Martin audio W0.5, W3, WS2A, WM0.5, W2 user manual

Martin Audio – WAVEFRONT PROFESSIONAL SERIES

CONTENTS (ENGLISH) Page No

1 INTRODUCTION 2
2 UNPACKING 2
3 OVERVIEW 2

3.1 W0.5 and WM0.5 2

3.2 W1 3

3.3 W2 3

3.4 W3 and W3P 3

3.5 WS2A 3

4 SAFETY FIRST 4

4.1 Tripod Mounting 4

4.2 Stacking 4

4.3 Rigging and Suspension 4
5 AMPLIFICATION 5
6 CONNECTIONS 6
7 CABLE LENGTHS 6
8 SYSTEM CONFIGURATIONS 7
9 WARRANTY 7
10 TECHNICAL SPECIFICATIONS 8

The Martin Experience

All material © 2007. Martin Audio Ltd. Subject to change without notice.

CONTENTS

<

>

PRINT

GUIDES

MARTIN AUDIO

LONDON

1 INTRODUCTION

Thank you for purchasing a Martin Audio Wavefront Professional Series
system. The Wavefront Professional Series is a range of powerful yet
compact loudspeakers designed to suit a variety of professional
applications. The trapezoid shape of the enclosures allows them to be
used singly or arrayed in multiples. Specific uses include live sound
reinforcement, theatre sound and audio-visual events.

2 UNPACKING

Each Martin Audio loudspeaker is built to the highest standard and
thoroughly inspected before it leaves the factory. After unpacking the
system, examine it carefully for any signs of transit damage and inform
your dealer if any such damage is found. It is suggested that you retain
the original packaging so that the system can be repacked at a future date
if necessary.

Please note that Martin Audio and its distributors cannot accept any
responsibility for damage to any returned product through the use of
non-approved packaging.

3 OVERVIEW

The Wavefront Professional Series consists of the W0.5 and WM0.5
miniature full-range systems, the W1, W2 and W3 compact full-range
systems and the WS2A sub-bass. For optimum performance it is
recommended that Wavefront Professional Series loudspeakers are used
with the WX3A System Controller or an appropriate digital controller such
as the Martin Audio DX1. Please refer to the controller user guide for
information on connections and limiter settings.

3.1 W0.5 and WM0.5

The W0.5 is a miniature high performance loudspeaker suited to a variety
of applications from sports bars to live sound infill. It is a passive two-way
system featuring an 8" (200mm) bass driver and a 1" (25mm) ferrofluid
cooled HF driver on a 70 x 50 degree horn.
The WM0.5 is a wedge monitor version of the W0.5, utilising the same
drive units and horn. In its wedge configuration, the horn of the WM0.5
exhibits a 50 x 70 degree dispersion pattern to increase the listening
window in the vertical plane. The base of the WM0.5 is provided with
threaded steel inserts for use with a tripod or for mounting upside down
close to a ceiling.

Martin Audio – WAVEFRONT PROFESSIONAL SERIES

ENGLISH

2

This equipment conforms to the requirements of the
EMC Directive 89/336/EEC, amended by 92/31/EEC
and 93/68/EEC and the requirements of the Low
Voltage Directive 73/23/EEC, amended by 93/68/EEC.

Standards Applied EMC Emission EN55103-1:1996

Immunity EN55103-2:1996

Electrical Safety EN60065:1993

All material © 2007. Martin Audio Ltd. Subject to change without notice.

CONTENTS

<

>

PRINT

GUIDES

3.2 W1

The W1 is an ultra-compact passive two-way system with a high output
capability for its small size. Featuring a 10" (250mm) bass driver and 1"
(25mm) compression driver on a 70 x 40 degree horn, it is particularly
useful in distributed sound and audio-visual appplications.

3.3 W2

The W2 is a powerful stand-alone system combining dynamic full-frequency
performance with exceptional articulation. Designed to meet the industry
standard requirement for a 12" (305mm) bass driver plus 70 x 40 horn
combination, the W2 can be configured as either an active or passive
system by means of a switch on the rear of the enclosure.

3.4 W3 and W3P

The W3 is an innovative full-range system achieving true three-way
performance from an enclosure only 28" (711mm) high. The low frequency
driver is a powerful 15" (380mm) device cooled by a heat exchange system
to reduce power compression. Midrange is produced by a unique 6.5"
(165mm) mid horn developed to overcome the power and distortion
limitations of traditionally used large format compression drivers whilst high
frequencies are produced by a 1" (25mm) compression driver. Mid and HF
dispersion patterns are 65 x 40 degrees. The W3 is a three-way system
designed for bi-amplification at its 650Hz low/mid crossover point. Afully
passive version, the W3P is available for situations which require simplicity
and reduced amplifier count.

