Infiniti QX50 2016 Quick Reference Guide

2016 Infiniti QX50

Quick Reference Guide

1 3

Behind

steering

wheel

5 6

Behind

steering

wheel

7 8 9

steering

Behind

15 16

steering

wheel

column

INSTRUMENT BRIGHTNESS CONTROL SWITCH*

VEHICLE INFORMATION DISPLAY

TRIP COMPUTER SWITCHES

LOW TIRE PRESSURE WARNING LIGHT

HEADLIGHT AND TURN SIGNAL SWITCH

WIPER AND WASHER SWITCH

STEERING WHEEL SWITCHES FOR

AUDIO* / BLUETOOTH

INTELLIGENT CRUISE CONTROL BUTTONS

PUSH-BUTTON IGNITION

WARNING SYSTEMS SWITCH*

/ NAVIGATION

DYNAMIC DRIVER ASSISTANCE SWITCH*

INTELLIGENT KEY PORT

TILT / TELESCOPIC STEERING

WHEEL SWITCH*

HOOD RELEASE*

VEHICLE DYNAMIC CONTROL (VDC)

OFF SWITCH*

CONTROL PANEL DISPLAY SCREEN*

AUDIO SYSTEM

HEATER AND AIR CONDITIONER (automatic)

FRONT PASSENGER AIR BAG

STATUS LIGHT*

INTELLIGENT BRAKE ASSIST (IBA)

OFF SWITCH*

*See your Owner’s Manual for information.

new system features

Around View ® Monitor (AVM) with Moving Object Detection (MOD)

(if so equipped) ................................................2

Snow Mode ...................................................3

Blind Spot Warning (BSW) (if so equipped) ..........................4

essential information

Tire Pressure Monitoring System (TPMS) ............................5

Loose Fuel Cap .................................................5

Fuel-filler Door .................................................6

Front Armrest/Center Console Storage Box ..........................6

Clock Set/Adjustment ...........................................6

first drive features

INFINITI Intelligent Key System ...................................7

Liftgate Release ................................................8

Power Seat Adjustments .........................................8

Heated Seats ..................................................9

Automatic Drive Positioner (if so equipped) .........................9

Outside Mirror Control Switch....................................10

Headlight Control Switch........................................10

Wiper and Washer Switch .......................................11

Starting/Stopping the Engine ....................................12

Heater and Air Conditioner (automatic) ............................12

FM/AM/SiriusXM® Satellite Radio with CD/DVD Player

(with Navigation System - if so equipped) ..........................14

USB (Universal Serial Bus) Connection Port and iPod® Interface........15

Conventional (Fixed Speed) Cruise Control .........................15

Intelligent Cruise Control (ICC) (if so equipped) .....................16

Power Outlets .................................................17

system guide

Trip Computer.................................................18

Bluetooth® Hands-free Phone System .............................19

System Operating Tips .......................................19

Bluetooth® System with Navigation (if so equipped) .................20

Bluetooth® System without Navigation (if so equipped) ..............22

Bluetooth® Streaming Audio with Navigation (if so equipped)..........23

Navigation System (if so equipped) ...............................24

DVD Player ...................................................25

HomeLink® Universal Transceiver (if so equipped) ...................26

Please see your Owner’s Manual for important safety information and system operation limitations.

• A cellular telephone should not be used for any purpose while driving so full attention may be given to vehicle operation.

• Always wear your seat belt.

• Supplemental air bags do not replace proper seat belt usage.

• Children 12 and under should always ride in the rear seat properly secured in child restraints or seat belts according to their age and weight.

For more information, refer to the “Safety — Seats, seat belts and supplemental

restraint system (section 1)”, the “Monitor, climate, audio, phone and voice recognition systems (section 4)” and the “Starting and driving (section 5)” of

your Owner’s Manual.

• Do not drink and drive.

Additional information about your vehicle is also available in your Owner’s Manual, Navigation System Owner’s Manual and at www.InfinitiUSA.com.

To view detailed instructional videos, go to

www.infinitiownersinfo.mobi/2016/qx50

or snap this barcode with an appropriate barcode reader.

new system features

Around View® Monitor (AVM) with Moving Object Detection (MOD) (if so equipped)

With the ignition switch in the ON position, the

AVM is activated by pressing the CAMERA button 1, located on the control panel, or by moving the shift lever to the R (REVERSE) position. The control panel displays various views of the position of the vehicle.

