The Quick Guide is not intended as a substitute for your
Not for Reproduction
Manual
. We strongly encourage you to review the
Manual
and supplementary manuals so you will have a better
understanding of your vehicle’s capabilities and limita tions.
Owner’s
Owner’s
Contents
Pictorial Index ............................................................................................................................. 3
Entering and Exiting
Keys........................................................................................................................................................11
Smart Entry & Start System........................................................................................................13
Theft Deterrent System................................................................................................................ 14
When Driving
Engine (Ignition) Switch...............................................................................................................15
Automatic Transmission ..............................................................................................................18
Turn Signal Lever............................................................................................................................21
Multi-information Display...........................................................................................................22
Eco Driving Indicator...................................................................................................................24
Headlights.........................................................................................................................................25
Automatic High Beam.................................................................................................................26
Windshield Wipers and Washer.............................................................................................28
Lexus Safety System +..................................................................................................................31
Dynamic Radar Cruise Control ..............................................................................................32
Cruise Control................................................................................................................................36
LDA (Lane Departure Alert with Steering Control)..................................................... 38
Stop & Start System......................................................................................................................39
BSM (Blind Spot Monitor).........................................................................................................40
Driving Mode Select Switch ......................................................................................................41
Tire Pressure Warning System................................................................................................44
ASC (Active Sound Control)...................................................................................................45
1
Driving Comfort
Not for Reproduction
Remote Touch ................................................................................................................................46
Center Display ............................................................................................................................... 47
Fuel Consumption Information ...............................................................................................50
Hands-free System For Cellular Phone ..............................................................................52
Automatic Air Conditioning System.....................................................................................56
Seat Heaters/Seat Ventilators ................................................................................................60
Opening and Closing
Door Locks ........................................................................................................................................61
Power Windows ............................................................................................................................62
Moon Roof .......................................................................................................................................63
Fuel Tank Cap.................................................................................................................................64
Trunk...................................................................................................................................................65
What to do if...
List of Warning/Indicator Lights.............................................................................................66
If the engine will not start............................................................................................................70
If the electronic key does not operate properly.................................................................71
Depending on specifications, the vehicle shown in the illustration may
differ from your vehicle in terms of equipment.
2
Pictorial Index
A
B
C
D
Not for Reproduction
■ Instrument panel
Engine switch ......................................................................................................................... P. 15
Starting the engine/changing the mode..................................................................................P. 15
Emergency stop of the engine.....................................................................................................P. 17
When the engine will not start ................................................................................................... P. 70
Warning messages
1
*
Shift lever ......................................................................... ....................................................... P. 18
Changing the shift position............................................................................................................P. 18
1
Precautions for towing
When the shift lever does not move
Meters
Reading the meters/adjusting the instrument panel lights
Warning lights/indicator lights..................................................................................................P. 66
When a warning light comes on
Multi-information display ................................................................................................. P. 22
Display.................................................................................................................................................. P. 22
When the warning messages are displayed
3
1
*
*
1
*
1
*
1
*
1
*
Parking brake
E
F
G
HIJ
K
L
M
N
Not for Reproduction
Applying/releasing
Precautions for winter season
Warning buzzer/message
Headlight switch ..................................................................................................................P. 25
Turn signal lever.................................................................................................................... P. 21
Headlights/front position lights/tail lights/daytime running lights............................. P. 25
Windshield wiper and washer switch ............................................................................P. 28
Usage...................................................................................................................................................P. 28
Adding washer fluid
Warning messages
Headlight cleaners..........................................................................................................................P. 28
Emergency flasher switch
Trunk opener switch ........................................................................................................... P. 65
Hood lock release lever
Tilt and telescopic steering control switch
Adjustment
Driving position memory
1
*
1
*
1
*
1
*
1
*
1
*
1
*
1
*
1
*
1,2
*
Air conditioning system ..................................................................................................... P. 56
Usage................................................................................................................................................... P. 56
Rear window defogger................................................................................................................. P. 56
3
Audio system
Trunk opener main switch................................................................................................. P. 65
1
*
: Refer to the “Owner’s Manual”.
2
*
: If equipped
3
*
: Refer to “Navigation System Owner’s Manual”.
*
4
■ Switches
A
B
C
D
E
F
Not for Reproduction
Instrument panel light control switches
Odometer/trip meter/trip meter reset button
ASC switch
Automatic High Beam switch
BSM (Blind Spot Monitor) main switch
Lexus parking assist-sensor switch
1
*
: Refer to the “Owner’s Manual”.
2
*
: If equipped
2
*
....................................................................................................................... P. 45
1
*
1
*
2
*
..................................................................................... P. 26
2
*
................................................................... P. 40
1,2
*
5
Tire pressure warning reset switch ................................................................................ P. 44
A
B
C
D
E
F
Not for Reproduction
Outside rear view mirror switches
Driving position memory switches
Window lock switch ............................................................................................................ P. 62
Power window switches..................................................................................................... P. 62
Door lock switches............................................................................................................... P. 61
1
*
: Refer to the “Owner’s Manual”.
2
*
: If equipped
1
*
1,2
*
6
Audio remote control switches
A
B
CDE
F
G
H
Not for Reproduction
Paddle shift switches ........................................... .................................................. ...... P. 19, 20
Meter control switches ..................................................................................................... P. 23
Vehicle-to-vehicle distance button
Cruise control switch
Cruise control
Dynamic radar cruise control
LDA (Lane Departure Alert with steering control) switch
Talk switch
Telephone switches
1
*
: Refer to “Navigation System Owner’s Manual”.
2
*
: If equipped
2
*
..............................................................................................................................P. 36
1
*
1
*
1
*
*
2
*
...............................................................................................P. 32
2
.......................................................................... P. 34
2
*
................................P. 38
7
Driving mode select switch ............................................................................................... P. 41
ABC
D
E
F
G
H
Not for Reproduction
VSC OFF switch
Snow mode switch ................................................................................................................P. 19
Stop & Start cancel switch
Seat heater switches ...................................................................................................... ....P. 60
Seat ventilator switches..................................................................................................... P. 60
Heated steering wheel switch
Remote Touch ...................................................................................................................... P. 46
1
*
: Refer to the “Owner’s Manual”.
