NOT FOR REPRODUCTION
1 QUICK GUIDE 11
NOT FOR REPRODUCTION
2 BASIC FUNCTION 43
3 NAVIGATION SYSTEM (EXCEPT FOR HONG KONG) 107
4 NAVIGATION SYSTEM (FOR HONG KONG) 185
5 AUDIO/VISUAL SYSTEM 255
6
SPEECH COMMAND SYSTEM (EXCEPT FOR HONG KONG)
7 SPEECH COMMAND SYSTEM (FOR HONG KONG) 337
8 PERIPHERAL MONITORING SYSTEM 343
9 TELEPHONE (EXCEPT FOR HONG KONG) 397
329
10 TELEPHONE (FOR HONG KONG) 441
11 LEXUS ENFORM 475
INDEX 493
For more information about the following items, see the “Owner’s Manual”.
• Air conditioning
• Energy monitor (NX300h only)
• Fuel consumption
• Vehicle customization settings
• Lexus parking assist-sensor
1
Introduction
NOT FOR REPRODUCTION
NAVIGATION SYSTEM OWNER’S MANUAL
This manual explains the operation of the Navigation System. Please read this manual
carefully to ensure proper use. Keep this manual in your vehicle at all times.
The screen shots in this document and the actual screens of the navigation system differ depending on whether the functions and/or a contract existed and the map data
available at the time of producing this document.
Please be aware that the content of this manual may be different from the navigation
system in some cases, such as when the system’s software is updated.
NAVIGATION SYSTEM
The Navigation System is one of the most technologically advanced vehicle accessories ever developed. The system receives satellite signals from the Global Positioning
System (GPS) operated by the U.S. Department of Defense. Using these signals and
other vehicle sensors, the system indicates your present position and assists in locating
a desired destination.
The navigation system is designed to select efficient routes from your present starting
location to your destination. The system is also designed to direct you to a destination
that is unfamiliar to you in an efficient manner. The system uses DENSO (except for
Hong Kong) or (for Hong Kong) maps. The calculated routes may not be the shortest nor the least traffic congested. Your own personal
local knowledge or “short cut” may at times be faster than the calculated routes.
The navigation system’s database includes Point of Interest categories to allow you to
easily select destinations such as restaurants and hotels. If a destination is not in the database, you can enter the street address or a major intersection close to it and the system will guide you there.
The system will provide both a visual map and audio instructions. The audio instructions
will announce the distance remaining and the direction to turn in when approaching an
intersection. These voice instructions will help you keep your eyes on the road and are
timed to provide enough time to allow you to maneuver, change lanes or slow down.
Please be aware that all current vehicle navigation systems have certain limitations that
may affect their ability to perform properly. The accuracy of the vehicle’s position depends on satellite conditions, road configuration, vehicle condition or other circumstances. For more information on the limitations of the system, refer to pages 178
(except for Hong Kong), 249 (for Hong Kong).
2
IMPORTANT INFORMATION ABOUT THIS MANUAL
NOT FOR REPRODUCTION
For safety reasons, this manual indicates items requiring particular attention with the
following marks.
WA R NI N G
● This is a warning against anything which may cause injury to people if the warning is
ignored. You are informed about what you must or must not do in order to reduce the risk of
injury to yourself and others.
NOTICE
● This is a warning against anything which may cause damage to the vehicle or its equipment
if the warning is ignored. You are informed about what you must or must not do in order to
avoid or reduce the risk of damage to your vehicle and its equipment.
SYMBOLS USED IN ILLUSTRATIONS
Safety symbol
The symbol of a circle with a slash through it means “Do not”, “Do not do
this”, or “Do not let this happen”.
Arrows indicating operations
Indicates the action (pushing, turning, etc.)
used to operate switches and other devices.
3
HOW TO READ THIS MANUAL
NOT FOR REPRODUCTION
No. Name Description
Operational
Outlines
Main Operations The steps of an operation are explained.
Related Operations A main operation’s supplementary operations are described.
Information Useful information for the user is described.
An outline of the operation is explained.
■ INFORMATION FOR HYBRID VEHICLES IS WRITTEN IN BRACKETS
NEXT TO THE INFORMATION FOR GASOLINE VEHICLES
Different writing styles for gasoline and hybrid vehicles
XExample
When the engine
<ON>*2 mode, the initial screen will be displayed and the system will begin
operating.
1
*
: Vehicles with gasoline engine
2
*
: Vehicles with hybrid system
INFORMATION
●
Illustrations may differ from the actual screen displayed depending on the specifications of
the vehicle. If so, see in brackets, for example, “General settings” (“Common settings”)
screen.
*1 <power>*2 switch is in ACCESSORY or IGNITION ON*
1
4
SAFETY INSTRUCTION
NOT FOR REPRODUCTION
To use this system in the safest possible
manner, follow all the safety tips shown below.
This system is intended to assist in reaching
the destination and, if used properly, can do
so. The driver is solely responsible for the
safe operation of your vehicle and the safety
of your passengers.
Do not use any feature of this system to the
extent it becomes a distraction and prevents safe driving. The first priority while
driving should always be the safe operation
of the vehicle. While driving, be sure to observe all traffic regulations.
Prior to the actual use of this system, learn
how to use it and become thoroughly familiar with it. Read the entire Navigation
System Owner’s Manual to make sure you
understand the system. Do not allow other
people to use this system until they have
read and understood the instructions in this
manual.
For your safety, some functions may become inoperable when driving. Unavailable
screen buttons are dimmed. Only when the
vehicle is not moving, can the destination
and route selection be done.
WA R NI N G
● For safety, the driver should not operate
the navigation system while he/she is
driving. Insufficient attention to the road
and traffic may cause an accident.
● While driving, be sure to obey the traffic
regulations and maintain awareness of
the road conditions. If a traffic sign on the
road has been changed, route guidance
may not have the updated information
such as the direction of a one way street.
While driving, listen to the voice instructions
as much as possible and glance at the
screen briefly and only when it is safe. However, do not totally rely on voice guidance.
Use it just for reference. If the system cannot determine the current position correctly, there is a possibility of incorrect, late, or
non-voice guidance.
The data in the system may occasionally be
incomplete. Road conditions, including
driving restrictions (no left turns, street closures, etc.) frequently change. Therefore,
before following any instructions from the
system, look to see whether the instruction
can be done safely and legally.
This system cannot warn about such things
as the safety of an area, condition of streets,
and availability of emergency services. If unsure about the safety of an area, do not drive
into it. Under no circumstances is this system a substitute for the driver’s personal
judgement.
Use this system only in locations where it is
legal to do so. Some countries/states/territories/areas may have laws prohibiting the
use of video and navigation screens next to
the driver.
5
TABLE OF CONTENTS
NOT FOR REPRODUCTION
QUICK GUIDE
1
1. BASIC OPERA TION....................... ............... 1 2
Remote Touch ........................................................... 12
“Menu” SCREEN.....................................................14
HOME SCREEN..................................................... 16
2. QUICK REF ERENCE........ .......................... 20
“Setup” (“Settings and editing”)
SCREEN ................................................................ 20
“Information” SCREEN
(EXCEPT FOR HONG KONG) ...............22
3. NAVIGATION OPERATION
(EXCEPT FOR HONG KONG)........... 24
REGISTERING HOME ......................................24
REGISTERING PRESET
DESTINATIONS.................................................26
OPERATION FLOW:
GUIDING THE ROUTE ................................ 28
SETTING HOME AS
THE DESTINATION ........................................ 30
4. NAVIGATION OPERATION
(FOR HONG KO NG) ............................ .. 32
REGISTERING HOME ..................................... 32
REGISTERING PRESET
DESTINATIONS................................................ 34
OPERATION FLOW:
GUIDING THE ROUTE ................................ 36
SETTING HOME AS
THE DESTINATION ........................................ 38
5. FUNCTION I NDEX .................. ................... 40
FUNCTION INDEX............................................ 40
BASIC FUNCTION
2
1. BASIC INFORMATION BEFORE
OPERATION ........ .......................... ............. 44
INITIAL SCREEN .................................................. 44
HOW TO USE THE Remote Touch..............46
HOME SCREEN OPERATION....................49
ENTERING LETTERS AND
NUMBERS/LIST SCREEN
OPERATION........................................................ 51
SCREEN ADJUSTMENT .................................. 57
LINKING MULTI-INFORMATION
DISPLAY AND NAVIGATION
SYSTEM.................................................................. 59
2. Bluetooth® SETTINGS
(EXCEPT FOR HONG KONG) ........... 60
REGISTERING/CONNECTING
Bluetooth
SETTING Bluetooth
3. Bluetooth® SETTINGS
(FOR HONG KONG) ...............................76
REGISTERING/CONNECTING
Bluetooth® DEVICE ......................................... 76
SETTING Bluetooth
4. OTHER SETT INGS ..................... ....................91
GENERAL SETTINGS ........................................ 91
VOICE SETTINGS ...............................................99
VEHICLE SETTINGS ......................................... 101
®
DEVICE .........................................60
®
DETAILS ..................... 66
®
DETAILS ...................... 81
6
NAVIGATION SYSTEM
NOT FOR REPRODUCTION
3
(EXCEPT FOR HONG KONG)
NAVIGATION SYSTEM
4
(FOR HONG KONG)
1
1. BASIC OPERATION ...................................108
QUICK REFERENCE....................................... 108
MAP SCREEN OPERATION ..........................111
MAP SCREEN INFORMATION ..................118
TRAFFIC INFORMATION .............................124
2. DESTINATION SEARCH....... .................. 127
DESTINATION SEARCH SCREEN .......... 127
SEARCH OPERATION ...................................129
STARTING ROUTE GUIDANCE .............. 142
3. ROUTE GUIDANCE ................................. 146
ROUTE GUIDANCE SCREEN ...................146
TYPICAL VOICE GUIDANCE
PROMPTS............................................................152
EDITING ROUTE ............................................... 153
4. MEMORY POINTS .................................... 158
MEMORY POINTS SETTINGS .................. 158
