Not for Reproduction
The Quick Guide is not intended as a substitute for your
Not for Reproduction
Manual
. We strongly encourage you to review the
Manual
and supplementary manuals so you will have a better
Contents
Pictorial Index ............................................................................................................................. 3
Entering and Exiting
Keys........................................................................................................................................................11
Smart Entry & Start System........................................................................................................13
When Driving
Engine (Ignition) Switch............................................................................................................... 14
Automatic Transmission .............................................................................................................. 17
Turn Signal Lever...........................................................................................................................20
Parking Brake...................................................................................................................................21
Brake Hold .......................................................................................................................................23
Multi-information Display...........................................................................................................24
Headlights.........................................................................................................................................26
AHS (Adaptive High-beam System).....................................................................................27
Automatic High Beam.................................................................................................................29
Windshield Wipers and Washer..............................................................................................31
Rear Window Wiper and Washer.........................................................................................32
Stop & Start system.......................................................................................................................33
Lexus Safety System+..................................................................................................................34
LDA (Lane Departure Alert with steering control) ........................................................35
Dynamic Radar Cruise Control with Full-speed Range...............................................36
Cruise Control.................................................................................................................................41
Lexus Parking Assist-sensor.....................................................................................................43
Panoramic View Monitor...........................................................................................................44
Driving Mode Select Switch .....................................................................................................47
BSM (Blind Spot Monitor).........................................................................................................49
Tire Pressure Warning System............................................................................................... 50
ASC (Active Sound Control)....................................................................................................51
understanding of your vehicle’s capabilities and limitations.
Owner’s
Owner’s
1
Driving Comfort
Not for Reproduction
Remote Touch ................................................................................................................................52
Fuel Consumption Screen.........................................................................................................56
Hands-free System For Cellular Phone ..............................................................................58
Air Conditioning System............................................................................................................63
Seat Heaters/Seat Ventilators ................................................................................................68
Opening and Closing
Door Locks ......................................................................................................................................70
Power Windows ..............................................................................................................................71
Moon Roof ....................................................................................................................................... 72
Fuel Tank Cap.................................................................................................................................73
Back Door ........................................................................................................................................ 74
What to do if...
List of Warning/Indicator Lights..............................................................................................77
If the electronic key does not operate properly................................................................81
If the engine will not start............................................................................................................83
Depending on specifications, the vehicle shown in the illustration may
differ from your vehicle in terms of equipment.
2
Pictorial Index
A
B
C
D
Not for Reproduction
■ Instrument panel
Engine switch ......................................................................................................................... P. 14
Starting the engine/changing the modes.........................................................................P. 14, 15
Emergency stop of the engine.....................................................................................................P. 16
When the engine will not start ....................................................................................................P.83
Warning messages
1
*
Shift lever .................................................... ............................................................................ P. 17
Changing the shift position............................................................................................................P. 17
Precautions against towing
When the shift lever does not move*
Meters*
Reading the meters/adjusting the instrument panel light*
Warning lights/indicator lights...................................................................................................P. 77
When the warning lights come on
Multi-information display ................................................................................................. P. 24
Display.................................................................................................................................................. P. 24
When the warning messages are displayed
3
1
1
*
1
1
1
*
1
*
Turn signal lever................................................................................................................... P. 20
E
F
G
H
I
J
K
Not for Reproduction
Headlight switch ............................................................. ................................................. .... P. 26
Headlights/front position lights/tail lights/license plate lights/
daytime running lights ....................................................................................................................P. 26
Front fog lights
Windshield wiper and washer switch ..................................................................... P. 31, 32
Usage.............................................................................................................................................P. 31, 32
Adding washer fluid
Warning messages*
Emergency flasher switch*
Hood lock release lever*
Tilt and telescopic steering control switch*
Adjustment*
Driving position memory*
Air conditioning system ............................................ ......................................................... P. 63
Usage...................................................................................................................................................P. 65
Rear window defogger................................................................................................................. P. 63
Audio system
1
*
: Refer to the “Owner’s Manual”.
2
*
: Refer to the “Navigation System Owner’s Manual”.
3
*
: If equipped
1, 3
*
/rear fog light*
1
2
*
1
*
1
1
1
1
1, 3
1
4
■ Switches
A
B
C
D
E
F
G
H
I
J
Not for Reproduction
Front seat heater switches*2........................................................................................... P. 68
Front seat ventilator switches
Odometer/trip meter and trip meter reset button
Instrument panel light control switches*
Automatic High Beam switch*2..................................................................................... P. 29
Adaptive High-beam System switch
BSM (Blind Spot Monitor) main switch
Power back door switch
All-wheel drive lock switch
2
*
..................................................................................... P. 69
1
*
1
2
*
........................................................................ P. 27
2
*
................................................................... P. 49
2
*
............................................................................................... P. 74
1, 2
*
Camera switch*2................................................................................................................ P. 44
Rear seat operation switches
1
*
: Refer to the “Owner’s Manual”.
2
*
: If equipped
5
1, 2
*
HUD (Head-up display) switches*
A
B
C
D
E
F
G
Not for Reproduction
ASC (Active Sound Control) dial*2............................................................................... P. 51
Outside rear view mirror switches
Window lock switch ............................................................................................................. P. 71
Power window switches...................................................................................................... P. 71
Driving position memory switches
Door lock switches..............................................................................................................P. 70
1
*
: Refer to the “Owner’s Manual”.
2
*
: If equipped
1, 2
*
*
1
1, 2
6
Audio remote control switches*
A
B
C
D
E
F
G
H
Not for Reproduction
Paddle shift switches .....................................................................................................P. 18, 19
Meter control switches .................................................................................................... .P. 24
Vehicle-to-vehicle distance switch
Cruise control switch
2
*
Cruise control
Dynamic radar cruise control with full-speed range
LDA (Lane Departure Alert with steering control) switch
Talk switch ............................................................................................................................. P. 62
Telephone switches ............................................................................................................ P. 62
1
*
: Refer to the “Navigation System Owner’s Manual”.
2
*
: If equipped
................................................................................................................................P. 41
1
2
*
...........................................................................P. 38
2
*
...................................................P. 36
2
*
................................ P. 35
7
VSC off switch*
A
B
C
D
E
F
G
Not for Reproduction
Driving mode select switch .............................................................................................. P. 47
Stop & Start cancel switch ................................................................................................ P. 33
Brake hold switch ................................................................................................................P. 23
Parking brake switch ........................................................................................................... P. 21
Applying/releasing...........................................................................................................................P. 21
Precautions against winter season
Warning buzzer/message*
Remote Touch ...................................................................................................................... P. 52
Rear seat heater switches
1
*
: Refer to the “Owner’s Manual”.
