Lexus Es350 2019 Owner's Manual

Pictorial index
For safety and security
Vehicle status information and indicators
Before driving
Driving
Interior features
Maintenance and care
When trouble arises
Vehicle specifications
Make sure to read through them (Main topics: Child seat, theft deterrent system)
Reading driving-related information (Main topics: Meters, multi-information display)
Opening and closing the doors and windows, adjustment before driving (Main topics: Keys, doors, seats, power windows)
Operations and advice which are necessary for driving (Main topics: Starting engine, refueling)
Usage of the interior features (Main topics: Air conditioner, storage features)
Caring for your vehicle and maintenance procedures (Main topics: Interior and exterior, light bulbs)
What to do in case of malfunction and emergency (Main topics: Battery discharge, flat tire)
Vehicle specifications, customizable features (Main topics: Fuel, oil, tire inflation pressure)
1
2
3
4
5
6
7
8
For owners
Index
Reporting safety defects for U.S. owners, and seat belt, SRS airbag and headlight aim instructions for Canadian owners
Search by symptom
Search alphabetically
9
2
TABLE OF CONTENTS
For your information ......................................6
Reading this manual.................................... 10
How to search .................................................11
Pictorial index .................................................12
1
For safety and security
1-1. For safe use
Before driving....................................22
For safe driving..................................23
Seat belts .............................................24
SRS airbags ....................................... 28
Front passenger occupant classifi-
cation system ................................. 37
Exhaust gas precautions ................41
1-2. Child safety
Riding with children.........................42
Child restraint systems ..................42
1-3. Theft deterrent system
Engine immobilizer system......... 54
Alarm.................................................... 56
Vehicle status information and
2
indicators
2-1. Instrument cluster
Warning lights and indicators.... 60
Gauges and meters (except F
SPORT models) ........................... 64
Gauges and meters (F SPORT
models)............................................. 67
Multi-information display...............71
Head-up display .............................. 78
Fuel consumption screen............. 82
3
Before driving
3-1. Key information
Keys...................................................... 86
3-2. Opening, closing and locking the
doors and trunk
Doors ................................................... 89
Trunk .....................................................93
Smart access system with push-but-
ton start ..........................................100
3-3. Adjusting the seats
Front seats........................................ 107
Driving position memory........... 108
Head restraints .................................111
3-4. Adjusting the steering wheel and
mirrors
Steering wheel .................................113
Inside rear view mirror .................114
Outside rear view mirrors...........115
3-5. Opening and closing the windows
and moon roof
Power windows .............................. 118
Moon roof........................................ 120
Panoramic moon roof..................123
4
Driving
4-1. Before driving
Driving the vehicle........................ 128
Cargo and luggage...................... 133
Vehicle load limits......................... 135
Trailer towing.................................. 135
Dinghy towing................................ 136
4-2. Driving procedures
Engine (ignition) switch...............137
TABLE OF CONTENTS
3
Automatic transmission............... 141
Turn signal lever............................. 145
Parking brake ................................. 146
Brake Hold....................................... 148
4-3. Operating the lights and wipers
Headlight switch............................150
Automatic High Beam................ 153
Windshield wipers and washer155
4-4. Refueling
Opening the fuel tank cap.......... 161
4-5. Using the driving support systems
Lexus Safety System+2.0.......... 163
PCS (Pre-Collision System)..... 169
LTA (Lane Tracing Assist)......... 176
RSA (Road Sign Assist)..............185
Dynamic radar cruise control with
full-speed range..........................187
BSM (Blind Spot Monitor) ........197
Driving Mode Select switch ....202
PKSA (Parking Support Alert)204
Intuitive parking assist ................205
RCTA (Rear cross traffic alert)
function............................................ 211
RCD (Rear Camera Detection)
function........................................... 215
PKSB (Parking Support Brake)218 Parking Support Brake function
(static objects) ............................ 224
Parking Support Brake function
(rear-crossing vehicles).......... 229
Parking Support Brake function
(rear pedestrians) ..................... 233
Driving assist systems................. 236
4-6. Driving tips
Winter driving tips .......................240
5
Interior features
5-1. Remote Touch
Remote Touch................................244
5-2. Lexus Climate Concierge
Lexus Climate Concierge........ 249
5-3. Using the air conditioning system
Automatic air conditioning system
............................................................251
Heated steering wheel/seat heat-
ers/seat ventilators................... 258
5-4. Using the interior lights
Interior lights list ............................262
5-5. Using the storage features
List of storage features .............. 265
Trunk features ............................... 268
5-6. Using the other interior features
Other interior features ..............269
Garage door opener .................. 281
Compass ......................................... 286
Lexus Enform Safety Connect289
Lexus Enform Remote............... 293
Lexus Enform Service Connect
.......................................................... 294
6
Maintenance and care
6-1. Maintenance and care
Cleaning and protecting the vehi-
cle exterior................................... 296
Cleaning and protecting the vehi-
cle interior
..
.................................. 299
6-2. Maintenance
Maintenance requirements...... 301
General maintenance................ 302
1
2
3
4
5
6
7
8
9
4
TABLE OF CONTENTS
Emission inspection and mainte-
nance (I/M) programs ............305
6-3. Do-it-yourself maintenance
Do-it-yourself service precautions
...........................................................306
Hood..................................................308
Positioning a floor jack...............308
Engine compartment................... 310
Tires .................................................... 316
Tire inflation pressure................. 325
Wheels.............................................. 327
Air conditioning filter.................. 328
Electronic key battery................330
Checking and replacing fuses. 331
Headlight aim................................. 333
Light bulbs....................................... 335
7
When trouble arises
7-1. Essential information
Emergency flashers.....................340
If your vehicle has to be stopped in
an emergency.............................340
If the vehicle is trapped in rising
water................................................ 341
7-2. Steps to take in an emergency
If your vehicle needs to be towed
........................................................... 343
If you think something is wrong
........................................................... 346
Fuel pump shut off system ........347
If a warning light turns on or a warn-
ing buzzer sounds.....................348
If a warning message is displayed
...........................................................358
If you have a flat tire..................... 362
If the engine will not start ..........369
If you lose your keys......................371
If the fuel filler door cannot be
opened ............................................371
If the electronic key does not oper-
ate properly................................. 372
If the battery is discharged....... 374
If your vehicle overheats........... 377
If the vehicle becomes stuck ... 379
8
Vehicle specifications
8-1. Specifications
Maintenance data (fuel, oil level,
etc.) ................................................. 382
Fuel information............................ 389
Tire information ............................. 391
8-2. Customization
Customizable features ..............400
8-3. Items to initialize
Items to initialize............................ 410
9
For owners
9-1. For owners
Reporting safety defects for U.S.
owners.............................................414
Seat belt instructions for Canadian
owners (in French) .....................414
SRS airbag instructions for Cana-
dian owners (in French) .......... 416
Headlight aim instructions for
Canadian owners (in French)422
Index
What to do if... (Troubleshooting)
........................................................... 426
Alphabetical index ...................... 429
TABLE OF CONTENTS
5
1
2
3
4
5
6
7
8
9
6
For your information
Main Owner’s Manual
Please note that this manual applies to all models and explains all equipment, including options. Therefore, you may find some explanations for equipment not installed on your vehicle.
All specifications provided in this man­ual are current at the time of printing. However, because of the Lexus policy of continual product improvement, we reserve the right to make changes at any time without notice.
Depending on specifications, the vehi­cle shown in the illustrations may differ from your vehicle in terms of color and equipment.
Noise from under vehicle after turning off the engine
Approximately five hours after the engine is turned off, you may hear sound coming from under the vehicle for several minutes. This is the sound of a fuel evaporation leakage check and, it does not indicate a malfunction.
Accessories, spare parts and modification of your Lexus
A wide variety of non-genuine spare parts and accessories for Lexus vehi­cles are currently available in the mar­ket. You should know that Toyota does not warrant these products and is not responsible for their performance,
repair, or replacement, or for any dam­age they may cause to, or adverse effect they may have on, your Lexus vehicle.
This vehicle should not be modified with non-genuine Lexus products. Modification with non-genuine Lexus products could affect its performance, safety or durability, and may even vio­late governmental regulations. In addi­tion, damage or performance problems resulting from the modifica­tion may not be covered under war­ranty.
Installation of a mobile two-way radio system
The installation of a mobile two-way radio system in your vehicle could affect electronic systems such as:
Multiport fuel injection sys-
tem/sequential multiport fuel injec­tion system
Lexus Safety System+2.0Anti-lock brake systemSRS airbag systemSeat belt pretensioner system
Be sure to check with your Lexus dealer for precautionary measures or special instructions regarding installa­tion of a mobile two-way radio system.
Vehicle data recording
The vehicle is equipped with sophisti­cated computers that will record cer­tain data, such as:
7
The recorded data varies according to the vehicle grade level and options with which it is equipped.
These computers do not record con­versations or sounds, and only record images outside of the vehicle in certain situations.
Engine speed / Electric motor
speed (traction motor speed)
Accelerator statusBrake statusVehicle speedOperation status of the driving
assist systems, such as the ABS and pre-collision system
Images from the front camera (avail-
able only when certain safety sys­tems are activated, which varies depending on the vehicle specifica­tions).
Data Transmission
Your vehicle may transmit the data recorded in these computers to Lexus without notification to you.
Data usage
Lexus may use the data recorded in this computer to diagnose malfunctions, con­duct research and development, and improve quality.
Lexus will not disclose the recorded data to a third party except:
• With the consent of the vehicle owner or with the consent of the lessee if the vehi­cle is leased
• In response to an official request by the police, a court of law or a government agency
• For use by Lexus in a lawsuit
• For research purposes where the data is not tied to a specific vehicle or vehicle owner
Recorded image information can be
erased by your Lexus dealer
The image recording function can be dis­abled. However, if the function is disabled, data from when the pre-collision system operates will not be available.
To learn more about the vehicle data col­lected, used and shared by Lexus, please visit
www.lexus.com/privacyvts/.
Usage of data collected through Lexus Enform (U.S.mainland on­ly)
If your Lexus has Lexus Enform and if you have subscribed to those services, please refer to the Lexus Enform Telematics Subscription Service Agreement for information on data collected and its usage.
To learn more about the vehicle data collected, used and shared by Lexus, please visit www.lexus.com/privacyvts/
.
Event data recorder
This vehicle is equipped with an event data recorder (EDR). The main pur­pose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed. The EDR is designed to
8
record data related to vehicle dynam­ics and safety systems for a short period of time, typically 30 seconds or less.
The EDR in this vehicle is designed to record such data as:
How various systems in your vehicle
were operating;
Whether or not the driver and pas-
senger safety belts were buck­led/fastened;
How far (if at all) the driver was
depressing the accelerator and/or
brake pedal; and, How fast the vehicle was traveling. These data can help provide a better
understanding of the circumstances in which crashes and injuries occur.
NOTE: EDR data are recorded by your vehicle only if a non-trivial crash situa­tion occurs; no data are recorded by the EDR under normal driving condi­tions and no personal data (e.g., name, gender, age, and crash location) are recorded. However, other parties, such as law enforcement, could combine the EDR data with the type of personally identifying data routinely acquired during a crash investigation.
To read data recorded by an EDR, spe­cial equipment is required, and access to the vehicle or the EDR is needed. In addition to the vehicle manufacturer, other parties, such as law enforcement, that have the special equipment, can read the information if they have access to the vehicle or the EDR.
Disclosure of the EDR data
Lexus will not disclose the data recorded in an EDR to a third party except when:
• An agreement from the vehicle’s owner (or the lessee for a leased vehicle) is obtained
• In response to an official request by the police, a court of law or a government agency
• For use by Lexus in a lawsuit
However, if necessary, Lexus may:
• Use the data for research on vehicle safety performance
• Disclose the data to a third party for research purposes without disclosing information about the specific vehicle or vehicle owner
Scrapping of your Lexus
The SRS airbag and seat belt preten­sioner devices in your Lexus contain explosive chemicals. If the vehicle is scrapped with the airbags and seat belt pretensioners not deployed, this may cause an accident such as fire. Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Lexus dealer before you scrap your vehicle.
Perchlorate Material
Special handling may apply, See www.dtsc.ca.gov/hazardouswaste/ perchlorate.
Your vehicle has components that may contain perchlorate. These compo­nents may include airbag, seat belt pre-
tensioners, and wireless remote
WARNING
control batteries.
General precautions while driving
Driving under the influence: Never drive your vehicle when under the influence of alcohol or drugs that have impaired your ability to operate your vehicle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordina­tion, which could lead to an accident that could result in death or serious injury.
Defensive driving: Always drive defen­sively. Anticipate mistakes that other drivers or pedestrians might make and be ready to avoid accidents.
Driver distraction: Always give your full attention to driving. Anything that dis­tracts the driver, such as adjusting con­trols, talking on a cellular phone or reading can result in a collision with resulting death or serious injury to you, your occupants or others.
9
General precaution regarding chil-
dren’s safety
Never leave children unattended in the vehicle, and never allow children to have or use the key.
Children may be able to start the vehicle or shift the vehicle into neutral. There is also a danger that children may injure themselves by playing with the windows, the moon roof or panoramic moon roof, or other features of the vehicle. In addi­tion, heat build-up or extremely cold temperatures inside the vehicle can be fatal to children.
10
Reading this manual
Explains symbols used in this man­ual
Symbols in this manual
Symbols Meanings
WARNING: Explains something that,
if not obeyed, could cause death or serious injury to people.
NOTICE: Explains something that,
if not obeyed, could cause damage to or a malfunction in the vehi­cle or its equipment.
Indicates operating or working procedures. Fol­low the steps in numeri­cal order.
Symbols in illustrations
Symbols Meanings
Indicates the action (pushing, turning, etc.) used to operate switches and other devices.
Indicates the outcome of an operation (e.g. a lid opens).
Symbols Meanings
Indicates the component or position being explained.
Means Do not, Do not do
this, or Do not let this happen.
