FRONT SEATS
Front seat precautions
SECTION 1 –
INSTRUMENTS AND CONTROLS
Comfort adjustment
Front seats 117. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trunk storage extension 124. . . . . . . . . . . . . . . . . . . . . . .
Head restraints 126. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tilt steering wheell 129. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside rear view mirrors 130. . . . . . . . . . . . . . . . . . . . . .
Inside rear view mirror 134. . . . . . . . . . . . . . . . . . . . . . . . .
Seat belts 136. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SRS airbags 152. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Child restraint 175. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driving position memory system 204. . . . . . . . . . . . . . . .
6
117
COMFORT ADJUSTMENT
CAUTION
The SRS side airbags are installed in the driver and front
passenger seats, observe the following precautions.
Do not lean over the front door when the vehicle is in
use. The side airbag inflates with considerable speed
and force; you may be killed or severely injured.
Do not use accessories for the seats which cover the
parts where the side airbags inflate. Such
accessories may prevent the side airbags from
activating correctly, causing death or serious injury.
Do not modify or replace the seats or upholstery of
the front seats with the side airbags. Such changes
may disable the system or cause the side airbags to
inflate accidentally, resulting in death or serious
injury. Consult your Lexus dealer if you insist on
modifications of this kind.
118
Seat adjustment precautions
Adjust the driver’s seat so that the foot pedals, steering
wheel and instrument panel controls are within easy
reach of the driver.
CAUTION
Do not adjust the seat while the vehicle is moving as
the seat may unexpectedly move and cause the
driver to lose control of the vehicle.
Be careful not to hit the seat against a passenger,
luggage or the rear seat.
COMFORT ADJUSTMENT
NOTICE
Do not operate the control switch in more than
one dimension at a time. It may cause electrical
overload.
Adjusting front seats
119
COMFORT ADJUSTMENT
16E153a
120
1
Seat position control switch, seat cushion
angle
and height control switch
2
Seatback angle control switch
3
Lumbar support control switch
16E154a
Move the control switch in the desired direction.
Releasing the switch will stop the seat in that position.
Do not place anything under the seat. It might interfere
with the seat movement.
COMFORT ADJUSTMENT
Adjusting seat position
121
COMFORT ADJUSTMENT
Adjusting seatback angle
16E155a
Move the control switch in the desired direction.
Releasing the switch will stop the seatback in that
position.
CAUTION
To reduce the risk of sliding under the lap belt during a
collision, avoid reclining the seatback any more than
needed. The seat belts provide maximum protection in
a frontal or rear collision when the driver and the
passenger are sitting up straight and well back in the
seats. If you are reclined, the lap belt may slide past
your hips and apply restraint forces directly to the
abdomen. Therefore, in the event of a frontal collision,
the risk of personal injury may increase with increasing
recline of the seatback.
122
Adjusting seat cushion angle and height
16E156a
Move the control switch in the desired direction.
Releasing the switch will stop the seat cushion in that
position.
COMFORT ADJUSTMENT
123
COMFORT ADJUSTMENT
Adjusting lumbar support
(driver’s seat only)
16E142
Push the control switch on either side.
The amount of lumbar support will change as long as the
switch is pushed.
16E196
124
TRUNK STORAGE EXTENSION
1
Unlock 2Lock 3Open
Pull down the center armrest in the rear seat. Pull
the lever of the armrest door and open the armrest
door.
Access to the trunk can be prevented by locking the
armrest door with the master key.
See “Luggage stowage precautions” on page 99 for
precautions to observe in loading luggage.
CAUTION
Be sure to close the door when the trunk storage
extension is not in use. Luggage or cargo in the trunk
may be thrown into the passenger compartment in a
sudden stop or crash resulting in injury.
COMFORT ADJUSTMENT
125
COMFORT ADJUSTMENT
HEAD RESTRAINTS
Front seats
16E007
To raise the head restraint, pull it up. To lower it,
press the lock release button and push the head
restraint down. To move the head restraint forward
or rearward, pull or push on the top.
The head restraint is most effective when it is close to
your head. Therefore, using a cushion on the seatback
is not recommended.
126
CAUTION
Adjust the center of the head restraint so that it is
closest to the top of your ears.
After adjusting the head restraint, make sure it is
locked in position.
Do not drive with the head restraints removed.
COMFORT ADJUSTMENT
127
COMFORT ADJUSTMENT
Rear seats
16E222
To raise the head restraint, pull it up. To lower it,
press the lock release button and push the head
restraint down. To move the head restraint forward
or rearward, pull or push on the top.
The head restraint is most effective when it is close to
your head. Therefore, using a cushion on the seatback
is not recommended.
CAUTION
Adjust the center of the head restraint so that it is
closest to the top of your ears.
After adjusting the head restraint, make sure it is
locked in position.
Do not drive with the head restraints removed.
128
TILT STEERING WHEEL
16E009
To change the steering wheel angle, hold the
steering wheel, pull up the lock release lever, tilt the
steering wheel to the desired angle and release the
lever.
When the steering wheel is in a low position, it will spring
up as you release the lock release lever.
CAUTION
Do not adjust the steering wheel while the vehicle is
moving. It may cause the driver to mishandle the
vehicle and an accident may occur resulting in death
or serious injuries.
After adjusting the steering wheel, try moving it up
and down to make sure it is locked in position.
COMFORT ADJUSTMENT
129
COMFORT ADJUSTMENT
OUTSIDE REAR VIEW MIRRORS
16E197
Adjust the m irror so that you can just see the side of
your vehicle in the mirror.
Be careful when judging the size or distance of any
object seen in the outside rear view mirror on the
passenger’s side. It is a convex mirror with a curved
surface. Any object seen in a convex mirror will look
smaller and farther away than if seen in a normal flat
mirror.
When the inside rear view mirror darkens in “AUTO”
mode, the driver’s side outside rear view mirror also
darken to reduce the reflection of the headlights of the
following vehicle. For details, see “Inside rear view
mirror” on page 134.
130
When you push the rear window and outside rear view
mirror defogger switch, the heater panels in the outside
rear view mirrors will quickly clear the mirror surface.
CAUTION
Do not adjust the mirror while the vehicle is moving.
It may cause the driver to mishandle the vehicle and
an accident may occur resulting in death or serious
injuries.
