LEXUS ASE30R, GSE31R owners manuals

Download

NOT FOR REPRODUCTION

Pictorial index

NOT FOR REPRODUCTION

For safety

and security

Search by illustration

Make sure to read through them

Instrument cluster

Operation of

each component

Driving

Lexus Display

Audio system

Interior features

Maintenance

and care

When trouble

arises

Vehicle

specifications

How to read the gauges and meters, the variety of warning lights and indicators, etc.

Opening and closing the doors and windows, adjustment before driving, etc.

Operations and advice which are necessary for driving

Operating the Lexus Display Audio system

Usage of the interior features, etc.

Caring for your vehicle and maintenance procedures

What to do in case of malfunction or emergency

Vehicle specifications, customizable features, etc.

Index

Search by symptom

Search alphabetically

TABLE OF CONTENTS2

NOT FOR REPRODUCTION

For your information...................................8

Reading this manual.................................. 12

How to search.............................................. 13

Pictorial index .............................................. 14

For safety and security

1-1. For safe use

Before driving.................................26

For safety drive...............................28

Seat belts..........................................30

SRS airbags .....................................35

Pop Up Hood..................................46

Safety information

for children....................................49

Child restraint systems................50

Installing child restraints............ 58

Exhaust gas precautions............69

1-2. Theft deterrent system

Engine immobilizer system....... 70

Alarm ...................................................71

Instrument cluster

2. Instrument cluster

Warning lights

and indicators..............................78

Gauges and meters.....................83

Multi-information display.......... 88

Fuel consumption

information....................................95

Operation of

each component

3-1. Key information

Keys...................................................102

3-2. Opening, closing and

locking the doors

and trunk

Doors ...............................................108

Trunk...................................................115

Smart entry & start system........119

3-3. Adjusting the seats

Front seats......................................125

Rear seats........................................127

Driving position

memory........................................129

Head restraints.............................134

3-4. Adjusting the steering

wheel and mirrors

Steering wheel ..............................137

Inside rear view mirror..............139

Outside rear view mirrors .........141

NOT FOR REPRODUCTION

3-5. Opening, closing the

windows and moon roof

Power windows ............................ 145

Moon roof......................................149

Driving

4-1. Before driving

Driving the vehicle......................154

Cargo and luggage.................... 162

Trailer towing (vehicles

without a towing

package)......................................163

Trailer towing (vehicles

with a towing package)..........164

4-2. Driving procedures

Engine (ignition) switch ............ 170

Automatic transmission.............175

Turn signal lever ............................ 181

Parking brake................................182

4-3. Operating the lights

and wipers

Headlight switch..........................183

Automatic High Beam..............185

Fog light switch.............................189

Windshield wipers

and washer..................................190

4-4. Refueling

Opening the fuel

tank cap........................................198

4-5. Using the driving support

systems

Stop & Start system

(Smart Stop)..............................202

Cruise control ................................211

Dynamic radar

cruise control.............................215

LDA (Lane Departure

Alert)............................................229

Lexus parking

assist-sensor..............................235

Rear view monitor

system..........................................242

Driving mode select

switch ...........................................252

Driving assist systems...............255

PCS (Pre-Crash Safety

system)...........................................261

BSM

(Blind Spot Monitor).............. 267

•The Blind Spot Monitor

function.....................................269

•The Rear Cross

Traffic Alert function.............271

4-6. Driving tips

Winter driving tips ......................274

TABLE OF CONTENTS4

NOT FOR REPRODUCTION

Lexus Display Audio system

5-1. Basic Operations

Lexus Display

Audio System........................... 280

Steering wheel audio

switches.......................................285

USB/AUX ports .........................286

5-2. Setup

Setup menu..................................288

General settings.........................289

Voice settings...............................292

Display settings...........................293

5-3. Using the audio system

Selecting the

audio source..............................294

Optimal use of the

audio system..............................295

Audio settings..............................296

Audio menu

screen operation .....................299

5-4. Using the radio

Radio operation..........................302

5-5. Playing an audio CD and

MP3/WMA/AAC discs

Audio CD player

operation................................... 304

5-6. Using an external device

Listening to an iPod .................. 309

Using USB memory

device............................................312

Using the AUX port...................316

5-7. Connecting Bluetooth

Steps for using Bluetooth®

devices..........................................317

Registering a Bluetooth

device............................................319

Selecting a Bluetooth

device...........................................320

Connecting a Bluetooth

audio player................................321

Connecting a Bluetooth

phone...........................................322

Displaying a Bluetooth

device details............................323

Detailed Bluetooth

settings.........................................324

5-8. Bluetooth

Listening to Bluetooth

Audio............................................325

Audio

NOT FOR REPRODUCTION

5-9. Bluetooth® Phone

Using a Bluetooth

Phone...........................................327

Making a call................................329

Receiving a call...........................332

Speaking on the phone............333

Using a Bluetooth

phone message........................335

Using the steering

wheel switches ........................ 338

Bluetooth

settings.........................................339

5-10. Phonebook

Contact settings..........................341

Messaging setting......................344

5-11. Bluetooth

Bluetooth®..................................345

5-12. Other function

“Information” screen ..................351

USB photo ....................................352

Speech command system......354

phone

Interior features

6-1. Using the air conditioning

system

Automatic air conditioning

system.........................................358

Seat heaters/

seat ventilators .........................367

6-2. Using the interior lights

Interior lights list..........................369

• Interior lights..........................370

• Personal lights........................370

6-3. Using the storage features

List of storage features............. 372

• Glove box................................373

• Console box...........................373

•Cup holders/

Bottle holders.........................374

Trunk features...............................376

6-4. Using the other interior

features

Other interior features ............ 379

• Sun visors ................................ 379

• Vanity mirrors ........................379

• Clock.........................................379

• Power outlet..........................380

• Armrest.....................................381

• Rear sunshade........................381

• Assist grips............................. 383

• Coat hooks............................ 383

TABLE OF CONTENTS6

NOT FOR REPRODUCTION

Maintenance and care

7-1. Maintenance and care

Cleaning and protecting

the vehicle exterior................386

Cleaning and protecting

the vehicle interior................. 390

7-2. Maintenance

Maintenance

requirements.............................393

7-3. Do-it-yourself maintenance

Do-it-yourself service

precautions................................395

Hood ...............................................397

Positioning a floor jack............ 398

Engine compartment................399

Tires...................................................410

Tire inflation pressure.................418

Wheels............................................420

Air conditioning filter................422

Electronic key battery ..............424

Checking and replacing

fuses..............................................426

Light bulbs.....................................429

When trouble arises

8-1. Essential information

Emergency flashers...................446

If your vehicle has to be

stopped in an

emergency................................. 447

8-2. Steps to take in an

emergency

If your vehicle needs

to be towed................................448

If you think something

is wrong.......................................454

Fuel pump shut off system ......455

If a warning light turns

on or a warning buzzer

sounds..........................................456

If a warning message

is displayed...................................461

If you have a flat tire

(vehicles with a spare

tire).................................................476

NOT FOR REPRODUCTION

If you have a flat tire

(vehicles with run-flat

tires)..............................................487

If the engine will

not start ......................................488

If the shift lever cannot

be shifted from P .....................490

If the electronic key does

not operate properly...............491

If the vehicle battery is

discharged.................................494

If your vehicle overheats .........498

If the vehicle

becomes stuck........................ 502

Vehicle specifications

9-1. Specifications

Maintenance data

(fuel, oil level, etc.).................. 506

Fuel information...........................519

9-2. Customization

Customizable features.............520

9-3. Initialization

Items to initialize .........................529

Index

What to do if...

(Troubleshooting)................................532

Alphabetical index .................................536

For vehicles with a navigation system, refer to the “Navigation System Owner’s Manual” for information regarding the equipment listed below.

• Navigation system

• Audio/video system

• Lexus parking assist-sensor

• Lexus parking assist monitor

NOT FOR REPRODUCTION

For your information

Main Owner’s Manual

Please note that this manual applies to all models and explains all equipment, including options. Therefore, you may find some explanations for equipment not installed on your vehicle.

All specifications provided in this manual are current at the time of printing. However, because of the Lexus policy of continual product improvement, we reserve the right to make changes at any time without notice.

Depending on specifications, the vehicle shown in the illustrations may differ from your vehicle in terms of color and equipment.

Accessories, spare parts and modification of your Lexus

A wide variety of non-genuine spare parts and accessories for Lexus vehicles are currently available in the market. Using these spare parts and accessories which are not genuine Lexus products may adversely affect the safety of your vehicle, even though these parts may be approved by certain authorities in your country. Toyota Motor Corporation therefore cannot accept any liability or guarantee spare parts and accessories which are not genuine Lexus products, nor for replacement or installation involving such parts.

This vehicle should not be modified with non-genuine Lexus products. Modification with non-genuine Lexus products could affect its performance, safety or durability, and may even violate governmental regulations. In addition, damage or performance problems resulting from the modification may not be covered under warranty.

Installation of an RF-transmitter system

NOT FOR REPRODUCTION

The installation of an RF-transmitter system in your vehicle could affect electronic systems such as:

● Multiport fuel injection system/sequential multiport fuel injection system

● Dynamic radar cruise control system

● Cruise control system

● Anti-lock brake system

● Vehicle dynamics integrated management

● SRS airbag system

● Seat belt pretensioner system

Be sure to check with your Lexus dealer for precautionary measures or special instructions regarding installation of an RF-transmitter system.

Further information regarding frequency bands, power levels, antenna positions and installation provisions for the installation of RF-transmitters, is available on request at your Lexus dealer.

Vehicle data recordings

Your Lexus is equipped with several sophisticated computers that will record certain data, such as:

• Engine speed

• Accelerator status

•Brake status

• Vehicle speed

•Shift position The recorded data varies according to the vehicle grade level and options with which it is equipped. Furthermore, these computers do not record conversations, sounds or pictures.

● Data usage

Lexus may use the data recorded in these computers to diagnose malfunctions, conduct research and development, and improve quality.

Lexus will not disclose the recorded data to a third party except:

• With the consent of the vehicle owner or with the consent of the lessee if the vehicle

is leased

• In response to an official request by the police, a court of law or a government

agency

• For use by Lexus in a law suit

• For research purposes where the data is not tied to a specific vehicle or vehicle

owner

NOT FOR REPRODUCTION

Event data recorder

This vehicle is equipped with an event data recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an airbag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed. The EDR is designed to record data related to vehicle dynamics and safety systems for a short period of time, typically 30 seconds or less. However, data may not be recorded depending on the severity and type of a crash.