How to search
Searching by name
Alphabetical index: P.429
Searching by installation position
Pictorial index: P.12
11
Searching by symptom or sound
What to do if... (Troubleshooting):
P.426
Searching by title
Table of contents: P.2
12
A
B
C
D
Pictorial index
Pictorial index
Exterior
Doors ...........................................................................................................................P.89
Locking/unlocking..............................................................................................................P.89
Opening/closing the side windows.............................................................................P.118
Locking/unlocking by using the mechanical key................................................P.372
Warning buzzer ...................................................................................................................P.92
Trunk .............................................................................................................................P.93
Opening from inside the cabin ......................................................................................P.95
Opening from outside .......................................................................................................P.95
Opening by using the mechanical key .................................................................... P.372
Warning buzzer ...................................................................................................................P.92
Outside rear view mirrors ..................................................................................... P.115
Adjusting the mirror angle...............................................................................................P.115
Folding the mirrors..............................................................................................................P.116
Driving position memory*..............................................................................................P.108
Defogging the mirrors....................................................................................................P.252
Windshield wipers ..................................................................................................P.155
Pictorial index
EFG
H
I
J
K
L
Precautions against winter season............................................................................P.242
To prevent freezing (windshield wiper de-icer)
*
.................................................P.255
Precautions against car wash ......................................................................................P.297
Fuel filler door ........................................................................................................... P.161
Refueling method ................................................................................................................P.161
Fuel type/fuel tank capacity .........................................................................................P.383
Tires............................................................................................................................. P.316
Tire size/inflation pressure ...........................................................................................P.387
Winter tires/tire chain ....................................................................................................P.240
Checking/rotation/tire pressure warning system............................................... P.316
Coping with flat tires........................................................................................................P.362
Hood ......................................................................................................................... P.308
Opening .............................................................................................................................. P.308
Engine oil..............................................................................................................................P.384
Coping with overheating............................................................................................... P.377
Warning messages ..........................................................................................................P.358
13
Light bulbs of the exterior lights for driving
(Replacing method: P.335, Watts: P.388)
Headlights/side marker lights/cornering lights............................................P.150
Turn signal lights ...................................................................................................... P.145
Parking lights/daytime running lights...............................................................P.150
Tail/stop lights..........................................................................................................P.150
License plate lights .................................................................................................P.150
Back up lights
Shifting the shift lever to R...............................................................................................P.142
*
:If equipped
14
A
B
C
D
Pictorial index
Instrument panel
Engine switch ........................................................................................................... P.137
Starting the engine/changing the mode.........................................................P.137, 139
Emergency stop of the engine ....................................................................................P.340
When the engine will not start.....................................................................................P.369
Warning messages ..........................................................................................................P.358
Shift lever.................................................................................................................... P.141
Changing the shift position.............................................................................................P.142
Precautions against towing...........................................................................................P.343
When the shift lever does not move ...........................................................................P.142
Meters .................................................................................................................. P.64, 67
Reading the meters/adjusting the instrument panel lights.........P.64, 66, 67, 70
Warning lights/indicator lights ......................................................................................P.60
When the warning lights come on.............................................................................P.348
Multi-information display ........................................................................................ P.71
Display........................................................................................................................................P.71
When the warning messages are displayed..........................................................P.358
Pictorial index
E
F
G
H
I
J
K
L
M
Parking brake switch ............................................................................................. P.146
Applying/releasing ............................................................................................................P.146
Precautions against winter season..............................................................................P.241
Warning buzzer/message............................................................................................P.359
Turn signal lever ...................................................................................................... P.145
Headlight switch......................................................................................................P.150
Headlights/parking lights/tail lights/daytime running lights........................... P.150
Automatic High Beam..................................................................................................... P.153
Windshield wiper and washer switch ................................................................ P.155
Usage......................................................................................................................................P.155
Adding washer fluid.......................................................................................................... P.315
Warning messages ..........................................................................................................P.359
Emergency flasher switch .................................................................................. P.340
Hood lock release lever ...................................................................................... P.308
15
Tilt and telescopic steering control switch/tilt and telescopic steering lock
release lever .............................................................................................................. P.113
Adjustment .............................................................................................................................P.113
Driving position memory
*1
.............................................................................................P.108
Air conditioning system ........................................................................................P.251
Usage...................................................................................................................................... P.251
Rear window defogger...................................................................................................P.252
Audio system
*2
Trunk opener main switch ...................................................................................... P.99
*1
: If equipped
*2
: Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
16
A
B
C
D
E
F
G
H
Switches
Pictorial index
Camera switch
*1, 2
Head-up display switch*1........................................................................................ P.78
Instrument panel light control switches ..................................................... P.66, 70
Odometer/trip meter/trip meter reset button ....................................... P.65, 70
VSC OFF switch.....................................................................................................P.237
Driving Mode Select switch .............................................................................. P.202
Trunk opener switch.................................................................................................P.95
Fuel filler door opener switch.............................................................................. P.162
*1
: If equipped
*2
: Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
Pictorial index
A
B
C
D
E
A
B
C
Driving position memory switches*.................................................................. P.108
Outside rear view mirror switches ..................................................................... P.115
Door lock switches .................................................................................................... P.91
Window lock switch ................................................................................................ P.119
17
Power window switches ......................................................................................... P.118
*
:If equipped
Meter control switches ........................................................................................... P.72
Paddle shift switches .............................................................................................. P.143
TEL switch
*
18
D
E
F
G
H
A
B
C
D
E
F
Pictorial index
LTA (Lane Tracing Assist) switch ....................................................................... P.176
Vehicle-to-vehicle distance switch ...................................................................P.192
Cruise control switches ........................................................................................ P.187
Audio remote control switches
Talk switch
*
: Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
*
*
Seat ventilator switches
Seat heater switches
Heated steering wheel switch
Rear sunshade switch
*
.................................................................................... P.258
*
.......................................................................................... P.258
*
......................................................................... P.258
*
..........................................................................................P.278
Remote Touch.........................................................................................................P.244
Brake hold switch ....................................................................................................P.148
*
:If equipped
Interior
A
B
C
D
E
F
G
H
I
Pictorial index
19
SRS airbags................................................................................................................ P.28
Floor mats ....................................................................................................................P.22
Front seats ................................................................................................................. P.107
Head restraints .......................................................................................................... P.111
Seat belts .....................................................................................................................P.24
Inside lock buttons ..................................................................................................... P.91
Console box............................................................................................................. P.266
Cup holder ............................................................................................................... P.266
Assist grips ...............................................................................................................P.278
20
A
B
C
D
E
F
G
H
I
Ceiling
Pictorial index
Interior lights ...........................................................................................................P.263
Personal lights.........................................................................................................P.263
*
Moon roof switches Panoramic moon roof switches
“SOS” button
.............................................................................................. P.120
*
.........................................................................P.123
*
........................................................................................................ P.289
Door-linked interior light switch .......................................................................P.263
Vanity mirrors ......................................................................................................... P.269
Sun visors.................................................................................................................. P.269
Inside rear view mirror ........................................................................................... P.114
Garage door opener buttons ..............................................................................P.281
*
:If equipped
21
For safety and security
1-1. For safe use
Before driving.................................22
For safe driving.............................. 23
Seat belts ..........................................24
SRS airbags .................................... 28
Front passenger occupant classifi-
cation system .............................. 37
Exhaust gas precautions .............41
1-2. Child safety
Riding with children......................42
Child restraint systems ...............42
1-3. Theft deterrent system
Engine immobilizer system...... 54
Alarm................................................. 56
1
1
For safety and security
22
WARNING
1-1.For safe use
1-1. For safe use
Before driving
Observe the following before start­ing off in the vehicle to ensure safety of driving.
Installing floor mats
Use only floor mats designed specifi­cally for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet.
1 Insert the retaining hooks (clips)
into the floor mat eyelets.
Observe the following precautions. Failure to do so may cause the driver’s floor mat to slip, possibly interfering with the pedals while driving. An unexpect­edly high speed may result or it may become difficult to stop the vehicle. This could lead to an accident, resulting in death or serious injury.
When installing the driver’s floor mat
Do not use floor mats designed for
other models or different model year vehicles, even if they are Lexus Genu­ine floor mats.
Only use floor mats designed for the
driver’s seat.
Always install the floor mat securely
using the retaining hooks (clips) pro­vided.
Do not use two or more floor mats on
top of each other.
2 Turn the upper knob of each retain-
ing hook (clip) to secure the floor mats in place.
Always align the marks . The shape of the retaining hooks (clips)
may differ from that shown in the illustra­tion.
A
Do not place the floor mat bottom-
side up or upside-down.
Before driving
Check that the floor mat is securely
fixed in the correct place with all the provided retaining hooks (clips). Be especially careful to perform this check after cleaning the floor.
With the engine stopped and the shift
lever in P, fully depress each pedal to the floor to make sure it does not inter­fere with the floor mat.
1-1. For safe use
WARNING
A
B
C
D
23
For safe driving
For safe driving, adjust the seat and mirror to an appropriate position before driving.
Correct driving posture
Adjust the angle of the seatback so that you are sitting straight up and so that you do not have to lean for­ward to steer. (P.107)
Adjust the seat so that you can depress the pedals fully and so that your arms bend slightly at the elbow when gripping the steering wheel. (P.107)
Lock the head restraint in place with the center of the head restraint closest to the top of your ears. (P.111)
Wear the seat belt correctly. (P.25)
Do not adjust the position of the
driver’s seat while driving. Doing so could cause the driver to lose control of the vehicle.
Do not place a cushion between the
driver or passenger and the seatback. A cushion may prevent correct pos­ture from being achieved, and reduce the effectiveness of the seat belt and head restraint.
Do not place anything under the front
seats. Objects placed under the front seats may become jammed in the seat tracks and stop the seat from locking in place. This may lead to an accident and the adjustment mechanism may also be damaged.
Always observe the legal speed limit
when driving on public roads.
When driving over long distances, take
regular breaks before you start to feel tired. Also, if you feel tired or sleepy while driving, do not force yourself to con­tinue driving and take a break immedi­ately.
Correct use of the seat belts
Make sure that all occupants are wear­ing their seat belts before driving the vehicle. (P.25) Use a child restraint system appropri­ate for the child until the child becomes large enough to properly wear the vehicle’s seat belt. (P.42)
1
For safety and security
Observe the following precautions. Failure to do so may result in death or serious injury.
Adjusting the mirrors
Make sure that you can see backward clearly by adjusting the inside and out­side rear view mirrors properly. (P.114, 115)
24
WARNING
1-1. For safe use
Seat belts
Make sure that all occupants are wearing their seat belts before driv­ing the vehicle.
Observe the following precautions to reduce the risk of injury in the event of sudden braking, sudden swerving or an accident. Failure to do so may cause death or seri­ous injury.
Wearing a seat belt
Ensure that all passengers wear a seat
belt.
Always wear a seat belt properly.
Each seat belt should be used by one
person only. Do not use a seat belt for more than one person at once, includ­ing children.
Lexus recommends that children be
seated in the rear seat and always use a seat belt and/or an appropriate child restraint system.
Pregnant women
Obtain medical advice and wear the seat belt in the proper way. (P.25)
Women who are pregnant should posi­tion the lap belt as low as possible over the hips in the same manner as other occupants, extending the shoulder belt completely over the shoulder and avoid­ing belt contact with the rounding of the abdominal area.
If the seat belt is not worn properly, not only the pregnant woman, but also the fetus could suffer death or serious injury as a result of sudden braking or a colli­sion.
To achieve a proper seating position,
do not recline the seat more than nec­essary. The seat belt is most effective when the occupants are sitting up straight and well back in the seats.
Do not wear the shoulder belt under
your arm.
Always wear your seat belt low and
snug across your hips.
People suffering illness
Obtain medical advice and wear the seat belt in the proper way. (P.25)
When children are in the vehicle
P.42
Seat belt damage and wear
Do not damage the seat belts by allow-
ing the belt, plate, or buckle to be jammed in the door.
Inspect the seat belt system periodi-
cally. Check for cuts, fraying, and loose parts. Do not use a damaged seat belt until it is replaced. Damaged seat belts cannot protect an occupant from death or serious injury.
WARNING
Ensure that the belt and plate are
WARNING
locked and the belt is not twisted. If the seat belt does not function cor­rectly, immediately contact your Lexus dealer.
Replace the seat assembly, including
the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
Do not attempt to install, remove,
modify, disassemble or dispose of the seat belts. Have any necessary repairs carried out by your Lexus dealer. Inap­propriate handling may lead to incor­rect operation.
Correct use of the seat belts
1-1. For safe use
Use a child restraint system appropriate
for the child, until the child becomes large enough to properly wear the vehicle’s seat belt. (P.42)
When the child becomes large enough to
properly wear the vehicle’s seat belt, fol­low the instructions regarding seat belt usage. (P.24)
Seat belt extender
If your seat belts cannot be fastened securely because they are not long enough, a personalized seat belt extender is avail­able from your Lexus dealer free of charge.
Using a seat belt extender
Observe the following precautions to reduce the risk of injury in the event of sudden braking, sudden swerving or an accident. Failure to do so may cause death or seri­ous injury.
25
1
For safety and security
Extend the shoulder belt so that it
comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
Position the lap belt as low as possi-
ble over the hips.
Adjust the position of the seatback.
Sit up straight and well back in the seat.
Do not twist the seat belt.
Child seat belt usage
The seat belts of your vehicle were princi­pally designed for persons of adult size.
Do not wear the seat belt extender if
you can fasten the seat belt without the extender.
Do not use the seat belt extender
when installing a child restraint system because the belt will not securely hold the child restraint system, increasing the risk of death or serious injury in the event of an accident.
The personalized extender may not be
safe on another vehicle, when used by another person, or at a different seat­ing position other than the one origi­nally intended.
26
NOTICE
WARNING
When using a seat belt extender
When releasing the seat belt, press on the buckle release button on the extender, not on the seat belt. This helps prevent damage to the vehicle interior and the extender itself.
1-1. For safe use
Fastening and releasing the seat belt
1 To fasten the seat belt, push the
plate into the buckle until a click sound is heard.
2 To release the seat belt, press the
release button .
Emergency locking retractor (ELR)
The retractor will lock the belt during a sud­den stop o r on impa ct. It ma y also lock if y ou lean forward too quickly. A slow, easy motion will allow the belt to extend so that you can move around fully.
Automatic locking retractor (ALR)
When a passenger’s shoulder belt is com­pletely extended and then retracted even slightly, the belt is locked in that position and cannot be extended. This feature is used to hold a child restraint system (CRS) firmly. To free the belt again, fully retract the belt and then pull the belt out once more.
A
Adjusting the seat belt shoulder anchor height (front seats)
1 Push the seat belt shoulder anchor
down while pressing the release button .
A
2 Push the seat belt shoulder anchor
up.
Move the height adjuster up and down as needed until you hear a click.
Adjustable shoulder anchor
Always make sure the shoulder belt is positioned across the center of your shoulder. The belt should be kept away from your neck, but not falling off your shoulder. Failure to do so could reduce the amount of protection in an accident and cause death or serious injuries in the event of a sudden stop, sudden swerve or accident.
Seat belt pretensioners (front and outboard rear seats)
The pretensioners help the seat belts to quickly restrain the occupants by retracting the seat belts when the vehi­cle is subjected to certain types of severe frontal or side collision or a vehicle rollover.
The pretensioners do not activate in the
event of a minor frontal impact, a minor
WARNING
side impact or a rear impact.
Replacing the belt after the preten-
sioner has been activated
If the vehicle is involved in multiple colli­sions, the pretensioner will activate for the first collision, but will not activate for the second or subsequent collisions.
Seat belt pretensioners
Observe the following precautions to reduce the risk of injury in the event of sudden braking, sudden swerving or an accident. Failure to do so may cause death or seri­ous injury.
1-1. For safe use
27
1
For safety and security
Do not place anything, such as a cush-
ion, on the front passenger’s seat. Doing so will disperse the passenger’s weight, which prevents the sensor from detecting the passenger’s weight properly. As a result, the seat belt pre­tensioner for the front passenger’s seat may not activate in the event of a colli­sion.
If the pretensioner has activated, the
SRS warning light will come on. In that case, the seat belt cannot be used again and must be replaced at your Lexus dealer.
28
A
B
C
D
1-1. For safe use
SRS airbags
The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury.