3.5 WS2A

Where a Wavefront Professional Series enclosure requires additional low
frequency enhancement, the WS2A will extend the power bandwidth of the
system to below 35Hz. It utilises twin high power 15" (380mm) drivers with
4" (100mm) voice coils in an optimally tuned compact reflex enclosure.

NO

TE:

Passive systems such as the W0.5, WM0.5, W1, W2 (in passive mode) and
W3P may be used without a WX3A controller provided recommended
amplifier power is not exceeded and care is taken to avoid amplifier
clipping. Use of an optional WX3A controller with its system specific low
frequency EQ and built in limiters will result in improved bass response and
system protection.

Martin Audio – WAVEFRONT PROFESSIONAL SERIES

ENGLISH

3

All material © 2007. Martin Audio Ltd. Subject to change without notice.

CONTENTS

<

>

PRINT

GUIDES

4 SAFETY FIRST

It is important that loudspeaker systems are used in a safe manner. Please
take some time to review the following points concerning safe use of
Wavefront Professional Series loudspeakers.

Professional loudspeakers are capable of producing extremely high sound
levels and should be used with care. Hearing loss is cumulative and can
result from levels above 90dB if people are exposed for a long period.
Never stand close to loudspeakers driven at high level.

4.1 Tripod Mounting

The W0.5, W1, W2 and W3 incorporate a pole mounting socket to facilitate
mounting on tripod stands. When using stands, the following precautions
are advised:

Ensure that the stand will support the weight of the speaker by checking
the stand manufacturers rating.

Make sure that the stand is placed on a level surface and that its legs are
fully extended.

Do not place more than one speaker on each stand.
Run cables so that they do not present a trip hazard which could pull the

speaker over.
When used outdoors in the wind, it may be necessary to add some weight

to the base of the stand.
When using a pole mount with a sub-bass system such as the WS2A,

observe similar precautions.

4.2 Stacking

Ensure that the floor or stage is level and solid.
Do not stack speakers too high outdoors where winds could topple the

stack.
Be aware that speakers producing very high power levels can move or

creep. To avoid this, place friction material between the floor and speaker
and between each speaker.

4.3 Rigging and Suspension

W

ARNING: Suspending the system should only be done by qualified
personnel following safe rigging practices. Secure fixings to the
building structure are vital. Seek help from architects, structural
engineers or other specialists if in any doubt.

Martin Audio – WAVEFRONT PROFESSIONAL SERIES

ENGLISH

4

All material © 2007. Martin Audio Ltd. Subject to change without notice.

CONTENTS

<

>

PRINT

GUIDES

The W0.5, WM0.5, W1, W2 and W3 are provided with threaded inserts to
allow the suspension of a single enclosure. Never suspend one

enclosure from another to form an array or cluster using these
fittings. The W2 and W3 are provided with optional MAN flying points for

array construction.
The common practice of using commercially available eye bolts for

suspension should only be undertaken with great caution. Eye bolts are
strongest along the thread axis. Angling the enclosures will result in an
angle pull and it is important to use eye bolts that are safe in these
circumstances. Only forged shoulder eye bolts should be considered and it
is important that the thread length is at least 30mm. Aflat washer should be
inserted between the eyebolt and the enclosure. Formed eye bolts i.e.

those which are formed from a steel rod bent into an eye should be
avoided.

5 AMPLIFICATION

Wavefront Professional Series loudspeakers are designed to be used with
professional power amplifiers capable of producing the following power
outputs into 4 ohms:

W0.5 & WM0.5 300-400W
W1 300-400W
W2 400-600W
W3 400-600W
W3P 550-800W
WS2 550-800W

Care should be taken to avoid amplifier clipping. It is important to
understand that a low power amplifier driven into clipping is more likely to
damage a loudspeaker than a higher power amplifier used within its ratings.
This is because music signals have a high peak-to-average "crest" factor.
When an amplifier is severely overdriven, its output waveform is clipped (its
peaks are squared off) – reducing the crest factor. In extreme cases, the
waveform can approach that of a square wave. An amplifier is normally
capable of producing far more power under these conditions than its
undistorted rated power output.
The use of very high power amplifiers with outputs greater than those
recommended is discouraged.

