Nokia E51-1, E51-2 User Manual

0 (0)

E51 User Guide

Issue 2

DECLARATION OF CONFORMITY

Hereby, NOKIA CORPORATION declares that this RM-244 / RM-426 product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. A copy of the Declaration of Conformity can be found at http:// www.nokia.com/phones/declaration_of_conformity/.

© 2007 Nokia. All rights reserved.

Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited.

Nokia, Nokia Connecting People, Eseries, E51, and Visual Radio are trademarks or registered trademarks of Nokia Corporation. Nokia tune is a sound mark of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.

This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommercial use in connection with information which has been encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial activity and (ii) for use in connection with MPEG-4 video provided by a licensed video provider. No license is granted or shall be implied for any other use. Additional information, including that related to promotional, internal, and commercial uses, may be obtained from MPEG LA, LLC. See http://www.mpegla.com.

This product includes software licensed from Symbian Software Ltd © 1998-2007. Symbian and Symbian OS are trademarks of Symbian Ltd. US Patent No 5818437 and other pending patents. T9 text input software Copyright © 1997-2007. Tegic Communications, Inc. All rights reserved.

Java and all Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc. Portions of the Nokia Maps software are copyright © 1996-2002 The FreeType Project. All rights reserved.

Nokia operates a policy of ongoing development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED.

THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.

The availability of particular products and applications for these products may vary by region. Please check with your Nokia dealer for details, and availability of language options.

Export controls

This device may contain commodities, technology or software subject to export laws and regulations from the US and other countries. Diversion contrary to law is prohibited.

FCC/INDUSTRY CANADA NOTICE

Your device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment).The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by Nokia could void the user's authority to operate this equipment.

Model number: E51-1 (RM-244) or E51-2 (RM-426) Issue 2

Contents



For your safety ...............................................

10

About your device...............................................................

11

Network services................................................................

11

Enhancements, batteries, and chargers...........................

12

Get started......................................................

13

Insert the SIM card and battery.........................................

13

Charge the battery..............................................................

14

Keys and parts.....................................................................

15

Connect the headset...........................................................

16

Attach the wrist strap.........................................................

16

First start-up........................................................................

16

Lock the keys.......................................................................

17

Display indicators...............................................................

17

Nokia support and contact information...........................

19

Your Nokia E51...............................................

20

Welcome..............................................................................

20

Settings wizard...................................................................

20

Standby modes...................................................................

21

Active standby..................................................................

21

Standby.............................................................................

21

Menu....................................................................................

21

Common actions in several applications..........................

22

Transfer................................................................................

23

Transfer content between devices.................................

23

View transfer log..............................................................

23

Synchronise, retrieve, and send data............................

24

Personalisation...................................................................

24

Profiles..............................................................................

24

Select ringing tones.........................................................

24

Customise profiles...........................................................

25

Change the display theme..............................................

25

Download a theme..........................................................

25

3-D ringing tones.............................................................

26

Volume control....................................................................

26

One-touch keys...................................................................

26

Home key..........................................................................

26

Contacts key......................................................................

27

Calendar key.....................................................................

27

E-mail key.........................................................................

27

Multitasking.........................................................................

27

Memory................................................................................

27

Free memory....................................................................

27

Memory card.....................................................................

28

MicroSD...........................................................................

28

Insert the memory card................................................

28

Use a memory card.......................................................

28

Eject the memory card..................................................

29

Write text.............................................................................

29

Traditional text input......................................................

29

Predictive text input........................................................

30

Change the writing language.........................................

30

Antennas..............................................................................

30

Further information...........................................................

31

Business communications..............................

32

Telephone............................................................................

32

Voice calls.........................................................................

32

Answer a call..................................................................

32

Make a call.....................................................................

32

Make a conference call..................................................

33

Fax calls..........................................................................

33

Video calls.........................................................................

33

Make a video call...........................................................

33

Share a video.................................................................

34

Receive a video sharing invitation..............................

34

Net calls.............................................................................

34

Create a net call profile.................................................

35

Connect to the net call service.....................................

35

Make net calls................................................................

35

Net call service settings................................................

36

Speed dialling...................................................................

36

Call divert..........................................................................

36

Call barring.......................................................................

37

Bar net calls......................................................................

37

Send DTMF tones..............................................................

37

Voice mail.........................................................................

38

Voice aid..............................................................................

38

Voice commands.................................................................

38

Make a call........................................................................

39

Launch an application.....................................................

39

Change profiles................................................................

39

Voice command settings.................................................

39

Log........................................................................................

39

Call and data registers.....................................................

40

Monitor all communications...........................................

40

Call and send messages from Log..................................

40

Log settings......................................................................

40

Contacts...............................................................................

40

Copy contacts between SIM and device memory.........

41

Manage contacts..............................................................

41

Manage contact groups...................................................

42

Add ringing tones for contacts.......................................

42

Send business cards.........................................................

42

Manage received business cards....................................

42

SIM directory.....................................................................

42

Calendar...............................................................................

43

Create calendar entries...................................................

43

Create a meeting entry....................................................

44

To-do entries....................................................................

44

Calendar views.................................................................

45

Work in different views................................................

45

Month view....................................................................

45

Week view.....................................................................

45

Day view.........................................................................

