Intel® Desktop Board DX58SO

Product Guide

Order Number: E43166-001

Revision History

Revision

Revision History

Date

-001

First release of the Intel® Desktop Board DX58SO Product Guide

August 2008

If an FCC declaration of conformity marking is present on the board, the following statement applies:

FCC Declaration of Conformity

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

For questions related to the EMC performance of this product, contact:

Intel Corporation, 5200 N.E. Elam Young Parkway, Hillsboro, OR 97124 1-800-628-8686

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and the receiver.

Connect the equipment to an outlet on a circuit other than the one to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Any changes or modifications to the equipment not expressly approved by Intel Corporation could void the user’s authority to operate the equipment.

Tested to comply with FCC standards for home or office use.

Canadian Department of Communications Compliance Statement

This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.

Le présent appareil numerique német pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la classe B prescrites dans le Réglement sur le broullage radioélectrique édicté par le ministére des Communications du Canada.

Disclaimer

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL® PRODUCTS. NO LICENSE, EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. Intel products are not intended for use in medical, life saving, or life sustaining applications. Intel may make changes to specifications and product descriptions at any time, without notice.

Intel Desktop Board DX58SO may contain design defects or errors known as errata which may cause the product to deviate from published specifications. Current characterized errata are available on request.

Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.

Copies of documents which have an ordering number and are referenced in this document, or other Intel literature, may be obtained from Intel Corporation by going to the World Wide Web site at: http://www.intel.com/ or by calling 1-800-548-4725.

Intel and Pentium are trademarks of Intel Corporation in the United States and other countries. * Other names and brands may be claimed as the property of others.

Copyright © 2008, Intel Corporation. All rights reserved.

Preface

This Product Guide gives information about board layout, component installation, BIOS update, and regulatory requirements for Intel® Desktop Board DX58SO.

Intended Audience

The Product Guide is intended for technically qualified personnel. It is not intended for general audiences.

Use Only for Intended Applications

All Intel Desktop Boards are evaluated as Information Technology Equipment (I.T.E.) for use in personal computers (PC) for installation in homes, offices, schools, computer rooms, and similar locations. The suitability of this product for other PC or embedded non-PC applications or other environments, such as medical, industrial, alarm systems, test equipment, etc. may not be supported without further evaluation by Intel.

Document Organization

The chapters in this Product Guide are arranged as follows:

1Desktop Board Features: a summary of product features

2Installing and Replacing Desktop Board Components: instructions on how to install the Desktop Board and other hardware components

3Updating the BIOS: instructions on how to update the BIOS

4Configuring for RAID: information about configuring your system for RAID

AError Messages and Indicators: information about BIOS error messages and beep codes

BRegulatory Compliance: describes the board’s adherence to safety standards and EMC regulations and its product certifications

Conventions

The following conventions are used in this manual:

CAUTION

Cautions warn the user about how to prevent damage to hardware or loss of data.

NOTE

Notes call attention to important information.

iii

Intel Desktop Board DX58SO Product Guide

Terminology

The table below gives descriptions of some common terms used in the product guide.

Term

Description





GB

Gigabyte (1,073,741,824 bytes)





GHz

Gigahertz (one billion hertz)





KB

Kilobyte (1024 bytes)





MB

Megabyte (1,048,576 bytes)





Mb

Megabit (1,048,576 bits)





MHz

Megahertz (one million hertz)





iv

Contents

1

Desktop Board Features





Supported Operating Systems..............................................................................

10



Desktop Board Components.................................................................................

11



Processor..........................................................................................................

13



Main Memory.....................................................................................................

14



Intel® X58 Express Chipset..................................................................................

15



Audio Subsystem ...............................................................................................

15



LAN Subsystem .................................................................................................

16



USB 2.0 Support ................................................................................................

17



Serial ATA.........................................................................................................

17



Legacy I/O........................................................................................................

18



Expandability.....................................................................................................

18



BIOS................................................................................................................

18



Serial ATA and IDE Auto Configuration...........................................................

18



PCI and PCI Express* Auto Configuration .......................................................

19



Security Passwords.....................................................................................

19



Hardware Management .......................................................................................

19



Hardware Monitoring and Fan Speed Control ..................................................

19



Intel® Precision Cooling Technology .......................................................

20



Chassis Intrusion........................................................................................

20



Power Management ............................................................................................

