Intel® Desktop Board DZ68BC

Product Guide

Order Number: G41105-003

Revision History

Revision

Revision History

Date

-001

First release of the Intel® Desktop Board DZ68BC Product Guide

August 2011

-002

Second release of the Intel® Desktop Board DZ68BC Product Guide

September 2011

-003

Third release of the Intel® Desktop Board DZ68BC Product Guide

March 2012

Disclaimer

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL® PRODUCTS. NO LICENSE, EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. Intel products are not intended for use in medical, life saving, or life sustaining applications. Intel may make changes to specifications and product descriptions at any time, without notice.

Intel Desktop Board DZ68BC may contain design defects or errors known as errata which may cause the product to deviate from published specifications. Current characterized errata are available on request.

Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.

Copies of documents which have an ordering number and are referenced in this document, or other Intel literature, may be obtained from Intel Corporation by going to the World Wide Web site at: http://www.intel.com/ or by calling 1-800-548-4725.

Intel, Intel Core, and Xeon are trademarks of Intel Corporation in the United States and/or other countries. * Other names and brands may be claimed as the property of others.

Copyright © 2011, 2012, Intel Corporation. All rights reserved.

Preface

This Product Guide gives information about board layout, component installation, BIOS update, and regulatory requirements for Intel® Desktop Board DZ68BC.

Intended Audience

The Product Guide is intended for technically qualified personnel. It is not intended for general audiences.

Use Only for Intended Applications

All Intel Desktop Boards are evaluated as Information Technology Equipment (I.T.E.) for use in personal computers (PC) for installation in homes, offices, schools, computer rooms, and similar locations. The suitability of this product for other PC or embedded non-PC applications or other environments, such as medical, industrial, alarm systems, test equipment, etc. may not be supported without further evaluation by Intel.

Document Organization

The chapters in this Product Guide are arranged as follows:

1Desktop Board Features: a summary of product features

2Installing and Replacing Desktop Board Components: instructions on how to install the Desktop Board and other hardware components

3Updating the BIOS: instructions on how to update the BIOS

AError Messages and Indicators: information about BIOS error messages and beep codes

BRegulatory Compliance: describes the board’s adherence to safety standards and EMC regulations and its product certifications

Conventions

The following conventions are used in this manual:

CAUTION

Cautions warn the user about how to prevent damage to hardware or loss of data.

NOTE

Notes call attention to important information.

iii

Intel Desktop Board DZ68BC Product Guide

Terminology

The table below gives descriptions of some common terms used in the product guide.

Term

Description





GB

Gigabyte (1,073,741,824 bytes)





GHz

Gigahertz (one billion hertz)





KB

Kilobyte (1024 bytes)





MB

Megabyte (1,048,576 bytes)





Mb

Megabit (1,048,576 bits)





MHz

Megahertz (one million hertz)





iv

Contents

1 Desktop Board Features



Supported Operating Systems..............................................................................

11

Desktop Board Components.................................................................................

12

Processor..........................................................................................................

14

Main Memory.....................................................................................................

15

Intel® Z68 Express Chipset..................................................................................

16

Intel® Rapid Storage Technology ..................................................................

16

Intel® Smart Response Technology ...............................................................

16

Audio Subsystem ...............................................................................................

16

LAN Subsystem .................................................................................................

17

USB Support .....................................................................................................

18

SATA Support....................................................................................................

18

SATA RAID ................................................................................................

19

Legacy I/O........................................................................................................

19

Expandability.....................................................................................................

19

Bluetooth*/WiFi Support .....................................................................................

20

Bluetooth Technology..................................................................................

20

WiFi 802.11 Wireless...................................................................................

20

BIOS................................................................................................................

21

Serial ATA Auto Configuration.......................................................................

21

PCI* and PCI Express* Auto Configuration .....................................................

21

Security Passwords .....................................................................................

21

Back to BIOS Button ...................................................................................

22

Hardware Management .......................................................................................

22

Hardware Monitoring and Fan Speed Control ..................................................

23

Chassis Intrusion........................................................................................

23

Power Management ............................................................................................

23

Software Support .......................................................................................

23

ACPI..................................................................................................

23

Hardware Support ......................................................................................

24

Power Connectors ...............................................................................

24

Fan Headers .......................................................................................

24

LAN Wake Capabilities..........................................................................

24

Instantly Available PC Technology..........................................................

25

Standby Power Indicator LED ................................................................

25

Wake from USB ..................................................................................

26

PME# Signal Wake-up Support..............................................................

26

WAKE# Signal Wake-up Support ...........................................................

26

Wake from Consumer IR ......................................................................

27

Wake from Serial Port ..........................................................................

27

Onboard Power and Reset Buttons........................................................................

27

Board Status LEDs .............................................................................................

28

Speaker............................................................................................................

30

Battery.............................................................................................................

30

Real-Time Clock.................................................................................................

30

v

Intel Desktop Board DZ68BC Product Guide

2

Installing and Replacing Desktop Board Components





Before You Begin ...............................................................................................

31



Installation Precautions.......................................................................................

32



Prevent Power Supply Overload ....................................................................

32



Observe Safety and Regulatory Requirements.................................................

32



Installing the I/O Shield ......................................................................................

33



Installing and Removing the Desktop Board ...........................................................

34



Installing and Removing a Processor.....................................................................

35



Installing a Processor ..................................................................................

35



Installing the Processor Fan Heat Sink ...........................................................

39



Connecting the Processor Fan Heat Sink Cable................................................

39



Removing the Processor ..............................................................................

39



Installing and Removing System Memory ..............................................................

40



Guidelines for Dual Channel Memory Configuration..........................................

40



Two or Four DIMMs .............................................................................

40



Three DIMMs ......................................................................................

41



Installing DIMMs ........................................................................................

42



Removing DIMMs........................................................................................

44



Installing and Removing PCI Express x16 Graphics Cards.........................................

44



Installing a PCI Express x16 Graphics Card ....................................................

44



Removing a PCI Express x16 Graphics Card....................................................

46



Installing Linked PCI Express Graphics Cards..................................................

46



Connecting SATA Cables .....................................................................................

48



Connecting to the Internal Headers and Connectors ................................................

49



Front Panel Intel HD Audio Header ................................................................

50



S/PDIF Header ...........................................................................................

50



IEEE 1394a Header.....................................................................................

50



Chassis Intrusion Header .............................................................................

51



Consumer IR (CIR) Headers .........................................................................

51



Front Panel Header .....................................................................................

52



Alternate Front Panel Power LED Header ........................................................

52



Serial Header.............................................................................................

53



USB 2.0 Headers ........................................................................................

53



USB 3.0 Connector .....................................................................................

54



Connecting to the Audio System...........................................................................

55



Connecting Chassis Fan and Power Supply Cables...................................................

56



Connecting Chassis Fan Cables .....................................................................

56



Connecting Power Supply Cables ..................................................................

57



Setting the BIOS Configuration Jumper .................................................................

58



Clearing Passwords ............................................................................................

59



Replacing the Battery .........................................................................................

60



Installing the WiFi/Bluetooth* Module in a Desktop Chassis (Optional).......................

66

3

Updating the BIOS





Updating the BIOS with the Intel® Express BIOS Update Utility.................................

67



Updating the BIOS Using the F7 Function Key ........................................................

68



Updating the BIOS with the Intel® Flash Memory Update Utility ................................

68



Recovering the BIOS ..........................................................................................

69

vi







Contents

A

Error Messages and Indicators





BIOS Error Codes...............................................................................................

71



BIOS Error Messages ..........................................................................................

72



Port 80h POST Codes..........................................................................................

73

B

Regulatory Compliance





Safety Standards ...............................................................................................

77





Battery Caution ..........................................................................................

77



European Union Declaration of Conformity Statement..............................................

78



Product Ecology Statements ................................................................................

79





Recycling Considerations .............................................................................

79





China RoHS ...............................................................................................

82



EMC Regulations ................................................................................................

83





FCC Declaration of Conformity......................................................................

83





Canadian Department of Communications Compliance Statement......................

84





Japan VCCI Statement ................................................................................

84





Korea Class B Statement .............................................................................

85





Ensure Electromagnetic Compatibility (EMC) Compliance..................................

85



Product Certifications..........................................................................................

86





Board-Level Certifications ............................................................................

86





Chassisand Component-Level Certifications..................................................

87





Chassis and Component Certifications............................................................

87



ENERGY STAR*, e-Standby, and ErP Compliance ....................................................

88

Figures





1.

Intel Desktop Board DZ68BC Components........................................................

12



2.

LAN Connector LEDs .....................................................................................

18



3.

Location of the Back to BIOS Button................................................................

22



4.

Location of the Standby Power Indicator ..........................................................

26



5.

Onboard Power and Reset Buttons ..................................................................

27



6.

Location of the Diagnostic LEDs ......................................................................

29



7.

Installing the I/O Shield ................................................................................

33



8.

Intel Desktop Board DZ68BC Mounting Screw Hole Locations ..............................

34



9.

Unlatch the Processor Socket Lever.................................................................

35



10.

Lift the Processor Socket Load Plate ................................................................

36



11.

Remove the Processor from the Protective Cover ..............................................

37



12.

Install the Processor .....................................................................................

37



13.

Secure the Processor Socket Load Plate in Place................................................

38



14.

Connecting the Processor Fan Heat Sink Power Cable to the Processor







Fan Header..................................................................................................

39



15.

Example Dual Channel Memory Configuration with Two DIMMs ...........................

40



16.

Example Dual Channel Memory Configuration with Four DIMMs ...........................

41



17.

Example Dual Channel Memory Configuration with Three DIMMs .........................

41



18.

Use DDR3 DIMMs .........................................................................................

42



19.

Installing a DIMM .........................................................................................

43



20.

Installing a PCI Express x16 Graphics Card ......................................................

45



21.

Removing a PCI Express x16 Graphics Card......................................................

46



22.

Installing Linked PCI Express Graphics Cards....................................................

47



23.

Connecting SATA Cables................................................................................

48



24.

Internal Headers and Connectors ....................................................................

49

vii

Intel Desktop Board DZ68BC Product Guide



25.

Back Panel Audio Connectors .........................................................................

55

26.

Location of the Chassis Fan Headers................................................................

56

27.

Connecting Power Supply Cables ....................................................................

57

28.

Location of the BIOS Configuration Jumper Block ..............................................

58

29.

Removing the Battery ...................................................................................

65

30.

Installing the WiFi/Bluetooth Module ...............................................................

66

31.

POST Code LED Display .................................................................................

73

32.

Intel Desktop Board DZ68BC China RoHS Material Self Declaration Table..............

82

Tables



1.

Feature Summary..........................................................................................

9

2.

Intel Desktop Board DZ68BC Components........................................................

13

3.

Audio Jack Retasking Support.........................................................................

17

4.

LAN Connector LEDs .....................................................................................

18

5.

Board Status LEDs........................................................................................

28

6.

Front Panel Intel HD Audio Header Signal Names ..............................................

50

7.

S/PDIF Header Signal Names .........................................................................

50

8.

IEEE 1394a Header Signal Names ...................................................................

50

9.

Chassis Intrusion Header Signal Names ...........................................................

51

10.

Front Panel CIR Receiver (Input) Header Signal Names ......................................

51

11.

Back Panel CIR Header Emitter (Output) Header Signal Names ...........................

52

12.

Front Panel Header Signal Names ...................................................................

52

13.

Alternate Front Panel Power LED Header Signal Names ......................................

52

14.

Serial Port Header ........................................................................................

53

15.

USB 2.0 Header Signal Names........................................................................

53

16.

USB 3.0 Connector .......................................................................................

54

17.

Jumper Settings for the BIOS Setup Program Modes..........................................

59

18.

BIOS Beep Codes .........................................................................................

71

19.

Front-panel Power LED Blink Codes .................................................................

71

20.

BIOS Error Messages ....................................................................................

72

21.

Port 80h POST Codes ....................................................................................

74

22.

Safety Standards..........................................................................................

77

23.

EMC Regulations...........................................................................................

83

24.

Regulatory Compliance Marks.........................................................................

86

viii

1 Desktop Board Features

This chapter briefly describes the features of Intel® Desktop Board DZ68BC. Table 1 summarizes the major features of the Desktop Board.