2
*
: If equipped
1
*
2
*
........................................................................................... P. 39
1,2
*
8
■ Interior
A
B
C
D
E
F
G
H
I
J
Not for Reproduction
SRS airbags
Floor mats
Front seats
Head restraints
Seat belts
Console box
Inside lock buttons ............................................................................................................... P. 61
Cup holders
Assist grips
Coat hooks
: Refer to the “Owner’s Manual”.
*
*
*
*
*
*
*
*
*
*
9
■ Ceiling
A
B
C
D
E
F
Not for Reproduction
Inside rear view mirror
Sun visors
Vanity mirrors
Interior light
Personal lights
Moon roof switches
Intrusion sensor and tilt sensor cancel switch............................................................. P. 73
1
*
: Refer to the “Owner’s Manual”.
2
*
: If equipped
1
*
1
*
1
*
1
*
*
1
*
2
....................................................................................................... P. 63
10
Keys
A
B
D
A
B
C
D
E
F
Not for Reproduction
The keys
Wireless remote control
Electronic keys
• Operating the smart entry & start system
(P. 13)
• Operating the wireless remote control
function
Mechanical keys
Key number plate
C
Card key (electronic key) (if equipped)
Operating the smart entry & start system
(P. 13)
Locks the doors
Closes the windows and moon roof
Unlocks the doors
Opens the windows and moon roof
Opens the trunk
Sounds the alarm
*
: These settings must be customized at your
Lexus dealer.
11
*
*
Mechanical key
Not for Reproduction
To take out the mechanical key, push the release
button and take the key out.
The mechanical key can only be inserted in one
direction, as the key only has grooves on one side.
If the key cannot be inserted in a lock cylinder,
turn it over and re-attempt to insert it.
After using the mechanical key, store it in the electronic key. Carry the mechanical key together
with the electronic key. If the electronic key battery is depleted or the entry function does not
operate properly, you will need the mechanical
key.
12
Smart Entry & Start System
Not for Reproduction
The following operations can be performed simply by carrying the electronic key (including the
card key) on your person, for example in your pocket. The driver should always carry the electronic key.
For details on starting the engine, see page 15.
Unlocking and locking the doors from the outside
1
Grip the driver’s door handle to unlock the
door. Grip the passenger’s door handle to
*
Opening the trunk
unlock both side doors.
Make sure to touch the sensor on the back of
the handle.
The doors cannot be unlocked for 3 seconds
after the doors are locked.
*
: The door unlock settings can be changed.
2
Touch the lock sensor (indentation on the
side of the door handle) to lock the doors.
Check that the door is securely locked.
While carrying the electronic key, press the button on the trunk lid.
When both side doors are unlocked using one of
the following methods, the trunk can be opened
without the electronic key:
•Entry function
• Wireless remote control
• Door lock switches
• Automatic door unlocking system
• Mechanical key
For details on what to do when the electronic key does not operate properly, see page 71.
13
Theft Deterrent System
Not for Reproduction
Engine immobilizer system
The indicator light flashes after the engine switch
has been turned off to indicate that the system is
operating.
The indicator light stops flashing after the engine
switch has been turned to ACCESSORY or
IGNITION ON mode to indicate that the system
has been canceled.
Alarm
The alarm uses light and sound to give an alert when an intrusion is detected.
■
Setting
Close the doors, trunk and hood, and lock both side doors. The system will be set automatically
after 30 seconds.
The indicator light changes from being on to flashing when the system is set.
■
Canceling or stopping
● Unlock the doors.
● Open the trunk using the entry function or wireless remote control.
● Turn the engine switch to ACCESSORY or IGNITION ON mode, or start the engine. (The
alarm will be deactivated or stopped after a few seconds.)
14
Engine (Ignition) Switch
Not for Reproduction
Performing the following operations when carrying the electronic key on your person starts the
engine or changes engine switch modes.
Starting the engine
1
Check that the parking brake is set.
2
Check that the shift lever is in P.
3
Firmly depress the brake pedal.
and a message will be displayed on the multi-information display.
If it is not displayed, the engine cannot be started.
4
Press the engine switch shortly and firmly.
When operating the engine switch, one
short, firm press is enough.
It is not necessary to press and hold the
switch.
The engine will crank until it starts or for up to
30 seconds, whichever is less.
Continue depressing the brake pedal until
the engine is completely started.
The engine can be started from any engine
switch mode.
15
Stopping the engine
Not for Reproduction
1
Stop the vehicle.
2
Set the parking brake, and shift the shift lever to P.
3
Press the engine switch.
4
Release the brake pedal and check that the display on the meters is off.
Changing engine switch modes
Modes can be changed by pressing the engine switch with brake pedal released. (The mode
changes each time the switch is pressed.)
1
Off
*
The emergency flashers can be used.
2
ACCESSORY mode
Some electrical components such as the
audio system can be used.
“ACCESSORY” will be displayed on the
meters.
3
IGNITION ON mode
All electrical components can be used.
“IGNITION ON” will be displayed on the
meters.
*
: If the shift lever is in a position other than P
when turning off the engine, the engine switch
will be turned to ACCESSORY mode, not to
off.
16
If your vehicle has to be stopped in an emergency
Not for Reproduction
Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop
the vehicle using the following procedure:
1
Steadily step on the brake pedal with both feet and firmly depress it.
Do not pump the brake pedal repeatedly as this will increase the effort required to slow the
vehicle.
2
Shift the shift lever to N.
If the shift lever is shifted to N
3
After slowing down, stop the vehicle in a safe place by the road.
4
Stop the engine.
If the shift lever cannot be shifted to N
3
Keep depressing the brake pedal with both feet to reduce vehicle speed as much as possible.
4
To stop the engine, press and hold the engine
switch for 2 consecutive seconds or more, or
press it briefly 3 times or more in succession.
5
Stop the vehicle in a safe place by the road.
17
Automatic Transmission
Not for Reproduction
Shifting the shift lever
Shift position purpose and function
While the engine switch is in IGNITION ON
mode, move the shift lever with the brake pedal
depressed.
When shifting the shift lever between P and D,
make sure that the vehicle is completely stopped.
Shift position Objective or function
P Parking the vehicle/starting the engine
R Reversing
N Neutral (Condition in which the power is not transmitted)
D Normal driving
M M mode driving
1
*
: To improve fuel efficiency and reduce noise, shift the shift lever to D for normal driving.
2
*
: Any gear range can be fixed when driving in M mode.
*
2
*
(P. 20)
1
18
Selecting the driving mode
Not for Reproduction
■
Sport mode/Eco drive mode
P. 41
■
Snow mode
Snow mode can be selected to suit the conditions when driving on slippery road surfaces, such
as snow.
