Lenovo RD210 User Manual

21.44 Mb

Installation and User Guide

ThinkServer RD210 Types 3795, 3796, 3818, and 3819

ThinkServer RD210 Types 3795, 3796, 3818, and 3819

Installation and User Guide

Note: Before using this information and the product it supports, read the general information in Appendix B, “Notices,” on page 171 and the Warranty and Support Information document on the ThinkServer Documentation DVD.

First Edition (June 2009)

© Copyright Lenovo 2008, 2009.

Portions © Copyright International Business Machines Corporation 2007, 2008. All rights reserved.

LENOVO products, data, computer software, and services have been developed exclusively at private expense and are sold to governmental entities as commercial items as defined by 48 C.F.R. 2.101 with limited and restricted rights to use, reproduction and disclosure.

LIMITED AND RESTRICTED RIGHTS NOTICE: If products, data, computer software, or services are delivered pursuant a General Services Administration ″GSA″ contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-35F-05925.

Contents

Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii

Chapter 1. Introduction . . . . . . . . . . . . . . . . . . . . . . 1 Notices and statements in this document . . . . . . . . . . . . . . . . 2 Related documentation . . . . . . . . . . . . . . . . . . . . . . 2

Chapter 2. Server setup roadmap . . . . . . . . . . . . . . . . . . 5

Chapter 3. What is included with your server . . . . . . . . . . . . . 7 Features and technologies . . . . . . . . . . . . . . . . . . . . . 7 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . 10 Software . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 EasyStartup . . . . . . . . . . . . . . . . . . . . . . . . . 12 EasyManage. . . . . . . . . . . . . . . . . . . . . . . . . 12 Reliability, availability, and serviceability . . . . . . . . . . . . . . . . 12

Chapter 4. Server controls, LEDs, and power. . . . . . . .

. .

. .

.

15

Front view . . . . . . . . . . . . . . . . . . . . .

. .

. .

.

15

Operator information panel . . . . . . . . . . . . . . .

. .

. .

.

16

EasyLED diagnostics panel . . . . . . . . . . . . . . .

. .

. .

.

17

Rear view . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 System-board internal connectors . . . . . . . . . . . . . . . . . . 27 System-board external connectors . . . . . . . . . . . . . . . . . . 28 System-board optional-device connectors . . . . . . . . . . . . . . . 29 System-board switches and jumpers . . . . . . . . . . . . . . . . . 30 System-board LEDs . . . . . . . . . . . . . . . . . . . . . . . 33 Power-supply LEDs . . . . . . . . . . . . . . . . . . . . . . . 34 System pulse LEDs . . . . . . . . . . . . . . . . . . . . . . . 34 Server power features . . . . . . . . . . . . . . . . . . . . . . 35

Turning on the server

. .

. .

. .

. .

.

.

.

. . .

.

. . .

. .

.

35

Turning off the server

. .

. .

. .

. .

.

.

.

. . .

.

. . .

. .

.

36

Chapter 5. Installing optional devices and replacing customer replaceable units. . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Installation guidelines . . . . . . . . . . . . . . . . . . . . . . 39 System reliability guidelines . . . . . . . . . . . . . . . . . . . 40 Working inside the server with the power on . . . . . . . . . . . . . 40 Handling static-sensitive devices . . . . . . . . . . . . . . . . . 41

Major components of the server .

. . . . . . . . . . . . . . .

.

.

42

Removing and replacing the cover.

. . . . . . . . . . . . . . .

.

.

43

Removing the cover . . . . . . . . . . . . . . . . . . . . . . 43 Replacing the cover . . . . . . . . . . . . . . . . . . . . . . 44

Internal cable routing and connectors . . . . . . . . . . . . .

.

.

.

44

Removing and installing the microprocessor 2 air baffle . . . . . . .

.

.

.

47

Removing the microprocessor 2 air baffle . . . . . . . . . . .

.

.

.

47

Installing the microprocessor 2 air baffle . . . . . . . . . . .

.

.

.

48

Removing and installing the DIMM air baffle . . . . . . . . . . .

.

.

.

48

Removing the DIMM air baffle . . . . . . . . . . . . . . .

.

.

.

48

Installing the DIMM air baffle . . . . . . . . . . . . . . . .

.

.

.

50

Removing and installing a hot-swap hard disk drive . . . . . . . .

.

.

.

50

Removing a hot-swap hard disk drive . . . . . . . . . . . .

.

.

.

51

Installing a hot-swap hard disk drive . . . . . . . . . . . . .

.

.

.

51

IDs for hot-swap hard disk drives . . . . . . . . . . . . . .

.

.

.

53

© Lenovo 2008, 2009. Portions © IBM Corp. 2007, 2008.

iii

Removing and installing a PCI riser-card assembly

. . . . . . . . .

.

.

53

Removing a PCI riser-card assembly . . . . .

. . . . . . . . .

.

.

53

Installing a PCI riser card assembly . . . . .

. . . . . . . . .

.

.

54

Removing and installing an adapter . . . . . .

. . . . . . . . .

.

.

55

Removing an adapter . . . . . . . . . .

. . . . . . . . .

.

.

56

Installing an adapter . . . . . . . . . . . . . . . . . . . . . . 57

Removing and installing a memory module (DIMMs) . . . . . . . . .

.

.

58

Removing a memory module (DIMMs) . . . . . . . . . . . . .

.

.

58

Installing a memory module (DIMMs). . . . . . . . . . . . . .

.

.

58

Removing and installing the IBM ServeRAID-BR10i SAS/SATA Controller .

.

. 64

Removing the IBM ServeRAID-BR10i SAS/SATA Controller . . . . .

.

. 64

Installing the IBM ServeRAID-BR10i SAS/SATA Controller . . . . . .

.

.

65

Removing and installing the optional IBM ServeRAID-MR10i SAS/SATA

Controller . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Removing the optional IBM ServeRAID-MR10i SAS/SATA Controller .

. .

. 68

Installing the optional IBM ServeRAID-MR10i SAS/SATA Controller. .

. .

.

68

Removing and installing a microprocessor and heat sink . . . . . .

. .

.

71

Removing a microprocessor and heat sink. . . . . . . . . . .

. .

.

71

Installing a microprocessor and heat sink . . . . . . . . . . .

. .

.

72

Thermal grease. . . . . . . . . . . . . . . . . . . . . . . . 75

Removing and installing a hot-swap power supply . . . . . . . .

. . .

.

76

Removing a hot-swap power supply . . . . . . . . . . . .

. . .

.

77

Installing a hot-swap power supply . . . . . . . . . . . .

. . .

.

78

Removing and installing a hot-swap fan assembly . . . . . . . .

. . .

.

79

Removing a hot-swap fan assembly . . . . . . . . . . . .

. . .

.

79

Installing a hot-swap fan assembly . . . . . . . . . . . .

. . .

.

80

Removing and installing the SAS/SATA RAID riser-card assembly . .

. . .

.

82

Removing the SAS/SATA RAID riser-card assembly . . . . . .

. . .

.

82

Installing the SAS/SATA RAID riser-card assembly . . . . . . .

. . .

.

82

Removing and installing the battery . . . . . . . . . . . . .

. . .

.

83

Removing the battery . . . . . . . . . . . . . . . . .

. . .

.

83

Installing the battery . . . . . . . . . . . . . . . . . . . . . . 84

Removing and installing the PCI riser-card assembly . . . . . . . . .

.

.

85

Removing the PCI riser-card assembly . . . . . . . . . . . . .

.

.

86

Installing the PCI riser-card assembly . . . . . . . . . . . . .

.

.

86

Removing and installing the hot-swap SAS/SATA hard disk drive backplane





87

Removing the hot-swap SAS/SATA hard disk drive backplane . . . .

.

.

87

Installing the hot-swap SAS/SATA hard disk drive backplane . . . . .

.

.

88

Removing and installing the operator information panel assembly . . . .

.

.

89

Removing the operator information panel assembly . . . . . . . .

.

.

89

Installing the operator information panel assembly . . . . . . . . .

.

.

90

Removing and installing the system board . . . . . . . . . . . . .

.

.

91

Removing the system board . . . . . . . . . . . . . . . . .

.

.

91

Installing the system board . . . . . . . . . . . . . . . . .

.

.

93

Removing and installing a CD/DVD drive . . . . . . . . . . . . .

.

.

94

Removing a CD/DVD drive . . . . . . . . . . . . . . . . .

.

.

94

Installing a CD/DVD drive . . . . . . . . . . . . . . . . . .

.

.

95

Removing and installing the virtual media key . . . . . . . . . . . .

.

100

Removing the virtual media key . . . . . . . . . . . . . . . .

.

100

Installing the virtual media key. . . . . . . . . . . . . . . . .

.

100

Removing and installing the optional two-port Ethernet adapter. . . . . . . 101

Removing the optional two-port Ethernet adapter . . . . . . . .

.

.

.

101

Installing the optional two-port Ethernet adapter . . . . . . . .

.

.

.

102

Removing and installing the PCI riser-card bracket from the riser card .

.

.

.

103

Removing the PCI riser-card bracket from the riser card . . . . .

.

.

.

103

Installing the PCI risercard bracket from the riser card . . . . .

.

.

.

104

iv ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

Removing and installing a remotely installed RAID adapter battery . .

. .

.

105

Removing a remotely installed RAID adapter battery . . . . . .

. .

.

105

Installing a RAID adapter remotely in the server . . . . . . . .

. .

.

106

Removing and installing the bezel . . . . . . . . . . . . . .

. .

.

108

Removing the bezel . . . . . . . . . . . . . . . . . .

. .

.

108

Installing the bezel . . . . . . . . . . . . . . . . . . . . . . 108 Removing and installing the operator information panel assembly . . . . . . 109

Removing the operator information panel assembly . . . . . . . . .

.

109

Installing the operator information panel assembly . . . . . . . . .

.

110

Completing the installation . . . . . . . . . . . . . . . . . . . . 111 Connecting the cables . . . . . . . . . . . . . . . . . . . . . 111

Updating the server configuration. . . . . . . . . . . . . . . .

.

113

Chapter 6. Configuring the server. . . . . . . . . . . . . . . .

.

115

Using the Setup Utility . . . . . . . . . . . . . . . . . . . . .

.

116

Starting the Setup utility . . . . . . . . . . . . . . . . . . .

.

116

UEFI Setup Utility menu choices . . . . . . . . . . . . . . . .

.

116

Passwords . . . . . . . . . . . . . . . . . . . . . . . . . 119

Using the Boot Manager program . . . . . . . . . . . . . . . .

.

122

Configuring RAID controllers . . . . . . . . . . . . . . . . . .

.

122

Using the LSI Configuration Utility program . . . . . . . . . . . .

.

123

Using the WebBIOS utility . . . . . . . . . . . . . . . . . . .

.

125

Starting the WebBIOS utility . . . . . . . . . . . . . . . . .

.

125

Main menu of the WebBIOS utility . . . . . . . . . . . . . . .

.

125

Creating a storage configuration using the Configuration Wizard . . . .

.

126

Viewing and changing adapter properties . . . . . . . . . . . . .

.

126

Viewing and changing virtual disk properties . . . . . . . . . . .

.

126

Using the EasyStartup DVD. . . . . . . . . . . . . . . . . . .

.

127

Before you use the EasyStartup DVD . . . . . . . . . . . . . .

.

127

Configuring RAID . . . . . . . . . . . . . . . . . . . . .

.

128

EasyStartup overview . . . . . . . . . . . . . . . . . . . . . 128 Installing your operating system without using EasyStartup . . . . . . . 130 Enabling the Broadcom Gigabit Ethernet Utility program . . . . . . . . . 130 Updating the firmware . . . . . . . . . . . . . . . . . . . . . . 130

Using the EasyUpdate Firmware Updater tool . . . . . . . . . . .

.

.

131

Starting the backup server firmware. . . . . . . . . . . . . . .

.

.

131

Recovering the UEFI firmware . . . . . . . . . . . . . . . . .

.

.

132

Using the integrated management module . . . . . . . . . . . .

.

.

133

IBM Advanced Settings Utility program. . . . . . . . . . . . . .

.

.

134

Installing ThinkServer EasyManage software . . . . . . . . . . .

.

.

134

Installation requirements . . . . . . . . . . . . . . . . . . . . 134 Installation order . . . . . . . . . . . . . . . . . . . . . . . 135

Installing Windows 2003 components on the Core Server. .

. . . . .

.

135

Installing Windows 2008 32-bit components . . . . . . .

. . . . .

.

136

Uninstalling the LANDesk Software Agent . . . . . . .

. . . . .

.

137

Using the remote presence capability and blue-screen capture . . . . . . . 137

Enabling the remote presence feature . . . . . . . . . . .

. . . . 137

Obtaining the IP address for the IMM . . . . . . . . . . .

. . . . 138

Logging on to the Web interface . . . . . . . . . . . . .

. . . . 138

Configuring the Gigabit Ethernet controllers . . . . . . . . . .

. . . . 138

Chapter 7. Solving problems. . . . . . . . . . . . . . .

. . . . 141

Diagnostic tools . . . . . . . . . . . . . . . . . . . .

. . . . 141

POST . . . . . . . . . . . . . . . . . . . . . . . .

. . . . 142

Error logs . . . . . . . . . . . . . . . . . . . . .

. . . . 142

POST error codes . . . . . . . . . . . . . . . . . .

. . . . 143

Contents v

Troubleshooting tables . . . . . . . . . . . . . . . . . . . . . 144 EasyStartup problems . . . . . . . . . . . . . . . . . . . . . 144 CD/DVD drive problems . . . . . . . . . . . . . . . . . . . . 145

General problems . . . . . . . . . . . . . . . . . . . .

.

.

145

Hard disk drive problems. . . . . . . . . . . . . . . . . .

.

.

146

Intermittent problems . . . . . . . . . . . . . . . . . . . . . 146 Keyboard, mouse, or pointing-device problems. . . . . . . . . . . . 147 Memory problems . . . . . . . . . . . . . . . . . . . . . . 149 Microprocessor problems. . . . . . . . . . . . . . . . . . . . 150

Monitor problems . . .

.

. . . .

.

. . . .

.

. . . . . . .

.

151

Optional-device problems

.

. . . .

.

. . . .

.

. . . . . . .

.

153

Power problems . . . .

.

. . . .

.

. . . .

.

. . . . . . .

.

154

Serial-device problems .

.

. . . .

.

. . . .

.

. . . . . . .

.

156

Software problems . . . . . . . . . . . . . . . . . . . . . . 156 Universal Serial Bus (USB) port problems . . . . . . . . . . . . . 157 Video problems . . . . . . . . . . . . . . . . . . . . . . . 157

EasyLED . . .

. . . . . . . . . . . . . . . .

. .

. . . .

.

157

Remind button

. . . . . . . . . . . . . . . .

. .

. . . .

.

158

EasyLED switch . . . . . . . . . . . . . . . . . . . . . . . 158 EasyLED LEDs . . . . . . . . . . . . . . . . . . . . . . . 159

Diagnostic programs and messages . . . . . . . . . . .

. .

. .

.

163

Power-supply diagnostics . . . . . . . . . . . . . . .

. .

. .

.

163

Appendix A. Getting help and technical assistance . . . . .

. .

. .

.

167

Before you call . . . . . . . . . . . . . . . . . . .

. .

. .

.

167

Using the documentation . . . . . . . . . . . . . . . . . . . . . 167

Getting help and information from the World Wide Web

. . . . . .

.

.

.

167

Calling for service . . . . . . . . . . . . . .

. . . . . .

.

.

.

168

Using other services . . . . . . . . . . . . . . . . . . . . . . 168 Purchasing additional services. . . . . . . . . . . . . . . . . . . 169 Lenovo product service . . . . . . . . . . . . . . . . . . . . . 169

Appendix B. Notices . . . . . . . . . . . . . . . . . . . . . . 171 Trademarks. . . . . . . . . . . . . . . . . . . . . . . . . . 172 Important notes . . . . . . . . . . . . . . . . . . . . . . . . 172 Compliance with Republic of Turkey Directive on the Restriction of Hazardous

Substances . . . . . . . . . . . . . . . . . . . . . . . . . 173

Product recycling and disposal . . . . . . . . . . . . . . . .

.

.

173

Battery return program . . . . . . . . . . . . . . . . . . .

.

.

174

German Ordinance for Work gloss statement . . . . . . . . . . .

.

.

175

Electronic emissions notices . . . . . . . . . . . . . . . . .