5. SETUP .. ............................ .......................... ...... 168
DETAILED NAVIGATION SETTINGS... 168
TRAFFIC SETTINGS .......................................... 174
6. TIPS FOR THE NAVIGATION
SYSTEM ....................................................... 178
GPS (GLOBAL POSITIONING
SYSTEM) ..............................................................178
MAP DATABASE VERSION AND
COVERED AREA ............................................ 181
1. BASIC OPERA TION......... .......................... 186
QUICK REFERENCE .......................................186
MAP SCREEN OPERATION .......................189
MAP SCREEN INFORMATION ................ 196
2. DESTINATION SEARCH........................ 204
DESTINATION SEARCH SCREEN ........ 204
SEARCH OPERATION................................. 206
STARTING ROUTE GUIDANCE .............. 216
3. ROUTE GUI DANCE ................... .............. 221
ROUTE GUIDANCE SCREEN................... 221
TYPICAL VOICE GUIDANCE
PROMPTS ..........................................................227
EDITING ROUTE.............................................. 228
4. MEMORY POINTS ................................... 230
MEMORY POINTS SETTINGS................. 230
5. SETUP ............................................................. 243
DETAILED NAVIGATION
SETTINGS ..........................................................243
6. TIPS FOR THE NAVIGATION
SYSTEM ...................................................... 249
GPS (GLOBAL POSITIONING
SYSTEM) .............................................................249
MAP DATABASE VERSION AND
COVERED AREA ..........................................252
2
3
4
5
6
7
8
9
10
11
7
TABLE OF CONTENTS
NOT FOR REPRODUCTION
AUDIO/VISUAL SYSTEM
5
1. BASIC OPERA TION....................... ........... 256
QUICK REFERENCE...................................... 256
SOME BASICS................................................... 258
2. RADIO OPER ATION.................... ............266
AM/FM/DAB RADIO..................................... 266
INTERNET RADIO
(EXCEPT FOR HONG KONG) ............. 271
3. MEDIA OPERA TION.................. ............. 27 2
CD ..............................................................................272
DVD...........................................................................277
USB MEMORY .................................................. 284
iPod ...........................................................................288
Bluetooth
AUX .........................................................................300
VTR ...........................................................................303
4. AUDIO/VISUAL REMOTE
CONTROLS ......................... ..................... 306
STEERING SWITCHES.................................. 306
5. SETUP ................. .......................... .................. 308
AUDIO SETTINGS ...........................................308
6. TIPS FOR OPERATING
THE AUDIO/VISUAL SYSTEM.......... 315
OPERATING INFORMATION ...................315
®
AUDIO .......................................... 294
SPEECH COMMAND SYSTEM
6
(EXCEPT FOR HONG KONG)
1. SPEECH COMMAND SYSTEM
OPERATION ........ ............................ ........330
SPEECH COMMAND SYSTEM.............. 330
COMMAND LIST..............................................335
SPEECH COMMAND SYSTEM
7
(FOR HONG KONG)
1. SPEECH COMMAND SYSTEM
OPERATION ........ .......................... .......... 338
SPEECH COMMAND SYSTEM.............. 338
COMMAND LIST............................................... 341
8
PERIPHERAL MONITORING
NOT FOR REPRODUCTION
8
SYSTEM
TELEPHONE
9
(EXCEPT FOR HONG KONG)
1
1. LEXUS PARKING ASSIST
MONITOR ...... ........................................... 344
LEXUS PARKING ASSIST
MONITOR ........................................................ 344
PERPENDICULAR PARKING
(ESTIMATED COURSE LINE
DISPLAY MODE).......................................... 350
PERPENDICULAR PARKING
(PARKING ASSIST GUIDE LINE
DISPLAY MODE).......................................... 352
PARALLEL PARKING .................................... 354
LEXUS PARKING ASSIST MONITOR
PRECAUTIONS ...............................................361
THINGS YOU SHOULD KNOW ............ 366
2. PANORAMIC VIEW MONITOR ........ 368
PANORAMIC VIEW MONITOR ............ 368
CHECKING AROUND
THE VEHICLE ................................................. 372
CHECKING THE FRONT AND
AROUND THE VEHICLE ......................... 373
CHECKING THE SIDES
OF THE VEHICLE ......................................... 375
CHECKING THE REAR AND
AROUND THE VEHICLE ..........................377
WHEN FOLDING THE OUTSIDE
REAR VIEW MIRRORS ..............................384
PANORAMIC VIEW MONITOR
PRECAUTIONS .............................................386
THINGS YOU SHOULD KNOW ............ 394
1. TELEPHONE OPERATION
(HANDS-FREE SYSTEM
FOR CELLULAR PHONES)................398
QUICK REFERENCE ..................................... 398
SOME BASICS................................................... 399
CALLING ON THE Bluetooth
PHONE............................................................... 403
RECEIVING ON THE Bluetooth®
PHONE............................................................... 409
TALKING ON THE Bluetooth
PHONE.................................................................410
Bluetooth® PHONE MESSAGE
FUNCTION ........................................................ 413
2. SETUP .............................................................. 419
TELEPHONE/MESSAGE SETTINGS ..... 419
3. WHAT TO DO IF... ..................................... 435
TROUBLESHOOTING ................................. 435
®
®
2
3
4
5
6
7
8
9
10
11
9
TELEPHONE
NOT FOR REPRODUCTION
10
(FOR HONG KONG)
1. TELEPHONE OPERATION
(HANDS-FREE SYSTEM
FOR CELLULAR PHONES) ............... 442
QUICK REFERENCE...................................... 442
SOME BASICS................................................... 443
CALLING ON THE Bluetooth
PHONE................................................................447
RECEIVING ON THE Bluetooth®
PHONE............................................................... 453
TALKING ON THE Bluetooth
PHONE............................................................... 454
2. SETUP ................. .......................... ...................457
TELEPHONE SETTINGS .............................. 457
3. WHAT TO DO IF... ..... ................................ 470
TROUBLESHOOTING ................................. 470
®
®
LEXUS ENFORM
11
1. LEXUS ENFORM-OVERVIEW ..............476
LEXUS ENFORM SERVICE ........................ 476
2. LEXUS ENFORM OPERATION . ......... 481
LEXUS ENFORM ...............................................481
3. SETUP ............................................................. 490
LEXUS ENFORM SETTINGS .................... 490
INDEX
ALPHABETICAL INDEX ... .......................... 494
10
QUICK GUIDE
NOT FOR REPRODUCTION
BASIC OPERATION
1
1. Remote Touch ................................................ 12
2. “Menu” SCREEN .......................................... 14
3. HOME SCREEN .......................................... 16
STATUS DISPLAY ..................................................... 18
QUICK REFERENCE
2
1. “Setup” (“Settings and editing”)
SCREEN .................................. .................... 20
1
NAVIGATION OPERATION
3
(EXCEPT FOR HONG KONG)
1. REGISTERING HOME............................. 24
2. REGISTERING PRESET
DESTINATIONS ..... ............................. ....26
3. OPERATION FLOW:
GUIDING THE ROUTE ... .....................28
4. SETTING HOME AS
THE DESTINATIO N ............................... 30
1
2
3
4
5
6
7
2. “Information” SCREEN
(EXCEPT FOR HONG KONG) ........22
NAVIGATION OPERATION
4
(FOR HONG KONG)
1. REGISTERING HOME. .............. ..............32
2. REGISTERING PRESET
DESTINATIONS ..... ............................. ....34
3. OPERATION FLOW:
GUIDING THE ROUTE ........................ 36
4. SETTING HOME AS THE
DESTINATION ........... ............................ ..38
FUNCTION INDEX
5
1. FUNCTION INDEX ...................................40
8
8
9
10
11
11
1. BASIC OPERATION
NOT FOR REPRODUCTION
1. Remote Touch
12
1. BASIC OPERATION
NOT FOR REPRODUCTION
No. Name Function Page
“MENU” button Press to display the “Menu” screen. 14
“·” button
“HOME” button Press to display the home screen. 16, 49
Touchpad
Press to change the scale of the map and to scroll
the list screen.
Slide your finger on the touchpad and move the
pointer to select a function, letter and screen button.
Press the touchpad to enter the selected function,
letter or screen button.
Certain finger movements on the touchpad can
perform functions, such as changing map scalings
and scrolling list screens.
46, 55, 112,
190
46
1
QUICK GUIDE
13
1. BASIC OPERATION
NOT FOR REPRODUCTION
2. “Menu” SCREEN
Press the “MENU” button on the Remote Touch to display the “Menu” screen.
XExcept for Hong Kong
XFor Hong Kong
14
1. BASIC OPERATION
NOT FOR REPRODUCTION
Page
No. Function
Select to display the air conditioning control screen. “Owner’s Manual”
Select to display the map screen. 108 186
Select to display the “Lexus Enform” screen. 481
Select to display the “Information” screen. 22
Select to display the radio control screen.
Select to display the media control screen.
Select to display the telephone top screen. 398 442
Select to display the “Setup” (“Settings and editing”)
screen.
Select to adjust the contrast and brightness of the
screens, turn the screen off, etc.
Select to display the fuel consumption screen.
(Except for
Hong Kong)
Page (For
Hong Kong)
256
20
57
“Owner ’s
Manual”
1
QUICK GUIDE
15
1. BASIC OPERATION
NOT FOR REPRODUCTION
3. HOME SCREEN
Press the “HOME” button on the Remote Touch to display the home screen.
The home screen can display multiple information screens, such as the navigation sys-
tem screen, audio system screen and fuel consumption screen, simultaneously. When
a screen is selected, the selected screen is switched to a full-screen display. The home
screen can be set to either a three-way split screen or a two-way split screen.
For details about setting the home screen: →P.49
XThree-way split screen
16
1. BASIC OPERATION
NOT FOR REPRODUCTION
XTwo-way split screen
No. Function Page
Displays the condition of the Bluetooth® connection 18
Select to change the display items/area and the home screen layout. 49
1
QUICK GUIDE
17
1. BASIC OPERATION
NOT FOR REPRODUCTION
STATUS DISPLAY
The condition of the Bluetooth® connection, as well as the level of reception and the
amount of cellular phone battery charge left, are displayed on the status bar. This status
bar is always shown on all modes.
No. Indicators Conditions
(Gray) (Blue)
No connection Poor Good
• An antenna for the Bluetooth
The condition of
the Bluetooth
connection
18
ment panel. The condition of the Bluetooth
deteriorate and the system may not function when a Bluetooth
®
phone is used in the following conditions and/or places:
The cellular phone is obstructed by certain objects (such as when
it is behind the seat or in the glove box or console box).
