1
Introduction
NOT FOR REPRODUCTION
NAVIGATION SYSTEM OWNER’S MANUAL
This manual explains the operation of the Navigation System. Please read this manual
carefully to ensure proper use. Keep this manual in your vehicle at all times.
The screen shots in this document and the actual screens of the navigation system differ depending on whether the functions and/or a contract existed and the map data
available at the time of producing this document.
NAVIGATION SYSTEM
The Navigation System is one of the most technologically advanced vehicle accessories ever developed. The system receives satellite signals from the Global Positioning
System (GPS) operated by the U.S. Department of Defense. Using these signals and
other vehicle sensors, the system indicates your present position and assists in locating
a desired destination.
The navigation system is designed to select efficient routes from your present starting
location to your destination. The system is also designed to direct you to a destination
that is unfamiliar to you in an efficient manner. The system uses DENSO maps. The calculated routes may not be the shortest nor the least traffic congested. Your own personal local knowledge or “short cut” may at times be faster than the calculated routes.
The navigation system’s database includes Point of Interest categories to allow you to
easily select destinations such as restaurants and hotels. If a destination is not in the database, you can enter the street address or a major intersection close to it and the system will guide you there.
The system will provide both a visual map and audio instructions. The audio instructions
will announce the distance remaining and the direction to turn in when approaching an
intersection. These voice instructions will help you keep your eyes on the road and are
timed to provide enough time to allow you to maneuver, change lanes or slow down.
Please be aware that all current vehicle navigation systems have certain limitations that
may affect their ability to perform properly. The accuracy of the vehicle’s position depends on satellite conditions, road configuration, vehicle condition or other circumstances. For more information on the limitations of the system, refer to pages 138
through 139.
2
IMPORTANT INFORMATION ABOUT THIS MANUAL
NOT FOR REPRODUCTION
For safety reasons, this manual indicates items requiring particular attention with the
following marks.
CAUTION
● This is a warning against anything which may cause injury to people if the warning is
ignored. You are informed about what you must or must not do in order to reduce the risk of
injury to yourself and others.
NOTICE
● This is a warning against anything which may cause damage to the vehicle or its equipment
if the warning is ignored. You are informed about what you must or must not do in order to
avoid or reduce the risk of damage to your vehicle and its equipment.
SYMBOLS USED IN ILLUSTRATIONS
Arrows indicating operations
Indicates the action (pushing, turning, etc.) used to operate switches
and other devices.
3
HOW TO READ THIS MANUAL
NOT FOR REPRODUCTION
No. Name Description
Operational
Outlines
Main Operations The steps of an operation are explained.
Related Operations A main operation’s supplementary operations are described.
Information Useful information for the user is described.
■ INFORMATION FOR HYBRID VEHICLES IS WRITTEN IN BRACKETS
NEXT TO THE INFORMATION FOR GASOLINE VEHICLES
Different writing styles for gasoline and hybrid vehicles
XExample
When the engine
<ON>*2 mode, the initial screen will be displayed and the system will begin
operating.
1
*
: Vehicles with gasoline engine
2
*
: Vehicles with hybrid system
*1 <power>*2 switch is in ACCESSORY or IGNITION ON*
An outline of the operation is explained.
1
4
SAFETY INSTRUCTION
NOT FOR REPRODUCTION
To use this system in the safest possible
manner, follow all the safety tips shown below.
This system is intended to assist in reaching
the destination and, if used properly, can do
so. The driver is solely responsible for the
safe operation of your vehicle and the safety
of your passengers.
Do not use any feature of this system to the
extent it becomes a distraction and prevents safe driving. The first priority while
driving should always be the safe operation
of the vehicle. While driving, be sure to observe all traffic regulations.
Prior to the actual use of this system, learn
how to use it and become thoroughly familiar with it. Read the entire Navigation System Owner’s Manual to make sure you
understand the system. Do not allow other
people to use this system until they have
read and understood the instructions in this
manual.
For your safety, some functions may become inoperable when driving. Unavailable
screen buttons are dimmed. Only when the
vehicle is not moving, can the destination
and route selection be done.
CAUTION
● For safety, the driver should not operate
the navigation system while he/she is
driving. Insufficient attention to the road
and traffic may cause an accident.
● While driving, be sure to obey the traffic
regulations and maintain awareness of
the road conditions. If a traffic sign on the
road has been changed, route guidance
may not have the updated information
such as the direction of a one way street.
While driving, listen to the voice instructions
as much as possible and glance at the
screen briefly and only when it is safe. However, do not totally rely on voice guidance.
Use it just for reference. If the system cannot determine the current position correctly, there is a possibility of incorrect, late, or
non-voice guidance.
The data in the system may occasionally be
incomplete. Road conditions, including
driving restrictions (no left turns, street closures, etc.) frequently change. Therefore,
before following any instructions from the
system, look to see whether the instruction
can be done safely and legally.
This system cannot warn about such things
as the safety of an area, condition of streets,
and availability of emergency services. If unsure about the safety of an area, do not drive
into it. Under no circumstances is this system a substitute for the driver’s personal
judgement.
Use this system only in locations where it is
legal to do so. Some areas may have laws
prohibiting the use of video and navigation
screens next to the driver.
5
TABLE OF CONTENTS
NOT FOR REPRODUCTION
QUICK GUIDE
1
1. NAVIGATION OPERATION........... .......... 10
Remote Touch ........................................................... 10
MAP SCREEN ......................................................... 12
REGISTERING HOME .......................................14
REGISTERING QUICK ACCESS.................16
OPERATION FLOW:
GUIDING THE ROUTE ..................................18
SETTING HOME AS THE
DESTINATION .................................................. 20
2. FUNCTION I NDEX .................. ................... 22
NAVIGATION SYSTEM FUNCTION
INDEX .....................................................................22
3. QUICK REF EREN CE............... ................... 24
“Menu” SCREEN....................................................24
“Navigation menu” SCREEN ............................26
“Setup” SCREEN ....................................................27
BASIC FUNCTION
2
1. BASIC INFORMATION BEFORE
OPERATION ....... .......................... .............. 30
INITIAL SCREEN.................................................. 30
HOW TO USE THE Remote Touch...............31
INPUTTING LETTERS AND
NUMBERS/LIST SCREEN
OPERATION ...................................................... 33
SCREEN ADJUSTMENT...................................37
MAP SCREEN OPERATION ........................ 39
2. SETUP ................. .......................... ..................... 49
GENERAL SETTINGS....................................... 49
VOICE SETTINGS............................................... 58
NAVIGATION SYSTEM
3
1. DESTINATION SEARCH............................ 62
QUICK REFERENCE ......................................... 62
DESTINATION SEARCH ................................. 64
STARTING ROUTE GUIDANCE............... 80
2. ROUTE GUIDANCE ................................... 83
ROUTE GUIDANCE SCREEN.....................83
TYPICAL VOICE GUIDANCE
PROMPTS .............................................................86
DISTANCE AND TIME TO
DESTINATION .................................................. 88
SUSPENDING AND RESUMING
GUIDANCE.........................................................89
TRAFFIC ....................................................................90
SETTING ROUTE .................................................93
DISPLAY POI* ICONS....................................100
3. MEMORY POINTS .................................... 103
MEMORY POINT SETTINGS ..................... 103
4. SETUP ................ .......................... .....................124
NAVIGATION SETTINGS ............................ 124
VEHICLE SETTINGS ........................................ 130
TRAFFIC SETTINGS.......................................... 135
5. GPS (GLOBAL POSITIONING
SYSTEM). ............................ ......................... 138
LIMITATIONS OF THE
NAVIGATION SYSTEM .............................138
MAP DATABASE VERSION
AND COVERED AREA .............................. 140
*: Point of Interest
6
SPEECH COMMAND SYSTEM
NOT FOR REPRODUCTION
4
1. SPEECH COMMAND SYSTEM
OPERATION..... ............................ ............. 144
SPEECH COMMAND SYSTEM ................ 144
COMMAND LIST .............................................. 148
1
2
5 12.3-INCH DISPLAY
1. 12.3-INCH DISPLAY OPERATION...... 150
12.3-INCH DISPLAY-OVERVIEW........... 150
INITIAL SCREEN.................................................152
“Menu” SCREEN ..................................................154
BASIC SCREENS............................................... 155
INTERRUPTION SCREENS ..........................162
INDEX
ALPHABETICAL INDEX ............................... 166
3
4
5
7
8
NOT FOR REPRODUCTION
1
NOT FOR REPRODUCTION
QUICK GUIDE
NAVIGATION OPERATION
1
1. Remote Touch ................................................ 10
2. MAP SCREEN .............................................. 12
3. REGISTERING HOME.............................. 14
4. REGISTERING QUICK ACCESS......... 16
5. OPERATION FLOW:
GUIDING THE ROUTE ... ...................... 18
6. SETTING HOME AS THE
DESTINATION ........... ............................ ..20
FUNCTION INDEX
2
1. NAVIGATION SYSTEM
FUNCTION INDEX ................................ 22
1
2
3
4
5
QUICK REFERENCE
3
1. “Menu” SCREEN ......................................... 24
2. “Navigation menu” SCREEN ................... 26
3. “Setup” SCREEN ......................................... 27
9
1. NAVIGATION OPERATION
NOT FOR REPRODUCTION
1. Remote Touch
10
1. NAVIGATION OPERATION
NOT FOR REPRODUCTION
No. Name Func tion Pa ge
“MENU” button Press to display the “Menu” screen. 24
“·” button
Press to change the scale of the map and to scroll
the list screen.
31, 35, 47
1
QUICK GUIDE
“MAP/VOICE”
button
Remote Touch
knob
Press to repeat a voice guidance, cancel screen
scroll, start guidance, and display the current position.
Move in the desired direction to select a function,
letter and map screen button.
Press to enter the selected function, letter or map
screen button.
39
31
11
1. NAVIGATION OPERATION
NOT FOR REPRODUCTION
2. MAP SCREEN
No. Name Func tion Pa ge
2D north up, 2D
heading up or 3D
heading up symbol
Scale indicator This figure indicates the map scale. 47
Zoom out button Select to reduce the map scale. 47
“Save”
“Route”
12
This symbol indicates whether the map orientation is set to north-up or heading-up. A north up
view of the map is available in 2D map mode only.
A heading up view of the map is available in 2D
and 3D map modes.
Select to register the current position or the cursor position as a memory point.
Select to change routes and/or destinations. In
addition, the route overview and route trace functions can also be used.
47
41
93
1. NAVIGATION OPERATION
NOT FOR REPRODUCTION
No. Name Func tion Pa ge
“POI”
“WW Off”
Zoom in button Select to magnify the map scale. 47
Select to set the Points of Interest to be displayed
on the screen.
Select to obtain a broader view. Some of the buttons on the screen will not be displayed. They are
displayed again by selecting “O n XX”.
