Mercedes Benz Actros, Axor, Atego accessories

Mercedes-Benz Truck

Spare parts and accessories

Spare parts to fit:

- Actros

- Axor

- Atego

Vehicle identification

The model overview and the vehicle type designations
given with the parts on the catalogue pages help in
finding the specific vehicle application. For many items,
the exact use depends on the model.
To uniquely identify a part, please contact your
EUROPART subsidiary with the complete Vehicle
Identification Number (VIN) or use the vehicle part
search in our EWOS.

Breakdown of the Mercedes-Benz VIN

WDB 930205 1 L689656

VIN

1 = Left-hand drive

Model

VIN plate

VIN

Classification of series and model

 Actros I (1996-) 950, 952, 953, 954
 Actros MP2 (2003-) 930, 932, 933, 934, 950, 954
 Actros MP3 (2008-) 930, 932, 933, 934, 950, 954

 Axor I (2001-) 375, 944
 Axor II (2004-) 374, 940, 942, 943, 944, 950, 958
 Axor III (2011-) 940, 942, 943, 944, 950, 958

 Atego I (1998-) 375, 957, 970, 972, 974, 975, 976
 Atego II (2004-) 375, 957, 958, 970, 972, 974, 975, 976
 Atego III (2011-) 375, 957, 958, 970, 972, 974, 975, 976

EUROPART®– a powerful brand

Alongside well-known manufacturer's brands,
EUROPART also offers a strong assortment of its
own-brand products with more than 5000 items
from the various EUROPART ranges.

Top quality at a fair price.

Your advantages:

 Low-cost alternative for OE standard

 Maximum availability at 200 locations

in 28 countries

 Increase your competitiveness

 Consistent service package

Commercial vehicle diagnosis?
Best go straight to EUROPART!

We keep vehicles on the move:

Across-brand diagnostic equipment for tractor units,
trailers, semi-trailers, agricultural vehicles, vans, cars
and buses

 Test and Diagnosis Technology

 Brakes/Axle Service

 Engines/Gearboxes

 Air suspension

and much more

More information from:

www.europart.net

Meet your objectives with the right
technology!

The AXONE product line

Hand-held diagnostic unit for all vehicle

categories

OBD Log and OBD MATRIX

Modern wireless exhaust gas measure-

ment on petrol and diesel engines

TEXA IDC4 universal software for control

KONFORT

Air conditioning service units for

R134a and R1234yf

of all TEXA workshop equipment

AUTOPOWER exhaust gas measuring

equipment

Modern wireless exhaust gas measurement

on petrol and diesel engines

The EUROPART partner for
diagnosis in the workshop

UNIPROBE

Measurement module with 4-channel

oscilloscope, multimeter,

CAN-BUS readings, etc.

NAVIGATOR TXT

Diagnostic interface for PC

Fly your banners. The workshop
concept from EUROPART!

Become part of a country-wide specialist
network.

Your advantages:

 Workshop network in Germany

 Effective marketing concepts!

 Technical information and Hotline

 Modern diagnostic equipment and assured parts

supply

 ISO certification possible if required

 No system charges for low sales volume

Become a partner now!

[e-mail]
[e-mail]
[e-mail]

Contents

Actros

Axor

Atego

Technical equipment and accessories

1

2

3

4

www.europart.net

1

Actros

2

Engine .............................................................................................................................4-19

Drive ..............................................................................................................................20-27

Suspension ..................................................................................................................28-33

Axle and steering........................................................................................................34-45

Braking system ...........................................................................................................46-51

Pneumatic system ......................................................................................................52-69

1

Lighting and electrics.................................................................................................70-87

Bodywork...................................................................................................................88-101

Driver’s cab.............................................................................................................102-123

Truck styling............................................................................................................124-129

3www.europart.net

1

Actros

Engine

Engine bearing

Vehicle type Actros I/MP2/MP3
Installation location front and rear
Width 230 mm
Thickness 130 mm
Inner thread M18 x 1.5

Order number Comparative number
1911 045 199 Mercedes-Benz 941 241 51 13
1911 045 206 Mercedes-Benz 941 241 58 13
1911 045 205 Mercedes-Benz 941 241 77 13

Engine piston

other versions possible
Vehicle type Motor type Order number

Actros I/MP2/MP3 e.g. OM 501, OM 502 EURO 3 1911 001 042
Actros MP2 e.g. OM 501, OM 502 EURO 5 1910 037 336

Crankcase seal set

Vehicle type Actros I/MP2/MP3
Motor type e.g. OM 501, OM 502

Scope of supply

without oil pan seal and cylinder liner sealing rings

Order number

8002 045 984

Cylinder head gasket set

Vehicle type Actros I/MP2/MP3
Version for one cylinder head

Motor type Order number

e.g. OM 501, OM 502 (up to engine no. 084423) 8022 341 900
e.g. OM 501, OM 502 (from engine no. 084424-155295) 8002 535 424
e.g. OM 501, OM 502 (from engine no. 155296-357748) 8002 000 118
e.g. OM 501, OM 502 (from engine no. 357749) 8002 290 400

4

Engine

Cylinder head repair kit

Vehicle type Actros I/MP2/MP3

Scope of supply

with cylinder head bolts and exhaust manifold bolts

Motor type Order number

e.g. OM 501, OM 502 (up to engine no. 357748),
optionally with 8022341900, 8002535424, 8002000118

e.g. OM 501, OM 502 (from engine no. 357749),
optionally with 8002290400

Cylinder head screw set

Vehicle type Actros I/MP2/MP3
Motor type e.g. OM 501, OM 502
Version external multi-tooth
Thread M18 x 2
Length 210 mm

Contents Order number
4-piece 8002 206 801

8002 045 419

8002 043 163

1

Actros

1

Actros

Engine

Cylinder liner

Vehicle type Actros I/MP2/MP3

other versions possible
Motor type Order number

e.g. OM 501, OM 502 EURO 3 1911 030 677
e.g. OM 501, OM 502 EURO 5 1910 034 700

Oil pan gasket

Vehicle type Actros I/MP2/MP3
Version for plastic oil pan

Motor type Order number

e.g. OM 501 (from engine no. 012091) 8002 532 585
e.g. OM 502 (from engine no. 012091) 8002 532 584

Oil pan gasket

Vehicle type Actros I/MP2
Version for aluminium oil pan

Motor type Order number

e.g. OM 501 (up to engine no. 012090) 8002 534 671
e.g. OM 502 (up to engine no. 012090) 8002 534 672

Valve cover gasket

Vehicle type Actros I/MP2/MP3

Motor type Order number

e.g. OM 501, OM 502 (up to engine no. 084423) 8022 500 132
e.g. OM 501, OM 502 (from engine no. 084424-155295) 8002 711 420
e.g. OM 501, OM 502 (from engine no. 155296),

for plastic valve cover

8002 533 431

6

Oil pressure sensor

Vehicle type Actros I/MP2/MP3
Motor type e.g. OM 904 LA, OM 906 LA
Thread M16 x 1.5
Connection metric

Version Order number

without warning contact 9465 420 517
with warning contact (on request) 9461 534 928

Dipstick

Vehicle type Actros I/MP2/MP3
Motor type e.g. OM 501, OM 502
Length 106 mm

Repair kit

air compressor

Vehicle type Actros I/MP2/MP3
Inner diameter 100 mm

Scope of supply

cylinder liner, seal, piston

Engine

1

Actros

Order number

9460 101 072

Order number

1911 010 313

Accessories
Description Order number

Gasket set for lamella valve 9460 006 669

Oil separator

for crankshaft housing ventilation

Vehicle type Actros MP2/MP3
Version with sealing ring

Order number

9750 050 005

Accessories
Description Order number

Gasket set (from engine no. 089132) 9740 050 002

Fuel pump

Vehicle type Actros I/MP2/MP3
Version with fuel pre-filter

Order number

9020 100 350

Service parts
Description Order number

Fuel filter housing 9460 000 400

7www.europart.net

1

Engine

Actros

Oil filter

Vehicle type Actros I/MP2/MP3
External diameter 113 mm
Inner diameter 45.4 mm
Height 312.5 mm

Order number

9020 121 400

Hydraulic filter

Vehicle type Actros I/MP2/MP3
External diameter 60 mm
Inner diameter 18/18 mm
Height 100.5 mm

(Illustration similar)

Order number

9025 503 090

Fuel filter

Vehicle type Actros I/MP2/MP3
External diameter 95 mm
Inner diameter 46 mm
Height 204.7 mm

Order number

9020 009 991

Air filter

Vehicle type Actros I/MP2/MP3

Dimensions mm Order number

∅ 420 x Height 263 9020 421 404
∅ 420 x Height 317 9024 217 290
∅ 267 x Height 533 9022 713 201
∅ 327 x Height 483 9020 331 840
∅ 281.5 x Height 406 9022 912 191

Length 626 x Width 564 x Height 78 9020 641 510
∅ 243 x Height 498 9020 007 030

8

Engine

1

Oil filter

Vehicle type Actros I
External diameter 200 mm
Inner diameter 27/27 mm
Height 255 mm

Oil filter

Vehicle type Actros MP2/MP3
External diameter 120.5 mm
Inner diameter 50 mm
Height 271.5 mm

Actros

Order number

9750 103 901

Order number

9750 103 657

Hydraulic filter

Vehicle type Actros I/MP2/MP3
External diameter 58 mm
Inner diameter 18/18 mm
Height 149 mm

Hydraulic filter

Vehicle type Actros I/MP2/MP3
External diameter 59 mm
Inner diameter 15.5 mm
Height 104 mm

Order number

9750 103 841

Order number

9750 103 779

9www.europart.net

1

Engine

Actros

Fuel filter

Vehicle type Actros I/MP2/MP3
External diameter 44 mm
Inner diameter 24 mm
Height 80 mm

Order number

9750 230 365

Fuel filter

Vehicle type Actros I/MP2/MP3
External diameter 107.5 mm
Height 219 mm

Order number

9750 104 510

Fuel filter

Vehicle type Actros I/MP2/MP3
External diameter 107.5 mm
Height 219 mm

Urea filter

Vehicle type Actros I/MP2/MP3/MP4
External diameter 43 mm
Height 85.5 mm

Order number

3565 429 204

Order number

9750 103 044

10

Engine

1

Air filter

Vehicle type Actros I/MP2/MP3
External diameter 64.6 mm
Inner diameter 31/46.5 mm
Height 120.3 mm

Air filter

Vehicle type Actros I/MP2/MP3
External diameter 520.5 mm
Inner diameter 221.8 mm
Height 332.3 mm

Actros

Order number

9750 104 112

Order number

9750 103 653

Main bearing set

Vehicle type Actros I/MP2/MP3
Motor type e.g. OM 501, OM 502

Order number

1911 037 842

Connecting rod bearing pair

Vehicle type Actros I/MP2/MP3

Motor type Order number

e.g. OM 501 1911 037 862
e.g. OM 502 1910 042 469

11www.europart.net

1

Actros

Engine

Inlet valve

Vehicle type Actros I/MP2/MP3
Motor type e.g. OM 501, OM 502
Length 145 mm
Valve stem diameter 9 mm
Valve disc diameter 45,7 mm
Valve seat angle 30°

Order number

1910 026 148

Output valve

Vehicle type Actros I/MP2/MP3
Motor type e.g. OM 501, OM 502
Length 145 mm
Valve stem diameter 9 mm
Valve disc diameter 41,1 mm
Valve seat angle 45°

Order number

1910 026 149

Exhaust turbocharger

Vehicle type Actros I/MP2/MP3
Motor type e.g. OM 501 LA (from engine no. 064476)
Special equipment 505127 01

engine type: 521.940/541.920-927/940-947/951/941.910/920/929/930/940/960/970/
980/981/990

