É1905844703dËÍ

1905844703

COMAND

Supplement

Order no. P190 0235 13 Part no. 190 584 47 03 Edition B-2018

COMAND Supplement

Mercedes-Benz

Symbols

In this Operator's Manual you will find the following symbols:

WARNING

Warning notes make you aware of dangers which could pose a threat to your health or life, or to the health and life of others.

Environmental note



Environmental notes provide you with information on environmentally aware actions or disposal.

Notes on material damage alert you to dan-

gers that could lead to damage to your vehicle.

Practical tips or further information that

could be helpful to you.

(Y page)

Dis‐ play

This symbol indicates an instruction that must be followed.

Several of these symbols in succession indicate an instruction with several steps.

This symbol tells you where you can find more information about a topic.

This text indicates a message in the multimedia display.



2005 The FreeType Project

Publication details

Internet

Further information about Mercedes-Benz vehicles and about Daimler AG can be found on the following websites:

http://www.mbusa.com (USA only) http://www.mercedes-benz.ca (Canada only)

Editorial office

You are welcome to forward any queries or suggestions you may have regarding this Operator's Manual to the technical documentation team at the following address:

Daimler AG, HPC: CAC, Customer Service, 70546 Stuttgart, Germany



Daimler AG: Not to be reprinted, translated or otherwise reproduced, in whole or in part, without written permission from Daimler AG.

Vehicle manufacturer

Daimler AG Mercedesstrae 137 70327 Stuttgart Germany

As at 10.08.2016

Welcome to the world of Mercedes-Benz

First of all, familiarize yourself with your multimedia system. Read these operating instructions, particularly the safety and warning notes, before you drive off.

This will help you to obtain the maximum pleasure from your multimedia system and avoid endangering yourself and others.

The equipment level and functions of your multimedia system may differ depending on:

Model

Order

Country specification

Availability

Mercedes-Benz therefore reserves the right to introduce changes in the following areas:

design

equipment

technical features

The equipment in your vehicle may therefore differ from that shown in the descriptions and illustrations.

Consult an authorized Mercedes-Benz Center if you have further questions.

The Operator's Manual and all supplements are integral parts of the vehicle. You should always keep it in the vehicle and pass it on to the new owner if you sell the vehicle.

The technical documentation team at Daimler AG wishes you safe and pleasant motoring.

Mercedes-Benz USA, LLC Mercedes-Benz Canada, Inc. A Daimler Company

1905844703

É1905844703dËÍ

Contents

Index ....................................................... 4

Introduction ......................................... 14

Operating safety .................................... 14

Data stored in the vehicle ...................... 15

Information on copyright .......................16

Your multimedia system equipment ...... 17

Overview and operation ..................... 18

Overview ................................................ 18

Touchpad ...............................................21

Basic functions ...................................... 26

Character entry (telephony) ................... 28

Character entry (navigation) .................. 29

Favorites ................................................ 31

System settings .................................. 33

Your multimedia system equipment ...... 33

Important safety notes .......................... 33

Display settings ..................................... 33

Time settings .........................................34

Text reader settings ...............................35

Voice Control System settings ............... 36

Wi-Fi ...................................................... 36

Bluetooth

Automatic volume adjustment ............... 38

Setting the system language .................38

Calling up and editing the Favorites

function .................................................39

Importing/exporting data ...................... 39

Reset function ....................................... 40

Vehicle functions ................................ 42

Your multimedia system equipment ...... 42

Important safety notes .......................... 42

Vehicle settings .....................................42

Rear view camera .................................. 43

Climate control settings ........................ 44

DYNAMIC SELECT .................................. 46

Navigation ........................................... 48

Your multimedia system equipment ...... 48

Introduction ...........................................48

Basic settings ........................................ 50

settings ............................... 38

Destination entry ................................... 52

Personal POIs and routes ...................... 63

Route guidance ...................................... 67

Real-time traffic reports ......................... 74

Storing destinations ............................... 77

Map functions ........................................ 79

Navigation functions .............................. 85

Problems with the navigation system .... 86

Telephone ............................................ 89

Your multimedia system equipment ...... 89

Important safety notes .......................... 89

General notes ........................................ 89

Telephone menu .................................... 90

Connecting/disconnecting a mobile

phone .................................................... 90

Reception and transmission volume ...... 94

Using the telephone .............................. 95

Mobile phone voice recognition ............. 99

Phone book ........................................... 99

Address book ...................................... 102

Call lists ............................................... 108

Speed dial lists .................................... 110

Messages ............................................ 111

Online and Internet functions .......... 118

Your multimedia system equipment .... 118

Important safety notes ........................ 118

General notes ...................................... 118

Conditions for access .......................... 118

Setting up an Internet connection

(Canada) .............................................. 119

Establishing/ending the connection .... 122

Mercedes-Benz Apps ........................... 123

Door-to-door navigation ....................... 123

Web browser .......................................124

Radio .................................................. 128

Your multimedia system equipment .... 128

Switching on the radio ......................... 128

Overview .............................................. 128

Setting the waveband .......................... 129

Station ................................................. 129

Tagging music tracks ........................... 130

Displaying station information ............. 131

Calling up sound settings .................... 131

Displaying information .........................131

Satellite radio ...................................... 131

Media ................................................. 136

Your multimedia system equipment .... 136

Activating media mode ........................ 136

Audio/video mode ............................... 137

Media search ....................................... 142

Media Register ....................................143

Bluetooth

audio mode ....................... 146

Operation with the Media Interface ..... 150

Video DVD mode ................................. 152

Picture viewer ...................................... 156

Sound ................................................. 158

Your multimedia system equipment .... 158

Sound settings ..................................... 158

Burmester Burmester

surround sound system .... 158

high-end surround sound

system ................................................. 159

SIRIUS Weather ................................ 162

Your multimedia system equipment .... 162

Weather forecasts ............................... 162

Contents

Index

Access data of the mobile phone network provider

Deleting .........................................121

Editing ...........................................121

Making entries ............................... 120

Selecting ........................................ 120

Acoustic locking confirmation

Activating/deactivating

(COMAND) ....................................... 42

Activating media mode

General notes ................................ 136

Switching on automatically ............ 136

Adding bookmarks ............................ 125

Address

Entering (navigation) ........................ 53

Address book

Adding a new contact .................... 103

Adding information to a contact .... 104

Automatically importing contacts

from the phone .............................. 106

Browsing ........................................ 102

Calling up ....................................... 102

Changing the category of an entry .. 105 Changing the display and sorting

criteria for contacts ....................... 106

Deleting contacts ........................... 106

Deleting imported contacts ........... 108

Displaying contact details .............. 103

Editing a contact ............................ 105

Entering characters ......................... 28

Importing contacts ........................ 107

Introduction ................................... 102

Making a call ................................. 104

Receiving vCards ........................... 107

Saving a contact ............................ 106

Searching for a contact ................. 103

Sending e-mails .............................104

Sending text messages .................. 104

Starting route guidance ................. 104

Storing a phone number as a

speed dial number ......................... 105

Voice tags ...................................... 105

Address entry menu

Navigation ........................................ 52

Adjusting the sound settings

Balance .......................................... 158

Adjusting the volume

COMAND ......................................... 26

Media source ................................... 26

Traffic announcements .................... 27

ve Route ................................ 72

ternati

Al Asterisk key

see Favorites button

Audio CD/DVD and MP3 mode

Bluetooth

audio mode ................. 146

Connecting USB devices ................ 139

Data media, file systems, formats .. 137

Gracenote

Media Database ......... 141

Inserting/removing a CD/DVD

(single drive) .................................. 139

Media interface .............................. 150

Media Register ............................... 143

Media search ................................. 142

Overview menu .............................. 138

Playback options ........................... 140

SD card .......................................... 139

Search menu ................................. 141

Selecting a track ............................ 141

Automatic folding mirror function

Activating/deactivating

(COMAND) ....................................... 42

Automatic locking feature

Activating/deactivating

(COMAND) ....................................... 43

Automatic time

Switching on/off .............................. 34

Automatic volume adjustment

General information ......................... 38

Switching on/off .............................. 38

Avoiding an area .................................. 82

Back button ......................................... 20

Bluetooth

Activating audio mode ................... 147

Activating/deactivating ................... 38

Audio device mode and searching

for mobile phones .......................... 150

Basic display (audio mode) ............ 147

Connecting a different mobile

phone .............................................. 94

Connecting audio devices .............. 147

Index

De-authorizing (de-registering) a

device ............................................ 150

Device list ...................................... 147

Displaying connection details .......... 94

Displaying details ........................... 148

Entering the passcode ..................... 92

External authorization (audio

device) ........................................... 148

General information ......................... 38

Increasing the volume using

COMAND ....................................... 149

Interface .......................................... 89

Introduction ..................................... 89

Playback options ........................... 149

Preparation .................................... 146

Reconnecting an audio device ....... 150

Searching for a mobile phone .......... 92

Selecting a playback option ........... 149

Selecting a track ............................ 149

Starting and stopping playback ..... 148

Starting playback if the Blue-

audio device has been

tooth

stopped ......................................... 149

Telephony ........................................ 90

Telephony notes .............................. 89

Burmester

high-end surround

sound system

Balance .......................................... 160

Calling up the sound menu ............ 160

Equalizer ........................................ 160

Equipment ..................................... 159

Sound profile ................................. 161

VIP & BAL selection ....................... 161

Burmester

surround sound sys-

tem

Balance .......................................... 159

Calling up the sound menu ............ 159

Equalizer ........................................ 159

Equipment ..................................... 158

Surround sound ............................. 159

Buttons and controller ........................ 20

Call lists

Displaying details ........................... 108

Opening and selecting an entry ..... 108

Saving an entry in the address

book .............................................. 109

Calling up the compass display ......... 85

Car pool lanes ...................................... 51

Category list (music search) ............ 142

Inserting ........................................ 139

Notes on discs ............................... 138

Characters

Entering (navigation) ........................ 29

Climate control

Calling up climate control

(COMAND) ....................................... 45

Calling up the climate control bar

(COMAND) ....................................... 44

COMAND ......................................... 44

Cooling with air dehumidification

(COMAND) ....................................... 45

Overview .......................................... 44

Setting the air distribution

(COMAND) ....................................... 44

Setting the airflow (COMAND) ......... 45

Setting the temperature

(COMAND) ....................................... 44

Switching on/off (COMAND) ........... 45

Climate control bar

Calling up ......................................... 44

COMAND

Basic display menu .......................... 27

Basic functions ................................ 26

Controller ......................................... 20

Display ............................................. 19

Selecting operating mode ................ 28

Settings ......................................... 126

Switching on/off .............................. 26

COMAND display

Cleaning instructions ....................... 19

Setting ............................................. 33

Contacts

Deleting ......................................... 106

Importing ....................................... 107

Controller ............................................. 20

Copying music files

see Media Register

Copying/renaming/deleting files

see Media Register

Index

Date format, setting ............................ 35

Day design, setting .............................33

Delayed switch-off time

Setting (COMAND) ...........................43

Deleting

Call lists ......................................... 110

Destination (navigation)

Editing a previous destination .......... 79

Entering a destination by address .... 52

Entering a destination using the

map ................................................. 60

Entering a point of interest .............. 57

Entering using geo-coordinates ....... 63

Entering using Mercedes-Benz

Apps ................................................ 62

General notes .................................. 52

Keyword search ............................... 55

Personal POIs and routes ................. 63

Saving .............................................. 77

Saving to the SD card. ..................... 78

Selecting an address book con-

tact as a destination ........................ 57

Selecting from the list of last des-

tinations ........................................... 56

Storing in the address book. ............ 77

Dialing a number (telephone) ............. 95

Display

Selecting the design ........................ 33

Switching on/off .............................. 33

Display COMAND

see COMAND display

Displaying current position (navi-

gation) .................................................. 72

Displaying the artist and track

Radio ............................................. 131

Distance

see Route (navigation)

DVD

Notes on discs ............................... 138

see Audio CD/DVD and MP3 mode

DVD video

Operating DVD functions ............... 156

Showing/hiding DVD functions ..... 155

DYNAMIC SELECT

Configuration via the DYNAMIC

SELECT controller ............................ 46

Configuring individual drive pro-

gram ................................................ 46

ne d

Displaying engi

Displaying vehicle data .................... 46

Setting options ................................ 47

ata ..................... 46

E-mail

Answering ...................................... 115

Calling up the settings menu ......... 111

Changing the name of the e-mail

account .......................................... 112

Configuring an e-mail account ....... 112

Configuring the e-mails displayed .. 112

Deactivating the e-mail function .... 112

Deleting ......................................... 117

Displaying details ........................... 114

Downloading e-mails manually ...... 112

Editing text templates .................... 116

Forwarding ..................................... 115

Inbox .............................................. 113

Reading .......................................... 113

Saving the sender in the address

book .............................................. 117

Settings ......................................... 111

Storing the sender as a new entry

in the address book ....................... 117

Unread messages .......................... 113

Using a phone number in the text .. 116

Using text templates ...................... 116

Writing ........................................... 115

EASY-ENTRY/EXIT feature

Activating/deactivating

(COMAND) ....................................... 42

Entering the city .................................. 53

Exterior mirror

Activating/deactivating the automatic folding mirror function

(COMAND) ....................................... 42

Factory setting (reset function) ......... 40

Favorites

Adding ............................................. 31

Adding (predefined) ......................... 31

Adding (your own) ............................ 32

Deleting ........................................... 32

Index

Displaying and calling up ................. 31

Moving ............................................. 32

Overview .......................................... 31

Renaming ......................................... 32

Favorites (Internet) ........................... 127

Favorites button .................................. 39

GPS reception ...................................... 48

Gracenote

Media Database ............ 141

Handwriting recognition

Switching text reader function

on/off .............................................. 25

Touchpad ......................................... 24

Heading up (navigation) ..................... 80

Home

see Home address

Home address

Entering and saving ......................... 53

Importing/exporting data .................. 39

Incident (traffic report) ....................... 74

Interior lighting

Setting the delayed switch-off

time (COMAND) ............................... 43

Intermediate destinations

Entering ........................................... 60

Internet

Conditions for access .................... 118

Creating favorites .......................... 127

Entering the URL ............................ 124

Favorites manager ......................... 127

Favorites menu .............................. 127

Menu functions .............................. 124

Options menu ................................ 125

Selecting/setting access data ....... 119

Setting automatic disconnection

of the Internet connection ............. 122

Setting up an Internet connection .. 119

Keyword search (navigation)

Entering keywords ........................... 55

Online search ................................... 56

Selecting search options ................. 56

Selecting search results ................... 55

Lane recommendations

Explanation ...................................... 69

Presentation .................................... 69

Lighting

Setting the delayed switch-off

time (COMAND) ............................... 43

Switching the locator lighting on/

off .................................................... 43

List of access data

New provider ................................. 120

List of mobile phone network providers

With the selected provider ............. 120

Locator lighting

Setting (COMAND) ........................... 43

Locking confirmation

see Acoustic locking confirmation

Making a call

Using speed dial .............................. 96

Using the call lists ............................ 96

Using the phone book ...................... 96

Map (navigation)

3D map ............................................ 80

Adjusting the scale .......................... 79

Building images ................................ 82

Displaying the next intersection ...... 81

Elevation modeling ........................... 82

Map heading up ............................... 80

Map settings .................................... 79

Moving ............................................. 49

North orientation ............................. 80

Notes ............................................... 79

Rotating the 3D map ........................ 82

Selecting POI symbols on the

map ................................................. 80

Index

Selecting text information on the

map ................................................. 80

Showing the map version ................. 81

Switching highway information

on/off .............................................. 81

Updating .......................................... 84

Map functions ...................................... 79

Media Interface

Basic display .................................. 151

Playback options ........................... 152

Search ........................................... 151

Selecting a music file ..................... 151

Supported devices ......................... 151

Supported file formats ................... 151

Switching to Media Interface ......... 151

Video function ............................... 152

Media mode

Bluetooth

Audio ........................... 146

Connections for external media

sources .......................................... 136

Switching on .................................. 136

Media Register

Basic display .................................. 144

Calling up memory space informa-

tion ................................................ 145

Copying files .................................. 144

Deleting all files ............................. 145

Renaming/deleting files ................ 145

Selecting a playback mode ............ 146

Switching on .................................. 143

Media search

By folder ........................................ 142

Category list .................................. 142

Current track list ............................ 142

General notes ................................ 142

Keyword search ............................. 143

Music genres ................................. 143

Selecting by cover ......................... 143

Starting the media search .............. 142

Mercedes-Benz Apps

Calling up ....................................... 123

Mercedes-Benz Companion

Door-to-door navigation ................. 123

Microphone, switching on/off ........... 97

Mobile phone

Authorizing ....................................... 92

Connecting (Bluetooth

inter-

face) ................................................ 90

Connecting another mobile

phone .............................................. 94

De-authorizing ................................. 94

Displaying Bluetooth

connection

details .............................................. 94

Enabling for Internet access .......... 119

Monitor

see COMAND display

MP3

Stop and playback function ........... 141

see Audio CD/DVD and

MP3 mo

Multimedia system

see Display

Music

see Audio CD/DVD and MP3 mode

MUSIC REGISTER

General notes ................................ 143

My address

Saving .............................................. 53

Navigation

Adjusting the volume of the navi-

gation announcements .................... 27

Alternative route .............................. 72

Avoiding an area .............................. 82

Basic settings .................................. 50

Blocking a route section affected

by a traffic jam ................................. 73

Calling up the compass display ........ 85

Calling up the menu ......................... 85

Canceling/continuing route guid-

ance ................................................. 71

Displaying current position .............. 72

Drive Information ............................. 86

Entering a destination ...................... 52

Entering a destination using geo-

coordinates ...................................... 63

Entering a destination using

Mercedes-Benz Apps ....................... 62

Entering a destination using the

map ................................................. 60

Entering a point of interest .............. 57

Index

Entering characters (character

bar) .................................................. 29

Entering intermediate destina-

tions .................................................60

Entry restriction ............................... 48

First use ........................................... 48

General notes .................................. 48

GPS reception .................................. 48

Important safety notes .................... 48

Info on navigation ............................ 86

Lane recommendation ..................... 69

Map functions .................................. 79

Moving the map ............................... 49

Off-road/Off-map (off-road desti-

nation) ............................................. 73

Online map display .......................... 85

Personal POIs and routes ................. 63

Problems ......................................... 86

Reading out traffic reports ............... 76

Repeating announcements .............. 70

Route flight ...................................... 86

Route information ............................ 71

Saving destinations .......................... 77

Saving home address ....................... 53

Selecting a destination from the

list of last destinations ..................... 56

Setting route options (avoiding: highways, toll roads, tunnels, fer-

ries) ................................................. 50

Setting the announcements vol-

ume ................................................. 70

Setting the route type (short route, fast route, dynamic route or

economic route) ............................... 50

Showing/hiding the menu ............... 49

Starting route calculation ................ 54

Switching announcements

on/off .............................................. 71

Switching to ..................................... 49

Traffic jam function .......................... 73

Updating the digital map .................. 84

Navigation announcements

Switching off .................................... 27

North orientation (navigation) ........... 80

Off-road ................................................ 73

Online and Internet functions

Calling up ....................................... 122

Calling up the device list ................ 121

Enabling a mobile phone for Inter-

net access ..................................... 119

Ending the connection ................... 123

Establishing a connection .............. 122

Managing all Internet devices ........ 122

Manually setting the access data of the mobile phone network pro-

vider .............................................. 120

Mercedes-Benz Apps ..................... 123

Selecting the access data of the

mobile phone network provider ..... 120

Setting automatic disconnection

of the Internet connection ............. 122

Setting up an Internet connection .. 119

Web browser .................................. 124

Own address (navigation)

see Home address

Pause function

Video DVD ..................................... 156

Personal POIs and routes

Alert when approaching (personal

POI) .................................................. 64

Editing .............................................. 66

General notes .................................. 63

Importing via Mercedes-Benz

Apps ................................................ 65

Recording the route ......................... 66

Saving .............................................. 64

Selecting .......................................... 65

Selecting and editing ....................... 65

Settings for personal POIs ............... 63

Phone book

Adding a new contact .................... 101

Adding information to a contact .... 101

Calling up ......................................... 99

Deleting a contact ......................... 102

Displaying the details of an entry ... 100

Entering characters ......................... 28

Saving a contact ............................ 101

Searching for a contact ................. 100

Symbol overview .............................. 99

Index

Phone call

Dialing ..............................................95

Picture viewer

Changing view ...............................157

Displaying pictures ........................ 156

Exiting the picture viewer .............. 157

General notes ................................ 156

Starting a slide show ..................... 157

PIN protection

Activating/deactivating ................... 39

POI (navigation)