45

To-do view.....................................................................

45

Calendar settings.............................................................

46

Web......................................................................................

46

Connection security.........................................................

46

Browse the web...............................................................

46

Bookmarks........................................................................

47

Clear the cache.................................................................

47

Feeds and blogs...............................................................

47

End a connection..............................................................

47

Web settings.....................................................................

47

Messaging.......................................................

48

Messaging folders...............................................................

48

Organise messages.............................................................

49

Message reader...................................................................

49

Speech..................................................................................

49

Edit the voice properties ................................................

49

E-mail messages.................................................................

49

Set up your e-mail with the mailbox guide..................

50

Connect to a remote mailbox.........................................

50

Read and reply to e-mail.................................................

51

Write and send e-mail.....................................................

51

Delete messages..............................................................

52

Subfolders in your remote e-mail..................................

52

Text messages.....................................................................

52

Write and send text messages.......................................

52

Sending options for text messages................................

53

Text messages on the SIM card......................................

53

View picture messages....................................................

53

Forward picture messages..............................................

53

Multimedia messages.........................................................

54

Create and send multimedia messages.........................

54

Receive and reply to multimedia messages..................

55

Create presentations.......................................................

55

View presentations..........................................................

56

View and save multimedia attachments.......................

56

Forward a multimedia message.....................................

56

Send a sound clip.............................................................

56

Sending options for multimedia messages..................

57

Special message types.......................................................

57

Service messages.............................................................

57

Send service commands..................................................

57

Cell broadcast......................................................................

57

Messaging settings.............................................................

58

Text message settings.....................................................

58

Multimedia message settings.........................................

58

E-mail account settings...................................................

59

Connection settings......................................................

59

User settings..................................................................

59

Retrieval settings..........................................................

60

Automatic retrieval settings........................................

60

Service message settings................................................

60

Cell broadcast settings....................................................

61

Other settings...................................................................

61

Nokia Office Tools...........................................

62

Active notes.........................................................................

62

Create and edit notes......................................................

62

Settings for Active notes.................................................

62

Search..................................................................................

63

Search for information ...................................................

63

Search results...................................................................

63

Calculator.............................................................................

63

File manager.......................................................................

63

Quickoffice...........................................................................

64

Work with files.................................................................

64

Nokia Team suite................................................................

64

Work with teams.............................................................

64

Edit teams.........................................................................

65

Nokia Team Suite settings..............................................

65

Action bar settings...........................................................

65

Converter.............................................................................

66

Convert measurements...................................................

66

Set base currency and exchange rate............................

66

Zip manager........................................................................

66

PDF reader...........................................................................

67

Printing................................................................................

67

Print files...........................................................................

67

Printing options...............................................................

67

Printer settings................................................................

67

Clock.....................................................................................

68

Alarm clock.......................................................................

68

World clock.......................................................................

68

Clock settings....................................................................

68

Notes....................................................................................

69

Write and send notes......................................................

69

Nokia Wireless Keyboard...................................................

69

Free time........................................................

70

Camera.................................................................................

70

Capture an image.............................................................

70

Record a video clip...........................................................

70

Camera settings...............................................................

71

Gallery..................................................................................

71

Work with media files and folders.................................

71

View images.....................................................................

71

Manage image files..........................................................

72

RealPlayer............................................................................

72

Play video clips and stream links...................................

72

Send audio files and video clips.....................................

73

View information about a media clip............................

73

RealPlayer settings..........................................................

73

Music player.........................................................................

73

Listen to music.................................................................

73

Track lists..........................................................................

74

Music categories...............................................................

74

Preset frequency settings...............................................

74

Recorder..............................................................................

74

Record a sound clip..........................................................

75

Play a recording...............................................................

75

Recorder settings.............................................................

75

Instant messaging..............................................................

75

Define IM settings............................................................

75

Start a conversation.........................................................

76

IM groups..........................................................................

76

Block users........................................................................

77

IM application settings....................................................

77

Flash player.........................................................................

78

Manage flash files............................................................

78

Visual radio..........................................................................

78

Listen to the radio...........................................................

78

View visual content.........................................................

79

Saved stations..................................................................

79

Visual Radio settings.......................................................

79

Push to talk.........................................................................

79

PTT settings......................................................................

80

Log in to PTT service........................................................

80

Make a PTT call.................................................................

80

Created PTT calls..............................................................

80

Manage PTT contacts.......................................................

80

Create a PTT channel.......................................................

81

Exit PTT..............................................................................

81

About GPS and satellite signals.........................................

81

Positioning settings...........................................................

82

Nokia Maps..........................................................................

82

Download maps...............................................................

82

Satellite information.......................................................

83

Browse maps....................................................................

84

Find a place.......................................................................

84

Plan a route......................................................................

84

Navigation........................................................................

85

Guides...............................................................................

85

GPS data...............................................................................

85

Use GPS data.....................................................................

86

Landmarks...........................................................................

86

Create a landmark............................................................

86

Edit landmarks.................................................................

86

Landmark categories.......................................................

87

Receive landmarks...........................................................

87

Connectivity....................................................

88

Fast downloading...............................................................

88

Nokia PC Suite.....................................................................

88

Data cable............................................................................

88

Infrared................................................................................