SRS airbag system
Location of the SRS airbags
SRS front airbags
SRS driver airbag/front passenger airbag Can help protect the head and chest of the driver and front passenger from impact with interior components
SRS knee airbags Can help provide driver and front passenger protection
SRS side and curtain shield airbags
SRS front side airbags Can help protect the torso of the front seat occupants
SRS rear side airbags Can help protect the torso of occupants in the rear outer seats
1-1. For safe use
E
A
B
C
D
E
F
G
H
I
J
K
L
M
SRS curtain shield airbags
• Can help protect primarily the head of occupants in the outer seats
• Can help prevent the occupants from being thrown from the vehicle in the event of vehi­cle rollover
SRS airbag system components
29
1
For safety and security
Front passenger occupant classification system (ECU and sensors) Knee airbags Front passenger airbag Curtain shield airbags Side impact sensors (front doors) Seat belt pretensioners and force limiters Side impact sensors (front) Front side airbags Side impact sensors (rear) Rear side airbags Driver airbag SRS warning light Driver’s seat position sensor
30
N
O
P
Q
R
1-1. For safe use
Driver’s seat belt buckle switch Airbag sensor assembly “AIR BAG ON” and “AIR BAG OFF” indicator lights Front passenger’s seat belt buckle switch Front impact sensors
Your vehicle is equipped with ADVANCED AIRBAGS designed based on the US motor vehicle safety standards (FMVSS208). The airbag sensor assembly (ECU) controls airbag deployment based on information obtained from the sensors etc. shown in the system components diagram above. This information includes crash severity and occupant information. As the airbags deploy, a chemical reaction in the inflators quickly fills the airbags with non-toxic gas to help restrain the motion of the occupants.
If the SRS airbags deploy (inflate)
Slight abrasions, burns, bruising etc., may
be sustained from SRS airbags, due to the extremely high speed deployment (infla­tion) by hot gases.
A loud noise and white powder will be
emitted.
Parts of the airbag module (steering
wheel hub, airbag cover and inflator) as well as the front seats, parts of the front and rear pillars, and roof side rails may be hot for several minutes. The airbag itself may also be hot.
The windshield may crack.
The interior lights will turn on automati-
cally. (P.262)
The emergency flashers will turn on auto-
matically. (P.340)
For Lexus Enform Safety Connect sub-
scribers, if any of the following situations occur, the system is designed to send an emergency call to the response center, notifying them of the vehicle’s location (without needing to push the “SOS” but­ton) and an agent will attempt to speak with the occupants to ascertain the level of emergency and assistance required. If the occupants are unable to communi­cate, the agent automatically treats the call as an emergency and helps to dis­patch the necessary emergency ser-
vices.(P.289)
• An SRS airbag is deployed.
• A seat belt pretensioner is activated.
• The vehicle is involved in a severe rear­end collision.
SRS airbag deployment conditions (SRS
front airbags)
The SRS front airbags will deploy in the
event of an impact that exceeds the set threshold level (the level of force corre­sponding to an approximately 12 - 18 mph [20 - 30 km/h] frontal collision with a fixed wall that does not move or deform). However, this threshold velocity will be considerably higher in the following situa­tions:
• If the vehicle strikes an object, such as a parked vehicle or sign pole, which can move or deform on impact
• If the vehicle is involved in an underride collision, such as a collision in which the front of the vehicle underrides, or goes under, the bed of a truck
Depending on the type of collision, it is
possible that only the seat belt preten­sioners and SRS knee airbags will acti­vate.
The SRS front airbags for the front pas-
senger will not activate if there is no pas­senger sitting in the front passenger seat. However, the SRS front airbags for the front passenger may deploy if luggage is
put in the seat, even if the seat is unoccu­pied.
SRS airbag deployment conditions (SRS
side and curtain shield airbags)
The SRS side and curtain shield airbags
will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to the impact force produced by an approximately 3300 lb. [1500 kg] vehicle colliding with the vehicle cabin from a direction per­pendicular to the vehicle orientation at an approximate speed of 12 - 18 mph [20 ­30 km/h]).
Both SRS curtain shield airbags may
deploy in the event of a severe side colli­sion.
Both SRS curtain shield airbags will
deploy in the event of vehicle rollover.
Both SRS curtain shield airbags may also
deploy in the event of a severe frontal col­lision.
Conditions under which the SRS air-
bags may deploy (inflate), other than a collision
The SRS front airbags and SRS curtain shield airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration.
Hitting a curb, edge of pavement or hard
surface
Falling into or jumping over a deep hole
Landing hard or falling
1-1. For safe use
Types of collisions that may not deploy
the SRS airbags (SRS front airbags)
The SRS front airbags do not generally inflate if the vehicle is involved in a side or rear collision, if it rolls over, or if it is involved in a low-speed frontal collision. But, when­ever a collision of any type causes sufficient forward deceleration of the vehicle, deploy­ment of the SRS front airbags may occur.
Collision from the side
Collision from the rear
Vehicle rollover
Types of collisions that may not deploy
the SRS airbags (SRS side and curtain shield airbags)
The SRS side and curtain shield airbags may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.
Collision from the side to the vehicle
body other than the passenger compart­ment
Collision from the side at an angle
31
1
For safety and security
The SRS curtain shield airbags may also deploy under the situations shown in the illustration.
The angle of vehicle tip-up is marginal.
The vehicle skids and hits a curb stone.
32
1-1. For safe use
The SRS side airbags do not generally inflate if the vehicle is involved in a frontal or rear collision, if it rolls over, or if it is involved in a low-speed side collision.
Collision from the front
Collision from the rear
Vehicle rollover
that was not severe enough to cause the SRS front airbags to inflate.
A portion of a door or its surrounding
area is damaged, deformed or has had a hole made in it, or the vehicle was involved in an accident that was not severe enough to cause the SRS side and curtain shield airbags to inflate.
The SRS curtain shield airbags do not gen­erally inflate if the vehicle is involved in a rear collision, if it pitches end over end, or if it is involved in a low-speed side or low­speed frontal collision.
Collision from the rear
Pitching end over end
When to contact your Lexus dealer
In the following cases, the vehicle will require inspection and/or repair. Contact your Lexus dealer as soon as possible.
Any of the SRS airbags have been
inflated.
The front of the vehicle is damaged or
deformed, or was involved in an accident
The pad section of the steering wheel,
dashboard near the front passenger air­bag or lower portion of the instrument panel is scratched, cracked, or otherwise damaged.
The surface of the seats with the SRS side
airbag is scratched, cracked, or other­wise damaged.
1-1. For safe use
WARNING
33
The portion of the front pillars, rear pillars
or roof side rail garnishes (padding) con­taining the SRS curtain shield airbags inside is scratched, cracked, or otherwise damaged.
SRS airbag precautions
Observe the following precautions regarding the SRS airbags. Failure to do so may cause death or seri­ous injury.
The driver and all passengers in the
vehicle must wear their seat belts properly. The SRS airbags are supplemental devices to be used with the seat belts.
The SRS driver airbag deploys with
considerable force, and can cause death or serious injury especially if the driver is very close to the airbag. The National Highway Traffic Safety Administration (NHTSA) advises: Since the risk zone for the driver’s air­bag is the first 2 - 3 in. (50 - 75 mm) of inflation, placing yourself 10 in. (250 mm) from your driver airbag provides you with a clear margin of safety. This distance is measured from the center of the steering wheel to your breast­bone. If you sit less than 10 in. (250 mm) away now, you can change your driving position in several ways:
• Move your seat to the rear as far as you can while still reaching the pedals comfortably.
• Slightly recline the back of the seat. Although vehicle designs vary, many drivers can achieve the 10 in. (250 mm) distance, even with the driver seat all the way forward, simply by reclining the back of the seat somewhat. If reclining the back of your seat makes it hard to see the road, raise yourself by using a firm, non-slippery cushion, or raise the seat if your vehicle has that feature.
• If your steering wheel is adjustable, tilt it downward. This points the airbag toward your chest instead of your head and neck.
1
For safety and security
The seat should be adjusted as recom­mended by NHTSA above, while still maintaining control of the foot pedals, steering wheel, and your view of the instrument panel controls.
34
WARNING
If the seat belt extender has been con-
1-1. For safe use
nected to the front seat belt buckles but the seat belt extender has not also been fastened to the latch plate of the seat belt, the SRS front airbags will judge that the driver and front passen­ger are wearing the seat belt even though the seat belt has not been con­nected. In this case, the SRS front air­bags may not activate correctly in a collision, resulting in death or serious injury in the event of a collision. Be sure to wear the seat belt with the seat belt extender.
Do not sit on the edge of the seat or
lean against the dashboard.
Do not allow a child to stand in front of
the SRS front passenger airbag unit or sit on the knees of a front passenger.
The SRS front passenger airbag also
deploys with considerable force, and can cause death or serious injury especially if the front passenger is very close to the airbag. The front passen­ger seat should be as far from the air­bag as possible with the seatback adjusted, so the front passenger sits upright.
Improperly seated and/or restrained
infants and children can be killed or seriously injured by a deploying airbag. An infant or child who is too small to use a seat belt should be properly secured using a child restraint system. Lexus strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front pas­senger seat. (P.42)
Do not allow the front seat occupants
to hold items on their knees.
Do not lean against the door, the roof
side rail or the front, side and rear pil­lars.
Do not allow anyone to kneel on the
passenger seats toward the door or put their head or hands outside the vehicle.
WARNING
Do not attach anything to or lean any-
thing against areas such as the dash­board, steering wheel pad and lower portion of the instrument panel. These items can become projectiles when the SRS driver, front passenger and knee airbags deploy.
Do not attach anything to areas such
as a door, windshield, side window, front or rear pillar, roof side rail and assist grip.
1-1. For safe use
Do not strike or apply significant levels
of force to the area of the SRS airbag components or the front doors. Doing so can cause the SRS airbags to malfunction.
Do not touch any of the component
parts immediately after the SRS air­bags have deployed (inflated) as they may be hot.
If breathing becomes difficult after the
SRS airbags have deployed, open a door or window to allow fresh air in, or leave the vehicle if it is safe to do so. Wash off any residue as soon as possi­ble to prevent skin irritation.
If the areas where the SRS airbags are
stored, such as the steering wheel pad and front and rear pillar garnishes are damaged or cracked, have them replaced by your Lexus dealer.
Do not place anything, such as a cush-
ion, on the front passenger’s seat. Doing so will disperse the passenger’s weight, which prevents the sensor from detecting the passenger’s weight properly. As a result, the SRS front air­bags for the front passenger may not deploy in the event of a collision.
35
1
For safety and security
Do not hang coat hangers or other
hard objects on the coat hooks. All of these items could become projectiles and may cause death or serious injury, should the SRS curtain shield airbags deploy.
If a vinyl cover is put on the area where
the SRS knee airbag will deploy, be sure to remove it.
Do not use seat accessories which
cover the parts where the SRS side air­bags inflate as they may interfere with inflation of the SRS airbags. Such accessories may prevent the side air­bags from activating correctly, disable the system or cause the side airbags to inflate accidentally, resulting in death or serious injury.
Modification and disposal of SRS air-
bag system components
Do not dispose of your vehicle or per­form any of the following modifications without consulting your Lexus dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Installation, removal, disassembly and
repair of the SRS airbags
Repairs, modifications, removal or
replacement of the steering wheel, instrument panel, dashboard, seats or seat upholstery, front, side and rear pil­lars, roof side rails, front door panels, front door trims or front door speakers
Modifications to the front door panel
(such as making a hole in it)
36
WARNING
Repairs or modifications of the front
1-1. For safe use
fender, front bumper, or side of the occupant compartment
Installation of a grille guard (bull bars,
kangaroo bar, etc.), snow plows, winches or roof luggage carrier
Modifications to the vehicle’s suspen-
sion system
Installation of electronic devices such
as mobile two-way radios and CD players
Modifications to your vehicle for a per-
son with a physical disability
1-1. For safe use
A
B
C
D
E
F
WARNING
Front passenger occupant classification system
Your vehicle is equipped with a front passenger occupant classification system. This system detects the conditions of the front passenger seat and activates or deactivates the front passenger airbag, and front passenger knee airbag.
37
System components
Driver’s and front passenger’s seat belt reminder light SRS warning light
For the U.S.A.
“AIR BAG ON” indicator light “AIR BAG OFF” indicator light
1
For safety and security
For Canada
“AIR BAG ON” indicator light “AIR BAG OFF” indicator light
Front passenger occupant classifica-
tion system precautions
Observe the following precautions regarding the front passenger occupant classification system. Failure to do so may cause death or seri­ous injury.
Wear the seat belt properly.
Make sure the front passenger’s seat
belt plate has not been left inserted into the buckle before someone sits in the front passenger seat.
38
WARNING
Make sure the “AIR BAG OFF” indica-
1-1. For safe use
tor light is not illuminated when using the seat belt extender for the front pas­senger seat. If the “AIR BAG OFF” indicator light is illuminated, discon­nect the extender tongue from the seat belt buckle, and reconnect the seat belt. Reconnect the seat belt extender after making sure the “AIR BAG ON” indicator light is illuminated. If you use the seat belt extender while the “AIR BAG OFF” indicator light is illumi­nated, the SRS airbags for the front passenger will not activate, which could cause death or serious injury in the event of a collision.
Do not apply a heavy load to the front
passenger seat or equipment (e.g. seatback pocket).
If an adult sits in the front passenger
seat, the “AIR BAG ON” indicator light is illuminated. If the “AIR BAG OFF” indicator is illuminated, ask the passen­ger to sit up straight, well back in the seat, feet on the floor, and with the seat belt worn correctly. If the “AIR BAG OFF” indicator still remains illumi­nated, either ask the passenger to move to the rear seat, or if that is not possible, move the front passenger seat fully rearward.
When it is unavoidable to install a for-
ward-facing child restraint system on the front passenger seat, install the child restraint system on the front pas­senger seat in the proper order. (P.44)
Do not modify or remove the front
seats.
Do not put weight on the front passen-
ger seat by putting your hands or feet on the front passenger seat seatback from the rear passenger seat.
Do not let a rear passenger lift the
front passenger seat with their feet or press on the seatback with their legs.
Do not put objects under the front pas-
senger seat.
Do not recline the front passenger
seatback so far that it touches a rear seat. This may cause the “AIR BAG OFF” indicator light to be illuminated, which indicates that the SRS airbags for the front passenger will not activate in the event of a severe accident. If the seatback touches the rear seat, return the seatback to a position where it does not touch the rear seat. Keep the front passenger seatback as upright as possible when the vehicle is moving. Reclining the seatback excessively may lessen the effectiveness of the seat belt system.
Do not kick the front passenger seat or
subject it to severe impact. Otherwise, the SRS warning light may come on to indicate a malfunction of the front pas­senger occupant classification system. In this case, contact your Lexus dealer immediately.
Child restraint systems installed on the
rear seat should not contact the front seatbacks.
Do not use a seat accessory, such as a
cushion and seat cover, that covers the seat cushion surface.
Do not modify or replace the uphol-
stery of the front seat.
Do not place anything between the
console box and front passenger seat. Otherwise, the system may not detect the front passenger properly, leading to improper operation of the airbags.
Adjust the front passenger seat so that
the head restraint does not touch the ceiling. If the head restraint is left in contact with the ceiling, the system may not detect the front passenger properly, leading to improper opera­tion of the airbags.
