. Inspect the hose each time before
using it. Check for cuts, leaks, abrasions or bulging
of cover, damage or movement of couplings. If any
of these conditions exist, replace the hose immediately.
WARNING! The high pressure stream of
water that this equipment produces can
pierce skin and its underlying tissues, leading to
serious injury and possible amputation.
NEVER
repair high pressure hose. Replace it. Replacement
hose rating MUST exceed maximum pressure rating
of unit.
Check Detergent Siphoning Tube
Examine the filter on the detergent tube and clean if
clogged. The tube should fit tightly on the barbed
fitting. Examine the tube for leaks or tears. Replace
the filter or tube if either is damaged.
IMPORTANT: Simply shutting OFF engine will not
release pressure in the system. When the engine has
shut down, squeeze the trigger on the spray gun to
relieve the pressure in the hose.
!
Cleaning Radiator Fins
IMPORTANT: Some engine and radiator
manufacturers may not permit cleaning radiators with
a high pressure washer - refer to the equipments
Operating Manual.
General Maintenance
The pressure washer warranty does not cover items
that have been subjected to operator abuse or
negligence. To receive full value from the warranty,
the operator must maintain the pressure washer as
instructed in this manual.
• Some adjustments will need to be made
periodically to properly maintain your pressure
washer.
• All maintenance in this manual should be made
at least once each season.
• If equipped with inflatable tires, keep the air
pressure at the value marked on the tyre or within
15 and 40 psi.
POWERJET HIGH PRESSURE CLEANER
14 .
Check Gun and Nozzle Extension
Examine the hose connection to the spray gun and
make sure it is secure. Test the trigger by pressing
it and making sure it springs back into place when
you release it. Put the safety latch in the on position
and test the trigger. You should not be able to press
the trigger.
spray tip clogged or restricted with foreign materials,
such as dirt, etc.
To correct the problem, immediately clean the spray
tips using the tools included with your pressure washer
and follow these instructions:
1. Shut off engine and turn off water supply.
2. Remove spray tip from end of nozzle extension.
3. Remove in-line filter from other end of nozzle
extension.
4. Use wire included in kit (or a small paper clip) to
free any foreign material clogging or restricting
spray tip (Fig. 9).
5. Using a garden hose, remove additional debris by
back flushing water through nozzle extension (Fig.10).
Back flush between 30 to 60 seconds.
Purge Pump of Air and Contaminants
To remove air from the pump, follow these steps:
1. Set up pressure washer as described in ‘Preparing
Pressure Washer For Use’. Connect water supply
and turn water on.
2. Pull trigger on spray gun and hold.
3. When water supply is steady and constant, engage
safety latch.
To remove contaminants from the pump, follow
these steps:
1. Set up pressure washer as described in ‘Preparing
Pressure Washer For Use’. Connect water supply
and turn water on.
2. Start engine according to instructions in ‘To Start
Pressure Washer’
3. Remove nozzle extension from spray gun.
4. Squeeze trigger on spray gun and hold.
5. When water supply is steady and constant, engage
safety latch and reattach nozzle extension.
9.
Use wire here to
remove debis
6. Reinstall spray tip into nozzle extension.
7. Reconnect nozzle extension to spray gun.
8. Reconnect water supply, turn on water and start
engine.
9. Test pressure washer by operating with each Quick
Connect spray tip.
10.
Cleaning Detergent Siphoning Tube
If you used the detergent siphoning tube, you must
flush it with clean water before stopping the engine.
1. Place chemical injection siphon/filter in a bucket
full of clean water.
2. Attach black low pressure spray tip.
3. Flush for 1-2 minutes.
4. Shut off engine.
O-Ring Maintenance
Through the normal operation of your pressure washer,
o-rings, which keep the connections of the hoses and
spraygun tight and leak-free, may become worn or
damaged.
To remove a worn or damaged o-ring; use a small
flathead screwdriver to get underneath the o-ring and
pry it off.
POWERJET HIGH PRESSURE CLEANER
15 .
Nozzle Maintenance
A pulsing sensation felt while squeezing the spray gun
trigger may be caused by excessive pump pressure.
The principal cause of excessive pump pressure is a
Check Oil Level
The oil level in the pump can be viewed by checking
the oil sight glass (B) on the side of the pump. The oil
level should be up to the middle of the sight glass with
the machine on level ground.
Oil Change Periods
The oil in the pump should be changed after the first
two hours of use. Following this, an oil change should
be performed when the oil becomes discoloured or
every 50 hours of use, whichever event occurs first.
CAUTION! Do not exceed the manufacturer's
maximum pressure by increasing the unloader
adjustment range. (This will void pump warranty.)
!