.

.

175

Federal Communications Commission (FCC) statement . . . . . .

.

.

175

Industry Canada Class A emission compliance statement . . . . . .

.

.

176

Avis de conformité à la réglementation d'Industrie Canada . . . . .

.

.

176

Australia and New Zealand Class A statement . . . . . . . . . .

.

.

176

United Kingdom telecommunications safety requirement . . . . . .

.

.

176

European Union EMC Directive conformance statement . . . . . .

.

.

176

German Class A compliance statement . . . . . . . . . . . .

.

.

177

Japanese Voluntary Control Council for Interference (VCCI) statement





178

Japanese recycling statements . . . . . . . . . . . . . . .

.

.

178

Taiwanese Class A warning statement . . . . . . . . . . . . .

.

.

179

Chinese Class A warning statement . . . . . . . . . . . . . .

.

.

179

Korean Class A warning statement . . . . . . . . . . . . . .

.

.

179

Index . . . . . . . . . . . . . . . . . . . . . . . . . .

.

.

181

vi ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

Safety

Before installing this product, read the Safety Information.

Antes de instalar este produto, leia as Informações de Segurança.

Pred instalací tohoto produktu si prectete prírucku bezpecnostních instrukcí.

Læs sikkerhedsforskrifterne, før du installerer dette produkt.

Lees voordat u dit product installeert eerst de veiligheidsvoorschriften.

Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Safety Information. Avant d’installer ce produit, lisez les consignes de sécurité.

Vor der Installation dieses Produkts die Sicherheitshinweise lesen.

Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza.

Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet.

Antes de instalar este produto, leia as Informações sobre Segurança.

© Lenovo 2008, 2009. Portions © IBM Corp. 2007, 2008.

vii

Antes de instalar este producto, lea la información de seguridad.

Läs säkerhetsinformationen innan du installerar den här produkten.

Important:

Each caution and danger statement in this document is labeled with a number. This number is used to cross reference an English-language caution or danger statement with translated versions of the caution or danger statement in the Safety Information document.

For example, if a caution statement is labeled “Statement 1,” translations for that caution statement are in the Safety Information document under “Statement 1.”

Be sure to read all caution and danger statements in this document before you perform the procedures. Read any additional safety information that comes with the server or optional device before you install the device.

viii ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

Statement 1:

DANGER

Electrical current from power, telephone, and communication cables is hazardous.

To avoid a shock hazard:

vDo not connect or disconnect any cables or perform installation, maintenance, or reconfiguration of this product during an electrical storm.

vConnect all power cords to a properly wired and grounded electrical outlet.

vConnect to properly wired outlets any equipment that will be attached to this product.

vWhen possible, use one hand only to connect or disconnect signal cables.

vNever turn on any equipment when there is evidence of fire, water, or structural damage.

vDisconnect the attached power cords, telecommunications systems, networks, and modems before you open the device covers, unless instructed otherwise in the installation and configuration procedures.

vConnect and disconnect cables as described in the following table when installing, moving, or opening covers on this product or attached devices.

To Connect:

To Disconnect:

1.

Turn everything OFF.

1.

Turn everything OFF.

2.

First, attach all cables to devices.

2.

First, remove power cords from outlet.

3.

Attach signal cables to connectors.

3.

Remove signal cables from connectors.

4.

Attach power cords to outlet.

4.

Remove all cables from devices.

5.

Turn device ON.













Safety ix

Statement 2:

CAUTION:

When replacing the lithium battery, use only the battery recommended by the manufacturer. If your system has a module containing a lithium battery, replace it only with the same module type made by the same manufacturer. The battery contains lithium and can explode if not properly used, handled, or disposed of.

Do not:

vThrow or immerse into water

vHeat to more than 100°C (212°F)

vRepair or disassemble

Dispose of the battery as required by local ordinances or regulations.

x ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

Statement 3:

CAUTION:

When laser products (such as CD-ROMs, DVD drives, fiber optic devices, or transmitters) are installed, note the following:

vDo not remove the covers. Removing the covers of the laser product could result in exposure to hazardous laser radiation. There are no serviceable parts inside the device.

vUse of controls or adjustments or performance of procedures other than those specified herein might result in hazardous radiation exposure.

DANGER

Some laser products contain an embedded Class 3A or Class 3B laser diode. Note the following.

Laser radiation when open. Do not stare into the beam, do not view directly with optical instruments, and avoid direct exposure to the beam.

Class 1 Laser Product

Laser Klasse 1

Laser Klass 1

Luokan 1 Laserlaite

`

Appareil A Laser de Classe 1

Safety xi

Statement 4:

≥ 18 kg (39.7 lb)

≥ 32 kg (70.5 lb)

≥ 55 kg (121.2 lb)

CAUTION:

Use safe practices when lifting.

Statement 5:

CAUTION:

The power control button on the device and the power switch on the power supply do not turn off the electrical current supplied to the device. The device also might have more than one power cord. To remove all electrical current from the device, ensure that all power cords are disconnected from the power source.

2 1

xii ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

Statement 8:

CAUTION:

Never remove the cover on a power supply or any part that has the following label attached.

Hazardous voltage, current, and energy levels are present inside any component that has this label attached. There are no serviceable parts inside these components. If you suspect a problem with one of these parts, contact a service technician.

Statement 26:

CAUTION:

Do not place any object on top of rack-mounted devices.

This server is suitable for use on an IT power-distribution system whose maximum phase-to-phase voltage is 240 V under any distribution fault condition.

Safety xiii

xiv ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

Chapter 1. Introduction

The Lenovo® ThinkServerRD210 Types 3795, 3796, 3818, and 819 server is a 1-U-high rack model server for-volume network transaction processing. The high-performance, dual-core, or quad-core server is ideally suited for networking environments that require superior microprocessor performance, input/output (I/O) flexibility, and high manageability.

Performance, ease of use, reliability, and expansion capabilities were key considerations in the design of the server. These design features make it possible for you to customize the system hardware to meet your needs today and provide flexible expansion capabilities for the future.

The server comes with a limited warranty. For information about the terms of the warranty and getting service and assistance, see the Warranty and Support Information document.

You can obtain up-to-date information about the server and other Lenovo server products at http://www.lenovo.com/thinkserver.

The server comes with the ThinkServer EasyStartup DVD to help you configure the hardware, install device drivers, and install the operating system.

This server supports six 2.5-inch hot-swap Serial Attached SCSI (SAS) hard disk drives. The illustrations in this document might differ slightly from your model.

Record information about the server in the following table.

Product name

ThinkServer RD210

Machine types

3795, 3796, 3818, and 3819

Model number

_____________________________________________

Serial number

_____________________________________________





The model number and serial number are on the ID label on the ID label on the bezel 1, as shown in the following illustration.

Note: The illustrations in this document might differ slightly from your hardware. The server comes with the ThinkServer EasyStartup DVD to help you configure the hardware and install the operating system.

For a list of supported optional devices for the server, see http://www.lenovo.com/ thinkserver.

© Lenovo 2008, 2009. Portions © IBM Corp. 2007, 2008.

1

Notices and statements in this document

The caution and danger statements in this document are also in the multilingual

Safety Information document, which is on the Lenovo ThinkServer Documentation

DVD. Each statement is numbered for reference to the corresponding statement in the Safety Information document.

The following notices and statements are used in this document:

vNote: These notices provide important tips, guidance, or advice.

vImportant: These notices provide information or advice that might help you avoid inconvenient or problem situations.

vAttention: These notices indicate potential damage to programs, devices, or data. An attention notice is placed just before the instruction or situation in which damage might occur.

vCaution: These statements indicate situations that can be potentially hazardous to you. A caution statement is placed just before the description of a potentially hazardous procedure step or situation.

vDanger: These statements indicate situations that can be potentially lethal or extremely hazardous to you. A danger statement is placed just before the description of a potentially lethal or extremely hazardous procedure step or situation.

Related documentation

The Lenovo ThinkServer Documentation DVD contains documentation for the server in Portable Document Format (PDF). The Lenovo ThinkServer Documentation DVD requires the following minimum hardware and software:

vAdobe® Acrobat Reader 5.0 (or later) or xpdf, which comes with Linux® operating systems

2 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

The following table describes the content and location of documentation that is provided with your server.

Document

Description

Location







Read Me First

This document directs you to the

printed, provided



ThinkServer Documentation DVD for

in server



complete warranty and support information.

packaging







Important Notices

This document includes safety and legal

printed, provided



notices that you are expected to read

in server



before using the server.

packaging







Rack Installation instructions

This document provides instructions on

English is printed



how to install your server in a rack.

and provided in





server





packaging.





Additional





languages are





provided on the





ThinkServer





Documentation





DVD and on the





Lenovo Support





Web site.







Hardware Maintenance

This document provides diagnostic

Lenovo Support

Manual

information, parts listing, and replacement

Web site:



procedures for all field replaceable units

http://



(parts replaced by trained service

www.lenovo.com/



personnel) as well as all customer

support



replaceable units (CRUs).









Warranty and Support

This document includes the warranty

Available on the

Information

statement and information about how to

ThinkServer



contact Lenovo Support.

Documentation





DVD.







Safety Information

This document includes translations of all

Available on the



of the safety statements used in the

ThinkServer



ThinkServer documentation.

Documentation





DVD.







Chapter 1. Introduction 3

4 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

Chapter 2. Server setup roadmap

The installation process varies depending on the configuration of the server when it was delivered. In some cases, the server is fully configured and just needs to be installed in the rack, connected to power and the network, and started. In other cases, the server needs to have hardware features installed, requires hardware and firmware configuration, and required the operating system to be installed.

Task

Where to find information





Unpack

7





Install hardware

Chapter 5, “Installing optional devices and replacing customer

features

replaceable units,” on page 39





Install in the rack

Rack Installation Instructions (printed and on ThinkServer



Documentation DVD





Connect Ethernet cable

“Rear view” on page 25

and power cords to



network and power



connectors







Start to verify operation

“Turning on the server” on page 35





Review UEFI settings

“Using the Setup Utility” on page 116

and customize as



needed.







Configure RAID

“Configuring RAID controllers” on page 122

controllers and arrays







Install operating system

“Using the EasyStartup DVD” on page 127

and basic drivers







Install any additional

Refer to the instructions that came with the hardware option.

drivers needed for



added features







Configure Ethernet

See the operating system help. This step is not required if the

settings in operating

operating system was installed using the ThinkServer EasyStartup

system

program.





Check for firmware and

See the Lenovo Support Web site:

driver updates.

1. Go to: http://www.lenovo.com/support.





2. Enter your product number (machine type and model number)



or select Servers and Storage from the Select your product



list.



3. From Family list, select ThinkServer RD210, and click



Continue.



4. Click Downloads and drivers to download firmware updates.





Test Integrated

“Using the integrated management module” on page 133

Management



Module(requires the



presence of the IMM



Premium option)







Install integrated

“Installing ThinkServer EasyManage software” on page 134

management



applications







Install applications

Refer to the documentation that accompanies the applications that



you want to install.





© Lenovo 2008, 2009. Portions © IBM Corp. 2007, 2008.

5

6 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

Chapter 3. What is included with your server

The RD210 server package includes the server, rail kit and rail kit instructions, as well as printed documentation, the ThinkServer Documentation DVD, and software media.



















































































































































































































































































































































































Power cord



















































1









2

Cable management arm









3

Rail kit









4

Server









Features and technologies

The server uses the following features and technologies:

vUEFI-compliant server firmware

UEFI replaces the basic input/output system (BIOS) and defines a standard interface between the operating system, platform firmware, and external devices. The server design combines the UEFI capabilities and features with legacy BIOS compatibility. UEFI-compliant servers are capable of booting UEFI-compliant operating systems, BIOS-based operating systems, and BIOS-based adapters as well as UEFI-compliant adapters.

Note: This server does not support DOS.

vDual-core or quad-core processing

The server supports up to two Xeondual-core or quad-core microprocessors. The server comes with only one microprocessor installed.

vIntegrated Management Module

The Integrated Management Module (IMM) combines service processor functions, video controller, and (when IMM Premium is installed) remote presence function in a single chip. The IMM provides advanced service-processor control, monitoring, and alerting function. If an environmental condition exceeds a threshold or if a system component fails, the IMM lights LEDs to help you diagnose the problem, records the error in the event log, and alerts you to the problem. Optionally, the IMM Premium also provides a virtual presence capability

© Lenovo 2008, 2009. Portions © IBM Corp. 2007, 2008.

7

for remote server management capabilities. The IMM provides remote server management through the following industry-standard interfaces:

Intelligent Platform Management Interface (IPMI) version 2.0

Simple Network Management Protocol (SNMP) version 3

Common Information Model (CIM)

Web browser

v Remote presence capability and blue-screen capture

IMM Premium is required to enable the remote presence and blue-screen capture features. The remote presence feature provides the following functions:

Remotely viewing video with graphics resolutions up to 1280 x 1024 at 75 Hz, regardless of the system state

Remotely accessing the server, using the keyboard and mouse from a remote client

Mapping the CD or DVD drive, diskette drive, and USB flash drive on a remote client, and mapping ISO and diskette image files as virtual drives that are available for use by the server

Uploading a diskette image to the IMM memory and mapping it to the server as a virtual drive

The blue-screen capture feature captures the video display contents before the IMM restarts the server when the IMM detects an operating-system hang condition. A system administrator can use the blue-screen capture to assist in determining the cause of the hang condition.

vLarge system-memory capability

The memory bus supports up to 128 GB of system memory. The memory controller supports error correcting code (ECC) for up to 16 industry-standard PC3-10600R-999 (single-rank or dual-rank), 800, 1067, and 1333 MHz, DDR3 (third-generation double-data-rate), registered, synchronous dynamic random access memory (SDRAM) dual inline memory modules (DIMMs).

vIntegrated network support

The server comes with an integrated dual-port Broadcom Gigabit Ethernet controller, which supports connection to a 10-Mbps, 100-Mbps, or 1000-Mbps network. For more information, see “Configuring the Gigabit Ethernet controllers” on page 138.

vIntegrated Trust Platform Module

This integrated security chip performs cryptographic functions and stores private and public secure keys. It provides the hardware support for the Trusted Computing Group (TCG) specification.

vLarge data-storage capacity and hot-swap capability

The server supports a maximum of six 2.5-inch hot-swap Serial Attached SCSI (SAS) hard disk drives or hot-swap Serial ATA (SATA) hard disk drives.

With the hot-swap feature, you can add, remove, or replace hard disk drives without turning off the server.

vEasyLED diagnostics

EasyLED diagnostics provides LEDs to help you diagnose problems. For more information about the EasyLED, see “EasyLED diagnostics panel” on page 17.

vPCI adapter capabilities

The server has two PCI interface slots (one supports low-profile cards and one supports half-length, full-height cards). Both slots can support PCI Express adapters. See “Removing and installing an adapter” on page 55 for detailed information.

8 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

vRedundant connection

The addition of an optional Ethernet daughter card provides failover capability to a redundant Ethernet connection with the applicable application installed. If a problem occurs with the primary Ethernet connection and the optional Ethernet daughter card is installed on the server, all Ethernet traffic that is associated with the primary connection is automatically switched to the optional redundant Ethernet daughter card connection. If the applicable device drivers are installed, this switching occurs without data loss and without user intervention.

vRedundant cooling and optional power capabilities

The server supports a maximum of two 675-watt hot-swap power supplies and six hot-swap fans, which provide redundancy and hot-swap capability for a typical configuration. The redundant cooling by the fans in the server enables continued operation if one of the fans fails. The server comes with one 675-watt hot-swap power supply and five fans. You can order the second optional power supply with the additional fan.

vRAID support

The RAID adapter provides hardware redundant array of independent disks (RAID) support to create configurations. The standard RAID adapter provides RAID levels 0, 1, and 1E. An optional RAID adapter is available for purchase that provides RAID levels 0, 1, 5, 6, 10, 50, and 60.

vSystems-management capabilities

The servers comes with an Integrated Management Module (IMM). When the IMM is used with the systems-management software that comes with the server, you can manage the functions of the server locally and remotely. The IMM also provides system monitoring, event recording, and network alert capability. The system-management connector provides additional security by physically separating the management network traffic from the production network. You can use the Setup utility to configure the server to use a dedicated systems-management network or a shared network.

vTCP/IP offload engine (TOE) support

The Ethernet controllers in the server support TOE, which is a technology that offloads the TCP/IP flow from the microprocessor and I/O subsystem to increase the speed of the TCP/IP flow. When an operating system that supports TOE is running on the server and TOE is enabled, the server supports TOE operation. See the operating-system documentation for information about enabling TOE.