100
126
1
QUICK GUIDE
Map
configuration
Distance and
time to destination
Traffic indicator
“GPS” mark
(Global Positioning System)
*:Press and hold the “PWR/VOL” knob for 3 seconds or more to turn off the screen and restart the
navigation system. Do this when the vehicle-mounted device response is extremely slow.
INFORMATION
●
Remove dirt from the display and its surrounding area by lightly wiping with a soft, dry cloth,
such as a cloth used for cleaning glasses with plastic lenses. Scrubbing too hard or using a
hard cloth could scratch the display. Also, the display is treated with a coating, and could be
damaged by coming into contact with benzine or alkaline solution.
● When the screen is viewed through polarized sunglasses, a rainbow pattern may appear on
the screen due to optical characteristics of the screen. If this is disturbing, please operate
the screen without polarized sunglasses.
Any one of the map configurations can be selected.
Select to display the distance, estimated travel
and arrival time to the destination.
This mark is displayed when traffic information is
received.
Whenever the vehicle is receiving signals from the
GPS, this mark is displayed.
44
88
91
138
13
1. NAVIGATION OPERATION
NOT FOR REPRODUCTION
3. REGISTERING HOME
1
Press the “MENU” button on the
Remote Touch.
2
Select “Navi” and press the Remote
Touch knob.
3
Select “Destination” and press the
Remote Touch knob.
4
Select “Home” and press the
Remote Touch knob.
If a home address has not been registered, it can be registered it by selecting
“Home”.
5
Select “Yes” and press the Remote
Touch knob.
6
There are 9 different methods to
search your home. (See “DESTINATION SEARCH” on page 64.)
14
7
NOT FOR REPRODUCTION
Select “Enter” and press the
Remote Touch knob.
Registration of home is complete.
Home can also be registered by selecting
“Memory” on the “Navigation menu”
screen. (See “REGISTERING HOME”
on page 104.)
The name, location, telephone number
and icon can be changed. (See “EDITING
HOME” on page 105.)
The registered points can be used on the
“Destination” screen. (See “DESTINATION SEARCH BY HOME” on page
66.)
1. NAVIGATION OPERATION
1
QUICK GUIDE
15
1. NAVIGATION OPERATION
NOT FOR REPRODUCTION
4. REGISTERING QUICK ACCESS
1
Press the “MENU” button on the
Remote Touch.
2
Select “Navi” and press the Remote
Touch knob.
3
Select “Destination” and press the
Remote Touch knob.
4
Select one of the quick access
screen buttons and press the
Remote Touch knob.
A quick access can be set to any quick access screen button that has not yet been
set.
5
Select “Yes” and press the Remote
Touch knob.
6
There are 9 different methods to
search quick access. (See “DESTINATION SEARCH” on page 64.)
16
7
NOT FOR REPRODUCTION
Select “Enter” and press the
Remote Touch knob.
Registration of quick access is complete.
Quick access can also be registered by
selecting “Memory” on the “Navigation
menu” screen. (See “REGISTERING
QUICK ACCESS” on page 106.)
The name, location, telephone number
and icon can be changed. (See “EDITING
QUICK ACCESS” on page 107.)
The registered points can be used on the
“Destination” screen. (See “DESTINATION SEARCH BY QUICK ACCESS”
on page 66.)
1. NAVIGATION OPERATION
1
QUICK GUIDE
17
1. NAVIGATION OPERATION
NOT FOR REPRODUCTION
5. OPERATION FLOW: GUIDING THE ROUTE
1
Press the “MENU” button on the
Remote Touch.
2
Select “Navi” and press the Remote
Touch knob.
3
Select “Destination” and press the
Remote Touch knob.
4
There are 11 different methods to
search destinations. (See “DESTINATION SEARCH” on page 64.)
XPage 1
XPage 2
5
Select “Enter” and press the
Remote Touch knob.
The navigation system performs a search
for the route.
18
6
NOT FOR REPRODUCTION
Select “Start” and press the Remote
Touch knob. Then start driving.
Routes other than the one recommended
can also be selected. (See “STARTING
ROUTE GUIDANCE” on page 80.)
Guidance to the destination is displayed
on the screen and can be heard via voice
guidance.
1. NAVIGATION OPERATION
1
QUICK GUIDE
19
1. NAVIGATION OPERATION
NOT FOR REPRODUCTION
6. SETTING HOME AS THE DESTINATION
1
Press the “MENU” button on the
Remote Touch.
2
Select “Navi” and press the Remote
Touch knob.
3
Select “Destination” and press the
Remote Touch knob.
4
Select “Home” and press the
Remote Touch knob.
“Home” can be used if your home ad-
dress has been registered. (To register
home, see “REGISTERING HOME” on
page 104.)
5
Select “Enter” and press the
Remote Touch knob.
The navigation system performs a search
for the route.
20
6
NOT FOR REPRODUCTION
Select “Start” and press the Remote
Touch knob. Then start driving.
Routes other than the one recommended
can also be selected. (See “STARTING
ROUTE GUIDANCE” on page 80.)
Guidance to the destination is displayed
on the screen and can be heard via voice
guidance.
1. NAVIGATION OPERATION
1
QUICK GUIDE
21
2. FUNCTION INDEX
NOT FOR REPRODUCTION
1. NAVIGATION SYSTEM FUNCTION INDEX
XMap
Displaying maps Pag e
Viewing the map screen 12
Displaying the current position 39
Viewing the current position vicinity map 40
Changing the scale 47
Changing the map orientation 47
Displaying Points of Interest 100
Displaying the estimated travel/arrival time to the destination 88
Selecting the map mode 44
Deleting map screen buttons 126
Displaying traffic information 90
Searching destinations Pag e
Searching the destination 64
Changing the search area 64
Operating the map location of the selected destination 80
XRoute guidance
Before starting route guidance Pag e
Setting the destination 80
Viewing alternative routes 82
Starting route guidance 80
Before starting or during route guidance Page
Viewing the route 80
Adding destinations 93
Changing the route 95
Displaying the estimated travel/arrival time to the destination 88
22
2. FUNCTION INDEX
NOT FOR REPRODUCTION
During route guidance Pa g e
Suspending route guidance 89
Adjusting route guidance volume 59
Deleting the destination 94
Displaying the entire route map 97
XUseful functions
Memory points Pa ge
Registering memory points 109
Marking icons on the map 109
Information Pa ge
Displaying vehicle maintenance 130
Speech command system Pa ge
1
QUICK GUIDE
Operating the system with your voice 144
23
3. QUICK REFERENCE
NOT FOR REPRODUCTION
1. “Menu” SCREEN
Press the “MENU” button on the Remote Touch to display the “Menu” screen.
24
3. QUICK REFERENCE
NOT FOR REPRODUCTION
No. Name Func tion Pa ge
14, 16, 18,
“Navi” Select to display the “Navigation menu” screen.
20, 26, 62,
90, 103,
140
1
QUICK GUIDE
“Info”
“Display”
“Setup” Select to display the “Setup” screen.
“Telephone” Select to display the hands-free operation screen.
“Climate”
“Media” Select to display the media control screen.
“Radio” Select to display the radio control screen.
Select to display the fuel consumption infromation.
Select to adjust the contrast and brightness of the
screens, turn the display off, etc.
Select to display the air conditioning operation
screen.
Owner’s
Manual
37
27, 49, 58,
124, 130,
135
Owner’s
Manual
Owner’s
Manual
Owner’s
Manual
Owner’s
Manual
25
3. QUICK REFERENCE
NOT FOR REPRODUCTION
2. “Navigation menu” SCREEN
This screen is used for functions such as setting a destination and registering memory
points. Press the “MENU” button on the Remote Touch, then select “Navi” to display
the “Navigation menu” screen.
No. Name Func tion Pa ge
“Destination”
“Suspend guidance” or “Resume guidance”
“Memory”
“Map data”
“Traffic
information”
26
One of 11 different methods can be used to search
for a destination.
Select to suspend or resume guidance. 89
Select to enable changes to “Home”, “Memory
points”, “Quick access”, “Area to avoid”, etc.
Select to display information regarding the map
database version and covered area.
Select to display the traffic information screen. 90
62
103
140
3. QUICK REFERENCE
NOT FOR REPRODUCTION
3. “Setup” SCREEN
The items shown on the “Setup” screen can be set. Press the “MENU” button on the
Remote Touch, then select “Setup” to display the “Setup” screen.
1
QUICK GUIDE
27
3. QUICK REFERENCE
NOT FOR REPRODUCTION
No. Name Func tion Pa ge
“General”
“Voice” Select to set the voice guidance settings. 58
“Navigation”
“Vehicle”
“Traffic”
“Audio” Select to set sound, radio, iPod settings.
“Bluetooth*”
“Telephone”
Select to change the operation sound, automatic
screen change settings, etc.
Select to access the page which enables the setting of the average speed, displayed screen contents, POI categories, etc.
Select to set vehicle information such as maintenance information.
Select to display traffic information icons, receivable traffic stations, etc.
Select to set Bluetooth® phones and Bluetooth
audio devices.
Select to set the telephone sound, phonebook settings, etc.
*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.
49
124
130
135
Owner’s
Manual
®
Owner’s
Manual
Owner’s
Manual
28
2
NOT FOR REPRODUCTION
BASIC FUNCTION
BASIC INFORMATION BEFORE
1
OPERATION
1. INITIAL SCREEN ........................................30
2. HOW TO USE THE Remote Touch ....... 31
3. INPUTTING LETTERS AND
NUMBERS/LIST SCREEN
OPERATION ....... ..................................... 33
4. SCREEN ADJUSTMENT ......................... 37
SCREEN SETTING ADJUSTMENT................. 37
5. MAP SCREEN OPERATION ................ 39
CURRENT POSITION DISPLAY...................... 39
SCREEN SCROLL OPERATION..................... 40
SWITCHING MAP
CONFIGURATIONS.......................................... 44
MAP SCALE ................................................................ 47
MAP ORIENTATION AND
3D MAP MODE..................................................... 47
STANDARD MAP ICONS ................................... 48
1
2
3
4
5
SETUP
2
1. GENERAL SETTINGS............................... 49
SCREENS FOR GENERAL SETTINGS......... 49
2. VOICE SETTINGS ...................................... 58
SCREEN FOR VOICE SETTINGS.................. 58
29
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
1. INITIAL SCREEN
1 When the engine <power> switch is in
ACCESSORY or IGNITION ON
<ON> mode, the initial screen will be
displayed and the system will begin operating.
z Images shown on the initial screen can be
changed to suit individual preferences.
(See page 51.)
CAUTION
● When the vehicle is stopped with the
engine running <the hybrid system operating>, always apply the parking brake for
safety.
z After a few seconds, the “CAUTION”
screen will be displayed.
MAINTENANCE
INFORMATION
This system reminds users when to replace certain parts or components and
shows dealer information (if registered)
on the screen.