20



Software Support .......................................................................................

20



ACPI..................................................................................................

20



Hardware Support ......................................................................................

20



Power Connectors ...............................................................................

20



Fan Headers .......................................................................................

21



LAN Wake Capabilities..........................................................................

21



Instantly Available PC Technology..........................................................

21



+5 V Standby Power Indicator...............................................................

22



Wake from USB ..................................................................................

23



PME# Signal Wake-up Support..............................................................

23



WAKE# Signal Wake-up Support ...........................................................

23



ENERGY STAR* Capable ..............................................................................

23



Onboard Power Button........................................................................................

23



Onboard VR and CPU LEDs ..................................................................................

24



Speaker............................................................................................................

25



Battery.............................................................................................................

25



Real-Time Clock.................................................................................................

25

2

Installing and Replacing Desktop Board Components





Before You Begin ...............................................................................................

27



Installation Precautions.......................................................................................

28



Prevent Power Supply Overload ....................................................................

28



Observe Safety and Regulatory Requirements.................................................

28



Installing the I/O Shield ......................................................................................

29



Installing and Removing the Desktop Board ...........................................................

30



Installing and Removing a Processor.....................................................................

31

v

Intel Desktop Board DX58SO Product Guide





Installing a Processor ..................................................................................

31



Installing the Processor Fan Heat Sink ...........................................................

35



Connecting the Processor Fan Heat Sink Cable................................................

35



Removing the Processor ..............................................................................

35



Installing the ICH Heat Sink Decorative Cover (Optional) .........................................

36



Installing the IOH Cooling Fan (Optional)...............................................................

37



Installing and Removing Memory..........................................................................

38



Guidelines for Memory Configuration .............................................................

38



Installing DIMMs ........................................................................................

39



Removing DIMMs........................................................................................

41



Installing and Removing a PCI Express x16 Card ....................................................

42



Installing Multiple PCI Express x16 Graphics Cards ..........................................

42



Installing a PCI Express x16 Card .................................................................

43



Removing a PCI Express x16 Card ................................................................

44



Connecting the Serial ATA (SATA) Cables ..............................................................

45



Connecting to the Internal Headers and Connectors ................................................

46



Front Panel Audio Header ............................................................................

47



HD Audio Link Header .................................................................................

47



Consumer IR (CIR) Headers .........................................................................

48



Chassis Intrusion Header .............................................................................

49



IEEE 1394a Header.....................................................................................

49



USB 2.0 Headers ........................................................................................

50



Front Panel Header .....................................................................................

50



Alternate Front Panel Power LED Header ........................................................

51



S/PDIF Connector .......................................................................................

51



Connecting to the Audio System...........................................................................

52



Connecting Chassis Fan and Power Supply Cables...................................................

53



Connecting Chassis Fan Cables .....................................................................

53



Connecting Power Supply Cables ..................................................................

54



Setting the BIOS Configuration Jumper .................................................................

55



Clearing Passwords ............................................................................................

56



Replacing the Battery .........................................................................................

57

3

Updating the BIOS





Updating the BIOS with the Intel® Express BIOS Update Utility.................................

63



Updating the BIOS with the ISO Image BIOS Update File or the Iflash Memory





Update Utility...............................................................................................

64



Obtaining the BIOS Update File ....................................................................

64



Updating the BIOS with the ISO Image BIOS Update File .................................

64



Updating the BIOS with the Iflash Memory Update Utility .................................

65



Recovering the BIOS...................................................................................

66

4

Configuring for RAID





Configuring for RAID Using Intel® Matrix Storage Technology ...................................

67



Configuring the BIOS ..................................................................................

67



Creating Your RAID Set ...............................................................................

67



Loading the Intel Matrix Storage Technology RAID Drivers and Software ............

68



Setting Up a “RAID Ready” System ...............................................................

68



Configuring for External RAID Using Marvell* Storage Technology.............................

69



Configuring the BIOS ..................................................................................

69



Creating Your RAID Set ...............................................................................

69



Loading the Marvell Storage Technology RAID Drivers and Software ..................

69

vi







Contents

A

Error Messages and Indicators





BIOS Beep Codes...............................................................................................

71



BIOS Error Messages ..........................................................................................

71

B

Regulatory Compliance





Safety Standards ...............................................................................................

73





Place Battery Marking .................................................................................

