Polk Audio Camden Square Owner's Manual

0 (0)
Polk Audio Camden Square Owner's Manual

camden squaretm

Bluetooth® party speaker

what’s in the box

Camden Square wireless speaker

power adapter

quick start guide (not pictured)

pairing & connecting

1.Turn power on.

2.Enable Bluetooth on your device.

3.In device’s Bluetooth settings menu, select “Camden Square”

source select

The Camden Square is always in Bluetooth source mode, unless a cable is plugged into the AUX input.

controls

Turns speaker on/off.

-Press & hold for one second then release. After a period of inactivity, the Camden Square

will automatically turn off. Clears Bluetooth connections

-Press & hold for three seconds then release. The speaker is now in discovery mode to connect to another device.

Adjusts volume up and down.

Play/Pause current song (Bluetooth only).

LED colors

Solid blue - speaker is ON and in normal operating mode.

Pulsing blue - no devices are connected and speaker is in discovery mode.

Slowly blinking blue - speaker volume is muted.

Solid red - speaker is in standby mode and plugged in.

Alternating red & blue - speaker battery is at critically low level.

aux input

battery

The battery in your Camden Square comes partially charged from the factory. The charge is enough so that you can enjoy playing music right out of the box. To charge your battery plug one end

of the included power adapter into an AC wall outlet and the other end into the Camden Square.

battery status indicator

The battery’s status is indicated by the blue () LED when you turn the Camden Square on and the red LED when you turn it off.

Four blinks indicate full battery.

Three blinks indicate normal battery.

Two blinks indicate low battery.

One blink indicates critical battery.

With less than 30 minutes of charge remaining in the battery, the LED will fade from RED to BLUE constantly, until the battery can no longer play music.

Next/Previous track press & release. Fast forward/rewind current track press & hold (Bluetooth only).