1-1. For safe use
Condition and operation in the front passenger occupant classification system
39
Adult
*1
“AIR BAG ON” and “AIR BAG OFF”
indicator lights
Indicator/warning light
SRS warning light Off
Driver’s and front passenger’s seat belt
Front passenger airbag
Devices
Front passenger knee airbag
Child
*4
“AIR BAG ON” and “AIR BAG OFF”
indicator lights
Indicator/warning light
SRS warning light Off
Driver’s and front passenger’s seat belt
Front passenger airbag
Devices
Front passenger knee airbag
Child restraint system with infant
reminder light
reminder light
*5
“AIR BAG ON”
Off*2 or flashing
*3
Activated
“AIR BAG OFF” or
“AIR BAG ON”
Off*2 or flashing
*4
*3
Deactivated or acti-
*4
vated
1
For safety and security
Indicator/warning light
Devices
“AIR BAG ON” and “AIR BAG OFF”
indicator lights
SRS warning light Off
Driver’s and front passenger’s seat belt
reminder light
Front passenger airbag
Front passenger knee airbag
“AIR BAG OFF”
Off*2 or flashing
Deactivated
*6
*3
40
Unoccupied
1-1. For safe use
Indicator/warning light
“AIR BAG ON” and “AIR BAG OFF”
indicator lights
SRS warning light
Driver’s and front passenger’s seat belt
“AIR BAG OFF”
Off
reminder light
Front passenger airbag
Devices
Deactivated
Front passenger knee airbag
There is a malfunction in the system
Indicator/warning light
“AIR BAG ON” and “AIR BAG OFF”
indicator lights
SRS warning light
Driver’s and front passenger’s seat belt
“AIR BAG OFF”
On
reminder light
Front passenger airbag
Devices
Deactivated
Front passenger knee airbag
*1
: The system judges a person of adult size as an adult. When a smaller adult sits in the
front passenger seat, the system may not recognize him/her as an adult depending on his/her physique and posture.
*2
: In the event the front passenger is wearing a seat belt.
*3
: In the event the front passenger does not wear a seat belt
*4
: For some children, child in seat, child in booster seat or child in convertible seat, the sys-
tem may not recognize him/her as a child. Factors which may affect this can be the phy­sique or posture.
*5
: Never install a rear-facing child restraint system on the front passenger seat. A forward-
facing child restraint system should only be installed on the front passenger seat when it is unavoidable. (P.44)
*6
: In case the indicator light is not illuminated, consult this manual on how to install the child
restraint system properly. (P.42)
1-1. For safe use
WARNING
41
Exhaust gas precautions
Harmful substance to the human body is included in exhaust gases if inhaled.
Exhaust gases include harmful carbon monoxide (CO), which is colorless and odorless. Observe the following precau­tions. Failure to do so may cause exhaust gases enter the vehicle and may lead to an accident caused by light-headedness, or may lead to death or a serious health hazard.
Important points while driving
Keep the trunk lid closed.
If you smell exhaust gases in the vehi-
cle even when the trunk lid is closed, open the windows and have the vehi­cle inspected at your Lexus dealer as soon as possible.
Exhaust pipe
The exhaust system needs to be checked periodically. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Lexus dealer.
1
For safety and security
When parking
If the vehicle is in a poorly ventilated
area or a closed area, such as a garage, stop the engine.
Do not leave the vehicle with the
engine running for a long time. If such a situation cannot be avoided, park the vehicle in an open space and ensure that exhaust fumes do not enter the vehicle interior.
Do not leave the engine running in an
area with snow build-up, or where it is snowing. If snowbanks build up around the vehicle while the engine is running, exhaust gases may collect and enter the vehicle.
42
WARNING
1-2.Child safety
1-2. Child safety
Riding with children
Child restraint systems
Observe the following precautions when children are in the vehicle. Use a child restraint system appro­priate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt.
It is recommended that children
sit in the rear seats to avoid acci­dental contact with the shift lever, wiper switch, etc.
Use the rear door child-protector
lock or the window lock switch to avoid children opening the door while driving or operating the power window accidentally. (P.92, 119)
Do not let small children operate
equipment which may catch or pinch body parts, such as the power window, hood, trunk, seats etc.
Before installing a child restraint system in the vehicle, there are pre­cautions that need to be observed, different types of child restraint sys­tems, as well as installation meth­ods, etc., written in this manual.
Use a child restraint system when riding with a small child that cannot properly use a seat belt. For the child’s safety, install the child restraint system to a rear seat. Be sure to fol­low the installation method that is in the operation manual enclosed with the restraint system.
Table of contents
Points to remember: P.42 Child restraint system: P.43 When using a child restraint system:
P.44
When children are in the vehicle
Never leave children unattended in the vehicle, and never allow children to have or use the key.
Children may be able to start the vehicle or shift the vehicle into neutral. There is also a danger that children may injure themselves by playing with the windows, the moon roof (if equipped), panoramic moon roof (if equipped), or other fea­tures of the vehicle. In addition, heat build-up or extremely cold temperatures inside the vehicle can be fatal to children.
Child restraint system installation method
• Fixed with a seat belt: P.46
• Fixed with a child restraint LATCH anchor: P.49
• Using an anchor bracket (for top tether strap): P.51
Points to remember
The laws of all 50 states of the U.S.A. as well as Canada now require the use of child restraint systems.
Prioritize and observe the warn-
ings, as well as the laws and regula-
1-2. Child safety
WARNING
43
tions for child restraint systems.
Use a child restraint system until the
child becomes large enough to properly wear the vehicle’s seat belt.
Choose a child restraint system that
suits your vehicle and is appropriate to the age and size of the child.
When a child is riding
Observe the following precautions. Failure to do so may result in death or serious injury.
For effective protection in automobile
accidents and sudden stops, a child must be properly restrained, using a seat belt or child restraint system which is correctly installed. For installa­tion details, refer to the operation man­ual enclosed with the child restraint system. General installation instruction is provided in this manual.
Lexus strongly urges the use of a
proper child restraint system that con­forms to the weight and size of the child, installed on the rear seat. According to accident statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Holding a child in your or someone
else’s arms is not a substitute for a child restraint system. In an accident, the child can be crushed against the wind­shield or between the holder and the interior of the vehicle.
Handling the child restraint system
If the child restraint system is not prop­erly fixed in place, the child or other pas­sengers may be seriously injured or even killed in the event of sudden braking, sud­den swerving, or an accident.
If the vehicle were to receive a strong
impact from an accident, etc., it is pos­sible that the child restraint system has damage that is not readily visible. In such cases, do not reuse the restraint system.
Make sure you have complied with all
installation instructions provided with the child restraint system manufac­turer and that the system is properly secured.
Keep the child restraint system prop-
erly secured on the seat even if it is not in use. Do not store the child restraint system unsecured in the passenger compartment.
If it is necessary to detach the child
restraint system, remove it from the vehicle or store it securely in the trunk.
1
For safety and security
Child restraint system
Types of child restraint system installation methods
Confirm with the operation manual enclosed with the child restraint system about the installation of the child restraint system.
44
1-2. Child safety
Installation method Page
Seat belt attachment P.46
Child restraint LATCH
anchors attachment
Anchor brackets (for top
tether strap) attachment
When using a child restraint sys­tem
When installing a child restraint
system to a front passenger seat
For the safety of a child, install child restraint systems to a rear seats. When installing child restraint system to a front passenger seat is unavoidable, adjust the seat as follows and install the child restraint system.
P.49
P.51
Move the front seat fully rearward.Adjust the seatback angle to the
most upright position.
When installing a forward-facing child seat, if there is a gap between the child seat and the seatback, adjust the seatback angle until good contact is achieved.
Adjust the front of the seat cushion
to the uppermost position.
Adjust the seat height to the upper-
most position.
1-2. Child safety
WARNING
45
Adjust the lumbar support to the
lowest position.
Adjust the pelvic support
*
to the
lowest position.
If the head restraint interferes with
the child restraint system installa­tion and the head restraint can be removed, remove the head restraint. Otherwise, put the head restraint in the upper most position.
*
:If equipped
A forward-facing child restraint system
may be installed on the front passen­ger seat only when it is unavoidable. A child restraint system that requires a top tether strap should not be used in the front passenger seat since there is no top tether strap anchor for the front passenger seat.
A forward-facing child restraint system
may be installed on the front passen­ger seat only when it is unavoidable. When installing a forward-facing child restraint system on the front passenger seat, adjust the seatback angle to the most upright position, move the seat to the rearmost position, and raise the seat to the upper most position, even if the “AIR BAG OFF” indicator light is illuminated.
1
For safety and security
When using a child restraint system
Observe the following precautions. Failure to do so may result in death or serious injury.
Never install a rear-facing child
restraint system on the front passenger seat even if the “AIR BAG OFF” indi­cator light is illuminated. In the event of an accident, the force of the rapid infla­tion of the front passenger airbag can cause death or serious injury to the child if the rear-facing child restraint system is installed on the front passen­ger seat.
Do not allow the child to lean his/her
head or any part of his/her body against the door or the area of the seat, front or rear pillars, or roof side rails from which the SRS side airbags or SRS curtain shield airbags deploy even if the child is seated in the child restraint system. It is dangerous if the SRS side and curtain shield airbags inflate, and the impact could cause death or serious injury to the child.
46
WARNING
When a booster seat is installed,
Use child restraint system suitable to
If the driver’s seat interferes with the
1-2. Child safety
always ensure that the shoulder belt is positioned across the center of the child’s shoulder. The belt should be kept away from the child’s neck, but not so that it could fall off the child’s shoulder.
the age and size of the child and install it to the rear seat.
child restraint system and prevents it from being attached correctly, attach the child restraint system to the right­hand rear seat.
Rear-facing Infant seat/con-
vertible seat
1 Place the child restraint system on
the rear seat facing the rear of the vehicle.
2 Run the seat belt through the child
restraint system and insert the plate into the buckle. Make sure that the belt is not twisted.
Adjust the front passenger seat so that
it does not interfere with the child restraint system.
Child restraint system fixed with a seat belt
A child restraint system for a small child or baby must itself be properly restrained on the seat with the lap por­tion of the lap/shoulder belt.
Installing child restraint system
using a seat belt (child restraint lock function belt)
Install the child restraint system in accordance to the operation manual enclosed with the child restraint sys­tem.
3 Fully extend the shoulder belt and
allow it to retract to put it in lock mode. In lock mode, the belt cannot be extended.
1-2. Child safety
47
4 While pushing the child restraint
system down into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place.
After the shoulder belt has retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
5 After installing the child restraint
system, rock it back and forth to ensure that it is installed securely. (P.49)
Forward-facing Convertible
seat
1 Adjust the seat
When using the front passenger seat: If installing the child restraint system to the front passenger seat is unavoid­able, refer to P.44 for front passenger seat adjustment.
2 Place the child restraint system on
the seat facing the front of the vehi­cle.
1
For safety and security
3 Run the seat belt through the child
restraint system and insert the plate into the buckle. Make sure that the belt is not twisted.
4 Fully extend the shoulder belt and
allow it to retract to put it in lock mode. In lock mode, the belt cannot be extended.
5 While pushing the child restraint
system into the rear seat, allow the shoulder belt to retract until the
48
1-2. Child safety
child restraint system is securely in place.
After the shoulder belt has retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
6 If the child restraint has a top tether
strap, follow the child restraint man­ufacturer’s operation manual regarding the installation, using the top tether strap to latch onto the top tether strap anchor. (P.51)
7 After installing the child restraint
system, rock it back and forth to ensure that it is installed securely. (P.49)
Booster seat
1 If installing the child restraint sys-
tem to the front passenger seat is unavoidable, refer to P.44 for front passenger seat adjustment.
2 Place the child restraint system on
the seat facing the front of the vehi­cle.
Booster type
High back type
3 Sit the child in the child restraint
system. Fit the seat belt to the child restraint system according to the manufacturer’s instructions and insert the plate into the buckle. Make sure that the belt is not twisted.
Check that the shoulder belt is correctly positioned over the child’s shoulder and that the lap belt is as low as possible. (P.24)
1-2. Child safety
WARNING
49
Removing a child restraint system
installed with a seat belt
Press the buckle release button and fully retract the seat belt.
When releasing the buckle, the child restraint system may spring up due to the rebound of the seat cushion. Release the buckle while holding down the child restraint system.
Since the seat belt automatically reels itself, slowly return it to the stowing position.
When installing a child restraint sys-
tem
Observe the following precautions. Failure to do so may result in death or serious injury.
Do not allow children to play with the
seat belt. If the seat belt becomes twisted around a child’s neck, it may lead to choking or other serious inju­ries that could result in death. If this occurs and the buckle cannot be unfastened, scissors should be used to cut the belt.
After securing a child restraint system,
never adjust the seat.
When a booster seat is installed,
always ensure that the shoulder belt is positioned across the center of the child’s shoulder. The belt should be kept away from the child’s neck, but not so that it could fall off the child’s shoulder.
Follow all installation instructions pro-
vided by the child restraint system manufacturer.
When securing some types of child
restraint systems in rear seats, it may not be possible to properly use the seat belts in positions next to the child restraint without interfering with it or affecting seat belt effectiveness. Be sure your seat belt fits snugly across your shoulder and low on your hips. If it does not, or if it interferes with the child restraint, move to a different posi­tion. Failure to do so may result in death or serious injury.
When installing a booster seat
To prevent the belt from going into ALR lock mode, do not fully extend the shoul­der belt. ALR mode causes the belt to tighten only. This could cause injury or discomfort to the child. (P.26)
Do not use a seat belt extender
If a seat belt extender is used when installing a child restraint system, the seat belt will not securely hold the child restraint system, which could cause death or serious injury to the child or other passengers in the event of sudden braking, sudden swerving or an accident.
1
For safety and security
Ensure that the belt and plate are
securely locked and the seat belt is not twisted.
Shake the child restraint system left
and right, and forward and backward to ensure that it has been securely installed.
Child restraint system fixed with a child restraint LATCH anchor
Child restraint LATCH anchors
LATCH anchors are provided for the outboard rear seat. (Marks displaying
50
A
A
1-2. Child safety
the location of the anchors are attached to the seats.)
Installation with LATCH system
Install the child restraint system in accordance to the operation manual enclosed with the child restraint sys­tem.
1 Remove the cover.
tem indicates the presence of a lower connector system.
Canada only
Type B
2 Latch the buckles onto the LATCH
anchors. For owners in Canada: The symbol on a child restraint sys-
Type A
2 Latch the hooks of the lower straps
onto the LATCH anchors. For owners in Canada: The symbol on a child restraint sys-
1-2. Child safety
A
WARNING
51
tem indicates the presence of a
A
lower connector system.
Canada only
3 If the child restraint has a top tether
strap, follow the child restraint man­ufacturer’s operation manual regarding the installation, using the top tether strap to latch onto the top tether strap anchor. (P.51)
4 After installing the child restraint
system, rock it back and forth to ensure that it is installed securely. (P.49)
Laws and regulations pertaining to
anchors
The LATCH system conforms to FMVSS225 or CMVSS210.2. Child restraint systems conforming to FMVSS213 or CMVSS213 specifications can be used. This vehicle is designed to conform to SAE J1819.
When installing a child restraint sys-
tem
Observe the following precautions. Failure to do so may result in death or serious injury.
After securing a child restraint system,
never adjust the seat.
When using the LATCH anchors, be
sure that there are no foreign objects around the anchors and that the seat belt is not caught behind the child restraint system.
Follow all installation instructions pro-
vided by the child restraint system manufacturer.
When securing some types of child
restraint systems in rear seats, it may not be possible to properly use the seat belts in positions next to the child restraint without interfering with it or affecting seat belt effectiveness. Be sure your seat belt fits snugly across your shoulder and low on your hips. If it does not, or if it interferes with the child restraint, move to a different posi­tion. Failure to do so may result in death or serious injury.
Using an anchor bracket (for top tether strap)
Anchor brackets (for top tether
strap)
Anchor brackets are provided for each rear seat.
Use anchor brackets when fixing the top tether strap.