Press the switch.
Press the switch again to return to normal mode.
Selecting shift ranges in the D position
When the “-” paddle shift switch is operated, the shift range will be downshifted to a range that
enables engine braking force that is suitable to driving conditions. When the “+” paddle shift
switch is operated, the shift range will be one gear higher than the gear in use during normal D
position driving.
1
Upshifting
2
Downshifting
The selected shift range, from D1 to D8, will be
displayed on the meter.
To return to normal D position driving, the “+”
paddle shift switch must be held down for a period
of time.
Meter display Function
D2 - D8
D1 Setting the gear at 1
A lower shift range will provide greater engine braking forces than a higher shift range.
19
A gear in the range between 1 and the selected gear is automatically
chosen depending on vehicle speed and driving conditions
Selecting gears in the M position
Not for Reproduction
To enter M mode, shift the shift lever to M. Gears can then be selected by operating the shift lever
or paddle shift switches, allowing you to drive in the gear of your choosing.
1
Upshifting
2
Downshifting
The gear changes once every time the shift lever
or paddle shift switch is operated.
The selected gear, from M1 to M8, will be fixed
and displayed on the meter.
When in the M position, the gear will not change unless the shift lever or paddle shift switches are
operated.
However, even when in the M position, the gears will be automatically changed in the following
situation:
● When vehicle speed drops (downshift only).
● When a gear change is necessary to protect the engine or automatic transmission when the
engine coolant temperature or automatic transmission fluid temperature is low, or other rea-
sons.
In the following situations, the gear will not shift even if the shift lever or paddle shift switches are
operated.
● “Slippery Road. Cannot Shift to Lower Gear.” is displayed on the multi-information display.
● The vehicle speed is low (upshift only).
20
Turn Signal Lever
Not for Reproduction
The lever will return to its original position immediately after operation.
1
Left turn
2
Lane change to the left (move the lever partway and release it)
The left hand signals will flash 3 times.
3
Lane change to the right (move the lever
partway and release it)
The right hand signals will flash 3 times.
4
Right turn
If the turn signals do not stop flashing after turning
left or right, or if you want to stop them flashing,
operate the lever in the opposite direction to
2
either position
either position
flash.
or 3. If you move the lever to
1
or 4, the selected turn signals will
21
Multi-information Display
Not for Reproduction
The multi-information display presents the driver with a variety of vehicle data.
Displays and menu icons
Except F SPORT models F SPORT models (main meter in center
position)
F SPORT models (main meter moved to
the right)
22
■
B
C
D
D
Not for Reproduction
Menu icons
Drive information
Navigation system-linked display
Audio system-linked display
Driving assist system information
Stop & Start system information (if equipped)
Warning message display
Settings display
If a problem is detected in any of the vehicle’s systems, a warning message is shown on the multiinformation display.
Changing the meter display
Select an item/change pages
A
Press: Enter/Set
Press and hold: Reset
Return to the previous screen
Pressing and holding the switch will display
the first screen of the selected menu icon.
Except F SPORT models
Press: Display the top screen
Press and hold: Register current screen as
the top screen
F SPORT models
Move the main meter
23
Eco Driving Indicator
A
B
C
D
Not for Reproduction
Eco Driving Indicator Light
During Eco-friendly acceleration (Eco driving), the Eco Driving Indicator Light will turn
on. When the acceleration exceeds the Zone
of Eco driving, or when the vehicle is
stopped, the light turns off.
Eco Driving Indicator Zone Display
Suggests the Zone of Eco driving with current Eco driving ratio based on acceleration.
Eco driving ratio based on acceleration
If the acceleration exceeds the Zone of Eco
driving, the right side of the Eco Driving Indicator Zone Display will illuminate. At this
time, the Eco Driving Indicator Light will turn
off.
Zone of Eco driving
Eco Driving Indicator will not operate under
the following conditions:
● The shift lever is in any position other than
D.
● A paddle shift switch is operated.
● Neither normal mode nor Eco mode is
selected.
● The vehicle speed is approximately 130
km/h (80 mph) or higher.
24
Headlights
Not for Reproduction
Turning on the high beam headlights
1
2
3
4
1
2
The front position, tail, license plate and
instrument panel lights turn on.
The headlights and all lights listed above
turn on.
The headlights, daytime running lights
and all the lights listed above turn on and off
automatically. (When the engine switch is in
IGNITION ON mode.)
The daytime running lights turn on.
With the headlights on, push the lever away
from you to turn on the high beams.
Pull the lever toward you to the center position to turn the high beams off.
Pull the lever toward you and release it to
flash the high beams once.
You can flash the high beams with the headlights on or off.
25
Automatic High Beam (if equipped)
Not for Reproduction
The Automatic High Beam uses a camera sensor located behind the upper portion of the windshield to assess the brightness of the lights of vehicles ahead, streetlights, etc., and automatically
turns the high beams on or off as necessary.
Activating the Automatic High Beam
1
Push the lever away from you with the head-
light switch in the or position.
2
Press the Automatic High Beam switch.
The Automatic High Beam indicator will
come on when the system is operating.
26
Turning the high beam on/off manually
Not for Reproduction
■
Switching to the low beams
■
Switching to the high beams
Pull the lever to its original position.
The Automatic High Beam indicator will turn off.
Push the lever away from you to activate the Automatic High Beam system again.
Press the Automatic High Beam switch.
The Automatic High Beam indicator will turn off
and the high beam indicator will turn on.
Press the switch to activate the Automatic High
Beam system again.
27
Windshield Wipers and Washer
A
Not for Reproduction
Operating the lever operates the wipers or washer as follows. The lever will return to its
original position immediately after operation.
1
2
3
4
5
The AUTO mode indicator will turn on when
AUTO mode is selected.
Move the lever up by 2 levels
Move the lever up by 1 level
Move the lever down by 1 level
Move the lever down by 2 levels
AUTO mode on/off switch
28
Depending on the operating state of the wipers when the wiper lever is operated, the wipers will
Not for Reproduction
operate as follows.