Note: The Linux operating system does not support TOE.

vPreboot diagnostics program

The preboot diagnostics programs are stored on the integrated USB memory. They collect and analyze system information to aid in diagnosing server problems. The diagnostic programs collect the following information about the server:

System configuration

Network interfaces and settings

Installed hardware

EasyLED status

Service processor status and configuration

Vital product data, firmware, and UEFI (formerly called BIOS) configuration

Hard disk drive health

RAID controller configuration

Event logs for RAID controllers and service processors

Chapter 3. What is included with your server 9

The diagnostics programs create a merged log that includes events from all collected logs. The information is collected into a file that you can send to service and support. Additionally, you can view the information locally through a generated text report file. You can also copy the log to a removable media and view the log from a Web browser.

For additional information about diagnostics, see the Hardware Maintenance

Manual.

vEasyStartup DVD

The ThinkServer EasyStartup program guides you through the configuration of the RAID controller and the installation of the operating system and device drivers. See “Using the EasyStartup DVD” on page 127 for details.

vEasyManage DVD

The ThinkServer EasyManage program helps you manage and administer your servers through remote problem notification as well as monitoring and alerting.

Specifications

The following information is a summary of the features and specifications of the server. Depending on the server model, some features might not be available, or some specifications might not apply.

10 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

Table 1. Features and specifications

Microprocessor:

vSupports up to two Intel® Xeonmicroprocessors, dual-core (two cores per microprocessor with 4 MB shared among cores) or quad-core (four cores per microprocessor with 8 MB shared among cores)

vLevel-2 cache

vQuickPath Interconnect (QPI) links speed up to 6.4 GT per second

Note:

vUse the Setup Utility program to determine the type and speed of the microprocessors.

vFor a list of supported microprocessors, go to www.lenovo.com/thinkserver and click on the Options & Software tab.

Memory:

vMinimum: 1 GB

vMaximum: 128 GB

vType: PC3-10600R-999 (single-rank or double-rank) or PC3-8500R-777 (quad-rank), 800, 1067, and 1333 MHz, ECC, DDR3 registered SDRAM DIMMs only

vSlots: 16 dual inline

vSupports 1 GB, 2 GB, 4 GB, and 8 GB (when available) DIMMs

SATA optical drives (depending on your model):

vCD-RW/DVD-ROM combo (on standard models)

vDVD-ROM (optional)

vMulti-burner (Rambo) (optional)

Hard disk drive expansion bays (depending on the model):

vSix 2.5-inch hot-swap SAS or hot-swap SATA hard disk drive bays

PCI expansion slots:

Supports two PCI riser slots:

vSlot 1 supports low-profile cards (PCI Express Gen2 x16 )

vSlot 2 supports half-length, full-height cards (PCI Express Gen2 x16)

Power supply:

vOne power supply standard

vMaximum of two 675-watt ac (110 or 220 V ac auto-sensing) hot-swap power supplies for redundancy support

Hot-swap fans:

The server comes standard with six hot-swap fans.

Size:

vHeight: 43 mm (1.69 inches, 1 U)

vDepth: 711 mm (28 inches)

vWidth: 440 mm (17.3 inches)

vMaximum weight: 15.4 kg (34 lb) when fully configured

Integrated functions:

vIntegrated Management Module (IMM), which provides service processor control and monitoring functions, video controller, and (when IMM Premium is installed) remote keyboard, video, mouse, and remote hard disk drive capabilities

vBroadcom BCM5709 Gb Ethernet controller with TCP/IP Offload Engine (TOE)

vFive Universal Serial Bus (USB) 2.0 ports

vFour Ethernet ports (two on system board and two additional ports when the optional Dual-Port 1 Gb Ethernet Daughter Card is installed)

vOne System Management RJ-45 on the rear to connect to a systems management network. This system management connector is dedicated to the IMM functions. This connector is active with or without IMM Premium.

vOne serial port

RAID controllers:

vA ServeRAID-BR10i SAS/SATA Controller that provides RAID levels 0, 1, and 1E (comes standard on some hot-swap SAS and hot-swap SATA models).

vAn optional ServeRAID-MR10i SAS/SATA Controller that provides RAID levels 0, 1, 1E, 5, 6, and 10 can also be ordered.

Acoustical noise emissions:

vSound power, idling: 6.1 bels maximum

vSound power, operating: 6.1 bels maximum

Environment:

vAir temperature:

Server on: 10° to 35°C (50.0° to 95.0°F); altitude: 0 to 914 m (2998.7 ft)

Server off: -40° to 60°C

(-104° to 140°F); maximum altitude: 2133 m (6998.0 ft)

vHumidity:

Server on: 8% to 80%

Server off: 8% to 80%

Heat output:

Approximate heat output in British thermal units (Btu) per hour:

vMinimum configuration: 662 Btu per hour (194 watts)

vMaximum configuration: 2302 Btu per hour (675 watts)

Electrical input:

vSine-wave input (47-63 Hz) required

vInput voltage low range:

Minimum: 100 V ac

Maximum: 127 V ac

vInput voltage high range:

Minimum: 200 V ac

Maximum: 240 V ac

vInput kilovolt-amperes (kVA), approximately:

Minimum: 0.194 kVA

Maximum: 0.700 kVA

Video controller (integrated into IMM):

vMatrox G200 (two analog ports - one front and one rear that can be connected at the same time)

Note: The maximum video resolution is 1280 x 1024 at 75 Hz.

SVGA compatible video controller

DDR2 250 MHz SDRAM video memory controller

Avocent Digital Video Compression

Video memory is not expandable

Notes:

1.Power consumption and heat output vary depending on the number and type of optional features installed and the power-management optional features in use.

2.These levels were measured in controlled acoustical environments according to the procedures specified by the American National Standards Institute (ANSI) S12.10 and ISO 7779 and are reported in accordance with ISO 9296. Actual sound-pressure levels in a given location might exceed the average values stated because of room reflections and other nearby noise sources. The declared sound-power levels indicate an upper limit, below which a large number of computers will operate.

Chapter 3. What is included with your server 11

Software

Lenovo provides software to help get your sever up and running.

EasyStartup

The ThinkServer EasyStartup program simplifies the process of configuring your RAID controllers and installing supported Windows and Linux operating systems and device drivers on your server. The EasyStartup program is provided with your server on DVD. The DVD is self starting (bootable). The User Guide for the EasyStartup program is on the DVD and can be accessed directly from the program's interface. For additional information, see “Using the EasyStartup DVD” on page 127.

EasyManage

The ThinkServer EasyManage Core server provides centralized hardware and software inventory management and secure automated system management through a centralized console. The ThinkServer EasyManage Agent enables other clients on the network to be managed be the centralized console. The ThinkServer EasyManage Core Server is supported on 32-bit Windows Server 2003 and 32-bit Windows Server 2008 products. The ThinkServer EasyManage Agent is supported on 32-bit and 64-bit Windows Red Hat and SUSE operating systems.

Reliability, availability, and serviceability

Three important computer design features are reliability, availability, and serviceability (RAS). The RAS features help to ensure the integrity of the data that is stored in the server, the availability of the server when you need it, and the ease with which you can diagnose and correct problems.

Your server has the following RAS features:

v1-year parts and 1-year labor or 3-year labor and 3-year labor limited warranty

vAutomatic error retry and recovery

vAutomatic restart on nonmaskable interrupt (NMI)

vAutomatic restart after a power failure

vBackup basic input/output system switching under the control of the Integrated Management Module (IMM)

vBuilt-in monitoring for fan, power, temperature, voltage, and power-supply redundancy

vCable-presence detection on most connectors

vAdvanced ECC memory protection

vDiagnostic support for RAID and Ethernet adapters

vError codes and messages

vError correcting code (ECC) L2 cache and system memory

vHot-swap cooling fans with speed-sensing capability

vHot-swap hard disk drives

vInformation and EasyLED Diagnostics LED panels

vIntegrated Management Module (IMM)

vMenu-driven setup, system configuration, and redundant array of independent disks (RAID) configuration programs

vMicroprocessor built-in self-test (BIST), internal error signal monitoring, configuration checking, and microprocessor and voltage regulator module failure identification through EasyLED

vMemory mirroring support Redundant Ethernet capabilities with failover support

vParity checking on the small computer system interface (SCSI) bus and PCI buses

12 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

vPower management: Compliance with Advanced Configuration and Power Interface (ACPI)

vPower-on self-test (POST)

vHardware Failure Protection alerts on memory, microprocessors, SCSI hard disk drives, fans, and power supplies

vRedundant hot-swap power supplies and redundant hot-swap fans (some models)

vRedundant Network Interface Card (NIC) support

vRemind button to temporarily turn off the system-error LED

vRemote system problem-determination support

vROM-based diagnostics

vROM checksums

vSerial Presence Detection (SPD) on memory, VPD, power supply, and hard disk drives backplane

vSingle-DIMM isolation of excessive correctable error or multi-bit error by the Unified Extensible Firmware Interface (UEFI - formerly called BIOS)

vStandby voltage for system-management features and monitoring

vStartup (boot) from LAN through remote initial program load (RIPL) or dynamic host configuration protocol/boot protocol (DHCP/BOOTP)

vSystem auto-configuring from the configuration menu

vSystem-error logging (POST and IMM)

vSystem-management monitoring through the Inter IC protocol

vUpgradeable POST, Unified Extensible Firmware Interface (UEFI), diagnostics, IMM firmware, and read-only memory (ROM) resident code, locally or over the LAN

vVital product data (VPD) on microprocessors, system board, power supplies, SAS/SATA (hot-swap-drive) backplane, and power backplane

Chapter 3. What is included with your server 13

14 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

Chapter 4. Server controls, LEDs, and power

This section describes the controls and light-emitting diodes (LEDs) and how to turn the server on and off.

Note: The illustrations in this document show the 3.5-inch hard disk drive models, unless specifically indicated otherwise.

Front view

The following illustration shows the controls, light-emitting diodes (LEDs), and connectors on the front of the server.































































































































































































































































































































































































































































































































































































































































































































1





Hard disk drive activity LED (green)

11



Rack release latch



2





Hard disk drive status LED (amber)

12



USB 2 connector



3





Drive bay 0

13 Optical drive eject button



4





Drive bay 2

14 Optical drive activity LED



5





Drive bay 4

15



Optical drive bay



6





Power-control button and LED

16



Drive bay 5



7





Operator information panel

17



Drive bay 3



8





Operator information panel release

18



Drive bay 1











latch











































9





Video connector

19



Rack release latch



10



USB 1 connector











































vHard disk drive activity LEDs: This LED is used on SAS or SATA hard disk drives. Each hot-swap hard disk drive has an activity LED, and when this LED is flashing, it indicates that the drive is in use.

vHard disk drive status LEDs: This LED is used on SAS or SATA hard disk drives. When this LED is lit, it indicates that the drive has failed. If an optional RAID controller is installed in the server, when this LED is flashing slowly (one flash per second), it indicates that the drive is being rebuilt. When the LED is flashing rapidly (three flashes per second), it indicates that the controller is identifying the drive.

vOperator information panel: This panel contains controls and LEDs that provides information about the status of the server.

vOperator information panel release latch: Slide the blue release latch to the left to pull out the EasyLED panel and view the EasyLED LEDs and buttons. See “EasyLED diagnostics panel” on page 17 for more information about the EasyLED.

vVideo connector: Connect a monitor to this connector. The video connectors on the front and rear of the server can be used simultaneously.

vUSB connectors: Connect a USB device, such as a USB mouse, keyboard, or other device to any of these connectors.

© Lenovo 2008, 2009. Portions © IBM Corp. 2007, 2008.

15

vRack release latches: Press the latches on each front side of the server to remove the server from the rack.

vCD-RW/DVD eject button: Press this button to release a DVD or CD from the CD/DVD drive.

vCD-RW/DVD drive activity LED: When this LED is lit, it indicates that the CD-RW/DVD drive is in use.

Operator information panel

The following illustration shows the controls and LEDs on the operator information panel.

























































































































































































































1

Power-control button cover

6

Release latch

2

Ethernet icon LED

7

Locator button/locator LED

3

Ethernet activity LEDs

8

Ethernet activity LEDs

4

Information LED

9

Power-control button/power-on LED

5 System-error LED

vEthernet activity LEDs: When these LEDs are lit, they indicate that the server is transmitting to or receiving signals from the Ethernet LAN that is connected to the Ethernet port.

vSystem-locator button/LED: Use this blue LED to visually locate the server among other servers. This LED is controlled by the IMM.

vSystem-information LED: When this amber LED is lit, it indicates that a noncritical event has occurred. Check the error log for additional information. See the Hardware Maintenance Manual for more information about error logs.

vSystem-error LED: When this amber LED is lit, it indicates that a system error has occurred. A system-error LED is also on the rear of the server. An LED on the EasyLED panel on the operator information panel is also lit to help isolate the error. This LED is controlled by the IMM.

vPower-control button and power-on LED: Press this button to turn the server on and off manually or to wake the server from a reduced-power state. The states of the power-on LED are as follows:

Off: AC power is not present, or the power supply or the LED itself has failed.

Flashing rapidly (4 times per second): The server is turned off and is not ready to be turned on. The power-control button is disabled. This will last approximately 1 to 3 minutes.

Flashing slowly (once per second): The server is turned off and is ready to be turned on. You can press the power-control button to turn on the server.

Lit: The server is turned on.

Fading on and off: The server is in a reduced-power state. To wake the server, press the power-control button or use the IMM Web interface. See “Logging on to the Web interface” on page 138 for information on logging on to the IMM Web interface.

16 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

EasyLED diagnostics panel

The EasyLED diagnostics panel is located on the top of the operator information panel.

Note: The system service label on the underside of the cover also provides information about the location of the EasyLED.

To access the EasyLED diagnostics panel, slide the blue release button on the operator information panel to the left. Pull forward on the unit until the hinge of the operator panel is free of the server chassis. Then pull down on the unit, so that you can view the EasyLED panel information.

Note: When you slide the EasyLED diagnostics panel out of the server to check the LEDs or checkpoint codes, do not run the server continuously with EasyLED diagnostics panel outside of the server. The panel should only be outside of the server a short time. The EasyLED panel must remain in the server when the server is running to ensure proper cooling.





































































































































1



Release latch

2



EasyLEDs

3



Operator information panel

The following illustration shows the LEDs and controls on the EasyLED panel.

vRemind button:This button places the system-error LED on the front panel into Remind mode. In Remind mode, the system-error LED flashes rapidly until the problem is corrected, the system is restarted, or a new problem occurs.

Chapter 4. Server controls, LEDs, and power 17

By placing the system-error LED indicator in Remind mode, you acknowledge that you are aware of the last failure but will not take immediate action to correct the problem. The remind function is controlled by the IMM.

vNMI button: Press this button to force a nonmaskable interrupt to the microprocessor. You might have to use a pen or the end of a straightened paper clip to press the button. It allows you to blue screen the server and take a memory dump (use this button only when directed by service personnel).

vCheckpoint code display: This display 1 provides a checkpoint code that indicates the point at which the system stopped during the boot block and POST. A checkpoint code is either a byte or a word value that is produced by UEFI. The display does not provide error codes or suggest components to be replaced. Checkpoint codes can be used by service and support for more in-depth troubleshooting. By using the checkpoint code display, you do not have to wait for the video to initialize each time you restart the server.

There are two types of checkpoint codes: field programmable gate array (FPGA) hardware checkpoint codes and UEFI checkpoint codes. The UEFI checkpoint codes might change because of code sequence and timing changes or when the server firmware is updated.

vReset button: Press this button to reset the server and run the power-on self-test (POST). You might have to use a pen or the end of a straightened paper clip to press the button. The Reset button is in the lower-right corner of the EasyLED panel.

18 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

The following table lists the LEDs on the EasyLED diagnostics panel and suggests actions to solve the detected problems.

Table 2. EasyLED diagnostics

v Follow the suggested actions in the order in which they are listed in the Action column until the problem is solved.

v See the parts listing in the Hardware Maintenance Manual to determine which components are customer replaceable units (CRU) and which components are field replaceable units (FRU).

v If an action step is preceded by “(Trained service technician only),” that step must be performed only by a trained service technician.

