Owner’s Manual
NX350 / NX250
© 2021 TOYOTA MOTOR CORPORATION
All rights reserved. This material may not be reproduced or copied, in whole or in part,
without the written permission of Toyota Motor Corporation.
Before driving
Important points to know before driving the vehicle
1
Driving the vehicle
Driving according
to the conditions
Interior features
Vehicle status information
and indicators
Driving support
system
Wireless
communication
Maintenance and
care
When trouble
arises
Basic operations for when driving the vehicle
Using the air conditioning system and interior convenience
features
Using the air conditioning system and interior convenience
features
Reading driving-related information
Safe driving support function and SRS airbag settings
Wireless communication services which support safety, comfort and convenience
Caring for your vehicle and maintenance procedures
What to do in case of malfunction and emergency
2
3
4
5
6
7
8
9
Vehicle
specifications
Index
Vehicle specifications, customizable features
Search alphabetically
10
TABLE OF CONTENTS
For your information
For your information............................8
Pictorial index........................................ 12
1
Before driving
1-1. Using the dedicated floor mats
Using the dedicated floor
mats correctly................................... 22
1-2. Preparations for safe driving with
children in the vehicle
Riding with children.......................... 24
Selecting an appropriate child
restraint system................................27
Installing a child restraint sys-
tem...........................................................34
Installing a child restraint sys-
tem to the front passenger's
seat...........................................................39
1-3. Entering/exiting the vehicle and
loading luggage
Key types.................................................. 41
Smart entry & start system........... 45
Opening/closing the doors......... 50
Locking/unlocking the doors......54
Theft deterrent system.................... 59
Loading the vehicle with lug-
gage ........................................................64
Trailer towing (vehicles with
towing package)..............................86
Trailer towing (vehicles with-
out towing package).....................93
Opening and closing the win-
dows........................................................ 94
1-4. Obtaining the correct driving pos-
ture
Adjusting the seats............................98
Adjusting the rear seats.............. 102
Using the seat belts........................ 103
Adjusting the position of the
steering wheel and mirrors.... 107
2
Driving the vehicle
2-1. Starting and stopping the engine
Starting the engine......................... 120
Stopping the engine .......................124
Stop & Start system ....................... 125
2-2. Driving procedures
Driving procedure.......................... 133
Breaking in your new Lexus..... 136
Intended use of each shift po-
sition..................................................... 137
Changing the shift position....... 139
Starting off ........................................... 145
Operations when turning left
or right or changing lanes....... 146
Changing the shift range.............147
Changing the gear step ..............149
2-3. Parking the vehicle
When parking the vehicle............151
Stopping................................................ 153
Parking the vehicle......................... 155
2-4. Refueling
Refueling............................................... 159
Driving according to the con-
3
ditions
2
TABLE OF CONTENTS
3-1. Driving when the surrounding
area is dark
Using the headlights.......................162
Automatically changing be-
tween the low beam headlights and high beam head-
lights..................................................... 165
3-2. Driving when the sun or head-
lights of other vehicles are
bright
Using the sun visors....................... 173
Inside rear view mirror anti-
glare function (vehicles with
auto anti-glare inside rear
view mirror)...................................... 174
Digital Rearview Mirror anti-
glare function (optical mirror
mode)...................................................175
3-3. Driving in the rain
Precautions for driving in the
rain .........................................................176
Ensuring visibility in the rain...... 177
3-4. Driving when the windows or mir-
rors are fogged up
Defog the windshield.................... 182
Defog the rear window................184
Defog the outside rear view
mirrors................................................ 185
3-5. Driving when it is cold
Preparing for cold weather.......186
Cold weather driving tips...........189
3-6. Driving when in the fog or on a
mountain road and visibility is
poor
Fog light illumination...................... 191
Sounding the horn...........................193
3-7. Utility vehicle precautions
Utility vehicle precautions......... 194
3-8. Changing the driving character-
istics
Driving modes....................................197
Changing the driving mode .....199
Trail Mode (AWD vehicles)...... 201
DAC（Downhill assist con-
trol system）.................................203
3-9. Brake hold system
Brake hold system..........................205
4
Interior features
4-1. Favorite settings
My Settings......................................... 210
4-2. Adjusting the preferred driving
position
Enabling easier driver entry
and exit (Power easy access
system) ................................................212
Driving position registration/
recall/deletion................................ 213
4-3. Adjusting the temperature/envi-
ronment inside the vehicle
Comfortable condition to be
maintained without adjusting
each system (Lexus Climate
Concierge)...................................... 217
Air conditioning controls ........... 219
Heated steering wheel ...............228
Seat heaters....................................... 229
Seat ventilators................................. 231
Using the moon roof.................... 232
Using the panoramic moon
roof....................................................... 235
3
TABLE OF CONTENTS
Opening and closing the elec-
tronic sunshade............................ 238
4-4. Illuminating the interior
Using the interior lights ..............240
4-5. Using the interior features
Location of the storage fea-
tures..................................................... 244
Convenient interior features...250
4-6. Using the luggage compartment
Using the cargo hooks..................261
Using the cargo net hooks........262
Using the grocery bag hooks. 263
Deck board........................................ 264
Stowing the luggage cover...... 266
Vehicle status information
5
and indicators
5-1. Functions and displays of the me-
ter
Warning lights and indicators. 270
Gauges and meters (except F
SPORT models) ...........................276
Gauges and meters (F
SPORT models) ...........................281
5-2. Functions of the displays
Multi-information display (ve-
hicles without a head-up dis-
play)..................................................... 286
Multi-information display (ve-
hicles with a head-up dis-
play).....................................................288
Head-up display..............................290
Displayed content.......................... 292
5-3. Changing the settings of the dis-
plays
Changing the instrument pan-
el light brightness........................303
Changing settings for the
head-up display............................304
6
Driving support system
6-1. Features of the safe driving sup-
port functions
Lexus Safety System +.................308
Driving assist systems................... 316
6-2. Using the safe driving support
functions
Pre-Collision System ...................324
Lane Tracing Assist .......................336
Lane Departure Alert................... 341
Assistance in detecting vehi-
cles behind when changing
lanes.................................................... 347
Supporting safe exit by de-
tecting detectable objects at
the rear of the vehicle by
outputting sounds, displaying screens as a warning or
cancelling opening of the
doors................................................... 353
Buzzer and screen notifica-
tions when approaching an
object at low speed....................360
Buzzer and screen notifica-
tions when traveling at a low
speed and an approaching
vehicle is detected at the
rear ......................................................368
Buzzer and screen notifica-
tions when traveling at a low
speed and a pedestrian is
detected at the rear................... 375
4
TABLE OF CONTENTS
Brake operation when an ob-
ject is detected while ap-
proaching at low speed ..........380
Road Sign Assist............................. 393
Dynamic radar cruise control.396
Cruise Control ................................409
Emergency Driving Stop Sys-
tem........................................................ 414
Engine output restriction
when the accelerator pedal
and brake pedal are de-
pressed at the same time ........417
Sudden start restraint control.. 418
6-3. Reducing impact to the occu-
pants in a collision
Reducing impact to passen-
gers in a collision.......................... 419
7
Wireless communication
7-1. Emergency assistance
Lexus Connected Services......430
8
Maintenance and care
8-1. Exterior maintenance and care
Washing the vehicle...................... 436
8-2. Cleaning and protecting the vehi-
cle interior
Cleaning the vehicle interior .. 442
Cleaning the areas with satin-
finish metal accents ...................444
Cleaning the leather areas....... 445
Cleaning the synthetic leather
areas....................................................446
8-3. Maintenance
Maintenance requirements..... 447
Scheduled maintenance out-
line........................................................448
Do-it-yourself maintenance..... 449
8-4. Inspection of consumables
Do-it-yourself service precau-
tions..................................................... 450
Opening the hood......................... 453
Engine compartment................... 454
Adding washer fluid...................... 465
Air conditioning filter mainte-
nance.................................................. 466
8-5. Tire maintenance
Tire maintenance ............................468
Tire inspection items..................... 469
Run-flat tire features.......................471
Operation of the tire pressure
warning system..............................472
Checking tire inflation pres-
sure......................................................484
Lifting the vehicle with a floor
jack.......................................................486
Rotating the tires.............................487
Wheels..................................................488
Replacing the tire...........................490
9
When trouble arises
9-1. What to do if a problem occurs
while driving
What to do if a problem oc-
curs while driving......................... 501
9-2. If a warning light illumi-
nates/flashes or a warning message is displayed on the meter
If a warning light turns on/
flashes ................................................505
5
TABLE OF CONTENTS
If a warning message is dis-
played.................................................. 516
9-3. If the engine will not start
When the engine will not start
even though the starter op-
erates.................................................. 528
When the starter operates
slowly and the engine cannot
be started......................................... 529
When the starter does not op-
erate and the engine cannot
be started.........................................530
When the interior lights or
headlights are dim and the
engine cannot be started....... 532
When the interior lights or
headlights do not illuminate
and the engine cannot be
started................................................538
When the horn sounds at a
low volume and the engine
cannot be started........................ 539
When the horn does not
sound and the engine cannot
be started.........................................540
9-4. If a tire is flat
Precautions for when you
have a flat tire.................................. 541
9-5. If a door cannot be opened or
locked
If a key has been lost..................... 542
When the doors/windows/
moon roof cannot be operated using an electronic key 543
If a door cannot be opened
using the door opener
switch.................................................. 552
If the rear doors cannot be
opened from the inside ...........555
If the back door cannot be
opened ..............................................556
9-6. If the moon roof or electronic
sunshade does not operate correctly
If the moon roof does not op-
erate correctly..............................558
If the panoramic moon roof/
electronic sunshade does
not operate correctly ...............560
9-7. If the rear seats does not operate
correctly
Initialize rear seats (Vehicles
with a power back door)......... 561
9-8. If refueling cannot be performed
If the fuel filler door cannot be
opened ..............................................562
9-9. If an indicator on an interior fea-
ture illuminates or flashes
When the wireless charger
operation indicator light (on
the charging tray) flashes....... 563
9-10. If the vehicle cannot move
When the engine can be start-
ed but the vehicle does not
move................................................... 565
If the transmission makes ab-
normal sounds ..............................566
Towing with a tow truck.............. 567
Using a flatbed truck......................571
Towing with another vehicle.....572
Getting unstuck from mud,
sand, or snow................................. 575
9-11. If you think something is wrong
6
TABLE OF CONTENTS
If a vehicle abnormality is
found....................................................576
If abnormal sounds are emit-
ted from the vehicle................... 577
If the vehicle behaves abnor-
mally.................................................... 578
9-12. Items to check before contacting
a dealership
The steering wheel cannot be
turned after the engine is
stopped............................................. 579
If the windows do not open or
close by operating the pow-
er window switches ...................580
The engine switch is turned off
automatically .................................582
If your vehicle overheats............583
If electrical components can-
not be used or do not operate when a switch is operat-
ed.......................................................... 587
If a light does not illuminate......588
Supplement ..................................................630
Index.................................................................. 634
Certification ................................................645
10
Vehicle specifications
10-1. Specifications
Maintenance data (fuel, oil
level, etc.)......................................... 596
Fuel information.............................. 607
10-2. Customizable features
User customization function
outline ................................................608
Method to change settings......609
Customizable features ................610
10-3. Initialization
Items to initialize ............................. 629
7
For your information
For your information
For your information
Information contained in this Owner’s Manual
Please note that this manual applies to all models and explains all equipment,
including options. Therefore, you may find some explanations for equipment not
installed on your vehicle.
All specifications provided in this manual are current at the time of printing. However, because of the Lexus policy of continual product improvement, we reserve
the right to make changes at any time without notice.
Depending on specifications, the vehicle shown in the illustrations may differ from
your vehicle in terms of color and equipment.
Reading this manual
This section explains symbols used in this manual.
■ Meanings of symbols in the text
The names and meanings of symbols are as follows:
● WARNING
Explains something that, if not obeyed, could cause death or serious injury to
people.
●
NOTICE
Explains something that, if not obeyed, could cause damage to or a malfunction
in the vehicle or its equipment.
● Step number
Indicates operating or working procedures. Follow the steps in numerical order.
●
Info
Explains important points other than functions and operating methods.
8
For your information
■ Meanings of symbols in illustrations
The names and meanings of symbols are as follows:
● Indicates the action (pushing, turning, etc.) used to operate switches
and other devices.
●
● Indicates the component or position being explained.
● Means Do not, Do not do this, or Do not let this happen.
Indicates the outcome of an operation (e.g. a lid opens).
Precautions for safe driving
WARNING
● Driving under the influence: Never drive your vehicle when under the influence of
alcohol or drugs that have impaired your ability to operate your vehicle. Alcohol and
9
For your information
WARNING
certain drugs delay reaction time, impair judgment and reduce coordination, which
could lead to an accident that could result in death or serious injury.
● Driver distraction: Always give your full attention to driving. Anything that distracts the
driver, such as adjusting controls, talking on a cellular phone or reading can result in a
collision with resulting death or serious injury to you, your occupants or others.
● Always observe the legal speed limit when driving on public roads.
● Defensive driving: Always drive defensively. Anticipate mistakes that other drivers or
pedestrians might make and be ready to avoid accidents.
● When driving over long distances, take regular breaks before you start to feel tired.
Also, if you feel tired or sleepy while driving, do not force yourself to continue driving
and take a break immediately.
General precaution regarding children's safety
WARNING
Never leave children unattended in the vehicle, and never allow children to have or use
the key.
Children may be able to start the vehicle or shift the vehicle into neutral.
There is also a danger that children may injure themselves by playing with the windows,
the moon roof, or other features of the vehicle. In addition, heat build-up or extremely
cold temperatures inside the vehicle can be fatal to children.
General precaution regarding a coin battery and button battery
This product contains a coin battery or button battery.
Observe the following precautions. Failure to do so may result in death or serious
injury.
● Keep away new and removed batteries from children.
●
Do not swallow the battery. Doing so may cause chemical burns.
10
For your information
● If a battery is swallowed, it may cause severe chemical burns in as little as 2
hours and may result in death or serious injury.