Order number

1902 431 000

Accessories
Description Order number

Add-on set 1902 316 690

Exhaust turbocharger

in exchange

Vehicle type Actros I/MP2
Motor type e.g. OM 501 LA (up to engine no. 000293)

Order number

1902 024 442

12

Accessories
Description Order number

Add-on set 1902 024 479

Engine

Exhaust turbocharger

in exchange

Vehicle type Actros I/MP2/MP3
Motor type e.g. OM 501 LA (from engine no. 000294 to engine no. 064475)

Order number

1902 316 756

Accessories
Description Order number

Add-on set 1911 316 756

Exhaust turbocharger

in exchange

Vehicle type Actros I/MP2/MP3
Motor type e.g. OM 501 LA (from engine no. 064476)
Special equipment 505127 02/05/12
engine type: 521.940/541.920-927/940-947/951/941.910(920/929/930/940/960/970/

980/981/990

Order number

1902 125 164

1

Actros

Accessories
Description Order number

Add-on set 1911 125 164

Charging pressure sensor

Vehicle type Actros I/MP2/MP3

Order number

3600 002 468

Charge air cooler

Vehicle type Actros I
Motor type OM 501 LA, OM 502 LA
Length 752 mm
Width 652 mm
Depth 52 mm

Order number

9100 137 070

Charge air cooler

Vehicle type Actros I/MP2/MP3
Motor type OM 501 LA, OM 502 LA
Length 752 mm
Width 852 mm
Depth 66 mm

Order number

9100 137 100

13www.europart.net

1

Actros

Engine

Charge air cooler

Vehicle type Actros MP2/MP3
Motor type OM 501 LA, OM 502 LA
Length 978 mm
Width 752 mm
Depth 68 mm

Order number

3563 298 868

Charge air hose

Vehicle type Actros I/MP2/MP3
Motor type OM 501 LA, OM 502 LA
Inner diameter 115 mm
Length 210 mm
Material thickness 4 mm

Order number

5529 000 180

Water pump

as replacement

Vehicle type Actros I/MP2/MP3
Motor type OM 501 LA to engine no. 019797, OM 502 LA
Type 220 880

Scope of supply

with seal

Water pump

in exchange

Vehicle type Actros I/MP2/MP3
Motor type OM 501 LA, OM 502 LA
Type 220 881
Version with retarder connection

Scope of supply

with seal

Order number

9150 000 240

Order number

9460 000 033

14

Water pump

Vehicle type Actros I/MP2/MP3
Motor type OM 501 LA

Scope of supply

with seals

Order number

6170 462 591

Water pump

Vehicle type Actros I/MP2/MP3
Motor type OM 502 LA

Scope of supply

with seals

Water pump

Vehicle type Actros I/MP2/MP3
Motor type OM 502 LA
Version with retarder connection

Engine

1

Actros

Order number

(on request) 5821 200 103

Order number

1102 201 071

Engine radiator

Vehicle type Actros I/MP2/MP3
Width 808 mm

Length mm Depth mm Order number

902 42 9100 132 081
952 40 9100 132 101
1015 42 9100 134 301

Surge tank

for coolant

Vehicle type Actros I/MP2/MP3
Colour black
Length 566 mm
Width 289 mm
Depth 444 mm
Volume 12,2 l

Order number

9100 134 070

Accessories
Description Order number

Radiator cap, without valve 1325 461 594
Surge tank lid, 1 bar (on request) 9465 000 206
Surge tank lid, 0,7 bar 1325 050 170

15www.europart.net

1

Actros

Engine

Thermostat

with seal

Vehicle type Actros I/MP2/MP3
Diameter 67 mm
Opening temperature 83 °C

Order number

9100 000 007

Coolant temperature sensor

with seal

Vehicle type Actros I/MP2/MP3
Outer thread M14 x 1.5

Motor type Spanner size Order number

OM 904 LA 19 6170 462 920
OM 904 LA, OM 906 LA 22 9460 462 921

Radiator fan coupling

Visco clutch without fan

Vehicle type Actros I/MP2/MP3
Diameter 233 mm

Radiator fan coupling

Visco clutch without fan

Vehicle type Actros I/MP2/MP3
Diameter 245 mm

Order number

1888 000 016

Order number

1851 698 013

16

Fan wheel

Vehicle type Actros I/MP2/MP3
Number of blades 8
External diameter 750 mm

Scope of supply

without clutch

Width mm Order number

78 9100 139 790
56 0376 756 081

This figure corresponds to 9100 139 790

1

Engine

Actros

Accessories
Description Order number

Front pipe 9464 903 019
Exhaust pipe clamp, Diameter 128.5 mm 8730 207 039
Exhaust pipe clamp, Diameter 135 mm 8730 207 037

Rear silencer

Vehicle type Actros I/MP2/MP3

Special equipment Order number

508108/09
531391/01

508108 07 8730 207 043

8730 100 927

Rear silencer

Vehicle type Actros I/MP2/MP3

Application range

for hazardous goods vehicles

Order number

8730 207 019

Accessories
Description Order number

Front pipe 8730 207 028
Exhaust pipe clamp, Diameter 142 mm 8730 207 029
Exhaust pipe clamp, Diameter 130.5 mm 8730 156 100

Fuel tank

steel

Vehicle type Actros I/MP2/MP3
Form rectangular

(Illustration similar)

Volume l Dimensions mm Order number

300 640 x 560 x 950 9469 410 201
400 640 x 560 x 1250 9469 410 401
590 640 x 560 x 1860 9469 410 601

Accessories
Description Order number

1 x Fuel cap, lockable, vented 9668 080 110
2 x Console 8730 122 493
1 x Console rubber 9660 022 455
2 x Tightening strap 9660 224 940
1 x Tightening strap rubber 9660 000 703
1 x Tank sensor 9660 022 481
1 x Connection set 8730 102 488
1 x Blind cover 9660 001 906
1 x Fuel Anti-syphon 9668 010 090

18

Engine

1

Fuel tank

aluminium

Vehicle type Actros I/MP2/MP3
Form rectangular

Volume l Dimensions mm Order number

230 640 x 560 x 720 9464 700 101
300 640 x 560 x 945 9469 420 301
400 640 x 560 x 1250 9469 420 401
500 640 x 560 x 1560 9469 420 501
600 640 x 560 x 1860 9469 420 601

Accessories
Description Order number

1 x Fuel cap, lockable, vented 9668 080 110
2 x Console 9660 860 050
4 x Console rubber 9660 860 070
2 x Tightening strap 9660 860 060
2 x Tightening strap rubber 9660 860 080
1 x Tank sensor 9660 022 481
1 x Connection set 8730 102 488
1 x Blind cover 9660 001 906
1 x Fuel Anti-syphon 9668 010 090

Actros

Fuel tank

aluminium

Vehicle type Actros I/MP2/MP3
Form rectangular

Volume l Dimensions mm Order number

300 700 x 700 x 750 9464 701 001
400 700 x 700 x 910 9660 234 200
550 700 x 700 x 1230 9664 701 401
650 700 x 700 x 1550 9660 234 100

Accessories
Description Order number

1 x Fuel cap, lockable, vented 9668 080 110
2 x Console 9660 860 330
4 x Console rubber 9660 860 070
2 x Tightening strap 9660 860 100
2 x Tightening strap rubber 9660 860 360
1 x Tank sensor 9660 022 481
1 x Connection set 8730 102 488
1 x Blind cover 9660 001 906
1 x Fuel Anti-syphon 9668 010 090

19www.europart.net

1

Actros

Drive

Slim V-belt

XPB 1900

Vehicle type Actros I/MP2/MP3
Version raw edge, cogged
Length 1900 mm

Order number

1865 774 070

Ribbed V-belt

Vehicle type Actros I/MP2/MP3

Length mm Number of ribs Order number

2000 8 3564 664 942
1725 9 1100 282 514
1825 9 1865 091 826
2080 9 1867 520 240
2325 9 1800 000 151
1670 10 1851 016 700
1815 10 1100 282 365
1890 11 9461 997 269
2871 11 1865 000 000
1515 12 1865 487 070
2490 12 1867 122 500

(Illustration similar)

Ribbed V-belt

Vehicle type Length mm Number of ribs Order number

Actros I/MP2/MP3 1215 8 1100 282 512
Actros I/MP2/MP3 1420 8 1100 219 670
Actros I/MP2/MP3 1480 8 9469 970 792
Actros I/MP2/MP3 1940 8 9050 289 190
Actros I/MP2/MP3 2085 8 3564 663 779
Actros I 1780 9 9465 997 219
Actros I/MP2/MP3 1890 9 1865 485 740
Actros I 2010 9 2300 000 379
Actros I/MP2/MP3 2295 9 1100 282 515
Actros I 2338 9 1325 000 748
Actros I/MP2/MP3 2835 9 1865 487 260
Actros I/MP2/MP3 2870 9 1100 211 715
Actros I/MP2/MP3 2020 11 3564 642 047
Actros I/MP3 2040 11 1100 282 464
Actros I/MP3 2044 11 2540 101 162
Actros I/MP2/MP3 2835 11 1100 282 465

20

1

Actros

Drive

Ribbed V-belt set

Vehicle type Actros I/MP2/MP3

Scope of supply

1 x ribbed V-belt 9 PK 1890, 1 x ribbed V-belt tensioner

Order number

3564 617 904

Contents
Description Order number

Ribbed V-belt, Length 1890 mm 1865 485 740
Poly-V belt tensioner 5930 000 542

Ribbed V-belt set

Vehicle type Actros I/MP2/MP3

Scope of supply

1 x ribbed V-belt 9 PK 2835, 1 x ribbed V-belt tensioner

Order number

1100 282 326

Contents
Description Order number

Ribbed V-belt, Length 2835 mm 1865 487 260
Poly-V belt tensioner 5930 000 540

12 3 4

56 7

Deflection pulley/guide pulley

for ribbed V-belt

Illustration Vehicle type Material Outer ∅mm Width mm Order number

1 Actros I metal 80 44 1362 010 040
2 Actros I metal 74 38 5930 000 551
3 Actros I/MP2/MP3 plastic 74 46.3 5930 000 499
4 Actros I/MP2/MP3 metal 80 48 5930 000 541
5 Actros I/MP2/MP3 metal 95 39 1362 010 041
6 Actros I/MP3 plastic 80 44 9465 500 433
7 Actros MP3 metal 107 34 3564 580 874

22

Drive

1

Actros

4312

678910

11 12

13

5

Poly-V belt tensioner

Illustration Vehicle type Outer ∅mm Roll width mm Order number

1 Actros I 80 34/102,5 9462 001 970
2 Actros I/MP3 74 39/57,7 5930 000 543
3 Actros I/MP3 78 42 1911 043 900
4 Actros I 78 42/104,5 3563 830 141
5 Actros I/MP3 74 46,3 5930 000 511
6 Actros I/MP2/MP3 70 35 9462 001 070
7 Actros I/MP2/MP3 74 34 9462 001 570
8 Actros I/MP2/MP3 74 46 5930 000 542
9 Actros I/MP2/MP3 80.5 48 5930 000 540
10 Actros MP2/MP3 90 34 1911 400 001
11 Actros MP3 74 34 1911 252 424
12 Actros MP3 74 38,3 5930 000 554
13 Actros MP3 74 35,5 5930 000 544

23www.europart.net

1

Drive

Actros

Flywheel

Vehicle type Actros I/MP2/MP3
Version with sprocket, 37 grooves
Diameter 430 mm

Order number

9060 100 000

Accessories
Fastening set

1 axial seal (external diameter 140 mm), 1 race (external diameter 120 mm), 1 pilot
bearing (external diameter 62 mm), 10 bolts M16 x 1.5

