Clock Radio
3000 Series
R3205
User manual
Register your product and get support at
www.philips.com/support
Contents
1 Important 2
Safety 2
2
Your clock radio 3
Introduction 3
What's in the box 3
Overview of the clock radio 3
3 Get started 4
Install batteries 4
Connect power 4
Set time 4
4 Listen to FM radio 5
Tune to FM radio stations 5
Store FM radio stations manually 5
Select a preset radio station 5
Adjust volume 5
5 Other features 6
Set alarm time 6
Set sleep timer 6
6 Product information 7
7 T
roubleshooting 7
8 Notice 8
EN
1
1 Important
Safety
Warning
• Never remove the casing of this clock radio.
• Never lubricate any part of this clock radio.
• Never place this clock radio on other
electrical equipment.
• Keep this clock radio away from direct
sunlight, naked ames or heat.
• Make sure that you always have easy access
to the power cord, plug or adaptor to
disconnect the clock radio from the power.
• Read these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
• Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus
(including ampliers) that produce heat.
• Protect the power cord from being walked on
or pinched, particularly at plugs, convenience
receptacles, and the point where they exit
from the clock radio.
• Only use attachments/accessories specied by
the manufacturer.
• Unplug this apparatus during lightning storms
or when unused for long periods of time.
• Refer all servicing to qualied service
personnel. Servicing is required when the
apparatus has been damaged in any way, such
as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate
normally, or has been dropped.
• Battery usage CAUTION - To prevent battery
leakage which may result in bodily injury,
property damage, or damage to the clock radio:
• Install all batteries correctly, + and - as
marked on the unit.
• Remove batteries when the unit is not
used for a long time.
• The battery shall not be exposed to
excessive heat such as sunshine, re or
the like.
• This clock radio shall not be exposed to
dripping or splashing.
• Do not place any sources of danger on the
clock radio (e.g. liquid lled objects, lighted
candles).
• Where the plug of the Direct Plug-in
Adapter is used as the disconnect device,
the disconnect device shall remain readily
operable.
2
EN
2
123
4
6
5
Your clock radio
Congratulations on your purchase, and
welcome to Philips! To fully benet from the
support that Philips offers, register your product
at www.philips.com/support.
Introduction
With this clock radio, you can
• listen to FM radio;
• set two alarms to ring at different times.
What's in the box
Check and identify the contents of your package:
• Main unit
• AC power adaptor
• Quick start guide
• Safety and Warranty leaet
Overview of the clock radio
a.
• Turn on or switch to standby.
b.PRESET / SET TIME
• Store radio stations in memory.
• Select a preset radio station.
• Set time.
c.HR / MIN / TUN
• Tune to FM radio stations.
• Set hour and minute.
d.SNOOZE / SLEEP
• Snooze alarm.
• Set the sleep timer.
e.Display panel
• Display current status.
f.AL1 / AL2 / VOL
• Set alarm.
• Adjust volume.
Clock Radio
3000 Series
R3205
Quick start guide
3
EN
3 Get started
Always follow the instructions in this chapter in
sequence.
Install batteries
The batteries can only back up clock and alarm
settings.
Caution
• Risk of explosion! Keep the batteries away from heat,
sunshine or re. Never discard batteries in re.
• Batteries contain chemical substances, so they should
be disposed of properly.
Insert 2 AAA batteries (not provided) with
correct polarity (+/-) as illustrated.
Note
• The type plate is located at the bottom of the clock radio.
Set time
Note
• You can only set time in standby mode.
Connect power
Caution
• Risk of product damage! Make sure that the power
voltage corresponds to the voltage printed on the back
or underside of the clock radio.
• Risk of electrical shock! When you unplug the power
adaptor, always pull the plug from the socket. Never
pull the cord.
• Use only the AC power adapter specied in the
manufacturer or sold with this unit.
4
EN
1 In standby mode, press and hold SET TIME
for 2 seconds.
2 Press HR to set hour and MIN to set
minute, then press SET TIME to conrm.
» The time is set.
4 Listen to FM
radio
Tip
• To remove a pre-stored station, store another station
in its place.
Note
• Keep the clock radio away from other electronic
devices to avoid radio interference.
• For better reception, fully extend and adjust the
position of the FM antenna.
Tune to FM radio stations
1 Press to turn on the clock radio.
2 Press and hold TUN for 2 seconds.
» The clock radio tunes to a station with
strong reception automatically.
3 Repeat Step 2 to tune to more radio stations.
To tune to a station manually:
Press TUN repeatedly to select a frequency.
Note
• The tuning grid of the clock radio is 50KHz, the radio
frequency on the display panel will increase 0.1MHz by
pressing TUN twice.
Store FM radio stations manually
Select a preset radio station
In FM tuner mode, press PRESET repeatedly to
select a preset number.
Adjust volume
While listening, press VOL to adjust volume.
Note
• You can store a maximum of 10 FM radio stations.
1 Tune to an FM radio station.
2 Press and hold PRESET for 2 seconds to
activate programming mode.