When the shift lever is in the P (PARK), N (NEUTRAL) or D

(DRIVE) position and the CAMERA button 1 is pressed, the following views will display in order:

Start from any Control Panel screen

Press

Front wide view

Press

Front view & bird’s-eye view

Press

Front view & front-side view

When the shift lever is in the R (REVERSE) position and the CAMERA button 1 is pressed,

the following views will display in order:

Rear view & bird’s-eye view

Press

Rear view & front-side view

Rear wide view

PressPress

The colored guide lines on the display screen indicate vehicle width and approximate

distances to objects with reference to the vehicle body line.

• Red 1.5 ft (0.5 m); Yellow 3 ft (1 m); Green 7 ft (2 m) and 10 ft (3 m).

There are some areas where the system will not

show objects.

• When in the front or the rear view display, an

object below the bumper or on the ground may not be viewed

• When in the bird’s-eye view, a tall object near the seam of the camera viewing areas

will not

appear in the monitor.

The distance between objects viewed on the AVM

differs from the actual distance.

Objects in the bird’s-eye view will appear further

than the actual distance.

MOVING OBJECT DETECTION

If the MOD system detects moving objects

surrounding the vehicle, a yellow frame 4 will

be displayed on the camera image and a chime will sound.

In the bird’s-eye view, a yellow frame is displayed on

those camera images (front, rear, right, left) where moving objects are detected.

When the following are displayed:

• Blue MOD icon

• Gray MOD icon

: the system is operative in this view.

: the system is not operative in this view.

• No MOD icon: the system is off.

To temporarily turn the system on or off, touch the MOD key 7 .

For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (section 4)” of your Owner’s Manual.

Snow Mode

When SNOW mode is activated, engine output

is controlled to avoid wheel spin when driving or starting the vehicle on snowy roads or slippery areas.

To turn on SNOW mode, press the SNOW switch 1,

located on the center console, to the ON position.

The indicator light

SNOW mode is on.

For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.

will illuminate when the

new system features

Blind Spot Warning (BSW) (if so equipped)

The BSW system alerts the driver when another

vehicle moves into the vehicle’s detection area.

An indicator light located near the outside mirrors 1

will illuminate if the radar sensors detect a vehicle in the detection zone.

Push the warning system switch 2 to temporarily

turn the system off. When the system is off, the indicator light 3 on the switch is off.

The indicator light 3 will also be off if all of the

warning systems are deactivated by pressing and holding down the warning system switch 2 for 4 seconds.

The indicator light 3 will illuminate after the ignition

switch is ON and the BSW system is enabled.

For more information, refer to the “Instruments and controls (section 2)” and the “Starting and driving (section 5)” of your Owner’s Manual.

essential information

Tire Pressure Monitoring System (TPMS)

A CHECK TIRE PRESSURE warning message will

appear in the vehicle information display 1 and the low tire pressure warning light 2 will illuminate when one or more tires are low in pressure and air is needed.

• The tire pressures should be checked when the tires are cold. The tires are considered cold after the vehicle has been parked for 3 hours or more or driven less than 1 mi (1.6 km) at moderate speeds.

After the tire pressures are adjusted, drive the

vehicle at speeds above 16 mph (25 km/h). The CHECK TIRE PRESSURE warning message and the low tire pressure warning light 2 will extinguish.

When the low tire pressure warning light 2 flashes for 1 minute and then remains on, the

TPMS is not functioning properly. Have the system checked by an INFINITI retailer.

Tire pressure rises and falls depending on the heat caused by the vehicle’s operation and

the outside temperature. Low outside temperature can lower the temperature of the air inside the tire, which can cause a lower tire inflation pressure. This may cause the low tire pressure warning light 2 to illuminate. If the warning light illuminates, check the tire pressure in your tires.

• Check the tire pressure (including the spare tire) often and always prior to long distance trips.

The Tire and Loading Information label contains valuable information. Please refer to the

“Technical and consumer information (section 9)” of your Owner’s Manual for the location of the Tire and Loading Information label.

For more information, refer to the “Instruments and controls (section 2)”, the “Starting and driving (section 5)” and the

“Maintenance and do-it-yourself (section 8)” of your Owner’s Manual.

Loose Fuel Cap

A LOOSE FUEL CAP warning message will appear

in the vehicle information display 1 when the fuel-filler cap is not tightened correctly.

To tighten, turn the cap clockwise until a single click

is heard.

The warning message will extinguish when the

vehicle detects the fuel-filler cap is properly tightened and the reset button 2 is pressed.