Since the mirror surfaces can get hot, keep your
hands off them when the rear window and outside
rear view mirror defogger switch is on.
COMFORT ADJUSTMENT
131
COMFORT ADJUSTMENT
Power rear view mirror control
16E011
1
Control switch 2Master switch
To adjust the power rear view mirror, first place the
master switch at “L” (left) or “R” (right), and push
the control switch on the desired side.
The power rear view mirror can be adjusted when the
key is in the “ACC” or “ON” position.
NOTICE
If ice should jam the mirror, do not operate the
control or scrape the mirror face. Use a spray
de–icer to free the mirror.
132
Folding rear view mirrors
16E198
To fold the rear view mirror, push backward.
The rear view mirrors can be folded backward for
parking in restricted areas.
CAUTION
Do not drive with the mirrors folded backward. Both the
driver and passenger side rear view mirrors must be
extended and properly adjusted before driving.
COMFORT ADJUSTMENT
133
COMFORT ADJUSTMENT
INSIDE REAR VIEW MIRROR
16E178
134
COMFORT ADJUSTMENT
Adjust the mirror so that you can just see the rear of
your vehicle in the mirror.
Pushing the switch changes the mode between
“AUTO” and “DAY”.
The indicator comes on when the “AUTO” mode is
selected.
“DAY” mode: The mirror surface is normal.
“AUTO” mode: If the mirror detects light from the
headlights of the vehicle behind you, the mirror
surface darkens slightly to reduce the reflected
light.
When the inside rear view mirror surface changes, the
driver’s side outside rear view mirror surface will also
become darker.
When the ignition key is inserted and turned on, the
inside rear view mirror always turns on in the “AUTO”
mode.
CAUTION
Do not adjust the mirror while the vehicle is moving. It
may cause the driver to mishandle the vehicle and an
accident may occur resulting in death or serious
injuries.
When the outside air temperature is low, it may take a
little longer for the mirror to darken in response to the
detection of headlights.
135
COMFORT ADJUSTMENT
SEAT BELTS
Seat belt precautions
Lexus strongly urges that the driver and passengers in
the vehicle be properly restrained at all times with the
seat belts provided. Failure to do so could increase the
chance of injury and/or the severity of injury in accidents.
Child. Use a child restraint system appropriate for the
child until the child becomes large enough to properly
wear the vehicle’s seat belts. See “Child restraint” on
page 175 for details.
If a child is too large for a child restraint system, the child
should sit in the rear seat and must be restrained using
the vehicle’s seat belt. According to accident statistics,
the child is safer when properly restrained in the rear
seat than in the front seat.
If a child must sit in the front seat, the seat belts should
be worn properly. Do not let the child sit on your lap. It
does not provide sufficient restraint. If an accident
occurs and the seat belts are not worn properly, the force
of the rapid inflation of the airbag may cause death or
serious injury to the child.
Do not allow the child to stand up or kneel on either rear
or front seats. An unrestrained child could suffer serious
injury or death during emergency braking or a collision.
Pregnant woman. Lexus recommends the use of a
seat belt. Ask your doctor for specific
recommendations. The lap belt should be worn securely
and as low as possible over the hips and not on the waist.
136
Injured person. Lexus recommends the use of a seat
belt. Depending on the injury, first check with your doctor
for specific recommendations.
COMFORT ADJUSTMENT
137
COMFORT ADJUSTMENT
CAUTION
Persons should ride in their seats properly wearing
their seat belts whenever the vehicle is moving.
Otherwise, they are much more likely to suffer serious
bodily injury or death in the event of sudden braking or
a collision.
When using the seat belts, observe the following:
Use the belt for only one person at a time. Do not use
a single belt for two or more people – even children.
Avoid reclining the seatbacks too much. The seat
belts provide maximum protection when the
seatbacks are in the upright position. (See
“Adjusting seatback angle” on page 122.)
Be careful not to damage the belt webbing or
hardware. Take care that they do not get caught or
pinched in the seat or doors.
Inspect the belt system periodically . Check for cuts,
fraying, and loose parts. Damaged parts should be
replaced. Do not disassemble or modify the system.
Keep the belts clean and dry. If they need cleaning,
use a mild soap solution or lukewarm water. Never
use bleach, dye, or abrasive cleaners – they may
severely weaken the belts. (See “Cleaning the
interior” on page 482 for instructions.)
138
Replace the belt assembly (including bolts) if it
has been used in a severe impact. The entire
assembly should be replaced even if damage is
not obvious.
COMFORT ADJUSTMENT
139
COMFORT ADJUSTMENT
Fastening front and rear seat belts
16E014a
Adjust the seat as needed and sit up straight and
well back in the seat. T o fasten your belt, pull it out
of the retractor and insert the tab into the buckle.
You will hear a click when the tab locks into the buckle.
The seat belt length automatically adjusts to your size
and the seat position.
The retractor will lock the belt during a sudden stop or on
impact. It also may lock if you lean forward too quickly .
A slow, easy motion will allow the belt to extend, and you
can move around freely.
140
When a passenger’s shoulder belt is completely
extended and is then retracted even slightly, the belt is
locked in that position and cannot be extended. This
feature is used to hold the child restraint system
securely. (For details, see “Child restraint” on page 175.)
To free the belt again, fully retract the belt and then pull
the belt out once more.
If the seat belt cannot be pulled out of the retractor, firmly
pull the belt and release it. You will then be able to
smoothly pull the belt out of the retractor.
CAUTION
After inserting the tab, make sure the tab and buckle
are locked and that the belt is not twisted.
Do not insert coins, clips, etc. in the buckle as this
may prevent you from properly latching the tab and
buckle.
If the seat belt does not function normally,
immediately contact your Lexus dealer. Do not use
the seat until the seat belt is fixed. It cannot protect
an adult occupant or your child from injury.
16E245
COMFORT ADJUSTMENT
141
COMFORT ADJUSTMENT
Adjust the position of the lap and shoulder belts.
1
Position the lap belt as low as possible on your hips
– not on your waist.
2
Adjust it to a snug fit by pulling the shoulder portion
upward through the latch plate.
CAUTION
Both high–positioned lap belts and loose–fitting
belts could cause serious injuries due to sliding
under the lap belt during a collision or other
unintended result. Keep the lap belt positioned as
low on hip as possible.