73



European Union Declaration of Conformity Statement..............................................

74



Product Ecology Statements ................................................................................

75





Recycling Considerations .............................................................................

75





Lead-free 2LI/Pb-free 2LI Board ...................................................................

78





Restriction of Hazardous Substances (RoHS) ..................................................

79





EU RoHS ............................................................................................

79





China RoHS ........................................................................................

80



EMC Regulations ................................................................................................

82





Ensure Electromagnetic Compatibility (EMC) Compliance..................................

83



Product Certifications..........................................................................................

84





Board-Level Certification Markings ................................................................

84





Chassis and Component Certifications............................................................

85

Figures





1.

Intel Desktop Board DX58SO Components .......................................................

11



2.

LAN Connector LEDs .....................................................................................

16



3.

HDD Activity LED..........................................................................................

17



4.

Location of the Standby Power Indicator ..........................................................

22



5.

Onboard Power Button ..................................................................................

24



6.

Location of the VR and CPU LEDs ....................................................................

25



7.

Installing the I/O Shield ................................................................................

29



8.

Intel Desktop Board DX58SO Mounting Screw Hole Locations..............................

30



9.

Lift the Socket Lever .....................................................................................

31



10.

Lift the Load Plate.........................................................................................

32



11.

Remove the Protective Socket Cover ...............................................................

32



12.

Remove the Processor from the Protective Processor Cover ................................

33



13.

Install the Processor .....................................................................................

33



14.

Close the Load Plate .....................................................................................

34



15.

Connecting the Processor Fan Heat Sink Cable to the Processor Fan Header..........

35



16.

Installing the ICH Heat Sink Decorative Cover ..................................................

36



17.

Installing the IOH Fan ...................................................................................

37



18.

Triple Channel Memory Configuration ..............................................................

38



19.

Dual Channel Memory Configuration................................................................

38



20.

Single Channel Memory Configuration .............................................................

39



21.

Use DDR3 DIMMs .........................................................................................

39



22.

Installing a DIMM .........................................................................................

40



23.

Installing Multiple PCI Express x16 Graphics Cards ............................................

42



24.

Installing a PCI Express x16 Card ...................................................................

43



25.

Removing a PCI Express x16 Card ..................................................................

44



26.

Connecting the Serial ATA Cables....................................................................

45



27.

Internal Headers and Connectors ....................................................................

46



28.

Back Panel Audio Connectors .........................................................................

52



29.

Location of the Chassis Fan Headers................................................................

53

vii

Intel Desktop Board DX58SO Product Guide



30.

Connecting Power Supply Cables ....................................................................

54

31.

Location of the BIOS Configuration Jumper Block ..............................................

55

32.

Removing the Battery ...................................................................................

61

33.

Intel Desktop Board DX58SO China RoHS Material Self Declaration Table .............

81

Tables



1.

Feature Summary..........................................................................................

9

2.

Intel Desktop Board DX58SO Components .......................................................

12

3.

LAN Connector LEDs .....................................................................................

16

4.

Front Panel Audio Header Signal Names...........................................................

47

5.

HD Audio Link Header Signal Names ...............................................................

47

6.

Front Panel CIR Receiver (Input) Header Signal Names ......................................

48

7.

Back Panel CIR Header Emitter (Output) Header Signal Names ...........................

48

8.

Chassis Intrusion Header Signal Names ...........................................................

49

9.

IEEE 1394a Header Signal Names ...................................................................

49

10.

USB 2.0 Header Signal Names........................................................................

50

11.

Front Panel Header Signal Names ...................................................................

50

12.

Alternate Front Panel Power LED Header Signal Names ......................................

51

13.

S/PDIF Connector Signal Names .....................................................................

51

14.

Jumper Settings for the BIOS Setup Program Modes..........................................

56

15.

Beep Codes .................................................................................................

71

16.

BIOS Error Messages ....................................................................................

71

17.

Safety Standards..........................................................................................

73

18.

Lead-Free Second Level Interconnect Marks .....................................................

79

19.

China RoHS Environmentally Friendly Use Period Mark .......................................

80

20.

EMC Regulations...........................................................................................

82

21.

Product Certification Markings ........................................................................

84

viii

1 Desktop Board Features

This chapter briefly describes the features of Intel® Desktop Board DX58SO. Table 1 summarizes the major features of the Desktop Board.

