Pelco P1220-ESR0, P1220-ESR1, P1220-FWH0, P1220-FWH1, P1220-PWH0 User Manual

...
5 (1)

Spectra® Professional

Series IP Dome System

User Manual

C2277M (11/14)

2

Contents



Important Safety Instructions........................................................................................................................................................

5

Important Notices .........................................................................................................................................................................

7

Regulatory Notices.........................................................................................................................................................

7

Radio and Television Interference .................................................................................................................................

7

KCC Certification ...........................................................................................................................................................

7

Korean Class A EMC............................................................................................................................................

7

Warranty ........................................................................................................................................................................

7

Legal Notice...................................................................................................................................................................

7

Audio Notice...................................................................................................................................................................

7

Video Quality Caution ....................................................................................................................................................

8

Frame Rate Notice Regarding User Selected Options...................................................................................................

8

Open Source Software...................................................................................................................................................

8

Network Topology Statement.........................................................................................................................................

8

Preface.........................................................................................................................................................................................

9

1. Product Overview............................................................................................................................................................

10

1.1 Dimensions ............................................................................................................................................................

10

1.2 Physical Characteristics.........................................................................................................................................

11

2. Installation and Connection ........................................................................................................................................

13

2.1 Unpacking Everything ............................................................................................................................................

13

2.2 Optional Accessories .............................................................................................................................................

13

2.3 Installation..............................................................................................................................................................

13

2.3.1 Checking Appearance ...............................................................................................................................

13

2.3.2 Disassembling the Camera........................................................................................................................

14

2.3.3 Connecting Wires ......................................................................................................................................

15

2.3.4 Installing the Camera.................................................................................................................................

16

2.3.5 Positioning & Adjusting the Field of View...................................................................................................

26

2.3.6 Network Topology........................................................................................

Error! Bookmark not defined.

2.3.7 System Requirements ...............................................................................................................................

27

2.4 Connection.............................................................................................................................................................

28

3

2.4.1 Default IP address .....................................................................................................................................

28

2.4.2 Connecting from a Computer & Viewing Preparation ................................................................................

28

3. Administration and Configuration..............................................................................................................................

30

3.1 Live ........................................................................................................................................................................

30

3.1.1 PTZ Control Panel .....................................................................................................................................

31

3.2 Settings..................................................................................................................................................................

32

3.2.1 System.......................................................................................................................................................

32

3.2.2 Network .....................................................................................................................................................

36

3.2.3 Imaging......................................................................................................................................................

44

3.2.4 A/V Streams ..............................................................................................................................................

54

3.2.5 Users .........................................................................................................................................................

59

3.2.6 Events........................................................................................................................................................

62

Pelco Troubleshooting Contact Information ...............................................................................................................................

71

4

Important Safety Instructions

1.Read these instructions.

2.Keep these instructions.

3.Heed all warnings.

4.Follow all instructions.

5.Clean only with dry cloth.

6.Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

7.Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

8.Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the points where they exit from the apparatus.

9.Only use attachments/accessories specified by the manufacturer.

10.Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

11.Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

12.Installation should be done only by qualified personnel and conform to all local codes.

13.Unless the unit is specifically marked as a NEMA Type 3, 3R, 3S, 4, 4X, 6, or 6P enclosure, it is designed for indoor use only and it must not be installed where exposed to rain and moisture.

14.Use only installation methods and materials capable of supporting four times the maximum specified load.

15.Use stainless steel hardware to fasten the mount to outdoor surfaces.

16.To prevent damage from water leakage when installing a mount outdoors on a roof or wall, apply sealant around the bolt holes between the mount and mounting surface.

CAUTION: These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock do not perform any servicing other that contained in the operating instructions unless you are qualified to do so.

Only use replacement parts recommended by Pelco.

The product and/or manual may bear the following marks:

This symbol indicates that dangerous voltage constituting a risk of electric shock is present within this unit.

CAUTION: RISK OF ELECTRIC SHOCK. DO NOT OPEN.

This symbol indicates that there are important operating and maintenance instructions in the literature accompanying this unit

5

WARNING: HAZARDOUS MOVING PARTS. KEEP FINGERS AND OTHER BODY PARTS AWAY.

WARNING: HIGH TOUCH CURRENT. EARTH CONNECTION ESSENTIAL BEFORE CONNECTING SUPPLY.

Denotes Class II double insulated device.