For your safety, do not place the shoulder belt under
your arm.
16E246
142
Front seat belts only
Adjust the shoulder anchor position to your size.
To raise the anchor position, push the anchor up. To
lower the anchor position, support the anchor while you
push the lock release button then slide the anchor down.
After the adjustment, make sure the anchor is locked in
position.
CAUTION
Always make sure the shoulder belt is positioned
across the center of your shoulder. The belt should be
kept away from your neck, but not falling off your
shoulder. Failure to do so could reduce the amount of
protection in an accident and cause severe injuries in a
collision.
16E017a
COMFORT ADJUSTMENT
143
COMFORT ADJUSTMENT
To release the belt, press the buckle release button
and allow the belt to retract.
If the belt does not retract smoothly, pull it out and check
for kinks or twists. Then make sure it remains untwisted
as it retracts.
CAUTION
When using the seat belt extender, observe the
following. Failure to follow these instructions could
result in less effectiveness of the seat belt restraint
system in case of vehicle accident, increasing the
chance of personal injury.
Never use the seat belt extender if you can fasten the
seat belt without it.
Remember that the extender provided for you may
not be safe when used on a different vehicle, or for
another person or at a different seating position than
the one originally intended for.
Seat belt extender
If your seat belts cannot be fastened securely because
it is not long enough, a personalized seat belt extender
is available from your Lexus dealer free of charge.
Please contact your local Lexus dealer so that the dealer
can order the proper required length for the extender.
Bring the heaviest coat you expect to wear for proper
measurement and selection of length. Additional
ordering information is available at your Lexus dealer.
144
16E018–2
To connect the extender to the seat belt, insert the
tab into the seat belt buckle so that the “PRESS”
signs on the buckle release buttons of the extender
and the seat belt are both facing outward as shown.
You will hear a click when the tab locks into the buckle.
When releasing the seat belt, press on the buckle
release butto n o n t h e e x t ender, not on the seat belt. This
helps prevent damage to the vehicle interior and
extender itself.
When not in use, remove the extender and store in the
vehicle for future use.
COMFORT ADJUSTMENT
145
COMFORT ADJUSTMENT
CAUTION
After inserting the tab, make sure the tab and buckle
are locked and that the belt is not twisted.
Do not insert coins, clips, etc. in the buckle as this
may prevent you from properly latching the tab and
buckle.
If the seat belt does not function normally,
immediately contact your Lexus dealer. Do not use
the seat until the seat belt is fixed. It cannot protect
an adult occupant or your child from injury.
146
Front seat belt pretensioners
16E228
The driver and front passenger’s seat belt
pretensioners are designed to be activated in
response to a severe frontal impact.
When the airbag sensor detects the shock of a severe
frontal impact, the front seat belts are quickly drawn
back in by the retractors so that the belts snugly restrain
the front seat occupants.
The front seat belt pretensioners are activated even with
no passenger in the front seat.
Collisions occurring at certain speeds and angles may
cause the seat belt pretensioners and SRS airbags not
to operate all together.
COMFORT ADJUSTMENT
147
COMFORT ADJUSTMENT
16E179
This indicator comes on when the ignition key is
turned to the “ACC” or “ON” position. It goes off
after about 6 seconds. This means the front seat belt
pretensioners are operating properly.
This warning light system monitors the airbag sensor
assembly, front airbag sensors, side airbag sensors,
front seat belt pretensioner assemblies, inflators,
warning light, interconnecting wiring and power sources.
(For details, see “Service reminder indicators and
warning buzzers” on page 60 for instructions.)
148
16E229
1
Front seat belt pretensioner assemblies
2
SRS warning light
3
Airbag sensor assembly
4
Front airbag sensors
The front seat belt pretensioner system mainly consists
of the above components, and their locations are shown
in the illustration.
The front seat belt pretensioners are controlled by the
airbag sensor assembly. The airbag sensor assembly
consists of a safing sensor and airbag sensor.
When the front seat belt pretensioners are activated, an
operating noise may be heard and a small amount of
smoke–like gas may be released. This gas is harmless
and does not indicate that a fire is occurring.
Once the front seat belt pretensioners have been
activated, the seat belt retractors remain locked.
COMFORT ADJUSTMENT
149
COMFORT ADJUSTMENT
CAUTION
Do not modify, remove, strike or open the front seat belt
pretensioner assemblies, airbag sensor or surrounding
area or wiring. Doing any of these may cause sudden
operation of the front seat belt pretensioners or disable
the system, which could result in death or serious
injury.
Failure to follow these instructions can result in death
or serious injuries.
NOTICE
Do not perform any of the following changes
without consulting your Lexus dealer. Such
changes can interfere with proper operation of the
front seat belt pretensioners in some cases.
Installation of electronic devices such as a
mobile two–way radio, cassette tape player or
compact disc player
Repairs on or near the front seat belt retractor
assemblies
Modification of the suspension system
Modification of the front end structure
Attachment of a grille guard (bull bar, kangaroo
bar, etc.), snowplow, winches or any other
equipment to the front end
Repair made on or near the front fenders, front
end structure or console
150
16E179
This front seat belt pretensioner system has a service
reminder indicator to inform the driver of operating
problems. If any of the following conditions occurs, this
indicates a malfunction of the airbags or pretensioners.
Contact your Lexus dealer as soon as possible to
service the vehicle.
The light does not come on when the ignition key is
turned to the “ACC” or “ON” position, or the light
remains on.
The light comes on or flashes while driving.
If either front seat belt does not retract or cannot be
pulled out due to a malfunction or activation of the
relevant front seat belt pretensioner.
COMFORT ADJUSTMENT
151
COMFORT ADJUSTMENT
16E230
In the following cases, contact your Lexus dealer as
soon as possible:
The front part of the vehicle (shaded in the illustration)
was involved in an accident that was not severe
enough to cause the front seat belt pretensioners to
operate.
Either front seat belt pretensioner assembly or
surrounding area is scratched, cracked, or otherwise
damaged.
16E231
152
SRS AIRBAGS
The SRS (Supplemental Restraint System) airbags
are designed to provide further protection for the
driver and front passenger in addition to the primary
safety protection provided by the seat belts.