Table 1. Feature Summary

Form Factor

ATX (304.80 millimeters [12.00 inches] x 243.84 millimeters



[9.60 inches])







Processor

Support for an Intel® processor in the LGA1366 package

Main Memory

Four 240-pin DDR3 SDRAM Dual Inline Memory Module (DIMM)





sockets arranged in three channels



Support for DDR3 1333 MHz, DDR3 1066 MHz, and DDR3 800 MHz





DIMMs



Support for non-ECC memory



Support for up to 16 GB of system memory







Chipset

Intel® X58 Express Chipset consisting of:



Intel X58 Express Chipset I/O Controller Hub (IOH)



Intel® I/O Controller Hub (ICH10R) supporting Intel® Matrix Storage





Technology







Graphics

Support for multiple PCI Express* graphics cards









Audio

Independent multi-streaming 8-channel (7.1) audio and 2-channel





audio subsystem, featuring:





― Intel® High Definition Audio interface





― RealTek* ALC889 codec



HD Audio Link header



HD Audio front panel header



Onboard 3-pin S/PDIF connector









Expansion

Two PCI Express 2.0 x16 ports

Capabilities

One PCI Express 2.0 x4 port





Two PCI Express 1.1 x1 ports



One PCI* bus connector







Legacy I/O Support

Legacy I/O Controller that provides Consumer Infrared (CIR) support









Peripheral

Up to 12 USB 2.0 ports:

Interfaces



― Eight ports routed to the back panel









― Four ports routed to two USB headers



Up to two IEEE 1394a ports:





― One port routed to the back panel





― One port routed to an IEEE 1394a header



Six Serial ATA (SATA) channels (3.0 Gb/s) via ICH10R



Two external SATA (eSATA) channels via a discrete controller









RAID

Intel® Matrix Storage Technology for Serial ATA





continued

9

Intel Desktop Board DX58SO Product Guide

Table 1. Feature Summary (continued)

LAN Support

Intel 82567LF Gigabit (10/100/1000 Mb/s) Ethernet LAN controller



including an RJ-45 back panel connector with integrated status LEDs

BIOS

Intel® Platform Innovation Framework for extensible firmware





interface



16 Mb symmetrical flash memory device



Support for SMBIOS



Intel® Rapid BIOS Boot



Intel® Express BIOS Update

Power Management

Support for Advanced Configuration and Power Interface (ACPI)



Suspend to RAM (STR)



Wake on USB, PCI, PCI Express, LAN, CIR, and front panel



ENERGY STAR* capable





Hardware

Hardware monitor with:

Management

Four fan sensing inputs used to monitor fan activity





Intel® Precision Cooling Technology fan speed control



Voltage sensing to detect out of range values







Related Links:

For more information about Intel Desktop Board DX58SO, including the Technical Product Specification (TPS), BIOS updates, and device drivers, go to http://support.intel.com/support/motherboards/desktop/

Supported Operating Systems

The Desktop Board supports the following operating systems:

Microsoft Windows Vista* Ultimate

Microsoft Windows Vista Enterprise

Microsoft Windows Vista Business

Microsoft Windows Vista Home Premium

Microsoft Windows Vista Home Basic

Microsoft Windows Vista Ultimate 64-bit edition

Microsoft Windows Vista Enterprise 64-bit edition

Microsoft Windows Vista Business 64-bit edition

Microsoft Windows Vista Home Premium 64-bit edition

Microsoft Windows Vista Home Basic 64-bit edition

Microsoft Windows* XP Media Center Edition 2005

Microsoft Windows XP Professional

Microsoft Windows XP Professional x64 Edition

Microsoft Windows XP Home

10

Intel DX58SO User Manual

Desktop Board Features

Desktop Board Components

Figure 1 shows the approximate location of the major components on Intel Desktop Board DX58SO.