2
*
: If equipped
1
1
*
1
2
*
............................................................................................ P. 68
8
■ Interior
A
B
C
D
EFG
H
I
J
Not for Reproduction
SRS airbags*
Floor mats*
Front seats*
Rear seats*
Head restraints*
Seat belts*
Console box*
Inside lock buttons .............................................................................................................. P. 70
Cup holders
Assist grips*
: Refer to the “Owner’s Manual”.
*
9
*
■ Ceiling
A
B
C
D
E
F
G
Not for Reproduction
Inside rear view mirror*
Sun visors*
Vanity mirrors*
Interior light*
Personal lights*
Moon roof switches*2....................................................................................................... P. 72
Moon roof switches
Electronic sunshade switch
Intrusion sensor and tilt sensor cancel switch*
1
*
: Refer to the “Owner’s Manual”.
2
*
: If equipped
1
1
1
1
*
1
2
....................................................................................................... P. 72
1, 2
*
1, 2
10
Keys
*
Not for Reproduction
Electronic key
Mechanical key
● Smart entry & start system (P. 13)
● Wireless remote control
*: If equipped
To take out the mechanical key, push the release
button and take the key out.
The mechanical key can only be inserted in one
direction, as the key only has grooves on one side.
If the key cannot be inserted in a lock cylinder,
turn it over and re-attempt to insert it.
After using the mechanical key, store it in the electronic key. Carry the mechanical key together
with the electronic key. If the electronic key battery is depleted or the entry function does not
operate properly, you will need the mechanical
key.
11
Wireless remote control
A
B
C
D
E
F
Not for Reproduction
Locks all the doors
Closes the windows and moon roof
Unlocks all the doors
Opens the windows and moon roof
Opens and closes the power back door*
Sounds the alarm*
*1: If equipped
2
*
: These settings must be customized at your Lexus dealer.
1, 2
*
1, 2
*
1
1
12
Smart Entry & Start System
Not for Reproduction
The following operations can be performed simply by carrying the electronic key (including the
card key) on your person, for example in your pocket. The driver should always carry the electronic key.
For details on starting the engine, see page 14.
Unlocking and locking the doors from the outside
1 Grip the driver’s door handle to unlock the
door. Grip any passenger door handle to
unlock all the doors.
Make sure to touch the sensor on the back of the
handle.
The doors cannot be unlocked for 3 seconds after
the doors are locked.
*: The door unlock settings can be changed.
2 Touch the lock sensor (the indentation on the surface of the door handle) to lock the doors.
Check that the door is securely locked.
Unlocking and locking the back door
*
1 Locks all the doors
Check that the door is securely locked.
2 Unlocks all the doors
The doors cannot be unlocked for 3 seconds
after the doors are locked.
For details on what to do when the electronic key does not operate properly, see page 81.
13
Engine (Ignition) Switch
Not for Reproduction
Performing the following operations when carrying the electronic key on your person starts the
engine or changes engine switch modes.
Starting the engine
1 Check that the parking brake is set.
2 Check that the shift lever is in P.
3 Firmly depress the brake pedal.
and a message will be displayed on the
multi-information display.
If it is not displayed, the engine cannot be
started.
4 Press the engine switch shortly and firmly.
When operating the engine switch, one short, firm press is enough. It is not necessary to press
and hold the switch.
The engine will crank until it starts or for up to 30 seconds, whichever is less.
Continue depressing the brake pedal until the engine is completely started.
The engine can be started from any engine switch mode.
14
Stopping the engine
Not for Reproduction
1 Stop the vehicle completely.
2 Set the parking brake (P. 21), and shift the shift lever to P (P. 17).
3 Press the engine switch.
4 Release the brake pedal and check that the display on the instrument cluster is off.
Changing engine switch modes
Modes can be changed by pressing the engine switch with brake pedal released. (The mode
changes each time the switch is pressed.)
1 Off*
The emergency flashers can be used.
2 ACCESSORY mode
Some electrical components such as the
audio system can be used.
“ACCESSORY” will be displayed on the
multi-information display.
3 IGNITION ON mode
All electrical components can be used.
“IGNITION ON” will be displayed on the
multi-information display.
*: If the shift lever is in a position other than P
when turning off the engine, the engine
switch will be turned to ACCESSORY
mode, not to off.
15
If your vehicle has to be stopped in an emergency
Press and hold for 2 seconds or more
or press briefly 3 times or more
Not for Reproduction
Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop
the vehicle using the following procedure:
1 Steadily step on the brake pedal with both feet and firmly depress it.
Do not pump the brake pedal repeatedly as this will increase the effort required to slow the
vehicle.
2 Shift the shift lever to N.
If the shift lever is shifted to N
3 After slowing down, stop the vehicle in a safe place by the road.
4 Stop the engine.
If the shift lever cannot be shifted to N
3 Keep depressing the brake pedal with both feet to reduce vehicle speed as much as possible.
4 To stop the engine, press and hold the engine
switch for 2 consecutive seconds or more, or
press it briefly 3 times or more in succession.
5 Stop the vehicle in a safe place by the road.
16
Automatic Transmission
Not for Reproduction
Shifting the shift lever
Shift position purpose and functions
While the engine switch is in IGNITION
ON mode, move the shift lever with the
brake pedal depressed.
When shifting the shift lever between P and
D, make sure that the vehicle is completely
stopped.
Shift position Objective or function
P Parking the vehicle/starting the engine
R Reversing
N Neutral
D Normal driving*
M M mode driving*2 (P. 19)
1
*
: To improve fuel efficiency and reduce noise, shift the shift lever to D for normal driving.
You can choose gear range suitable for your driving situation by operating the paddle shift
switches.
2
*
: Any gear range can be fixed when driving in M mode.
17
1
Selecting the driving mode
Not for Reproduction
P. 47
Selecting shift ranges in the D position
To drive using temporary shift range selection, operate the “-” paddle shift switch while the shift
lever in D. Changing the shift range enables the level of engine braking force to be selected. The
shift range can then be selected by operating the “-” and “+” paddle shift switches.
1 Upshifting
2 Downshifting
The selected shift range, from 1 to 6, will be displayed on the multi-information display.
The initial shift range when the “-” paddle shift
switch is operated is automatically set to 2, 3, 4 or
5 according to the vehicle speed.
To return to normal D position driving, the “+”
paddle shift switch must be held down for a period
of time.
Meter display Function
D2 - D6
D1 1st gear is set
A lower shift range will provide greater engine braking forces than a higher shift range.