SRS front airbags
In response to a severe frontal impact, the SRS front
airbags work together with the seat belts to help
reduce injury by inflating. The SRS front airbags
help to reduce injuries mainly to the driver’s or front
passenger’s head or chest caused by directly hitting
the steering wheel or dashboard.
The front passenger airbag is activated even with no
passenger in the front seat.
Be sure to wear your seat belt properly.
COMFORT ADJUSTMENT
153
COMFORT ADJUSTMENT
CAUTION
The driver or front passenger too close to the steering
wheel or dashboard during airbag deployment can be
killed or seriously injured. Lexus strongly recommends
that:
The driver sit as far back as possible from the
steering wheel while still maintaining control of the
vehicle.
The front passenger sit as far back as possible from
the dashboard.
All vehicle occupants be properly restrained using
the available seat belts.
16E257
154
SRS side airbags
In response to a severe side impact, the SRS side
airbags work together with the seat belts to help
reduce injury by inflating. The SRS side airbags help
to reduce injuries mainly to the driver’s or front
passenger’s chest.
The SRS side airbag on the passenger seat is activated
even with no passenger in the front seat.
Be sure to wear your seat belt properly.
COMFORT ADJUSTMENT
155
COMFORT ADJUSTMENT
CAUTION
SRS side airbags inflate with considerable force. To
avoid potential death or serious injury when they inflate,
the driver and front passenger must:
Wear their seat belts properly.
Remain properly seated with their back upright and
against the seat at all times.
16E179
156
The indicator comes on when the ignition key is
turned to the “ACC” or “ON” position. It goes off
after about 6 seconds. This means the SRS airbags
are operating properly.
This warning light system monitors the airbag sensor
assembly, front airbag sensors, side airbag sensors,
front seat belt pretensioner assemblies, inflators,
warning light, interconnecting wiring and power sources.
(For details, see “Service reminder indicators and
warning buzzers” on page 60 for instructions.)
16E023
COMFORT ADJUSTMENT
The SRS front airbag system is designed to activate
in response to a severe frontal impact within the
shaded area between the arrows in the illustration.
The SRS front airbags will deploy if the severity of the
impact is above the designed threshold level,
comparable to an approximate 25 km/h (15 mph)
collision when impacting straight into a fixed barrier that
does not move or deform.
If the severity of the impact is below the above threshold
level, the SRS front airbags may not deploy.
However, this threshold velocity will be considerably
higher if the vehicle strikes an object, such as a parked
vehicle or sign pole, which can move or deform on
impact, or if it is involved in an underride collision (e.g.
a collision in which the nose of the vehicle “underrides”,
or goes under, the bed of a truck, etc.).
It is possible that in some collisions at the lower zone of
airbag sensor detection and activation the SRS airbags
and seat belt pretensioners will not operate all together.
For the safety of all occupants, always wear your seat
belts properly.
157
COMFORT ADJUSTMENT
16E134–1
1
Collision from the rear
2
Vehicle rollover
The SRS front airbags are not designed to inflate if
the vehicle is involved in a rear collision, if it rolls
over, or if it is involved in a low–speed frontal
collision.
The SRS side airbags are designed to inflate when
the passenger compartment gets a severe collision
from the side.
The SRS side airbags may rather not to activate in the
impact in which the occupant wearing the seat belt
correctly would not get serious injury.
158
16E135
1
Collision from the side at an angle
2
Collision from the side to the vehicle body
other
than the passenger compartment
The SRS side airbag system may not activate if the
vehicle is subjected to a collision from the side at
certain angles, or a collision to the side of the
vehicle body other than the passenger
compartment as shown in the illustration.
COMFORT ADJUSTMENT
159
COMFORT ADJUSTMENT
16E171
1
Collision from the front
2
Collision from the rear
3
Vehicle rollover
The SRS side airbags are not designed to inflate if
the vehicle is involved in a front or rear collision, if
it rolls over, or if it is involved in a low–speed side
collision.
160
16E159
1
Hitting a curb, edge of pavement or hard
material
2
Falling into or jumping over a deep hole
3
Landing hard or vehicle falling
The SRS front airbags may deploy if a serious
impact occurs to the underside of your vehicle.
Some examples are shown in the illustration.
COMFORT ADJUSTMENT
161
COMFORT ADJUSTMENT
16E232
1
Side airbag modules (airbag and inflator)
2
Airbag module for front passenger
(airbag and inflator)
3
Side airbag sensors
4
Airbag module for driver (airbag and inflator)
5
SRS warning light
6
Airbag sensor assembly
7
Front airbag sensors
The SRS airbag system consists mainly of the above
components, and their locations are shown in the
illustration.
The airbag sensor assembly consists of a safing sensor
and airbag sensor.
162
In a severe frontal impact, the sensors detect
deceleration and the system triggers the front airbag
inflators. In a severe side impact, the side airbag sensor
triggers the side airbag inflator. Then a chemical
reaction in the inflators quickly fills the airbags with
non–toxic gas to help restrain the forward or lateral
motion of the occupants.
When the SRS operates, it produces a fairly loud noise
and release some smoke and residue along with
non–toxic gas. This does not indicate a fire. This gas is
normally harmless; however, for those who have
delicate skin, it may cause a minor skin irritation. Be
sure to wash off any residue as soon as possible to
prevent any potential skin irritation.
Deployment of the airbags happens in a fraction of a
second, so the airbags must inflate with considerable
force. While the system is designed to reduce serious
injuries, it may also cause minor burns or abrasions and
swelling.
Parts of the airbag module (steering wheel hub,
dashboard, front seats) may be hot for several minutes,
but the airbags themselves will not be hot. The airbags
are designed to inflate only once.
A crash severe enough to inflate the driver and front
passenger airbags may break the windshield as the
vehicle buckles. In vehicles with a front passenger
airbag, the windshield may also be damaged by
absorbing some of the force of the inflating airbag.
COMFORT ADJUSTMENT
163
COMFORT ADJUSTMENT
CAUTION
The SRS airbag system is designed only as a
supplement to the primary protection of the driver
side and front passenger side seat belt systems. The
front seat occupants can be killed or seriously
injured by the inflating airbags if they do not wear the
available seat belts properly. During sudden braking
just before a collision, an unrestrained driver or front
passenger can move forward into direct contact with
or close proximity to the airbag which may then
deploy during the collision. To ensure maximum
protection in an accident, the driver and all
passengers in the vehicle must wear their seat belts
properly. Wearing a seat belt properly during an
accident reduces the chances of death or serious
injury or being thrown out of the vehicle. For
instructions and precautions concerning the seat
belt system, see “Seat belts” on page 136.
