Standard Specifications
1-/3-phase 200V class
|
|
|
European Version |
002SFEF2 |
004SFEF2 |
005SFEF2 |
007SFEF2 |
011SFEF2 |
|
015SFEF2 |
|
022SFEF2 |
|
- |
|
- |
- |
Model X200- |
|
|
US Version |
002NFU2 |
004NFU2 |
- |
007NFU2 |
- |
|
015NFU2 |
|
022NFU2 |
|
037LFU2 |
|
55LFU2 |
075LFU2 |
|
|
|
JP Version |
002LFRF2 |
004LFRF2 |
- |
007LFRF2 |
- |
|
015LFRF2 |
|
022LFRF2 |
|
037LFRF2 |
|
055LFRF2 |
075LFRF2 |
|
Applicable motor size, 4-pole kW(HP) *1 |
0.2(1/4) |
0.4(1/2) |
0.55(3/4) |
0.75(1) |
1.1(1.5) |
|
1.5 (2) |
|
2.2(3) |
|
3.7(5) |
|
5.5(7.5) |
7.5(10) |
||
|
Rated capacity |
|
230V |
0.5 |
1.0 |
1.1 |
1.5 |
1.9 |
|
2.8 |
|
3.9 |
|
6.3 |
|
9.6 |
12.7 |
Output Ratings |
|
240V |
0.5 |
1.0 |
1.2 |
1.6 |
2.0 |
|
2.9 |
|
4.1 |
|
6.6 |
|
9.9 |
13.3 |
|
|
|
|
|
|
|
||||||||||||
Rated output current (A) *2 |
1.4 |
2.6 |
3.0 |
4.0 |
5.0 |
|
7.1 |
|
10.0 |
|
15.9 |
|
24.0 |
32.0 |
|||
|
|
|
|
|
|||||||||||||
|
Overload capacity(output current) |
|
|
|
|
150% for 60 sec. |
|
|
|
|
|
|
|||||
|
Rated output voltage (V) |
|
|
3-phase (3-wire) 200 to 240V (corresponding to input voltage) |
|
|
|
|
|||||||||
|
|
|
|
|
|
|
SFEF: 1-phase 200 to 240V+10%, -15%, 50/60Hz ±5% |
|
|
|
|
||||||
|
Rated input voltage (V) |
|
|
|
|
NFU: 1-/3-phase 200 to 240V+10%, -15%, 50/60Hz ±5% |
|
|
|
|
|||||||
Input Rating |
|
|
|
|
|
|
LFU/LFRF: 3-phase 200 to 240V+10%, -15%, 50/60Hz ±5% |
|
|
||||||||
|
Rated input current |
|
SFEF2 |
3.1 |
5.8 |
6.7 |
9.0 |
11.2 |
|
16.0 |
|
22.5 |
|
- |
|
- |
- |
|
(A) |
|
NFU2/LFUF2/LFRF2 |
1.8 |
3.4 |
- |
5.2 |
- |
|
9.3 |
|
13.0 |
|
20.0 |
|
30.0 |
40.0 |
Enclosure *4 |
|
|
|
|
|
|
|
IP20 |
|
|
|
|
|
|
|||
Cooling method |
|
|
|
|
|
Self-cooling |
|
|
|
|
|
Force ventilation |
|
|
|||
Integrated EMC filter |
|
|
-SFEF2 |
|
|
|
|
EN61800-3 category C1 filter |
|
|
|
|
|
|
|||
|
|
-NFU2/LFU2/LFRF2 |
|
|
|
|
|
- |
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
Zero phase Reactor |
|
|
-LFRF2 |
|
|
|
|
Built-in |
|
|
|
|
|
|
|||
|
|
|
-SFEF2 |
0.8 |
1.0 |
1.5 |
1.5 |
2.4 |
|
2.4 |
|
2.5 |
|
- |
|
- |
- |
Weight (kg) |
|
|
-NFU2/LFU2 |
0.8 |
0.9 |
- |
1.5 |
- |
|
2.3 |
|
2.4 |
|
2.3 |
|
4.2 |
4.2 |
|
|
|
-LFRF2 |
0.8 |
0.9 |
- |
1.1 |
- |
|
2.2 |
|
2.4 |
|
2.4 |
|
4.2 |
4.2 |
3-phase 400V class
|
|
|
European Version |
004HFEF2 |
007HFEF2 |
015HFEF2 |
022HFEF2 |
|
030HFEF2 |
040HFEF2 |
055HFEF2 |
075HFEF2 |
Model X200- |
|
|
US Version |
004HFU2 |
007HFU2 |
015HFU2 |
022HFU2 |
|
- |
040HFU2 |
055HFU2 |
075HFU2 |
|
|
|
JP Version |
004HFRF2 |
007HFRF2 |
015HFRF2 |
022HFRF2 |
|
- |
037HFRF2 |
055HFRF2 |
075HFRF2 |
|
Applicable motor size, 4-pole kW(HP) *1 |
0.4(1/2) |
0.75(1) |
1.5 (2) |
2.2(3) |
|
3(4) |
4(5) |
5.5(7.5) |
7.5(10) |
||
|
Rated capacity |
|
400V |
1.0 |
1.7 |
2.6 |
3.8 |
|
5.4 |
5.9 |
9.0 |
11.1 |
Output Ratings |
|
480V |
1.2 |
2.0 |
3.1 |
4.5 |
|
6.4 |
7.1 |
10.8 |
13.3 |
|
|
|
|
||||||||||
Rated output current (A) *2 |
1.5 |
2.5 |
3.8 |
5.5 |
|
7.8 |
8.6 |
13.0 |
16.0 |
|||
|
|
|||||||||||
|
Overload capacity(output current) |
|
|
|
150% for 60 sec. |
