Pictorial index
For safety
1
and security
Search by illustration
Make sure to read through them
2
Instrument cluster
Operation of each
3
component
4
Driving
Lexus Display
5
Audio system
6
Interior features
Maintenance
7
and care
When trouble
8
arises
Vehicle
9
specifications
How to read the gauges and meters, the variety of
warning lights and indicators, etc.
Opening and closing the doors and windows,
adjustment before driving, etc.
Operations and advice which are necessary for driving
Operating the Lexus Display Audio system
Usage of the interior features, etc.
Caring for your vehicle and maintenance procedures
What to do in case of malfunction or emergency
Vehicle specifications, customizable features, etc.
10
For owners
Index
ES350_OM_OM06134U_(U)
Reporting safety defects for U.S. owners, and seat belt
and SRS airbag instructions for Canadian owners
Search by symptom
Search alphabetically
TABLE OF CONTENTS2
For your information................................... 8
Reading this manual...................................12
How to search..............................................13
Pictorial index...............................................14
1
For safety and security
1-1. For safe use
Before driving ................................ 26
For safe driving ..............................28
Seat belts.......................................... 30
SRS airbags..................................... 35
Front passenger occupant
classification system ................. 44
Safety information
for children ...................................50
Child restraint systems.................51
Installing child restraints............. 55
Exhaust gas precautions............ 64
1-2. Theft deterrent system
Engine immobilizer system....... 65
Alarm..................................................67
2
Instrument cluster
Operation of each
3
component
3-1. Key information
Keys.................................................... 92
3-2. Opening, closing and locking
the doors and trunk
Doors................................................. 95
Trunk.................................................. 101
Smart access system
with push-button start............ 108
3-3. Adjusting the seats
Front seats ....................................... 116
Driving position memory........... 117
Head restraints.............................. 121
3-4. Adjusting the steering wheel
and mirrors
Steering wheel..............................124
Inside rear view mirror ..............126
Outside rear view mirrors ...... 128
3-5. Opening, closing the windows
and moon roof
Power windows............................. 131
Moon roof.......................................134
2. Instrument cluster
Warning lights
and indicators...............................72
Gauges and meters......................76
Multi-information display ..........80
Fuel consumption
information ...................................86
ES350_OM_OM06134U_(U)
3
4
Driving
4-1. Before driving
Driving the vehicle ..................... 140
Cargo and luggage ................... 148
Vehicle load limits ........................151
Trailer towing ................................152
Dinghy towing.............................. 153
4-2. Driving procedures
Engine (ignition) switch.............154
Automatic transmission ........... 159
Turn signal lever...........................163
Parking brake................................164
4-3. Operating the lights
and wipers
Headlight switch ..........................165
Automatic High Beam.............. 168
Fog light switch............................. 172
Windshield wipers
and washer ..................................173
4-4. Refueling
Opening the fuel tank cap .......177
4-5. Using the driving support
systems
Lexus Safety System+............... 180
PCS
(Pre-Collision System)...........187
LDA (Lane Departure Alert
with steering control)............. 198
Dynamic radar
cruise control............................ 207
Cruise control...............................219
Intuitive parking assist.............. 222
Lexus parking assist
monitor..........................................231
Driving mode select
switch............................................247
BSM (Blind Spot Monitor)..... 249
•Blind Spot Monitor
function ....................................252
• Rear Cross Traffic Alert
function ....................................254
Driving assist systems ..............257
4-6. Driving tips
Winter driving tips..................... 262
1
2
3
4
5
6
7
8
ES350_OM_OM06134U_(U)
9
10
TABLE OF CONTENTS4
5
Lexus Display Audio system
5-1. Basic Operations
Lexus Display Audio
system..........................................268
Steering wheel audio
switches .......................................274
Mobile Assistant ........................ 275
USB/AUX ports.........................277
5-2. Setup
Setup menu ..................................280
General settings.......................... 281
Voice settings.............................. 284
Display settings...........................285
5-3. Using the audio system
Selecting the audio
source.......................................... 286
Optimal use of the audio
system.......................................... 287
Audio settings .............................288
Audio menu screen
operation......................................291
5-4. Using the radio
Radio operation.......................... 294
5-5. Playing an audio CD and
MP3/WMA/AAC discs
CD player operation................300
5-6. Using an external device
Listening to an iPod ..................307
Using USB memory
device .............................................311
Using the AUX port.................. 315
5-7. Connecting Bluetooth
Steps for using Bluetooth®
devices ..........................................316
Registering a Bluetooth
device ........................................... 318
Selecting a Bluetooth
device ............................................319
Connecting a Bluetooth
audio player ..............................320
Connecting a Bluetooth
phone.............................................321
Displaying a Bluetooth
device details............................ 322
®
Detailed Bluetooth
settings ........................................323
5-8. Bluetooth® Audio
Listening to Bluetooth
Audio ...........................................326
5-9. Bluetooth
Using a Bluetooth
®
Phone
®
Phone........................................... 327
Making a call................................ 329
Receiving a call........................... 332
Speaking on the phone ...........333
Using a Bluetooth
®
phone message .......................335
Using the steering wheel
switches ...................................... 337
Bluetooth
®
phone
settings ........................................338
®
®
®
®
®
®
®
ES350_OM_OM06134U_(U)
5
5-10. Phonebook
Contact settings.........................340
Messaging setting .....................343
5-11. Bluetooth
®
What to do if...
(Troubleshooting)................... 344
Bluetooth
®
...................................348
5-12. Other function
“Information” screen ................354
USB photo.................................... 356
Weather information................358
Voice command system .........359
6
Interior features
6-1. Using the air conditioning
system and defogger
Automatic air conditioning
system.......................................... 366
Heated steering wheel/
seat heaters/seat
ventilators................................... 375
6-2. Using the interior lights
Interior lights list ..........................377
• Interior lights.......................... 378
• Personal lights....................... 378
6-3. Using the storage features
List of storage features............380
• Glove box................................ 381
• Console box ........................... 381
• Cup holders ...........................382
• Auxiliary box..........................383
Trunk features............................. 384
6-4. Using the other interior
features
Other interior features............386
• Sun visors................................386
• Vanity mirrors .......................386
• Clock ........................................ 387
• Power outlets ........................ 387
• Armrest....................................388
• Rear sunshade/rear door
sunshades ...............................389
•Trunk storage
extension...................................391
• Coat hooks............................. 392
• Assist grips ............................. 392
Garage door opener ...............393
Compass.......................................400
LEXUS Enform Safety
Connect...................................... 404
LEXUS Enform Remote......... 409
LEXUS Enform Service
Connect....................................... 410
1
2
3
4
5
6
7
8
9
ES350_OM_OM06134U_(U)
10
TABLE OF CONTENTS6
7
Maintenance and care
7-1. Maintenance and care
Cleaning and protecting
the vehicle exterior ..................412
Cleaning and protecting
the vehicle interior....................415
7-2. Maintenance
Maintenance
requirements ............................. 418
General maintenance................421
Emission inspection
and maintenance (I/M)
programs.................................... 424
7-3. Do-it-yourself maintenance
Do-it-yourself service
precautions................................ 425
Hood................................................427
Positioning a floor jack ............428
Engine compartment ...............429
Tires................................................. 440
Tire inflation pressure ..............450
Wheels...........................................453
Air conditioning filter ...............455
Electronic key battery.............. 457
Checking and replacing
fuses.............................................. 459
Light bulbs .................................... 462
8
When trouble arises
8-1. Essential information
Emergency flashers...................474
If your vehicle has to be
stopped in an emergency ... 475
8-2. Steps to take in an emergency
If your vehicle needs
to be towed ............................... 476
If you think
something is wrong................480
Fuel pump shut off system....... 481
If a warning light turns on or
a warning buzzer sounds ....482
If a warning message
is displayed ................................488
If you have a flat tire ....................491
If the engine will not start........502
If the electronic key does not
operate properly.....................504
If the battery is discharged.....506
If your vehicle overheats.......... 510
If the vehicle becomes
stuck...............................................513
ES350_OM_OM06134U_(U)
9
For vehicles with navigation system, refer to the “NAVIGATION SYSTEM
OWNER’S MANUAL” for information regarding the equipment listed below.
• Navigation system
• Lexus parking assist monitor
• Audio/video system
• Lexus Enform
Vehicle specifications
9-1. Specifications
Maintenance data
(fuel, oil level, etc.)....................516
Fuel information .........................525
Tire information.......................... 528
9-2. Customization
Customizable features............538
9-3. Initialization
Items to initialize.........................548
10
For owners
7
1
2
3
4
Reporting safety defects
for U.S. owners ....................................550
Seat belt instructions
for Canadian owners
(in French)............................................... 551
SRS airbag instructions
for Canadian owners
(in French)..............................................552
Index
What to do if...
(Troubleshooting)...............................560
Alphabetical index ................................564
5
6
7
8
9
10
ES350_OM_OM06134U_(U)
8
For your information
Main Owner’s Manual
The Owner’s Manual provides instructions on the proper operation of this vehicle. The
driver should read the Owner’s Manual prior to driving the vehicle. Failure to follow the
instructions in the Owner’s Manual could lead to an accident, resulting in death or serious injury.
Please note that this manual applies to all models and explains all equipment, including
options. Therefore, you may find some explanations for equipment not installed on your
vehicle.
All specifications provided in this manual are current at the time of printing. However,
because of the Lexus policy of continual product improvement, we reserve the right to
make changes at any time without notice.
Depending on specifications, the vehicle shown in the illustrations may differ from your
vehicle in terms of color and equipment.
Noise from under vehicle after turning off the engine
Approximately five hours after the engine is turned off, you may hear sound coming from
under the vehicle for several minutes. This is the sound of a fuel evaporation leakage
check and, it does not indicate a malfunction.
Accessories, spare parts and modification of your Lexus
A wide variety of non-genuine spare parts and accessories for Lexus vehicles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any
damage they may cause to, or adverse effect they may have on, your Lexus vehicle.
This vehicle should not be modified with non-genuine Lexus products. Modification with
non-genuine Lexus products could affect its performance, safety or durability, and may
even violate governmental regulations. In addition, damage or performance problems
resulting from the modification may not be covered under warranty.
Installation of a mobile two-way radio system
The installation of a mobile two-way radio system in your vehicle could affect electronic
systems such as:
● Multiport fuel injection system/sequential multiport fuel injection system
● Dynamic radar cruise control system
● Cruise control system
● Anti-lock brake system
● SRS airbag system
● Seat belt pretensioner system
● Lexus Safety System+
Be sure to check with your Lexus dealer for precautionary measures or special instructions regarding installation of a mobile two-way radio system.
ES350_OM_OM06134U_(U)
Vehicle data recordings
Your Lexus is equipped with several sophisticated computers that will record certain
data, such as:
• Engine speed
• Accelerator status
•Brake status
• Vehicle speed
•Shift position
The recorded data varies according to the vehicle grade level and options with which it is
equipped. These computers do not record conversations or sounds, and only record
images outside of the vehicle in certain situations.
● Data Transmission
Your vehicle may transmit the data recorded in these computers to Lexus without notification to you.
● Data usage
Lexus may use the data recorded in these computers to diagnose malfunctions, conduct research and development, and improve quality.
Lexus will not disclose the recorded data to a third party except:
• With the consent of the vehicle owner or with the consent of the lessee if the vehicle
is leased
• In response to an official request by the police, a court of law or a government
agency
• For use by Lexus in a lawsuit
• For research purposes where the data is not tied to a specific vehicle or vehicle
owner
● Usage of data collected through Lexus Enform (U.S. mainland only)
If your Lexus has Lexus Enform and if you have subscribed to those services, please
refer to the Lexus Enform Telematics Subscription Service Agreement for information
on data collected and its usage.
● To learn more about the vehicle data collected, used and shared by Lexus,
please visit www.lexus.com/privacyvts/.
9
ES350_OM_OM06134U_(U)
10
Event data recorder
This vehicle is equipped with an event data recorder (EDR). The main purpose of an EDR
is to record, in certain crash or near crash-like situations, such as an air bag deployment
or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems
performed. The EDR is designed to record data related to vehicle dynamics and safety
systems for a short period of time, typically 30 seconds or less.
The EDR in this vehicle is designed to record such data as:
• How various systems in your vehicle were operating;
• Whether or not the driver and passenger safety belts were buckled/fastened;
• How far (if at all) the driver was depressing the accelerator and/or brake pedal; and,
• How fast the vehicle was traveling.