When the vehicle reaches a previously
set driving distance or date specified for
a scheduled maintenance check, the “Information” screen will be displayed
when the navigation system begins operating.
z This screen goes off if the screen is not
operated for several seconds.
z To prevent this screen from being dis-
played again, select “Don’t show this info
again.”.
z To register maintenance information, see
“MAINTENANCE” on page 130.
z After about 5 seconds, the “CAUTION”
screen automatically switches to the map
screen. (If a button other than the “MAP/
VOIC E” button on the Remote Touch is
pressed, the function’s corresponding
screen will be displayed.)
30
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
2. HOW TO USE THE Remote Touch
This navigation system can be operated
by the Remote Touch when the engine
<power> switch is in ACCESSORY or
IGNITION ON <ON> mode.
1 Use the Remote Touch knob to select
the desired buttons on the screen.
2 To select the button on the screen, press
the Remote Touch knob. Once a button
has been selected, the screen will
change.
z When the pointer moves close to a button,
it will be automatically pulled onto that button. The strength of this pull can be
adjusted. (See page 56.)
z The pointer will disappear from the screen
if it is not moved for 6 seconds. Operation
of the Remote Touch knob will cause the
pointer to reappear.
z Press the “” button on the Remote Touch
to zoom in on the map screen and the “”
button to zoom out. These buttons can also
be used to scroll up and down on list
screens.
z Press the “MENU” button on the Remote
Touch to set a destination or adjust settings
for the audio/video system, air conditioning
system, etc.
z The map screen can be returned to by
pressing the “MAP/VOICE” button on the
Remote Touch.
CAUTION
● Do not allow fingers, fingernails or hair to
become caught in the Remote Touch as
this may cause an injury.
● Be careful when touching the Remote
Touch in extreme temperatures as it may
become very hot or cold due to the temperature inside the vehicle.
2
BASIC FUNCTION
31
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
NOTICE
● Do not allow the Remote Touch to come
into contact with food, liquid, stickers or lit
cigarettes as doing so may cause it to
change colour, emit a strange odor or
stop functioning.
● Do not subject the Remote Touch to
excessive pressure or strong impact as
the knob may bend or break off.
● Do not allow coins, contact lenses or
other such items to become caught in the
Remote Touch as this may cause it to stop
functioning.
● Items of clothing may rip if they become
caught on the Remote Touch knob.
● If your hand or any object is on the
Remote Touch knob when the engine
<power> switch is turned to
ACCESSORY mode, the Remote Touch
knob may not operate properly.
INFORMATION
●
Under extremely cold conditions, the
Remote Touch knob may react slowly.
32
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
3. INPUTTING LETTERS AND NUMBERS/LIST SCREEN OPERATION
When searching for an address or
name, or entering data, letters and numbers can be input via the screen.
TO INPUT LETTERS AND
NUMBERS
1 Select the keys directly to enter letters
or numbers.
: Select to erase one character. Select
and hold to continue erasing characters.
z On certain letter entry screens, letters can
be entered in upper or lower case.
TO CHANGE CHARACTER
AND KEYBOARD TYPE
1 Select .
2
BASIC FUNCTION
2 Select the desired character and key-
board and select “OK”.
z Perform each setting according to the pro-
cedures outlined on the following pages.
■ TO INPUT UMLAUTS
1 Select .
2 Select .
Icon Function
Select to enter in lower case.
Select to enter in upper case.
33
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
3 Select the umlaut keys directly to enter
umlauts.
: Select to erase one umlaut. Select
and hold to continue erasing umlauts.
■ TO INPUT NUMBERS AND SYM-
BOLS
1 Select .
2 Select “0-9-%”.
■ SELECTING A KEYBOARD TYPE
Keyboard type can be changed.
1 Select .
2 Select the desired keyboard type.
X“A B C D E ” type
X“QWE RTY” type
3 Select the keys directly to enter num-
bers or symbols.
: Select to erase one number or symbol. Select and hold to continue erasing
numbers and/or symbols.
, : Select to display other symbols.
34
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
TO DISPLAY THE LIST
1 Select “List” to search for an address or
a name.
z Matching items from the database are
listed even if the entered address or name
is incomplete.
z The list will be displayed automatically if the
maximum number of characters is entered
or the number of matching items is 5 or
less.
INFORMATION
●
The number of matching items is shown
on the right side of the screen. If the number of matching items is more than 9999,
the system displays “
” on the screen.
∗∗∗∗
LIST SCREEN OPERATION
When a list is displayed, use the appropriate screen button to scroll through
the list.
Icon Function
Select to skip to the next or previous page.
Select and hold or to scroll
through the displayed list.
This indicates the displayed
screen’s position.
If appears to the right of an item
name, the complete name is too
long to display.
Select to scroll to the end of the
name.
Select to move to the beginni ng
of the name.
INFORMATION
●
The “” and “” buttons on the Remote
Touch can be used to scroll up and down
on list screens.
2
BASIC FUNCTION
35
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
SORTING
The order of a list displayed on the
screen can be rearranged.
1 Select “Sor t”.
2 Select the desired sorting criteria.
Screen button Function
Select to sort in order of
“Distance”
distance from the current
location.
DISPLAYING THE GROUP
LIST
It is possible to display only the desired
group items in the memory point list.
1 Select “Group list”.
z The list of memory points that is registered
in the selected group will be displayed.
“A l l g ro u p” : Select to close the displayed
items, and display all groups.
2 Select the desired group.
“Date”
“Cat egory”
“Icon”
“Name”
36
Select to sort in order of
date.
Select to sort in order of
category.
Select to sort in order of
icon.
Select to sort in order of
name.
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
4. SCREEN ADJUSTMENT
The contrast and brightness of the
screen display and the image the camera displays can be adjusted. The display
can also be turned off, and/or changed
to either day or night mode.
SCREEN SETTING
ADJUSTMENT
ADJUSTING SCREEN
DISPLAY AND CAMERA
SETTINGS
1 Press the “MENU” button on the
Remote Touch.
XAdjusting the screen display
2
BASIC FUNCTION
“Camera”: Select to adjust the image the
camera displays.
XAdjusting the image the camera displays
“Map·Menu”: Select to return to the
screen display settings.
2 Select “Display”.
37
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
CONTRAST AND
BRIGHTNESS ADJUSTMENT
The contrast and brightness of the
screen can be adjusted according to the
brightness of your surroundings. The
display can also be turned off.
1 Select “” or “” to select the desired
function (“Contrast” or “Brightness”).
2 Select the desired screen button to ad-
just contrast and brightness.
Screen button Function
“Contrast” “+”
“Contrast” “-”
“Brightness” “+”
Select to strengthen the
contrast of the screen.
Select to weaken the
contrast of the screen.
Select to brighten the
screen.
CHANGING BETWEEN DAY
AND NIGHT MODE
Depending on the position of the headlight switch, the screen changes to day
or night mode.
1 To display the screen in day mode even
with the headlight switch on, select “Day
mode” on the “Display” screen for
brightness and contrast control.
z The display condition is not changed to
night mode even if head light switch is
turned on when the vehicle is in a bright
area, such as outside in direct sunlight.
INFORMATION
●
If the screen is set to day mode with the
headlight switch turned on, this condition
is memorized in the system even with the
engine <hybrid system> turned off.
“Brightness” “-”
Select to darken the
screen.
3 After adjusting the screen, select “OK”.
z The screen goes off when “Screen off” is
selected. To turn the screen back on, press
any button on the audio panel or on the
Remote Touch. The selected screen
appears.
38
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
5. MAP SCREEN OPERATION
CURRENT POSITION DISPLAY
Press the “MAP/VOICE” button on the
Remote Touch to display the current position. This screen displays the current
position and a map of the surrounding
area.
z The current position mark ( ) appears in
the centre or bottom centre of the map
screen.
z A street name will appear on the bottom of
the screen, depending on the scale of the
map ( ).
z The screen can be returned to this map
screen that shows the current position at any
time, from any screen by pressing the
“MAP/VOICE” button on the Remote
To u c h .
INFORMATION
●
While driving, the current position mark
is fixed on the screen and the map moves.
● The current position is automatically set
as the vehicle receives signals from the
GPS (Global Positioning System). If the
current position is not correct, it is automatically corrected after the vehicle
receives signals from the GPS.
● After 12-volt battery disconnection, or on
a new vehicle, the current position may
not be correct. As soon as the system
receives signals from the GPS, the correct current position is displayed.
2
BASIC FUNCTION
z To correct the current position manually,
see page 128.
39
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
SCREEN SCROLL
OPERATION
When any point on the map is selected,
that point moves to the centre of the
screen and is shown by the cursor mark
().
z Use the scroll feature to move the desired
point to the centre of the screen for looking
at a point on the map that is different from
the current position.
z To scroll over the map, place the pointer in
a position near the desired destination and
then press and hold the Remote Touch
knob. The map will continue scrolling in that
direction until the knob is released.
z A street name, town name, etc. of the
selected point will be shown, depending on
the scale of the map ( ). Distance from
the current position to will also be
shown ( ).
z After the screen is scrolled, the map
remains centred at the selected location
until another function is activated. The
current position mark will continue to
move along your actual route and may
move off the screen. When the “MAP/
VOIC E” button on the Remote Touch is
pressed, the current position mark
returns to the centre of the screen and
the map moves as the vehicle proceeds
along the designated route.
z When the scroll feature is used, the cur-
rent position mark may disappear from
the screen. Press the “MAP/VOICE”
button on the Remote Touch to display
the current position on the map screen.
TO SET THE CURSOR
POSITION AS A DESTINATION
A specific point on the map can be set as
a destination using the scroll function.
1 Select “Enter ”.
z The screen changes and displays the map
location of the selected destination and the
road preference. (See “STARTING
ROUTE GUIDANCE” on page 80.)
40
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
TO REGISTER THE CURSOR
POSITION AS A MEMORY
POINT
Memory point registration enables easy
access to a specific point.
1 Select “Save”.
2 This screen is displayed.
TO REGISTER THE CURSOR
LOCATION AS AN AREA TO
AVOID
A specific location on the map can be
set as an area to avoid using the scroll
function.
1 Select “A v o i d ” .
2 Select either or to change the
size of the area to be avoided.
2
BASIC FUNCTION
z The registered point is shown by on the
map.
3 Select “OK”.
z To change the icon or name, etc., see
“EDITING MEMORY POINTS” on
page 109.
INFORMATION
●
Up to 500 memory points can be registered. If there is an attempt to register
more than 500 memory points, an error
message will appear.
INFORMATION
●
If a destination is input in the area to avoid
or the route calculation cannot be made
without running through the area to
avoid, a route passing through the area to
be avoided may be shown.
● Up to 10 locations can be registered as
areas to avoid. If there are 10 locations
already registered, the following message
will be displayed: “Unable to register
additional points. Perform the operation
again after deleting 1 or more points.”.
41
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
TO SEE INFORMATION
ABOUT THE ICON WHERE
THE CURSOR IS SET
z To display information about an icon, set
the cursor on it.
■ POI INFORMATION
When the cursor is set on a POI icon, the
name and “Info” are displayed at the top
of the screen.
1 Select “Info”.
z If “Enter ” is selected, the position of
the cursor will be set as a destination.
z If there is already a set destination, “Ad d
to ” and “Replace ” will be dis-
played.