Order number

9060 000 103

Flywheel

Vehicle type Actros MP2/MP3
Special equipment SA 505009 05
Version with gear rim
Diameter 395 mm

Order number

9460 301 905

Accessories
Grooved ball bearing with 2 sealing washers

External diameter 52 mm
Inner diameter 20 mm
Height 15 mm

Flywheel

Vehicle type Actros MP2/MP3
Special equipment SA 505009 58
Version with gear rim
Diameter 362 mm

Order number

8001 630 423

Order number

9060 100 065

24

Drive

1

Dual mass flywheel

Vehicle type Actros I/MP2/MP3
Diameter 430 mm

Scope of supply

with mounting screws

Order number

9754 000 008

Accessories
Crankshaft seal

Dimensions 115 x 140 x 12 mm

Order number

8002 534 667

Clutch kit

as replacement

Vehicle type Actros I/MP2/MP3
Parameter MFZ430
Diameter 430 mm
Number of teeth 18
Toothed hub profile 45x50-18N

Scope of supply

Release bearing, mounted with pressure plate

Order number Comparative number
9270 122 801 Sachs 3400 122 801

Actros

Clutch kit

In exchange

Vehicle type Actros I/MP2/MP3
Parameter MFZ2/400
Diameter 400 mm
Number of teeth 8
Toothed hub profile 45x50-18N

Scope of supply

Disc, automatic unit, release bearing mounted

Order number Comparative number
9270 121 501 Sachs 3400 121 501

25www.europart.net

1

Drive

Actros

Clutch kit

Vehicle type Actros MP2/MP3
Parameter MFZ2/400X
Diameter 400 mm
Number of teeth 18
Toothed hub profile 45x50-18N

Scope of supply

Disc, automatic unit, release bearing mounted

Order number Comparative number
9270 700 355 Sachs 3400 700 355

Clutch kit

Vehicle type Actros MP2/MP3
Parameter MFZ430
Diameter 430 mm
Number of teeth 18
Toothed hub profile 45x50-18N

Scope of supply

Disc, automatic unit, release bearing mounted

Order number Comparative number
9270 004 003 Sachs 3400 700 446

Everything your engine
loves!

Spare parts documentation for more
than 550 engine variants from the
manufacturers:



DAF
MAN




MERCEDES-BENZ



SCANIA



VOLVO
... and much more besides!

Request your free catalogue copy!

26

Storage

for propeller shaft

Vehicle type Actros I/MP2/MP3
External diameter 94 mm
Inner diameter 71 mm

Scope of supply

with ball bearing

Storage

for propeller shaft

Vehicle type Actros I
External diameter 105 mm
Inner diameter 70 mm

Scope of supply

with ball bearing

Drive

1

Actros

Order number

9220 001 086

Order number

9460 119 845

Drive shaft

with joint

Vehicle type Actros I/MP2/MP3

Installation side Length mm Order number

left 1262 9031 300 047
right 1102 9460 307 001

Oil cooler

for retarder

Vehicle type Actros I/MP2/MP3
Length 285 mm
Width 203 mm
Height 160 mm

Order number

1911 333 019

27www.europart.net

1

Actros

Suspension

Parabolic spring

Front axle

Vehicle type Actros I/MP2/MP3
Form 1J
Number of leaves 2
Thickness 58
Width 90 mm
Length front/rear 900/900 mm
Bushing front/rear 24/60, 24/60 mm
Axle load 7,1

Order number

1033 816 000

Parabolic spring

front axle

Vehicle type Actros I/MP2/MP3
Form 1J
Number of leaves 2
Thickness 60
Width 90 mm
Length front/rear 900/900 mm
Bushing front/rear 24/60, 24/60 mm
Axle load 7,5 t

Order number

1033 818 000

Parabolic spring

front axle

Vehicle type Actros I/MP2/MP3
Form 1KM
Number of leaves 3
Width 90 mm
Length front/rear 900/900 mm
Bushing front/rear 24/60, 24/60 mm

Thickness mm Axle load t Order number

79 7,5 1033 684 000
81 8 1033 682 000
83 9 1033 690 000

Spring hoop

Front axle

Thread M20 x 1.5
Form 0
Interior width 91 mm

Vehicle type Length mm Order number

Actros I/MP2/MP3 205 1301 903 205
Actros I/MP2/MP3 225 1301 903 225
Actros I/MP2/MP3 240 1309 894 324
Actros I/MP3 320 1301 943 320

28

Accessories
Flat collar nut

Thread M20 x 1.5
Height 20 mm

Order number

6604 020 150

Parabolic spring

Rear axle

Vehicle type Actros I/MP2/MP3
Form 8BP
Number of leaves 2/1
Thickness 128 mm
Width 100 mm
Length front/rear 780/780 mm
Axle load 9,5 t

Parabolic spring

rear axle

Vehicle type Actros I/MP2/MP3
Form 8KP
Number of leaves 5
Thickness 195 mm
Width 100 mm
Length front/rear 780/780 mm
Axle load 16 t

Suspension

1

Actros

Order number

1033 887 000

Order number

1033 885 000

Parabolic spring

Rear axle

Vehicle type Actros I/MP2/MP3
Form 1BK
Number of leaves 3/1
Width 100 mm
Length front/rear 900/885 mm
Bushing front/rear 24/60, 24/60 mm
Axle load 13 t

Thickness mm Order number

127 1033 681 000
133 1033 683 000

Hollow rubber spring

Vehicle type Actros I/MP2/MP3
Length 210-232 mm
Width 135-165 mm

Height mm Order number

120 1593 103 050
152 9560 066 359

29www.europart.net

1

Actros

Suspension

Spring hoop

Rear axle

Vehicle type Actros I/MP2/MP3
Form 1
Thread M24 x 1.5
Interior width 101 mm

Length mm Order number

440 1301 553 440
480 1301 553 480

Accessories
Hexagon nut

Thread M24 x 1.5
Height 24 mm

Order number

9900 135 145

Spring hoop

Rear axle

Vehicle type Actros I/MP2/MP3
Form 3/7
Thread M27 x 2
Interior width 101 mm

Length mm Order number

380 1301 593 380
430 1398 593 430

Accessories
Hexagon nut

Thread M27 x 2
Height 40 mm

Order number

1303 270 211

30

Air spring

complete, with steel piston

Vehicle type Actros I/MP2/MP3
Piston diameter 280 mm
Inner diameter 280 mm
Height 270 mm

Order number

1788 475 721

Suspension

1

Air spring

with piston

Vehicle type Actros I/MP2/MP3
Version VOSS 232
External diameter 342-352 mm
Piston diameter 265 mm
Height 280 mm

Air spring

with steel piston

Vehicle type Actros I/MP2/MP3
Version VOSS 232
External diameter 276-286 mm
Piston diameter 200 mm
Height 292 mm

Actros

Order number

1788 418 324

Order number

1788 439 022

Air spring

with piston

Lower attachment: central inner thread M16 x 1.5
Air connection: outer thread M24 x 1.5, inner thread M16 x 1.5

Vehicle type Actros I/MP2/MP3
Version VOSS 232
External diameter 276-286 mm
Piston diameter 200 mm
Height 292 mm

Air spring bellows

with piston

Vehicle type Actros I/MP2/MP3
suitable for Low Liner
Version VOSS 232
External diameter 297-307 mm
Inner diameter 280 mm
Height 197 mm

Order number

1788 439 012

Order number

1780 475 921

31www.europart.net

1

Actros

Suspension

Air spring

with piston

Vehicle type Actros I/MP2/MP3
Version VOSS 232
Outer ∅ 360 mm
Height 360 mm

Piston dia. mm Order number

220 1788 483 822
230 1788 483 823

Shock absorber

Fastening eye/eye
Version oil pressure, twin-tube system

(Illustration similar)

Vehicle type Installation location Order number Comparative number

Actros I/MP2/MP3 front axle 9200 000 570 Sachs 310 803
Actros I/MP2/MP3 front axle 9200 001 290 Sachs 131 944
Actros I/MP2/MP3 front axle 9200 124 678 Sachs 124 678
Actros I/MP2/MP3 front axle 9200 001 235 Sachs 310 807
Actros I/MP2/MP3 Front axle 9200 124 639 Sachs 124 639
Actros I rear axle 9200 001 245 Sachs 124 359
Actros I/MP2/MP3 rear axle 9200 001 310 Sachs 124 376
Actros I/MP2/MP3 rear axle 9200 124 567 Sachs 124 567
Actros I/MP2/MP3 Rear axle 9200 124 638 Sachs 124 638
Actros I/MP2/MP3 rear axle 9200 131 623 Sachs 131 623

Shock absorber

front axle

Vehicle type Actros I/MP2/MP3
Fastening eye/eye
Version Oil pressure, twin-tube
Installation location front axle

Order number Comparative number
9201 317 470 Sachs 131 747
9201 319 440 Sachs 131 944

(Illustration similar)

9463 239 500 Sachs 310 163
9463 235 400 Sachs 131 622

32

Suspension

1

(Illustration similar)

Shock absorber

Rear axle

Fastening Eye/eye
Version Oil pressure, twin-tube
Installation location Rear axle

Vehicle type Order number Comparative number

Actros I/MP2/MP3 9201 243 130 Sachs 124 313
Actros I/MP2/MP3 9270 311 644 Sachs 311 644
Actros MP2/MP3 9750 001 258 Sachs 311 665
Actros I/MP2/MP3 9201 243 600 Sachs 124 360

Actros

1

∅

Axle and steering

Actros

Length mm Pipe

725 36 22 9070 900 087
876 40 28.6 9070 900 039
879 42 30 9070 900 037
858 40 28,6 9079 927 683

Drag-link

Vehicle type Actros I/MP2/MP3
Installation location drop arm to the 1st front axle

mm Cone-∅mm Order number

Drag-link

Vehicle type Actros I/MP2/MP3
Installation location intermediate lever 1 to intermediate bearing 2
Length 1095 mm
Pipe diameter 42 mm
Cone diameter 32 mm

Order number

9070 001 014

Drag-link

Vehicle type Actros I/MP2/MP3
Installation location drop arm to the 1st front axle
Length 879 mm
Pipe diameter 36 mm
Cone diameter 28,6 mm

Drag-link

X-CAP

Vehicle type Actros I/MP2/MP3
Installation location drop arm to the 1st front axle
Length 711 mm
Pipe diameter 42 mm
Cone diameter 32 mm

Order number

9070 900 008

Order number

9890 200 163

34

Axle and steering

1

Ball joint

for steering rod

Vehicle type Actros I/MP2/MP3
Installation location front axle

(Illustration similar)

Threadtype Outer thread Cone-∅mm Length mm Order number

right-hand thread M28 x 1.5 28.6 141 9070 900 053
right-hand thread M30 x 1.5 28.6 115 9079 927 623
right-hand thread M24 x 1.5/M30 x 1.5 30 120 9070 900 117
left-hand thread M24 x 1.5/M30 x 1.5 30 120 9070 900 123

Power-steering pump

in exchange

Version hydraulic

Actros

(Illustration similar)

Vehicle type Order number Comparative number

Actros MP2/MP3 9074 204 210 Mercedes-Benz 001 460 44 80
Actros MP2/MP3 9074 209 110 Mercedes-Benz 002 460 14 80
Actros I/MP3 6952 009 210 Mercedes-Benz 002 460 15 80