These data can help provide a better understanding of the circumstances in which
crashes and injuries occur.
NOTE: EDR data are recorded by your vehicle only if a non-trivial crash situation occurs;
no data are recorded by the EDR under normal driving conditions and no personal data
(e.g., name, gender, age, and crash location) are recorded. However, other parties, such
as law enforcement, could combine the EDR data with the type of personally identifying
data routinely acquired during a crash investigation.
To read data recorded by an EDR, special equipment is required, and access to the vehicle or the EDR is needed. In addition to the vehicle manufacturer, other parties, such as
law enforcement, that have the special equipment, can read the information if they have
access to the vehicle or the EDR.
● Disclosure of the EDR data
Lexus will not disclose the data recorded in an EDR to a third party except when:
• An agreement from the vehicle’s owner (or the lessee for a leased vehicle) is
obtained
• In response to an official request by the police, a court of law or a government
agency
• For use by Lexus in a lawsuit
However, if necessary, Lexus may:
• Use the data for research on vehicle safety performance
• Disclose the data to a third party for research purposes without disclosing informa-
tion about the specific vehicle or vehicle owner
ES350_OM_OM06134U_(U)
Scrapping of your Lexus
WARNING
The SRS airbag and seat belt pretensioner devices in your Lexus contain explosive
chemicals. If the vehicle is scrapped with the airbags and seat belt pretensioners not
deployed, this may cause an accident such as fire. Be sure to have the systems of the SRS
airbag and seat belt pretensioner removed and disposed of by a qualified service shop or
by your Lexus dealer before you scrap your vehicle.
Perchlorate Material
Special handling may apply, See www.dtsc.ca.gov/hazardouswaste/perchlorate.
Your vehicle has components that may contain perchlorate. These components may
include airbag, seat belt pretensioners, and wireless remote control batteries.
■ General precautions while driving
● Obey all traffic laws
● The driver is responsible for the proper operation of the vehicle, including evaluation
of weather conditions and road conditions.
Driving under the influence: Never drive your vehicle when under the influence of
alcohol or drugs that have impaired your ability to operate your vehicle. Alcohol and
certain drugs delay reaction time, impair judgment and reduce coordination, which
could lead to an accident that could result in death or serious injury.
Defensive driving: Always drive defensively. Anticipate mistakes that other drivers or
pedestrians might make and be ready to avoid accidents.
Driver distraction: Always give your full attention to driving. Anything that distracts the
driver, such as adjusting controls, talking on a cellular phone or reading can result in a
collision causing death or serious injury to you, your occupants or others.
■ General precaution regarding children’s safety
Never leave children unattended in the vehicle, and never allow children to have or use
the key.
Children may be able to start the vehicle or shift the vehicle into neutral. There is also a
danger that children may injure themselves by playing with the windows, the moon
roof, or other features of the vehicle. In addition, heat build-up or extremely cold temperatures inside the vehicle can be fatal to children.
11
ES350_OM_OM06134U_(U)
12
Reading this manual
WARNING:
Explains something that, if not obeyed, could cause death or serious injury
to people.
NOTICE:
Explains something that, if not obeyed, could cause damage to or a malfunction in the vehicle or its equipment.
Indicates operating or working procedures. Follow the steps in
numerical order.
Indicates the action (pushing,
turning, etc.) used to operate
switches and other devices.
Indicates the outcome of an
operation (e.g. a lid opens).
Indicates the component or position being explained.
Means “Do not”, “Do not do this”,
or “Do not let this happen”.
ES350_OM_OM06134U_(U)
How to search
■ Searching by name
• Alphabetical index............... P. 564
■ Searching by installation position
• Pictorial index.............................P. 14
■ Searching by symptom or sound
• What to do if...
(Troubleshooting)................P. 560
13
■ Searching by title
• Table of contents.........................P. 2
ES350_OM_OM06134U_(U)
14
Pictorial index
Pictorial index
■ Exterior
1
Doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 95
Locking/unlocking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 95
Opening/closing the door glasses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 131
Locking/unlocking by using the mechanical key . . . . . . . . . . . . . . . . . . . . . . . P. 504
Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 488
2
Trunk. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 101
Opening from inside. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 101
Opening from outside . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 101
Opening by using the mechanical key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 504
Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 488
3
Outside rear view mirrors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 128
Adjusting the mirror angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 128
Folding the mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 128
Driving position memory
Defogging the mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 370
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 117
ES350_OM_OM06134U_(U)
Pictorial index
9
12
4
Windshield wipers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 173
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 262
To prevent freezing (windshield wiper de-icer)
Precautions against car wash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 413
5
Fuel filler door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 177
Refueling method. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 177
Fuel type/fuel tank capacity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 518
6
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 440
Tire size/inflation pressure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 522
Winter tires/tire chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 262
Checking/rotation/tire pressure warning system . . . . . . . . . . . . . . . . . . . . . . P. 440
Coping with flat tires. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 491
7
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 427
Opening. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 427
Engine compartment cover. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 430
Engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 518
Coping with overheat. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 510
Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 488
Light bulbs of the exterior lights for driving
(Replacing method: P. 462, Watts: P. 524)
*. . . . . . . . . . . . . . . . . . . . . . . . P. 371
15
8
Headlights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 165
Parking lights/daytime running lights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 165
10
Fog lights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 172
11
Turn signal lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 163
Stop/tail lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 165
13
License plate lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 165
14
Back-up lights
Shifting the shift lever to R . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 159
15
Side marker lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 165
*: If equipped
ES350_OM_OM06134U_(U)
16
Pictorial index
■ Instrument panel
1
Engine switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 154
Starting the engine/changing the modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 154
Emergency stop of the engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 475
When the engine will not start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 502
Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 488
2
Shift lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 159
Changing the shift position. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 159
Precautions against towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 476
When the shift lever does not move. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 162
3
Meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 76
Reading the meters/adjusting the instrument panel light . . . . . . . . . . . . . . . . . P. 76
Warning lights/indicator lights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 72
When the warning lights come on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 482
ES350_OM_OM06134U_(U)
Pictorial index
11
13
4
Multi-information display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 80
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 80
When the warning messages are displayed . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 488
5
Parking brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 164
Applying/releasing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 164
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 263
Warning buzzer/message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 164, 488
6
Turn signal lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 163
Headlight switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 165
Headlights/parking lights/tail lights/daytime running lights . . . . . . . . . . . . . P. 165
Fog lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 172
7
Windshield wiper and washer switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 173
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 173
Adding washer fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 439
Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 488
8
Emergency flasher switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 474
9
Fuel filler door opener. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 178
Refueling method. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 177
Fuel type/fuel tank capacity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 518
10
Trunk opener . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 101
Hood lock release lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 427
12
Tilt and telescopic steering control switch
1
*
. . . . . . . . . . . . . . . . . . . . . . . P. 124
Driving position memory*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 117
Tilt and telescopic steering lock release lever*1 . . . . . . . . . . . . . . . . . . . P. 124
14
Air conditioning system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 366
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 366
Rear window and outside rear view mirror defoggers. . . . . . . . . . . . . . . . . . P. 370
15
Audio system*2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 268
Hands-free system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 327
17
1
*
: If equipped
2
*
: For vehicles with navigation system, refer to
“NAVIGATION SYSTEM OWNER’S MANUAL”.
ES350_OM_OM06134U_(U)
18
7
■ Switches
1
2
3
4
5
6
Pictorial index
Outside rear view mirror switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 128
Instrument panel light control switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 77
Odometer/trip meter and trip meter reset button . . . . . . . . . . . . . . . . . . .P. 77
Automatic High Beam switch
Intuitive parking assist switch
BSM (Blind Spot Monitor) main switch
*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 168
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 222
*. . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 249
Tire pressure warning reset switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 442
ES350_OM_OM06134U_(U)
Pictorial index
1
Driving position memory switches*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 117
2
Door lock switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 97
3
Power window switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 131
4
Window lock switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 131
5
Trunk opener main switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 102
19
ES350_OM_OM06134U_(U)
*: If equipped
20
7
Pictorial index
1
Audio remote control switches*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 274
2
Talk switch
3
LDA (Lane Departure Alert with steering control) switch*2 . . . . . . P. 198
4
Meter control switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 81
5
Vehicle-to-vehicle distance switch
6
Cruise control switch
Cruise control*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 219
Dynamic radar cruise control*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 207
1
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 337
2
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 207
Telephone switches*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 337
ES350_OM_OM06134U_(U)
Pictorial index
1
Seat heater and ventilator switches*2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 376
2
Heated steering wheel switch
3
Rear sunshade switch*2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 389
4
Driving mode select switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 247
5
VSC OFF switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 258
6
Remote Touch
7
Lexus Display Audio controller*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 270
1
*
2
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 376
21
ES350_OM_OM06134U_(U)
1
*
: For vehicles with navigation system, refer to
“NAVIGATION SYSTEM OWNER’S MANUAL”.
2
*
: If equipped
22
9
■ Interior
Pictorial index
1
SRS airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 35
2
Floor mats. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 26
3
Front seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 116
4
Head restraints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 121
5
Seat belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 30
6
Console box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 381
7
Inside lock buttons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 97
8
Cup holders. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 382
Assist grips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 392
ES350_OM_OM06134U_(U)
Pictorial index
1
Inside rear view mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 126
2
Sun visors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 386
3
Vanity mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 386
4
Interior lights
5
Personal lights
6
Moon roof switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 134
7
“SOS” button
8
Garage door opener switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 393
1
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 378
1
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 378
2
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 404
23
1
*
: The illustration shows the front, but they are also equipped in the rear.
ES350_OM_OM06134U_(U)
2
*
: If equipped
24
Pictorial index
ES350_OM_OM06134U_(U)
25
For safety and security
1
1-1. For safe use
Before driving................................. 26
For safe driving ..............................28
Seat belts ..........................................30
SRS airbags .....................................35
Front passenger occupant
classification system.................. 44
Safety information
for children ...................................50
Child restraint systems ................ 51
Installing child restraints............. 55
Exhaust gas precautions............ 64
1-2. Theft deterrent system
Engine immobilizer system....... 65
Alarm ................................................. 67
ES350_OM_OM06134U_(U)
26
1
*
2
1-1. For safe use
Before driving
Floor mat
Use only floor mats designed specifically for vehicles of the same model and
model year as your vehicle. Fix them securely in place onto the carpet.
Insert the retaining hooks (clips) into
the floor mat eyelets.
Turn the upper knob of each retaining hook (clip) to secure the floor
mats in place.
*: Always align the marks.
The shape of the retaining hooks (clips) may differ from that shown in the illustration.
ES350_OM_OM06134U_(U)
1-1. For safe use
WARNING
● Check that the floor mat is securely fixed in
the correct place with all the provided retaining hooks (clips). Be especially careful to perform this check after cleaning the floor.
● With the engine stopped and the shift lever in
P, fully depress each pedal to the floor to
make sure it does not interfere with the floor
mat.
Observe the following precautions.
Failure to do so may cause the driver’s floor mat to slip, possibly interfering with the pedals while driving. An unexpectedly high speed may result or it may become difficult to
stop the vehicle. This could lead to an accident, resulting in death or serious injury.
■ When installing the driver’s floor mat
● Do not use floor mats designed for other models or different model year vehicles,
even if they are Lexus Genuine floor mats.
● Only use floor mats designed for the driver’s seating position.
● Always install the floor mat securely using the retaining hooks (clips) provided.
● Do not use two or more floor mats on top of each other.
● Do not place the floor mat bottom-side up or upside-down.
■ Before driving
27
1
For safety and security
ES350_OM_OM06134U_(U)
28
4
1-1. For safe use
For safe driving
For safe driving, adjust the seat and mirror to an appropriate position before
driving.
Correct driving posture
1
Adjust the angle of the seatback so
that you are sitting straight up and so
that you do not have to lean forward
to steer. (→P. 116)
2
Adjust the seat so that you can
depress the pedals fully and so that
your arms bend slightly at the elbow
when gripping the steering wheel.