WARNING: This product is sensitive to Electrostatic Discharge (ESD). To avoid ESD damage to this product, use ESD safe practices during installation. Before touching, adjusting or handling this product, correctly attach an ESD wrist strap to your wrist and appropriately discharge your body and tools. For more information about ESD control and safe handling practices of electronics, please refer to ANSI/ESD S20.20-1999 or contact the Electrostatic Discharge Association (www.esda.org).

6

Important Notices

Regulatory Notices

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Radio and Television Interference

This equipment has been tested and found to comply with the limits of a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

Changes and Modifications not expressly approved by the manufacturer or registrant of this equipment can void your authority to operate this equipment under Federal Communications Commission’s rules.

This Class A digital apparatus complies with Canadian ICES-003.

Industry Canada ICES-003 Compliance Label: CAN ICES-3(A)/NMB-3(A)

KCC Certification

Korean Class A EMC

Warranty

For information about Pelco’s product warranty and thereto related information, refer to www.pelco.com/warranty.

Legal Notice

SOME PELCO EQUIPMENT CONTAINS, AND THE SOFTWARE ENABLES, AUDIO/VISUAL AND RECORDING CAPABILITIES, THE IMPROPER USE OF WHICH MAY SUBJECT YOU TO CIVIL AND CRIMINAL PENALTIES. APPLICABLE LAWS REGARDING THE USE OF SUCH CAPABILITIES VARY BETWEEN JURISDICTIONS AND MAY REQUIRE, AMONG OTHER THINGS, EXPRESS WRITTEN CONSENT FROM RECORDED SUBJECTS. YOU ARE SOLELY RESPONSIBLE FOR INSURING STRICT COMPLIANCE WITH SUCH LAWS AND FOR STRICT ADHERENCE TO ANY/ALL RIGHTS OF PRIVACY AND PERSONALTY. USE OF THIS EQUIPMENT AND/OR SOFTWARE FOR ILLEGAL SURVEILLANCE OR MONITORING SHALL BE DEEMED UNAUTHORIZED USE IN VIOLATION OF THE END USER SOFTWARE AGREEMENT AND RESULT IN THE IMMEDIATE TERMINATION OF YOUR LICENSE RIGHTS THEREUNDER.

Audio Notice

NOTE: Improper use of audio/visual recording equipment may subject you to civil and criminal penalties. Applicable laws regarding the use of such capabilities vary between jurisdictions and may require, among other things, express written consent from the recorded subjects. You are solely responsible for insuring strict compliance with such laws and for strict adherence to any/all right of privacy and personalty.

7

Video Quality Caution

Frame Rate Notice Regarding User Selected Options

Pelco systems are capable of providing high quality video for both live viewing and playback. However, the systems can be used in lower quality modes, which can degrade picture quality, to allow for a slower rate of data transfer and to reduce the amount of video data stored. The picture quality can be degraded by either lowering the resolution, reducing the picture rate, or both. A picture degraded by having a reduced resolution may result in an image that is less clear or even indiscernible. A picture degraded by reducing the picture rate has fewer frames per second, which can result in images that appear to jump or move more quickly than normal during playback. Lower frame rates may result in a key event not being recorded by the system.

Judgment as to the suitability of the products for users' purposes is solely the users' responsibility. Users shall determine the suitability of the products for their own intended application, picture rate and picture quality. In the event users intend to use the video for evidentiary purposes in a judicial proceeding or otherwise, users should consult with their attorney regarding any particular requirements for such use.

Open Source Software

This product includes certain open source or other software originated from third parties that is subject to the GNU General Public License (GPL), GNU Library/Lesser General Public License (LGPL) and different and/or additional copyright licenses, disclaimers, and notices.

The exact terms of GPL, LGPL, and some other licenses are provided to you with this product. Please refer to the exact terms of the GPL and LGPL at http://www.fsf.org (Free Software Foundation) or http://www.opensource.org (Open Source Initiative) regarding your rights under said license. You may obtain a complete corresponding machine-readable copy of the source code of such software under the GPL or LGPL by sending your request to digitalsupport@pelco.com; the subject line should read Source Code Request. You will then receive an email with a link for you to download the source code.

This offer is valid for a period of three (3) years from the date of the distribution of this product by Pelco.

Network Topology Statement

IMPORTANT NOTE. PLEASE READ. The network implementation is shown as a general representation only and is not intended to show a detailed network topology. Your actual network will differ, requiring changes or perhaps additional network equipment to accommodate the system as illustrated. Please contact your local Pelco representative to discuss your specific requirements.