● If you accidentally swallow a battery or put a battery into a part of your body, get
emergency medical attention immediately.
Usage of data collected through Lexus Connected Services
If your Lexus has Lexus Connected Services and if you have subscribed to those
services, please refer to the Lexus Connected Services usage contract for information on data collected and its usage.
For more information, please visit https://www.lexus.com.au/privacy
11
For your information
Pictorial index
Exterior
INFORMATION
Light bulbs of the exterior lights for driving (Replacing method: → P.591)
A
Side doors ........................................................................................................................ P.50
Locking/unlocking .....................................................................................................................P.54
Opening/closing the side doors.......................................................................................... P.50
Opening/closing the side windows............................................................................. P.94,95
Locking/unlocking by using the mechanical key .......................................................P.546
Warning messages................................................................................................................... P.516
B
Back door ..........................................................................................................................P.65
Opening from inside the cabin.............................................................................................P.65
Opening from outside..............................................................................................................P.65
Warning messages................................................................................................................... P.516
C
Outside rear view mirrors........................................................................................... P.116
Adjusting the mirror angle......................................................................................................P.116
12
For your information
Folding the mirrors.....................................................................................................................P.117
Driving position memory*.....................................................................................................P.213
Defogging the mirrors............................................................................................................P.185
D
Windshield wipers ............................................................................................... P.177,180
Precautions against winter season....................................................................................P.186
Precautions against car wash............................................................................................ P.440
E
Fuel filler door................................................................................................................ P.159
Refueling method.....................................................................................................................P.159
Fuel type/fuel tank capacity ............................................................................................... P.599
F
Tires..................................................................................................................................P.468
Tire size/inflation pressure....................................................................................... P.485,605
Winter tires/tire chain............................................................................................................. P.186
Checking/rotation/tire pressure warning system.......................P.468,469,472,487
Coping with flat tires............................................................................................................... P.541
G
Hood ................................................................................................................................P.453
Opening......................................................................................................................................P.453
Engine oil .........................................................................................................................P.599,600
Coping with overheat........................................................................................................... P.583
Warning messages................................................................................................................... P.516
H
Headlights/front position lights/daytime running lights/turn signal lights.. P.162
I
Cornering lights*.......................................................................................................... P.164
J
Front fog lights*.............................................................................................................. P.191
K
Turn signal lights ............................................................................................................ P.146
L
Stop/tail lights ................................................................................................................P.162
M
Turn signal lights ............................................................................................................ P.146
N
Back-up light
Changing the shift position to R.........................................................................................P.140
O
Stop lights
Emergency brake signal........................................................................................................ P.316
P
Rear fog light................................................................................................................... P.191
Q
License plate lights....................................................................................................... P.162
* :
If equipped
13
For your information
Instrument panel
A
Engine switch .................................................................................................................P.120
Starting the engine/changing the modes ................................................................P.120,121
Emergency stop of the engine............................................................................................P.501
When the engine will not start ...........................................................................................P.528
Warning messages................................................................................................................... P.516
B
Shift lever ........................................................................................................................ P.137
Changing the shift position ..................................................................................................P.139
Precautions against towing.............................................................................. P.567,571,572
C
Meters.....................................................................................................................P.276,281
Reading the meters/adjusting the instrument panel light....................P.276,281,303
Warning lights/indicator lights........................................................................................... P.270
When the warning lights come on ..................................................................................P.505
D
Multi-information display............................................................................... P.286,288
Display ..............................................................................................................................P.286,288
When the warning messages are displayed .................................................................P.516
E
Turn signal lever/Headlight switch..................................................................P.146,162
14
For your information
Headlights/front position lights/tail lights/license plate lights/daytime running
lights............................................................................................................................................... P.162
Front fog lights*/Rear fog light............................................................................................. P.191
F
Windshield wiper and washer switch............................................................. P.177,180
Usage ...................................................................................................................................P.177,180
Adding washer fluid................................................................................................................P.465
Warning messages................................................................................................................... P.516
G
Emergency flasher switch..........................................................................................P.501
H
Hood lock release lever.............................................................................................P.453
I
Tilt and telescopic steering control switch............................................................P.107
Adjustment.................................................................................................................................. P.107
Driving position memory*.....................................................................................................P.213
J
Air conditioning system ..............................................................................................P.219
Usage ...........................................................................................................................................P.220
Rear window defogger ..........................................................................................................P.184
K
Audio system
*1
* :
If equipped
*1 :
Refer to "Multimedia Owner's Manual".
15
For your information
Switches
A
Instrument panel light control switches............................................................... P.303
B
ODO/TRIP switch .....................................................................................................P.280
C
Camera switch
D
Fuel filler door opener switch ...................................................................................P.159
E
Power back door switch*..............................................................................................P.72
F
Driving position memory switches*........................................................................P.213
G
Outside rear view mirror switches........................................................................... P.116
H
Door lock switches.........................................................................................................P.56
I
Power window switches .........................................................................................P.94,95
J
Window lock switch .......................................................................................................P.97
**2
* :
If equipped
*2 :
Refer to "Multimedia Owner's Manual".
16
For your information
A
Paddle shift switches............................................................................................P.147,149
B
Meter control switches..............................................................................................P.292
C
Cruise control switch
Dynamic radar cruise control ............................................................................................P.396
D
Audio remote control switches
E
LTA (Lane Tracing Assist) switch .............................................................................P.336
F
Telephone switch
G
Talk switch
H
Audio remote control switches/telephone switch/talk switch*6..................P.292
I
Switch function change switch ................................................................................P.292
*4
*5
*3
*3 :
Refer to "Multimedia Owner's Manual".
*4 :
Refer to "Multimedia Owner's Manual".
*5 :
Refer to "Multimedia Owner's Manual".
*6 :
Refer to "Multimedia Owner's Manual".
17
For your information
A
Driving mode select switch........................................................................................P.199
B
P position switch............................................................................................................P.140
C
Brake hold switch........................................................................................................ P.205
D
VSC OFF switch ...........................................................................................................P.316
E
Trail Mode switch*........................................................................................................P.201
F
Stop & Start cancel switch .........................................................................................P.129
G
DAC switch*................................................................................................................. P.203
H
Parking brake switch ................................................................................ P.140,155,205
Applying/releasing .............................................................................................. P.140,155,205
Precautions against winter season....................................................................................P.189
Warning buzzer/message..................................................................................................... P.516
18
For your information
Interior
A
SRS airbags .................................................................................................................... P.419
B
Floor mats ........................................................................................................................ P.22
C
Front seats........................................................................................................................ P.98
D
Rear seats........................................................................................................................P.102
E
Head restraints................................................................................................................P.99
F
Seat belts.........................................................................................................................P.103
G
Console box ..................................................................................................................P.248
H
Cup holders...................................................................................................................P.246
I
Assist grips.....................................................................................................................P.259
19
For your information
Ceiling
A
Inside rear view mirror....................................................................... P.107,108,174,175
B
Sun visors*7..................................................................................................................... P.173
C
Vanity mirrors................................................................................................................P.260
D
Auxiliary box .................................................................................................................P.245
E
Moon roof switches*/Panoramic moon roof switches*................................... P.232
F
Interior light/Personal lights .......................................................................... P.242,243
G
[SOS] button*.............................................................................................................. P.430
H
Door-linked interior light switch............................................................................. P.242
*7 :
NEVER use a rearward facing child restraint on a seat protected by an ACTIVE
AIRBAG in front of it, DEATH or SERIOUS INJURY to the CHILD can occur.
* :
If equipped
20
1
Before driving
1
Before driving
1-1. Using the dedicated floor mats
Using the dedicated floor
mats correctly................................ 22
1-2. Preparations for safe driving with
children in the vehicle
Riding with children........................ 24
Selecting an appropriate child
restraint system............................. 27
Installing a child restraint sys-
tem......................................................34
Installing a child restraint sys-
tem to the front passenger's
seat .....................................................39
1-3. Entering/exiting the vehicle and
loading luggage
Key types..............................................41
Smart entry & start system ..........45
Opening/closing the doors.........50
Locking/unlocking the doors .....54
Theft deterrent system..................59
Loading the vehicle with lug-
gage ...................................................64
Trailer towing (vehicles with
towing package)...........................86
Trailer towing (vehicles with-
out towing package) ...................93
Opening and closing the win-
dows...................................................94
1-4. Obtaining the correct driving pos-
ture
Adjusting the seats..........................98
Adjusting the rear seats.............
Using the seat belts ..................... 103
Adjusting the position of the
steering wheel and mirrors ....107
102
21
1-1. Using the dedicated floor mats
Using the dedicated floor mats
Using the dedicated floor mats correctly
Use only floor mats designed specifically for vehicles of the same model and model
year as your vehicle. Fix them securely in place onto the carpet.
WARNING
● When installing a driver's side floor mat, do not use floor mats designed for other
models or different model year vehicles, even if they are Lexus Genuine floor mats.
● Only use floor mats designed for the driver’s seat.
● Do not use two or more floor mats on top of each other.
● Do not place the floor mat bottomside up or upside-down.
Securing the floor mats
WARNING
Check the following before driving.
● Check that the floor mat is securely fixed in the correct place with all the provided
retaining hooks (clips). Be especially careful to perform this check after cleaning the
floor.
● With the engine stopped and the shift position in P, fully depress each pedal to the floor
to make sure it does not interfere with the floor mat.
1 Insert the retaining hooks (clips) into the
floor mat eyelets.
22
1-1. Using the dedicated floor mats
WARNING
Always install the floor mat securely using the retaining hooks (clips) provided.
2 Turn the upper knob of each retaining hook
(clip) to secure the floor mats in place.
Always align the △ marks .
The shape of the retaining hooks (clips) may differ
from that shown in the illustration.
1
Before driving
23
1-2. Preparations for safe driving with children in the vehicle
Preparations for safe driving with children in the vehicle
Riding with children
If a child which is not large enough to correctly wear a seat belt intended for adults
is to ride in the vehicle, use a child restraint system. Child restraint systems are
designed to keep children safe.
To ensure safety, observe the following when children are in the vehicle.
● Make sure that children always wear a seat belt.
If a child is not wearing a seat belt, in a collision, they may collide with a window,
other passenger, or the interior of the vehicle. Also, if a child is riding on the
lap of another passenger, in a collision, they may collide with a window, other
passenger, or the interior of the vehicle.
Seat children in the rear seats.
●
It is recommended that children sit in the rear seats to avoid accidental contact
with the driver's controls.
Do not allow children to operate equipment such as the doors, windows, etc.
●
Do not let children operate equipment such as the doors, power windows, seats,
etc. as a part of their body may become pinched.
To prevent children from opening and closing the doors and power windows, use
the child-protector locks and window lock switch.
● Extreme Hazard! Do not use a rearward facing child restraint on a seat protect-
ed by an airbag in front of it! This is because the force of the rapid inflation of the
front passenger airbag can cause death or serious injury to the child.
There is a label(s) on the passenger side sun visor, indicating it is forbidden to
attach a rear-facing child restraint system to the front passenger seat.
WARNING
● Never leave children unattended in the vehicle, and never allow children to have or
use the key.
24
1-2. Preparations for safe driving with children in the vehicle
WARNING
Children may be able to start the vehicle or shift the vehicle into neutral.
● Do not leave children unattended in the vehicle.
Children may accidentally cause the vehicle to move, leading to an accident, or start a
fire.
● Do not leave people or animals in the vehicle.
The temperature inside the vehicle can become extremely high during the daytime,
possibly leading to heat stroke or death.
● Do not allow children to ride on the lap of a passenger.
If a child is riding on the lap of another passenger, in a collision, they may collide with a
window, another passenger, or the interior of the vehicle. Make sure that children wear
a seat belt or use a child restraint system.
● Use a child restraint system for small children.
If a child which is not large enough to correctly wear a seat belt is to ride in the vehicle,
use a child restraint system.
● Use child restraint systems correctly.
Child restraint systems are designed to protect children in a collision or sudden stop.
Make sure to securely install child restraint systems and use them correctly.
● Replace child restraint systems which have been involved in a collision.
If the vehicle has been involved in a collision, it is possible that an installed child
restraint system has been damaged and will not be able to deliver the same level of
impact absorption performance, even if the outside of it looks normal.
● When a child restraint system is not in use, secure it so that it does not interfere with
driving.
When removing a child restraint system, store it outside of the vehicle or securely in
the luggage compartment.
1
Before driving
Seating positions for children
It is recommended that children sit in the rear seats to avoid accidental contact
with the driver’s controls. In the event of an accident, the force of deployment of the
SRS front passenger airbag can cause death or serious injury to a child seated on
the front passenger’s seat. Do not allow a child to ride on the front passenger’s seat
unless it is unavoidable.
25
1-2. Preparations for safe driving with children in the vehicle
WARNING
● When installing a child restraint system to the front passenger’s seat is unavoidable,
move the seat as far back as possible, and install the child restraint system so that it
faces forward. If the child restraint system is not installed correctly, in the event of an
accident, the force of deployment of the SRS front passenger airbag can cause death
or serious injury.
● Do not allow children to lean against the doors, roof side rails, or pillars. In the event
of an accident, the force of deployment of an SRS airbag can cause death or serious
injury to a child.
● When adjusting the driver’s seat, if it contacts a child or child restraint system, install
the child restraint system to the rear seat behind the front passenger’s seat.
● Adjust the front passenger seat so that it does not interfere with the child or child
restraint system.
● If a child which is over 100 cm tall is to ride in the vehicle, use a junior seat (booster
seat). When using a junior seat (booster seat), make sure that the seat belt is worn
correctly.
Preventing the rear doors from being opened from the inside of the
vehicle (child-protector lock)
The door cannot be opened from inside the vehicle when the lock is set.
1 Unlock
2 Lock
These locks can be set to prevent children from
opening the rear doors. Push down on each
rear door switch to lock both rear doors.
INFORMATION
■ Door opening method when using a child-protector lock
Unlock the door and pull the exterior door handle to open the door. If it is necessary to
open the door from inside the vehicle, open the rear door window and pull the exterior
door handle.