89

Bluetooth.............................................................................

89

About Bluetooth...............................................................

89

Send and receive data with Bluetooth..........................

90

Pair devices.......................................................................

91

Security tips......................................................................

92

SIM access profile................................................................

92

Wireless LAN........................................................................

92

WLAN connections...........................................................

93

See WLAN availability......................................................

93

WLAN wizard....................................................................

93

Internet access points........................................................

94

Set up an internet access point for packet data



(GPRS)................................................................................

95

Advanced internet access point settings for packet



data (GPRS).......................................................................

95

Set up an access point for WLAN manually...................

96

Advanced access point settings for WLAN.....................

96

Modem.................................................................................

96

Connection manager..........................................................

97

View and end active connections...................................

97

Search for WLAN...............................................................

97

Security and data management.....................

98

Lock the device...................................................................

98

Memory card security.........................................................

98

Fixed dialling.......................................................................

99

Certificate manager............................................................

99

View certificate details..................................................

100

Certificate trust settings................................................

100

Security modules..............................................................

100

View and edit security modules...................................

100

Back up data......................................................................

101

Remote configuration......................................................

101

Application manager........................................................

102

Install applications........................................................

102

Installation settings......................................................

103

Java security settings....................................................

103

Activation keys..................................................................

104

Use activation keys........................................................

104

Data synchronisation.......................................................

105

Create a synchronisation profile..................................

105

Select applications to synchronise...............................

105

Synchronisation connection settings..........................

106

Download!.........................................................................

106

Select catalogs, folders, and items..............................

106

Download! settings.......................................................

107

Software updates.............................................................

107

Settings........................................................

108

General settings................................................................

108

Personalisation settings...............................................

108

Display settings...........................................................

108

Standby mode settings..............................................

109

Tone settings...............................................................

109

Language settings......................................................

109

Notification light.........................................................

109

Date and time settings..................................................

109

Enhancement settings...................................................

110

Common enhancement settings...............................

110

Security settings............................................................

110

Device and SIM card security......................................

110

Restore original settings...............................................

111

Telephone settings...........................................................

111

Call settings....................................................................

111

Network settings...........................................................

112

Connection settings..........................................................

112

Access points..................................................................

112

Packet data (GPRS) settings..........................................

112

WLAN settings................................................................

113

Advanced WLAN settings..............................................

113

WLAN security settings..................................................

113

WEP security settings

114



Operating environment

130



WEP key settings............................................................

114



Medical devices.................................................................

130

802.1x security settings................................................

114



Implanted medical devices...........................................

130

WPA security settings....................................................

114



Hearing aids...................................................................

131

Wireless LAN plugins.....................................................

115



Vehicles..............................................................................

131

EAP plug-ins.................................................................

115



Potentially explosive environments...............................

131

Use EAP plug-ins..........................................................

115



Emergency calls................................................................

132

Session initiation protocol (SIP) settings....................

115



CERTIFICATION INFORMATION (SAR).................................

132

Edit SIP profiles..............................................................

115



Index

134

Edit SIP proxy servers....................................................

116



Edit registration servers................................................

116







Net call settings.............................................................

116







Configuration settings...................................................

116







Restrict packet data.......................................................

117







Application settings.........................................................

117







Shortcuts......................................................

118







General shortcuts..............................................................

118







Glossary........................................................

120







Troubleshooting...........................................

123







Battery information.....................................

126







Charging and discharging................................................

126







Nokia battery authentication guidelines.......................

127







Authenticate hologram.................................................

127







What if your battery is not authentic?........................

127







Care and maintenance.................................

128







Disposal.............................................................................

128







Additional safety information.....................

130







Small children...................................................................

130







For your safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.

SWITCH ON SAFELY

Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect performance.

SWITCH OFF IN HOSPITALS

Follow any restrictions. Switch the device off near medical equipment.

SWITCH OFF IN AIRCRAFT

Follow any restrictions. Wireless devices can cause interference in aircraft.

SWITCH OFF WHEN REFUELING

10Do not use the device at a refueling point. Do not use near fuel or chemicals.

SWITCH OFF NEAR BLASTING

Follow any restrictions. Do not use the device where blasting is in progress.

USE SENSIBLY

Use only in the positions as explained in the product documentation. Do not touch the antenna areas unnecessarily.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

ENHANCEMENTS AND BATTERIES

Use only approved enhancements and batteries. Do not connect incompatible products.

WATER-RESISTANCE

Your device is not water-resistant. Keep it dry.

BACK-UP COPIES

Remember to make back-up copies or keep a written record of all important information stored in your device.

CONNECTING TO OTHER DEVICES

When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.

EMERGENCY CALLS

Ensure the phone function of the device is switched on and in service. Press the end key as many times as needed to clear the display and return to the standby mode. Enter the emergency number, then press the call key. Give your location. Do not end the call until given permission to do so.

About your device

The wireless device described in this guide is approved for use on the GSM 850, 900, 1800, 1900, and UMTS 850 and 2100 networks. Contact your service provider for more information about networks.

When using the features in this device, obey all laws and respect local customs, privacy and legitimate rights of others, including copyrights.

Copyright protections may prevent some images, music (including ringing tones), and other content from being copied, modified, transferred, or forwarded.