(→P. 116)
3
Lock the head restraint in place with the center of the head restraint closest to
the top of your ears. (→P. 121)
Wear the seat belt correctly. (→P. 30)
Correct use of the seat belts
Make sure that all occupants are wearing their seat belts before driving the vehicle. (→P. 30)
Use a child restraint system appropriate for the child until the child becomes
large enough to properly wear the vehicle’s seat belt. (→P. 51)
Adjusting the mirrors
Make sure that you can see backward clearly by adjusting the inside and outside
rear view mirrors properly. (→P. 126, 128)
ES350_OM_OM06134U_(U)
1-1. For safe use
WARNING
Observe the following precautions.
Failure to do so may result in death or serious injury.
● Do not adjust the position of the driver’s seat while driving.
Doing so could cause the driver to lose control of the vehicle.
● Do not place a cushion between the driver or passenger and the seatback.
A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt, head restraint and other safety systems, increasing the risk of
death or serious injury to the occupant.
● Do not place anything under the front seats.
Objects placed under the front seats may become jammed in the seat tracks and stop
the seat from locking in place. This may lead to an accident and the adjustment mechanism may also be damaged.
● Always observe the legal speed limit when driving on public roads.
● When driving over long distances, take regular breaks before you start to feel tired.
Also, if you feel tired or sleepy while driving, do not force yourself to continue driving
and take a break immediately.
29
1
For safety and security
ES350_OM_OM06134U_(U)
30
Release button
1-1. For safe use
Seat belts
Make sure that all occupants are wearing their seat belts before driving the
vehicle.
Correct use of the seat belts
● Extend the shoulder belt so that it
comes fully over the shoulder, but
does not come into contact with the
neck or slide off the shoulder.
● Position the lap belt as low as possi-
ble over the hips.
● Adjust the position of the seatback.
Sit up straight and well back in the
seat.
● Do not twist the seat belt.
Fastening and releasing the seat belt
1
To fasten the seat belt, push the plate
into the buckle until a click sound is
heard.
2
To release the seat belt, press the
release button.
Adjusting the seat belt shoulder anchor height (front seats)
1
Push the seat belt shoulder anchor
down while pressing the release button.
2
Push the seat belt shoulder anchor
up.
Move the height adjuster up and down
as needed until you hear a click.
ES350_OM_OM06134U_(U)
1-1. For safe use
Seat belt pretensioners (front and outboard rear seats)
The pretensioners help the seat belts to
quickly restrain the occupants by
retracting the seat belts when the vehicle is subjected to certain types of
severe frontal collision or a vehicle rollover.
The front seat belt pretensioners also
activate when the vehicle is subjected to
certain types of severe side collision.
The pretensioners do not activate in the event of a minor frontal impact, a minor side
impact or a rear impact.
■ Emergency locking retractor (ELR)
The retractor will lock the belt during a sudden stop or on impact. It may also lock if you
lean forward too quickly. A slow, easy motion will allow the belt to extend so that you can
move around fully.
■ Automatic locking retractor (ALR)
When a passenger’s shoulder belt is completely extended and then retracted even
slightly, the belt is locked in that position and cannot be extended. This feature is used to
hold the child restraint system (CRS) firmly. To free the belt again, fully retract the belt
and then pull the belt out once more. (→P. 55)
■ Child seat belt usage
The seat belts of your vehicle were principally designed for persons of adult size.
● Use a child restraint system appropriate for the child, until the child becomes large
enough to properly wear the vehicle’s seat belt. (→P. 51)
● When the child becomes large enough to properly wear the vehicle’s seat belt, follow
the instructions regarding seat belt usage. (→P. 30)
■ Replacing the belt after the pretensioner has been activated
If the vehicle is involved in multiple collisions, the pretensioner will activate for the first
collision of sufficient severity, but will not activate for the second or subsequent collisions.
The seat belt must be replaced if the pretensioner has been activated.
■ Seat belt extender
If your seat belts cannot be fastened securely
because they are not long enough, a personalized seat belt extender is available from your
Lexus dealer free of charge.
31
1
For safety and security
ES350_OM_OM06134U_(U)
32
WARNING
Obtain medical advice and wear the seat belt
in the proper way. (→P. 30)
Women who are pregnant should position the
lap belt as low as possible over the hips in the
same manner as other occupants, extending
the shoulder belt completely over the shoulder
and avoiding belt contact with the rounding of
the abdominal area.
If the seat belt is not worn properly, not only the
pregnant woman, but also the fetus could suffer
death or serious injury as a result of sudden
braking or a collision.
1-1. For safe use
Observe the following precautions to reduce the risk of injury in the event of sudden
braking, sudden swerving or an accident.
Failure to do so may cause death or serious injury.
■ Wear a seat belt
● Ensure that all passengers wear a seat belt.
● Always wear a seat belt properly.
● Each seat belt should be used by one person only. Do not use a seat belt for more
than one person at once, including children.
● Lexus recommends that children be seated in the rear seat and always use a seat belt
and/or an appropriate child restraint system.
● To achieve a proper seating position, do not recline the seat more than necessary. The
seat belt is most effective when the occupants are sitting up straight and well back in
the seats.
● Do not wear the shoulder belt under your arm.
● Always wear your seat belt low and snug across your hips.
■ Pregnant women
ES350_OM_OM06134U_(U)
1-1. For safe use
WARNING
■ People with medical conditions
Obtain medical advice and wear the seat belt in the proper way. (→P. 30)
■ When children are in the vehicle
Do not allow children to play with the seat belt. If the seat belt becomes twisted around
a child’s neck, it may lead to choking or other serious injuries that could result in death.
If this occurs and the child cannot be released from the seat belt, scissors should be
used to cut the belt.
■ Seat belt pretensioners
● Do not place anything, such as a cushion, on the front passenger’s seat. Doing so will
disperse the passenger’s weight, which prevents the sensor from detecting the passenger’s weight properly. As a result, the seat belt pretensioner for the front passenger’s seat may not activate in the event of a collision.
● If the pretensioner has activated, the SRS warning light will come on. In that case, the
seat belt cannot be used again and must be replaced at your Lexus dealer.
■ Adjustable shoulder anchor
Always make sure the shoulder belt is positioned across the center of your shoulder.
The belt shoul d be kept away from your neck , but not falling off your shoulder. Failure to
do so could reduce the amount of protection in an accident and cause death or serious
injuries in the event of a sudden stop, sudden swerve or accident. (→P. 30)
■ Seat belt damage and wear
● Do not damage the seat belts by allowing the belt, plate, or buckle to be jammed in
the door.
● Inspect the seat belt system periodically. Check for cuts, fraying, and loose parts. Do
not use a damaged seat belt until it is replaced. Damaged seat belts cannot protect an
occupant from death or serious injury.
● Ensure that the belt and plate are locked and the belt is not twisted.
If the seat belt does not function correctly, immediately contact your Lexus dealer.
● Replace the seat assembly, including the belts, if your vehicle has been involved in a
serious accident, even if there is no obvious damage.
● Do not attempt to install, remove, modify, disassemble or dispose of the seat belts.
Have any necessary repairs carried out by your Lexus dealer. Inappropriate handling
may lead to incorrect operation.
■ Using a seat belt extender
● Do not wear the seat belt extender if you can fasten the seat belt without the extender.
● Do not use the seat belt extender when installing a child restraint system because the
belt will not securely hold the child restraint system, increasing the risk of death or
serious injury in the event of an accident.
● The personalized extender may not be safe on another vehicle, when used by another
person, or at a different seating position other than the one originally intended.
33
1
For safety and security
ES350_OM_OM06134U_(U)
34
NOTICE
■ When using a seat belt extender
1-1. For safe use
When releasing the seat belt, press on the buckle release button on the extender, not
on the seat belt.
This helps prevent damage to the vehicle interior and the extender itself.
ES350_OM_OM06134U_(U)
1-1. For safe use
SRS airbags
The SRS airbags inflate when the vehicle is subjected to certain types of
severe impacts that may cause significant injury to the occupants. They work
together with the seat belts to help reduce the risk of death or serious injury.
35
1
For safety and security
◆ SRS front airbags
1
SRS driver airbag/front passenger airbag
Can help protect the head and chest of the driver and front passenger from
impact with interior components
2
SRS knee airbags
Can help provide driver and front passenger protection
◆ SRS side and curtain shield airbags
3
SRS front side airbags
Can help protect the torso of the front seat occupants
SRS rear side airbags
Can help protect the torso of occupants in the rear outer seats
ES350_OM_OM06134U_(U)
36
8
9
10
11
12
13
14
15
16
17
1-1. For safe use
4
SRS curtain shield airbags
● Can help protect primarily the head of occupants in the outer seats
● Can prevent the occupants from being thrown from the vehicle in the
event of vehicle rollover
SRS airbag system components
1
Front passenger occupant classification system (ECU and sensors)
2
Side impact sensors (front doors)
3
Knee airbags
4
Front passenger airbag
5
Curtain shield airbags
6
“AIR BAG ON” and “AIR BAG
OFF” indicator lights
7
Seat belt pretensioners and force
limiters
Side impact sensors (front)
Front side airbags
SRS warning light
Driver airbag
Rear side airbags
Side impact sensors (rear)
Driver’s seat belt buckle switch
Airbag sensor assembly
Front passenger’s seat belt buckle
switch
Front impact sensors
ES350_OM_OM06134U_(U)
1-1. For safe use
WARNING
Your vehicle is equipped with ADVANCED AIRBAGS designed based on the
US motor vehicle safety standards (FMVSS208). The airbag sensor assembly
(ECU) controls airbag deployment based on information obtained from the sensors etc. shown in the system components diagram above. This information
includes crash severity and occupant information. As the airbags deploy, a
chemical reaction in the inflators quickly fills the airbags with non-toxic gas to
help restrain the motion of the occupants.
■ SRS airbag precautions
Observe the following precautions regarding the SRS airbags.
Failure to do so may cause death or serious injury.
● The driver and all passengers in the vehicle must wear their seat belts properly.
The SRS airbags are supplemental devices to be used with the seat belts.
● The SRS driver airbag deploys with considerable force, and can cause death or seri-
ous injury especially if the driver is very close to the airbag. The National Highway
Traffic Safety Administration (NHTSA) advises:
Since the risk zone for the driver’s airbag is the first 2 - 3 in. (50 - 75 mm) of inflation,
placing yourself 10 in. (250 mm) from your driver airbag provides you with a clear
margin of safety. This distance is measured from the center of the steering wheel to
your breastbone. If you sit less than 10 in. (250 mm) away now, you can change your
driving position in several ways:
• Move your seat to the rear as far as you can while still reaching the pedals comfortably.
• Slightly recline the back of the seat.
Although vehicle designs vary, many drivers can achieve the 10 in. (250 mm) distance, even with the driver seat all the way forward, simply by reclining the back of
the seat somewhat. If reclining the back of your seat makes it hard to see the road,
raise yourself by using a firm, non-slippery cushion, or raise the seat if your vehicle
has that feature.
• If your steering wheel is adjustable, tilt it downward. This points the airbag toward
your chest instead of your head and neck.
The seat should be adjusted as recommended by NHTSA above, while still maintaining control of the foot pedals, steering wheel, and your view of the instrument panel
controls.
37
1
For safety and security
ES350_OM_OM06134U_(U)
38
WARNING
● If the seat belt extender has been connected
to the front seat belt buckle but the seat belt
extender has not also been fastened to the
latch plate of the seat belt, the SRS front airbags will judge that the driver and front passenger are wearing the seat belt even though
the seat belt has not been connected. In this
case, the SRS front airbags may not activate
correctly in a collision, resulting in death or
serious injury in the event of a collision. Be
sure to wear the seat belt with the seat belt
extender.
● Do not sit on the edge of the seat or lean
against the dashboard.
● Do not allow a child to stand in front of the
SRS front passenger airbag unit or sit on the
knees of a front passenger.
● Do not allow the front seat occupants to hold
items on their knees.
■ SRS airbag precautions
1-1. For safe use
● The SRS front passenger airbag also deploys with considerable force, and can cause
death or serious injury especially if the front passenger is very close to the airbag. The
front passenger seat should be as far from the airbag as possible with the seatback
adjusted, so the front passenger sits upright.
● Improperly seated and/or restrained infants and children can be killed or seriously
injured by a deploying airbag. An infant or child who is too small to use a seat belt
should be properly secured using a child restraint system. Lexus strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front
passenger seat. (→P. 51)
ES350_OM_OM06134U_(U)
WARNING
■ SRS airbag precautions
● Do not lean against the door, the roof side rail
or the front, side and rear pillars.
● Do not allow anyone to kneel on the passen-
ger seats toward the door or put their head or
hands outside the vehicle.