The EDR in this vehicle is designed to record such data as:

• How various systems in your vehicle were operating;

• How far (if at all) the driver was depressing the accelerator and/or brake pedal; and,

• How fast the vehicle was traveling. These data can help provide a better understanding of the circumstances in which crashes and injuries occur.

NOTE: EDR data are recorded by your vehicle only if a non-trivial crash situation occurs; no data are recorded by the EDR under normal driving conditions and no personal data (e.g., name, gender, age, and crash location) are recorded. However, other parties, such as law enforcement, could combine the EDR data with the type of personally identifying data routinely acquired during a crash investigation. To read data recorded by an EDR, special equipment is required, and access to the vehicle or the EDR is needed. In addition to the vehicle manufacturer, other parties, such as law enforcement, that have the special equipment, can read the information if they have access to the vehicle or the EDR.

● Disclosure of the EDR data

Lexus will not disclose the data recorded in an EDR to a third party except when:

• An agreement from the vehicle’s owner (or the lessee for a leased vehicle) is

obtained

• In response to an official request by the police, a court of law or a government

agency

• For use by Lexus in a law suit However, if necessary, Lexus may:

• Use the data for research on vehicle safety performance

• Disclose the data to a third party for research purposes without disclosing informa-

tion about the specific vehicle or vehicle owner

Scrapping of your Lexus

NOT FOR REPRODUCTION

The SRS airbag and seat belt pretensioner devices in your Lexus contain explosive chemicals. If the vehicle is scrapped with the airbags and seat belt pretensioners left as they are, this may cause an accident such as fire. Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Lexus dealer before you scrap your vehicle.

CAUTI ON

■ General precautions while driving

Driving under the influence: Never drive your vehicle when under the influence of alcohol or drugs that have impaired your ability to operate your vehicle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that could result in death or serious injury.

Defensive driving: Always drive defensively. Anticipate mistakes that other drivers or pedestrians might make and be ready to avoid accidents.

Driver distraction: Always give your full attention to driving. Anything that distracts the driver, such as adjusting controls, talking on a cellular phone or reading can result in a collision with resulting death or serious injury to you, your occupants or others.

■ General precaution regarding children’s safety

Never leave children unattended in the vehicle, and never allow children to have or use the key.

Children may be able to start the vehicle or shift the vehicle into neutral. There is also a danger that children may injure themselves by playing with the windows, the moon roof, or other features of the vehicle. In addition, heat build-up or extremely cold temperatures inside the vehicle can be fatal to children.

NOT FOR REPRODUCTION

Reading this manual

CAUTION: Explains something that, if not obeyed, could cause death or serious injury to people.

NOTICE: Explains something that, if not obeyed, could cause damage to or a malfunction in the vehicle or its equipment.

Indicates operating or working procedures. Follow the steps in numerical order.

Indicates the action (pushing, turning, etc.) used to operate switches and other devices.

Indicates the outcome of an operation (e.g. a lid opens).

Indicates the component or position being explained.

Means “Do not”, “Do not do this”, or “Do not let this happen”.

How to search

NOT FOR REPRODUCTION

■ Searching by name

• Alphabetical index................P. 536

■ Searching by installation position

• Pictorial index ..............................P. 14

■ Searching by symptom or sound

• What to do if...

(Troubleshooting) ..................P. 532

■ Searching by title

• Table of contents .......................... P. 2

NOT FOR REPRODUCTION

Pictorial index

■ Exterior

The shape of the headlights may differ depending on the grade, etc. (→P. 4 30 )

Doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 108

Locking/unlocking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 108

Opening/closing the side windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 145

Locking/unlocking by using the mechanical key . . . . . . . . . . . . . . . . . . . . . . . . P. 491

Warning lights/warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 457, 463

Trunk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 115

Opening from inside the cabin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 115

Opening from outside . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 115

Opening by using the mechanical key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 491

Warning lights/warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 457, 463

Outside rear view mirrors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 141

Adjusting the mirror angle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 141

Folding the mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 14 2

Driving position memory

Defogging the mirrors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 363

*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 129

Pictorial index

NOT FOR REPRODUCTION

Windshield wipers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 190

Precautions against winter season . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 274

Precautions against car wash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 388

Fuel filler door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 198

Refueling method. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 198

Fuel type/fuel tank capacity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 509

Tires. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 410

Tire size/inflation pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 516

Winter tires/tire chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 274

Checking/rotation/tire pressure warning system. . . . . . . . . . . . . . . . . . . . . . . . P. 410

Coping with flat tires. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 476, 487

Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 397

Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 397

Engine oil. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 510

Coping with overheat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 498

Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 463

Light bulbs of the exterior lights for driving (Replacing method: P. 429, Watts: P. 518)

Headlights/front position lights/daytime running lights . . . . . . . . . . . . .P. 183

Fog lights

Turn signal lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 18 1

Tail lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 183

Stop lights

Emergency brake signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 256

License plate lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 183

Back-up lights

Shifting the shift lever to R . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 175

* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 189

*: If equipped

NOT FOR REPRODUCTION

Pictorial index

■ Instrument panel

Engine switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 170

Starting the engine/changing the modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 170

Emergency stop of the engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 447

When the engine will not start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 488

Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 471

Shift lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 175

Changing the shift position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 175

Precautions against towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 448

When the shift lever does not move. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 490

Meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 83

Reading the meters/adjusting the instrument panel light . . . . . . . . . . . . . . . . . P. 83

Warning lights/indicator lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 78

When the warning lights come on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 456

Pictorial index

NOT FOR REPRODUCTION

Multi-information display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 88

Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 88

When the warning messages are displayed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 461

Parking brake. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 182

Applying/releasing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 182

Precautions against winter season . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 275

Warning buzzer/message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 461

Turn signal lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 181

Headlight switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 183

Headlights/front position lights/tail lights/daytime running lights . . . . . . . . P. 183

Fog lights

Windshield wiper and washer switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 190

Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 190

Adding washer fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 409

Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 468

Emergency flasher switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 446

Trunk opener . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 115

Hood lock release lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 397

Tilt and telescopic steering control switch. . . . . . . . . . . . . . . . . . . . . . . . . . . P. 137

Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 137

Driving position memory

Air conditioning system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 358

Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 358

Rear window defogger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 363

Audio system*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 280

Audio system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 280

Hands-free system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 327

Trunk opener main switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 116

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 189

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 129

: For vehicles with a navigation system, refer to “Navigation System Owner's Manual”.

: If equipped

NOT FOR REPRODUCTION

■ Switc hes

Pictorial index

Instrument panel light control switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 86

Odometer/trip meter and trip meter reset button . . . . . . . . . . . . . . . . . . .P. 85

Automatic high beam switch

BSM (Blind Spot Monitor) main switch

Lexus parking assist-sensor switch

Rear sunshade switch

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 185

. . . . . . . . . . . . . . . . . . . . . . . . . . . P. 267

1, 2

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 235

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 381

Pictorial index

NOT FOR REPRODUCTION

PCS OFF switch*1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 262

Tire pressure warning reset switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 413

Outside rear view mirror switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 141

Driving position memory switches

Window lock switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 145

Power window switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 145

Door lock switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 111

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 129

: For vehicles with a navigation system, refer to “Navigation System Owner's Manual”.

: If equipped

NOT FOR REPRODUCTION

Pictorial index

Audio remote control switches*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 285

Paddle shift switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 177

Meter control switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 89

Vehicle-to-vehicle distance button

Cruise control switch

Cruise control*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 211

Dynamic radar cruise control

LDA (Lane Departure Alert) switch*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 229

Ta l k sw i t c h

Telephone switches

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 338

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 338

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 219

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 215

Pictorial index

NOT FOR REPRODUCTION

Driving mode select switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 252

VSC OFF switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 257

Snow mode switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 176

Stop & Start cancel switch

Seat heater switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 367

Seat ventilator switches

Remote Touch

Lexus Display Audio controller*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 282

2, 3

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 202

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 367

: For vehicles with a navigation system, refer to “Navigation System Owner's Manual”.

: Refer to “Navigation System Owner’s Manual”.

: If equipped

NOT FOR REPRODUCTION

■ Interior

Pictorial index

SRS airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 35

Floor mats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 26

Front seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 125

Head restraints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 134

Seat belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 30

Console box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 373

Inside lock buttons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 111

Cup holders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 374

Assist grips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 383

Pictorial index

NOT FOR REPRODUCTION

Inside rear view mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 139

Sun visors

Vanity mirrors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 379

Interior light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 370

Personal lights

Moon roof switches

Intrusion sensor cancel switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 73

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 379

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 370

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 149

: NEVER use a rearward facing child re-

straint on a seat protected by an ACTIVE AIRBAG in front of it, DEATH or SERIOUS INJURY to the CHILD can occur. (→P. 67 )

: The illustration shows the front, but they are also equipped in the rear.

: If equipped

NOT FOR REPRODUCTION

Pictorial index

NOT FOR REPRODUCTION

For safety and security

1-1. For safe use

Before driving.................................26

For safety drive...............................28

Seat belts..........................................30

SRS airbags.....................................35

Pop Up Hood .................................46

Safety information

for children...................................49

Child restraint systems...............50

Installing child restraints.............58

Exhaust gas precautions............ 69

1-2. Theft deterrent system

Engine immobilizer

system.............................................70

Alarm...................................................71

NOT FOR REPRODUCTION

1-1. For safe use

Before driving

Floor mat

Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet.

Insert the retaining hooks (clips) into the floor mat eyelets.

Turn the upper knob of each retaining hook (clip) to secure the floor mats in place.

*: Always align the marks.

The shape of the retaining hooks (clips) may differ from that shown in the illustration.

1-1. For safe use

NOT FOR REPRODUCTION

CAUTI ON

Observe the following precautions. Failure to do so may cause the driver's floor mat to slip, possibly interfering with the pedals while driving. An unexpectedly high speed may result or it may become difficult to stop the vehicle. This could lead to an accident, resulting in death or serious injury.

■ When installing the driver’s floor mat

● Do not use floor mats designed for other models or different model year vehicles,

even if they are Lexus Genuine floor mats.

● Only use floor mats designed for the driver’s seat.

● Always install the floor mat securely using the retaining hooks (clips) provided.

● Do not use two or more floor mats on top of each other.

● Do not place the floor mat bottom-side up or upside-down.

■ Before driving

● Check that the floor mat is securely fixed in

the correct place with all the provided retaining hooks (clips). Be especially careful to perform this check after cleaning the floor.

● With the engine stopped and the shift lever in

P, fully depress each pedal to the floor to make sure it does not interfere with the floor mat.

For safety and security

NOT FOR REPRODUCTION

1-1. For safe use

For safety drive

For safe driving, adjust the seat and mirror to an appropriate position before driving.