|
|
|
||||
|
Rated output voltage (V) |
|
|
3-phase (3-wire) 380 to 480V (corresponding to input voltage) |
|
|
||||||
Input Rating |
Rated input voltage (V) |
|
|
|
3-phase 380 to 480V +10%, -15%, 50/60Hz±5% |
|
|
|||||
|
Rated input current (A) |
|
2.0 |
3.3 |
5.0 |
7.0 |
|
10.0 |
11.0 |
16.5 |
20.0 |
|
Enclosure *4 |
|
|
|
|
|
|
|
IP20 |
|
|
|
|
Cooling method |
|
|
|
Self-cooling |
|
|
|
Force ventilation |
|
|
||
Integrated EMC filter |
|
|
-HFEF2 |
|
|
|
EN61800-3 category C2 filter |
|
|
|
||
|
|
-HFU2/HFRF2 |
|
|
|
|
- |
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|||
Zero phase Reactor |
|
|
-HFRF2 |
|
|
|
|
Built-in |
|
|
|
|
|
|
|
-HFEF2 |
1.5 |
2.3 |
2.4 |
2.4 |
|
2.4 |
2.4 |
4.2 |
4.2 |
Weight (kg) |
|
|
-HFU2 |
1.4 |
2.2 |
2.3 |
2.3 |
|
- |
2.3 |
4.2 |
4.2 |
|
|
|
-HFRF2 |
1.5 |
2.3 |
2.4 |
2.4 |
|
2.4 |
2.4 |
4.2 |
4.2 |
General Specifications
|
Item |
|
General Specifications |
|
|
Control method |
|
Line-to-line sine wave pulse-width modulation (PWM) control |
|
|
Output frequency range *5 |
|
0.5 to 400Hz |
|
|
Frequency accuracy *6 |
|
Digital command :±0.01%, Analog command±0.4% (25 ±10˚C) |
|
|
Frequency setting resolution |
Digital: 0.1Hz, Analog: (max frequency)/1000 |
||
Control |
Voltage/Frequency Characteristic |
V/f control,V/f variable (constant torque, reduced torque) |
||
Acceleration/deceleration time |
0.01 to 3000 sec. (linear, sigmoid), two-stage accel./decel. |
|||
|
||||
|
Starting torque *7 |
|
100%/6Hz |
|
|
Carrier frequency range |
|
2.0 to 12kHz |
|
|
Protective functions |
|
Over-current, over-voltage, under-voltage, overload, overheat, ground fault at power-on, input over-voltage, external trip, EEPROM error, |
|
|
|
CPU error, USP error, Termister error, Driver error, Safety stop |
||
|
|
|
||
|
Specification |
|
10kohm input impedance, sink/source logic selectable |
|
|
|
|
FW(Forward), RV(Reverse), CF1-CF4(Multispeed command), JG(Jogging), DB(External DC braking), SET(Second motor constants setting), |
|
Input terminal |
|
|
2CH(Second accel./decel.), FRS(Free-run stop), EXT(External trip), USP(Unattended start protection), SFT(Software lock), AT(Analog input |
|
Functions |
|
selection), RS(Reset), PTC(Thermistor input) *8, STA(3-wire start), STP(3-wire stop), F/R(3-wire fwd./rev.), PID(PID On/Off), PIDC(PID reset), |
||
|
|
|||
|
|
|
UP/DWN(Remote-controlled accel./decel.) , UDC(Remote-controlled data clearing), OPE(Operator control), ADD(ADD frequency enable), F- |
|
|
|
|
TM(force terminal mode), RDY(quick start enable),S-ST(Special-Set 2nd Motor Data),EMR(Safety stop), NO(Not selected) |
|
|
|
Specification |
27V DC 50mA max open collector output, 1 terminals 1c output 250V AC/30V DC 2.5A relay (AL0, AL1, AL2 terminals) |
|
|
Intelligent output terminal |
|
RUN(run signal), FA1(Frequency arrival type 1 - constant speed), FA2(Frequency arrival type 2 - over-frequency), OL(overload advance |
|
|
Function |
notice signal), OD(Output deviation for PID control), AL(alarm signal), DC(Wire brake detect on analog input), FBV(PID Second Stage |