Improperly seated and/or restrained infants and
children can be killed or seriously injured by the
deploying airbags. An infant or child who is too small
to use a seat belt should be properly secured using
a child restraint system. Lexus strongly
recommends that all infants and children be placed
in the rear seat of the vehicle and properly restrained.
The rear seat is the safest for infants and children.
For instructions concerning the installation of a child
restraint system, see “Child restraint” on page 175 .
164
16E177
Never put a rear–facing child restraint system
on the front passenger seat because the force
of the rapid inflation of the front passenger
airbag can cause death or serious injury to the
child.
COMFORT ADJUSTMENT
165
COMFORT ADJUSTMENT
16L146
Move seat fully back
A forward–facing child restraint system should
be allowed to be put on the front passenger
seat only when it is unavoidable. Always move
the seat as far back as possible, because the
force of the deploying front passenger airbag
could cause death or serious injury to the child.
Do not allow the child to lean against the front
door or around the front door even if the child
is seated in a child restraint system. It is
dangerous if the side airbag inflates, and the
impact could cause death or serious injury to
the child.
For instructions concerning the installation of
a child restraint system, see “Child restraint”
on page 175.
166
16E028
Do not sit on the edge of the seat or lean over
the dashboard when the vehicle is in use. The
front airbags inflate with considerable speed
and force; you may be killed or seriously
injured. Sit up straight and well back in the seat,
and always use your seat belt properly.
COMFORT ADJUSTMENT
167
COMFORT ADJUSTMENT
16E126
Do not lean against the front door when the
vehicle is in use. The side airbag inflates with
considerable speed and force; you may be
killed or seriously injured.
Do not apply excessive weight to the outer side
of the front seats on vehicles with side airbags.
168
16E029
Do not allow a child to stand up, or to kneel on
the front passenger seat. The front airbag
inflates with considerable speed and force; the
child may be killed or seriously injured.
Do not hold a child on your lap or in your arms.
Use a child restraint system in the rear seat.
For instructions concerning the installation of
a child restraint system, see “Child restraint”
on page 175.
COMFORT ADJUSTMENT
169
COMFORT ADJUSTMENT
16E030
Do not put objects or your pets on or in front of
the dashboard or steering wheel pad that
houses the front airbag system. They might
restrict inflation or cause death or serious
injury as they are projected rearward by the
force of the deploying airbags. Likewise, the
driver and front passenger should not hold
things in their arms or on their knees.
170
16E127
Do not attach a cup holder or any other device
or object on or around the door. When the side
airbag inflates, the cup holder or any other
device or object will be thrown with great force,
or the side airbag may not activate correctly,
resulting in death or serious injury. Likewise,
the driver and front passenger should not hold
things in their arms or on their knees.
COMFORT ADJUSTMENT
171
COMFORT ADJUSTMENT
Do not use accessories for the seats which
cover the parts where the side airbags inflate.
Such accessories may prevent the side airbags
from activating correctly, causing death or
serious injury.
Do not modify or remove any wiring. Do not
modify, remove, strike or open any
components, such as the steering wheel pad,
steering wheel, column cover, front passenger
airbag cover, front seats or airbag sensor
assembly. Doing any of these may cause
sudden SRS airbag inflation or disable the
system, which could result in death or serious
injury.
Do not modify or replace the seats or
upholstery of the front seats with the side
airbags. Such changes may disable the system
or cause the si de airbags to inflate accidentally,
resulting in death or serious injury. Consult
your Lexus dealer if you insist on modifications
of this kind.
Failure to follow these instructions can result in
death or serious injury.
NOTICE
Do not perform any of the following changes
without consulting your Lexus dealer. Such
changes can interfere with proper operation of the
SRS in some cases.
Installation of electronic devices such as a
mobile two–way radio, cassette tape player or
compact disc player
Modification of the suspension system
Modification of the front end structure and side
structure of the passenger compartment
Attachment of a grille guard (bull bar, kangaroo
bar, etc.), snowplow, winches or any other
equipment to the front end
Repairs made on or near the front fenders, front
end structure, console, steering column,
steering wheel, dashboard near the front
passenger airbag or front seats
172
16E179
This SRS airbag system has an indicator to inform the
driver of operating problems. If either of the following
conditions occurs, this indicates a malfunction of the
airbags. Contact your Lexus dealer as soon as possible
to service the vehicle.
When the ignition key is turned to the “ACC” or “ON”
position, the light does not come on, stays on or
flashes.
The light comes on or starts flashing while driving.
If the light stays on, it indicates that the SRS front airbags
fail. If the light flashes, the SRS side airbags fail.
COMFORT ADJUSTMENT
173
COMFORT ADJUSTMENT
16E218
174
COMFORT ADJUSTMENT
In the following cases, contact your Lexus dealer as
soon as possible:
Any of the SRS airbags have been inflated.
The front part of the vehicle and portion of the doors
(shaded in the illustration) were involved in an
accident that was not severe enough to cause the
SRS airbags to inflate.
The surface of the seats with the side airbags or the
pad section of the steering wheel or front passenger
airbag cover (shaded in the illustration) is scratched,
cracked, or otherwise damaged.
NOTICE
Do not disconnect the battery cables before
contacting your Lexus dealer.
CHILD RESTRAINT
Child restraint precautions
Lexus strongly urges the use of child restraint
systems for children small enough to use them.
The laws of all fifty states in the U.S.A. and Canada now
require the use of a child restraint system.
Your vehicle conforms to SAE J1819.
If a child is too large for a child restraint system, the child
should sit in the rear seat and must be restrained using
the vehicle’s seat belt. See “Seat belts” on page 136 for
details.
175
COMFORT ADJUSTMENT
CAUTION
For effective protection in automobile accidents and
sudden stops, child must be properly restrained
using a seat belt or child restraint depending on age
and size. Holding a child in your arms is not a
substitute for a child restraint system. In an accident,
the child can be crushed against the windshield, or
between you and the vehicle’s interior if you are
unrestrained.
