Sivoia QED®

Installation
Instructions

Jamb Mount
Roller Blind

NNoottee:: IIff iinnssttaalllliinngg aa ccoouupplleedd ssyysstteemm,

,

uussee IInn--LLiinnee CCoouupplleedd RRoolllleer

r

BBlliinndd AAddddeenndduumm aass tthhe

e

pprriimmaarryy iinnssttaallllaattiioonn gguuiiddee.

.

SIVOIA QED® Jamb Mount Installation Instr

uctions

1

Tools Required:

T

ape Measure 1/4 in. Hex-Head Driver
Wire Cutter/Stripper Level
Pliers Power Drill
#2 Phillips Screwdriver

Box Contents:

Sivoia QED®Roller Blind (2) Jamb Sub-Brackets

Left and Right Side Blind Brackets (attached)

(8) Mounting Scr

ews

(#8x44 mm (#8x1-3/4 in.) Hex Head Screws)

(1) 7 Pin Ter

minal Block

(2) Extra Retaining Scr

ews

(#6x6 mm (#6x1/4 in.) Phillips Head Screws)

(Actual Size)

(Actual Size)

(2) (102 mm (4 in.) Cable

T

ies

(2) (178 mm (7 in.) Cable

T

ies

Notes:

1) For In-Line Coupled Blind Systems, begin with Sivoia QED In-Line Coupled Roller Blind
Addendum, P/N 045-105-12. The Addendum will indicate when to use this document.

2) Complete wiring and programming information can be found in the Sivoia QED Wire and
Programming Guide, P/N 045-038-12 or at www.lutron.com.

3) The Electronic Drive Unit (EDU) will need to be powered to complete installation.

Sivoia QED®|jamb mount

Installation Instructions

SIVOIA QED® Jamb Mount Installation Instr

uctions

2

1

Match Blind to Window

1.1

1

Match Blind to Window

System Width

System Height

System Width

System Height

Confirm system dimensions on
package label and window
dimensions to verify appropriate
window/blind combination.

1.1

P

ackage Label

SIVOIA QED® Jamb Mount Installation Instr

uctions

3

2

Pre-drill for Cable

Determine where to drill for cable
access. See options below.

Cable should exit from wall, ceiling
or jamb on EDU side of system.

Note: Leave 305-457 mm (12-18 in.)
of cable exposed.

2.1

Ceiling

Drill for cable 64-76 mm (2 1/2 in. - 3 in.)
from back of the system and
32-57 mm (1 1/4 in. - 2 1/4 in.) from
end of the system.

Jamb

Drill for cable 51 mm (2 in.) fr

om top

of the system and 51 mm (2 in.) from
end of the system.

Wall

Drill for cable 64-76 mm (2 1/2 in. - 3 in.)
from top of the system and
32-57 mm (1 1/4 in. - 2 1/4 in.)
from end of the system.

Ceiling

Wall

Jamb

3

Mount Sub-Brackets

U

se fabric alignment holes
to position the sub-bracket
right to left. The fabric
alignment holes will line up
with the outside edge of the
fabric panel.

Note: Fabric edge may not
line up with edge of tube.

Note: Distance between
fabric edge and end of
system is 19 mm (3/4 in.)
per side.

3.1

Once their position has
been established, mount
sub-brackets using
appr

opriate fasteners.

Note: If sub-bracket position
is not flush to jamb as shown
to the left, sub-bracket can be
mounted to ceiling or rear wall
using appropriate fasteners.

3.2

SIVOIA QED® Jamb Mount Installation Instr

uctions

4

FFaabbrriic

c

AAlliiggnnmmeennt

t

HHoollees

s

WARNING:

The sub-brackets for each
blind tube should be mounted
to support a weight of at least
136 kg (300 pounds). The fasteners
provided with the sub-brackets
may not be appropriate for use in
all applications.

SIVOIA QED® Jamb Mount Installation Instr

uctions

5

4

Wire 7-Pin Terminal Block

Wire 7-Pin terminal
block (provided)
to cable.

Note: SVQ-CBL-250
shown

Pre-wire via ceiling shown.

4.2

Strip jacket off entire
length of exposed cable.
(305-457 mm or 12-18 in.)

4.1

T

o EDU

Connector

EGND

(Y

ellow/Gr

een)
24 V~ (Red)
24 V~ (Red/White)
MUX (Purple)
MUX (Gray)
12 V (Blue)
Common (Y

ellow)

SIVOIA QED® Jamb Mount Installation Instr

uctions

6

5

Mount Blind to Sub-Brackets

Swing blind down until
bottoms of blind brackets
r

est against sub-brackets.

5.3

Route cable wires from wall,
ceiling or jamb between the
blind bracket and the
sub-bracket being careful
not to pinch wir

e.