Calling up the menu ......................... 57

Category .......................................... 57

Defining the position for the POI

search .............................................. 58

Entering ...........................................57

Rotating 3D POI ...............................60

Selecting .......................................... 59

Previous destinations (navigation) .... 79

Radio

Activating/deactivating the sta-

tion presets display ....................... 130

Deleting a station .......................... 130

Displaying information ................... 131

Displaying station information ....... 131

Displaying the artist and track ....... 131

Moving stations ............................. 130

Overview ........................................ 128

Setting the waveband .................... 129

Sound settings (balance, bass,

treble) ............................................ 131

Station list ..................................... 130

Storing stations ............................. 130

Switching on .................................. 128

Tagging music tracks (downloading/purchasing tracks from the iTunes Store

Radio station

Storing ........................................... 130

Read-aloud function

Automatic ........................................ 77

Read-aloud function for e-mails ....... 114

Reading out

Traffic reports on the route .............. 76

Real-time traffic reports ..................... 74

) ............................... 130

Rear view camera

Displaying the image ........................ 43

Switching on/off (COMAND) ........... 44

Receiving vCards ............................... 107

Redialing (telephone) .......................... 96

Reducing the volume

Switching announcements on/off

(COMAND) ....................................... 51

Reserve fuel level

Switching announcements on/off

(COMAND) ....................................... 51

Resetting (factory settings) ............... 40

Road map

see Map (navigation)

Route (navigation)

Selecting an alternative route .......... 72

Setting route options (avoiding: highways, toll roads, tunnels, fer-

ries) ................................................. 50

Setting the route type (short route, fast route, dynamic route or

economic route) ............................... 50

Starting calculation .......................... 54

Route guidance

Canceling/continuing ...................... 71

Continue .......................................... 71

Freeway information ........................ 69

General notes .................................. 67

Lane recommendations ................... 69

Off-road ........................................... 73

Traffic reports .................................. 74

Safety notes

Audio CD/DVD and MP3 mode ..... 137

Using the telephone ......................... 89

Satellite radio

Displaying information ................... 135

Overview ........................................ 132

Presets menu view ......................... 133

Registering .................................... 132

Switching to ................................... 132

SatRadio

Channel list updates ...................... 135

Memory functions .......................... 133

Music and sports alerts ................. 134

Notes ............................................. 131

Index

Selecting a category ...................... 132

Selecting a channel ....................... 133

Tagging music tracks ..................... 134

SD card

Inserting ........................................ 139

Inserting/removing ........................ 139

Removing ....................................... 139

Searching for a gas station

When the fuel level is low ................ 62

Seat-belt adjustment function

Activating/deactivating

(COMAND) ....................................... 42

Selecting stations

Radio ............................................. 129

Sending DTMF tones ........................... 97

Setting access data

Online and Internet ........................ 120

Setting the language

COMAND ......................................... 39

Setting the night design ..................... 33

Setting the text reader speed ............ 35

Setting the volume

Telephone calls ................................ 27

Settings

Sound settings ............................... 158

Short message

see Text messages (SMS)

SIRIUS weather display

5-day forecast ................................ 162

Daily forecast ................................. 162

Detail information .......................... 163

Information chart ........................... 162

Selecting a location for the

weather forecast ............................ 163

Switching on/off ........................... 162

Weather map ................................. 165

SMS

Unread messages .......................... 113

Sound

Switching on/off .............................. 27

Sound settings

Calling up the sound menu ............ 158

Equalizer ........................................ 158

Sound system

see Burmester

surround sound system

Speed dial

Deleting ......................................... 110

Setting up ...................................... 110

State/province

Selecting .......................................... 53

Station presets (radio)

Deleting marked stations ............... 130

Stop function

Video DVD ..................................... 156

Storing stations

Radio ............................................. 130

Street name announcements

Switching on/off (COMAND) ........... 51

Switching between summer time

and standard time ............................... 34

Switching on media mode

Via the device list .......................... 136

functio

Via the main

n bar ............... 136

System settings

Automatic volume adjustment ......... 38

Bluetooth

....................................... 38

Date ................................................. 34

Importing/exporting data ................ 39

Language ......................................... 38

Text reader speed ............................ 35

Time ................................................. 34

Time zone ........................................ 34

Voice Control System ...................... 36

Telephone

Accepting a call (COMAND) ............. 95

Adding a call .................................... 97

Adjusting the volume for calls .......... 27

Authorizing a mobile phone (con-

necting) ............................................ 92

Call lists ......................................... 108

Call waiting ...................................... 98

Calling up the telephone menu ........ 90

Calls with several participants ......... 97

Conference calls .............................. 98

Connecting a mobile phone (gen-

eral information) .............................. 90

De-authorizing (disconnecting) a

mobile phone ................................... 94

Deleting a speed dial preset .......... 110

Deleting messages ........................ 117

Displaying Bluetooth

connection

details .............................................. 94

Index

Downloading messages manually .. 112

E-mail ............................................. 111

E-mail requirements ....................... 111

E-mail settings ............................... 111

Ending an active call ........................ 99

Entering a number ........................... 95

Entering phone numbers .................. 95

Establishing the connection from

the mobile phone ............................. 93

Function restrictions ........................ 90

Functions available during a call ...... 96

General notes .................................. 89

Incoming call during an existing

call ................................................... 98

Making a call .................................... 95

Message conditions ....................... 111

Message settings ........................... 111

Operating options ............................ 90

Phone book ...................................... 99

Reading messages ......................... 113

Reception and transmission vol-

ume ................................................. 94

Reconnecting a mobile phone

automatically ................................... 94

Rejecting a call (COMAND) .............. 95

Safety notes ..................................... 89

Sending DTMF tones ........................ 97

Setting up a speed dial .................. 110

Switching between calls (call wait-

ing) .................................................. 97

Switching between mobile

phones ............................................. 94

Switching the microphone on/off .... 97

Telephone menu overview ............... 90

Text message conditions ............... 111

Text message settings ................... 111

Text messages (SMS) .................... 111

Toggling ........................................... 97

Using the telephone ......................... 95

Writing e-mails ............................... 115

Writing text messages ................... 114

Telephone number

Entering ........................................... 95

Text messages (SMS)

Calling the sender .......................... 116

Calling up the settings menu ......... 111

Configuring the text messages

displayed ....................................... 111

Deleting ......................................... 117

Displaying details ........................... 114

Downloading manually ................... 112

Editing text templates .................... 116

Inbox .............................................. 113

Reading .......................................... 113

alo

Reading

Settings ......................................... 111

Storing sender in address book ..... 117

Storing the sender as a new

address book entry ........................ 116

Using a phone number in the text .. 116

Using text templates ...................... 116

Writing ........................................... 114

Time

Setting ............................................. 35

Setting the format ............................ 35

Setting the time ............................... 35

Setting the time zone ....................... 34

Setting the time/date format .......... 35

Switching automatic time on/off ..... 34

Touchpad

Calling up quick access for audio .... 23

Changing the input language for

handwriting recognition ................... 25

Changing the station/music

track ................................................ 26

Character suggestions ..................... 25

Deleting characters ......................... 25

Entering a space .............................. 25

Entering characters ......................... 25

Gesture control ................................ 22

Handwriting recognition ................... 24

Operating the touchpad ................... 22

Overview .......................................... 21

Quick access for Audio .................... 26

Selecting a menu item ..................... 22

Switching ......................................... 22

Switching input line ......................... 25

Track

Selecting (CD, DVD, MP3) .............. 141

Traffic reports

Calling up a list ................................ 74

Real-time traffic report .................... 75

ud ................................ 114

Updating the digital map .................... 84

Index

USB audio mode

Selecting a track ............................ 141

USB devices

Connecting to the Media Inter-

face ...............................................139

see Audio CD/DVD and MP3 mode

Vehicle

Data acquisition ............................... 15

Vehicle settings

Calling up ......................................... 42

Video

see Video DVD

Video DVD

Control option ................................ 153

DVD menu ..................................... 155

DVD's control menu ......................155

Full-screen mode ........................... 154

Function restrictions ......................153

Menu options ................................. 154

Notes on discs ............................... 153

Overview ........................................ 154

Overview of DVD functions ............ 155

Pause function ............................... 156

Picture settings .............................. 154

Playing conditions .......................... 153

Safety notes .................................. 152

Selecting a scene/chapter ............ 156

Stop function ................................. 156

Switching to ................................... 154

Video menu ................................... 155

Voice Control System

Settings ...........................................36

see Voice Control System

Volume, adjusting

Navigation messages ....................... 27

Storm watch areas ......................... 168

Time stamp ....................................168

Weather memory (SIRIUS)

Selecting an area ........................... 165

Storing an area .............................. 165

Web browser

Entering a web address ................. 124

WiFi

Activating ......................................... 36

Changing the name of the SSID ....... 37

Connecting the device ..................... 36

Connecting via security key ............. 37

Connecting via WPS PBC ................. 37

Connecting via WPS PIN .................. 36

Weather map (SIRIUS)

Activating/deactivating display

levels ............................................. 166

Calling up ....................................... 165

Legend ...........................................168

Moving ...........................................165

Showing/hiding the menu ............. 165

Storm overview .............................. 169

Introduction

Operating safety

Important safety notes

WARNING

If you operate information systems and communication equipment integrated in the vehicle when driving, you may be distracted from the traffic situation. You could also lose control of the vehicle. There is a risk of an accident.

Only operate this equipment when the traffic situation permits. If you are not sure that this is possible, park the vehicle paying attention to traffic conditions and operate the equipment when the vehicle is stationary.

You must observe the legal requirements for the country in which you are currently driving when operating the multimedia system.

The multimedia system calculates the route to the destination without taking account of the following, for example:

traffic lights

stop and yield signs

merging lanes

parking or stopping in a no parking/no stopping zone

other road and traffic rules and regulations

narrow bridges

The multimedia system may provide incorrect navigation recommendations if the actual street/traffic situation does not correspond with the digital map's data. Digital maps do not cover all areas nor all routes in an area. For example, a route may have been diverted or the direction of a one-way street may have changed.

For this reason, you must always observe road and traffic rules and regulations during your journey. Road and traffic rules and regulations always have priority over the system's driving recommendations.

Navigation announcements are intended to direct you while driving without diverting your attention from the road and driving.

Please always use this feature instead of consulting the map display for directions. Looking at the icons or map display can distract you from traffic conditions and driving, and increase the risk of an accident.

Bear in mind that at a speed of only 30 mph (approximately 50 km/h), your vehicle covers a distance of 44 feet (approximately 14 m) every second.

This equipment complies with FCC radiation exposure limits set forth for uncontrolled equip-

he FCC radio frequency (RF)

ment and

meets t

Exposure Guidelines in Supplement C to OET65. This equipment has very low levels of RF energy

that is deemed to comply without maximum permissive exposure evaluation (MPE). However, it is recommended to install it at a distance of at least 8 inches (approx. 20 cm) between the radiation source and a person's body (not including limbs such as hands, wrists, feet and legs).

WARNING

Modifications to electronic components, their software as well as wiring can impair their function and/or the function of other networked components. In particular, systems relevant to safety could also be affected. As a result, these may no longer function as intended and/or jeopardize the operating safety of the vehicle. There is an increased risk of an accident and injury.

Never tamper with the wiring as well as electronic components or their software. You should have all work to electrical and electronic equipment carried out at a qualified specialist workshop.

Declarations of conformity

Vehicle components which receive and/or transmit radio waves

USA only: The wireless devices of this vehicle

comply with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

1) These devices may not cause interference, and

2) These devices must accept any interference, including interference that may cause undesired operation of the device.

Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

Introduction

Canada only: The wireless devices of this vehi-

cle comply with Industry Canada licenseexempt RSS standard(s). Operation is subject to the following two conditions:

1) These devices may not cause interference, and

2) These devices must accept any interference, including interference that may cause undesired operation of the device.

Correct use

You need to observe the following information when using the multimedia system:

the safety notes in this manual

traffic rules and regulations

laws and safety standards pertaining to motor vehicles

Attaching metalized retrofit film to the windshield may affect radio reception. This can have a negative impact on all other antennas (e.g. emergency call antenna) in the vehicle interior.

Protection against theft: this device is equipped with technical provisions to protect it against theft. Further information on protection against theft can be obtained from an authorized Mercedes-Benz Center.

Qualified specialist workshop

Read the information on qualified specialist workshops in the vehicle Operator's Manual.

Function restrictions

For safety reasons, some functions are restricted or unavailable while the vehicle is in motion. You will notice this, for example, because either you will not be able to select certain menu items or a message will appear to this effect.

Data stored in the vehicle

Data recording

A wide range of electronic components in your vehicle contain data memories.

These data memories temporarily or permanently store technical information about:

the vehicle's operating state

events

malfunctions

In general, this technical information documents the state of a component, a module, a system or the surroundings.

These include, for example:

operating conditions of system components, e.g. fluid levels

the vehicle's status messages and those of its individual components, e.g. number of wheel revolutions/speed, deceleration in movement, lateral acceleration, accelerator pedal position

malfunctions and defects in important system components, e.g. lights, brakes

vehicle reactions and operating conditions in special driving situations, e.g. air bag deployment, intervention of stability control systems

ambient conditions, e.g. outside temperature

This data is of an exclusively technical nature and can be used to:

assist in detecting and rectifying faults and defects

analyze vehicle functions, e.g. after an accident

optimize vehicle function

The data cannot be used to trace the vehicle's movements.

When your vehicle is serviced, technical information can be read from the event data memory and fault data memory.

Services include, for example:

repair services

service processes

warranty events

quality assurance

The vehicle is read out by employees of the service network (including the manufacturer) using special diagnostic testers. You can obtain more information there, if required.

After a malfunction has been rectified, the information is deleted from the malfunction memory or is continually overwritten.

When operating the vehicle, situations are conceivable in which this technical data, in connec-

Introduction

tion with other information (if necessary, after consultation with an authorized expert), could be traced to a person.

Examples include:

accident reports

damage to the vehicle

witness statements

Further additional functions that have been contractually agreed upon with the customer allow certain vehicle data to be conveyed by the vehicle as well. The additional functions include, for example, vehicle location in case of an emergency.

COMAND/mbrace

If the vehicle is equipped with COMAND or mbrace, additional data about the vehicle’s operation, the use of the vehicle in certain situations, and the location of the vehicle may be compiled through COMAND or the mbrace system.

For additional information please refer to the COMAND User Manual and/or the mbrace Terms and Conditions.

Event data recorders

This vehicle is equipped with an event data recorder (EDR). The main purpose of an EDR is to record data that will assist in understanding how a vehicle’s systems performed in certain crash or near crash-like situations, such as during air bag deployment or when hitting a road obstacle. The EDR is designed to record data related to vehicle dynamics and safety systems for a short period of time, typically 30 seconds or less.

The EDR in this vehicle is designed to record such data as:

how various systems in your vehicle are operating

whether or not the driver and passenger seat belts are fastened

how far (if at all) the driver is depressing the accelerator and/or brake pedal and

how fast the vehicle is traveling

This data can help provide a better understanding of the circumstances in which crashes and injuries occur. NOTE: EDR data is recorded by

your vehicle only if a non-trivial crash situation occurs; no data is recorded by the EDR under normal driving conditions and no personal data (e.g., name, gender, age, and crash location) are recorded. However, other parties, such as law

data w

enforcement, can combine the EDR

ith the type of personal identification data routinely acquired during a crash investigation.

To read data recorded by an EDR, special equipment is required, and access to the vehicle or the EDR is needed. In addition to the vehicle manufacturer, other parties that have the special equipment, such as law enforcement, can read the information by accessing the vehicle or the EDR.

EDR data may be used in civil and criminal matters as a tool in accident reconstruction, accident claims, and vehicle safety. Since the Crash Data Retrieval CDR tool that is used to extract data from the EDR is commercially available, Mercedes-Benz USA, LLC ("MBUSA") expressly disclaims any and all liability arising from the extraction of this information by unauthorized Mercedes-Benz personnel.

MBUSA will not share EDR data with others without the consent of the vehicle owners or, if the vehicle is leased, without the consent of the lessee. Exceptions to this representation include responses to subpoenas by law enforcement; by federal, state or local government; in connection with or arising out of litigation involving MBUSA or its subsidiaries and affilia

tes; o

as required by law. Warning: The EDR is a component of the Sup-

plemental Restraint System ("SRS") Module. Tampering with, altering, modifying or removing the EDR component may result in a malfunction of the SRS Module and other systems.

State laws or regulations regarding EDRs that conflict with federal regulation are pre-empted. This means that in the event of such conflict, the federal regulation governs. As of February 2013, 13 states have enacted laws relating to EDRs.

Information on copyright

Information on licenses for free and Open Source software used in your vehicle and in the electronic components can be found on this website: http://www.mercedes-benz.com/ opensource.

Your multimedia system equipment

These operating instructions describe all the standard and optional equipment of your multimedia system, as available at the time of going to press. Country-specific differences are possible. Bear in mind that your vehicle may not feature all functions described here. This also applies to safety-relevant systems and functions.

Read the information on qualified specialist workshops in the vehicle Operator's Manual.

Introduction

Overview

Components

Overview and operation

Multimedia system display

;

Touchpad

Controller

The multimedia system consists of:

the display The display has 960 x 540 pixels

the single DVD drive

the controller

the touchpad (for multimedia system with touchpad)

ports in the center console (2 x USB, SD-card slot)

An iPod

The controller and touchpad provide two options for entering characters and selecting functions.

is connected via a USB cable.

Functions

HD FM radio and HD AM radio/satellite radio

Media

Media support: audio CD, MP3 CD, DVD video, two connection options for Media Interface (e.g. iPod audio, 10.8 GB Media Register on the hard drive

Music search using all media

Sound system

), SD card, Bluetooth

You can select from two sound systems:

Burmester®surround sound system

Burmester high-end surround sound system for ultimate listening pleasure

Navigation system

Navigation via the hard drive

Destination entry using keyword search

Realistic 3D map with textured city models

Personal POIs and routes using SD memory card

Dynamic route guidance with traffic reports via SIRIUS satellite radio

Additional navigation system functions, such as Drive Information

Communication

Messaging functions (text messages, email)

Address book

Internet browser

Mercedes-Benz Apps with online search, Facebook, stock prices, news and much more

Mercedes-Benz Companion app

Mercedes-Benz Mobile Website

Wi-Fi interface for the connection of a smartphone to the multimedia system

SIRIUS Weather

Weather data as an information chart (current forecast, 5-day preview, detailed information)

Weather data on the weather map, e.g. rain radar data, storm characteristics and the track of tropical cyclones (hurricanes, typhoons)

Vehicle functions

Vehicle settings, e.g. belt adjustment

Rear view camera

DYNAMIC SELECT (individual drive program)

Climate control functions

Setting climate mode, for example

Favorites button

fast access to favorites on the controller or on the touchpad

adds and edits favorites

Display

General notes

Avoid any direct contact with the display

surface. Pressure on the display surface may result in impairments to the display, which could be irreversible.

Wearing polarized sunglasses may impair your ability to read the display.

Overview

The display has an automatic temperature-controlled switch-off feature. The brightness is automatically reduced if the temperature is too high. The display may then temporarily switch off completely.

Overview

Status bar with displays

;

Cover view (if available)

Main display field

Climate control status display

The example shows media playback in SD memory card mode.

Cleaning instructions

Do not touch the display. The display has a

very sensitive high-gloss surface; there is a risk of scratching. If you have to clean the screen, however, use a mild cleaning agent and a soft, lint-free cloth.

The display must be switched off and have cooled down before you start cleaning. Clean the display screen, when necessary, with a commercially available microfiber cloth and cleaning agent for TFT and LCD displays. Do not apply pressure to the display surface when cleaning it, as this could cause irreversible damage to the display. Then, dry the surface with a dry microfiber cloth.

Avoid using alcoholic thinners, gasoline or abrasive cleaning agents. These could damage the display surface.

Overview and operation

Overview

Buttons and controller

Overview

Overview and operation

Back button

;

Controller

Favorites button

Switches the multimedia system on/off (Y page 26) and adjusts volume (Y page 26)

Touchpad

Back button

You can use the % button to exit a menu or to call up the basic display of the current operating mode.

To exit the menu: briefly press the % button. The multimedia system changes to the next higher menu level in the current operating mode.

To call up the basic display: press the % button for longer than two seconds. The multimedia system changes to the basic display of the current operating mode.

Controller

The controller in the center console lets you:

select menu items on the display

enter characters

select a destination on the map

save entries

The controller can be:

turned 3

slid left or right 1

slid forwards or back 4

slid diagonally 2

pressed briefly or pressed and held7

Favorites button

With the favorites button, you can select, add or edit favorites.

Press the favorites button on the controller. The favorites are displayed.

To select a favorite: turn and press the controller.

Other functions (

Y page 31).

Touchpad

Alternatively, you can use the touchpad to select and enter information (

Y page 21).