Care should be taken to avoid switch-on surges, which can result in
momentary power peaks in excess of specified ratings. When powering up
a sound system it is important to switch on the amplifiers after the mixer
and control electronics have stabilised. When powering down the system,
reverse the sequence and switch off the amplifiers first.

Martin Audio – WAVEFRONT PROFESSIONAL SERIES

ENGLISH

5

All material © 2007. Martin Audio Ltd. Subject to change without notice.

CONTENTS

<

>

PRINT

GUIDES

6 CONNECTIONS

Each connector panel has two Neutrik Speakon connectors wired in parallel
with each other. The second connector allows use of a short link lead to
power another parallel loudspeaker. The connectors are wired as follows:

W0.5/WM0.5 W2 Active

NL4 Pin W1/W2 Passive/W3P/WS2 W3

1- Input -ve Low -ve
1+ Input +ve Low +ve
2- N/C (Mid)/High -ve
2+ N/C (Mid)/High +ve

7 CABLE LENGTHS

When connecting loudspeaker systems to an amplifier, it is recommended
that the return resistance of the cable used is less than one tenth of the
nominal impedance of the system or systems in parallel. The table below
gives an indication of the maximum permissible cable runs for various
conductor cross-sectional areas.

Conductor CSA

Maximum Cable Run

4 ohms 8 ohms 16 ohms

1.0mm

2

11m 22m 44m

1.5mm

2

17m 34m 68m

2.0mm

2

22m 44m 88m

2.5mm

2

29m 58m 116m

4.0mm

2

44m 88m 176m

6.0mm

2

66m 132m 264m

Martin Audio – WAVEFRONT PROFESSIONAL SERIES

ENGLISH

6

All material © 2007. Martin Audio Ltd. Subject to change without notice.

CONTENTS

<

>

PRINT

GUIDES

8 SYSTEM CONFIGURATIONS

The W0.5, WM0.5, W1, W2 and W3 may be used to cover the full-frequency
range – either distributed singly or arrayed in multiples. The WX3A and DX1
controllers provide appropriate system-specific low frequency equalisation for
full-frequency operation. Where additional low frequency output is required,
a WS2A sub-bass system driven from a separate amplifier fed from the sub­bass output of the controller can be added.

Wavefront Professional Series loudspeakers combined with the appropriately
configured controller exhibit an essentially flat on-axis frequency response.
Equalisation to compensate for a particular acoustic environment may be
performed where required. Where loudspeakers are arrayed, they may
benefit from a degree of equalisation to reduce the effect of the low/mid build
up and tilting of the response inherent in the use of multiple arrayed
enclosures.

9 WARRANTY

Martin Audio Wavefront Professional Series products are warranted against
manufacturing defects in materials or craftsmanship over a period of 5 years
from the date of original purchase. During the warranty period Martin Audio
will, at it's discretion, either repair or replace products which prove to be
defective provided that the product is returned in its original packaging,
shipping prepaid, to an authorised Martin Audio service agent or distributor.

Martin Audio Ltd. cannot be held responsible for defects caused by
unauthorised modifications, improper use, negligence, exposure to inclement
weather conditions, act of God or accident, or any use of this product that is
not in accordance with the instructions provided by Martin Audio.
Martin Audio is not liable for consequential damages.

This warranty is exclusive and no other warranty is expressed or implied.
This warranty does not affect your statutory rights.

Martin Audio – WAVEFRONT PROFESSIONAL SERIES

ENGLISH

7

All material © 2007. Martin Audio Ltd. Subject to change without notice.

CONTENTS

<

>

PRINT

GUIDES

10 TECHNICAL SPECIFICATIONS

W0.5/WM0.5

TYPE (W0.5) Ultra-compact 2-way passive trapezoid
TYPE (WM0.5) Miniature 2-way passive stage monitor

FREQUENCY RESPONSE 70Hz-18kHz ± 3dB
LOW FREQUENCY LIMIT -10dB @ 50Hz
DRIVERS 8” (200mm) LF

1” (25mm) exit HF compression driver
RATED POWER 125W AES, 500W peak
RECOMMENDED AMPLIFIER 300-400W into 4 ohms
SENSITIVITY 94dB
MAXIMUM SPL 114dB continuous, 120dB peak
IMPEDANCE 8 ohms nominal
DISPERSION (W0.5) 70 degs horizontal x 50 degs vertical (-6dB)
DISPERSION (WM0.5) 50 degs horizontal x 70 degs vertical (-6dB)
CROSSOVER 3kHz, passive
CONNECTORS 2 x Neutrik Speakon NL4
FITTINGS (W0.5) 10 x M8 threaded inserts