||
Output signal |
|
|||
|
|
Output), NDC(ModBus Network Detection Signal), LOG(Logic Output Function), ODC(Option Card Detection Signal), LOC(Low load) |
||
|
|
|
||
|
Analog output terminal |
Specification |
0 to 10V DC |
|
|
Function |
Analog Frequency monitor, analog current monitor |
||
|
|
|||
|
|
Specification |
4-digits 7 segment LEDs |
|
Operator |
Display |
Function |
Parameter setting, output frequency, output current, scaled value of output frequency, trip history, I/O terminal condition, output |
|
|
voltage. Rotation direction, PID Feedback, RON time, Power-on time. |
|||
|
|
|
||
|
Status LED Interface |
|
Power, Alarm, Run, Prg, Hz and A Potentiometer, RUN, STOP/RESET, UP, DOWN, FUN and STR keys |
|
|
|
Operator keypad |
Up and Down keys / Value settings or analog setting via potentiometer on operator keypad |
|
|
Frequency setting |
External signal |
0 to 10 V DC, 4 to 20 mA |
|
Operation |
|
Serial port |
RS485 interface (Modbus RTU) |
|
|
Operator Keypad |
Run key / Stop key (change FW/RV by function command) |
||
|
|
|||
|
FW/RV Run |
External signal |
FW Run/Stop (NO contact), RV set by terminal assignment (NC/NO), 3-wire input available |
|
|
|
Serial port |
RS485 interface (Modbus RTU) |
|
|
Operating temperature |
|
-10 to 50˚C(carrier derating required for aambient temperature higher than 40°C), no freezing |
|
|
Storage temperature |
|
-20 to 65˚C |
|
Environment |
Humidity |
|
20 to 90% RH |
|
|
Vibration |
|
5.9mm/s2 (0.6G) 10 to 55Hz |
|
|
Location |
|
Altitude 1,000 m or less, indoors (no corrosive gasses or dust) |
|
|
Other functions |
|
AVR (Automatic Voltage Regulation), V/f characteristic selection, accel./decel. curve selection, frequency upper/lower limit, 16 stage |
|
|
|
multispeed, PID control, frequency jump, external frequency input bias start/end, jogging, cooling fan On/Off, trip history etc. |
||
|
|
|
||
|
Coating color |
|
Blue |
|
|
Options |
|
Remote operator with copy function (SRW-0EX), input/output reactors, DC reactors, radio noise filters, braking resistors, braking units, LCR filter, communication cables (ICS-1, 3) |
|
Note 1: The applicable motor refers to Hitachi standard 3-phase motor (4-pole). When using other motors, care must be |
|
taken to prevent the rated motor current (50/60 Hz) from exceeding the rated output current of the inverter. |
|
Note 2: The output voltage decreases as the main supply voltage decreases (except when using the AVR function). In |
|
any case, the output voltage cannot exceed the input power supply voltage. |
|
Note 3: The braking torque via capacitive feedback is the average deceleration torque at the shortest |
|
deceleration (stopping from 50/60 Hz as indicated). It is not continuous regenerative braking torque. |
3 |
The average decel torque varies with motor loss. This value decreases when operating beyond 50 Hz. |
If a large regenerative torque is required, the optional regenerative braking resistor should be used. |
Note 4: The protection method conforms to JEM 1030.