• Current wiper operation: Off
Wiper lever operation Wiper operation
Temporary operation
Temporary operation
Low speed operation
High speed operation
• Current wiper operation: Low speed operation
Wiper lever operation Wiper operation
Off
Off
High speed operation
High speed operation
• Current wiper operation: High speed operation
Wiper lever operation Wiper operation
Off
Low speed operation
No change
No change
• Current wiper operation: AUTO mode (Intermittent operation)
Wiper lever operation Wiper operation
Off
Temporary operation
Low speed operation
High speed operation
29
1
*
2
*
2
*
• Current wiper operation: AUTO mode (Continuously)
Not for Reproduction
Wiper lever operation Wiper operation
No change
Low speed operation
High speed operation
1
*
: After temporary operation, the mode will return to AUTO mode.
2
*
: AUTO mode will be canceled.
When AUTO mode is selected, the sensor sensitivity can be adjusted by turning the switch ring.
6
Increases the sensitivity
7
Decreases the sensitivity
Off
2
*
2
*
8
Pulling the lever operates the wipers and washer.
The wipers will automatically operate a couple of
times after the washer squirts.
When the engine switch is in IGNITION ON
mode and the headlights are on, if the lever is
pulled, the headlight cleaners will operate once.
After this, the headlight cleaners will operate
every 5th time the lever is pulled.
Washer/wiper dual operation
30
Lexus Safety System + (if equipped)
Not for Reproduction
The Lexus Safety System + consists of the following drive assist systems and contributes to a safe
and comfortable driving experience:
Driving assist system
■
PCS (Pre-Collision System)
The pre-collision system uses a radar sensor and camera sensor to detect vehicles and pedestrians in front of your vehicle. When the system determines that the possibility of a frontal collision
with a vehicle or pedestrian is high, a warning operates to urge the driver to take evasive action
and the potential brake pressure is increased to help the driver avoid the collision. If the system
determines that the possibility of a frontal collision with a vehicle or pedestrian is extremely high,
the brakes are automatically applied to help avoid the collision or help reduce the impact of the
collision.
■
LDA (Lane Departure Alert with steering control)
P. 38
■
Automatic High Beam
P. 26
■
Dynamic radar cruise control
P. 32
31
Dynamic Radar Cruise Control (if equipped)
A
B
C
D
E
Not for Reproduction
In vehicle-to-vehicle distance control mode, the vehicle automatically accelerates and decelerates to match the speed changes of the preceding vehicle even if the accelerator pedal is not
depressed. In constant speed control mode, the vehicle runs at a fixed speed.
Use the dynamic radar cruise control on freeways and highways.
System Components
Vehicle-to-vehicle distance switch
Display
Set speed
Indicators
Cruise control switch
32
Setting the vehicle speed (vehicle-to-vehicle distance control mode)
Not for Reproduction
1
Press the “ON/OFF” button to activate the
cruise control.
Radar cruise control indicator will come on
and a message will be displayed on the multiinformation display.
Press the button again to deactivate the
cruise control.
If the “ON/OFF” button is pressed and held
for 1.5 seconds or more, the system turns on
in constant speed control mode. (P. 35)
2
Accelerate or decelerate, with accelerator
pedal operation, to the desired vehicle speed
(at or above approximately 50 km/h [30
mph]) and push the lever down to set the
speed.
Cruise control “SET” indicator will come on.
The vehicle speed at the moment the lever is
released becomes the set speed.
Adjusting the set speed
1
Increases the speed
2
Decreases the speed
Fine adjustment: Momentarily move the lever in
the desired direction.
Large adjustment: Hold the lever up or down to
change the speed, and release when the desired
speed is reached.
33
Changing the vehicle-to-vehicle distance (vehicle-to-vehicle distance con-
A
Not for Reproduction
trol mode)
Pressing the switch changes the vehicle-to-vehicle distance as follows:
1
Long
2
Medium
3
Short
The vehicle-to-vehicle distance is set automatically to long mode when the engine switch is
turned to IGNITION ON mode.
If a vehicle is running ahead of you, the preceding
vehicle mark will also be displayed.
Canceling and resuming the speed control
1
Pulling the lever toward you cancels the
speed control.
The speed control is also canceled when the
brake pedal is depressed.
2
Pushing the lever up resumes the cruise control and returns vehicle speed to the set
speed.
However, cruise control does not resume
when the vehicle speed is approximately
40 km/h (25 mph) or less.
34
Selecting constant speed control mode
Not for Reproduction
1
2
With the cruise control off, press and hold the
“ON/OFF” button for 1.5 seconds or more.
Immediately after the “ON/OFF” button is
pressed, the radar cruise control indicator
will come on. Afterwards, it switches to the
cruise control indicator.
Switching to constant speed control mode is
only possible when operating the lever with
the cruise control off.
Accelerate or decelerate, with accelerator
pedal operation, to the desired vehicle speed
(at or above approximately 40 km/h [25
mph]) and push the lever down to set the
speed.
Cruise control “SET” indicator will come on.
The vehicle speed at the moment the lever is
released becomes the set speed.
35
Cruise Control (if equipped)
A
B
C
Not for Reproduction
Use the cruise control to maintain a set speed without depressing the accelerator pedal.
System components
Set speed
Indicators
Cruise control switch
Setting the vehicle speed
1
Press the “ON/OFF” button to activate the
cruise control.
Cruise control indicator will come on.
Press the button again to deactivate the
cruise control.
2
Accelerate or decelerate, with accelerator
pedal operation, to the desired vehicle speed
(above approximately 40 km/h [25 mph])
and push the lever down to set the speed.
Cruise control “SET” indicator and set speed
will be displayed on the multi-information display.
The vehicle speed at the moment the lever is
released becomes the set speed.
36
Adjusting the set speed
Not for Reproduction
1
Increases the speed
2
Decreases the speed
Fine adjustment: Momentarily move the lever in
the desired direction.
Large adjustment: Hold the lever in the desired
direction.
Canceling and resuming the constant speed control
1
Pulling the lever toward you cancels the constant speed control.
The speed setting is also canceled when the
brake pedal is depressed.
2
Pushing the lever up resumes the constant
speed control.
However, resuming is available when the
vehicle speed is more than approximately
40 km/h (25mph).
37
LDA (Lane Departure Alert with Steering Control) (if
Not for Reproduction
equipped)
When driving on highways and freeways with white (yellow) lines, this function alerts the driver
when the vehicle might depart from its lane and provides assistance by operating the steering
wheel to keep the vehicle in its lane.
The LDA system recognizes visible white (yellow) lines with the camera sensor on the upper
portion of the front windshield.
Turning LDA system on
Press the LDA switch to turn the LDA system on.
The LDA indicator illuminates and a message is
displayed on the multi-information display.