Lexus strongly urges use of a proper child restraint
which conforms to the size of the child, and is put on
the rear seat. According to accident statistics, the
child is safer when properly restrained in the rear
seat than in the front seat.
176
Never put a rear–facing child restraint system on the
front seat. In the event of an accident, the force of the
rapid inflation of the airbag can cause death or
serious injury if a rear–facing child restraint system
is put on the front seat.
Unless it is unavoidable, do not put a forward–facing
child restraint system on the front seat.
A forward–facing child restraint system should be
allowed to be put on the front passenger seat only
when it is unavoidable. Always move the seat as far
back as possible, because the force of the deploying
front passenger airbag could cause death or serious
injury to the child.
Do not allow the child to lean against the front door
or around the front door even if the child is seated in
a child restraint system. It is dangerous if the side
airbag inflates, and the impact could cause death or
serious injury to the child.
Make sure you have complied with all installation
instructions provided by the child restraint
manufacturer and that the system is properly
secured.
COMFORT ADJUSTMENT
177
COMFORT ADJUSTMENT
Child restraint system
A child restraint system for a small child or baby
must itself be properly restrained on the seat with
the lap portion of the lap/shoulder belt. You must
carefully consult the manufacturer’s instructions
which accompany the child restraint system.
To provide proper restraint, use a child restraint system
following the manufacturer’s instructions about the
appropriate age and size of the child for the restraint
system.
Install the child restraint system correctly following the
instructions provided by its manufacturer. General
directions are also provided under the following
illustrations.
The child restraint system should be installed on the rear
seat. According to accident statistics, the child is safer
when properly restrained in the rear seat than in the front
seat.
178
CAUTION
Never put a rear–facing child restraint system on the
front seat. In the event of an accident, the force of the
rapid inflation of the airbag can cause death or
serious injury if a rear–facing child restraint system
is put on the front seat.
Unless it is unavoidable, do not put a forward–facing
child restraint system on the front seat.
A forward–facing child restraint system should be
allowed to be put on the front passenger seat only
when it is unavoidable. Always move the seat as far
back as possible, because the force of the deploying
front passenger airbag could cause death or serious
injury to the child.
Do not allow the child to lean against the front door
or around the front door even if the child is seated in
a child restraint system. It is dangerous if the side
airbag inflates, and the impact could cause death or
serious injury to the child.
After installing the child restraint system, make sure
it is secured in place according to the manufacturer’s
instructions. If it is not restrained securely, it may
cause death or serious injury to the child in the event
of a sudden stop or accident.
COMFORT ADJUSTMENT
179
COMFORT ADJUSTMENT
When not using the child restraint system, keep it
secured with the seat belt or place it in the trunk or
somewhere other than in the passenger compartment.
This will prevent it from injuring passengers in the event
of a sudden stop or accident.
Your vehicle has anchors for securing the top strap of a
child restraint system.
For instructions about how to use the anchor bracket,
see “Using a top strap” on page 201.
16E181
Types of child restraint system
Child restraint systems are classified into the following
3 types depending on the child’s age and size.
(A) Infant seat
(B) Convertible seat
(C) Booster seat
Install the child restraint system following the
instructions provided by its manufacturer.
(A) Infant seat
180
(B) Convertible seat
16E182
(C) Booster seat
16E183
COMFORT ADJUSTMENT
181
COMFORT ADJUSTMENT
INSTALLATION WITH 3–POINT TYPE SEAT BELT
(A) Infant seat installation
16E181
An infant seat is used in rear–facing position only.
182
16E177
CAUTION
Never put a rear–facing child restraint system on the
front passenger seat because the force of the rapid
inflation of the front passenger airbag can cause death
or serious injury to the child.
COMFORT ADJUSTMENT
183
COMFORT ADJUSTMENT
16E253
If your driving seat position is not satisfactory, install
the child restraint system at another position.
16E185
184
1. Run the lap and shoulder belt through or around the
infant seat following the instructions provided by its
manufacturer and inserting the tab into the buckle taking
care not to twist the belt. Keep the lap portion of the belt
tight.
COMFORT ADJUSTMENT
185
COMFORT ADJUSTMENT
CAUTION
After inserting the tab, make sure the tab and buckle
are locked and that the lap and shoulder portions of
the belt are not twisted.
Do not insert coins, clips, etc. in the buckle as this
may prevent you from properly latching the tab and
buckle.
If the seat belt does not function normally,
immediately contact your Lexus dealer. Do not use
the seat until the seat belt is fixed. It cannot protect
your child from injury.
16E186
186
2. Fully extend the shoulder belt to put it in the lock
mode. When the belt is then retracted even slightly, it
cannot be extended.
To hold the infant seat securely, make sure the belt is in
the lock mode before letting the belt retract.
16E187
3. While pressing the infant seat firmly against the seat
cushion and seatback, let the shoulder belt retract as far
as it will go to hold the infant seat securely.
COMFORT ADJUSTMENT
187
COMFORT ADJUSTMENT
16E188
CAUTION
Push and pull the child restraint system in different
directions to be sure it is secure. Follow all the
installation instructions provided by its manufacturer.
16E110a
188
COMFORT ADJUSTMENT
4. To remove the infant seat, press the buckle–release
button and allow the belt to retract completely. The belt
will move freely again and be ready to work for an adult
or older child passenger.
16E189
A convertible seat is used in forward–facing or
rear–facing position depending on the age and size of
the child. When installing, follow the manufacturer’s
instructions about the applicable child’s age and size as
well as directions for installing the child restraint system.
(B) Convertible seat installation
189
COMFORT ADJUSTMENT
16E101-1
CAUTION
Never put a rear–facing child restraint system on the
front passenger seat because the force of the rapid
inflation of the front passenger airbag can cause
death or serious injury to the child.
190
16L146
Move seat fully back
A forward–facing child restraint system should
be allowed to be put on the front passenger
seat only when it is unavoidable. Always move
the seat as far back as possible, because the
force of the deploying front passenger airbag
could cause death or serious injury to the child.
Do not allow the child to lean against the front
door or around the front door even if the child
is seated in a child restraint system. It is
dangerous if the side airbag inflates, and the
impact could cause death or serious injury to
the child.