Table 1. Feature Summary

Form Factor

ATX (304.80 millimeters [12.00 inches] x 243.84 millimeters



[9.60 inches])





Processor

Support for an Intel® processor in the LGA1155 package

Main Memory

Four 240-pin DDR3 SDRAM Dual Inline Memory Module (DIMM)





sockets arranged in two channels



Support for DDR3 2133 MHz to DDR3 1066 MHz DIMMs



Support for 1.35 V low voltage and 1.25 V ultra low voltage JEDEC





memory



Support for non-ECC memory



Support for up to 32 GB of memory





Chipset

Intel® Z68 Express Chipset consisting of the Intel Z68 Platform



Controller Hub (PCH) with support for Intel® Rapid Storage Technology



(Intel® RST) and Intel® Smart Response Technology

Graphics Support

Integrated Graphics:



Support for processors with Intel HD 2000 or 3000





Graphics:





― DVI-I





― High-Definition Multi-media Interface* (HDMI*) 1.4





― DisplayPort* 1.1



External Graphics:



Support for multiple PCI Express* 2.0 graphics cards







Audio

Independent multi-streaming 8-channel (7.1) audio and 2-channel





audio subsystem, featuring:





― Intel® High Definition (Intel® HD) Audio interface





― Realtek* ALC892 codec



Intel HD Audio front panel header



Onboard 4-pin S/PDIF out header



Back panel S/PDIF out optical connector (TOSLINK)







Expansion

One PCI Express 2.0 x16 port

Capabilities

One PCI Express 2.0 x8 port (x8 electrical; x16 compatible)





Two PCI Express 2.0 x1 ports



Three PCI* bus connectors





Legacy I/O

Nuvoton W83677HG-I legacy I/O controller that provides support for:

Support

Consumer Infrared (CIR)





Serial port via an onboard header



Thermal and hardware management







continued

9

Intel Desktop Board DZ68BC Product Guide

Table 1. Feature Summary (continued)

Peripheral

USB Support:

Interfaces

Four USB 3.0 ports:







― Two ports implemented with stacked back panel connectors





(blue)





― Two ports via an internal dual-port connector (blue)



Fourteen USB 2.0 ports:





― Six ports implemented with stacked back panel connectors





(black)





― Eight front panel ports implemented with four dual-port internal





headers (black)



Serial ATA (SATA) Support:



Four SATA 6.0 Gb/s ports:





― Two ports from the Intel Z68 PCH (dark blue)





― Two ports from an onboard Marvell controller (light blue)



Four SATA 3.0 Gb/s ports (black)



One external SATA (eSATA) 6.0 Gb/s port on the back panel from





an onboard Marvell controller (red)



IEEE 1394a Support:



One port routed to the back panel



One port routed to the IEEE 1394a header





RAID

Intel® Rapid Storage Technology (Intel® RST) version 10.6

LAN Support

Intel 82579V Gigabit (10/100/1000 Mb/s) Ethernet LAN controller



including an RJ-45 back panel connector with integrated status LEDs







BIOS

Intel® Platform Innovation Framework for extensible firmware





interface



32 Mb symmetrical flash memory device



Support for SMBIOS



Intel® Express BIOS Update

Power Management

Support for Advanced Configuration and Power Interface (ACPI)



Suspend to RAM (STR)



Wake on USB, PCI, PCI Express, LAN, CIR, serial port, and front





panel



ENERGY STAR* capable





Hardware and

Hardware and thermal management based on:

Thermal

Nuvoton W83677HG-I legacy I/O controller

Management

Four fan sensing inputs to monitor fan activity





Voltage sensing to detect out of range values







10

Desktop Board Features

Supported Operating Systems

The Desktop Board provides full support for the following operating systems:

Microsoft Windows* 7 Ultimate 64-bit edition

Microsoft Windows 7 Ultimate 32-bit edition

Microsoft Windows 7 Professional 64-bit edition

Microsoft Windows 7 Professional 32-bit edition

Microsoft Windows 7 Home Premium 64-bit edition

Microsoft Windows 7 Home Premium 32-bit edition

Microsoft Windows 7 Starter 64-bit edition

Microsoft Windows 7 Starter 32-bit edition

Microsoft Windows Vista* Ultimate 32-bit edition

Microsoft Windows Vista Business 32-bit edition

Microsoft Windows Vista Home Premium 32-bit edition

Microsoft Windows Vista Home Basic 32-bit edition

Microsoft Windows Vista Ultimate 64-bit edition

Microsoft Windows Vista Business 64-bit edition

Microsoft Windows Vista Home Premium 64-bit edition

Microsoft Windows Vista Home Basic 64-bit edition

The Desktop Board provides limited support for the following operating systems:

Microsoft Windows Vista Home Basic 64-bit edition

Microsoft Windows* XP Media Center Edition 2005

Microsoft Windows XP Professional

Microsoft Windows XP Professional x64 Edition

Microsoft Windows XP Home

11

Intel Desktop Board DZ68BC Product Guide

Desktop Board Components

Figure 1 shows the approximate location of the major components on Intel Desktop Board DZ68BC.

Figure 1. Intel Desktop Board DZ68BC Components

12

Desktop Board Features

Table 2. Intel Desktop Board DZ68BC Components

Label

Description





A

PCI bus connector





B

PCI bus connector





C

S/PDIF header





D

PCI Express 2.0 x16 connector (x8 electrical; x16 compatible)





E

Speaker





F

PCI Express 2.0 x1 connector





G

PCI bus connector





H

PCI Express 2.0 x16 connector





I

Rear chassis fan header





J

PCI Express 2.0 x1 connector





K

Back panel connectors





L

12 V processor core voltage connector (2 x 4 pin)





M

Processor socket





N

Processor fan header





O

DIMM 3 socket





P

DIMM 1 socket





Q

DIMM 4 socket





R

DIMM 2 socket





S

Front panel CIR receiver (input) header





T

Back panel CIR transmitter (output) header





U

Main power connector (2 x 12 pin)





V

Standby power indicator LED





W

Onboard reset button





X

Onboard power button





Y

Front panel header





Z

Front chassis fan header





AA

Alternate front panel power LED header





BB

Intel Z68 PCH





CC

Battery





DD

Two 6.0 Gb/s SATA ports (Marvell controller)





EE

Two 6.0 Gb/s SATA ports (Intel Z68 PCH)





FF

Four 3.0 Gb/s SATA ports (Intel Z68 PCH)





GG

Serial port header





HH

USB 2.0 headers





II

BIOS configuration jumper block





JJ

POST code LED display





KK

Chassis intrusion header





continued

13

Intel Desktop Board DZ68BC Product Guide

Table 2. Intel Desktop Board DZ68BC Components (continued)

Label Description

LLUSB 3.0 connector

MMIEEE 1394a header

NNAuxiliary chassis fan header

OOBoard status LEDs

PPFront panel audio header

Online Support

For more information on Intel Desktop Board DZ68BC consult the following online resources:

Intel Desktop Board DZ68BC

http://www.intel.com/products/motherboard/index.ht





m

Desktop Board Support

http://www.intel.com/p/en_US/support?iid=hdr+supp





ort

Available configurations for Intel

http://ark.intel.com



Desktop Board DZ68BC



Supported processors

http://processormatch.intel.com

Chipset information

http://www.intel.com/products/desktop/chipsets/inde





x.htm

BIOS and driver updates

http://downloadcenter.intel.com/

Integration information

http://www.intel.com/support/go/buildit

Processor

CAUTION

Failure to use an appropriate power supply and/or not connecting the 12 V (2 x 4 pin) power connector to the Desktop Board may result in damage to the board, or the system may not function properly.

Intel Desktop Board DZ68BC supports an Intel processor in the LGA1155 package. Processors are not included with the Desktop Board and must be purchased separately. The processor connects to the Desktop Board through the LGA1155 socket.

For information on supported processors for Intel Desktop Board DZ68BC, go to http://processormatch.intel.com.

14

Desktop Board Features

Main Memory

NOTE

To be fully compliant with all applicable Intel® SDRAM memory specifications, the board should be populated with DIMMs that support the Serial Presence Detect (SPD) data structure. If your memory modules do not support SPD, you will see a notification to this effect on the screen at power up. The BIOS will attempt to configure the memory controller for normal operation.

The Desktop Board supports the following memory and interface:

Four 240-pin Double Data Rate 3 (DDR3) SDRAM Dual Inline Memory Module (DIMM) sockets with gold-plated contacts arranged in two channels

2133 MHz to 1066 MHz DDR3 SDRAM Memory Modules

Support for singleand dual-channel memory interleaving

Unbuffered, non-registered singleor double-sided DIMMs with a voltage rating of 1.65 V or less

CAUTION

Using a DIMM with a voltage rating higher than 1.65 V may damage the processor.

Non-ECC DDR3 memory

Serial Presence Detect (SPD) memory only

Up to 32 GB maximum total system memory using 8 GB DIMMs

NOTE

32-bit operating systems are limited to a maximum of 4 GB of memory. These operating systems will report less than 4 GB because of the memory used by add-in graphics cards and other system resources.

15

Intel Desktop Board DZ68BC Product Guide

Intel® Z68 Express Chipset

The Intel Z68 Express Chipset consists of the Intel Z68 PCH. The Intel Z68 PCH includes Intel Rapid Storage Technology and Intel Smart Response Technology.

Intel® Rapid Storage Technology

Intel Rapid Storage Technology version 10.6 enables Intel Smart Response Technology and full Serial ATA (SATA) interface speed up to 6 Gb/s to support next-generation Solid State Drives (SSDs) or traditional Hard Disk Drives (HDDs). Intel Rapid Storage Technology 10.6 also adds support for greater than 2.2 TB HDDs in a RAID configuration.

Intel® Smart Response Technology

Intel Smart Response Technology supports a single drive volume that combines the high-performance benefits of SSDs with the large storage capacities of traditional HDDs to dramatically increase system responsiveness and enable faster boot times. The two technologies (SSD and HDD) appear as a single C:\ drive letter that provides you with the familiar storage identifier.

The system automatically learns which files you access frequently and then copies them from the HDD to the SSD. The next time you request these files, the system loads them from the fast SSD rather than the slower HDD. For infrequently-used files, the system loads them from the HDD when you need them.

For more information on Intel Smart Response Technology refer

to http://download.intel.com/design/flash/nand/325554.pdf or download the user guide at http://www.intel.com/support/motherboards/desktop/dz68db/sb/CS032499.htm?wapkw=(smart+response)

Audio Subsystem

The onboard audio subsystem consists of the following components:

Intel Z68 PCH

Realtek ALC892 codec

The subsystem has the following headers and connectors:

Back panel audio connectors, including an S/PDIF out optical port.

Advanced jack sense for the back panel audio connectors that enables the audio codec to recognize the device that is connected to an audio port

Front panel audio header that supports Intel HD Audio and AC ‘97 Audio. This header provides mic in and line out signals for front panel audio connectors.

An onboard S/PDIF output header

16

Desktop Board Features

The audio subsystem supports the following features:

A signal-to-noise (S/N) ratio of 97 dB

Independent multi-streaming 8-channel (7.1) audio (using the back panel audio connectors) and 2-channel audio (using the Intel HD Audio front panel header)

Table 3 lists the supported functions of front panel and back panel audio jacks.

Table 3. Audio Jack Retasking Support



Micro-















phone/













Audio

Side

Head-

Front



Side

Rear

Center/

Jack

Surround

phones

Speakers

Line In

Surround

Surround

Subwoofer

















FP Green



Default



























FP Pink

Default





























BP Blue







Default























BP Green



Control

Default













panel



























BP Pink

Default







Default





















BP Black











Default



















BP Orange













Default

















LAN Subsystem

The LAN subsystem includes:

Intel Z68 PCH

Intel 82579V Gigabit (10/100/1000 Mb/s) Ethernet LAN controller

RJ-45 LAN connector with integrated status LEDs

The subsystem features:

CSMA/CD protocol engine

LAN connect interface between the Intel Z68 PCH and the LAN controller

PCI bus power management

Two LEDs are built into the RJ-45 LAN connector located on the back panel (see Figure 2). These LEDs indicate the status of the LAN as shown in Table 4.

17

Intel Desktop Board DZ68BC Product Guide

Figure 2. LAN Connector LEDs

Table 4. LAN Connector LEDs

LED

LED Color

LED State

Indicates









A

Green

Off

LAN link is not established













On

LAN link is established













Blinking

LAN activity is occurring









B

N/A

Off

10 Mb/s data rate











Green

On

100 Mb/s data rate











Yellow

On

1000 Mb/s data rate









USB Support

The Desktop Board supports USB 2.0 and USB 3.0. There are 14 USB 2.0 ports (six ports routed to back panel connectors and eight ports routed to four onboard headers). The USB 2.0 ports are high-speed, full-speed, and low-speed capable.