26
1-2. Preparations for safe driving with children in the vehicle
Selecting an appropriate child restraint system
Precautions for selecting a child restraint system
To ensure safety, observe the following when using a child restraint system.
● Make sure to observe the precautions regarding child restraint systems.
● Choose a child restraint system appropriate to the age and size of the child.
● Check the compatibility of the child restraint system with each seating position.
Depending on the child restraint system, it may not be able to be installed.
For details about use of a child restraint system, check the user’s manual of the
●
child restraint system.
WARNING
● Check that the seat belt for the seat next to a child restraint system can be worn
properly. Depending on the type of child restraint system, the seat belt may not be able
to be worn properly. In this case, use another seat.
● When adjusting the driver’s seat, if it contacts a child or child restraint system, install
the child restraint system to the rear seat behind the front passenger’s seat.
● Adjust the front passenger seat so that it does not interfere with the child or child
restraint system.
● When installing a child restraint system with support base, if the child restraint system
contacts a seatback when installing it to the support base, adjust the seatback rearward until they do not contact.
● If the seat belt shoulder anchor is in front of the
seat belt guide of a child restraint system, move
the seat forward.
1
Before driving
● When installing a junior seat, if the child in your child restraint system is in a very
upright position, adjust the seatback angle to the most comfortable position.
Selecting a child restraint system
Use a child restraint system that conforms to UN (ECE) R44 or UN (ECE) R129.
UN (ECE) R44 and UN (ECE) R129 are U.N. regulations for child restraint
systems.
27
1-2. Preparations for safe driving with children in the vehicle
■ Example
"UN（ECE） R44"
"UN（ECE） R129"
NOTICE
● The displayed mark may differ depending on the product.
● If the category of a child restraint system is unclear, refer to the user's manual of the
child restraint system or check with the manufacturer.
INFORMATION
Lexus recommends the use of a Lexus genuine child restraint system, as they meet strict
quality standards.
Lexus genuine child restraint systems are made specifically for Lexus vehicles. For details,
refer to the Lexus web site or contact your Lexus dealer.
28
1-2. Preparations for safe driving with children in the vehicle
Child restraint system compatibility with each seating position
Seating position
Seat position
number
Seating position
suitable for universal belted
(Yes/No)
(4)
(1)(2)(3)
Yes
Forward-facing
only
(2)(3)
(2)(3)
Yes Yes Yes
(2)(3)
1
Before driving
i-Size seating
position
(Yes/No)
Seating position
suitable for lateral fixture
(L1/L2/No)
Suitable rearward facing fixture
(R1/R2X/R2/R
3/No)
No Yes No Yes
No No No No
No R1, R2X, R2, R3 No R1, R2X, R2, R3
29
1-2. Preparations for safe driving with children in the vehicle
Seating position
Seat position
number
(1)(2)(3)
(2)(3)
(2)(3)
Suitable forward facing fixture
No F2X, F2, F3 No F2X, F2, F3
(F2X/F2/F3/N
o)
Suitable junior
seat fixture
No B2, B3 No B2, B3
(B2/B3/No)
(1)
Move the front seat fully rearward. If the passenger seat height can be adjusted, move
it to the upper most position.
(2)
Raise the seatback to be as upright as possible and reduce the gap between the child
restraint system and seatback.
(2)(3)
30
1-2. Preparations for safe driving with children in the vehicle
(3)
If the head restraint interferes with your child restraint system, and the head restraint
can be removed, remove the head restraint. Otherwise, put the head restraint in the
upper most position.
(4)
All universal categories (group 0, 0+, I, II and III).
● Lexus suggests the users to use and seating positions.
Activation of front passenger airbag.
Never use a rear-facing child restraint system on the front passenger seat when the airbag manual on-off switch is on.
Suitable for "universal" category child restraint system fixed with
the seat belt.
Suitable for forward-facing "universal" category child restraints
system fixed with the seat belt.
Suitable for i-Size and ISOFIX child restraint system.
Includes a top tether anchorage point.
1
Before driving
In the following situations, refer to the "vehicle compatibility list" from the manufacturer of the child restraint system, or contact your Lexus dealer or the retailer of the
child restraint system.
● When the child restraint system is not a "universal" category child restraint
system
● When it is unknown if the child restraint system is a "universal" category child
restraint system or not
Installation fixture list
ISOFIX child restraint systems are divided into different "fixture" types. Select a
fixture type according to the position where the child restraint system is to be
installed. Refer to the following table for the "fixture" types.
● To check the "fixture" type of a child restraint system, check the user's manual
included with it.
● If the child restraint system has no "fixture" type (or if the information is not in the
table), refer to the "vehicle compatibility list" from the manufacturer of the child
restraint system or contact the retailer of the child restraint system.
31
1-2. Preparations for safe driving with children in the vehicle
Mass group Child weight Size class Fixture Description
0
0 ＋
Up to 10 kg (22
lb.)
Up to 13 kg (28
lb.)
E R1
F L1
G L2
C R3
D R2
— R2X
E R1
Rearward-facing
infant seat
Left lateral-facing
infant seat (Carrycot)
Right lateral-facing
infant seat (Carrycot)
Full-size, rearwardfacing child restraint systems
Reduced-size,
rearward-facing
child restraint systems
Reduced-size,
rearward-facing
child restraint systems
Rearward-facing
infant seat
I
32
9 to 18 kg (20 to
39 lb.)
A F3
B F2
B1 F2X
C R3
Full-height, forward-facing child
restraint systems
Reduced-height
forward-facing
child restraint systems
Reduced-height
forward-facing
child restraint systems
Full-size, rearwardfacing child restraint systems
1-2. Preparations for safe driving with children in the vehicle
Mass group Child weight Size class Fixture Description
Reduced-size,
I
Ⅱ
Ⅲ
9 to 18 kg (20 to
39 lb.)
15 to 25 kg (34
to 55 lb.)
22 to 36 kg (48
to 79 lb.)
D R2
— B2, B3 Junior seat
rearward-facing
child restraint systems
1
Before driving
33
1-2. Preparations for safe driving with children in the vehicle
Installing a child restraint system
Lexus recommends that child restraint systems be installed to a rear seat. For
safety, when using a child restraint system, make sure to install it to a rear seat.
If installing the child restraint system to the front passenger seat is unavoidable,
refer to Installing a child restraint system to the front passenger's seat(→ P.39).
Use a child restraint system appropriate for the size of the child. Never use an
incorrectly sized child restraint system.
NOTICE
Before installing a child restraint system, make sure to read the user's manual included
with it.
Installing an ISOFIX/i-Size compatible child restraint system
This vehicle is equipped with ISOFIX rigid anchors. Therefore, ISOFIX compatible
child restraint systems can quickly and easily be installed.
WARNING
■ Using child restraint anchorages
WARNING: child restraint anchorages are designed to withstand only those loads
imposed by correctly fitted child restraints. Under no circumstances are they to be used
for adult seatbelts, harnesses, or for attaching other items or equipment to the vehicle.
Installation using ISOFIX rigid anchors
Install the child restraint system according to the user's manual included with it.
In the following situations, refer to the "vehicle compatibility list" from the manufacturer of the child restraint system, or contact your Lexus dealer or the retailer of the
child restraint system.
● When the child restraint system is not a "universal" category child restraint
system
● When it is unknown if the child restraint system is a "universal" category child
restraint system or not
WARNING
Observe the following when installing a child restraint system.
● After installing a child restraint system, do not adjust the seat.
34
1-2. Preparations for safe driving with children in the vehicle
WARNING
● When using the rigid anchors, make sure that the area around the anchors is free of
objects and that the seat belt will not be caught behind the child restraint system.
● Securely install the child restraint system according to the user's manual of the child
restraint system.
If a head restraint interferes with a child restraint system
When installing a child restraint system, if a head restraint interferes with the child
restraint system, remove the head restraint or adjust its position.
● Remove the head restraint.
If a head restraint cannot be removed, move it to the uppermost position.
Installing a child restraint system with ISOFIX rigid anchors
Engage the connectors of an ISOFIX compatible child restraint system to the ISOFIX rigid
anchors of the vehicle.
Install the child restraint system according to the
user's manual included with it.
1
Before driving
1 Check the positions of the rigid anchors.
2 Install the child restraint system to the seat.
3 Engage the connectors of the child restraint system to the rigid anchors.
4 Install the child restraint system according to the user's manual included with it.
5 Shake the installed child restraint system in all directions.
Make sure that the child restraint system is securely installed.
Using an anchor fitting
WARNING
Observe the following when installing a child restraint system.
● Make sure that the upper anchorage strap is not twisted.
35
1-2. Preparations for safe driving with children in the vehicle
WARNING
● Make sure that the top strap is engaged to the anchor fittings.
● Make sure that the upper anchorage is securely attached.
● After installing a child restraint system, do not adjust the seat.
● After installing a child restraint system, do not adjust the head restraint.
● Securely install the child restraint system according to the user’s manual of the child
restraint system.
Attach the top strap of the child restraint system to the anchor fitting of the vehicle.
Install the child restraint system according to the user’s manual included with it.
A
Anchor fittings
B
Upper anchorage strap
C
Attaching clip
1 Remove the head restraint.
If the head restraint cannot be removed, move it to the uppermost position.
Route the upper anchorage strap under the head restraint.
2 Engage the attaching clip to the anchor fitting.
3 Tighten the upper anchorage strap to secure the attaching clip.
Make sure that the upper anchorage strap is tight and the attaching clip is securely
engaged.
Installing a child restraint system with a seat belt
Install the child restraint system according to the user's manual included with it.
In the following situations, refer to the "vehicle compatibility list" from the manufacturer of the child restraint system, or contact your Lexus dealer or the retailer of the
child restraint system.
36
1-2. Preparations for safe driving with children in the vehicle
● When the child restraint system is not a "universal" category child restraint
system
● When it is unknown if the child restraint system is a "universal" category child
restraint system or not
WARNING
Observe the following when installing a child restraint system.
● After installing a child restraint system, do not adjust the seat.
● Securely install the child restraint system according to the user's manual of the child
restraint system.
If a head restraint interferes with a child restraint system
When installing a child restraint system, if a head restraint interferes with the child
restraint system, remove the head restraint or adjust its position.
● Remove the head restraint.
If a head restraint cannot be removed, move it to the uppermost position.
Installing a child restraint system with a seat belt
When installing a child restraint system which is not ISOFIX/i-Size compatible, use
a seat belt to install it.
1
Before driving
Install the child restraint system according to the user’s manual included with it.
WARNING
Observe the following when installing a child restraint system with a seat belt.
● Do not allow children to play with the seat belt. If the seat belt becomes twisted around
a child’s neck, it may lead to choking or other serious injuries that could result in death.
If this occurs and the buckle cannot be unfastened, scissors should be used to cut the
belt.
37
1-2. Preparations for safe driving with children in the vehicle
WARNING
● When using a junior seat (booster seat), make sure that the shoulder belt is securely
positioned over the child’s shoulder.
● After installing a child restraint system, do not adjust the seat.
● Make sure that the seat belt plate and buckle are securely fastened.
● Make sure that the seat belt is not twisted.
● Securely install the child restraint system according to the procedure in the user’s
manual of the child restraint system.
● Shake the child restraint system left and right, and forward and backward to ensure
that it has been securely installed.
1 Pass the seat belt through the child restraint system.
Install the child restraint system according to the user’s manual included with it.
2 Insert the plate into buckle until a sound is heard.
Make sure that the belt is not twisted.
3 Check that the seat belt is secure.
You may need a locking clip to install the child
restraint system. Follow the instructions provided
by the manufacturer of the system. If your child
restraint system does not provide a locking clip,
you can purchase the following item from your
Lexus dealer: Locking clip for child restraint system (Part No. 73119-22010)
4 After installing the child restraint system, rock it back and forth to ensure that it
is installed securely.
Make sure that the child restraint system is securely installed.
Removing a child restraint system that is installed with a seat belt
If a child restraint system is installed with a seat belt, release the seat belt to remove
it.
1 Press the buckle release button.
When the buckle is released, the child restraint system may spring up. Make sure to
hold down the child restraint system when releasing the buckle.
2 Remove the seat belt from the child restraint system.
The seat belt will be retracted automatically.
38
1-2. Preparations for safe driving with children in the vehicle
Installing a child restraint system to the front passenger's seat
Do not install a child restraint system to the front passenger's seat unless it is
unavoidable. In the event of an accident, the force of deployment of an SRS airbag
can cause death or serious injury to a child.
If installation of a child restraint system to the front passenger's seat is unavoidable,
adjust the front passenger's seat as follows:
● Move the seat to the rearmost position
● Move the seat to the uppermost position
Adjust the seatback angle to the most upright position.
●
Adjust the seatback angle of the front passenger's seat until good contact is
achieved.
Remove the head restraint
●
If the head restraint cannot be removed, move it to the uppermost position.
1
Before driving
WARNING
● Extreme Hazard! Do not use a rearward facing child restraint on a seat protected
by an airbag in front of it! This is because the force of the rapid inflation of the front
passenger airbag can cause death or serious injury to the child.
There is a label(s) on the passenger side sun visor, indicating it is forbidden to attach a
rear-facing child restraint system to the front passenger seat.
39
1-2. Preparations for safe driving with children in the vehicle
WARNING
● When installing a child restraint system to the front passenger's seat, move the seat as
far back as possible. In the event of an accident, the force of deployment of an SRS
airbag can cause death or serious injury to a child.
● Make sure that the child's body will not contact the doors, roof side rails, or pillars. In
the event of an accident, the force of deployment of an SRS airbag can cause death or
serious injury to a child.
● When using a junior seat (booster seat), make sure that the seat belt is worn correctly.
● Choose a child restraint system appropriate to the age and size of the child.
Installing a child restraint system to the front passenger's seat
● Make sure to appropriately adjust the front passenger's seat before installing the
child restraint system.
Install the child restraint system according to the user's manual included with it.
40
1-3. Entering/exiting the vehicle and loading luggage
Entering/exiting the vehicle and loading luggage
Key types
The following keys are provided with the vehicle.