The cellular phone is touching or is covered with metal materials.
• Leave the Bluetooth
Bluetooth
®
®
connection is good.
®
connection is built into the instru-
phone in a place where the condition of the
®
connection may
®
1. BASIC OPERATION
NOT FOR REPRODUCTION
No. Indicators Conditions
Poor Excellent
• The level of reception does not always correspond with the level
displayed on the cellular phone. The level of reception may not be
The level of reception
The amount of
battery charge
left
displayed depending on the telephone you have.
When the cellular phone is out of the service area or in a place
inaccessible by radio waves, “No Service” is displayed.
• “Rm” is displayed when receiving in a roaming area. While roaming, display “Rm” top-left on the icon.
• The receiving area may not be displayed depending on the type of
telephone you have.
Empty Full
• The amount displayed does not always correspond with the
amount displayed on the Bluetooth
The amount of battery charge left may not be displayed depending
on the type of the Bluetooth
This system does not have a charging function.
®
®
device connected.
1
QUICK GUIDE
device.
19
2. QUICK REFERENCE
NOT FOR REPRODUCTION
1. “Setup” (“Settings and editing”) SCREEN
The items shown on the “Setup” (“Settings and editing”) screen can be set. Press the
“MENU” button on the Remote Touch, then select “Setup” to display the “Setup”
(“Settings and editing”) screen.
XExcept for Hong Kong
XFor Hong Kong
20
2. QUICK REFERENCE
NOT FOR REPRODUCTION
Page
No. Function
Select to change the operation sound, automatic screen
change settings, etc.
Select to set the voice guidance settings. 99
Select to set Bluetooth® phones and Bluetooth® audio
devices.
Select to set radio or external media settings. 308
Select to set traffic information.
For Hong Kong: This function is not available.
Select to set memory points (home, preset destinations,
address book entries, etc.), navigation details or to delete previous destinations.
Select to set vehicle information such as maintenance information.
Select to set the telephone sound, contacts, message
settings*, etc.
Select to set Lexus Enform settings. 490
(Except for
Hong Kong)
66 81
174
158, 168 230, 243
419 457
Page (For
Hong Kong)
91
101
1
QUICK GUIDE
*: If equipped
21
2. QUICK REFERENCE
NOT FOR REPRODUCTION
2. “Information” SCREEN (EXCEPT FOR HONG KONG)
This screen can be used to display traffic information, fuel consumption, etc. Press the
“MENU” button on the Remote Touch, then select “Info” to display the “Information”
screen.
22
2. QUICK REFERENCE
NOT FOR REPRODUCTION
No. Function Page
Select to display the fuel consumption screen.
Select to display traffic information. 124
“Owner ’s
Manual”
1
QUICK GUIDE
23
3. NAVIGATION OPERATION (EXCEPT FOR HONG KONG)
NOT FOR REPRODUCTION
1. REGISTERING HOME
1
Press the “MENU” button on the
Remote Touch.
2
Select “Nav”.
3
Select “Dest.”.
4
Select “Go home”.
5
Select “Yes”.
6
There are different kinds of methods to search for your home.
(→P.1 2 7 )
24
3. NAVIGATION OPERATION (EXCE PT FOR HONG KONG)
NOT FOR REPRODUCTION
7
Select “Enter”.
8
Select “OK”.
Registration of home is complete.
XRegistering home in a different way
→P.159
XEditing the name, location, telephone
number and icon
→P.159
XSetting home as the destination
→P.131
1
QUICK GUIDE
25
3. NAVIGATION OPERATION (EXCEPT FOR HONG KONG)
NOT FOR REPRODUCTION
2. REGISTERING PRESET DESTINATIONS
1
Press the “MENU” button on the
Remote Touch.
2
Select “Nav”.
3
Select “Dest.”.
4
Select one of the preset destination
buttons.
5
Select “Yes”.
6
There are different kinds of methods to search for a destination.
(→P.1 2 7 )
26
3. NAVIGATION OPERATION (EXCE PT FOR HONG KONG)
NOT FOR REPRODUCTION
7
Select “Enter”.
8
Select “OK”.
Registration of preset destinations is complete.
XRegistering preset destinations in a dif-
ferent way
→P.160
XEditing the name, location, telephone
number and icon
→P.161
XSetting preset destinations as the desti-
nation
→P.131
1
QUICK GUIDE
27
3. NAVIGATION OPERATION (EXCEPT FOR HONG KONG)
NOT FOR REPRODUCTION
3. OPERATION FLOW: GUIDING THE ROUTE
1
Press the “MENU” button on the
Remote Touch.
2
Select “Nav”.
3
Select “Dest.”.
4
There are different kinds of methods to search for a destination.
(→P.1 2 7 )
5
Select “Go”.
28
3. NAVIGATION OPERATION (EXCE PT FOR HONG KONG)
NOT FOR REPRODUCTION
6
Select “OK”.
Selecting routes other than the one recommended (→P.142)
Guidance to the destination is displayed on
the screen and can be heard via voice guidance.
1
QUICK GUIDE
29
3. NAVIGATION OPERATION (EXCEPT FOR HONG KONG)
NOT FOR REPRODUCTION
4. SETTING HOME AS THE DESTINATION
1
Press the “MENU” button on the
Remote Touch.
2
Select “Nav”.
3
Select “Dest.”.
4
Select “Go home”.
30
3. NAVIGATION OPERATION (EXCE PT FOR HONG KONG)
NOT FOR REPRODUCTION
5
Select “OK”.
Selecting routes other than the one recommended (→P.142)
Guidance to the destination is displayed on
the screen and can be heard via voice guidance.
1
QUICK GUIDE
31
4. NAVIGATION OPERATION (FOR HONG KONG)
NOT FOR REPRODUCTION
1. REGISTERING HOME
1
Press the “MENU” button on the
Remote Touch.
2
Select “Navigation”.
3
Select “Dest”.
4
Select “Set home”.
5
There are different kinds of methods to search for your home.
(→P.2 0 4 )
6
Select “Set”.
32
4. NAVIGATION OPERATION (FOR HONG KONG)
NOT FOR REPRODUCTION
7
Select “Complete”.
Registration of home is complete.
XRegistering home in a different way
→P.231
XEditing the name, location, telephone
number and icon
→P.232
XSetting home as the destination
→P.207
1
QUICK GUIDE
33
4. NAVIGATION OPERATION (FOR HONG KONG)
NOT FOR REPRODUCTION
2. REGISTERING PRESET DESTINATIONS
1
Press the “MENU” button on the
Remote Touch.
2
Select “Navigation”.
3
Select “Dest”.
4
Select one of the preset destination
button.
5
Select “Yes”.
6
There are different kinds of methods to search for a destination.
(→P.2 0 4 )
34
4. NAVIGATION OPERATION (FOR HONG KONG)
NOT FOR REPRODUCTION
7
Select “Set”.
8
Select “Complete”.
Registration of preset destinations is complete.
XRegistering preset destinations in a dif-
ferent way
→P.233
XEditing the name, location, telephone
number and icon
→P.234
XSetting preset destinations as the desti-
nation
→P.208
1
QUICK GUIDE
35
4. NAVIGATION OPERATION (FOR HONG KONG)
NOT FOR REPRODUCTION
3. OPERATION FLOW: GUIDING THE ROUTE
1
Press the “MENU” button on the
Remote Touch.
2
Select “Navigation”.
3
Select “Dest”.
4
There are different kinds of methods to search for a destination.
(→P.2 0 4 )
5
Select “Complete”.
36
4. NAVIGATION OPERATION (FOR HONG KONG)
NOT FOR REPRODUCTION
6
Select “Guidance start”.
Selecting routes other than the one recommended (→P.216)
Guidance to the destination is displayed on
the screen and can be heard via voice guidance.
1
QUICK GUIDE
37
4. NAVIGATION OPERATION (FOR HONG KONG)
NOT FOR REPRODUCTION
4. SETTING HOME AS THE DESTINATION
1
Press the “MENU” button on the
Remote Touch.
2
Select “Navigation”.
3
Select “Dest”.
4
Select “Go home”.
38
4. NAVIGATION OPERATION (FOR HONG KONG)
NOT FOR REPRODUCTION
5
Select “Guidance start”.
Selecting routes other than the one recommended (→P.216)
Guidance to the destination is displayed on
the screen and can be heard via voice guidance.