5.4

Hook the lip of each blind
bracket onto the top of each
sub-bracket.

5.2

Remove retaining screws from
blind brackets.

5.1

W

ARNING:

Blinds wider than 1.2 m (4 ft)
require two people to install.

Note: If installing a coupled
blind system, install the blind
with the EDU first.

Note: Leave protective
wrapping on blind
during installation.

SIVOIA QED® Jamb Mount Installation Instr

uctions

7

6

Center and Secure Blind

Inser

t and tighten
retaining screws on
BOTH blind brackets
to secure the blind
into position. Screws
should be tightened
down all the way.

WARNING:

After installing retaining
scr

ews, gently push up
and pull down on the
roller blind to ensure a
secur

e installation.

6.2

Move the blind left
or right until centered.

6.1

WARNING:

Blind is not secured to
the wall during the
adjustment procedure.
Extreme movement
fr

om side-to-side may
cause blind to fall.
Attention should be
paid to the blind
brackets’ engagement
into the sub-bracket as
side-to-side movement
is not restricted at this
point. Blinds wider than

1.22 m (4 ft) r

equire
two people to center
the blind.

SIVOIA QED® Jamb Mount Installation Instr

uctions

8

7

Adjust Blind Level

Turn leveling screw
to raise or lower idler
side of blind until level.

7.1

Confirm roller tube turns
fr

eely without rubbing

on anything.

7.3

Adjust blind projection from
window so that it clears any
window trim or hardware
when operating.

7.2

SIVOIA QED® Jamb Mount Installation Instr

uctions

9

8

Connect Terminal Blocks

Plug 7-pin terminal
block on cable into
EDU terminal block
attached to
blind bracket.

8.1

Note: EDU terminal block
clips onto blind bracket to
hold connected terminal
block in place.

Ensure ter

minal blocks

are oriented as shown.

8.2

Secur

e ter

minal block

with 178 mm (7 in.) cable tie.

8.3

Use 102 mm (4 in.)
Cable Ties to dress
wires to prevent
them from rubbing
against blind fabric.

8.4

178 mm (7 in.) cable tie

Note: If installing a
coupled blind system,
go to Section 3 of the
In-Line Coupled Roller
Blind Addendum.

SIVOIA QED® Jamb Mount Installation Instr

uctions

10

9

IR Receiver Connection (if applicable)

Ensure IR connector
does not rub on blind.

Plug in EDU IR
connector to remote
eye connector (SV-IR).

9.1

Position IR eye where
it is not covered from
view of remote control.

9.2

9.3

EDU IR connector

SV-IR connector

SIVOIA QED® Jamb Mount Installation Instr

uctions

11

10

Programming Setting Limits from the EDU

Press and release the
“Open Limit Button” ( ),
the LED on the roller Blind
EDU will turn on steady,
indicating that the EDU is in
“Set Open Limit Mode”.

10.1

Press and Release the
Open Limit Button.

Steady LED

Adjust the position of the
EDU to the desir

ed Open
Limit using the adjustment
buttons ( ).

10.2

Use the Adjustment
buttons to move the
EDU position.

T

he Open and Close Limits determine how far an EDU will travel. When the open button is pressed on a

K

eypad, IR transmitter, or CCI, the EDU will move to the Open Limit. When the close button is pressed on
a keypad, IR transmitter, or CCI, the EDU will move to the Close Limit. The EDU will not move higher than
t

he Open Limit or lower than the Close Limit.

Note: Setting the Open Limit lower than the Close Limit will cause the blind to move down
when raise is pressed and up when lower is pressed.

Setting the Open Limit from the EDU

SIVOIA QED® Jamb Mount Installation Instr

uctions

12

10

Programming Setting Limits from the EDU
(continued)

Press and hold the “Open
Limit Button” ( ) for 5
seconds. The LED on the
roller blind EDU will flash for
2 seconds, then go dark,
indicating that the current
position has been stored as
the Open Limit.

10.3

Press and hold the
Open Limit Button
for 5 seconds.

Pr

ess and r

elease the
“Close Limit Button” ( ),
the LED on the roller
Blind EDU will turn on
steady, indicating that the
EDU is in “Set Close
Limit Mode”.

10.4

Setting the Open Limit from the EDU

Setting the Close Limit from the EDU

Pr

ess and Release the

Close Limit Button.

Steady LED

Flashing LED

SIVOIA QED® Jamb Mount Installation Instr

uctions

13

10

Programming Setting Limits from the EDU
(continued)

Adjust the position of the
EDU to the desired Close
Limit using the adjustment
buttons ( ).

10.5

Use the Adjustment
buttons to move
the EDU position.