● Do not attach anything to or lean anything
against areas such as the dashboard, steering
wheel pad, lower portion of the instrument
panel and door of the glove box.
These items can become projectiles when the
SRS driver, front passenger and knee airbags
deploy.
● Do not attach anything to areas such as a
door, windshield glass, side door glass, front
or rear pillar, roof side rail and assist grip.
1-1. For safe use
39
1
For safety and security
● Do not hang coat hangers or hard objects on the coat hooks. All of these items could
become projectiles and may cause death or serious injury, should the SRS curtain
shield airbags deploy.
● If a vinyl cover is put on the area where the SRS knee airbag will deploy, be sure to
remove it.
● Do not use seat accessories which cover the parts where the SRS side airbags inflate
as they may interfere with inflation of the airbags. Such accessories may prevent the
side airbags from activating correctly, disable the system or cause the side airbags to
inflate accidentally, resulting in death or serious injury.
ES350_OM_OM06134U_(U)
40
WARNING
■ SRS airbag precautions
1-1. For safe use
● Do not strike or apply significant levels of force to the area of the SRS airbag compo-
nents.
Doing so can cause the SRS airbags to malfunction.
● Do not touch any of the component parts immediately after the SRS airbags have
deployed (inflated) as they may be hot.
● If breathing becomes difficult after the SRS airbags have deployed, open a door or
window to allow fresh air in, or leave the vehicle if it is safe to do so. Wash off any residue as soon as possible to prevent skin irritation.
● If the areas where the SRS airbags are stored, such as the steering wheel pad and
front and rear pillar garnishes are damaged or cracked, have them replaced by your
Lexus dealer.
■ Modification and disposal of SRS airbag system components
Do not dispose of your vehicle or perform any of the following modifications without
consulting your Lexus dealer. The SRS airbags may malfunction or deploy (inflate)
accidentally, causing death or serious injury.
● Installation, removal, disassembly and repair of the SRS airbags
● Repairs, modifications, removal or replacement of the steering wheel, instrument
panel, dashboard, glove box, seats or seat upholstery, front, side and rear pillars or
roof side rails
● Repairs or modifications of the front fender, front bumper, or side of the occupant
compartment
● Installation of a grille guard (bull bars, kangaroo bar, etc.), snow plows, winches or
roof luggage carrier
● Modifications to the vehicle’s suspension system
● Installation of electronic devices such as mobile two-way radios and CD players
● Modifications to your vehicle for a person with a physical disability
■ If the SRS airbags deploy (inflate)
● Slight abrasions, burns, bruising etc., may be sustained from SRS airbags, due to the
extremely high speed deployment (inflation) by hot gases.
● A loud noise and white powder will be emitted.
● Parts of the airbag module (steering wheel hub, airbag cover and inflator) as well as the
seats, parts of the front and rear pillars, and roof side rails may be hot for several minutes. The airbag itself may also be hot.
● The windshield may crack.
● For Lexus Enform Safety Connect subscribers, if the SRS airbags deploy or in the event
of a severe rear-end collision, the system is designed to send an emergency call to the
response center, notifying them of the vehicle’s location (without needing to push the
“SOS” button) and an agent will attempt to speak with the occupants to ascertain the
level of emergency and assistance required. If the occupants are unable to communicate, the agent automatically treats the call as an emergency and helps to dispatch the
necessary emergency services. (→P. 404)
ES350_OM_OM06134U_(U)
1-1. For safe use
■ SRS airbag deployment conditions (SRS front airbags)
● The SRS front airbags will deploy in the event of an impact that exceeds the set thresh-
old level (the level of force corresponding to an approximately 12 - 18 mph [20 - 30
km/h] frontal collision with a fixed wall that does not move or deform).
However, this threshold velocity will be considerably higher in the following situations:
• If the vehicle strikes an object, such as a parked vehicle or sign pole, which can move
or deform on impact
• If the vehicle is involved in an underride collision, such as a collision in which the
front of the vehicle “underrides”, or goes under, the bed of a truck
● Depending on the type of collision, it is possible that only the seat belt pretensioners will
activate.
● The SRS front airbags for the front passenger will not activate if there is no passenger
sitting in the front passenger seat. However, the SRS front airbags for the front passenger may deploy if luggage is put in the seat, even if the seat is unoccupied. (→P. 44)
■ SRS airbag deployment conditions (SRS side and curtain shield airbags)
● The SRS side and curtain shield airbags will deploy in the event of an impact that
exceeds the set threshold level (the level of force corresponding to the impact force
produced by an approximately 3300 lb. [1500 kg] vehicle colliding with the vehicle
cabin from a direction perpendicular to the vehicle orientation at an approximate
spe ed of 12 - 18 mph [20 - 30 km/h]).
● The SRS curtain shield airbags will deploy in the event of vehicle rollover.
● The SRS side and curtain shield airbags may also deploy in the event of a severe frontal
collision.
■ Conditions under which the SRS airbags may deploy (inflate), other than a collision
The SRS front airbags and SRS curtain shield airbag may also deploy if a serious impact
occurs to the underside of your vehicle. Some examples are shown in the illustration.
● Hitting a curb, edge of pavement or hard sur-
face
● Falling into or jumping over a deep hole
● Landing hard or falling
41
1
For safety and security
The SRS curtain shield airbags may also deploy under the situations shown in the illustration.
● The angle of vehicle tip-up is marginal.
● The vehicle skids and hits a curb stone.
ES350_OM_OM06134U_(U)
42
■ Types of collisions that may not deploy the SRS airbags (SRS front airbags)
1-1. For safe use
The SRS front airbags do not generally inflate if the vehicle is involved in a side or rear
collision, if it rolls over, or if it is involved in a low-speed frontal collision. But, whenever a
collision of any type causes sufficient forward deceleration of the vehicle, deployment of
the SRS front airbags may occur.
● Collision from the side
● Collision from the rear
● Vehicle rollover
■ Types of collisions that may not deploy the SRS airbags (SRS side and curtain shield air-
bags)
The SRS side and curtain shield airbags may not activate if the vehicle is subjected to a
collision from the side at certain angles, or a collision to the side of the vehicle body other
than the passenger compartment.
● Collision from the side to the vehicle body
other than the passenger compartment
● Collision from the side at an angle
The SRS side airbags do not generally inflate if the vehicle is involved in a rear collision, if
it rolls over, or if it is involved in a low-speed side or low-speed frontal collision.
● Collision from the rear
● Vehicle rollover
The SRS curtain shield airbags do not generally inflate if the vehicle is involved in a rear
collision, if it pitches end over end, or if it is involved in a low-speed side or low-speed
frontal collision.
● Collision from the rear
● Pitching end over end
ES350_OM_OM06134U_(U)
1-1. For safe use
■ When to contact your Lexus dealer
In the following cases, the vehicle will require inspection and/or repair. Contact your
Lexus dealer as soon as possible.
● Any of the SRS airbags have been inflated.
● The front of the vehicle is damaged or
deformed, or was involved in an accident that
was not severe enough to cause the SRS front
airbags to inflate.
● A portion of a door or its surrounding area is
damaged or deformed, or the vehicle was
involved in an accident that was not severe
enough to cause the SRS side and curtain
shield airbags to inflate.
● The pad section of the steering wheel, dash-
board near the front passenger airbag or
lower portion of the instrument panel is
scratched, cracked, or otherwise damaged.
43
1
For safety and security
● The surface of the seats with the side airbag is
scratched, cracked, or otherwise damaged.
● The portion of the front pillars, rear pillars or
roof side rail garnishes (padding) containing
the curtain shield airbags inside is scratched,
cracked, or otherwise damaged.
ES350_OM_OM06134U_(U)
44
1-1. For safe use
Front passenger occupant classification system
Your vehicle is equipped with a front passenger occupant classification system. This system detects the conditions of the front passenger seat and activates or deactivates the devices for the front passenger.
1
Seat belt reminder light
2
SRS warning light
3
“AIR BAG OFF” indicator light
4
“AIR BAG ON” indicator light
ES350_OM_OM06134U_(U)
1-1. For safe use
Condition and operation in the front passenger occupant classification
system
■ Adult*
1
45
Indicator/
warning light
Devices
■ Child*
Indicator/
warning light
“AIR BAG ON” and “AIR BAG OFF”
indicator lights
SRS warning light Off
Seat belt reminder light Off*2 or flashing*
Front passenger airbag
Side airbag
on the front passenger seat
Curtain shield airbag
in the front passenger side
Front passenger knee airbag
Front passenger’s seat belt pretensioner
4
“AIR BAG ON” and “AIR BAG OFF”
indicator lights
SRS warning light Off
Seat belt reminder light Off*2 or flashing*
“AIR BAG ON”
Activated
“AIR BAG OFF” or
“AIR BAG ON”
*
3
4
3
1
For safety and security
Devices
ES350_OM_OM06134U_(U)
Front passenger airbag
Side airbag
on the front passenger seat
Curtain shield airbag
in the front passenger side
Front passenger knee airbag
Front passenger’s seat belt pretensioner Activated
Deactivated or
activated
Activated
Deactivated or
activated
4
*
4
*
46
■ Child restraint system with infant*
1-1. For safe use
5
Indicator/
warning light
Devices
■ Unoccupied
Indicator/
warning light
“AIR BAG ON” and “AIR BAG OFF”
indicator lights
“AIR BAG OFF”*
SRS warning light Off
Seat belt reminder light Off*2 or flashing*
Front passenger airbag Deactivated
Side airbag
on the front passenger seat
Activated
Curtain shield airbag
in the front passenger side
Front passenger knee airbag Deactivated
Front passenger’s seat belt pretensioner Activated
“AIR BAG ON” and “AIR BAG OFF”
indicator lights
“AIR BAG OFF”
SRS warning light
Off
Seat belt reminder light
6
3
Devices
ES350_OM_OM06134U_(U)
Front passenger airbag Deactivated
Side airbag
on the front passenger seat
Activated
Curtain shield airbag
in the front passenger side
Front passenger knee airbag Deactivated
Front passenger’s seat belt pretensioner Activated
■ There is a malfunction in the system
1-1. For safe use
47
“AIR BAG ON” and “AIR BAG OFF”
indicator lights
Indicator/
warning light
Devices
Front passenger’s seat belt pretensioner Activated
1
*
: The system judges a person of adult size as an adult. When a smaller adult sits in
the front passenger seat, the system may not recognize him/her as an adult
depending on his/her physique and posture.
2
*
: In the event the front passenger is wearing a seat belt.
3
*
: In the event the front passenger does not wear a seat belt
4
*
: For some children, child in seat, child in booster seat or child in convertible seat,
the system may not recognize him/her as a child. Factors which may affect this can
be the physique or posture.
5
*
: Never install a rear-facing child restraint system on the front passenger seat. A for-
ward-facing child restraint system should only be installed on the front passenger
seat when it is unavoidable. (→P. 51)
6
*
: In case the indicator light is not illuminated, consult this manual on how to install the
child restraint system properly. (→P. 55)
SRS warning light
Seat belt reminder light
Front passenger airbag Deactivated
Side airbag
on the front passenger seat
Curtain shield airbag
in the front passenger side
Front passenger knee airbag Deactivated
“AIR BAG OFF”
On
Activated
1
For safety and security
ES350_OM_OM06134U_(U)
48
WARNING
■ Front passenger occupant classification system precautions
1-1. For safe use
Observe the following precautions regarding the front passenger occupant classification system.
Failure to do so may cause death or serious injury.
● Wear the seat belt properly.
● Make sure the front passenger’s seat belt plate has not been left inserted into the
buckle before someone sits in the front passenger seat.
● Make sure the “AIR BAG OFF” indicator light is not illuminated when using the seat
belt extender for the front passenger seat. If the “AIR BAG OFF” indicator light is illuminated, disconnect the extender tongue from the seat belt buckle, and reconnect
the seat belt. Reconnect the seat belt extender after making sure the “AIR BAG ON”
indicator light is illuminated. If you use the seat belt extender while the “AIR BAG
OFF” indicator light is illuminated, the SRS airbags for front passenger will not activate, which could cause death or serious injury in the event of a collision.
● Do not apply a heavy load to the front passenger seat or equipment (e.g. seatback
pockets).
● Do not put weight on the front passenger seat by putting your hands or feet on the
front passenger seat seatback from the rear passenger seat.
● Do not let a rear passenger lift the front passenger seat with their feet or press on the
seatback with their legs.