A gear in the range between 1 and the selected gear is automatically
chosen depending on vehicle speed and driving conditions
18
Selecting shift ranges in the M position
Not for Reproduction
To enter M mode, shift the shift lever to M. Gears can then be selected by operating the shift lever
or paddle shift switches, allowing you to drive in the gear of your choice. The gear can be selected
by operating the shift lever or the “-” and “+” paddle shift switches.
1 Upshifting
2 Downshifting
The gear changes once every time the shift lever
or paddle shift switch is operated. The selected
gear, from 1 to 6, will be fixed and displayed on the
multi-information display. When in the M position,
the gear will not change unless the shift lever or
paddle shift switches are operated. However,
even when in the M position, the gears will be
automatically changed in the following situation:
● When vehicle speed drops (downshift only).
● When the accelerator pedal is depressed fur-
ther, while driving (downshift only).
● When the needle of the tachometer is in the
red zone (the range which exceeds the allowable revs of the engine).
19
Turn Signal Lever
Not for Reproduction
1 Left turn
2 Lane change to the left (move the lever part-
way and release it)
The left hand signals will flash 3 times.
3 Lane change to the right (move the lever
partway and release it)
The right hand signals will flash 3 times.
4 Right turn
20
Parking Brake
A
B
Not for Reproduction
The parking brake can be set or released automatically or manually.
Turning the automatic mode on
In automatic mode, the parking brake can be set or released automatically according to shift lever
operation. Also, even in automatic mode, the parking brake can be set or released manually.
While the vehicle is stopped, pull and hold the
parking brake switch until the automatic mode
lamp turns on
Parking brake lamp
Automatic mode lamp
The parking brake is set or released automatically
according to shift lever operation.
● When the shift lever is moved out of P, the
parking brake will be released, and the parking
brake indicator light and parking brake lamp
turn off.
● When the shift lever is moved into P, the parking brake will be set, and the parking brake
indicator light and parking brake lamp turn on.
Operate the shift lever with the brake pedal
depressed.
21
Using the manual mode
A
A
A
B
Not for Reproduction
The parking brake can be set and released manually.
1 Sets the parking brake
2 Releases the parking brake
If the parking brake indicator light and parking
brake lamp flashes, operate the switch again.
Turning the automatic mode off
While the vehicle is stopped, press and hold the
parking brake switch until the automatic mode
lamp turns off.
The parking brake indicator light and parking
brake lamp will turn on.
Pull and hold the parking brake switch if an
emergency occurs and it is necessary to
operate the parking brake while driving.
Operate the parking brake switch while
depressing the brake pedal. Make sure that
the parking brake indicator light and parking
brake lamp turn off.
A
Automatic mode lamp
Parking brake lamp
22
Brake Hold
B
Not for Reproduction
The brake hold system keeps the brake applied when the shift lever is in D, M or N with the system on and the brake pedal has been depressed to stop the vehicle. The system releases the
brake when the accelerator pedal is depressed with the shift lever in D or M to allow smooth
start off.
Turns the brake hold system on
The brake hold standby indicator (green)
comes on. While the system is holding the brake,
the brake hold operated indicator (yellow)
comes on.
A
23
Multi-information Display
A
BCD
Not for Reproduction
The multi-information display presents the driver with a variety of vehicle data.
Display
Selecting a menu icon displays a variety of vehicle
data or allows vehicle settings to be customized.
Changing the meter display
Select an item/change pages
Enter/set
Return to the previous screen
Press:
Displays the screen registered to
When no screen has been registered, the
drive information screen will be displayed.
Press and hold:
Registers the currently displayed screen to
The registration confirmation screen is displayed. If the selected screen cannot be registered, a registration failure message will be
shown.
24
Menu icons
Not for Reproduction
Drive information
Select to display various drive data.
Navigation system-linked display
Select to display the following navigation system-linked information.
• Route guidance
• Compass display (heading-up display)
Audio system-linked display
Select to enable selection of an audio source or track on the display using the meter
control switches.
Driving assist system information
Select to display the following system information, when the system is used.
• Dynamic radar cruise control with full-speed range (if equipped) (P. 36)
• LDA (Lane Departure Alert with steering control) (if equipped) (P. 35)
Stop & Start system information
Able to display the operation status of the Stop & Start system.
Warning message display
Select to display warning messages and measures to be taken if a malfunction is
detected.
Settings display
Select to change the meter display settings
If a problem is detected in any of the vehicle’s systems, a warning message is shown on the multiinformation display.
25
Headlights
Not for Reproduction
Turning on the headlights
Turning on the high beam headlights
1 The front position, tail, license plate,
instrument panel and switch lights turn on.
2 The headlights and all lights listed
above turn on.
3 The headlights, daytime running
lights and all the lights listed above turn on
and off automatically.
4 The daytime running lights turn on.
1 With the headlights on, push the lever away
from you to turn on the high beams.
Pull the lever toward you to the center position to turn the high beams off.
2 Pull the lever toward you and release it to
flash the high beams once.
You can flash the high beams with the headlights on or off.
26
AHS (Adaptive High-beam System) (if equipped)
Not for Reproduction
The Adaptive High-beam System uses a camera sensor located behind the upper portion of the
windshield to assess the brightness of the lights of vehicles ahead, streetlights, etc., and automatically controls the headlight light distribution as necessary.
Activating the Adaptive High-beam System
1 Push the lever away from you with the head-
light switch in the or position.
2 Press the Adaptive High-beam System
switch.
The Adaptive High-beam System indicator
will come on when the system is operating.
27
Turning the high beams on/off manually
Not for Reproduction
■ Switching to the low beams
■ Switching to the high beams
Pull the lever to its original position.
The Adaptive High-beam System indicator will
turn off.
Push the lever away from you to activate the
Adaptive High-beam System again.
Press the Adaptive High-beam System switch.
The Adaptive High-beam System indicator will
turn off and the high beam indicator will turn on.
Press the switch to activate the Adaptive Highbeam System again.
28
Automatic High Beam (if equipped)
Not for Reproduction
The Automatic High Beam uses an in-vehicle camera sensor to assess the brightness of streetlights, the lights of oncoming and preceding vehicles, etc., and automatically turns high beam on
or off as necessary.
Activating the Automatic High Beam system
1 Push the lever away from you with the head-
light switch in or position.
2 Press the Automatic High Beam switch.
The Automatic High Beam indicator will
come on when the headlights are turned on
automatically to indicate that the system is
active.
29
Changing to manual control mode
Not for Reproduction
■ Switching to low beam
■ Switching to high beam
Pull the lever to original position.
The Automatic High Beam indicator will turn off.
Push the lever away from you to activate the Automatic High Beam system again.
Press the Automatic High Beam switch.
The Automatic High Beam indicator will turn off
and the high beam indicator will turn on.
Press the switch to activate the Automatic High
Beam system again.