COMFORT ADJUSTMENT
191
COMFORT ADJUSTMENT
16E254
If your driving seat position is not satisfactory, install
the child restraint system at another position.
16E190
192
1. Run the lap and shoulder belt through or around the
convertible seat following the instructions provided by its
manufacturer and inserting the tab into the buckle taking
care not to twist the belt. Keep the lap portion of the belt
tight.
COMFORT ADJUSTMENT
193
COMFORT ADJUSTMENT
CAUTION
After inserting the tab, make sure the tab and buckle
are locked and that the lap and shoulder portions of
the belt are not twisted.
Do not insert coins, clips, etc. in the buckle as this
may prevent you from properly latching the tab and
buckle.
If the seat belt does not function normally,
immediately contact your Lexus dealer. Do not use
the seat until the seat belt is fixed. It cannot protect
your child from injury.
16E191
194
2. Fully extend the shoulder belt to put it in the lock
mode. When the belt is then retracted slightly, it cannot
be extended.
To hold the convertible seat securely, make sure the belt
is in the lock mode before letting the belt retract.
16E192
3. While pressing the convertible seat firmly against the
seat cushion and seatback, let the shoulder belt retract
as far as it will go to hold the convertible seat securely.
COMFORT ADJUSTMENT
195
COMFORT ADJUSTMENT
16E193
CAUTION
Push and pull the child restraint system in different
directions to be sure it is secure. Follow all the
installation instructions provided by its manufacturer.
16E115c
196
COMFORT ADJUSTMENT
4. To remove the convertible seat, press the
buckle–release button and allow the belt to retract
completely . The belt will move freely again and be ready
to work for an adult or older child passenger.
16E194
A booster seat is used in forward–facing position only.
(C) Booster seat installation
197
COMFORT ADJUSTMENT
16L152
Move seat fully back
198
CAUTION
A forward–facing child restraint system should be
allowed to be put on the front passenger seat only
when it is unavoidable. Always move the seat as far
back as possible, because the force of the deploying
front passenger airbag could cause death or serious
injury to the child.
Do not allow the child to lean over the front door or
around the front door even if the child is seated in a
child restraint system. It is dangerous if the side
airbag inflates, and the impact could cause death or
serious injury to the child.
16E195
COMFORT ADJUSTMENT
199
COMFORT ADJUSTMENT
1. Sit the child on a booster seat . Run the lap and
shoulder belt through or around the booster seat and
child following the instructions provided by its
manufacturer and insert the tab into the buckle.
Make sure the shoulder belt is correctly across the
child’s shoulder and that the lap belt is positioned as low
as possible on child’s hips. See “Seat belts” on page 136
for details.
CAUTION
Always make sure the shoulder belt is positioned
across the center of child’s shoulder. The belt should
be kept away from child’s neck, but not falling off
child’s shoulder. Failure to do so could reduce the
amount of protection in an accident and cause
serious injuries in a collision.
Both high–positioned lap belts and
loose–fitting belts could cause serious injuries
due to sliding under the lap belt during a
collision or other unintended result. Keep the
lap belt positioned as low on a child’s hips as
possible.
For child’s safety, do not place the shoulder
belt under child’s arm.
After inserting the tab, make sure the tab and
buckle are l ocked and that the lap and shoulder
portions of the belt are not twisted.
Do not insert coins, clips, etc. in the buckle as
200
this may prevent your child from properly
latching the tab and buckle.
If the seat belt does not function normally,
immediately contact your Lexus dealer . D o n o t
use the seat until the seat belt is fixed. It cannot
protect your child from injury.
16E117c
COMFORT ADJUSTMENT
2. To remove the child restraint system, press the
buckle–release button and allow the belt to retract.
16E219
Follow the procedure below for a child restraint
system that requires the use of a top strap.
Using a top strap
201
COMFORT ADJUSTMENT
16E248
Anchor bracket
Use the anchor bracket on the package tray behind the
rear seat to attach the top strap.
Anchor brackets are installed for each rear seating
position.
202
16E211
Fix the child restraint system with the seat belt.
Latch the hook onto the anchor bracket and tighten
the top strap.
For instructions to install the child restraint system, see
“Child restraint system” on page 178.
CAUTION
Make sure the top strap is securely latched, and check
that the child restraint system is securely by pushing
and pulling it in different directions. Follow all the
installation instructions provided by its manufacturer.
COMFORT ADJUSTMENT
203
COMFORT ADJUSTMENT
DRIVING POSITION MEMORY
SYSTEM
The micro computer can memorize the positions of the
driver’s seat and outside rear view mirrors. Two dif ferent
driving position profiles can be entered into the
computer’s memory.
Recording a driving position in the computer’s memory
can only be done when the ignition key is in the “ON”
position and the selector lever is in the “P” position.
Setting a driving position
16E047
204
COMFORT ADJUSTMENT
1. Adjust the driver’s seat and outside rear view
mirrors to the desired position.
2. While pushing the “SET” button, push button “1”
or “2” until the signal beeps.
The beep sound means that the positions are recorded
in the computer’s memory.
By repeating these two steps and pressing the
remaining button, the driving position for another driver
can be recorded.
To set a new memorized position, select the desired
position and perform step 2. The previous memory will
be erased and the new position will be set.
To make only slight changes to an already memorized
position, the easiest way is to first activate the
memorized position, then make the desired changes
and perform step 2 above.
205
COMFORT ADJUSTMENT
Activating a memorized position
16E048
When you push button “1” or “2”, the driving
position will be automatically adjusted to the
position recorded for that button.
206
Conditions for memorized position activation
Ignition key “ON” and selector lever in “P” position
All parts of the memorized positions can be activated.
However, if the brake pedal is being depressed, the
seat position will not change.
Key not in ignition switch and within 30 seconds of
opening driver’s door.
The memorized position can be activated.
If any driving position memory switch is pushed while
one of the memorized driving position profiles is being
activated, the operation will stop.
To activate the system, push the desired button (“1” or
“2”) again.
The driving position memory control system cannot be
operated while the vehicle is moving.
If the vehicle’s battery is disconnected, the computer’s
memory will be erased and the memorized positions will
have to be set again.
COMFORT ADJUSTMENT
207
COMFORT ADJUSTMENT
CAUTION
Do not start the vehicle while the adjustments are
being made.