Figure 1. Intel Desktop Board DX58SO Components

11

Intel Desktop Board DX58SO Product Guide

Table 2. Intel Desktop Board DX58SO Components

Label

Description





A

Rear chassis fan header 2 (4-pin)





B

PCI Express 1.1 x1 connector





C

PCI Express 2.0 x16 secondary connector





D

Front panel audio header





E

PCI bus connector





F

PCI Express 1.1 x1 connector





G

PCI Express 2.0 x16 primary connector





H

PCI Express 2.0 x4 connector





I

Auxiliary PCI Express graphics power connector (1 x 4 pin)





J

Back panel connectors





K

Processor fan header (4-pin)





L

Rear chassis fan header (3-pin)





M

Processor socket





N

DDR3 Channel A, DIMM 0 and DIMM 1 sockets





O

DDR3 Channel B, DIMM 0 socket





P

DDR3 Channel C, DIMM 0 socket





Q

Main power connector (2 x 12 pin)





R

IOH fan header (3-pin)





S

12 V processor core voltage connector (2 x 4 pin)





T

Chassis intrusion header





U

Front chassis fan header (3-pin)





V

Serial ATA connectors





W

USB 2.0 headers





X

Battery





Y

IEEE 1394a header





Z

Onboard power button





AA

BIOS configuration jumper block





BB

Alternate front panel power LED header





CC

Front panel CIR receiver (input) header





DD

Back panel CIR transmitter (output) header





EE

Front panel header





FF

High Definition Audio Link header





GG

Auxiliary PCI Express graphics power connector (SATA-style)





HH

S/PDIF connector





12

Desktop Board Features

Related Links:

Go to the following links for more information about:

Intel Desktop Board DX58SO

http://www.intel.com/design/motherbd





http://support.intel.com/support/motherboards/





desktop

Supported processors

http://processormatch.intel.com

Audio software and utilities

http://www.intel.com/design/motherbd

LAN software and drivers

http://www.intel.com/design/motherbd

Processor

CAUTION

Failure to use an appropriate power supply and/or not connecting the 12 V (2 x 4 pin) power connector to the Desktop Board may result in damage to the board, or the system may not function properly.

Intel Desktop Board DX58SO supports an Intel processor in the LGA1366 package. Processors are not included with the Desktop Board and must be purchased separately. The processor connects to the Desktop Board through the LGA1366 socket.

Related Links:

Go to the following page or link for more information about:

Instructions on installing or upgrading the processor, page 31 in Chapter 2

Supported processors for Intel Desktop Board DX58SO, http://processormatch.intel.com

13

Intel Desktop Board DX58SO Product Guide

Main Memory

NOTE

To be fully compliant with all applicable Intel® SDRAM memory specifications, the board should be populated with DIMMs that support the Serial Presence Detect (SPD) data structure. If your memory modules do not support SPD, you will see a notification to this effect on the screen at power up. The BIOS will attempt to configure the memory controller for normal operation.

The Desktop Board supports the following memory features:

Four 240-pin Double Data Rate 3 (DDR3) SDRAM Dual Inline Memory Module (DIMM) connectors with gold-plated contacts arranged in three channels

1333/1066/800 MHz DDR3 SDRAM interface

Support for single-, dual-, and triple-channel memory interleaving

Unbuffered, non-registered single or double-sided DIMMs with a voltage rating of less than 1.6 V.

NOTE

Using a DIMM with a voltage rating higher than 1.6 V may damage the processor.

Non-ECC DDR3 memory

Serial Presence Detect (SPD) memory only

Up to 16 GB maximum total system memory

NOTE

32-bit operating systems are limited to a maximum of 4 GB of memory. The operating system report less than 4 GB because of the memory used by add-in graphics cards.

Related Links:

Go to the following links or pages for more information about:

SDRAM specifications, http://www.intel.com/technology/memory/

Installing memory, page 38 in Chapter 2

14

Desktop Board Features

Intel® X58 Express Chipset

The Intel X58 Express Chipset consists of the following devices:

Intel X58 Express Chipset I/O Hub (IOH)

Intel 82801IJR I/O Controller Hub (ICH10R)

The IOH provides interfaces to the processor and the PCI Express bus. ICH10R is the centralized controller for the board’s I/O paths.