Pump Components
A. Oil Filler Bung
B. Oil Sight Glass
C. Oil Drain Bung (obscured)
D. Water Outlet
E. Unloader (Pressure) Adjustment Knob
F. Detergent Pickup
G. Water Inlet (partially obscured)
POWERJET HIGH PRESSURE CLEANER
16 .
Engine Maintenance
See the engine owner’s manual for instructions on
how to properly maintain the engine.
KEEP OUT OF REACH OF
CHILDREN. DON'T POLLUTE.
CONSERVE RESOURCES. RETURN
USED OIL TO COLLECTION
CENTRES.
CAUTION! Avoid prolonged or repeated skin
contact with used motor oil.
Used motor oil
has been shown to cause skin cancer in certain
laboratory animals.
!
!
CAUTION! The maximum engine RPM has
been set at the factory. TAMPERING WITH
ENGINE GOVERNOR WILL VOID
WARRANTY.
Changing the Oil
1. Ensure the machine is on a level stable surface
NOTE: Performing an oil change will be easier if the
machine has been run and the pump is still warm.
2. Place a suitable container under the pump and
remove the drain bung (C).
3. Replace the oil drain bung once all the old oil has
drained from the pump. Dispose the waste oil in
an environmentally responsible manner, ensuring
local & governmental regulations are adhered to.
4. Re-fill the pump with a quality, fresh, low foaming
SAE30 oil through the oil filler hole (A) and refit
the oil filler bung. Oil capacity = 120mls.
Pressure Adjustment
Pump pressure may be adjusted by turning the
unloader adjustment knob (E).
Pump failure is most commonly due to lack of care in
operation and poor or no maintenance rather than
manufacturing defects. Issues caused by operator
error and/or lack of correct maintenance will not be
considered under warranty.
Pump Maintenance
B
A
C
F
G
E
D
Service Chart
1. Perform engine oil change after first 5 hours of use
and then at recommended intervals. Change engine
oil every 25 hours when used under heavy load or
in high ambient temperatures.
2. Service more frequently when used in dusty areas.
3. Air filter element may require replacement earlier
in dusty areas. A dirty air filter reduces engine
performance.
4. Unit should be serviced by authorised dealer unless
owner has proper tools and is mechanically
proficient and experienced in the repair of pressure
washers.
!
!
Protecting the Pump
To protect the pump from damage caused by mineral
deposits or freezing, use PumpSaver to treat pump.
This prevents freeze damage and lubricates pistons
and seals.
NOTE: PumpSaver is available as an optional
accessory. It is not included with the pressure washer.
Contact the nearest authorized service center to
purchase PumpSaver.
CAUTION! You must protect your unit from
freezing temperatures.
Failure to do so will
permanently damage your pump and render your unit
inoperable. Freeze damage is not covered under
warranty.
To use PumpSaver, make sure the pressure washer
is turned off and disconnected from supply water.
Read and follow all instructions and warnings given
on the PumpSaver container.
NOTE: PumpSaver will drip from pump after treatment
and will stain wood and concrete.
CAUTION! Read and follow all cautions and
warnings on the PumpSaver can label.
Always wear eye protection when using PumpSaver.
NOTE: If PumpSaver is not available, draw RV antifreeze (non-alcohol) into the pump by pouring the
solution into a 3-foot section of garden hose connected
to inlet adapter and pulling recoil handle twice.
POWERJET HIGH PRESSURE CLEANER
17.
Storage
Water shouldn’t remain in unit for long periods of time.
Sediments or minerals can deposit on pump parts
and ‘freeze’ pump action.
If you do not plan to use the pressure washer for
more than 30 days, follow this procedure:
1. Flush detergent siphoning tube by placing filter
into a pail of clean water while running pressure
washer in low pressure mode. Flush for one to
two minutes.
2. Shut off engine and let it cool, then remove high
pressure and garden hoses. Disconnect spark
plug wire from spark plug.
3. Empty pump of liquids by pulling engine recoil
handle about 6 times. This should remove most
liquid in pump.
4. Use pump saver to prevent corrosion build up and
freezing of pump.
POWERJET HIGH PRESSURE CLEANER
18 .
Troubleshooting
NOTE: Most problems with pressure washers are not
a malfunction of the pump or motor!! ALWAYS trouble
shoot from water source and/or nozzle towards the
pump and motor. Example: Check water supply and
nozzle if pressure fluctuates, unit is noisy or does not
reach full pressure.
Follow these trouble shooting rules closely
With proper care and use of the pressure washer,
the unit should remain free of problems. Most problems
are caused by careless or improper use of equipment.
Operation of the unit without an inlet water supply will
result in damage to seals and other components.
Another common cause of damage is running unit for
long periods with spray gun trigger in its "Closed"
position.
The latter can result in high water temperatures,
resulting in damage to seals and other components.