Pr

ess and hold the “Close
Limit Button” ( ) for 5
seconds. The LED on the
roller blind EDU will flash for
2 seconds, then go dark,
indicating that the cur

rent

position has been stor

ed as

the Close Limit.

10.6

Setting the Close Limit from the EDU

Pr

ess and hold the
Close Limit Button
for 5 seconds.

Flashing LED

SIVOIA QED® Jamb Mount Installation Instr

uctions

14

11

Finish System Programming

The Sivoia QED blind is now installed, wired, and the OPEN/CLOSE limits for each blind have
been set.

The next step is to finish programming the system.

Use the instructions in the

Wiring and Programming Guide (p/n 045-038-12) or the

Technical Reference Guide (p/n 367-592-12) and perform these four easy steps:

1.

Address the system. This gives each EDU, keypad and contact closure interface
in the system a unique address number or “name”, allowing proper communication
between components.

2.

Assign blinds (EDUs) to keypads, IR hand controls and/or contact closure
interfaces. Tell system which blinds (EDUs) respond to which keypads and IR hand
controls and contact closure Interfaces.

3.

Set and save PRESET blind positions if you desire them to be different from the
factory defaults.

S

ymptom

E

DU will not move...

S

olution

.

..EDU is not powered - check EDU Power.
...Blind is caught on something - free blind.
...Blind is not assigned to keypad, IR, or CCI.
...Limits set at same place.

Blind does not fully open or fully close... ...Limits have been set incorrectly - refer to “set

open limit” and “set close limit” sections.

...Blind fabric is caught on something - free blind.

Fabric not level... ...Adjust using level adjustment screw.

...Check that brackets are mounted level.
...Check that fabric is tracking correctly on

the blind tube.

Fabric not centered over window... ...Center blind using center adjustment.

...Check that brackets are centered.

Blind does not move smoothly... ...Check for binding of blind fabric on

side channels.

...

Check fabric tracking.

IR controls will not operate blind.... ...IR transmitter does not have line-of-sight to

IR receiver.

...Out of range - move to within 12 m (40 ft) of

IR receiver.

...EDUs not assigned to IR

receiver.

...

IR r

eceiver not plugged into any EDU within range.
...Batteries are not providing power, replace them.
...IR receiver not properly oriented.

15

12

Troubleshooting

SIVOIA QED® Jamb Mount Installation Instr

uctions

TTeecchhnniiccaall AAssssiissttaanncce

e

W

ORLD

HEADQUARTERS

Lutron Electronics Co., Inc.
7

200 Suter Road

C

oopersburg, PA 18036

U

nited States
Tel: [phone]
Fax:[phone]

ASIAN
HEADQUARTERS

Lutron GL Ltd.
15 Hoe Chiang Road
#07-03 Tower Fifteen
S

ingapore 089316
Tel: [phone]
Fax: [phone]
[e-mail]

EUROPEAN
HEADQUARTERS

Lutron EA Ltd.
6 Sovereign Close
London, E1W 3JF
United Kingdom
Tel: [phone]
Fax: [phone]

CUSTOMER
SERVICE/ORDERING

UK [phone] –

09.00 - 18.00 GMT
USA [phone] –

08.00 - 20.00 EST

CUSTOMER SERVICE
/E-MAIL

[e-mail]

TECHNICAL SUPPORT
& SERVICES

USA [phone] –
24 hours/7 days
UK [phone]

09.00 - 18.00 GMT

INTERNET:

www.lutron.com

A

DDITIONAL LUTRON

SALES OFFICES:
G

ermany

T

el: [phone]

F

ax: [phone]
FREEPHONE
00800-5887 6635

F

rance

Lutron Ltc, S.A.R.L.-Paris
90 rue Villiers
92300 Levallois Perret,
France
T

el: [phone]

F

ax: [phone]
F

REEPHONE: 0800.90.12.18
[e-mail]

Spain-Madrid

Tel: [phone]
Fax: [phone]
FREEPHONE 0900-948-944

Spain-Barcelona

Tel: [phone]
Fax: [phone]
FREEPHONE 0900-948-944

Hong Kong

Tel: [phone]
Fax: [phone]

Beijing

Tel: [phone]
Fax: [phone]

Singapore

LUTRON GL Ltd. ­Singapore
15 Hoe Chiang Road
#7-03 Tower 15
Singapore 089316
Tel: [phone]
Fax: [phone]

Japan

T

el: [phone]

Fax: [phone]

These products may be covered by one or more
of the following US patents:

5,671,387; 6,100,659

and corresponding foreign patents. US and
foreign patents pending.

Lutron, the Sunburst logo, Sivoia, and
Sivoia QED are registered trademarks.
©2007 Lutron Electronics Co., Inc.

Printed in the U.S.A.

P/N 045-104-12 Rev. A