LED

Description

Action

None, but the

An error has occurred and cannot

Use the UEFI Setup Utility program to check the system error

system error LED

be isolated. The error is not

log for information about the error.

is lit.

represented by a path.











OVER SPEC

The power supplies are using

If the OVER SPEC LED on the EasyLED panel is lit, or any of



more power than their maximum

the six 12V channel error LEDs (A, B, C, D, E, or AUX) on the



rating.

system board are lit, follow the instructions below.





If the 12V channel A error LED is lit, complete the following





steps:





1.

Turn the server off and disconnect the power from the







server.





2.

Remove the optical drive, fans, hard disk drives, and hard







disk drive backplane.





3.

Restart the server to see if the problem remains.





4.

Reinstall each device that was removed in step b one at a







time, starting the server each time, to isolate the failing







device.





5.

Replace any failing device.





6.

(Trained service technician only) Replace the system







board.

If the 12V channel B error LED is lit, complete the following steps:

1.Turn the server off and disconnect the power from the server.

2.Remove the PCI riser card in connector 1, all DIMMs, and the microprocessor in socket 2.

3.Restart the server to see if the problem remains.

4.Reinstall each device that was removed in step b one at a time, starting the server each time, to isolate the failing device.

5.Replace any failing device.

6.(Trained service technician only) Replace the system board, if the problem remains.

(Continued on the next page)

Chapter 4. Server controls, LEDs, and power 19

Table 2. EasyLED diagnostics (continued)

vFollow the suggested actions in the order in which they are listed in the Action column until the problem is solved.

vSee the parts listing in the Hardware Maintenance Manual to determine which components are customer replaceable units (CRU) and which components are field replaceable units (FRU).

vIf an action step is preceded by “(Trained service technician only),” that step must be performed only by a trained service technician.

LED

Description

Action

OVER SPEC

The power supplies are using

If the 12V channel C error LED is lit, complete the following

(Continued)

more power than their maximum

steps:



rating.

1.

Turn the server off and disconnect the power from the











server.





2.

Remove the SAS/SATA RAID riser card, DIMMs in







connectors 1 through 8, and the microprocessor in socket







1.







Note: The server will not power-on when the







microprocessor in socket 1 is not installed in the server.







You will need to toggle the switch block (SW3) to pin 6 to







power-on the server.





3.

Restart the server to see if the problem remains.





4.

Reinstall each device that was removed in step b one at a







time, starting the server each time, to isolate the failing







device.





5.

Replace any failing device.





6.

(Trained service technician only) Replace the system







board, if the problem remains.

If the 12V channel D error LED is lit, complete the following steps:

1.Turn the server off and disconnect the power from the server.

2.Remove the microprocessor in socket 1.

Note: The server will not power-on when the microprocessor in socket 1 is not installed in the server. You will need to toggle the switch block (SW3) to pin 6 to power-on the server.

3.Restart the server to see if the problem remains.

4.Reinstall the microprocessor in socket 1 and restart the server.

5.Replace any failing device.

6.(Trained service technician only) Replace the system board, if the problem remains.

(Continued on the next page.)

20 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

Table 2. EasyLED diagnostics (continued)

vFollow the suggested actions in the order in which they are listed in the Action column until the problem is solved.

vSee the parts listing in the Hardware Maintenance Manual to determine which components are customer replaceable units (CRU) and which components are field replaceable units (FRU).

vIf an action step is preceded by “(Trained service technician only),” that step must be performed only by a trained service technician.

LED

Description

Action

OVER SPEC

The power supplies are using

If the 12V channel E error LED is lit, complete the following

(Continued)

more power than their maximum

steps:



rating.

1.

Turn the server off and disconnect the power from the











server.





2.

Remove the PCI riser card from PCI riser connector 2







and the microprocessor in socket 2.





3.

Restart the server to see if the problem remains.





4.

Reinstall each device that was removed in step b one at a







time, starting the server each time, to isolate the failing







device.





5.

Replace any failing device.





6.

(Trained service technician only) Replace the system







board, if the problem remains.

If the 12V AUX channel error LED is lit, complete the following steps:





1.

Turn the server off and disconnect the power from the







server.





2.

Remove all PCI Express cards, all PCI riser cards, the







operator information panel, and the Ethernet daughter







card (if installed).





3.

Restart the server to see if the problem remains.





4.

Reinstall each device that was removed in step b one at a







time, starting the server each time, to isolate the failing







device.





5.

Replace any failing device.





6.

(Trained service technician only) Replace the system







board, if the problem remains.







LOG

An error occurred.

Check the IMM System Event log and the system-error log for





information about the error. Replace any components





identified in the error logs.









LINK

Reserved.













PS

Power supply 1 or 2 has failed.

1.

Make sure that the power supplies are seated correctly.









2.

Remove one of the power supplies to isolate the failed







power supply.





3.

Replace the failed power supply.

Chapter 4. Server controls, LEDs, and power 21

Table 2. EasyLED diagnostics (continued)

vFollow the suggested actions in the order in which they are listed in the Action column until the problem is solved.

vSee the parts listing in the Hardware Maintenance Manual to determine which components are customer replaceable units (CRU) and which components are field replaceable units (FRU).

vIf an action step is preceded by “(Trained service technician only),” that step must be performed only by a trained service technician.

LED

Description

Action









PCI

An error has occurred on a PCI

1.

Check the LEDs on the PCI slots to identify the



bus or on the system board. An





component that caused the error.



additional LED will be lit next to a





2.

Check the system-error log for information about the error.



failing PCI slot.

3.

If you cannot isolate the failing adapter using the LEDs











and the information in the system-error log, remove one







adapter at a time from the failing PCI bus; then, restart the







server after each adapter is removed.





4.

If the problem remains, replace the following components,







in the order shown, restarting the server each time:







v PCI riser card







v (Trained service technician only) Replace the system







board, if the problem remains.









SP

The service processor has failed.

1.

Remove power from the server; then, reconnect the server











to power and restart the server.





2.

Update the IMM firmware.





3.

(Trained service technician only) Replace the system







board, if the problem remains.









FAN

A fan has failed, is operating too

1.

Reseat the fan.



slowly, or has been removed. The



2.

Replace the failing fan, which is indicated by a lit LED



TEMP LED might also be lit.



next to the fan.















TEMP

The system temperature has

1.

Determine whether a fan has failed. If it has, replace it.



exceeded a threshold level. A



2.

Make sure that the room temperature is not too high. See



failing fan can cause the TEMP





Table 1 on page 11 for the server temperature information.



LED to be lit.





3.

Make sure that the air vents are not blocked.













MEM

An invalid memory configuration

1.

If the MEM LED and the CNFG LED are lit, the system



or a memory error has occurred





issues an invalid memory configuration error. Complete



(both the MEM LED and the







the following steps to correct the problem:



CNFG LED might be lit).







a. Make sure that the DIMM configuration is supported.













b. Replace the DIMMs with a supported configuration.





2.

If the CNFG LED is not lit, the system might detect a







memory error. Complete the following steps to correct the







problem:







a. Run the memory test to isolate the problem.







b. If the test indicates that a memory error has occurred,







replace the failing DIMM, which is indicated by the lit







DIMM latch on the system board (the DIMM LED is







underneath the DIMM latch).







NMI

A machine check error has

Check the system-error log for information about the error.



occurred or the NMI button was







pressed.













22 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

Table 2. EasyLED diagnostics (continued)

vFollow the suggested actions in the order in which they are listed in the Action column until the problem is solved.

vSee the parts listing in the Hardware Maintenance Manual to determine which components are customer replaceable units (CRU) and which components are field replaceable units (FRU).

vIf an action step is preceded by “(Trained service technician only),” that step must be performed only by a trained service technician.

LED

Description

Action







CNFG

A hardware configuration error

1. If the CNFG LED and the CPU LED are lit, complete the



has occurred.



following steps to correct the problem:









a. Check the microprocessors that were just installed to





make sure that they are compatible with each other





(see 11 for additional information about





microprocessor requirements).





b. (Trained service technician only) Replace the





incompatible microprocessor.





c. Check the system-error logs for information about the





error. Replace any components that are identified in





the error log.





2. If the CNFG LED and the MEM LED are lit, complete the





following steps:





a. Make sure that the DIMM configuration is supported.





b. Replace the DIMMs with a supported configuration.







CPU

An invalid microprocessor

1. If the CNFG LED is lit, the system issues an invalid



configuration or a microprocessor



microprocessor configuration error. Complete the following



has failed (both the CP LED and



steps to correct the problem:



the CNFG LED might be lit).



a. Check the microprocessors that were just installed to









make sure that they are compatible with each other





(see 11 for additional information about





microprocessor requirements) and use the Setup utility





and select System Information → System Summary





→ Processor Details to verify the microprocessors





information.





b. (Trained service technician only) Replace the





incompatible microprocessor.





c. Check the system-error logs for information about the





error. Replace any components that are identified in





the error log.





2. If a microprocessor failure occurs, complete the following





steps:





a. (Trained service technician only) Make sure that the





failing microprocessor, which is indicated by a lit LED





on the system board, is installed correctly. See 11 for





information about installation and requirements.







VRM

Reserved.









Chapter 4. Server controls, LEDs, and power 23

Table 2. EasyLED diagnostics (continued)

vFollow the suggested actions in the order in which they are listed in the Action column until the problem is solved.

vSee the parts listing in the Hardware Maintenance Manual to determine which components are customer replaceable units (CRU) and which components are field replaceable units (FRU).

vIf an action step is preceded by “(Trained service technician only),” that step must be performed only by a trained service technician.

LED

Description

Action











DASD

A hard disk drive error has

1.

Check the LEDs on the hard disk drives for the drive with



occurred.





a lit status LED and reseat the hard disk drive.











2.

Reseat the hard disk drive backplane.





3.

For more information, see “Hard disk drive problems” on







page 146.





4.

If the error remains, replace the following components in







the order listed, restarting the server after each:







a. Replace the hard disk drive.







b. Replace the hard disk drive backplane.





5.

If the error remains, replace the following components one







at a time, in the order listed, restarting the server after







each:







a. Replace the hard disk drive.







b. Replace the hard disk drive backplane.











RAID

Reserved.

















BRD

An error has occurred on the

1.

Check the LEDs on the system board to identify the



system board.





component that caused the error. The BRD LED can be lit













due to any of the following reasons:







v

Battery







v Missing PCI riser-card assembly







v

Failed voltage regulator





2.

Check the system-error log for information about the error.





3.

Replace any failed or missing replacement components,







such as the battery or PCI riser-card assembly.





4.

If a voltage regulator has failed, (trained service technician







only) replace the system board.











24 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

Rear view

The following illustration shows the LEDs on the rear of the server.





























































































































































































































































































































































































































































































































































































































































1



Slot 1, PCI Express

11

USB 3 connector

2



Ethernet activity LED

12

Serial connector

3



Ethernet link LED

13

System-error LED (amber)

4



Video connector

14

System-locator LED (blue)

5



Slot 2, PCI Express









15 Power-control button LED (green)

6



USB 4 connector

16

Ethernet 2 connector

7



AC LED (green)

17

Ethernet 1 connector

8



DC LED (green)









18 Ethernet connectors 3 and 4 (with





































































optional 2-port Ethernet card)

9



Power supply error LED (amber)

19

System management Ethernet





































































connector

10

Power cord connectors























































vPCI slot 1: Insert a low-profile PCI Express adapter into this slot. Standard models of the server come with two PCI Express rise assemblies installed.

vPCI slot 2: Insert a half-length, full-height PCI Express adapter into this slot. Standard models of the server come with two PCI Express rise assemblies installed.

vAC power LED: Each hot-swap power supply has an ac power LED and a dc power LED. When the ac power LED is lit, it indicates that sufficient power is coming into the power supply through the power cord. During typical operation, both the ac and dc power LEDs are lit. For any other combination of LEDs, see the Hardware Maintenance Manual.

vDC power LED: Each hot-swap power supply has a dc power LED and an ac power LED. When the dc power LED is lit, it indicates that the power supply is supplying adequate dc power to the system. During typical operation, both the ac and dc power LEDs are lit. For any other combination of LEDs, see the

Hardware Maintenance Manual.

vPower connector: Connect the power cord to this connector.

vPower-on LED: When this LED is lit and not flashing, it indicates that the server is turned on. The states of the power-on LED are as follows:

Off: AC power is not present, or the power supply or the LED itself has failed.

Flashing rapidly (4 times per second): The server is turned off and is not ready to be turned on. The power-control button is disabled. This will last approximately 1 to 3 minutes.

Flashing slowly (once per second): The server is turned off and is ready to be turned on. You can press the power-control button to turn on the server.

Lit: The server is turned on.

Fading on and off: The server is in a reduced-power state. To wake the server, press the power-control button or use the IMM Web interface.

vSystem-error LED: When this LED is lit, it indicates that a system error has occurred. An LED on the EasyLED panel is also lit to help isolate the error.

Chapter 4. Server controls, LEDs, and power 25

vSystem-locator LED: Use this LED to visually locate the server among other servers.

vVideo connector: Connect a monitor to this connector. The video connectors on the front and rear of the server can be used simultaneously.

vSerial connector: Connect a 9-pin serial device to this connector. The serial port is shared with the integrated management module (IMM). The IMM can take control of the shared serial port to redirect serial traffic, using Serial over LAN (SOL).

vUSB connectors: Connect a USB device, such as a USB mouse, keyboard, or other device to any of these connectors.

vEthernet link LEDs: When these LEDs are lit, they indicate that there is an active link connection on the 10BASE-T, 100BASE-TX, or 1000BASE-TX interface for the Ethernet port.

vEthernet connectors: Use either of these connectors to connect the server to a network. When you use the Ethernet 1 connector, the server's network can be shared with the IMM using a single network cable.

vSystems-management Ethernet connector: Use this connector to manage the server using a dedicated management network. By using this connector, IMM cannot be accessed directly from production network. A dedicated management network provides additional security by physically separating the management network traffic from the production network. You can use the UEFI Setup Utility to configure the server to use a dedicated systems management network or a shared network.

26 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

System-board internal connectors

The following illustration shows the internal connectors on the system board.









































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































1



Battery

12







Fan 4 connector

2



Optional two-port Ethernet card

13







Fan 5 connector







connector





































3



PCI riser connector

14







Fan 6 connector

4



DIMM connectors

15







Fan 4 connector

5



Microprocessor 1

16







Hot-swap SAS/SATA power connector

6



Operator information panel connector

17







Hot-swap SAS/SATA configuration



































































cable connector

7



Optical drive connector

18 Auxillary power for PCI Express



































































graphics adapter connector

8



Front video/USB connector

19







Microprocessor 2

9



Fan 1 connector

20 PCI riser connector 2

10

Fan 2 connector

21 Virtual media key connector

11

Fan 3 connector





































Chapter 4. Server controls, LEDs, and power 27

System-board external connectors

The following illustration shows the external connectors on the system board.







































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































USB 2 connector















































Ethernet 2 connector























































































































































1

5







2

USB 1 connector

6







Ethernet 1 connector

3

Serial connector

7







System management Ethernet



































































connector

4

Video connector



























































28 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

System-board optional-device connectors

The following illustration shows the connectors for user-installable optional devices.













































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































1





Battery

















2





DIMM 9

















3





DIMM 10

















4





DIMM 11

















5





DIMM 12

















6





DIMM 13

















7





DIMM 14

















8





DIMM 15

















9





DIMM 16

















10



PCI riser connector 1

















11



Optional two-port Ethernet card























connector

















12



Microprocessor 1

















13



DIMM 1

















14 DIMM 2

15 DIMM 3

16 DIMM 4

17 DIMM 5

18 DIMM 6

19 DIMM 7

20 DIMM 8

21 SAS/SATA RAID riser-card connector 22 Power supply 2 connector

23 Power supply 1 connector 24 Microprocessor 2

25 PCI riser connector 2

26 Virtual media key connector

Chapter 4. Server controls, LEDs, and power 29

System-board switches and jumpers

The following illustration shows the switches and jumpers on the system board.

30 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide



Jumper name

Jumper setting







1

UEFI boot recovery jumper

v Pins 1 and 2: Normal (default) Loads the primary UEFI



(J29)

(formerly called BIOS) firmware ROM page.









v Pins 2 and 3: Loads the secondary (backup) UEFI





firmware ROM page.







2

IMM recovery jumper

v Pins 1 and 2: Normal (default) Loads the primary IMM



(J147)

firmware ROM page.









v Pins 2 and 3: Loads the secondary (backup) IMM





firmware ROM page.