Power-steering pump

Tandem pump

Vehicle type Actros I/MP2/MP3

Order number Comparative number
6542 045 410 Mercedes-Benz 003 460 03 80

35www.europart.net

1

∅

Actros

Axle and steering

Stabilizer mounting

Vehicle type Actros I/MP2/MP3

Installation location Outer

front 51 28 55 rubber 9463 236 285
front 61 38 55 rubber 9460 109 904
front/rear 70 40 46 rubber/metal 9290 002 430
front 74 47 56 rubber 9460 109 905
rear 87 56 56 rubber 1597 200 333
rear 80 40 46 rubber/metal 9463 238 185
front 98 70 67 rubber 9461 323 015
front/rear 108.5 80 67 rubber 1583 006 123

mm Inner ∅mm Length mm Material Order number

Stabilizer mounting

Vehicle type Actros I/MP2/MP3
Version for vehicles with air suspension
Installation location rear
External diameter 109 mm
Inner diameter 88 mm
Length 175 mm
Distance between centres 130 mm
Bore hole diameter 20.5 mm

Order number

1583 006 121

36

Steering Track Rod

Vehicle type Actros I/MP2/MP3
Form straight
Installation location front axle
Threadtype right-hand thread
Length 1735 mm
Pipe diameter 50 mm
Cone diameter 32 mm

Order number

9070 900 013

Axle and steering

∅

1

Steering Track Rod

Vehicle type Actros I/MP2/MP3
Form offset
Installation location Front axle
Threadtype Right-hand thread

Length mm Pipe

1588 60 30 9079 924 315
1735 52 32 9070 001 410

mm Cone-∅mm Order number

Ball joint

for steering track rod

Vehicle type Actros I/MP2
Installation location front axle
Threadtype right-hand thread

(Illustration similar)

Outer thread M38 x 1.5
Cone diameter 38 mm
Length 135 mm

Order number

9070 900 130

Actros

(Illustration similar)

Ball joint

for track rod

Vehicle type Actros I/MP2/MP3
Installation location front axle
Outer thread M27 x 1.5/M30 x 1.5
Cone 32 mm
Length 120 mm

Threadtype Order number

left-hand thread 9070 900 045
right-hand thread 9070 900 015

37www.europart.net

1

Axle and steering

Repair kit

Kingpin

Actros

Installation location Installation side Order number

track-rod arm side left 9460 066 235
steering arm side right 9460 066 328

Accessories
Description Order number

Kingpin 9463 320 006

Vehicle type Actros I/MP2/MP3
Bolt diameter 50 mm
Bolt length 223 mm

Scope of supply

2 top needle bearings, 2 bottom needle bearings, 1 thrust bearing, 1 sealing ring,
1 thrust collar

Repair kit

Kingpin

Vehicle type Actros I/MP2/MP3
Bolt diameter 50/64 mm
Bolt length 119 mm

Scope of supply

1 axle bolt, 1 sealing ring, 1 bush, 1 shaft sealing ring, 1 snap ring, 1 screw plug

Order number

1583 005 100

Repair kit

Kingpin

Vehicle type Actros I/MP2/MP3
Installation location top
Bolt diameter 50 mm
Bolt length 109 mm

Scope of supply

1 axle bolt, 1 sealing ring, 1 bush, 1 pressure disc, 1 shaft sealing ring, 1 circlip,
1 screw plug

Order number

1583 005 000

Repair kit

Kingpin

Vehicle type Actros I/MP2/MP3
Installation location bottom
Bolt diameter 50 mm
Bolt length 120 mm

Scope of supply

1 axle bolt, 1 sealing ring, 1 snap ring, 1 shaft sealing ring, 1 screw plug, 2 needle
bearings

Order number

9463 300 219

38

1

Actros

Axle and steering

Wheel hub

Installation location Front axle

Vehicle type Version Order number

Actros I/MP2/MP3 without bearing 9870 102 496
Actros I with bearing 9463 300 125

This figure corresponds to 9463 300 125

Wheel hub

Vehicle type Actros I
Version with bearing
Installation location Rear axle

Order number

(on request) 9463 500 335

Compact bearing

Vehicle type Actros I/MP2/MP3
External diameter 140 mm
Inner diameter 82 mm
Width 115 mm

Scope of supply

inner and outer bearing with sealing ring

Tapered roller bearing

Vehicle type Actros I/MP2/MP3

Order number

9469 819 305

(Illustration similar)

Version Outer ∅mm Inner ∅mm Height mm Order number

wheel hub, outer 130 60 48.5 8001 323 122
wheel hub, outer 130 80 37 8001 331 162
wheel hub, inner 150 100 39 8001 330 202
wheel hub, inner 170 110 47 8001 330 222

40

∅

Tapered roller bearing

Vehicle type Actros I/MP2/MP3

Axle and steering

1

Actros

Version Outer

Wheel hub, inside 110 55 39 6950 001 328
wheel hub, inner 150 70 64 8001 228 000
wheel hub, outside 72 35 28 8001 332 070
wheel hub, outer 157 100 42 9469 812 305
rear axle, outer 160 100 44 8001 805 312

1

mm Inner ∅mm Height mm Order number

23

Shaft sealing ring

for wheel hub

Installation location Rear axle, inner

Illustration Vehicle type Outer ∅mm Inner ∅mm Height mm Order number

1 Actros I 150 125 15 8002 971 436
2 Actros I/MP2/MP3 175 145 15 8002 972 816
3 Actros I/MP2/MP3 175 145 17/21 8002 972 815

Shaft sealing ring

for wheel hub

Vehicle type Actros I/MP2/MP3
Installation location front axle, inner
Version for 8-hole wheel connection
External diameter 150 mm
Inner diameter 120 mm
Height 12 mm

Order number

9460 245 939

41www.europart.net

1

Actros

Axle and steering

Shaft sealing ring

for wheel hub

Vehicle type Actros I
Installation location Front axle, inner
Version with ABS ring
External diameter 134 mm
Inner diameter 75 mm

Order number

9479 970 446

Repair kit

for wheel hub

Vehicle type Actros I
Installation location Rear axle
Installation side left, right
External diameter 150 mm
Inner diameter 125 mm
Height 15 mm

Scope of supply

1 shaft seal, 1 seal, 1 locking washer

Order number

9460 006 120

Gasket set

for wheel hub

Vehicle type Actros I/MP2/MP3
Installation location front axle
External diameter 150 mm
Inner diameter 120 mm
Height 20 mm

Scope of supply

2 axial seals, 1 seal, 1 pulse wheel, 8 hexagon bolts

Gasket set

for wheel hub

Vehicle type Actros I/MP2/MP3
Installation location rear axle
Installation side left/right
External diameter 175 mm
Inner diameter 145 mm
Height 17 mm

Scope of supply

1 axial seal, 1 thrust ring, 1 pulse wheel, 1 cover plate, 1 tab washer

Order number

9463 301 025

Order number

8002 000 033

42

Axle and steering

∅

1

Actros

12

3

4

Axle nut

Illustration Vehicle type Installation location Thread Order number

1 Actros I/MP2/MP3 Front axle/rear axle M45 x 1.5 1325 040 294
2 Actros I/MP2/MP3 Front axle M70 x 1.5 9469 908 150
3 Actros I/MP2 Rear axle M75 x 1.5 (on request) 9463 530 026
4 Actros I/MP2/MP3 Rear axle M100 x 1.5 9463 560 226

12

'A' frame

with molecular bearing

Vehicle type Actros I/MP2/MP3
Installation location rear axle
Length 622 mm
Distance between holes 152/130/130 mm

Illustration Pipe

1 48 25/23/23 9070 001 009 Mercedes-Benz 942 350 12 05
2 46 25/25/25 9070 001 021 Mercedes-Benz 942 350 15 05
2 46 25/25/25 9070 001 022 Mercedes-Benz 948 350 04 05

mm Bore hole ∅mm Order number Comparative number

'A' frame

with molecular bearing

Vehicle type Actros I/MP2/MP3
Installation location rear axle
Length 622 mm
Distance between holes 152/130/130 mm
Pipe diameter 46 mm
Bore hole diameter 25/23/23 mm

Order number

5220 090 013

43www.europart.net

1

∅

Actros

Axle and steering

Repair kit

for wishbone

Vehicle type Actros I/MP2/MP3
Version with molecular bearing
Bore hole diameter 23 mm
Distance between holes 130 mm

Order number

9079 991 558

Repair kit

for wishbone

Vehicle type Actros I/MP2/MP3
Version with molecular bearing

Bore hole

24 130 9463 504 805
25 130 9079 991 608
25 152 9077 200 300
25 152 9079 991 609
25 152 9070 310 410

mm Distance between holes mm Order number

Trailing arm

Vehicle type Actros I/MP2/MP3
Version with molecular bearing
Length 850 mm
Pipe diameter 52 mm
Bore hole diameter 17 mm
Distance between holes 100 mm

Trailing arm

Vehicle type Actros I/MP2/MP3
Version with molecular bearing
Length 754 mm
Pipe diameter 58 mm
Bore hole diameter 17 mm
Distance between holes 100 mm

Order number

9070 022 092

Order number

9079 991 543

44

Trailing arm

Vehicle type Actros I/MP2/MP3
Version with molecular bearing
Length 565 mm
Pipe diameter 50 mm
Bore hole diameter 21 mm
Distance between holes 152 mm

Repair kit

axle strut, torque rod

Vehicle type Actros I/MP2/MP3
Version with molecular bearing
Installation location Rear axle
Installation side left, right
External diameter 85 mm
Inner diameter 21 mm
Distance between holes 152 mm

Axle and steering

1

Actros

Order number

5210 090 055

Order number

6170 490 816

Wheel bolt

Vehicle type Actros I/MP2/MP3
Outer thread M22 x 1.5

Installation location Overall length mm Order number

front axle/rear axle 78,5 2213 000 105
rear axle 96,6 2213 000 106
rear axle 101,5 2213 000 110

Wheel nut

Vehicle type Actros I/MP2/MP3
Thread M22 x 1.5
Spanner size 32

Installation location suitable for Height mm Order number

front axle/rear axle steel and aluminium wheels 27 1303 221 551
front axle aluminium wheels 34 (Short sleeve) 6136 320 442
rear axle aluminium wheels 62 (Long sleeve) 6136 320 452

45www.europart.net

1

Braking system

Actros

1 2

Brake disc

Vehicle type Actros I/MP2/MP3
Installation location front/rear axle
Version internally ventilated
External diameter 430 mm
Thickness 45 mm

Illustration Height mm Hole pattern Order number

1 132.5 10 x M14 x 1,5 3403 460 000
2 143.5 10 x M20 x 1,5 3403 460 001

Suitable brake piston resetting tools available from EUROPART!