1
QUICK GUIDE
39
5. FUNCTION INDEX
NOT FOR REPRODUCTION
1. FUNCTION INDEX
XMap
Displaying maps
Viewing the map screen 108 186
Displaying the current position 111 189
Viewing the current position vicinity map 116 195
Changing the scale 112 190
Changing the map orientation 113 191
Displaying map information 118 196
Displaying the estimated travel/arrival time to the destination 146 222
Selecting the map mode 114 192
Displaying traffic information 124
Searching for destinations
Searching for the destination 129 206
Changing the search area 130
Page
(Except for
Hong Kong)
Page
(Except for
Hong Kong)
Page (For
Hong Kong)
Page (For
Hong Kong)
XRoute guidance
Before starting or during route guidance
Starting route guidance 142 216
Editing the route 153 228
Viewing the entire route map 148 223
Pausing guidance 145 220
Adjusting route guidance volume 99
Deleting the destination 155 219
40
Page
(Except for
Hong Kong)
Page (For
Hong Kong)
5. FUNCTION INDEX
NOT FOR REPRODUCTION
Page
Address book (memory point)
Registering address book entries (memory points) 162 235
Marking icons on the map 163 236
(Except for
Hong Kong)
Page (For
Hong Kong)
XUseful functions
Information
Displaying vehicle maintenance 102
Hands-free system (for cellular phone)
Registering/connecting a Bluetooth® phone 60 76
Making a call on a Bluetooth® phone 403 447
Receiving a call on the Bluetooth® phone 409 453
Speech command system
Page
(Except for
Hong Kong)
Page
(Except for
Hong Kong)
Page
(Except for
Hong Kong)
Page (For
Hong Kong)
Page (For
Hong Kong)
Page (For
Hong Kong)
1
QUICK GUIDE
Operating the system with your voice 330 338
41
BASIC INFORMATION BEFORE
NOT FOR REPRODUCTION
1
OPERATION
Bluetooth® SETTINGS
2
(EXCEPT FOR HONG KONG)
1. INITIAL SCREEN ........................................ 44
2. HOW TO USE THE Remote Touch ...... 46
TOUCHPAD GESTURES.................................... 48
3. HOME SCREEN OPERATION............ 49
4. ENTERING LETTERS AND
NUMBERS/LIST SCREEN
OPERATION ......... .......................... .......... 51
ENTERING LETTERS AND NUMBERS
(EXCEPT FOR HONG KONG)..................... 51
SELECTING AN ENTERING METHOD
(FOR HONG KONG) ....................................... 52
LIST SCREEN.............................................................. 54
5. SCREEN ADJUSTMENT ......................... 57
6. LINKING MULTI-INFORMATION
DISPLAY AND NAVIGATION
SYSTEM .............. ............................ ............ 59
1. REGISTERING/CONNECTING
Bluetooth
REGISTERING A Bluetooth® PHONE
FOR THE FIRST TIME.......................................... 60
REGISTERING A Bluetooth
PLAYER FOR THE FIRST TIME ..................... 62
PROFILES ..................................................................... 64
®
DEVICE .... ........................ ... 60
®
AUDIO
2. SETTING Bluetooth® DETAILS ..............66
“Bluetooth* Setup” SCREEN ............................... 66
REGISTERING A Bluetooth
DELETING A Bluetooth
CONNECTING A Bluetooth
EDITING THE Bluetooth
INFORMATION...................................................... 71
“System settings” SCREEN..................................... 74
®
DEVICE .......... 67
®
DEVICE.................. 69
®
DEVICE ...... 69
®
DEVICE
42
2
NOT FOR REPRODUCTION
BASIC FUNCTION
1
2
Bluetooth® SETTINGS
3
(FOR HONG KONG)
1. REGISTERING/CONNECTING
Bluetooth
REGISTERING A Bluetooth® PHONE
FOR THE FIRST TIME.......................................... 76
REGISTERING A Bluetooth
PLAYER FOR THE FIRST TIME...................... 78
PROFILES..................................................................... 80
2. SETTING Bluetooth® DETAILS .............. 81
“Bluetooth* setup” SCREEN.................................. 81
REGISTERING A Bluetooth
DELETING A Bluetooth
CONNECTING A Bluetooth
EDITING THE Bluetooth
INFORMATION .................................................... 86
“System settings” SCREEN .................................... 89
®
DEVICE... ............................. 76
®
AUDIO
®
DEVICE.......... 82
®
DEVICE .................. 84
®
DEVICE....... 84
®
DEVICE
OTHER SETTINGS
4
1. GENERAL SETTINGS................................ 91
GENERAL SETTINGS SCREEN....................... 92
2. VOICE SETTINGS ...................................... 99
VOICE SETTINGS SCREEN
(EXCEPT FOR HONG KONG) ................... 99
VOICE SETTINGS SCREEN
(FOR HONG KONG)...................................... 100
3. VEHICLE SETTINGS ................................ 101
MAINTENANCE..................................................... 102
3
4
5
6
7
8
9
10
11
*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.
43
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
1. INITIAL SCREEN
1 When the engine <power> switch is in
ACCESSORY or IGNITION ON
<ON> mode, the initial screen will be
displayed and the system will begin operating.
z Images shown on the initial screen can be
changed to suit individual preferences.
(→P.9 5 )
z After a few seconds, the caution screen will
be displayed.
z After about 5 seconds, the caution screen
automatically switches to the home screen.
(Select “Cont inue” or press the “HOME”
button on the Remote Touch to display the
home screen.)
WA R NI N G
● When the vehicle is stopped with the
engine running <the hybrid system operating>, always apply the parking brake for
safety.
44
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
MAINTENANCE
INFORMATION
This system reminds users when to replace certain parts or components and
shows dealer information (if registered)
on the screen.
When the vehicle reaches a previously
set driving distance or date specified for
a scheduled maintenance check, the
“Maintenance reminder” (“Remainder”)
screen will be displayed when the navigation system is turned on.
z This screen goes off if the screen is not
operated for several seconds.
z To prevent this screen from being dis-
played again, select “Do not display this
message again” (“Do not disp. next
time.”).
z To register maintenance information:
→P.1 0 3
RESTARTING THE SYSTEM
When system response is extremely
slow, the system can be restarted.
1 Press and hold the “PWR•VOL” knob
for 3 seconds or more.
2
BASIC FUNCTION
z If is selected, the registered tele-
phone number can be called.
45
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
2. HOW TO USE THE Remote Touch
This navigation system can be operated
by the Remote Touch when the engine
<power> switch is in ACCESSORY or
IGNITION ON <ON> mode.
1 Use the touchpad of the Remote Touch
to select the desired button on the
screen.
2 The buttons on the screen can be select-
ed by either double tapping or depressing on the touchpad. Once a button has
been selected, the screen will change.
z When the pointer moves close to a button,
it will automatically snap to that button and
a feedback force is relayed from the touchpad. This feedback force can be adjusted.
(→P.9 1)
z When is displayed on the screen,
select to return to the previous
screen.
z Press the “MENU” button on the Remote
Touch to display the “Menu” screen.
(→P.1 4)
z The home screen can be displayed by
pressing the “HOME” button on the
Remote Touch. (→P.1 6)
z Press the “” button on the Remote Touch
to zoom in on the map screen and the “”
button to zoom out. These buttons can also
be used to scroll up and down on list
screens.
NOTICE
● Do not allow the Remote Touch to come
into contact with food, liquid, stickers or lit
cigarettes as doing so may cause damage.
● Do not subject the Remote Touch to
excessive pressure or strong impact as
doing so may cause damage.
● Do not push the touchpad with a strong
force or use a sharp pointed object to
operate the pad, as it is possible to cause
damage.
46
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
INFORMATION
●
Perform touchpad operations using a finger. Do not use nails or other objects like
pens, etc.
● Perform pointer movement operations
using only one finger. The pointer can not
be operated if other fingers are touching
the touchpad.
● When water or other foreign materials
are on the touchpad, a malfunction may
occur. In those cases, wipe off the water
or foreign materials and wait about
30 seconds before operating the touchpad.
● In the following cases, there is a possibility
that the touchpad may not react normally:
• When wearing gloves, etc.
• When operated with a wet hand.
• When a film, paint-like substance, etc., is
on the touchpad.
• When water, dirt, etc., have adhered to
the touchpad.
• Near a TV tower, electrical power plant,
gas station, radio station, large display,
airport or other facility that generates
strong radio waves or electrical noise.
• When wireless devices, such as portable radios and mobile phones are
nearby.
• When the following metal items are
placed on the touchpad:
•Coins
•Keys
• Metal parts of a wallet or purse
• A card in which aluminum foil, etc., is
attached
•A box of cigarettes that uses aluminum foil
•Disposable hand warmers
• Media such as CD/DVDs, USB
cables, etc.
INFORMATION
●
If a hand or object was placed on the
touchpad when the engine <power>
switch is turned to ACCESSORY or
IGNITION ON <ON> mode, the touchpad may not react normally. In those
cases, remove what was set on the touchpad and operate it after waiting about 30
seconds. If there still no reaction, turn off
the engine <power> switch and then set it
to ACCESSORY or IGNITION ON
<ON> mode again.
● Clean the touchpad frequently, as the
reaction of the touch operation may
worsen if the touchpad is dirty. In order to
prevent malfunctions when cleaning the
touchpad, turn the engine <power> switch
off.
2
BASIC FUNCTION
47
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
TOUCHPAD GESTURES
Operations are performed by touching the touchpad with your finger.
Operation method Outline Main use
Double tap
Tap the touchpad
twice, quickly.
Flick
Quick and long movement along the touchpad with your finger.
Pinch in/Pinch out
Slide fingers toward
each other or apart on
the touchpad.
INFORMATION
●
Setting for the touchpad, such as movement speed of the pointer, can be changed.
For details, contact your Lexus dealer.
Selecting the button on the screen.
Moving the list screen or map (single
map only) screen.
Changing the scale of the map.
48
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
3. HOME SCREEN OPERATION
The home screen can display multiple
information screens, such as the navigation system screen, audio system screen
and fuel consumption screen, simultaneously.
1 Press the “HOME” button on the
Remote Touch.
2 Check that the home screen is dis-
played.
CUSTOMIZING THE HOME
SCREEN
The display items/area on the home
screen and the home screen layout can
be changed.
1 Select .
2 Check that “Customise home screen”
(“Home screen customization”) is displayed.
2
BASIC FUNCTION
z When a screen is selected, the selected
screen is switched to a full-screen display.
No. Function Page
Select to change the display items/area.
Select to change the home
screen layout.
50
50
49
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
■ CHANGING THE DISPLAY
ITEMS/AREA
1 Select the desired item.
2 Select the desired area.
INFORMATION
●
When the selected item is already being
displayed and another area is selected for
that item, the item that it is replacing will
be displayed in the original item’s location.
■ CHANGING THE HOME SCREEN
LAYOUT
1 Select “Change layout”.
2 Select the desired screen layout.
50
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
4. ENTERING LETTERS AND NUMBERS/LIST SCREEN OPERATION
When searching by an address, name,
etc., or entering data, letters and numbers can be entered via the screen.
ENTERING LETTERS AND
NUMBERS (EXCEPT FOR
HONG KONG)
No. Function
Select to enter desired characters.
Text field. Entered character(s) will
be displayed.
During character entry, when there is
only one available option for the next
character(s), the next character(s)
will be displayed in gray text in the
text field automatically. Gray text is
entered by selecting this button.
z On certain letter entry screens, letters can
be entered in upper or lower case.
: Select to enter in lower case.
: Select to enter in upper case.
2
BASIC FUNCTION
Select to erase one character. Select
and hold to continue erasing characters.
Select to display the alphabet keys.
Select to display other symbols.
51
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
SELECTING AN ENTERING
METHOD (FOR HONG
KONG)
Hand written, alphanumeric and pinyin
entering methods can be selected.
When searching by address or facility
name, a search is performed even if only
part of the address or facility name is entered.
1 Select “Switch input”.
z The characters entered before “Switch
input” is selected may be deleted.
2 Select the desired entering method.
No. Function
Select to change to the hand written
method.
Select to change to the alphanumeric method.