3

SW4 switch block





(reserved)









4

SW3 switch block









Notes:

1.If no jumper is present, the server will respond as if the pins are set to 1 and 2.

2.Changing the position of the UEFI boot recovery jumper from pins 1 and 2 to pins 2 and 3 before the server is turned on will alter which flash ROM page is loaded. Do not change the jumper pin position after the server is turned on. This can cause an unpredictable problem.

The following table describes the functions of the SW3 switch block.

Table 3. SW3 switch block definition

Switch





number

Default position

Description







1

Off

Clear CMOS. When this switch is





toggled to On, it clears the CMOS





data, which clears the power-on





password.







2

Off

Reserved.







3

Off

Reserved.







4

Off

Reserved.







5

Off

Power-on password override.





Changing the position of this switch





bypasses the power-on password





check the next time the server is





turned on and starts the UEFI Setup





Utility program so that you can





change or delete the power-on





password. You do not have to move





the switch back to the default





position after the power-on password





in overridden.





Changing the position of this switch





does not affect the administrator





password check if an administrator





password is set.





See “Passwords” on page 119 for





additional information about





passwords.







Chapter 4. Server controls, LEDs, and power 31

Table 3. SW3 switch block definition (continued)

Switch





number

Default position

Description







6

Off

When you toggle this switch to On,





this causes a forced power-on which





overrides the power-on and





power-off button on the server and





they become nonfunctional.







7

Off

Reserved.







8

Off

Reserved.







Important:

1.Before you change any switch settings or move any jumpers, turn off the server; then, disconnect all power cords and external cables. See safety information in “Safety” on page vii.

2.Any system-board switch or jumper blocks that are not shown in the illustrations in this document are reserved.

32 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

System-board LEDs

The following illustration shows the light-emitting diodes (LEDs) on the system board.



































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































1



Slot 2 missing PCI riser card LED

13 Fan 6 error LED

2



Enclosure manager heartbeat LED

14







Power channel A error LED

3



Battery LED

15 Power channel B error LED

4



IMM heartbeat LED

16 Power channel C error LED

5



Slot 1 missing PCI riser card LED

17 Power channel D error LED

6



Microprocessor 1 error LED

18 Power channel E error LED

7



DIMM 1-8 error LEDs

19 Power channel F error LED

8



Fan 1 error LED

20







240 VA error LED

9



Fan 2 error LED

21 SAS/SATA RAID riser card LED

10

Fan 3 error LED

22







System error LED

11

Fan 4 error LED

23 Microprocessor 2 error LED

12

Fan 5 error LED

































Chapter 4. Server controls, LEDs, and power 33

Power-supply LEDs

The following illustration shows the location of the power-supply LEDs on the rear of the server. See the Hardware Maintenance Manual for additional information on solving power supply problems.

Table 4.

1 AC LED (green)

2 DC LED (green)

3 Power supply error LED (amber)

System pulse LEDs

The following LEDs are on the system board and monitors the system power-on and power-off sequencing and boot progress (see “System-board LEDs” on page 33 for the location of these LEDs):

Table 5. System pulse LEDs

LED

Description

Action









Enclosure manager heartbeat

power-on and power-off sequencing.

1.

If the LED blinks at 1Hz, it is











functioning properly and no action







is necessary.





2.

If the LED is not blinking, (trained







service technician only) replace







the system board.









34 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

Table 5. System pulse LEDs (continued)

LED

Description

Action









IMM heartbeat

IMM heartbeat boot process.

The following steps describe the





different stages of the IMM heartbeat





sequencing process.





1. When this LED is blinking fast





(approximately 4Hz), this





indicates, that the IMM code is in





the loading process.





2. When this LED goes off





momentarily, this indicates that





the IMM code has loaded





completely.





3. When this LED goes off





momentarily and then starts





blinking slowing (approximately





1Hz), this indicates that IMM is





fully operational. You can now





press the power-control button to





power-on the server.





4. If this LED does not blink within





30 seconds of connecting a power





source to the server, complete the





following steps:





a.

(Trained service technician







only) use the IMM recovery







jumper to recover the firmware







(see “System-board switches







and jumpers” on page 30).





b.

(Trained service technician







only) replace the system







board.









Server power features

When the server is connected to an ac power source but is not turned on, the operating system does not run, and all core logic except for the service processor (the Integrated Management Module) is shut down; however, the server can respond to requests to the service processor, such as a remote request to turn on the server. The power-on LED flashes to indicate that the server is connected to ac power but is not turned on.

Turning on the server

Approximately 5 seconds after the server is connected to ac power, one or more fans might start running to provide cooling while the server is connected to power and the power-on button LED will blink quickly. Approximately 1 to 3 minutes after the server is connected to ac power, the power-control button becomes active (the power-on LED will blink slowly), and one or more fans might start running to provide cooling while the server is connected to power. You can turn on the server by pressing the power-control button.

The server can also be turned on in any of the following ways:

vIf a power failure occurs while the server is turned on, the server will restart automatically when power is restored.

Chapter 4. Server controls, LEDs, and power 35

Note: When 4 GB or more of memory (physical or logical) is installed, some memory is reserved for various system resources and is unavailable to the operating system. The amount of memory that is reserved for system resources depends on the operating system, the configuration of the server, and the configured PCI options.

Turning off the server

When you turn off the server and leave it connected to ac power, the server can respond to requests to the service processor, such as a remote request to turn on the server. While the server remains connected to ac power, one or more fans might continue to run. To remove all power from the server, you must disconnect it from the power source.

Some operating systems require an orderly shutdown before you turn off the server. See your operating-system documentation for information about shutting down the operating system.

36 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

Statement 5:

CAUTION:

The power control button on the device and the power switch on the power supply do not turn off the electrical current supplied to the device. The device also might have more than one power cord. To remove all electrical current from the device, ensure that all power cords are disconnected from the power source.

2 1

The server can be turned off in any of the following ways:

vYou can turn off the server from the operating system, if your operating system supports this feature. After an orderly shutdown of the operating system, the server will turn off automatically.

vYou can press the power-control button to start an orderly shutdown of the operating system and turn off the server, if your operating system supports this feature.

vIf the operating system stops functioning, you can press and hold the power-control button for more than 4 seconds to turn off the server.

vThe integrated management module (IMM) can turn off the server as an automatic response to a critical system failure.

Chapter 4. Server controls, LEDs, and power 37

38 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

Chapter 5. Installing optional devices and replacing customer replaceable units

This chapter provides detailed instructions for installing optional hardware devices in the server.

Installation guidelines

Before you install optional devices, read the following information:

vRead the safety information in “Safety” on page vii. This information will help you work safely.

vWhen you install your new server, take the opportunity to download and apply the most recent firmware updates. This step will help to ensure that any known issues are addressed and that your server is ready to function at maximum levels of performance. To download firmware updates for your server, complete the following steps:

Note: Changes are made periodically to the Lenovo Web site. The actual procedure might vary slightly from what is described in this document.

1.Go to: http://www.lenovo.com/support.

2.Enter your product number (machine type and model number) or select

Servers and Storage from the Select your product list.

3.From Family list, select ThinkServer RD210, and click Continue.

4.Click Downloads and drivers to download firmware updates.

vBefore you install optional hardware, make sure that the server is working correctly. Start the server, and make sure that the operating system starts, if an operating system is installed, or that a I9990305 error code is displayed, indicating that an operating system was not found but the server is otherwise working correctly. If the server is not working correctly, see the Hardware Maintenance Manual for diagnostic information.

vObserve good housekeeping in the area where you are working. Place removed covers and other parts in a safe place.

vIf you must start the server while the is removed, make sure that no one is near the server and that no tools or other objects have been left inside the server.

vDo not attempt to lift an object that you think is too heavy for you. If you have to lift a heavy object, observe the following precautions:

– Make sure that you can stand safely without slipping.

– Distribute the weight of the object equally between your feet.

– Use a slow lifting force. Never move suddenly or twist when you lift a heavy object.

– To avoid straining the muscles in your back, lift by standing or by pushing up with your leg muscles.

vMake sure that you have an adequate number of properly grounded electrical outlets for the server, monitor, and other devices.

vBack up all important data before you make changes to disk drives.

vHave a small flat-blade screwdriver available.

vYou do not have to turn off the server to install or replace hot-plug Universal Serial Bus (USB) devices.

© Lenovo 2008, 2009. Portions © IBM Corp. 2007, 2008.

39

vBlue on a component indicates touch points, where you can grip the component to remove it from or install it in the server, open or close a latch, and so on.

vOrange on a component or an orange label on or near a component indicates that the component can be hot-swapped, which means that if the server and operating system support hot-swap capability, you can remove or install the component while the server is running. (Orange can also indicate touch points on hot-swap components.) See the instructions for removing or installing a specific hot-swap component for any additional procedures that you might have to perform before you remove or install the component.

vWhen you are finished working on the server, reinstall all safety shields, guards, labels, and ground wires.

vFor a list of supported optional devices for the server, see http://www.lenovo.com/ thinkserver.

System reliability guidelines

To help ensure proper system cooling and system reliability, make sure that the following requirements are met:

vEach of the drive bays has a drive or a filler panel and electromagnetic compatibility (EMC) shield installed in it.

vIf the server has redundant power, each of the power-supply bays has a power supply installed in it.

vThere is adequate space around the server to allow the server cooling system to work properly. Leave approximately 50 mm (2.0 in.) of open space around the front and rear of the server. Do not place objects in front of the fans. For proper cooling and airflow, replace the server cover before you turn on the server. Operating the server for extended periods of time (more than 30 minutes) with the server cover removed might damage server components.

vYou have followed the cabling instructions that come with optional adapters.

vYou have replaced a failed fan within 48 hours.

vYou have replaced a hot-swap drive within 2 minutes of removal.

Working inside the server with the power on

Attention: Static electricity that is released to internal server components when the server is powered-on might cause the server to halt, which might result in the loss of data. To avoid this potential problem, always use an electrostatic-discharge wrist strap or other grounding system when you work inside the server with the power on.

You might be instructed to turn on the server while the cover is off, to look at system-board LEDs. Follow these guidelines when you work inside a server that is turned on:

vAvoid wearing loose-fitting clothing on your forearms. Button long-sleeved shirts before working inside the server; do not wear cuff links while you are working inside the server.

vDo not allow your necktie or scarf to hang inside the server.

vRemove jewelry, such as bracelets, necklaces, rings, and loose-fitting wrist watches.

vRemove items from your shirt pocket, such as pens and pencils, that could fall into the server as you lean over it.

vAvoid dropping any metallic objects, such as paper clips, hairpins, and screws, into the server.

40 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

Handling static-sensitive devices

Attention: Static electricity can damage the server and other electronic devices. To avoid damage, keep static-sensitive devices in their static-protective packages until you are ready to install them.

To reduce the possibility of damage from electrostatic discharge, observe the following precautions:

vLimit your movement. Movement can cause static electricity to build up around you.

vThe use of a grounding system is recommended. For example, wear an electrostatic-discharge wrist strap, if one is available.

vHandle the device carefully, holding it by its edges or its frame.

vDo not touch solder joints, pins, or exposed circuitry.

vDo not leave the device where others can handle and damage it.

vWhile the device is still in its static-protective package, touch it to an unpainted metal part of the server for at least 2 seconds. This drains static electricity from the package and from your body.

vRemove the device from its package and install it directly into the server without setting down the device. If it is necessary to set down the device, put it back into its static-protective package. Do not place the device on the server cover or on a metal surface.

vTake additional care when you handle devices during cold weather. Heating reduces indoor humidity and increases static electricity.

Chapter 5. Installing optional devices and replacing customer replaceable units 41

Major components of the server

The following illustrations show the major components in the server. The illustrations in this document might differ slightly from your hardware.

42 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

1

Cover

10 2.5 inch hot-swap hard disk drive filler







panel

2

DIMM air baffle

11

SAS/SATA backplane

3

Slot 2, PCI riser card assembly

12

Fans

4

Slot 1, PCI riser card assembly

13

System board

5

Power supply filler

14

Retainer bracket

6

Power supply

15

Microprocessor

7

Optical drive

16

Heat sink

8

Operator information panel

17 Microprocessor 2 air baffle

9

2.5 inch hard disk drive





Removing and replacing the cover

Important: Before you install optional hardware, make sure that the server is working correctly. Start the server, and make sure that the operating system starts, if an operating system is installed, or that a 19990305 error code is displayed, indicating that an operating system was not found but the server is otherwise working correctly. If the server is not working correctly, see the Hardware Maintenance Manual for diagnostic information.

Removing the cover

To remove the server cover, complete the following steps:

1.Read the safety information in “Safety” on page vii and “Installation guidelines” on page 39.

2.Turn off the server and peripheral devices and disconnect the power cords and all external cables, if necessary.

Note: When you disconnect the power source from the server, you will lose the ability to view the LEDs because the LEDs will not be lit with the power source removed. Before disconnecting the power source, make a note of which LEDs are lit, including the LEDs that are lit on the operation information panel, the EasyLED panel, and LEDs that are lit inside the server on the system board; then, see the Hardware Maintenance Manual for information on how to solve the problem.

1 Cover

2 Tab 3 Tab

Chapter 5. Installing optional devices and replacing customer replaceable units 43

3.If the server has been installed in a rack, slide the server out from the rack enclosure. See the Rack Installation Instructions that come with the server for information about removing the server from the rack.

4.Press down firmly on the two blue tabs on the top (near the front of the server) of the cover and slide the cover toward the rear of the server until the cover has disengaged from the chassis.

5.Lift the server cover off the server and set it aside.

Replacing the cover

Attention: For proper cooling and airflow, replace the server cover before you turn on the server.

To replace the server cover, complete the following steps:

1.Align the cover 1 over the server (toward the rear of the server) until the cover edges slip in position over the chassis.

2.Press down on the two blue tabs 2 and 3 on the front of the cover, while sliding the cover forward toward the front of the server until the cover is completely closed.

Internal cable routing and connectors

The following illustration shows the internal routing and connectors for the two SAS signal cables (in server models with eight SAS drive bays).

Notes:

1.To connect the SAS signal cables, make sure that you first connect the signal cable, and then the power cable and signal cable.

2.To disconnect the SAS signal cables, make sure that you first disconnect the power cable, and then the signal cable and configuration cable.

44 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

1 ServeRAID- MR10i SAS/SATA controller

2 SAS signal cables

The SATA cable is a combination power and signal cable with a shared connector on both ends. The following illustration shows the internal routing and connector for the SATA cable 1.

Chapter 5. Installing optional devices and replacing customer replaceable units 45

The following illustration shows the internal routing and connector for the operator information panel cable.

1 Top cover latch receptacle

2 Operator panel cable

46 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

The following illustration shows the internal routing and connector for the USB/video cable.

Note: The USB cable is routed under the video cable and then both the USB and video cables are routed under the cable retention tab and the top cover latch receptacle.

1 Top cover latch receptacle

2 Cable retention tab

3 Video cable

4

USB cable

Removing and installing the microprocessor 2 air baffle

To remove and install the microprocessor 2 air baffle, complete the steps in this section.

Removing the microprocessor 2 air baffle

To remove the microprocessor 2 air baffle, complete the following steps:

1.Read the safety information in “Safety” on page vii and “Installation guidelines” on page 39.

2.Turn off the server and peripheral devices and disconnect the power cords and all external cables, if necessary; then, remove the cover (see “Removing and replacing the cover” on page 43).

3.Lift the air baffle 2 up, making sure that the tab 1 comes out of the hole 3 on the side of the power-supply cage; then, remove it from the server and set it aside.

Attention: For proper cooling and airflow, replace the air baffle before you turn on the server. Operating the server with the air baffle removed might damage server components.

Chapter 5. Installing optional devices and replacing customer replaceable units 47

Installing the microprocessor 2 air baffle

To install the microprocessor 2 air baffle (if you removed it), complete the following steps:

1.Read the safety information in “Safety” on page vii and “Installation guidelines” on page 39.

2.Turn off the server and peripheral devices and disconnect the power cords and all external cables, if necessary.

3.Align the microprocessor 2 air baffle tab with the hole on the side of the power-supply cage; then insert the tab into the hole on the cage (make sure that the front end of the air baffle is lined up with the blue press point tab on the left of fan 6). Press the air baffle down until the it is securely seated.

4.Install the cover see “Removing and replacing the cover” on page 43).