Multifunction steering wheel

Multifunction display

;

Right control panel

Left control panel

9 :

Calls up the main menu

Press briefly:

Scrolls in lists

Selects a menu or function

In the Radio/Media menu: opens the track or station list and selects a station, an audio track or a video scene

In the Telephone menu: switches to the phone book and selects a name or a telephone number

Press and hold:

Scrolls quickly through all lists

In the Radio/Media menu: selects a station, audio track or video scene using rapid scrolling

In the Telephone menu: starts rapid scrolling if the phone book is open

In all menus: confirms the selected entry in the list

In the Radio/Media menu: opens the list of available radio sources and media

In the Telephone menu: switches to the phone book and starts dialing the selected number

Switches off the Voice Control System (see the separate operating instructions)

Press briefly:

Back

In the Radio/Media menu: deselects the track, station list or list of available radio sources and media

Hides display messages

Exits the telephone book/redial memory

Press and hold:

Calls up the standard display in the

Trip

Right control panel

Rejects or ends a call

Exits the telephone book/redial memory

Makes or accepts a call

Switches to the redial memory

Adjusts the volume

Mute

Switches on the Voice Control System (see the separate operating instructions)

Touchpad

Touchpad overview

Do not use any sharp objects on the touch-

pad. This could damage the touchpad.

Overview and operation

Touchpad

Touch-sensitive surface

;

Favorites button

Calls up quick access for audio

Back button

Using the touchpad, you can:

Overview and operation

select menu items (Y page 22)

enter characters (handwriting recognition)

Y page 25)

(

control the active audio source

Y page 26)

(

create, manage and call up favorites

Y page 31)

(

enter destinations in the navigation system

save entries

Further information on operating the touchpad

Y page 22).

(

Operating the touchpad

Selecting a menu item

Use one finger to touch the touch-sensitive surface.

Swipe your finger up, down, to the left or right. The selection in the display moves in accordance with the direction of movement. You can navigate in lists or menus in this way.

Confirming a selection

Switching the touchpad on/off

Press Vehicle in the main function bar. The vehicle menu is displayed.

To select System Settings: slide 6, turn and press the controller. A menu appears.

To select Touchpad: turn and press the controller.

Select Activate Touchpad. The touchpad is switched on O or off ª.

Do not press your finger too hard on the touchpad. This could cause malfunctions.

Use one finger to press the touch-sensitive surface until you reach the pressure point. A menu, an option or an application is started.

Calling up quick access for audio

Use two fingers to touch the lower part of the touch-sensitive surface.

Swipe your fingers up. Quick access is displayed.

Further information on quick access for audio

Y page 26).

(

Hiding quick access for audio

Touchpad

Touch the touch-sensitive surface with two fingers, spaced slightly apart.

Turn both fingers clockwise. The control setting is increased.

Turn both fingers counter-clockwise. The control setting is decreased.

Moving the map

Use one finger to press the touch-sensitive surface until you reach the pressure point. The crosshair is shown.

Overview and operation

Use two fingers to touch the touch-sensitive surface.

Swipe your fingers down. Quick access is hidden.

Operating the control for vehicle and sound settings

Touch the touch-sensitive surface again with one finger.

Swipe your finger in any direction. The map is moved is the direction of movement.

Touchpad

Zooming in on the map

Touch the touch-sensitive surface with two fingers, spaced slightly apart.

Glide your fingers away from each other.

Overview and operation

The map scale is magnified.

Zooming out of the map

Handwriting recognition

Handwriting recognition overview

Active input line

;

Inserts a space (Y page 25)

Illustration of the touch-sensitive surface

Deletes characters (Y page 25)

You can use handwriting recognition for text, numbers or characters in any input line.

If the character that you have entered can be interpreted in different ways, these options are displayed. More information on the character suggestions (

You can additionally switch the handwriting recognition read-aloud function on and off.

Y page 25).

Touch the touch-sensitive surface with two fingers, spaced far apart.

Glide your fingers towards each other. The map scale is reduced.

To exit the menu

;

To return to handwriting recognition

To use the phone book or text templates

To change the input line or the position of the cursor

To change the input language

To finish character entry

To display the menu: press the touchpad.

Switching the text reader function of the handwriting recognition on/off

You can switch the text reader function of the handwriting recognition on or off.

Press Vehicle in the main function bar. The vehicle menu is displayed.

To select System Settings: slide 6, turn and press the controller. A menu appears.

To select Touchpad: turn and press the controller.

To select Read Out Handwriting Recog‐

nition: turn and press the controller.

The text reader function is switched on O or off ª.

Entering characters

Requirement: an input line for text, numbers or characters has been selected.

Use one finger to draw the desired character on the touch-sensitive surface. The character recognized is entered in the input line. You can draw the next character on the touch-sensitive surface.

If the character can be interpreted in different ways, these options are displayed.

More information on the character suggestions

Y page 25).

(

Touchpad

Use your finger to touch the touch-sensitive surface and swipe to the left. The character last entered is deleted.

Switching input lines

Press the touchpad. A symbol is shown.

To select p: swipe your finger to the left or right and press.

To select the input line: swipe up or down and press. The selected input line is active and character entry can be continued.

Moving the cursor within the input line

Overview and operation

Character suggestions

To select a character suggestion: turn the controller. The selected character is entered instead of the automatically recognized character. Character entry can be continued.

Inserting a space

Requirement: an input line for text, numbers or characters has been selected.

Use your finger to touch the touch-sensitive surface and swipe to the right. A space is entered into the input line.

Deleting characters

Requirement: an input line for text, numbers or characters has been selected.

Press the touchpad. A symbol is shown.

To select p: glide your finger to the left or right and press.

To move the cursor: glide to the left or right.

Changing the input language for handwriting recognition

Requirement: an input line for text, numbers or characters has been selected.

Basic functions

Press the touchpad. A symbol is shown.

To select B: swipe your finger to the left or right and press. The list of available input languages appears.

To select a language: swipe up or down and press. The input language for handwriting recognition has been changed.

Searching in lists

The phone book search is used as an example. You determine the first letter of the contact you

are looking for with the first character you enter.

Draw the letter on the touchpad surface.

Overview and operation

The first contact with the selected first character is highlighted in the phone book.

Further information on handwriting recognition on the touchpad (

Draw additional letters on the touchpad sur-

Y page 24).

face one after another.

To complete the search and return to the

phone book: press the touchpad.

Switching between the controller and the touchpad as input device

Requirement: an input line for text, numbers or characters has been selected.

To switch from character entry using the

controller to handwriting recognition on the touchpad: use one finger to press the

touchpad. Handwriting recognition on the touchpad is active.

To switch from handwriting recognition

on the touchpad to character entry using the controller: press the controller.

Character entry using the controller is active.

Quick access for audio

Depending on the audio source that is currently activated, you can use this function to select the next station or music track.

Call up quick access (Y page 23). The current audio source is displayed.

To select the previous or next station or music track: swipe to the left or right. The selected station or music track is played.

Basic functions

Switching the multimedia system on/ off

Press the Ä control knob on the center console to the right of the controller. The multimedia system calls up the previously selected menu.

If you switch the multimedia system off, playback of the current media source will also be switched off.

Adjusting the volume

Adjusting the volume for media sources

Turn the Ä control knob on the center console to the right of the controller.

Press the W or X button on the multifunction steering wheel. The volume of the media source currently selected changes.

Adjusting the volume for traffic announcements and navigation announcements

During traffic or navigation announcements:

Turn the Ä control knob on the center console to the right of the controller.

Press the W or X button on the multifunction steering wheel.

You can set the volume for navigation

announcements to be different from the volume of the respective media source.

Basic functions

To switch navigation announcements on

again: switch the multimedia system off and then on again (

Start a new route calculation (Y page 54).

While route guidance is active, show the menu and select +(

Basic menu displays

Y page 26).

Y page 71).

Adjusting the volume for phone calls

You can adjust the volume for hands-free mode during a telephone call.

Turn the Ä control knob on the center console to the right of the controller.

Press the W or X button on the multifunction steering wheel.

Setting the volume for the Voice Control

System voice output; see the separate operating instructions.

Switching the sound on or off

Media source sound

Press the 8 button on the multifunction steering wheel.

If the audio output is switched off, the status

line will show the 8 symbol. If you switch the media source or change the volume, the sound is automatically switched on.

Even if the sound is switched off, you will still

hear navigation system announcements.

Switching navigation announcements off and on again

To switch off navigation announcements:

press the 8 button on the multifunction steering wheel during the announcement. The Spoken driving recommendations

have been deactivated. message

appears.

To show the main function bar: slide 5 the controller.

To select a main function, e.g. Navi

: turn and

press the controller. Navigation: the map displays the current vehicle position.

Radio: the basic menu of the last radio mode set appears.

Media: the basic display for the last media source set appears. In the example, SD card mode is set.

Telephone: the basic display of the telephone menu appears.

Vehicle functions: the basic display appears.

Overview and operation

Character entry (telephony)

To show the menu: slide 4 the controller. The menu for the selected functions appears. Depending on the operation, the marking is shown in main function bar : or menu bar ;.

To select a menu item: turn and press the controller. Once you have selected a menu item in :, the last menu set for the selected function appears.

Menu bar ; offers options in the current media mode.

Selecting the operating mode for a main function

Overview and operation

You can select the available operating modes for the main functions, e.g. telephone.

In the telephone menu, you can:

switch to telephone mode

call up the address book

call up the Digital Operator's Manual for the telephone

To display the main function bar: slide 5 the controller.

To select Phone: turn and press the controller. The telephone menu is displayed.

To select Phone: slide 5 and press the controller. A menu appears. Phone

To select Address Book, for example: turn and press the controller.

is at the front.

Character entry (telephony)

Writing a text message is used as an example. Further information on writing a text message

Y page 114).

(

To select a character: turn and press the controller. The character selected in character bar ; is entered into telephone number input line :.

To delete a character: to switch to the bottom line of the character bar: slide 6 the controller.

To select : turn and press the controller. The character last entered is deleted.

To switch input line: to switch to the bottom line of the character bar: slide 6 the controller.

To select 5, turn and press the controller.

Slide 5 the controller repeatedly until the character bar disappears.

To select the input line for the text of the

text message: slide 6 and press the con- troller. The input line for the text of the text message is selected. The character bar has been adapted for entering text.

To select a character: turn and press the controller. The character selected in character bar ? is entered into text message input line =.

To delete a character: to switch to the bottom line of the character bar: slide 6 the controller.

To select : turn and press the controller. The character last entered is deleted.

To delete a whole entry: to switch to the bottom line of the character bar: slide 6 the controller.

To select : turn the controller.

Press and hold the controller until the entire entry is deleted.

To change the country setting of the char-

acter bar: to switch to the bottom line of the character bar: slide 6 the controller.

To select B, turn and press the controller. The available languages are displayed.

Turn and press the controller.

Functions in the character bar

Switches between digits and symbols

Switches the character bar to uppercase/ lowercase letters

Changes the country setting for the character bar

Deletes a character/an entry

Selects the input line

Moves the cursor within the input line

Confirms an entry

Cancels input

Inserts a paragraph

Uses a text template

Character entry (navigation)

Character entry options

You can enter characters using the controller or the touchpad. With the controller, you enter characters using a character bar. To enter using the touchpad, draw the character in the entry field. The multimedia system supports this using a handwriting recognition function.

Entering characters using the character bar

Characters STUT entered by the user (orange)

;

Characters automatically added by the multimedia system EBÜLL

Switches to keyword search

Characters not currently available

Currently selected character

Characters currently available

Character bar

The example shows the address entry

Y page 53).

(

To enter a character: turn, slide 6 or 5 and press the controller. Selected character : is entered in the upper line. The multimedia system adds the missing characters and shows the entry that best matches the current input.

The characters are available B or not ?, depending on the characters already entered and the data stored in the digital map.

The G symbol indicates that an entry exists more than once.

To delete a character: slide 6 and turn the controller, then press it after selecting

Overview and operation

Character entry (navigation)

To delete an entire entry: slide 6 and turn

the controller, then after selecting press and hold down the controller until the entire entry is deleted.

To switch to keyword search: slide 6 and turn the controller, then press it after select-

Y page 55).

ing = (

To confirm an entry: slide 6 and turn the controller, then press it after selecting¬.

Slide 5 the controller repeatedly until the character bar disappears. The location selection list appears. The selected entry is highlighted.

Overview and operation

Cursor

;

Entry line

The example shows the character entry when you save a destination as a navigable contact in the address book (

To select an input line: slide 6 and turn the controller, then press it after selecting 4 or 5.

Slide 5 the controller repeatedly until the character bar disappears.

Turn and press the controller.

To move the cursor: select the input line.

Slide 6 and turn the controller, then press it after selecting 2 or 3.

Y page 53).

To change the character bar language:

slide 6 and turn the controller, then press it after selecting B. A menu appears.

To select the language: turn and press the controller. The character set for the selected language is set.

Functions in the character bar

Switches between digits and symbols

Switches the character bar to uppercase/ lowercase letters

Changes the country setting for the character bar

Deletes a character/an entry

Switches to keyword search (

Y page 55)

Selects the input line

Moves the cursor within the input line

Confirms an entry

Cancels input

Favorites

Entering characters using the touchpad

Alternatively, you can enter characters using the touchpad ( ported by a handwriting recognition function.

An example is the address entry (

With one finger, draw the desired character, e.g. the letter B face. In the list (e.g. City), the first entry that starts with the letter entered is highlighted. You can draw the next character on the touch-sensitive surface.

If the character that you have entered can be interpreted in different ways, these options are displayed.

To select a character suggestion: turn the controller. The selected character is used for the list display instead of the automatically recognized character. Character entry can be continued.

To delete a character: touch the touch-sensitive surface with your finger and glide your finger to the left. The character last entered is deleted.

To complete the entry and switch to the

list: press the touchpad.

Y page 21). Character entry is sup-

Y page 53).

, on the touch-sensitive sur-

Favorites

Overview of favorites

Adds a new favorite (Y page 31)

;

Renames a selected favorite (Y page 32)

Moves a selected favorite (Y page 32)

Deletes a selected favorite (Y page 32)

To display the favorites overview: press the favorites button on the controller.

To show the menu bar: slide 6 the con- troller.

You can manage a total of 20 favorites.

Displaying and selecting favorites

Press the favorites button on the controller. The favorites are displayed.

To call up a favorite: turn and press the controller.

Adding favorites

Adding predefined favorites

Press the favorites button on the controller.

To show the menu bar: slide 6 the con- troller.

To select Reassign: turn and press the controller. The categories and predefined favorites are displayed.

To select a category: turn and press the controller. The available favorites are displayed.

Overview and operation

Favorites

To select a favorite: turn and press the controller.

To add a favorite at the desired position:

turn and press the controller. If there is already a favorite at this position, then this will be deleted.

Adding your own favorites

You can store phone numbers from the phone book, radio stations or destinations as favorites.

A phone number from the phone book is used as an example.

Call up the phone book (Y page 99).

Search for and highlight a contact

Y page 100).

(

Overview and operation

To add a telephone number as a favorite

at the desired position: press and hold the favorites button on the controller until the favorites are displayed.

Turn and press the controller. If there is already a favorite at this position, it will be deleted and replaced by a new one.

Renaming favorites

Press the favorites button on the controller. The favorites are displayed.

To select a favorite to be renamed: turn the controller.

To show the menu bar: slide 6 the con- troller.

To select Rename: turn and press the controller.

Enter characters using the controller

Y page 28) or the touchpad (Y page 25).

(

To finish the entry: select OK. The favorite has been renamed.

To select Move: turn and press the controller.

To store a favorite in the desired order:

turn and press the controller. If a favorite is stored over another favorite, the favorite underneath is deleted.

Deleting favorites

Press the favorites button on the controller. The favorites are displayed.

To select a favorite to be deleted: turn the controller.

To show the menu bar: slide 6 the con- troller.

To select Delete: turn and press the controller.

To select Yes: turn and press the controller. The favorite is deleted.

If you select No, the process is canceled.

Moving favorites

Press the favorites button on the controller. The favorites are displayed.

To select a favorite to be moved: turn the controller.

To show the menu bar: slide 6 the con- troller.

Your multimedia system equipment

Read the information on qualified specialist workshops in the vehicle Operator's Manual.

Important safety notes

WARNING

If you operate mobile communication equipment when driving, you may be distracted from the traffic situation. You could also lose control of the vehicle. There is a risk of an accident.

Only operate this equipment when the vehicle is stationary.

WARNING

SD cards are small parts. They can be swallowed and cause choking. This poses an increased risk of injury or even fatal injury.

Keep the SD card out of the reach of children. If a SD card is swallowed, seek medical attention immediately.

You must observe the legal requirements for the country in which you are currently driving when operating mobile communications equipment in the vehicle.

Display settings

To select System Settings: turn and press the controller. A menu appears.

To select Display: turn and press the controller. A menu appears.

Select Brightness. A control appears.

Select the desired brightness.

Display design

The display features optimized designs for daytime and night-time operation. You can set the design by manually selecting day or night design or opt for an automatic setting.

Press Vehicle in the main function bar. The vehicle menu is displayed.

To switch to the menu bar: slide 6 the controller.

To select System Settings: turn and press the controller. A menu appears.

To select Display: turn and press the controller. A menu appears.

Select Day Mode, Night Mode or Auto. The # dot indicates the current setting.

Design Explanation

Day Mode

Night Mode

Automatic

The display is set permanently to day design.

The display is set permanently to night design.

The multimedia system evaluates the data of the light sensor and automatically switches over the display design.

System settings

Setting the brightness

The brightness detected by the display light sensor affects the setting options for this function.

Press Vehicle in the main function bar. The vehicle menu is displayed.

To switch to the menu bar: slide 6 the controller.

Switching the display on/off

Switching off the display

Press Vehicle in the main function bar. The vehicle menu is displayed.

To select Display Off: slide 6, turn and press the controller. The display goes out.

Time settings

To switch the display on again: press the controller.

Time settings

General information

The multimedia system can automatically set the time and date.

The following navigation system functions require the time, time zone and summer/standard time to be set correctly in order to work properly:

route guidance on routes with time-depend-

System settings

ent traffic guidance

calculation of expected time of arrival

Switching automatic time on and off

The Automatic Time Settings function is used to activate or deactivate the automatic setting of the time and date. This function is activated when the vehicle leaves the factory.

Press Vehicle in the main function bar. The vehicle menu is displayed.

To switch to the menu bar: slide 6 the controller.

To select Time: turn and press the controller. A menu appears.

To activate O or deactivate ª Automatic

Time Settings: turn and press the control-

ler.

Setting the time zone

To set the time zone, the Automatic Time

Settings function must be activated.

Press Vehicle in the main function bar. The vehicle menu is displayed.

To switch to the menu bar: slide 6 the controller.

To select Time: turn and press the controller. A menu appears.

To select Time Zone:: turn and press the controller. A list of countries appears. The # dot indicates the current setting.

Select the country you are currently in by turning and pressing the controller. The country is accepted.

A time zone list may also be displayed, depending on the country selected.

To select the desired time zone: turn and press the controller. The time zone is accepted.

A list of available options for setting summer time appears (

Y page 34).

Setting summer and standard time

Using the Daylight Saving Time function, you can set the automatic changeover to summer time or switch the summer time settings on and off. The changeover to summer time advances the time by one hour.

The Daylight

matic option is not available in all countries.

Press Vehicle in the main function bar. The vehicle menu is displayed.

To switch to the menu bar: slide 6 the controller.

To select Time: turn and press the controller. A menu appears.

To select Daylight Saving Time: turn and press the controller. A list of available options for setting summer time appears.

To select Automatic, On or Off: turn and press the controller.

Setting Function

Automatic

Off

Saving Time function or Auto‐

The summer and standard time are automatically changed over.

The clock is advanced one hour ahead of standard time.

The standard time for the chosen time zone is selected.

Manual time setting

Using the manual time settings, you can set the time forwards or backwards by up to several hours.

Press Vehicle in the main function bar. The vehicle menu is displayed.

To switch to the menu bar: slide 6 the controller.

To select Time: turn and press the controller. A menu appears.

To select Set Time Manually: turn and press the controller. An analog clock appears.

To set the hour: turn the controller.

To highlight minutes: slide 9 the controller.

To set minutes: turn and press the controller. The time is accepted.

The Automatic Time Settings

function is

deactivated ª.

If Automatic Time Settings is reactiva-

ted, the previous settings for time zone and summer time changeover are restored.

Setting the time and date format

Use this function to set the time and date format for all displays in the vehicle.

Press Vehicle in the main function bar. The vehicle menu is displayed.

To switch to the menu bar: slide 6 the controller.

To select Time: turn and press the controller. A menu appears.

To select Format: turn and press the controller.

Text reader settings

To select the desired date format: turn and press the controller. The # dot indicates the current setting.

To select the desired time format: turn and press the controller. The # dot indicates the current setting.

Abbreviation Meaning

YYYY/MM/DD

YY/MM/DD

MM/DD/YYYY

DD/MM/YYYY

HH:MM (24 hrs)

HH:MM (AM/PM)

Text reader settings

Press Vehicle in the main function bar. The vehicle menu is displayed.