● Do not put objects under the front passenger seat.
ES350_OM_OM06134U_(U)
1-1. For safe use
WARNING
■ Front passenger occupant classification system precautions
● Do not recline the front passenger seatback so far that it touches a rear seat. This may
cause the “AIR BAG OFF” indicator light to be illuminated, which indicates that the
SRS airbags for front passenger will not activate in the event of a severe accident. If
the seatback touches the rear seat, return the seatback to a position where it does not
touch the rear seat. Keep the front passenger seatback as upright as possible when
the vehicle is moving. Reclining the seatback excessively may lessen the effectiveness
of the seat belt system.
● If an adult sits in the front passenger seat, the “AIR BAG ON” indicator light is illumi-
nated. If the “AIR BAG OFF” indicator is illuminated, ask the passenger to sit up
straight, well back in the seat, feet on the floor, and with the seat belt worn correctly. If
the “AIR BAG OFF” indicator still remains illuminated, either ask the passenger to
move to the rear seat, or if that is not possible, move the front passenger seat fully
rearward.
● When it is unavoidable to install a forward-facing child restraint system on the front
passenger seat, install the child restraint system on the front passenger seat in the
proper order. (→P. 55)
● Do not modify or remove the front seats.
● Do not kick the front passenger seat or subject it to severe impact. Otherwise, the
SRS warning light may come on to indicate a malfunction of the front passenger
occupant classification system. In this case, contact your Lexus dealer immediately.
● Child restraint systems installed on the rear seat should not contact the front seat-
backs.
● Do not use a seat accessory, such as a cushion and seat cover, that covers the seat
cushion surface.
● Do not modify or replace the upholstery of the front seat.
49
1
For safety and security
ES350_OM_OM06134U_(U)
50
WARNING
1-1. For safe use
Safety information for children
Observe the following precautions when children are in the vehicle.
Use a child restraint system appropriate for the child, until the child becomes
large enough to properly wear the vehicle’s seat belt.
● It is recommended that children sit in the rear seats to avoid accidental con-
tact with the shift lever, wiper switch etc.
● Use the rear door child-protector lock or the window lock switch to avoid
children opening the door while driving or operating the power window accidentally. (→P. 98, 131)
● Do not let small children operate equipment which may catch or pinch body
parts, such as the power window, hood, trunk, seats etc.
Never leave children unattended in the vehicle, and never allow children to have or use
the key.
Children may be able to start the vehicle or shift the vehicle into neutral. There is also a
danger that children may injure themselves by playing with the windows, the moon roof
or other features of the vehicle. In addition, heat build-up or extremely cold temperatures inside the vehicle can be fatal to children.
ES350_OM_OM06134U_(U)
1-1. For safe use
Child restraint systems
A child restraint system for a small child or baby must itself be properly
restrained on the seat with the LATCH anchors or the lap portion of the lap/
shoulder belt.
The laws of all 50 states of the U.S.A. and Canada now require the use of child
restraint systems.
Points to remember
Studies have shown that installing a child restraint on a rear seat is much safer
than installing one on the front passenger seat.
● Choose a child restraint system that suits your vehicle and is appropriate to
the age and size of the child.
● For installation details, follow the instructions provided with the child restraint
system.
General installation instructions are provided in this manual. (→P. 55)
51
1
For safety and security
ES350_OM_OM06134U_(U)
52
1-1. For safe use
Types of child restraints
Child restraint systems are classified into the following 3 types according to the
age and size of the child:
Rear facing ⎯ Infant seat/convert-
ible seat
Booster seat
Forward facing ⎯ Convertible
seat
■ Selecting an appropriate child restraint system
● Use a child restraint system appropriate for the child until the child becomes large
enough to properly wear the vehicle’s seat belt.
● If the child is too large for a child restraint system, sit the child on a rear seat and use the
vehicle’s seat belt. (→P. 30)
ES350_OM_OM06134U_(U)
1-1. For safe use
WARNING
■ Child restraint precautions
● For effective protection in automobile accidents and sudden stops, a child must be
properly restrained, using a seat belt or child restraint system depending on the age
and size of the child. Holding a child in your arms is not a substitute for a child restraint
system. In an accident, the child can be crushed against the windshield, or between
you and the vehicle’s interior.
● Lexus strongly urges the use of a proper child restraint system that conforms to the
size of the child, installed on the rear seat. According to accident statistics, the child is
safer when properly restrained in the rear seat than in the front seat.
● Never install a rear-facing child restraint system on the front passenger seat even if
the “AIR BAG OFF” indicator light is illuminated.
In the event of an accident, the force of the rapid inflation of the front passenger airbag can cause death or serious injury to the child if the rear-facing child restraint system is installed on the front passenger seat.
● A forward-facing child restraint system may be installed on the front passenger seat
only when it is unavoidable. A child restraint system that requires a top tether strap
should not be used in the front passenger seat since there is no top tether strap
anchor for the front passenger seat. Adjust the seatback as upright as possible and
always move the seat as far back as possible even if the “AIR BAG OFF” indicator
light is illuminated, because the front passenger airbag could inflate with considerable
speed and force. Otherwise, the child may be killed or seriously injured.
● Do not use the seat belt extender when installing a child restraint system on the front
or rear passenger seat. If installing a child restraint system with the seat belt extender
connected to the seat belt, the seat belt will not securely hold the child restraint system, which could cause death or serious injury to the child or other passengers in the
event of a sudden stop, sudden swerve or accident.
● Do not allow the child to lean his/her head or any part of his/her body against the
door or the area of the seat, front and rear pillars or roof side rails from which the SRS
side airbags or SRS curtain shield airbags deploy even if the child is seated in the child
restraint system. It is dangerous if the SRS side airbags and curtain shield airbags
inflate, and the impact could cause death or serious injury to the child.
● Make sure you have complied with all installation instructions provided by the child
restraint manufacturer and that the system is properly secured. If it is not secured
properly, it may cause death or serious injury to the child in the event of a sudden
stop, sudden swerve or accident.
53
1
For safety and security
ES350_OM_OM06134U_(U)
54
WARNING
■ When children are in the vehicle
1-1. For safe use
Do not allow children to play with the seat belt. If the seat belt becomes twisted around
a child’s neck, it may lead to choking or other serious injuries that could result in death.
If this occurs and the child cannot be released from the seat belt, scissors should be
used to cut the belt.
■ When the child restraint system is not in use
● Keep the child restraint system properly secured on the seat even if it is not in use. Do
not store the child restraint system unsecured in the passenger compartment.
● If it is necessary to detach the child restraint system, remove it from the vehicle or
store it securely in the trunk. This will prevent it from injuring passengers in the event
of a sudden stop, sudden swerve or accident.
ES350_OM_OM06134U_(U)
1-1. For safe use
Installing child restraints
Follow the child restraint system manufacturer’s instructions. Firmly secure
child restraints to the seats using the LATCH anchors or a seat belt. Attach the
top tether strap when installing a child restraint.
The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Children) system.
Child restraint LATCH anchors
LATCH anchors are provided for the
outboard rear seats. (Buttons displaying
the location of the anchors are attached
to the seats.)
Seat belts equipped with a child
restraint locking mechanism (ALR/
ELR belts except driver’s seat belt)
(→P. 31)
55
1
For safety and security
Anchor brackets (for top tether strap)
An anchor bracket is provided for each
rear seat.
ES350_OM_OM06134U_(U)
56
1
2
Canada only
3
1-1. For safe use
Installation with LATCH system
Lower the head restraint in place at
the lowest position.
Widen the gap between the seat cushion and seatback slightly.
Type A
Latch the hooks of the lower straps
onto the LATCH anchors. If the child
restraint has a top tether strap, the
top tether strap should be latched
onto the top tether strap anchor.
For owners in Canada:
The symbol on a child restraint system indicates the presence of a
lower connector system.
ES350_OM_OM06134U_(U)
Type B
Canada only
3
Latch the buckles onto the LATCH
anchors. If the child restraint has a
top tether strap, the top tether strap
should be latched onto the top
tether strap anchor.
For owners in Canada:
The symbol on a child restraint system indicates the presence of a
lower connector system.
1-1. For safe use
57
1
For safety and security
ES350_OM_OM06134U_(U)
58
1
2
3
4
1-1. For safe use
Installing child restraints using a seat belt (child restraint lock function
belt)
■ Rear-facing ⎯ Infant seat/convertible seat
Place the child restraint system
on the rear seat facing the rear of
the vehicle.
Run the seat belt through the
child restraint system and insert
the plate into the buckle. Make
sure that the belt is not twisted.
Fully extend the shoulder belt and
allow it to retract to put it in lock
mode. In lock mode, the belt cannot be extended.
While pushing the child restraint
system down into the rear seat,
allow the shoulder belt to retract
until the child restraint system is
securely in place.
After the shoulder belt has retracted
to a point where there is no slack in
the belt, pull the belt to check that it
cannot be extended.
ES350_OM_OM06134U_(U)
■ Forward-facing ⎯ Convertible seat
1
2
3
4
Lower the head restraint in place
at the lowest position.
Place the child restraint system
on the seat facing the front of the
vehicle.
Run the seat belt through the
child restraint system and insert
the plate into the buckle. Make
sure that the belt is not twisted.
1-1. For safe use
59
1
For safety and security
Fully extend the shoulder belt and
allow it to retract to put it in lock
mode. In lock mode, the belt cannot be extended.
ES350_OM_OM06134U_(U)
60
5
6
1
2
While pushing the child restraint
system into the rear seat, allow
the shoulder belt to retract until
the child restraint system is
securely in place.
After the shoulder belt has retracted
to a point where there is no slack in
the belt, pull the belt to check that it
cannot be extended.
If the child restraint has a top tether strap, the top tether strap should be
latched onto the top tether strap anchor. (→P. 61)
■ Booster seat
Place the child restraint system
on the seat facing the front of the
vehicle.
1-1. For safe use
Sit the child in the child restraint
system. Fit the seat belt to the
child restraint system according
to the manufacturer’s instructions
and insert the plate into the
buckle. Make sure that the belt is
not twisted.
Check that the shoulder belt is correctly positioned over the child’s
shoulder and that the lap belt is as
low as possible. (→P. 30)
ES350_OM_OM06134U_(U)
Removing a child restraint installed with a seat belt
1
2
3
Push the buckle release button and fully
retract the seat belt.
Child restraint systems with a top tether strap
Lower the head restraint in place at
the lowest position.
1-1. For safe use
61
1
For safety and security
Secure the child restraint system
using the seat belt or LATCH
anchors.
Open the anchor bracket cover,
latch the hook onto the anchor
bracket and tighten the top tether
strap.
Make sure the top tether strap is
securely latched.
ES350_OM_OM06134U_(U)
62
WARNING
● If the driver’s seat interferes with the child
restraint system and prevents it from being
attached correctly, attach the child restraint
system to the right-hand rear seat.
● Adjust the front passenger seat so that it does
not interfere with the child restraint system.
● Only put a forward-facing child restraint sys-
tem on the front seat when unavoidable.
When installing a forward-facing child
restraint system on the front passenger seat,
move the seat as far back as possible even if
the “AIR BAG OFF” indicator light is illuminated. Failure to do so may result in death or
serious injury if the airbags deploy (inflate).
■ Laws and regulations pertaining to anchorages
1-1. For safe use
The LATCH system conforms to FMVSS225 or CMVSS210.2.
Child restraint systems conforming to FMVSS213 or CMVSS213 specifications can be
used.
This vehicle is designed to conform to the SAE J1819.
■ When installing a booster seat
To prevent the belt from going into ALR lock mode, do not fully extend the shoulder
belt. ALR mode causes the belt to tighten only. This could cause injury or discomfort to
the child. (→P. 31)
■ When installing a child restraint system
Follow the directions given in the child restraint system installation manual and fix the
child restraint system securely in place.
If the child restraint system is not correctly fixed in place, the child or other passengers
may be seriously injured or even killed in the event of sudden braking, sudden swerving
or an accident.
ES350_OM_OM06134U_(U)
1-1. For safe use
WARNING
■ When installing a child restraint system
● When a booster seat is installed, always ensure that the shoulder belt is positioned
across the center of the child’s shoulder. The belt should be kept away from the child’s
neck, but not so that it could fall off the child’s shoulder. Failing to do so may result in
death or serious injury in the event of sudden braking, sudden swerving or an accident.
