DS-2CD2543G0-I(W)(S)
4 MP IR Fixed Mini Dome Network Camera
High quality imaging with 4 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong back light due to 120 dB true
WDR technology
Water and dust resistant (IP66) and vandal proof (IK08)
-W: Wi-Fi connection
-S: build-in microphone, audio and alarm interface
available
Mini size suitable for limited space
Specification
Camera
Image Sensor
1/3" Progressive Scan CMOS
Min. Illumination
Color: 0.018 lux @(F1.6, AGC ON), 0 lux with IR
Shutter Speed
1/3 s to 1/100,000 s
Slow Shutter
Yes
Day &Night
IR Cut Filter
Wide Dynamic Range
120 dB
Angle Adjustment
Pan: -30° to 30°, tilt: 0° to 75°, rotate: 0° to 360°
DNR
3D DNR
Lens
Lens
2.8, 4, 6 mm
Aperture
F1.6
FOV
2.8 mm, horizontal FOV: 98°, vertical FOV: 55°, diagonal FOV: 114°
4 mm, horizontal FOV: 78°, vertical FOV: 42°, diagonal FOV: 93°
6 mm, horizontal FOV: 48°, vertical FOV: 27°, diagonal FOV: 54°
Lens Mount
M12
Illuminator
IR Range
Up to 10 m
Wavelength
850 nm
Video
Max. Resolution
2688 × 1520
Main Stream
50Hz: 25 fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz: 30 fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720)
Sub Stream
50Hz: 25 fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30 fps (640 × 480, 640 × 360, 320 × 240)
Third Stream
50Hz: 25 fps (1280 × 720, 640 × 360, 352 × 288)
60Hz: 30 fps (1280 × 720, 640 × 360, 352 × 240)
Video Compression
Main stream: H.265/H.264
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
H.264 Type
Main Profile/High Profile
H.265 Type
Main Profile
Video Bit Rate
32 Kbps to 16 Mbps
SVC
Support H.264 and H.265 encoding
Audio
Audio Compression
G722.1/G711ulaw/G711alaw/G726/MP2L2/PCM
Audio Bit Rate
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)
Environment Noise Filtering
Yes
Audio Sampling Rate
16 kHz, 32kHz, 44.1kHz, 48kHz
Image Enhancement
BLC/3D DNR/HLC
Image Setting
Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable
by client software or web browser
Day/Night Switch
Auto/Schedule/Day/Night/Triggered by Alarm In (-S model)
Wi-Fi
Frequency
2.412 GHz to 2.4835 GHz
Channel Bandwidth
20 MHz/40 MHz
Security
WPA, WPA2
Transfer Rate
11b: 11 Mbps
11g: 54 Mbps
11n: up to 150 Mbps
Wireless Range
Up to 50 m (The performance varies based on actual environment)
Wireless Standards
IEEE 802.11b/g/n
Network
Network Storage
Support MicroSD/SDHC/SDXC card (128 GB), local storage and NAS (NFS, SMB/CIFS),
ANR
Protocols
802.11b: DQPSK, DBPSK, CCK
802.11g/n: OFDM /64-QAM,16-QAM, QPSK, BPSK
API
ONVIF (PROFILE S, PROFILE G), ISAPI
Simultaneous Live View
Up to 6 channels
User/Host
Up to 32 users. 3 levels: administrator, operator and user
Client
Wired network: Hik-Connect, iVMS-4200, Hik-Central
Wi-Fi: iVMS-4200, Hik-Central
Web Browser
Plug-in required live view: IE8+, Chrome 41.0-44, Firefox 30.0-51, Safari 8.0-11
Plug-in free live view: Chrome 45.0+, Firefox 52.0+
Alarm Trigger
Motion detection, video tampering, network disconnected, IP address conflict, HDD
full, HDD error, illegal login
Interface
Communication Interface
1 RJ45 10M/100M self-adaptive Ethernet port
Audio
2 Inputs: line in, or mic in (built-in microphone)
1 Output: line out, mono sound, terminal block
Alarm
1 Input: Alarm in
1 Output: Alarm out (max. 12 VDC, 30 mA), terminal block
On-board Storage
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
General
General Function
One-key reset, anti-flicker, three streams, heartbeat, mirror, password protection,
privacy mask, watermark, IP address filter
Firmware Version
V5.6.5
Reset
Yes
Startup and Operating
Conditions
-30 °C to +60 °C (-22 °F to +140 °F), humidity 95% or less (non-condensing)
Power Supply
12 VDC ± 25%, PoE (802.3af, class 3)
Power Consumption and
Current
12 VDC, 0.7 A, max. 8.5 W, Ø 5.5mm coaxial plug power; PoE (802.3af, 36 V to 57 V),
0.3 A to 0.1 A, max. 10 W
Material
Front cover: plastic, bottom base: metal
Dimensions
Ø 110 mm × 56.4 mm (Ø 4.3" × 2.2")
Weight
Camera: Approx. 400 g (0.9 lb.)
Approval
Protection
Ingress protection: IP66 (IEC 60529-2013), IK08 (IEC 60529-2013)
Compression Standard
H.264+
Main stream supports
H.265+
Main stream supports
Smart Feature-set
Face Detection
Yes
Dimension
Accessory
DS-1275ZJ-SUS
DS-1272ZJ-120B
DS-1271ZJ-120
Vertical Pole Mount
Wall Mount
Pendant Mount
DS-1280ZJ-DM46
DS-1272ZJ-120
DS-1276ZJ-SUS
Junction Box
Wall Mount
Corner Mount
Available Model
DS-2CD2543G0-I (2.8 mm, 4 mm, 6 mm)
DS-2CD2543G0-IS (2.8 mm, 4 mm, 6 mm)
DS-2CD2543G0-IW (2.8 mm, 4 mm, 6 mm)
DS-2CD2543G0-IWS (2.8 mm, 4 mm, 6 mm)
05060520200508