Your device supports internet connections and other methods of connectivity. Like computers, your device may be exposed to viruses, malicious messages and applications, and other harmful content. Exercise caution and open messages, accept connectivity requests, download content, and accept installations only from trustworthy sources. To increase the security of your

devices, consider installing, using, and regularly updating antivirus software, firewall, and other related software on your device and any connected computer.

Warning: To use any features in this device, other than the alarm clock, the device must be switched on. Do not switch the device on when wireless device use may cause interference or danger.

During extended operation, such as an active video sharing session or high-speed data connection, the device may feel warm. In most cases, this condition is normal. If you suspect the device is not working properly, take it to the nearest authorized service facility.

The office applications support common features of Microsoft Word, PowerPoint, and Excel (Microsoft Office 2000, XP, and 2003). Not all file formats can be viewed or modified.

Network services

To use the phone you must have service from a wireless service provider. Many of the features require special network features. These features are not available on all networks; other networks may require that you make specific arrangements with your service provider before you can use the network services. Your service provider can give you instructions and explain what charges will apply. Some networks may have limitations that affect how you can use network services. For instance, some networks may not support all language-dependent characters and services.

Your service provider may have requested that certain 11 features be disabled or not activated in your device. If so,

these features will not appear on your device menu. Your device may also have a special configuration such as changes in menu names, menu order, and icons. Contact your service provider for more information.

This device supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP protocols. Some features of this device, such as MMS, browsing, and e-mail require network support for these technologies.

Enhancements, batteries, and chargers

Always switch the device off and disconnect the charger before removing the battery.

Check the model number of any charger before use with this device. This device is intended for use when supplied with power from the AC-5 charger.

The battery intended for use with this device is BP-6MT.

Warning: Use only batteries, chargers, and enhancements approved by Nokia for use with this particular model. The use of any other types may invalidate any approval or warranty, and may be dangerous.

For availability of approved enhancements, please check with your dealer. When you disconnect the power cord of any enhancement, grasp and pull the plug, not the cord.

12

Nokia E51-1, E51-2 User Manual

Get started

Model number: Nokia E51-1 (RM-244, with camera) and Nokia E51-2 (RM-426, without camera).

Hereinafter referred to as Nokia E51.

Insert the SIM card and battery

For availability and information on using SIM card services, contact your SIM card vendor. This may be the service provider or other vendor.

1.With the back of the device facing you, press the release button (1) and slide the back cover off (2).

2.If the battery is inserted, lift the battery in the direction of the arrow to remove it.

3.Insert the SIM card. Make sure that the contact area on the card is facing the connectors on the device and that the bevelled corner is facing the top of the device.

4.Insert the battery. Align the contacts of the battery with the corresponding connectors on the battery compartment and insert in the direction of the arrow.

13

5. Slide the back cover back to place.

Charge the battery

1. Connect a compatible charger to a wall outlet.

2.

Connect the power cord to the device. If the battery is completely discharged, it may take a while before the charging indicator starts scrolling.

14

3.When the battery is fully charged, disconnect the charger from the device, then from the wall outlet.

Your battery has been precharged at the factory, but the charging levels may vary. To reach the full operation time, charge the battery until it has been fully charged according to the battery level indicator.

Tip: If you have old compatible Nokia chargers, you can use them with the Nokia E51 by attaching the CA-44 charger adapter to the old charger. The adapter is available as a separate enhancement.

Keys and parts

1 — Power key

2 — Earpiece

3 — Volume up key

4 — Mute key. Press the key to mute the microphone during a call.

5 — Volume down key

6 — Navi™ scroll key. Press the scroll key to enter a selection, to scroll left, right, up, and down on the display.

7 — Selection key. Press the selection key to perform the function shown above it on the display.

8 — End key. Press the end key to reject a call, end active calls and held calls, and with a long keypress, end data connections.

9 — Backspace key. Press the key to delete items.

10 — Shift key. When writing text, press and hold the key and select the text with the scroll key. Press this key for a few seconds to toggle between the Silent and General profiles.

11 — Press the key for a few seconds to switch on Bluetooth connectivity. When writing text, press the key and select More symbols to access special characters.

12 — Call key

13 — Selection key

14 — Infrared port

15 — Voice key. This key is used in the voice commands, Recorder, and Push to talk applications.

16 — Notification light and light sensor

17 — Microphone

18 — Headset connector

19 — Wrist strap hole

20 — Mini-USB port

21 — Charger connector

15

1 — Home key

2 — Contacts key

3 — E-mail key

4 — Calendar key

Connect the headset

Warning: When you use the headset, your ability to hear outside sounds may be affected. Do not use the headset where it can endanger your safety.

Connect the compatible headset to the headset connector of your device.

16

Attach the wrist strap

Thread the wrist strap as shown, and tighten it.

First start-up

1.Press and hold the power key.

2.If the device asks for a PIN code or lock code, enter the code, and select OK.

3.When prompted, enter the country in which you are located and the current date and time. To find your country, enter the first letters of the country name. It is important to select the correct country, because scheduled calendar entries may change if you change the country later and the new country is located on a different time zone

4.The Welcome application opens. Select from the various options, or select Exit to close the application.

