WALL MOUNT PD02W T M L, PD02W T L L & PD03W T M P
UNIVERSAL MEDIUM & LARGE TILT WALL MOUNT
Solid universal wall mount with tilt function for NEC Large
Format Displays from 32” to 65” available for either landscape
or portrait orientation.
This wall mount is not only the perfect mount for single display installations.
Together with specic connectors, this wall mount includes a variety of
features to make multi display installations fast and easy. It is therefore the
ideal solution for quick serve restaurants and for airport ight information
boards. In addition optional video conference accessories make it the
perfect choice for any kind of meeting room situation.
PD02W T M L - Medium Landscape
PD03W T M P- Medium Portrait
Delivering Genuine Benefits
Provides effortless tilting by using the center of gravity to balance
the screen
Post-installation lateral shift allows displays to slide apart and
back together to simplify installation and maintenance
Hear an audible click when the displays safely engage with the
mount
Provides low-profile, fingertip tilt
Built-in cable stand provides easy access under the screen
Optional Connector Kits easily connect mounts to create multimonitor menu board configurations
Optional accessories (Video Conference Shelf, Component
Shelf, etc.) make it the perfect solution for video conferencing
applications
PD02W T L L - Large Landscape
TECHNICAL DRAWINGS
PD02W T M L
2.07
52.5
25.75
654.1
25.00
635.0
2.00
50.9
PD03W T M P
3.23
82.1
22.75
577.9
22.00
558.8
6.00
152.4
1.25
31.8
24.50
622.3
7.00
177.8
3.05
77.5
2.61
66.2
1.63
41.3
RAILS CAN BE SLID LEFT OR RIGHT
FOR OFFSET
20.88
530.4
1.94
49.2
209.9
1.73
43.8
0.75
12°
19.2
16.50
7.00
177.8
14.00
355.6
15.00
381.0
0.34
8.7
1.00
25.4
17.38
8.26
441.3
13.50
342.9
419.1
7.00
177.8
12°
3.52
89.5
7.00
177.8
0.38
9.5
0.49
TYP.
12.5
0.34
8.7
0.49
TYP.
12.5
7.87
200.0
15.75
400.0
3.44
TYP.
87.5
0.34
8.7
0.44
11.2
11.81
300.0
23.62
600.0
1.13
28.7
PD02W T L L
2.00
50.9
34.00
863.6
34.75
882.7
37.00
2.05
52.0
15.75
400.0
939.9
RAILS CAN BE SLID LEFT OR RIGHT FOR OFFSET
16.00
406.3
MINIMUM UPRIGHT SPACING
2.07
52.5
6.00
152.4
2.64
67.0
1.63
41.3
1.25
31.8
0.34
8.7
1.00
25.4
RAILS CAN BE SLID LEFT OR RIGHT
FOR OFFSET
15.00
381.0
7.00
14.00
355.6
177.8
0.75
19.2
16.50
419.1
12°
7.00
177.8
1.48
TYP.
37.5
0.34
8.7
0.38
9.5
7.87
200.0
15.75
400.0
3.44
TYP.
87.5
0.34
8.7
CONNECTOR KITS AVAILABLE TO MAKE MENU BOARD INSTALLATIONS QUICK AND EASY*
NEC MULTISYNC® V423, X401S, P403
CONFIGURATIONS
2x1 3x1 4x1 5x1 2x1 3x1 4x1 5x1
Mount PD02W T M L PD02W T M L PD02W T M L PD02W T M L PD03W T M P PD03W T M P PD03W T M P PD03W T M P
Mount QTY 2 3 4 5 2 3 4 5
Connector Kit CK MB L CK MB L CK MB L CK MB L CK MB L CK MB L CK MB L CK MB L
Connector Kit QTY 1 2 3 4 1 2 3 4
LANDSCAPE PORTRAIT
2
This document is © Copyright 2013 NEC Display Solutions Europe GmbH. All rights are reserved in favour of their respective owners. The document, or parts
thereof, should not be copied, adapted, redistributed, or otherwise used without the prior written permission of NEC Display Solutions Europe GmbH. This
document is provided “as is” without warranty of any kind whatsoever, either express or implied. Errors and omissions are excepted.
NEC Display Solutions Europe GmbH may make changes, revisions or improvements in, or discontinue the supply of any product described or referenced in
this document at any time without notice. 30 April 2015
WALL MOUNT PD02W T M L, PD02W T L L & PD03W T M P
UNIVERSAL MEDIUM & LARGE TILT WALL MOUNT
NEC MULTISYNC® V463, X462S, P463
CONFIGURATIONS
Mount PD02W T M L PD02W T M L PD02W T M L PD02W T M L PD03W T M P PD03W T M P PD03W T M P PD03W T M P
Mount QTY 2 3 4 5 2 3 4 5
Connector Kit CK MB L CK MB L CK MB L CK MB L CK MB L CK MB L CK MB L CK MB L
Connector Kit QTY 1 2 3 4 1 2 3 4
2x1 3x1 4x1 5x1 2x1 3x1 4x1 5x1
NEC MULTISYNC® V552, X552S, P553
CONFIGURATIONS
Mount PD02W T L L PD02W T L L PD02W T L L PD02W T L L PD03W T M P PD03W T M P PD03W T M P PD03W T M P
Mount QTY 2 3 4 5 2 3 4 5
Connector Kit CK MB M CK MB M CK MB M CK MB M CK MB M CK MB M CK MB M CK MB M
Connector Kit QTY 1 2 3 4 1 2 3 4
* If you need the configurations for other NEC display models, please contact NEC.
2x1 3x1 4x1 5x1 2x1 3x1 4x1 5x1
LANDSCAPE PORTRAIT
LANDSCAPE PORTRAIT
TECHNICAL SPECIFICATIONS
CONNECTOR KITS ORDER CODES
CK MB S 100013092
CK MB M 100013093
CK MB L 100013094
PD02W T M L PD02W T L L PD03W T M P
ORDER CODES 100014007 100014008 100014010
RECOMMENDED DISPLAY SIZES 32” to 46” 40” to 65” 32” to 65”
MIN. DEPTH 51.0 mm 51.0 mm 81.0 mm
TILT FUNCTION +2°, -12° +2°, -12° +5°, -12°
LATERAL SHIFT 327.0 mm 441.0 mm 265.0 mm
CONFIGURATION Unlimited number of displays in a row for Menu Board installation
ORIENTATION Landscape & Portrait
MAX. WEIGHT CAPACITY 56.7 kg * 90.7 kg * 56.7 kg *
WEIGHT OF MOUNT 7.0 kg 8.1 kg 11.2 kg
PACKAGE DIMENSIONS (H X W X D) 790 x 470 x 80 mm 940 x 470 x 80 mm 700 x 680 x 80 mm
SUPPORTED DISPLAYS All NEC Large Format Displays from 32” to 65”
CERTIFICATIONS UL Listed
WARRANTY 5 years
For additional pictures and Solutions overview,
Visit www.nec-display-solutions.com for details.
* Please consider the overall weight of the complete construction. It is the installers responsibility to make certain the structure to which the mount
is being attached is capable of supporting all equipment. For this NEC does not take any responsibility. Please consult your local vendor if advise is
needed.