If the cap is not properly tightened, the Malfunction

Indicator Light may illuminate.

For more information, refer to the “Instruments and controls (section 2)” and the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.

essential information

Fuel-filler Door

Unlock the fuel-filler door using one of the following operations then push and release the left side of the door to open.

Push either door handle request switch or the liftgate

request switch while carrying the INFINITI Intelligent Key with you (that is, in your pocket or purse).

Press the button on the Intelligent Key.

Push the power door lock switch to the position.

For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.

Front Armrest/Center Console Storage Box

To access the center console storage box, press

the button 1.

For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.

Clock Set/Adjustment

DIGITAL CLOCK WITH NAVIGATION (IF SO EQUIPPED)

To adjust the time and the appearance of the clock

on the display:

1. Press the SETTING button on the control panel.

2. Select the “Others” key.

3. Select the “Clock” key.

The following settings can be adjusted:

• On-screen Clock: The clock in the upper right corner of the display can be turned on or off.

• Clock Format (24h): The clock can be set to 12 hours or 24 hours.

• Offset (hour): The time can be adjusted by increasing or decreasing per hour.

• Offset (min): The time can be adjusted by increasing or decreasing per minute.

• Daylight Savings Time: The application of Daylight Savings Time can be turned on or off.

• Time Zone: Adjust the time zone. Choose a time zone from the available list.

Press the BACK button to return to the previous screen.

For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (section 4)” of your Owner’s Manual.

first drive features

INFINITI Intelligent Key System

The INFINITI Intelligent Key System allows you to lock or unlock your vehicle, open your liftgate and start the engine. It is important to make sure the Intelligent Key is with you (that is, in your pocket or purse).

LOCKING AND UNLOCKING YOUR VEHICLE

The operating range of the Intelligent Key is within

31.5 in (80 cm) from each request switch.

To lock the vehicle, push either door handle request

switch 1 or the liftgate request switch 2 or press the button 3 on the key fob.

To unlock the vehicle, perform one of the

following procedures:

• Push either door handle request switch

or the liftgate request switch 2; the corresponding door will unlock. Push the door handle request switch 1 or the liftgate request switch 2 again within 1 minute; all other doors will unlock, or

• Press the

button 4 on the key fob to unlock the driver’s side

door. Press the button 4 again; all other doors will unlock.

The Intelligent Key can also be used to activate the panic alarm by

pressing and holding the button 5 for more than 1 second. Once activated, the panic alarm and headlights will stay on for a period of time.

INFINITI INTELLIGENT KEY BATTERY DISCHARGE

If the battery in the Intelligent Key is almost

discharged, the guide light 6 of the Intelligent Key port blinks and the Intelligent Key insertion indicator

is displayed in the vehicle information display.

To start the engine under these circumstances,

insert the Intelligent Key into the key port with the key ring side facing backward until it latches into place. Then push the ignition switch to start the engine.

To remove the Intelligent Key from the port, push the

ignition switch to turn the engine off and then pull the Intelligent Key out of the port.

The Intelligent Key port does not charge the

Intelligent Key battery. If you see the Intelligent Key warning light 8, replace the battery in the Intelligent Key.

Do not insert the mechanical key or other objects into

the key port because they will damage the key port.

For more information, refer to the “Pre-driving checks and adjustments (section 3)”, the “Starting and driving (section 5)” and the “Maintenance and do-it-yourself (section 8)” of your Owner’s Manual.

F E

first drive features

Liftgate Release

It is important to make sure the Intelligent Key is with you

(that is, in your pocket or purse).

Use one of the following methods to unlock the liftgate:

• Press the

• Push the liftgate request switch

To open the liftgate, push the opener switch 3 located just

above the license plate and pull the opener handle.

For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.

button 1 on the INFINITI Intelligent Key twice.

Power Seat Adjustments

To slide the seat forward or backward, push the

switch 1 forward or backward.

To recline the seatback, push the switch

forward or backward.

SEAT LIFTER (driver’s seat and if so equipped for passenger’s seat)

To adjust the angle of the front portion or height of

the seat, push the front or rear end of the switch

up or down.

POWER LUMBAR SUPPORT (if so equipped for driver’s seat)

To adjust the seat lumbar support, push the front or back end of the switch

For more information, refer to the “Safety — Seats, seat belts and supplemental restraint system (section 1)” of your Owner’s Manual.

+ 22 hidden pages

Infiniti QX50 2016 Quick Reference Guide

table of contents