“Add to ”: Select to add a destination.
“Replace ”: Select to delete the existing
destination(s) and set a new one.
z To register this POI as a memory point,
select “Save”. (See “REGISTERING
MEMORY POINTS” on page 109.)
z If is selected, the registered tele-
phone number can be called.
z The desired POI can be displayed on the
map screen. (See “DISPLAY POI
ICONS” on page 100.)
■ MEMORY POINT INFORMATION
When the cursor is set on a memory
point icon, the name and “Info” are displayed at the top of the screen.
1 Select “Info”.
2 Information such as the name, address,
position and telephone number are displayed.
42
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
2 Information such as the name, address,
position and telephone number are displayed.
z If “Enter ” is selected, the position of
the cursor will be set as a destination.
z If there is already a set destination, “A d d
to ” and “Replace ” will be dis-
played.
“Add to ”: Select to add a destination.
“Replace ”: Select to delete the existing
destination(s) and set a new one.
z To edit a memory point, select “Edit”.
(See “EDITING MEMORY POINTS” on
page 109.)
z To delete a memory point, select
“Delete”.
z If is selected, the registered tele-
phone number can be called.
z If detailed memory point information or
images are registered in the navigation system, select “Detail” to view the information.
■ DESTINATION INFORMATION
When the cursor is set on a destination
icon, the name and “Info” are displayed
on the top of the screen.
2
1 Select “Info”.
BASIC FUNCTION
2 Information such as the name, address,
position and telephone number are displayed.
z To delete a destination, select “Delete”.
z If is selected, the registered tele-
phone number can be called.
“Comm ent”: Select to view detailed memory point information.
“Image”: Select to view memory point images.
43
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
■ TRAFFIC INFORMATION
When the cursor is pointed to a traffic information icon while a traffic station is
being received, the traffic information
and “Info” are displayed.
1 Select “Info”.
2 Traffic information will be displayed on
the screen.
SWITCHING MAP
CONFIGURATIONS
Any of the screen configurations can be
selected.
1 Select .
2 Select the screen buttons to select the
desired configuration.
z To display detailed traffic event information,
select “Details”.
INFORMATION
●
Even when traffic information is not currently being received, traffic information
and “Info” will be displayed for a while
after traffic information has been
received.
44
z Depending on the conditions, certain con-
figuration screen buttons cannot be
selected.
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
Screen button Function
Select to display the sin-
“Single map”
“Dual map”
“Compass”
“Turn List”
“A r r o w ”
“Intersection”
“Motorway”
gle map screen. (See
page 45.)
Select to display the dual
map screen. (See page
45.)
Select to display the
compass mode screen.
(See page 46.)
Select to display the turn
list screen. (See page
85.)
Select to display the arrow screen. (See page
85.)
Select to display the intersection guidance
screen or the guidance
screen on the motorway.
(See page 84.)
Select to display the motorway information. (See
page 83.)
SCREEN CONFIGURATIONS
■ SINGLE MAP
This is a regular map screen.
z The screen shows the single map.
z While on a different screen, selecting
“Single map” will display the single map
screen.
■ DUAL MAP
The map screen can be split into two.
2
BASIC FUNCTION
z This screen shows the dual map. The map
on the left is the main map.
z While on a different screen, selecting
“Dual map” will display the dual map
screen.
45
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
■ EDITING RIGHT MAP
The right side map can be edited by selecting any specific point on the right
side map.
1 Select the desired screen button.
z The following procedures can be per-
formed on this screen:
No. Function
Changing the orientation of the map
Displaying POI icons
Showing traffic information (See
page 90.)
Changing the map scale
2 Select “OK” when editing is completed.
z The screen returns to the dual map screen.
■ COMPASS
The current position is indicated with a
compass not with a map.
z Information about the destination, current
position and a compass is displayed on the
screen.
z While on a different screen, selecting
“Compass” will display the compass
mode screen.
INFORMATION
●
The destination mark is displayed in the
direction of the destination. When driving, refer to the longitude and latitude
coordinates, and the compass, to make
sure that the vehicle is headed in the
direction of the destination.
● When the vehicle travels out of the cover-
age area, the guidance screen changes to
the compass mode screen.
46
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
MAP SCALE
1 Select or to change the scale
of the map screen.
z The scale bar and indicator at the bottom of
the screen indicates the map scale menu.
The scale range is from 50 m to 400 km.
z Select and hold or to continue
changing the scale of the map screen.
z The scale of the map screen can be
changed by selecting the scale bar directly.
This function is not available while driving.
INFORMATION
●
Press the “” button on the Remote
Touch to zoom in on the map screen and
the “” button to zoom out.
● The map scale is displayed under the
north-up or heading-up symbol at the top
left of the screen.
● When the map scale is at the maximum
range of 400 km, is not shown.
When the map scale is at the minimum
range of 50 m,
is not shown.
MAP ORIENTATION AND 3D
MAP MODE
The orientation of the map can be
changed between 2D north-up, 2D
heading-up and 3D heading-up by selecting the orientation symbol displayed
at the top left of the screen.
1 Select , or .
XNorth-up screen
XHeading-up screen
X3D screen
2
BASIC FUNCTION
47
1. BASIC INFORMATION BEFORE OPERATION
NOT FOR REPRODUCTION
: North-up symbol
Regardless of the direction of vehicle travel,
north is always up.
: Heading-up symbol (When in 2D
map mode)
The direction of vehicle travel is always up.
A red arrow indicates north.
: Heading-up symbol (When in 3D
map mode)
The direction of vehicle travel is always up.
A red arrow indicates north.
z When in 3D map mode, only the heading
up map orientation is available.
STANDARD MAP ICONS
Icon Description
Island
Park
Industry
Business facility
Airport
Military
University
Hospital
Stadium
Shopping mall
Golf
48
2. SETUP
NOT FOR REPRODUCTION
1. GENERAL SETTINGS
Used for the on/off settings of operation
sounds, automatic screen change, etc.
1 Press the “MENU” button on the
Remote Touch.
2 Select “Setup”.
3 Select “General”.
4 Select the items to be set.
2
BASIC FUNCTION
5 Select “OK”.
SCREENS FOR GENERAL
SETTINGS
z On this screen, the following functions can
be performed:
49
2. SETUP
NOT FOR REPRODUCTION
No. Function
Select to change the time zone and
select “O n” or “Off ” for daylight saving time. (See “SYSTEM TIME SETTINGS” on page 50.)
Select to customize the opening image. (See “CHANGING THE
OPENING IMAGE” on page 51.)
Select to customize the screen off image. (See “CHANGING THE
SCREEN OFF IMAGE” on page
53.)
Select to set automatic screen changes from the audio/air conditioning
control screen to the map screen to
“On” or “Of f”. If “O n” is selected, the
screen will automatically return to the
map screen from the audio/air conditioning control screen after 20 seconds.
Select to change the screen button
colour. (See “SELECTING A BUTTON COLOUR” on page 55.)
Select to turn the selection sounds
“On” or “Of f”.
SYSTEM TIME SETTINGS
Used for changing time zones and the
on/off settings of daylight saving time.
1 Press the “MENU” button on the
Remote Touch, then select “Setup”.
2 Select “Ge neral” on the “Setup” screen.
3 Select “System time”.
4 Select the items to be set.
Select to turn the pointer sounds
“On” or “Of f”.
Select to turn the error sounds “On”
or “Off ”.
Select to adjust the pointer sound volume. (See “POINTER SOUND
VOLUME SETTINGS” on page 55.)
Select to adjust the strength of the
pull from the buttons to the pointer.
(See “SETTING A FEEDBACK
FORCE” on page 56.)
Select to delete personal data. (See
“DELETING PERSONAL DATA”
on page 56.)
50
z On this screen, the following functions can
be performed:
No. Function
Select to change the time zone. (See
“TIME ZONE” on page 51.)
Select “On” or “Off ” for daylight saving time.
5 Select “OK”.
2. SETUP
NOT FOR REPRODUCTION
■ TIME ZONE
A time zone can be selected and GMT
can be set.
1 Press the “MENU” button on the
Remote Touch, then select “Setup”.
2 Select “General” on the “Setup” screen.
3 Select “System time” on the “General
settings” screen.
4 Select “Time zone”.
5 Select the desired time zone.
z If “Ot her ” is selected, the zone can be
adjusted manually. Select “+” or “-” to
adjust the time zone and then select “OK”.
CHANGING THE OPENING
When the engine <power> switch is in
ACCESSORY or IGNITION ON
<ON> mode, the initial screen will be
displayed.
Also, an image can be copied from a
USB memory and used as the opening
image. (For information regarding the
opening image, see “INITIAL SCREEN”
on page 30.)
INFORMATION
●
When saving the images to a USB, name
the folder that the startup image is saved
to “StartupImage” and name the folder
that the screen off image is saved to
“DisplayOffImage”. If these folder names
are not used, the navigation system cannot download the images. (The folder
names are case sensitive.)
● The images file extension is JPG or
JPEG.
● The images file name, including the file
extension, can be up to 32 characters.
● Image files of 10 MB or less can be saved.
● Up to 3 images can be downloaded.
● On vehicles with a 12.3-inch display, the
opening image can be selected from 3
preregistered movies. (See page 152.)
2
BASIC FUNCTION
6 Select “OK” .
51
2. SETUP
NOT FOR REPRODUCTION
■ TRANSFERRING DATA
1 Open the console box.
2 Open the cover and connect a USB
memory.
z Turn on the power of the USB memory if it
is not turned on.
3 Close the console box.
6 Select “Change opening image”.
7 Select “Transfer”.
8 Select “Yes”.
4 Press the “MENU” button on the
Remote Touch, then select “Setup”.
5 Select “General” on the “Setup” screen.
52
2. SETUP
NOT FOR REPRODUCTION
■ SETTING THE OPENING IMAGE
1 Press the “MENU” button on the
Remote Touch, then select “Setup”.
2 Select “General” on the “Setup” screen.
3 Select “Change opening image” on the
“General settings” screen.
4 Select the desired image.
5 Select “OK”.
■ DELETING TRANSFERRED IMAG-
ES
1 Press the “MENU” button on the
Remote Touch, then select “Setup”.
2 Select “General” on the “Setup” screen.
3 Select “Change opening image” on the
“General settings” screen.
4 Select “Delete all”.
CHANGING THE SCREEN
OFF IMAGE
Select “Screen off” to turn off the
screen. An image can be copied from a
USB memory and can be set to display
when “Screen off” is selected. (For
more information on “Screen off”, see
“SCREEN ADJUSTMENT” on page
37.)
■ TRANSFERRING DATA
1 Open the console box.
2 Open the cover and connect a USB
memory.
2
BASIC FUNCTION
z Turn on the power of the USB memory if it
5 Select “Yes”.
is not turned on.
53
2. SETUP
NOT FOR REPRODUCTION
3 Close the console box.
4 Press the “MENU” button on the
Remote Touch, then select “Setup”.