A
Electronic keys
● Operating the smart entry & start system
● Operating the wireless remote control
function
B
Mechanical keys
C
Key number plate
D
Card key (electronic key)
Operating the smart entry & start system
NOTICE
■ To prevent key damage
Observe the following precautions
● Do not drop the keys, subject them to strong shocks or bend them.
● Do not expose the keys to high temperatures for long periods of time.
● Do not get the keys wet or wash them in an ultrasonic washer, etc.
● Do not attach metallic or magnetic materials to the keys or place the keys close to
such materials.
● Do not disassemble the keys.
● Do not attach a sticker or anything else to the surface of the electronic key.
● Do not place the keys near objects that produce magnetic fields, such as TVs, audio
systems and induction cookers, or medical electrical equipment, such as low-frequency therapy equipment.
■ Carrying the electronic key on your person
Carry the electronic key 10 cm (3.9 in.) or more away from electric appliances that are
turned on. Radio waves emitted from electric appliances within 10 cm (3.9 in.) of the
electronic key may interfere with the key, causing the key to not function properly.
■ Handling the card key
● If the battery or card key terminals get wet, the battery may corrode and the card key
may stop working.If the key is dropped into water, or if drinking water, etc., is spilled on
the key, immediately remove the battery cover and wipe the battery and terminals. (To
*
1
Before driving
* :
If equipped
41
1-3. Entering/exiting the vehicle and loading luggage
NOTICE
remove the battery cover, lightly grasp and pull it.) If the battery is corroded, have your
Lexus dealer replace the battery.
● Do not crush the battery cover or use a screwdriver to remove the battery cover.
Forcibly removing the battery cover may bend or damage the key.
● If the battery cover is frequently removed, the battery cover may become loose.
● When installing the battery, make sure to check the direction of the battery.Installing
the battery in the wrong direction may cause the battery to deplete rapidly.
● The surface of the card key may be damaged, or its coating may peel off in the
following situations:
•
The card key is carried together with hard objects, such as coins and keys.
•
The card key is scraped with a sharp object, such as the tip of a mechanical pencil.
•
The surface of the card key is wiped with thinner or benzene.
INFORMATION
■ Handling the card key
● The mechanical key that is stored inside the card key should be used only if a problem
arises, such as when the card key does not operate properly.
● If the battery cover is not installed and the battery
falls out or if the battery was removed because the
key got wet, reinstall the battery with the positive
terminal facing the Lexus emblem.
● The card key is not waterproof.
■ When riding in an aircraft
When bringing an electronic key onto an aircraft, make sure you do not press any buttons
on the electronic key while inside the aircraft cabin. If you are carrying an electronic key
in your bag, etc., ensure that the buttons are not likely to be pressed accidentally. Pressing
a button may cause the electronic key to emit radio waves that could interfere with the
operation of the aircraft.
■ Electronic key battery depletion
● The standard battery life is 1 to 2 years (The card key battery life is about 1 year.).
● If the battery becomes low, an alarm will sound in the cabin when the engine stops.
42
1-3. Entering/exiting the vehicle and loading luggage
● As the electronic key always receives radio waves, the battery will become depleted
even if the electronic key is not used. The following symptoms indicate that the
electronic key battery may be depleted. Replace the battery when necessary.
• The smart entry & start system or the wireless remote control does not operate.
• The detection area becomes smaller.
• The LED indicator on the key surface does not turn on.
● To avoid serious deterioration, do not leave the electronic key within 1 m (3 ft.) of the
following electrical appliances that produce a magnetic field:
•
TVs
•
Personal computers
•
Cellular phones, cordless phones and battery chargers
•
Table lamps
•
Induction cookers
•
Table lamps
■ Battery-saving function
The battery-saving function will be activated in order to prevent the electronic key
battery and the battery from being discharged while the vehicle is not in operation for a
long time.
● In the following situations, the smart entry & start system may take some time to unlock
the doors.
• The electronic key has been left in an area of approximately 3.5 m (11 ft.) of the
outside of the vehicle for 10 minutes or longer.
• The smart entry & start system has not been used for 5 days or longer.
● If the smart entry & start system has not been used for 14 days or longer, the doors
cannot be unlocked at any doors except the driver’s door. In this case, take hold of
the driver’s door handle, or use the wireless remote control or the mechanical key, to
unlock the doors.
■
Electronic key battery-saving mode
When battery-saving mode is set, battery depletion is minimized by stopping the electronic key from receiving radio waves.
1
Before driving
While pressing and holding
on the electronic key, press twice. The indicator on
the electronic key will flash 4 times and battery-saving mode will be entered.
43
1-3. Entering/exiting the vehicle and loading luggage
The smart entry & start system cannot be used while the electronic key is in battery-saving mode. Battery saving mode can be cancelled by pressing any switch on the electronic
key.
■ Confirmation of the registered key number
The number of keys already registered to the vehicle can be confirmed. Ask your Lexus
dealer for details.
■ When required to leave the vehicle’s key with a parking attendant
Lock the glove box as circumstances demand. Remove the mechanical key for your own
use and provide the attendant with the electronic key only.
44
1-3. Entering/exiting the vehicle and loading luggage
Smart entry & start system
WARNING
■ Affects influenced by the radio wave (Affect from the Smart entry & start system
antennas)
● People with implantable cardiac pacemakers, cardiac resynchronization therapy-
pacemakers or implantable cardioverter defibrillators should maintain a reasonable
distance between themselves and the smart entry & start system antennas. The radio
waves may affect the operation of such devices. If necessary, the entry function can
be disabled. Ask your Lexus dealer for details, such as the frequency of radio waves
and timing of the emitted radio waves. Then, consult your doctor to see if you should
disable the entry function.
● Users of any electrical medical device other than implantable cardiac pacemakers,
cardiac resynchronization therapy-pacemakers or implantable cardioverter defibrillators should consult the manufacturer of the device for information about its operation
under the influence of radio waves. Radio waves could have unexpected effects on the
operation of such medical devices.
Ask your Lexus dealer for details on disabling the entry function.
INFORMATION
■ Antenna location
A
Antennas outside the cabin
B
Antennas inside the cabin
C
Antenna outside the luggage compartment
1
Before driving
45
1-3. Entering/exiting the vehicle and loading luggage
■ Effective range (areas within which the electronic key is detected)
A
When locking or unlocking the doors
The system can be operated when the electronic key is within about 0.7 m (2.3 ft.) of an
outside door handle. (Only the doors detecting
the key can be operated.)
B
When starting the engine or changing engine switch modes
The system can be operated when the electronic key is inside the vehicle.
■ If an alarm sounds or a warning message is displayed
A combination of exterior and interior alarms as well as warning messages shown on
the multi-information display are used to prevent theft of the vehicle and accidents resulting from erroneous operation. Take appropriate measures in response to any warning
message on the multi-information display.
The following table describes situations and correction procedures when only an alarm
sounds.
● When an exterior alarm sounds once for 5 seconds
Situation: An attempt was made to lock the vehicle while a door was open.
Correction procedure: Close all of the doors and lock the doors again.
● When an interior alarm pings repeatedly
Situation: The engine switch was turned to ACC while the driver’s door was open (The
driver’s door was opened when the engine switch was in ACC).
Correction procedure: Turn the engine switch off and close the driver’s door.
■ Conditions affecting operation
The smart entry & start system, wireless remote control and immobilizer system use weak
radio waves. In the following situations, the communication between the electronic key
and the vehicle may be affected, preventing the smart entry & start system, wireless
remote control and immobilizer system from operating properly.
● When the electronic key battery is depleted
● Near a TV tower, electric power plant, gas station, radio station, large display, airport
or other facility that generates strong radio waves or electrical noise
● When the electronic key is in contact with, or is covered by the following metallic
objects
• Cards to which aluminum foil is attached
• Cigarette boxes that have aluminum foil inside
46
1-3. Entering/exiting the vehicle and loading luggage
• Metallic wallets or bags
• Coins
• Hand warmers made of metal
• Media such as CDs and DVDs
● When other wireless keys (that emit radio waves) are being used nearby
● When carrying the electronic key together with the following devices that emit radio
waves
• Portable radio, cellular phone, cordless phone or other wireless communication
devices
•
Another vehicle’s electronic key or a wireless key that emits radio waves
•
Personal computers or personal digital assistants (PDAs)
•
Digital audio players
•
Portable game systems
● If window tint with a metallic content or metallic objects are attached to the rear
window
● When the electronic key is placed near a battery charger or electronic devices
● When the vehicle is parked in a pay parking spot where radio waves are emitted
Even when the electronic key is within the effective range (detection areas), the system
may not operate properly in the following cases:
● The electronic key is too close to the window or outside door handle, near the ground,
or in a high place when the doors are locked or unlocked.
● The electronic key is near the ground or in a high place, or too close to the rear
bumper center when the back door is opened.
● The electronic key is on the instrument panel, rear package tray or floor, or in the door
pockets or glove box when the engine is started or engine switch modes are changed.
■
Note for the entry function
● Do not leave the electronic key on top of the instrument panel or near the door
pockets when exiting the vehicle. Depending on the radio wave reception conditions,
it may be detected by the antenna outside the cabin and the door will become
lockable from the outside, possibly trapping the electronic key inside the vehicle.
● As long as the electronic key is within the effective range, the doors may be locked or
unlocked by anyone.
● Even if the electronic key is not inside the vehicle, it may be possible to start the hybrid
system if the electronic key is near the window.
1
Before driving
47
1-3. Entering/exiting the vehicle and loading luggage
● The doors may unlock if a large amount of water splashes on the door handle, such as
in the rain or in a car wash when the electronic key is within the effective range. (The
door will automatically be locked after approximately 30 seconds if the doors are not
opened and closed.)
● If the wireless remote control is used to lock the doors when the electronic key is
near the vehicle, there is a possibility that the door may not be unlocked by the entry
function. (Use the wireless remote control to unlock the doors.)
● Touching the door lock sensor while wearing gloves may delay or prevent lock
operation. Remove the gloves and touch the lock sensor again.
● When the lock operation is performed using the lock sensor, recognition signals will
be shown up to two consecutive times. After this, no recognition signals will be given.
● If the door handle becomes wet while the electronic key is within the effective range,
the door may lock and unlock repeatedly. In that case, follow the following correction
procedures to wash the vehicle:
•
Place the electronic key in a location 2 m (6 ft.) or more away from the vehicle.
(Take care to ensure that the key is not stolen.)
•
Set the electronic key to battery-saving mode to disable the smart entry & start
system.
● If the electronic key is inside the vehicle and a door handle becomes wet during a
car wash, a message may be shown on the multi-information display and a buzzer will
sound outside the vehicle. To turn off the alarm, lock all the doors.
● The lock sensor may not work properly if it comes into contact with ice, snow, mud.
Clean the lock sensor and attempt to operate it again.
● A sudden approach to the effective range or door handle may prevent the doors from
being unlocked. In this case, return the door handle to the original position and check
that the doors unlock before pulling the door handle again.
● If there is another electronic key in the detection area, it may take slightly longer to
unlock the doors after the door handle is gripped.
■ When the vehicle is not driven for extended periods
● To prevent theft of the vehicle, do not leave the electronic key within 2 m (6 ft.) of the
vehicle.
● The smart entry & start system can be deactivated in advance.
● Setting the electronic key to battery-saving mode helps to reduce key battery deple-
tion.
48
1-3. Entering/exiting the vehicle and loading luggage
■ To operate the system properly
Make sure to carry the electronic key when operating the system. Do not get the
electronic key too close to the vehicle when operating the system from the outside of the
vehicle.
Depending on the position and holding condition of the electronic key, the key may not
be detected correctly and the system may not operate properly. (The alarm may go off
accidentally, or the door lock prevention may not operate.)
Related Links
Customizable features(P. 610)
1
Before driving
49
1-3. Entering/exiting the vehicle and loading luggage
Opening/closing the doors
WARNING
■ Precautions for when driving
Observe the following precautions while driving.
● Make sure that all of the doors are closed and locked.
● Do not press an inside door opener switch while driving.
Be especially careful with the driver’s door, as it can be opened even when the doors
are locked.
● When a child is riding in a rear seat, set the child protector locks to prevent the rear
doors from being opened from inside the vehicle.
■ Precautions for when opening or closing a door
When opening or closing a door, check the surrounding area and hold the door handle
tightly.
● When on a slope
● When the space between a door and a wall, etc. is small
● When in an area with strong winds
INFORMATION
■ Door lock buzzer
If an attempt to lock the doors is made when a door is not fully closed, a buzzer sounds
continuously for 5 seconds. Fully close the door to stop the buzzer, and lock the vehicle
once more.
■ Open door warning buzzer
If the vehicle speed reaches 5 km/h (3 mph), the master warning light flashes and a
buzzer sounds to indicate that door(s) or the hood in not fully closed.The open door(s) or
hood is displayed on the multi-information display.
■ Rear seat reminder function
In order to remind you not to forget luggage, etc. in the rear seat, when the engine switch
is turned off after any of the following conditions are met, a buzzer will sound and a
message will be displayed on the multi-information display for approximately 6 seconds.
● The engine is started within 10 minutes after opening and closing a rear door.
● A rear door has been opened and closed after the engine was started.
However, if a rear door is opened and then closed within approximately 2 seconds, the
rear seat reminder function may not operate.
50
1-3. Entering/exiting the vehicle and loading luggage
The rear seat reminder function determines that luggage, etc. has been placed in a
rear seat based on opening and closing of a rear door. Therefore, depending on the
situation, the rear seat reminder function may not operate and you may still forget
luggage, etc. in the rear seat, or it may operate unnecessarily.
● The rear seat reminder function can be enabled/disabled.
Related Links
Key types(P. 41)
Locking/unlocking the doors(P. 54)
Using the mechanical key(P. 546)
If a door cannot be opened using the door opener switch(P. 552)
Customizable features(P. 610)
Opening the doors
▶ Outside the vehicle
1
Before driving
When the doors are locked:
While carrying an electronic key, press the door opener switch of the door handle and
open the door.
Make sure to securely press the door opener switch
handle with the electronic key within the detection area.
When the doors are unlocked:
Press the door opener switch of the door handle to open the door.