Select to change to the pinyin method.
z The entering methods that can be selected
differ depending on the function.
z From next time, the selected method will be
displayed on the screen.
52
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
HAND WRITTEN METHOD
Characters can be entered by hand
writing with an optional tool. For details,
contact your Lexus dealer.
No. Function
Write the characters to be entered.
Select the candidate character that
corresponds to the entered hand
written character.
Select the candidate character that
is displayed to enter the next desired
character.
Select to erase one character. Select
and hold to continue erasing characters.
Select to move the cursor position.
Select to enter in Traditional Chinese or in Simplified Chinese.
z Depending on the input screen and con-
ditions, the following operations can be
performed.
Back space: Draw a straight line from the
bottom right to the bottom left.
Space: Draw a line from the top left to the
bottom left and then continue to the bottom right at a right angle.
Line Break: Draw a line from the top right
to the bottom right and then continue to
the bottom left at a right angle.
ALPHANUMERIC METHOD
No. Function
Select to enter desired characters.
Select to erase one character. Select
and hold to continue erasing characters.
Select to move the cursor position.
Select to enter characters in lower
case or in upper case.
2
BASIC FUNCTION
Select to change keyboard layout.
Select to display the 2 byte or 1 byte
entering screen.
53
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
PINYIN METHOD
1 Select “Hanzi”, , , , or after
entering the pin-yin.
No. Function
Select to move the cursor position.
Select to erase one character. Select
and hold to continue erasing characters.
z Enter “v” instead of “ü”.
z When entering a name, etc., it is possible to
use initials. For example, Beijing is “beijing”,
therefore Beijing can be searched using
“BJ”.
2 A list of Chinese characters to convert is
displayed. Select the desired Chinese
character.
LIST SCREEN
DISPLAYING THE LIST
The list screen may be displayed after
entering characters.
1 Enter characters and select “OK”
(“Complete”).
z Matching items from the database are
listed even if the entered address or name
is incomplete.
z The list will be displayed automatically if the
maximum number of characters is entered
or matching items can be displayed on a
single list screen.
INFORMATION
●
The number of matching items is shown
z Selecting “Prev. page” or “Next page”
scrolls the list screen by pages.
3 When the previous screen is displayed,
“Complete”.
select
54
on the right side of the screen. If the number of matching items is more than 999,
the system displays “∗∗∗” (“1000 or
more”) on the screen.
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
■ SELECTING ALL ITEMS
Some lists contain “Select all”. If “Select
all” is selected, it is possible to select all
items.
1 Select “Select all”.
“Unselect all”: Unselect all items on the list.
LIST SCREEN OPERATION
When a list is displayed, use the appropriate screen button to scroll through
the list.
XExcept for Hong Kong
Icon Function
Select to skip to the next or previous page.
Select and hold or to
scroll through the displayed list.
Select to scroll up or down by phonetic notation. (for Hong Kong)
This indicates the displayed
screen’s position.
If appears to the right of an
item name, the complete name is
too long to display.
Select to scroll to the end of
the name.
Select to move to the beginning of the name.
INFORMATION
●
The “” and “” buttons on the Remote
Touch can be used to scroll up and down
on list screens.
2
BASIC FUNCTION
XFor Hong Kong
55
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
SORTING
The order of a list displayed on the
screen can be sorted in the order of distance from the current location, date,
category, etc.
1 Select “Sor t”.
2 Select the desired sorting criteria.
1 Select the desired character jump but-
tons.
INFORMATION
●
Every time the same character screen
button is selected, the list starting with the
subsequent character is displayed.
DISPLAYING THE GROUP
LIST (FOR HONG KONG)
It is possible to display the desired group
items in the memory point list.
1 Select “Narrow group”.
CHARACTER JUMP BUTTONS
IN LISTS
Some lists contain character screen buttons, “ABC”, “DEF” etc., which allow a
direct jump to list entries that begin with
the same letter as the character screen
button.
z The list of memory points that is registered
in the selected group will be displayed.
“Focus release”: Select to close the displayed items, and display all groups.
2 Select the desired group.
56
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
5. SCREEN ADJUSTMENT
The contrast and brightness of the
screen display and the image of the
camera display can be adjusted. The
screen can also be turned off, and/or
changed to either day or night mode.
(For information regarding audio/visual
screen adjustment: →P.264)
1 Press the “MENU” button on the
Remote Touch.
2 Select “Display”.
3 Select the items to be set.
XExcept for Hong Kong
XFor Hong Kong
No. Function Page
Select to turn the screen off.
To turn it on, press any button on the audio panel or on
the Remote Touch.
2
BASIC FUNCTION
Select to turn day mode on/
off.
Select to adjust the screen
display.
Select to adjust the camera
display.
INFORMATION
●
When the screen is viewed through
polarized sunglasses, a rainbow pattern
may appear on the screen due to optical
characteristics of the screen. If this is disturbing, please operate the screen without polarized sunglasses.
58
58
57
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
CHANGING BETWEEN DAY
AND NIGHT MODE
Depending on the position of the headlight switch, the screen changes to day
or night mode.
1 To display the screen in day mode even
with the headlight switch on, select “Day
mode” (“Daytime screen mode”).
I
INFORMATION
●
If the screen is set to day mode with the
headlight switch turned on, this condition
is memorized even with the engine
<hybrid system> turned off.
ADJUSTING THE CONTRAST/
BRIGHTNESS
The contrast and brightness of the
screen can be adjusted according to the
brightness of your surroundings.
1 Select “General” (“Common”) or
“Camera”.
2 Select the desired item.
z “Display (general)” (“Image quality adjust-
ment (common)”) screen only: Select “”
or “” to select the desired display.
Screen button Function
“Contrast” “+”
Select to strengthen the
contrast of the screen.
“Contrast” “-”
“Brightness” “+”
“Brightness” “-”
58
Select to weaken the
contrast of the screen.
Select to brighten the
screen.
Select to darken the
screen.
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
6. LINKING MULTI-INFORMATION DISPLAY AND NAVIGATION SYSTEM
The following functions of the navigation system are linked with the multi-information
display in the instrument cluster:
• Navigation
•Audio
•Telephone
etc.
These functions can be operated using multi-information display control switches on
the steering wheel. For details, refer to “Owner’s Manual”.
2
BASIC FUNCTION
59
2. Bluetooth® SETTINGS (EXCEPT FOR HONG KONG)
NOT FOR REPRODUCTION
1. REGISTERING/CONNECTING Bluetooth® DEVICE
REGISTERING A Bluetooth®
PHONE FOR THE FIRST TIME
To use the hands-free system, it is necessary to register a Bluetooth
the system.
Once the telephone has been regis-
tered, it is possible to use the hands-free
system.
This operation cannot be performed
while driving.
For details about registering a
®
Bluetooth
device: →P.67
®
phone with
1 Turn the Bluetooth
of your cellular phone on.
z This function is not available when
Bluetooth
lular phone is set to off.
®
connection setting of your cel-
®
connection setting
2 Press the “MENU” button on the
Remote Touch.
3 Select “Telephone”.
z Operations up to this point can also be per-
formed by pressing the switch on the
steering wheel.
60
2. Bluetooth® SETTINGS (EXCEPT FOR HONG KONG)
NOT FOR REPRODUCTION
4 Select “Yes” to register a telephone.
5 When this screen is displayed, search
for the device name displayed on this
screen on the screen of your
Bluetooth
z For details about operating the Bluetooth
device, see the manual that comes with it.
z To cancel the registration, select “Canc el”.
®
device.
6 Register the Bluetooth
your Bluetooth
z A PIN-code is not required for SSP
(Secure Simple Pairing) compatible
Bluetooth
type of Bluetooth
nected, a message confirming registration
may be displayed on the Bluetooth
device’s screen. Respond and operate the
Bluetooth
mation message.
®
®
devices. Depending on the
®
device according to the confir-
®
device using
device.
®
device being con-
7 Check that the following screen is dis-
played when registration is complete.
®
z The system waits for connection requests
coming from the registered device.
z At this stage, the Bluetooth
not yet available.
®
functions are
2
BASIC FUNCTION
®
61
2. Bluetooth® SETTINGS (EXCEPT FOR HONG KONG)
NOT FOR REPRODUCTION
8 Select “OK” when the connection sta-
tus changes from “Connecting...” to
“Connected”.
z If an error message is displayed, follow the
guidance on the screen to try again.
REGISTERING A Bluetooth®
AUDIO PLAYER FOR THE
FIRST TIME
To use the Bluetooth® Audio, it is necessary to register an audio player with
the system.
Once the player has been registered, it
®
is possible to use the Bluetooth
This operation cannot be performed
while driving.
For details about registering a
®
Bluetooth
device: →P.67
Audio.
62
2. Bluetooth® SETTINGS (EXCEPT FOR HONG KONG)
NOT FOR REPRODUCTION
1 Turn the Bluetooth
of your audio player on.
z This function is not available when the
Bluetooth
audio player is set to off.
®
connection setting of your
®
connection setting
2 Press the “MENU” button on the
Remote Touch.
3 Select “Radio” or “Media”.
4 Select “Source”.
2
BASIC FUNCTION
5 Select “Bluetooth*”.
6 Select “Connect”.
7 Select “Yes” to register a audio player.
8 Follow the steps in “REGISTERING A
Bluetooth
TIME” from “STEP 5”. (→P.60)
*: Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
®
PHONE FOR THE FIRST
63
2. Bluetooth® SETTINGS (EXCEPT FOR HONG KONG)
NOT FOR REPRODUCTION
PROFILES
This system supports the following services.
Bluetooth®
Device
Bluetooth
Phone/
Bluetooth
Audio
Player
Bluetooth®
Device
Bluetooth
Phone
Bluetooth
Audio
Player
Spec. Function
®
®
Bluetooth® Specification
Profile Function
HFP (Hands-Free Profile)
OPP (Object Push Profile)
PBAP (Phone Book Access
®
Profile)
MAP (Message Access Profile)
SPP (Serial Port Profile)
A2DP (Advanced Audio Distri-
®
bution Profile)
AVRCP (Audio/Video Remote
Control Profile)
Registering a
Bluetooth
device
Hands-free
system
Transferring the
contacts
Bluetooth
phone message
“Lexus Enform”
function
Bluetooth®
audio system
®
®
Require-
ments
Ver. 2. 0
Require-
ments
Ver. 1. 0 Ver. 1. 6
Ver. 1.1 Ve r. 1 .2
Ver. 1. 0 Ver. 1.1
Ver. 1. 0
Ver. 1.1
Ver. 1. 0 Ve r. 1 .2
Ver. 1. 0 Ver. 1.4
Recommenda-
tions
Ver. 3. 0
+EDR
Recommenda-
tions
64
2. Bluetooth® SETTINGS (EXCEPT FOR HONG KONG)
NOT FOR REPRODUCTION
INFORMATION
●
If your cellular phone does not support HFP, registering the Bluetooth® phone or using
OPP, PBAP, MAP or SPP profiles individually will not be possible.