Related Links:

Go to the following link for more information about the Intel X58 Express Chipset: http://developer.intel.com/products/chipsets/index.htm

Audio Subsystem

The onboard audio subsystem consists of the following components:

Intel® ICH10R I/O controller hub

RealTek ALC889 codec

The subsystem has the following headers and connectors:

Back panel audio connectors, including an S/PDIF optical port

High Definition (HD) Audio front panel header that provides mic in and line out signals for front panel audio connectors

HD Audio Link header used for HDMI video cards

S/PDIF connector that can be used for HDMI video cards that do not work with the HD Audio Link header

The audio subsystem supports the following features:

Dolby* Home Theater

A signal-to-noise (S/N) ratio of 95 dB

Independent multi-streaming 8-channel (7.1) audio (using the back panel audio connectors) and 2-channel audio (using the Intel High Definition Audio front panel header)

Related Links:

Go to the following link or pages for more information about:

Audio drivers and utilities http://support.intel.com/support/motherboards/desktop/

The location of the onboard audio headers, Figure 27 on page 46

The signal names for the Intel High Definition Audio front panel header and the HD Audio Link header, page 47

The back panel audio connectors, Figure 28 on page 52

15

Intel Desktop Board DX58SO Product Guide

LAN Subsystem

The LAN subsystem includes:

Intel ICH10R

Intel 82567LF Gigabit (10/100/1000 Mb/s) Ethernet LAN controller

RJ-45 LAN connector with integrated status LEDs

The subsystem features:

CSMA/CD protocol engine

LAN connect interface between ICH10R and the LAN controller

PCI bus power management

Related Links:

Go to the following link for information about LAN software and drivers: http://support.intel.com/support/motherboards/desktop

Two LEDs are built into the RJ-45 LAN connector located on the back panel (see Figure 2). These LEDs indicate the status of the LAN.

Figure 2. LAN Connector LEDs

Table 3 describes the LED states when the board is powered up and the LAN subsystem is operating.

Table 3. LAN Connector LEDs

LED

LED Color

LED State

Indicates









A

Green

Off

LAN link is not established













On

LAN link is established













Blinking

LAN activity is occurring









B

N/A

Off

10 Mb/s data rate











Green

On

100 Mb/s data rate











Yellow

On

1000 Mb/s data rate









16

Desktop Board Features

USB 2.0 Support

The Desktop Board supports up to 12 USB 2.0 ports (eight ports routed to back panel connectors and four ports routed to two onboard headers) via the ICH10R. USB 2.0 ports are backward compatible with USB 1.1 devices. USB 1.1 devices will function normally at USB 1.1 speeds.

USB 2.0 support requires both an operating system and drivers that fully support USB 2.0 transfer rates. Disabling Hi-Speed USB in the BIOS reverts all USB 2.0 ports to USB 1.1 operation. This may be required to accommodate operating systems that do not support USB 2.0.

Serial ATA

Intel Desktop Board DX58SO supports six onboard Serial ATA channels (3.0 Gb/s) via ICH10R and two eSATA channels (3.0 Gb/s) via a discrete controller.

The Desktop Board includes a disk drive activity indicator (a green LED) shown in Figure 3.

Figure 3. HDD Activity LED

17

Intel Desktop Board DX58SO Product Guide

The six onboard Serial ATA channels provided by ICH10R support the following RAID (Redundant Array of Independent Drives) levels:

RAID 0 - data striping

RAID 1 - data mirroring

RAID 0+1 (or RAID 10) - data striping and data mirroring

RAID 5 - distributed parity

For information on configuring your system for RAID using Intel® Matrix Storage Technology see Chapter 4.

Legacy I/O

Intel Desktop Board DX58SO includes an I/O controller that provides the following legacy I/O features:

Consumer Infrared (CIR) support

Low pin count (LPC) interface

Intelligent power management, including a programmable wake up event interface

PCI power management support

Expandability

Intel Desktop Board DX58SO provides the following expansion capability:

Two PCI Express 2.0 x16 ports

One PCI Express 2.0 x4 port

Two PCI Express 1.1 x1 ports

One PCI bus connector

BIOS

The BIOS provides the Power-On Self-Test (POST), the BIOS Setup program, and the PCI/PCI Express and IDE auto-configuration utilities. The BIOS is stored in the Serial Peripheral Interface (SPI) Flash device.

The BIOS can be updated by following the instructions on page 63 in Chapter 3.

Serial ATA and IDE Auto Configuration

If you install a Serial ATA or IDE device (such as a hard drive) in your computer, the auto-configuration utility in the BIOS automatically detects and configures the device for your computer. You do not need to run the BIOS Setup program after installing a Serial ATA or IDE device. You can override the auto-configuration options by specifying manual configuration in the BIOS Setup program.