To configure the various settings in your device, use the Settings wizard application

and the wizards available in the standby mode. When you switch the device on, it may recognise the SIM card provider and configure some settings automatically. You can also contact your service provider for the correct settings.

You can switch the device on with no SIM card inserted, in which case the device starts up in the offline mode, and you cannot use the network-dependent phone functions.

To switch the device off, press and hold the power key.

Lock the keys

When the device or keypad is locked, calls may be possible to the official emergency number programmed into your device.

The keypad of your device locks automatically to prevent the keys from being accidentally pressed. To change the period after which the keypad is locked, select Menu >

Tools > Settings > General > Security > Phone and SIM card > Keypad autolock period.

To lock the keys manually in the standby mode, press the left selection key and *.

To unlock the keys, press the left selection key and *.

Tip: To lock the keys in the menu or in an open application, press the power key briefly, and select Lock keypad. To unlock, press the left selection key and *.

Display indicators

The device is being used in a GSM network (network service). The bar next to the icon indicates the signal strength of the network at your current location. The higher the bar, the stronger the signal.

The device is being used in a UMTS network (network service).

The battery charge level. The higher the bar, the stronger the charge in the battery.

17



You have one or more unread messages in the Inbox



folder in Messaging.



You have received new e-mail in the remote mailbox.



There are messages waiting to be sent in the Outbox



folder in Messaging.



You have one or more missed phone calls.



The keys of the device are locked.



An alarm is active.



You have selected the Silent profile, and the device does



not ring for an incoming call or message.



Bluetooth is active.



Data is being transmitted using Bluetooth



connectivity. When the indicator is blinking, your device is



trying to connect with another device.



An infrared connection is active. If the indicator



blinks, your device is trying to connect to the other device,



or the connection has been lost.



A GPRS packet data connection is available (network



service).



A GPRS packet data connection is active.



A GPRS packet data connection is on hold.



An EGPRS packet data connection is available (network



service).



An EGPRS connection is active.



An EGPRS packet data connection is on hold.

18

A UMTS packet data connection is available (network

service).

A UMTS packet data connection is active.

A UMTS packet data connection on hold.

High-speed downlink packet access (HSDPA) is supported and available (network service). The icon may vary between regions.

High-speed downlink packet access (HSDPA) is active. The icon may vary between regions.

High-speed downlink packet access (HSDPA) is on hold. The icon may vary between regions.

You have set the device to scan for WLANs, and a WLAN is available.

A WLAN connection is active in a network that does not have encryption.

A WLAN connection is active in a network that has encryption.

Your device is connected to a computer with a USB data cable.

The second phone line is being used (network service).

All calls are forwarded to another number. If you have two phone lines, a number indicates the active line.

A headset is connected to the device.

The connection to a headset with Bluetooth connectivity has been lost.

A hands-free car kit is connected to the device.

A loopset is connected to the device.

A text phone is connected to the device. Your device is synchronising.

You have an ongoing push-to-talk connection.

Your push-to-talk connection is in the do not disturb mode, because the ringing type setting of your device is set to Beep once or Silent, or you have an incoming or ongoing phone call. In this mode, you cannot make PTT calls.

Nokia support and contact information

Check www.nokia.com/support or your local Nokia website for the latest guides, additional information, downloads, and services related to your Nokia product.

If you need to contact customer service, check the list of local Nokia Care contact centres at www.nokia.com/ customerservice.

For maintenance services, check your nearest Nokia service centre at www.nokia.com/repair.

19

Your Nokia E51

The images in this guide may differ from your device display.

Welcome

When you switch on your device for the first time, the Welcome application opens. Select from the following:

Tutorial provides information about your device and shows you how to use it.

Switch enables you to transfer content, such as contacts and calendar entries, from a compatible Nokia device. See "Transfer content between

devices", p. 23.

Settings wizard helps you configure various settings. See "Settings wizard", p. 20.

Operator contains a link to your operator's home portal.

To open the Welcome application later, select Menu >

Help > Welcome.

The available items may vary between regions.

20 Settings wizard

Select Menu > Tools > Sett. wizard.

Settings wizard configures your device for settings based on your network operator information. To use these services, you may have to contact your service provider to activate a data connection or other services.

The availability of the different settings items in Settings wizard depends on the features of the device, SIM card, wireless service provider, and the availability of the data in the Settings wizard database.

If Settings wizard is not available from your service provider, it may not appear in the menu of your device.

To start the wizard, select Start. When you use the wizard for the first time, you are guided through the settings configuration. If there is no SIM card inserted, you need to select the home country of your service provider, and your service provider. If the country or service provider suggested by the wizard is not correct, select the correct one from the list. If the settings configuration is interrupted, the settings are not defined.

To access the main view of the Settings wizard after the wizard has finished the settings configuration, select OK.

In the main view, select Options and from the following:

Operator — Configure operator-specific settings such as MMS, internet, WAP, and streaming settings.

E-mail settings — Configure e-mail settings.

Push to talk — Configure push-to-talk settings.

Video sharing — Configure video sharing settings.

If you are not able to use Settings wizard, visit the Nokia phone settings web site.

Standby modes

Your device has two different standby modes: active standby mode and standby mode.

Active standby

After you have switched on your device and it is ready for use, but you have not entered any characters or made other selections, the device is in the active standby mode. In the active standby mode, you can view different indicators such as network operator indicators or indicators for alarms, and applications you want to access fast.

