Q U I C K I N S T A L L G U I D E
GXR2 EX
MODULAR MULTIZONE RECEIVER
The IntelliControl® ICS GXR2 EX Modular Multizone Receiver
works |
as |
the main system distribution center for IntelliControl |
|
ICS. |
This |
receiver uses module |
cards from the iPod®, |
Network Integration, AM/FM Export and Legacy Audio |
|||
modules, |
and distributes the audio |
and metadata throughout |
|
6 zones as well as receives controls from our user interfaces such as the iRemote® RF Remote Control with LCD display, the Contact Touch Screen Control Keypad, the Display System Control Keypad with LCD display and the Single Wall Mount Control Keypad.
www.nilesaudio.com
FEATURES AND BENEFITS
•Modular MultiZone Receiver distributes up to six sources to six zones
•Built-in High Current 12-channel Amplifier delivers 55 watts per channel RMS @ 8 ohm
and 85 watts per channel @ 4 ohm to each of six zones
•Integrated Six Slot Card Cage accepts any combination of up to six IntelliControl ICS integration modules
•Plug and Play Integration of TM-AM/FM, IM-AUDIO TM-XM, HD Radio™, TM-Sirius and IM-iPod IntelliControl ICS integration modules
•Reliable “One Touch to Music” operation using IntelliControl ICS Touch Screens, Keypads and remote controls
•Party Mode turns on all your favorite areas from any keypad or remote control
•Global Off turns off all areas from any keypad or remote control
•Tone Controls fine tune bass and treble in each separate zone
•Balance Control fine tunes channel levels in each separate zone
3
FEATURES AND BENEFITS (CONT’D)
•Programmable Turn-On Volume for each zone
•Alarm Clock and Sleep Timer for each zone
•Paging/Doorbell Input enables system wide voice announcements from a phone system or doorbell sounds from the Niles DBI-1
•Zone Linking allows a grouping of zones to be controlled as a single zone. Turn-on, source selection, paging and turn-off all work in unison, yet each zone has independent volume adjustment and muting
•Home Theater Integration Ports enable audio and video source components shared with the home theater system to be turned on, controlled via IR and turned off as needed
•Selectable Fixed/Variable Zone Preamp Outputs with 12 volt triggers for external amplifier applications
•Source Matching Gain Control ensures changing sources doesn’t require changing volume control settings
•Removable Speaker Connectors hold up to 12-gauge speaker wire
•Expandable Up To 30 Zones with additional GXR2 EXs
4