Correct driving posture

Adjust the angle of the seatback so that you are sitting straight up and so that you do not have to lean forward to steer. (→P. 12 5)

Adjust the seat so that you can depress the pedals fully and so that your arms bend slightly at the elbow when gripping the steering wheel. (→P. 1 25)

Lock the head restraint in place with the center of the head restraint closest to the top of your ears. (→P. 13 4)

Wear the seat belt correctly. (→P. 3 0)

Correct use of the seat belts

Make sure that all occupants are wearing their seat belts before driving the vehicle. (→P. 30) Use a child restraint system appropriate for the child until the child becomes large enough to properly wear the vehicle’s seat belt. (→P. 50 )

1-1. For safe use

NOT FOR REPRODUCTION

Adjusting the mirrors

Make sure that you can see backward clearly by adjusting the inside and outside rear view mirrors properly. (→P. 139, 141)

CAUTI ON

Observe the following precautions. Failure to do so may result in death or serious injury.

● Do not adjust the position of the driver’s seat while driving.

Doing so could cause the driver to lose control of the vehicle.

● Do not place a cushion between the driver or passenger and the seatback.

A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint.

● Do not place anything under the front seats.

Objects placed under the front seats may become jammed in the seat tracks and stop the seat from locking in place. This may lead to an accident and the adjustment mechanism may also be damaged.

● When driving over long distances, take regular breaks before you start to feel tired.

Also, if you feel tired or sleepy while driving, do not force yourself to continue driving and take a break immediately.

For safety and security

NOT FOR REPRODUCTION

1-1. For safe use

Seat belts

Make sure that all occupants are wearing their seat belts before driving the vehicle.

Correct use of the seat belts

● Extend the shoulder belt so that it

comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.

● Position the lap belt as low as possi-

ble over the hips.

● Adjust the position of the seatback.

Sit up straight and well back in the seat.

● Do not twist the seat belt.

Fastening and releasing the seat belt

To fasten the seat belt, push the plate into the buckle until a click sound is heard.

To release the seat belt, press the release button.

Release button

1-1. For safe use

NOT FOR REPRODUCTION

Adjusting the seat belt shoulder anchor height (front seats)

Push the seat belt shoulder anchor down while pressing the release button.

Push the seat belt shoulder anchor up.

Move the height adjuster up and down as needed until you hear a click.

Seat belt pretensioners (front seats and outboard rear seats)

The pretensioners help the seat belts to quickly restrain the occupants by retracting the seat belts when the vehicle is subjected to certain types of severe frontal collision.

The front seat belt pretensioners also activate when the vehicle is subjected to certain types of severe side collision.

The pretensioners do not activate in the event of a minor frontal impact, a minor side impact, a rear impact or a vehicle rollover.

For safety and security

NOT FOR REPRODUCTION

■ After the rear center seat belt has been used

■ Emergency locking retractor (ELR)

■ Child seat belt usage

■ Replacing the belt after the pretensioner has been activated

■ Seat belt regulations

1-1. For safe use

Stow the buckle as shown.

The retractor will lock the belt during a sudden stop or on impact. It may also lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend so that you can move around fully.

The seat belts of your vehicle were principally designed for persons of adult size.

● Use a child restraint system appropriate for the child, until the child becomes large

enough to properly wear the vehicle’s seat belt. (→P. 5 0)

● When the child becomes large enough to properly wear the vehicle’s seat belt, follow

the instructions regarding seat belt usage. (→P. 3 0)

If the vehicle is involved in multiple collisions, the pretensioner will activate for the first collision, but will not activate for the second or subsequent collisions.

If seat belt regulations exist in the country where you reside, please contact your Lexus dealer for seat belt replacement or installation.

1-1. For safe use

NOT FOR REPRODUCTION

CAUTI ON

Observe the following precautions to reduce the risk of injury in the event of sudden braking, sudden swerving or an accident. Failure to do so may cause death or serious injury.

■ Wearing a seat belt

● Ensure that all passengers wear a seat belt.

● Always wear a seat belt properly.

● Each seat belt should be used by one person only. Do not use a seat belt for more

than one person at once, including children.

● Lexus recommends that children be seated in the rear seat and always use a seat belt

and/or an appropriate child restraint system.

● To achieve a proper seating position, do not recline the seat more than necessary. The

seat belt is most effective when the occupants are sitting up straight and well back in the seats.

● Do not wear the shoulder belt under your arm.

● Always wear your seat belt low and snug across your hips.

■ Pregnant women

Obtain medical advice and wear the seat belt in the proper way. (→P. 30 )

Women who are pregnant should position the lap belt as low as possible over the hips in the same manner as other occupants, extending the shoulder belt completely over the shoulder and avoiding belt contact with the rounding of the abdominal area.

If the seat belt is not worn properly, not only the pregnant woman, but also the fetus could suffer death or serious injury as a result of sudden braking or a collision.

For safety and security

NOT FOR REPRODUCTION

1-1. For safe use

CAUTI ON

■ People suffering illness

Obtain medical advice and wear the seat belt in the proper way. (→P. 30 )

■ When children are in the vehicle

Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’s neck, it may lead to choking or other serious injuries that could result in death. If this occurs and the buckle cannot be unfastened, scissors should be used to cut the belt.

■ Seat belt pretensioners

If the pretensioner has activated, the SRS warning light will come on. In that case, the seat belt cannot be used again and must be replaced at your Lexus dealer.

■ Adjustable shoulder anchor

Always make sure the shoulder belt is positioned across the center of your shoulder. The belt should be kept away from your neck, but not falling off your shoulder. Failure to do so could reduce the amount of protection in an accident and cause death or serious injuries in the event of a sudden stop, sudden swerve or accident. (→P. 31 )

■ Seat belt damage and wear

● Do not damage the seat belts by allowing the belt, plate, or buckle to be jammed in

the door.

● Inspect the seat belt system periodically. Check for cuts, fraying, and loose parts. Do

not use a damaged seat belt until it is replaced. Damaged seat belts cannot protect an occupant from death or serious injury.

● Ensure that the belt and plate are locked and the belt is not twisted.

If the seat belt does not function correctly, immediately contact your Lexus dealer.

● Replace the seat assembly, including the belts, if your vehicle has been involved in a

serious accident, even if there is no obvious damage.

● Do not attempt to install, remove, modify, disassemble or dispose of the seat belts.

Have any necessary repairs carried out by your Lexus dealer. Inappropriate handling may lead to incorrect operation.

1-1. For safe use

NOT FOR REPRODUCTION

SRS airbags

The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury.

For safety and security

◆ SRS front airbags

SRS driver airbag/front passenger airbag Can help protect the head and chest of the driver and front passenger from impact with interior components

SRS knee airbags Can help provide driver and front passenger protection

◆ SRS side and curtain shield airbags

SRS front side airbags Can help protect the torso of the front seat occupants

SRS rear side airbags Can help protect the torso of occupants in the rear outer seats

SRS curtain shield airbags Can help protect primarily the head of occupants in the outer seats

NOT FOR REPRODUCTION

1-1. For safe use

SRS airbag system components

Side impact sensors (rear)

Rear side airbags

Curtain shield airbags

Front side airbags

Driver airbag

SRS warning light

Pop up hood lifters

Side impact sensors (front)

Seat belt pretensioners and force limiters

Front passenger airbag

Front impact sensors

Pop up hoo d sens o rs

Knee airbags

Airbag sensor assembly

Driver’s seat belt buckle switch

Driver’s seat position sensor

The main SRS airbag system and Pop Up Hood components are shown above. The SRS airbag system and Pop Up Hood are controlled by the airbag sensor assembly. As the airbags deploy, a chemical reaction in the inflators quickly fills the airbags with non-toxic gas to help restrain the motion of the occupants. When the Pop Up Hood is activated, a non-toxic gas is released due to a chemical reaction in the lifters, which causes the pistons to eject quickly and raise the rear portion of the hood. (Pop Up Hood: →P. 4 6)

1-1. For safe use

NOT FOR REPRODUCTION

CAUTI ON

■ SRS airbag precautions

Observe the following precautions regarding the SRS airbags. Failure to do so may cause death or serious injury.

● The driver and all passengers in the vehicle must wear their seat belts properly.

The SRS airbags are supplemental devices to be used with the seat belts.

● The SRS driver airbag deploys with considerable force, and can cause death or seri-

ous injury especially if the driver is very close to the airbag. Since the risk zone for the driver’s airbag is the first 50 - 75 mm (2 - 3 in.) of inflation,

placing yourself 250 mm (10 in.) from your driver airbag provides you with a clear margin of safety. This distance is measured from the center of the steering wheel to your breastbone. If you sit less than 250 mm (10 in.) away now, you can change your driving position in several ways:

• Move your seat to the rear as far as you can while still reaching the pedals comfortably.

• Slightly recline the back of the seat. Although vehicle designs vary, many drivers can achieve the 250 mm (10 in.) distance, even with the driver seat all the way forward, simply by reclining the back of the seat somewhat. If reclining the back of your seat makes it hard to see the road, raise yourself by using a firm, non-slippery cushion, or raise the seat if your vehicle has that feature.

• If your steering wheel is adjustable, tilt it downward. This points the airbag toward your chest instead of your head and neck.

The seat should be adjusted as recommended above, while still maintaining control of the foot pedals, steering wheel, and your view of the instrument panel controls.

For safety and security

NOT FOR REPRODUCTION

1-1. For safe use

CAUTI ON

■ SRS airbag precautions

● The SRS front passenger airbag also deploys with considerable force, and can cause

death or serious injury especially if the front passenger is very close to the airbag. The front passenger seat should be as far from the airbag as possible with the seatback adjusted, so the front passenger sits upright.

● Improperly seated and/or restrained infants and children can be killed or seriously

injured by a deploying airbag. An infant or child who is too small to use a seat belt should be properly secured using a child restraint system. Lexus strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat. (→P. 5 0)

● Do not sit on the edge of the seat or lean

against the dashboard.

● Do not allow a child to stand in front of the

SRS front passenger airbag unit or sit on the knees of a front passenger.

● Do not allow the front seat occupants to hold

items on their knees.

● Do not lean against the door, the roof side rail

or the front, side and rear pillars.

CAUTI ON

NOT FOR REPRODUCTION

■ SRS airbag precautions

● Do not allow anyone to kneel on the passen-

ger seats toward the door or put their head or hands outside the vehicle.

● Do not attach anything to or lean anything

against areas such as the dashboard, steering wheel pad and lower portion of the instrument panel. These items can become projectiles when the SRS driver, front passenger and knee airbags deploy.