Make sure to securely press the door opener switch on the inner side of the door
handle.
on the inner side of the door
51
1-3. Entering/exiting the vehicle and loading luggage
▶ Inside the vehicle
Driver's door:
Even if the door is locked, pressing the front side of the door opener switch
will open
the door.
The door will unlock and the door lock indicator will turn off.
Passenger doors:
Press the door lock switch to unlock the door, and then pressing the front side of the door
opener switch
to open the door.
The door will unlock and the door lock indicator will turn off.
INFORMATION
■ Inside door opener switch operating conditions
When any of the following conditions are met:
● The vehicle speed is less than 4 km/h (2 mph) and the parking brake is engaged
● The vehicle speed is less than 4 km/h (2 mph) and the brake pedal is depressed
● The shift position is in P
■ When opening a door from inside the vehicle
Open the door pressing the door opener switch.
If the door is not fully unlatched, press the door opener switch twice to open the door.
■ Manual release handles inside the vehicle
The door opener switches inside the vehicle can also be used to manually open the
doors.
52
1-3. Entering/exiting the vehicle and loading luggage
A door can be opened through electronic operation by pressing a the door opener
switch, or it can be opened using the door opener switch as a manual release handle and
pulling it twice.
1
Before driving
53
1-3. Entering/exiting the vehicle and loading luggage
Locking/unlocking the doors
INFORMATION
■ Impact detection door lock release system
If the vehicle is involved in a severe frontal or rear collision, manual release handle
operation will be enabled for all of the doors.
■ Operation signals
Unlocking is indicated by a buzzer sounding and the emergency flashers flashing. (twice)
Locking is indicated by a buzzer sounding and the emergency flashers flashing. (Once)
■ Security feature
If a door is not opened within approximately 30 seconds after the vehicle is unlocked, the
security feature automatically locks the vehicle again.
Using the smart entry & start system
Locking/unlocking the doors using smart entry & start system
The driver should always carry an electronic key (or the card key) on their person,
for example in their pocket.
Grip the door handle to unlock the doors.
1
*1
Make sure to touch the sensor on the back
of the handle.
The doors cannot be unlocked for 3 seconds after the doors are locked.
2 Touch the lock sensor (the indentation on
the surface of the door handle) to lock the
doors.
Check that the door is securely locked.
Locking the doors will set the alarm system.
INFORMATION
■ When the door cannot be locked even though the lock sensor has been touched
with a finger
Touch the lock sensor with the palm of your hand.
When gloves are being worn, remove the gloves.
*1 :
The door unlock settings can be changed.
54
1-3. Entering/exiting the vehicle and loading luggage
Switching the door unlock function
It is possible to set which doors the entry function unlocks using the wireless
remote control.
1 Turn the engine switch off.
2 Cancel the intrusion sensor and tilt sensor of the alarm system to prevent
unintended triggering of the alarm while changing the settings.
1
Before driving
3
When the indicator light on the key surface is not on, press and hold
or for approximately 5 seconds while pressing and holding .
The setting changes each time an operation is performed, as shown below. (When
changing the setting continuously, release the buttons, wait for at least 5 seconds, and
repeat step 3.)
Multi-information display/Beep
Holding the driver’s door handle unlocks
only the driver’s door.
Exterior: Beeps 3 times
Interior: Pings once
Exterior: Beeps twice
Interior: Pings once
To prevent unintended triggering of the alarm, unlock the doors using the wireless
remote control and open and close a door once after the settings have been changed.
(If a door is not opened within 30 seconds after is pressed, the doors will be
locked again and the alarm will automatically be set.)In a case that the alarm is
triggered, immediately stop the alarm.
Holding any of the passenger door handles unlocks all the doors.
Holding a door handle unlocks all the
doors.
Unlocking function
,
55
1-3. Entering/exiting the vehicle and loading luggage
Operations using the wireless remote control
Lock/unlock the doors using wireless remote control
1 Locks all the doors
Check that the door is securely locked.
2 Unlocks all the doors
INFORMATION
■ Theft deterrent panic mode
When is pressed for longer than about 1 second, an alarm will sound intermittently and the vehicle
lights will flash to deter any person from trying to
break into or damage your vehicle.
To stop the alarm, press any button on the electronic
key.
Using the door lock switches
Locking/unlocking the doors with the door lock switches
Press the
1
All of the doors will lock.
The indicator comes on.
Press the switch.
2
All of the doors will unlock.
The indicator turns off.
switch.
Close & lock (walk away) *function
When the power back door is open, all of the doors will be locked when the power
back door is closed.
* :
If equipped
56
1-3. Entering/exiting the vehicle and loading luggage
INFORMATION
■ Close & lock (walk away) function operating conditions
This function can be operated when all of the following conditions are met:
● An electronic key is not detected within the vehicle.
● All of the doors other than the power back door are closed.
● The brake pedal is not depressed.
● The engine switch is off.
■ Hands free close & lock (walk away) function
*
operating conditions
This function can be operated when all of the following conditions are met:
● The hands free close & lock function setting is on.
● The Hands Free Power Back Door operating conditions are met.
● An electronic key is not detected within the vehicle.
● All of the doors other than the power back door are closed.
● The brake pedal is not depressed.
● The engine switch is off.
■ Situations in which the close & lock (walk away) function may not operate properly
In the following situations, the close & lock function may not operate properly:
● If the switch on the lower part of the power back door is pressed by a hand which
is holding an electronic key
1
Before driving
● If the switch on the lower part of the power back door is pressed when the
electronic key is in a bag, etc. that is placed on the ground
● If the
switch on the lower part of the power back door is pressed with the
electronic key not near the vehicle
Closing the back door and lock all of the doors
57
1-3. Entering/exiting the vehicle and loading luggage
1 Perform the following procedure with no electronic keys for this vehicle inside
the vehicle. When the power back door is closed, all of the doors will lock.
Using the switch:
2 While carrying an electronic key, press the
switch on the lower part of the
power back door.
When you move away from the power back door, it will automatically fully close.
If the power back door is approached while carrying an electronic key, the closing
operation will stop.
A different buzzer than normal will sound. When the power back door is closed, door
lock operation signals will indicate that all of the doors have been locked.
Vehicles with Hands Free Power Back Door:
*2
3 If the power back door is closed using a hands free power back door close
operation while carrying an electronic key, all of the doors will be locked at the
same time.
When you move away from the power back door, it will automatically fully close.
If the power back door is approached while carrying an electronic key, the closing
operation will stop.
A different buzzer than normal will sound. When the power back door is closed, door
lock operation signals will indicate that all of the doors have been locked.
WARNING
When closing the power back door using the close & lock function, a different
buzzer than the normal one will sound before the operation begins.
To check that the operation has started correctly, check that a different buzzer than
the normal one has sounded.
Additionally, when the power back door is fully closed and locked, operation signals
will indicate that all of the doors have been locked.
Before leaving the vehicle, make sure that the operational signals have operated and
that all of the doors are locked.
*2 :
This setting can be customized by your Lexus dealer.
58
1-3. Entering/exiting the vehicle and loading luggage
Theft deterrent system
This vehicle is equipped with an engine immobilizer system and alarm system to
help prevent vehicle theft.The engine immobilizer is a system which helps prevent
intrusion into the vehicle and starting of the engine using keys other than a key
registered to this vehicle. Through a transponder chip built into the keys, registered
keys can be recognized over unauthorized copies.The alarm uses light and sound
to give an alert when an intruder is detected.
INFORMATION
■ Note for the entry function
The engine immobilizer system is designed to help prevent vehicle theft but does not
guarantee absolute security against all vehicle thefts.
■ System maintenance
The engine immobilizer system and alarm system are maintenance-free.
■ Triggering of the alarm
The alarm may be triggered in the following situations:
● The doors are unlocked using the mechanical key.
● A person inside the vehicle opens a door or the hood, or unlocks the vehicle using the
lock lever on an inside door handle.
● The battery is recharged or replaced when the vehicle is locked.
● A locked door is unlocked or opened in any way other than using the entry function,
wireless remote control or mechanical key. (The doors will lock again automatically.)
● The hood is opened from outside of the vehicle.
● The intrusion sensor detects something moving inside the vehicle. (Example: an
intruder breaks a window and gets into the vehicle.)
● The tilt sensor detects a change of vehicle inclination.
■ Alarm-operated door lock function operating conditions
In the following cases, depending on the situation, the door may automatically lock to
prevent improper entry into the vehicle:
● When a person remaining in the vehicle unlocks the door and the alarm is activated.
● While the alarm is activated, a person remaining in the vehicle unlocks the door.
● When recharging or replacing the battery.
1
Before driving
59
1-3. Entering/exiting the vehicle and loading luggage
Enable the engine immobilizer system
NOTICE
Do not modify or remove the system. If modified or removed, the proper operation of the
system cannot be guaranteed.
Turn the engine switch off.
When the engine immobilizer system is enabled, the
security indicator flashes to indicate that the system is
operating.
Never leave the keys inside the vehicle when you
leave the vehicle.
INFORMATION
■ Cancel the engine immobilizer system
While carrying a key registered to the vehicle, change the engine switch to ACC or ON.
The engine immobilizer system will be cancelled and the security indicator will turn off.
Setting the alarm system
Make sure of the following before setting the alarm:
● Nobody is in the vehicle.
● The windows and moon roof are closed before the alarm is set.
● No valuables or other personal items are left in the vehicle.
NOTICE
Do not modify or remove the system. If modified or removed, the proper operation of the
system cannot be guaranteed.
Close the doors and hood, and lock all the doors.
The system will be set automatically after 30
seconds.
The indicator light changes from being on to flashing
when the system is set.
If all doors are closed with hood open, alarm system
can be set.
60
1-3. Entering/exiting the vehicle and loading luggage
Canceling/stopping the alarm system
Do one of the following to deactivate or stop the alarms:
● Unlock the doors.
● Turn the engine switch to ACC or ON, or start the engine.
The alarm will be deactivated or stopped after a few seconds.
Intrusion sensor and tilt sensor
The intrusion sensor detects intruders or movement in the vehicle.The tilt sensor
detects changes in vehicle inclination, such as when the vehicle is towed away.This
system is designed to deter and prevent vehicle theft but does not guarantee
absolute security against all intrusions.
NOTICE
To ensure correct operation of the intrusion sensor, observe the following.
● Do not spray air fresheners or other products
directly into the sensor holes.
1
Before driving
● Do not touch or cover the sensors.
● Do not install accessories other than genuine Lexus parts or leaving objects between
the driver’s seat and front passenger’s seat. Otherwise, the detection performance
may reduce.
● The intrusion sensor may be canceled when the electronic key is near the vehicle.
INFORMATION
■ Intrusion sensor detection considerations
The sensor may trigger the alarm in the following situations:
61
1-3. Entering/exiting the vehicle and loading luggage
● People or pets are in the vehicle.
● A window or the moon roof is open. In this case, the sensor may detect the following:
• Wind or the movement of objects such as leaves and insects inside the vehicle
• Ultrasonic waves emitted from devices such as the intrusion sensors of other
vehicles
• The movement of people outside the vehicle
● Small insects such as moths or flies are in the vehicle.
● Unstable items, such as dangling accessories or clothes hanging on the coat hooks,
are in the vehicle.
● The vehicle is parked in a place where extreme vibrations or noises occur, such as in a
parking garage.
● Ice or snow is removed from the vehicle, causing the vehicle to receive repeated
impacts or vibrations.
● The vehicle is inside an automatic or high-pressure car wash.
● The vehicle experiences impacts, such as hail, lightning strikes, and other kinds of
repeated impacts or vibrations.
■ Tilt sensor detection considerations
The sensor may trigger the alarm in the following situations:
● The vehicle is transported by a ferry, trailer, train, etc.
● The vehicle is parked in a parking garage.
● The vehicle is inside a car wash that moves the vehicle.
● Any of the tires loses air pressure.
● The vehicle is jacked up.
● An earthquake occurs or the road caves in.
● Cargo is loaded onto or unloaded from the roof luggage carrier.
Related Links
Customizable features(P. 610)
Set the intrusion sensor and tilt sensor
The intrusion sensor and tilt sensor will be set automatically when the alarm is set.
62
1-3. Entering/exiting the vehicle and loading luggage
Cancel the intrusion sensor and tilt sensor
If you are leaving pets or other moving things inside the vehicle, make sure to
disable the intrusion sensor and tilt sensor before setting the alarm, as they will
respond to movement inside the vehicle.
The alarm will still be set even when the intrusion sensor and tilt sensor are
canceled.
1 Touch the Shortcut screen switch.
2 Touch the .
Operation of the intrusion sensor and tilt sensor will be canceled, and a message will
be displayed on the multi-information display in the instrument cluster.
Touch the switch again to set the intrusion / tilt sensor again.
A message will be shown on the multi-information display in the instrument cluster.
INFORMATION
■ Automatic re-enabling of the intrusion sensor and tilt sensor
● After the intrusion sensor and tilt sensor are canceled, unlocking the doors using
the entry function or wireless remote control will re-enable the intrusion sensor
and tilt sensor.
● The intrusion sensor and tilt sensor will automatically be re-enabled when the
alarm system is reactivated.
1
Before driving
63
1-3. Entering/exiting the vehicle and loading luggage
Loading the vehicle with luggage
Precautions for loading luggage into the luggage compartment
WARNING
■ Storage precautions
Observe the following precautions.
Failure to do so may prevent the pedals from being depressed properly, may block the
driver’s vision, or may result in items hitting the driver or passengers, possibly causing an
accident.
● The following things may cause a fire if loaded in the luggage compartment:
• Receptacles containing gasoline
• Aerosol cans
● Stow cargo and luggage in the luggage compartment whenever possible.
● Do not stack cargo and luggage in the luggage compartment higher than the seat-
backs.
● When you fold down the rear seats, long items should not be placed directly behind
the front seats.
● Never allow anyone to ride in the luggage compartment.
It is not designed for passengers.
They should ride in their seats with their seat belts properly fastened.
● Do not place cargo or luggage in or on the following locations.
• At the feet of the driver
• On the front passenger or rear seats (when stacking items)
• On the luggage cover
• On the instrument panel
• On the dashboard
● Secure all items in the occupant compartment.