Take care not to select the wrong button, or the seat
could strike the rear passenger or hit your body
against the steering wheel. If this happens, you can
stop the movement by pressing another driving
position memory switch, or depressing the brake
pedal.
208
COMFORT ADJUSTMENT
209
SECTION 3 –
STARTING AND DRIVING
Driving tips
Break–in period 319. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation in foreign countries 319. . . . . . . . . . . . . . . . . .
Tips for driving in various conditionss 319. . . . . . . . . . . .
Winter driving tips 321. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dinghy towing 324. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trailer towing 327. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How to save fuel and make your vehicle last longer 338
2
318
DRIVING TIPS
BREAK–IN PERIOD
Drive gently and avoid high speeds.
You need not follow a break–in schedule with your new
Lexus. But following a few simple tips for the first 1600
km (1000 miles) can add to the future economy and long
life of your vehicle:
Do not drive over 88 km/h (55 mph).
Avoid overrevving. Maintain engine speed between
2000 and 4000 rpm.
Avoid full–throttle starts.
Try to avoid hard stops during the first 300 km (200
miles).
Do not drive for a long time at any single speed, either
fast or slow.
Do not tow a trailer during the first 800 km (500 miles).
OPERATION IN FOREIGN
COUNTRIES
If you plan to drive your Lexus in another country ...
First, comply with the vehicle registration laws.
Second, confirm the availability of the correct fuel
(unleaded and minimum octane rating).
TIPS FOR DRIVING IN VARIOUS
CONDITIONS
Always slow down in gusty crosswinds. This will
allow you much better control.
Drive slowly onto curbs and, if possible, at a right
angle. Avoid driving onto high, sharp–edged objects
and other road hazards. Failure to do so can lead to
severe tire damage resulting in tire bursts.
When parking on a hill, turn the front wheels until they
touch the curb so that the vehicle will not roll. Apply
the parking brake, and place the transmission in “P”.
If necessary, block the wheels.
Washing your vehicle or driving through deep water
may get the brakes wet. To see whether they are wet,
check that there is no traffic near you and then press
the pedal lightly. If you do not feel a normal braking
force, the brakes are probably wet. To dry them, drive
the vehicle cautiously while lightly pressing the brake
pedal with the parking brake applied. If they still do
not work safely, pull to the side of the road and call a
Lexus dealer for assistance.
319
DRIVING TIPS
CAUTION
Before driving off, make sure the parking brake is
fully released and that the parking brake reminder
light is off.
Do not rest your foot on the brake pedal while driving.
It can cause dangerous overheating, needless wear,
and poor fuel economy.
To drive down a long or steep hill, reduce your speed
and downshift. Remember, if you ride the brakes
excessively, they may overheat and not work
properly. See page 290.
Be careful when accelerating, upshifting,
downshifting or braking on a slippery surface. The
abrupt change in engine speed, such as sudden
acceleration or engine braking, could cause the
vehicle to spin or skid.
Do not drive in excess of the speed limit. Even if the
legal speed limit permits it, do not drive over 140 km/h
(85 mph) unless your vehicle has high–speed
capability tires. Driving over 140 km/h (85 mph) may
result in tire failure, loss of control and possible
injury. Be sure to consult a tire dealer to determine
whether the tires on your vehicle are high–speed
capability tires or not before driving at such speeds.
320
DRIVING TIPS
Do not continue normal driving when the
brakes are wet. If they are wet, your vehicle will
require a longer stopping distance, and it may
pull to one side when the brakes are applied.
Also, the parking brake will not hold the vehicle
securely.
WINTER DRIVING TIPS
Make sure you have a proper freeze protection of
engine coolant.
Your coolant must contain ethylene–glycol type coolant
for a proper corrosion protection of aluminum
components. Use “Toyota Long Life Coolant” or
equivalent. See “Checking the engine coolant level” on
page 415 for instructions.
NOTICE
Do not use alcohol type antifreeze or plain water
alone.
When it is extremely cold, we recommend to use 60%
solution for your Lexus, to provide protection down to
about –50C (–58F). Do not use more than 70%
solution for better coolant performance.
Check the condition of the battery and cables.
Cold temperatures reduce the capacity of any battery, so
it must be in top shape to provide enough power for
winter starting. Page 451 tells you how to visually
inspect the battery. Your Lexus dealer and most service
stations will be pleased to check the battery charge
level.
Make sure the engine oil viscosity is suitable for the
cold weather.
321
DRIVING TIPS
See page 414 for recommended viscosity. Leaving a
heavy summer oil in your vehicle during winter months
may cause harder starting. If you are not sure about
which oil to use, call your Lexus dealer – they will be
pleased to help.
Check the electronic ignition system for loose
connections or obvious damage.
Keep the door locks from freezing.
Squirt lock de–icer or glycerine into the locks to keep
them from freezing.
Use a washer fluid containing an antifreeze solution.
This product is available at your Lexus dealer and most
auto parts stores. Follow the manufacturer’s directions
for how much to mix with water.
NOTICE
Do not use engine antifreeze or any other
substitute because it may damage your vehicle’s
paint.
Do not use your parking brake when there is a
possibility it could freeze.
When parking, put the transmission into “P” and block
the rear wheels. Do not use the parking brake, or snow
or water accumulated in and around the parking brake
mechanism may freeze the parking brake, making it
hard to release.
Keep ice and snow from accumulating under the
fenders.
Ice and snow built up under your fenders can make
steering difficult. During bad winter driving, stop and
check under the fenders occasionally.
322
Depending on where you are driving, we
recommend you carry some emergency equipment.
Some of the things you might put in the vehicle are tire
chains, window scraper, bag of sand or salt, flares, small
shovel, jumper cables, etc.
DRIVING TIPS
323
DRIVING TIPS
DINGHY TOWING
32E002
Your vehicle can be dinghy towed (with four wheels
on the ground) from the front behind a motorhome.
CAUTION
Dinghy towing requires special equipment and
accessories. Please refer to your service outlet of the
motorhome manufacture for the recommended
equipment.
NOTICE
Dinghy towing does not eliminate the possibility
of damage to your vehicle.
324
Dinghy towing tips
Before dinghy towing, be sure to observe the
following in order to reduce the damage to your
vehicle.
1. Turn the ignition switch to the “ON” position.
Loading...