Attachment screw

for brake disc

Vehicle type Actros I/MP2/MP3
Installation location Front axle
Surface dacrotized
Thread M14 x 1.5
Property class 10.9
Length 60 mm

Attachment screw

for brake disc

Vehicle type Actros I/MP2/MP3
Installation location Rear axle
Surface phosphated
Thread M14 x 1.5
Property class 10.9
Length 75 mm

Order number

9460 066 205

Order number

9469 900 004

46

1

Braking system

Actros

Brake pad set

front/rear axle

Vehicle type Actros I/MP2/MP3
Contents of set 4
Coating length 248 mm
Lining width 108 mm
Lining thickness 30.00 mm
Brake system Knorr SB/SN 7
WVA no. 29061

Scope of supply

with accessories

Order number

2323 405 106

Brake pad set

Vehicle type Actros MP2/MP3
Brake system SB/SN7 (ProTecS)
WVA no. 29253
Contents of set 4
Coating length 247,7 mm
Lining width 109,7 mm
Lining thickness 30.00 mm

Scope of supply

with accessories

Order number

2120 292 530

48

Brake pad set

Vehicle type Actros MP2
Brake system Knorr SB 7000
WVA no. 29202
Contents of set 4
Coating length 247,7 mm
Lining width 109,7 mm
Lining thickness 30.00 mm

Scope of supply

with accessories

Order number

2190 873 005

Braking system

Brake caliper

Vehicle type Actros I/MP2/MP3
Installation location front axle/rear axle
Version standardised

Application range

for 22.5" wheel size

Type Installation side Order number

SN7211RC left 3450 003 800
SN7201RC right 3450 003 799

Accessories
Description Order number

Pressure pad set 3400 110 013
Guide sealing set 3450 414 380
Adjuster cap set 3450 411 915

1

Actros

Brake caliper

Vehicle type Actros I/MP2/MP3
Installation location front axle/rear axle
Version standardised

Application range

for 22.5" wheel size

Type Installation side Order number

SN7300RC left 3400 047 092
SN7310RC right 3400 013 182

Accessories
Description Order number

Pressure pad set 3400 110 013
Guide sealing set 3450 414 380
Adjuster cap set 3450 411 915

Brake caliper

Vehicle type Actros I/MP2/MP3
Installation location front axle/rear axle
Version standardised

Application range

for 17.5" wheel size

Type Installation side Order number

SN5016RC left 3450 414 785
SN5006RC right 3450 414 784

Accessories
Description Order number

Pressure pad set 3400 001 929
Guide sealing set 3400 047 188
Adjuster cap set 3450 411 915

49www.europart.net

1

∅

Actros

Braking system

Brake caliper

Vehicle type Actros I/MP2/MP3
Installation location front axle/rear axle
Version standardised

Application range

for 17.5" wheel size

Type Installation side Order number

SN5015RC left 3450 414 783
SN5005RC right 3450 414 782

Accessories
Description Order number

Pressure pad set 3400 001 929
Guide sealing set 3400 047 188
Adjuster cap set 3450 411 915

Sensor ring, ABS

ABS

Vehicle type Actros I/MP2/MP3

Brake caliper carrier

Vehicle type Actros I/MP2/MP3
Brake system Knorr SB/SN 7

Installation location Order number

front axle 3450 411 905
rear axle 3450 411 910

21

Illustration Installation location Outer

- Front axle 178 140 15 9463 334 011
1 Front axle 164/188 160 12 1593 102 551
2 Rear axle 176/195.5 153 16.5 1593 102 550

mm Inner ∅mm Thickness mm Order number

50

Braking system

21

Brake drum

Vehicle type Actros I/MP2/MP3

Illustration suitable for Dimensions mm Brake path mm Order number

1 front axle 410 x 237 x 10 x 23/3 x M12 x 1,5 191 2030 410 039
2 rear axle 410 x 306 x 10 x 24/5 x 24/3 x M12 x 1,5 237 2030 410 040
1 rear axle 410 x 306 x 10 x 23/5 x 24/3 x M12 x 1,5 240 2030 410 034

1

Actros

Brake lining set

Vehicle type Actros I/MP2/MP3
Lining thickness 17.00 mm
Contents of set 8

WVA no. Dimensions mm Order number

19495 410 x 183 2119 487 008
19496 410 x 223 2119 488 008

51www.europart.net

1

Actros

Pneumatic system

Air dryer

Vehicle type Actros I/MP2/MP3
Version 1-chamber system
Operating pressure max. 13 bar

Order number Comparative number
0565 000 070 WABCO 932 500 110 0

Air dryer

Vehicle type Actros I
Version 1-chamber system with integrated pressure regulator and

heating
Operating pressure max. 13 bar
Opening pressure 14,5 + 2,5 bar
Cut-off pressure 12 ± 0,3 bar
Operating range 1,5 +/- 0,25 bar
Voltage 24 V

Order number Comparative number
0564 000 020 WABCO 932 400 024 0

Air dryer

Vehicle type Actros I/MP2/MP3
Version 2 chamber system
Operating pressure max. 13 bar
Opening pressure 14,5 ± 2,5 bar
Cut-off pressure 12 ± 0,3 bar
Voltage 24 V

Order number Comparative number
0174 330 020 WABCO 432 433 002 0
0174 320 060 WABCO 432 433 206 0

Air dryer

as replacement

Vehicle type Actros I/MP2/MP3
Thread M39 x 1.5
Operating pressure max. 13 bar

Order number Comparative number
3419 851 271 WABCO 432 410 222 7

52

Pneumatic system

Air dryer

Vehicle type Actros I/MP2/MP3
Version 1-chamber system
Cut-off pressure 12,3 +/- 0,3 bar
Operating range 1,5 +/- 0,25 bar
Voltage 24 V

Order number Comparative number
3450 409 045 Knorr II38310FN00

Air dryer

Vehicle type Actros I/MP2/MP3
Version 1-chamber system
Cut-off pressure 12,3 +/- 0,3 bar
Operating range 1,5 +/- 0,25 bar
Voltage 24 V

Order number Comparative number
3400 038 309 Knorr II38308FN00

1

Actros

Four-circuit protection valve

as replacement

Vehicle type Actros I/MP2/MP3
Operating pressure max. 13 bar

Order number Comparative number
0577 050 050 WABCO 934 705 005 7

Pressure sensor

Vehicle type Actros I/MP2/MP3

Order number Comparative number
0210 435 011 WABCO 932 500 501 1

53www.europart.net

1

∅

∅

Actros

Pneumatic system

Pressure sensor

Vehicle type Actros I

Order number Comparative number
3450 414 230 Knorr II39746F004

Compressed air tank

EN 286-2, steel

Vehicle type Actros I/MP2/MP3
Version with bracket
Volume 5 l
Diameter 154 mm
Length 341 mm
Connection 3 x M22 x 1.5
Operating pressure 10 bar

Order number

3620 001 545

Compressed air tank

EN 286-2, steel

Connection 4 x M22 x 1.5
Operating pressure max. 15.5 bar

Vehicle type Volume l

Actros I/MP2/MP3 10 206 368 3620 020 610
Actros I/MP2/MP3 20 246 493 3620 024 620
Actros I 20 276 414 3620 027 620
Actros I/MP2/MP3 30 276 583 3620 027 630

mm Length mm Order number

Compressed air tank

to EN 286-2, Aluminium

Vehicle type Actros I/MP2/MP3
Connection 2 x M22 x 1.5

Volume l

20 246 500 max. 12.5 1740 200 024
30 246 720 max. 12.5 1742 302 460
40 276 770 max. 12.5 1742 402 760
60 310 907 max. 10 1742 603 100

mm Length mm Operating pressure bar Order number

54

∅

Pneumatic system

Air reservoir tensioning strap

with bracket, 1-piece

mm Order number

206 1740 012 060
246 1740 022 460
276 1740 032 760
310 1740 043 100

Accessories
Tensioning strap base

Length 1000 mm
Material rubber

Order number

9085 413 340

Dehumidification valve

DIN 74292, standard B

Version mechanical, with ring
Material brass
Connection M22 x 1,5
Operating pressure 20 bar
Spanner size 27

Order number

1740 060 020

1

Actros

Braking-value sensor

EBS

Vehicle type Actros I
Operating pressure max. 10 bar
Thread VOSS

Version Connection 1-2 Connection 4 Order number Comparative number

without silencer M22 x 1,5 M16 x 1,6 0640 060 030 WABCO 480 001 000 0
with silencer VOSS 232 NG 12 VOSS 232 NG 8 0360 010 100 WABCO 480 001 010 0

Braking-value sensor

EBS

Vehicle type Actros MP2/MP3
Version with silencer
Operating pressure max. 13 bar

Order number Comparative number
3800 030 100 WABCO 480 003 000 0

55www.europart.net

1

Actros

Pneumatic system

Hand brake valve

Vehicle type Actros I
Operating pressure max. 10 bar

Order number Comparative number
0607 231 250 WABCO 961 723 125 0

Hand brake valve

Vehicle type Actros I
Version lateral connections
Operating pressure max. 10 bar

Order number Comparative number
3400 006 770 Knorr K038804N00

Hand brake valve

Vehicle type Actros I
Operating pressure max. 10 bar

Order number Comparative number
3400 006 760 Knorr K038803N00

Hand brake valve

Vehicle type Actros I/MP2/MP3
Operating pressure max. 10/8.5 bar

Order number Comparative number
3401 970 066 Knorr K038808N00

56

Pneumatic system

Motor coach brake valve

with VOSS 232 coupling unit
Vehicle type Actros I
Version lead 0.5 bar, control ratio 2:1, with silencer
Operating pressure max. 10 bar

Order number Comparative number
0283 192 740 WABCO 461 319 274 0

EBS trailer control valve

Vehicle type Actros I
Version connector, horizontal
Operating pressure max. 8.5 bar

Order number Comparative number
0064 060 070 WABCO 480 204 002 0

1

Actros

EBS axle modulator

Vehicle type Actros I

Order number Comparative number
0362 000 037 WABCO 480 103 011 0

EBS axle modulator

Vehicle type Actros I/MP2/MP3

Order number Comparative number
3800 105 006 WABCO 480 105 006 0
3801 050 070 WABCO 480 105 007 0

57www.europart.net

1

Actros

Pneumatic system

EBS relay valve

Vehicle type Actros I/MP2
Version proportional relay valve, with silencer
Thread VOSS 232
Connection electric, bayonet DIN
Connection 1-2 M22 x 1,5
Connection 4 M16 x 1,5

Order number Comparative number
0640 060 040 WABCO 480 202 004 0

EBS relay valve

Vehicle type Actros MP3
Version Proportional relay valve, with silencer
Thread VOSS 232
Connection electric, bayonet DIN
Connection 1-2 M22 x 1,5
Connection 4 M16 x 1,5

Order number Comparative number
0392 020 090 WABCO 480 202 009 0

Relay valve

Vehicle type Actros I/MP2/MP3
Thread VOSS 230
Connection electric, bayonet (DIN)
Connection 1-2 M22 x 1,5
Connection 3 with muffler
Connection 4 M16 x 1,5

Order number Comparative number
0640 060 037 WABCO 973 006 003 0

Relay valve

Vehicle type Actros I/MP2/MP3
Operating pressure max. 10.2 bar
Thread VOSS
Connection 1-2 M22 x 1,5
Connection 3 with muffler
Connection 4 M16 x 1,5

Order number Comparative number
0640 110 040 WABCO 973 011 004 0

58

1

Actros

Pneumatic system

Solenoid control valve

for ABS

Vehicle type Actros I/MP2/MP3
Installation location rear axle
Voltage 24 V
Electric current 1,65 A
Connection electric, bayonet (DIN)
Connection thread M22 x 1.5 JED-388

Order number Comparative number
0371 950 087 WABCO 472 195 016 0

123

Speed sensor

S plus

Vehicle type Actros I/MP2/MP3

Illustration Colour Cable length mm Order number Comparative number

1 orange 2500 0210 329 200 WABCO 441 032 920 0
1 orange 3000 0210 329 420 WABCO 441 032 942 0
1 orange 3600 0210 329 460 WABCO 441 032 946 0
2 black 1500 0210 328 510 WABCO 441 032 851 0
2 black 2000 0210 328 230 WABCO 441 032 823 0
3 black 3400 0210 329 410 WABCO 441 032 941 0

Accessories
Clamping sleeve

Length 33 mm

Order number

0687 605 104

60

1

Actros

Pneumatic system

Combination brake cylinder

Type 20/24 IBV

with VOSS 232 coupling unit
Vehicle type Actros I/MP3
Installation location rear axle
Connection M22 x 1.5, VOSS NG 12
Operating pressure max. 10.2/8.5 bar
Stroke 64/64 mm
Length of piston rod 15 mm