5 Select “General” on the “Setup” screen.
6 Select “Change screen off image”.
7 Select “Transfer”.
8 Select “Yes”.
■ SETTING THE SCREEN OFF IM-
AGE
1 Press the “MENU” button on the
Remote Touch, then select “Setup”.
2 Select “Ge neral” on the “Setup” screen.
3 Select “Change screen off image” on
the “General settings” screen.
4 Select the desired image.
5 Select “OK”.
■ DELETING TRANSFERRED IMAG-
ES
1 Press the “MENU” button on the
Remote Touch, then select “Setup”.
2 Select “Ge neral” on the “Setup” screen.
3 Select “Change screen off image” on
the “General settings” screen.
4 Select “Delete all”.
5 Select “Yes”.
54
2. SETUP
NOT FOR REPRODUCTION
SELECTING A BUTTON
COLOUR
The colour of the screen buttons can be
changed.
1 Press the “MENU” button on the
Remote Touch, then select “Setup”.
2 Select “General” on the “Setup” screen.
3 Select “Button colour”.
4 Select the desired screen button colour.
POINTER SOUND VOLUME
SETTINGS
The pointer sound volume can be adjusted.
1 Press the “MENU” button on the
Remote Touch, then select “Setup”.
2 Select “General” on the “Setup” screen.
3 Select “Pointer sound volume”.
4 Select the desired button.
2
BASIC FUNCTION
z The previous screen will be displayed.
5 Select “OK”.
5 Select “OK”.
55
2. SETUP
NOT FOR REPRODUCTION
SETTING A FEEDBACK
FORCE
When the pointer moves close to a button, it will be automatically pulled onto
that button. The strength of this pull can
be adjusted.
1 Press the “MENU” button on the
Remote Touch, then select “Setup”.
2 Select “General” on the “Setup” screen.
3 Select “Feedback force”.
4 Select “+” or “-”.
DELETING PERSONAL DATA
1 Press the “MENU” button on the
Remote Touch, then select “Setup”.
2 Select “Ge neral” on the “Setup” screen.
3 Select “Delete personal data”.
4 Select “Delete”.
5 Select “Yes”.
5 Select “OK”.
56
z The following personal data can be deleted
NOT FOR REPRODUCTION
or returned to their default settings:
• Maintenance conditions
• Maintenance information off setting
•Memory point
• Password settings for backing up and
copying memory points
•Areas to avoid
•Previous points
•Route guidance
• Route trace
• Phonebook data
• Call history data
• Speed dial data
• Bluetooth
• Telephone sound settings
• Telephone display settings
• Audio/video setting
• Bluetooth
•Opening image data
• Screen off image data
®
phone data
®
audio setting
2. SETUP
2
BASIC FUNCTION
INFORMATION
●
This function is not available while driving.
57
2. SETUP
NOT FOR REPRODUCTION
2. VOICE SETTINGS
Voice guidance etc. can be set.
1 Press the “MENU” button on the
Remote Touch.
2 Select “Setup”.
3 Select “Voice”.
SCREEN FOR VOICE
SETTINGS
z On this screen, the following functions can
be performed:
No. Function
The voice guidance volume can be
adjusted or switched off. (See
“VOICE VOLUME” on page 59.)
Voice recognition guidance can be
set to “On” or “O ff”. This setting can
also be changed on the “Main menu”
screen. (See page 144.)
Voice guidance during audio/video
and/or air conditioning system use
can be set to “On” or “Off ”.
Voice guidance during route guidance can be set to “On” or “O ff”.
z To reset all setup items, select “Default”.
4 Select the items to be set.
5 Select “OK”.
58
VOICE VOLUME
NOT FOR REPRODUCTION
The voice guidance volume can be adjusted or switched off.
1 Press the “MENU” button on the
Remote Touch, then select “Setup”.
2 Select “Voice” on the “Setup” screen.
3 Select the desired level by selecting the
appropriate number.
z If voice guidance is not needed, select
“Off ” to disable the feature.
4 Select “OK”.
2. SETUP
2
BASIC FUNCTION
59
DESTINATION SEARCH
NOT FOR REPRODUCTION
1
ROUTE GUIDANCE
2
1. QUICK REFERENCE ............................... 62
2. DESTINATION SEARCH ........................ 64
SELECTING THE SEARCH AREA .................. 64
DESTINATION SEARCH BY HOME............ 66
DESTINATION SEARCH BY QUICK
ACCESS .................................................................... 66
DESTINATION SEARCH BY “Address”........ 67
DESTINATION SEARCH BY “POI*” ............. 70
DESTINATION SEARCH BY
“POI* near cursor”.................................................. 72
DESTINATION SEARCH BY “Map”................ 75
DESTINATION SEARCH BY “Memory” ....... 76
DESTINATION SEARCH BY “Previous” ....... 76
DESTINATION SEARCH BY
“Intersection” ............................................................. 77
DESTINATION SEARCH BY
“Motorway ent./exit”............................................. 78
DESTINATION SEARCH BY
“Coordinates”............................................................ 79
3. STARTING ROUTE GUIDANCE ........ 80
1. ROUTE GUIDANCE SCREEN ............ 83
2. TYPICAL VOICE GUIDANCE
PROMPTS ............................ ...................... 86
3. DISTANCE AND TIME TO
DESTINATION ..................... .................... 88
4. SUSPENDING AND RESUMING
GUIDANCE ....... .......................... ............. 89
SUSPENDING GUIDANCE.............................. 89
RESUMING GUIDANCE.................................... 89
5. TRAFFIC ........ ............................ .................... 90
TRAFFIC INFORMATION .................................. 90
60
3
NOT FOR REPRODUCTION
NAVIGATION SYSTEM
6. SETTING ROUTE ....................................... 93
ADDING DESTINATIONS .................................. 93
REORDERING DESTINATIONS ..................... 94
DELETING DESTINATIONS.............................. 94
SEARCH CONDITION......................................... 95
DETOUR SETTING.................................................. 95
ROAD PREFERENCE ............................................ 97
ROUTE OVERVIEW ............................................... 97
ROUTE TRACE.......................................................... 98
7. DISPLAY POI* ICONS........................... 100
SELECTING POI* ICONS TO BE
DISPLAYED............................................................ 100
3 MEMORY POINTS
1. MEMORY POINT SETTINGS ............. 103
SETTING UP THE “Home” .................................. 104
SETTING UP THE “Quick access”................... 106
SETTING UP THE “Memory points” ............... 108
SETTING UP THE “Area to avoid”..................... 114
DELETING PREVIOUS
DESTINATIONS .................................................... 119
BACKUP TO A USB MEMORY ....................... 119
COPYING FROM A USB MEMORY.......... 122
SETUP
4
1. NAVIGATION SETTINGS .................... 124
SCREENS FOR NAVIGATION
SETTINGS................................................................ 124
2. VEHICLE SETTINGS ............................... 130
MAINTENANCE..................................................... 130
VEHICLE CUSTOMIZATION......................... 134
3. TRAFFIC SETTINGS ................................ 135
SCREEN FOR TRAFFIC SETTINGS.............. 135
GPS (GLOBAL POSITIONING
5
SYSTEM)
1. LIMITATIONS OF THE
NAVIGATION SYSTEM....... ..............138
2. MAP DATABASE VERSION
AND COVERED AREA ...................... 140
MAP INFORMATION .......................................... 140
1
2
3
4
5
*: Point of Interest
61
1. DESTINATION SEARCH
NOT FOR REPRODUCTION
1. QUICK REFERENCE
The “Destination” screen enables a destination search. Press the “MENU” button on
the Remote Touch, and select “Navi”. Then select “Destination” to display the “Destination” screen.
No. Name Func tion Pa ge
“Address”
“POI”
“POI near
cursor”
“Previous”
“Memory”
62
Select to input a house number and the street address using the input keys.
Select one of the Points of Interest that have already been stored in the system’s database.
Select to set the destination by selecting the
search point and the POI category.
Select a destination from any of the last 100 previously set destinations and from the previous starting point.
Select the desired location from registered memory points. (To register memory points, see “REGISTERING MEMORY POINTS” on page 109.)
67
70
72
76
76
1. DESTINATION SEARCH
NOT FOR REPRODUCTION
No. Name Func tion Pa ge
“Map”
“Intersection”
“Motorway
ent./exit”
Search area
screen button
Quick access
screen button
“Home”
“Coordinates” Select to enter latitude and longitude coordinates. 79
Select to enable setting a destination by specifying
a location on the map screen.
Select to enter the names of 2 intersecting streets.
This is helpful if only the general vicinity, not the
specific address, is known.
Select to enter the names of a motorway entrance
or exit.
Select to change the search area. 64
Select one of the 5 quick access as a destination.
To use this function, it is necessary to set quick access screen buttons. (To register a quick access,
see “REGISTERING QUICK ACCESS” on page
106.)
Select your personal home address without having to enter the address each time. If a home address has not been registered, a message will be
displayed and the setting screen will automatically
appear. (To register home, see “REGISTERING
HOME” on page 104.)
75
77
78
66
66
3
NAVIGATION SYSTEM
63
1. DESTINATION SEARCH
NOT FOR REPRODUCTION
2. DESTINATION SEARCH
1 Press the “MENU” button on the
Remote Touch.
2 Select “Navi”.
3 Select “Destination”.
INFORMATION
●
When searching a destination, the
response to the screen button may be
slow.
SELECTING THE SEARCH
AREA
1 Press the “MENU” button on the
Remote Touch. (See “Remote Touch”
on page 10.)
2 Select “Navi” on the “Menu” screen.
3 Select “Destination” on the “Navigation
menu” screen.
4 Select the search area screen button to
display a map.
z For map database information and
updates, see “MAP DATABASE VERSION AND COVERED AREA” on page
4 This screen is displayed.
140.
5 Select the desired search area.
z One of 11 different methods can be used to
search a destination. (See pages 64
through 79.)
64
1. DESTINATION SEARCH
NOT FOR REPRODUCTION
6 Select “OK” and the “Destination”
screen will be displayed.
SELECTING THE SEARCH
AREA ON THE INPUT SCREEN
To set a destination from a different area,
change the search area by using “A d -
dress”, “POI”, “Motorway ent./exit” or
“Intersection”.
1 Select the search area screen button on
the input screen to display a map.
z For map database information and
updates, see “MAP DATABASE VERSION AND COVERED AREA” on page
140.
2 Select the desired search area.
Screen button
“WA”
“NT”
“SA” South Australia, Australia
“QLD” Queensland, Australia
“NSW”
“VIC” Victoria, Australia
“TAS” Tasmania, Australia
“NZN”
“NZS”
Countries, states
or territories
Western Australia, Australia
Northern Territory, Australia
New South Wales,
Australia
Australian Capital
Territory (ACT), Australia
Northern Island,
New Zealand
Southern Island,
New Zealand
3 Select “OK” and the previous screen
will be displayed.