USB 3.0 is supported with two back panel connectors (blue) and one onboard dualport connector (blue). USB 3.0 ports are backward compatible with USB 2.0 and

USB 1.1 devices. The USB 3.0 ports are SuperSpeed, high-speed, full-speed, and lowspeed capable.

SATA Support

Intel Desktop Board DZ68BC provides the following SATA support:

Two onboard 6.0 Gb/s SATA channels provided by the Intel Z68 PCH (dark blue connectors)

Two onboard 6.0 Gb/s SATA channels provided by a Marvell 88SE9128 SATA controller (light blue connectors)

Four onboard 3.0 Gb/s SATA channels provided by the Intel Z68 PCH (black connectors)

One back panel 6.0 Gb/s eSATA channel (red connector)

18

Desktop Board Features

SATA RAID

The onboard SATA channels provided by the Intel Z68 PCH support Intel Rapid Storage Technology version 10.6 which provides the following RAID (Redundant Array of Independent Drives) levels:

RAID 0 - data striping

RAID 1 - data mirroring

RAID 0+1 (or RAID 10) - data striping and data mirroring

RAID 5 - distributed parity

Legacy I/O

Intel Desktop Board DZ68BC includes a legacy I/O controller that provides the following I/O features:

Consumer Infrared (CIR) support

Serial port support via an onboard header

Low pin count (LPC) interface

Intelligent power management, including a programmable wake up event interface

PCI power management support

Expandability

Intel Desktop Board DZ68BC provides the following expansion capability:

One PCI Express 2.0 x16 port

One PCI Express 2.0 x8 port (x8 electrical; x16 compatible)

Two PCI Express 2.0 x1 ports

Three PCI bus connectors

19

Intel Desktop Board DZ68BC Product Guide

Bluetooth*/WiFi Support

Intel Desktop Board DZ68BC ships with an external Bluetooth*/WiFi module that allows you to connect to wireless networks and Bluetooth peripherals. For instructions on how to install the Bluetooth/WiFi module in a desktop chassis, refer to “Installing the WiFi/Bluetooth* Module in a Desktop Chassis (Optional)” on page 66.

Bluetooth Technology

The Bluetooth/WiFi Module enables you to connect with a variety of Bluetooth-enabled devices. Driver support is provided by Microsoft operating systems such as Microsoft Vista and Microsoft Windows 7. The Bluetooth driver stack is supplied by Microsoft but some Bluetooth enabled devices might provide additional Bluetooth features and for proper functioning of those features, will need their own supplied drivers installed.

CSR Bluetooth module (BC0401PC08)

Maximum data rate 3.0 Mb/s

Forward and backward compatibility with Bluetooth v1.1, v1.2, v2.0, and v2.1

Integrated antenna

Operating system support for Windows XP, Windows Vista, and Windows 7 both 32 bit and 64 bit

To obtain more Bluetooth information and drivers go to http://msdn.microsoft.com/enus/library/aa362932(VS.85).aspx

WiFi 802.11 Wireless

The Bluetooth/WiFi Module also enables you to connect with a variety of WiFi enabled networks and access points and also allows peer to peer connections. Driver support is provided by Microsoft operating systems such as Microsoft Vista and Microsoft Windows 7 with additional support provided by the supplied WiFi driver included on the Driver DVD and online.

Ralink WiFi 802.11 (RT8070)

Range up to 300 meters

Supports the following:

IEEE 802.11B supports up to 11 Mb/s data rate

IEEE 802.11G supports up to 54 Mb/s data rate

IEEE 802.11N supports up to 150 Mb/s data rate

Integrated antenna

Operating system support for Windows XP, Windows Vista, and Windows 7 both 32 bit and 64 bit

To obtain more WiFi information and drivers go to http://msdn.microsoft.com/enus/library/aa362932(VS.85).aspx

20

Desktop Board Features

BIOS

The BIOS provides the Power-On Self-Test (POST), the BIOS Setup program, and the PCI/PCI Express and SATA auto-configuration utilities. The BIOS is stored in a Serial Peripheral Interface (SPI) Flash device.

The BIOS can be updated by following the instructions in Chapter 3 starting on page 67.

Serial ATA Auto Configuration

If you install a Serial ATA device (such as a hard drive) in your computer, the autoconfiguration utility in the BIOS automatically detects and configures the device for your computer. You do not need to run the BIOS Setup program after installing a Serial ATA. You can override the auto-configuration options by specifying manual configuration in the BIOS Setup program.

PCI* and PCI Express* Auto Configuration

If you install a PCI/PCI Express add-in card in your computer, the PCI/PCI Express auto-configuration utility in the BIOS automatically detects and configures the resources (IRQs, DMA channels, and I/O space) for that add-in card. You do not need to run the BIOS Setup program after you install a PCI/PCI Express add-in card.

Security Passwords

The BIOS includes security features that restrict whether the BIOS Setup program can be accessed and who can boot the computer. A supervisor password and a user password can be set for the BIOS Setup and for booting the computer, with the following restrictions:

The supervisor password gives unrestricted access to view and change all Setup options. If only the supervisor password is set, pressing <Enter> at the password prompt of Setup gives the user restricted access to Setup.

If both the supervisor and user passwords are set, you must enter either the supervisor password or the user password to access Setup. Setup options are then available for viewing and changing depending on whether the supervisor or user password was entered.

Setting a user password restricts who can boot the computer. The password prompt is displayed before the computer is booted. If only the supervisor password is set, the computer boots without asking for a password. If both passwords are set, you can enter either password to boot the computer.

Related Links:

For instructions on resetting the password, go to Clearing Passwords on page 59.

21

Intel Desktop Board DZ68BC Product Guide

Back to BIOS Button

The back panel Back to BIOS button (Figure 3, A) duplicates the functionality of the BIOS configuration jumper (see Setting the BIOS Configuration Jumper on page 58) with the following exceptions:

It can only be used to force the board to power on to the BIOS Maintenance Menu using default values but it will retain all previously saved changes.

It cannot be used to override passwords set in the BIOS.

It cannot be used to invoke BIOS recovery mode.

The button glows red when it is activated.

NOTE

Using the Back to BIOS button does not set the board to the factory BIOS defaults. To restore settings to the factory defaults, use the <F9> key once BIOS setup mode is active.

Figure 3. Location of the Back to BIOS Button

Hardware Management

The hardware management features of Intel Desktop Board DZ68BC enable the board to be compatible with the Wired for Management (WfM) specification. The board has several hardware management features including the following:

Fan speed monitoring and control

Thermal and voltage monitoring

Chassis intrusion detection

22

Desktop Board Features

Hardware Monitoring and Fan Speed Control

The features of the hardware monitoring and fan speed control include:

Monitoring of power supply voltages to detect levels above and below acceptable values

Smart fan control provided by the legacy I/O controller, delivering acousticallyoptimized thermal management. Fan speed controllers and sensors are integrated into the legacy I/O controller.

A thermal sensor in the processor

Thermally monitored closed-loop fan control, for all onboard fans, that can adjust fan speed

Chassis Intrusion

The board supports a chassis security feature that detects if the chassis cover has been removed. The security feature uses a mechanical switch on the chassis that can be connected to the chassis intrusion header on the Desktop Board. See Figure 24, D for the location of the chassis intrusion header.

Power Management

Power management is implemented at several levels, including software support through the Advanced Configuration and Power Interface (ACPI) and the following hardware support:

Power connectors

Fan headers

LAN wake capabilities

Instantly Available PC technology (Suspend to RAM)

Standby Power Indicator LED

Wake from USB

Power Management Event signal (PME#) wakeup support

WAKE# signal wake-up support

Wake from Consumer IR

Wake from serial port

Software Support

ACPI

ACPI gives the operating system direct control over the power management and Plug and Play functions of a computer. The use of ACPI with the Desktop Board requires an operating system that provides full ACPI support.

23

Intel Desktop Board DZ68BC Product Guide

Hardware Support

Power Connectors

ATX12V-compliant power supplies can turn off the computer power through system control. When an ACPI-enabled computer receives the correct command, the power supply removes all non-standby voltages.

When resuming from an AC power failure, the computer returns to the power state it was in before power was interrupted (either on or off). The computer’s response can be set by using the Last Power State feature in the BIOS Setup program’s Boot menu.

The Desktop Board has three power connectors. See Figure 27 on page 57 for the location of the power connectors.

Fan Headers

The function/operation of the fans is as follows:

The fans are on when the computer is in the ACPI S0 state.

The fans are off when the computer is in the ACPI S3, S4, or S5 state.

Each fan header is wired to a tachometer input of the hardware monitoring and control device.

All fan headers support closed-loop fan control that can adjust the fan speed or switch the fan on or off as needed.

All fan headers have a +12 V DC connection.

The Desktop Board has a 4-pin processor fan header and three 4-pin chassis fan headers.

LAN Wake Capabilities

CAUTION

For LAN wake capabilities, the 5 V standby line for the power supply must be capable of delivering adequate +5 V standby current. Failure to provide adequate standby current when using this feature can damage the power supply.

LAN wakeup capabilities enable remote wake-up of the computer through a network. The LAN subsystem monitors network traffic and upon detecting a Magic Packet* frame, it asserts a wake-up signal that powers up the computer.

24

Desktop Board Features

Instantly Available PC Technology

CAUTIONS

For Instantly Available PC technology, the 5 V standby line for the power supply must be capable of delivering adequate +5 V standby current. Failure to provide adequate standby current when using this feature can damage the power supply and/or effect ACPI S3 sleep state functionality.

Power supplies used with this Desktop Board must be able to provide enough standby current to support the standard Instantly Available (ACPI S3 sleep state) configuration. If the standby current necessary to support multiple wake events from the PCI and/or USB buses exceeds power supply capacity, the Desktop Board may lose register settings stored in memory.

Instantly Available PC technology enables the board to enter the ACPI S3 (Suspend-to- RAM) sleep state. While in the S3 sleep state, the computer will appear to be off. If the computer has a dual-colored power LED on the front panel, the sleep state is indicated by the LED turning amber. When signaled by a wake-up device or event, the computer quickly returns to its last known awake state.

The Desktop Board supports the PCI Bus Power Management Interface Specification. Add-in cards that support this specification can participate in power management and can be used to wake the computer.

Standby Power Indicator LED

CAUTION

If the AC power has been switched off and the standby power indicator is still lit, disconnect the power cord before installing or removing any devices connected to the board. Failure to do so could damage the board and any attached devices.

The Desktop Board’s standby power indicator, shown in Figure 4, is lit when there is standby power still present on the board even when the computer appears to be off. For example, when this green LED is lit, standby power is still present at the memory module sockets and the PCI Express connector.

25

Intel Desktop Board DZ68BC Product Guide

Figure 4. Location of the Standby Power Indicator

For more information on standby current requirements for the Desktop Board, refer to the Technical Product Specification

at http://support.intel.com/support/motherboards/desktop/

Wake from USB

NOTE

Wake from USB requires the use of a USB peripheral that supports Wake from USB and an operating system that supports Wake from USB.

USB bus activity wakes the computer from an ACPI S3 state.

PME# Signal Wake-up Support

When the PME# signal on the PCI bus is asserted, the computer wakes from an ACPI S3, S4, or S5 state.

WAKE# Signal Wake-up Support

When the WAKE# signal on the PCI Express bus is asserted, the computer wakes from an ACPI S3, S4, or S5 state.

26

Desktop Board Features

Wake from Consumer IR

Consumer IR device activity wakes the computer from an ACPI S3, S4, or S5 state.

Wake from Serial Port

Serial port activity wakes the computer from an ACPI S3, S4, or S5 state.

Onboard Power and Reset Buttons

The lighted Power button on the Desktop Board (Figure 5, A) can be used to turn the computer on or off. This button duplicates the function of the front panel power button. To turn off the computer using the onboard Power button, press it for three seconds.

The Power button stays lit when there is standby power still present on the board. This is the case even when the computer appears to be off. For example, when this button is lit, standby power is still present at the memory module sockets and the PCI bus connectors.

CAUTION

If the AC power has been switched off and the onboard power button is still lit, disconnect the power cord before installing or removing any devices connected to the board. Failure to do so could damage the board and any attached devices.

The lighted Reset button on the Desktop Board (Figure 5, B) can be used to reset the board. This button duplicates the function of the front panel Reset button.

