Philips BT3000W/05 user manual

Always there to help you

Question?

Contact

Philips

Register your product and get support at

www.philips.com/support

BT3000

User manual

Contents

1 Important 2

2 Your Bluetooth speaker 3

Introduction 3
What's in the box 3
Overview of the speaker 4

3 Get started 6

Power supply 6
Turn on 6

4 Use Bluetooth devices 8

Play from Bluetooth devices 8
Control your phone call 8

5 Other features 9

Listen to an external device 9
Adjust volume 9

6 Product information 10

Specications 10

7 Troubleshooting 11

General 11
About Bluetooth device 11

8 Notice 12

Compliance 12
Care of the environment 12
Trademark notice 12

1EN

1 Important

Warning

• Never remove the casing of this speaker.

• Never lubricate any part of this speaker.

• Never place this speaker on other electrical equipment.

• Keep this speaker away from direct sunlight, naked

amesorheat.

• Make sure that you always have easy access to the

power cord, plug, or adaptor to disconnect the speaker
from the power.

• Make sure that there is enough free space
around the speaker for ventilation.

• Onlyuseattachments/accessoriesspecied
by the manufacturer.

• Battery usage CAUTION – To prevent
battery leakage which may result in bodily
injury, property damage, or damage to the
speaker:

• Install the batteries correctly, + and - as

marked on the speaker.

• Do not mix batteries (old and new or

carbon and alkaline, etc.).

• Remove the batteries when the

speaker is not used for a long time.

• The batteries shall not be exposed to

excessiveheatsuchassunshine,reor

the like.

• Use only power supplies listed in the user
manual.

• The speaker shall not be exposed to
dripping or splashing.

• Do not place any sources of danger on

thespeaker(e.g.liquidlledobjects,lighted

candles).

• Where the plug of the Direct Plug-in
Adapter is used as the disconnect device,
the disconnect device shall remain readily
operable.

Note

• The type plate is located on the bottom of the product.

2 EN

2 Your Bluetooth

speaker

Congratulations on your purchase, and

welcometoPhilips!Tofullybenetfromthe

support that Philips offers, register your product
at www.philips.com/welcome.

Introduction

With this speaker, you can enjoy audio from
your Bluetooth-enabled devices, or other
external audio devices.

What's in the box

Check and identify the contents of your
package:

• Speaker

• Power adapter

• Short user manual

Always there to help you

Register your product and get support at

www.philips.com/welcome

Question?
Contact

Philips

Short user manual

3EN

Overview of the speaker

abc

ef

a

• Turn the speaker on or off.

b +/-

• Adjust volume.

4 EN

d

c /PAIRING

• Disconnect Bluetooth connection.

• Enter Bluetooth pairing mode.

• Answer or reject an incoming call.

• End the current phone call.

d Battery compartment
e AUDIO IN

• Connect an external audio device.

f DC IN

• Connect power.

5EN

3 Get started

4 x AA

2”

Always follow the instructions in this chapter in
sequence.

Option 2: AC power

Caution

• Risk of product damage! Make sure that the power

voltage corresponds to the voltage printed on the back
or underside of the speaker.

Power supply

The Bluetooth speaker can be powered by
either AC mains or batteries.

Option 1: Battery power

Caution

• Risk of explosion! Keep batteries away from heat,

sunshine,orre.Neverdiscardbatteriesinre.

• Batteries contain chemical substances, so they should

be disposed of properly.

Note

• Batteries are not supplied with the accessories.

• WhenLEDindicatorashesred,replacethebatteries.

1 Open the battery compartment.

Connect the power adaptor to:

• the DC IN socket on the speaker.

• the wall outlet.

Turn on

Press and hold for 2 seconds.

» The speaker switches to Bluetooth

mode automatically.

» TheLEDindicatorashesblue.

Note

• Ifbatteryislow,theLEDindicatorashesred.

2 Inser t 4 AA batteries with correct polarity

(+/-) as indicated.

3 Close the battery compartment.

6 EN

Turn off

The speaker is turned off in the following
situations:

• Press and hold for 2 seconds again;

or

• The Bluetooth connection is

disconnected and there is no audio-in
cable inserted for 15 minutes.

» The LED indicator is turned off.

7EN

4 Use Bluetooth

devices

With this speaker, you can listen to audio from
Bluetooth-enabled devices and control the
incoming call through Bluetooth.

Play from Bluetooth devices

Note

• Make sure that your Bluetooth device is compatible

with this speaker.

• Before pairing a device with this speaker, read its user

manual for Bluetooth compatibility.

• The speaker can memorize a maximum of 4 paired

devices.

• Make sure that Bluetooth function is enabled on your

device, and your device is set as visible to all other
Bluetooth devices.

• Any obstacle between this speaker and a Bluetooth

device can reduce the operational range.

• Keep away from any other electronic device that may

cause interference.

• The operational range between this speaker and a

Bluetooth device is approximately 10 meters (30 feet).

• If there is an incoming call on the connected mobile

phone, music playback pauses.

4 Play audio on the Bluetooth device.

» Audio streams from your Bluetooth

device to the speaker.

To disconnect the Bluetooth-enabled device:

• Press and hold PAIRING for 2 seconds
when it is not during a call;

• Disable Bluetooth on your device; or

• Move the device beyond the
communication range.

To reconnect the Bluetooth device:

• Next time you turn on the speaker, the
speaker will reconnect the last connected
device automatically; or

• On your Bluetooth device, select "PHILIPS

BT3000" on your Bluetooth menu.