To select applications that you want to access from active

standby, select Menu > Tools > Settings > General > Personalisation > Standby mode > Active standby apps..

To change the functions of the selection keys in active standby, select Menu > Tools > Settings > General > Personalisation > Standby mode > Shortcuts.

To use the basic standby mode, select Menu > Tools >

Settings > General > Personalisation > Standby mode > Active standby > Off.

Standby

In the basic standby mode, you can see your service provider, time, and different indicators, such as indicators for alarms.

To view the most recently dialled numbers, press the call key. Scroll to a number or name, and press the call key again to call the number.

To call your voice mailbox (network service), press and hold 1.

To view calendar information, scroll right.

To write and send text messages, scroll left.

To change these shortcuts, select Menu > Tools >

Settings > General > Personalisation > Standby mode > Shortcuts.

Menu

Select Menu.

21

The menu is a starting point from which you can open all applications in the device or on a memory card.

The menu contains applications and folders, which are groups of similar applications. All applications you install in the device yourself are by default saved in the Installations folder.

To open an application, scroll to it, and press the scroll key.

To view the applications in a list, select Options > Change view > List view. To return to the grid view, select Options > Change view > Grid view.

To make the application icons and folders animated, select

Options > Icon animation > On.

To view the memory consumption of different applications and data stored on the device or memory card and to check the amount of free memory, select Options >

Memory details.

To create a new folder, select Options > New folder. To rename a new folder, select Options > Rename.

To rearrange the folder, scroll to the application you want to move, and select Options > Move. A check mark is placed beside the application. Scroll to a new location, and select OK.

To move an application to a different folder, scroll to the 22 application you want to move, and select Options >

Move to folder, the new folder, and OK.

To download applications from the web, select Options >

Download applications.

Common actions in several applications

You can find the following actions in several applications:

To change the profile, or switch off or lock the device, press the power key briefly.

If an application consists of several tabs (see figure), open a tab by scrolling right or left.

To save the settings that you have configured in an application, select Back.

To save a file, select Options > Save. There are different saving options depending on the application you use.

To send a file, select Options > Send. You can send a file in an e-mail or multimedia message,

or using Bluetooth connectivity or infrared.

To copy, press and hold the shift key, and select the text with the scroll key. Press and hold the shift key, and select Copy. To paste, scroll to where you want to paste the text, press and hold the shift key, and select Paste. This method may not work in applications that have their own copy and paste commands.

To select different items, such as messages, files, or contacts, scroll to the item you want to select. Select

Options > Mark/Unmark > Mark to select one item or Options > Mark/Unmark > Mark all to select all items.

Tip: To select almost all items, first select Options > Mark/Unmark > Mark all, then select the items you do not want, and Options > Mark/Unmark > Unmark.

To select an object (for example, an attachment in a document) scroll to the object so that square markers appear on each side of the object.

Transfer

Select Menu > Tools > Switch.

You can transfer content, such as contacts, from a compatible Nokia device to your new Eseries device using Bluetooth connectivity or infrared. The type of content that can be transferred depends on the device model. If the other device supports synchronisation, you can also synchronise data between the two devices or send data from this device to the other device.

When you transfer data from your previous device, it may require you to insert the SIM card. Your new Eseries device does not need a SIM card when transferring data.

Content is copied from the memory of the other device to the corresponding location in your device. Copying time depends on the amount of data to be transferred. You can also cancel and continue later.

The necessary steps for data transfer may vary depending on your device, and whether you have interrupted data

transfer earlier. The items that you can transfer vary depending on the other device.

Transfer content between devices

To connect the two devices, follow the instructions on the display. For some device models, the Transfer application is sent to the other device as a message. To install Transfer on the other device, open the message, and follow the instructions on the display. On your new Eseries device, select the content you want to copy from the other device.

After the data transfer, you can save the shortcut with the transfer settings to the main view to repeat the same transfer later. To edit the shortcut, select Options >

Shortcut settings.

View transfer log

A transfer log is shown after every transfer.

To view the transfer details, scroll to the transferred item in the log, and select Options > Details.

To view the log of a previous transfer, scroll to a transfer shortcut, if available, in the main view, and select

Options > View log.

Any unresolved transfer conflicts are also displayed in the log view. To start solving conflicts, select Options > Solve conflicts.

23

Synchronise, retrieve, and send data

If you have previously transferred data to your device with the Transfer application, select from the following icons in the Transfer main view:

Synchronise data with a compatible device if the other device supports synchronisation. With synchronisation, you can keep the data up-to-date in both devices.

Retrieve data from the other device to your new Eseries device.

Send data from your new Eseries device to your other device.

Personalisation

You can personalise your device by adjusting the various tones, background images, and screen savers, for example.

Profiles

Select Menu > Tools > Profiles.

You can adjust and customise the ringing tones, alert tones, and other device tones for different events, environments, or caller groups. The profile currently in use is shown at the top of the display in the standby mode. However, if the active profile is General, only today's date is shown.

24To create a new profile, select Options > Create new, and define the settings.

To customise a profile, select a profile and Options >

Personalise.