● Do not attach anything to areas such as a door,

windshield glass, side door glass, front or rear pillar, roof side rail and assist grip.

1-1. For safe use

For safety and security

● Do not hang coat hangers or hard objects on the coat hooks. All of these items could

become projectiles and may cause death or serious injury, should the SRS curtain shield airbags deploy.

● If a vinyl cover is put on the area where the SRS knee airbag will deploy, be sure to

remove it.

● Do not use seat accessories which cover the parts where the SRS side airbags inflate

as they may interfere with inflation of the airbags. Such accessories may prevent the side airbags from activating correctly, disable the system or cause the side airbags to inflate accidentally, resulting in death or serious injury.

NOT FOR REPRODUCTION

1-1. For safe use

CAUTI ON

■ SRS airbag precautions

● Do not strike or apply significant levels of force to the area of the SRS airbag compo-

nents. Doing so can cause the SRS airbags to malfunction.

● Do not touch any of the component parts immediately after the SRS airbags have

deployed (inflated) as they may be hot.

● If breathing becomes difficult after the SRS airbags have deployed, open a door or

window to allow fresh air in, or leave the vehicle if it is safe to do so. Wash off any residue as soon as possible to prevent skin irritation.

● If the areas where the SRS airbags are stored, such as the steering wheel pad and

front and rear pillar garnishes are damaged or cracked, have them replaced by your Lexus dealer.

■ Modification and disposal of SRS airbag system components

Do not dispose of your vehicle or perform any of the following modifications without consulting your Lexus dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.

● Installation, removal, disassembly and repair of the SRS airbags

● Repairs, modifications, removal or replacement of the steering wheel, instrument

panel, dashboard, seats or seat upholstery, front, side and rear pillars or roof side rails

● Repairs or modifications of the front fender, front bumper, or side of the occupant

compartment

● Installation of a grille guard (bull bars, kangaroo bar, etc.), snow plows, winches

● Modifications to the vehicle’s suspension system

● Installation of electronic devices such as mobile two-way radios (RF-transmitter) and

CD players

● Modifications to your vehicle for a person with a physical disability

1-1. For safe use

NOT FOR REPRODUCTION

■ If the SRS airbags deploy (inflate)

● Slight abrasions, burns, bruising etc., may be sustained from SRS airbags, due to the

extremely high speed deployment (inflation) by hot gases.

● A loud noise and white powder will be emitted.

● Parts of the airbag module (steering wheel hub, airbag cover and inflator) as well as the

seats, parts of the front and rear pillars, and roof side rails may be hot for several minutes. The airbag itself may also be hot.

● The windshield may crack.

■ SRS airbag deployment conditions (SRS front airbags)

● The SRS front airbags will deploy in the event of an impact that exceeds the set thresh-

old level (the level of force corresponding to an approximately 20 - 30 km/h [12 - 18 mph] frontal collision with a fixed wall that does not move or deform).

However, this threshold velocity will be considerably higher in the following situations:

• If the vehicle strikes an object, such as a parked vehicle or sign pole, which can move or deform on impact

• If the vehicle is involved in an underride collision, such as a collision in which the front of the vehicle “underrides”, or goes under, the bed of a truck

● Depending on the type of collision, it is possible that only the seat belt pretensioners will

activate.

■ SRS airbag deployment conditions (SRS side and curtain shield airbags)

● The SRS side and curtain shield airbags will deploy in the event of an impact that

exceeds the set threshold level (the level of force corresponding to the impact force produced by an approximately 1500 kg [3300 lb.] vehicle colliding with the vehicle cabin from a direction perpendicular to the vehicle orientation at an approximate sp eed of 20 - 30 km/h [12 - 18 mph]).

● The SRS curtain shield airbags may also deploy in the event of a severe frontal collision.

For safety and security

NOT FOR REPRODUCTION

■ Conditions under which the SRS airbags may deploy (inflate), other than a collision

■ Types of collisions that may not deploy the SRS airbags (SRS front airbags)

1-1. For safe use

The SRS front airbags and SRS curtain shield airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration.

● Hitting a curb, edge of pavement or hard sur-

face

● Falling into or jumping over a deep hole

● Landing hard or falling

The SRS front airbags do not generally inflate if the vehicle is involved in a side or rear collision, if it rolls over, or if it is involved in a low-speed frontal collision. But, whenever a collision of any type causes sufficient forward deceleration of the vehicle, deployment of the SRS front airbags may occur.

● Collision from the side

● Collision from the rear

● Vehicle rollover

1-1. For safe use

NOT FOR REPRODUCTION

■ Types of collisions that may not deploy the SRS airbags (SRS side and curtain shield air-

bags)

The SRS side and curtain shield airbags may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.

● Collision from the side to the vehicle body

other than the passenger compartment

● Collision from the side at an angle

The SRS side airbags do not generally inflate if the vehicle is involved in a frontal or rear collision, if it rolls over, or if it is involved in a low-speed side collision.

● Collision from the front

● Collision from the rear

● Vehicle rollover

The SRS curtain shield airbags do not generally inflate if the vehicle is involved in a rear collision, if it rolls over, or if it is involved in a low-speed side or low-speed frontal collision.

● Collision from the rear

● Vehicle rollover

For safety and security

NOT FOR REPRODUCTION

■ When to contact your Lexus dealer

1-1. For safe use

In the following cases, the vehicle will require inspection and/or repair. Contact your Lexus dealer as soon as possible.

● Any of the SRS airbags have been inflated.

● The front of the vehicle is damaged or

deformed, or was involved in an accident that was not severe enough to cause the SRS front airbags to inflate.

● A portion of a door or its surrounding area is

damaged or deformed, or the vehicle was involved in an accident that was not severe enough to cause the SRS side and curtain shield airbags to inflate.

● The pad section of the steering wheel, dash-

board near the front passenger airbag or lower portion of the instrument panel is scratched, cracked, or otherwise damaged.

● The surface of the seats with the side airbag is

NOT FOR REPRODUCTION

scratched, cracked, or otherwise damaged.

1-1. For safe use

● The portion of the front pillars, rear pillars or

roof side rail garnishes (padding) containing the curtain shield airbags inside is scratched, cracked, or otherwise damaged.

For safety and security

NOT FOR REPRODUCTION

1-1. For safe use

Pop Up Hood

In the event of a frontal collision with a body, such as a pedestrian, the Pop Up Hood system raises the rear portion of the hood to reduce the possibility of a serious impact to the pedestrian’s head area by adding clearance to the engine compartment.

Pop Up Hood mechanism

When the sensors located at the back of the front bumper detect an impact with a body, such as a pedestrian, which meets or exceeds the threshold level while the vehicle is being driven within the operational speed range, the system becomes operational and raises the rear portion of the hood.

Sensors

Hood

Lifters

1-1. For safe use

NOT FOR REPRODUCTION

Pop Up Hood operational conditions

The Pop Up Hood will operate when the vehicle detects an impact such as the following:

● The front bumper detects a frontal impact equivalent to or greater than that of

a pedestrian while the vehicle being driven within the operational speed range of approximately 25 to 55 km/h (16 to 34 mph). (The system is operated by an impact of threshold level or greater, even in the case of a minor collision that may not leave a trace on the front bumper. Also, depending on the impact conditions or vehicle speed, the system may be operated by a collision with a light or small object or a small animal.)

● In other situations the system may operate when an impact is applied to the

lower part of the vehicle or front bumper, such as the following:

• Colliding with a curb

• Falling into a deep hole

•Landing hard

• Hitting the slope of a parking lot, an undulating road, a protruding object or falling object

CAUTI ON

For safety and security

■ When the Pop Up Hood is operated

● Do not pull the hood lock release lever. Doing so after the Pop Up Hood has oper-

ated will further raise the hood and may cause an injury. Do not drive with the hood raised, as doing so may block the driver’s vision, possibly causing an accident. Do not forcibly push down the hood. As the popped up hood cannot be lowered by hand, doing so may deform the hood or cause an injury. If the Pop Up Hood has operated, have the vehicle inspected by your Lexus dealer. If the Pop Up Hood has operated, stop the vehicle in a safe place and contact your Lexus dealer.

● Do not touch the lifters immediately after the Pop Up Hood has operated, as the lift-

ers may be hot and burn you.

NOT FOR REPRODUCTION

■ Po p Up Hood pre ca utions

1-1. For safe use

● Before scrapping your vehicle, make sure to contact your Lexus dealer.

● The Pop Up Hood system cannot be reused once it has operated. Have it replaced by

your Lexus dealer.

■ Conditions under which the Pop Up Hood may not operate properly

The Pop Up Hood may not operate properly under the following conditions:

● If a pedestrian collides with the right or left corner of the front bumper or the side of the

vehicle. As such impacts may be difficult to detect, the system may not operate.

● If the vehicle speed is not detected correctly, such as if the vehicle is sliding sideways,

the system may not operate properly.

■ Conditions under which the Pop Up Hood may not operate

The Pop Up Hood may not operate in the following situations:

● Colliding with a lying pedestrian

● A frontal impact applied to the front bumper while driving at speeds outside of the

operational speed range

● A side impact or rear impact

● A vehicle rollover (In some accident situations, the Pop Up Hood may operate.)

NOTICE

■ Pop Up Hood precautions

● Make sure to close the hood before driving, as the system may not operate properly if

the hood is not fully closed.

● Make sure that all 4 tires are of the specified size and inflated to the specified tire

pressure (→P. 516). If tires of a different size are used, the system may not operate properly.

● If something has hit the area around the front bumper, the sensors may be damaged

even if the Pop Up Hood has not operated. Have the vehicle inspected by your Lexus dealer.

● Do not remove or repair the parts or wiring of the Pop Up Hood, as doing so may

cause accidental operation or prevent the system from operating properly. If repair or replacement is necessary, contact your Lexus dealer.

● Do not remove such components as the front bumper, hood or suspension, or

replace them with non-genuine parts, as doing so may prevent the system from operating properly.

● Do not install anything to the front bumper or hood, as doing so may prevent the sen-

sors from detecting an impact correctly and prevent the system from operating properly.

● Do not close the hood with force or apply load to the lifters, as doing so may damage

the lifters and prevent the system from operating properly.

● Do not modify the suspension, as changes made to the vehicle height may prevent

the system from operating properly.

1-1. For safe use

NOT FOR REPRODUCTION

Safety information for children

Observe the following precautions when children are in the vehicle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt.

● It is recommended that children sit in the rear seats to avoid accidental con-

tact with the shift lever, wiper switch etc.

● Use the rear door child-protector lock or the window lock switch to avoid

children opening the door while driving or operating the power window accidentally.