● If the connected Bluetooth
the Bluetooth® device function may not work properly.
Bluetooth is a registered trademark of Bluetooth SIG, Inc.
®
device version is older than recommended or incompatible,
2
BASIC FUNCTION
65
2. Bluetooth® SETTINGS (EXCEPT FOR HONG KONG)
NOT FOR REPRODUCTION
2. SETTING Bluetooth® DETAILS
1 Press the “MENU” button on the
Remote Touch.
2 Select “Setup”.
3 Select “Bluetooth*”.
“Bluetooth* Setup” SCREEN
Function Page
Registering a Bluetooth® device 67
Deleting a Bluetooth® device 69
Connecting a Bluetooth® device 69
Editing the Bluetooth® device information
Bluetooth® system settings 74
*: Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
71
4 Select the desired item to be set.
66
2. Bluetooth® SETTINGS (EXCEPT FOR HONG KONG)
NOT FOR REPRODUCTION
DISPLAYING THE “Bluetooth*
Setup” SCREEN IN A
DIFFERENT WAY
1 Press the “MENU” button on the
Remote Touch. (→P.12)
2 Select “Setup”.
3 Select “Telephone”.
4 Select “Connect telephone”.
REGISTERING A Bluetooth®
DEVICE
Up to 5 Bluetooth® devices can be registered.
Bluetooth
and audio players (AVP) can be registered simultaneously.
This operation cannot be performed
while driving.
®
compatible phones (HFP)
1 Display the “Bluetooth* Setup” screen.
(→P.66)
2 Select “Ad d ” .
XWhen another Bluetooth
nected
z To disconnect the Bluetooth® device,
select “Yes”.
XWhen 5 Bluetooth® devices have al-
ready been registered
z A registered device needs to be replaced.
Select “Yes”, and select the device to be
replaced.
*: Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
®
dev ice is con-
2
BASIC FUNCTION
67
2. Bluetooth® SETTINGS (EXCEPT FOR HONG KONG)
NOT FOR REPRODUCTION
3 When this screen is displayed, search
for the device name displayed on this
screen on the screen of your
Bluetooth
z For details about operating the Bluetooth
device, see the manual that comes with it.
z To cancel the registration, select “Ca ncel” .
4 Register the Bluetooth
your Bluetooth
z A PIN-code is not required for SSP
(Secure Simple Pairing) compatible
Bluetooth
type of Bluetooth
nected, a message confirming registration
may be displayed on the Bluetooth
device’s screen. Respond and operate the
Bluetooth
mation message.
®
device.
®
device using
®
device.
®
devices. Depending on the
®
device being con-
®
device according to the confir-
5 Check that the following screen is dis-
played when registration is complete.
z The system waits for connection requests
coming from the registered device.
®
z At this stage, the Bluetooth
not yet available.
®
6 Select “OK” when the connection sta-
tus changes from “Connecting...” to
“Connected”.
®
z If an error message is displayed, follow the
guidance on the screen to try again.
functions are
68
2. Bluetooth® SETTINGS (EXCEPT FOR HONG KONG)
NOT FOR REPRODUCTION
DELETING A Bluetooth®
DEVICE
1 Display the “Bluetooth* Setup” screen.
(→P.66)
2 Select “Remove”.
3 Select the desired device.
4 Select “Yes” when the confirmation
screen appears.
5 Check that a confirmation screen is dis-
played when the operation is complete.
INFORMATION
●
When deleting a Bluetooth® phone, the
contact data will be deleted at the same
time.
CONNECTING A Bluetooth®
DEVICE
Up to 5 Bluetooth® devices (Telephones (HFP) and audio players (AVP))
can be registered.
If more than 1 Bluetooth
been registered, select which device to
connect to.
®
device has
1 Display the “Bluetooth* Setup” screen.
(→P.66)
2 Select the device to be connected.
z Supported profile icons will be displayed.
:Telephone
:Audio player
2
BASIC FUNCTION
: Telephone/“Lexus Enform” service
z The profile icon for a currently connected
device will be displayed in colour.
z Selecting a profile icon which is not cur-
rently connected will switch the connection
to the function.
z If the desired Bluetooth® device is not on
the list, select “Add” to register the
device. (→P.6 7 )
*: Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
69
2. Bluetooth® SETTINGS (EXCEPT FOR HONG KONG)
NOT FOR REPRODUCTION
3 Select the desired connection.
®
XWhen another Bluetooth
nected
z To disconnect the Bluetooth® device,
select “Yes”.
dev ice is con-
4 Check that a confirmation screen is dis-
played when the connection is complete.
z If an error message is displayed, follow the
guidance on the screen to try again.
INFORMATION
●
It may take time if the device connection
is carried out during Bluetooth
playback.
● Depending on the type of Bluetooth
device being connected, it may be necessary to perform additional steps on the
device.
®
audio
®
■ AUTO CONNECTION MODE
To turn auto connection mode on, set
“Bluetooth* Power” to on. (→P.74)
®
Leave the Bluetooth
device in a location where the connection can be established.
z When the engine <power> switch is in
ACCESSORY or IGNITION ON <ON>
mode, the system searches for a nearby
registered device.
z The system will connect with the registered
device that was last connected, if it is
nearby.
■ CONNECTING MANUALLY
When the auto connection has failed or
“Bluetooth* Power” is turned off, it is
®
necessary to connect Bluetooth
man-
ually.
1 Press the “MENU” button on the
Remote Touch and select “Setup”.
2 Select “Bluetooth*”.
3 Follow the steps in “CONNECTING A
Bluetooth
(→P.69)
*: Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
®
DEVICE” from “STEP 2”.
70
2. Bluetooth® SETTINGS (EXCEPT FOR HONG KONG)
NOT FOR REPRODUCTION
■ RECONNECTING THE Bluetooth
PHONE
If a Bluetooth® phone is disconnected
due to poor reception from the
®
Bluetooth
<power> switch is in ACCESSORY or
IGNITION ON <ON> mode, the system automatically reconnects the
Bluetooth
z If a Bluetooth® phone is disconnected on
purpose, such as turning it off, this does not
happen. Reconnect the Bluetooth
manually.
network when the engine
®
phone.
®
phone
®
EDITING THE Bluetooth®
DEVICE INFORMATION
The Bluetooth® device’s information
can be displayed on the screen. The displayed information can be edited.
1 Display the “Bluetooth* Setup” screen.
(→P.66)
2 Select the desired device to be edited.
3 Select “Device info”.
*: Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
2
BASIC FUNCTION
71
2. Bluetooth® SETTINGS (EXCEPT FOR HONG KONG)
NOT FOR REPRODUCTION
4 Confirm and change the Bluetooth
device information.
®
No. Information
The name of the Bluetooth® device.
Can be changed to a desired name.
(→P.73)
Select to set the Bluetooth® audio
player connection method. (→P.73)
Device address is unique to the device and cannot be changed.
Telephone number of the
Bluetooth
Compatibility profile of the
Bluetooth
Select to reset all setup items.
INFORMATION
●
If 2 Bluetooth® devices have been registered with the same device name, the
devices can be distinguished referring to
the device’s address.
● Depending on the type of telephone,
some information may not be displayed.
®
phone.
®
device.
72
2. Bluetooth® SETTINGS (EXCEPT FOR HONG KONG)
NOT FOR REPRODUCTION
CHANGING A DEVICE NAME
1 Select “Device name”.
2 Enter the name and select “OK” .
INFORMATION
●
Even if the device name is changed, the
name registered in your Bluetooth
device does not change.
SETTING AUDIO PLAYER
CONNECTION METHOD
1 Select “Connect audio player from”.
2 Select the desired connection method.
®
“Vehicle”: Select to connect the audio system to the audio player.
“Device”: Select to connect the audio play-
er to the audio system.
z Depending on the audio player, the “Vehi-
cle” or “Device” connection method may
be best. As such, refer to the manual that
comes with the audio player.
z To reset the connection method, select
“Default”.
2
BASIC FUNCTION
73
2. Bluetooth® SETTINGS (EXCEPT FOR HONG KONG)
NOT FOR REPRODUCTION
“System settings” SCREEN
The Bluetooth® settings can be confirmed and changed.
1 Display the “Bluetooth* Setup” screen.
(→P.66)
2 Select “System settings”.
3 Select the desired item to be set.
No. Information Page
Select to set Bluetooth
connection on/off.
Displays system name. Can
be changed to a desired
name.
PIN-code used when the
Bluetooth
registered. Can be
changed to a desired code.
Device address is unique to
the device and cannot be
changed.
Select to set the telephone
connection status display
on/off.
Select to set the connection
status display of the audio
player on/off.
Compatibility profile of the
system.
Select to reset all setup
items.
®
device was
®
75
75
75
*: Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
74
2. Bluetooth® SETTINGS (EXCEPT FOR HONG KONG)
NOT FOR REPRODUCTION
CHANGING “Bluetooth*
Power”
1 Select “Bluetooth* Power”.
When “Bluetooth* Power” is on:
The Bluetooth
connected when the engine <power> switch
is in ACCESSORY or IGNITION ON
<ON> mode.
When “Bluetooth* Power” is off:
The Bluetooth
and the system will not connect to it next
time.
INFORMATION
●
While driving, the auto connection state
can be changed from off to on, but cannot be changed from on to off.
®
device is automatically
®
device is disconnected,
EDITING THE SYSTEM NAME
1 Select “Bluetooth* Name”.
2 Enter a name and select “OK”.
EDITING THE PIN-CODE
1 Select “Bluetooth* PIN”.
2 Enter a PIN-code and select “OK”.
*: Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
2
BASIC FUNCTION
75
3. Bluetooth® SETTINGS (FOR HONG KONG)
NOT FOR REPRODUCTION
1. REGISTERING/CONNECTING Bluetooth® DEVICE
REGISTERING A Bluetooth®
PHONE FOR THE FIRST TIME
To use the hands-free system, it is necessary to register a Bluetooth
the system.