To change a profile, select a profile and Options > Activate. The Offline profile prevents your device from accidentally switching on, sending or receiving messages, or using wireless LAN, Bluetooth, or FM radio; it also closes any internet connection that may be in operation when the profile is selected. The Offline profile does not prevent you from establishing a wireless LAN or Bluetooth connection at a later time, or from restarting the FM radio, so comply with any applicable safety requirements when establishing and using these features.

To delete a profile that you created, select Options > Delete profile. You cannot delete the predefined profiles.

Select ringing tones

To set a ringing tone for a profile, select Options > Personalise > Ringing tone. Select a ringing tone from the list, or select Download sounds to open a bookmark folder containing a list of bookmarks for downloading tones using the browser. Any downloaded tones are saved to Gallery.

To play the ringing tone for a selected contact group only, select Options > Personalise > Alert for, and select the desired group. Phone calls coming from outside that group have a silent alert.

To change the message tone, select Options >

Personalise > Message alert tone.

Customise profiles

Select Options > Personalise, and define the following:

Ringing tone — Select a ringing tone from the list, or select Download sounds to open a bookmark folder containing a list of bookmarks for downloading tones using the browser. If you have two alternate phone lines in use, you can specify a ringing tone for each line.

Video call tone — Select a ringing tone for video calls.

Say caller's name — When you select this option and someone from your contacts list calls you, the device sounds a ringing tone that is a combination of the spoken name of the contact and the selected ringing tone.

Ringing type — Select how you want the ringing tone to alert.

Ringing volume — Select the volume level of the ringing tone.

Message alert tone — Select a tone for received text messages.

E-mail alert tone — Select a tone for received e-mail messages.

IM alert tone — Select a tone for received instant messages.

Vibrating alert — Select whether you want the device to vibrate when you receive a call.

Keypad tones — Set the volume level of the device keypad tones.

Warning tones — Set the warning tones on or off.

Alert for — You can set the device to ring only upon calls from phone numbers that belong to a selected contact group. Phone calls coming from outside that group have a silent alert.

Profile name — You can give a name to a new profile or rename an existing profile. The General and Offline profiles cannot be renamed.

Change the display theme

Select Menu > Tools > Themes.

To change the theme used in all applications, select the

General folder.

To change the theme used in the main menu, select the

Menu view folder.

To change the theme for a particular application, select the application-specific folder.

To change the background image for the standby mode, select the Wallpaper folder.

To select an image or write a text for the screen saver, select the Power saver folder.

Download a theme

To download a theme, select General or Menu view > Download themes. Enter the link from which you want to download your theme. Once the theme is downloaded, you can preview, activate, or edit it.

To preview a theme, select Options > Preview.

To start using the selected theme, select Options > Set.

25

3-D ringing tones

Select Menu > Media > 3-D ringing tones.

To enable three-dimensional sound effects for ringing tones, select 3-D ringing tone effects > On. Not all ringing tones support 3–D effects.

To change the 3–D effect that is applied to the ringing tone, select Sound trajectory and the desired effect.

To modify the 3–D effect, select from the following:

Trajectory speed — Select the speed at which sound moves from one direction to another. This setting is not available for all effects.

Reverberation — To adjust the amount of echo, select the desired effect.

Doppler effect — Select On to have the ringing tone sound higher when you are closer to your device, and lower when you are farther away. This setting is not available for all effects.

To listen to the ringing tone with the 3–D effect, select

Options > Play tone.

To adjust the volume of the ringing tone, select Menu >

Tools > Profiles > Options > Personalise > Ringing volume.

Volume control

To adjust the earpiece volume during a phone call or the volume of the media applications, use the volume keys.

26

One-touch keys

With the One-touch keys you can access applications and tasks quickly. Each key has been assigned an application and a task. To change these, select Menu > Tools >

Settings > General > Personalisation > One-touch keys. Your network operator may have assigned applications to the keys, in which case you cannot change them.

1 — Home key

2 — Contacts key

3 — E-mail key

4 — Calendar key

Home key

To access the main menu, press the home key briefly. Press the home key briefly again to access the active standby.

To view the list of active applications, press the home key for a few seconds. When the list is open, press the home key briefly to scroll the list. To open the selected application, press the home key for a few seconds, or press the scroll key. To close the selected application, press the backspace key.

Leaving applications running in the background increases the demand on battery power and reduces the battery life.

Contacts key

To open the Contacts application, press the contacts key briefly.

To create a new contact, press the contacts key for a few seconds.

Calendar key

To open the Calendar application, press the calendar key briefly.

To create a new meeting entry, press the calendar key for a few seconds.

E-mail key

To open your default mailbox, press the e-mail key briefly.

To create a new e-mail message, press the e-mail key for a few seconds.

Multitasking

You can have several applications open at the same time. To switch between active applications, press and hold the home key, scroll to an application, and press the scroll key. To close the selected application, press the backspace key.

Example: When you have an active phone call and want to check your calendar, press the home key to access the menu, and open the Calendar application. The phone call remains active in the background.

Example: When you are writing a message and want to check a web site, press the home key to access the menu, and open the Web application. Select a bookmark or enter the web address manually, and select Go to. To return to your message, press and hold the home key, scroll to the message and press the scroll key.

Memory

There are two types of memory into which you can save data or install applications: device memory and memory card.