Installation side Order number Comparative number

left 0554 600 010 WABCO 925 480 005 0
right 0554 600 000 WABCO 925 480 004 0

Combination brake cylinder

Type 12/16 IBV

Vehicle type Actros MP3
Installation location rear axle
Installation side left/right
Connection M22 x 1.5, VOSS 232
Operating pressure max. 10.2/8.5 bar
Stroke 57/57 mm
Length of piston rod 15 mm

Order number Comparative number
0554 661 010 WABCO 925 486 101 0

Combination brake cylinder

Type 20/24 IBV

with VOSS 232 coupling unit
Vehicle type Actros I/MP2/MP3
Installation location rear axle
Connection M22 x 1.5, VOSS NG12
Operating pressure max. 10.2/8.5 bar
Stroke 64/64 mm
Length of piston rod 15 mm

Installation side Order number Comparative number

left 0554 600 110 WABCO 925 480 011 0
right 0554 600 100 WABCO 925 480 010 0

62

Pneumatic system

Membrane brake cylinder

Type 24

with VOSS 232 coupling unit
Vehicle type Actros I/MP2/MP3
Installation location front axle
Connection 1 side, M22 x 1.5, VOSS NG 12
Connection 2 central, M12 x 1.5
Stroke 64 mm
Length of piston rod 15 mm

Installation side Order number Comparative number

left 3405 351 500 Knorr K002720N00
right 3405 351 400 Knorr K002624N00

1

Actros

Membrane brake cylinder

Type 24

Vehicle type Actros MP3
Installation location front axle
Connection 1 M22 x 1.5
Connection 2 M12 x 1.5
Stroke 64 mm
Length of piston rod 15 mm

Installation side Order number Comparative number

right 3405 351 600 Knorr K002721N00
left 3405 352 200 Knorr K002722N00

Membrane brake cylinder

Type 24

with clutch unit VOSS 232
Vehicle type Actros MP3
Installation location Front axle
Connection 1 on the side, M22 x 1.5, VOSS NG 12
Installation side left, right
Stroke 64 mm
Length of piston rod 15 mm

Order number Comparative number
3779 021 830 Haldex 125 240 400

63www.europart.net

1

Actros

Pneumatic system

Combination brake cylinder

Type 20/24

with VOSS 232 coupling unit
Vehicle type Actros I
Installation location rear axle
Connection M22 x 1.5
Stroke 57/57 mm
Length of piston rod 15 mm

Installation side Order number Comparative number

left 3400 009 492 Knorr K004032000
right 3400 009 491 Knorr K004031000

Combination brake cylinder

Type 20/24

with VOSS 232 coupling unit
Vehicle type Actros MP2
Installation location rear axle
Connection M22 x 1.5
Stroke 64/64 mm
Length of piston rod 15 mm

Installation side Order number Comparative number

left 3404 045 000 Knorr K004045000
right 3404 044 000 Knorr K004044000

Combination brake cylinder

Type 20/24 HFL3

with VOSS 232 coupling unit
Vehicle type Actros I
Installation location rear axle
Connection M22 x 1.5, VOSS NG 12
Stroke 64/64 mm
Length of piston rod 15 mm

Installation side Order number Comparative number

left 3400 019 060 Knorr K002860N00
right 3400 046 505 Knorr K002861N00

64

Pneumatic system

Clutch servo

in exchange

Vehicle type Actros I
Piston diameter 102 mm
Connection M16 x 1.5
Stroke 85 mm
Operating pressure max. 10 bar

Order number Comparative number
0730 514 057 WABCO 970 051 431 7

Clutch servo

Vehicle type Actros MP2/MP3
Connection M16 x 1.5
Stroke 85 mm
Operating pressure max. 10 bar

Order number Comparative number
0730 514 410 WABCO 970 051 441 0

1

Actros

Coupling head

automatic

Version with valve

Version Connection thread Colour Order number

brake line M16 x 1.5 yellow 3700 000 011
brake line M22 x 1.5 yellow 3700 000 013
supply line M16 x 1.5 red 3700 000 012
supply line M22 x 1.5 red 3700 000 014

Coupling head

automatic

Version supply line
Connection thread M16 x 1.5

Order number

3700 000 008

65www.europart.net

1

Pneumatic system

ECAS path sensor

Actros

for air suspension

Vehicle type Actros I, Atego II
Connection bayonet DIN 72585-A1-2.1-Sn/K2

Order number Comparative number
0210 500 120 WABCO 441 050 012 0

ECAS path sensor

for air suspension

Vehicle type Actros MP2/MP3
Connection bayonet DIN 72585-A1-2.1-Sn/K2

Order number Comparative number
9465 422 618 WABCO 441 050 121 0

ECAS solenoid valve

Vehicle type Actros I/MP2
Installation location rear axle
Version 3 magnets, with silencer
Connection electric, bayonet DIN
Connection thread M22 x 1.5
Voltage 24 V
Operating pressure max. 13 bar

Order number Comparative number
0379 000 600 WABCO 472 900 060 0

Accessories
Muffler

Diameter 69 mm
Height 45/56.5 mm
Operating pressure max. 13 bar
Connection M22 x 1.5

Order number

0174 070 000

66

Pneumatic system

ECAS solenoid valve

Vehicle type Actros MP2
Installation location Rear axle
Version with muffler
Connection electric, bayonet DIN
Connection thread M22 x 1.5
Voltage 24 V
Operating pressure max. 13 bar

Order number Comparative number
0378 800 000 WABCO 472 880 000 0

ECAS solenoid valve

Vehicle type Actros MP3
Installation location rear axle, tag axle
Version with noise reducer, solenoid connection at top
Connection electric, 2 x bayonet (DIN)
Connection thread M22 x 1.5, VOSS 230
Voltage 24 V
Operating pressure max. 5-13 bar

Order number Comparative number
0379 051 110 WABCO 472 905 111 0

1

Actros

ECAS control unit

Vehicle type Actros I
System 6 x 2
Voltage 24 V

Order number Comparative number
0761 700 520 WABCO 446 170 055 0

Central module

Vehicle type Actros I
Version 4S/4M

Order number Comparative number
0362 000 030 WABCO 446 130 014 0

67www.europart.net

1

Pneumatic system

Assortment case

for VOSS connector system 230, complete

Actros

Contents
Number Description Dimensions mm Order number

2 Straight connector NG 8, Pipe connector 6 x 1 0307 000 050
2 Straight connector NG 8, Pipe connector 9 x 1,5 0307 000 350
2 Straight connector NG 12, Pipe connector 9 x 1,5 0307 000 180
2 Straight connector NG 12, Pipe connector 12 x 1,5 0307 000 200
1 Straight connector NG 12, Pipe connector 16 x 2 0307 000 060
1 Tee plug connector NG 12, Pipe connector 12 x 1,5 0307 001 960
1 Angled plug NG 8, 90°, Pipe connector 6 x 1 0307 000 070
2 Angled plug NG 8, 90°, Pipe connector 8 x 1 0307 000 340
2 Angled plug NG 12, 90°, Pipe connector 8 x 1 0307 000 220
2 Angled plug NG 12, 90°, Pipe connector 12 x 1,5 0307 000 230
6 Gasket set for connectors NG 8 9460 002 310
6 Gasket set for connectors NG 12 9460 002 311
4 Union bolt NG 8, M16 x 1.5 0307 000 030
4 Union bolt NG 12, M22 x 1.5 0307 000 160
1 Threaded compression adapter NG 8, M16 x 1.5 3800 022 601
1 Straight screw-in coupling NG 12, M16 x 1.5 0307 000 300
1 Straight screw-in coupling NG 12, M22 x 1.5 0307 000 240
1 Sealing plug NG 8 0307 001 990
1 Sealing plug NG 12 0307 001 980

Version Order number
42-piece 0307 001 415

68

Pneumatic system

Assortment case

for VOSS connector system 232, complete
Version Order number

381-piece 0307 000 145

Contents
Number Description Type Dimensions mm Order number

4 Straight coupling 232 NG 8, Pipe connector 8 x 1 0307 124 325
4 Straight coupling 232 NG 12, Pipe connector 12 x 1,5 0307 124 330
10 Adapter for units with step drilling 230 NG 6 0307 000 194
4 Straight screw-in coupling 232 NG 8, M16 x 1.5 0307 124 220
4 Straight screw-in coupling 232 NG 12, M16 x 1.5 0307 124 290
4 Straight screw-in coupling 232 NG 12, M22 x 1.5 0307 124 310
20 Union bolt 230 NG 6, M10 x 1 0307 003 300
6 Union bolt 230 NG 8, M16 x 1.5 0307 000 030
6 Union bolt 230 NG 12, M22 x 1.5 0307 000 160
12 Union bolt 232 NG 8, M16 x 1.5 0307 124 700
12 Union bolt 232 NG 12, M22 x 1.5 0307 124 695
10 Straight connector 230 NG 6, Pipe connector 6 x 1 0307 003 430
15 Straight connecting plug 232 NG 8, Pipe connector 8 x 1 0307 124 360
5 Straight connecting plug 232 NG 12, Pipe connector 8 x 1 0307 124 395
9 Straight connecting plug 232 NG 12, Pipe connector 12 x 1,5 0307 124 400
10 Sealing plug 232 NG 8 0307 124 755
3 Sealing plug 232 NG 12 0307 124 760
10 Straight quick-fit coupling 230 Pipe diameter 6 0307 003 060
4 Angled plug 230 NG 6, 90°, Pipe connector 6 x 1 0307 000 055
10 Angled plug 232 NG 8, 90°, Pipe connector 8 x 1 0307 124 945
6 Angled plug 232 NG 12, 90°, Pipe connector 8 x 1 0307 124 970
6 Angled plug 232 NG 12, 90°, Pipe connector 12 x 1,5 0307 124 975
2 Tee plug connector 232 NG 12, Pipe connector 12 x 1,5/8 x 1 0307 124 660
1 Tee plug connector 232 NG 12, Pipe connector 12 x 1,5/12 x 1,5 0307 124 680
30 O-ring, Mud ring 232 NG 8, 7.5 x 2 0307 239 961
30 O-ring, Mud ring 232 NG 12, 12 x 2 0307 449 961
30 O-ring, Sealing ring 232 NG 8, 7 x 1.5 5239 390 055
30 O-ring, Sealing ring 232 NG 12, 12 x 1.6 0307 089 971
30 O-ring, Mud ring 230 NG 6, 5.5 x 1.5 0307 159 972
30 O-ring, Sealing ring 230 NG 6, 3.5 x 1.5 0307 149 971
20 Spring element 230 NG 6, 6.5 0307 062 179
6 Spring element 230 NG 8, 9.7 0307 000 040
6 Spring element 230 NG 12, 15.2 0307 000 170
20 Clamp 230 NG 6, 7.4 0307 016 900
6 Clamp 230 NG 8, 11.6 0307 000 020
6 Clamp for 6 tube 230 NG 12, 17.6 0307 000 150

1

Actros

69www.europart.net

1

Lighting and electrics

H4 main headlamp

Vehicle type Actros I
Version with indicator, high beam and side light

Actros

Installation side Application Order number

left for vehicles without headlight levelling 3600 100 030
right for vehicles without headlight levelling 3600 100 040
left for vehicles with headlight levelling (electric) 3600 100 055
right for vehicles with headlight levelling (electric) 3600 100 060

Service parts
Description Order number

Side light/indicator lens, left 3600 100 015
Side light/indicator lens, right 3600 100 025
Reflector, left 3605 321 867
Reflector, right 3605 321 868
H4 halogen headlamp bulb 8900 006 000
Bulb, Drop-shaped, 24 V, 21 W 8900 003 000
Bulb, Drop-shaped, BA 15 s, 24 V, HD version 8900 010 000
Glass-base bulb, 24 V, 5 W 8900 040 130

Voltage 24 V

H4 main headlamp

Vehicle type Actros I
Voltage 24 V

Application range

for vehicles with headlight levelling (electric)

Installation side Version Order number

left with high beam and side light 9468 204 761
right with high beam and side light 9468 204 861
left with indicator and fog light 9468 204 361
right with indicator and fog light 9468 204 461

Service parts
Description Order number

Side light/indicator lens, left 3600 100 015
Side light/indicator lens, right 3600 100 025
Reflector, left 3600 321 871
Reflector, right 3600 321 872
H1 halogen headlamp bulb 8900 040 100
H4 halogen headlamp bulb 8900 006 000
Bulb, Drop-shaped, 24 V, 21 W 8900 003 000
Bulb, Drop-shaped, BA 15 s, 24 V, HD version 8900 010 000
Glass-base bulb, 24 V, 5 W 8900 040 130

70

Headlamp adjustment equipment available from EUROPART!