To switch to the menu bar: slide 6 the controller.

To select System Settings: turn and press the controller. A menu appears.

To select Text Reader Speed: turn and press the controller. A list appears.

Select Fast, Medium or Slow. The # dot indicates the current setting.

Year/Month/Day date format, year (all

four digits)

Year/Month/Day date format, year

(two digits)

Month/Day/Year date format, year (all

four digits)

Day/Month/Year date format, year (all

four digits)

Hours : Minutes (24 hour time format)

Hours : Minutes (AM/PM time format)

System settings

Wi-Fi

Voice Control System settings

Opening/closing the help window

If the set system language is not supported

by the Voice Control System, English will be selected.

The help window also shows you information on audible instructions:

during individualization

during subsequent operation of the Voice Control System

Press Vehicle in the main function bar. The vehicle menu is displayed.

System settings

To switch to the menu bar: slide 6 the controller.

To select System Settings: turn and press the controller. A menu appears.

To select Voice Control: turn and press the controller.

To activate O or deactivate ª Help Win‐

dow: turn and press the controller.

More information on the Voice Control System is available in the separate operating instructions.

Individualization

Using individualization, you can fine-tune the Voice Control System to your own voice. This will help improve voice recognition; see the separate operating instructions.

Wi-Fi

Overview

Establishing a Wi-Fi connection between the multimedia system and a Wi-Fi-enabled device, such as a tablet computer or smartphone, requires the following:

Wi-Fi must be activated on the multimedia system and on the device to be connected.

If the multimedia system is to be used as a Wi-Fi hotspot:

The multimedia system must be connected to an Internet-enabled mobile phone via Blue-

or USB.

tooth

The Internet access data for the mobile phone network provider must be selected or set in the multimedia system

An Internet connection must be established on the multimedia system.

Activating Wi-Fi

To select Vehicle from the main function bar: turn and press the controller.

To switch to the menu bar: slide 6 the controller.

Select System Settings.

Select WiFi. The Wi-Fi menu appears.

Select Activate.

Press the controller. Switch the connection on O or off ª, depending on the previous setting.

Connecting the device

General notes

The exact Wi-Fi connection procedure may vary depending on the device to be connected. Follow the instructions that are shown in the display. Further information; see the manufacturer's operating instructions.

Connecting a device via WPS PIN

Requirement: for this type of connection, the device to be connected must support "Connect using WPS PIN".

To select Vehicle from the main function bar: turn and press the controller.

To switch to the menu bar: slide 6 the controller.

Select System Settings.

Select WiFi. The Wi-Fi menu appears.

Select Connect via WPS PIN.

Select the vehicle from the device to be connected and "Connect using WPS PIN". The

Wi-Fi

vehicle is displayed with the SSID MB WLAN

XXXXX.

The device to be connected generates a PIN.

Also enter this PIN into the multimedia system.

Connecting the device by pressing a button (push button)

Requirement: for this type of connection, the device to be connected must support "Connect via push button".

To select Vehicle from the main function bar: turn and press the controller.

To switch to the menu bar: slide 6 the controller.

Select System Settings.

Select WiFi. The Wi-Fi menu appears.

Select Connect via WPS PBC.

Select the vehicle from the device to be connected and Connect

via WPS PBC. The vehi-

cle is displayed with the SSID MB WLAN

XXXXX.

Select Continue in the multimedia system.

Connecting the device via the security key

To select Vehicle from the main function bar: turn and press the controller.

To switch to the menu bar: slide 6 the controller.

Select System Settings.

Select WiFi. The Wi-Fi menu appears.

Select Connect Using Security Key.

Select the vehicle from the device to be connected. The vehicle is displayed with the SSID

MB WLAN XXXXX

Enter the security key that appears on the multimedia system display into the device to be connected.

Confirm the entry.

Generating a new security key

To select Vehicle from the main function bar: turn and press the controller.

To switch to the menu bar: slide 6 the controller.

Select System Settings.

Select WiFi. The Wi-Fi menu appears.

Select Generate Security Key.

Select Regenerate. A new security key is generated.

To save the security key: turn the controller and select Save

. The Wi-Fi menu appears. The new security key will now be displayed and verified when a WiFi connection is established. The connection must be re-established with the newly created security key.

Device connections established using the

previous security key will no longer work after the security key is changed. You have to reconnect these devices (

Y page 36).

Changing the name of the SSID

To select Vehicle from the main function bar: turn and press the controller.

To switch to the menu bar: slide 6 the controller.

Select System Settings.

Select WiFi. The Wi-Fi menu appears.

Select Change SSID. A dialog for entering the SSID appears.

Enter the new SSID.

System settings

Setting the system language

Select ¬.

Press the controller. From now on, when establishing a connection, the vehicle will be shown with the new SSID both on the device to be connected and in the Connect

Device connections established using the

Using Security Key menu.

previous SSID will no longer work after the SSID is changed. You have to reconnect these devices (

Y page 36).

Bluetooth®settings

System settings

General information about Blue-

tooth

Bluetooth®-capable devices, e. g. mobile phones, need to comply with a certain profile in order to be connected to the multimedia system. Every Bluetooth cific Bluetooth

Bluetooth

technology is a standard for shortrange wireless data transmissions up to approximately 10 m.

You can use Bluetooth phone to the multimedia system, for example:

use the hands-free system

establish an Internet connection

listen to music using Bluetooth®Audio

exchange vCards

Bluetooth

is a registered trademark of Bluetooth Special Interest Group (SIG) Inc.

name.

device has its own spe-

to connect your mobile

Automatic volume adjustment

General information

With the Automatic Volume Adjustment function, the volumes of different audio sources are adjusted for each other, to compensate for relative differences in volume.

For example: changing from a relatively quiet to a relatively loud radio station. The volume for both stations sounds the same. Manual readjustment of the volume is not required.

The Automatic Volume Adjustment

function

is deactivated ª when the vehicle leaves the factory. Using this function, the dynamic range of the music is slightly reduced. To make the most of the audiophile sound quality, it is recommended to leave it off.

Switching the automatic volume adjustment on/off

Press Vehicle in the main function bar. The vehicle menu is displayed.

To switch to the menu bar: slide 6 the controller.

To select System Settings: turn and press the controller. A menu appears.

To select Automatic Volume Adjustment: turn and press the controller. Switch the Automatic Volume Adjustment function on O or off ª.

Activating/deactivating Bluetooth

Press Vehicle in the main function bar. The vehicle menu is displayed.

To switch to the menu bar: slide 6 the controller.

To select System Settings: turn and press the controller. A menu appears.

To activate O or deactivate ª Activate

Bluetooth: turn and press the controller.

Setting the system language

General information

This function allows you to determine the language for the menu displays and the navigation messages. The selected language affects the characters available for entry.

The navigation announcements are not

available in all languages. If a language is not available, the navigation announcements will be in English.

When you set the system language, the lan-

guage of the Voice Control System will change accordingly. If it is not supported by the Voice Control System, English will be selected.

Importing/exporting data

Setting the system language

Press Vehicle in the main function bar. The vehicle menu is displayed.

To switch to the menu bar: slide 6 the controller.

To select System Settings: turn and press the controller. A menu appears.

To select Language: turn and press the controller. The list of languages appears. The # dot indicates the current setting.

Select the desired language. The multimedia system loads the selected language and sets it.

Calling up and editing the Favorites function

The Favorites function can, depending on the vehicle equipment, be called up as follows:

via the System Settings menu

via the Favorites button on the controller

via the Favorites button on the touchpad

Y page 21)

(

Calling up the Favorites function via the system menu

Press Vehicle in the main function bar. The vehicle menu is displayed.

To switch to the menu bar: slide 6 the controller.

To select System Settings: turn and press the controller. A menu appears.

To select Favorite Functions: press the controller. The favorites are displayed.

To select the desired function, e.g. Phone‐

book: turn and press the controller.

Calling up the Favorites function via the controller or touchpad

Press the Favorites button on the controller or touchpad. The menu for setting favorites appears.

To select the desired function, e.g. Phone‐

book: turn and press the controller.

Exiting the Favorites function

Press the Favorites button again.

Press the % button.

Further information on favorites (

Y page 31).

Importing/exporting data

General notes

When writing data onto the USB stick or the SD card, it is important not to remove the stick or the card. Otherwise, data loss may occur.

Using this function you can do the following with your personal data:

transfer your data from one multimedia system to another multimedia system

The transfer may be limited or not possible, depending on the vehicle's equipment.

make a backup copy of your personal data (export data) and load it again (import data)

protect your data from unwanted export by activating a pin prompt (presetting: deactivated ª)

You can either use an SD card or a USB storage device (e.g. a USB stick) as temporary storage.

You can obtain further information on data import and export from an authorized Mercedes-Benz Center.

Activating/deactivating PIN protection

Press Vehicle in the main function bar. The vehicle menu is displayed.

To switch to the menu bar: slide 6 the controller.

To select System Settings: turn and press the controller. A menu appears.

To select Data Import/Export: turn and press the controller.

Select Activate PIN Protection. Activate O or deactivate ª PIN protection. When activating PIN protection, you will be prompted to enter a PIN.

System settings

Reset function

To enter the 4-digit PIN and select ¬: turn and press the controller. You will be prompted to enter the PIN again.

Enter the PIN again and select ¬. The PIN prompt now protects your personal data from unwanted export.

If you deactivate your PIN protection, you

will first be prompted to enter your PIN. If you have forgotten your PIN, an authorized Mercedes-Benz Center can deactivate your PIN protection for you. Alternatively, you can deactivate PIN protection by resetting your personal data (

Y page 40).

System settings

Importing/exporting data

The following data can be exported:

address data

system settings that you have made

bookmarks

radio station lists

Personal music files in the Media Register cannot be saved or transferred using this function.

Mercedes-Benz is not liable for any loss of data.

Connecting a USB storage device

Inserting an SD card (Y page 139)

Connect a USB device (e.g. a USB memory

Y page 139).

stick) (

Importing or exporting data

If you import data such as address data, the

existing data in the multimedia system is overwritten. You will see a message to this effect. The multimedia system is restarted after the data import.

Press Vehicle in the main function bar. The vehicle menu is displayed.

To switch to the menu bar: slide 6 the controller.

To select System Settings: turn and press the controller. A menu appears.

To select Data Import/Export: turn and press the controller.

Select Import Data or Export Data. If PIN protection is activated, a PIN prompt appears when you select Export Data

To enter the 4-digit PIN and select ¬: turn and press the controller. PIN protection is deactivated.

To select Memory Card, Media Interface 1 or Media Interface 2: turn and press the controller. This function exports all the data to the selected disc.

Reset function

General information

You can reset the multimedia system to the factory settings. Resetting is recommended before handing over or selling the vehicle, for example.

This includes the deletion of all of your personal data on the multimedia system. These include, for example:

Station presets

Entries in the destination memory

Entries in the list of previous destinations in the navigation system

Entries in the address book

Authorized telephone

Data on the internal hard drive, e.g. music files in the Media Register, will be deleted during a reset.

In addition, an activated PIN protection, which you have used to protect your data against unwanted export, will be deactivated during a reset.

Mercedes-Benz is not liable for any loss of data.

Resetting the multimedia system

Press Vehicle in the main function bar. The vehicle menu is displayed.

To switch to the menu bar: slide 6 the controller.

To select System Settings: turn and press the controller. A menu appears.

To select Reset: turn and press the controller. A prompt appears asking whether you wish to reset.

Select Yes. A prompt appears again asking whether you really wish to reset.

Select Yes. A message appears. The multimedia system is reset to the factory settings and restarted.

Reset function

System settings

Vehicle settings

Your multimedia system equipment

Read the information on qualified specialist workshops in the vehicle Operator's Manual.

Important safety notes

WARNING

Vehicle functions

If you operate mobile communication equipment when driving, you may be distracted from the traffic situation. You could also lose control of the vehicle. There is a risk of an accident.

Only operate this equipment when the vehicle is stationary.

You must observe the legal requirements for the country in which you are currently driving when operating mobile communications equipment in the vehicle.

Vehicle settings

Calling up vehicle settings

Press Vehicle in the main function bar. The vehicle menu is displayed.

To select Vehicle Settings: press the controller. The Vehicle Settings

To select the desired vehicle setting: turn and press the controller. The main area with the setting element is active.

Selecting a different vehicle setting:

To activate the menu for selecting the vehicle setting: slide 5 the controller.

Exiting the vehicle settings:

To select &: slide 6 and press the controller.

menu is active.

Setting the easy entry and exit feature

This function makes getting in and out of your vehicle easier.

Call up Vehicle Settings (Y page 42).

To select Easy Entry/Exit: turn and press the controller. The setting element is active.

To change the setting: press the controller.

You can find further information on the easy entry and exit feature in the vehicle Operator's Manual.

Activating/deactivating the acoustic locking verification signal

You can also set an audible signal to confirm that the vehicle has been locked.

Call up Vehicle Settings (Y page 42).

To select Acoustic Lock Feedback: turn and press the controller. The function switches on or off, depending on the previous setting.

You can find further information on the locking feature in the vehicle Operator's Manual.

Switching the seat belt adjustment on/off

The Belt Adjustment function adjusts the driv- er's and front-passenger seat belt to the upper body of the vehicle occupants.

Call up Vehicle Settings (Y page 42).

To select Belt Adjustment: turn and press the controller. The function switches on or off, depending on the previous setting.

You can find further information on seat belt adjustment in the vehicle Operator's Manual.

Switching the automatic mirror folding function on/off

When the Automatic Mirror Folding function is activated, the outside mirrors fold in automatically as soon as you lock the vehicle from the outside. The outside mirrors fold out automatically again as soon as you unlock the vehicle.

Call up Vehicle Settings (Y page 42).

To select Automatic Mirror Folding: turn and press the controller. The function switches on or off, depending on the previous setting.

You can find further information on the automatic folding mirror function in the vehicle Operator's Manual.

Switching locator lighting on/off

If you switch on the Locator Lighting function, the exterior lighting is switched on for a short time when it is dark. The light switch must be set to Ã; see the vehicle Operator's Manual.

The exterior lighting remains lit for 40 seconds after the vehicle is unlocked. When you start the engine, the locator lighting is switched off and the automatic driving lights are activated.

Call up Vehicle Settings (Y page 42).

To select Locator Lighting: turn and press the controller.

Press the controller. The function is switched on or off, depending on the previous status.

You can find further information on the locator lighting in the vehicle Operator's Manual.

Activating/deactivating the automatic door locking mechanism

The vehicle is locked automatically when the ignition is switched on and the vehicle is traveling faster than walking pace.

Call up Vehicle Settings (Y page 42).

To select Automatic Locking: turn and press the controller. The function switches on or off, depending on the previous setting.

You can find further information on the locking feature in the vehicle Operator's Manual.

Rear view camera

Setting the switch-off delay time

Interior lighting switch-off delay time

The interior lighting is activated for the duration of the switch-off delay time when the SmartKey is removed from the ignition lock.

Call up Vehicle Settings (Y page 42).

To select Interior Lighting Delayed

Switch-off: turn and press the controller.

The setting element is active.

To change the delayed switch-off time: turn and press the controller.

You can find further information on the interior lighting in the vehicle Operator's Manual.

Exterior lighting switch-off delay time

If you switch on the Exterior Lighting

Delayed Switch-off function, the exterior

lighting is switched on for a short time after the engine is switched off. The light switch must be set to c; see the vehicle Operator's Manual.

The exterior lighting remains lit for 60 seconds after the engine is switched off. If you close all the doors and the tailgate, the exterior lighting switches off after the set time.

Call up Vehicle Settings (Y page 42).

To select Exterior Lighting Delayed

Switch-off: turn and press the controller.

The setting element is active.

To change the delayed switch-off time: turn and press the controller.

Rear view camera

General notes

The rear view camera covers the immediate surroundings behind the vehicle and assists you when parking.

The rear view camera is only an aid. It is not a replacement for your attention to your immediate surroundings. You are always responsible for safe maneuvering and parking. Make sure that there are no persons, animals or objects in the maneuvering area while maneuvering and parking in parking spaces.

You can find further information about the rear view camera in the vehicle Operator's Manual.

Vehicle functions

Climate control settings

Switching automatic mode of the rear view camera on/off

This function activates the rear view camera when reverse gear is engaged.

Press Vehicle in the main function bar. The vehicle menu is displayed.

Slide 6 the controller.

To select System Settings: turn and press the controller.

Select Rear View Camera.

Select Activation by R gear. The function is switched on O or off ª, depending on the previous status.

For further information on the rear view camera; see the vehicle Operator's Manual.

Vehicle functions

Climate control settings

Overview

You can adjust the climate control settings using the climate control bar ( the climate control menu (

Using the climate control bar you can set the most important climate control functions, for example:

Temperature (Y page 44)

Airflow (Y page 45)

Air distribution (Y page 44)

You can find all available climate control functions in the climate control menu. You can use the climate control bar ( to the climate control menu.

Y page 44) or

Y page 45).

Y page 44) to switch

Settings in the climate control bar

Overview

Adjusts temperature and air distribution and displays the current setting

;

Calls up the climate control menu, displays the current cooling and climate mode setting

Adjusts airflow and temperature and displays the current setting

Calling up the climate control bar

Press Vehicle in the main function bar. The vehicle menu is displayed.

Slide 6 the controller repeatedly until the climate control bar is activated.

Setting the temperature

Call up the climate control bar (Y page 44).

To select the current temperature on the left or right: turn and press the controller. The temperature setting scale appears.

To change the setting: turn the controller.

To close the temperature setting scale: press the controller.

You can also use the climate control menu

to set the temperature (

Y page 45).

Setting the air distribution

Call up the climate control bar (Y page 44).

To select the current air distribution display on the left or right, e.g. O: turn and press the controller. The air distribution setting scale appears.

To change the setting: turn the controller.

To close the temperature setting scale: press the controller.

You can also use the climate control menu

Y page 45) to set the air distribution.

(

Setting the airflow

Call up the climate control bar (Y page 44).

To select J: turn and press the controller. The airflow setting scale appears.

To change the setting: turn the controller.

To close the temperature setting scale: press the controller.

You can also use the climate control menu

Y page 45) to set the airflow.

(

Calling up the climate control menu

Press Vehicle in the main function bar. The vehicle menu is displayed.

Slide 6 the controller repeatedly until the climate control bar is activated.

To select from climate control bar ;: turn and press the controller. The menu for selecting the climate control function is activated.

To select the climate control function: turn and press the controller. The selected climate control function appears.

Climate control settings

To change the setting: turn the controller.

To exit the menu: press the % button.

The current airflow setting is shown in the climate control bar: DIFFUSE (Y page 44).

Settings in the bottom bar of the climate control menu

Activating/deactivating climate control

This setting is made in the bottom bar of the climate control menu.

Call up the climate control menu (Y page 45).

Slide 6 the controller repeatedly until the bottom bar is activated.

To select O Climate Ctrl On: turn and press the controller. The climate control is switched on O or off ª depending on the settings.

If the climate control is switched off:

the climate control setting functions are deactivated.

the blower is switched off.

the air recirculation flaps are closed.

Switching cooling with air dehumidification on/off

This setting is made in the bottom bar of the climate control menu.

Call up the climate control menu (Y page 45).

Slide 6 the controller repeatedly until the bottom bar is activated.

To select O A/C: turn and press the controller.

Switch cooling with air dehumidification on O or off ª.

, MEDIUM or FOCUS

Vehicle functions

Adjusting the climate mode settings

By setting the climate mode you determine the type of airflow. The setting is active when the air conditioning system is set to Ã, see the vehicle Operator's Manual.

Call up the climate control menu (Y page 45).

To select Climate Mode: turn and press the controller.

The current status of the cooling function is

displayed in the climate control bar: A/C ON – activated, A/C OFF – deactivated

Y page 44).

(

Deactivating the cooling with air dehumidi-

fication function reduces fuel consumption.

DYNAMIC SELECT

Synchronizing the climate control settings

Use O Sync (synchronization) to select the climate control setting for all zones together O or separately ª.

This setting is made in the bottom bar of the climate control menu.

Call up the climate control menu (Y page 45).

Slide 6 the controller repeatedly until the bottom bar is activated.

To select O Sync: turn and press the controller.

Switch the synchronization function on O or off ª.

For further information on synchronizing climate control settings (see the vehicle Operator's Manual).

Vehicle functions

DYNAMIC SELECT

General notes

You can use DYNAMIC SELECT to configure the following settings for the Individual drive program:

Drive system

Suspension

Transmission

Sports exhaust system

ESP®(Electronic Stability Program)

In addition, current vehicle and engine data can be visualized via the two further Vehicle Data and Engine Data menus.

There may be fewer settings depending on the vehicle equipment.

Configuration via the DYNAMIC SELECT controller

Use the DYNAMIC SELECT controller to select the Individual Configuration

drive program (see the vehicle Operator's Manual). A window appears after a short while.

To confirm Adjust: press the controller. The Individual Configuration

menu for

setting the drive program appears.