To connect another Bluetooth-enabled device:

1 Press and hold PAIRING for 2 seconds to

disconnect the currently connected device.

» The speaker enters Bluetooth pairing

mode.

2 Connect another Bluetooth device.

LED indicator Description

Flashing blue Connecting;

Waiting for pairing

Solid blue Connected

1 Press and hold for 2 seconds.

» TheLEDindicatorashesblue.

2 On your Bluetooth device, enable

Bluetooth and search for Bluetooth devices
that can be paired (refer to the user
manual of the device).

3 When [PHILIPS BT3000] is displayed on

your device, select it to start pairing and
connection. If necessary, input “0000” as
the pairing password.

» After successful pairing and connection,

the speaker beeps twice, and the LED
indicator turns solid blue.

• Ifyoufailtond[Philips BT3000] on
your device for pairing, press and hold
PAIRING until you hear beep sound,
and then try again.

8 EN

Control your phone call

After Bluetooth connection, you can control an
incoming call with this speaker.

Button Function

Press to answer an incoming call.
Press and hold for 2 seconds to reject

an incoming call.
During a call, press to end the current

call.

5 Other features

Adjust volume

During play, press + or - repeatedly to increase
or decrease the volume level.

Listen to an external device

With this speaker, you can also listen to an
external audio device such as an MP3 player.

Note

• Make sure that there is no Bluetooth connection, or

music playback through Bluetooth is pauzed.

1 Connect an audio input cable (not

supplied) with a 3.5 mm connector on
both ends to

• the AUDIO IN socket on this speaker,
and

• the headphone socket on the external
device.

» The speaker switches to audio-in

mode automatically.

2 Play audio on the external device (refer to

its user manual).

Tip

• To increase or decrease volume continuously, press and

hold + or - for 2 seconds.

9EN

6 Product

information

Note

• Product information is subject to change without prior

notice.

Specications

Amplier

Total Output Power 5 W
Signal to Noise Ratio >67 dB
Audio-in Input 600 mV RMS

20 kohm

Bluetooth

Bluetooth Version V3.0
SupportedProles HFP, A2DP, AVRCP
Range 10 m (Free space)

General information

Power Supply

- AC Power
(power adapter)

- Battery 4 x 1.5 V LR6 AA
Operation Power

Consumption
Dimensions - Main

Unit (W x H x D)
Weight - Main Unit 1.3 kg

10 EN

Brand name: PHILIPS;
Model: AS100-050­AI150;
Input: 100-240 V~,
50/60 Hz, 0.5 A
Output: 5 V 1.5 A;

1.95 W

280 x 121 x 93 mm

7 Troubleshooting

About Bluetooth device

Warning

• Never remove the casing of this device.

To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this
device, check the following points before
requesting service. If the problem remains
unsolved, go to the Philips Web page (www.
philips.com/support). When you contact Philips,
make sure that the device is nearby and the
model number and serial number are available.

General

No power

• Make sure that the AC power plug of the
speaker is connected properly.

• Make sure that there is power at the AC
outlet.

• Make sure that the batteries are inserted
correctly.

No sound or poor sound

• Adjust volume on the product.

• Adjust volume on the connected device.

No response from the speaker

• Restart the speaker.

The LED indicator ashes blue for 5 times,

and the speaker has no response when
pressing any key.

• The speaker is in DEMO mode. Press and
hold for 15 seconds to exit this mode.

The audio quality is poor after connection
with a Bluetooth-enabled device.

• The Bluetooth reception is poor. Move the
device closer to this product or remove
any obstacle between them.

• The batteries are low. Replace the
batteries.

Cannot connect with the device.

• The Bluetooth function of the device is not
enabled. Refer to the user manual of the
device for how to enable the function.

• This product is already connected with
another Bluetooth-enabled device.
Disconnect that device and then try again.

The paired device connects and disconnects
constantly.

• The Bluetooth reception is poor. Move the
device closer to this product or remove
any obstacle between them.

• For some devices, Bluetooth connection
may be deactivated automatically as a
power-saving feature. This does not indicate
any malfunction of this product.

11EN

8 Notice

Anychangesormodicationsmadetothis

device that are not expressly approved by
Gibson Innovations may void the user’s
authority to operate the equipment.

Compliance

Environmental information

All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and old
equipment.

Hereby, Gibson Innovations declares that this
product is in compliance with the essential
requirements and other relevant provisions

ofDirective1999/5/EC.Youcanndthe

Declaration of Conformity on www.philips.com/
support.

Care of the environment

Disposal of your old product

Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.

This symbol on a product means that the
product is covered by European Directive
2012/19/EU. Inform yourself about the local
separate collection system for electrical and
electronic products. Follow local rules and never
dispose of the product with normal household
waste. Correct disposal of old products
helps prevent negative consequences for the
environment and human health.

Trademark notice

The Bluetooth® word mark and logos are
registered trademarks owned by Bluetooth
SIG, Inc. and any use of such marks by Gibson
is under license. Other trademarks and trade
names are those of their respective owners.

12 EN

13

Specifications are subject to change without notice.
2015 © Gibson Innovations Limited. All rights reserved.

This product has been manufactured by, and is sold under the responsibility of Gibson
Innovations Ltd., and Gibson Innovations Ltd. is the warrantor in relation to this product.

Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V.
and are used under license from Koninklijke Philips N.V.

BT3000_05_UM_V2.0