Lighting and electrics

H4/H1 main headlamp

Vehicle type Actros I
Version with high beam, fog and side light
Voltage 24 V

Application range

for vehicles without headlight levelling

Installation side Order number

left 3600 100 045
right 3600 100 050

Service parts
Description Order number

Side light/indicator lens, left 3600 100 015
Side light/indicator lens, right 3600 100 025
Reflector, left 3600 321 871
Reflector, right 3600 321 872
H1 halogen headlamp bulb 8900 040 100
H4 halogen headlamp bulb 8900 006 000
Bulb, Drop-shaped, 24 V, 21 W 8900 003 000
Bulb, Drop-shaped, BA 15 s, 24 V, HD version 8900 010 000
Glass-base bulb, 24 V, 5 W 8900 040 130

1

Actros

Xenon headlamp

Vehicle type Actros MP2
Version with indicator, high beam and side light
Socket D2R
Bulb type H1/Xenon
Voltage 24 V

Application range

for vehicles without headlight range adjustment (electric)

Installation side Order number

left 9468 200 961
right 9468 201 061

Service parts
Description Order number

Side light/indicator lens, left 0170 064 011
Side light/indicator lens, right 0170 064 021
Gas discharge lamp, P32d-2, 35 W 0007 949 101
H1 halogen headlamp bulb, P 14,5 s, 70 W 8900 040 100
Bulb, 24 V, 21 W, yellow 9560 013 496
Glass-base bulb, 24 V, 5 W 8900 040 130

71www.europart.net

1

Lighting and electrics

H7/H1 main headlamp

Vehicle type Actros MP2/MP3
Version with indicator, high beam and parking light

Actros

Installation side Version Order number

left for vehicles without headlight levelling 9501 658 202
right for vehicles without headlight levelling 9501 658 203
left for vehicles with headlight levelling (electric) 9501 658 200
right for vehicles with headlight levelling (electric) 9501 658 201

Service parts
Description Order number

Side light/indicator lens, left 0170 064 011
Side light/indicator lens, right 0170 064 021
H1 halogen headlamp bulb, P 14,5 s, 70 W 8900 040 100
H7 halogen headlamp bulb, PX 26 d, 70 W 8900 001 030
Bulb, 24 V, 21 W, yellow 9560 013 496
Glass-base bulb, 24 V, 5 W 8900 040 130

Voltage 24 V

H7/H1 main headlamp

Vehicle type Actros MP3
Version with indicator, high beam and side light
Voltage 24 V

Installation side Version Order number

left for vehicles without headlight levelling 9269 513 011
right for vehicles without headlight levelling 9269 513 021
left for vehicles with headlight range adjustment (electric) 9501 658 224
right for vehicles with headlight range adjustment (electric) 9501 658 225

Service parts
Description Order number

Side light/indicator lens, left 0170 064 011
Side light/indicator lens, right 0170 064 021
H1 halogen headlamp bulb 8900 040 100
H7 halogen headlamp bulb, PX 26 d, 70 W 8900 001 030
Headlight frame, left 0165 229 031
Headlight frame, right 0165 230 031
Bulb, 24 V, 21 W, yellow 9560 013 496
Glass-base bulb, 24 V, 5 W 8900 040 130
Bracket, left 9468 806 414
Bracket, right 9468 806 514
Plastic cable tie 3237 000 047

72

Lighting and electrics

Xenon headlamp

Vehicle type Actros MP2/MP3
Version with indicator, high beam and parking light
Socket D1S/H1/PY21W/W5W
Voltage 24 V

Application range

for vehicles without headlight range adjustment, without setting motor

Installation side Order number

left 9501 658 206
right 9501 658 207

Service parts
Description Order number

Side light/indicator lens, left 0170 064 011
Side light/indicator lens, right 0170 064 021
H1 halogen headlamp bulb, P 14,5 s, 70 W 8900 040 100
H7 halogen headlamp bulb, PX 26 d, 70 W 8900 001 030
Headlight frame, left 0165 229 031
Headlight frame, right 0165 230 031
Bulb, 24 V, 21 W, yellow 9560 013 496
Glass-base bulb, 24 V, 5 W 8900 040 130
Gas discharge lamp, 85 V, 35 W 2748 541 000
Bracket, left 9468 806 414
Bracket, right 9468 806 514
Plastic cable tie 3237 000 047

1

Actros

H3 spotlight

Vehicle type Actros I
Width 175.3 mm
Height 89 mm
Depth 78 mm
Voltage 12 V

Installation side Order number

left 3600 100 085
right 3600 100 090

Accessories
H3 halogen headlamp bulb

Voltage 24 V
Power 70 W

Order number

8900 009 000

73www.europart.net

1

Actros

Lighting and electrics

H3 spotlight

Vehicle type Actros l
Width 195 mm
Height 103 mm
Depth 98 mm
Voltage 24 V

Installation side Order number

left 9648 207 656
right 9648 207 756

Accessories
Description Order number

H3 halogen headlamp bulb, 24 V, 70 W 8900 009 000
Mounting frame, left 9648 261 759
Mounting frame, right 9648 261 859

H3 fog light

Vehicle type Actros I
Width 175.3 mm
Height 89 mm
Depth 78 mm
Voltage 24 V

Installation side Order number

left 3600 100 080
right 3600 100 065

Accessories
H3 halogen headlamp bulb

Voltage 24 V
Power 70 W

Order number

8900 009 000

H3 fog light

Vehicle type Actros I
Width 195 mm
Height 103 mm
Depth 98 mm
Voltage 24 V

Scope of supply

with bulbs

Installation side Order number

left 9648 207 856
right 9648 207 956

Accessories
Description Order number

H3 halogen headlamp bulb, 24 V, 70 W 8900 009 000
Mounting frame, left 9648 261 759
Mounting frame, right 9648 261 859

74

Lighting and electrics

H3 fog light

Vehicle type Actros MP2/MP3
Width 300 mm
Height 120 mm
Depth 130 mm
Voltage 24 V

Installation side Order number

left 9500 440 200
right 9500 440 201

Accessories
H3 halogen headlamp bulb

Voltage 24 V
Power 70 W

Order number

8900 009 000

Indicator light

Vehicle type Actros I
Installation location front
Installation side left, right
Voltage 24 V
Colour yellow

Scope of supply

with cable and circular connector

Order number

1325 063 537

1

Actros

Accessories
Bulb

Voltage 24 V
Power 21/5 W

Order number

8900 013 000

Indicator light

Vehicle type Actros I
Installation location front
Installation side left/right
Width 102 mm
Height 75 mm
Depth 68 mm
Voltage 24 V
Colour yellow

Scope of supply

with bulb

Order number

9460 009 937

Accessories
Bulb

Description Order number

for indicator, brake, rear fog, reversing lights, 24 V, 21 W 8900 003 000
for brake/tail light, 24 V, 21/5 W 8900 013 000

75www.europart.net

1

Lighting and electrics

Indicator light

Vehicle type Actros I/MP2
Installation location front, bottom

Actros

Installation side Order number

left 6170 463 536
right 6170 463 559

Accessories
Description Order number

Bulb for indicator, brake, rear fog, reversing lights, 24 V, 21 W 8900 003 000
Bulb for brake/tail light, 24 V, 21/5 W 8900 013 000
Bulb socket 9460 463 655

Width 102 mm
Height 75 mm
Depth 68 mm
Socket BA 15 s/BAY 15 d
Voltage 24 V
Colour yellow

Scope of supply

with connection cable

Position light

Parklight

Vehicle type Actros I/MP2/MP3
Version with rubber underlay
Installation side left, right
Width 53.5 mm
Height 48 mm
Depth 68,2 mm
Socket BA15s
Bulb type R10W
Voltage 12/24 V
Colour yellow

Accessories
Bulb

Voltage 24 V
Power 10 W
Bulb type R10W

Order number

0006 679 017

Order number

8900 002 000

76

1

Actros

Lighting and electrics

Position light

Vehicle type Actros I/MP2/MP3
Installation side left/right
Width 100 mm
Height 40 mm
Voltage 12/24 V
Fastening 2 x 4,2 mm, hole spacing 82 mm
Socket SV 8,5
Colour white

Application range

for vehicles with sun visor

Order number

1325 063 538

Service parts
Description Order number

Lens, left/right, white 0137 241 001
Bulb, 24 V, 5 W 8900 005 000

Position light

Vehicle type Actros I/MP2/MP3
Installation side left/right
Width 100 mm
Height 40 mm
Socket SV 8,5
Bulb type C5W
Voltage 24 V
Power 5W
Plug type 2 flat plugs
Fastening 2 x 4.2 mm, hole spacing 82 mm
Colour white

Scope of supply

with bulb holder

Application range

for vehicles without sun visor

Order number

0961 167 021

Service parts
Description Order number

Lens, left/right, white 0137 241 001
Bulb, 24 V, 5 W 8900 005 000

78

Lighting and electrics

LED side marker light

Vehicle type Actros I/MP2/MP3
Installation side left, right
Voltage 24 V
Colour yellow

Version Order number

with connector, 2-pin 8000 463 509
with 0.5 m cable, 90° cable connection, reverse light 9505 940 112

Accessories
Description Order number

Connector set 9465 401 581

1

Actros

Side marker light

Vehicle type Actros I
Version with reflector, without seal
Installation side left/right
Width 41 mm
Height 110 mm
Depth 35,2 mm
Voltage 24 V
Fastening 2 x 5.2 mm
Distance between centres 75 mm
Colour yellow

Order number

9465 444 111

Accessories
Description Order number

Glass-base bulb, 24 V, 3 W 3610 002 841
Lamp holder, with diaphragm ventilation 9641 520 337
Contact carrier 9463 303 870
Plug housing, AMP, 2-pin 9501 245 102
Plug housing, AMP, 2-pin, handle on housing 9501 002 420
Cable grommet, straight 9501 002 248
Cable grommet, 90° angle 9501 002 249

79www.europart.net

1

Lighting and electrics

Actros

Clearance light

Rear-Logic

Vehicle type Actros I
Width 42 mm
Height 109.3 mm
Depth 56,2 mm
Voltage 12/24 V
Type surface-mounting
Colour white/red/amber

Installation side Order number

left 0007 841 011
right 0007 841 021

Accessories
Description Order number

Bulb, spherical, 24 V, 10 W 8900 002 000
Lens, yellow 0146 838 001
Lens, black 0148 673 021

Rear light

Vehicle type Actros I/MP2/MP3
Width 425 mm
Height 110 mm
Depth 82 mm
Socket BA15s/P21W/R10W
Voltage 12/24 V
Connection Cable grommet
Fastening 2 x M8
Pin spacing 152 mm

Installation side Version Order number

left with indicator, brake, tail and rear fog light, reflector 4300 218 011
right with indicator, brake, tail and reversing light, reflector 4300 218 012
left with indicator, brake, tail, rear fog and number plate light, reflector 8840 218 013
right with indicator, brake, tail and rear fog light, reflector 8840 218 014