8

Preface

This user manual is to be used as a reference for the installation and manipulation of the camera unit including features, functions, and a detailed explanation of the menu tree.

This manual provides the following information:

Product Overview: the main functions and system requirements of the unit

Installation and Connection: instructions on unit installation and wire connections

Administration and Configuration: the main menu navigation and controls explanations

9

1. Product Overview

1.1 Dimensions

The Spectra® Professional PTZ Camera System has several installation methods. Figure 1-1 depicts the dimensions of the Spectra® Professional PTZ Camera Systems.

VALUES IN PARENTHESES ARE INCHES; ALL OTHERS ARE MILLIMETERS.

PTZ Dome Indoor In-ceiling Mount































PTZ Dome Outdoor In-ceiling Mount

































































































































































































































































































































































































































































































































































































































































































































































































































































































PTZ Dome Outdoor/Indoor Pendant Mount

FIGURE 1-1: PHYSICAL DIMENSIONS

10

Pelco P1220-ESR0, P1220-ESR1, P1220-FWH0, P1220-FWH1, P1220-PWH0 User Manual

1.2 Physical Characteristics

FIGURE 1-2: PICTORIAL INDEX

11





TABLE 1 - 1: PICTORIAL INDEX DEFINITION















Index #

Name

Descriptions





1

Audio In (Black/White)

Connect to an auxiliary microphone to record audio for the





camera.



























Connect the power terminal with a power supply via





2

24VAC Power Input Terminal

power cord. Make sure to wire the terminals to correct









jacks. Avoid this connector if PoE+ is applicable.



















Ethernet/PoE+ connection. Cabling this port to the RJ-45





3

RJ-45

jack of standard network devices for connection or PoE+









compatible devices for power supply to the unit as well.















4

Alarm & Relay Connectors

Connect to external device that can trigger alarm signals





and device to be triggered by alarm output signals.























5

Default Button

Press the button for 5 seconds to restore the camera





back to the factory default settings.























6

Reset Button

Press the button to reboot the camera.















7

SD Card Slot

Insert Micro SD card into the slot for file storage.1



















Note

1. Power supply terminal/adaptor for connectors and field wiring should comply with the







Class 2 Circuit standard for ensuring safe from electrical fires and providing acceptable







protection against electrical shock.



2.For indoor series models, the product is intended to be supplied by a Listed Power Unit marked "L.P.S." (or "Limited Power Source") and rated output 48Vdc, 600mA minimum or 24Vac, 1.1A minimum. The product shall be installed by a qualified service person and the installation shall conform to all local codes.

3.For outdoor series models, if the power supply installed outdoor, the product is intended to be supplied by a Listed rainproof/raintight class 2/LPS power supply or a listed power supply complying with UL60950-1 part 1 and part 22 which rated output 48Vdc, 0.6A minimum or 24Vac, 2.1A minimum. The product shall be installed by a qualified service person and wiring method should comply article 725 and article 300 in national electrical code for class 2 circuit and wiring in duct.

1It is required to disassemble the camera before inserting micro SD card. Refer to 2.3.2 Disassembling the Camera page 14 for more information.

12

2. Installation and Connection

2.1 Unpacking Everything

Check everything in the packing box matches to the order form and the packing slip. In addition to this manual, items below are included in the packing box.

One Network PTZ camera (indoor or outdoor)

One Backbox (pendant or in-ceiling)

One Lower Dome (version depends upon indoor, outdoor, in-ceiling, or pendant)

One CD containing user manual, and quick installation guide

One printed quick installation guide

One Terminal header 2 pin for 24VAC

One Terminal header 3 pin for Audio port

One Terminal header 8 pin for alarm / relay port

One Pin-In T-20 Torx Bit

MAC Address Labels

Template guide to cut hole in ceiling (only supplied with in-ceiling versions)

Anti-Seize lubricant (only supplied with pendant versions)

Please contact your dealer if any item is missing.