To select Drive, Suspension, Transmis‐

sion, Exhaust Systemor ESP: turn and press

the controller. The menu symbol, text and image show the selected setting.

Displaying vehicle data

There may be fewer displays depending on

your vehicle's equipment.

Press Vehicle in the main function bar. The vehicle menu is displayed.

To select DYNAMIC SELECT: turn and press the controller. The Individual

Data and Engine Data menus appear.

Select Vehicle Data. Updates of the following data are displayed:

Road type analogous to the selected drive program

G-force display of longitudinal and lateral acceleration

Accelerator and brake pedal activity

Activity of the suspension struts

Wheel angle

Overrun mode animation

The G-force display is not available in all of the drive programs.

Daytime or night-time view is shown depending on the automatic light sensor.

Configuration, Vehicle

Displaying engine data

There may be fewer displays depending on

your vehicle's equipment.

DYNAMIC SELECT

Press Vehicle in the main function bar. The vehicle menu is displayed.

To select DYNAMIC SELECT: turn and press the controller. The Individual

Configuration, Vehicle

Data and Engine Data menus appear.

Select Engine Data. The following current data is displayed:

Engine output

Engine torque

Transmission oil temperature

Engine oil temperature

Setting options

You can choose from the following settings for the drive:

R Race

C Comfort

S Sport

S+ Sport +

You can make the following settings for the suspension:

You can choose from the following settings for

the ESP

(Electronic Stability Program):

S Sport

Activates ESP®(Electronic Stability Program)

Vehicle functions

C Comfort

S Sport

S+ Sport +

You can choose from the following settings for the transmission:

D Automatic

M Manual

You can make the following settings for the sports exhaust system:

C Comfort

S+ Sport +

Introduction

Your multimedia system equipment

Read the information on qualified specialist workshops in the vehicle Operator's Manual.

Introduction

Important safety notes

Navigation

WARNING

You must observe the legal requirements for the country in which you are currently driving when operating the multimedia system.

The multimedia system calculates the route to the destination without taking the following into account, for example:

traffic lights

stop and yield signs

merging lanes

parking or stopping in a no parking/no stopping zone

other road and traffic rules and regulations

narrow bridges

The multimedia system may give incorrect navigation commands if the actual street/traffic situation does not correspond with the digital map's data. For example, a route may have bee d

iverted or the direction of a one-way street may

have changed.

Navigation announcements are intended to direct you while driving without diverting your attention from the road and driving.

General notes

Operational readiness of the navigation system

The navigation system must determine the position of the vehicle before first use or whenever operational status is restored. Therefore, you may have to drive for a while before precise route guidance is possible.

GPS reception

Among other things, correct functioning of the navigation system depends on GPS reception. In certain situations, GPS reception may be impaired, there may be interference or there may be no reception at all, e.g. in tunnels or parking garages.

Entry restriction

For vehicles in certain countries, there is a data entry restriction.

The restriction is active from a vehicle speed of above approximately 3 mph (5 km/h). As soon as the speed falls below approximately 2 mph (3 km/h), the restriction becomes inactive.

When the restriction is active, certain entries cannot be made. Menu items are shown in gray and cannot be selected.

For example:

entering the destination city and street

entering a destination via the map

entering POIs in the vicinity of a city or via a

name search

editing entries

Other entries are possible, such as entering points of interest in the vicinity of the destination or current position.

Switching to navigation mode

Traffic reports can be received or traffic reports are available

To show the menu: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

Introduction

To hide: press the % button.

Slide 5 the controller. Full screen symbol : appears.

Press the controller.

Moving the map

Navigation

Showing/hiding the menu

Using the menu, you can make a destination entry or select the navigation settings, for example.

To show: slide 6 the controller when the map appears.

Swipe down the touchpad with one finger. If there has been no route calculated, Des‐

tination is marked.

If a route has been calculated, y is marked.

Requirement: the map is in full screen mode, the menu is faded out (

Press the controller.

Y page 49).

The crosshair is shown.

Slide 1, 4 or 2 the controller. The map moves in the corresponding direction under the crosshair.

Enter a destination using the map

Y page 60).

(

Basic settings

Selecting the route type

To switch to navigation mode: slide 5 the controller.

Navigation

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Options: turn and press the controller.

Select Route Settings.

Select a route type. A filled circle indicates the current selection.

Active route guidance: the multimedia system calculates a new route.

Inactive route guidance: the multimedia system uses the selection as the new setting.

Route guidance active: a destination has

been entered and the route has been calculated.

Route guidance inactive: no destination has been entered yet and no route has been calculated yet.

Fast Route

Dynamic Traffic Route

The multimedia system calculates a route with a short travel time.

Based on the Fast Route route type and includes traffic reports on the route for the route guidance.

Eco Route

The multimedia system calculates an economical route. The journey may take slightly longer compared to taking the fast route.

Short Route

The multimedia system calculates a short distance route.

The Dynamic Traffic Route route type uses real-time traffic reports from SIRIUS satellite radio.

Further Information on real-time traffic reports

Y page 74).

(

To calculate alternative routes: select

Calculate Alternative Routes

Switch the function on O or off ª. Function activated: after each route calcula-

tion, route alternatives are offered that correspond to the local conditions (

Y page 72).

If desired, you can have the multimedia system calculate alternative routes even during route guidance (

Y page 72).

Setting route options

To avoid/use route options: select Avoid

Options.

A menu appears.

Select one of the options.

O: using or avoiding route options is enabled ª: using or avoiding route options is disabled

Menu item Avoid Area (Y page 82) The multimedia system enables you to avoid

areas you do not wish to drive through.

Menu item Avoid Highways

Menu item Avoid Ferries

Menu item Avoid Auto Trains

Basic settings

Menu item Avoid Tunnels

Menu item Avoid Unpaved Roads The function is not available in all countries.

Menu item Use Toll Roads The route calculation includes roads which

require you to pay a usage fee (toll).

Menu item Use Carpool Lanes If your vehicle meets the access conditions

for carpool lanes, you can use this function. Navigation includes carpool lanes if the car-

pool lanes option is activated.

Depending on local conditions, the multimedia system may not always be able to include all route options. A route may include a ferry, for instance, even though Avoid Ferries

is enabled. The multimedia system will notify you of this visually and through a navigation message.

To use toll roads: turn and press the controller. A menu appears.

Select an option. The options include using roads that require cash payment or electronic billing, or switching off the function.

To exit a menu: slide 8 the controller.

Selecting announcements

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Options: turn and press the controller.

Select Settings.

Select an option. Switch the option on O or off ª.

Announce Street Names

The multimedia system announces the names of the roads onto which the upcoming change of direction leads.

The function is not available in all countries.

Audio Fadeout

The volume of an active media source is automatically reduced during a navigation announcement.

Gas on Reserve

Function activated: once the reserve fuel tank level is reached, a message appears to help you start a gas station search.

Atten‐ tion Assist

Function activated: if ATTENTION ASSIST displays a warning in the multifunction display, a message appears in the multimedia system display when you drive on a highway. This can help you start a rest stop search.

For further information on ATTENTION ASSIST, see the vehicle Operator's Manual.

Using car pool lanes

You can include carpool lanes (HOV or car sharing lanes) in the route calculation.

If you use HOV or carpool lanes, please observe the applicable laws as well as the local and time limitation conditions.

Carpool lanes may only be used under certain conditions. They can normally be used when there are two people in the vehicle. However, there are also carpool lanes which can only be used when there are three or more people in the vehicle. If the vehicle's emission or consumption values are below the prescribed levels, lone drivers may also use the carpool lanes in California.

Carpool lanes may be reserved for specific times (e.g. during the peak period).

Navigation

Destination entry

Carpool lanes are indicated by a diamond symbol on specific road signs and on the road surface. The road signs may also include the designation CARPOOL. The lanes are arranged as a separate lane next to the others or are built as a physically separate lane.

Depending on the setting under Use Carpool

Lanes, the multimedia system uses carpool

lanes when calculating the route. During route guidance, visual and audible driving directions provide guidance into and out of carpool lanes.

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the

Navigation

controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Options: turn and press the controller.

Select Route Settings.

Select Avoid Options.

Select Use Carpool Lanes. Carpool lanes will either be used O or avoided ª when calculating the route.

Destination entry may be blocked while driving, depending on the country specifications.

General notes

The various character entry options are described for the controller. Alternatively you can use the touchpad to enter characters and select

Y page 21).

menus (

Using an address

Calling up the address entry menu

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Destination: turn and press the controller.

Select Address Entry.

Destination entry

Important safety notes

WARNING

You must observe the legal requirements for the country in which you are currently driving when operating the multimedia system.

Address entry options

Examples of how you can enter an address:

City/ZIP code, street, house number

City/ZIP code, street

City/ZIP code, center

City/ZIP code, street, intersection

Street, City/ZIP code, house number

Street, City/ZIP code, intersection

The address can be entered faster by entering the street before the city if the address has an unusual street name.

While entering an address, you can also switch to other destination entry options:

Keyword search (Y page 55)

Map (Y page 60)

POI (Y page 57)

Entering an address

The example shows you how to enter a city, street and house number for an address, e.g. for your home address.

Call up the address entry menu (Y page 52).

To select Street: turn and press the controller.

Enter BROADWAY. Character entry (Y page 29).

To call up the list: slide 5 the controller

repeatedly until the character bar disappears.

To select OK, turn and press the controller.

Destination entry

Enter the house number.

Confirm the entry. The address entry menu shows the address.

The city in which the vehicle is currently located (current vehicle position) is at the top of the list of cities. When entering an address as the destination, the locations for which route guidance has already been carried out are more prominently available.

You can enter any of the cities, streets, ZIP codes, etc. which are stored in the digital map.

State/province and city are sufficient to start navigating. You can enter either a city or a ZIP code. The street and house number complete the destination address.

Entering additional address data

You can enter additional address data:

State/province You can use Last Used

selected state (USA) or province (Canada). You can also select Mexico and The Bahamas.

ZIP code Entering a ZIP code will delete a previously

entered city.

Center Entering a center will delete a previously

entered street.

Intersection Entering an intersection will delete a previ-

ously entered house number.

Call up the address entry menu (Y page 52).

To select State/Province, ZIP Code, Cen‐

ter or Intersection: turn, slide 6 and

press the controller.

Enter and select the address element.

to select the last

Navigation

To select Town: press the controller.

Enter the city, e.g. New York. Then call up the list and select an entry. Proceed in the same way as when entering a street.

To select No.: press the controller.

Saving an address

You can store the address entered as:

a home address in the address book

a navigable address book contact For further information on the address book,

Y page 102)

see (

a personal destination on the SD card

Y page 78)

(

Destination entry

Call up the address entry menu (Y page 52).

To select Save: slide 6, turn and press the controller.

As the home address: select As "My

Address".

The home address is stored in the list of contacts under the entry My Address

Navigation

As a contact: select As New Contact.

Select Not Classified, Home or Work.

Enter a surname and first name (Y page 28).

To select OK: turn and press the controller. The destination address is saved in the address book as a navigable contact.

Starting route calculation

To view the vicinity of the destination

The entered destination appears in the address entry menu.

To confirm Start or Continue: press the controller. If you select Start with the current route settings ( While route calculation is in progress, an arrow will indicate the direction to your destination. Once the route has been calculated, route guidance begins. If the vehicle is traveling on a non-digitized road, the system displays the linear distance to the destination,

: the route is calculated

Y page 50).

the direction to the destination and the Road

Not Mapped message.

Selection Continue

: if Calculate Alter‐

native Routes is activated, alternative

routes are calculated. These can be displayed and selected for route guidance

Y page 72).

( If route guidance has already been activated,

a prompt will appear asking whether you wish to end the current route guidance.

To select Yes or Set as Intermediate

Destination: turn and press the controller.

cancels the current route guidance and

Yes

starts route calculation to the new destination.

Set as Intermediate Destination

the new destination in addition to the existing destination and opens the intermediate destinations list.

The route is calculated using the digital map

data. The calculation time depends on the distance from the destination, for example.

The calculated route may differ from the ideal route, e.g. due to roadworks or incomplete map data. Please also refer to the notes about the digital map (

To call up the keyword search: select è

Y page 84).

by sliding 6, turning and pressing the controller in the address entry menu.

To view the vicinity of the destination: to select :, turn and press the controller. You can explore the destination area.

Requirement for exploring a destination (USA): mbrace must be activated for Internet

Y page 118).

access ( Requirement for exploring a destination (Can-

ada): a mobile phone is connected to the multimedia system via Bluetooth

Y page 151).

or USB (

(Y page 90)

adds

Destination entry

Keyword search

Entering keywords

The keyword search is used to help find destinations using fragments of words. The keyword search is tolerant of errors.

It can be used for an address or a POI. For example, you can search for the Empire State Building in New York.

The keyword search finds geographically tolerant hits. If, for example, you are searching for a street located on the edge of a major city, the search will also cover adjacent smaller cities.

The keyword search supports languages using Latin characters.

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Destination: turn and press the controller.

Select Keyword Search.

Enter the first few letters of the city and street, e.g. NEW While entering the information, the number of exact matches/all hits is shown.

---/---

acters have been entered.

is displayed if there are too many hits.

999+

Select the ¬ symbol. The search results are displayed

Y page 55).

(

and EMP.

is displayed if fewer than three char-

Selecting search results

The search results are divided into categories, such as addresses. The number of exact/total hits is shown in brackets.

Further search results are displayed, if POI

Search and/or Fuzzy Search are activated in

the search options (

To select Addresses : press the controller. The search results are displayed.

Exact hits are shown at the very top of the list. Hits are listed alphabetically. The search term that you entered is highlighted in orange in the entries.

Select an entry: turn and press the controller. The address entry menu appears, showing the destination address.

To start route calculation: select Start.

To select a POI: select POIs in the Vicin‐

ity or All POIs by turning and pressing the

controller. A list appears. The search results are displayed according to the linear distance, starting with those closest.

Select a POI. The POI is shown.

To start route calculation: select Start.

Y page 56).

Navigation

Destination entry

To use online search: select Online

Search by turning and pressing the control-

ler. The search switches to the online functions.

Online search requirement (USA): mbrace must be activated for Internet access

Y page 118).

( Requirement for the online map display (Can-

ada): a mobile phone is connected to the multimedia system via Bluetooth

Y page 151).

or USB (

(Y page 90)

Selecting search options

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller.

Navigation

The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Destination: turn and press the controller.

Select Keyword Search.

To select Search Options: slide 5, turn and press the controller.

Select Fuzzy Search or POI Search. Switch the setting on O or off ª.

The error-tolerant search is useful if parts of the address are incomplete or the spelling is unclear.

The POI search takes into account points of interest in the search.

To select State/Province: slide 5, turn and press the controller. States/provinces are sorted alphabetically.

To select a state/province: turn and press the controller.

Using online search

Requirement (USA): mbrace must be activated for Internet access (

Requirement (Canada): a mobile phone is connected to the multimedia system via Bluetooth (Y page 90) or USB (Y page 151).

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Destination: turn and press the controller.

Select Keyword Search.

To select Online Search: slide 5, turn and press the controller. The search switches to the online functions.

Y page 118).

Selecting a destination from the list of last destinations

Selecting a state/province

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Destination: turn and press the controller.

Select Keyword Search.

The last 50 destinations are stored automatically.

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

Destination entry

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Destination: turn and press the controller.

Select From Previous Destinations.

Select the destination. The address entry menu appears, showing the destination address.

To start route calculation: select Start.

Selecting an address book contact as a destination

You can select navigable address book contacts as the destination. These are identified by the L symbol. If you have already entered and saved your home address, you can select this as the destination by using My Address

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Destination: turn and press the controller.

Select From Contacts.

Select the destination. The address entry menu appears, showing the contact and associated destination address.

To start route calculation: select Start.

Selecting a destination from POIs

Calling up the POI menu

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Destination: turn and press the controller.

Select From POIs.

Navigation

Selecting a POI category

Destination entry

Select a category or one of the searches listed in the table. The G symbol after an entry shows that further categories are available.

Select a sub-category. The search for POIs starts.

If route guidance is active, first define the position for the POI search (

Y page 58).

If no route guidance is active, the POI search covers a 240 mile (400 km) radius around the current vehicle position.

Once the search is completed, the POI list is displayed. The search results display the following information:

an arrow that shows the linear direction to the POI (search around vehicle position)

the linear distance to the POI

the name of the POI

Select a point of interest (Y page 59). The complete address of the POI is shown.

Selection Instructions

Navigation

Search By Name

The search looks for all POIs on the digital map or

To select Search By Name: turn and press the controller.

Select All POIs or a position for the POI search.

The search for POIs starts. around one of the three previously specified posi-

Y page 58).

tions (

Search By Phone Num‐ ber

All POIs with a telephone

To select Search By Phone Number: turn and press the control-

ler.

The search for POIs starts. number can be selected.

Defining the position for the POI search

The POI search covers a 240 mi (400 km) radius around the selected position.

Selection Instructions

Near Destination

The search is performed in the vicinity of the desti-

Select a category or Search By Name (Y page 57).

Select Near Destination. The search for POIs starts.

nation.

Current Position

Searches in the vicinity of the current vehicle posi-

Select a category or Search By Name (Y page 57).

Select Current Position. The search for POIs starts.

tion.

Other City

After entering a city, the search is performed within the city's boundaries

Option 1

Call up the POI menu (Y page 57).

To select Other City: turn and press the controller.

Select the state/province (Y page 53), if desired.

Enter the city (Y page 53).

Select a POI category (Y page 57).

Option 2

Enter a city in the address entry menu (Y page 53).

To select POIs: slide 6, turn and press the controller.

Select a POI category (Y page 57).

Selecting a POI

Requirement for "Calling up a POI": a mobile phone must be connected to the multimedia system (

Requirements for "Viewing the vicinity of the destination" and "Loading data from the Internet" (USA): mbrace must be activated for Internet access (

Requirements for "Viewing the vicinity of the destination" and "Loading data from the Internet" (Canada): a mobile phone must be connected to the multimedia system via Bluetooth (Y page 90) or USB (Y page 151).

The complete address of the POI is shown.

Y page 90).

Y page 118).

Destination entry

To view the vicinity of the destination:

select : by turning and pressing the controller. If street images are available, the street in the vicinity of the destination address is shown.

To call up the map: select Map.

Move the map, change the map scale

Y page 60) and select the POI.

( 3D POIs can be displayed in an all-round view

Y page 60)

(

To call up a POI: select Call. If a phone number is available, the multimedia system switches to the telephone function.

To load data from the Internet: select www. If an Internet address is available, data is loaded from the Internet.

To store a POI: select Save. The POI can be saved as:

home address

a navigable address book contact

Y page 102)

(

a personal destination on the SD card

Y page 78)

(

To start route calculation: select Start or

Continue

troller.

by turning and pressing the con-

Navigation

Destination entry

If Calculate Alternative Routes is acti-

Y page 50), Continue is available.

vated (

Rotating a 3D POI

Realistically modeled buildings are shown on the map in an all-round view. These 3D POIs are sights or buildings of regional importance, e.g. a main railway station.

3D POIs can be turned on the 20 m, 50 m and 100 m map scales. To aid orientation, the points of the compass are shown while turning.

Select a point of interest (Y page 59).

To select Map: turn and press the controller.

Select a 3D POI from the map using Previous or Next. If the 3D POI is marked in gold, you can select

Navigation

Select 3D. The 3D POI turns on its own axis.

To exit the all-round view, press the controller.

Using the map

Select Using Map. The map with crosshair is shown.

To move the map: slide 1, 4 or 2 the controller.

To change the map scale: turn the controller until the desired map scale is selected. The scale is displayed at the bottom.

To enlarge the map: turn the controller counter-clockwise.

To zoom the map out: turn the controller clockwise.

To select a destination: press the controller.

To select a destination from the selection list: turn and press the controller. If the digital map provides navigable address data, you will see the destination address in the address entry menu.

To start route calculation: select Start.

Entering intermediate destinations

Introduction

You can also map the route to the destination yourself by entering up to four intermediate destinations. The sequence of the intermediate destinations can be changed at any time.

The multimedia system provides a selection of predefined destinations in eight categories for this purpose, such as Gas Station also use the destination entry options to enter intermediate destinations.

. You can

Crosshair

;

Distance of crosshair position from current vehicle position

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Destination: turn and press the controller.

Creating intermediate destinations

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Destination: turn and press the controller.

Select Intermediate Destinations.

To select a POI category or Other: turn and press the controller. After selecting one of the eight POI categories, available POIs are displayed:

along the route

in the vicinity

The multimedia system first searches for destinations on the route. The search for destinations is then initiated in the area around the current vehicle position.

After selecting Other, select one of the destination entry options.

Selection Step

Address Entry

Keyword Search

From Previ‐ ous Destina‐ tions

From Con‐ tacts

From POIs

Using Map

From Memory Card

From MercedesBenz Apps

Using GeoCoordinates

Enter a destination by address (

Select a destination

Y page 52).

using a keyword search

Y page 55).