■
Precautions for luggage weight and distribution
● Do not overload your vehicle.
● Load the vehicle as evenly as possible.
If the vehicle is loaded unevenly, the load on each tire will differ. This will lead to a
decrease in handling ability and brake performance, possibly leading to an accident.
64
1-3. Entering/exiting the vehicle and loading luggage
WARNING
■ When using a roof luggage carrier (vehicles with roof rails)
Observe the following precautions:
● Place the cargo so that its weight is distributed evenly between the front and rear
axles.
● If loading long or wide cargo, never exceed the vehicle overall length or width.
● Before driving, make sure the cargo is securely fastened on the roof luggage carrier.
● Loading cargo on the roof luggage carrier will make the center of gravity of the
vehicle higher.
Avoid high speeds, sudden starts, sharp turns, sudden braking, or abrupt maneuvers.
The vehicle may not be able to be controlled correctly and may rollover.
● If driving for a long distance, on rough roads, or at high speeds, stop the vehicle now
and then during the trip to make sure the cargo remains in its place.
● Do not exceed 80 kg (176.3 lb.) cargo weight on the roof luggage carrier.
NOTICE
Do not set luggage on the moon roof and panoramic roof. Failure to observe so may lead
to cause damage.
Back door functions and operation
1
Before driving
The back door can be locked/unlocked and opened/closed by the following
procedures.
WARNING
■ Before driving the vehicle
Observe the following precautions.
Before driving the vehicle, make sure that the back door is fully closed. If the back door is
not fully closed, it may open unexpectedly while driving, causing an accident.
■ Caution while driving
● Keep the back door closed while driving.
If the back door is left open, it may hit nearby objects while driving or luggage may be
unexpectedly thrown out, causing an accident.
In addition, exhaust gases may enter the vehicle, causing death or a serious health
hazard. Make sure to close the back door before driving.
● Never let anyone sit in the luggage compartment.
65
1-3. Entering/exiting the vehicle and loading luggage
WARNING
In the event of sudden braking, sudden swerving or a collision, they are susceptible to
death or serious injury.
■ When children are in the vehicle
Observe the following precautions.
● Do not allow children to play in the luggage compartment.
If a child is accidentally locked in the luggage compartment, they could have heat
exhaustion or other injuries.
● Do not allow a child to open or close the back door.
Doing so may cause the back door to move unexpectedly, or cause the child’s hands,
arms, head, or neck to be caught by the closing back door.
■ Operating the back door
Observe the following precautions.
● Remove any heavy loads, such as snow and ice, from the back door before opening it.
Failure to do so may cause the back door to suddenly shut again after it is opened.
● When opening or closing the back door, thoroughly check to make sure the surround-
ing area is safe.
● If anyone is in the vicinity, make sure they are safe and let them know that the back
door is about to open or close.
● Use caution when opening or closing the back door in windy weather as it may move
abruptly in strong wind.
● Vehicles without power back door: The back door may suddenly shut if it is not
opened fully. It is more difficult to open or close the back door on an incline than
on a level surface, so beware of the back door unexpectedly opening or closing by
itself. Make sure that the back door is fully open and secure before using the luggage
compartment.
● Vehicles with power back door: The back door may suddenly shut if it is not opened
fully. It is more difficult to open or close the back door on an incline than on a
level surface, so beware of the back door unexpectedly opening or closing by itself.
Make sure that the back door is fully open and secure before using the luggage
compartment.
● When closing the back door, take extra care to prevent your fingers, etc., from being
caught.
● When closing the back door, make sure to press it lightly on its outer surface. If the
back door handle is used to fully close the back door, it may result in hands or arms
being caught.
66
1-3. Entering/exiting the vehicle and loading luggage
WARNING
● Do not pull on the back door damper stay (vehicles without power back door) or
back door spindle (vehicles with power back door) to close the back door, and do not
hang on the back door damper stay (vehicles without power back door) or back door
spindle (vehicles with power back door). Doing so may cause hands to be caught or
the back door damper stay (vehicles without power back door) or back door spindle
(vehicles with power back door) to break, causing an accident.
● If a bicycle carrier or similar heavy object is attached to the back door, it may suddenly
shut again after being opened, causing someone’s hands, arms, head or neck to be
caught and injured. When installing an accessory part to the back door, using a
genuine Lexus part is recommended.
■ Back door closer (vehicles with power back door)
● In the event that the back door is left slightly open, the back door closer will automati-
cally close it to the fully closed position. It takes several seconds before the back door
closer begins to operate. Be careful not to catch fingers or anything else in the back
door, as this may cause bone fractures or other serious injuries.
● Be careful not to catch fingers or anything else when using the back door closer as it
still operates when the power back door system is canceled.
■ Power back door
Observe the following precautions.
● Check the safety of the surrounding area to make sure there are no obstacles or
anything that could cause any of your belongings to get caught.
● If anyone is in the vicinity, make sure they are safe and let them know that the power
back door is about to open or close.
● If the power back door system is disabled while the power back door is operating, the
power back door will stop operating. The power back door must then be operated
manually. Take extra care in this situation, as the power back door may open or close
suddenly.
● If the operating conditions of the power back door are no longer met, a buzzer may
sound and the power back door may stop opening or closing. The power back door
must then be operated manually. Take extra care on an incline in this situation, as the
power back door may move suddenly.
● On an incline, the power back door may suddenly shut after it opens. Make sure the
power back door is fully open and secure.
● In the following situations, the power back door may detect an abnormality and
automatic operation may be stopped. In this case, the power back door must then be
operated manually. Take extra care in this situation, as the stopped power back door
may suddenly open or close, causing an accident.
1
Before driving
67
1-3. Entering/exiting the vehicle and loading luggage
WARNING
• When the power back door contacts an obstacle
• When the battery voltage suddenly drops, such as when the engine switch is turned
to ON or the engine is started during automatic operation
● If a bicycle carrier or similar heavy object is attached to the power back door, the
power back door may not operate, causing a malfunction, or the power back door
may suddenly shut again after being opened, causing someone’s hands, arms, head or
neck to be caught and injured. When installing an accessory part to the power back
door, using a genuine Lexus part is recommended.
■ Jam protection function (vehicles with power back door)
Observe the following precautions.
● Never use any part of your body to intentionally activate the jam protection function.
● The jam protection function may not work if something gets caught just before the
power back door fully closes. Be careful not to get fingers caught or anything else.
● The jam protection function may not work depending on the shape of the object that is
caught. Be careful not to catch fingers or anything else.
NOTICE
■ Precautions for the back door spindles (vehicles with the power back door)
The back door is equipped with spindles that hold
the back door in place.
Observe the following precautions. Failure to do so
may cause damage to the back door spindle ,
resulting in malfunction.
● Do not attach any foreign objects, such as stickers, plastic sheets, or adhesives to the
spindle rod.
● Do not touch the spindle rod with gloves or other fabric items.
● Do not attach heavy accessories to the back door.
When attaching, ask your Lexus dealer for details.
● Do not place your hand on the spindle or apply lateral forces to it.
68
1-3. Entering/exiting the vehicle and loading luggage
NOTICE
■ Precautions for the back door damper stays (vehicles without the power back door)
The back door is equipped with damper stays that
hold the back door in place. Observe the following
precautions. Failure to do so may cause damage to
the back door damper stay resulting in malfunction.
● Do not attach any foreign objects, such as stickers, plastic sheets, or adhesives to the
damper stay rod.
● Do not touch the damper stay rod with gloves or other fabric items.
● Do not attach any accessories other than genuine Lexus parts to the back door.
● Do not place your hand on the damper stay or apply lateral forces to it.
■ To prevent malfunction of the power back door and back door closer (vehicles with
the power back door)
Observe the following precautions. Failure to do so may lead to malfunction of the power
back door or back door closer.
● Do not apply excessive force to the back door while the back door closer is operating.
● Make sure that there is no ice between the back door and frame that would prevent
movement of the back door.
● Take care not to damage the sensors (installed on the right and left edges of the power
back door) with a knife or other sharp object.
If the sensor is disconnected, the power back door will not close automatically.
1
Before driving
INFORMATION
■ Luggage compartment light
● The luggage compartment light turns on when the back door is opened.
● If the luggage compartment light is left on when the engine switch is turned off, the
light will go off automatically after 20 minutes.
■ Power back door operating conditions
With the power back door operations set to ON, it can automatically open and close for
the following conditions:
● When the back door is unlocked.
69
1-3. Entering/exiting the vehicle and loading luggage
However, if the back door is locked, the power back door can be operated in the
following situations:
• When the electronic key is being carried and the power back door switch is pushed
• When set up by customizable functions to be able to operate, even when locked,
when using the wireless remote control
■ Operation of the power back door (vehicles with the power back door)
In the event that the back door is left slightly open, the back door closer will automatically
close it to the fully closed position.
Whatever the state of the engine switch, the back door closer operates.
■ Operation of the power back door (vehicles with the power back door)
● A buzzer sounds and the emergency flashers flash twice to indicate that the back door
is opening/closing.
● When the power back door operations are OFF, the power back door does not
operate but it can be opened and closed by hand.
● When the power back door automatically opens, if an abnormality due to people or
objects is detected, operation will stop.
■ When reconnecting the battery (vehicles with the power back door)
To enable the power back door to operate properly, close the back door manually.
■ Jam protection function (vehicles with the power back door)
Sensors are installed in the right and left sides of the
power back door.
When the door is automatically closing and the sensors are pushed due to an object being clamped, the
jam protection function operates. From that position
the door automatically moves a little in the opposite
direction and then the function stops.
Related Links
Customizable features(P. 610)
Operating the back door using the smart entry & start system
The back door can be locked/unlocked while carrying an electronic key or the
card key.The driver should always carry the electronic key or the card key.
Locking/unlocking the back door using smart entry & start system
Perform the following while carrying an electronic key.
70
1-3. Entering/exiting the vehicle and loading luggage
1 Press 1.
All of the doors will unlock. However, the doors
cannot be unlocked within 3 seconds after they
were locked.
2 Press 2.
All of the doors will lock. Make sure that the
doors are securely locked.
Locking/unlocking the back door using the door lock switches
Locking/unlocking the back door using the door lock switches
1
Press the switch.
All of the doors, including the back door, will
lock.
2
Press the
switch.
All of the doors, including the back door, will
unlock.
Back door operations using the wireless remote control
1
Before driving
Opening/closing the back door using the wireless remote control(vehicles
with the power back door)
● Press for 1 second.
The power back door can be operated when it is unlocked*1.
The back door will open.
*1 :
Through a customization setting, the back door can also be operated when it is locked
71
1-3. Entering/exiting the vehicle and loading luggage
Lock/unlock the back door using wireless remote control
1 Press .
All of the doors, including the back door, will
lock.
Make sure that the doors are securely locked.
2 Press .
Pressing the button unlocks the driver’s door.
Pressing the button again within 3 seconds unlocks all of the other doors, including the back
door.
All of the doors, including the back door, will
unlock.
Back door operations using the back door operation switch inside the vehi-
*
cle
Opening/closing the back door from the inside
Press the for 1 second.
A buzzer sounds and the back door automatically opens and closes.
Pressing the while the back door is
opening/closing stops the operation.
When the is pressed again during the
halted operation, the back door will perform the reverse operation.
Back door operations using the back door switch
*
Opening/closing the back door using the back door switch
Press the .
A buzzer sounds and the back door automatically closes.
Pressing the
while the back door is clos-
ing stops the operation.
* :
If equipped
72
1-3. Entering/exiting the vehicle and loading luggage
Pressing the again will reverse the operation.
Back door operations using the back door opener switch
Open the back door automatically using the back door opener switch(vehicles
with power back door)
Press the back door opener switch with the back
door unlocked.
A buzzer sounds and the back door automatically opens.
Pressing the switch while the back door is opening
stops the operation.
INFORMATION
■ Open the back door with the back door opener switch when the back door is locked
While carrying the electronic key on your person, press the back door opener switch.
A buzzer sounds and the back door automatically opens.
Open the back door manually using the back door opener switch (vehicles
without power back door)
1
Before driving
Lift the back door while pressing the back door opener switch.
Back door operations using the back door handle
Closing the back door automatically using the back door handle
*2 :
Vehicles with power back door
*2
73
1-3. Entering/exiting the vehicle and loading luggage
WARNING
Observe the following when closing the back door.
● When closing the back door, take extra care to prevent your fingers, etc., from being
caught.
● When closing the back door, make sure to press it lightly on its outer surface.
If the back door handle is used to fully close the back door, it may result in hands or
arms being caught.
● Do not pull on the back door spindle to close the back door, and do not hang on the
back door spindle.
Doing so may cause hands to be caught or the back door spindle to break, causing an
accident.
Pull the back door downward using the back
door handle.
A buzzer sounds and the back door automatically closes.
Close the back door manually using the back door handle
*3
WARNING
Observe the following when closing the back door.
● When closing the back door, take extra care to prevent your fingers, etc., from being
caught.
● If the back door handle is used to fully close the back door, it may result in hands or
arms being caught.
● Do not pull on the back door damper stay to close the back door, and do not hang on
the back door damper stay.
Doing so may cause hands to be caught or the back door damper stay to break,
causing an accident.
*3 :
Vehicles without power back door
74
1-3. Entering/exiting the vehicle and loading luggage
Lower the back door using the back door handle, and make sure to push the back
door down from the outside to close it.
Back door operations using the kick sensor
NOTICE
The kick sensor is located behind lower center part of the rear bumper.
Observe the following to ensure that the power back door operates properly:
● Keep the lower center part of the rear bumper clean at all times.
If the lower center part of the rear bumper is dirty or covered with snow, the kick
sensor may not operate.
In this situation, clean off the dirt or snow, move the vehicle from the current position
and then check if the kick sensor operates.
If it does not operate, have the vehicle inspected by your Lexus dealer.
● Do not apply coatings that have a rain clearing (hydrophilic) effect, or other coatings,
to the lower center part of the rear bumper.
● Do not park the vehicle near objects that may move and contact the lower center part
of the rear bumper, such as grass or trees.
