MXR WA44 User guide

Wylde Audio Overdrive

WA44

Celebrate the 20th anniversary of the explosive
collaboration between Dunlop and Zakk Wylde with

®

the MXR Wylde Audio Overdrive. Custom built for

Zakk’s loud, tough, and relentless ris and leads, this

muscular stomp box will transform your amp into
a heavy, chunky crunch machine.

jimdunlop.com/wa44

External Controls

3

2

4

1

1 FOOTSWITCH toggles eect on/bypass (red LED indicates on)

2 OUTPUT knob adjusts overall eect volume

3 TONE knob adjusts overdrive EQ

4 GAIN knob adjusts overdrive intensity

WA44 | MXR® Wylde Audio Overdrive 2

Basic Operation

Power Directions

The MXR® Wylde Audio Overdrive is powered by a single

9-volt battery (remove bottom plate to install), a 9-volt AC
adapter such as the Dunlop ECB003, or an MXR® Brick™

Series power supply.

1. Run a cable from your guitar to the WA44’s INPUT jack

and run another cable from the WA44’s OUTPUT jack to your

amplier.

2. Start with all knobs at 12 o’clock. Turn the eect on by

depressing the footswitch.

3. Rotate OUTPUT knob clockwise to increase eect volume

or counterclockwise to decrease it.

4. Rotate TONE knob clockwise for a brighter tone or

counterclockwise for a warmer tone.

5. Rotate GAIN knob clockwise to increase overdrive

intensity or counterclockwise to decrease it.

WA44 | MXR® Wylde Audio Overdrive 3

Specications

Input Impedance

Output Impedance

Nominal Input

Noise Floor*

Bypass

Current Draw 2.2 mA

Voltage Requirements

* A-weighted

1 MΩ

7.5 kΩ

-22 dBV

-88 dBV

Hardwire

9 volts DC

WA44 | MXR® Wylde Audio Overdrive 4