Cavitation
If the water pressure falls below a certain point (called
vapor pressure) the water will begin to boil even
though the temperatures are below normal boiling
point. Tiny bubbles of vapor will then form in the
boiling water. If the vapor bubbles are carried away
to a higher pressure area in the system the vapor will
condense again and leave a cavity in the midst of the
flow. The surrounding water will then rush in to fill
these cavities. Extremely high local pressures are
then created (up to 100,000 PSI). Such high pressures
may result in erosion, turbulence, noise, vibration,
and excess wear and tear on the pump.
The pump inlet, where the pistons pull the water in,
is very susceptible to cavitation problems.
Anything that obstructs the flow of water into the pump
can result in cavitation such as:
• A clogged water inlet filter
• Inlet piping or hoses that are too small
Some Pressure Washer Problems
Some of the problems that might occur in a pressure
washer system are as follows:
• Failure of the unit to produce pressure
• Erratic pressure
• Chattering
• Reduction in pressure
• Low water volume
When a problem arises don't remove the pump
immediately and start replacing parts. First check the
following possible causes of the problem:
• Make sure the water supply is turned on and the
water supply is adequate.
• Make sure the water inlet hose is not kinked or
damaged.
• Check the inlet water filter. Clean or replace if
necessary.
• Make sure the water supply is not too hot. Inlet
water temperature should not exceed 40° C.
• If a detergent is being used, make sure the
detergent hose is submerged and not drawing air
into the system. If detergent is not being used,
the chemical injector valve should be turned off.
• Make sure the unloader/regulator valve is properly
adjusted.
• Make sure the pump outlet hose is not leaking
and is not blocked.
• Check the wand and high pressure hose quick
couplers for missing O-rings.
• Check that the nozzle is clear and unobstructed.
• Excessive numbers of restrictions in the water
inlet (such as too many valves, or too many bends).
• Excessive turbulence or heat
POWERJET HIGH PRESSURE CLEANER
19 .
Problems with Detergent
Problems with use of detergent are often caused by
incorrect procedures of operator. Problems encount-
ered that involve the use of cleaning agents can often
be attributed to one or more of the following:
1. Hose is not fully submerged in solution: If the tube
isn’t fully immersed, the unit will be picking up air.
2. Injection valve is closed: The detergent valve must
be open in order to pick up detergent.
3. Wrong type of detergent: Only soaps designed
specifically for pressure washers should be used.
Household detergents could damage the pressure
washer.
Engine will not start or stops while operating:
Low-oil shutdown: Fill engine with oil
Engine switch not in ‘ON’ position: Turn switch ‘ON’
Pressure built up in hose: Squeeze trigger while starting
Engine is overloaded:
Nozzle partially blocked: Clean Nozzle
Excessive pressure: Shorten the spring coil on the unloader
Pressure increases when gun is locked:
Bypass valve blocking: Clean the bypass valve
3. Damage to the pump can result from
a) Inadequate water supply,
b) Vacuum lift too high, or
c) Excessive water temperature.
4. Check the pump crankcase for correct oil level and
for oil contamination. If oil appears milky, water
has entered the oil and the piston seals should be
replaced.
1. If the pump is running but produces no flow, try
priming the pump.
a) To prime the pump, keep suction at a
minimum and keep the discharge line open.
b) Open and close the spray gun trigger
repeatedly to aid the priming process.
2. A chattering noise usually indicates a restricted
water supply or air leaks.
a) Check for kinks or leaks in the hoses
b) Look for a plugged or damaged inlet water filter
c) If the filter has been damaged, sediment may
have entered the pump. The sediment will be
lodged in the inlet valve(s) and must be removed.
Troubleshooting Tips
Engine is running but pump won’t build maximum pressure or has irregular pressure:
Faucet closed: Open faucet
Unit has been stored in freezing temperature: Thaw out unit completely
Inadequate water supply: Provide a minimum of 12L/min at 20 PSI
Water inlet screen clogged: Clean screen
Kink in garden hose: Straighten garden hose
Wand nozzle worn or damaged: Replace nozzle
Air in pump:
Run with gun open & wand removed until
steady stream of water is released
Unloader not set correctly Adjust unloader to correct position
Suction or discharge valves clogged
Clean or replace the suction or discharge valves
or worn out:
Bypass valve not operating effectively: Clean the bypass valve
No intake of chemicals:
Injection tube not securely inserted: Push firmly into injector into unit
Tube cracked or split: Replace tube
Wrong nozzle: Switch to low pressure nozzle
Injector turned off: Turn collar counter
Trigger will not move:
Gun safety lock engaged: Release safety lock
Water in crankcase:
High humidity: Change oil more frequently
Worn seals: Change the oil seals
Noisy operation:
Worn bearings: Change the bearings
Air mixed with water:
Check inlet lines for restrictions
and / or proper sizing
Rough / pulsating, operating with pressure drop:
Inlet restriction:
Check system for stoppages, air leaks,
correctly sized inlet plumbing to pump
Unloader: Check unloader for proper operation
Air mix in water:
Check inlet lines for restrictions and or
proper sizing
High crankcase temperatures:
Wrong grade of oil: Use recommended oil
Improper amount of oil in crankcase: Adjust oil to proper amount
POWERJET HIGH PRESSURE CLEANER
20.