If the vehicle has been parked for a while near objects that may move and contact the
lower center part of the rear bumper, such as grass or trees, the kick sensor may not
operate.
In this situation, move the vehicle from the current position and then check if the kick
sensor operates.
If it does not operate, have the vehicle inspected by your Lexus dealer.
● Do not subject the kick sensor or its surrounding area to a strong impact.
If the kick sensor or its surrounding area has been subjected to a strong impact, the
kick sensor may not operate properly.
*4
1
Before driving
*4 :
Vehicles with Hands Free Power Back Door
75
1-3. Entering/exiting the vehicle and loading luggage
NOTICE
If the kick sensor does not operate in the following situations, have the vehicle
inspected by your Lexus dealer.
• The kick sensor or its surrounding area has been subjected to a strong impact.
• The lower center part of the rear bumper is scratched or damaged.
● Do not disassemble the rear bumper.
● Do not attach stickers to the rear bumper.
● Do not paint the rear bumper.
● If a bicycle carrier or similar heavy object is attached to the power back door, disable
the kick sensor.
INFORMATION
■ Kick sensor operating conditions
● When the kick sensor operation setting is turned on
● The electronic key is within the operational range
■ Situations in which the kick sensor does not operate properly
In the following situations, the kick sensor may not operate properly:
● When a foot remains under the rear bumper
● If the rear bumper is strongly hit with a foot or is touched for a while
If the rear bumper has been touched for a while, wait for a short time before attempting to operate the back door again.
● When operated while a person is too close to the rear bumper
● When an external radio wave source interferes with the communication between the
vehicle and electronic key
● When the vehicle is parked near an electrical noise source which affects the sensitivity
of the kick sensor, such as a pay parking spot, gas station, electrically heated road, or
fluorescent light
● When the vehicle is near a TV tower, electric power plant, radio station, large display,
airport or other facility that generates strong radio waves or electrical noise
● When a large amount of water is applied to the rear bumper, such as when the vehicle
is being washed or in heavy rain
● When mud, snow or ice is attached to the rear bumper
● When the vehicle has been parked for a while near objects that may move and contact
the rear bumper, such as plants
76
1-3. Entering/exiting the vehicle and loading luggage
● When an accessory is installed to the rear bumper
If an accessory has been installed, turn the kick sensor operation setting off.
■ Situations in which the kick sensor may operate unintentionally
When an electronic key is in the operation range, the kick sensor may operate unintentionally, so be careful in the following situations.
● When a large amount of water is applied to the rear bumper, such as when the vehicle
is being washed or in heavy rain
● When dirt is wiped off the rear bumper
● When a small animal or small object, such as a ball, moves under the rear bumper
● When an object is moved from under the rear bumper
● If someone is swinging their legs while sitting on the rear bumper
● If the legs or another part of someone’s body contacts the rear bumper while passing
by the vehicle
● When the vehicle is parked near an electrical noise source which affects the sensitivity
of the kick sensor, such as a pay parking spot, gas station, electrically heated road, or
fluorescent light
● When the vehicle is near a TV tower, electric power plant, radio station, large display,
airport or other facility that generates strong radio waves or electrical noise
● When the vehicle is parked in a place where objects such as plants are near the rear
bumper
● If luggage is set near the rear bumper
● If accessories or a vehicle cover is installed/removed near the rear bumper
● When the vehicle is being towed
To prevent unintentional operation, turn the kick sensor operation setting off.
1
Before driving
Open/close the back door using the kick sensor(vehicles with Hands Free
Power Back Door)
WARNING
Observe the following precautions when operating the power back door.
● Check the safety of the surrounding area to make sure there are no obstacles or
anything that could cause any of your belongings to get caught.
● When putting your foot near the lower center part of the rear bumper and moving it
from the rear bumper, be careful not to touch the exhaust pipes until they have cooled
down sufficiently.
77
1-3. Entering/exiting the vehicle and loading luggage
WARNING
If the exhaust pipes are hot, they can cause burns.
● Do not operate the Hands Free Power Back Door if there is little space under the rear
bumper.
A
Kick sensor
B
Kick sensor detection area
C
Smart entry & start system operation detection area
1 While carrying an electronic key, stand with-
in the smart entry & start system operation
range, approximately 50 to 70 cm (19.7 to
27.6 in.) from the rear bumper.
2 Move your foot to approximately 10 cm (3.9
in.) from the rear bumper.
Operate the back door without contacting the
rear bumper with your foot.
3 When a buzzer sounds, move your foot back. A buzzer will sound and the
back door will automatically fully open or close.
● Perform the entire kick operation within 1 second.
● The back door will not start operating while a foot is detected under the rear
bumper.
● If another electronic key is in the cabin or luggage compartment, it may take slightly
longer than normal for the operation to occur.
● If the buzzer sounds twice, perform a kick operation again.
If a kick operation is performed while the power back door is operating, the power
back door will stop.
INFORMATION
When all of the doors are locked, if a kick operation is detected by the kick sensor, all
of the doors will unlock.
Adjusting the open position of the back door(vehicles with the power back
door)
The open position of the power back door can be adjusted.
1 Stop the back door in the desirable position.
78
1-3. Entering/exiting the vehicle and loading luggage
2 Press and hold the switch on the lower part of the back door for
approximately 2 seconds.
When the settings are completed, the buzzer sounds 4 times.
When opening the back door the next time, the back door will stop at that position.
Canceling the adjusted open position of the back door
● Press and hold the switch on the lower part of the back door for
approximately 7 seconds.
After the buzzer sounds 4 times, it sounds twice more.
When the power back door does the opening operation the next time, the door will
open to the initial settings position.
Rear seat seatbacks
Folding the seat backs can be done with either lever or switch operations.
WARNING
■ When operating the rear seatback
Observe the following precautions.
● Do not operate the rear seat if it is occupied.
● After adjusting the seat, make sure that the seat is locked in position. If the seatback is
not securely locked, the red marking will be visible. Make sure that the red marking is
not visible.
1
Before driving
■ When a rear seatback is folded
Observe the following precautions.
● Do not fold down the rear seatbacks while driving.
● Stop the vehicle on level ground, apply the parking brake and change the shift position
to P.
● Do not allow anyone to sit on a folded rear seatback or in the luggage compartment
while driving.
79
1-3. Entering/exiting the vehicle and loading luggage
WARNING
● Do not allow children to enter the luggage compartment.
■ After adjusting the rear seats
Observe the following precautions.
● Make sure that the rear seatback is securely locked in position by lightly pushing it
back and forth.
If the seatback is not securely locked, the red marking will be visible. Make sure that
the red marking is not visible.
● Check that the seat belts are not twisted or caught between or behind in the rear
seatback.
■ Jam protection function (power seat)
Observe the following precautions.
● Never use any part of your body to intentionally activate the jam protection function.
● The jam protection function may not operate if something is caught just before the
seatback is fully returned. Be careful so that fingers, etc. do not get caught.
● The jam protection function may not operate depending on the shape or position of
the obstruction. Be careful so that fingers, etc. do not get caught.
NOTICE
The seat belt for the rear center seat, seat belt buckles and armrest must be stowed
before you fold down the rear seatbacks.
Automatic folding of the rear seat seatbacks by pressing the switch in the
luggage compartment (vehicles with power seats)
INFORMATION
■ Operating conditions for folding down the seatback
When all of the following conditions are met, a rear seat operation switch can be used to
fold down the rear seatback:
80
1-3. Entering/exiting the vehicle and loading luggage
● When the back door is open.
● When the other operation switches for the seat being operated are not pressed.
When the engine switch is in ON, in addition to the above, the power seat operates for
any of the following conditions:
● Parking brake is engaged
● The brake pedal is depressed
● The shift position is in P
1 Stow the rear center seat belt, seat belt buckles and armrest.
2 Lower the head restraint of the rear seat.
3 Press and hold the switch to fold down the
corresponding seatback.
A buzzer will sound and the seatback folding
operation will begin. When the operation is completed, the buzzer will sound again.
To stop the seatback folding operation partway,
press either side of the rear seat switch or the
switch in the luggage compartment for the operating seat. When the operation stops, a buzzer will sound.
1
Before driving
If the seatback is outside of the range shown in the illustration, it will not be possible
to stop the operation.
Automatic folding of the rear seat seatbacks by touching the switch on the
center display (vehicles with power seats)
INFORMATION
■ Operating conditions for folding down the seatback
When all of the following conditions are met, a rear seat operation switch can be used to
fold down the rear seatback:
When the other operation switches for the seat being operated are not pressed.
81
1-3. Entering/exiting the vehicle and loading luggage
When the engine switch is in ON, in addition to the above, the power seat operates for
any of the following conditions:
● Parking brake is engaged
● The brake pedal is depressed
● The shift position is in P
1 Stow the rear center seat belt, seat belt buckles and armrest.
2 Lower the head restraint of the rear seat.
3
Touch the on the main menu.
4 Touch the [Seats].
5 When folding down all of the seatbacks: Touch [Fold all]. When folding down a
selected seatback: Touch the seat you wish to adjust, and then touch [Fold].
A buzzer will sound and the seatback folding operation will begin. When the operation
is completed, the buzzer will sound again.
Fold the rear seatbacks manually
1 Stow the rear center seat belt, seat belt buckles and armrest.
2 Lower the head restraint of the rear seat.
3 Pull the seatback angle adjustment lever and
fold down the seatback.
Automatic returning of the rear seat seatbacks by pressing the rear seat
switch/switch in the luggage compartment (vehicles with power seats)
INFORMATION
■ Operating conditions for folding down the seatback
When all of the following conditions are met, a rear seat operation switch can be used to
fold down the rear seatback:
● When operating the rear seat switch: When the rear door for the seat to be operated
is open.
82
1-3. Entering/exiting the vehicle and loading luggage
● When operating the luggage compartment switch: When the back door is open.
● When the other operation switches for the seat being operated are not pressed.
When the engine switch is in ON, in addition to the above, the power seat operates for
any of the following conditions:
● Parking brake is engaged
● The brake pedal is depressed
● The position lever is in P
■ Seatback jam protection function
When returning the seatback, if an object is detected between the seatback and seat
cushion, the seatback will move in the opposite direction and then stop. A buzzer will
sound intermittently when the seatback is moving in the opposite direction. When it stops
moving, the seatback can be operated again.
1 Using the rear seat switch/switch in the luggage compartment:Press either
switch to return the seatback.
▶ Rear seat switch
1
Before driving
▶ Switch in the luggage compartment
A buzzer will sound and the seatback returning operation will begin. When the
operation is completed, the buzzer will sound again.
83
1-3. Entering/exiting the vehicle and loading luggage
To stop the seatback return operation partway, press either side of the rear seat switch
or the switch in the luggage compartment for the operating seat. When the operation
stops, a buzzer will sound.
2 Check that the plate for each seat belt is on
the front side of the seat.
Automatic returning of the rear seat seatbacks by touching the switch on the
center display (vehicles with power seats)
INFORMATION
■ Operating conditions for folding down the seatback
When all of the following conditions are met, a rear seat operation switch can be used to
fold down the rear seatback:
When the other operation switches for the seat being operated are not pressed.
When the engine switch is in ON, in addition to the above, the power seat operates for
any of the following conditions:
● Parking brake is engaged
● The brake pedal is depressed
● The position lever is in P
■ Seatback jam protection function
When returning the seatback, if an object is detected between the seatback and seat
cushion, the seatback will move in the opposite direction and then stop. A buzzer will
sound intermittently when the seatback is moving in the opposite direction. When it stops
moving, the seatback can be operated again.
1
Touch the
on the main menu.
2 Touch the [Seats].
3 When returning a selected seatback: Touch the seat you wish to adjust, and
then touch [Raise]. When returning all of the seatbacks: Touch [Raise all].
A buzzer will sound and the seatback returning operation will begin. When the
operation is completed, the buzzer will sound again.
84
1-3. Entering/exiting the vehicle and loading luggage
To stop the seatback return operation partway, touch [Cancel]stop on the center
display.
4 Check that the plate for each seat belt is on
the front side of the seat.
Return the rear seatbacks manually
1 Raise the rear seatback until it locks.
2 Check that the plate for each seat belt is on
the front side of the seat.
1
Before driving
85
1-3. Entering/exiting the vehicle and loading luggage
Trailer towing (vehicles with towing package)
Trailer towing
Your vehicle is designed primarily as a passenger carrying vehicle. Towing a trailer
will have an adverse effect on handling, performance, braking, durability, and fuel
consumption. For your safety and the safety of others, do not overload the vehicle
or trailer. Lexus warranties do not apply to damage or malfunction caused by
towing a trailer for commercial purposes.
INFORMATION
■ Before towing
Check that the following conditions are met:
● The vehicle's tires are properly inflated.
● Trailer tires are inflated according to the trailer manufacturer's recommendation.
● All trailer lights work.
● All lights work each time you connect them.
● The trailer ball is set up at the proper height for the coupler on the trailer.
● The trailer is level when it is hitched.
Do not drive if the trailer is not level, and check for improper tongue weight, overloading, worn suspension, or other possible causes.
● The trailer cargo is securely loaded.
● The rear view mirrors conform to all applicable federal, state/provincial or local
regulations. If they do not, install rear view mirrors appropriate for towing purposes.
■ Break-in schedule
Lexus recommends that you do not use a new vehicle or a vehicle with any new power
train components (engine, transmission, differential, wheel bearings, etc.) to tow a trailer
for the first 800 km (500 miles) of driving.
■
Maintenance
● If you tow a trailer, your vehicle will require more frequent maintenance due to the
additional load. (See "Warranty and Service Booklet".)
● Retighten the fixing bolts of the towing ball and bracket after approximately 1000 km
(600 miles) of trailer towing.
86
1-3. Entering/exiting the vehicle and loading luggage
WARNING
■ To avoid accident or injury
● The total trailer weight (trailer weight plus the weight of cargo) must not exceed the
following:
For Australia: 1000 kg (2205 lb.)
For New Zealand: 1500 kg (3307 lb.)
● The gross combined weight (sum of your vehicle weight plus its load and the total
trailer weight) must not exceed the following:
2WD models:
•
For Australia: 3205 kg (7066 lb.)