2.2 Optional Accessories

LDP-PWH-0: LOWER DOME PRO PENDANT WHITE SMOKE

LDP-PWH-1: LOWER DOME PRO PENDANT WHITE CLEAR

LDP-FWH-0: LOWER DOME PRO FLUSH WHITE SMOKE

LDP-FWH-1: LOWER DOME PRO FLUSH WHITE CLEAR

LDP-ESR-0: LOWER DOME PRO ENV PDNT SR GRAY SMK

LDP-ESR-1: LOWER DOME PRO ENV PDNT SR GRAY CLR

LDP-YSR-0: LOWER DOME PRO ENV FLSH SR GRAY SMK

LDP-YSR-1: LOWER DOME PRO ENV FLSH SR GRAY CLR

2.3 Installation

Following tools and parts might help you complete the installation:

a drill

wire cutters

saw for cutting a hole in ceiling (in-ceiling version only)

Pipe / Conduit (weather-proof if applicable to installation)

Conduit Adapters (if applicable)

RJ-45 connector to terminate wires

Cat5 (or higher) cable

24 AWG, 8-wire multi-conductor cable (if using alarms, relays and/or line-in and line-out audio)

2.3.1 Checking Appearance

When first unboxing, please check if there is any visible damage to appearance of the unit and its accessories. The protective materials used for the packaging should protect the unit during transportation. Please remove the protective film of the unit when every item is checked in accordance with the list in 2.1 Unpacking Everything

13

2.3.2 Disassembling the Camera

For operating certain features, e.g. SD card installation / removal, it is necessary to dismantle the camera first. By following the illustrations, please do as the steps below.

1.Loosen the 2 screws on the top cover by T20 screwdriver (bit provided).

2.Gently lift up the top cover from the camera body and put it aside.

3.The SD card can be found on the rear of the IOP module. Refer to 1.2 Physical Characteristics page 11 for more details.

FIGURE 2-1: DISASSEMBLE THE CAMERA

14

2.3.3 Connecting Wires

Flip to the bottom side of the camera and the I/O connectors will appear for user to connect required cables as the following:

24 VAC: Connect 24V (~) cables to terminals ~24 VAC

PoE+: Connect the RJ-45 network connector to a PoE+ compatible network device that has supplied power through the Ethernet cable.

Network: Connect the RJ-45 network connector to the RJ-45 network port of a switch via a network cable for network data transmission.

Alarm, Audio Input/Output: Insert audio cable and alarm cable to the camera if needed.

NOTES:

Cable Management: To avoid the length deficiency, you should reserve about 10mm length of the network cable for connecting the cable to the RJ-45 network port before attaching the cable to the connector.

Cable Relief: There are four cable reliefs (aka. tabs) around the perimeter of the I/O connections. After the cables are installed, they can be wrapped around these four tabs to provide relief from cable strain and to allow for ease of installation into the backbox.

FIGURE 2-2: CONNECTORS FOR WIRING

15

2.3.4 Installing the Camera

You can install the PTZ dome camera using one of the following installation methods:

Pendant Installation with Conduit / Pipe (refer to 2.3.4.1 Pendant Installation with Conduit/Pipe )

Pendant Installation with Pelco Mount (refer to 2.3.4.2 Pendant Installation with Pelco Mount)

In-Ceiling Installation (refer to 2.3.4.3 In-Ceiling Installation)

2.3.4.1 Pendant Installation with Conduit/Pipe

The Pendant installation with conduit/pipe involves mounting the PTZ camera to the ceiling where the conduit / pipe is routed along the wall.

1.Install Conduit (not supplied).

2.Mount back box to conduit. (When installing in a high humidity or water prone area, use weather proof conduit.)

NOTE: If using the pendant threads, anti-seize compound should be applied on both indoor and environmental pendants. Not doing so might prevent the units from being separated in the future. Waterproof tape can also be used the help prevent water ingress damage.

FIGURE 2-3: INDOOR / OUTDOOR PENDANT CABLING

3.Pass all required cables through the conduit and the back box.

16

4.Install the Camera:

a.Align the tether from the back box (Position #2) and attach it to the camera (Position #3). There are red dots on the camera and the back box to aid alignment.

#2 connects with #3

#1 connects with #4 (later step)

Back Box

Camera Body

Dome Cover

FIGURE 2-4: INDOOR / OUTDOOR PENDANT ALIGNING

b.While the camera body hangs from the tether, connect the power wiring and all corresponding I/O connectors. The cables can be wrapped around the cable reliefs for optimum strain relief.

c.Push the camera into the backbox until the clips on both sides click into place. The clips temporarily hold the camera in place.

d.Screw in the three captive fasteners until they are secure.