(

Select a destination from the list of last destinations (

Select a contact from

Y page 56).

the address book as the destination (

Select a point of interest

Y page 59).

(

Enter a destination using the map (

Select a personal POI

Y page 65).

(

Enter a destination from

Y page 57).

Y page 60).

Mercedes-Benz Apps

Y page 62).

(

Enter a destination using the geo-coordinates

Y page 63).

(

Destination entry

To select a POI: turn the controller and press to confirm. After selecting a POI or entering a destination, the address of the intermediate destination is displayed.

After the destination is entered via the map, the address is displayed.

To call up a map: select Map by turning and pressing the controller. You can move the map and select the destination.

To make a call: select Call. If the intermediate destination has a telephone number and a mobile phone is connected to the multimedia system

Y page 90), the call is connected.

(

To load data from the Internet: select www. If an Internet address is available, data is loaded from the Internet.

To store an intermediate destination in

the destination memory: select Save (Y page 77).

To accept an intermediate destination:

select OK The destination is entered in the intermediate destinations menu.

To enter another intermediate destina-

tion: slide 5 the controller and highlight

Add New:

Press the controller.

Proceed as described above.

Editing intermediate destinations

You can perform the following functions:

change intermediate destinations

switch the sequence of the intermediate destinations in the intermediate destinations menu

delete intermediate destinations

by pressing the controller.

Navigation

Destination entry

You cannot edit POIs.

To select an intermediate destination in the intermediate destinations menu: turn and press the controller. A menu appears.

To change an intermediate destination:

Navigation

select Edit

Change the address, e.g. the city and street.

To select OK: turn and press the controller.

in the menu.

The intermediate destinations menu appears and displays the changed intermediate destination.

You can enter the intermediate destinations and the destination in any order. To change the order, at least one intermediate destination and the destination must be entered.

To change the order: in the menu, select

Move

Turn the controller and move the intermediate destination or destination to the desired position.

Press the controller.

To delete an intermediate destination:

select Delete

in the menu.

Accepting intermediate destinations for the route

To select Start Route Guidance in the intermediate destinations menu: press the controller. The route is calculated with the entered intermediate destinations.

If an intermediate destination was passed during route guidance, a green tick mark will be entered in the intermediate destinations menu. Once the route has been recalculated, the intermediate destination is deleted from the intermediate destinations menu.

Saving as a personal route

You can save a route including intermediate destinations on the SD card.

Requirements: the SD card has the FAT data system format (e.g. FAT32).

Insert the SD memory card (Y page 139).

To select Save As Personal Route in the intermediate destinations menu: press the controller. An input field appears.

Enter a file name in the input field. Press OK to confirm. The route is saved to the SD memory card.

Searching for a gas station when the fuel level is low

Requirement: the setting Gas on Reserve must be enabled (

If the fuel tank reserve level is displayed, you will see the Reserve Fuel Would you like to

start a search for surrounding gas stations? message.

To select Yes or No: turn and press the controller. If you select Yes starts. When the search is complete, a list of the gas stations available along the route or in the vicinity is displayed.

If you select No

Select the gas station. The address of the gas station is displayed.

To select Start: press the controller. The selected gas station is entered into position 1 of the intermediate destinations menu. Route guidance begins.

If the intermediate destinations menu already contains four intermediate destinations, a prompt will be displayed, asking you whether you wish to enter the gas station into position

1. If you select Yes ferred into the list and intermediate destination 4 is deleted.

Y page 51).

: the gas station search

: the search is canceled.

, the gas station is trans-

Entering a destination from Mercedes-Benz Apps

Requirement (USA): mbrace is activated for the Mercedes-Benz Apps (

Y page 118).

Personal POIs and routes

Requirement (Canada): a mobile phone is connected to the multimedia system via Bluetooth (Y page 90) or USB (Y page 151).

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Destination: turn and press the controller.

Select From Mercedes-Benz Apps. The list of Mercedes-Benz Apps appears.

Using geo-coordinates

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Destination: turn and press the controller.

Select Using Geo-Coordinates. Geo-coordinates (longitude and latitude) are entered in degrees, minutes and seconds.

To enter geo-coordinates: turn the controller. The value for degree, minute or second changes.

To move the selection within the line: slide 1 the controller.

To move the selection between lines: slide 4 the controller.

To confirm the value: press the controller.

To store geo-coordinates: select Save by turning and pressing the controller. The destination with the geo-coordinates can be saved as:

a home address in the address book

a navigable address book contact

For further information on the address book, see (

a personal destination on the SD card

Y page 78)

(

To start route calculation: select Start

Y page 102)

Route Guidance by turning and pressing the

controller.

Personal POIs and routes

General notes

The use of personal POIs for displaying traffic surveillance equipment is not permitted in every country. Please observe the country-specific regulations and always drive at a suitable speed.

Personal POIs are filed in categories:

Not Classified

Standard entry for personal POIs

Mercedes-Benz Apps

Personal POIs (destinations, routes) that you have imported via the online functions.

Categories which you have created yourself, e.g. on your PC

Personal routes are not categorized.

Settings for personal POIs

Displaying on the map

Requirements: an SD card with personal POIs is inserted (

The SD card has the FAT data system format (e.g. FAT32).

All personal POIs of the selected category are displayed on the map with a corresponding symbol.

Y page 139).

Navigation

Personal POIs and routes

If the "Alert when approaching" function is acti-

Y page 64), the symbols are displayed

vated ( up to a map scale of 2 mi.

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Options: turn and press the controller.

Select Personal POIs.

Select Display on the Map.

Navigation

The menu displays the categories available on the SD card.

To select a category: turn and press the controller. All personal POIs in the selected category are displayed O or not displayed ª, depending on the previous status.

Alert when approaching

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Options: turn and press the controller.

Select Personal POIs.

Select Approaching POI Cue. The menu displays the categories available on the SD card.

Select Audible or Optical. The function is switched on O or off ª, depending on the previous status.

To select a category: turn and press the controller. The function is switched on O or off ª, for all personal POIs of this category, depending on the previous setting.

Saving personal POIs and routes

General notes

Personal POIs and routes are geodata which are saved in open GPX format (GPS Exchange format) on the SD card.

Requirements: the SD card has the FAT data system format (e.g. FAT32).

Requirements: an SD card with personal POIs is inserted (

Y page 139).

The SD card has the FAT data system format (e.g. FAT32).

If the vehicle is approaching a personal POI, this is highlighted on the map and/or an audible signal sounds.

For this purpose, both the corresponding function Approaching POI Cue

and the category

containing the personal POI must be activated.

Personal POI from current vehicle position or crosshair position

Insert the SD memory card (Y page 139).

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

When the map is displayed, press the controller until a message appears. The current vehicle position is saved to the

Not Classified

category on the SD card

Personal POIs and routes

and also stored in the "Last destinations" memory (

Y page 79).

If the "Move map" function is selected

Y page 49), the crosshair position is saved.

(

If no SD card is inserted, the personal POI

will only be stored in the "Last destinations" memory.

Personal POI from destination address

Insert the SD memory card (Y page 139).

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

Call up the address entry menu and enter the destination address (

To select Save, slide 6 the controller.

Turn and press the controller.

To make a selection, turn and press the con-

Y page 52).

troller.

Enter the name.

Select a category. The current address is saved as a personal POI on the SD card.

You can select a destination from the From

Previous Destinations or From Contacts

memories and save it on the SD card.

From Previous Destinations

(Y page 56)

From Contacts (Y page 57)

Personal route from a tour including intermediate destinations

Insert the SD memory card (Y page 139).

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

Enter a destination, e.g. by address

Y page 53).

(

Start route calculation (Y page 54).

Enter an intermediate destination

Y page 60).

(

Select Save As Personal Route in the intermediate destinations menu. The route is saved in the Personal Routes folder on the SD card.

Importing personal destinations and routes via Mercedes-Benz Apps

You can import destinations and routes into the navigation via the Mercedes-Benz apps. These have their own symbol and are filed in the

Mercedes-Benz Apps

category.

Mercedes-Benz apps are, for example:

Download POI

Local Search

You can save the imported destinations and routes as personal POIs and routes (

Y page 64).

When importing routes, please note:

The Mercedes-Benz Apps may generate a route based on a different map from the one used by the multimedia system. Points on the route may therefore be situated off the digital roads.

The Mercedes-Benz Apps minimize the number of route points offered.

For this reason an imported route commenced in the multimedia system may deviate from the original route from the Mercedes-Benz Apps.

Selecting and editing personal POIs and routes

Selecting

Navigation

Personal POIs and routes

The example shows a personal POI.

Insert the SD memory card (Y page 139).

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Destination: turn and press the controller.

Select From Memory Card. The menu displays the categories available on the SD card.

Navigation

To select a category or Personal Routes, turn and press the controller. The available personal POIs or route entries are displayed.

Select personal POI or personal route. The address of the personal POI appears or the personal route is displayed in the map.

If a large number of entries are stored, a register for quick selection appears. Personal POIs and routes can be saved and sorted with different character sets (e.g. Latin, Cyrillic, Arabic).

To select a register: slide 9 the control- ler.

To select a character: turn and press the controller.

To select a character set for sorting: slide

9 the controller to select B.

Press the controller. The available character sets are displayed. The # dot indicates the current setting.

Turn and press the controller.

Editing

The example shows a personal route.

Select personal POI or personal route

Y page 65).

(

To explore a personal POI or personal

route: turn and press the controller to select

Map

The map with the crosshair appears and shows the destination.

Scroll the map (Y page 49).

Set the map scale (Y page 79).

To switch to the menu: press the % button.

To call the personal POI: turn and press the controller to select Call

. If a mobile phone is connected to the multimedia system and the telephone number is available, the call is connected (

To save a personal POI: turn and press the controller to select Save

Continue saving (Y page 77).

To edit the name and symbol: turn and press the controller to select Edit

Select Change Name or Edit Icon.

Character entry (Y page 28).

Select a symbol.

To delete a personal POI or route: turn and press the controller to select Delete

Y page 96).

A prompt will appear.

Select Yes or No. If you select Yes

, the personal destination or

personal route is deleted.

To select the outward and return route:

select Swap

by turning and pressing the controller. The starting and destination positions of your personal route, and thus the direction for route guidance, are switched round. One-way streets or restricted intersections are taken into consideration. Therefore, the outward and return routes may differ from each other.

To start route guidance: turn and press the controller to select Start

Recording the route

General notes

Routes are recorded using the SD card. Requirements: the SD card has the FAT data

system format (e.g. FAT32).

Route guidance

When recording the route, bear in mind the following:

If the SD card is inserted, it must not be removed during recording.

If route recording is started manually, it must be finished manually before the multimedia system is switched off (e. g. when the engine is switched off).

The multimedia system minimizes the number of route points recorded. Therefore when the recorded route is subsequently commenced, it may differ from the route that was originally recorded.

Starting/finishing route recording

Insert the SD memory card (Y page 139).

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Destination: turn and press the controller.

Select From Memory Card.

Select Start Route Recording. The route is recorded and REC appears at the bottom edge of the screen.

To stop recording, select End Route

Recording from the menu.

The route is stored under Personal Routes

Displaying/editing the recorded route

Insert the SD memory card (Y page 139).

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Destination: turn and press the controller.

Select From Memory Card.

Select Personal Routes. Previously recorded routes are displayed.

To select a route, turn and press the controller. The map appears with a menu. The recorded route is shown on the map in blue.

To calculate a route: select Start.

To change the name and symbol: select

Edit

Select Change Name or Edit Icon.

Character entry (Y page 28).

Select a symbol.

Route guidance

General notes

The multimedia system calculates the route to the destination without taking the following into account, for example:

traffic lights

stop and yield signs

parking or stopping restrictions

road narrowing

temporary traffic rules and regulations

The navigation system can give differing driving recommendations if the actual street/traffic situation does not correspond with the digital map's data. For example, if the road layout or the direction of a one-way street has been changed.

For this reason, you must always observe road and traffic rules and regulations during your

journey. Road and traffic rules and regulations always have priority over system driving recommendations.

Route guidance begins once a route has been calculated (

The multimedia system guides you to your destination by means of navigation announcements in the form of audible navigation announcements and route guidance displays.

The route guidance displays can be seen if navigation mode is switched on.

If you do not follow the navigation announcements or if you leave the calculated route, the multimedia system automatically calculates a new route to the destination.

Y page 54).

Navigation

Route guidance

If the digital map contains the corresponding information, the following applies:

During route guidance, the multimedia system tries to avoid roads with restricted access. These include, for example, roads which are closed to through-traffic.

Roads that have time restrictions (e.g. closed on Sundays and public holidays) are considered for route guidance on days when they are open. For this purpose, the relevant times must be correctly stored in the database.

Change of direction

Overview

Changes of direction have three phases:

Navigation

Preparation phase

Announcement phase

Change-of-direction phase

Changes in direction are also shown in the multifunction display of the instrument cluster (see the vehicle Operator's Manual).

Preparation phase

The multimedia system prepares you for the upcoming driving maneuver, e.g. with the announcement "Prepare to turn right". You see the full-screen map.

Announcement phase

The display is now split into two sectors. The map is shown on the left side of the display, and a detailed image of the intersection or a 3D image of the imminent change of direction is shown on the right side of the display.

Change-of-direction phase

The multimedia system announces the immediate change of direction. The change of direction is announced ahead of time, e.g. with the announcement "Now turn right".

The display is split in two like in the announcement phase.

The change of direction is performed when the light-color bar on the right drops down to 0 ft and the current vehicle position symbol has reached the white change-of-direction point.

When the change of direction is completed, the map will appear in full screen mode again.

Display on highways

Next road or direction

;

Point at which the change of direction takes place (white dot)

Change of direction (turn right here)

Distance to the next change of direction

The multimedia system announces the imminent change of direction.

The image shows an example of route guidance at a highway intersection when driving on a highway.

Route guidance

Lane recommendations

Display on multi-lane roads

Lanes not recommended (dark gray)

;

Possible lane (light gray)

Recommended lanes (white)

If the digital map contains the relevant data, the multimedia system can display lane recommendations on multi-lane roads for the next change of direction.

Lane not recommended :: you will not be able to complete the next change of direction if you stay in this lane.

Possible lane ;: you will only be able to complete the next change of direction in this lane.

Recommended lane =: in this lane you will be able to complete the next change of direction and the one after that.

The multimedia system shows the lane recommendations for the next two changes of direction. Lane recommendations are also shown in the multifunction display of the instrument cluster (see the vehicle Operator's Manual).

lane recommendations with a lower boundary line.

Highway information

Display mode

Requirement: the Highway Information map content must be enabled (

While driving on the highway, gas stations, rest stops, rest areas and highway exits are displayed along with their immediate distances from the current vehicle position.

Y page 81).

Calling up the selection mode

Navigation

Approaching new lanes

Approaching new lane

During the change of direction, new lanes may be added. These will be shown in the display of

When highway information is displayed, slide 9 the controller. The marker is on the highway information. The associated position is highlighted on the map.

To select the desired rest stop/freeway

exit: turn and press the controller. The available POIs are displayed.

Route guidance

Starting route guidance to a POI

To select a POI: turn the controller and press to confirm. The POI details are displayed.

You can perform the following functions:

Navigation

Store in the address book (Y page 77)

View on the map (Y page 82)

Called if a phone is connected and a phone number is available (

Select for route guidance and calculate a route to it (

Y page 54)

Y page 96)

Using the traffic jam function

Highway information enables the use of the traffic jam function. The remaining route on the highway in this case is blocked in the direction of travel from the selected exit.

To select Detour: turn and press the controller. The traffic jam function appears

Y page 73).

(

Destination reached

Once the destination is reached, you will see the checkered flag. Route guidance is finished.

Navigation announcements

Repeating navigation announcements

If you missed the current navigation announcement, you can call it up again.

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select +: turn and press the controller. The navigation announcement is repeated.

If the Repeat Spoken Driving Recom‐

mendations function has previously been

added as a favorite, you can alternatively select the function using the favorites button

Y page 31).

(

Setting the volume manually

During a navigation announcement, turn Ä the control knob.

When you start the engine, the volume is set

to the lowest setting.

Route guidance

Switching navigation announcements on/off

To switch off navigation announcements:

press the 8 button on the multifunction steering wheel during a navigation message.

To switch navigation announcements

back on: slide 6 the controller.

To select +: turn and press the controller.

The multimedia system automatically switches the navigation announcements back on when:

a new route is calculated

the vehicle is started

A navigation message is given if the route is recalculated during dynamic route guidance due to new traffic reports (

Y page 74).

Canceling/continuing route guidance

Canceling route guidance

Slide 6 the controller. The menu is shown.

To select Destination: turn and press the controller.

Select Cancel Active Route Guidance. The blue route line is no longer shown on the map.

Resuming route guidance

Slide 6 the controller. The menu is shown.

To select Destination: turn and press the controller.

Select Continue Route Guidance. The multimedia system calculates the route.

Route information

Destination information

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Route: turn and press the controller.

Select Destination Information. The destination and existing intermediate destinations are displayed with distances, travel time and arrival time.

To select destination or intermediate des-

tination: turn and press the controller. The address appears.

Select Save. The destination or intermediate destination can be saved as:

a navigable address book contact

a home address

To call up the map, select Map.

Move the map, change the map scale and select the destination or the intermediate destination (

To call the destination or intermediate destination, select Call If a phone is connected and a phone number is available, the multimedia system switches to the telephone function.

Y page 60).

Navigation

Route guidance

Taking an alternate route

If the Calculate Alternative Routessetting is activated O, different routes will be offered each time a route is calculated (

You can call up alternative routes to the current

Navigation

route. Routes 1, 2 and 4 are displayed with a dark blue

line. Route 3 is the most economic route and is dis-

played with a green line.

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Route: turn and press the controller.

Select Alternative Route. Route 1 is shown.

To display additional routes: select Next or

To start a new route guidance: select

Start

Y page 50).

Select Route List. The route list shows the next change of direction and the immediate distances from the current vehicle position.

To display additional route sections: turn the controller. The position of the change of direction that belongs to the respective route section is indicated on the map with a cross.

Where am I?

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Position: turn and press the controller.

Select Where am I?. The street you are currently on and the previous and next intersections are displayed.

Route list

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Route: turn and press the controller.

Route guidance

Traffic jam function

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Route: turn and press the controller.

Select Detour.

To specify the start of the traffic jam sec-

tion: select Beginning

. The next possible traffic jam section starting point is marked.

Turn the controller. The marking moves along the route to the next starting position.

Press the controller. The start of the traffic jam is set.

To specify the end of a traffic jam section:

select End

. The next possible traffic jam section end point is marked.

Turn the controller. The marking moves along the route to the next end position.

Press the controller. The end of the traffic jam is determined.

To calculate the detour: select Start.

Off-road

General notes

The navigation system may guide you to off-road routes that your vehicle cannot drive on without causing damage to the tires or wheels or the

vehicle itself. It is the driver’s sole responsibility to determine the suitability of the route. The condition of the off-road routes may vary. The navigability of off-road routes may be influenced by various factors such as time of day, time of year and prevailing weather conditions. The navigation system cannot judge these factors or take them into account for route guidance.

Route guidance to an off-road destination

The multimedia system can guide you to destinations which are within the area of the digital map, but which are not themselves on the map.

These destinations are known as off-road destinations, which you can enter using the map, for example. The multimedia system guides you for as long as possible with navigation announcements and displays on roads known to the system.

If the vehicle reaches an area which is not part of the digital map, the display appears as a splitscreen view. On the right, an arrow appears that points to the off-road destination. You hear the announcement: "Please follow the arrow on the display". As the vehicle approaches the destination, you will see a display to this effect.

Route guidance from an off-road location to a destination

Off-road location: the vehicle's position is on the digital map, but the map does not contain any information about that location. The multimedia system is able to guide you to a destination even from an off-road location.

At the start of route guidance, you will see the

Road Not Mapped

message, an arrow and the distance to the destination. The arrow shows the compass heading to the actual destination.

As soon as the vehicle is back on a road known to the system, route guidance continues in the usual way.

Off-road during route guidance

Due to road construction, for example, there may be differences between the data on the digital map and the actual course of the road.

In such cases, the system will temporarily be unable to locate the vehicle position on the digital map. The vehicle is therefore in an off-road position.

Navigation

Real-time traffic reports

In the display, you will then see the Road Not

Mapped message, an arrow and the distance to

the destination. The direction arrow shows the compass heading to the destination.

As soon as the system can assign the vehicle position to the map again, route guidance continues in the usual way.

Real-time traffic reports

Prerequisites

This function is currently not available for Canada.

In order to receive real-time traffic reports via satellite radio, you need to subscribe to SIRIUS XM Satellite Radio Traffic Message Service.

Navigation

Further information on satellite radio

Y page 131).