Free memory

To see how much memory is currently in use, how much free memory remains, and how much memory is consumed by each data type, select Menu > Options >

Memory details > Phone memory or Memory card.

Tip: To ensure that you have adequate memory, transfer data regularly to a memory card or computer, or use File manager to delete files you no longer need.

After you install applications to a compatible memory

card, installation files (.sis) remain in the device memory. 27 The files may use large amounts of memory and prevent

you from storing other files. To maintain sufficient memory, use Nokia PC Suite to back up installation files to a compatible PC, then use the file manager to remove the installation files from the device memory. If the .sis file is a message attachment, delete the message from the Messaging inbox.

Memory card

Select Menu > Tools > Memory.

If you cannot use a memory card in your device, you may have the wrong type of memory card, the card may not be formatted for your device, or the card has a corrupted file system. Your Nokia device supports the FAT16 and FAT32 file system for memory cards.

MicroSD

This device uses a microSD memory card.

To ensure interoperability, use only compatible microSD cards with this device.

Check the compatibility of a microSD card with its manufacturer or provider. Other memory cards than microSD cards are not compatible with this device. Using an incompatible memory card may damage the memory card as well as the device, and data stored on the incompatible card may be corrupted.

Insert the memory card

Use a memory card to save the memory on your device. You can also back up information from your device to the memory card.

28

The sales package of your device may not include a memory card. Memory cards are available as separate enhancements.

1.With the back of the device facing you, press the release button (1) and slide the back cover off (2).

2.Insert the memory card in the slot with the contact area first. Make sure that the contact area is facing the connectors on the device.

3.Push the card in until it locks into place.

4.Close the back cover.

Use a memory card

To format a memory card for your device, select Options > Format memory card. When a memory card is formatted, all data on the card is lost permanently. Consult your retailer to find out if you must format the memory card before you can use it.

To change the name of the memory card, select Options >

Memory card name.

You can protect a memory card with a password to prevent unauthorised access. To set a password, select Options > Set password. The password can be up to eight characters long and is case-sensitive. The password is stored in your device. You do not need to enter it again while you use the memory card in the same device. If you use the memory card in another device, you are asked for the password.

Not all memory cards support password protection.

To remove the memory card password, select Options > Remove password. When you remove the password, the data on the memory card is not protected against unauthorised use.

To open a locked memory card, select Options > Unlock memory card. Enter the password.

Eject the memory card

Important: Do not remove the memory card in the middle of an operation when the card is being accessed. Removing the card in the middle of an operation may damage the memory card as well as the device, and data stored on the card may be corrupted.

1.Press the power key briefly, and select Remove memory card.

2.Press the release button and slide off the back cover.

3.Press the end of the memory card to release it from the memory card slot.

4.Close the back cover.

Write text

The input methods provided in the device may vary according to different sales markets.

Traditional text input

is shown on the top right of the display when you

are writing text using traditional text input.

and

indicate the selected case.

indicates that the first letter of the sentence is written in

uppercase and all the other letters are automatically

written in lowercase.

indicates the number mode.

To write text with the keypad, press a number key 2-9 repeatedly until the desired character appears. There are more characters available for a number key than are printed on the key. If the next letter is located on the same key as the present one, wait until the cursor appears, and enter the letter.

To insert a number, press and hold the number key.

To switch between the upper and lower case mode and



the number mode, press #.



To erase a character, press the backspace key. Press and



hold the backspace key to erase more than one character.



To access the most common punctuation marks, press the



1 key. Press 1 repeatedly to reach the desired punctuation



mark.



To add special characters, press *. Scroll to the desired



character and press the scroll key.

29



To insert a space, press 0. To move the cursor to the next line, press 0 three times.

To switch between the different character cases, press #.

Predictive text input

1.To activate predictive text input, press # twice quickly. This activates predictive text input for all editors in the device. The indicator is shown on the display.

2.To write the desired word, press 2-9. Press each key only once for one letter.

3.When you have finished writing the word and it is correct, scroll right to confirm it, or press 0 to add a space.

If the word is not correct, press * repeatedly to view the matching words the dictionary has found.

If the ? character is shown after the word, the word you intended to write is not in the dictionary. To add a word to the dictionary, select Spell, enter the word (up to 32 letters) using traditional text input, and select OK. The word is added to the dictionary. When the dictionary is full, the new word replaces the oldest added word.

Write the first half of a compound word; to confirm it, scroll right. Write the last part of the compound word. To complete the compound word, press 0 to add a space.

To switch predictive text input off for all editors in the device, press # twice quickly.

30

Change the writing language

When you are writing text, you can change the writing language. For example, if you press the 6 key repeatedly to reach a specific character, changing the writing language gives you access to characters in a different order.

If you are writing text using a non-Latin alphabet and want to write Latin characters, for example e-mail or web addresses, you may need to change the writing language. To change the writing language, select Options > Writing language, and a writing language that uses Latin characters.

Antennas

Your device has internal antennas.

Note: As with any other radio transmitting device, do not touch the antenna unnecessarily when the device is switched on. Contact with the antenna affects call quality and may cause the device to operate at a higher power level than otherwise needed. To optimize antenna performance and battery life, avoid contact with the antenna area when operating the device.

Loading...
+ 110 hidden pages