Figure 5. Onboard Power and Reset Buttons

27

Intel Desktop Board DZ68BC Product Guide

Board Status LEDs

The Desktop Board includes thirteen LEDs that allow you to monitor the board’s progress through the BIOS Power-on Self-Test, Hard Drive activity, processor and voltage regulator temperature, and certain error conditions. At initial power on, all the LEDs are off. Figure 6 shows the location the LEDs and Table 5 briefly describes their function.

Table 5. Board Status LEDs

Item/Callout



LED





in Figure 6

Activity

Color

Description











A

Hard Drive Activity

Blue

This LED blinks on and off with hard







drive activity.











B

Processor Hot

Red

When lit, this LED indicates an elevated







temperature on the processor that







could affect performance.











C

Voltage Regulator Hot

Red

When lit, this LED indicates an elevated







temperature in the processor voltage







regulator circuit that could affect







performance.











D

Watch Dog Timer Fire/

Red

When the watch dog timer fires to reset



Back to BIOS



the board, this LED will flash.







In addition, this LED will light and stay







on when the Back to BIOS button has







been pressed.











E

Processor Initialization

Green

This LED will flash when the processor







initialization activity starts. Then the







LED will stay on when processor







initialization is complete.











F

Memory Initialization

Green

This LED will flash when the memory







initialization activity starts. Then the







LED will stay on when memory







initialization is complete.











G

Video Initialization

Green

This LED will flash when the video







initialization activity starts. Then the







LED will stay on when video







initialization is complete.











H

USB Initialization

Green

This LED will flash when the USB







initialization activity starts. Then the







LED will stay on when USB initialization







is complete.











I

Hard Drive Initialization

Green

This LED will flash when the hard drive







activity starts. Then the LED will stay







on when hard drive initialization is







complete.

















continued

28









Desktop Board Features





Table 5. Board Status LEDs (continued)



















Item/Callout



LED







in Figure 6

Activity

Color

Description

















J

Option ROM Initialization

Green

This LED will flash when the option











ROM activity starts. Then the LED will











stay on when option ROM initialization











is complete.

















K

OS Start

Green

Just before the BIOS transfers control











to the operating system, this LED will











light and stay on.

















L

IERR#_LED

Red



















M

PME#_LED

Red





























Figure 6. Location of the Diagnostic LEDs

29

Intel Desktop Board DZ68BC Product Guide

Speaker

A speaker is mounted on the Desktop Board. The speaker provides audible error code (beep code) information during the Power-On Self-Test (POST). Refer to Appendix A for a description of the board’s beep codes.

Battery

A battery on the Desktop Board keeps the values in CMOS RAM and the clock current when the computer is turned off. Go to page 60 for instructions on how to replace the battery.

Real-Time Clock

The Desktop Board has a time-of-day clock and 100-year calendar. The battery on the Desktop Board keeps the clock current when the computer is turned off.

30

2Installing and Replacing Desktop Board Components

This chapter tells you how to:

Install the I/O shield

Install and remove the Desktop Board

Install and remove a processor

Install and remove memory

Install and remove a PCI Express x16 graphics card

Connect SATA cables

Connect to the internal headers

Connect to the audio system

Connect chassis fan and power supply cables

Set the BIOS configuration jumper

Clear passwords

Replace the battery

Install the WiFi/BlueTooth Module (optional)

Before You Begin

CAUTIONS

The procedures in this chapter assume familiarity with the general terminology associated with personal computers and with the safety practices and regulatory compliance required for using and modifying electronic equipment.

Disconnect the computer from its power source and from any telecommunications links, networks, or modems before performing any of the procedures described in this chapter. Failure to disconnect power, telecommunications links, networks, or modems before you open the computer or perform any procedures can result in personal injury or equipment damage. Some circuitry on the board can continue to operate even though the front panel power button is off.

Follow these guidelines before you begin:

Always follow the steps in each procedure in the correct order.

Set up a log to record information about your computer, such as model, serial numbers, installed options, and configuration information.

Electrostatic discharge (ESD) can damage components. Perform the procedures described in this chapter only at an ESD workstation using an antistatic wrist strap and a conductive foam pad. If such a station is not available, you can provide some ESD protection by wearing an antistatic wrist strap and attaching it to a metal part of the computer chassis.

31

Intel Desktop Board DZ68BC Product Guide

Installation Precautions

When you install and test the Intel Desktop Board, observe all warnings and cautions in the installation instructions.

To avoid injury, be careful of:

Sharp pins on connectors

Sharp pins on printed circuit assemblies

Rough edges and sharp corners on the chassis

Hot components (such as processors, voltage regulators, and heat sinks)

Damage to wires that could cause a short circuit

Observe all warnings and cautions that instruct you to refer computer servicing to qualified technical personnel.

Prevent Power Supply Overload

Do not overload the power supply output. To avoid overloading the power supply, make sure that the calculated total current loads of all the modules within the computer is less than the output current rating of each of the power supplies output circuits.

Observe Safety and Regulatory Requirements

Read and follow the instructions in this section and the instructions supplied with the chassis and associated modules. If you do not follow these instructions and the instructions provided by the chassis and module suppliers, you increase your safety risk and the possibility of noncompliance with regional laws and regulations. If the instructions for the chassis are inconsistent with these instructions or the instructions for associated modules, contact the supplier to find out how you can ensure that your computer meets safety and regulatory requirements.

For information about the Desktop Board’s regulatory compliance, refer to Appendix B.

32

Installing and Replacing Desktop Board Components

Installing the I/O Shield

The Desktop Board comes with an I/O shield. When installed in the chassis, the shield blocks radio frequency transmissions, protects internal components from dust and foreign objects, and promotes correct airflow within the chassis.

Install the I/O shield before installing the Desktop Board in the chassis. Place the shield inside the chassis as shown in Figure 7. Press the shield into place so that it fits tightly and securely. If the shield does not fit, obtain a properly sized shield from the chassis supplier.

Figure 7. Installing the I/O Shield

33

Intel Desktop Board DZ68BC Product Guide

Installing and Removing the Desktop Board

CAUTION

Only qualified technical personnel should perform this procedure. Disconnect the computer from its power source before performing the procedures described here. Failure to disconnect the power before you open the computer can result in personal injury or equipment damage.

Refer to your chassis manual for instructions on installing and removing the Desktop Board.

Figure 8 shows the location of the mounting screw holes for Intel Desktop Board DZ68BC.

Figure 8. Intel Desktop Board DZ68BC Mounting Screw Hole Locations

34

Installing and Replacing Desktop Board Components

Installing and Removing a Processor

Instructions on how to install the processor on the Desktop Board are given below.

Installing a Processor

CAUTION

Before installing or removing a processor, make sure the AC power has been removed by unplugging the power cord from the computer. Failure to do so could damage the processor and the board.

To install a processor, follow these instructions:

1.Observe the precautions in "Before You Begin" on page 31.

2.Unlatch the processor socket lever by pushing it down and away from the socket (Figure 9, A, B).

Figure 9. Unlatch the Processor Socket Lever

35

Intel Desktop Board DZ68BC Product Guide

3.Rotate the socket lever to lift the load plate away from the socket (Figure 10, A). Make sure that the load plate is in the fully open position (Figure 10, B) while being careful not to damage adjacent components. Do not touch the socket contacts.

Figure 10. Lift the Processor Socket Load Plate

36

Installing and Replacing Desktop Board Components

4.Remove the processor from its protective cover. Hold the processor only at the edges, being careful not to touch the bottom of the processor (see Figure 11).

NOTE

Do not discard the processor cover. Always replace the processor cover if you remove the processor from the socket.

Figure 11. Remove the Processor from the Protective Cover

5.Hold the processor with your thumb and index finger oriented as shown

in Figure 12 to align your fingers with the socket finger cutouts. Make sure that the processor Pin 1 indicator (gold triangle) is aligned with the Pin 1 chamfer on the socket (Figure 12, B) and that the notches on the processor align with the posts on the socket (Figure 12, C). Lower the processor straight down without tilting or sliding it in the socket (Figure 12, A).

Figure 12. Install the Processor

37

Intel Desktop Board DZ68BC Product Guide

7.Carefully lower the socket lever (Figure 13, A) while making sure that the front edge of the load plate slides under the shoulder screw cap as the lever is lowered. Latch the socket lever under the load plate tab (Figure 13, C, D). The socket cover (Figure 13, B) will pop off as shown.

Figure 13. Secure the Processor Socket Load Plate in Place

8. Pick up the socket cover and remove it from the desktop board.

NOTE

Do not discard the socket cover; save it for possible future use. Always replace the socket cover if you remove the processor from the socket.

38

Installing and Replacing Desktop Board Components

Installing the Processor Fan Heat Sink

Intel Desktop Board DZ68BC has mounting holes for a processor fan heat sink. For instructions on how to attach the processor fan heat sink to the Desktop Board, refer to the boxed processor manual or boxed thermal solution manual.

Connecting the Processor Fan Heat Sink Cable

Connect the processor fan heat sink power cable to the 4-pin processor fan header (see Figure 14). A fan with a 4-pin connector as shown in Figure 14 is recommended.

Figure 14. Connecting the Processor Fan Heat Sink Power Cable to the Processor Fan Header

Removing the Processor

For instructions on how to remove the processor fan heat sink and processor, refer to the processor installation manual.

39

Intel Desktop Board DZ68BC Product Guide

Installing and Removing System Memory

Desktop board DZ68BC has four 240-pin DDR3 DIMM sockets arranged in two channels (A and B).

Guidelines for Dual Channel Memory Configuration

Before installing DIMMs, read and follow these guidelines for dual channel memory configuration.

Two or Four DIMMs

Install a matched pair of DIMMs equal in speed and size (see Figure 15) in the blue socket of channel A (DIMM 1) and channel B (DIMM 2).

Figure 15. Example Dual Channel Memory Configuration with Two DIMMs

40

Installing and Replacing Desktop Board Components

If additional memory is to be used, install another matched pair of DIMMs

(see Figure 16) in the black socket of channel A (DIMM 3) and channel B (DIMM 4).

Figure 16. Example Dual Channel Memory Configuration with Four DIMMs

Three DIMMs

If you want to use three DIMMs in a dual-channel configuration, install a matched pair of DIMMs equal in speed and size in DIMM 1 and DIMM 3 of channel A. Then install another DIMM equal to the speed and total size of the DIMMs installed in channel A in either DIMM 2 or DIMM 4 of channel B (Figure 17).

Figure 17. Example Dual Channel Memory Configuration with Three DIMMs

NOTE

All other memory configurations will result in single channel memory operation.

41

Intel Desktop Board DZ68BC Product Guide

Installing DIMMs

To make sure you have the correct DIMM, place it on the illustration of the DDR3 DIMM in Figure 18. All the notches should match with the DDR3 DIMM.

Figure 18. Use DDR3 DIMMs

42

Installing and Replacing Desktop Board Components

NOTE

For best memory performance, install memory in the blue DIMM sockets first.

To install a DIMM, follow these steps:

1.Observe the precautions in "Before You Begin" on page 31.

2.Turn off all peripheral devices connected to the computer. Turn off the computer and disconnect the AC power cord.

3.Remove the computer’s cover and locate the DIMM sockets (see Figure 19).

Figure 19. Installing a DIMM

4.Make sure the clips at either end of the DIMM socket(s) are pushed outward to the open position.

5.Holding the DIMM by the edges, remove it from its anti-static package.

6.Position the DIMM above the socket. Align the small notch at the bottom edge of the DIMM with the keys in the socket (see inset in Figure 19).

7.Insert the bottom edge of the DIMM into the socket.

8.When the DIMM is inserted, push down on the top edge of the DIMM until the retaining clips snap into place. Make sure the clips are firmly in place.

9.Replace the computer’s cover and reconnect the AC power cord.

43

Intel Desktop Board DZ68BC Product Guide

Removing DIMMs

To remove a DIMM, follow these steps:

1.Observe the precautions in "Before You Begin" on page 31.

2.Turn off all peripheral devices connected to the computer. Turn off the computer.

3.Remove the AC power cord from the computer.

4.Remove the computer’s cover.

5.Gently spread the retaining clips at each end of the DIMM socket. The DIMM pops out of the socket.

6.Hold the DIMM by the edges, lift it away from the socket, and store it in an anti-static package.

7.Replace the computer’s cover and reconnect the AC power cord.

Installing and Removing PCI Express x16

Graphics Cards

Installing a PCI Express x16 Graphics Card

CAUTION

When installing a PCI Express card, ensure that the card is fully seated in the PCI Express connector before you power on the system. If the card is not fully seated in the connector, an electrical short may result across the connector pins. Depending on the over-current protection of the power supply, certain Desktop Board components and/or traces may be damaged.