● Do not let small children operate equipment which may catch or pinch body

parts, such as the power window, hood, trunk, seats etc.

CAUTI ON

Never leave children unattended in the vehicle, and never allow children to have or use the key.

Children may be able to start the vehicle or shift the vehicle into neutral. There is also a danger that children may injure themselves by playing with the windows, the moon roof or other features of the vehicle. In addition, heat build-up or extremely cold temperatures inside the vehicle can be fatal to children.

For safety and security

NOT FOR REPRODUCTION

1-1. For safe use

Child restraint systems

Lexus strongly urges the use of child restraint systems.

Points to remember

Studies have shown that installing a child restraint on a rear seat is much safer than installing one on the front passenger seat.

● Choose a child restraint system that suits your vehicle and is appropriate to

the age and size of the child.

● For installation details, follow the instructions provided with the child restraint

system. General installation instructions are provided in this manual. (→P. 58 )

● If child restraint system regulations exist in the country where you reside,

please contact your Lexus dealer for the child restraint system installation.

● Lexus recommends that you use a child restraint system which conforms to

the regulation ECE No.44.

1-1. For safe use

NOT FOR REPRODUCTION

Types of child restraints

Child restraint systems are classified into the following 5 groups according to the regulation ECE No.44:

Group 0: Up to 10 kg (22 lb.) (0 - 9 months)

Group 0 Group I: 9 to 18 kg (20 to 39 lb.) (9 months - 4 years) Group II: 15 to 25 kg (34 to 55 lb.) (4 years - 7 years) Group III: 22 to 36 kg (49 to 79 lb.) (6 years - 12 years) In this owner’s manual, the following 3 types of popular child restraint systems

that can be secured with the seat belts are explained:

X Baby seat (infant seat) X Child seat (convertible seat)

: Up to 13 kg (28 lb.) (0 - 2 years)

For safety and security

Equal to Group 0 and 0 No.44

X Junior seat (booster seat)

Equal to Group II and III of ECE No.44

of ECE

Equal to Group 0+ and I of ECE No.44

NOT FOR REPRODUCTION

1-1. For safe use

Child restraint system suitability for various seating positions (except for New Zealand)

Information provided in the table shows your child restraint system suitability for various seating positions.

Seating position

Mass groups

0 Up to 10 kg (22 lb.) (0 - 9 months)

0 Up to 13 kg (28 lb.) (0 - 2 years)

I 9 to 18 kg (20 to 39 lb.) (9 months - 4 years)

II, III 15 to 36 kg (34 to 79 lb.) (4 - 12 years)

Front passenger seat

Never put

Rear-facing — X

Never put

Forward-facing — UF

1, 2

Rear seat

Outboard Center

U L1*

L2*

2, 3

3 3

Key of letters inserted in the above table: U: Suitable for “universal” category child restraint system approved for the

use in this mass group.

UF: Suitable for forward-facing “universal” category child restraint system

approved for the use in this mass group.

L1: Suitable for “LEXUS G 0

, BABY SAFE PLUS with SEAT BELT FIXATION, BASE PLATFORM” (0 to 13 kg [0 to 28 lb.]) approved for the use in this mass group.

L2: Suitable for “LEXUS KIDFIX” (15 to 36 kg [34 to 79 lb.]) approved for the

use in this mass group.

X: Not suitable seat position for children in this mass group.

1-1. For safe use

NOT FOR REPRODUCTION

NOTE:

: Adjust the front seatback to the most upright position. Move the front seat cushion to

the fully rearward. Adjust the seat cushion to the highest position. When the child restraint system touched the ceiling, lower the seat position.

Follow these procedures

• For installing a baby seat (infant seat) with support base If the baby seat (infant seat) interferes with the seatback when latching the baby

seat (infant seat) into the support base, adjust the seatback rearward until there is no interference.

• For installing a forward-facing child seat (convertible seat) If there is gap between the child seat (convertible seat) and the seatback, tilt the

seatback rearward until good contact is achieved. If the seatbelt shoulder anchor is ahead of the child seat belt guide, move the seat

cushion forward.

• For installing a junior seat (booster seat) If the child in your child restraint system is in a very upright position, adjust the seat-

back to the most comfortable position. If the seat belt shoulder anchor is ahead of the child seat belt guide, move the seat

cushion forward.

: Remove the head restraint if it interferes with your child restraint system.

: When using the left side seat for the child restraint system, do not sit in the center seat.

The child restraint system mentioned in the table may not be available outside of the EU area.

Other child restraint systems which are different from the systems mentioned in the table can be used, but the suitability of the systems must be carefully checked with the child restraint system manufacturer and retailer.

For safety and security

NOT FOR REPRODUCTION

1-1. For safe use

Child restraint system suitability for various seating positions (with ISOFIX rigid anchors) (except for New Zealand)

Information provided in the table shows your child restraint system suitability for various seating positions.

Vehicle ISOFIX

Mass groups Size class Fixture

FISO/L1 X

positions

Rear outboard

Carrycot

Group 0 Up to 10 kg (22 lb.)

Group 0+ Up to 13 kg (28 lb.)

Group I 9 to 18 kg (20 to 39 lb.)

Group II 15 to 25 kg (34 to 55 lb.)

Group III 22 to 36 kg (49 to 79 lb.)

GISO/L2 X

(1) X

EISO/R1IL1

(1) X

EISO/R1IL1

DISO/R2IL1*, IL2* CISO/R3IL1*, IL2*

(1) X

DISO/R2 X

CISO/R3 IL3

BISO/F2IUF*, IL2* B1 ISO/F2X IUF*, IL2* AISO/F3IUF*, IL2*

(1) X

*, IL2*

1-1. For safe use

NOT FOR REPRODUCTION

(1) For the child restraint system which do not carry the ISO/XX size class

identification (A to G), for the applicable mass group, the car manufacturer shall indicate the vehicle specific ISOFIX child restraint system(s) recom-

mended for each position. Key of letters inserted in the above table: IUF: Suitable for ISOFIX forward-facing child restraint systems of universal cat-

egory approved for use in this mass group. IL1: Suitable for “LEXUS MINI” (0 to 13 kg [0 to 28 lb.]) approved for the use

in this mass group. IL2: Suitable for “LEXUS MIDI” (0 to 18 kg [0 to 39 lb.]) approved for the use

in this mass group. When using a “LEXUS MINI” or “LEXUS MIDI”, adjust the support leg and the

ISOFIX connectors as follows:

Lock the support leg where 4th hole can be seen. (“LEXUS MIDI” rearfacing, “LEXUS MINI”)

Lock the support leg where 6th hole can be seen. (“LEXUS MIDI” forward-facing only)

Lock the ISOFIX connectors where

numbers 4 and 5 can be seen. IL3: Refer to the “HTS iZi Kid X3” user manual for fitment method. X: ISOFIX position not suitable for ISOFIX child restraint systems in this mass

group and/or this size class.

*: Remove the head restraint if it interferes with your child restraint system. Do not sit on

rear center seat when child restraint system is installed to rear left seat.

The child restraint system mentioned in the table may not be available outside of the EU area.

For safety and security

NOT FOR REPRODUCTION

■ When installing a child restraint system on the front passenger seat

■ Selecting an appropriate child restraint system

1-1. For safe use

When you have to use a child restraint system on the front passenger seat, adjust the following:

● The seatback to the most upright position

● The seat cushion to the highest position

● The seat cushion to the fully rearward position

● Use a child restraint system appropriate for the child until the child becomes large

enough to properly wear the vehicle’s seat belt.

● If the child is too large for a child restraint system, sit the child on a rear seat and use the

vehicle’s seat belt. (→P. 30 )

CAUTI ON

■ Using a child restraint system

The use of a child restraint system not suitable for the vehicle may not properly secure the infant or child. It may result in death or serious injury (in the event of sudden braking or an accident).

■ Child restraint precautions

● For effective protection in automobile accidents and sudden stops, a child must be

properly restrained, using a seat belt or child restraint system depending on the age

and size of the child. Holding a child in your arms is not a substitute for a child restraint

system. In an accident, the child can be crushed against the windshield, or between

you and the vehicle’s interior. This may cause death or serious injury to the child in the

event of a sudden stop, sudden swerve or accident.

● Lexus strongly urges the use of a proper child restraint system that conforms to the

size of the child, installed on the rear seat. According to accident statistics, the child is

safer when properly restrained in the rear seat than in the front seat.

● Never install a rear-facing child restraint system on the front passenger seat.

In the event of an accident, the force of the rapid inflation of the front passenger air-

bag can cause death or serious injury to the child if the rear-facing child restraint sys-

tem is installed on the front passenger seat.

● A forward-facing child restraint system may be installed on the front passenger seat

only when it is unavoidable. A child restraint system that requires a top strap should

not be used in the front passenger seat since there is no top strap anchor for the front

passenger seat. Adjust the seatback as upright as possible and always move the seat

as far back as possible because the front passenger airbag could inflate with consid-

erable speed and force. Otherwise, the child may be killed or seriously injured.

● Do not allow the child to lean his/her head or any part of his/her body against the

door or the area of the seat, front, center and rear pillars or roof side rails from which

the SRS side airbags or SRS curtain shield airbags deploy even if the child is seated in

the child restraint system. It is dangerous if the SRS side airbags and curtain shield air-

bags inflate, and the impact could cause death or serious injury to the child.

1-1. For safe use

NOT FOR REPRODUCTION

CAUTI ON

■ Child restraint precautions

● Make sure you have complied with all installation instructions provided by the child

restraint manufacturer and that the system is properly secured. If it is not secured

properly, it may cause death or serious injury to the child in the event of a sudden

stop, sudden swerve or accident.

■ When children are in the vehicle

■ When the child restraint system is not in use

● Keep the child restraint system properly secured on the seat even if it is not in use. Do

not store the child restraint system unsecured in the passenger compartment.

● If it is necessary to detach the child restraint system, remove it from the vehicle or

store it securely in the trunk. This will prevent it from injuring passengers in the event

of a sudden stop, sudden swerve or accident.

For safety and security

NOT FOR REPRODUCTION

1-1. For safe use

Installing child restraints

Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the seats using a seat belt or ISOFIX rigid anchors. Attach the upper anchorage strap when installing a child restraint.

Seat belts (An ELR belt requires a locking clip)

ISOFIX rigid anchors

Lower anchors are provided for the out-

board rear seats, behind the anchor

covers.

X Ty pe A

NOT FOR REPRODUCTION

Child restraint anchor fitting

An anchor fitting is provided for each

rear seat.

X Ty pe B

Child restraint anchor fitting

An anchor fitting is provided for the out-

board rear seats.