( The multimedia system can receive traffic

reports via satellite radio and take account of these for route guidance in the navigation system. Received traffic reports are displayed on the map either as text or as symbols.

Real-time traffic reports on the map

To hide the menu: slide 5 and press the controller. The map can be seen in the full-screen display.

To set the map scale: turn the controller until the desired map scale is selected.

Traffic jam on the route

;

Slow-moving traffic on the route

Road blocked

Traffic jam

Traffic warning

Dashed red and white line delimiting the traffic warning

Road block (crosses along the affected road)

Slow-moving traffic (orange line along the affected route)

Traffic jam (red line along the affected route)

The multimedia system can show certain traffic incidents on the map with symbols (type of incident) and colored lines (extent). Traffic reports are shown on the map at scales of 1/32 mi to 20 mi.

When : is displayed, traffic reports can be received or traffic reports are available. If it is not displayed, no reception is possible.

Displaying real-time traffic reports

Starting a search for traffic reports

Real-time traffic reports

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Traffic: turn and press the controller. If satellite signals cannot be received or there are no traffic reports, you will see a message to this effect.

To close the report: press the controller.

Traffic symbol information

Affected roads with indication of direction

;

Symbol for report type, e.g. traffic flow message

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Traffic: turn and press the controller.

To select Traffic Symbol Information: turn and press the controller. The map appears and shows the available traffic information as icons. The first traffic information is highlighted.

To highlight additional traffic symbols, select

or Previous.

To move the map: select Map. You can move the map to enable further traffic information to be displayed.

You can have the traffic report relevant to a traffic icon shown.

To select Details: turn and press the controller.

The report shows the following information:

State/province, road and display of the affected direction

Section of the road to which the traffic report applies

Traffic icon and traffic report

To close the detailed display: press the

% button.

Displaying reports on the route

The function is only available while route guidance is active. It shows the available traffic reports affecting the current route.

If there are no reports for the route or the function is not supported in the selected language: the Messages cannot be selected.

On Route menu item is gray and

Navigation

Real-time traffic reports

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Traffic: turn and press the controller.

To select Messages On Route: turn and press the controller. The traffic report window appears. Several traffic reports may be available for the calculated route, marked for example by 1/3.

The report shows the following information:

Navigation

State/province, road and display of the affected direction

Section of the road to which the traffic report applies

Traffic icon and traffic report

To display the next/previous traffic

report: turn the controller.

To close the display: press the % button.

Displaying all traffic reports

To select All Messages: turn and press the controller. A list is shown containing all roads, areas or regions affected by traffic reports. Roads, areas or regions not on the route also appear in the list.

To select the road, area or region: turn the controller and press to confirm. The traffic report is displayed (

Y page 75).

There may be several traffic reports for the affected road.

To close the display: press the % button.

Settings for the display on the map

You can switch these displays on/off on the map:

Incidents

Speed & Flow

Free Flow

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Traffic: turn and press the controller.

To select Traffic Information On Map: turn and press the controller.

Select Incidents, Speed & Flow or Free

Flow.

The display is on O or off ª.

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Traffic: turn and press the controller.

Reading out traffic reports on the route

Introduction

The text reader function is only available while route guidance is active. It reads out traffic reports affecting the current route.

You can select from the following text reader properties:

Language (Y page 38)

Text reader speed (Y page 35)

Storing destinations

You can start the text reader function manually or set it to automatic.

Starting the text reader function manually

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Traffic: turn and press the controller.

Select Read Out All Messages on Route. The multimedia system reads out the reports in sequential order.

If there are no reports for the route, the Read

Out All Messages on Route menu item is

gray and cannot be selected.

To cancel the read-aloud function: select

Cancel Read-Aloud Function

The multimedia system reads the current report aloud and then exits the read-aloud function.

for the current route when calculating the route

Y page 50).

( If you have selected Dynamic Traffic Route

as the route type, the multimedia system guides you to your destination along the updated route.

Storing destinations

General notes

If a route to a destination has been calculated, the multimedia system saves the destination to the last destinations memory. If the memory is full, the multimedia system overwrites the oldest destination. When you save the current vehicle position or a crosshair position, this position is stored in the "Last destinations" memory.

You can save destinations permanently in the address book and on an SD card. For example, you can save a destination as your home address immediately after entering the address

Y page 53).

( Requirements: the SD card has the FAT data

system format (e.g. FAT32).

Storing the destination in the address book

Navigation

Automatic text reader function

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Traffic: turn and press the controller.

Select Read Traffic Announcements

Automatically.

Depending on the previous state, switch the option on O or off ª.

Recalculating the route dynamically

The Dynamic Traffic Route route type takes into account all of the traffic reports it receives

The example shows an intermediate destination.

To select Save: turn and press the controller. A menu appears.

New contact: select As New Contact. If the address book already contains contacts, the entry Add

to Contactis also avail-

able.

Select Not Classified, Home or Work. An input menu shows the destination address.

Storing destinations

Enter a surname and first name. Character

Y page 28).

entry (

To select OK: turn and press the controller. The Saving Successful

message appears. The destination address is saved in the address book as a navigable contact.

To add to a contact: select Add to Con‐

tact.

The address book appears.

Search for a contact (Y page 103).

Press the controller. The Saving Successful

message appears. The destination address is allocated to a contact in the address book.

Telephone numbers are not transferred to the telephone number fields of the address book. After selecting the destination address from

Navigation

the address book for navigation, the associated telephone number will be displayed.

If the contact already has two destination addresses, a prompt will appear asking if a destination address should be overwritten.

Select Yes or No. If you select Yes

, a list showing both destina-

tion addresses appears.

To select the destination address: turn and press the controller. The destination address is overwritten.

Select Save as "My address" As "My

Address".

The destination is saved as your home address.

Saving a destination to an SD card

Insert the SD memory card (Y page 139).

Select a POI, for example (Y page 57).

To select Save: turn and press the controller. A menu appears.

Select To Memory Card. If no destination has been saved yet on the SD card, an input menu will appear.

Select Not Classifiedor, if available, select a category that you have created yourself. An input menu appears.

Enter a new name and a new category for the destination in the input menu if required. Character entry (

Select OK. The Saving Successful

Y page 29).

message appears.

The destination is saved to the SD card.

Saving the current vehicle position

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Position: turn and press the controller.

Select Save. The current vehicle position is saved in "Last destinations".

Saving the crosshair position

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To display the crosshair: press the controller.

Move the map to the desired position

Y page 49).

(

To show the menu: press the controller.

To select Position: turn and press the controller.

Select Save. The crosshair position is saved in the last destinations.

Editing the last destinations

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Destination: turn and press the controller.

Select From Previous Destinations. The "Last destinations" memory appears.

To save the destination: select the destination. The destination address appears.

Store the destination in the address book

Y page 77).

(

Save the destination to the SD card

Y page 78).

(

To view the details: while in the "Last destinations" memory, turn the controller and highlight the entry.

Slide 9 the controller. A menu appears.

To select Details: press the controller.

The destination address can be changed if

desired. For instance, a different street or house number can be selected.

To delete one or all destinations: while in the "Last destinations" memory, turn the controller and highlight the entry.

Slide 9 the controller. A menu appears.

Map functions

To select Delete or Delete All: turn and press the controller. A prompt appears.

Select Yes or No. Selecting Yes tion or all destinations.

Map functions

General notes

Company logos displayed on the map are trademarks of the respective companies and used solely for the purpose of indicating the locations of these companies. The use of such logos on the map does not indicate approval of, support of or advertising by these companies for the navigation system itself.

Alternatively, you can carry out this opera-

tion using the touchpad (

Map settings

Setting the map scale

Requirement: the map is in full screen mode, the menu is faded out (

The lower left-hand section of the map shows the currently set map scale and compass needle.

Right-hand-drive vehicles: the currently set map scale and compass needle are displayed in the lower right-hand section of the map.

To show the map in full screen mode: to hide the menu, push the % button.

Slide the controller to the center of the map and press to confirm.

To set the map scale: as soon as you turn the controller, the scale bar appears on the bottom of the display.

Turn the controller until the needle points to the desired map scale. Once you are finished selecting a map scale, the new map scale will be shown.

deletes the selected destina-

Y page 22).

Y page 49).

Navigation

Map functions

Selecting map orientation

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position

Navigation

or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Options: turn and press the controller.

Select Map Orientation. The # dot indicates the current setting.

Turn and press the controller. The map orientation is set.

Change map direction

North Up

Heading Up

3-D Map

Explanation

0 The map view is displayed so that north is always up.

¤ The map view is aligned to the direction of travel. The direction of travel is always at the top; the red tip of the symbol points north.

¤ The map view is aligned to the direction of travel. The map displays a 3D oblique view with elevation; the red tip of the symbol points north.

Selecting POI symbols on the map

POIs can be displayed as symbols in the map display. POIs include, for example, gas stations, hotels and restaurants.

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Options: turn and press the controller.

Select Map Content.

Select POI Symbols On Map. The # dot indicates the current setting.

Turn and press the controller.

Default Symbols

fined categories in the map.

Custom

Symbols allows symbols to be selec-

ted from other/all available categories.

Turn and press the controller. You have the option of selecting symbols to be displayed O or not displayed ª on the map.

The list shows all symbols that are contained on the digital map across all countries. However, not all points of interest are available in all countries. As a result, certain point of interest symbols may not be displayed on the map, even if the symbol display is switched on.

shows symbols of prede-

Selecting text information on the map

At the bottom of the display, you can specify whether to display geo-coordinates or not to display text information for the street you are currently on.

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Options: turn and press the controller.

Select Map Content.

Select Text Information On Map. The # dot indicates the current setting.

Turn and press the controller.

Current

Street shows the current street at

the bottom of the display.

Geo-coordinates

shows the longitude and latitude, elevation and number of satellites received.

The elevation shown may deviate from the actual elevation.

Turn and press the controller.

Switching highway information on/off

The following can be displayed when driving on a highway:

the nearest gas stations and rest stops

rest areas and highway exits and their present distances from the vehicle's

current position (

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Options: turn and press the controller.

Select Map Content.

Select Highway Information. Switch the display in the map on O or off ª. Further information (

Y page 69)

Y page 69).

Map functions

Displaying the next crossroads

If route guidance is not active, the next crossroads can be displayed at the upper edge of the display.

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Options: turn and press the controller.

Select Map Content.

Select Next Intersecting Street. Switch the display in the map on O or off ª.

Showing the map version

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Options: turn and press the controller.

Select Map Content.

Select Map Version. Information on the current map version is shown. Information about new versions of the digital map can be obtained from an authorized Mercedes-Benz Center.

Navigation

Map functions

Rotating the 3D map

You can use this function to explore the vicinity of the destination in a 3D view. The function is available in all map scales.

To switch to navigation mode: slide 5 the

Navigation

controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Position: turn and press the controller.

Select 3D Map Rotation.

Turn the controller to change to the 3D map perspective.

Additional functions:

Moving the map (Y page 49)

Map display

Displaying the navigation map

The multimedia system displays the navigation map and globe satellite images. This allows for a

realistic map display free from distortion in all map scales.

Other functions:

Moving the map (Y page 49)

Changing the map scale (Y page 79)

Building images

In small map scales 1/32 mi (20 m) and 1/16 mi (50 m) important buildings are depicted realistically on the map. Other buildings are shown as models.

Elevation model

The map uses elevation modeling to show a realistic illustration.

Avoiding an area

General notes

The multimedia system enables you to avoid areas you do not wish to drive through.

If you activate or deactivate a route block while route guidance is active, the multimedia system will calculate a new route. If you activate or deactivate a route block while route guidance is inactive, the multimedia system will use the new setting for the next route guidance.

The calculated route may include an area to be avoided if:

your destination is located in such an area

there is no alternative route of comparable length available

Highways within blocked areas are always taken into consideration in the route calculation.

Alternatively, you can carry out this opera-

tion using the touchpad (

Y page 22).

Avoiding a new area

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Options: turn and press the controller.

Select Route Settings.

Select Avoid Options.

Select Avoid Area.

Select Avoid New Area. A menu appears.

Select Using Map or Address Entry. If you select Using Map hair appears.

When you have selected Address Entry address entry menu appears ( map appears with the crosshair after the address is entered.

, the map with cross-

Y page 52). The

Map functions

To select an area: when the map with crosshair appears, press the controller. A red square appears on the map, symbolizing the area to be blocked.

To change the size of the area, turn the controller. The map scale is shown at the bottom of the display. The needle points to the map scale currently selected.

When the desired size is set, press the controller. The area is entered into the list.

Turning an area on/off and displaying/ changing the area

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

the

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Options: turn and press the controller.

Select Route Settings.

Select Avoid Options.

Select Avoid Area. A list appears.

To switch an area to avoid on/off: select an area by turning and pressing the controller. The area will be avoided O or not ª.

To display/change an area: mark an area by turning the controller.

Slide 9 the controller.

To select Display/Change: press the controller. The map with the crosshair appears.

Navigation

Map functions

The area currently blocked is displayed as a red square.

To move the area to a new location: slide 1, 4, 2 the controller.

To change the size of the area: press the controller.

Turn the controller.

To accept changes: press the controller. A message appears stating that the area has been set.

Deleting one/all areas

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position

Navigation

or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Options: turn and press the controller.

Select Route Settings.

Select Avoid Options.

Select Avoid Area. A list appears.

To delete an area: mark an area by turning the controller.

Slide 9 the controller.

Select Delete or Delete All. A prompt appears asking whether you wish to delete the area.

Select Yes or No. After selecting Yes

To delete all areas: when the list appears, slide 9 the controller.

Select Delete All. A prompt appears asking whether you wish to delete all areas.

Select Yes or No. After selecting Yes

, the area is deleted.

, all areas are deleted.

SIRIUS XM service

Displaying SIRIUS XM service information

You can display the SIRIUS XM service information.

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The map displays the current vehicle position or the navigation menu appears.

If the navigation menu appears, press the controller. The map shows the vehicle's current position.

To show the menu: slide 6 the controller.

To select Traffic: turn and press the controller.

Select SIRIUS Service. The provider's phone number (SIRIUS XM) and the serial number of your service module are displayed.

Alternatively you can call up this function

using the touchpad (

Y page 22).

Registering for the SIRIUS XM traffic report service

Call the provider telephone number shown on the multimedia system display.

You can also have the satellite service acti-

vated online. To do so, visit the SIRIUS XM Radio website at http://www.sirius.com (USA).

The connection is established: follow the service employee's instructions. The activation process may take up to ten minutes.

If registration is not included when purchas-

ing the system, your credit card details will be required to activate your account.

Updating the digital map

Introduction

The digital maps generated by the map software become outdated in the same way as conventional road maps. Optimal route guidance can only be provided by the navigation system in

Navigation functions

conjunction with the most up-to-date map software.

Information about new versions of the digital map can be obtained from an authorized Mercedes-Benz Center. You can have the digital map updated there using a data medium, or you can update it yourself.

Carrying out a manual update

You can carry out the update yourself. The update process may take some time (up to

45 minutes), depending on the size of the digital map. The update will be completed more quickly if the vehicle is stationary. If you begin the update while the vehicle is stationary and the starter battery has insufficient power, the multimedia system may switch off automatically. This protects the battery. In order to prevent this, a suitable power supply to the vehicle must be maintained.

Navigation functions

Calling up the navigation system menu

To switch to navigation mode: slide 5 the controller.

To select Navi: turn and press the controller. The navigation menu appears or the map displays the current vehicle position.

If the map appears, slide 5 the controller.

Press the controller. The navigation menu appears.

To return to the map: turn the controller until Navigation

appears and then press the

controller.

Calling up the online map display

Requirement for online map display (USA): mbrace must be activated for Internet access

Y page 118).

( Requirement for the online map display (Can-

ada): a mobile phone is connected to the multimedia system via Bluetooth

Y page 151).

USB (

Call up the navigation menu (Y page 85).

Turn the controller until Online Map Dis‐

play is brought to the front.

(Y page 90) or

Press the controller. The online connection is established. Once the connection is established, the Google Maps™ map shows the vicinity of the current vehicle position.

Alternatively you can call up this function

using the touchpad (

To exit the online map display: press the %

Y page 22).

button.

Calling up the compass display

Call up the navigation menu (Y page 85).

Turn the controller until Compass is brought to the front.

Press the controller. The compass display provides the following information:

The current direction of travel with bearing (360 degree format) and compass direction

Longitude and latitude coordinates in degrees, minutes and seconds

Height (rounded off) above sea level

Number of GPS satellites from which a signal can be received

Alternatively you can call up this function

using the touchpad (

To exit the compass display: press the % button.

Y page 22).

Navigation

Problems with the navigation system

Drive information

Call up the navigation menu (Y page 85).

Turn the controller until Drive Information is brought to the front.

Press the controller.

Navigation

The Starting Drive Information.

Please Wait... message appears.

You will then see maps with the current vehicle position and the vicinity of the destination in different scales, these are automatically displayed one after another.

If mbrace is activated for Internet access

Y page 118), additional information can be

( displayed, e.g. weather at the destination.

Alternatively you can call up this function

using the touchpad (

To exit Drive Information: press the controller.

Press the % button.

Y page 22).

Route flight

Call up the navigation menu (Y page 85).

Turn the controller until Route Flight is brought to the front.

Press the controller.

Alternatively you can call up this function

using the touchpad (

Select Ì.

Y page 22).

The route will be flown along from a helicopter perspective.

To stop route flight: select Ë.

To exit the route flight: press the controller.

Press the % button.

Info on navigation

Call up the navigation menu (Y page 85).

Turn the controller until Info on Naviga‐

tion is brought to the front.

Press the controller. The Digital Operator's Manual is opened at the section on navigation.

Alternatively you can call up this function

using the touchpad (

Y page 22).

Problems with the navigation system

Problem

The multimedia system does not resume route guidance after the journey has been interrupted.

Possible causes/consequences and M Solutions

Route guidance is canceled if you interrupt the journey for more than two hours.

"Interrupting the journey" refers to stopping the vehicle. "Continuing route guidance" refers to switching the multimedia sys-

tem back on and driving on.

Continue route guidance (Y page 71).

Problems with the navigation system

Problem

The multimedia system is unable to determine the vehicle's position.

Problem

The Navigation

Unavailable Please refer to the Opera‐ tor's Manual. mes-

sage appears.

Possible causes/consequences and M Solutions

The multimedia system must identify the vehicle’s position again after it has been transported.

Example:

After transporting the vehicle by ferry

After transporting the vehicle by motorail

Start the vehicle and pull away. The multimedia system calculates the vehicle's position. Depending on the driving situation, this may take some time.

Route guidance may be restricted during the determination of the vehicle's position.

When positioning is complete, route guidance is resumed with navigation announcements and route guidance displays.

Possible causes/consequences and M Solutions

The multimedia system has an integrated hard drive on which the digital map is stored.

To protect the integrated hard drive against damage, the multimedia system deactivates it at very high and low temperatures. The navigation system will then be temporarily unavailable.

Let the vehicle and the multimedia system heat up or cool down to a normal temperature.

To hide the message: switch the multimedia system off and then on again.

Navigation

Problem

A message informs you that the data medium containing the digital map is incompatible with the vehicle software.

Problem

The map software update has failed.

Possible causes/consequences and M Solutions

The data medium containing the digital map cannot be used for the update.

To confirm the message: press the controller.

Remove the data medium.

Have the system database checked at an authorized MercedesBenz Center.

Possible causes/consequences and M Solutions

The data medium is dirty.

Clean the data medium.

Restart the update.

The data medium is scratched.

Consult an authorized Mercedes-Benz Center.

Problems with the navigation system

Problem

The multimedia system asks for an activation code during the map

Navigation

update.

Possible causes/consequences and M Solutions

There is overheating due to excessive temperatures in the vehicle interior.

Wait until the vehicle interior has cooled down.

Restart the update.

The multimedia system's integral hard disk has been physically damaged.

Consult an authorized Mercedes-Benz Center.

Possible causes/consequences and M Solutions

The digital map is secured with an activation code.

Consult an authorized Mercedes-Benz Center.

General notes

Your multimedia system equipment

Read the information on qualified specialist workshops in the vehicle Operator's Manual.

Important safety notes

WARNING

If you operate mobile communication equipment when driving, you may be distracted from the traffic situation. You could also lose control of the vehicle. There is a risk of an accident.

Only operate this equipment when the vehicle is stationary.

If you make a call on your mobile phone while driving, always use hands-free mode. Only use the mobile phone when road, weather and traffic conditions permit. Some jurisdictions prohibit the driver from using a mobile phone while driving a vehicle.

Keep in mind that at a speed of 30 mph (approximately 50 km/h), the vehicle covers a distance of 44 ft (approximately 14 m) per second.

Excessive levels of electromagnetic radiation may cause damage to your health and the health of others.

There is scientific discussion surrounding the possible health risks posed by electromagnetic fields. You can reduce this risk by using an exterior antenna.

Therefore, connect your mobile communications equipment to the vehicle's exterior antenna wherever possible.