3
NAVIGATION SYSTEM
65
1. DESTINATION SEARCH
NOT FOR REPRODUCTION
DESTINATION SEARCH BY
HOME
1 Press the “MENU” button on the
Remote Touch. (See “Remote Touch”
on page 10.)
2 Select “Navi” on the “Menu” screen.
3 Select “Destination” on the “Navigation
menu” screen.
4 Select “Home”.
z The screen changes and displays the map
location for the registered home address
and the road preference. (See “STARTING
ROUTE GUIDANCE” on page 80.)
z To use this function, it is necessary to set a
home address. (To register home, see
page 104.)
INFORMATION
●
If a home address has not been registered, a message will be displayed and
the setting screen will automatically
appear.
● Guidance starts from the current position
to the set home address if “Enter” is
selected even while driving.
DESTINATION SEARCH BY
QUICK ACCESS
1 Press the “MENU” button on the
Remote Touch. (See “Remote Touch”
on page 10.)
2 Select “Navi” on the “Menu” screen.
3 Select “Destination” on the “Navigation
menu” screen.
4 Select any of the quick access screen
buttons (1-5).
z The screen changes and displays the map
location of the quick access and the road
preference. (See “STARTING ROUTE
GUIDANCE” on page 80.)
z To use this function, it is necessary to set
quick access to the quick access screen
buttons (1-5). (See “REGISTERING
QUICK ACCESS” on page 106.)
INFORMATION
●
If a quick access has not been registered,
a message confirming if it is desirable to
set a quick access will be displayed.
● Guidance starts from the current position
to the preset destination point if “Enter”
is selected even while driving.
66
1. DESTINATION SEARCH
NOT FOR REPRODUCTION
DESTINATION SEARCH BY
“Address”
Searching for a destination using an address can be performed by one of the 2
methods shown below:
(a) Inputting a street name
(b) Selecting a town to search
1 Press the “MENU” button on the
Remote Touch. (See “Remote Touch”
on page 10.)
2 Select “Navi” on the “Menu” screen.
3 Select “Destination” on the “Navigation
menu” screen.
4 Select “Address” on the “Destination”
screen.
5 Input the street name or select “Town” to
select a town.
INPUTTING A STREET NAME
1 Press the “MENU” button on the
Remote Touch, then select “Navi”.
2 Select “Destination” on the “Navigation
menu” screen.
3 Select “Ad d r e s s ” on the “Destination”
screen.
4 Input the street name and select “List”.
5 Select the screen button of the desired
street name from the displayed list.
3
NAVIGATION SYSTEM
z If the same address exists in more than 1
town, a screen requesting the town name to
be input or selected will be displayed.
67
1. DESTINATION SEARCH
NOT FOR REPRODUCTION
6 Select or enter the desired town.
“Enter name”: Select to narrow down the
listed items by inputting the town name.
z If an address’s house number has more than
1 prefix, the selection screen will be displayed. Select the desired house number.
7 Input the house number.
z If the house number list screen appears, an
address range on that screen can be
selected.
z The screen changes and displays the map
location of the selected destination and the
road preference. (See “STARTING
ROUTE GUIDANCE” on page 80.)
SELECTING A TOWN TO
SEARCH
1 Press the “MENU” button on the
Remote Touch, then select “Navi”.
2 Select “Destination” on the “Navigation
menu” screen.
3 Select “Address” on the “Destination”
screen.
4 Select “Town”.
5 Select the desired screen button.
z On this screen, the following operations
can be performed:
No. Function
Input the town name
Select from the nearest 5 towns
Cancel the town setting
Select from the last 5 towns
68
1. DESTINATION SEARCH
NOT FOR REPRODUCTION
■ INPUTTING THE TOWN NAME
1 Select “Town name”.
2 Input the town name.
3 Select the screen button of the desired
town name from the displayed list.
: Select to display the selected destination and the road preference. (See
“STARTING ROUTE GUIDANCE” on
page 80.)
z The current screen changes to the screen
for inputting a street name. After inputting
a street name, the screen may change to
the screen for inputting a house number or
a street map.
■ SELECTING FROM THE NEAREST
5 TOWNS
1 Select “Nearest 5 towns”.
2 Select the screen button of the desired
town name from the displayed list.
3
NAVIGATION SYSTEM
z The current screen changes to the screen
for inputting a street name. After inputting
a street name, the screen may change to
the screen for inputting a house number or
a street map.
■ SEARCHING FROM THE LAST 5
TOWNS
1 Select the screen button of the desired
town name.
z If the navigation system has not been used,
no towns will be displayed on the screen.
z The current screen changes to the screen
for inputting a street name. After inputting
a street name, the screen may change to
the screen for inputting a house number or
a street map.
69
1. DESTINATION SEARCH
NOT FOR REPRODUCTION
DESTINATION SEARCH BY
“POI”
1 Press the “MENU” button on the
Remote Touch. (See “Remote Touch”
on page 10.)
2 Select “Navi” on the “Menu” screen.
3 Select “Destination” on the “Navigation
menu” screen.
4 Select “POI” on the “Destination”
screen.
5 Input the name of the POI.
6 Select the screen button of the desired
destination.
XWhen inputting the name of a specific
POI, and there are 2 or more sites with
the same name, the list screen is displayed.
1 Select the screen button of the desired
destination.
z The desired POI can be displayed on the
map screen. (See “DISPLAY POI ICONS”
on page 100.)
SELECTING A TOWN TO
SEARCH
1 Press the “MENU” button on the
Remote Touch, then select “Navi”.
2 Select “Destination” on the “Navigation
menu” screen.
3 Select “POI” on the “Destination”
screen.
4 Select “Town”.
z The screen changes and displays the map
location of the selected destination and the
road preference. (See “STARTING
ROUTE GUIDANCE” on page 80.)
• If the same name exists in more than 1
town, a search can be performed more
easily using “Town” or “Cate gory”. (See
“S ELECTING A TOWN TO SEARCH”
on page 70 and “SELECTING FROM
THE CATEGORIES” on page 72.)
70
1. DESTINATION SEARCH
NOT FOR REPRODUCTION
5 Select the desired screen button.
z On this screen, the following operations
can be performed.
No. Function
Input the town name
Select from the nearest 5 towns
Cancel the town setting
Select from the last 5 towns
■ INPUTTING THE TOWN NAME
1 Select “Town name”.
2 Input the town name.
z The current screen changes to the screen
for inputting the name of the POI. After
inputting the name of the POI, the POI
name list screen may be displayed.
■ SELECTING FROM THE NEAREST
5 TOWNS
1 Select “Nearest 5 towns”.
2 Select the screen button of the desired
town name.
z The current screen changes to the screen
for inputting the name of the POI. After
inputting the name of the POI, the POI
name list screen may be displayed.
■ SEARCHING FROM THE LAST 5
TOWNS
3
NAVIGATION SYSTEM
1 Select the screen button of the desired
town name.
3 Select the screen button of the desired
town name from the displayed list.
z The current screen changes to the screen
for inputting the name of the POI. After
inputting the name of the POI, the POI
name list screen may be displayed.
z If the navigation system has not been used,
no towns will be displayed on the screen.
71
1. DESTINATION SEARCH
NOT FOR REPRODUCTION
SELECTING FROM THE
CATEGORIES
1 Press the “MENU” button on the
Remote Touch, then select “Navi”.
2 Select “Destination” on the “Navigation
menu” screen.
3 Select “POI” on the “Destination”
screen.
4 Select “Cat egor y”.
5 This screen is displayed.
z When the desired category is selected, the
POI name list screen is displayed.
DESTINATION SEARCH BY
“POI near cursor”
The destination can be set by selecting
the search point and the POI category.
1 Press the “MENU” button on the
Remote Touch. (See “Remote Touch”
on page 10.)
2 Select “Navi” on the “Menu” screen.
3 Select “Destination” on the “Navigation
menu” screen.
4 Select “POI near cursor” on the “Desti-
nation” screen.
z If the desired POI category is on the
screen, select its screen button to display a
detailed list of the POI category.
z If the desired POI category is not on the
screen, select “List all categories” to list all
POI categories.
72
1. DESTINATION SEARCH
NOT FOR REPRODUCTION
5 Set the search point by one of the fol-
lowing methods.
No. Function
Enter the town centre
Set the current position as th e search
point
Set the search point via the map
Set the search point from any destination
z It is possible to display the names of POIs
located within approximately 30 km
from the selected search point.
INPUTTING THE TOWN
CENTRE
1 Select “Enter town centre”.
2 Input the town centre name.
3
NAVIGATION SYSTEM
3 Select the screen button of the desired
town centre name.
4 When an arrow facing the desired point
is selected, the map scrolls in that direction.
z The scroll stops when the selection of the
arrow is released.
5 Select “OK”.
z The search point is set and the “POI near
cursor” screen will be displayed.
73
1. DESTINATION SEARCH
NOT FOR REPRODUCTION
SETTING THE CURRENT
POSITION AS THE SEARCH
POINT
1 Select “Current p ositi on”.
z The search point is set at the current posi-
tion, and the “POI near cursor” screen is
displayed.
SETTING THE SEARCH POINT
VIA THE MAP
1 Select “Map”.
2 When an arrow facing the desired point
is selected, the map scrolls in that direction.
z The scroll stops when the selection of the
arrow is released.
3 Select “OK”.
z The search point is set and the “POI near
cursor” screen will be displayed.
SETTING THE SEARCH POINT
FROM DESTINATIONS
1 Select one of the destination screen but-
tons at the bottom of the screen.
2 When an arrow facing the desired point
is selected, the map scrolls in that direction.
z The scroll stops when the selection of the
arrow is released.
3 Select “OK”.
z The search point is set and the “POI near
cursor” screen will be displayed.
■ TO SEARCH FOR POIs NEAR THE
SEARCH POINT
When the search point is set, the “POI
near cursor” screen will be displayed.
1 Select the desired POI categories.
“List”: If the desired POI categories have al-
ready been selected, a list of POI will be displayed from among the selected
categories.
z The selected category’s icon will appear on
the top left of the screen.
74
1. DESTINATION SEARCH
NOT FOR REPRODUCTION
XIf the desired POI category is not on the
screen, select “List all categories” to list
all POI categories.
1 Select the desired POI categories from
the list and select “OK”.
z The selected category’s icon will appear on
the top left of the screen.
No. Function
Select to return to the POI category
selection screen.
Select to display the list of POIs in
the selected categories.
z By selecting the screen button of the
desired item, the screen changes and displays the map location of the selected destination and the road preference. (See
“STARTING ROUTE GUIDANCE” on
page 80.)
z The direction arrows of POIs are displayed
only when the current position is set as the
search point.
“On ro ute”: When the indicator is illuminated by selecting this screen button, the list of
the items searched along the route is displayed.
DESTINATION SEARCH BY
“Map”
1 Press the “MENU” button on the
Remote Touch. (See “Remote Touch”
on page 10.)
2 Select “Navi” on the “Menu” screen.
3 Select “Destination” on the “Navigation
menu” screen.
4 Select “Map” on the “Destination”
screen.