44

Installing and Replacing Desktop Board Components

Follow these instructions to install a PCI Express x16 graphics card:

1.Observe the precautions in "Before You Begin" on page 31.

2.Place the card in the PCI Express x16 connector (Figure 20, A) and press down on the card until it is completely seated in the connector and the card retention notch on the card snaps into place around the retention mechanism pin on the connector.

3.Secure the card’s metal bracket to the chassis back panel with a screw (Figure 20, B).

4.Connect the monitor cable to the graphics card according to the manufacturer’s instructions.

Figure 20. Installing a PCI Express x16 Graphics Card

45

Intel Desktop Board DZ68BC Product Guide

Removing a PCI Express x16 Graphics Card

Follow these instructions to remove a PCI Express x16 graphics card from a connector:

1.Observe the precautions in "Before You Begin" on page 31.

2.Remove the screw (Figure 21, A) that secures the card’s metal bracket to the chassis back panel.

3.Push the card ejector lever down using the tip of a pencil or similar tool (Figure 21, B) in the notch. This will release the card from the connector (C).

4.Pull the card straight up to remove it.

Figure 21. Removing a PCI Express x16 Graphics Card

Installing Linked PCI Express Graphics Cards

The Desktop Board supports technology that allows you to install linked PCI Express graphics cards such as NVIDIA* SLI* (Scalable Link Interface) cards. Make sure you use two identical SLI-ready graphics cards that are NVIDIA certified and the latest graphics driver. You can use the connector included with the Desktop Board to connect the two graphics cards together. Consult the user documentation for your graphics cards or visit the NVIDIA GeForce* website (http://www.geforce.com/#/News) for more information on graphics card configurations.

46

Installing and Replacing Desktop Board Components

To install two linked PCI Express graphics cards:

1.Observe the precautions in "Before You Begin" on page 31.

2.Install the first card in the PCI Express x16 connector as described in “Installing a PCI Express x16 Graphics Card” on page 44.

3.Place the second card in the secondary PCI Express x16 connector (Figure 22, A) and press down on the card until it is completely seated in the connector and the card retention notch on the card snaps into place around the retention mechanism pin on the connector.

4.Secure the card’s metal bracket to the chassis back panel with a screw (Figure 22, B).

5.Connect the two cards together with the SLI bridge (Figure 22, C) as shown.

6.Connect the monitor cable to the graphics card according to the manufacturer’s instructions.

Figure 22. Installing Linked PCI Express Graphics Cards

For more complete installation and configuration information refer to the documentation supplied by the graphics card manufacturer or visit their website.

47

Intel Desktop Board DZ68BC Product Guide

Connecting SATA Cables

SATA cables support the Serial ATA protocol. Each cable can be used to connect one internal SATA drive to the Desktop Board. For correct cable function:

1.Observe the precautions in “Before You Begin” on page 31.

2.Attach one end of the SATA cable to one of the SATA connectors on the board (Figure 23, A) and attach the other end of the cable to the SATA drive (Figure 23, B).

Figure 23. Connecting SATA Cables

48

Installing and Replacing Desktop Board Components

Connecting to the Internal Headers and Connectors

Before connecting cables to any of the internal headers or connectors, observe the precautions in “Before You Begin” on page 31. Figure 24 shows the location of the internal headers and connectors on Intel Desktop Board DZ68BC.

Figure 24. Internal Headers and Connectors

49

Intel Desktop Board DZ68BC Product Guide

Front Panel Intel HD Audio Header

Figure 24, A shows the location of the front panel Intel HD Audio header. Table 6 shows the pin assignments and signal names for the front panel Intel HD Audio header.

Table 6. Front Panel Intel HD Audio Header Signal Names

Pin

Signal Name

Pin

Signal Name









1

PORT 1L

2

GND









3

PORT 1R

4

PRESENCE#









5

PORT 2R

6

SENSE1_RETURN









7

SENSE_SEND

8

KEY (no pin)









9

PORT 2L

10

SENSE2_RETURN









S/PDIF Header

Figure 24, B shows the location of the S/PDIF output header. Table 7 shows the pin assignments and signal names for the S/PDIF connector.

Table 7. S/PDIF Header Signal Names

Pin Description

1Ground

2S/PDIF Out

3Key (no pin)

4+5 VDC

IEEE 1394a Header

Figure 24, C shows the location of the IEEE 1394a header. Table 8 shows the pin assignments and signal names for the IEEE 1394a header.

Table 8. IEEE 1394a Header Signal Names

Pin

Signal Name

Pin

Signal Name









1

TPA1+

2

TPA1-









3

Ground

4

Ground









5

TPA2+

6

TPA2-









7

+12 V

8

+12 V









9

Key (no pin)

10

Ground









50

Installing and Replacing Desktop Board Components

Chassis Intrusion Header

Figure 24, D shows the location of the chassis intrusion header. This header can be connected to a mechanical switch on the chassis to detect if the chassis cover is removed. This switch should be in the open position when the chassis cover is installed and closed when the cover is removed.

Table 9 shows the pin assignments and signal names for the chassis intrusion header.

Table 9. Chassis Intrusion Header Signal Names

Pin Description

1Ground

2Intruder#

Consumer IR (CIR) Headers

The Desktop Board has two CIR headers: the input or receiver header (Figure 24, E) and the output or emitter header (Figure 24, F). The receiver header consists of a filtered translated infrared input compliant with Microsoft CIR specifications and a “learning” infrared input. The learning input is a high-pass input which the computer can use to “learn” to speak the infrared communication language of other user remotes. The emitter header consists of two output ports which the computer can use to emulate “learned” infrared commands in order to control external electronic hardware.

NOTE

The Consumer IR option must be enabled in the system BIOS before it can function. Press <F2> at boot to enter the system BIOS, and go to Advanced > Peripheral Configuration > Enhanced Consumer IR, and set this option to Enabled.

Table 10 shows the pin assignments and signal names for the front panel CIR receiver (input) header and Table 11 shows the pin assignments and signal names for the back panel CIR emitter (output) header.

Table 10. Front Panel CIR Receiver (Input) Header Signal Names

Pin

Signal Name

Pin

Signal Name









1

Ground

2

LED









3

No Connection

4

Learn-In









5

+5 V Standby

6

Vcc









7

Key (no pin)

8

CIR Input









51

Intel Desktop Board DZ68BC Product Guide

Table 11. Back Panel CIR Header Emitter (Output) Header Signal Names

Pin

Signal Name

Pin

Signal Name









1

Emitter Out 1

2

Emitter Out 2









3

Ground

4

Key (no pin)









5

Jack Detect 1

6

Jack Detect 2









Front Panel Header

Figure 24, G shows the location of the front panel header. Table 12 shows the pin assignments and signal names for the front panel header.

Table 12. Front Panel Header Signal Names

Pin

Description

In/Out

Pin

Description

In/Out















Hard Drive Activity LED





Power LED















1

Hard disk LED pull-up to +5 V

Out

2

Front panel green LED

Out













3

Hard disk active LED

Out

4

Front panel yellow LED

Out















Reset Switch





On/Off Switch















5

Ground



6

Power switch

In













7

Reset switch

In

8

Ground

















Power





Not Connected















9

Power

Out

10

No pin















NOTE

When connecting individual wires from your chassis front panel to the front panel header, be sure to observe the connection polarity. Positive wires are usually solid color and negative wires are usually white or striped.

Alternate Front Panel Power LED Header

Figure 24, H shows the location of the alternate front panel power LED header. Pins 1 and 3 of this header duplicate the signals on pins 2 and 4 of the front panel header. If your chassis has a three-pin power LED cable, connect it to this header. Table 13 shows the pin assignments for the alternate front panel header.

Table 13. Alternate Front Panel Power LED Header Signal Names

Pin

Signal Name

In/Out







1

Front panel green LED

Out







2

No pin









3

Front panel yellow LED

Out







52

Installing and Replacing Desktop Board Components

Serial Header

Figure 24, I shows the location of the serial headers. Table 14 shows the pin assignments and signal names for each serial header.

Table 14. Serial Port Header

Pin

Signal Name

Pin

Signal Name









1

DCD (Data Carrier Detect)

2

RXD# (Receive Data)









3

TXD# (Transmit Data)

4

DTR (Data Terminal Ready)









5

Ground

6

DSR (Data Set Ready)









7

RTS (Request To Send)

8

CTS (Clear To Send)









9

RI (Ring Indicator)

10

Key (no pin)









USB 2.0 Headers

Figure 24, J shows the location of the four USB 2.0 headers. Table 15 shows the pin assignments and signal names for each USB 2.0 header. Each USB 2.0 header can be used to connect two USB devices.

Table 15. USB 2.0 Header Signal Names



Port A



Port B

Pin

Signal Name

Pin

Signal Name









1

Power (+5 V)

2

Power (+5 V)









3

D-

4

D-









5

D+

6

D+









7

Ground

8

Ground









9

Key

10

No Connection









NOTE

Computer systems that have an unshielded cable attached to a USB port might not meet FCC Class B requirements, even if no device or a low-speed USB device is attached to the cable. Use a shielded cable that meets the requirements for a full-speed USB device.

53

Intel Desktop Board DZ68BC Product Guide

USB 3.0 Connector

Figure 24, K shows the location of the USB 3.0 connector. assignments and signal names for the USB 3.0 connector. be used to connect two USB devices.

Table 16 shows the pin The USB 3.0 connector can

Table 16. USB 3.0 Connector

Pin

Signal Name

Pin

Signal Name









10

ID

11

IntA_P2_D+









9

IntA_P1_D+

12

IntA_P2_D−









8

IntA_P1_D−

13

Ground









7

Ground

14

IntA_P2_SSTX+









6

IntA_P1_SSTX+

15

IntA_P2_SSTX−









5

IntA_P1_SSTX−

16

Ground









4

Ground

17

IntA_P2_SSRX+









3

IntA_P1_SSRX+

18

IntA_P2_SSRX−









2

IntA_P1_SSRX−

19

Vbus









1

Vbus

20

Key (no pin)









54

Installing and Replacing Desktop Board Components

Connecting to the Audio System

After installing the Realtek audio driver from the Intel® Express Installer DVD-ROM, the multi-channel audio feature can be enabled. Figure 25 shows the back panel audio connectors. The default connector assignments are shown in the table.

Item Description

ARear surround speakers

BCenter/subwoofer

CLine in

DFront speakers

EMic in/side surround speakers

FS/PDIF (optical)

Figure 25. Back Panel Audio Connectors

NOTE

The back panel line out connector is designed to power either headphones or amplified speakers only. Poor audio quality may occur if passive (non-amplified) speakers are connected to this output.

55

Intel Desktop Board DZ68BC Product Guide

Connecting Chassis Fan and Power Supply

Cables

Connecting Chassis Fan Cables

Connect chassis fan cables to the chassis fan headers on the Desktop Board. Figure 26 shows the location of the chassis fan headers.

Figure 26. Location of the Chassis Fan Headers

56

Installing and Replacing Desktop Board Components

Connecting Power Supply Cables

Figure 27 shows the location of the power connectors.

CAUTION

Failure to use an appropriate power supply and/or not connecting the 12 V (Figure 27, A) power connector to the Desktop Board may result in damage to the board or the system may not function properly.

The 2 x 12 pin main power connector (Figure 27, B) is backwards compatible with ATX12V power supplies with 2 x 10 connectors.

Figure 27. Connecting Power Supply Cables

1.Observe the precautions in "Before You Begin" on page 31.

2.Connect the 12 V processor core voltage power supply cable to the 2 x 4 pin connector (Figure 27, A).

3.Connect the main power supply cable to the 2 x 12 pin connector (Figure 27, B).

57

Intel Desktop Board DZ68BC Product Guide

Setting the BIOS Configuration Jumper

NOTE

Always turn off the power and unplug the power cord from the computer before moving the jumper. Moving the jumper with the power on may result in unreliable computer operation.

Figure 28 shows the location of the Desktop Board’s BIOS configuration jumper block.

Figure 28. Location of the BIOS Configuration Jumper Block

58

Installing and Replacing Desktop Board Components

The three-pin BIOS jumper block enables board configuration to be done in the BIOS Setup program. Table 17 shows the jumper settings for the BIOS Setup program modes.

Table 17. Jumper Settings for the BIOS Setup Program Modes

Mode

Description





Normal (default) (1-2)

The BIOS uses the current configuration and



passwords for booting.





Configure (2-3)

After the Power-On Self-Test (POST) runs, the



BIOS displays the Maintenance Menu. Use this



menu to clear passwords.