Service parts
Description Order number

Lens, left/right, with rear fog light 4300 218 111
Lens, left/right, with reversing light 4300 218 112
Bulb, for indicator, brake, rear fog, reversing lights, 24 V, 21 W 8900 003 000
Bulb, for tail, licence plate, position and interior lights, 24 V, 10 W 8900 002 000
Nozzle 0141 941 001

80

Lighting and electrics

Rear light

Vehicle type Actros I/MP2/MP3
Width 139 mm
Height 525 mm
Depth 84,5 mm
Socket BA 15 s
Voltage 24 V
Connection Round connector
Pin spacing 200 mm

Installation side Version Order number

left with indicator, brake, tail, rear fog, reversing, number plate, clearance and side

marker light, reflector

right with indicator, stop, tail, rear fog, reversing, clearance and side marker light,

reflector

Service parts
Description Order number

Lens, left, with rear fog, indicator, stop, reversing and taillight 1040 000 009
Lens, right, with indicator, stop, reversing, taillight 1040 000 010
Bulb, for indicator, brake, rear fog, reversing lights, 24 V, 21 W 8900 003 000
Bulb, for tail, licence plate, position and interior lights, 24 V, 10 W 8900 002 000

8840 220 203

8840 220 202

1

Actros

H1 rotating beacon

Version Halogen
Type surface-mounting
Voltage 24 V
Dimensions 155 x 194 mm
Colour yellow

Scope of supply

with bulb

Order number

0008 061 111

Accessories
Base

Material Rubber
Diameter 155 mm

Form Order number

flat 0862 164 001
wedge-shaped 8000 005 762

81www.europart.net

1

Actros

Lighting and electrics

Indicator switch

Vehicle type Actros I/MP2/MP3
Installation side left
Voltage 24 V
Cable length 560 mm

Order number

9465 453 125

Light switch

Vehicle type Actros I
Version Rotary knob
Colour black
Material Plastic

Order number

1325 060 695

Light switch

Vehicle type Actros MP2/MP3
Version Rotary switch
Colour black
Material Plastic

Order number

(on request) 9465 450 904

Pressure switch

Vehicle type Actros I/MP2/MP3
Voltage 24 V

Installation location Switching pressure bar Order number

Brake circuit III/IV 5,5 9465 455 414
Rear axle 6,5 6170 463 109

82

Lighting and electrics

Window winder

electrical

Vehicle type Actros I

Installation side Order number

left 8000 461 924
right 8000 461 925

Window winder

electric, with motor

Vehicle type Actros I/MP2/MP3

Installation side Order number

left 3870 050 964
right 3870 050 965

1

Actros

Window winder

electric, with motor

Vehicle type Actros I/MP2/MP3

Installation side Order number

left 5828 722 346
right 1325 063 373

Electric motor

for window regulators

Vehicle type Actros I

Installation side Order number

left 5828 820 043
right 8000 463 381

Electric motor

for window regulators

Vehicle type Actros MP2/MP3

Installation side Order number

left 1325 004 908
right 1325 002 908

83www.europart.net

1

Lighting and electrics

Actros

Starter Motor

Vehicle type Actros I/MP2/MP3
Voltage 24 V
Power 6.2 kW
Number of teeth 11
Flange 3-hole flange
Flange diameter 92 mm
Fastening 75°

Order number

7063 000 217

Starter Motor

Vehicle type Actros I/MP2/MP3
Voltage 24 V
Power 6.2 kW
Number of teeth 11
Flange 3-hole flange
Flange diameter 92 mm
Fastening 81°

Order number

7063 002 371

Starter Motor

Vehicle type Actros I/MP2/MP3
Voltage 24 V
Power 6.2 kW
Number of teeth 11
Flange 3-hole flange
Flange diameter 92 mm
Fastening 85°

Starter Motor

with reduction gear

Vehicle type Actros I/MP2/MP3
Voltage 24 V
Power 7.5 kW
Number of teeth 12
Flange 3-hole
Flange diameter 92 mm

Order number

7063 002 370

Order number

9461 511 501

84

Lighting and electrics

1

Alternator

Vehicle type Actros MP3
Version with belt pulley
Pulley diameter 72 mm
Voltage 24 V
Charging current 80 A
Flange 3-hole flange

Alternator

Vehicle type Actros I/MP2/MP3
Version with belt pulley
Pulley diameter 77 mm
Voltage 28 V
Charging current 80 A
Flange 3-hole flange

Actros

Order number

7063 001 031

Order number

7063 001 032

Alternator

Vehicle type Actros I/MP2/MP3
Version without belt pulley
Voltage 28 V
Charging current 80 A
Flange 3-hole flange

Alternator

Vehicle type Actros I/MP3
Version right stop, without pulley
Voltage 24 V
Charging current 140 A
Flange 2-hole

Order number

7063 000 003

Order number

1902 533 300

85www.europart.net

1

Actros

Lighting and electrics

Alternator

Vehicle type Actros I/MP2/MP3
Version with belt pulley
Pulley diameter 77 mm
Voltage 24 V
Charging current 100 A
Flange 3-hole

Order number

5240 860 563

Alternator

Vehicle type Actros I/MP2/MP3
Version without pulley
Voltage 24 V
Charging current 110 A
Flange 3-hole

Order number

5240 860 807

EUROPART

Alongside well-known manufacturer's brands, EUROPART also offers a
strong assortment of its own-brand products with more than 5000 items
from the various EUROPART ranges.

– a powerful brand

Your advantages:

Low-cost alternative for OE standard
Maximum availability at 200 locations in 28 countries
Increase your competitiveness
Consistent service package

86

®

Lighting and electrics

Compressor cool box

CoolMatic CS-MP2

custom-made compressor box operates quietly in the drawer under the driver's bed, (L or LH cab), inviting interior lighting,
generous volume, top cooling power with minimal power consumption, fully hermetic Danfoss BD35F compressor with integrated
control electronics, undervoltage protection, electronic fuse/automatic protection against polarity inversion, dynamically ventilated
wire tube condenser, back-foamed coiled-pipe evaporator, steplessly adjustable thermostat with switch on/off function

current consumption: 1.13 Ah/h at +20 °C ambient temperature, 1.88 Ah/h at +32 °C ambient temperature (at +5 °C temperature
inside device in each case)
average power consumption approx. 45 W

Vehicle type Actros MP2/MP3
Volume 25 l
Material polystyrene
Voltage 12/24 V
Temperature range +10 to 0 °C
Length 554 mm
Width 451 mm
Height 219 mm
Weight 12.5 kg

Order number

9710 004 714

1

Actros

Top quality at

a fair price.

87www.europart.net

1

Actros

Bodywork

Front grille

Vehicle type Actros I
Colour black

Order number

9467 510 518

Front grille

Vehicle type Actros MP2
Driver cab short, medium-long, long
Colour black

Order number

9190 500 218

Front grille

Vehicle type Actros MP2
Driver cab Megaspace

Front grille

Vehicle type Actros MP3
Driver cab short, medium-long, long

Order number

8256 000 154

Order number

9190 501 418

88

Front grille

Vehicle type Actros MP3
Driver cab Megaspace

Order number

(on request) 9467 501 518

Bodywork

Bumper

Vehicle type Actros I
Driver cab short, medium-long, long
Material plastic
Colour grey

Installation side Order number

left 9190 000 521
centre, top 9190 800 303
right 9190 000 520

1

Actros

Accessories
Description Installation side Order number

Foot step centre, top 9460 066 305
Flap centre 9460 066 307
Step-up centre, bottom 9190 801 670

Bumper

Vehicle type Actros I
Driver cab short, medium-long, long
Material steel
Colour grey

Application range

Construction site vehicles

Installation side Order number

left (on request) 9468 806 170
centre, top 9190 800 303
right 9468 806 270

Accessories
Description Installation side Order number

Foot step centre, top 9460 066 305
Flap centre 9460 066 307
Step-up centre, bottom (on request) 9468 805 370

89www.europart.net

1

Bodywork

Actros

Rear apron

Vehicle type Actros I
Driver cab short, medium-long, long
Version Low
Colour grey

Installation side Order number

left 9190 850 924
centre 9460 066 311
right 9190 850 925

Accessories
Step-up

Installation side Order number
centre (on request) 9460 066 356

Bumper

Vehicle type Actros I
Driver cab Megaspace
Material plastic
Colour grey

Installation side Order number

left 9190 005 500
centre, top 9190 851 301
right 9190 000 551

Accessories
Description Installation side Order number

Step-up centre, top 9460 066 317
Flap centre 9460 066 316
Step-up centre, bottom 9190 801 670

90

Bodywork

Bumper

Vehicle type Actros MP2/MP3
Driver cab short, medium-long, long
Material plastic
Colour grey

Installation side Order number

left 9190 800 401
centre, top 9190 800 405
right 9190 800 402

1

Actros

Accessories
Description Installation side Order number

Flap centre 9190 850 326
Step-up centre, bottom 9190 830 001

Bumper corner

Vehicle type Actros MP2/MP3
Driver cab short, medium-long, long
Version with cutout for auxiliary driving lamp
Material plastic
Colour grey

Installation side Order number

left 9190 800 403
right 9190 800 404

Bumper corner

Vehicle type Actros MP2/MP3
Driver cab short, medium-long, long
Material steel
Colour grey

Installation side Order number

left (on request) 9468 808 070
right (on request) 9468 808 170

91www.europart.net

1

Bodywork

Actros

Rear apron

Vehicle type Actros MP2
Driver cab short, medium length, long
Version Low
Colour grey

Installation side Order number

left 9198 850 325
centre, bottom 9198 850 525
right 9198 850 425

Accessories
Description Installation side Order number

Cover centre (on request) 9468 830 024
Step-up centre, bottom (on request) 9468 830 101
Step-up, foldable centre, bottom (on request) 9468 800 931

Our network – 200 locations
in 28 countries

EUROPART – the international
partner for the workshop

www.europart.net

92

Bodywork

1

Actros

Bumper

Vehicle type Actros MP2/MP3
Driver cab Megaspace
Version with cutout for fog light
Colour grey

Installation side Order number

left 9468 809 370
centre 8256 000 117
right 9468 809 470

Accessories
Description Installation side Order number

Step-up centre, bottom 9190 830 001
Flap centre 9190 850 326
Front flap centre 9468 850 526
Air duct left 8256 000 165
Air duct right 8256 000 164

Bumper corner

Vehicle type Actros MP2/MP3
Driver cab Megaspace
Version with cutout for fog light and air inlet
Installation location front
Colour grey

Installation side Order number

left 9190 800 004
right 9190 800 005

Accessories
Air intake

Installation side Order number

left 9190 840 060
right 9190 840 160

93www.europart.net

1

Bodywork

Actros

Rear apron

Vehicle type Actros MP3
Driver cab short, medium-long, long
Version low

Installation side Order number

left 9190 851 625
centre* 9190 851 825
right 9190 851 725

Accessories
Cover

Colour grey

Installation side Order number

left, outside (on request) 9468 851 422
right, outside (on request) 9468 851 522
left, centre (on request) 9463 885 122
centre (on request) 9463 885 112
right, centre (on request) 9468 851 322

*For vehicles up to 442 hp

Rear apron

Vehicle type Actros MP3
Driver cab Megaspace

Installation side Order number

left 9190 851 125
centre 9190 851 325
right 9190 851 225

Accessories
Description Installation side Order number

Step-up centre, bottom (on request) 9468 830 501
Cover left, outside (on request) 9468 851 422
Cover right, outside (on request) 9468 851 522
Cover left, centre (on request) 9463 885 092
Cover right, centre (on request) 9463 885 102

94