5 Scroll the map to the desired point.
3
NAVIGATION SYSTEM
6 Select “Enter”.
z The navigation system performs a search
for the route. (See “STARTING ROUTE
GUIDANCE” on page 80.)
75
1. DESTINATION SEARCH
NOT FOR REPRODUCTION
INFORMATION
●
Guidance starts if “OK” is selected even
while driving. However, the cursor cannot
be moved.
DESTINATION SEARCH BY
“Memory”
1 Press the “MENU” button on the
Remote Touch. (See “Remote Touch”
on page 10.)
2 Select “Navi” on the “Menu” screen.
3 Select “Destination” on the “Navigation
menu” screen.
4 Select “Memory” on the “Destination”
screen.
5 Select the screen button of the desired
memory point.
z A list of registered memory points is dis-
played.
z The screen changes and displays the map
location of the selected destination and the
road preference. (See “STARTING
ROUTE GUIDANCE” on page 80.)
DESTINATION SEARCH BY
“Previous”
1 Press the “MENU” button on the
Remote Touch. (See “Remote Touch”
on page 10.)
2 Select “Navi” on the “Menu” screen.
3 Select “Destination” on the “Navigation
menu” screen.
4 Select “Previous” on the “Destination”
screen.
5 Select the screen button of the desired
destination.
z The previous starting point and up to 100
previously set destinations are displayed on
the screen.
“Delete”: Select to delete the previous destination. (To delete previous destinations,
see page 119.)
z The screen changes and displays the map
location of the selected destination and the
road preference. (See “STARTING
ROUTE GUIDANCE” on page 80.)
z The list of previous destinations can also
be deleted by selecting “Delete previous
points” on the “Memory point” screen
when the vehicle is stopped. (See
“DELETING PREVIOUS DESTINATIONS” on page 119.)
76
1. DESTINATION SEARCH
NOT FOR REPRODUCTION
DESTINATION SEARCH BY
“Intersection”
1 Press the “MENU” button on the
Remote Touch. (See “Remote Touch”
on page 10.)
2 Select “Navi” on the “Menu” screen.
3 Select “Destination” on the “Navigation
menu” screen.
4 Select “Intersection” on the second
page of the “Destination” screen.
5 Input the name of the 2 intersecting
streets which are located near the destination to be set.
6 Select “List”.
INFORMATION
AU3237TI
If the same 2 streets cross at more than 1
●
intersection, the screen changes and displays the menu to select the town name
where the streets intersect. Select the
town, and the map location of the
selected destination and the road preference. (See “STARTING ROUTE GUIDANCE” on page 80.)
3
NAVIGATION SYSTEM
7 Select the screen button of the desired
item.
z After inputting the 2 intersecting streets,
the screen changes and displays the map
location of the selected destination and the
road preference. (See “STARTING
ROUTE GUIDANCE” on page 80.)
77
1. DESTINATION SEARCH
NOT FOR REPRODUCTION
DESTINATION SEARCH BY
“Motorway ent./exit”
1 Press the “MENU” button on the
Remote Touch. (See “Remote Touch”
on page 10.)
2 Select “Navi” on the “Menu” screen.
3 Select “Destination” on the “Navigation
menu” screen.
4 Select “Motor way ent./exit” on the sec-
ond page of the “Destination” screen.
5 Input a motorway name.
z Be sure to use the complete name of the
motorway when entering the destination.
6 Select the screen button of the desired
motorway.
7 Select “Entrance” or “Exit”.
8 Select the screen button of the desired
entrance or exit name.
z The screen changes and displays the map
location of the selected destination and the
road preference. (See “STARTING
ROUTE GUIDANCE” on page 80.)
78
DESTINATION SEARCH BY
NOT FOR REPRODUCTION
“Coordinates”
1 Press the “MENU” button on the
Remote Touch. (See “Remote Touch”
on page 10.)
2 Select “Navi” on the “Menu” screen.
3 Select “Destination” on the “Navigation
menu” screen.
4 Select “Co ordi nate s” on the second
page of the “Destination” screen.
5 Input the latitude and the longitude.
1. DESTINATION SEARCH
3
NAVIGATION SYSTEM
6 After inputting the latitude and longi-
tude, select “OK”.
z By selecting the screen button of the
desired point, the screen changes and displays the map location of the selected destination and the road preference. (See
“STARTING ROUTE GUIDANCE” on
page 80.)
79
1. DESTINATION SEARCH
NOT FOR REPRODUCTION
3. STARTING ROUTE GUIDANCE
After inputting the destination, the
screen changes and displays the map location of the selected destination and
the road preference.
1 When an arrow facing the desired point
is selected, the map scrolls in that direction.
z The scroll stops when the selection of the
arrow is released.
2 Select “Enter”.
z The system starts route search and displays
recommended routes.
z If a destination has already been set, “Ad d
to ” and “Replace ” will be dis-
played.
“Replace ”: Select to delete the existing
destinations and set a new one.
“Add to ”: Select to add a destination(s).
“Road preference”: Select to change the
road preference. (See page 97.)
“Info”: If this screen button is displayed on
the top of the screen, select it to view
items such as name, address, position and
telephone number.
3 To start guidance, select “Start”.
No. Function
Current position
Destination point
Type of route and its distance
Distance of the entire route
Select the desired route from 3 possible routes. (See page 82.)
Select to change the route. (See
page 93.)
z Guidance can be paused or resumed.
(See “SUSPENDING AND RESUMING GUIDANCE” on page 89.)
z If “Start” is selected until a beep sounds,
demo mode will start. Press the “MAP/
VOIC E” button on the Remote Touch to
end demo mode.
CAUTION
● Be sure to obey traffic regulations and
keep road conditions in mind while driving. If a traffic sign on the road has been
changed, the route guidance may not
indicate such changed information.
80
1. DESTINATION SEARCH
NOT FOR REPRODUCTION
INFORMATION
●
The route for returning may not be the
same as that for going.
● The route guidance to the destination
may not be the shortest route nor a route
without traffic congestion.
● Route guidance may not be available if
there is no road data for the specified
location.
● When setting the destination on a map
with a scale larger than 800 m, the map
scale changes to 800 m automatically. If
this occurs, set the destination again.
● If a destination that is not located on a
road is set, the vehicle will be guided to
the point on a road nearest to the destination. The road nearest to the point
selected is set as the destination.
TO CHANGE THE ROUTE
BEFORE STARTING
GUIDANCE
■ ROAD PREFERENCES
1 Road preferences can be changed by
selecting “Road preference”.
2 Select the desired road preferences.
z The system will avoid using routes that
include items whose indicators are off.
3 After selecting the desired road prefer-
ence, select “OK”.
z Even if the “A l l o w m o to r w a y ” indicator is
dimmed, the route cannot avoid including a
motorway in some cases.
INFORMATION
●
If the calculated route includes a trip by
ferry, the route guidance shows a sea
route. After you travel by ferry, the current position may be incorrect. Upon
reception of GPS signals, it is automatically corrected.
3
NAVIGATION SYSTEM
81
1. DESTINATION SEARCH
NOT FOR REPRODUCTION
■ 3 ROUTES SELECTION
1 Select “3 routes”.
No. Function
2 Select “Quick 1”, “Quick 2” or “Short”.
No. Function
Select to display the recommended
route.
Select to display the alternative
route.
Select to display the route that is the
shortest distance to the set destination.
Select to display the information
shown below about each of the 3
routes.
Time necessary for the entire trip
Distance of the entire trip
Toll road
Motorway
Ferry
82
2. ROUTE GUIDANCE
NOT FOR REPRODUCTION
1. ROUTE GUIDANCE SCREEN
During route guidance, various types of
guidance screens can be displayed depending on conditions.
SCREEN LAYOUT
No. Function
Distance to the next turn and an arrow indicating the turning direction
Current street name
Distance and travel/arrival time to
the destination
Current position
Guidance route
DURING MOTORWAY
DRIVING
During motorway driving, this screen
displays the distance to the next junction/exit, or POIs in the vicinity of the
motorway exit.
No./
Icon
Current position
POIs that are close to a motorway
exit, exit number and junction name
Distance from the current position to
the exit or junction
Traffic information icons
Function
3
NAVIGATION SYSTEM
INFORMATION
●
If the vehicle goes off the guidance route,
the route is searched again.
● For some areas, the roads have not been
completely digitized in our database. For
this reason, the route guidance may
select a road that should not be traveled
on.
● When arriving at the set destination, the
destination name will be displayed on the
top of the screen. Selecting “Of f” clears
the display.
● When the head-up display is on, turn-by-
turn guidance arrows will be displayed on
the windshield.
Current street name
Select to display the distance to the
next and subsequent parking areas
and parking area POIs.
Select to scroll to farther junctions or
exits.
Select to scroll to closer junctions or
exits.
Select to display the closest 3 junctions or exits.
83
2. ROUTE GUIDANCE
NOT FOR REPRODUCTION
WHEN APPROACHING A
MOTORWAY EXIT OR
JUNCTION
When the vehicle approaches an exit or
junction, the motorway guidance screen
will be displayed.
No. Function
Next street name
Distance from the current position to
the exit or junction
Current position
: Select to hide the motorway guidance
screen.
z Select “Intersection”, or press the “MAP/
VOIC E” button on the Remote Touch, to
change back to the motorway guidance
screen.
WHEN APPROACHING AN
INTERSECTION
When the vehicle approaches an intersection, the intersection guidance
screen will be displayed.
No. Function
Next street name
Distance to the intersection
Current position
: Select to hide the intersection guid-
ance screen.
z Select “Intersection”, or press the “MAP/
VOI CE ” button on the Remote Touch, to
change back to the intersection guidance
screen.
84
2. ROUTE GUIDANCE
NOT FOR REPRODUCTION
OTHER SCREENS
■ TURN LIST SCREEN
On this screen, the list of turns on the
guidance route can be viewed.
1 Select “Turn List” during guidance to
display the turn list.
No. Function
Next street or destination name
Turn direction
Distance between turns
Current street name
■ ARROW SCREEN
On this screen, information about the
next turn on the guidance route can be
viewed.
1 Select “A r ro w ” during guidance to dis-
play the arrow screen.
3
NAVIGATION SYSTEM
No. Function
Exit number or street name
Turn direction
Distance to the next turn
Current street name
85
2. ROUTE GUIDANCE
NOT FOR REPRODUCTION
2. TYPICAL VOICE GUIDANCE PROMPTS
As the vehicle approaches an intersection, or point, where maneuvering the
vehicle is necessary, the system’s voice
guidance will provide various messages.
5km
400m
60m
z The following guidance will be narrated
when the navigation system recognizes the
next action of the vehicle is a U-turn.
No. Voice guidance
No. Voice guidance
“Proceed about 5 kilometers, on the
current road.”
“In 400 meters, heading right at the
roundabout. Take 3rd exit.”
“Heading right at the roundabout.
Take 3rd exit.”
“Exit coming up.”
INFORMATION
●
Even if the surface street and motorway
have a similar configuration, voice guidance will be made at the different point.