1 x pole mounting socket
FITTINGS (WM0.5) 4 x M8 threaded inserts
DIMENSIONS (W0.5) (W) 278mm x (H) 391mm x (D) 264mm

(W) 10.9ins x (H) 15.4ins x (D) 10.4ins
WEIGHT (W0.5) 10kg (22lbs)
DIMENSIONS (WM0.5) (W) 390mm x (H) 270mm x (D) 334mm

(W) 15.3ins x (H) 10.6ins x (D) 13.2ins
WEIGHT (WM0.5) 9kg (19.8lbs)
SHIPPING DIMENSIONS(W0.5) (W) 490mm x (H) 560mm x (D) 300mm

(W)19.3ins x (H) 22.0ins x (D) 11.8ins
SHIPPING WEIGHT(W0.5) 22kg (48.5lbs)
SHIPPING DIMENSIONS (WM0.5) (W) 500mm x (H) 360mm x (D) 404mm

(W) 19.7ins x (H) 14.2ins x (D) 15.6ins
SHIPPING WEIGHT(WM0.5) 11kg (24.2lbs)

Martin Audio – WAVEFRONT PROFESSIONAL SERIES

ENGLISH

8

All material © 2007. Martin Audio Ltd. Subject to change without notice.

CONTENTS

<

>

PRINT

GUIDES

W1

TYPE Ultra-compact 2-way passive trapezoid
FREQUENCY RESPONSE 75Hz-18kHz ± 3dB
LOW FREQUENCY LIMIT -10dB @ 55Hz
DRIVERS 10” (250mm) LF

1” (25mm) exit HF compression driver
RATED POWER 150W AES, 600W peak
RECOMMENDED AMPLIFIER 300-400W into 4 ohms
SENSITIVITY 97dB
MAXIMUM SPL 118dB continuous, 124dB peak
IMPEDANCE 8 ohms nominal
DISPERSION 70 degs horizontal, 40 degs vertical (-6dB)
CROSSOVER 2.2kHz, passive
CONNECTORS 2 x Neutrik Speakon NL4
FITTINGS 12 x M8 threaded inserts

1 x pole mounting socket
DIMENSIONS (W) 335mm x (H) 487mm x (D) 325mm

(W) 13.2ins x (H) 19.2ins x (D) 12.8ins
WEIGHT 14.5kg (32lbs)
SHIPPING DIMENSIONS (W) 420mm x (H) 600mm x (D) 420mm

(W) 16.5ins x (H) 23.6ins x (D) 16.5ins
SHIPPING WEIGHT 16kg (35.3lbs)

Martin Audio – WAVEFRONT PROFESSIONAL SERIES

ENGLISH

9

All material © 2007. Martin Audio Ltd. Subject to change without notice.

CONTENTS

<

>

PRINT

GUIDES

W2

TYPE Compact 2-way trapezoid, switchable

active/passive
FREQUENCY RESPONSE 60Hz-18kHz ± 3dB
LOW FREQUENCY LIMIT -10dB @ 50Hz
DRIVERS 12” (305mm) / 3” (75mm) voice coil

1” (25mm) exit HF compression driver
RATED POWER LF/FR: 300W AES, 1200W peak

HF: 60W AES, 240W peak
RECOMMENDED AMPLIFIER 400-600W into 4 ohms
SENSITIVITY LF/FR: 98dB, HF: 106dB
MAXIMUM SPL 122dB continuous, 128dB peak
IMPEDANCE F/R, LF & HF: 8 ohms nominal
DISPERSION 70 degs horizontal, 40 degs vertical (-6dB)
CROSSOVER 1.5kHz active or internal passive
CONNECTORS 2 x Neutrik Speakon NL4
FITTINGS 8 x M8

1 x pole mounting socket

2 x MAN blanking plates

2 x rear kelp fittings
DIMENSIONS (W) 365mm x (H) 554mm x (D) 364mm

(W) 14.4ins x (H) 21.8ins x (D) 14.3ins
WEIGHT 24kg (53lbs)
SHIPPING DIMENSIONS (W) 460mm x (H) 660mm x (D) 460mm

(W) 18.1ins x (H) 26ins x (D) 18.1ins
SHIPPING WEIGHT 24kg (52.9lbs)

Martin Audio – WAVEFRONT PROFESSIONAL SERIES

ENGLISH

10

All material © 2007. Martin Audio Ltd. Subject to change without notice.