30
Windshield Wipers and Washer
Not for Reproduction
Operating the wiper lever
1 Off
2 Rain-sensing operation
3 Low speed operation
4 High speed operation
5 Temporary operation
When “AUTO” is selected, the wipers will operate
automatically when the sensor detects falling rain.
The system automatically adjusts wiper timing in
accordance with rain volume and vehicle speed.
The sensor sensitivity can be adjusted when
“AUTO” is selected.
6 Increases the sensitivity
7 Decreases the sensitivity
8 Washer/wiper dual operation
The wipers will automatically operate a couple of times after the washer squirts. Vehicles
with headlight cleaners: When the headlights
are on and the lever is pulled and held, the
headlight cleaners will operate once. After
this, the headlight cleaners will operate every
5th time the lever is pulled.
31
Rear Window Wiper and Washer
Not for Reproduction
Operating the wiper lever
1 Off
2 Intermittent operation
3 Normal operation
4 Washer/wiper dual operation
The wiper will automatically operate a couple
of times after the washer squirts.
32
Stop & Start system
Not for Reproduction
The Stop & Start system stops and restarts the engine according to the brake pedal for stopping
and starting the vehicle.
Stopping the engine
While driving in D or M, depress the brake pedal,
and stop the vehicle.
The engine will stop and the Stop & Start indicator
will come on.
Restarting the engine
Release the brake pedal.
The engine will restart. The Stop & Start indicator will go off.
Disabling the Stop & Start system
Press the Stop & Start cancel switch to disable the Stop & Start system. (P. 8)
33
Lexus Safety System+ (if equipped)
Not for Reproduction
The Lexus Safety System+ consists of the following drive assist systems and contributes to a safe
and comfortable driving experience:
Drive assist systems of Lexus Safety System+
■ PCS (Pre-Collision System)
The pre-collision system uses a radar sensor and camera sensor to detect vehicles and pedestrians in front of your vehicle. When the system determines that the possibility of a frontal collision
with a vehicle or pedestrian is high, a warning operates to urge the driver to take evasive action
and the potential brake pressure is increased to help the driver avoid the collision. If the system
determines that the possibility of a frontal collision with a vehicle or pedestrian is extremely high,
the brakes are automatically applied to help avoid the collision or help reduce the impact of the
collision.
■ LDA (Lane Departure Alert with steering control)
P. 35
■ AHS (Adaptive High-beam System)
P. 27
■ Automatic High Beam
P. 29
■ Dynamic radar cruise control with full-speed range
P. 36
34
LDA (Lane Departure Alert with steering control) (if
Not for Reproduction
equipped)
When driving on highways and freeways with white (yellow) lines, this function alerts the driver
when the vehicle might depart from its lane and provides assistance by operating the steering
wheel to keep the vehicle in its lane.
The LDA system recognizes visible white (yellow) lines with the camera sensor on the upper
portion of the windshield.
Turning LDA system on
Press the LDA switch to turn the LDA system on.
The LDA indicator illuminates and a message is
displayed on the multi-information display.
Press the LDA switch again to turn the LDA system off.
When the LDA system is turned on or off, operation of the LDA system continues in the same condition the next time the engine is started.
35
Dynamic Radar Cruise Control with Full-speed Range (if
ABC
D
E
Not for Reproduction
equipped)
In vehicle-to-vehicle distance control mode, the vehicle automatically accelerates, decelerates
and stops to match the speed changes of the preceding vehicle even if the accelerator pedal is
not depressed. In constant speed control mode, the vehicle runs at a fixed speed.
Use the dynamic radar cruise control with full-speed range on freeways and highways.
System Components
Display
Set speed
Indicators
Vehicle-to-vehicle distance switch
Cruise control switch
36
Setting the vehicle speed (vehicle-to-vehicle distance control mode)
Not for Reproduction
1 Press the “ON/OFF” button to activate the
cruise control.
Radar cruise control indicator will come on
and a message will be displayed on the multiinformation display.
Press the button again to deactivate the
cruise control.
If the “ON/OFF” button is pressed and held
for 1.5 seconds or more, the system turns on
in constant speed control mode. (P. 40)
2
Accelerate or decelerate, with accelerator
pedal operation, to the desired vehicle speed
(at or above approximately 50 km/h [30 mph])
and push the lever down to set the speed.
Cruise control “SET” indicator will come on.
The vehicle speed at the moment the lever is
released becomes the set speed.
If the lever is operated while the vehicle
speed is below approximately 50 km/h
(30 mph) and a preceding vehicle is present,
the set speed will be adjusted to approximately 50 km/h (30 mph).
37
Adjusting the set speed
A
Not for Reproduction
1 Increases the speed
(Except when the vehicle has been stopped
by system control in vehicle-to-vehicle distance control mode)
2 Decreases the speed
Fine adjustment: Momentarily move the lever in
the desired direction.
Large adjustment: Hold the lever up or down to
change the speed, and release when the desired
speed is reached.
Changing the vehicle-to-vehicle distance (vehicle-to-vehicle distance control mode)
Pressing the switch changes the vehicle-to-vehicle distance as follows:
1 Long
2 Medium
3 Short
The vehicle-to-vehicle distance is set automatically to long mode when the engine switch is
turned to IGNITION ON mode.
If a vehicle is running ahead of you, the preceding
vehicle mark will also be displayed.
38
Resuming follow-up cruising when the vehicle has been stopped by system
Not for Reproduction
control (vehicle- to-vehicle distance control mode)
After the vehicle ahead of you starts off, push the
lever up. Your vehicle will also resume follow-up
cruising if the accelerator pedal is depressed after
the vehicle ahead of you starts off.
Canceling and resuming the speed control
1 Pulling the lever toward you cancels the
speed control.
The speed control is also canceled when the
brake pedal is depressed.
(When the vehicle has been stopped by system control, depressing the brake pedal does
not cancel the setting.)
2 Pushing the lever up resumes the cruise con-
trol and returns vehicle speed to the set
speed.
However, when a vehicle ahead is not
detected, cruise control does not resume
when the vehicle speed is approximately
40 km/h (25 mph) or less.
39
Selecting constant speed control mode
Not for Reproduction
1 With the cruise control off, press and hold the
2 Accelerate or decelerate, with accelerator
“ON/OFF” button for 1.5 seconds or more.
Immediately after the “ON/OFF” button is
pressed, the radar cruise control indicator
will come on. Afterwards, it switches to the
cruise control indicator.
Switching to constant speed control mode is
only possible when operating the switch with
the cruise control off.
pedal operation, to the desired vehicle speed
(at or above approximately 40 km/h
[25 mph]) and push the lever down to set the
speed.
Cruise control “SET” indicator will come on.