Note 5: To operate the motor beyond 50/60 Hz, consult the motor manufacturer for the maximum allowable rotation speed.
Note 6: The output frequency may exceed the maximum frequency setting (A004 or A204) for automatic stabilization control.
Note 7: At the rated voltage when using a Hitachi standard 3-phase, 4pole motor.
Note 8: Only terminal 5 is assignable the PTC (thermistor) function.
Dimensions
● X200-002SFEF2, NFU2, LFRF2
80(3.15)
67(2.64)
5(0.20)
6(0.24) |
143(5.63) |
155(6.10) |
|
|
|
|
|
|
Wall |
||
|
|
|
|
|
|
|
5(0.20) |
|
4.4(0.17) |
|
|
|
|
|
|
|
|
|
|
13(0.51) |
93(3.66) |
|
|
|
2.6(0.10) |
|
|
|
|
● X200-007LFRF2 |
80(3.15) |
|
|
|
|
|
67(2.64) |
|
|
|
|
5(0.20) |
|
|
|
|
|
6(0.24) |
|
143(5.63) |
155(6.10) |
|
|
|
|
|
Wall |
||
|
|
|
|
|
|
|
5(0.20) |
|
4.4 |
(0.17) |
|
|
|
|
|
||
|
2.6(0.10) |
50(1.97) |
|
130(5.12) |
|
● X200-011SFEF2 |
● X200-015 022SFEF2, NFU2 |
||||
● X200-037LFU2 |
● X200-007~040HFEF2, HFU2 |
||||
● X200-015~037LFRF2 ● X200-007~037HFRF2 |
|||||
110(4.33) |
|
|
|
|
|
98(3.86) |
|
|
|
Exhaust |
|
5(0.20) |
|
|
|
||
|
|
|
|
||
6(0.24) |
176(6.93) |
189(7.44) |
|
|
Wall |
|
5(0.20) |
4.4 (0.17) |
Air Intake |
||
|
|
55(2.17) |
155(6.10) |
011SFEF2,007HFEF2,HFU2: |
|
|
|
without FAN |
|||
|
6(0.24) |
|
|
|
|
|
|
|
[Unit: mm(inch)] |
● X200-004SFEF2, NFU2, LFRF2 |
|
Inches for reference only |
|
|
|
||
80(3.15) |
|
|
|
67(2.64) |
|
|
|
5(0.20) |
|
|
|
6(0.24) |
155(6.10) |
|
|
143(5.63) |
|
Wall |
|
5(0.20) |
|
4.4(0.17) |
|
|
|
|
|
|
27(1.06) |
107(4.21) |
|
2.6(0.10) |
|
|
|
● X200-005SFEF2 |
|
|
● X200-007SFEF2,NFU2 |
● X200-004HFEF2,HFU2, HFRF2 |
|
|
|
110(4.33) |
|
|
|
98(3.86) |
|
|
|
5(0.20) |
|
|
|
6(0.24) |
176(6.93) |
189(7.44) |
|
|
Wall |
||
|
|
|
|
5(0.20) |
|
4.4 |
(0.17) |
|
|
||
|
|
28(1.10) |
128(5.04) |
|
2.6(0.10) |
|
|
● X200-055~075LFU2,LFRF2 ● X200-055~075HFEF2,HFU2,HFRF2
180(7.09) 2-φ6(0.24) 164(6.46)
235(9.25) |
250(9.84) |
Wall |
6(0.24) |
|
4.4(0.17) |
|
|
|
165(6.50) |
|
|
4