1-1. For safe use

For safety and security

NOT FOR REPRODUCTION

1-1. For safe use

Installing child restraints using a seat belt

■ Rear-facing  Baby seat (infant seat)/child seat (convertible seat)

Remove the head restraint if it interferes with your child restraint system.

Place the child restraint system on the rear seat facing the rear of the vehicle.

Run the seat belt through the child restraint system and insert the plate into the buckle. Make sure that the belt is not twisted.

Latch the attaching clip of the upper anchorage strap onto the anchor fitting. (→P. 65 )

Make sure the seat belt is tightly secured, and that there is no slack in the belt.

If your child restraint system is not

NOT FOR REPRODUCTION

equipped with a lock-off (a seat belt

locking feature), secure the child

restraint system using a locking clip.

1-1. For safe use

After installing the child restraint system, rock it back and forth to ensure that

it is installed securely.

■ Fo rward -facing  Child seat (convertible seat)

Remove the head restraint if it interferes with your child restraint system.

Place the child restraint system on the seat facing the front of the vehicle.

Run the seat belt through the child restraint system and insert the plate into the buckle. Make sure that the belt is not twisted.

For safety and security

NOT FOR REPRODUCTION

1-1. For safe use

Latch the attaching clip of the upper anchorage strap onto the anchor fitting. (→P. 65 )

Make sure the seat belt is tightly secured, and that there is no slack in the belt.

If your child restraint system is not

equipped with a lock-off (a seat belt

locking feature), secure the child

restraint system using a locking clip.

After installing the child restraint system, rock it back and forth to ensure that

it is installed securely.

■ Junior seat (booster seat)

NOT FOR REPRODUCTION

Place the child restraint system on the seat facing the front of the vehicle.

Sit the child in the child restraint system. Fit the seat belt to the child restraint system according to the manufacturer’s instructions and insert the plate into the buckle. Make sure that the belt is not twisted.

Check that the shoulder belt is correctly positioned over the child’s shoulder and that the lap belt is as low as possible. (→P. 3 0)

1-1. For safe use

For safety and security

Removing a child restraint installed with a seat belt

Push the buckle release button and fully retract the seat belt.

NOT FOR REPRODUCTION

1-1. For safe use

Installation with ISOFIX rigid anchor

Remove the head restraint if it inter-

feres with your child restraint system.

Latch the buckles onto the exclusive

fixing bars.

If the child restraint has a upper anchor-

age strap, the upper anchorage strap

should be latched onto the anchor fit-

ting.

Using the child restraint anchor fitting

NOT FOR REPRODUCTION

Remove the head restraint if it inter-

feres with your child restraint system.

Secure the child restraint system

using the seat belt or ISOFIX rigid

anchors.

Open the anchor fitting cover, latch

the attaching clip onto the anchor fit-

ting and tighten the upper anchor-

age strap.

Make sure the upper anchorage strap is

securely latched.

Attaching clip

Upper anchorage strap

Anchor fitting

Front of vehicle

1-1. For safe use

For safety and security

■ When installing a child restraint system

You need a locking clip to install the child restraint system. Follow the instructions provided by the manufacturer of the system. If your child restraint system does not provide a locking clip, you can purchase the following item from your Lexus dealer:

Locking clip for child restraint system (Part No. 73119-22010)

NOT FOR REPRODUCTION

1-1. For safe use

CAUTI ON

■ When installing a child restraint system

Follow the directions given in the child restraint system installation manual and fix the child restraint system securely in place. If the child restraint system is not correctly fixed in place, the child or other passengers may be seriously injured or even killed in the event of a sudden braking, sudden swerving or an accident.

● If the driver’s seat interferes with the child

restraint system and prevents it from being

attached correctly, attach the child restraint

system to the left-hand rear seat.

● Adjust the front passenger seat so that it does

not interfere with the child restraint system.

● Only put a forward-facing child restraint sys-

tem on the front seat when unavoidable.

When installing a forward-facing child

restraint system on the front passenger seat,

move the seat as far back as possible.

Failure to do so may result in death or serious

injury if the airbags deploy (inflate).

CAUTI ON

NOT FOR REPRODUCTION

■ When installing a child restraint system

● Extreme Hazard! Do not use a rearward fac-

ing child restraint on a seat protected by an

airbag in front of it! This is because the force

of the rapid inflation of the front passenger

airbag can cause death or serious injury to

the child.

There is a label(s) on the passenger side sun

visor, indicating it is forbidden to attach a

rear-facing child restraint system to the front

passenger seat.

Details of the label(s) are shown in the illus-

tration below.

1-1. For safe use

For safety and security

NOT FOR REPRODUCTION

1-1. For safe use

CAUTI ON

■ When installing a child restraint system

● If child restraint system regulations exist in the country where you reside, please con-

tact your Lexus dealer for the child restraint system installation.

● When a junior (booster) seat is installed, always ensure that the shoulder belt is posi-

tioned across the center of the child’s shoulder. The belt should be kept away from the

child’s neck, but not so that it could fall off the child’s shoulder. Failing to do so may

result in death or serious injury in the event of sudden braking, sudden swerving or an

accident.

● Ensure that the belt and plate are securely locked and the seat belt is not twisted.

● Shake the child restraint system left and right, and forward and backward to ensure

that it has been securely installed.

● After securing a child restraint system, never adjust the seat.

● Follow all installation instructions provided by the child restraint system manufacturer.

■ To correctly attach a child restraint system to the anchors

When using the lower anchors, be sure that there are no foreign objects around the anchors and that the seat belt is not caught behind the child restraint system. Make sure the child restraint system is securely attached, or it may cause death or serious injury to the child or other passengers in the event of a sudden braking, sudden swerve or an accident.

■ Using child restraint anchorages

WARNING: child restraint anchorages are designed to withstand only those loads imposed by correctly fitted child restraints. Under no circumstances are they to be used for adult seatbelts, harnesses, or for attaching other items or equipment to the vehicle.

1-1. For safe use

NOT FOR REPRODUCTION

Exhaust gas precautions

Harmful substance to the human body is included in exhaust gases if inhaled.

CAUTI ON

Exhaust gases include harmful carbon monoxide (CO), which is colorless and odorless. Observe the following precautions. Failure to do so may cause exhaust gases enter the vehicle and may lead to an accident caused by light-headedness, or may lead to death or a serious health hazard.

■ Important points while driving

● Keep the trunk lid closed.

● If you smell exhaust gases in the vehicle even when the trunk lid is closed, open the

windows and have the vehicle inspected at your Lexus dealer as soon as possible.

■ When parking

● If the vehicle is in a poorly ventilated area or a closed area, such as a garage, stop the

engine.

● Do not leave the vehicle with the engine on for a long time.

If such a situation cannot be avoided, park the vehicle in an open space and ensure

that exhaust fumes do not enter the vehicle interior.

● Do not leave the engine running in an area with snow build-up, or where it is snowing.

If snowbanks build up around the vehicle while the engine is running, exhaust gases

may collect and enter the vehicle.

■ Exhaust pipe

The exhaust system needs to be checked periodically. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Lexus dealer.

For safety and security

NOT FOR REPRODUCTION

1-2. Theft deterrent system

Engine immobilizer system

The vehicle’s keys have built-in transponder chips that prevent the engine from starting if a key has not been previously registered in the vehicle’s onboard computer.

Never leave the keys inside the vehicle when you leave the vehicle.

This system is designed to help prevent vehicle theft but does not guarantee absolute security against all vehicle thefts.

The indicator light flashes after the engine switch has been turned off to indicate that the system is operating.

The indicator light stops flashing after the engine switch has been turned to ACCESSORY or IGNITION ON mode to indicate that the system has been canceled.

■ System maintenance

The vehicle has a maintenance-free type engine immobilizer system.

■ Conditions that may cause the system to malfunction

● If the grip portion of the key is in contact with a metallic object

● If the key is in close proximity to or touching a key registered to the security system (key

with a built-in transponder chip) of another vehicle

NOTICE

■ To ensure the system operates correctly

Do not modify or remove the system. If modified or removed, the proper operation of the system cannot be guaranteed.

1-2. Theft deterrent system

NOT FOR REPRODUCTION

Alarm

The alarm

The alarm uses light and sound to give an alert when an intrusion is detected. The alarm is triggered in the following situations when the alarm is set:

● A locked door or trunk is unlocked or opened in any way other than using the

entry function, wireless remote control or mechanical key. (The doors will lock

again automatically.)

● The hood is opened.

● The intrusion sensor detects something moving inside the vehicle. (An

intruder gets in the vehicle.)

Setting the alarm system

Close the doors, trunk and hood, and lock all the doors. The system will be set automatically after 30 seconds.

The indicator light changes from being

on to flashing when the system is set.

For safety and security

Deactivating or stopping the alarm

Do one of the following to deactivate or stop the alarm:

● Unlock the doors or open the trunk.

● Turn the engine switch to ACCESSORY or IGNITION ON mode, or start

the engine. (The alarm will be deactivated or stopped after a few seconds.)

NOT FOR REPRODUCTION

■ System maintenance

■ Items to check before locking the vehicle

■ Triggering of the alarm

1-2. Theft deterrent system

The vehicle has a maintenance-free type alarm system.

To prevent unexpected triggering of the alarm and vehicle theft, make sure of the following:

● Nobody is in the vehicle.

● The windows and moon roof (if equipped) are closed before the alarm is set.

● No valuables or other personal items are left in the vehicle.

The alarm may be triggered in the following situations: (Stopping the alarm deactivates the alarm system.)

● A person inside the vehicle opens a door, the

trunk or hood, or unlocks the vehicle using a inside lock button.

● The battery is recharged or replaced when the

vehicle is locked. (→P. 4 96 )

■ Alarm-operated door lock

In the following cases, depending on the situation, the door may automatically lock to prevent improper entry into the vehicle:

● The doors are unlocked manually without the mechanical key and the alarm is trig-

gered.

● While the alarm is operating, the doors are unlocked manually without the mechanical

key.

● When recharging or replacing the battery

1-2. Theft deterrent system

NOT FOR REPRODUCTION

NOTICE

■ To ensure the system operates correctly

Do not modify or remove the system. If modified or removed, the proper operation of the system cannot be guaranteed.

Intrusion sensor

The intrusion sensor detects intruders or movement in the vehicle. When an intruder or movement is detected, the alarm will be triggered.

This system is designed to deter and prevent vehicle theft but does not guarantee absolute security against all intrusions.

■ Setting the intrusion sensor

The intrusion sensor will be set automatically when the alarm is set. (

■ Canceling the intrusion sensor

If you are leaving pets or other moving things inside the vehicle, make sure to

disable the intrusion sensor before setting the alarm, as it will respond to

movement inside the vehicle.