The vehicle speed at the moment the lever is
released becomes the set speed.
40
Cruise Control (if equipped)
Not for Reproduction
Use the cruise control to maintain a set speed without operating the accelerator pedal.
Use the cruise control on freeways and highways.
System components
Indicators
A
Cruise control switch
B
Setting the vehicle speed
1 Press the “ON/OFF” button to activate the
cruise control.
Cruise control indicator will come on.
Press the button again to deactivate the
cruise control.
2 Accelerate or decelerate, with accelerator
pedal operation, to the desired vehicle speed
(above approximately 40 km/h [25 mph])
and push the lever down to set the speed.
Cruise control “SET” indicator will come on.
The vehicle speed at the moment the lever is
released becomes the set speed.
41
Adjusting the set speed
Not for Reproduction
1 Increases the speed
2 Decreases the speed
Fine adjustment: Momentarily move the lever in
the desired direction.
Large adjustment: Hold the lever in the desired
direction.
Canceling and resuming the constant speed control
1 Pulling the lever toward you cancels the con-
stant speed control.
The speed setting is also canceled when the
brake pedal is depressed.
2 Pushing the lever up resumes the constant
speed control.
However, resuming is available when the
vehicle speed is more than approximately
40 km/h (25 mph).
42
Lexus Parking Assist-sensor (if equipped)
Not for Reproduction
The distance from your vehicle to nearby obstacles when parallel parking or maneuvering into a
garage is measured by the sensors and communicated via the displays and a buzzer. Always
check the surrounding area when using this system.
Turning Lexus parking assist-sensor on/off
1 Press or of meter control switches
and select .
2 Press or of meter control switches
and select “PKSA”.
3 Press or of meter control switches,
select , and then press to select the
desired setting (on/off).
When ON (enable) is selected, the Lexus
parking assist-sensor indicator comes on.
43
Panoramic View Monitor (if equipped)
Not for Reproduction
Panoramic view monitor assists the driver in viewing the surroundings, when operating at low
speeds, by combining the front, side and rear cameras and displaying a complete vehicle overhead image on the screen.
Camera switch
The camera switch is located as shown in the illustration.
How to switch the display
When you press the camera switch or shift the shift lever to the “R” position while the engine
switch is in IGNITION ON mode, the panoramic view monitor operates. (The following is an
example)
When the shift lever is in the “P” position
44
When the shift lever is in the “D” or “N” position
Not for Reproduction
45
When the shift lever is in the “R” position
A
BCD
EFG
H
I
J
K
Not for Reproduction
Map screen, audio screen, etc.
Moving view
See-through view
Side Clearance View & panoramic view
Cornering View & panoramic view
Wide front view & panoramic view
Rear view & panoramic view
Wide rear view & panoramic view
Pressing the camera switch
Selecting the display mode switching button
When the steering wheel is turned by 180° or more from the center (straight-line) position
46
Driving Mode Select Switch
Not for Reproduction
The driving modes can be selected to suit driving conditions.
Vehicles without Adaptive Variable Suspension system
1 Normal
For normal driving.
Press the switch to change the driving mode
to Normal mode when selected to Eco mode
or Sport mode.
2 Eco mode
In contrast to Normal mode when stepping
on the accelerator pedal, torque generation
becomes slower, air conditioning operations
(heating/cooling) are restrained, and driving
is suited for improved fuel consumption.
When not in Eco mode and the driving mode
select switch is turned to the left, “Eco” indicator will be shown on the multi-information
display.
3 Sport mode
Assists acceleration response by controlling the engine, transmission and steering. Suitable
for when precise handling is desirable, for example when driving on mountain roads.
When not in Sport mode and the driving mode select switch is turned to the right, “Sport”
indicator will be shown on the multi-information display.
47
Vehicles with Adaptive Variable Suspension system
Not for Reproduction
1 Normal/Custom mode
Press the switch and select Normal mode or
Custom mode. Each time the switch is
pressed, the system changes between Normal mode and Custom mode.
When Custom mode is selected, the “Custom” indicator comes on.
When in Eco mode or Sport mode, when the
switch is pressed, the system returns to Normal mode. Press the switch to change the
driving mode to Normal mode when
selected to Eco mode or Sport mode.
Custom mode can be setup on the navigation
system screen.
•Normal mode
Suitable when driving in the city, for good
fuel consumption efficiency, silence, and
drive-ability.
• Custom mode
Driving is possible by setting the desired function for power train control, chassis control or
air conditioning operations.
2 Eco mode
In contrast to Normal mode when stepping on the accelerator pedal, torque generation
becomes slower, air conditioning operations (heating/cooling) are restrained, and driving is
suited for improved fuel consumption.
When not in Eco mode and the driving mode select switch is turned to the left, “Eco” indicator
will be shown on the multi-information display.
3 Sport mode
•Sport S mode
Assists acceleration response by controlling the engine and transmission. Suitable for when
powerful acceleration is desirable.
When not in Sport S mode and the driving mode select switch is turned to the right, “Sport
S” indicator will be shown on the multi-information display.
•Sport S+ mode
Helps to ensure superior vehicle stability by simultaneously controlling the steering and suspension in addition to the engine and transmission. Suitable for sporty driving.
When in Sport S mode and the driving mode select switch is turned to the right, “Sport S+”
indicator will be shown on the multi-information display.
48
BSM (Blind Spot Monitor) (if equipped)
C
D
Not for Reproduction
The Blind Spot Monitor is a system that has two functions;
● The Blind Spot Monitor function
Assists the driver in making the decision when changing lanes
● The Rear Cross Traffic Alert function
Assists the driver when backing up
These functions use the same sensors.
BSM main switch
A
Pressing the switch turns the system on or off.
When the switch is set to on, the switch’s indicator illuminates and the buzzer sounds. This
switch is for both Blind Spot Monitor function
and Rear Cross Traffic Alert function.
BSM outside rear view mirror indicators
B
Blind Spot Monitor function:
When a vehicle is detected in a blind spot of
the outside rear view mirrors or approaching
rapidly from behind into a blind spot, the outside rear view mirror indicator on the
detected side will illuminate. If the turn signal
lever is operated toward the detected side,
the outside rear view mirror indicator will
flash.
Rear Cross Traffic Alert function:
When a vehicle approaching from the right
or left at the rear of the vehicle is detected,
both outside rear view mirror indicators will
flash.
Rear Cross Traffic Alert buzzer (Rear Cross Traffic Alert function only)
When a vehicle approaching from the right or left rear of the vehicle is detected, a buzzer
sounds from behind the right-hand rear seat.
Navigation system screen (Rear Cross Traffic Alert function only)
If a vehicle approaching from the right or left at the rear of the vehicle is detected, the Rear
Cross Traffic Alert icon for the detected side will be displayed.