18

Desktop Board Features

PCI and PCI Express* Auto Configuration

If you install a PCI/PCI Express add-in card in your computer, the PCI/PCI Express auto-configuration utility in the BIOS automatically detects and configures the resources (IRQs, DMA channels, and I/O space) for that add-in card. You do not need to run the BIOS Setup program after you install a PCI/PCI Express add-in card.

Security Passwords

The BIOS includes security features that restrict whether the BIOS Setup program can be accessed and who can boot the computer. A supervisor password and a user password can be set for the BIOS Setup and for booting the computer, with the following restrictions:

The supervisor password gives unrestricted access to view and change all Setup options. If only the supervisor password is set, pressing <Enter> at the password prompt of Setup gives the user restricted access to Setup.

If both the supervisor and user passwords are set, you must enter either the supervisor password or the user password to access Setup. Setup options are then available for viewing and changing depending on whether the supervisor or user password was entered.

Setting a user password restricts who can boot the computer. The password prompt is displayed before the computer is booted. If only the supervisor password is set, the computer boots without asking for a password. If both passwords are set, you can enter either password to boot the computer.

Related Links:

For instructions on resetting the password, go to Clearing Passwords on page 56.

Hardware Management

The hardware management features of Intel Desktop Board DX58SO enable the board to be compatible with the Wired for Management (WfM) specification. The board has several hardware management features including the following:

Fan speed monitoring and control

Thermal and voltage monitoring

Chassis intrusion detection

Hardware Monitoring and Fan Speed Control

The features of the hardware monitoring and fan speed control include:

Monitoring of power supply voltages to detect levels above and below acceptable values

Intel® Precision Cooling Technology fan speed control, delivering acousticallyoptimized thermal management

A thermal sensor in the processor

Thermally monitored closed-loop fan control, for all onboard fans, that can adjust fan speed

19

Intel Desktop Board DX58SO Product Guide

Intel® Precision Cooling Technology

Intel Precision Cooling Technology automatically adjust processor fan speed based on the processor temperature and adjusts chassis fan speeds based on the internal system temperature.

Chassis Intrusion

The board supports a chassis security feature that detects if the chassis cover has been removed. The security feature uses a mechanical switch on the chassis that can be connected to the chassis intrusion header on the Desktop Board. See Figure 27 for the location of the chassis intrusion header.

Power Management

Power management is implemented at several levels, including software support through the Advanced Configuration and Power Interface (ACPI) and the following hardware support:

Power connectors

Fan headers

LAN wake capabilities

Instantly Available PC technology (Suspend to RAM)

+5 V standby power indicator LED

Wake from USB

Power Management Event signal (PME#) wakeup support

WAKE# signal wake-up support

ENERGY STAR capable

Software Support

ACPI

ACPI gives the operating system direct control over the power management and Plug and Play functions of a computer. The use of ACPI with the Desktop Board requires an operating system that provides full ACPI support.

Hardware Support

Power Connectors

ATX12V-compliant power supplies can turn off the computer power through system control. When an ACPI-enabled computer receives the correct command, the power supply removes all non-standby voltages.

When resuming from an AC power failure, the computer returns to the power state it was in before power was interrupted (either on or off). The computer’s response can be set by using the Last Power State feature in the BIOS Setup program’s Boot menu.

20

Desktop Board Features

The Desktop Board has three power connectors. See Figure 30 on page 54 for the location of the power connectors.

Fan Headers

The function/operation of the fans is as follows:

The fans are on when the computer is in the ACPI S0 state.

The fans are off when the computer is in the ACPI S3, S4, or S5 state.

Each fan header is wired to a tachometer input of the hardware monitoring and control device.

All fan headers support closed-loop fan control that can adjust the fan speed or switch the fan on or off as needed.

All fan headers have a +12 V DC connection.

The Desktop Board has a 4-pin processor fan header, one 4-pin and two 3-pin chassis fan headers, and one 3-pin IOH fan header.

LAN Wake Capabilities

CAUTION

For LAN wake capabilities, the 5 V standby line for the power supply must be capable of delivering adequate +5 V standby current. Failure to provide adequate standby current when using this feature can damage the power supply.

LAN wakeup capabilities enable remote wake-up of the computer through a network. The LAN subsystem monitors network traffic and upon detecting a Magic Packet* frame, it asserts a wake-up signal that powers up the computer.

Instantly Available PC Technology

CAUTIONS

For Instantly Available PC technology, the 5 V standby line for the power supply must be capable of delivering adequate +5 V standby current. Failure to provide adequate standby current when using this feature can damage the power supply and/or effect ACPI S3 sleep state functionality.