Press the LDA switch again to turn the LDA system off.
When the LDA system is turned on or off, operation of the LDA system continues in the same condition the next time the engine is started.
38
Stop & Start System (if equipped)
Not for Reproduction
The Stop & Start system stops and restarts the engine according to the brake pedal or shift lever
operation when the vehicle is stopped.
Stop & Start system operation
■
When the shift lever is in D
Stopping the engine
While driving with the shift lever in D, depress the
brake pedal and stop the vehicle.
The Stop & Start indicator will come on.
Restarting the engine
Release the brake pedal.
The Stop & Start indicator will turn off.
■
When the shift lever is shifted to P
Stopping the engine
1
While driving with the shift lever in D, depress
the brake pedal and stop the vehicle.
The engine will be stopped by the Stop &
Start system and the Stop & Start indicator
will come on.
2
Shift the shift lever to P. (P. 18)
If the brake pedal is released, the engine will
remain stopped by the Stop & Start system.
Restarting the engine
With the brake pedal depressed, shift the shift lever to a position other than P. (P. 18)
Disabling the Stop & Start system
Press the Stop & Start cancel switch to disable the Stop & Start system.
39
BSM (Blind Spot Monitor) (if equipped)
A
C
D
Not for Reproduction
The Blind Spot Monitor is a system that has 2 functions:
● The BSM (Blind Spot Monitor) function
Assists the driver in making a decision when changing lanes
● The RCTA (Rear Cross Traffic Alert) function
Assists the driver when backing up
These functions use same sensors.
BSM main switch
This switch is for both the BSM function and
RCTA function.
Pressing the switch turns the system on or off.
When the switch is turned on, the indicator
on the switch illuminates.
Outside rear view mirror indicators
B
BSM function:
When a vehicle is detected in a blind spot of
the outside rear view mirrors or approaching
rapidly from behind into a blind spot, the outside rear view mirror indicator on the
detected side will illuminate. If the turn signal
lever is operated toward the detected side,
the outside rear view mirror indicator will
flash.
RCTA function:
When a vehicle approaching from the right
or left at the rear of the vehicle is detected,
both outside rear view mirror indicators will
flash.
Center Display
If a vehicle approaching from the right or left at the rear of the vehicle is detected, the RCTA
icon for the detected side will be displayed on the Center Display.
This illustration shows an example of a vehicle approaching from both sides of the vehicle.
RCTA buzzer (RCTA function only)
If a vehicle approaching from the right or left at the rear of the vehicle is detected, a buzzer
will sound. The buzzer also sounds for approximately 1 second immediately after the BSM
main switch is operated to turn the system on.
40
Driving Mode Select Switch
Not for Reproduction
The driving modes can be selected to suit driving condition.
Vehicles without AVS
1
Normal mode
Provides an optimal balance of fuel economy,
quietness, and dynamic performance. Suitable for city driving.
Press the switch to change the driving mode
to normal mode when Eco drive mode or
sport mode is selected.
2
Eco drive mode
Helps the driver accelerate in an eco-friendly
manner and improve fuel economy through
moderate throttle characteristics and by controlling the operation of the air conditioning
system (heating/cooling).
When not in Eco drive mode, if the driving
mode select switch is turned to the left, the
Eco drive mode indicator will come on.
3
Sport mode
Controls the transmission and engine to provide quick, powerful acceleration. This mode also
changes the steering feel, making it suitable for when agile driving response is desired, such
as when driving on roads with many curves.
When not in sport mode, if the driving mode select switch is turned to the right, the “SPORT”
indicator will comes on.
41
Vehicles with AVS
A
B
Not for Reproduction
Except F SPORT models
F SPORT models
1
Normal mode/Custom mode
Normal mode and custom mode are
selected by pressing the driving mode select
switch. Each time the switch is pressed, the
driving mode changes between normal
mode and custom mode. When custom
mode is selected, the “CUSTOM” indicator
will be illuminated.
When Eco drive mode or sport mode is
selected, pressing the switch changes the
driving mode to normal mode.
• Normal mode
Provides an optimal balance of fuel economy, quietness, and dynamic performance. Suitable for city driving.
• Custom mode
Allows you to drive with the following functions set to your preferred settings.
Custom mode settings can only be changed on the drive mode customization display of the
Center Display.
Function Setting
Normal
Powertrain
Chassis
Air conditioning system
Power
Eco
Normal
Sport
Normal
Eco
42
2
Not for Reproduction
Eco drive mode
Helps the driver accelerate in an eco-friendly manner and improve fuel economy through
moderate throttle characteristics and by controlling the operation of the air conditioning system (heating/cooling).
When not in Eco drive mode, if the driving mode select switch is turned to the left, the Eco
drive mode indicator will come on.
3
Sport mode
• SPORT S mode
Controls the transmission and engine to provide quick, powerful acceleration. Also, gear
shift timing is controlled to suit sporty driving, making this mode is suitable for when agile
driving response is desired, such as when driving on roads with many curves.
When not in SPORT S mode, if the driving mode select switch is turned to the right, the
“SPORT S” indicator will come on.
• SPORT S+ mode
Provides earlier downshift timing than SPORT S mode in order to maintain a high engine
speed and provides faster gear changes. This mode also changes the steering feel, suspension control and VDIM control, making it suitable for powerful sporty driving.
When in SPORT S mode, if the driving mode select switch is turned to the right, the
“SPORT S+” indicator will come on.
43
Tire Pressure Warning System
Not for Reproduction
Your vehicle is equipped with a tire pressure warning system that uses tire pressure warning
valves and transmitters to detect low tire inflation pressure before serious problems arise.
Initializing the tire pressure warning system
1
Park the vehicle in a safe place and turn the engine switch off.
Initialization cannot be performed while the vehicle is moving.
2
Adjust the tire inflation pressure to the specified cold tire inflation pressure level.
Make sure to adjust the tire pressure to the specified cold tire inflation pressure level. The tire
pressure warning system will operate based on this pressure level.
3
Turn the engine switch to IGNITION ON mode.
4
Press and hold the tire pressure warning
reset switch until the tire pressure warning
light blinks slowly 3 times.
5
Wait for a few minutes with the engine switch in IGNITION ON mode and then turn the
engine switch off.
44
ASC (Active Sound Control) (if equipped)
Not for Reproduction
The ASC system is an electronic sound system that generates engine sound, conveying the
kinetic situations of the vehicle’s acceleration and deceleration to the driver through the speakers inside the instrument panel.