49
Tire Pressure Warning System
Not for Reproduction
Your vehicle is equipped with a tire pressure warning system that uses tire pressure warning
valves and transmitters to detect low tire inflation pressure before serious problems arise.
Initializing the tire pressure warning system
1 Turn the engine switch to IGNITION ON mode.
2 Press or of the meter control
switches and select .
3 Press or of the meter control switches, select the “Vehicle Settings” and then press
.
4 Press or of the meter control switches, select the “TPMS” and then press and hold
the .
The “Tire Pressure Recalibrating. Please Wait Until Complete” will be displayed on the multi-
information display and the tire pressure warning light will blink slowly 3 times.
When the message disappears, initialization is complete.
50
ASC (Active Sound Control) (if equipped)
Not for Reproduction
The ASC system is an electronic sound system that generates engine sound, conveying the
kinetic situations of the vehicle’s acceleration and deceleration to the driver through the speakers inside the instrument panel.
The vehicle’s response to the driver’s acceleration behavior and shift operations are also conveyed in sound.
When Sport mode is selected, the sound conveyed to the driver will be louder.
Controlling volume
1 Louder
2 Lower
The indicator comes on when the ASC system is on.
When the dial is turned to the lowest volume,
the ASC system will be turned off and the
indicator will go off.
51
Remote Touch
A
B
C
D
E
Not for Reproduction
The Remote Touch can be used to operate the navigation system display.
Remote Touch is the name for the device that includes the “MAP” button, “MENU” button, back
button, touchpad and sub function button.
Names and operations of each part
“MAP” button
Press this button to display the vehicle’s current position.
“MENU” button
Press this button to display the menu screen.
Back button
Press this button to display the previous
screen.
Touchpad
Slide your finger on the touchpad and move the pointer to select a function, letter and screen
button.
Press the touchpad to enter the selected function, letter or screen button. Certain finger
movements on the touchpad can perform functions, such as changing map scalings and
scrolling list screens.
Sub function button
When is displayed on the screen, a function screen assigned to the screen can be displayed.
Menu screen
Press the “MENU” button on the Remote Touch to display the menu screen.
52
Switch Function
Not for Reproduction
Select to display the “Destination” screen.*
Select to display the radio control screen.*
Select to display the media control screen.*
Select to display the hands-free control screen. (P. 61)
Select to display the “Apps” screen.*
Select to display the information screen.* (P. 56)
Select to display the “Setup” screen.*
Select to display the air conditioning control screen. (P. 65)
*: Refer to the “Navigation System Owner’s Manual”.
53
Split-screen display
Not for Reproduction
Different information can be displayed on the left and right of the screen. For example, air conditioning system screen can be displayed and operated while the fuel consumption information
screen is being displayed. The large screen on the left of the display is called the main display, and
the small screen to the right is called the side display.
54
Side display
B
Not for Reproduction
The following functions can be displayed and
operated on the side display.
A
C
D
E
: Refer to the “Navigation System Owner’s Manual”.
*
Navigation system
Audio*
Vehicle information (P. 57)
Air conditioning system (P. 67)
Show/hide the side display
*
Screen scroll operation
Select the desired point on the map screen.
Move the desired point on the center of the map
screen.
Cursor mark
A
Distance from the current position to the cur-
B
sor mark
Press the “MAP” button on the Remote Touch to return to the current position.
*
55
Fuel Consumption Screen
ABC
DEF
A
B
CDE
Not for Reproduction
Fuel consumption information can be displayed on the navigation system display.
The fuel consumption information can be displayed and operated on the side display. For details,
refer to the “Owner’s Manual”.
Fuel consumption
■ Trip information
Press the “MENU” button on the Remote Touch, then select on the screen.
If a screen other than “Trip information” is displayed, select “Trip information”.
Resetting the consumption data
Fuel consumption in the past 15 minutes
Current fuel consumption
Average vehicle speed since the engine was
started.
Elapsed time since the engine was started.
Cruising range
■ History
Press the “MENU” button on the Remote Touch, then select on the screen.
If a screen other than “History” is displayed, select “History”.
Best recorded fuel consumption
Latest fuel consumption
Previous fuel consumption record
Resetting the history data
Updating the latest fuel consumption data
56
Side display
Not for Reproduction
Vehicle information can be displayed on the side display.
Select or to display the desired screen.
● Trip information (type A/type B)
● History
57
Hands-free System For Cellular Phone
Not for Reproduction
Registering/connecting Bluetooth® device
To use the hands-free system, it is necessary to register a Bluetooth® phone with the system.
Please refer to the cellular phone manufacturer’s user guide for pairing procedures.
1 Turn the Bluetooth
2 Press the “MENU” button on the Remote Touch.
Please refer to P. 52 for the Remote Touch operation.
3 Select “Phone”.
Operations up to this point can also be performed by pressing the switch on the steering
wheel.
4 Select “Yes” to register a phone.
®
connection setting of your cellular phone on.
5 Select the desired Bluetooth
If the desired Bluetooth
list, select “If you cannot find...” and follow the
guidance on the screen.
6 Register the Bluetooth
Bluetooth
®
device.
®
device.
®
phone is not on the
®
device using your
7 Check that this screen is displayed, indicating
pairing was successful.
8 Check that “Connected” is displayed and
registration is complete.
58
Contacts transfer
Not for Reproduction
1 Press the “MENU” button on the Remote Touch.
Please refer to P. 52 for the Remote Touch operation.
2 Select “Setup”.
3 Select “Phone” on the sub menu.
4 Select “Contacts/Call history”.
5 Select “Transfer contacts from device”.
6 Select “From phone (Bluetooth)”.
7 Transfer the contact data to the system using a Bluetooth
8 Check that a confirmation screen is displayed when the operation is complete.
.
®
phone.
Contacts transfer may not be possible depending on the type of phone.
59
Registering the contacts in the favorites list
Not for Reproduction
1 Press the “MENU” button on the Remote Touch.
Please refer to P. 52 for the Remote Touch operation.
2 Select “Setup”.
3 Select “Phone” on the sub menu.
4 Select “Contacts/Call history”.
5 Select “Add favourite”.
6 Select the desired contact to add to the favorites list.
7 Check that a confirmation screen is displayed when the operation is complete.
60
Calling by favorites list
Not for Reproduction
1 Press the “MENU” button on the Remote Touch.
Please refer to P. 52 for the Remote Touch operation.
2 Select “Phone”.
3 Select “Favourites” on the sub menu and select the desired contact.
4 Select the desired number.
5 Check that the call screen is displayed.
Calling the message sender
1 Select or press the switch on the steering wheel.
2 Check that the call screen is displayed.
Receiving a call
Select “Answer” or press the switch on the steering wheel to talk on the phone.