17

5.Install the Lower Dome:

a.Attach the back box tether to the lower dome from position #1 (back box tether) to position #4 (lower dome).

b.Push the lower dome onto the backbox.

c.Tighten the four screws to secure the lower dome to the back box.

Back Box

Camera Body

Dome Cover

FIGURE 2-5: INDOOR / OUTDOOR PENDANT INSTALLATION

6.Apply power to the dome. The dome system will complete a configuration sequence.

18

2.3.4.2 Pendant Installation with Pelco Mount

The Pendant installation with Pelco mount involves mounting the PTZ camera to the wall with a Pelco mount.

1.Install the pendant mount to the wall (not supplied). Refer to the instructions supplied with the mount.

2.Screw the compression connector onto the pendant back box. Screw the lock nut onto the compression connector protruding from beneath the back box. Tighten the lock nut until the compression connector is held firmly to the back box.

NOTE: The Outdoor Pendant Installation requires critical waterproof resistance and therefore needs the optional accessories: Compression Gland Connector and Lock Nut as the following figure displayed. Prior to screwing the back box onto the pendant pipe, it should be installed with a 3/4” Compression Gland Connector and a Lock Nut (sold separately) so that the threaded cables can be completely free from leaking issues.

Compression Gland Connector

Lock Nut

FIGURE 2-6: COMPRESSION GLAND CONNECTOR & LOCK NUT

3.Apply thread compound (supplied) to the threads on the back box. Screw the back box onto the pendant mount.

NOTE: Anti-seize compound should be applied on both indoor and environmental pendants. Not doing so might prevent the units from being separated in the future. Waterproof tape can also be used the help prevent water ingress damage.

FIGURE 2-7: INDOOR / OUTDOOR PENDANT CABLING

4.Pull the wiring through the mount and into the back box

19

5.Install the camera:

a.Align the tether from the back box (Position #2) and attach it to the camera (Position #3). There are red dots on the camera and the back box to aid alignment:

#2 connects with #3

#1 connects with #4 (later step)

Back Box

Camera Body

Dome Cover

FIGURE 2-8: INDOOR / OUTDOOR PENDANT ALIGNING

b.While the camera body hangs from the tether, connect the power wiring and all the corresponding I/O connectors. The cables can be wrapped around the cable reliefs for optimum strain relief.

c.Push the camera into the backbox until the clips on both sides click into place. The clips temporarily hold the camera in place.

d.Screw in the three captive fasteners until they are secure.

20

6.Install the Lower Dome:

a.Attach the back box tether to the lower dome from position #1 (back box tether) to position #4 (lower dome) as shown:

Back Box

Camera Body

Dome Cover

FIGURE 2-9: INDOOR / OUTDOOR PENDANT INSTALLATION

b.Align the back box screws with the slots on the lower dome. There are red dots on the lower dome and the back box to aid alignment.

c.Push the lower dome onto the back box.

d.Tighten the screws to secure the lower dome to the back box.

21

2.3.4.3 In-Ceiling Installation

The In-Ceiling Installation involves mounting the PTZ camera into the ceiling.

1.Attach the guide pattern used for in-ceiling mount to the ceiling.

FIGURE 2-10: GUIDE PATTERN

2.According to the guide pattern, cut a hole in the ceiling/wall.

3.Install a safety chain/cable (not supplied) to ¼-20 threaded hole on the top of the back box. The safety chain/cable should be capable of supporting up to 7.3 kg (16 pounds).

4.Insert the back box into the hole and fasten the 3 screws with a screwdriver and supplied Torx bit so that the locking spring paddles can slide out to secure the back box into the ceiling/wall (refer to Figure2-14 & Figure2-15).

Back Box

FIGURE 2-11: INSERTING THE BACK BOX

22

Spring Paddles

FIGURE 2-12: SECURING THE BACK BOX

5.Pass all required cables clad in the 3/4 PF pipe (sold separately) through one of the back box conduit holes (side or bottom) and screw the lock nut onto the 3/4 PF pipe protruding from beneath the back box until it is firmly into place.

Note: It is necessary to apply Waterproof Tape around the screw thread of 3/4 PF pipe before screwing the lock nut with the 3/4 PF pipe for ensuring fully waterproof functionality in outdoor in-ceiling application.

Lock Nut

FIGURE 2-13: OUTDOOR IN-CEILING CABLING

23

Loading...
+ 51 hidden pages