1
For safety and security
52
ABA
B
A
B
A
1-2. Child safety
Outboard rear seats
Anchor brackets Top tether strap
Rear center seat
1 Remove the head restraint.
2 Open the anchor bracket cover,
latch the hook onto the anchor bracket and tighten the top tether strap.
Make sure the top tether strap is securely latched. (P.49)
Outboard rear seats
Anchor bracket Top tether strap
Fixing the top tether strap to the
anchor bracket
Install the child restraint system in accordance to the operation manual enclosed with the child restraint sys­tem.
Hook Top tether strap
Rear center seat
Hook
Top tether strap
WARNING
NOTICE
B
Laws and regulations pertaining to
anchors
The LATCH system conforms to FMVSS225 or CMVSS210.2. Child restraint systems conforming to FMVSS213 or CMVSS213 specifications can be used. This vehicle is designed to conform to SAE J1819.
When installing a child restraint sys-
tem
Observe the following precautions. Failure to do so may result in death or serious injury.
Firmly attach the top tether strap and
make sure that the belt is not twisted.
Do not attach the top tether strap to
anything other than the anchor bracket.
1-2. Child safety
53
1
For safety and security
After securing a child restraint system,
never adjust the seat.
Follow all installation instructions pro-
vided by the child restraint system manufacturer.
Anchor brackets (for top tether
strap)
When not in use, make certain to close the lid. If it remains open, the lid may be damaged.
54
1-3.Theft deterrent system
Engine immobilizer system
1-3. Theft deterrent system
ACCESSORY or IGNITION ON mode to indicate that the system has
The vehicle’s keys have built-in tran-
been canceled.
sponder chips that prevent the engine from starting if a key has not been previously registered in the vehicle’s on-board computer.
Never leave the keys inside the vehicle when you leave the vehicle.
This system is designed to help pre­vent vehicle theft but does not guar­antee absolute security against all vehicle thefts.
Operating the system
The indicator light flashes after the engine switch has been turned off to indicate that the system is operating.
The indicator light stops flashing after the engine switch has been turned to
Certifications for the engine immobilizer system
For vehicles sold in the U.S.A., Hawaii, Guam and Puerto Rico
System maintenance
The vehicle has a maintenance-free type engine immobilizer system.
Conditions that may caus e the system to
malfunction
If the grip portion of the key is in contact
with a metallic object
If the key is in close proximity to or touch-
ing a key registered to the security sys­tem (key with a built-in transponder chip) of another vehicle
For vehicles sold in Canada
NOTICE
To ensure the system operates cor-
rectly
Do not modify or remove the system. If modified or removed, the proper opera­tion of the system cannot be guaranteed.
1-3. Theft deterrent system
55
1
For safety and security
56
1-3. Theft deterrent system
Alarm
The alarm uses light and sound to give an alert when an intrusion is detected. The alarm is triggered in the follow­ing situations when the alarm is set:
A locked door is unlocked or
opened in any way other than using the entry function, wireless remote control or mechanical key. (The doors will lock again automatically.)
A locked trunk is unlocked or
opened in any way other than using the entry function or wire­less remote control.
The hood is opened.
Setting/canceling/stopping the alarm system
Items to check before locking the
vehicle
To prevent unexpected triggering of the alarm and vehicle theft, make sure of the following:
Nobody is in the vehicle.The windows and moon roof (if
equipped) or panoramic moon roof (if equipped) are closed before the alarm is set.
set automatically after 30 seconds.
The indicator light changes from being on to flashing when the system is set.
Canceling or stopping
Do one of the following to deactivate or stop the alarm:
Unlock the doors.Turn the engine switch to ACCES-
SORY or IGNITION ON mode, or start the engine. (The alarm will be deactivated or stopped after a few seconds.)
System maintenance
The vehicle has a maintenance-free type alarm system.
Triggering of the alarm
The alarm may be triggered in the following situations: (Stopping the alarm deactivates the alarm system.)
The trunk is unlocked using the mechani-
cal key.
No valuables or other personal
items are left in the vehicle.
Setting
Close the doors, trunk and hood, and lock all the doors. The system will be
A person inside the vehicle opens a door,
the trunk or hood, or unlocks the vehicle
using a door lock switch.
NOTICE
1-3. Theft deterrent system
57
1
The battery is recharged or replaced
when the vehicle is locked. (P.376)
Alarm-operated door lock
In the following cases, depending on the sit­uation, the door may automatically lock to prevent improper entry into the vehicle:
When a person remaining in the vehicle
unlocks the door and the alarm is acti­vated.
While the alarm is activated, a person
remaining in the vehicle unlocks the door.
When recharging or replacing the bat-
tery
To ensure the system operates cor-
rectly
Do not modify or remove the system. If modified or removed, the proper opera­tion of the system cannot be guaranteed.
For safety and security
58
1-3. Theft deterrent system
59
Vehicle status information
and indicators
2-1. Instrument cluster
Warning lights and indicators. 60 Gauges and meters (except F
SPORT models) ........................ 64
Gauges and meters (F SPORT
models).......................................... 67
Multi-information display............71
Head-up display ........................... 78
Fuel consumption screen.......... 82
2
2
Vehicle status information and indicators
60
2-1.Instrument cluster
2-1. Instrument cluster
Warning lights and indicators
The warning lights and indicators on the instrument cluster, center panel and outside rear view mirrors inform the driver of the status of the vehicle’s various systems.
Warning lights and indicators displayed on the instrument cluster
Except F SPORT models
The image may differ from the actual condition.
F SPORT models
The image may differ from the actual condition.
2-1. Instrument cluster
61
Warning lights
Warning lights inform the driver of mal­functions in the indicated vehicle’s sys­tems.
Brake system warning light*1
(U.S.A.)
(Canada)
(yellow)
(U.S.A.)
(Canada)
(U.S.A.)
(P.348)
Brake system warning light*1 (P.348)
(red)
Brake system warning light*1 (P.348)
High coolant temperature warning light
Charging system warning
*2
(P.349)
light Low engine oil pressure warn-
*2
ing light
(P.349)
Malfunction indicator lamp*1 (P.349)
Malfunction indicator lamp*1 (P.349)
SRS warning light
ABS warning light*1 (P.350)
*2
(P.348)
*1
(P.349)
(yellow)
(orange)
(flashes)
(flashes)
(flashes)
(flashes)
(flashes or
illuminates)
Electric power steering system
*1
warning light
(P.350)
Low fuel level warning light (P.351)
Driver’s and front passenger’s seat belt reminder light (P.351)
Rear passengers’ seat belt reminder lights (P.351)
Tire pressure warning light*1 (P.352)
LTA indicator (P.352)
Intuitive parking assist OFF indi-
*1
(if equipped) (P.352)
cator
RCTA OFF indicator*1 (if equipped) (P.353)
RCD OFF indicator (if equipped) (P.353)
PKSB OFF indicator*1 (if equipped) (P.353)
PCS warning light*1 (P.354)
*1
Slip indicator
(P.354)
2
Vehicle status information and indicators
(Canada)
(red)
ABS warning light*1 (P.350)
Brake Override System warn­ing light/Drive-Start Control
warning light
*2
(P.350)
Electric power steering system
*1
warning light
(P.350)
(flashes)
(U.S.A.)
(flashes)
(Canada)
Parking brake indicator (P.354)
Parking brake indicator (P.354)
62
WARNING
2-1. Instrument cluster
Brake hold operated indicator*1
(flashes)
(P.355)
Master warning light
*1
(P.355)
*1
: These lights come on when the engine
switch is turned to IGNITION ON mode to indicate that a system check is being performed. They will go off after the engine is on, or after a few seconds. There may be a malfunction in a system if the lights do not come on, or go off. Have the vehicle inspected by your Lexus dealer.
*2
: This light illuminates on the multi-infor-
mation display.
If a safety system warning light does
not come on
Should a safety system light such as the ABS and SRS warning light not come on when you start the engine, this could mean that these systems are not available to help protect you in an accident, which could result in death or serious injury. Have the vehicle inspected by your Lexus dealer immediately if this occurs.
Indicators
The indicators inform the driver of the operating state of the vehicle’s various systems.
Turn signal indicator (P.145)
Headlight indicator (P.150)
(U.S.A.)
Tail light indicator (P.150)
(Canada)
(white)
(green)
(orange) (flashes)
(flashes)
Headlight high beam indicator (P.152)
Automatic High Beam indicator (P.153)
*1, 2
PCS warning light
(P.171)
Cruise control indicator (P.194)
Dynamic radar cruise control indicator (P.187)
Cruise control “SET” indicator (P.187)
LTA indicator (P.181)
LTA indicator (P.181)
LTA indicator (P.181)
BSM outside rear view mirror indicators
*1, 3
(if equipped)
(P.197, 211) BSM indicator (if equipped)
(P.197) Intuitive parking assist OFF indi-
*1, 2
cator
(if equipped)
(P.206)
*1, 2
RCTA OFF indicator
(if
equipped) (P.212)
*2
RCD OFF indicator
(if
equipped) (P.215)
*1, 2
PKSB OFF indicator
(if
equipped) (P.219)
Slip indicator*1 (P.237)
*1, 2
VSC OFF indicator (P.237)
2-1. Instrument cluster
63
Smart access system with push­button start indicator (P.137)
Parking brake indicator
(U.S.A.)
(P.146)
Parking brake indicator
(Canada)
(P.146)
Brake hold standby indicator (P.148)
Brake hold operated indicator (P.148)
Eco Driving Indicator Light (P.74) Low outside temperature indi-
*4
(P.64, 67)
cator Security indicator
56)
“AIR BAG ON/OFF” indica-
*1, 5
(P.37)
tor
(U.S.A.)
“AIR BAG ON/OFF” indica-
*1, 5
(P.37)
tor
(Canada)
Drive mode indicators
Except F SPORT models
Eco drive mode indicator (P.202)
Sport mode indicator (P.202)
*5
(P.54,
F SPORT models
Custom mode indicator (P.202)
Eco drive mode indicator (P.202)
*1
*1
*1
*1
: These lights come on when the engine
Sport S mode indicator (P.202)
Sport S+ mode indicator (P.202)
2
Vehicle status information and indicators
switch is turned to IGNITION ON mode to indicate that a system check is being performed. They will go off after the engine is on, or after a few seconds. There may be a malfunction in a system if the lights do not come on, or go off. Have the vehicle inspected by your Lexus dealer.
*2
: This light comes on when the system is
turned off.
*3
: This light illuminates on the outside rear
view mirrors.
*4
: When the outside temperature is
approximately 37°F (3°C) or lower, this indicator will flash for approximately 10 seconds, then stay on.
*5
: This light illuminates on the center
panel.
64
A
B
C
D
E
F
G
2-1. Instrument cluster
Gauges and meters (except F SPORT models)
Meter display
Locations of gauges and meters
The units of measure may differ depending on the intended destination of the vehicle.
Multi-information display
Presents the driver with a variety of vehicle data (P.71) Displays warning messages if a malfunction occurs (P.358)
Outside temperature
Displays the outside temperature within the range of -40°F (-40°C) to 122°F (50°C) Low outside temperature indicator comes on when the ambient temperature is 37°F (3°C)
or lower
Tachometer
Displays the engine speed in revolutions per minute When sport mode is selected for the driving mode, the periphery of the tachometer will change color and the scale of the tachometer will be emphasized.
Speedometer Clock
Time displayed is linked to the analog clock on the center panel. (P.269)
Engine coolant temperature gauge
Displays the engine coolant temperature
Fuel gauge
Displays the quantity of fuel remaining in the tank
Shift position and shift range (P.141)
H
I
WARNING
NOTICE
Odometer and trip meter display (P.65)
Outside temperature display
In the following situations, the correct
outside temperature may not be dis­played, or the display may take longer than normal to change:
• When stopped, or driving at low speeds (less than 12 mph [20 km/h])
• When the outside temperature has changed suddenly (at the entrance/exit of a garage, tunnel, etc.)
When “--” or “E” is displayed, the system
may be malfunctioning. Take your vehicle to your Lexus dealer.
Liquid crystal display
P.72
Customization
The gauges and meters can be customized on of the multi-information display.
(P.76)
The information display at low tem-
peratures
Allow the interior of the vehicle to warm up before using the liquid crystal infor­mation display. At extremely low tem­peratures, the information display monitor may respond slowly, and display changes may be delayed.
For example, there is a lag between the driver’s shifting and the new gear number appearing on the display. This lag could cause the driver to downshift again, causing rapid and excessive engine brak­ing and possibly an accident resulting in death or injury.
2-1. Instrument cluster
To prevent damage to the engine and
its components
Do not let the indicator needle of the
tachometer enter the red zone, which indicates the maximum engine speed.
The engine may be overheating if the
engine coolant temperature gauge is in the red zone (H). In this case, imme­diately stop the vehicle in a safe place, and check the engine after it has cooled completely. (P.377)
Odometer and trip meter dis­play
Display items
Odometer
Displays the total distance the vehicle has been driven.
Trip meter A/trip meter B
Displays the distance the vehicle has been driven since the meter was last reset. Trip meters A and B can be used to record and display different distances independently.
Distance until next engine oil
change
Displays the distance the vehicle can be driven until an oil change is necessary.
Changing the display
Each time the “ODO TRIP” switch is pressed, the displayed item will be changed. When the trip meter is dis­played, pressing and holding the switch will reset the trip meter.
65
2
Vehicle status information and indicators
66
Pop-up display
2-1. Instrument cluster
Distance until the next engine oil change will displayed when a warning message indicating that oil mainte­nance should be performed soon or is required is displayed.
Changing the instrument panel light brightness
The brightness of the instrument panel lights can be adjusted.
rounding area is bright
Night mode: When the tail lights are on
and the surrounding area is dark
1 Darker 2 Brighter
Brightness of the meter lights (day mode
and night mode)
The brightness of the meter lights can be adjusted individually.
In the following situations, the meters changes between day mode and night mode.
Day mode: When the tail lights are off or
when the tail lights are on but the sur-
2-1. Instrument cluster
A
B
C
D
E
F
Gauges and meters (F SPORT models)
Meter display
Locations of gauges and meters
When the main meter is moved to the right, some of the meter displays and the gauge layout will change. (P.71)
Main meter in center position
67
2
Vehicle status information and indicators
The units of measure may differ depending on the intended destination of the vehicle.
Odometer and trip meter display (P.70) Engine coolant temperature gauge
Displays the engine coolant temperature
Outside temperature
Displays the outside temperature within the range of -40°F (-40°C) to 122°F (50°C) Low outside temperature indicator comes on when the ambient temperature is 37°F (3°C)
or lower
Tachometer
Displays the engine speed in revolutions per minute When sport mode is selected for the driving mode, the periphery of the tachometer will change color and the scale of the tachometer will be emphasized.
• Rev indicator (P.69)
•Rev peak (P.69)
Speedometer Shift position/shift range/gear position (P.141)
68
G
H
I
A
B
C
D
E
F
2-1. Instrument cluster
Clock
Time displayed is linked to the analog clock on the center panel. (P.269)
Fuel gauge
Displays the quantity of fuel remaining in the tank
Multi-information display
Presents the driver with a variety of vehicle data (P.71) Displays warning messages if a malfunction occurs (P.358)
Main meter moved to the right
The units of measure may differ depending on the intended destination of the vehicle.