•
For New Zealand: 3705 kg (8168 lb.)
AWD models:
•
For Australia: 3370 kg (7430 lb.)
•
For New Zealand: 3870 kg (8532 lb.)
● Do not exceed the trailer hitch assembly weight, gross vehicle weight, gross axle
weight and trailer tongue load capacities.
● Never load more weight in the back than in the front of the trailer. About 60% of the
load should be in the front half of the trailer, and the remaining 40% in the rear.
■ When towing a trailer
● If the total trailer weight exceeds the following, trailer brakes are required.
For Australia: 500 kg (1102 lb.)
For New Zealand: 750 kg (1653 lb.)
● Never tap into your vehicle's hydraulic system, as this will lower the vehicle's braking
effectiveness.
● Never tow a trailer without using a safety chain securely attached to both the trailer
and the vehicle. If damage occurs to the coupling unit or hitch ball, there is a risk of the
trailer wandering into another lane.
■ When the gross vehicle mass or maximum permissible axle capacity is exceeded
1
Before driving
Failing to observe this precaution may lead to an accident causing death or serious injury.
● Add an additional 20.0 kPa (0.2 kgf/cm
2
or bar, 3 psi) to the recommended tire
inflation pressure value.
● Do not exceed the established speed limit for towing a trailer in built-up areas or 100
km/h (62 mph), whichever is lower.
87
1-3. Entering/exiting the vehicle and loading luggage
NOTICE
Lexus recommends trailers with brakes that conform to all applicable federal and state/
provincial regulations.
Weight
For towing purposes, Lexus recommends using a sway control device when the
total trailer weight is greater than the vehicle weight.
■ Weight limits
Confirm that the total trailer weight, gross vehicle weight, gross axle weight and
trailer tongue load are all within the limits.
■ Gross vehicle weight
The gross vehicle weight must not exceed the following:
2WD models: 2205 kg (4861 lb.)
AWD models: 2370 kg (5225 lb.)
The gross vehicle weight is the sum weight of the unloaded vehicle, driver, passengers, luggage, hitch and trailer tongue load. Also included is the weight of any
special equipment installed on your vehicle.
■ Gross axle weight
The load on either the front or rear axle resulting from distribution of the gross
vehicle weight on both axles must not exceed 1270 kg (2800 lb.).
■ Trailer tongue load
The trailer cargo load should be distributed so that the tongue load is 9 to 11% of
the total trailer weight, not exceed the following:
For Australia: 100 kg (220.5 lb.)
For New Zealand: 150 kg (330.7 lb.)
(Tongue load/Total trailer weight × 100 = 9 to 11%)
The total trailer weight and tongue load can be measured with platform scales
found at a highway weighing stations, building supply companies, trucking companies, junk yards, etc.
88
1-3. Entering/exiting the vehicle and loading luggage
A
Total trailer weight
B
Tongue load
Towing a trailer
Contact your Lexus dealer for further information about additional requirements
such as a towing kits etc.
Hitch
Trailer hitch assemblies have different weight capacities established by the hitch
manufacturer. Even though the vehicle may be rated for towing a higher weight, the
operator must never exceed the maximum weight rating specified for the trailer
hitch.
For vehicles where the towing device blocks any of the lights or license plate, the
following shall be observed:
● Do not use towing devices that cannot be easily removed or repositioned.
1
Before driving
● Towing devices must be removed or repositioned when not in use.
WARNING
Observe the following precautions.
● Use only a hitch that conforms to the total trailer weight requirement.
● Follow the directions supplied by the hitch manufacturer.
● Depending on the type of trailer coupler you use, the trailer ball may need to be
coated with grease. If so, apply grease to the trailer ball in accordance with the
instructions of the manufacturer of the trailer coupler.
● Remove the trailer ball whenever you are not towing a trailer. Remove the trailer hitch
if you do not need it. After removing the hitch, seal any mounting holes in the vehicle
body to prevent entry of any substances into the vehicle.
NOTICE
Observe the following precautions.
● Use only the position recommended by your Lexus dealer. Do not install the trailer
hitch on the bumper; this may cause body damage.
89
1-3. Entering/exiting the vehicle and loading luggage
NOTICE
● Do not use axle-mounted hitches, as they can cause damage to the axle housing,
wheel bearings, wheels or tires.
Connecting trailer lights
Please consult your Lexus dealer when installing trailer lights, as incorrect installation may cause damage to the vehicle's lights. Please take care to comply with your
state's laws when installing trailer lights.
NOTICE
Do not directly splice trailer lights. Directly splicing trailer lights may damage your
vehicle's electrical system and cause a malfunction.
Trailer towing tips
Your vehicle will handle differently when towing a trailer. In order to avoid accident,
death or serious injury, keep the following in mind when towing:
Before starting out, check the trailer lights and the vehicle-trailer connections.
●
Recheck after driving a short distance.
● Practice turning, stopping and reversing with the trailer attached in an area away
from traffic until you become accustomed to the feel of the vehicle.
● Reversing with a trailer attached is difficult and requires practice. Grip the
bottom of the steering wheel and move your hand to the left to move the
trailer to the left. Move your hand to the right to move the trailer to right. (This
is generally opposite to reversing without a trailer attached.) Avoid sharp or
prolonged turning. Have someone guide you when reversing to reduce the risk
of an accident.
● As stopping distance is increased when towing a trailer, vehicle-to-vehicle
distance should be increased. For each 10 km/h (6 mph) of speed, allow at least
one vehicle and trailer length.
● Avoid sudden braking as you may skid, resulting in jackknifing and loss of
control. This is especially true on wet or slippery surfaces.
● Avoid jerky starts or sudden acceleration.
● Avoid jerky steering and sharp turns, and slow down before making turns.
90
1-3. Entering/exiting the vehicle and loading luggage
● Note that when making a turn, the trailer wheels will be closer than the vehicle
wheels to the inside of the turn. Compensate by making a larger than normal
turning radius.
● Crosswinds and rough roads will adversely affect handling of your vehicle and
trailer, causing sway. Periodically check the rear to prepare for being passed
by large trucks or buses, which may cause your vehicle and trailer to sway.
If swaying occurs, firmly grip the steering wheel, reduce speed immediately
but gradually, and steer straight ahead. Never increase speed. If you make no
extreme correction with the steering or brakes, your vehicle and trailer will
stabilize.
Take care when passing other vehicles. Passing requires considerable distance.
●
After passing a vehicle, do not forget the length of your trailer, and be sure you
have plenty of room before changing lanes.
To maintain engine braking efficiency and charging system performance, when
●
using engine braking, do not use the transmission in D. If in the M mode, the
transmission shift range position must be in 6 or lower.
Due to the added load of the trailer, your vehicle's engine may overheat on
●
hot days (at temperatures over 30°C [85°F]) when driving up a long or
steep grade. If the engine coolant temperature gauge indicates overheating.
Immediately turn off the air conditioning (if in use), pull your vehicle off the road
and stop in a safe spot.
1
Before driving
WARNING
Observe the following precautions.
● Observe the legal maximum speeds for trailer towing.
● Slow down and downshift before descending steep or long downhill grades. Do not
make sudden downshifts while descending steep or long downhill grades.
● Avoid holding the brake pedal down too long or applying the brakes too frequently.
This could cause the brakes to overheat and result in reduced braking efficiency.
Parking on a slope when towing a trailer
Always place wheel blocks under both the vehicle and the trailer wheels when
parking. Apply the parking brake and put the transmission in P. Avoid parking on a
slope, but if unavoidable, do so only after performing the following:
1 Apply the brakes and keep them applied.
2 Have someone place wheel blocks under both the vehicle and trailer wheels.
91
1-3. Entering/exiting the vehicle and loading luggage
3 When the wheel blocks are in place, release the brakes slowly until the blocks
absorb the load.
4 Apply the parking brake.
5 Shift into P and turn off the engine.
Starting off on a slope when towing a trailer
1 With the transmission in the P, start the engine.
2 Be sure to keep the brake pedal depressed.
3 Shift into a forward gear.
If reversing, shift into R.
4 If the parking brake is in manual mode, release the parking brake.
5 Release the brake pedal, and slowly pull or back away from the wheel blocks.
Stop and apply the brakes.
6 Have someone retrieve the blocks.
92
1-3. Entering/exiting the vehicle and loading luggage
Trailer towing (vehicles without towing package)
Lexus does not recommend towing a trailer with your vehicle. Lexus also does not
recommend the installation of a tow hitch or the use of a tow hitch carrier for a
wheelchair, scooter, bicycle, etc. Your vehicle is not designed for trailer towing or
for the use of tow hitch mounted carriers.
1
Before driving
93
1-3. Entering/exiting the vehicle and loading luggage
Opening and closing the windows
WARNING
Observe the following precautions. The driver is responsible for all power window
operations, including the operation for the passengers.
● Do not let a child operate the power windows. Operation by a child may cause a child
or other passengers to have a body part caught in a power window. Also, when riding
with a child, it is recommended to turn the window lock switch on.
● Check to make sure that all passengers do not have any part of their body in a position
where it could be caught when a window is being operated.
● When exiting the vehicle, turn the engine switch off, carry the key and exit the vehicle
along with the child. There may be accidental operation, due to mischief, etc., that may
possibly lead to an accident.
INFORMATION
■ Operating conditions of the power windows
The engine switch is in ON.
■ Operating the power windows after turning the engine off
The power windows can be operated for approximately 45 seconds after the engine
switch is turned to ACC or OFF.
They cannot, however, be operated once either front door is opened.
■ Using the voice control system
The following operations can be performed using the voice control system:
● Opening/closing of all of the windows simultaneously
● Opening/closing of each window individually
(Operation is possible only when the window lock switch is off.)
For details, refer to the "Multimedia Owner's Manual".
*
Functions which aid in safe opening and closing of the windows
The following functions aid in safe opening and closing of the windows.
● Jam protection function
If an object becomes jammed between the window and the window frame while
the window is closing, window movement is stopped and the window is opened
slightly.
* :
If equipped
94
1-3. Entering/exiting the vehicle and loading luggage
● Catch protection function
If an object becomes caught between the door and window while the window is
opening, window movement is stopped.
● Power windows open warning buzzer
The buzzer sounds and a message is shown on the multi-information display in
the instrument cluster when the engine switch is turned off and the driver’s door
is opened with the power windows open.
WARNING
■ Jam protection function
● Never use any part of your body to intentionally activate the jam protection function.
● The jam protection function may not work if something gets jammed just before the
window is fully closed.
Be careful not to get any part of your body jammed in the window.
■ Catch protection function
● Never use any part of your body or clothing to intentionally activate the catch
protection function.
● Be careful not to get any part of your body or clothing caught in the window. The catch
protection function may not work if something gets caught just before the window is
fully opened.
1
Before driving
Operations using the power window switches
Opening/closing the windows using the power window switch
1 Lift the power window swich partway.
The window will close while the switch is
lifted.
2 Fully lift the power window swich.
The window will fully close automatically.
To stop the window partway, operate the switch
in the opposite direction.
3 Push the power window swich partway.
The window will open while the switch is
pushed.
4 Fully push the power window switch.
The window will fully open automatically.
95
1-3. Entering/exiting the vehicle and loading luggage
To stop the window partway, operate the switch
in the opposite direction.
Operations using the wireless remote control
The power windows can be opened and closed using the wireless remote control.
WARNING
When using the wireless remote control or to operate the power windows, operate the
power windows after making sure that there is no possibility of any passenger having any
of their body parts caught in a power window. Also do not let a child operate the windows
using the wireless remote control. Children and other passengers may get caught in the
power window.
Related Links
Customizable features(P. 610)
Open the windows using the wireless remote control
Using the wireless remote control, the doors can be unlocked and all of the
windows opened at the same time.
*2
*1
●
Push and hold the unlock switch on the wireless remote control.
The doors will unlock and the windows and moon roof* or panoramic moon roof* will
open.
A buzzer sounds to indicate that all of the windows and the moon roof* or panoramic
moon roof* are opening.
*1 :
These settings must be customized at your Lexus dealer.
*2 :
This setting must be customized at your Lexus dealer.
* :
If equipped
96
1-3. Entering/exiting the vehicle and loading luggage
Close the windows using the wireless remote control
Using the wireless remote control, the doors can be locked and all of the windows
closed at the same time.
● Press and hold the lock switch on the wireless remote control.
All of the doors will lock and the windows and moon roof* or panoramic moon roof*will
close.
A buzzer sounds to indicate that all of the windows and the moon roof * or panoramic
moon roof* are opening/closing.
Check that the doors are securely locked and the windows are fully closed.
*3
Prevent accidental operation of the windows
The window lock switch is designed to prevent children from accidentally opening
or closing a window.
1
Before driving
Press the window lock switch.
The indicator
windows will be locked.
*3 :
This setting must be customized at your Lexus dealer.
* :
If equipped
will come on and the passenger
97
1-4. Obtaining the correct driving posture
Obtaining the correct driving posture
Adjusting the seats
Adjusting the front seats
Adjust the seat forward/backward and up/down as necessary to obtain a correct
posture.
A
Seat position adjustment switch
B
Seat cushion (front) angle adjustment
switch
C
Vertical height adjustment switch
D
Seatback angle adjustment switch
E
Lumbar support firmness adjustment switch
(for driver’s side)
F
Lumbar support height adjustment switch
(for driver’s side)
INFORMATION
■ When adjusting the seats
Take care so that a head restraint does not contact the ceiling or a sun visor.
*
WARNING
Observe the following when adjusting the seats.
● Do not adjust the position of the driver’s seat while driving.
Doing so could cause the driver to lose control of the vehicle.
● Be careful so that the seat does not contact and injure a passenger.
● Do not place anything under the front seats.
Objects placed under the front seats may become jammed in the seat tracks and
stop the seat from locking in place. This may lead to an accident and the adjustment
mechanism may also be damaged.
● Do not put your hands under the seat or near the moving parts to avoid injury.
Fingers or hands may become jammed in the seat mechanism.
● To reduce the risk of sliding under the lap belt during a collision, do not recline the seat
more than necessary.
* :
If equipped
98
Loading...