“In 600 meters, make a U-turn.”
“Make a U-turn if possible.”
No. Voice guidance
“Your destination is ahead.”
or
“The route guidance will discontinue
ahead.”
“You have arrived at your destination. The route guidance is now finished.”
or
“You are in the vicinity of your destination, the route guidance is now finished.”
86
2. ROUTE GUIDANCE
NOT FOR REPRODUCTION
■ ROUTE INCLUDING IPD ROADS
*
Canberra
No. Voice guidance
“In 1 kilometer, keep right.”
“Keep right, then 500 meters later
keep right, towards Canberra.”
z If a voice guidance command cannot be
heard, press the “MAP/VOICE” button
on the Remote Touch while the current
position screen is displayed on the
screen to hear it again.
z To adjust the voice guidance volume, see
“VOICE VOLUME” on page 59.
INFORMATION
●
Voice guidance may be made early or
late.
● If the system cannot determine the cur-
rent position correctly, you may not hear
voice guidance or may not see the magnified intersection on the screen.
3
NAVIGATION SYSTEM
z After the system has calculated a route, it
will advise the user whether IPD roads are
included in the route or not.
z The portion of the route that covers IPD
roads is indicated by light blue.
No. Voice guidance
“There is the possibility that there are
traffic regulations that are not known
on the way to the destination.” (start
point)
“In 400 meters, left turn.”
“Next left. Please obey all traffic regulations.”
*: The area that includes IPD roads.
z IPD roads are roads that are not yet com-
pletely digitized in our database. However, their geometry, name and
administrative coding are already known.
CAUTION
● Be sure to obey the traffic regulations and
keep the road condition in mind especially when you are driving on IPD roads.
The route guidance may not have the
updated information such as the direction
of a one way street.
87
2. ROUTE GUIDANCE
NOT FOR REPRODUCTION
3. DISTANCE AND TIME TO DESTINATION
When the vehicle is on the guidance
route, the distance and the estimated
travel/arrival time to the destination are
displayed. When the vehicle is not on the
guidance route, the distance and direction of the destination are displayed.
When driving on the guidance route
with more than 1 destination set, the distance and estimated travel/arrival time
from the current position to each destination are displayed.
1 Select the screen button indicated by
the arrow.
2 Select the number screen button to dis-
play the desired destination.
Icon Function
Estimated travel time is displayed.
Estimated arrival time is displayed.
Select to switch to estimated arrival time.
Select to switch to estimated
travel time.
Displayed while driving off the
guidance route. The destination
direction is indicated by an arrow.
INFORMATION
●
When the vehicle is on the guidance
route, the distance measured along the
route is displayed. Travel time and arrival
time are calculated based on the set vehicle speed information. (See “AVERAGE
SPEED” on page 125.) However, when
the vehicle is not on the guidance route,
the distance is the linear distance
between the current position and the
destination.
z The distance, estimated travel time and
estimated arrival time from the current
position to the selected destination are displayed.
88
2. ROUTE GUIDANCE
NOT FOR REPRODUCTION
4. SUSPENDING AND RESUMING GUIDANCE
SUSPENDING GUIDANCE RESUMING GUIDANCE
1 Press the “MENU” button on the
Remote Touch.
2 Select “Navi”.
3 Select “Suspend guidance”.
1 Press the “MENU” button on the
Remote Touch. (See “Remote Touch”
on page 10.)
2 Select “Navi” on the “Menu” screen.
3 Select “Resume guidance”.
3
NAVIGATION SYSTEM
z The map screen, with the current position
displayed, will be returned to.
z The screen will return to the current posi-
tion map without route guidance.
89
2. ROUTE GUIDANCE
NOT FOR REPRODUCTION
5. TRAFFIC
Traffic information can be viewed.
1 Press the “MENU” button on the
Remote Touch.
2 Select “Navi”.
3 Select “Traffic information”.
TRAFFIC INFORMATION
This system can receive traffic information from RDS-TMC* stations based on
FM-multiple broadcasting or traffic information providers. It assists the driver
to avoid areas with traffic congestion.
*: Can only be used when receiving RDS-TMC
information. Depending on the country, states
or territories, RDS-TMC may not be possible.
SHOW TRAFFIC EVENT
Traffic events near the current position
can be viewed as a list.
1 Press the “MENU” button on the
Remote Touch, then select “Navi”.
2 Select “Traffic information”.
z A list of traffic information which can be
received is displayed.
90
2. ROUTE GUIDANCE
NOT FOR REPRODUCTION
3 Select the desired traffic event.
“On current road”: To display traffic events
relating to the road currently being used.
“On current route”: To display traffic
events relating to the route currently being
used.
4 Traffic information is displayed on the
screen.
XSelect “Detail” to display detailed traffic
event information.
XSelect “Map” to display around traffic
event information.
TRAFFIC INFORMATION
SCREENS
Traffic information such as traffic congestion, accidents and road closures are
displayed on the map. (For setting traffic
information icons displayed on the
screen, see page 90.)
XOn map screen
3
NAVIGATION SYSTEM
XOn motorway screen
91
2. ROUTE GUIDANCE
NOT FOR REPRODUCTION
No. Name Function
Icons are displayed
Traffic
information
icon
Traffic
information
arrow
on the map. To display information, select the
corresponding icon
on the screen.
Using traffic information, the system
displays arrows
along a road. The colour of the arrow indicates specific road
condition information.
“Red” indicates normal traffic flow.
“Orange” indicates a
traffic jam.
“Blue” indicates a
closed road, accident and so on.
Traffic
information
indicator
92
The indicator comes
on when traffic information is received.
2. ROUTE GUIDANCE
NOT FOR REPRODUCTION
6. SETTING ROUTE
Detour and route conditions can be set
and destinations can be added.
1 Select “Route”.
2 Perform operations according to the
procedures outlined on the following
pages.
z On this screen, the following operations
can be performed:
No. Function Page
Select to set search conditions. 95
Select to set detours. 95
Select to set road preferences.
97
ADDING DESTINATIONS
Destinations can be added and routes
can be searched again.
1 Select “Route”.
3
NAVIGATION SYSTEM
2 Select “Ad d ” .
3 Input an additional destination in the
same way as a destination search. (See
“DESTINATION SEARCH” on page
64.)
4 Select the desired “Add destination
here” to insert the new destination into
the route.
Select to add destinations. 93
Select to delete destinations. 94
Select to reorder destinations. 94
Select to display route
overview.
Select to set route trace. 98
97
z The route overview screen will be dis-
played. (See “ROUTE OVERVIEW” on
page 97.)
93
2. ROUTE GUIDANCE
NOT FOR REPRODUCTION
REORDERING
DESTINATIONS
When more than 1 destination is set, the
arrival order of the destinations can be
changed.
1 Select “Route”.
2 Select “Reorder”.
3 Select the desired destination and se-
lect “Move up” or “Move down” to
change the arrival order.
DELETING DESTINATIONS
A set destination can be deleted.
1 Select “Route”.
2 Select “Delete”.
z When more than 1 destination is set, a list
will be displayed on the screen.
3 Select the destination to be deleted.
“Delete all”: Select to delete all destinations
on the list.
z A message appears to confirm the request
4 After selecting the destinations, select
“OK”.
z The system searches for the guidance
route again, and displays the entire route.
94
to delete.
2. ROUTE GUIDANCE
NOT FOR REPRODUCTION
4 Select “Yes” to delete the destination(s).
z If “Yes” is selected, the data cannot be
recovered. If more than 1 destination has
been set, the system will recalculate the
route(s) to the set destination(s) as necessary.
z If “No” is selected, the previous screen will
be displayed.
SEARCH CONDITION
Road conditions of the route to the destination can be set.
1 Select “Route”.
2 Select “Search condition”.
4 The entire route from the starting point
to the destination is displayed.
No. Function
Select to change a route. (See page
93.)
Select to start guidance.
DETOUR SETTING
While the route guidance is operating,
the route can be changed to detour
around a section of the route where a
delay is caused by road repairs, an accident, etc.
3
NAVIGATION SYSTEM
1 Select “Route”.
3 Select “Qui ck”, “Qui ck 1”, “Qu ick 2”
or “Short” and then select “OK”.
2 Select “Detour”.
95
2. ROUTE GUIDANCE
NOT FOR REPRODUCTION
3 Select a screen button to select the de-
sired detour distance.
“1km”, “3km” or “5km”: Select one of these
screen buttons to start the detour process.
After detouring, the system returns to the
original guidance route.
“Whole route”: Select to make the system
calculate an entire new route to the destination.
“A ro un d t r a f f i c e ve nt ”: Select to make the
system search for the route based on the
traffic congestion information received.
INFORMATION
This picture shows an example of how the
●
system would guide around a delay
caused by a traffic jam.
This position indicates the location of a
traffic jam caused by road repairs, an accident, etc.
This route indicates the detour suggested by the system.
● When the vehicle is on a motorway, the
detour distance selections are 5, 15 and
25 km.
● The system may not be able to calculate a
detour route depending on the selected
distance and surrounding road conditions.
96
2. ROUTE GUIDANCE
NOT FOR REPRODUCTION
ROAD PREFERENCE
A number of choices are available when
setting the conditions the system uses to
determine the route to the destination.
1 Select “Route”.
2 Select “Road preferences” to display
conditions that can be selected when
the system determines the route to the
destination.
ROUTE OVERVIEW
1 Select “Route”.
3
NAVIGATION SYSTEM
2 Select “Route overview”.
3 The entire route from the current posi-
tion to the destination is displayed.
3 Select the desired road preferences.
No. Function
Select to display a list of the turns required to reach the destination.
Select to change the route. (See
z The system will avoid using routes that
include items whose indicators are off.
page 93.)
Select to start guidance.
4 After selecting the desired road prefer-
ence, select “OK”.
97
2. ROUTE GUIDANCE
NOT FOR REPRODUCTION
TURN LIST
1 Select or to skip to the next page
of the list of roads. Select and hold or
to scroll through the list of roads.
: This mark indicates the direction in
which you should turn at the intersection.
“Map”: The selected point is displayed on
the map screen.
ROUTE TRACE
Up to 200 km of the traveled route can
be stored and retraced on the display.
INFORMATION
●
This feature is available when the map
scale is more than 50 km.
TO START RECORDING THE
ROUTE TRACE
1 Select “Route”.
2 Select “Start route trace”.
INFORMATION
●
However, not all road names in the route
may appear on the list. If a road changes
its name without requiring a turn (such as
on a street that runs through 2 or more
towns), the name change will not appear
on the list. The street names will be displayed in order from the starting point,
along with the distance to the next turn.
98
TO STOP RECORDING THE
NOT FOR REPRODUCTION
ROUTE TRACE
1 Select “Route”.
2 Select “Stop route trace”.
2. ROUTE GUIDANCE
3
NAVIGATION SYSTEM
z Selecting “Yes” stops recording and the
route trace remains displayed on the
screen.
z Selecting “No” stops recording and the
route trace is erased.
99
Loading...
