SPECIFICATION DRAWING
Collection:
GEM
6
5.0
5
16
Product #:
"
HANDBLOWN
IDB0039-18
GLASS GEM
9.1
12.0
17.9
**NOTE**
DRIVER TO BE INSTALLED IN JUNCTION BOX.
MINIMUM SIZE J-BOX REQUIRED IS
4" L X 4" W X 1.5" D
All dimensions are shown in inches unless otherwise stated.
Visit
hammertonstudio.com
Mounting Packet:
UL Location:
Finish:
SEE WEBSITE FOR OPTIONS
Top Diffuser:
Bottom Diffuser:
All Hammerton fixtures are handcrafted by artisans. Subtle imperfections reflect the mark of the
artisan and should be expected in any handcrafted product. Dimensions may vary up to 7/8".
© Copyright 2020. All rights in design, detail or invention of this drawing are reserved as the property of
Hammerton. Any imitation or adaptation without written consent is strictly prohibited.
Hammerton Inc. 217 Wright Brothers Dr. Salt Lake City, UT 84116 (801)973-8095
N
DRY
N/A
CLOSED GLASS
Weight(lbs.):
for product options.
6
Electrical Type:
Elec. Qty:
Source Lumens:
Dimmable:
CRI:
93+
CCT:
LED
Wattage:
12
UP:
Forward/Reverse Phase To 1%
Power Factor:
2700K OR 3000K
5.2
Voltage:
N/A
Down:
>0.9
2.7
TO CENTER
OF J-BOX
HANDBLOWN GLASS DIMENSIONS
Canopy Mounting Detail
120
340
MOUNTS DIRECTLY TO J-BOX
MAY VARY
6.6
1
1"
1
6.1
8/28/2020
3.5 2.8
A