Power supplies used with this Desktop Board must be able to provide enough standby current to support the standard Instantly Available (ACPI S3 sleep state) configuration. If the standby current necessary to support multiple wake events from the PCI and/or USB buses exceeds power supply capacity, the Desktop Board may lose register settings stored in memory.

Instantly Available PC technology enables the board to enter the ACPI S3 (Suspend-to- RAM) sleep state. While in the S3 sleep state, the computer will appear to be off. If the computer has a dual-colored power LED on the front panel, the sleep state is indicated by the LED turning amber. When signaled by a wake-up device or event, the computer quickly returns to its last known awake state.

21

Intel Desktop Board DX58SO Product Guide

The Desktop Board supports the PCI Bus Power Management Interface Specification. Add-in cards that support this specification can participate in power management and can be used to wake the computer.

+5 V Standby Power Indicator

CAUTION

If the AC power has been switched off and the standby power indicator is still lit, disconnect the power cord before installing or removing any devices connected to the board. Failure to do so could damage the board and any attached devices.

The Desktop Board’s standby power indicator, shown in Figure 4, is lit when there is standby power still present on the board even when the computer appears to be off. For example, when this LED is lit, standby power is still present at the memory module sockets and the PCI bus connectors.

Figure 4. Location of the Standby Power Indicator

For more information on standby current requirements for the Desktop Board, refer to the Technical Product Specification at http://support.intel.com/support/motherboards/desktop/

22

Desktop Board Features

Wake from USB

NOTE

Wake from USB requires the use of a USB peripheral that supports Wake from USB and an operating system that supports Wake from USB.

USB bus activity wakes the computer from an ACPI S3 state.

PME# Signal Wake-up Support

When the PME# signal on the PCI bus is asserted, the computer wakes from an ACPI S1, S3, S4, or S5 state.

WAKE# Signal Wake-up Support

When the WAKE# signal on the PCI Express bus is asserted, the computer wakes from an ACPI S1, S3, S4, or S5 state.

ENERGY STAR* Capable

In 2007, the US Department of Energy and the US Environmental Protection Agency revised the ENERGY STAR requirements. Intel worked directly with these two governmental agencies to define the new requirements. Currently Intel Desktop Boards are capable of meeting the new ENERGY STAR requirements depending upon system configuration.

Go to the following link for information and recommendations concerning the new ENERGY STAR requirements: http://www3.intel.com/cd/channel/reseller/asmona/eng/337748.htm.

Onboard Power Button

CAUTION

Electrostatic discharge (ESD) can damage components. Perform the procedure described in this section only at an ESD workstation using an antistatic wrist strap and a conductive foam pad. If such a station is not available, you can provide some ESD protection by wearing an antistatic wrist strap and attaching it to a metal part of the computer chassis.

A power button on the Desktop Board (see Figure 5) can be used to turn the computer on or off. This button is intended for use at integration facilities to remove standby power before making changes to the system configuration, or for testing purposes. The power button on the front panel is recommended for all other instances of turning the computer on or off. To turn off the computer using the onboard power button, keep the button pressed down for three seconds.

23

Intel Desktop Board DX58SO Product Guide

Figure 5. Onboard Power Button

Onboard VR and CPU LEDs

The Desktop Board contains the following two LEDs (see Figure 6) that indicate the status of the board’s voltage regulation circuitry and the processor:

The CPU LED (Figure 6, A) indicates an elevated temperature on the processor that could affect performance.

The VR LED (Figure 6, B) indicates an elevated temperature in the processor voltage regulator circuit that could affect performance.

24

Desktop Board Features

Figure 6. Location of the VR and CPU LEDs

Speaker

A speaker is mounted on the Desktop Board. The speaker provides audible error code (beep code) information during the Power-On Self-Test (POST). Refer to Appendix A for a description of the board’s beep codes.

Battery

A battery on the Desktop Board keeps the values in CMOS RAM and the clock current when the computer is turned off. Go to page 57 for instructions on how to replace the battery.

Real-Time Clock

The Desktop Board has a time-of-day clock and 100-year calendar. The battery on the Desktop Board keeps the clock current when the computer is turned off.

25

Intel Desktop Board DX58SO Product Guide

26