Outside temperature
Displays the outside temperature within the range of -40°F (-40°C) to 122°F (50°C) Low outside temperature indicator comes on when the ambient temperature is 37°F (3°C)
or lower
Clock
Time displayed is linked to the analog clock on the center panel. (P.269)
Tachometer
Displays the engine speed in revolutions per minute When sport mode is selected for the driving mode, the periphery of the tachometer will change color and the scale of the tachometer will be emphasized.
• Rev indicator (P.69)
•Rev peak (P.69)
Speedometer Shift position and shift range (P.141) Odometer and trip meter display (P.70)
2-1. Instrument cluster
G
H
I
A
Fuel gauge
Displays the quantity of fuel remaining in the tank
Engine coolant temperature gauge
Displays the engine coolant temperature
Multi-information display
Presents the driver with a variety of vehicle data (P.71) Displays warning messages if a malfunction occurs (P.358)
Rev indicator
When the engine speed reaches a set speed or the red zone, a ring-shaped
indicator ( ) will be displayed on the tachometer.
The indicators will be displayed in amber when the engine speed reaches a set speed, and in red when the engine speed reaches the red zone.
The engine speed at which the rev indica­tor will begin to be displayed can be set on
of the multi-information display.
(P.76)
Rev peak
When the engine speed reaches or exceeds 5000 rpm, an afterimage of
Outside temperature display
In the following situations, the correct
outside temperature may not be dis­played, or the display may take longer than normal to change:
• When stopped, or driving at low speeds (less than 12 mph [20 km/h])
• When the outside temperature has changed suddenly (at the entrance/exit of a garage, tunnel, etc.)
When “--” or “E” is displayed, the system
may be malfunctioning. Take your vehicle to your Lexus dealer.
Liquid crystal display
P.72
Customization
The gauges and meters can be customized on of the multi-information display.
(P.76)
the tachometer will be displayed at the highest engine speed for approxi­mately 1 second.
69
2
Vehicle status information and indicators
70
WARNING
NOTICE
The information display at low tem-
Allow the interior of the vehicle to warm up before using the liquid crystal infor­mation display. At extremely low tem­peratures, the information display monitor may respond slowly, and display changes may be delayed.
For example, there is a lag between the driver’s shifting and the new gear number appearing on the display. This lag could cause the driver to downshift again, causing rapid and excessive engine brak­ing and possibly an accident resulting in death or injury.
To prevent damage to the engine and
Do not let the indicator needle of the
The engine may be overheating if the
2-1. Instrument cluster
peratures
its components
tachometer enter the red zone, which indicates the maximum engine speed.
engine coolant temperature gauge is in the red zone (H). In this case, imme­diately stop the vehicle in a safe place, and check the engine after it has cooled completely. (P.377)
change
Displays the distance the vehicle can be driven until an oil change is necessary.
Changing the display
Each time the “ODO TRIP” switch is pressed, the displayed item will be changed. When the trip meter is dis­played, pressing and holding the switch will reset the trip meter.
Pop-up display
The distance until the next engine oil change will displayed when a warning message indicating that oil mainte­nance should be performed soon or is required is displayed.
Odometer and trip meter dis­play
Display items
Odometer
Displays the total distance the vehicle has been driven.
Trip meter A/trip meter B
Displays the distance the vehicle has been driven since the meter was last reset. Trip meters A and B can be used to record and display different distances independently.
Distance until next engine oil
Changing the instrument panel light brightness
The brightness of the instrument panel lights can be adjusted.
2-1. Instrument cluster
71
1 Darker 2 Brighter
Brightness of the meter lights (day mode
and night mode)
The brightness of the meter lights can be adjusted individually.
In the following situations, the meters changes between day mode and night mode.
Day mode: When the tail lights are off or
when the tail lights are on but the sur­rounding area is bright
Night mode: When the tail lights are on
and the surrounding area is dark
Changing the main meter loca­tion
The display can be switched between the center and side positions.
Multi-information display
Display and menu icons
Display (except F SPORT models)
By selecting menu icons on the multi­information display, a variety of driving­related information can be displayed. The multi-information display can also be used to change display settings and other vehicle settings.
Warning or suggestion/advice pop-up displays are also displayed in certain situations.
2
Vehicle status information and indicators
Display (F SPORT models)
Main meter in center position
The multi-information display presents the driver with a variety of driving­related information.
Warning or suggestion/advice pop-up displays are also displayed in certain situations.
72
WARNING
2-1. Instrument cluster
Audio system-linked display (P.75)
Driving support system infor­mation display (P.76)
Warning message display (P.358)
Settings display (P.76)
Main meter moved to the right
By selecting menu icons on the multi­information display, a variety of driving­related information can be displayed. The multi-information display can also be used to change display settings and other vehicle settings.
Warning or suggestion/advice pop-up displays are also displayed in certain situations.
Menu icons
The menu icons will be displayed by pressing or of the meter con-
trol switches.
F SPORT models: The menu icons can be displayed when the main meter is moved to the right.
Liquid crystal display
Small spots or light spots may appear on the display. This phenomenon is characteristic of liquid crystal displays, and there is no problem continuing to use the display.
Caution for use while driving
When operating the multi-information
display while driving, pay extra atten­tion to the safety of the area around the vehicle.
Do not look continuously at the multi-
information display while driving as you may fail to see pedestrians, objects on the road, etc. ahead of the vehicle.
The information display at low tem-
peratures
P.65, 70
Changing the meter display
The multi-information display is oper­ated using the meter control switches.
Driving information display (P.73)
Navigation system-linked dis­play (if equipped) (P.75)
2-1. Instrument cluster
A
B
C
73
/ : Select menu icons
/ : Change displayed con­tent, scroll up/down the screen and move the cursor up/down
Press: Enter/Set Press and hold: Reset
Move the main meter
*
and return
to the previous screen
*
:F SPORT models
Content of driving information
Display items (except F SPORT
models)
Press or of the meter control switches and select . Then press or to display the following items:
Drive information 1Drive information 2Eco Driving IndicatorTire pressure (P.319)Display off
Display items (F SPORT models)
Main meter in center position
Press or of the meter control switches to display the following items:
Drive information 1Drive information 2Gear positionTire pressure (P.319)UnitsDisplay off
Main meter moved to the right
Press or of the meter control switches and select . Then press or to display the following items:
Drive information 1Drive information 2Eco Driving IndicatorG-forceGear PositionTire pressure (P.319)Display off
Drive information 1/Drive infor-
mation 2
Displays drive information such as the following:
Use the displayed values as a reference only.
Drive information 1
• Current fuel consumption
• Average fuel economy (after reset)
Drive information 2
• Distance (driving range)
• Average vehicle speed (after reset)
Displayed items (listed below) can be changed on . (P.76) Current fuel consumption
Bar type: Displays instantaneous current fuel consumption
Average fuel economy
After reset: Displays average fuel con­sumption since the display was reset
After start: Displays average fuel con­sumption since engine start
*1
2
Vehicle status information and indicators
74
A
B
C
D
2-1. Instrument cluster
After refuel: Displays average fuel con­sumption since refuel
Average vehicle speed
After reset: Displays average vehicle speed since the display was reset
After start: Displays average vehicle speed since engine start
*1
Elapsed time
After reset: Displays elapsed time since the display was reset
After start: Displays elapsed time since engine start
*1
Distance
Driving range: Displays driving range with remaining fuel
After start: Displays the distance driven since engine start
*2, 3
Other
Blank: No item
*1
: To reset, display the desired item and
press and hold “OK” of the meter con­trol switches.
*2
: This distance is computed based on
your average fuel consumption. As a result, the actual distance that can be driven may differ from that displayed.
*3
: When only a small amount of fuel is
added to the tank, the display may not be updated. When refueling, turn the engine switch off. If the vehicle is refueled without turning the engine switch off, the display may not be updated.
Eco Driving Indicator
Eco Driving Indicator Light
During Eco-friendly acceleration (Eco driving), the Eco Driving Indicator Light will turn on. When the acceleration exceeds the Zone of Eco driving, or when the vehicle is stopped, the light turns off.
Eco Driving Indicator Zone Display
Suggests the Zone of Eco driving with cur­rent Eco driving ratio based on accelera­tion.
Eco driving ratio based on acceler­ation
If the acceleration exceeds the Zone of Eco driving, the right side of the Eco Driv­ing Indicator Zone Display will illuminate.
At this time, the Eco Driving Indicator Light will turn off.
Zone of Eco driving
Boost gauge
Displays the boost pressure. The dis­play will change color if the specified pressure is exceeded.
This display is intended for use as a guide­line. Depending on factors such as the road surface condition, temperature and vehicle
2-1. Instrument cluster
ABC
75
speed, the display may not show the actual condition of the vehicle.
G-force (F SPORT models)
Displays lateral G-forces on the vehi­cle.
Acceleration G-force on the vehi­cle
Current G-force value (analyzed value of front/rear and left/right G­forces)
Record of the maximum G-forces
This display is intended for use as a guide­line. Depending on factors such as the road surface condition, temperature and vehicle speed, the display may not show the actual condition of the vehicle.
Resetting the record of maximum
G-forces
Press and hold “OK” of the meter control switches to reset the record.
Peak hold function
If lateral G-forces of 0.5 G or greater are generated, the G-force value display will turn amber and be held for 2 seconds.
Gear Position (F SPORT models)
Displays the current shift range or gear position when the shift lever is in D or S.
Units (F SPORT models)
The units of measure used can be changed while driving.
Unlike the units setting performed on the settings display, the units setting per­formed on the drive information display can be changed while driving.
Eco Driving Indicator
Eco Driving Indicator will not operate under the following conditions:
The shift lever is in any position other than
D.
A paddle shift switch is operated.
The driving mode is set to other than nor-
mal mode or eco drive mode.
The vehicle speed is approximately 80
mph (130 km/h) or higher.
Navigation system-linked dis­play (if equipped)
Select to display the following naviga­tion system-linked information.
Route guidance to destinationCompass display (heading-up dis-
play)
Route guidance to destination display
When the route guidance to destination display is enabled on the head-up display, it will not be displayed on the multi-informa­tion display. (P.79)
Audio system-linked display
Select to enable selection of an audio source or track on the meter using the meter control switches.
2
Vehicle status information and indicators
76
WARNING
2-1. Instrument cluster
Driving support system informa­tion display
Select to display the operational status of the following systems:
LTA (Lane Tracing Assist) (P.176)Dynamic radar cruise control with
full-speed range (P.187)
RSA (Road Sign Assist) (if
equipped) (P.185)
Settings display
Meter display settings that can be
changed
Language
Select to change the language displayed.
Units
Select to change the units of measure dis­played.
Speedometer display (except F
SPORT models)
Select to set the display of the speedome­ter to digital/analog/both digital and ana­log.
Drive information 1/Drive informa-
tion 2
Select to select up to 2 items (P.73) that will be displayed on each Drive information screen (Drive information 1 screen and Drive information 2 screen) respectively.
Clock
Select to switch between 12-hour display and 24-hour display.
Pop-up display
Select to enable/disable pop-up displays for each relevant system.
Accent color
Select to change the accent color on the screen, such as the cursor color.
Rev indicator (F SPORT models)
• Select to enable/disable the rev indica­tor.
• Select to set the engine speed at which the rev indicator (amber) will begin to be displayed.
Rev peak (F SPORT models)
Select to enable/disable the rev peak.
Eco Driving Indicator Light
Select to enable/disable the Eco Driving Indicator Light.
Default setting
Select to reset the meter display settings to the default setting.
Vehicle functions and settings that
can be changed
P.400
Suspension of the settings display
Some settings cannot be changed while
driving. When changing settings, park the vehicle in a safe place.
If a warning message is displayed, opera-
tion of the settings display will be sus­pended.
Cautions during setting up the dis-
play
As the engine needs to be running during setting up the display, ensure that the vehicle is parked in a place with ade­quate ventilation. In a closed area such as a garage, exhaust gases including harm­ful carbon monoxide (CO) may collect and enter the vehicle. This may lead to death or a serious health hazard.
NOTICE
During setting up the display
To prevent battery discharge, ensure that the engine is running while setting up the display features.
Suggestion function
Displays suggestions to the driver in the following situations. To select a response to a displayed suggestion, use the meter control switches.
Suggestion to turn off the head-
lights
If the headlights are left on for a certain amount of time with the headlight
switch in after the engine switch has been turned off, a suggestion mes-
sage will be displayed asking if you wish to turn the headlights off.
2-1. Instrument cluster
77
2
Vehicle status information and indicators
To turn the headlights off, select “Yes”.
If a front door is opened after the engine switch is turned off, this suggestion mes­sage will not be displayed.
Customization
Some functions can be customized. (P.400)
78
A
B
C
2-1. Instrument cluster
Head-up display
*
:If equipped
*
The head-up display projects a variety of driving-related information and the operating state of the driving support systems on the windshield.
System components
Illustrations used in this text are intended as examples, and may differ from the image that is actually displayed by the head-up display.
Driving support system display area (P.80) Navigation system-linked display area (if equipped)
Displays the following items which are linked to the navigation system:
• Route guidance to destination
•Street name
• Compass (heading-up display)
Driving information display area
Displays the following items:
• Speed limit of the current road (linked to the navigation system) (U.S.A. only)
• RSA (Road Sign Assist) display (if equipped) (P.185)
• Speedometer
• Shift position and shift range (P.141)
Tachometer/Eco Driving Indicator display area (P.81)
Head-up display switch
D
WARNING
NOTICE
2-1. Instrument cluster
79
Head-up display will operate when
The engine switch is in IGNITION ON mode.
When using the head-up display
The head-up display may seem dark or hard to see when viewed through sunglasses, especially polarized sunglasses. Adjust the brightness of the head-up display or remove your sunglasses.
Street name display
Only street names which are included in the map data will be displayed.
When using the head-up display
Check that the position and brightness
of the head-up display image does not interfere with safe driving. Incorrect adjustment of the image’s position or brightness may obstruct the driver’s view and lead to an accident, resulting in death or serious injury.
Do not continuously look at the head-
up display while driving as you may fail to see pedestrians, objects on the road, etc. ahead of the vehicle.
Do not place anything on or put stick-
ers onto the head-up display projector. Doing so could interrupt head-up dis­play indications.
Do not touch the inside of the head-up
display projector or thrust sharp edges or the like into the projector. Doing so could cause mechanical mal­functions.
Using the head-up display
Enabling/disabling the head-up dis-
play
Press the Head-up display switch.
Changing settings of the head-up
display
2
Vehicle status information and indicators
Head-up display projector
Do not place any drinks near the head-
up display projector. If the projector gets wet, electrical malfunctions may result.
The following settings can be changed on of the multi-information display.
(P.400) Brightness and vertical position of
the head-up display
Select to adjust the brightness or vertical position of the head-up display.
Tachometer/Eco Driving Indicator
Select to display the tachometer, Eco Driv­ing Indicator or no content.
Display content
Select to enable/disable the following
80
WARNING
NOTICE
items:
• Route guidance to destination/street name
• Driving support system display
• Compass (heading-up display)
• Audio system operation status
*
: Make sure to enable this display when
using the driving support systems
2-1. Instrument cluster
*
Display angle
Select to adjust the angle of the head-up display.
Caution for changing settings of the
head-up display
As the engine needs to be running while changing the settings of the head-up dis­play , ens ure t hat t he ve hicl e is p arke d in a place with adequate ventilation. In a closed area such as a garage, exhaust gases including harmful carbon monox­ide (CO) may collect and enter the vehi­cle. This may lead to death or a serious health hazard.