Turn the engine switch off.

Press the intrusion sensor cancel switch.

Press the switch again to re-enable the intrusion sensor.

Each time the intrusion sensor is canceled/set, a message will be shown on the multi-information display in the instrument cluster.

→P. 7 1)

For safety and security

NOT FOR REPRODUCTION

■ Canceling and automatic re-enabling of the intrusion sensor

■ Intrusion sensor detection considerations

1-2. Theft deterrent system

● The alarm will still be set even when the intrusion sensor is canceled.

● After the intrusion sensor is canceled, pressing the engine switch or unlocking the

doors using the entry function, wireless remote control or mechanical key will reenable the intrusion sensor.

● The intrusion sensor and will automatically be re-enabled when the alarm system is

deactivated.

The sensor may trigger the alarm in the following situations:

● A window or the moon roof is open.

In this case, the sensor may detect the following:

• Wind or the movement of objects such as leaves and insects inside the vehicle

• Ultrasonic waves emitted from devices such as the intrusion sensors of other vehicles

• The movement of people outside the vehicle

● Unstable items, such as dangling accessories

or clothes hanging on the coat hooks, are in the vehicle.

● Places with extreme vibrations or noises, or situations in which the vehicle is subject to

repeated impacts or vibrations:

• When parked in a parking garage

• When the vehicle is transported on a ferry, trailer, train, etc.

• When ice adhering to the vehicle is removed

• When the vehicle is in an automatic or high-pressure car wash

• When in a hail or lightning storm

1-2. Theft deterrent system

NOT FOR REPRODUCTION

NOTICE

■ To ensure the intrusion sensor functions correctly

● To ensure that the sensors operate properly,

do not touch or cover them.

● Do not spray air fresheners or other products

directly into the sensor holes.

● Installing accessories other than genuine Lexus parts or leaving objects between the

driver’s seat and front passenger’s seat may reduce the detection performance.

For safety and security

NOT FOR REPRODUCTION

1-2. Theft deterrent system

NOT FOR REPRODUCTION

Instrument cluster

2. Instrument cluster

Warning lights and

indicators.......................................78

Gauges and meters.....................83

Multi-information display..........88

Fuel consumption

information ...................................95

NOT FOR REPRODUCTION

2. Instrument cluster

Warning lights and indicators

The warning lights and indicators on the instrument cluster and center panel inform the driver of the status of the vehicle’s various systems.

For the purpose of explanation, the following illustrations display all warning lights and indicators illuminated.

X Except F SPORT models

X F SPORT models

2. Instrument cluster

NOT FOR REPRODUCTION

Wa rn i ng li gh ts

Warning lights inform the driver of malfunctions in the indicated vehicle systems.

1, 2

(if equipped)

Brake system warning light (→P. 45 6)

Charging system warning light (→P. 45 6)

Malfunction indicator lamp (→P. 4 56 )

SRS warning light (→P. 45 6)

ABS warning light (→P. 45 6)

Electric power steering sys-

tem warning light (→P. 45 6)

Pre-crash safety system warning light (→P. 45 7)

Automatic headlight level-

ing system warning light (→P. 45 7)

Open door warning light (→P. 45 7)

Low fuel level warning light (→P. 45 7)

Instrument cluster

Driver’s and front passenger’s seat belt reminder light (→P. 45 7)

Rear passengers’ seat belt reminder lights (→P. 457 )

Master warning light (→P. 45 8)

Tire pressure warning light (→P. 45 8)

Slip indicator (→P. 457 )

: These lights turn on when the engine switch is turned to IGNITION ON mode to

indicate that a system check is being performed. They will turn off after the engine is started, or after a few seconds. There may be a malfunction in a system if the light does not come on, or turn off. Have the vehicle inspected by your Lexus dealer.

: The light flashes to indicate a malfunction.

: This light illuminates on the center panel.

NOT FOR REPRODUCTION

2. Instrument cluster

Indicators

The indicators inform the driver of the operating state of the vehicle’s various systems.

1, 2

Turn signal indicator (→P. 18 1)

Tail light indicator (→P. 18 3)

Headlight high beam indicator (→P. 18 3)

Automatic High Beam indicator (→P. 18 5)

(if equipped)

Fog light indicator (→P. 18 9)

(if equipped)

4, 5

(if equipped)

Slip indicator (→P. 25 6)

VSC OFF indicator (→P. 25 8)

1, 3

Pre-crash safety system warning light (→P. 26 2)

BSM (Blind Spot Monitor) outside rear view mirror indicators (→P. 2 67 )

Security indicator (→P. 70 , 7 1)

Low outside temperature indicator (→P. 8 3)

Eco Driving Indicator Light (→P. 93 )

Eco drive mode indicator (→P. 252 )

1, 10

Stop & Start indicator (→P. 202)

(if equipped)

Cruise control indicator (→P. 211, 215)

Dynamic radar cruise control indicator (→P. 21 5)

Cruise control “SET” indicator (→P. 21 1, 2 15 )

LDA (Lane Departure Alert) indicator (→P. 229)

Lexus parking assist-sensor indicator (→P. 23 5)

(if equipped)

2. Instrument cluster

NOT FOR REPRODUCTION

“SPORT” indicator (→P. 25 2)

(if equipped)

“SPORT S” indicator (→P. 25 2)

(if equipped)

“SPORT S+” indicator (→P. 25 2)

(if equipped)

“SPORT S” indicator (→P. 25 2)

: These lights turn on when the engine switch is turned to IGNITION ON mode to

: The light flashes to indicate that the system is operating.

: The light comes on when the system is turned off. The light flashes faster than usual to

indicate that the system is operating.

: In order to confirm operation, the BSM outside rear view mirror indicators illuminate

in the following situations:

• When the engine switch is turned to IGNITION ON mode while the BSM main switch is set to ON.

• When the BSM main switch is set to ON while the engine switch is in IGNITION ON mode.

If the system is functioning correctly, the BSM outside rear view mirror indicators will turn off after a few seconds. If the BSM outside rear view mirror indicators do not illuminate or do not turn off, there may be a malfunction in the system. If this occurs, have the vehicle inspected by your Lexus dealer.

: This light illuminates on the outside rear view mirrors.

: This light illuminates on the center panel.

: When the outside temperature is approximately 3°C (37°F) or lower, the indicator

will flash for approximately 10 seconds, then stay on.

:Except F SPORT models

:F SPORT models

: This light illuminates on the multi-information display

1, 10

(if equipped)

Stop & Start cancel indicator (→P. 2 04 )

“SPORT S+” indicator (→P. 252 )

Snow mode indicator (→P. 176 )

Instrument cluster

NOT FOR REPRODUCTION

2. Instrument cluster

CAUTI ON

■ If a safety system warning light does not come on

Should a safety system light such as the ABS and SRS warning light not come on when you start the engine, this could mean that these systems are not available to help protect you in an accident, which could result in death or serious injury. Have the vehicle inspected by your Lexus dealer immediately if this occurs.

2. Instrument cluster

NOT FOR REPRODUCTION

Gauges and meters

X Except F SPORT models

X F SPORT models (when the main meter is in the center position)

Instrument cluster

NOT FOR REPRODUCTION

2. Instrument cluster

X F SPORT models (when the main meter is in the right-side position)

Engine coolant temperature gauge

Displays the engine coolant temperature

Tachometer

Displays the engine speed in revolutions per minute

Outside temperature

Displays the outside temperature within the range of -40°C (-40°F) to 50°C (122°F). Low outside temperature indicator comes on when the ambient temperature is 3°C (37°F) or lower.

Shift position and gear position (→P. 1 75 )

Speedometer

Fuel gauge

Multi-information display

Presents the driver with a variety of vehicle data (→P. 8 8) Displays warning messages in case of a malfunction (→P. 4 61 )

Odometer and trip meter display

Odometer: Displays the total distance the vehicle has been driven

Tr ip me te r : Displays the distance the vehicle has been driven since the meter was last reset. Trip meters “A” and “B” can be used to record and display different distances independently.

Changing the display

NOT FOR REPRODUCTION

X Odometer/Trip meter

Switches between odometer and trip meter displays. When the trip meter is displayed, pressing and holding the button will reset the trip meter.

2. Instrument cluster

X Main meter (F SPORT models)

Moves between center and rightside positions.

Instrument cluster

NOT FOR REPRODUCTION

2. Instrument cluster

Instrument panel light control

The brightness of the instrument panel lights can be adjusted.

Darker

Brighter

■ The meters and display illuminate when

The engine switch is in IGNITION ON mode.

■ Instrument panel brightness adjustment

The instrument panel brightness levels when the tail lights are on and off can be adjusted individually. However, when the surroundings are bright (daytime, etc.), turning on the tail lights will not change the instrument panel brightness.

■ Outside temperature display

In the following situations, the correct outside temperature may not be displayed, or the display may take longer than normal to change.

● When stopped, or driving at low speeds (less than 20 km/h [12 mph])

● When the outside temperature has changed suddenly (at the entrance/exit of a garage,

tunnel, etc.)

■ Po p- up di spla y

In some situations, a pop-up display will be temporarily displayed on the multi-information display or the odometer/trip meter screen (F SPORT models only). The pop-up display function can be set on/off. (→P. 9 1)

■ Liquid crystal display

Small spots or light spots may appear on the display. This phenomenon is characteristic of liquid crystal displays, and there is no problem continuing to use the display.

■ Customization

The meter display can be customized on the multi-information display. (→P. 88 )

2. Instrument cluster

NOT FOR REPRODUCTION

NOTICE

■ To prevent damage to the engine and its components

● Do not let the indicator needle of the tachometer enter the red zone, which indicates

the maximum engine speed.

● The engine may be overheating if the engine coolant temperature gauge is in the red

zone (H). In this case, immediately stop the vehicle in a safe place, and check the engine after it has cooled completely. (→P. 49 8)

Instrument cluster

NOT FOR REPRODUCTION

2. Instrument cluster

Multi-information display

The multi-information display presents the driver with a variety of vehicle data.

Drive information

Select to display various drive data. (→P. 8 9)

Navigation system-linked display (if equipped)

Select to display the following navigation system-linked information.

•Route guidance

• Compass display (north-up display/heading-up display)

Audio system-linked display

Select to enable selection of an audio source or track on the meter using the meter control switches.

Dynamic radar cruise control operational status

(vehicles with a dynamic radar cruise control)

Select to display the operational status of the dynamic radar cruise control. (→P. 2 15)

The tab will change to when the vehicle is in constant speed control mode. (→P. 2 21 ) If LDA (Lane Departure Alert) is activated, the operational status of the LDA

system will also be displayed. (If equipped) (→P. 2 31 )

LDA (Lane Departure Alert) operational status

(vehicles with LDA but without a dynamic radar cruise control)

Select to display the operational status of the LDA. (→P. 23 1)

Stop & Start System (Smart Stop) Information (if equipped)

Able to display the operation status of the Stop & Start system.