The vehicle’s response to the driver’s acceleration behavior and shift operations are also conveyed in sound.
When sport mode is selected, the sound conveyed to the driver will be louder.
Controlling volume
1
Louder
2
Lower
The indicator comes on when the ASC system is
on.
When the dial is turned to the lowest volume, the
ASC system will be turned off and the indicator
will go off.
45
Remote Touch
A
B
C
D
E
Not for Reproduction
The Remote Touch can be used to operate Center Display.
Remote Touch is the name for the device that includes the “MAP” button, “MENU” button, back
button, touchpad and sub function button.
Names and operations of each part
“MAP” button
Press this button to display the vehicle’s current position.
“MENU” button
Press this button to display the menu screen.
Back button
Press this button to display the previous
screen.
Touchpad
Slide your finger on the touchpad and move the pointer to select a function, letter and screen
button.
Press the touchpad to enter the selected function, letter or screen button. Certain finger
movements on the touchpad can perform functions, such as changing map scalings and
scrolling list screens.
Sub function button
When is displayed on the screen, a function screen assigned to the screen can be displayed.
46
Center Display
Not for Reproduction
Menu screen
Press the “MENU” button on the Remote Touch to display the menu screen.
Switch Function
Select to display the “Destination” screen.
Select to display the radio control screen.
Select to display the media control screen.
Select to display the hands-free control screen. (P. 52)
Select to display the “Apps” screen.
Select to display the information screen.
Select to display the setup screen.
Select to display the air conditioning control screen. (P. 57)
1
*
: Refer to the “Navigation System Owner’s Manual”.
2
*
: This function is not available on some models.
*
*
1
1, 2
*
1
*
1
*
1
*
1
(P. 50)
47
Split-screen display
Not for Reproduction
Different information can be displayed on the left and right sides of the screen. For example, air
conditioning system screen can be displayed and operated while the fuel consumption information screen is being displayed. The large screen on the left of the display is called the main display,
and the small screen to the right is called the side display.
48
Side display
A
Not for Reproduction
The following functions can be displayed and
operated on the side display.
B
C
D
E
: Refer to the “Navigation System Owner’s Manual”.
*
Screen scroll operation
Select the desired point on the map screen.
Move the desired point on the centre of the map
screen.
Press the “MAP” button on the Remote Touch to
return to the current position.
Navigation system
Audio
*
Vehicle information (P. 51)
Air conditioning system (
Show/hide the side display
*
*
P. 59)
49
Fuel Consumption Information
A
B
C
D
E
F
A
B
C
D
E
Not for Reproduction
Fuel consumption information can be displayed on the Center Display.
The fuel consumption information can be displayed and operated on the side display. For details,
refer to the “Owner’s Manual”.
Consumption
Press the “MENU” button on the Remote Touch, then select on the menu screen, and then
select “ECO”.
■
Trip information
If a screen other than “Trip information” is displayed, select “Trip information”.
Resetting the consumption data
Fuel consumption in the past 15 minutes
Current fuel consumption
Average vehicle speed since the engine was
started.
Elapsed time since the engine was started.
Cruising range
■
History
If a screen other than “History” is displayed, select “History”.
Best recorded fuel consumption
Latest fuel consumption
Previous fuel consumption record
Resetting the history data
Updating the latest fuel consumption data
50
Using the side display
Not for Reproduction
Display the vehicle information on the side display, and then select or to display the
desired screen.
● Trip information (type A/type B)
● History
51
Hands-free System For Cellular Phone
Not for Reproduction
Registering/connecting a Bluetooth® device
To use the hands-free system, it is necessary to register a Bluetooth® phone with the system.
1
Turn the Bluetooth® connection setting of your cellular phone on.
2
Press the “MENU” button on the Remote Touch.
3
Select “Phone”.
4
Select “Yes” to register a phone.
5
Select the desired Bluetooth® device.
6
Register the Bluetooth® device using your
Bluetooth
7
Check that the following screen is displayed,
indicating pairing was successful.
8
Check that “Connected” is displayed and
registration is complete.
®
device.
52
Contacts transfer
Not for Reproduction
1
Press the “MENU” button on the Remote Touch.
Please refer to P. 46 for the Remote Touch operation.
2
Select “Setup”.
3
Select “Phone” on the sub menu.
4
Select “Contacts/Call history”.
5
Select “Transfer contacts from device”.
6
Select “From phone (Bluetooth*)”.
7
Transfer the contact data to the system using a Bluetooth® phone.
8
Check that a confirmation screen is displayed when the operation is complete.
*
: The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
Contacts transfer may not be possible depending on the type of phone.
Registering the contacts in the favorites list
1
Press the “MENU” button on the Remote Touch.
Please refer to P. 46 for the Remote Touch operation.
2
Select “Setup”.
3
Select “Phone” on the sub menu.
4
Select “Contacts/Call history”.
5
Select “Add favourite”.
6
Select the desired contact to add to the favorites list.
7
Check that a confirmation screen is displayed when the operation is complete.
53
Calling by favorites list
Not for Reproduction
1
Press the “MENU” button on the Remote Touch.
Please refer to P. 46 for the Remote Touch operation.
2
Select “Phone”.
3
Select “Favourites” on the sub menu and select the desired contact.
4
Select the desired number.
5
Check that the dialing screen is displayed.
Calling the message sender
1
Press the “MENU” button on the Remote Touch.
Please refer to P. 46 for the Remote Touch operation.
2
Select “Phone”.
3
Select “Message” on the sub menu.
4
Select a desired account name that is displayed on the left side of screen.
5
Select the desired message.
6
Select or press the switch on the steering wheel.
7
Check that the dialing screen is displayed.
Receiving a call
Select “Answer”/ or press the switch on the steering wheel to talk on the phone.
Main display Side display
“Decline”/ : Select to refuse to receive the call.
54
Steering switches
D
Not for Reproduction
Volume control switch
A
• Press the “+” side to increase the volume.
• Press the “-” side to decrease the volume.
Off hook switch
B
• Press to start talking.
• Press to put a call on hold.
On hook switch
C
• Press to end talking/dialing.
• Press to refuse to receive the call.
Talk switch
• Press the talk switch to start the speech
command system.
• To cancel voice recognition, press and hold
the talk switch.