Once the telephone has been regis-
tered, it is possible to use the hands-free
system.
This operation cannot be performed
while driving.
For details about registering a
®
Bluetooth
device: →P.82
®
phone with
1 Turn the Bluetooth
of your cellular phone on.
z This function is not available when
Bluetooth
lular phone is set to off.
®
connection setting of your cel-
®
connection setting
2 Press the “MENU” button on the
Remote Touch.
3 Select “Telephone”.
z Operations up to this point can also be per-
formed by pressing the switch on the
steering wheel.
76
3. Bluetooth® SETTINGS (FOR HONG KONG)
NOT FOR REPRODUCTION
4 Select “Yes” to register a telephone.
5 When this screen is displayed, search
for the device name displayed on this
screen on the screen of your
Bluetooth
z For details about operating the Bluetooth
device, see the manual that comes with it.
z To cancel the registration, select “Canc el”.
®
device.
6 Register the Bluetooth
your Bluetooth
z A PIN-code is not required for SSP
(Secure Simple Pairing) compatible
Bluetooth
type of Bluetooth
nected, a message confirming registration
may be displayed on the Bluetooth
device’s screen. Respond and operate the
Bluetooth
mation message.
®
®
devices. Depending on the
®
device according to the confir-
®
device using
device.
®
device being con-
7 Check that the following screen is dis-
played when registration is complete.
®
z The system waits for connection requests
coming from the registered device.
z At this stage, the Bluetooth
not yet available.
®
functions are
2
BASIC FUNCTION
®
77
3. Bluetooth® SETTINGS (FOR HONG KONG)
NOT FOR REPRODUCTION
8 Select “Complete” when the connec-
tion status changes from “Connecting...”
to “Connection complete”.
z If an error message is displayed, follow the
guidance on the screen to try again.
REGISTERING A Bluetooth®
AUDIO PLAYER FOR THE
FIRST TIME
To use the Bluetooth® Audio, it is necessary to register an audio player with
the system.
Once the player has been registered, it
®
is possible to use the Bluetooth
This operation cannot be performed
while driving.
For details about registering a
®
Bluetooth
device: →P.82
Audio.
78
3. Bluetooth® SETTINGS (FOR HONG KONG)
NOT FOR REPRODUCTION
1 Turn the Bluetooth
of your audio player on.
z This function is not available when the
Bluetooth
audio player is set to off.
®
connection setting of your
®
connection setting
2 Press the “MENU” button on the
Remote Touch.
3 Select “Radio” or “Media”.
4 Select “Source”.
2
BASIC FUNCTION
5 Select “Bluetooth*”.
6 Select “Connect”.
7 Select “Yes” to register a audio player.
8 Follow the steps in “REGISTERING A
Bluetooth
TIME” from “STEP 5”. (→P.76)
*: Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
®
PHONE FOR THE FIRST
79
3. Bluetooth® SETTINGS (FOR HONG KONG)
NOT FOR REPRODUCTION
PROFILES
This system supports the following services.
Recommenda-
tions
Ver.3.0
+EDR
Recommenda-
tions
Device
Device
®
®
®
Bluetooth® Specification
®
HFP (Hands-Free Profile)
®
OPP (Object Push Profile)
PBAP (Phone Book Access
Profile)
A2DP (Advanced Audio Distri-
®
bution Profile)
AVRCP (Audio/Video Remote
Control Profile)
Spec. Function
Profile Function
Registering a
Bluetooth
device
Hands-free
system
Transferring the
contacts
Bluetooth®
audio system
®
Require-
ments
Ver. 2. 0
Require-
ments
Ver. 1. 0 Ver. 1. 6
Ver. 1.1 Ve r. 1 .2
Ver. 1. 0 Ver. 1.1
Ver. 1. 0 Ve r. 1 .2
Ver. 1. 0 Ver. 1.4
Bluetooth
Bluetooth
Phone/
Bluetooth
Audio
Player
Bluetooth
Bluetooth
Phone
Bluetooth
Audio
Player
INFORMATION
●
If your cellular phone does not support HFP, registering the Bluetooth® phone or using
OPP or PBAP profiles individually will not be possible.
● If the connected Bluetooth
®
device version is older than recommended or incompatible,
the Bluetooth® device function may not work properly.
Bluetooth is a registered trademark of Bluetooth SIG, Inc.
80
3. Bluetooth® SETTINGS (FOR HONG KONG)
NOT FOR REPRODUCTION
2. SETTING Bluetooth® DETAILS
1 Press the “MENU” button on the
Remote Touch.
2 Select “Setup”.
3 Select “Bluetooth*”.
“Bluetooth* setup” SCREEN
Function Page
Registering a Bluetooth® device 82
Deleting a Bluetooth® device 84
Connecting a Bluetooth® device 84
Editing the Bluetooth® device information
Bluetooth® system settings 89
*: Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
86
2
BASIC FUNCTION
4 Select the desired item to be set.
81
3. Bluetooth® SETTINGS (FOR HONG KONG)
NOT FOR REPRODUCTION
DISPLAYING THE “Bluetooth*
setup” SCREEN IN A
DIFFERENT WAY
1 Press the “MENU” button on the
Remote Touch. (→P.12)
2 Select “Setup”.
3 Select “Telephone”.
4 Select “Telephone connection”.
REGISTERING A Bluetooth®
DEVICE
Up to 5 Bluetooth® devices can be registered.
Bluetooth
and audio players (AVP) can be registered simultaneously.
This operation cannot be performed
while driving.
®
compatible phones (HFP)
1 Display the “Bluetooth* setup” screen.
(→P.81)
2 Select “Registration”.
XWhen another Bluetooth
nected
z To disconnect the Bluetooth® device,
select “Yes”.
XWhen 5 Bluetooth® devices have al-
ready been registered
z A registered device needs to be replaced.
Select “Yes”, and select the device to be
replaced.
*: Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
®
device is con-
82
3. Bluetooth® SETTINGS (FOR HONG KONG)
NOT FOR REPRODUCTION
3 When this screen is displayed, search
for the device name displayed on this
screen on the screen of your
Bluetooth
z For details about operating the Bluetooth
device, see the manual that comes with it.
z To cancel the registration, select “Can cel”.
4 Register the Bluetooth
your Bluetooth
z A PIN-code is not required for SSP
(Secure Simple Pairing) compatible
Bluetooth
type of Bluetooth
nected, a message confirming registration
may be displayed on the Bluetooth
device’s screen. Respond and operate the
Bluetooth
mation message.
®
device.
®
device using
®
device.
®
devices. Depending on the
®
device being con-
®
device according to the confir-
5 Check that the following screen is dis-
played when registration is complete.
z The system waits for connection requests
coming from the registered device.
®
z At this stage, the Bluetooth
not yet available.
®
functions are
6 Select “Comp lete” when the connec-
tion status changes from “Connecting...”
to “Connection complete”.
®
z If an error message is displayed, follow the
guidance on the screen to try again.
2
BASIC FUNCTION
83
3. Bluetooth® SETTINGS (FOR HONG KONG)
NOT FOR REPRODUCTION
DELETING A Bluetooth®
DEVICE
1 Display the “Bluetooth* setup” screen.
(→P.81)
2 Select “Delete”.
3 Select the desired device.
4 Select “Yes” when the confirmation
screen appears.
5 Check that a confirmation screen is dis-
played when the operation is complete.
INFORMATION
●
When deleting a Bluetooth® phone, the
contact data will be deleted at the same
time.
CONNECTING A Bluetooth®
DEVICE
Up to 5 Bluetooth® devices (Telephones (HFP) and audio players (AVP))
can be registered.
If more than 1 Bluetooth
been registered, select which device to
connect to.
®
device has
1 Display the “Bluetooth* setup” screen.
(→P.81)
2 Select the device to be connected.
z Supported profile icons will be displayed.
: Telephone
: Audio player
z The profile icon for a currently connected
device will be displayed in colour.
z Selecting a profile icon which is not cur-
rently connected will switch the connection
to the function.
z If the desired Bluetooth® device is not on
the list, select “Registration” to register
the device. (→P. 8 2 )
*: Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
84
3. Bluetooth® SETTINGS (FOR HONG KONG)
NOT FOR REPRODUCTION
3 Select the desired connection.
®
XWhen another Bluetooth
nected
z To disconnect the Bluetooth® device,
select “Yes”.
device is con-
4 Check that a confirmation screen is dis-
played when the connection is complete.
z If an error message is displayed, follow the
guidance on the screen to try again.
INFORMATION
●
It may take time if the device connection
is carried out during Bluetooth
playback.
● Depending on the type of Bluetooth
device being connected, it may be necessary to perform additional steps on the
device.
®
audio
®
■ AUTO CONNECTION MODE
To turn auto connection mode on, set
“Bluetooth* power” to on. (→P.89)
®
Leave the Bluetooth
device in a location where the connection can be established.
z When the engine <power> switch is in
ACCESSORY or IGNITION ON <ON>
mode, the system searches for a nearby
registered device.
z The system will connect with the registered
device that was last connected, if it is
nearby.
■ CONNECTING MANUALLY
When the auto connection has failed or
“Bluetooth* power” is turned off, it is
®
necessary to connect Bluetooth
man-
ually.
1 Press the “MENU” button on the
Remote Touch and select “Setup”.
2 Select “Bluetooth*”.
3 Follow the steps in “CONNECTING A
Bluetooth
(→P.84)
*: Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
®
DEVICE” from “STEP 2”.
2
BASIC FUNCTION
85
3. Bluetooth® SETTINGS (FOR HONG KONG)
NOT FOR REPRODUCTION
■ RECONNECTING THE Bluetooth
PHONE
If a Bluetooth® phone is disconnected
due to poor reception from the
®
Bluetooth
<power> switch is in ACCESSORY or
IGNITION ON <ON> mode, the system automatically reconnects the
Bluetooth
z If a Bluetooth® phone is disconnected on
purpose, such as turning it off, this does not
happen. Reconnect the Bluetooth
manually.
network when the engine
®
phone.