Main display Side display
● To refuse to receive the call, select “Decline”.
61
Steering switches
A
B
C
D
Not for Reproduction
Volume control switch
Press to adjust the volume.
Off hook switch
Press to start talking.
On hook switch
Press to end talking/dialing.
Talk switch
Press to start the speech command system.
• Speech command list
62
Air Conditioning System
A
BCD
EFG
H
I
J
K
Not for Reproduction
Press the “MENU” button on the Remote Touch, then select to display the air conditioning
control screen.
Control panel
Left-hand side temperature control switch
Airflow mode control switch
Fan speed control switch
Right-hand side temperature control switch
“DUAL” switch
“A/C” switch
Outside/recirculated air mode switch
Windshield defogger switch
Rear windshield and outside rear view mirror defogger switch
Off switch
Automatic mode switch
63
■ Adjusting the temperature setting
A
BCD
Not for Reproduction
Operate the temperature control switch upwards to increase the temperature and downwards
to decrease the temperature.
If “A/C” switch is not pressed, the system will blow ambient temperature air or heated air.
■ Adjusting the fan speed setting
Operate the fan speed control switch upwards to increase the fan speed and downwards to
decrease the fan speed.
Press the off switch to turn the fan off.
■ Change the airflow mode
Operate the airflow mode control switch upwards or downwards.
The mode changes as follows each time the switch is operated.
Air flows to the upper body.
Air flows to the upper body and feet.
Air flows to the feet.
Air flows to the feet and the windshield
defogger operates.
64
Air conditioning control screen
E
BCD
E
F
Not for Reproduction
■ Main control screen
Using the touchpad of the Remote Touch, select the button on the screen.
to can be adjusted by performing the following operations.
B
Flick operation: Move the pointer to the desired item and flick the touchpad up or down.
The item can be adjusted by one level.
Trace operation: After selecting the desired item, slide your finger up or down.
The item can be adjusted by the amount that you trace.
Trace operation cannot be used while driving.
Sub menu
A
Selecting the sub menu item to switch the
main screen.
: Display the air conditioning control
screen
: Display the option control screen
Adjust the left-hand side temperature setting
Adjust the fan speed setting
Select the air flow mode
: Air flows to the upper body
: Air flows to the upper body and feet
: Air flows to the feet
: Air flows to the feet and the windshield defogger operates
Adjust the right-hand side temperature setting
Function on/off indicators
When the function is on, the indicator illuminates on the control screen.
65
Sub function menu
G
A
B
C
D
E
Not for Reproduction
When the button on the Remote Touch is pressed, the following functions can be
switched on and off.
“AUTO”: Set automatic mode on/off (P. 67)
“Off”: Turn the fan off
“A/C”: Set cooling and dehumidification function
“DUAL”: Adjust the temperature for driver and passenger seats separately (“DUAL” mode)
: Set eco air conditioning mode
■ Option control screen
Select on the sub menu to display the option control screen.
The functions can be switched on and off.
When the function is on, the indicator illuminates on the screen.
Adjusting the temperature for driver and passenger seats separately (“DUAL” mode)
Set eco air conditioning mode
Air conditioning and heater output is limited
to prioritize fuel economy.
Cooling and dehumidification function
Select S-FLOW mode
Removing pollen from the air (Pollen removal mode)
66
■ Side display
E
F
Not for Reproduction
Adjust the left-hand side temperature setting
A
Adjust the fan speed setting
B
Adjust the right-hand side temperature set-
C
ting
Set cooling and dehumidification function
D
on/off
Adjust the temperature for the driver’s and front passenger’s seats separately (“DUAL” mode)
Select the air flow mode
Using automatic mode
1 Press the “AUTO” button.
2 Adjust the temperature setting.
3 To stop the operation, press the “OFF” button.
67
Seat Heaters (if equipped)/Seat Ventilators (if equipped)
A
A
Not for Reproduction
Seat heaters
■ Front
Vehicles without seat ventilators
Each time the switch is pressed, the operation
condition changes as follows.
Hi (3 segments lit) Mid (2 segments lit) Lo
(1 segment lit) Off
Vehicles with seat ventilators
■ Rear
The level indicator (amber) light up during
operation.
Each time the switch is pressed, the operation
condition changes as follows.
Hi (3 segments lit) Mid (2 segments lit) Lo
(1 segment lit) Off
The indicator (amber) and level indicator (green)
light up during operation.
Each time the switch is pressed, the operation
condition changes as follows.
Hi (3 segments lit) Mid (2 segments lit) Lo
(1 segment lit) Off
The level indicator (amber) lights up during
operation.
A
68
Seat ventilators (front)
A
Not for Reproduction
Each time the switch is pressed, the operation
condition changes as follows.
Hi (3 segments lit) Mid (2 segments lit) Lo
(1 segment lit) Off
The indicator (green) and level indicator (green)
light up during operation.
69
Door Locks
Not for Reproduction
The vehicle can be locked and unlocked using the entry function, wireless remote control or
door lock switch.
For details about the entry function or wireless remote control, refer to P. 12, 13.
Unlocking and locking the doors from the inside
■ Door lock switch
Locks all the doors
1
2 Unlocks all the doors
■ Inside lock buttons
Locks the door
1
2 Unlocks the door
The driver’s door can be opened by pulling the
inside handle even if the lock button is in the lock
position.
■ Rear door child-protector lock
The door cannot be opened from inside the vehicle when the lock is set.
1 Unlock
2 Lock
These locks can be set to prevent children from
opening the rear doors. Push down on each rear
door switch to lock both rear doors.
70
Power Windows
Not for Reproduction
Opening and closing the power windows
1 Closing
2 One-touch closing*
3 Opening
4 One-touch opening*
: To stop the window partway, operate the
*
switch in the opposite direction.
To prevent accidental operation (window lock switch)
This function is designed to prevent children from accidentally opening or closing a passenger
window.
Press the switch down to lock the passenger window.
71
Moon Roof (if equipped)
Not for Reproduction
Opening and closing
Tilting up and down
1 Open
Press and hold the “OPEN” switch. The
moon roof tilts up and then fully opens auto-
matically.
2 Close
Press and hold the “CLOSE” switch. The
moon roof fully closes automatically.
*
1 Tilt up
Press and hold the “UP” switch. It automatically opens until the tilt up stop position.
2 Tilt down
Press and hold the “DOWN” switch. The
moon roof full close automatically.
*
: Lightly press either end of the moon roof
open/close switch to stop the moon roof
while it is operating.
*
*
*
*
: Lightly press either end of the moon roof
switch to stop the moon roof while it is
operating.
