Lithonia Lighting KBMF1458 Specifications

OLF LED

Security Floodlight Series

Security Lighting the Way
You Need It!

The OLF family from Lithonia Lighting® has the largest breadth of offering
from one security floodlight family. The OLF family provides a multitude of
lighting, energy saving packages and control options to meet the varying
needs of your residential single and multi-family applications.

Breadth of Offering

OFL offers 10 configurations providing the widest selection from a security
floodlight. The family offering includes two finishes, two lumen packages, with
and without photocell. Motion occupancy light-on-detection also available.

Control Choices

OLF has it all. The built-in dusk-to-dawn photocell option provides energy­savings convenience. For further savings, order without controls and wire to
a central time clock or photocell. Want the lights to come on when motion is

detected? Simply go with MO, motion occupancy option.

Long Life with Less Energy Used

Replace your incandescent energy-hogs with the long life, energy-saving OLF
LED. OLF LED 2 and 3-head models can replace up to (2) 150W incandescent
PAR lamps and offer 50,000 hours service life. These provide 16-25 times more
life for one seventh of the energy of traditional sources!

Quick Facts:

 Small, compact form in a

traditional shape

 Two lumen packages ranging

from 2 ,10 0 -3,10 0 l u m e n s

 OLF 2RH replaces up to (2) 90W

PAR lamps

 OLF 3RH replaces up to (2) 150W

PAR lamps

 Suitable for wall or ceiling mount

 Adjustable heads can be aimed

without the use of tools

 Visors are removable

Learn more about our security floodlights at www.lithonia.com

Outdoor

OLF LED

Ordering Information

Product Catalog Nomenclature Lumens Watts UPC Cod e CI Code

OLF 2RH 40K 120 BZ M4 2,159 25 00889804043778 * 232VW8

OLF 2RH 40K 120 WH M4 2,159 25 00889804043785 *232VW9

OLF 2RH 40K 120 PE BZ M4 2,159 25 00820476314650 *220R63

OLF 2RH 40K 120 PE WH M4 2,159 25 00889804043723 *232VW3

OLF 2RH 40K 120 MO BZ M6 2,159 25 00820476314605 *220R5X

OLF 2RH 40K 120 MO WH M6 2,159 25 00820476314636 *220R61

OLF 3RH 40K 120 BZ M4 3,100 36 00889804043884 *232VWM

OLF 3RH 40K 120 WH M4 3,100 36 00889804043914 *232VWR

OLF 3RH 40K 120 PE BZ M4 3,100 36 00889804043792 *232VWA

OLF 3RH 40K 120 PE WH M4 3,100 36 00889804043877 *232VWL

LED Security Floodlight Solutions

OVFL 1RH/2RH

Value Solution

950-1,770 lumens 2,100-3,100 lumens 1,900-2,500 lumens

OLF 2RH/3RH

More Performance and Options

OLMF/OLFL

Other Shapes

Learn more about our security floodlights at www.acuitybrands.com.

One Lithonia Way | Conyers, Georgia 30012 | Phone: [phone]

©2018 Acuity Brands Lighting, Inc. All rights reserved. | LL_6101_0118