● Ensure that the belt and plate are securely locked and the seat belt is not twisted.
● Shake the child restraint system left and right, and forward and backward to ensure
that it has been securely installed.
● If the seat is adjusted, reconfirm the security of the child restraint system.
● Follow all installation instructions provided by the child restraint system manufacturer.
● When securing some types of child restraint systems in rear seat, it may not be possi-
ble to properly use the seat belts in positions next to the child restraint without interfering with it or affecting seat belt effectiveness. Be sure your seat belt fits snugly
across your shoulder and low on your hips. If it does not, or if it interferes with the child
restraint, move to a different position. Failure to do so may result in death or serious
injury.
■ Do not use a seat belt extender
If a seat belt extender is used when installing a child restraint system, the seat belt will
not securely hold the child restraint system, which could cause death or serious injury
to the child or other passengers in the event of sudden braking, sudden swerving or an
accident.
■ To correctly attach a child restraint system to the anchors
When using the LATCH anchors, be sure that there are no foreign objects around the
anchors and that the seat belt is not caught behind the child restraint system. Make sure
the child restraint system is securely attached, or it may cause death or serious injury to
the child or other passengers in the event of sudden braking, sudden swerving or an
accident.
63
1
For safety and security
ES350_OM_OM06134U_(U)
64
WARNING
1-1. For safe use
Exhaust gas precautions
Harmful substance to the human body is included in exhaust gases if inhaled.
Exhaust gases include harmful carbon monoxide (CO), which is colorless and odorless.
Observe the following precautions.
Failure to do so may cause exhaust gases enter the vehicle and may lead to an accident
caused by light-headedness, or may lead to death or a serious health hazard.
■ Important points while driving
● Keep the trunk lid closed.
● If you smell exhaust gases in the vehicle even when the trunk lid is closed, open the
windows and have the vehicle inspected at your Lexus dealer as soon as possible.
■ When parking
● If the vehicle is in a poorly ventilated area or a closed area, such as a garage, stop the
engine.
● Do not leave the vehicle with the engine running for a long time.
If such a situation cannot be avoided, park the vehicle in an open space and ensure
that exhaust fumes do not enter the vehicle interior.
● Do not leave the engine running in an area with snow build-up, or where it is snowing.
If snowbanks build up around the vehicle while the engine is running, exhaust gases
may collect and enter the vehicle.
■ Exhaust pipe
The exhaust system needs to be checked periodically. If there is a hole or crack caused
by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle
inspected and repaired by your Lexus dealer.
ES350_OM_OM06134U_(U)
1-2. Theft deterrent system
Engine immobilizer system
The vehicle’s keys have built-in transponder chips that prevent the engine
from starting if a key has not been previously registered in the vehicle’s onboard computer.
Never leave the keys inside the vehicle when you leave the vehicle.
This system is designed to help prevent vehicle theft but does not guarantee
absolute security against all vehicle thefts.
The indicator light flashes after the
engine switch has been turned off to
indicate that the system is operating.
The indicator light stops flashing after
the engine switch has been turned to
ACCESSORY or IGNITION ON
mode to indicate that the system has
been canceled.
■ System maintenance
The vehicle has a maintenance-free type engine immobilizer system.
■ Conditions that may cause the system to malfunction
● If the grip portion of the key is in contact with a metallic object
● If the key is in close proximity to or touching a key to the security system (key with a
built-in transponder chip) of another vehicle
65
1
For safety and security
ES350_OM_OM06134U_(U)
66
WARNING
NOTICE
■ Certifications for the engine immobilizer system
For vehicles sold in the U.S.A., Hawaii, NATO Germany, Guam and Puerto Rico
For vehicles sold in Canada
1-2. Theft deterrent system
■ Certifications for the engine immobilizer system
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
■ To ensure the system operates correctly
Do not modify or remove the system. If modified or removed, the proper operation of
the system cannot be guaranteed.
ES350_OM_OM06134U_(U)
1-2. Theft deterrent system
Alarm
The alarm
The alarm uses light and sound to give an alert when an intrusion is detected.
The alarm is triggered in the following situations when the alarm is set:
● A locked door is unlocked or opened in any way other than using the entry
function, wireless remote control or mechanical key. (The doors will lock again
automatically.)
● A locked trunk is unlocked or opened in any way other than using the entry
function or wireless remote control.
● The hood is opened.
Setting the alarm system
Close the doors, trunk and hood, and
lock all the doors. The system will be set
automatically after 30 seconds.
The indicator light changes from being
on to flashing when the system is set.
67
1
For safety and security
Deactivating or stopping the alarm
Do one of the following to deactivate or stop the alarms:
● Unlock the doors or open the trunk using the entry function or wireless
remote control.
● Turn the engine switch to ACCESSORY or IGNITION ON mode, or start
the engine. (The alarm will be deactivated or stopped after a few seconds.)
ES350_OM_OM06134U_(U)
68
■ System maintenance
1-2. Theft deterrent system
The vehicle has a maintenance-free type alarm system.
■ Items to check before locking the vehicle
To prevent unexpected triggering of the alarm and vehicle theft, make sure of the following:
● Nobody is in the vehicle.
● The windows and moon roof are closed before the alarm is set.
● No valuables or other personal items are left in the vehicle.
■ Triggering of the alarm
The alarm may be triggered in the following situations:
(Stopping the alarm deactivates the alarm system.)
● The trunk is unlocked using the mechanical
key.
● A person inside the vehicle opens a door, the
trunk or hood, or unlocks the vehicle using an
inside lock button.
● The battery is recharged or replaced when the
vehicle is locked. (→P. 508)
■ Alarm-operated door lock
In the following cases, the door may automatically lock:
● When a person remaining in the vehicle unlocks the door and the alarm is activated.
● While the alarm is activated, a person remaining in the vehicle unlocks the door.
● When recharging or replacing the battery.
ES350_OM_OM06134U_(U)
1-2. Theft deterrent system
NOTICE
■ To ensure the system operates correctly
Do not modify or remove the system. If modified or removed, the proper operation of
the system cannot be guaranteed.
69
1
For safety and security
ES350_OM_OM06134U_(U)
70
1-2. Theft deterrent system
ES350_OM_OM06134U_(U)
71
Instrument cluster
2
2. Instrument cluster
Warning lights
and indicators.............................. 72
Gauges and meters..................... 76
Multi-information display ..........80
Fuel consumption
information ...................................86
ES350_OM_OM06134U_(U)
72
2. Instrument cluster
Warning lights and indicators
The warning lights and indicators on the instrument cluster and center panel
inform the driver of the status of the vehicle’s various systems.
For the purpose of explanation, the following illustration displays all warning
lights and indicators illuminated.
The units used on the speedometer and some indicators may differ depending on the
target region or grade/type.
ES350_OM_OM06134U_(U)
2. Instrument cluster
Warning lights
Warning lights inform the driver of malfunctions in the indicated vehicle’s systems.
73
(U.S.A.)
(Canada)
(U.S.A.)
(Canada)
(U.S.A.)
(Canada)
1
*
Brake system warning light
(→P. 482)
1
*
Brake system warning light
(→P. 482)
1
*
Malfunction indicator lamp
(→P. 482)
1
*
Malfunction indicator lamp
(→P. 482)
1
*
SRS warning light
(→P. 482)
1
*
ABS warning light
(→P. 482)
1
*
ABS warning light
(→P. 482)
1, 3
*
(if equipped)
1
*
Electric power steering
system warning light
(→P. 483)
1
*
Slip indicator light
(→P. 483)
Low fuel level warning light
(→P. 483)
Seat belt reminder light
(→P. 483)
1
*
Master warning light
(→P. 483)
1
*
Tire pressure warning light
(→P. 484)
“AFS OFF” indicator
(→P. 484)
2
Instrument cluster
1, 2
*
PCS warning light
(→P. 483)
(if equipped)
1
*
: These lights turn on when the engine switch is turned to IGNITION ON mode to
indicate that a system check is being performed. They will turn off after the engine is
on, or after a few seconds. There may be a malfunction in a system if a light does not
come on, or turn off. Have the vehicle inspected by your Lexus dealer.
2
*
: The light flashes or illuminates to indicate a malfunction.
3
*
: The light flashes to indicate a malfunction.
ES350_OM_OM06134U_(U)
74
2. Instrument cluster
Indicators
The indicators inform the driver of the operating state of the vehicle’s various systems.
(U.S.A.)
(Canada)
(if equipped)
Turn signal indicator
(→P. 163)
Headlight indicator
(→P. 165)
Tail light indicator
(→P. 165)
Headlight high beam
indicator (→P. 166)
Automatic High Beam
indicator (→P. 168)
Fog light indicator
(→P. 172)
1
*
Eco Driving Indicator
Light (→P. 84)
(if equipped)
1, 2
*
1, 3
*
(if equipped)
4, 5
*
(if equipped)
1, 6
*
Intuitive parking assist
indicator (→P. 222)
Slip indicator light
(→P. 258)
1
*
VSC OFF indicator
(→P. 259)
PCS warning light
(→P. 190)
BSM outside rear view
mirror indicators
(→P. 249)
“AIR BAG ON/OFF”
indicator (→P. 44)
Cruise control indicator
(→P. 215, 219)
Radar cruise control
indicator (→P. 207)
(if equipped)
Cruise control “SET”
indicator (→P. 219)
LDA indicator (→P. 198)
(if equipped)
ES350_OM_OM06134U_(U)
(U.S.A.)
(Canada)
Parking brake indicator
(→ P. 164)
Parking brake indicator
(→P. 164)
7
*
Low outside temperature
indicator (→P. 76)
2. Instrument cluster
WARNING
1
*
: These lights turn on when the engine switch is turned to IGNITION ON mode to
indicate that a system check is being performed. They will turn off after the engine is
on, or after a few seconds. There may be a malfunction in a system if a light does not
come on, or turn off. Have the vehicle inspected by your Lexus dealer.
2
*
: The light flashes to indicate that the system is operating.
3
*
: The light turns on when the system is turned off.
4
*
: In order to confirm operation, the BSM outside rear view mirror indicators illuminate
in the following situations:
• When the engine switch is turned to IGNITION ON mode while the BSM main
switch is set to ON.
• When the BSM main switch is set to ON while the engine switch is in IGNITION
ON mode.
If the system is functioning correctly, the BSM outside rear view mirror indicators will
turn off after a few seconds.
If the BSM outside rear view mirror indicators do not illuminate or do not turn off,
there may be a malfunction with the system. If this occurs, have the vehicle inspected
by your Lexus dealer.
5
*
: This light illuminates on the outside rear view mirrors.
6
*
: This light illuminates on the center panel.
7
*
: When the outside temperature is approximately 37°F (3°C) or lower, the indicator
will flash for approximately 10 seconds, then stay on.
75
2
Instrument cluster
■ If a safety system warning light does not come on
Should a safety system light such as the ABS and SRS warning light not come on when
you start the engine, this could mean that these systems are not available to help protect you in an accident, which could result in death or serious injury. Have the vehicle
inspected by your Lexus dealer immediately if this occurs.
ES350_OM_OM06134U_(U)
76
6
7
2. Instrument cluster
Gauges and meters
The units used on the speedometer may differ depending on the target region.
1
Engine coolant temperature gauge
Displays the engine coolant temperature
2
Tachometer
Displays the engine speed in revolution per minute
3
Outside temperature
Displays the outside temperature within the range of -40°F (-40°C) to 122°F
(50°C). Low outside temperature indicator comes on when the ambient temperature
is 37°F (3°C) or lower.
4
Clock
Time can be adjusted or a clock format can be set from (settings display) of
the multi-information display. (→P. 80)
5
Multi-information display
Presents the driver with a variety of vehicle data (→P. 80)
Displays warning messages in case of a malfunction (→P. 488)
Speedometer
Displays the vehicle speed
Fuel gauge
Displays the quantity of fuel remaining in the tank
8
Shift position and shift range
Displays the selected shift position or selected shift range (→P. 159)
ES350_OM_OM06134U_(U)
2. Instrument cluster
9
Odometer, trip meter and maintenance required information display
Odometer:
Displays the total distance the vehicle has been driven
Trip meter:
Displays the distance the vehicle has been driven since the meter was last reset.
Trip meters “A” and “B” can be used to record and display different distances independently.
Maintenance required information:
• Displays the maintenance required information when the engine switch is in
IGNITION ON mode.
• It can be reset from (settings display) of the multi-information display.