72
Fuel Tank Cap
Not for Reproduction
Before refueling the vehicle
● Turn the engine switch off and ensure that all the doors and windows are closed.
● Confirm the type of fuel.
Opening the fuel tank cap
1 With the all doors unlocked, press the center
of the rear edge of the fuel filler door.
Push inward and take your hand away to
slightly open the fuel filler door. Then open
the door fully by hand.
2 Turn the fuel tank cap slowly to open it and
put it into the holder on the fuel filler door.
73
Back Door
Not for Reproduction
Back door opener switch
Power back door switch
Instrument panel
Vehicles without power back door
Raise the back door while pressing up the back
door opener switch.
Vehicles with power back door
When the back door is unlocked: Press the back
door opener switch.
When the back door is locked: While carrying the
electronic key on your person, press the back
door opener switch.
To open or close the back door, press the for
1 second.
Power back door
To close the back door, press the .
74
Wireless remote control
Not for Reproduction
P. 12
Kick sensor (vehicles with hands free power back door)
The power back door enables automatic opening and closing of the power back door by putting
your foot near the lower center part of the rear bumper and then moving it away.
1 While carrying an electronic key, put your
foot within 100 mm (3.94 in.) of the lower
center part of the rear bumper, where the
kick sensor is located, and move it away.
When all of the doors are locked: When the
movement is detected by the kick sensor, all
of the doors will be unlocked.
2 The buzzer sounds and the power back door begins to operate.
The buzzer sounds and the power back door automatically opens or closes.
To stop the power back door partway or operate it again, use either the kick sensor, the wireless remote control, or power back door switch.
Back door closer (vehicles with power back door)
A
In the event that the back door is left slightly open, the back door closer will automatically close it
to the fully closed position.
75
76
Not for Reproduction
What to do if...
Not for Reproduction
List of Warning/Indicator Lights
Immediately stop the vehicle in a safe place and contact your Lexus dealer. Continuing to
drive the vehicle may be dangerous.
Brake system warning light
(Red)
Charging system warning light
Have the vehicle inspected by your Lexus dealer immediately.
Brake system warning light PCS warning light (if equipped)
(Yellow)
Malfunction indicator lamp Slip indicator light
Low engine oil pressure warning
light
High coolant temperature warning light
(Yellow)
(Red)
SRS warning light
(Flashes)
ABS warning light
(Blinking and
then continu-
Electric power steering system
warning light
For further information, refer to the “Owner’s Manual”.
ously on)
Brake hold operated indicator
Tire pressure warning light
77
What to do if...
Not for Reproduction
Follow the correction procedures.
LDA indicator (if equipped)
(Orange)
Parking brake indicator Master warning light
(Flashes)
Rear passengers’ seat belt
reminder light
Low fuel level warning light
Driver’s and front passenger’s
seat belt reminder light
For further information, refer to the “Owner’s Manual”.
(Illuminates
without
blinking)
Tire pressure warning light*
Brake Override System/
Drive-Start Control warning
light
78
What to do if...
Not for Reproduction
See the “Owner’s Manual”.
(White or
green)
Turn signal indicator
(Flashes)
Tail light indicator VSC off indicator
Headlight high beam indicator PCS warning light (if equipped)
Automatic High Beam indicator/Adaptive High-beam Syst em
indicator (if equipped)
Front fog light indicator
(if equipped)
Rear fog light indicator Parking brake indicator
Eco Driving Indicator Light Brake hold standby indicator
Dynamic radar cruise control
indicator (if equipped)
Cruise control “SET” indicator
Cruise control indicator
LDA indicator (if equipped)
Slip indicator light
Stop & Start indicator
Stop & Start cancel indicator
Brake hold operated
indicator
All-wheel drive lock indicator
(AWD models only)
Low outside temperature
indicator
BSM outside rear view mirror
indicators (if equipped)
(Flashes in
orange)
79
LDA indicator (if equipped) Security indicator
Lexus parking assist-sensor
indicator (if equipped)
For further information, refer to the “Owner’s Manual”.
What to do if...
Not for Reproduction
See the “Owner’s Manual”.
● Drive mode indicators
“Eco” indicator
“Sport” indicator
(if equipped)
“Sport S” indicator
(if equipped)
For further information, refer to the “Owner’s Manual”.
“Sport S+” indicator
(if equipped)
“Custom” indicator
(if equipped)
*: It also comes on due to natural causes such as natural air leaks and tire inflation pressure
changes caused by temperature. Adjust the tire inflation pressure to the specified level. The
light will turn off after a few minutes. In case the light does not turn off even if the tire inflation
pressure is adjusted, have the system checked by your Lexus dealer.
80
What to do if...
Not for Reproduction
If the electronic key does not operate properly
Locking and unlocking the door
■ Unlocking the door
Insert the mechanical key while pulling on the
1
driver’s door handle.
2 Turn the key in order to perform the following
operations.
Unlocking the door
A
Opens the windows and moon roof
B
(turn and hold)
Closes the windows and moon roof
C
(turn and hold)
*
*
*: These settings must be customized at your
Lexus dealer
3 Remove the key, return the handle, and then pull the handle again.
■ Locking the door
Move the inside lock button to the lock posi-
1
tion.
2 Close the door while pulling the door handle.
81
What to do if...
Not for Reproduction
Starting the engine
1 Ensure that the shift lever is in P and depress
the brake pedal.
2 Touch the Lexus emblem side of the elec-
tronic key to the engine switch.
When the electronic key is detected, a
buzzer sounds and the engine switch will turn
to IGNITION ON mode.
When the smart entry & start system is deactivated in customization setting, the engine
switch will turn to ACCESSORY mode.
3 Firmly depress the brake pedal and check
that message is shown on the multi-information display.
4 Press the engine switch.
In the event that the engine still cannot be operated, contact your Lexus dealer.
.
If the electronic key battery becomes depleted, a warning message will be shown on the multiinformation display. Replace the battery with a new one. For instructions on replacing the battery,
refer to the “Owner’s Manual”.
If you need further assistance, contact your Lexus dealer.
82
What to do if...
Brake pedal
Not for Reproduction
If the engine will not start
Make sure that the correct operating procedures have been followed.
Make sure that the brake pedal is firmly
depressed when attempting to start the engine.
(P. 14)
If the engine still does not start, see the “Owner’s Manual” for more information or contact your
Lexus dealer.
83
Memo
Not for Reproduction
84
Memo
Not for Reproduction
85
©2018 TOYOTA MOTOR CORPORATION
All rights reserved. This material may not be reproduced or copied, in whole or in part,
without the written permission of Toyota Motor Corporation.
Not for Reproduction
86
Not for Reproduction
Loading...