Recovery (None)

The BIOS recovers data in the event of a failed



BIOS update.





Clearing Passwords

This procedure assumes that the board is installed in the computer and the configuration jumper block is set to normal mode.

1.Observe the precautions in "Before You Begin" on page 31.

2.Turn off all peripheral devices connected to the computer. Turn off the computer. Disconnect the computer’s power cord from the AC power source (wall outlet or power adapter).

3.Remove the computer cover.

4.Find the configuration jumper block (see Figure 28).

5.Place the jumper on pins 2-3.

6.Replace the cover, plug in the computer, turn on the computer, and allow it to boot.

7.The computer starts the Setup program. Setup displays the Maintenance menu.

8.Use the arrow keys to select Clear Passwords. Press <Enter> and Setup displays a pop-up screen requesting that you confirm clearing the password. Select Yes and press <Enter>. Setup displays the maintenance menu again.

9.Press <F10> to save the current values and exit Setup.

10.Turn off the computer. Disconnect the computer’s power cord from the AC power source.

11.Remove the computer cover.

12.To restore normal operation, place the jumper on pins 1-2.

13.Replace the cover, plug in the computer, and turn on the computer.

59

Intel Desktop Board DZ68BC Product Guide

Replacing the Battery

A coin-cell battery (CR2032) powers the real-time clock and CMOS memory. When the computer is not plugged into a wall socket, the battery has an estimated life of three years. When the computer is plugged in, the standby current from the power supply extends the life of the battery. The clock is accurate to ± 13 minutes/year at 25 ºC with 3.3 VSB applied.

When the voltage drops below a certain level, the BIOS Setup program settings stored in CMOS RAM (for example, the date and time) might not be accurate. Replace the battery with an equivalent one. Figure 29 on page 65 shows the location of the battery.

CAUTION

Risk of explosion if the battery is replaced with an incorrect type. Batteries should be recycled where possible. Disposal of used batteries must be in accordance with local environmental regulations.

PRÉCAUTION

Risque d'explosion si la pile usagée est remplacée par une pile de type incorrect. Les piles usagées doivent être recyclées dans la mesure du possible. La mise au rebut des piles usagées doit respecter les réglementations locales en vigueur en matière de protection de l'environnement.

FORHOLDSREGEL

Eksplosionsfare, hvis batteriet erstattes med et batteri af en forkert type. Batterier bør om muligt genbruges. Bortskaffelse af brugte batterier bør foregå i overensstemmelse med gældende miljølovgivning.

OBS!

Det kan oppstå eksplosjonsfare hvis batteriet skiftes ut med feil type. Brukte batterier bør kastes i henhold til gjeldende miljølovgivning.

VIKTIGT!

Risk för explosion om batteriet ersätts med felaktig batterityp. Batterier ska kasseras enligt de lokala miljövårdsbestämmelserna.

VARO

Räjähdysvaara, jos pariston tyyppi on väärä. Paristot on kierrätettävä, jos se on mahdollista. Käytetyt paristot on hävitettävä paikallisten ympäristömääräysten mukaisesti.

60

Installing and Replacing Desktop Board Components

VORSICHT

Bei falschem Einsetzen einer neuen Batterie besteht Explosionsgefahr. Die Batterie darf nur durch denselben oder einen entsprechenden, vom Hersteller empfohlenen Batterietyp ersetzt werden. Entsorgen Sie verbrauchte Batterien den Anweisungen des Herstellers entsprechend.

AVVERTIMENTO

Esiste il pericolo di un esplosione se la pila non viene sostituita in modo corretto. Utilizzare solo pile uguali o di tipo equivalente a quelle consigliate dal produttore. Per disfarsi delle pile usate, seguire le istruzioni del produttore.

PRECAUCIÓN

Existe peligro de explosión si la pila no se cambia de forma adecuada. Utilice solamente pilas iguales o del mismo tipo que las recomendadas por el fabricante del equipo. Para deshacerse de las pilas usadas, siga igualmente las instrucciones del fabricante.

WAARSCHUWING

Er bestaat ontploffingsgevaar als de batterij wordt vervangen door een onjuist type batterij. Batterijen moeten zoveel mogelijk worden gerecycled. Houd u bij het weggooien van gebruikte batterijen aan de plaatselijke milieuwetgeving.

ATENÇÃO

Haverá risco de explosão se a bateria for substituída por um tipo de bateria incorreto. As baterias devem ser recicladas nos locais apropriados. A eliminação de baterias usadas deve ser feita de acordo com as regulamentações ambientais da região.

AŚCIAROŽZNAŚĆ

Існуе рызыка выбуху, калі заменены акумулятар неправільнага тыпу. Акумулятары павінны, па магчымасці, перепрацоўвацца. Пазбаўляцца ад старых акумулятараў патрэбна згодна з мясцовым заканадаўствам па экалогіі.

61

Intel Desktop Board DZ68BC Product Guide

UPOZORNÌNÍ

V případě výměny baterie za nesprávný druh může dojít k výbuchu. Je-li to možné, baterie by měly být recyklovány. Baterie je třeba zlikvidovat v souladu s místními předpisy o životním prostředí.

Προσοχή

Υπάρχει κίνδυνος για έκρηξη σε περίπτωση που η μπαταρία αντικατασταθεί από μία λανθασμένου τύπου. Οι μπαταρίες θα πρέπει να ανακυκλώνονται όταν κάτι τέτοιο είναι δυνατό. Η απόρριψη των χρησιμοποιημένων μπαταριών πρέπει να γίνεται σύμφωνα με τους κατά τόπο περιβαλλοντικούς κανονισμούς.

VIGYÁZAT

Ha a telepet nem a megfelelő típusú telepre cseréli, az felrobbanhat. A telepeket lehetőség szerint újra kell hasznosítani. A használt telepeket a helyi környezetvédelmi előírásoknak megfelelően kell kiselejtezni.

AWAS

Risiko letupan wujud jika bateri digantikan dengan jenis yang tidak betul. Bateri sepatutnya dikitar semula jika boleh. Pelupusan bateri terpakai mestilah mematuhi peraturan alam sekitar tempatan.

OSTRZEŻENIE

Istnieje niebezpieczeństwo wybuchu w przypadku zastosowania niewłaściwego typu baterii. Zużyte baterie należy w miarę możliwości utylizować zgodnie z odpowiednimi przepisami ochrony środowiska.

PRECAUŢIE

Risc de explozie, dacă bateria este înlocuită cu un tip de baterie necorespunzător. Bateriile trebuie reciclate, dacă este posibil. Depozitarea bateriilor uzate trebuie să respecte reglementările locale privind protecţia mediului.

62

Installing and Replacing Desktop Board Components

ВНИМАНИЕ

При использовании батареи несоответствующего типа существует риск ее взрыва. Батареи должны быть утилизированы по возможности. Утилизация батарей должна проводится по правилам, соответствующим местным требованиям.

UPOZORNENIE

Ak batériu vymeníte za nesprávny typ, hrozí nebezpečenstvo jej výbuchu. Batérie by sa mali podľa možnosti vždy recyklovať. Likvidácia použitých batérií sa musí vykonávať v súlade s miestnymi predpismi na ochranu životného prostredia.

POZOR

Zamenjava baterije z baterijo drugačnega tipa lahko povzroči eksplozijo.

Če je mogoče, baterije reciklirajte. Rabljene baterije zavrzite v skladu z lokalnimi okoljevarstvenimi predpisi.

.

UYARI

Yanlış türde pil takıldığında patlama riski vardır. Piller mümkün olduğunda geri dönüştürülmelidir. Kullanılmış piller, yerel çevre yasalarına uygun olarak atılmalıdır.

OСТОРОГА

Використовуйте батареї правильного типу, інакше існуватиме ризик вибуху. Якщо можливо, використані батареї слід утилізувати. Утилізація використаних батарей має бути виконана згідно місцевих норм, що регулюють охорону довкілля.

63

Intel Desktop Board DZ68BC Product Guide

64

Installing and Replacing Desktop Board Components

To replace the battery, follow these steps:

1.Observe the precautions in "Before You Begin" (see page 31).

2.Turn off all peripheral devices connected to the computer. Disconnect the computer’s power cord from the AC power source (wall outlet or power adapter).

3.Remove the computer cover.

4.Locate the battery on the board (see Figure 29).

5.With a medium flat-bladed screwdriver, gently pry the battery free from its connector. Note the orientation of the “+” and “-” on the battery.

6.Install the new battery in the connector, orienting the “+” and “-” correctly.

7.Replace the computer cover.

Figure 29. Removing the Battery

65

Intel Desktop Board DZ68BC Product Guide

Installing the WiFi/Bluetooth* Module in a

Desktop Chassis (Optional)

Installing the WiFi/Bluetooth module that is shipped with Intel Desktop Board DZ68BC in your desktop system allows you to connect to wireless networks and Bluetooth peripherals.

The recommended installation procedure for a typical desktop chassis is as follows:

1.Observe the precautions in "Before You Begin" on page 31.

2.Make sure that the system is turned off and disconnected from its power source.

3.Remove the plastic cover from an empty 5-1/4 inch drive bay in the chassis bezel (Figure 30, A).

4.Remove the metal filler plate from the internal drive bay (Figure 30, B).

5.Remove the paper backing covering the adhesive on the back of the WiFi/Bluetooth Module and attach the module to the back side of the plastic drive bay cover (Figure 30, C).

6.Connect one end of the USB cable to the connector on the front of the module (Figure 30, D).

7.Reinstall the plastic drive bay cover in the chassis bezel while routing the USB cable into the chassis through the empty drive bay (Figure 30, E).

8.Connect the free end of the USB cable to an unused front panel USB header on the Desktop Board (see Figure 1, HH for locations) (Figure 30, F).

Figure 30. Installing the WiFi/Bluetooth Module

66

3 Updating the BIOS

The BIOS Setup program can be used to view and change the BIOS settings for the computer. You can access the BIOS Setup program by pressing the F2 key after the Power-On Self-Test (POST) memory test begins and before the operating system boot begins.

This chapter tells you how to update the BIOS by either using the Intel Express BIOS Update utility or the Intel® Flash Memory Update Utility, and how to recover the BIOS if an update fails.

Updating the BIOS with the Intel® Express

BIOS Update Utility

With the Intel Express BIOS Update utility you can update the system BIOS while in the Windows environment. The BIOS file is included in an automated update utility that combines the functionality of the Intel Flash Memory Update Utility and the ease of use of Windows-based installation wizards.

To update the BIOS with the Intel Express BIOS Update utility:

1.Go to the Intel World Wide Web site Download Center at http://downloadcenter.intel.com/

2.Navigate to the DZ68BC page. Click on the “BIOS Update” link and then select the Express BIOS Update file.

3.Download the file to your hard drive. (You can also save this file to a removable USB device. This is useful if you are updating the BIOS for multiple identical systems.)

4.Close all other applications. This step is required. Your system will be rebooted at the last Express BIOS Update window.

5.Double-click the executable file from the location on your hard drive where it was saved. This runs the update program.

6.Follow the instructions provided in the dialog boxes to complete the BIOS update.

67

Intel Desktop Board DZ68BC Product Guide

Updating the BIOS Using the F7 Function Key

To use this BIOS update method:

1.Download and save the Recovery BIOS (.BIO) file to a temporary directory.

2.Copy the .BIO file to a USB thumb drive.

3.Plug the thumb drive into a USB port of the target computer.

4.Shut down the target computer.

5.Enable the F7 prompt display:

a.Power the computer on.

b.Enter the BIOS Setup by pressing the F2 key during boot.

c.Go to the Advanced > Boot Configuration menu.

d.Enable Display F7 to Update BIOS

e.Press the F10 key to save and exit.

6.During boot, when the F7 prompt is displayed, press the F7 key to enter the BIOS Flash Update tool.

7.Select the USB thumb drive and press Enter.

8.Select the .BIO file and press Enter

9.Confirm you want to update the BIOS by pressing Enter.

10.Wait 2-5 minutes for the update to complete.

11.Remove the thumb drive.

12.Restart the computer.

Updating the BIOS with the Intel® Flash Memory Update Utility

You can use the information in this section to update the BIOS using the Intel® Flash Memory Update Utility. With the Intel Flash Memory Update Utility you can update the system BIOS from a bootable CD-ROM, bootable USB flash drive, or other bootable USB media.