5.Reconnect the power cords and any cables that you removed.

6.Turn on the peripheral devices and the server.

Removing and installing the DIMM air baffle

To remove and install the DIMM air baffle, complete the steps in this section.

Removing the DIMM air baffle

To remove the DIMM air baffle, complete the following steps:

1.Read the safety information in “Safety” on page vii and “Installation guidelines” on page 39.

2.Turn off the server and peripheral devices and disconnect the power cords and all external cables.

Note: When you disconnect the power source from the server, you will lose the ability to view the LEDs because the LEDs will not be lit with the power source removed. Before disconnecting the power source, make a note of which LEDs are lit, including the LEDs that are lit on the operation information panel, the EasyLED panel, and LEDs that are lit inside the server on the system board; then, see the Hardware Maintenance Manual for information on how to solve the problem.

48 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

3.Grasp the DIMM air baffle 2 and lift the baffle up, making sure that the pin 1 comes out of the pin hole 3 on the system board to the left of DIMM connector 8.

4. Remove it from the server and set it aside.

Chapter 5. Installing optional devices and replacing customer replaceable units 49

Installing the DIMM air baffle

Attention: For proper cooling and airflow, replace the air baffle before you turn on the server. Operating the server with the air baffle removed might damage server components.

To install the DIMM air baffle, complete the following steps:

1.Read the safety information in “Safety” on page vii and “Installation guidelines” on page 39.

2.Turn off the server and peripheral devices and disconnect the power cords and all external cables, if necessary.

3.Align the DIMM air baffle over the DIMMs so that the baffle pin on the left side of the air baffle aligns with the pin hole next to DIMM connector 8 on the system board and lower it into the server.

Removing and installing a hot-swap hard disk drive

The following notes describe the type of internal drives that the server supports and other information that you must consider when installing a drive. For a list of supported hard disk drives, go to www.lenovo.com/thinkserver and click on the

Options & Software tab.

vLocate the documentation that comes with the drive and follow those instructions in addition to the instructions in this chapter.

vMake sure that you have all the cables and other equipment that are specified in the documentation that comes with the drive.

vSelect the bay in which you want to install the drive.

vCheck the instructions that come with the drive to determine whether you have to set any switches or jumpers on the drive. If you are installing a SAS or SATA hard disk drive, be sure to set the SAS or SATA ID for that device.

vThe server supports six 2.5-inch hot-swap SAS or hot-swap SATA hard disk drives.

vAll hot-swap drives in the server should have the same throughput speed rating. Mixing hard disk drives with different speed ratings will cause all drives to operate at the lower throughput speed.

50 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

vDo not mix SAS and SATA hard disk drives in the same system.

vThe electromagnetic interference (EMI) integrity and cooling of the server are protected by having all bays and PCI and PCI Express slots covered or occupied. When you install a drive, PCI, or PCI Express adapter, save the EMC shield and filler panel from the bay or PCI or PCI Express adapter slot cover in the event that you later remove the device.

vFor a complete list of supported optional devices for the server, go to www.lenovo.com/thinkserver and click on the Options & Software tab.

To remove and install a hot-swap hard disk drive, complete the steps in this section.

Removing a hot-swap hard disk drive

To remove a hot-swap hard disk drive, complete the following steps.

Attention:

vTo avoid damage to the hard disk drive connectors, make sure that the server cover is in place and fully closed whenever you install or remove a hard disk drive.

vTo make sure that there is adequate system cooling, do not operate the server for more than 2 minutes without either a hard disk drive or a filler panel installed in each bay.

1 Drive-tray assembly

2 Drive handle

1.Read the safety information in “Safety” on page vii and “Installation guidelines” on page 39.

2.Slide the release latch (orange) gently to the left to unlock the drive handle.

3.Grasp the handle and slide the drive out of the drive bay.

4.If you are instructed to return the drive assembly, follow all packaging instructions, and use any packaging materials for shipping that are supplied to you.

Installing a hot-swap hard disk drive

The following notes describe the type of hard disk drives that the server supports and other information that you must consider when you install a hard disk drive. For a list of supported hard disk drives, see www.lenovo.com/thinkserver.

vLocate the documentation that comes with the hard disk drive and follow those instructions in addition to the instructions in this chapter.

Chapter 5. Installing optional devices and replacing customer replaceable units 51

vMake sure that you have all the cables and other equipment that are specified in the documentation that comes with the drive.

vSelect the bay in which you want to install the drive.

vCheck the instructions that come with the drive to determine whether you have to set any switches or jumpers on the drive. If you are installing a SAS or SATA device, be sure to set the SAS or SATA ID for that device.

vThe server supports six 2.5-inch hot-swap SAS or hot-swap SATA hard disk drives.

vYou can mix SAS and SATA hard disk drives in the same server as long as they are not on the same array.

vThe electromagnetic interference (EMI) integrity and cooling of the server are protected by having all bays and PCI and PCI Express slots covered or occupied. When you install a drive, PCI, or PCI Express adapter, save the EMC shield and filler panel from the bay or PCI or PCI Express adapter slot cover in the event that you later remove the device.

vFor a complete list of supported optional devices for the server, see www.lenovo.com/thinkserver.

To install a 2.5-inch hot-swap SAS or SATA hard disk drive, complete the following steps:

1.Read the safety information in “Safety” on page vii and “Installation guidelines” on page 39.

2.Remove the filler panel 1 from the empty drive bay.

3.Touch the static-protective package that contains the drive to any unpainted metal surface on the server; then, remove the drive from the package and place it on a static-protective surface.

4.Install the hard disk drive in the drive bay.

a.Make sure that the tray handle 2 is in the open (unlocked) position.

b.Align the drive assembly 3 with the guide rails in the bay.

c.Gently push the drive assembly into the bay until the drive stops.

d.Rotate the tray handle to the closed (locked) position.

e.Check the hard disk drive status LED to verify that the hard disk drive is operating correctly. If the amber hard disk drive status LED for a drive is lit continuously, that drive is faulty and must be replaced. If the green hard disk drive activity LED is flashing, the drive is being accessed.

Note: If the server is configured for RAID operation using a RAID adapter, you might have to reconfigure your disk arrays after you install hard disk drives. See the RAID adapter documentation for additional information about RAID operation and complete instructions for using the RAID adapter.

52 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

5.If you are installing additional hot-swap hard disk drives, do so now.

6.Turn on the peripheral devices and the server.

IDs for hot-swap hard disk drives

The hot-swap-drive ID that is assigned to each drive is printed on the front of the server. The following illustration shows the location of the IDs of the hard disk drives. The ID numbers and the drive bay numbers are the same.

1 Hard disk drive activity LED (green) 2 Hard disk drive status LED (amber) 3 Drive bay 0

4 Drive bay 2 5 Drive bay 4 6 Drive bay 5 7 Drive bay 3 8 Drive bay 1

Removing and installing a PCI riser-card assembly

To remove and install a PCI riser-card assembly, complete the steps in this section.

Removing a PCI riser-card assembly

To remove a PCI riser-card assembly, complete the following steps:

1.Read the safety information in “Safety” on page vii and “Installation guidelines” on page 39.

2.Turn off the server and peripheral devices and disconnect the power cords and all external cables.

Note: When you disconnect the power source from the server, you will lose the ability to view the LEDs because the LEDs will not be lit with the power source removed. Before disconnecting the power source, make a note of which LEDs are lit, including the LEDs that are lit on the operation information panel, the EasyLED panel, and LEDs that are lit inside the server on the system board; then, see the Hardware Maintenance Manual for information on how to solve the problem.

3.Remove the cover (see “Removing and replacing the cover” on page 43).

4.If an adapter is installed in the riser-card assembly, disconnect any cables that are connected to the adapter.

5.Grasp the rear of the riser-card assembly from the rear and lift it out of the PCI riser-card slot on the system board.

Chapter 5. Installing optional devices and replacing customer replaceable units 53

1 PCI riser-card assembly (full-height, full-length adapters) 2 PCI riser-card assembly (low-profile adapters)

3 PCI riser connector 1 4 PCI riser connector 2

6.Remove the adapter, if one is present, from the riser-card assembly.

7.Set the adapter and riser-card assembly aside.

Installing a PCI riser card assembly

To install a PCI riser-card assembly, complete the following steps:

1.Read the safety information in “Safety” on page vii and “Installation guidelines” on page 39.

2.Turn off the server and peripheral devices and disconnect the power cords and all external cables.

3.Remove the cover (see “Removing and replacing the cover” on page 43).

4.Install the adapter in the new PCI riser-card assembly.

5.Set any jumpers or switches on the adapter as directed by the adapter manufacturer.

6.Align the PCI riser-card assembly with the PCI slot connector on the system board: then, press down firmly until the riser-card assembly in seated correctly in the connector on the system board.

54 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

1 PCI riser-card assembly (full-height, full-length adapters) 2 PCI riser-card assembly (low-profile adapters)

3 PCI riser connector 1 4 PCI riser connector 2

Removing and installing an adapter

The following describe the types of adapters that the server supports and other information that you must consider when installing an adapter:

vLocate the documentation that comes with the adapter and follow those instructions in addition to the instructions in this section.

vThe server provides two PCI riser slots on the system board. Each slot comes with a PCI riser assembly with a bracket installed. The following information indicates the riser card slots and the type of adapters that the riser cards support:

Standard models of the server comes with two PCI Express riser-card assemblies installed.

A PCI Express riser card assembly has a black connector and supports PCI Express adapters.

PCI riser slot 1 (this slot is the farthest slot away from the power supplies). This slot supports only low-profile adapters.

PCI riser slot 2 (this slot is the closest slot to the power supplies). This slot supports only full-height, half-length adapters.

vDo no set the maximum digital video adapter resolution above 1600 x 1200 at 60 Hz for an LCD monitor. This is the highest resolution that is supported for any add-on video adapter that you install in the server.

vAny high-definition video-out connector or stereo connector on any add-on video adapter is not supported.

vThe server does not support full-length adapters.

vWhen you install any PCI adapter, the power cords must be connected form the power source before you remove the PCI Express riser-card assembly.

Chapter 5. Installing optional devices and replacing customer replaceable units 55

Otherwise, the active power management event signal will be disabled by the system-board logic, and the WAN feature might not work. However, after the server is powered on locally, the active power manager active power management event signal will be enabled by the system-board logic.

vIf you switch the PCI adapter from slot 1 riser assembly to slot 2, you will need to remove the screw from the standard bracket and then replace the standard bracket with the low-profile bracket.

vThe server provides two PCI riser-card slots

vTo install any PCI adapter, both the AC and DC power cords must be disconnected from the power source before you remove the PCI Express riser assembly. Otherwise, this will cause the active power management event signal to become disabled by hardware. However, after the server is powered-on locally, the active power manager active power management event signal will be enabled by hardware.

Removing an adapter

To remove an adapter, complete the following steps:

1.Read the safety information in “Safety” on page vii and “Installation guidelines” on page 39.

2.Turn off the server and peripheral devices and disconnect all power cords; then, remove the cover (see “Removing and replacing the cover” on page 43).

3.Disconnect any cables from the adapter.

4.Grasp the riser-card assembly at the rear edge and lift to remove the riser-card assembly.

5.Place the riser-card assembly on a flat, static-protective surface.

6.Carefully grasp the adapter by its top edge or upper corners, and pull the adapter from the riser-card assembly.

1 Adapter

2 Expansion slot cover 3 PCI riser-card assembly 4 PCI riser-card connector

56 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

7.If you are instructed to return the adapter, follow all packaging instructions, and use any packaging materials for shipping that are supplied to you.

Installing an adapter

To install an adapter, complete the following steps:

Notes:

1.The instructions in this section apply to any PCI adapter (for example, video graphics adapters or network adapters).

2.Do not set the maximum digital video adapter resolution above 1600 x 1200 at 60 Hz for an LCD monitor. This is the highest resolution that is supported for any add-on video adapter that you install in the server.

3.Any high-definition video-out connector or stereo connector on any add-on video adapter is not supported

1.Read the safety information in “Safety” on page vii and “Installation guidelines” on page 39.

2.Turn off the server and peripheral devices and disconnect the power cords and all external cables; then, remove the server cover (see “Removing and replacing the cover” on page 43).

3.Follow the cabling instructions, if any come with the adapter. Route the adapter cables before you install the adapter.

4.Insert the adapter into the riser-card assembly, aligning the edge connector on the adapter with the connector on the riser-card assembly. Press the edge of the connector firmly into the riser-card assembly. Make sure that the adapter snaps into the riser-card assembly securely.

Attention: When you install an adapter, make sure that the adapter is correctly seated in the riser-card assembly and that the riser-card assembly is securely seated in the riser-card connector on the system board before you turn on the server. An incorrectly seated adapter might cause damage to the system board, the riser-card assembly, or the adapter.

Chapter 5. Installing optional devices and replacing customer replaceable units 57

1

Adapter

2

Expansion slot cover

3

PCI riser card assembly

5.Install the riser-card assembly in the server (see “Removing and installing a PCI riser-card assembly” on page 53).

6.Perform any configuration tasks that are required for the adapter.

If you have other options to install or remove, do so now. Otherwise, go to “Completing the installation” on page 111.

Removing and installing a memory module (DIMMs)

To remove and install a memory module, complete the steps in this section.

Removing a memory module (DIMMs)

To remove a dual inline memory module (DIMM), complete the following steps:

1.Read the safety information in “Safety” on page vii and “Installation guidelines” on page 39.

2.Turn off the server and peripheral devices and disconnect all power cords.

3.Remove the cover (see “Removing and replacing the cover” on page 43).

4.Disconnect any cables that impede access to the DIMMs.

5.Remove the DIMM air baffle (see “Removing and installing the DIMM air baffle” on page 48).

6.Carefully open the retaining clips 2 on each end of the DIMM connector and remove the DIMM 1.

Attention: To avoid breaking the retaining clips or damaging the DIMM connectors, open and close the clips gently.

7.If you are instructed to return the DIMM, follow all packaging instructions, and use any packaging materials for shipping that are supplied to you.

Installing a memory module (DIMMs)

The following notes describe the types of DIMMs that the server supports and other information that you must consider when you install DIMMs :

58 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

vThe server supports only industry-standard double-data-rate 3 (DDR3), 800, 1066, or 1333 MHz, PC3-10600R-999 (single-rank or dual-rank), registered, synchronous dynamic random-access memory (SDRAM) dual inline memory modules (DIMMs) with error correcting code (ECC).

The specifications of a DDR3 DIMM are on a label on the DIMM, in the following format.

ggg eRxff-PC3-wwwwwm-aa-bb-cc where:

ggg is the total capacity of the DIMM (for example, 1GB, 2GB, or 4GB) e is the number of ranks

1 = single-rank

2 = dual-rank

4 = quad-rank

ff is the device organization (bit width)

4 = x4 organization (4 DQ lines per SDRAM)

8 = x8 organization

16 = x16 organization

wwwww is the DIMM bandwidth, in MBps

6400 = 6.40 GBps (PC3-800 SDRAMs, 8-byte primary data bus) 8500 = 8.53 GBps (PC3-1066 SDRAMs, 8-byte primary data bus) 10600 = 10.66 GBps (PC3-1333 SDRAMs, 8-byte primary data bus) 12800 = 12.80 GBps PC3-1600 SDRAMs, 8-byte primary data bus)

m is the DIMM type

E = Unbuffered DIMM (UDIMM) with ECC (x72-bit module data bus) R = Registered DIMM (RDIMM)

U = Unbuffered DIMM with no ECC (x64-bit primary data bus)

aais the CAS latency, in clocks at maximum operating frequency

bbis the JEDEC SPD Revision Encoding and Additions level

ccis the reference design file for the design of the DIMM

d is the revision number of the reference design of the DIMM

vThe server supports a maximum of 16 single-rank or dual-rank DIMMs.

Note: To determine the type of a DIMM, see the label on the DIMM. The information on the label is in the format xxxxx nRxxx PC3-xxxxx-xx-xx-xxx. The numeral in the sixth numerical position indicates whether the DIMM is single-rank (n=1) or dual-rank (n=2).

vThe server supports three single-rank or dual-rank DIMMs per channel. The following table shows an example of the maximum amount of memory that you can install using ranked DIMMs:

Table 6. Maximum memory installation using ranked DIMMs

Number of DIMMs

DIMM type

DIMM size

Total memory











16

Single-rank DIMMs

4

GB

64 GB











16

Dual-rank DIMMs

4

GB

64 GB











16

Dual-rank DIMMs

8

GB (if available)

128 GB











Chapter 5. Installing optional devices and replacing customer replaceable units 59

vThe DIMM options that are available for the server are 1 GB, 2 GB, 4 GB, and 8 GB (when available). The sever supports a minimum of 1 GB and a maximum of 128 GB of system memory.