Enabling/disabling of the head-up dis-
play
If the head-up display is disabled, it will remain disabled when the engine switch is turned off then back to IGNITION ON mode.
Display brightness
The brightness of the head-up display can be adjusted on of the multi-information
display. Also, it is automatically adjusted according to the ambient brightness.
Head-up display automatic position
adjustment
If the display position is recorded into mem­ory, the head-up display will be automati­cally adjusted to the desired position. (P.108)
When the battery is disconnected
The customize settings of the head-up dis­play will be reset.
When changing the settings of the
head-up display
To prevent battery discharge, ensure that the engine is running while the changing the settings of the head-up display.
Driving support system display area
Displays the operational status of the following systems:
LTA (Lane Tracing Assist) (P.176)Dynamic radar cruise control with
full-speed range (P.187)
Details of content displayed on the head­up display may differ from that displayed on the multi-information display. For details, refer to the explanation of each sys­tem.
Pop-up display
Pop-up displays for the following sys­tems will be displayed when necessary.
Driving support systems
Displays a warning/suggestion/advice message or the operating state of a rel-
2-1. Instrument cluster
A
B
C
81
evant system. PCS (Pre-Collision System)
(P.169)
Intuitive parking assist (if equipped)
(P.205)
Parking Support Brake function
(static objects) (if equipped) (P.224)
Brake Override System (P.128)Drive-Start Control (P.129)
Details of content displayed on the head­up display may differ from that displayed on the multi-information display. For details, refer to the explanation of each sys­tem.
/ icons
These icons are linked to the multi­information display
: Master warning icon
Displayed when a warning message is dis­played on the multi-information display. (P.358)
operated.
Hands-free system status
Displayed when the hands-free system is operated.
When a pop-up display is displayed
When a pop-up display is displayed, a cur­rent display may no longer be displayed. In this case, the display will return after the pop-up display disappears.
Tachometer/Eco Driving Indica­tor display area
Tachometer
Displays the engine speed in revolu­tions per minute.
Eco Driving Indicator
2
Vehicle status information and indicators
: Information icon
Displayed when a suggestion pop-up dis­play (P.77) or advice pop-up display is displayed on the multi-information display.
Warning message
Some warning messages are displayed when necessary, according to certain conditions.
Details of content displayed on the head­up display may differ from that displayed on the multi-information display.
Audio system operation status
Displayed when an audio remote con­trol switch on the steering wheel is
Eco Driving Indicator Zone Display Eco driving ratio based on acceler-
ation Zone of Eco driving
Displayed content is the same as that dis­played on the multi-information display (Eco Driving Indicator). For details, refer to P.74.
82
A
B
C
D
E
A
B
C
D
E
F
2-1. Instrument cluster
Fuel consumption screen
You can view the status of your fuel consumption information on the multi-information display and Cen­ter Display.
12.3-inch display model: The con­sumption screen can be displayed on the side display.
System components
Remote Touch, then select on the screen, and then select “Trip Informa­tion” or “History”.
Trip information
If a screen other than “Trip Information” is displayed, select “Trip Information”.
Resetting the consumption data Fuel consumption in the past 15
minutes Current fuel consumption Average vehicle speed since the
engine was started.
Multi-information display Center Display Meter control switches “MENU” button Touchpad
Consumption
Press the “MENU” button on the
Elapsed time since the engine was started.
Cruising range
Average fuel consumption for the past 15 minutes is divided by color into past aver­ages and averages attained since the engine switch was last turned to IGNI­TION ON mode. Use the displayed aver­age fuel consumption as a reference.
The image is an example only, and may vary slightly from actual conditions.
History
If a screen other than “History” is dis­played, select “History”.
Best recorded fuel consumption
A
B
C
D
E
Latest fuel consumption Previous fuel consumption record Resetting the history data Updating the latest fuel consump-
tion data
The average fuel consumption history is divided by color into past averages and the average fuel consumption since the last updated. Use the displayed average fuel consumption as a reference.
The image is an example only, and may vary slightly from actual conditions.
Updating the history data
Update the latest fuel consumption by selecting “Clip” to measure the current fuel consumption again.
Resetting the data
The fuel consumption data can be deleted by selecting “Clear”.
Cruising range
Displays the estimated maximum distance that can be driven with the quantity of fuel remaining.
This distance is computed based on your average fuel consumption. As a result, the actual distance that can be driven may differ from that displayed.
2-1. Instrument cluster
Using the side display (12.3-inch display model)
Display the vehicle information on the side display (P.247), and then select
or to display the desired
screen.
Trip information (type A)
Displays the average fuel consumption for the past 10 minutes in 1 minute intervals, as well as the cruising range.
The image is an example only, and may vary slightly from actual conditions.
Use the displayed average fuel consump­tion as a reference.
Trip information (type B)
Displays the cruising range, latest fuel consumption and the amount of time elapsed since the engine was started.
83
2
Vehicle status information and indicators
The image is an example only, and may vary slightly from actual conditions.
84
Use the displayed average fuel consump­tion as a reference.
History
2-1. Instrument cluster
Displays the average fuel consumption and highest fuel consumption.
The image is an example only, and may vary slightly from actual conditions.
Use the displayed average fuel consump­tion as a reference.
85
Before driving
3-1. Key information
Keys ................................................... 86
3-2. Opening, closing and locking the
doors and trunk
Doors................................................. 89
Trunk.................................................. 93
Smart access system with push-
button start.................................100
3-3. Adjusting the seats
Front seats.....................................107
Driving position memory ........108
Head restraints.............................. 111
3-4. Adjusting the steering wheel and
mirrors
Steering wheel.............................. 113
Inside rear view mirror.............. 114
Outside rear view mirrors....... 115
3-5. Opening and closing the win-
dows and moon roof
Power windows............................ 118
Moon roof .....................................120
Panoramic moon roof ..............123
3
3
Before driving
86
A
B
C
3-1.Key information
3-1. Key information
Keys
Key types
The following keys are provided with the vehicle.
Electronic keys
• Operating the smart access system with push-button start (P.100)
• Operating the wireless remote control function
Mechanical keys Key number plate
When riding in an aircraft
When bringing an electronic key onto an aircraft, make sure you do not press any buttons on the electronic key while inside the aircraft cabin. If you are carrying an electronic key in your bag etc., ensure that the buttons are not likely to be pressed acci­dentally. Pressing a button may cause the electronic key to emit radio waves that could interfere with the operation of the air­craft.
Electronic key battery depletion
The standard battery life is 1 to 2 years.
If the battery becomes low, an alarm will
sound in the cabin when the engine is stopped.
Battery-saving mode can reduce the
power consumption of electronic keys that are not used for long periods of time. (P.101)
As the electronic key always receives
radio waves, the battery will become depleted even if the electronic key is not used. The following symptoms indicate that the electronic key battery may be depleted. Replace the battery when nec­essary. (P.330)
• The smart access system with push-but­ton start or the wireless remote control does not operate.
• The detection area becomes smaller.
• The LED indicator on the key surface does not turn on.
You can replace the battery by yourself (P.330). However, as there is a danger that the electronic key may be damaged, it is recommended that replacement be car­ried out by your Lexus dealer.
To avoid serious deterioration, do not
leave the electronic key within 3 ft. (1 m) of the following electrical appliances that produce a magnetic field:
•TVs
• Personal computers
• Cellular phones, cordless phones and battery chargers
• Recharging cellular phones or cordless phones
•Table lamps
• Induction cookers
Replacing the battery
P.330
Confirmation of the registered key
number
The number of keys already registered to the vehicle can be confirmed. Ask your Lexus dealer for details.
If “A New Key has been Registered
Contact Your Dealer for Details” is shown on the multi-information display
This message will be displayed each time the driver’s door is opened when the doors are unlocked from the outside for approxi­mately 10 days after a new electronic key has been registered. If this message is displayed but you have not had a new electronic key registered, ask your Lexus dealer to check if an unknown electronic key (other than those in your
3-1. Key information
NOTICE
A
B
C
D
E
87
possession) has been registered.
To prevent key damage
Do not drop the keys, subject them to
strong shocks or bend them.
Do not expose the keys to high tem-
peratures for long periods of time.
Do not get the keys wet or wash them
in an ultrasonic washer etc.
Do not attach metallic or magnetic
materials to the keys or place the keys close to such materials.
Do not disassemble the keys.
Do not attach a sticker or anything else
to the surface of the electronic key.
Do not place the keys near objects that
produce magnetic fields, such as TVs, audio systems and induction cookers.
Do not place the keys near medical
electrical equipment such as low-fre­quency therapy equipment or micro­wave therapy equipment, and do not receive medical attention with the keys on your person.
Wireless remote control
The electronic keys are equipped with the following wireless remote control:
Locks the doors (P.89) Unlocks the doors (P.89) Opens the windows and moon roof
(if equipped) or panoramic moon roof (if equipped)
Opens the trunk (P.95) Sounds the alarm (P.87)
*
: This setting must be customized at your
Lexus dealer.
*
(P.89)
3
Before driving
Carrying the electronic key on your
person
Carry the electronic key 3.9 in. (10 cm) or more away from electric appliances that are turned on. Radio waves emitted from electric appliances within 3.9 in. (10 cm) of the electronic key may interfere with the key, causing the key to not func­tion properly.
In case of a smart access system with
push-button start malfunction or other key-related problems
P.372
When an electronic key is lost
P.371
Theft deterrent panic mode
When is pressed for longer than about one second, an alarm will sound intermittently and the vehicle lights will flash to deter any person from trying to break into or damage your vehicle.
To stop the alarm, press any button on the electronic key.
88
3-1. Key information
Using the mechanical key
To take out the mechanical key, push the release button and take the key out.
The mechanical key can only be inserted in one direction, as the key only has grooves on one side. If the key cannot be inserted in a lock cylinder, turn it over and re-attempt to insert it.
After using the mechanical key, store it in the electronic key. Carry the mechanical key together with the electronic key. If the electronic key battery is depleted or the entry function does not operate properly, you will need the mechanical key. (P.372)
When required to leave the vehicle’s
key with a parking attendant
Turn the trunk opener main switch off (P.99), lock the glove box (P.266) and armrest door (P.279) as circumstances demand. Remove the mechanical key for your own use and provide the attendant with the elec­tronic key only.
If you lose your mechanical keys
P.371
3-2. Opening, closing and locking the doors and trunk
3-2.Opening, closing and locking the doors an d trunk
Doors
Unlocking and locking the doors from the outside
Smart access system with push-
button start
Carry the electronic key to enable this function.
1 Grip the driver’s door handle to
unlock the door. Holding the driver’s door handle for approxi­mately 2 seconds unlocks all the doors. Grip the passenger’s door
handle to unlock all the doors.
Make sure to touch the sensor on the back of the handle.
The doors cannot be unlocked for 3 sec­onds after the doors are locked.
*
: The door unlock settings can be
changed.
2 Touch the lock sensor (the indenta-
tion on the upper part of the door handle) to lock all the doors.
Check that the door is securely locked.
*
89
Wireless remote control
1 Locks all the doors
Check that the door is securely locked.
2 Unlocks all the doors
Pressing the button unlocks the driver’s door. Pressing the button again within 5 seconds unlocks the other doors.
Press and hold to open the windows and moon roof (if equipped) or panoramic
moon roof (if equipped).
*
: This setting must be customized at your
Lexus dealer.
Switching the door unlock function
It is possible to set which doors the entry function unlocks using the wireless remote control.
1 Turn the engine switch off. 2 When the indicator light on the key sur-
face is not on, press and hold ,
or for approximately 5
seconds while pressing and holding
.
The setting changes each time an operation is performed, as shown below. (When changing the setting continuously, release the buttons, wait for at least 5 seconds, and repeat step 2.)
*
3
Before driving
90
3-2. Opening, closing and locking the doors and trunk
Multi-information
display/Beep
Unlocking function
Holding the driver’s door handle unlocks only the driver’s door.
Exterior: Beeps 3
times
Interior: Pings
once
Exterior: Beeps
twice
Holding a passenger’s door handle unlocks all the doors.
Holding a door handle unlocks all the doors.
Interior: Pings
once
To prevent unintended triggering of the alarm, unlock the doors using the wireless remote control and open and close a door once after the settings have been changed. (If a door is not opened within 60 seconds
after is pressed, the doors will be locked again and the alarm will automati­cally be set.) In a case that the alarm is triggered, imme­diately stop the alarm. (P.56)
Impact detection door lock release sys-
tem
In the event that the vehicle is subject to a strong impact, all the doors are unlocked. Depending on the force of the impact or the type of accident, however, the system may not operate.
Operation signals
A buzzer sounds and the emergency flash­ers flash to indicate that the doors have been locked/unlocked. (Locked: once; Unlocked: twice)
Windows and moon roof (if equipped) or panoramic moon roof (if equipped): A buzzer sounds to indicate that the windows and moon roof or panoramic moon roof are opening.
Security feature
If a door is not opened within approximately 60 seconds after the vehicle is unlocked, the security feature automatically locks the vehicle again. (However, depending on the location of the electronic key, the key may be detected as being in the vehicle. In this case, vehicle may be unlocked.)
When the doors cannot be locked by the
lock sensor on the upper part of the door handle
When the doors cannot be locked even if the lock sensor on the surface of the door handle is touched by a finger, touch the lock sensor with the palm.
If you are wearing gloves, remove them.
Open door warning buzzer
If an attempt to lock the doors is made when a door is not fully closed, a buzzer sounds continuously for 5 seconds. Fully close the door to stop the buzzer, and lock the vehi­cle once more.
Setting the alarm
Locking the doors will set the alarm system. (P.56)
Conditions affecting the operation of
the smart access system with push-but­ton start or wireless remote control
P.101
If the smart access system with push-
button start or the wireless remote con­trol does not operate properly
Use the mechanical key to lock and unlock the doors. (P.372) Replace the key battery with a new one if it is depleted. (P.330)
If the battery is discharged
The doors cannot be locked and unlocked using the smart access system with push-
3-2. Opening, closing and locking the doors and trunk
WARNING
91
button start or wireless remote control. Lock or unlock the doors using the mechanical key. (P.372)
Customization
Settings (e.g. unlocking function using a key) can be changed. (Customizable features: P.400)
To prevent an accident
Observe the following precautions while driving the vehicle. Failure to do so may result in a door opening and an occupant being thrown out of the vehicle, resulting in death or serious injury.
Ensure that all doors are properly
closed and locked.
Do not pull the inside handle of the
doors while driving. Be especially careful for the front doors, as the doors may be opened even if the inside lock buttons are in locked position.
Set the rear door child-protector locks
when children are seated in the rear seats.
Unlocking and locking the doors from the inside
Door lock switches (to
lock/unlock)
1 Locks all the doors 2 Unlocks all the doors
Inside lock buttons (to lock)
Push down the inside lock button to lock the door.
3
Before driving
When opening or closing a door
Check the surroundings of the vehicle such as whether the vehicle is on an incline, whether there is enough space for a door to open and whether a strong wind is blowing. When opening or clos­ing the door, hold the door handle tightly to prepare for any unpredictable move­ment.
Inside door handles (to unlock)
For the front doors
Pull the handle to unlock and open the door.
When the door is unlocked, the inside lock button will pop up.
For the rear doors
Pull the handle to unlock the door. Pull the handle a second time to open the door.
92
3-2. Opening, closing and locking the doors and trunk
When the door is unlocked, the inside lock button will pop up.