(→P. 80)
10
Background color of drive mode
Background color changes according to the drive mode. (→P. 247)
•Sport mode: Red
• Eco drive mode: Blue
When in Normal mode, the background color is Black.
Changing the display
Switches between odometer, trip meter
and maintenance required information
displays. When the trip meter is displayed, pressing and holding the button
will reset the trip meter.
77
2
Instrument cluster
Instrument panel light control
The brightness of the instrument panel lights can be adjusted.
1
Darker
2
Brighter
ES350_OM_OM06134U_(U)
78
WARNING
■ The meters and display illuminate when
2. Instrument cluster
The engine switch is in IGNITION ON mode.
■ Instrument panel brightness adjustment
The instrument panel brightness levels when the tail lights are on and off can be adjusted
individually. However, when the surroundings are bright (daytime, etc.), turning on the tail
lights will not change the instrument panel brightness. At this time, any adjustments made
to the instrument panel brightness levels will be applied to both settings at once.
■ Limitation of brightness adjustment
The brightness of the instrument panel lights is automatically adjusted based on the light
sensor detecting how bright the surroundings are. However, if the instrument panel
brightness has been manually set to either the brightest or darkest setting, the automatic
adjustment will not be performed.
■ Outside temperature display
● In the following situations, the correct outside temperature may not be displayed, or the
display may take longer than normal to change.
• When stopped, or driving at low speeds (less than 12 mph [20 km/h])
• When the outside temperature has changed suddenly (at the entrance/exit of a
garage, tunnel, etc.)
• When the vehicle is parked in direct sunlight
● When “--” or “E” is displayed, the system may be malfunctioning.
Take your vehicle to your Lexus dealer.
■ Pop-up display
In some situations, a pop-up display will be temporarily displayed on the multi-information display or the odometer/trip meter/maintenance required information screen.
The pop-up display function can be set on/off. (→P. 539)
■ Liquid crystal display
Small spots or light spots may appear on the display. This phenomenon is characteristic
of liquid crystal displays, and there is no problem continuing to use the display.
■ Customization
The meter display can be customized on the multi-information display.
(Customizable features →P. 538)
■ The information display at low temperatures
Allow the interior of the vehicle to warm up before using the liquid crystal information
display. At extremely low temperatures, the information display monitor may respond
slowly, and display changes may be delayed.
For example, there is a lag between the driver’s shifting and the new gear number
appearing on the display. This lag could cause the driver to downshift again, causing
rapid and excessive engine braking and possibly an accident resulting in personal
death or injury.
ES350_OM_OM06134U_(U)
2. Instrument cluster
NOTICE
■ To prevent damage to the engine and its components
● Do not let the indicator needle of the tachometer enter the red zone, which indicates
the maximum engine speed.
● The engine may be overheating if the engine coolant temperature gauge is in the red
zone (H); or “Engine Coolant Temp High” is shown on the multi-information display.
In this case, immediately stop the vehicle in a safe place, and check the engine after it
has cooled completely. (→P. 510)
79
2
Instrument cluster
ES350_OM_OM06134U_(U)
80
2. Instrument cluster
Multi-information display
Display contents
The multi-information display presents the driver with a variety of vehicle data.
Displays the following information
when an icon is selected. (→P. 81)
Drive information
Select to display various drive
data. (→P. 81)
Navigation system-linked
display (if equipped)
Select to display the following navigation system-linked information.
•Route guidance
• Compass display (north-up display/heading-up display)
Audio system-linked display
Select to enable selection of an audio source or track on the display using the
meter control switches.
Driving assist information
Select to display the cruise control or dynamic radar cruise control/LDA (Lane
Departure Alert with steering control) (if equipped) information, when the system is used.
(→P. 198, 207, 219)
Warning message display
Select to display warning messages and measures to be taken if a malfunction is
detected. (→P. 488)
Settings display
Select to change the meter display settings. (→P. 539)
ES350_OM_OM06134U_(U)
2. Instrument cluster
1
2
3
4
Operating the meter control switches
The multi-information display is operated using the meter control switches.
Select an item/change pages
Enter/Set
Return to the previous screen
Press:
Displays the screen registered to
When no screen has been registered, the drive information screen will be displayed.
Press and hold:
Registers the currently displayed screen to (→P. 539)
The registration confirmation screen is displayed. If the selected screen cannot be
registered, a registration failure message will be shown.
Drive information
Items displayed can be switched by pressing or of the meter control
switches to select and pressing or .
■ Current fuel consumption*
Displays the current rate of fuel consumption
■ Average fuel economy (after reset*
Displays the average fuel consumption since the function was reset, the
engine was started, and the vehicle was refueled, respectively
Use the displayed average fuel consumption as a reference.
■ Average speed (after reset*
Displays the average vehicle speed since the function was reset and the
engine was started, respectively
■ Elapsed time (after reset*
Displays the elapsed time since the function was reset and the engine was
started, respectively
1
2
/after start)*
2
/after start)*
2
/after start/after refuel)*
1
1
1
81
2
Instrument cluster
ES350_OM_OM06134U_(U)
82
■ Distance (range/after start)*
2. Instrument cluster
1
Displays the estimated maximum distance that can be driven with the quantity
of fuel remaining and the distance driven after the engine was started respectively.
• This distance is computed based on your average fuel consumption. As a result,
the actual distance that can be driven may differ from that displayed.
• When only a small amount of fuel is added to the tank, the display may not be
updated.
When refueling, turn the engine switch off. If the vehicle is refueled without turning
the engine switch off, the display may not be updated.
■ Eco Driving Indicator Zone Display
→P. 84
■ Tire inflation pressure
Displays inflation pressure of each tire.
The inflation pressure of the spare tire will not be displayed.
■ LDA (Lane Departure Alert with steering control) vehicle sway warning (if
equipped)
→P. 198
■ Display off
A blank screen is displayed
1
*
: Displayed when the item is set in “Drive Info 1”, “Drive Info 2” or “Drive Info 3”.
(→P. 539)
2
*
: The function can be reset by pressing the of the meter control switches for lon-
ger than 1 second when the item to reset is displayed.
If there is more than one item that can be reset, the item selection screen will appear.
ES350_OM_OM06134U_(U)
2. Instrument cluster
Settings display
The settings of the following items can be changed, refer to P. 538
For functions that can be enabled or disabled, the function switches between on and
off each time is pressed.
● (Lane Departure Alert with steering control) (if
equipped) (→P. 198)
83
● (Pre-Collision System) (if equipped) (→P. 187)
● AFS (Adaptive Front-lighting System) (if equipped) (→P. 166)
● Clock
Adjusts the hour and minute of the clock on the multi-information display.
● Ambient illumin.
Select to turn the ornament lights on and off.
● Vehicle Settings
• Scheduled Maintenance (→P. 419)
• Oil Maintenance (→P. 433)
● Meter Settings
• Language
Select to change the language on the display.
•Units
Select to change the unit of measure.
• Eco Driving Indicator Light
Select to activate/deactivate the Eco Driving Indicator Light
• switch
Displays a procedure to register a desired screen to .
You can register 1 screen as a shortcut, which can be displayed by pressing .
• Drive information 1/2/3
Select to select up to 2 items that will be displayed on a Drive information
screen, up to 3 Drive information screens can be set.
•Pop-up display
Select to set the pop-up displays, which may appear in some situations, on/off.
• Accent color
Select to change the accent colors on the screen, such as the cursor color.
• Default settings
Registered or changed meter settings will be deleted or returned to their
default setting.
2
Instrument cluster
ES350_OM_OM06134U_(U)
84
■ System check display
2. Instrument cluster
After turning the engine switch to IGNITION ON mode, opening image is displayed
while system operation is checked. When the system check is complete, the normal
screen will return.
■ Eco Driving Indicator
1
Eco Driving Indicator Light
During Eco-friendly acceleration (Eco driving), the Eco Driving Indicator Light will turn
on. When the acceleration exceeds the Zone
of Eco driving, or when the vehicle is stopped,
the light turns off.
2
Eco Driving Indicator Zone Display
Suggests the Zone of Eco driving with current
Eco driving ratio based on acceleration.
3
Eco driving ratio based on acceleration
If the acceleration exceeds the Zone of Eco
driving, the right side of the Eco Driving Indicator Zone Display will illuminate.
When this happens, the Eco Driving Indicator
Light will turn off.
4
Zone of Eco driving
Eco Driving Indicator will not operate under the following conditions:
● The engine is not running.
● The shift lever is in any position other than D.
● Neither normal mode nor Eco drive mode is selected. (→P. 247)
● The vehicle speed is approximately 80 mph (130 km/h) or higher.
Settings of the display and non-display of the Eco Driving Indicator Light can be
changed.
■ Suspension of the settings display
In the following situations, the settings display using the meter control switches will be
suspended.
● When a warning message appears on the multi-information display
● When the vehicle begins to move
■ Tire inflation pressure
● It may take a few minutes to display the tire inflation pressure after the engine switch is
turned to IGNITION ON mode. It may also take a few minutes to display the tire inflation pressure after inflation pressure has been adjusted.
● “---” may be displayed if the tire information cannot be determined due to unfavorable
radio wave conditions.
● Tire inflation pressure changes with temperature. The displayed values may also be dif-
ferent from the values measured using a tire pressure gauge.
ES350_OM_OM06134U_(U)
2. Instrument cluster
WARNING
NOTICE
■ When disconnecting and reconnecting battery terminals
The drive information will be reset.
■ Liquid crystal display
→P. 78
■ Caution for use while driving
For safety, avoid operating the meter control switch while driving as much as possible,
and do not look continuously at the multi-information display while driving. Stop the
vehicle and operate the meter control switch. Failure to do so may cause a steering
wheel operation error, resulting in an unexpected accident.
■ Cautions during setting up the display
As the engine needs to be operating during setting up the display, ensure that the vehicle is parked in a place with adequate ventilation. In a closed area such as a garage,
exhaust gases including harmful carbon monoxide (CO) may collect and enter the
vehicle. This may lead to death or a serious health hazard.
■ During setting up the display
To prevent battery discharge, ensure that the engine is operating while setting up the
display features.
85
2
Instrument cluster
ES350_OM_OM06134U_(U)
86
2. Instrument cluster
Fuel consumption information
Fuel consumption information can be displayed on the navigation system
screen or Lexus Display Audio system screen.
1
Navigation system screen or Lexus
Display Audio system screen
Navigation system
2
“MENU” button
3
Remote Touch knob
For use of Remote Touch, refer to the
“NAVIGATION SYSTEM OWNER’S
MANUAL”.
Lexus Display Audio system
4
“MENU” button
5
Lexus Display Audio controller
(→P. 270)
ES350_OM_OM06134U_(U)
2. Instrument cluster
1
2
3
4
5
6
Trip information
Navigation system screen
Press the “MENU” button on the Remote Touch, then select on the “Menu”
screen, and then select “Fuel Consumption”.
If the “Trip Information” screen does not appear, select “Trip Information”.
Resetting the consumption data
Fuel consumption in the past 15 min-
utes
Current fuel consumption
Average vehicle speed since the
engine was started
Elapsed time since the engine was
started
Cruising range (→P. 89)
Lexus Display Audio screen
Press the “MENU” button on the Lexus Display Audio controller, then select
“Info” on the “Menu” screen, and then select “Fuel Consumption”.
If the “Trip Information” screen does not appear, move the controller to the right and
select “Trip Information”.
1
Fuel consumption in the past 15 minutes
2
Current fuel consumption
3
Average vehicle speed since the
engine was started
4
Elapsed time since the engine was
started
5
Cruising range (→P. 89)
Average fuel consumption for the past 15 minutes is divided by color into past
averages and averages attained since the engine switch was last turned to IGNITION ON mode. Use the displayed average fuel consumption as a reference.
The image is an example only.
87
2
Instrument cluster
ES350_OM_OM06134U_(U)
88
1
2
3
4
5
1
2
3
2. Instrument cluster
Past record
Navigation system screen
Press the “MENU” button on the Remote Touch, then select on the “Menu”
screen, and then select “Fuel Consumption”.
If the “Past Record” screen does not appear, select “Past Record”.
Resetting the past record data
Best recorded fuel consumption
Average fuel consumption
Previous fuel consumption record
Updating the average fuel con-
sumption data
Lexus Display Audio screen
Press the “MENU” button on the Lexus Display Audio controller, then select
“Info” on the “Menu” screen, and then select “Fuel Consumption”.