CONTENTS

<

>

PRINT

GUIDES

W3

TYPE Compact bi-amplified 3-way trapezoid
FREQUENCY RESPONSE 55Hz-18kHz ± 3dB
LOW FREQUENCY LIMIT -10dB @ 45Hz
DRIVERS 15” (380mm) / 3” (75mm) voice coil

6.5” (165mm) horn loaded mid-range
1” (25mm) exit HF compression driver

RATED POWER LF: 400W AES, 1600W peak

MF/HF: 150W AES, 600W peak
RECOMMENDED AMPLIFIER 400-600W into 4 ohms
SENSITIVITY LF: 100dB

MF/LF: 104dB
MAXIMUM SPL 125dB continuous, 131dB peak
IMPEDANCE LF: 8 ohms nominal

MF/HF: 16 ohms nominal
DISPERSION 65 degs horizontal, 40 degs vertical (-6dB)
CROSSOVER 650Hz active, 3.3kHz internal passive
CONNECTORS 2 x Neutrik Speakon NL4
FITTINGS 8 x M8, 4 x M6 threaded inserts

1 x pole mounting socket

2 x MAN blanking plates

2 x rear kelp fittings
DIMENSIONS (W) 435mm x (H) 708mm x (D) 425mm

(W) 17.1ins x (H) 27.9ins x (D) 16.7ins
WEIGHT 31.5kg (69lbs)
SHIPPING DIMENSIONS (W) 550mm x (H) 790mm x (D) 550mm

(W) 21.7ins x (H) 31.1ins x (D) 21.7ins
SHIPPING WEIGHT 36kg (79.4lbs)

Martin Audio – WAVEFRONT PROFESSIONAL SERIES

ENGLISH

11

All material © 2007. Martin Audio Ltd. Subject to change without notice.

CONTENTS

<

>

PRINT

GUIDES

WS2A

TYPE Compact sub-bass
FREQUENCY RESPONSE 38Hz-100Hz ± 3dB with controller
LOW FREQUENCY LIMIT -10dB @ 30Hz
DRIVERS 2 x 15” (380mm) / 4” (100mm)

voice coil
RATED POWER 800W AES, 3200W peak
RECOMMENDED AMPLIFIER 550-800W into 4 ohms
SENSITIVITY 99dB
MAXIMUM SPL 126dB continuous, 132dB peak
IMPEDANCE 4 ohms nominal
CROSSOVER 100Hz active
CONNECTORS 2 x Neutrik Speakon NL4
DIMENSIONS (W) 572mm x (H) 827mm x (D) 585mm

(W) 22.5ins x (H) 32.5ins x (D) 23.0ins
WEIGHT 60kg (132lbs)
SHIPPING DIMENSIONS (W) 600mm x (H) 850mm x (D) 740mm

(W) 23.6ins x (H) 33.5ins x (D) 29.1ins
SHIPPING WEIGHT 64kg (141.1lbs)

Due to our policy of continuous improvement all specifications are subject
to change without notice.

Martin Audio – WAVEFRONT PROFESSIONAL SERIES

ENGLISH

12

All material © 2007. Martin Audio Ltd. Subject to change without notice.

CONTENTS

<

>

PRINT

GUIDES

Wavefront Professional Series

W0.5/WM0.5/W1/W2/W3/WS2A

Century Point, Halifax Road, Cressex Business Park, High Wycombe, Buckinghamshire HP12 3SL, England.

Telephone: [phone] Facsimile: [phone]

Web: www.martin-audio.com E-mail: [e-mail]

The Martin Experience

Please Click here to
return to main menu

Please Click here to
visit our website

All material © 2007. Martin Audio Ltd. Subject to change without notice.

CONTENTS

<

>

PRINT

GUIDES

MARTIN AUDIO

LONDON

The Martin Experience

ENGLISH

Wavefront Professional Series

W0.5/WM0.5/W1/W2/W3/WS2A

User’s Guide

All material © 2007. Martin Audio Ltd. Subject to change without notice.

CONTENTS

<

PRINT

GUIDES

>

MARTIN AUDIO

LONDON