Warning message display

Select to display warning messages and measures to be taken if a malfunction is detected. (→P. 4 61 )

2. Instrument cluster

NOT FOR REPRODUCTION

Settings display

Select to change the meter display settings. (→P. 9 1)

◆ Operating the meter control switches

The multi-information display is operated using the meter control switches.

Select an item/change pages

Enter/Set

X Except F SPORT models

Press: Displays the screen registered to

When no screen has been registered, the drive information screen will be displayed.

Press and hold: Registers the currently displayed screen to

When the confirmation screen is displayed, select yes to register the screen. If the selected screen cannot be registered, a registration failure message will be shown.

X F SPORT models

Move the main meter

Return to the previous screen

Instrument cluster

Drive information

■ Current fuel consumption*

Displays the current rate of fuel consumption

■ Average fuel economy (after reset/after start/after refuel)*

Displays the average fuel economy since the function was reset, the engine was started, and the vehicle was refueled, respectively

■ Average vehicle speed (after reset/after start)*

Displays the average vehicle speed since the function was reset and the engine was started, respectively

■ Elapsed time (after reset/after start)*

Displays the elapsed time since the function was reset and the engine was started, respectively

1, 2

NOT FOR REPRODUCTION

2. Instrument cluster

■ Distance (driving range/after start)*

Displays the estimated maximum distance that can be driven with the quantity of fuel remaining and the distance driven after the engine was started respectively.

• This distance is computed based on your average fuel consumption. As a result, the actual distance that can be driven may differ from that displayed.

• When only a small amount of fuel is added to the tank, the display may not be updated. When refueling, turn the engine switch off. If the vehicle is refueled without turning the engine switch off, the display may not be updated.

■ Eco Driving Indicator

→P. 93

■ Boost Meter/Oil Temperature Gauge/Oil Pressure Gauge (F SPORT

models for IS200t)

Boost Meter: Displays the boost pressure. The display changes colors when the set pressure is exceeded.

Oil Temperature Gauge: Displays the temperature of the engine oil. The display flashes when the engine oil exceeds 140°C (284°F).

Oil Pressure Gauge: Displays the oil pressure for the engine interior. A buzzer sounds and warning message is displayed when the oil pressure gets low. (→P. 466)

Depending on the road conditions, temperature, vehicle speed, etc., the actual vehicle condition on the display screen may differ. Use the display screen as a reference.

■ Gear positions

→P. 17 9

: Displayed when the item is set in “Drive Info 1” or “Drive Info 2”. Use these values as a

reference.

: Resetting

The following displays can be reset: average fuel consumption after reset, average vehicle speed after reset, and elapsed time after reset.

• To reset, display the desired item and press and hold .

• If both displayed items are resettable, a reset selection screen will appear.

2. Instrument cluster

NOT FOR REPRODUCTION

Settings display

■ Language

Select to change the language on the display.

■ Units

Select to change the unit of measure for fuel consumption.

■ Maintenance system (IS200t only)

Select to reset the maintenance data after the required maintenance is performed. (

■ Eco Driving Indicator Light

Select to activate/deactivate the Eco Driving Indicator Light.

■ switch settings (except F SPORT models)

Displays a procedure to register a desired screen to . You can register 1 screen as a shortcut, which can be displayed by pressing

■ Drive information 1 /Drive information 2

Select to select up to 2 items that will be displayed on the “Drive Info 1” screen and “Drive Info 2” screen respectively. (→P. 8 9)

■ Pop-up display

Select to set the following pop-up displays, which may appear in some situations, on/off.

• Route guidance display of the navigation system-linked system

• Incoming call display of the hands-free phone system

• Dynamic radar cruise control operation display (if equipped)

• Instrument panel brightness adjustment display

• Main meter switch operation display (F SPORT models)

• Stop & Start system duration (if equipped)

• Stop & Start system status (if equipped)

■ Accent color (except F SPORT models)

Select to change the accent colors on the screen, such as the cursor color.

■ Needle (F SPORT models)

Select to change the needle color for the tachometer.

→P. 4 03 )

. (→P. 8 9)

(if equipped)

Instrument cluster

NOT FOR REPRODUCTION

2. Instrument cluster

■ Speed indicator (F SPORT models)

Select to set the speed indicator on/ off.

When set to on, both sides of the displayed speed unit will turn yellow when the vehicle reaches a set speed.

Selectable speed range: 50 km/h to 200 km/h (30 mph to 125 mph)

The indicator will illuminate in yellow at an optionally set speed and red at the fixed high speed.

*: Always observe the legal speed limit when driving on public roads.

■ Rev indicator (F SPORT models)

Select to set the rev indicator on/off.

When set to on, the tachometer will show a ring-shaped indicator in red when the engine reaches a set speed.

Selectable engine speed range: IS350: 2000 r/min to 6600 r/min

IS200t: 2000 r/min to 6100 r/min

■ Rev peak (F SPORT models)

Select to set the rev peak on/off.

When set to on and the engine speed reaches or exceeds 5000 r/min, an afterimage of the tachometer will be displayed at the highest engine speed for approximately 0.5 seconds.

■ Initialization

Select to reset the meter display settings. (→P. 52 1)

2. Instrument cluster

NOT FOR REPRODUCTION

Stop & Start system (Smart Stop) information (if equipped)

■ Smart Stop settings

→P. 2 07

■ Idling Stop Time

Displays the current idling stop time (Engine stop time due to the Stop & Start system)

■ Idling Stop Time (after reset/after start)

Displays the total idling stop time (engine stop time via the Stop & Start system) after resetting and engine startup.

■ Idling Stop Time fuel savings (after reset/after start)

Displays the fuel savings (reference) during idling stop time after resetting and engine startup.

■ Eco Driving Indicator

Eco Driving Indicator Light

During Eco-friendly acceleration (Eco driving), the Eco Driving Indicator Light will turn on. When the acceleration exceeds the Zone of Eco driving, or when the vehicle is stopped, the light turns off.

Eco Driving Indicator Zone Display

Suggests the Zone of Eco driving with current Eco driving ratio based on acceleration.

Eco driving ratio based on acceleration

If the acceleration exceeds the Zone of Eco driving, the right side of the Eco Driving Indicator Zone Display will illuminate.

Zone of Eco driving

Instrument cluster

Eco Driving Indicator will not operate under the following conditions:

● The shift lever is in any position other than D.

● A paddle shift switch is operated.

● Neither normal mode nor Eco drive mode is selected. (→P. 252)

● The vehicle speed is approximately 130 km/h (80 mph) or higher.

■ Suspension of the settings display

In the following situations, the settings display using the meter control switches will be suspended.

● When a warning message appears on the multi-information display

● When the vehicle begins to move

NOT FOR REPRODUCTION

■ Liquid crystal display

2. Instrument cluster

→P. 8 6

CAUTI ON

■ The information display at low temperatures

Allow the interior of the vehicle to warm up before using the liquid crystal information display. At extremely low temperatures, the information display monitor may respond slowly, and display changes may be delayed. For example, there is a lag between the driver’s shifting and the new gear number appearing on the display. This lag could cause the driver to downshift again, causing rapid and excessive engine braking and possibly an accident resulting in death or injury.

■ Cautions during setting up the display

As the engine needs to be running during setting up the display, ensure that the vehicle is parked in a place with adequate ventilation. In a closed area such as a garage, exhaust gases including harmful carbon monoxide (CO) may collect and enter the vehicle. This may lead to death or a serious health hazard.

NOTICE

■ During setting up the display

To prevent battery discharge, ensure that the engine is running while setting up the display features.

2. Instrument cluster

NOT FOR REPRODUCTION

Fuel consumption information

Fuel consumption information can be displayed on the navigation system screen or the Lexus Display Audio screen.

X Navigation system X Lexus Display Audio system

Instrument cluster

Navigation system screen

“MENU” button

Remote Touch knob

Lexus Display Audio screen

“MENU” button

Lexus Display Audio controller

NOT FOR REPRODUCTION

2. Instrument cluster

Trip information

X Navigation system

Press the “MENU” button on the Remote Touch, then select “Info” on the “Menu” screen, and then select “Fuel consumption”.

If the “Past record” screen is displayed, select “Trip information”.

Resetting the consumption data

Fuel consumption in the past 15 minutes

Displays the average vehicle speed since the engine was started.

Displays the elapsed time since the engine was started.

Cruising range (→P. 99)

X Lexus Display Audio system

NOT FOR REPRODUCTION

Press the “MENU” button on the Lexus Display Audio controller, then select “Info” on the “Menu” screen, and then select “Fuel consumption”.

If the “Trip information” screen does not appear, move the controller to the right and select “Trip information”.

2. Instrument cluster

Fuel consumption in the past 15 minutes

Displays the average vehicle speed since the engine was started.

Displays the elapsed time since the engine was started.

Cruising range (→P. 99)

Average fuel consumption for the past 15 minutes is divided by color into past averages and averages attained since the engine switch was last turned to IGNITION ON mode. Use the displayed average fuel consumption as a reference.

The image is an example only.

Instrument cluster

NOT FOR REPRODUCTION

2. Instrument cluster

Past record

X Navigation system

Press the “MENU” button on the Remote Touch, then select “Info” on the “Menu” screen, and then select “Fuel consumption”.

If the “Trip information” screen is displayed, select “Past record”.

Resetting the past record data

Best recorded fuel consumption

Average fuel consumption

Previous fuel consumption record

Updating the average fuel consumption data

X Lexus Display Audio system

Press the “MENU” button on the Lexus Display Audio controller, then select “Info” on the “Menu” screen, and then select “Fuel consumption”.

If the “Past record” screen does not appear, move the controller to the right and select “Past record”.

Previous fuel consumption record

Average fuel consumption

Best recorded fuel consumption

The average fuel consumption history is divided by color into past averages and the average fuel consumption since the last updated. Use the displayed average fuel consumption as a reference.

The image is an example only.

LEXUS ASE30R, GSE31R owners manuals

Specifications and Main Features

Frequently Asked Questions

User Manual

For your information

Reading this manual

How to search

Pictorial index

Before driving

For safety drive

Seat belts

SRS airbags

Pop Up Hood

Safety information for children

Child restraint systems

Installing child restraints

Exhaust gas precautions

Engine immobilizer system

Alarm

Warning lights and indicators

Gauges and meters

Multi-information display

Fuel consumption information