» The preset number begins to blink.
3 Press TUN repeatedly to select a number.
4 Press PRESET again to conrm.
5 Repeat steps 1 to 4 to store more FM radio
stations.
EN
5
5 Other features
» The alarm repeats ringing for the next day.
» To stop the alarm, press the coresponding
AL1 or AL2.
Set alarm time
Set alarm
Note
• You can only set the alarm in standby mode.
• Make sure that you have set the clock correctly.
1 In standby mode, press and hold AL1 or
AL2 for 2 seconds to set alarm time.
2 Press HR to set hour and MIN to set
minute, then press AL1 or AL2 to conrm.
Tip
• The unit exits alarm setting mode when being idle for 10
seconds.
Select alarm source
You can select FM radio or buzzer as the alarm
source by pressing AL1 or AL2 in standby
mode.
» The corresponding alarm icon lights up.
Snooze the alarm
When the alarm sounds, press SNOOZE.
» The alarm snoozes and repeats ringing 9
minutes later.
Set sleep timer
This clock radio can switch to standby mode
automatically after a preset period.
• Press SLEEP repeatedly to select a period
(in minutes).
» The clock radio switches to standby mode
automatically after the preset period.
To deactivate the sleep timer:
• Press SLEEP repeatedly until [OFF] (off)
appears.
Note
• The gentle wake-up function is designed for FM radio
source only.
Activate/deactivate alarm timer
Press AL1 or AL2 repeatedly to activate or
deactivate the alarm timer.
» If the alarm timer is activated, the alarm
indicator turns on.
» If the alarm timer is deactivated, the alarm
indicator turns off.
6
EN
6 Product
information
Note
• Product information is subject to change without prior notice.
Amplier
Rated Output Power 200mW RMS
Tuner (FM)
Tuning Range 87.5-108 MHz
Tuning Grid 50 KHz
Sensitivity
- Mono, 26 dB S/N Ratio
Total Harmonic Distortion <3%
Signal to Noise Ratio >50 dBA
General information
Brand: Philips;
AC Power (power
adaptor)
Operation Power
Consumption
Standby Power
Consumption
Dimensions
(W x H x D)
Weight
(Main unit)
Model: AS030-050-EE060
Input: 100-240V~
50/60 Hz; 0.15A
Output: 5V 0.6A
<3 W
<1 W
131 x 54 x 131 mm
198.9 g
<22 dBf
7 T
• Never remove the casing of the product
To keep the warranty valid, never try to repair
the device yourself.
If you encounter problems when using this
device, check the following points before
requesting service. If the problem remains
unsolved, go to the Philips webpage (ww.philips.
com/support). When you contact Philips, make
sure that the device is nearby and the model
number and serial number are available.
roubleshooting
Warning
No power
• Make sure that the AC power plug of the unit
is connected properly.
• Make sure that there is power at the AC outlet.
No sound
• Adjust the volume.
No response from the unit
• Disconnect and reconnect the AC power
plug, then turn on the unit again.
Poor radio reception
• Keep the clock radio away from other
electronic devices to avoid radio interference.
• Fully extend and adjust the position of the antenna.
Alarm does not work
• Set the clock/alarm correctly.
Clock/alarm setting erased
• Power has been interrupted or the power
plug has been disconnected.
• Reset the clock/alarm.
EN
7
8 Notice
Any changes or modications made to this
device that are not expressly approved by
MMD Hong Kong Holding Limited may void
the user’s authority to operate the product.
Hereby, TP Vision Europe BV declares that
this product is in compliance with the essential
requirements and other relevant provisions
of Directive 2014/53/EU. You can nd the
Declaration of Conformity on
www. philips.com/support.
This product complies with the radio
interference requirements of the European
Community.
This product is designed and manufactured with
high-quality materials and components, which
can be recycled and reused.
never dispose of the product and batteries
with normal household waste. Correct disposal
of old products and batteries helps prevent
negative consequences for the environment and
human health.
Removing the disposal batteries
To remove the disposable batteries, see batter y
install section.
This symbol means the product must not be
discarded as household waste and should be
delivered to an appropriate collection facility for
recycling. Follow local rules and never dispose
of the product and rechargeable batteries with
normal household waste. Correct disposal
of old products and rechargeable batteries
helps prevent negative consequences for the
environment and human health.
This symbol means that the product contains
batteries covered by European Directive
2013/56/EU which cannot be disposed of with
normal household waste.
Inform yourself about the the local separate
collection system for electrical and electronic
products and batteries. Follow local rules and
8
EN
Specications are subject to change without notice.
2020 © Philips and the Philips Shield Emblem are registered trademarks
of Koninklijke Philips N.V. and are used under license. This product has been
manufactured by and is sold under the responsibility of MMD Hong Kong
Holding Limited or one of its afliates, and MMD Hong Kong Holding
Limited is the warrantor in relation to this product.
TAR3205_12_UM_V1.0
Loading...