B. ANY INCIDENTAL, INDIRECT, OR CONSEQUENTIAL
LOSS, DAMAGE, OR EXPENSE THAT MAY RESULT
FROM ANY DEFECT, FAILURE OR MALFUNCTION
OF THIS PRODUCT.
C. This warranty does not apply to any accessory or
consumable items included with the product which are
subject to wear from usage; the repair or replacement
of these items shall be at the expense of the owner.
These items include, but are not limited to: sparkplugs,
seals, o-rings, lances, nozzles, thermal dump valves,
hoses etc. In addition, this warranty does not extend to
any damage caused by the untimely replacement or
maintenance of any of the previously listed
CONSUMABLE parts.
D. Any failure that results from accident, purchaser’s abuse,
neglect or failure to operate products in accordance with
instructions provided in the owner’s manual(s) supplied
with the product.
E. Pre-delivery service, i.e. assembly and adjustment.
6. RESPONSIBILITIES OF WARRANTOR UNDER THIS
WARRANTY: Repair or replace, at Warrantor’s option,
products or components which have failed within duration
of the warranty period.
7. RESPONSIBILITIES OF PURCHASER UNDER THIS
WARRANTY:
A. Please call your re-seller or the number listed above for
warranty assistance.
B. Provide dated proof of purchase and maintenance
records.
C. All high pressure cleaners must be delivered or shipped
to the nearest Service Agent or re-seller. Freight costs,
if any, must be borne by the purchaser.
D. Use reasonable care in the operation and maintenance
of the products as described in the owner’s manual(s).
E. No warranty costs incurred will be considered for, or
covered if Euroquip has not been contacted and prior
permission for repair / replacement has been granted.
8. WHEN WARRANTOR WILL PERFORM REPAIR OR
REPLACEMENT UNDER THIS WARRANTY:
Repair or replacement will be scheduled and serviced
according to the normal work flow at the servicing location
and depending on availability of replacement parts.
Whilst every effort is made to ensure your complete satisfaction
with this tool, occasionally, due to the mass manufacturing
techniques, a tool may not live up to our required level of
performance and you may need the assistance of our service
department.
This product is warranted for a 12 month period for home domestic
use from the date of the original purchase. If found to be defective
in materials or workmanship, the tool or the offending faulty
component will be replaced free of charge with another of the
same item. A small freight charge may apply. Proof of purchase
is essential.
We reserve the right to reject any claim where the purchase
cannot be verified.This warranty does not include damage or
defects to the tool caused by or resulting from abuse, accidents,
alterations or commercial or business use. It also does not cover
any bonus items or included accessories. Only the high pressure
cleaner is covered under this warranty.
Please ensure that you store your receipt in a safe place.
Conditions apply to the above warranty.
1. DURATION: The manufacturer warrants that it will
repair or replace, at no charge for parts or labour, the
POWERJET 2500RS High Pressure Cleaner, if proven
defective in material or workmanship, during the following
time period(s) after date of original retail purchase:
For 1 Year:
The POWERJET 2500RS High Pressure Cleaner
(excluding accessories)
2. WHO GIVES THIS WARRANTY (Warrantor):
EUROQUIP NZ EUROQUIP AUSTRALIA
Service Line Service Line
++64 3 547 8409 1-800 040 947
3. WHO RECEIVES THIS WARRANTY (Purchaser):
The original purchaser of this POWERJET product.
4. WHAT IS COVERED UNDER THIS WARRANTY:
Defects in material and workmanship which occur within
the duration of the warranty period.
5. WHAT IS NOT COVERED UNDER THIS WARRANTY:
A. Implied warranties, including those of merchantability
and FITNESS for a particular purpose are limited in
duration to this express warranty. After this period, all
risks of loss, from whatever reason, shall be on the
purchaser.
POWERJET HIGH PRESSURE CLEANER
Warranty
21.
POWERJET HIGH PRESSURE CLEANER
22.
POWERJET HIGH PRESSURE CLEANER
23.
Congratulations on your new POWERJET product. We are proud to have you as our customer and will
strive to provide you with the best service and reliability in the industry. This product is backed by our
extensive warranty and world-wide service network. To locate your nearest distributor or service agency
call 0800 387 678, or email us at info@euroquip.co.nz.
Loading...