You can update to a new version of the BIOS by using the Intel Flash Memory BIOS update file. The Intel Flash Memory BIOS update file is a compressed file that contains the files you need to update the BIOS. The BIOS update file contains:

New BIOS file (including the Intel® Management Engine (Intel® ME) Firmware Image)

Intel® Integrator Toolkit Configuration File (optional)

Intel Flash Memory Update Utility

You can obtain this file through your computer supplier or by navigating to the Intel Desktop Board DZ68BC page on the Intel World Wide Web site Download Center

at http://downloadcenter.intel.com.

On the DZ68BC page, click on the “BIOS Update” link and then select the Iflash BIOS Update file.

68

Updating the BIOS

NOTE

Review the instructions distributed with the update utility before attempting a BIOS update.

CAUTION

Do not interrupt the process or the system may not function properly.

1.Uncompress the BIOS update file and copy the .BIO file, IFLASH.EXE, and .ITK file (optional) to a bootable USB flash drive or other bootable USB media.

2.Configure the BIOS or use the F10 key option during POST to boot to the USB device.

3.Manually run the IFLASH.EXE file from the USB device and manually update the BIOS.

CAUTION

DO NOT POWER DOWN YOUR COMPUTER before the update is complete. The update may take up to 5 minutes.

Recovering the BIOS

It is unlikely that anything will interrupt the BIOS update; however, if an interruption occurs, the BIOS could be damaged. Due to BIOS size and recovery requirements, a CD-R with the .BIO file in the root directory will be required.

You can obtain the Recovery BIOS Update file through your computer supplier or by navigating to the Intel Desktop Board DZ68BC page on the Intel World Wide Web site Download Center at http://downloadcenter.intel.com.

On the DZ68BC page, click on the “BIOS Update” link and then select the Recovery BIOS Update file.

NOTE

For more information about updating the Intel Desktop Board BIOS or recovering from a BIOS update failure, go

to http://support.intel.com/support/motherboards/desktop/sb/CS-022312.htm.

69

Intel Desktop Board DZ68BC Product Guide

70

A Error Messages and Indicators

Intel Desktop Board DZ68BC reports POST errors in three ways:

By sounding a beep code and blinking the front panel power LED

By displaying an error message on the monitor

By displaying diagnostic progress codes (POST codes)

BIOS Error Codes

Whenever a recoverable error occurs during POST, the BIOS causes the board’s speaker to beep and the front panel power LED to blink an error message indicating the problem (see Table 18).

Table 18. BIOS Beep Codes

Type

Pattern





Processor

One 0.5 second beep when the CPU initialization process

initialization complete

completes.





POST complete

One 0.5 second beep when POST completes.





Video error

On-off (0.5 seconds each) two times, then 3.0 second pause



(off), entire pattern repeats (beeps and pause) until the system



is powered off.





Memory error

On-off (0.5 seconds each) three times, then 3.0 second pause



(off), entire pattern repeats (beeps and pause) until the system



is powered off.





Thermal trip warning

On-off (0.5 seconds each) four times, then 3.0 second pause



(off), entire pattern repeats (beeps and pause) until the



sixteenth beep, then ends.





Table 19. Front-panel Power LED Blink Codes

Type

Pattern





Processor

On when the system powers up, then off for 0.5 seconds.

initialization complete







POST complete

On when the system powers up, then off for 0.5 seconds.





BIOS update in

Off when the update begins, then on for 0.5 seconds, then off for

progress

0.5 seconds. The pattern repeats until the BIOS update is



complete.





Video error

On-off (0.5 seconds each) two times, then 3.0 second pause



(off), entire pattern repeats (blink and pause) until the system is



powered off.





Memory error

On-off (0.5 seconds each) three times, then 3.0 second pause



(off), entire pattern repeats (blinks and pause) until the system



is powered off.





Thermal trip warning

On-off (0.5 seconds each) four times, then 3.0 second pause



(off), entire pattern repeats (blinks and pause) until the



sixteenth blink, then ends.





71

Intel Desktop Board DZ68BC Product Guide

BIOS Error Messages

When a recoverable error occurs during the POST, the BIOS displays an error message describing the problem. Table 20 gives an explanation of the BIOS error messages.

Table 20. BIOS Error Messages

Error Message

Explanation





PROCESSOR_THERMAL_TRIP_ERROR

Processor was previously shutdown due to a thermal



event (overheating).





CMOS_BATTERY_ERROR

The firmware has detected that a CMOS battery failure



occurred.





CMOS_CHECKSUM_ERROR

The firmware has detected that a CMOS Checksum Error



occurred.





CMOS_TIMER_ERROR

The firmware has detected that the system date/time



has not been set.





MEMORY_SIZE_DECREASE_ERROR

The firmware has detected that the system memory has



decreased.





INTRUDER_DETECTION_ERROR

The system chassis was opened.





SPD_TOLER_ERROR

SERIAL PRESENCE DETECT (SPD) device data missing or



inconclusive. Properly programmed SPD device data is



required for reliable operation.





MEM_OPTIMAL_ERROR

The installed amount of memory in Channel A is not



equal to the amount of memory in Channel B. Maximum



memory performance is achieved with equal amounts of



memory installed in each channel.





72

Error Messages and Indicators

Port 80h POST Codes

During the POST, the BIOS generates diagnostic progress codes (POST codes) to I/O port 80h. If the POST fails, execution stops and the last POST code generated is left at port 80h and displayed on the Desktop Board’s seven-segment LED display shown in Figure 31. This code is useful for determining the point where an error occurred during the POST.

Figure 31. POST Code LED Display

73

Intel Desktop Board DZ68BC Product Guide

Table 21 lists the Port 80h POST codes in hexadecimal notation.

Table 21. Port 80h POST Codes

POST Code

Description







ACPI S States





00

Entering S0 state, standard





01-05

Entering S1-S5 state





10, 20, 30,

Resuming from S1-S5 state

40, 50









Security Phase (SEC)





08

Starting BIOS execution after CPU BIST





09

SPI prefetching and caching





0A, 0B

Load BSP/APS microcode





0C

Platform program base addresses





0D

Wake up all APS





0E

Initialize NEM





0F

Pass entry point of the PEI core







PEI Phase Before MRC





11

Set bootmode, GPIO init





12

Early chipset register programming





13

Basic PCH init, discrete device init





14

LAN init





15

Exit early platform init driver





16

SMBUS driver init





17, 18

Entry/Exit to SMBUS execute read/write





19, 1A

Entry/Exit to CK505 programming





1B, 1C

Entry/Exit to PEI overclock programming







MEC Memory Detection





21

MRC entry point





23

Reading SPD from memory DIMMs





24

Detecting presence of memory DIMMs





27

Configuring memory





28

Testing memory





29

Exit MRC driver







PEI After MRC





2A, 2B

Start/finish programming MTRR settings







PEIMs/Recovery





31, 33, 34

Recovery has initiate, load, valid





continued

74

Error Messages and Indicators

Table 21. Port 80h POST Codes (continued)



CPU Initialization (PEI, DXE, SMM)





41-43

Begin to end CPU PEI init





44-46

Begin to end CPU SMM init/relocate bases





47-4C

CPU DXE phase begin to end





4D-4F

CPU DXE SMM phase begin to end







I/O Buses





50-52

PCI enumeration, allocation, hot plug





58, 59

Resetting USB bus





5A, 5B

Resetting SATA bus and all devices





5F

Unrecoverable error, start with PIC







Boot Device Selection (BDS)





60-6F

BDS driver entry





E4

Entered DXE phase





E7

Waiting for user input





E8

Checking password





E9

Entering BIOS setup





EB

Calling legacy option ROMs







Keyboard/Mouse (PS/2 or USB)





90-95

Keyboard initialization





98-9B

Mouse initialization







Fixed Media





B0-BF

Detecting and initializing fixed media







Runtime Phase/EFI Operating System Boot





F8

EFI boot service ExitBootServices





F9

EFI runtime service SetVirtualAddressMap





75

Intel Desktop Board DZ68BC Product Guide

76

B Regulatory Compliance

This appendix contains the following regulatory compliance information for Intel Desktop Board DZ68BC:

Safety standards

European Union Declaration of Conformity statement

Product Ecology statements

Electromagnetic Compatibility (EMC) regulations

Product certifications

Safety Standards

Intel Desktop Board DZ68BC complies with the safety standards stated in Table 22 when correctly installed in a compatible host system.

Table 22. Safety Standards

Regulation

Title





CSA/UL 60950-1

Information Technology Equipment – Safety - Part 1: General



Requirements (USA and Canada)





EN 60950-1

Information Technology Equipment – Safety - Part 1: General



Requirements (European Union)





IEC 60950-1

Information Technology Equipment – Safety - Part 1: General



Requirements (International)





Battery Caution

There is insufficient space on this Desktop Board to provide instructions for replacing and disposing of the Lithium ion coin cell battery. For system safety certification, the statement below or an equivalent statement is required to be permanently and legibly marked on the chassis near the battery.

A suitable caution label is included with Intel Desktop Board DZ68BC.

CAUTION

Risk of explosion if the battery is replaced with an incorrect type. Batteries should be recycled where possible. Disposal of used batteries must be in accordance with local environmental regulations.

For information about replacing the battery, go to page 60.

77

Intel Desktop Board DZ68BC Product Guide

European Union Declaration of Conformity

Statement

We, Intel Corporation, declare under our sole responsibility that the product Intel® Desktop Board DZ68BC is in conformity with all applicable essential requirements necessary for CE marking, following the provisions of the European Council Directives 2004/108/EC (EMC Directive), 2006/95/EC (Low Voltage Directive), and 2002/95/EC (ROHS Directive).

The product is properly CE marked demonstrating this conformity and is for distribution within all member states of the EU with no restrictions.

This product follows the provisions of the European Directives 2004/108/EC, 2006/95/EC and 2002/95/EC.

Čeština Tento výrobek odpovídá požadavkům evropských směrnic 2004/108/EC, 2006/95/EC a 2002/95/EC.

Dansk Dette produkt er i overensstemmelse med det europæiske direktiv 2004/108/EC, 2006/95/EC & 2002/95/EC.

Dutch Dit product is in navolging van de bepalingen van Europees Directief 2004/108/EC, 2006/95/EC & 2002/95/EC.

Eesti Antud toode vastab Euroopa direktiivides 2004/108/EC, ja 2006/95/EC ja 2002/95/EC kehtestatud nõuetele.

Suomi Tämä tuote noudattaa EU-direktiivin 2004/108/EC, 2006/95/EC & 2002/95/EC määräyksiä.

Français Ce produit est conforme aux exigences de la Directive Européenne 2004/108/EC, 2006/95/EC & 2002/95/EC.

Deutsch Dieses Produkt entspricht den Bestimmungen der Europäischen Richtlinie 2004/108/EC, 2006/95/EC & 2002/95/EC.

Ελληνικά Το παρόν προϊόν ακολουθεί τις διατάξεις των Ευρωπαϊκών Οδηγιών

2004/108/EC, 2006/95/EC και 2002/95/EC.

Magyar E termék megfelel a 2004/108/EC, 2006/95/EC és 2002/95/EC Európai Irányelv előírásainak.

Icelandic Þessi vara stenst reglugerð Evrópska Efnahags Bandalagsins númer 2004/108/EC, 2006/95/EC, & 2002/95/EC.

Italiano Questo prodotto è conforme alla Direttiva Europea 2004/108/EC, 2006/95/EC & 2002/95/EC.

Latviešu Šis produkts atbilst Eiropas Direktīvu 2004/108/EC, 2006/95/EC un 2002/95/EC noteikumiem.

Lietuvių Šis produktas atitinka Europos direktyvų 2004/108/EC, 2006/95/EC, ir 2002/95/EC nuostatas.

Malti Dan il-prodott hu konformi mal-provvedimenti tad-Direttivi Ewropej 2004/108/EC, 2006/95/EC u 2002/95/EC.

Norsk Dette produktet er i henhold til bestemmelsene i det europeiske direktivet 2004/108/EC, 2006/95/EC & 2002/95/EC.

78

Regulatory Compliance

Polski Niniejszy produkt jest zgodny z postanowieniami Dyrektyw Unii Europejskiej 2004/108/EC, 206/95/EC i 2002/95/EC.

Portuguese Este produto cumpre com as normas da Diretiva Européia 2004/108/EC, 2006/95/EC & 2002/95/EC.

Español Este producto cumple con las normas del Directivo Europeo 2004/108/EC, 2006/95/EC & 2002/95/EC.

Slovensky Tento produkt je v súlade s ustanoveniami európskych direktív 2004/108/EC, 2006/95/EC a 2002/95/EC.

Slovenščina Izdelek je skladen z določbami evropskih direktiv 2004/108/EC, 2006/95/EC in 2002/95/EC.