Note: The amount of usable memory is reduced depending on the system configuration. A certain amount of memory must be reserved for system resources. To view the total amount of installed memory and the amount of configured memory, run the Setup utility.

vA minimum of one DIMM must be installed for each microprocessor. For example, you must install a minimum of two DIMMs if the server has two microprocessors installed. However, to improve system performance, install a minimum of three DIMMs for each microprocessor.

vThe maximum operating speed of the server is determined by the slowest DIMM installed in the server.

DIMM installation sequence

vThe server comes with a minimum of two 1 GB DIMMs, installed in connectors 3 and 6. When you install additional DIMMs, install them in the order shown in the following table to optimize system performance. In non-mirroring mode, all three channels on the memory interface for each microprocessor can be populated in any order and have no matching requirements.

Table 7. Non-mirroring (normal) mode DIMM installation sequence

Installed microprocessors

DIMM connector population sequence





Microprocessor socket 1

3, 6, 8, 2, 5, 7, 1, 4





Microprocessor socket 2

11, 14, 16, 10, 13, 15, 9, 12





Memory mirroring

vThe server supports memory mirroring (mirroring mode):

Memory-mirroring mode replicates and stores data on two pairs of DIMMs within two channels simultaneously. If a failure occurs, the memory controller switches from the primary pair of memory DIMMs to the backup pair of DIMMs. To enable memory mirroring through the Setup utility, select System Settings → Memory. When you use the memory mirroring feature, consider the following information:

-When you use memory mirroring, you must install a pair of DIMMs at a time. One DIMM must be in channel 0, and the mirroring DIMM must be in the same slot in channel 1. The two DIMMs in each pair must be identical in size, type, and rank (single or dual) , and organization, but not in speed. The channels run at the speed of the slowest DIMM in any of the channels.

-Channel 2, DIMM connectors 8 ,7, 15, and 16 are not used in memory-mirroring mode.

-The maximum available memory is reduced to half of the installed memory when memory mirroring is enabled. For example, if you install 64 GB of memory, only 32 GB of addressable memory is available when you use memory mirroring.

The following diagram shows the memory channel interface layout with the DIMM installation sequence for mirroring mode. The numbers within boxes indicate the DIMM population sequence in pairs within the channels, and the numbers next to the boxes indicate the DIMM connectors within the channels. For example, the following illustration shows the first pair of DIMMs (indicated by ones (1) inside the boxes) should be installed in DIMM connectors 3 on channel 0 and DIMM connector 6 on channel 1 DIMM connectors 7, 8, 15, and 16 on channel 2 are

60 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

not used in memory-mirroring mode.

The following table lists the DIMM connectors on each memory channel.

Table 8. Connectors on each memory channel

Memory channel

DIMM connectors





Channel 0

1, 2, 3, 9, 10, 11





Channel 1

4, 5, 6, 12, 13, 14





Channel 2

7, 8, 15, 16





The following illustration shows the memory connector layout that is associated with each microprocessor. For example, DIMM connectors 9, 10, 11, 12, 13, 14, 15, and 16 (DIMM connectors are shown underneath the boxes) are associated with microprocessor 2 slot (CPU2) and DIMM connectors 1, 2, 3, 4, 5, 6, 7, and 8 are associated with microprocessor 1 slot (CPU1). The numbers within the boxes indicates the installation sequence of the DIMM pairs. For example, the first DIMM pair (indicated within the boxes by ones (1)) should be installed in DIMM connectors 3 and 6, which is associated with microprocessor 1 (CPU1).

Note: You can install DIMMs for microprocessor 2 as soon as you install microprocessor 2; you do not have to wait until all of the DIMM slots for microprocessor 1 are filled.

The following table shows the installation sequence for installing DIMMs in memory-mirroring mode:

Table 9. Memory-mirroring mode DIMM population sequence



Number of installed



DIMMs

microprocessors

DIMM connector







First pair of DIMMs

1

3, 6







Second pair of DIMMs

1

2, 5







Chapter 5. Installing optional devices and replacing customer replaceable units 61

Table 9. Memory-mirroring mode DIMM population sequence (continued)



Number of installed



DIMMs

microprocessors

DIMM connector







Third pair of DIMMs

1

1, 4







Fourth pair of DIMMs

2

14, 11







Fifth pair of DIMMs

2

13, 10







Sixth pair of DIMMs

2

12, 9







Note: DIMM connectors 7, 8, 15, and 16 are not used in memory-mirroring mode.

vWhen you install or remove DIMMs, the server configuration information changes. When you restart the server, the system displays a message that indicates that the memory configuration has changed.

The following illustration shows the location of the DIMMs connectors on the system board.

62 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

1

DIMM 1 connector

10

DIMM 10 connector

2

DIMM 2 connector

11

DIMM 11 connector

3

DIMM 3 connector

12

DIMM 12 connector

4

DIMM 4 connector

13

DIMM 13 connector

5

DIMM 8 connector

14

DIMM 14 connector

6

DIMM 7 connector

15

DIMM 15 connector

7

DIMM 6 connector

16

DIMM 16 connector

8

DIMM 5 connector





9

DIMM 9 connector





Installation steps

To install a DIMM, complete the following steps:

1.Read the safety information in “Safety” on page vii and “Installation guidelines” on page 39.

2.Turn off the server and peripheral devices and disconnect all power cords.

3.Remove the cover (see “Removing and replacing the cover” on page 43).

4.Disconnect any cables that impede access to the DIMMs.

5.Remove the DIMM air baffle (see “Removing and installing the DIMM air baffle” on page 48).

6.Carefully open the retaining clips 2 on each end of the DIMM connector and remove the DIMM 1.

Attention: To avoid breaking the retaining clips or damaging the DIMM connectors, open and close the clips gently.

7.Touch the static-protective package that contains the DIMM to any unpainted metal surface on the outside of the server. Then, remove the DIMM from the package.

8.Turn the DIMM so that the DIMM keys align correctly with the connector.

9.Insert the DIMM into the connector by aligning the edges of the DIMM with the slots at the ends of the DIMM connector.

10.Firmly press the DIMM straight down into the connector by applying pressure on both ends of the DIMM simultaneously. The retaining clips snap into the locked position when the DIMM is firmly seated in the connector.

Chapter 5. Installing optional devices and replacing customer replaceable units 63

Note: If there is a gap between the DIMM and the retaining clips, the DIMM has not been correctly inserted; open the retaining clips, remove the DIMM, and then reinsert it.

11.Reconnect the power cord and any cables that you removed.

12.Replace the cover (see “Removing and replacing the cover” on page 43).

13.Turn on the peripheral devices and the server.

Removing and installing the IBM ServeRAID-BR10i SAS/SATA Controller

To remove and install the IBM ServeRAID-BR10i SAS/SATA Controller, complete the steps in this section.

Removing the IBM ServeRAID-BR10i SAS/SATA Controller

To remove the IBM ServeRAID-BR10i SAS/SATA controller from the system board, complete the following steps:

1.Read the safety information in “Safety” on page vii and “Installation guidelines” on page 39.

2.Turn off the server and peripheral devices and disconnect the power cords.

Note: When you disconnect the power source from the server, you will lose the ability to view the LEDs because the LEDs will not be lit with the power source removed. Before disconnecting the power source, make a note of which LEDs are lit, including the LEDs that are lit on the operation information panel, the EasyLED panel, and LEDs that are lit inside the server on the system board; then, see “EasyLED” on page 157 for information on how to solve the problem.

3.Remove the cover (see “Removing and replacing the cover” on page 43).

4.Disconnect the signal cables that are attached to the drive backplane from the connectors on the controller.

5.Grasp the SAS/SATA controller near the end next to the power-supply cage and press the black plastic tab (next to the power supply) that is holding the controller in place toward the power supply.

6.Pull up on the SAS/SATA controller until the RAID riser card assembly disengages from the connector on the system board.

1 USB embedded connector 2 RAID controller connector 3 Riser card error LED

4 SAS/SATA RAID riser card

7.Grasp the SAS/SATA controller and pull it out of the connector on the RAID riser card assembly.

64 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

1 SAS/SATA riser card

2 ServeRAID-BR10i controller

8.If you are instructed to return the SAS/SATA controller, follow all packaging instructions, and use any packaging materials for shipping that are supplied to you.

Installing the IBM ServeRAID-BR10i SAS/SATA Controller

Some server models come with the IBM ServeRAID-BR10i SAS/SATA Controller installed. The adapter can be installed only in the dedicated slot on the SAS/SATA RAID riser card assembly on the system board (see “System-board internal connectors” on page 27 for the location of the connector). Use the connector on the SAS/SATA RAID riser card assembly for the RAID controllers. The IBM ServeRAID-BR10i SAS/SATA controller enables integrated RAID levels 0, 1, and 1E capability on hot-swap hard disk drives. To install the adapter if your server model did not come with this adapter installed, complete the following steps to install the IBM ServeRAID-BR10i SAS/SATA Controller:

Attention: Some cluster solutions require specific code levels or coordinated code updates. If the device is part of a cluster solution, verify that the latest level of code is supported for the cluster solution before you update the code.

1.Read the safety information in “Safety” on page vii and “Installation guidelines” on page 39.

2.Turn off the server and peripheral devices and disconnect the power cords and all external cables, if necessary.

Note: When you disconnect the power source from the server, you will lose the ability to view the LEDs because the LEDs will not be lit with the power source removed. Before disconnecting the power source, make a note of which LEDs are lit, including the LEDs that are lit on the operation information panel, the EasyLED panel, and LEDs that are lit inside the server on the system board; then, see the “EasyLED” on page 157 for information on how to solve the problem.

3.Remove the cover (see “Removing and replacing the cover” on page 43).

Chapter 5. Installing optional devices and replacing customer replaceable units 65

4.Touch the static-protective package that contains the new ServeRAID-BR10i SAS/SATA controller to any unpainted surface on the outside of the server; then, grasp the adapter by the top edge or upper corners of the controller and remove it from the package.

5.Align the ServeRAID-BR10i SAS/SATA controller so that the keys align correctly with the connector on the SAS/SATA RAID riser card assembly.

1 USB embedded connector 2 RAID controller connector 3 Riser card error LED

4 SAS/SATA RAID riser card

6.Insert the SAS/SATA controller 2 into the connector on the SAS/SATA RAID riser card assembly 1 until it is firmly seated.

Attention: Incomplete insertion might cause damage to the server or the controller.

7.Tilt the SAS/SATA RAID riser-card assembly slightly and insert the end of the adapter in the slot on the retention bracket as shown in the following illustration. Make sure that the SAS/SATA RAID riser-card assembly keys align correctly with the connector on the system board and press down on the assembly until it is seated firmly into the connector on the system board.

66 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

1 SAS/SATA RAID front retention bracket 2 SAS/SATA RAID riser card

3 ServeRAID-BR10i adapter 4 Alignment post

5 Plastic tab

8.Route the signal cables from the drive backplane over the blue adapter retention bracket as shown in the following illustration.

1 Connector for drive bays 0-3 signal cable 2 Connector for drive bays 4-5 signal cable 3 SAS/SATA RAID riser-card

4 ServeRAID-BR10i adapter

9.Take the signal cable that is attached to the drive backplane for drive bays 4 and 5 and connect it to the RAID controller connector that is closest to the power supply cage. Connect the other signal cable so that is attached to the drive backplane for drive bays 0 through 3 and connect it to the other connector on the controller. The following illustration show how to route the signal cables.

Note: When you restart the server, you will be prompted to import the existing RAID configuration to the new ServeRAID controller.

Chapter 5. Installing optional devices and replacing customer replaceable units 67

If you have other devices to install or remove, do so now. Otherwise, go to “Completing the installation” on page 111.

Removing and installing the optional IBM ServeRAID-MR10i SAS/SATA Controller

To remove and install the optional IBM ServeRAID-MR10i SAS/SATA Controller, complete the steps in this section.

Removing the optional IBM ServeRAID-MR10i SAS/SATA Controller

To remove the IBM ServeRAID-MR10i SAS/SATA controller, complete the following steps:

1.Read the safety information in “Safety” on page vii and “Installation guidelines” on page 39.

2.Turn off the server and peripheral devices and disconnect the power cords.

Note: When you disconnect the power source from the server, you will lose the ability to view the LEDs because the LEDs will not be lit with the power source removed. Before disconnecting the power source, make a note of which LEDs are lit, including the LEDs that are lit on the operation information panel, the EasyLED panel, and LEDs that are lit inside the server on the system board; then, see “EasyLED” on page 157 for information on how to solve the problem.

3.Remove the cover (see “Removing and replacing the cover” on page 43).

4.Disconnect the signal cables that are attached to the existing SAS/SATA controller from the connectors on the controller.

5.Grasp the SAS/SATA controller near the end next to the power-supply cage and press the black plastic tab (next to the power supply) that is holding the controller in place toward the power supply.

6.Pull up on the SAS/SATA controller until the RAID riser card assembly disengages from the connector on the system board.

7.Grasp the SAS/SATA controller and pull it out of the connector on the RAID riser card assembly.

8.If you are instructed to return the SAS/SATA controller, follow all packaging instructions, and use any packaging materials for shipping that are supplied to you.

Installing the optional IBM ServeRAID-MR10i SAS/SATA Controller

An optional IBM ServeRAID-MR10i SAS/SATA controller can also be purchased. It can be installed only in the dedicated slot on the SAS/SATA RAID riser card assembly on the system board (see “System-board internal connectors” on page 27 for the location of the connector). Use the connector on the SAS/SATA RAID riser card assembly to install the RAID controllers.

To install the IBM ServeRAID-MR10i SAS/SATA controller, complete the following steps:

1.Read the safety information in “Safety” on page vii and “Installation guidelines” on page 39.

2.Turn off the server and peripheral devices and disconnect the power cords and all external cables, if necessary.

Note: When you disconnect the power source from the server, you will lose the ability to view the LEDs because the LEDs will not be lit with the power source

68 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

removed. Before disconnecting the power source, make a note of which LEDs are lit, including the LEDs that are lit on the operation information panel, the EasyLED panel, and LEDs that are lit inside the server on the system board; then, see the “EasyLED” on page 157 for information on how to solve the problem.

3.Remove the cover (see “Removing and replacing the cover” on page 43).

4.Touch the static-protective package that contains the new ServeRAID-MR10i SAS/SATA controller to any unpainted surface on the outside of the server; then, grasp the adapter by the top edge or upper corners of the controller and remove it from the package.

5.Align the ServeRAID-MR10i SAS/SATA controller so that the keys align correctly with the connector on the SAS/SATA RAID riser card assembly.

6.Insert the SAS/SATA adapter into the connector on the SAS/SATA RAID riser-card until it is firmly seated.

Attention: Incomplete insertion might cause damage to the server or the adapter.

1 USB embedded connector 2 RAID adapter connector 3 Riser card error LED

4 SAS/SATA RAID riser card

1 SAS/SATA RAID riser-card 2 ServeRAID-MR10i adapter

7.Tilt the SAS/SATA RAID riser-card assembly slightly and insert the end of the adapter in the slot on the retention bracket as shown in the following illustration. Make sure that the SAS/SATA RAID riser-card assembly keys align correctly

Chapter 5. Installing optional devices and replacing customer replaceable units 69

with the connector on the system board and press down on the assembly until it is seated firmly into the connector on the system board.

1 SAS/SATA RAID front retention bracket 2 SAS/SATA RAID riser card

3 ServeRAID-MR10i adapter 4 Plastic tab

5 Alignment post

8.Route the signal cables from the drive backplane over the blue adapter retention bracket as shown in the following illustration.

1 Connector for drive bays 0-3 signal cable 2 Connector for drive bays 4-5 signal cable 3 SAS/SATA RAID riser card

4 ServeRAID-MR10i controller

9.Take the signal cable that is attached to the drive backplane for drive bays 4 and 5 and connect it to the RAID controller connector that is closest to the power supply cage. Connect the other signal cable so that is attached to the drive backplane for drive bays 0 through 3 and connect it to the other connector on the controller. The following illustration show how to route the signal cables.

Note: When you restart the server, you will be prompted to import the existing RAID configuration to the new RAID controller.