General notes

Telephony

A Bluetooth®interface is available for telephony.

If your mobile phone supports the Bluetooth

profile PBAP (Phone Book Access Profile), the contacts are automatically displayed in the multimedia system.

You can use the message function if your mobile phone supports the MAP Bluetooth

profile

(Message Access Profile). With a suitable mobile phone, you can use the

hands-free system and receive vCards via the Bluetooth

interface.

You can obtain more information about suitable mobile phones on the Internet at http://www.mercedes-benz.com/connect.

Or call the Mercedes-Benz Service Center at 1-800-FOR-MERCedes(1-800-367-6372) for the USA or at 1-800-387-0100 for Canada.

HD Voice

The multimedia system supports telephone calls in HD Voice

. The voice quality can be

improved with this procedure.

Requirements for HD Voice

Your mobile phone and mobile phone network provider support HD Voice

The mobile phone and mobile phone network provider of the person you are calling support HD Voice

Depending on the quality of the connection, the voice quality may fluctuate.

Call disconnection while the vehicle is in motion

A call may be disconnected if:

there is insufficient network coverage in certain areas

you move from one transmitter/receiver area (cell) into another and no channels are free

you use a SIM card that is not compatible with the network available

Telephone

Connecting/disconnecting a mobile phone

Operating options

You can operate the telephone by:

using the controller by turning, pressing, sliding 1 or 4

using the touchpad (Y page 22)

using the 6 or ~ button on the multifunction steering wheel

using the Voice Control System (see the separate operating instructions)

Function restrictions

You may have to wait to use telephony via the multimedia system in the following situations:

if the mobile phone is switched off

if Bluetooth®is switched off on the mobile phone

Telephone

if the mobile phone is not (or not yet) logged into a mobile phone network

if the Bluetooth®function is switched off in the multimedia system

The telephone automatically tries to log on to a network. If no network is available, you may not be able to make a "911" emergency call. If you attempt to make an outgoing call, the No Ser‐

vice message will appear for a short while.

Telephone menu

Symbols : to = and A are not shown until after a mobile phone has been connected to the multimedia system. The symbols depend on your mobile phone and your mobile phone network provider. Further information on connecting a mobile phone (

Y page 90).

Symbol ; shows the current signal strength of the mobile phone network. If all bars are filled, you have optimum reception.

If the bars are not filled, you have very poor reception or no reception at all.

Receiver icon shows whether a call is

active/being connected ¡ or not ¢.

Calling up the telephone menu

To show the main function bar: slide 5 the controller.

To select Phone: turn and press the controller. The telephone menu is displayed.

Showing the menu bar

Slide 6 the controller.

If the mobile phone connected supports the MAP Bluetooth

profile (Message Access

Profile), the 1 menu item is available. Further information on text messages and e-mail (

Y page 111).

If you have an unread text message or e-mail, the 0 mail symbol is displayed at the top in the status bar. The symbol disappears once you have read the text message or e-mail. The ú symbol is displayed as soon as the message memory on the mobile phone or SIM card is full. The symbol disappears once you delete at least one message.

Mobile phone network provider

;

Signal strength of the mobile phone network

Receiver icon ¢ or ¡

Telephone menu character bar

Bluetooth®device name of the currently connected mobile phone

Enters characters using the touchpad

Displays the phone book

Connecting/disconnecting a mobile phone

Prerequisites

For telephony via the Bluetooth®interface, you require a Bluetooth mobile phone must support Hands-Free Profile

1.0 or above.

On the multimedia system

Activate Bluetooth®(Y page 38).

-capable mobile phone. The

Connecting/disconnecting a mobile phone

On the mobile phone

Switch on the mobile phone and enter the PIN when prompted to do so (see the manufacturer's operating instructions).

Activate Bluetooth®and, if necessary, Blue-

visibility for other devices (see the

tooth manufacturer's operating instructions).

This visibility is for restricted periods of time on some mobile phones (see the manufacturer's operating instructions).

Set the Bluetooth®device name for the mobile phone if necessary.

The Bluetooth

device names for all of one manufacturer's products might be identical. To make it possible to clearly identify your mobile phone, change the device name (see the manufacturer's operating instructions). The name can be freely selected.

If the mobile phone supports the PBAP (Phone

Book Access Profile) and MAP (Message Access Profile) Bluetooth

profiles, the following information will be transmitted after you connect:

Phone book

Call lists

Messages

Further information on allowing or suppressing the automatic download of the phone book

Y page 106).

( The battery of the mobile phone should always

be kept sufficiently charged in order to prevent malfunctions.

Not all mobile phones available on the mar-

ket are equally suitable. You can obtain further information about suitable mobile phones and about the connection between the mobile phone and the multimedia system on the Internet at http://www.mercedes- benz.com/connect.

You can also obtain more information by calling.

In the USA, you can get in touch with the Mercedes-Benz Customer Assistance Center on 1-800-FOR-MERCedes (1-800-367-6372).

In Canada, you can get in touch with the Customer Relations Center on 1-800-387-0100.

Some displays (e.g. the signal strength)

depend on the supported version of the Hands-Free Profile.

Procedure and general information

Searching for and authorizing (connecting) a mobile phone

Before using your mobile phone with the multimedia system for the first time, you will need to search for the phone ( authorize it (

Y page 92). Depending on the

mobile phone, authorization either takes place by means of Secure Simple Pairing or by entering a passkey. The multimedia system automatically makes the procedure that is relevant for your mobile phone available. You can recognize Secure Simple Pairing by the fact that a code is displayed on the mobile phone and on the multimedia system. You can recognize the passkey system by the fact that you have to enter a code on the mobile phone and on the multimedia system. The mobile phone is always connected automatically after authorization.

If the multimedia system does not detect your mobile phone, this may be due to particular security settings on your mobile phone. You can also start the search procedure and authorization on the mobile phone (

Device-specific information on authorizing and connecting Bluetooth can be found on the Internet at http:// www.mercedes-benz.com/connect.

You can authorize up to 15 mobile phones. After authorization, the connection of the last two telephones used always functions automatically. Only one mobile phone can be connected to the multimedia system at any one time.

De-authorizing (disconnecting) a mobile phone

The connection is terminated automatically if you leave the receiver range of the multimedia system or deactivate Bluetooth phone.

If you no longer want the Bluetooth to be established automatically, the mobile phone must be de-authorized (disconnected)

Y page 94).

(

Y page 92) and then

Y page 93).

-capable mobile phones

on your mobile

connection

Telephone

Connecting/disconnecting a mobile phone

Searching for a mobile phone

To show the main function bar: slide 5 the controller.

To select Phone: turn and press the controller. The telephone menu is displayed.

To switch to the menu bar in the telephone menu: slide 6 the controller.

Telephone

To select Connect Device: turn and press the controller. The device list is displayed.

To select Search for Phones: turn and press the controller. A message is displayed that Bluetooth be activated on the mobile phone and must be made visible to other devices.

To select Start Search: press the controller. The available mobile phones are displayed in the device list.

The duration of the search depends on the number of Bluetooth their characteristics.

If a new phone is found, it appears in the device list with the Ï symbol. You can now authorize (connect) the mobile phone found

Y page 92).

( If the maximum number of authorized devices in

the device list is reached, you will be requested to de-authorize a mobile phone (

When you call up the device list again, deauthorized devices will be removed from the list. To update the device list, start the search again.

telephones within range and

Y page 94).

Symbols in the device list

Sym-

Explanation

bol

New mobile phone found, not yet authorized.

Mobile phone is authorized, but is not connected

Mobile phone is authorized and connected

Authorizing a mobile phone (connecting)

Authorization via Secure Simple Pairing

If the multimedia system has found your mobile phone, you can authorize (connect) it.

To select a mobile phone from the device list: turn the controller and press to confirm. A code is displayed in the multimedia system and on the mobile phone.

must

The code is the same

Multimedia system: select Yes.

Mobile phone: confirm the code. Depending on the mobile phone used, you may have to confirm the connection to the multimedia system and for the PBAP and MAP Bluetooth profiles. The prompt to confirm may take up to two minutes to be displayed. You may also save the confirmation on the mobile phone (see the manufacturer's operating instructions). The mobile phone is now authorized and connected to the multimedia system. You can now speak using the hands-free system.

To ensure an optimum language quality, you can set the mobile phone's transmission and reception volume (

The code is different

Multimedia system: select No. The process is canceled. Repeat the authorization.

Y page 94).

Authorization via passkey entry (access code)

If the multimedia system has found your mobile phone, you can authorize (connect) it.

Connecting/disconnecting a mobile phone

To select the Bluetooth®name of the desired mobile phone in the device list: turn and press the controller. The input menu for the passkey is displayed.

The passkey is a one- to sixteen-digit number combination which you can choose yourself.

Multimedia system: enter the passkey using the character bar.

Select ¬ once all the numbers have been entered.

Mobile phone: enter the same passkey and confirm your entry. Depending on the mobile phone used, you may have to confirm the connection to the multimedia system and for the PBAP and MAP Bluetooth

profiles. The prompt to confirm may take up to two minutes to be displayed. You may also save the confirmation on the mobile phone (see the manufacturer's operating instructions). The mobile phone is now authorized and connected to the multimedia system. You can now speak using the hands-free system.

To ensure an optimum language quality, you can set the mobile phone's transmission and reception volume (

If the Authorization Failed

Y page 94).

message appears, you may have entered a different passkey or exceeded the prescribed time limit. Repeat the procedure.

Some mobile phones require a passkey with

four or more digits.

If you wish to re-authorize the mobile phone

after de-authorizing it, you can choose another passkey for it.

Establishing the connection from the mobile phone

The Bluetooth®device name of the multimedia system is MB Bluetooth

Multimedia system: call up the telephone menu.

To switch to the menu bar: slide 6 the controller.

To select Connect Device: turn and press the controller. The device list is displayed.

To select Connect via Phone: turn and press the controller. A message is displayed, stating that you can start the search on your mobile phone.

Mobile phone: start the search for a Blue-

device (see manufacturer's operating

tooth instructions). The multimedia system is displayed with the name MB Bluetooth

in the mobile phone's

device list.

Select MB Bluetooth. A prompt appears in the multimedia system's display asking if the mobile phone should be authorized.

Multimedia system: select Yes.

is selected, the procedure is canceled.

If No If your mobile phone supports Secure Simple Pairing, a code is now displayed on both devices.

The code is the same

Multimedia system: select Yes.

Mobile phone: confirm the code. Depending on the mobile phone used, you may have to confirm the connection to the multimedia system and for the PBAP and MAP Bluetooth

To ensure an optimum language quality, you can set the mobile phone's transmission and reception volume (

Y page 94).

The code is different

Multimedia system: select No. The process is canceled. Repeat the procedure.

If your mobile phone does not support Secure Simple Pairing, an input menu is displayed for the passkey. The passkey is a one- to sixteendigit number combination which you can choose yourself. Enter the same passkey in both the multimedia system and on the mobile phone and confirm. Depending on the mobile phone used, you may have to confirm the connection to the multimedia system and for the PBAP and MAP Bluetooth

profiles.

Telephone

Reception and transmission volume

Reconnecting automatically

The multimedia system always searches for the last connected mobile phone.

If no connection can be made to the most recently connected mobile phone, the system searches for the mobile phone that was connected before that one.

Switching between mobile phones

If you have authorized more than one mobile phone, you can switch between the individual phones.

To show the main function bar: slide 5 the controller.

To select Phone: turn and press the controller. The telephone menu is displayed.

To show the menu bar: slide 6 the control-

Telephone

ler.

To select Connect Device: turn and press the controller. The device list is displayed.

To select the desired mobile phone: turn and press the controller. The selected mobile phone is searched for and connected if it is within Bluetooth and if Bluetooth

is activated.

Only one mobile phone can be connected at any one time. The currently connected mobile phone is indicated by the # dot in the device list.

You can only switch to another authorized

mobile phone if you are not currently making a call.

De-authorizing (disconnecting) a mobile phone

Mercedes-Benz USA, LLC recommends deauthorization in the multimedia system as well as on the mobile phone. Subsequent authorization may otherwise fail.

To show the main function bar: slide 5 the controller.

To select Phone: turn and press the controller. The telephone menu is displayed.

To show the menu bar: slide 6 the controller.

range

To select Connect Device: turn and press the controller.

To highlight the desired mobile phone in the device list: turn the controller.

To select G: slide 9 the controller.

To select Deauthorize: turn and press the controller. A prompt appears, asking whether you really wish to de-authorize this device.

To select Yes: turn and press the controller. The mobile phone is de-authorized.

Before re-authorizing the mobile phone, you

should also delete the device name MB

Blue‐

tooth from your mobile phone's Bluetooth

list.

Displaying connection details

To show the main function bar: slide 5 the controller.

To select Phone: turn and press the controller. The telephone menu is displayed.

To switch to the menu bar in the telephone menu: slide 6 the controller.

To select Connect Device: turn and press the controller.

To highlight the desired mobile phone in the device list: turn the controller.

To select G: slide 9 the controller.

To select Details: turn and press the controller. The following information concerning the selected mobile phone is shown:

Bluetooth®device name

Bluetooth®address

Availability status (shown after a new search)

Authorization status

To close the detailed display: slide 8 the controller.

Reception and transmission volume

Once the mobile phone has been authorized, you can optimize the transmission and reception volume settings. To find out about the best possible settings for your mobile phone, visit http://www.mercedes-benz.com/connect.

Using the telephone

Or call the Mercedes-Benz Customer Assistance Center at 1-800-FOR-MERCedes (1-800-367-6372) (USA) or Customer Relations at 1-800-387-0100 (Canada).

To show the main function bar: slide 5 the controller.

To select Phone: turn and press the controller. The telephone menu is displayed.

To switch to the menu bar: slide 6 the controller.

To select Connect Device: turn and press the controller. The device list appears.

To highlight the desired mobile phone in the device list: turn the controller.

To select G: slide 9 the controller.

To select Reception Volume or Transmis‐

sion Volume: turn and press the controller.

To select a volume setting: turn the controller.

To accept changes: press the controller.

If the phone number of the caller is trans-

ferred, it appears in the display. If the phone number is saved in the phone book, the contact's name is also displayed. If the phone number is not transferred, Unknown

is shown

in the display.

Rejecting a call

To select = Reject: turn and press the controller.

Press ~ on the multifunction steering wheel.

Making a call

Using the telephone menu

To show the main function bar: slide 5 the controller.

To select Phone: turn and press the controller. The telephone menu is displayed.

To select the sequence of numbers: turn and press the controller for each number.

To select w in the telephone menu: turn and press the controller. The call is made.

Further information about ending a call

Y page 99).

(

Telephone

Incorrect settings may have an impact on

the quality of calls.

Using the telephone

Accepting a call

To select w Accept: press the controller.

Press 6 on the multifunction steering wheel. The call is accepted.

Additional functions available during a call

Y page 96).

( Adjusting the call volume ( Further information about ending a call

Y page 99).

(

Y page 94).

Using the touchpad

To display the main function bar: slide 5 the controller.

To select Phone: turn and press the controller. The telephone menu is displayed.

To select n: turn and press the controller.

Draw the sequence of numbers on the touchsensitive surface.

To select w in the telephone menu: turn and press the controller. The call is made.

Further information about the touchpad

Y page 24).

(

Using the telephone

Using favorites

This function can be used when a telephone number has been added as a favorite. Further information about adding favorites (

Press the favorites button on the controller.

Y page 32).

The favorites are displayed.

To select a telephone number: turn the controller.

To make a call: press the controller.

Redial

To show the main function bar: slide 5 the controller.

To select Phone: turn and press the controller. The telephone menu is displayed.

To select w in the telephone menu: turn and press the controller. The list of outgoing calls is displayed. The

Telephone

most recently dialed number is at the top.

To select an entry and make a call: turn and press the controller.

For redialing using the multifunction steering wheel (see the vehicle Operator's Manual).

Further information about ending a call

Y page 99).

(

Using call lists

To show the main function bar: slide 5 the controller.

To select Phone: turn and press the controller. The telephone menu is displayed.

To switch to the menu bar: slide 6 the controller.

To select Call Lists: turn and press the controller.

To select Calls Receivedor Calls Dialed: turn and press the controller. The relevant list is displayed.

To select an entry and make a call: turn and press the controller.

Selecting and placing a call using the multifunction steering wheel (see vehicle Operator's Manual)

Further information about ending a call

Y page 99).

(

Using the phone book

To show the main function bar: slide 5 the controller.

To select Phone: turn and press the controller. The telephone menu is displayed.

To select Name in the telephone menu: turn and press the controller.

Search for a contact (Y page 100).

To make a call: press the controller.

Selecting and placing a call using the multifunction steering wheel (see vehicle Operator's Manual)

Further information about ending a call

Y page 99).

(

Using speed dial

To show the main function bar: slide 5 the controller.

To select Phone: turn and press the controller. The telephone menu is displayed.

To highlight a number from the character bar: turn the controller.

Press the controller for longer than two seconds. The telephone menu displays the selected entry. The number is dialed.

Further information on setting up speed dial

Y page 110).

( Further information about ending a call

Y page 99).

(

Functions available during a call

Overview

Adds a call (Y page 97)

;

Person you are calling

Symbol for active telephone connection

Using the telephone

Ends a call

Switches the microphone on or off

Y page 97)

(

Sends DTMF tones (not possible with all mobile phones) (

Y page 97)

Other functions:

Accepting a waiting call (Y page 98)

Call waiting (Y page 97)

Conducting a conference call (Y page 98)

Availability depends on the network (only possible on GSM networks) and the Bluetooth

mobile phone.

Adding a call

If the mobile phone network provider and the mobile phone support the function, you can make another call during an existing call. The previously active call is held.

Adds a call

To select °2: turn and press the controller.

To make a call, for example:

Using the telephone menu (Y page 95)

using redial (Y page 96)

using the call lists (Y page 96)

using the phone book (Y page 96)

using speed dial (Y page 96)

Switching off the microphone:

To switch to the menu bar: slide 6 the controller.

To select Microphone Off: turn and press the controller. If the microphone is switched off, the Q symbol and the The microphone is off. message are displayed.

Switching on the microphone:

Select Microphone On. The Q symbol disappears. The The micro‐

phone is on. message is shown.

Sending DTMF tones

This function is not supported by all mobile phones.

Answering machines or other devices can be controlled by DTMF tones, e.g. for remote query functions.

If you would like to listen to the messages on your answering machine, for example, dial the corresponding number.

Transmitting individual characters

Once a connection has been established to the answer phone, select the desired characters in the telephone menu: turn and press the controller each time. Every character selected will be transmitted immediately.

Calls with several participants

Switching between calls (call waiting)

Telephone

Switching the microphone on/off

This function is available in the telephone menu during an active phone call.

If you make another call, you can switch between the two calls (call waiting). This function depends on your mobile phone network

Using the telephone

provider and the mobile phone (see the manufacturer's operating instructions).

The calls are marked 1 and 2. The active call is highlighted.

Switching between the calls

To select °1or °2: turn and press the controller.

Press 6 on the multifunction steering wheel. The selected call is active. The other call is on hold.

Ending the active call

To select = in the telephone menu: turn and press the controller.

Press ~ on the multifunction steering wheel.

Telephone

The other call is still on hold.

To activate the call on hold: select w

Resume.

The call on hold is activated. If you select

Hang Up, the call on hold is also ended.

On some mobile phones, the call on hold is

activated as soon as the active call is ended.

Conference call

You can interconnect active and held calls. This permits several parties to hear one another and speak with one another. This function depends on your mobile phone network provider and the mobile phone (see the manufacturer's operating instructions).

Add a call (Y page 97).

Answer an incoming call (Y page 98).

To select Conference in the telephone menu: turn and press the controller. The new participant is included in the conference call. Conference

is displayed in the tele-

phone menu.

Incoming call during an existing call (call waiting)

The call waiting function depends on your mobile phone network provider and your mobile phone. Depending on the mobile phone used, behavior when answering a call may vary (see the manufacturer's operating instructions).

Call waiting: if you receive a call while already

in a call, a message is shown. You also hear a tone. You can decide whether to accept or reject the call.

Accepting

To select w Accept: press the controller.

Press 6 on the multifunction steering wheel. The incoming call is active, the previously active call is on hold. You can switch back and forth between both calls (call waiting)

Y page 97).

(

Depending on the mobile phone, you may

also be able to accept the incoming call (call waiting) on your mobile phone. This function and behavior depends on your mobile phone network provider and the mobile phone (see the manufacturer's operating instructions).

Rejecting

To select = Reject: turn and press the controller.

Press ~ on the multifunction steering wheel. The behavior after the call is rejected depends on your mobile phone and mobile phone network provider.

Option 1: The originally active call is continued and the incoming call is rejected.

Option 2: The originally active call is ended and the incoming call is accepted.

Option 3: Both calls are ended.

Mercedes Benz AMG GT 2018 Roadster COMAND Operator Instruction Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