®
phone
®
EDITING THE Bluetooth®
DEVICE INFORMATION
The Bluetooth® device’s information
can be displayed on the screen. The displayed information can be edited.
1 Display the “Bluetooth* setup” screen.
(→P.81)
2 Select the desired device to be edited.
3 Select “Device info”.
*: Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
86
3. Bluetooth® SETTINGS (FOR HONG KONG)
NOT FOR REPRODUCTION
4 Confirm and change the Bluetooth
device information.
®
No. Information
The name of the Bluetooth® device.
Can be changed to a desired name.
(→P.88)
Select to set the Bluetooth® audio
player connection method.
(→P.88)
Device address is unique to the device and cannot be changed.
Telephone number of the
Bluetooth
Compatibility profile of the
Bluetooth
Select to reset all setup items.
INFORMATION
●
If 2 Bluetooth® devices have been registered with the same device name, the
devices can be distinguished referring to
the device’s address.
● Depending on the type of telephone,
some information may not be displayed.
®
phone.
®
device.
2
BASIC FUNCTION
87
3. Bluetooth® SETTINGS (FOR HONG KONG)
NOT FOR REPRODUCTION
CHANGING A DEVICE NAME
1 Select “Device name”.
2 Enter the name and select “O K”.
INFORMATION
●
Even if the device name is changed, the
name registered in your Bluetooth
device does not change.
SETTING AUDIO PLAYER
CONNECTION METHOD
1 Select “Connection method”.
2 Select the desired connection method.
®
“Vehicle”: Select to connect the audio system to the audio player.
“From device”: Select to connect the audio
player to the audio system.
z Depending on the audio player, the “Vehi-
cle” or “From device” connection method
may be best. As such, refer to the manual
that comes with the audio player.
z To reset the connection method, select
“Default”.
88
3. Bluetooth® SETTINGS (FOR HONG KONG)
NOT FOR REPRODUCTION
“System settings” SCREEN
The Bluetooth® settings can be confirmed and changed.
1 Display the “Bluetooth* setup” screen.
(→P.81)
2 Select “System settings”.
3 Select the desired item to be set.
No. Information Page
Select to set Bluetooth
connection on/off.
Displays system name. Can
be changed to a desired
name.
PIN-code used when the
Bluetooth
registered. Can be
changed to a desired code.
Device address is unique to
the device and cannot be
changed.
Select to set the telephone
connection status display
on/off.
Select to set the connection
status display of the audio
player on/off.
Compatibility profile of the
system.
Select to reset all setup
items.
®
device was
®
90
90
90
2
BASIC FUNCTION
*: Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
89
3. Bluetooth® SETTINGS (FOR HONG KONG)
NOT FOR REPRODUCTION
CHANGING “Bluetooth*
power”
1 Select “Bluetooth* power”.
When “Bluetooth* power” is on:
The Bluetooth
connected when the engine <power> switch
is in ACCESSORY or IGNITION ON
<ON> mode.
When “Bluetooth* power” is off:
The Bluetooth
and the system will not connect to it next
time.
INFORMATION
●
While driving, the auto connection state
can be changed from off to on, but cannot be changed from on to off.
®
device is automatically
®
device is disconnected,
EDITING THE SYSTEM NAME
1 Select “Bluetooth* device name”.
2 Enter a name and select “Complete ”.
EDITING THE PIN-CODE
1 Select “Bluetooth* device PIN code”.
2 Enter a PIN-code and select “Co m-
plete”.
*: Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
90
4. OTHER SETTINGS
NOT FOR REPRODUCTION
1. GENERAL SETTINGS
Settings are available for auto screen
change, operation sounds, etc.
1 Press the “MENU” button on the
Remote Touch.
2 Select “Setup”.
3 Select “General” (“Common”).
2
BASIC FUNCTION
4 Select the items to be set.
91
4. OTHER SETTINGS
NOT FOR REPRODUCTION
GENERAL SETTINGS SCREEN
XExcept for Hong Kong XFor Hong Kong
92
4. OTHER SETTINGS
NOT FOR REPRODUCTION
No. Function
Select to change the time zone and
set the daylight saving time on/off.
(→P.94)
Select to change the unit of measure
for fuel consumption.
Select to change the screen button
colour.
Select to customize the startup/
screen off images. (→P.95)
Select to set automatic screen
changes from the audio/air conditioning control screen to the previous screen to on/off. When set to on,
the screen will automatically return
to the previous screen from the audio/air conditioning control screen
after 20 seconds.
Select to set the selection sounds
on/off.
Select to set the pointer sounds on/
off.
Select to set the error sounds on/off.
No. Function
Select to delete personal data.
(→P.98)
Select to update software versions.
For details, contact your Lexus dealer.
Select to display the software information. Notices related to third party
software used in this product are enlisted. (This includes instructions for
obtaining such software, where applicable.)
Select to change the language.
2
BASIC FUNCTION
Select to adjust the pointer sound
volume.
Select to adjust the level of the feedback force to the touchpad, when
selecting a screen button.
93
4. OTHER SETTINGS
NOT FOR REPRODUCTION
SYSTEM TIME SETTINGS
Used for changing time zones and the
on/off settings of daylight saving time.
1 Display the “General settings” (“Com-
mon settings”) screen. (→P.91)
2 Select “System time”.
3 Select the items to be set.
XExcept for Hong Kong
XFor Hong Kong
■ SETTING THE TIME ZONE
1 Select “Time zone” (“Switch time
zone”).
2 Select the desired time zone.
XExcept for Hong Kong
XFor Hong Kong
z If “Other” (“General settings”) is selected,
the zone can be adjusted manually. Select
“+” or “-” to adjust the time zone.
No. Function
Select to change the time zone.
(→P.94)
Select to set daylight saving time on/
off.
Select to set automatic adjustment of
the clock by GPS on/off. When set
to on, the system will automatically
adjust the clock to the current position’s time zone when the vehicle
moves to a different time zone.
94
4. OTHER SETTINGS
NOT FOR REPRODUCTION
CUSTOMIZING THE STARTUP
AND SCREEN OFF IMAGES
An image can be copied from a USB
memory and used as the startup and
screen off Images.
When the engine <power> switch is in
ACCESSORY or IGNITION ON
<ON> mode, the initial screen will be
displayed. (→P.44)
When “Screen off” on the “Display”
(“Image quality adjustment”) screen is
selected, the screen is turned off and the
desired screen off image that is set is displayed. (To turn the screen off: →P.57)
1 Display the “General settings”
(“Common settings”) screen. (→P.91)
2 Select “Customise images” (“Screen
customization”).
3 Select the items to be set.
XExcept for Hong Kong
XFor Hong Kong
No. Function Page
2
BASIC FUNCTION
Select to copy images from
a USB memory.
Select to delete images. 97
Select to set an image as the
startup and screen off image.
96
97
95
4. OTHER SETTINGS
NOT FOR REPRODUCTION
■ TRANSFERRING IMAGES
1 Press the button to release the lock and
lift the armrest.
2 Open the cover and connect a USB
memory.
z Turn on the power of the USB memory if it
is not turned on.
3 Select “Copy from USB” (“Copy
images from USB”).
4 Select the desired images from the list
and then select “Copy” (“Transfer”).
z The selected image is displayed on the
right side of the screen. If the selected
image file is broken or incompatible,
will be displayed.
z The remaining number of image files that
can be transferred is displayed at the bottom of the screen.
5 Select “Yes” when the confirmation
screen appears.
INFORMATION
●
When saving image files to a USB memory to be transferred to the navigation
system, save the images in a folder
named “Image” (I-m-a-g-e, case sensitive). If a different folder name is used, the
navigation system will not recognize the
image files.
● The compatible file extensions are JPG
and JPEG.
● An image’s file name, including file exten-
sion, can be up to 32 characters.
● Image files of 10 MB or less can be trans-
ferred.
● Up to 10 images can be transferred to the
navigation system.
● Files with non-ASCII filenames cannot be
transferred.
96
4. OTHER SETTINGS
NOT FOR REPRODUCTION
■ SETTING THE STARTUP AND
SCREEN OFF IMAGES
1 Select “Set images” (“Image settings”).
2 Select the desired image.
3 Select the desired items to be set.
XExcept for Hong Kong
XFor Hong Kong
■ DELETING TRANSFERRED IMAG-
ES
1 Select “Delete images” (“Delete im-
age”).
2 Select the images to be deleted and se-
lect “Delete”.
3 Select “Yes” when the confirmation
screen appears.
2
BASIC FUNCTION
No. Function
Select to set an image as the startup
image.
Select to set an image as the screen
off image.
Select to set an image as both the
startup and screen off image.
97
4. OTHER SETTINGS
NOT FOR REPRODUCTION
DELETING PERSONAL DATA
1 Display the “General Settings”
(“Common settings”) screen. (→P.91)
2 Select “Delete personal data”
(“Personal information initialisation”).
3 Select “Delete” (“Initialise”).
4 Select “Yes” when the confirmation
screen appears.
z Registered or changed personal settings
will be deleted or returned to their default
conditions.
For example:
• General settings
• Navigation settings
• Audio settings
•Telephone settings
• Lexus Enform settings (except for Hong
Kong)
NOTICE
● Make sure the map SD card is inserted
when deleting personal data. The personal data cannot be deleted when the
map SD card is removed. To delete the
data, after inserting the map SD card,
turn the engine <power> switch to
ACCESSORY or IGNITION ON <ON>
mode.
98
4. OTHER SETTINGS
NOT FOR REPRODUCTION
2. VOICE SETTINGS
Voice guidance etc. can be set.
1 Press the “MENU” button on the
Remote Touch.
2 Select “Setup”.
3 Select “Voice”.
VOICE SETTINGS SCREEN
(EXCEPT FOR HONG KONG)
2
BASIC FUNCTION
No. Function
Select to adjust the volume of voice
guidance.
Select to set the voice guidance during route guidance on/off.
Select to set the voice guidance during audio/visual and/or air conditioning system use on/off.
Select to set the voice recognition
prompts on/off.
4 Select the items to be set.
●
Select to set the beep sound of navigation guidance.
Select to reset all setup items.
INFORMATION
“Voice settings” screen can also be displayed from the voice recognition top
screen. (→P. 3 3 2 )
99
Loading...