55
Automatic Air Conditioning System
A
B
C
D
E
F
G
H
I
J
K
L
M
Not for Reproduction
Press the “MENU” button on the Remote Touch, then select “Climate” to display the air conditioning control screen.
Control panel
Left-hand side temperature control switch
S-FLOW mode switch
Air flow mode switch
Fan speed down switch
Fan speed up switch
Off switch
Automatic mode switch
Right-hand side temperature control switch
Rear window defogger and outside rear view mirror defoggers switch
Windshield defogger switch
Outside/recirculated air mode switch
A/C switch
DUAL mode switch
56
■
B
C
F
G
H
Not for Reproduction
Adjusting the temperature setting
To adjust the temperature setting, touch and slide
your finger up or down on the sensor.
The temperature setting can also be adjusted by
touching on the sensor.
When the temperature setting is changed, a
buzzer sounds.
If is not pressed, the system will blow
ambient temperature air or heated air.
■
Fan speed setting
Press to increase the fan speed.
Press to decrease the fan speed.
■
Change the airflow mode
To change the airflow, press .
The air outlets used are switched each time the button is pressed.
Air conditioning control screen
Display the air conditioning control screen
A
Display the option control screen
Adjust the left-hand side temperature setting
Adjust the fan speed setting
D
Select the air flow mode
E
Adjust the right-hand side temperature setting
Function on/off indicators
Display the sub function menu
57
■
A
B
C
D
A
B
C
D
E
Not for Reproduction
Option control screen
The functions can be switched on and off.
Adjusting the temperature for driver and passenger seats separately (“DUAL” mode)
Set cooling and dehumidification function
on/off
Select the S-FLOW mode (if equipped)
Removing pollen from the air (Pollen removal
mode)
■
Sub function menu
When the sub function button on the Remote Touch is pressed, the following functions can be
switched on and off.
Set automatic mode on/off
Turn the fan off
Set cooling and dehumidification function
on/off
Adjust the temperature for driver and passenger seats separately (“DUAL” mode)
Select to set eco mode on/off
58
■
B
C
E
F
Not for Reproduction
Side display
Adjust the left-hand side temperature setting
A
Adjust the fan speed setting
Adjust the right-hand side temperature setting
Set cooling and dehumidification function
D
on/off
Adjust the temperature for the driver's and front passenger's seats separately (“DUAL”
mode)
Select the air flow mode
Using automatic mode
1
Press , or select “AUTO” on the air conditioning control screen.
2
Press to switch to automatic air intake mode.
The air conditioning system automatically switches between outside air and recirculated air
modes.
3
Adjust the temperature setting.
4
To stop the operation, press or select “Off” on the sub function menu.
59
Seat Heaters/Seat Ventilators
A
Not for Reproduction
Seat heaters
Each time the switch is pressed, the intensity of the
seat heater changes and the level indicator lights
(amber) light as follows:
Hi (3 segments lit)Mid (2 segments lit)Lo (1
segment lit)Off
Seat ventilators
Each time the switch is pressed, the intensity of the
seat ventilator changes and the level indicator
lights (green) light as follows:
Hi (3 segments lit)Mid (2 segments lit)Lo (1
segment lit)Off
A
■ Seat heater timer control
To enable seat heater timer control, press and hold the driver and front passenger seat heater
switches at the same time when the vehicle is stopped until a buzzer sounds once. If a seat
heater is turned on while seat heater timer control is enabled, the intensity of the seat heater will
automatically change from HiMidLo.
The timing of the change in seat heater intensity differs depending on the temperature inside
the cabin, etc. when the seat heater is operating.
To disable seat heater timer control, press and hold the driver and front passenger seat heater
switches at the same time until a buzzer sounds twice.
60
Door Locks
Not for Reproduction
The vehicle can be locked and unlocked using the entry function, wireless remote control or
door lock switches.
For details about the entry function or wireless remote control, refer to P. 11, 13.
Unlocking and locking the doors from the inside
■
Door lock switches (to lock/unlock)
Locks both side doors
1
2
Unlocks both side doors
■
Inside lock buttons (to lock/unlock)
Locks the door
1
2
Unlocks the door
Both side doors can be opened by pulling the
inside handle even if the lock buttons are in the
lock position.
61
Power Windows
A
Not for Reproduction
Opening and closing the power windows
1
Closing
2
One-touch closing
3
Opening
4
One-touch opening
: To stop the window partway, operate the
*
switch in the opposite direction.
Preventing accidental operation (window lock switch)
Press the switch.
The indicator will come on and the passenger
windows will be locked.
The passenger window can still be opened and
closed using the driver’s switch even if the lock
switch is on.
This function can be used to prevent children from
accidentally opening or closing a passenger window.
*
*
62
Moon Roof (if equipped)
Not for Reproduction
Operating the moon roof
■
Opening and closing
■
Tilting up and down
1
Opens the moon roof
The moon roof tilts up and then fully opens.
2
Closes the moon roof
: Lightly press either way of the moon roof
*
switch to stop the moon roof partway.
1
Tilts the moon roof up
2
Tilts the moon roof down
: Lightly press either way of the moon roof
*
switch to stop the moon roof partway.
*
*
*
*
63
Fuel Tank Cap
Not for Reproduction
Before refueling the vehicle
● Close both side doors and windows, and turn the engine switch off.
● Confirm the type of fuel.
Opening the fuel tank cap
1
With the doors unlocked, press the center of
the rear edge of the fuel filler door.
Push until you hear a click and take your hand
away to slightly open the fuel filler door. Then
open the door fully by hand.
2
Turn the fuel tank cap slowly and remove it,
then put it into the holder on the fuel filler
door.
64
Trunk
A
B
Not for Reproduction
Opening/closing the trunk
■
Trunk opener switch
Press the trunk opener switch.
■
Smart entry & start system
P. 13
■
Wireless remote control
P. 11
Luggage security system
To protect luggage stored in the trunk against theft, the luggage security system can be set to on.
1
Move the luggage security system levers to
the lock position.
To lock a luggage security system lever from
inside the cabin, fold the rear seatback forward, move the lever to the lock position, and
return the seatback to its original position.
2
To disable the trunk opener, turn the main
switch in the glove box off.
On
Off
When the main switch is off, the trunk lid cannot
be opened even with the wireless remote control
or entry function.
65
What to do if...
Not for Reproduction
List of Warning/Indicator Lights
Immediately stop the vehicle in a safe place and contact your Lexus dealer. Continuing to
drive the vehicle may be dangerous.