70 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

Removing and installing a microprocessor and heat sink

To remove and install a microprocessor and heat sink, follow the instructions in this section.

Removing a microprocessor and heat sink

Attention:

vDo not allow the thermal grease on the microprocessor and heat sink to come in contact with anything. Contact with any surface can compromise the thermal grease and the microprocessor socket.

vDo not touch the microprocessor contacts; handle the microprocessor by the edges only. Contaminants on the microprocessor contacts, such as oil from your skin, can cause connection failures between the contacts and the socket.

To remove a microprocessor and heat sink, complete the following steps:

1.Read the safety information in “Safety” on page vii and “Installation guidelines” on page 39.

2.Turn off the server and peripheral devices and disconnect the power cords and all external cables, if necessary.

3.Remove the cover (see “Removing and replacing the cover” on page 43).

4.Disconnect any cables that impede access to the heat sink and microprocessor.

5.Open the heat sink release lever to the fully open position.

6.Lift the heat sink out of the server. After removal, place the heat sink on its side on a clean, flat surface.

1 Heat sink release lever 2 Microprocessor

3 Retainer bracket 4 Lock tab

7.Release the microprocessor retention latch by pressing down on the end, moving it to the side, and releasing it to the open (up) position.

8.Open the microprocessor bracket frame by lifting up the tab on the top edge. Keep the bracket frame in the open position.

Chapter 5. Installing optional devices and replacing customer replaceable units 71

1 Microprocessor bracket frame 2 Microprocessor

3 Microprocessor release lever

9.Carefully lift the microprocessor straight up and out of the socket, and place it on a static-protective surface.

10.If you are instructed to return the microprocessor, follow all packaging instructions, and use any packaging materials for shipping that are supplied to you.

Installing a microprocessor and heat sink

The following notes describe the type of microprocessor that the server supports and other information that you must consider when you install a microprocessor and heat sink:

vThe server supports up to two Intel Xeondual-core or quad-core microprocessors. See http://www.lenovo.com/thinkserver for a list of supported microprocessors.

vDo not mix dual-core and quad-core microprocessors in the same server.

vThe upgrade of microprocessors are not supported on this server. For example, if the server came with a 2.0 GHz microprocessor, you cannot upgrade the microprocessor to a 2.3 GHz microprocessor, it is not supported.

vThe first microprocessor must always be installed in microprocessor socket 1 on the system board.

vWhen one microprocessor is installed, a heat sink filler is not required for microprocessor socket 2, however, the microprocessor 2 air baffle and the DIMM air baffle must be installed to provide proper system cooling.

vDo not remove the first microprocessor from the system board when you install the second microprocessor.

vWhen you install the second microprocessor, you must also install additional memory.

vTo ensure proper server operation when you install an additional microprocessor, use microprocessors that have the same QuickPath Interconnect (QPI) link speed, integrated memory controller frequency, core frequency, power segment, internal cache size, and type.

vMixing microprocessors of different stepping levels within the same server model is supported.

vWhen mixing microprocessors with different stepping levels within the same server model, you do not have to install the microprocessor with lowest stepping level and features in microprocessor socket 1.

72 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

vBoth microprocessor voltage regulator modules are integrated on the system board.

vIf you have to replace a microprocessor, call for service.

vRead the documentation that comes with the microprocessor, so that you can determine whether you have to update the server firmware. To download the latest level of server firmware and other code updates for your server, complete the following steps:

1.Go to: http://www.lenovo.com/support.

2.Enter your product number (machine type and model number) or select

Servers and Storage from the Select your product list.

3.From Family list, select ThinkServer RD210, and click Continue.

4.Click Downloads and drivers to download firmware updates.

vThe microprocessor speeds are automatically set for this server; therefore, you do not have to set any microprocessor frequency-selection jumpers or switches.

vIf the thermal-grease protective cover (for example, a plastic cap or tape liner) is removed from the heat sink, do not touch the thermal grease on the bottom of the heat sink or set down the heat sink. For more information about applying or working with thermal grease, see “Thermal grease” on page 75.

Note: Removing the heat sink from the microprocessor destroys the even distribution of the thermal grease and requires replacing the thermal grease.

vTo order an additional optional microprocessor, contact your marketing representative or authorized reseller.

To install an additional microprocessor and heat sink, complete the following steps:

Attention: When you handle static-sensitive devices, take precautions to avoid damage from static electricity. For details about handling these devices, see “Handling static-sensitive devices” on page 41.

1.Read the safety information in “Safety” on page vii and “Installation guidelines” on page 39.

2.Install the microprocessor:

a.Press down and out on the release lever on microprocessor socket and lift up the microprocessor release lever until it stops in the fully open position.

b.Lift the hinged microprocessor bracket frame into an open position and remove the microprocessor dust cover, tape, or label from the surface of the microprocessor socket, if one is present. Store the dust cover in a safe place.

Attention: When you handle static-sensitive devices, take precautions to avoid damage from static electricity. For details about handling these devices, see “Handling static-sensitive devices” on page 41.

c.Touch the static-protective package that contains the new microprocessor to any unpainted metal surface on the server; then, remove the microprocessor from the package.

Chapter 5. Installing optional devices and replacing customer replaceable units 73

Attention:

vDo not touch the microprocessor contacts; handle the microprocessor by the edges only. Contaminants on the microprocessor contacts, such as oil from your skin, can cause connection failures between the contacts and the socket.

vHandle the microprocessor carefully. Dropping the microprocessor during installation or removal can damage the contacts.

vDo not use excessive force when you press the microprocessor into the socket.

vMake sure that the microprocessor is oriented and aligned and positioned in the socket before you try to close the lever.

d.Align the microprocessor with the socket (note the alignment mark and the position of the notches); then, carefully place the microprocessor on the socket and close the microprocessor bracket frame.

Note: The microprocessor fits only one way on the socket.

1 Microprocessor bracket frame 2 Microprocessor

3 Alignment marks

4 Microprocessor release level

e.Carefully close the microprocessor release lever to the closed position to secure the microprocessor in the socket.

3.Install the heat sink:

a.Clean the grease from the heat sink and apply new grease on the microprocessor.

b.Align the heat sink on top of the microprocessor.

c.Lower the rear flange of the heat-sink into the opening in the retainer bracket and press down firmly on the front of the heat-sink until it is seated securely.

74 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

1 Heat sink release lever 2 Lock tab

3 Retainer bracket 4 Microprocessor

d.Rotate the heat-sink release lever to the closed position and hook it underneath the lock tab.

4.If you removed the microprocessor 2 air baffle, install it (see “Removing and installing the microprocessor 2 air baffle” on page 47).

Thermal grease

The thermal grease must be replaced whenever the heat sink has been removed from the top of the microprocessor and is going to be reused or when debris is found in the grease.

When you are installing the heat sink on the same microprocessor that is was removed from, make sure that:

vThe thermal grease on the heat sink and microprocessor is not contaminated.

vAdditional thermal grease is not added to the existing thermal grease on the heat sink and microprocessor.

Note:

vRead the safety information in “Safety” on page vii and “Installation guidelines” on page 39.

To replace damaged or contaminated thermal grease on the microprocessor and heat sink, complete the following steps:

1.Place the heat sink on a clean work surface.

2.Remove the cleaning pad from its package and unfold it completely.

3.Use the cleaning pad to wipe the thermal grease from the bottom of the heat sink.

Note: Make sure that all of the thermal grease is removed.

4.Use a clean area of the cleaning pad to wipe the thermal grease 1 from the microprocessor2; then, dispose of the cleaning pad after all of the thermal grease is removed.

Chapter 5. Installing optional devices and replacing customer replaceable units 75

5.Use the thermal-grease syringe to place 9 uniformly spaced dots of 0.02 mL each on the top of the microprocessor. The outermost dots must be within approximately 5 mm of the edge of the microprocessor, this is to ensure uniform distribution of the grease.

Note: If the grease is properly applied, approximately half of the grease will remain in the syringe.

6. Install the heat sink onto the microprocessor.

If you have other options to install or remove, do so now. Otherwise, go to “Completing the installation” on page 111.

Removing and installing a hot-swap power supply

This procedure is used when either installing an optional hot-swap power supply or replacing a defective power supply. The removal procedure is used only when replacing a power supply.

This procedure applies only to server models that have hot-swap power supplies. When you remove or install a hot-swap power supply, observe the following precautions.

vThe server comes with one 675-watt hot-swap 12-volt output power supply. The input voltage is 110 V ac or 220 V ac auto-sensing.

vYou can install an optional 675-watt hot-swap 12-volt output power supply for redundancy.

vThese power supplies are designed for parallel operation. In the event of a power-supply failure, the redundant power supply continues to power the system. The server supports a maximum of two power supplies.

Statement 5:

76 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

CAUTION:

The power control button on the device and the power switch on the power supply do not turn off the electrical current supplied to the device. The device also might have more than one power cord. To remove all electrical current from the device, ensure that all power cords are disconnected from the power source.

2 1

Statement 8:

CAUTION:

Never remove the cover on a power supply or any part that has the following label attached.

Hazardous voltage, current, and energy levels are present inside any component that has this label attached. There are no serviceable parts inside these components. If you suspect a problem with one of these parts, contact a service technician.

Removing a hot-swap power supply

To remove a hot-swap power supply, complete the following steps:

1.Read the safety information in “Safety” on page vii and “Installation guidelines” on page 39.

2.If only one power supply is installed, turn off the server and peripheral devices and disconnect all power cords.

3.If the server is in a rack, at the back of the server, pull back the cable-management arm to gain access to the rear of the server and the power supply 1.

4.Press and hold the release tab 2 to the left. Grasp the handle and pull the power supply out of the server.

Chapter 5. Installing optional devices and replacing customer replaceable units 77

5.If you are instructed to return the power supply, follow all packaging instructions, and use any packaging materials for shipping that are supplied to you.

6.If you are replacing a defective power supply, continue to “Installing a hot-swap power supply.”

Installing a hot-swap power supply

The following notes describe the type of power supply that the server supports and other information that you must consider when installing a power supply:

To install a hot-swap power supply, complete the following steps:

1.Read the safety information in “Safety” on page vii and “Installation guidelines” on page 39.

2.Touch the static-protective package that contains the hot-swap power supply 2 to any unpainted metal surface on the server; then, remove the power supply2 from the package and place it on a static-protective surface.

3.If you are installing a hot-swap power supply into an empty bay, remove the power-supply filler panel 3 from the power-supply bay.

4.Grasp the handle on the rear of the power supply and slide the power supply forward into the power-supply bay until it clicks. Make sure that the power supply connects firmly into the power-supply backplane.

78 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

5.Route the power cord through the handle so that it does not accidentally become unplugged.

6.Connect the power cord for the new power supply to the power-cord connector on the power supply.

7.Connect the other end of the power cord to a properly grounded electrical outlet.

8.Make sure that the ac power LED and the dc power LED on the power supply are lit, indicating that the power supply is operating correctly. The two green LEDs are to the right of the power-cord connector.

Removing and installing a hot-swap fan assembly

The server supports up to six hot-swap cooling fans.

Removing a hot-swap fan assembly

Attention: To ensure proper server operation, replace a failed fan within 30 seconds.

To remove a hot-swap-fan, complete the following steps:

1.Read the safety information in “Safety” on page vii and “Installation guidelines” on page 39.

2.Remove the cover (see “Removing and replacing the cover” on page 43). The LED near the connector of the failing fan assembly is lit.

3.Disconnect the cable of the failing fan from the connector.

Chapter 5. Installing optional devices and replacing customer replaceable units 79

1

Fan tabs

6

Fan 4

2 Fan connector on the

7

Fan 5



system board





3

Fan 1

8

Fan 6

4

Fan 2

9

Fan connector

5

Fan 3

10

Fan (side view)

4.Grasp the orange fan tabs on both ends of the fan and pull it up out of the server. If you are removing fans 3 and 4, you need to first remove the DIMM air baffle (see “Removing and installing the DIMM air baffle” on page 48).

Attention: To ensure proper operation, replace a failed fan as soon as possible.

5.If you are instructed to return the fan, follow all of the packaging instructions, and use any packaging materials for shipping that are supplied to you.

Installing a hot-swap fan assembly

To install an additional hot-swap fan, complete the following steps:

1.Read the safety information in “Safety” on page vii and “Installation guidelines” on page 39.

2.Remove the cover (see “Removing and replacing the cover” on page 43).

3.Touch the static-protective package that contains the new fan to any unpainted metal surface on the server. Then, remove the new fan from the package.

4.If you are replacing a fan, grasp the orange fan tabs 1 on both ends of the existing fan and pull it up out of the server. If you are replacing fans 3 and 4, you will need to remove the DIMM air baffle first (see “Removing and installing the DIMM air baffle” on page 48).

80 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































1

Fan tabs

6







Fan 4









2 Fan connector on the

7







Fan 5











system board





































3

Fan 1

8







Fan 6









4

Fan 2

9







Fan connector









5

Fan 3

10



Fan (side view)









Attention: To ensure proper operation, replace a failed fan as soon as possible.

5.Orient the new fan over the fan slot in the fan assembly bracket so that the fan cable connector aligns with the fan connector on the system board.

6.Insert the fan into the fan slot in the fan assembly bracket and press it down until it is seated correctly in the slot and the fan cable is seated correctly in the fan connector on the system board.

Chapter 5. Installing optional devices and replacing customer replaceable units 81

If you have other options to install or remove, do so now. Otherwise, go to “Completing the installation” on page 111.

Removing and installing the SAS/SATA RAID riser-card assembly

To remove and install the SAS/SATA RAID riser-card assembly, complete the steps in this section.

Removing the SAS/SATA RAID riser-card assembly

To remove the SAS/SATA RAID riser-card assembly, complete the following steps:

1.Read the safety information in “Safety” on page vii and “Installation guidelines” on page 39.

2.Turn off the server and peripheral devices and disconnect all power cords; then, remove the cover (see “Removing and replacing the cover” on page 43).

3.Disconnect the cables from the connectors on the SAS/SATA controller; then, grasp the controller and pull it out of the connector on the RAID riser-card assembly.

4.Remove the flash device from the SAS/SATA RAID riser card 1, if one is installed.

1 SAS/SATA riser card

2 ServeRAID-BR10i controller

5.If you are instructed to return the RAID riser-card assembly, follow all packaging instructions, and use any packaging materials for shipping that are supplied to you.

Installing the SAS/SATA RAID riser-card assembly

To install the SAS/SATA RAID riser-card assembly, complete the following steps:

1.Read the safety information in “Safety” on page vii and “Installation guidelines” on page 39.

2.Turn off the server and peripheral devices and disconnect the power cords and all external cables; then, remove the server cover (see “Removing and replacing the cover” on page 43).

3.Reinstall the SAS/SATA adapter, if one was removed.

82 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide

4.Reinstall the flash device, if it was removed.

5.Align the SAS/SATA RAID riser-card assembly keys correctly with the connector on the system board and press down on the assembly until it is seated firmly into the connector on the system board.

6.Connect the signal cables to the SAS/SATA adapter.

7.Install the cover.

8.Slide the server into the rack.

9.Reconnect the power cord and any cables that you removed.

10.Turn on the peripheral devices and the server.

Removing and installing the battery

To remove and install the battery, complete the steps in this section.

Removing the battery

To remove the system-board battery, complete the following steps:

1.Read the safety information in “Safety” on page vii and “Installation guidelines” on page 39.

2.Turn off the server and peripheral devices and disconnect all power cords; then, remove the cover (see “Removing and replacing the cover” on page 43).

3.If necessary, lift the riser-card assembly out of the way (see “Removing and installing a PCI riser-card assembly” on page 53).

4.Locate the battery 1 on the system board.

Chapter 5. Installing optional devices and replacing customer replaceable units 83

5.Remove the system-board battery:

a. Use one finger to push the battery horizontally out of its housing.

b. Use your thumb and index finger to lift the battery from the socket.

6.Dispose of the battery as required by local ordinances or regulations. See the

Safety and Warranty Guide for more information.

Installing the battery

The following notes describe information that you must consider when replacing the system-board battery in the server.

vWhen replacing the system-board battery, you must replace it with a lithium battery of the same type from the same manufacturer.

vAfter you replace the system-board battery, you must reconfigure the server and reset the system date and time.

vTo avoid possible danger, read and follow the following safety statement.

84 ThinkServer RD210 Types 3795, 3796, 3818, and 3819: Installation and User Guide