Svenska Denna produkt har tillverkats i enlighet med EG-direktiv 2004/108/EC, 2006/95/EC & 2002/95/EC.

Türkçe Bu ürün, Avrupa Birliği’nin 2004/108/EC, 2006/95/EC ve 2002/95/EC yönergelerine uyar.

Product Ecology Statements

The following information is provided to address worldwide product ecology concerns and regulations.

Recycling Considerations

As part of its commitment to environmental responsibility, Intel has implemented the Intel® Product Recycling Program to allow retail consumers of Intel’s branded products to return used products to selected locations for proper recycling.

Please consult http://intel.com/intel/other/ehs/product_ecology

for the details of this program, including the scope of covered products, available locations, shipping instructions, terms and conditions, etc.

Intel Product Recycling Program

http://intel.com/intel/other/ehs/product_ecology

79

Intel Desktop Board DZ68BC Product Guide

Deutsch

Als Teil von Intels Engagement für den Umweltschutz hat das Unternehmen das Intel Produkt-Recyclingprogramm implementiert, das Einzelhandelskunden von Intel Markenprodukten ermöglicht, gebrauchte Produkte an ausgewählte Standorte für ordnungsgemäßes Recycling zurückzugeben.

Details zu diesem Programm, einschließlich der darin eingeschlossenen Produkte, verfügbaren Standorte, Versandanweisungen, Bedingungen usw., finden Sie auf der http://intel.com/intel/other/ehs/product_ecology

Español

Como parte de su compromiso de responsabilidad medioambiental, Intel ha implantado el programa de reciclaje de productos Intel, que permite que los consumidores al detalle de los productos Intel devuelvan los productos usados en los lugares seleccionados para su correspondiente reciclado.

Consulte la http://intel.com/intel/other/ehs/product_ecology

para ver los detalles del programa, que incluye los productos que abarca, los lugares disponibles, instrucciones de envío, términos y condiciones, etc.

Français

Dans le cadre de son engagement pour la protection de l'environnement, Intel a mis en œuvre le programme Intel Product Recycling Program (Programme de recyclage des produits Intel) pour permettre aux consommateurs de produits Intel de recycler les produits usés en les retournant à des adresses spécifiées.

Visitez la page Web http://intel.com/intel/other/ehs/product_ecology pour en savoir plus sur ce programme, à savoir les produits concernés, les adresses disponibles, les instructions d'expédition, les conditions générales, etc.

サイクルを適切に行えるよう、インテル製品リサイクル

http://intel.com/intel/other/ehs/product_ecology

Malay

Sebagai sebahagian daripada komitmennya terhadap tanggungjawab persekitaran, Intel telah melaksanakan Program Kitar Semula Produk untuk membenarkan pengguna-pengguna runcit produk jenama Intel memulangkan produk terguna ke lokasi-lokasi terpilih untuk dikitarkan semula dengan betul.

Sila rujuk http://intel.com/intel/other/ehs/product_ecology untuk mendapatkan butirbutir program ini, termasuklah skop produk yang dirangkumi, lokasi-lokasi tersedia, arahan penghantaran, terma & syarat, dsb.

80

Regulatory Compliance

Portuguese

Como parte deste compromisso com o respeito ao ambiente, a Intel implementou o Programa de Reciclagem de Produtos para que os consumidores finais possam enviar produtos Intel usados para locais selecionados, onde esses produtos são reciclados de maneira adequada.

Consulte o site http://intel.com/intel/other/ehs/product_ecology (em Inglês) para obter os detalhes sobre este programa, inclusive o escopo dos produtos cobertos, os locais disponíveis, as instruções de envio, os termos e condições, etc.

Russian

В качестве части своих обязательств к окружающей среде, в Intel создана программа утилизации продукции Intel (Product Recycling Program) для предоставления конечным пользователям марок продукции Intel возможности возврата используемой продукции в специализированные пункты для должной утилизации.

Пожалуйста, обратитесь на веб-

сайт http://intel.com/intel/other/ehs/product_ecology за информацией об этой программе, принимаемых продуктах, местах приема, инструкциях об отправке, положениях и условиях и т.д.

Türkçe

Intel, çevre sorumluluğuna bağımlılığının bir parçası olarak, perakende tüketicilerin Intel markalı kullanılmış ürünlerini belirlenmiş merkezlere iade edip uygun şekilde geri dönüştürmesini amaçlayan Intel Ürünleri Geri Dönüşüm Programı’nı uygulamaya koymuştur.

Bu programın ürün kapsamı, ürün iade merkezleri, nakliye talimatları, kayıtlar ve şartlar v.s dahil bütün ayrıntılarını ögrenmek için

lütfen http://intel.com/intel/other/ehs/product_ecology web sayfasına gidin.

81

Intel Desktop Board DZ68BC Product Guide

China RoHS

Intel Desktop Board DZ68BC is a China RoHS-compliant product.

The China Ministry of Information Industry (MII) stipulates that a material Self Declaration Table (SDT) must be included in a product’s user documentation. The SDT for Intel Desktop Board DZ68BC is shown in Figure 32.

Figure 32. Intel Desktop Board DZ68BC China RoHS Material

Self Declaration Table

82

Regulatory Compliance

EMC Regulations

Intel Desktop Board DZ68BC complies with the EMC regulations stated in Table 23 when correctly installed in a compatible host system.

Table 23. EMC Regulations

Regulation

Title





FCC 47 CFR Part 15,

Title 47 of the Code of Federal Regulations, Part 15, Subpart B,

Subpart B

Radio Frequency Devices. (USA)





ICES-003

Interference-Causing Equipment Standard, Digital Apparatus.



(Canada)





EN55022

Limits and methods of measurement of Radio Interference



Characteristics of Information Technology Equipment. (European



Union)





EN55024

Information Technology Equipment – Immunity Characteristics



Limits and methods of measurement. (European Union)





EN55022

Australian Communications Authority, Standard for



Electromagnetic Compatibility. (Australia and New Zealand)





CISPR 22

Limits and methods of measurement of Radio Disturbance



Characteristics of Information Technology Equipment.



(International)





CISPR 24

Information Technology Equipment – Immunity Characteristics –



Limits and Methods of Measurement. (International)





VCCI V-3, V-4

Voluntary Control for Interference by Information Technology



Equipment. (Japan)





KN-22, KN-24

Korean Communications Commission – Framework Act on



Telecommunications and Radio Waves Act. (South Korea)





CNS 13438

Bureau of Standards, Metrology and Inspection. (Taiwan)





FCC Declaration of Conformity

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause undesired operation.

For questions related to the EMC performance of this product, contact:

Intel Corporation, 5200 N.E. Elam Young Parkway, Hillsboro, OR 97124 1-800-628-8686

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to

83

Intel Desktop Board DZ68BC Product Guide

radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and the receiver.

Connect the equipment to an outlet on a circuit other than the one to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Any changes or modifications to the equipment not expressly approved by Intel Corporation could void the user’s authority to operate the equipment.

Tested to comply with FCC standards for home or office use.

Canadian Department of Communications Compliance Statement

This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.

Le présent appareil numerique német pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la classe B prescrites dans le Réglement sur le broullage radioélectrique édicté par le ministére des Communications du Canada.

Japan VCCI Statement

Japan Statement translation: This is a Class B product based on the standard of the Voluntary Control Council for Interference from Information Technology Equipment (VCCI). If this is used near a radio or television receiver in a domestic environment, it may cause radio interference. Install and use the equipment according to the instruction manual.

84

Regulatory Compliance

Korea Class B Statement

Korea Class B Statement translation: This equipment is for home use, and has acquired electromagnetic conformity registration, so it can be used not only in residential areas, but also other areas.

Ensure Electromagnetic Compatibility (EMC) Compliance

Before computer integration, make sure that the power supply and other modules or peripherals, as applicable, have passed Class B EMC testing and are marked accordingly.

Pay close attention to the following when reading the installation instructions for the host chassis, power supply, and other modules:

Product certifications or lack of certifications

External I/O cable shielding and filtering

Mounting, grounding, and bonding requirements

Keying connectors when mating the wrong connectors could be hazardous

If the power supply and other modules or peripherals, as applicable, are not Class B EMC compliant before integration, then EMC testing may be required on a representative sample of the newly completed computer.

85

Intel Desktop Board DZ68BC Product Guide

Product Certifications

Board-Level Certifications

Intel Desktop Board DZ68BC has the regulatory compliance marks shown in Table 24.

Table 24. Regulatory Compliance Marks

Description

Mark

UL joint US/Canada Recognized Component mark. Includes adjacent



UL file number for Intel Desktop Boards: E210882.







FCC Declaration of Conformity logo mark for Class B equipment.







CE mark. Declaring compliance to European Union (EU) EMC



directive, Low Voltage directive, and RoHS directive.







Australian Communications Authority (ACA) and New Zealand Radio



Spectrum Management (NZ RSM) C-tick mark. Includes adjacent



Intel supplier code number, N-232.







Japan VCCI (Voluntary Control Council for Interference) mark.







Korea Certification mark. Includes an adjacent KCC (Korean



Communications Commission) certification number:



KCC-REM-CPU-DZ68BC.







Taiwan BSMI (Bureau of Standards, Metrology and Inspections)



mark. Includes adjacent Intel company number, D33025.







Printed wiring board manufacturer’s recognition mark. Consists of a

V-0

unique UL recognized manufacturer’s logo, along with a flammability



rating (solder side).







China RoHS/Environmentally Friendly Use Period Logo: This is an



example of the symbol used on Intel Desktop Boards and associated



collateral. The color of the mark may vary depending upon the



application. The Environmental Friendly Usage Period (EFUP) for



Intel Desktop Boards has been determined to be 10 years.







86

Regulatory Compliance

Chassisand Component-Level Certifications

Ensure that the chassis and certain components; such as the power supply, peripheral drives, wiring, and cables; are components certified for the country or market where used. Agency certification marks on the product are proof of certification. Typical product certifications include:

In Europe

The CE mark indicates compliance with all applicable European requirements. If the chassis and other components are not properly CE marked, a supplier’s Declaration of Conformity statement to the European EMC directive, Low Voltage directive (as applicable), and ROHS directive, should be obtained. Additionally, other directives, such as the Radio and Telecommunications Terminal Equipment (R&TTE) directive may also apply depending on product features.

In the United States

A certification mark by a Nationally Recognized Testing Laboratory (NRTL) such as UL, CSA, or ETL signifies compliance with safety requirements. Wiring and cables must also be UL listed or recognized and suitable for the intended use. The FCC Class B logo for home or office use signifies compliance with electromagnetic interference (EMI) requirements.

In Canada

A nationally recognized certification mark such as CSA or cUL signifies compliance with safety requirements. The Industry Canada statement on page 84 of this product guide demonstrates compliance with Canadian EMC regulations.

Chassis and Component Certifications

Ensure that the chassis and certain components; such as the power supply, peripheral drives, wiring, and cables; are components certified for the country or market where used. Agency certification marks on the product are proof of certification. Typical product certifications include:

In Europe

The CE marking signifies compliance with all applicable European requirements. If the chassis and other components are not properly CE marked, a supplier’s Declaration of Conformity statement to the European EMC directive and Low Voltage directive (as applicable), should be obtained. Additionally, other directives, such as the Radio and Telecommunications Terminal Equipment (R&TTE) directive may also apply depending on product features.

In the United States

A certification mark by a Nationally Recognized Testing Laboratory (NRTL) such as UL, CSA, or ETL signifies compliance with safety requirements. Wiring and cables must also be UL listed or recognized and suitable for the intended use. The FCC Class B logo for home or office use signifies compliance with electromagnetic interference (EMI) requirements.

87

Intel Desktop Board DZ68BC Product Guide

In Canada

A nationally recognized certification mark such as CSA or cUL signifies compliance with safety requirements. The Industry Canada statement on page 84 of this product guide demonstrates compliance with Canadian EMC regulations.

ENERGY STAR*, e-Standby, and ErP

Compliance

The US Department of Energy and the US Environmental Protection Agency have continually revised the ENERGY STAR requirements. Intel has worked directly with these two governmental agencies in the definition of the new requirements.

Intel Desktop Board DZ68BC meets the following program requirements in an adequate system configuration, including appropriate selection of an efficient power supply:

Energy Star v5.0, category D

EPEAT

Korea e-Standby

European Union Energy-related Products Directive 2009 (ErP)

For information about ENERGY STAR requirements and recommended configurations, go to http://www.intel.com/go/energystar.

88