Brake system warning light
Immediately stop the vehicle in a safe place and contact your Lexus dealer.
Charging system warning light
Have the vehicle inspected by your Lexus dealer immediately.
Low engine oil pressure warning
light
Malfunction indicator lamp
SRS warning light
ABS warning light
Brake Override System
warning light/Drive-Start
Control warning light
Electric power steering
system warning light
For further information, refer to the “Owner’s Manual”.
(flashe s or
illuminates)
(flashes)
(Blinking and
then continu-
ously on)
PCS warning light (If equipped)
Slip indicator
Stop & Start cancel indicator (If
equipped)
Tire pressure warning light
66
What to do if...
Not for Reproduction
Follow the correction procedures.
Parking brake warning light
LDA (Lane Departure Alert)
(orange)
indicator (if equipped)
Driver’s and front passenger’s
seat belt reminder light
Rear passengers’ seat belt
reminder lights
PCS warning light (If equipped)
(flashes or
illuminates)
Open door warning light
Low fuel level warning light
Stop and check.
High coolant temperature warning light
Master warning light
Tire pressure warning light
(Illuminates
without
blinking)
For further information, refer to the “Owner’s Manual”.
*
67
What to do if...
Not for Reproduction
See the “Owner’s Manual”.
Turn signal indicator
Tail light indicator
Headlight high beam indicator
Automatic High Beam indicator
(if equipped)
Stop & Start indicator (if
equipped)
(white)
(green)
(orange)
(flashes)
LDA (Lane Departure Alert)
indicator (if equipped)
LDA (Lane Departure Alert)
indicator (if equipped)
LDA (Lane Departure Alert)
indicator (if equipped)
BSM (Blind Spot Monitor) outside rear view mirror indicators
(if equipped)
Lexus parking assist-sensor indicator (if equipped)
Stop & Start cancel indicator (if
equipped)
PCS warning light (if equipped)
Cruise control indicator Security indicator
Dynamic radar cruise control
indicator (if equipped)
Cruise control “SET” indicator Eco Driving Indicator Light
For further information, refer to the “Owner’s Manual”.
(flashes)
Slip indicator
VSC OFF indicator
Low outside temperature indicator
68
What to do if...
Not for Reproduction
See the “Owner’s Manual”.
● Drive mode indicators
Except F SPORT models
Eco drive mode indicator
“SPORT” indicator (if equipped)
“SPORT S” indicator (if
equipped)
● F SPORT models
Eco drive mode indicator “CUSTOM” indicator
“SPORT S” indicator Snow mode indicator
“SPORT S+” indicator
For further information, refer to the “Owner’s Manual”.
“SPORT S+” indicator (if
equipped)
“CUSTOM” indicator (if
equipped)
Snow mode indicator
*
: It also comes on due to natural causes such as natural air leaks and tire inflation pressure
changes caused by temperature. Adjust the tire inflation pressure to the specified level. The
light will turn off after a few minutes. In case the light does not turn off even if the tire inflation
pressure is adjusted, have the system checked by your Lexus dealer.
69
What to do if...
Brake pedal
Not for Reproduction
If the engine will not start
Make sure that the correct operating procedures have been followed.
Make sure that the brake pedal is firmly
depressed when attempting to start the engine.
(P. 15)
If the engine still does not start, see the “Owner’s Manual” for more information or contact your
Lexus dealer.
70
What to do if...
Not for Reproduction
If the electronic key does not operate properly
Locking and unlocking the doors and opening the trunk
■
Unlocking the door
Use the mechanical key in order to perform the following operations:
1
Insert the mechanical key while pulling on the
driver’s door handle.
2
Unlocking the door.
3
Remove the key, return the handle, and then pull the handle again.
■
Locking the door
Move the inside lock button to the lock posi-
1
tion.
2
Close the door while pulling the door handle.
71
What to do if...
Not for Reproduction
■
Opening the trunk
Starting the engine
Turn the mechanical key clockwise to open.
1
Ensure that the shift lever is in P and depress
the brake pedal.
2
Touch the Lexus emblem side of the electronic key to the engine switch.
When the electronic key is detected, a
buzzer sounds and the engine switch will turn
to IGNITION ON mode.
When the smart entry & start system is deactivated in customization setting, the engine
switch will turn to ACCESSORY mode.
3
Firmly depress the brake pedal and check that is shown on the multi-information display.
4
Press the engine switch.
In the event that the engine still cannot be started, contact your Lexus dealer.
If the electronic key battery becomes depleted, a warning message will be shown on the multiinformation display. Replace the battery with a new one. For instructions on replacing the battery,
refer to the “Owner’s Manual”.
If you need further assistance, contact your Lexus dealer.
72
What to do if...
Not for Reproduction
Intrusion sensor and tilt sensor
● The intrusion sensor detects intruders or movement in the vehicle.
● The tilt sensor detects changes in vehicle inclination, such as when the vehicle is towed away.
The sensor may trigger the alarm in the following situations:
● A window or the moon roof is open. In this case, the
sensor may detect the following:
• Wind or the movement of objects such as leaves and
insects inside the vehicle
• Ultrasonic waves emitted from devices such as the
intrusion sensors of other vehicles
• The movement of people outside the vehicle
● Unstable items, such as dangling accessories or clothes
hanging on the coat hooks, are in the vehicle.
● Places with extreme vibrations or noises, or situations in which the vehicle is subject to
repeated impacts or vibrations:
• When parked in a parking garage
• When ice adhering to the vehicle is removed
• When the vehicle is in an automatic or high-pressure car wash
• When in a hail or lightning storm
73
What to do if...
Not for Reproduction
■
Canceling the intrusion sensor and tilt sensor
Turn the engine switch off.
1
2
Press the intrusion sensor and tilt sensor cancel switch.
Press the switch again to re-enable the intrusion sensor and tilt sensor.
Each time the intrusion sensor is canceled/
set, a message will be shown on the multiinformation display in the instrument cluster.
The alarm will still be set even when the intrusion sensor is canceled. For details about the alarm
and the intrusion sensor, refer to the “Owner’s Manual”.
74
Memo
Not for Reproduction
75
Memo
Not for Reproduction
76
Memo
Not for Reproduction
77
©2018 TOYOTA MOTOR CORPORATION
All rights reserved. This material may not be reproduced or copied, in whole or in part,
without the written permission of Toyota Motor Corporation.
Not for Reproduction
78
Not for Reproduction
Loading...