If the “Past Record” screen does not appear, move the controller to the right and
select “Past Record”.
Previous fuel consumption record
Current fuel consumption
Best recorded fuel consumption
The average fuel consumption history is divided by color into past averages and
the average fuel consumption since the last updated. Use the displayed average
fuel consumption as a reference.
The image is an example only.
ES350_OM_OM06134U_(U)
2. Instrument cluster
■ Updating the past record data
Vehicles with navigation system
Update the average fuel consumption by selecting “Update” to measure the current fuel
consumption again.
Vehicles with Lexus Display Audio system
Update the average fuel consumption by moving the controller to the left and select
“Update” to measure the current fuel consumption again.
■ Resetting the data
Vehicles with navigation system
The fuel consumption data can be deleted by selecting “Clear”.
Vehicles with Lexus Display Audio system
The fuel consumption data can be deleted by moving the controller to the left and select
“Clear”.
■ Cruising range
Displays the estimated maximum distance that can be driven with the quantity of fuel
remaining.
This distance is computed based on your average fuel consumption.
As a result, the actual distance that can be driven may differ from that displayed.
89
2
Instrument cluster
ES350_OM_OM06134U_(U)
90
2. Instrument cluster
ES350_OM_OM06134U_(U)
Operation of
each component
91
3
3-1. Key information
Keys.................................................... 92
3-2. Opening, closing and locking
the doors and trunk
Doors .................................................95
Trunk ..................................................101
Smart access system
with push-button start ............108
3-3. Adjusting the seats
Front seats........................................ 116
Driving position memory........... 117
Head restraints ..............................121
3-4. Adjusting the steering wheel
and mirrors
Steering wheel ..............................124
Inside rear view mirror ..............126
Outside rear view mirrors....... 128
3-5. Opening, closing the windows
and moon roof
Power windows .............................131
Moon roof...................................... 134
ES350_OM_OM06134U_(U)
92
3-1. Key information
Keys
The keys
The following keys are provided with the vehicle.
1
Electronic keys
• Operating the smart access system
with push-button start (→P. 108)
• Operating the wireless remote control function
2
Mechanical keys
3
Key number plate
Wireless remote control
1
Locks the doors (→P. 95)
2
Unlocks the doors (→P. 95)
3
Opens the windows and moon roof
(→P. 95)
4
Opens the trunk (→P. 101)
5
Sounds the alarm (→P. 93)
*: This setting must be customized at your
Lexus dealer.
*
Using the mechanical key
To take out the mechanical key, push
the release button and take the key out.
The mechanical key can only be
inserted in one direction, as the key only
has grooves on one side. If the key cannot be inserted in a lock cylinder, turn it
over and re-attempt to insert it.
After using the mechanical key, store it
in the electronic key. Carry the mechanical key together with the electronic key.
If the electronic key battery is depleted
or the entry function does not operate
properly, you will need the mechanical
key. (→P. 504)
ES350_OM_OM06134U_(U)
3-1. Key information
■ Panic mode
When is pressed for longer than about
one second, an alarm will sound intermittently
and the vehicle lights will flash to deter any person from trying to break into or damage your
vehicle.
To stop the alarm, press any button on the electronic key.
■ When required to leave the vehicle’s key with a parking attendant
Turn the trunk opener main switch off and lock the glove box as circumstances demand.
(→P. 102, 381)
Remove the mechanical key for your own use and provide the attendant with the electronic key only.
■ If you lose your mechanical keys
New genuine mechanical keys can be made by your Lexus dealer using the other
mechanical key and the key number stamped on your key number plate. Keep the plate
in a safe place such as your wallet, not in the vehicle.
■ When riding in an aircraft
When bringing an electronic key onto an aircraft, make sure you do not press any buttons on the electronic key while inside the aircraft cabin. If you are carrying an electronic
key in your bag etc., ensure that the buttons are not likely to be pressed accidentally.
Pressing a button may cause the electronic key to emit radio waves that could interfere
with the operation of the aircraft.
■ Electronic key battery depletion
● The standard battery life is 1 to 2 years.
● If the battery becomes low, an alarm will sound in the cabin when the engine stops.
(→P. 457)
● As the electronic key always receives radio waves, the battery will become depleted
even if the electronic key is not used. The following symptoms indicate that the electronic key battery may be depleted. Replace the battery when necessary. (→P. 457)
• The smart access system with push-button start or the wireless remote control does
not operate.
• The detection area becomes smaller.
• The LED indicator on the key surface does not turn on.
● To avoid serious deterioration, do not leave the electronic key within 3 ft. (1 m) of the
following electrical appliances that produce a magnetic field:
•TVs
• Personal computers
• Cellular phones, cordless phones and battery chargers
• Recharging cellular phones or cordless phones
•Table lamps
• Induction cookers
■ If “Key Battery Low” is displayed on the multi-information display
The electronic key has a low battery. Replace the electronic key battery. (→P. 457)
93
3
Operation of each component
ES350_OM_OM06134U_(U)
94
NOTICE
■ Replacing the battery
3-1. Key information
→P. 457
■ Confirmation of the registered key number
The number of keys already registered to the vehicle can be confirmed. Ask your Lexus
dealer for details.
■ If a wrong key is used
The key cylinder rotates freely to isolate inside mechanism.
■ To prevent key damage
● Do not drop the keys, subject them to strong shocks or bend them.
● Do not expose the keys to high temperatures for long periods of time.
● Do not get the keys wet or wash them in an ultrasonic washer etc.
● Do not attach metallic or magnetic materials to the keys or place the keys close to
such materials.
● Do not disassemble the keys.
● Do not attach a sticker or anything else to the surface of the electronic key.
● Do not place the keys near objects that produce magnetic fields, such as TVs, audio
systems and induction cookers, or medical electrical equipment, such as low-frequency therapy equipment.
■ Carrying the electronic key on your person
Carry the electronic key 3.9 in. (10 cm) or more away from electric appliances that are
turned on. Radio waves emitted from electric appliances within 3.9 in. (10 cm) of the
electronic key may interfere with the key, causing the key to not function properly.
■ In case of a smart access system with push-button start malfunction or other key-
related problems
Take your vehicle with all the electronic keys provided with your vehicle to your Lexus
dealer.
■ When an electronic key is lost
If the electronic key remains lost, the risk of vehicle theft increases significantly. Visit
your Lexus dealer immediately with all remaining electronic keys that was provided
with your vehicle.
ES350_OM_OM06134U_(U)
3-2. Opening, closing and locking the doors and trunk
1
Doors
Unlocking and locking the doors from the outside
◆ Smart access system with push-button start
Carry the electronic key to enable this function.
Grip the driver’s door handle to
unlock the door. Grip the passenger’s door handle to unlock all the
doors.
*
Make sure to touch the sensor on the
back of the handle.
The doors cannot be unlocked for
3 seconds after the doors are locked.
*: The door unlock settings can be
changed. (→P. 542)
2
Touch the lock sensor (the indentation on the upper part of the door handle) to lock all the doors.
Check that the door is securely locked.
◆ Wireless remote control
95
3
Operation of each component
1
Locks all the doors
Check that the door is securely
locked.
2
Unlocks all the doors
Pressing the button unlocks the
driver’s door. Pressing the button
again within 5 seconds unlocks the
other doors.
Press and hold to open the windows
and moon roof
: This setting must be customized at your Lexus dealer.
*
*
ES350_OM_OM06134U_(U)
96
■ Operation signals
3-2. Opening, closing and locking the doors and trunk
A buzzer sounds and the emergency flashers flash to indicate that the doors have been
locked/unlocked. (Locked: Once; Unlocked: Twice)
Windows and moon roof:
A buzzer sounds to indicate that the windows and moon roof are opening.
■ Security feature
If a door is not opened within approximately 60 seconds after the vehicle is unlocked, the
security feature automatically locks the vehicle again.
■ Welcome light illumination control
The side marker, parking, tail and license plate lights automatically turn on at night when
the doors are unlocked using the entry function or wireless remote control if the light
switch is in the “AUTO” position.
■ When the door cannot be locked by the lock sensor on the upper part of the door han-
dle
If the door will not lock even when the topside
sensor area is touched, try touching both the
topside and underside sensor areas at the same
time.
■ Door lock buzzer
If an attempt to lock the doors is made when a door is not fully closed, a buzzer sounds
continuously for 5 seconds. Fully close the door to stop the buzzer, and lock the vehicle
once more.
■ Setting the alarm
Locking the doors will set the alarm system. (→P. 67)
■ If the smart access system with push-button start or the wireless remote control does
not operate properly
● Use the mechanical key to lock and unlock the doors. (→P. 504)
● Replace the key battery with a new one if it is depleted. (→P. 457)
ES350_OM_OM06134U_(U)
3-2. Opening, closing and locking the doors and trunk
1
2
Unlocking and locking the doors from the inside
◆ Door lock switch
1
Locks all the doors
2
Unlocks all the doors
97
◆ Inside lock buttons
1
Locks the door
2
Unlocks the door
The front doors can be opened by
pulling the inside handle even if the
lock buttons are in the lock position.
Locking the front doors from the outside without a key
Move the inside lock button to the lock position.
Close the door.
The door cannot be locked if the engine switch is in ACCESSORY or IGNITION ON mode, or the electronic key is left inside the vehicle.
The key may not be detected correctly and the door may be locked.
3
Operation of each component
ES350_OM_OM06134U_(U)
98
1
2
3-2. Opening, closing and locking the doors and trunk
Rear door child-protector lock
The door cannot be opened from inside
the vehicle when the lock is set.
Unlock
Lock
These locks can be set to prevent children from opening the rear doors. Push
down on each rear door switch to lock
both rear doors.
Automatic door locking and unlocking systems
The following functions can be set or canceled:
For instructions on customizing, refer to P. 538.
Function Operation
Shift position linked
door locking function
Shift position linked
door unlocking function
Speed linked door locking
function
Driver’s door linked door
unlocking function
Shifting the shift lever out of P locks all doors.
Shifting the shift lever to P unlocks all doors.
All doors are locked when the vehicle speed is approximately 12 mph (20 km/h) or higher.
All doors are unlocked when the driver’s door is
opened within 45 seconds after turning the engine
switch off.
ES350_OM_OM06134U_(U)
3-2. Opening, closing and locking the doors and trunk
2
2
■ Switching the door unlock function
It is possible to set which doors the entry function unlocks using the wireless remote control.
1
Turn the engine switch off.
When the indicator light on the key surface is not on, press and hold , or
for approximately 5 seconds while pressing and holding .
The setting changes each time an operation is performed, as shown below. (When
changing the setting continuously, release the buttons, wait for at least 5 seconds, and
repeat step .)
99
Multi-information
display
Unlocking function Beep
Holding the driver’s door handle
unlocks only the driver’s door.
Holding a passenger’s door han-
Exterior: Beeps 3 times
Interior: Pings once
dle unlocks all the doors.
Holding a door handle unlocks
all the doors.
Exterior: Beeps twice
Interior: Pings once
To prevent unintended triggering of the alarm, unlock the doors using the wireless
remote control and open and close a door once after the settings have been changed. (If
a door is not opened within 60 seconds after is pressed, the doors will be locked
again and the alarm will automatically be set.)
In case that the alarm is triggered, immediately stop the alarm. (→P. 67)
■ Impact detection door lock release system
In the event that the vehicle is subject to a strong impact, all the doors are unlocked.
Depending on the force of the impact or the type of accident, however, the system may
not operate.
■ Using the mechanical key
The doors can also be locked and unlocked with the mechanical key. (→P. 504)
■ Conditions affecting the operation of the smart access system with push-button start
or wireless remote control
→P. 110
■ Customization
Settings (e.g. unlocking function using a key) can be changed.
(Customizable features: →P. 538)
3
Operation of each component
ES350_OM_OM06134U_(U)
100
WARNING
■ To prevent an accident
3-2. Opening, closing and locking the doors and trunk
Observe the following precautions while driving the vehicle.
Failure to do so may result in a door opening and an occupant throwing out of the vehicle, resulting in death or serious injury.
● Ensure that all doors are properly closed and locked.
● Do not pull the inside handle of the doors while driving.
Be especially careful for the front doors, as the doors may be opened even if the
inside lock buttons are in locked position.
● Set the rear door child-protector locks when children are seated in the rear seats.
ES350_OM_OM06134U_(U)
Loading...