Locking the front doors from the outside
without a key
1 Push down the inside lock button. 2 Close the door.
The door cannot be locked if the engine switch is in ACCESSORY or IGNITION ON mode, or the electronic key is left inside the vehicle. However, the key may not be detected correctly and the door may be locked.
Open door warning buzzer
The hood, one or all of the doors, or trunk is not fully closed. If the vehicle reaches a speed of 3 mph (5 km/h), the master warn­ing light flashes and a buzzer sounds to indi­cate that the door(s) are not fully closed. Make sure to close hood, all doors and trunk.
Rear door child-protector lock
The door cannot be opened from inside the vehicle when the lock is set.
2 Lock
These locks can be set to prevent chil­dren from opening the rear doors. Push down on each rear door switch to lock both rear doors.
Automatic door locking and unlocking systems
The following functions can be set or canceled:
For instructions on customizing, refer to P.400.
Function Operation
All doors are automati­Speed linked door locking function
Shift position linked door lock­ing function
Shift position linked door unlocking func­tion
Driver’s door linked door unlocking func­tion
cally locked when vehi-
cle speed is
approximately 12 mph
(20 km/h) or higher.
All doors are automati-
cally locked when the
shift lever is shifted to a
position other than P.
All doors are automati-
cally unlocked when
the shift lever is shifted
to P.
All doors are automati-
cally unlocked when
driver’s door is opened
within approximately
45 seconds after turn-
ing the engine switch
off.
1 Unlock
3-2. Opening, closing and locking the doors and trunk
WARNING
93
Trunk
The trunk can be opened using the trunk opener switch, entry function or wireless remote control.
If the vehicle is equipped with a power trunk lid, the trunk can be closed using the trunk closer.
Observe the following precautions. Failure to do so may result in death or serious injury.
Before driving
Make sure that the trunk lid is fully
closed. If the trunk lid is not fully closed, it may open unexpectedly while driving and hit near-by objects or luggage in the trunk may be thrown out, causing an accident.
Do not allow children to play in the
trunk. If a child is accidentally locked in the trunk, they could suffer from heat exhaustion, suffocation or other inju­ries.
Remove any heavy lo ads, such as snow
and ice, from the trunk lid before opening it. Failure to do so may cause the trunk lid to suddenly shut again after it is opened.
When opening or closing the trunk lid,
thoroughly check to make sure the surrounding area is safe.
If anyone is in the vicinity, make sure
they are safe and let them know that the trunk is about to open or close.
Use caution when opening or closing
the trunk lid in windy weather as it may move abruptly in strong wind.
Vehicles without power trunk lid: The
trunk lid may suddenly shut if it is not opened fully. It is more difficult to open or close the trunk lid on an incline than on a level surface, so beware of the trunk lid unexpectedly opening or closing by itself. Make sure that the trunk lid is fully open and secure before using the trunk.
3
Before driving
Do not allow a child to open or close
the trunk lid. Doing so may cause the trunk lid to open unexpectedly, or cause the child’s hands, head, or neck to be caught by the closing trunk lid.
Important points while driving
Never let anyone sit in the trunk. In the event of sudden braking or a collision, they are susceptible to death or serious injury.
Using the trunk
Observe the following precautions. Failure to do so may cause parts of the body to be caught, resulting in serious injury.
When closing the trunk lid, take extra
care to prevent your fingers etc. from being caught.
94
WARNING
Vehicles without power trunk lid:
3-2. Opening, closing and locking the doors and trunk
When closing the trunk lid, make sure to press it lightly on its outer surface. If the trunk grip is used to fully close the trunk lid, it may result in hands or arms being caught.
Do not attach any accessories other
than genuine Lexus parts to the trunk lid. Such additional weight on the trunk lid may cause the lid to suddenly shut again after it is opened.
Trunk easy closer (vehicles with
power trunk lid)
In the event that the trunk lid is left slightly open, the trunk easy closer will automati­cally close it to the fully closed position. It takes several seconds before the trunk easy closer begins to operate. Be careful not to catch fingers or anything else in the trunk lid, as this may cause bone frac­tures or other serious injuries.
If the trunk closer switch is pressed
while the trunk lid is opening during automatic operation, the trunk lid stops opening. Take extra care when on an incline, as the trunk lid may open or close suddenly.
On an incline, the trunk lid may sud-
denly shut after it opens automatically. Make sure the trunk lid is fully open and secure before using the trunk.
In the following situations, the power
trunk lid may detect an abnormality and automatic operation may be stopped. In this case, the trunk lid has to be operated manually. Take extra care in this situation, as the stopped trunk lid may suddenly shut, causing an accident.
• When the trunk lid contacts an obsta­cle
• When the battery voltage suddenly drops, such as when the engine switch is turned to IGNITION ON mode or the engine is started during automatic operation
Power trunk lid (if equipped)
Observe the following precautions when operating the power trunk lid. Failure to do so may cause serious injury.
Check the safety of the surrounding
area to make sure there are no obsta­cles or anything that could cause any of your belongings to get caught.
If anyone is in the vicinity, make sure
they are safe and let them know that the trunk is about to open or close.
Do not attach any accessories other
than genuine Lexus parts to the trunk lid. The power trunk lid may not oper­ate, causing itself to malfunction, or the trunk lid may suddenly shut again after it is opened.
Hands Free Power Trunk Lid (vehicles
with power trunk lid)
Observe the following precautions. Failure to do so may cause serious injury.
Exhaust gases cause the exhaust pipes
to become quite hot. When operating the Hands Free Power Trunk Lid, be careful not to touch the exhaust pipe.
Do not operate the Hands Free Power
Trunk Lid if there is little space under the rear bumper.
Jam protection function (vehicles
with power trunk lid)
Observe the following precautions. Failure to do so may cause serious injury.
3-2. Opening, closing and locking the doors and trunk
WARNING
NOTICE
Never use any part of your body to
intentionally activate the jam protec­tion function.
The jam protection function may not
work if something gets caught just before the trunk lid fully closes. Be careful not to catch fingers or anything else in the trunk lid.
The jam protection function may not
work depending on the shape of the object that is caught. Be careful not to catch fingers or anything else.
To prevent trunk easy closer malfunc-
tions (vehicles with power trunk lid)
Do not apply force to the trunk lid while the trunk easy closer is operating.
To prevent damage to the power
trunk lid (vehicles with power trunk lid)
Make sure that there is no luggage or
snow on the trunk lid before operating the power trunk lid. In addition, make sure that there is no ice between the trunk lid and frame that prevents movement of the trunk lid. Operating the power trunk lid when excessive load is present on the trunk lid may cause a malfunction.
Smart access system with push-
button start
While carrying the electronic key, press the button.
When all the doors are unlocked using one of the following methods, the trunk can be opened without the electronic key:
•Entry function
• Wireless remote control
• Door lock switches
• Automatic door unlocking system
• Mechanical key
95
3
Before driving
Do not apply excessive force to the
trunk lid while the power trunk lid is operating.
Opening/closing the trunk
Trunk opener switch
Press the trunk opener switch.
Wireless remote control
Press and hold the switch.
A buzzer sounds.
96
A
BCA
B
Hands Free Power Trunk Lid (vehi-
3-2. Opening, closing and locking the doors and trunk
cles with power trunk lid)
1 While carrying an electronic key,
stand within the smart access sys­tem with push-button start opera­tion range, approximately 11.8 to
19.7 in. (30 to 50 cm) from the rear bumper.
while a foot is detected under the rear bumper.
• Operate the Hands Free Power Trunk Lid without contacting the rear bumper with your foot.
• If another electronic key is in the cabin or trunk, it may take slightly longer than normal for the opera­tion to occur.
Hands Free Power Trunk Lid sensor Hands Free Power Trunk Lid opera-
tion detection area
Hands Free Power Trunk Lid sensor Hands Free Power Trunk Lid opera-
tion detection area Smart access system with push-
button start operation detection area (P.100)
2 Perform a kick operation by mov-
ing your foot to within approxi­mately 3.9 in. (10 cm) of the rear bumper and then pulling it back.
• Perform the entire kick operation within 1 second.
• The trunk lid will not start operating
3 When the sensor detects that your
foot is pulled back, a buzzer will sound and the trunk will automati­cally fully open/close.
If a foot is moved under the rear bumper while the trunk lid is opening, the trunk lid will stop moving. If a foot is moved under the rear bumper while the trunk lid is closing, the trunk lid will open.
Trunk closer switch (vehicles with
power trunk lid)
Press the trunk closer switch.
A buzzer will sound and the trunk lid will fully close.
Pressing the switch while the trunk lid is closing opens the trunk lid again.
3-2. Opening, closing and locking the doors and trunk
Trunk grip
Using the trunk grip, pull down the trunk lid without applying sideways force and push the trunk lid down from the outside to close it.
Trunk light
The trunk light turns on when the trunk is opened.
Trunk easy closer (vehicles with power
trunk lid)
In the event that the trunk lid is left slightly open, the trunk easy closer will automati­cally close it to the fully closed position.
The trunk easy closer will operate
regardless of the engine switch mode.
If the trunk easy closer does not operate,
open the trunk to the half open position or more and then close it.
Function to prevent the trunk being
locked with the electronic key inside
When all doors are locked, closing the
trunk lid with the electronic key left inside the trunk will sound an alarm. In this case, the trunk lid can be opened by pressing the trunk release button on
97
the trunk lid.
If the spare electronic key is put in the
trunk with all the doors locked, the key confinement prevention function is acti­vated so the trunk can be opened. In order to prevent theft, take all electronic keys with you when leaving the vehicle.
If the electronic key is put in the trunk with
all the doors locked, the key may not be detected depending on the location of the key and the surrounding radio wave conditions. In this case, the key confine­ment prevention function cannot be acti­vated, causing the doors to lock when the trunk is closed. Make sure to check where the key is before closing the trunk.
The key confinement prevention function
cannot be activated if any one of the doors is unlocked. In this case, open the trunk using the trunk opener.
Overload protection function (vehicles
with power trunk lid)
The trunk lid will not operate when exces­sive load is present on the top of the trunk lid.
Fall-down protection function (vehicles
with power trunk lid)
While the trunk lid is opening automatically, applying excessive force to it will stop the opening operation to prevent the trunk lid from rapidly falling down.
Jam protection function (vehicles with
power trunk lid)
While the trunk lid is closing automatically, the trunk lid will stop closing and open if something gets caught.
Internal trunk release lever
The trunk lid can be opened by pulling the glow-in-the-dark lever located on the inside of the trunk to the side. The lever will con­tinue to glow for some time after the trunk lid is closed.
3
Before driving
98
Using the mechanical key
3-2. Opening, closing and locking the doors and trunk
The trunk can be also opened using the mechanical key. (P.372) If the trunk is unlocked using the mechanical key, the power trunk lid and trunk easy closer will not be operational. To return them to an operational state, fully close the trunk lid by hand.
If the smart access system with push-
button start or the wireless remote con­trol does not operate properly
Use the mechanical key to unlock the trunk. (P.372) Replace the key battery with a new one if it is depleted. (P.330)
Hands Free Power Trunk Lid operating
conditions (vehicles with power trunk lid)
When the Hands Free Power Trunk Lid
(kick sensor) operation setting is turned on and the engine switch is turned off
When an electronic key is carried within
the operation range
Situations in which the Hands Free
Power Trunk Lid may not operate prop­erly (vehicles with power trunk lid)
In the following situations, the Hands Free Power Trunk Lid may not operate properly:
When a foot remains under the rear
bumper
If the rear bumper is strongly hit with a
foot or is touched for a while If the rear bumper has been touched for a while, wait for a short time before attempting to operate the Hands Free Power Trunk Lid again.
When operated while a person is too
close to the rear bumper
When an external radio wave source
interferes with the communication
between the electronic key and the vehi­cle (P.101)
When the vehicle is parked near an elec-
trical noise source which affects the sen­sitivity of the Hands Free Power Trunk Lid, such as a pay parking spot, gas station, electrically heated road, or fluorescent light
When the vehicle is near a TV tower,
electric power plant, radio station, large display, airport or other facility that gen­erates strong radio waves or electrical noise
When a large amount of water is applied
to the rear bumper, such as when the vehicle is being washed or in heavy rain
When mud, snow, ice, etc. is attached to
the rear bumper
When the vehicle has been parked for a
while near objects that may move and contact the rear bumper, such as plants
When an accessory is installed to the rear
bumper If an accessory has been installed, turn the Hands Free Power Trunk Lid (kick sensor) operation setting off.
Preventing unintentional operation of
the Hands Free Power Trunk Lid (vehi­cles with power trunk lid)
When an electronic key is in the operation range, the Hands Free Power Trunk Lid may operate unintentionally, so be careful in the following situations.
When a large amount of water is applied
to the rear bumper, such as when the vehicle is being washed or in heavy rain
When dirt is wiped off the rear bumper
When a small animal or small object, such
as a ball, moves under the rear bumper
When an object is moved from under the
rear bumper
If someone is swinging their legs while sit-
ting on the rear bumper
If the legs or another part of someone’s
body contacts the rear bumper while passing by the vehicle
When the vehicle is parked near an elec-
trical noise source which affects the sen-
3-2. Opening, closing and locking the doors and trunk
A
B
99
sitivity of the Hands Free Power Trunk Lid, such as a pay parking spot, gas station, electrically heated road, or fluorescent light
When the vehicle is near a TV tower,
electric power plant, radio station, large display, airport or other facility that gen­erates strong radio waves or electrical noise
When the vehicle is parked in a place
where objects such as plants are near the rear bumper
If luggage, etc. is set near the rear
bumper
If accessories or a vehicle cover is
installed/removed near the rear bumper
When the vehicle is being towed
To prevent unintentional operation, turn the Hands Free Power Trunk Lid (kick sensor) operation setting off.
Open door warning buzzer
P.92
Customization
Some functions can be customized. (Cus­tomizable features: P.400)
On Off
When the trunk opener main switch is off, the trunk lid cannot be opened even with the wireless remote control, entry function or Hands Free Power Trunk Lid.
When leaving a key to the vehicle with a
parking attendant
P.88
3
Before driving
Protecting luggage against theft
The trunk opener switch can be tem­porarily disabled to protect luggage stored in the trunk against theft.
Turn the trunk opener main switch in the glove box off to disable the trunk opener.
100
ABC
D
A
B
C
3-2. Opening, closing and locking the doors and trunk
Smart access system with push-button start
The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. The driver should always carry the electronic key.
Locks and unlocks the doors
(P.89)
Opens the trunk (P.95)Starts the engine (P.137)
Antenna location
Effective range (areas within which the
electronic key is detected)
When locking or unlocking the doors The system can be operated when the electronic key is within about 2.3 ft. (0.7 m) of an outside door handle. (Only the doors detecting the key can be oper­ated.)
When opening the trunk The system can be operated when the electronic key is within about 2.3 ft. (0.7 m) of the trunk release button.
When starting the engine or changing engine switch modes The system can be operated when the electronic key is inside the vehicle.
If an alarm sounds or a warning message
is displayed
An alarm sounds and warning messages are displayed on the multi-information dis­play to protect against unexpected acci­dents or theft of the vehicle resulting from
Antennas outside the cabin
Antennas inside the cabin
Antenna inside the trunk
Antenna outside the trunk
erroneous operation. When a warning mes­sage is displayed, take appropriate mea­sures based on the displayed message.
When only an alarm sounds, circumstances and correction procedures are as follows.
When an exterior alarm sounds once for
5 seconds
Loading...
