NOTEBOOK
REFERENCEGUIDE
®
Chapter 1: About This Reference. . . . . . . . . . . . 1
About this guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Accessing your online User Guide . . . . . . . . . . . . . . . . . . . . . 2 Gateway contact information . . . . . . . . . . . . . . . . . . . . . . . . . 3 Gateway model and serial number . . . . . . . . . . . . . . . . . 3 Microsoft Certificate of Authenticity . . . . . . . . . . . . . . . . . . . 3 For more information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Chapter 2: Checking Out Your Notebook . . . . . 5
Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Left . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Right . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Bottom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Keyboard area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Chapter 3: Setting Up and Getting Started . . 13
Working safely and comfortably . . . . . . . . . . . . . . . . . . . . . 14 Reducing eye strain . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Setting up your computer desk and chair . . . . . . . . . . . 15 Sitting at your notebook . . . . . . . . . . . . . . . . . . . . . . . . . 15 Avoiding discomfort and injury from repetitive strain . 15
Connecting the AC adapter . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Protecting from power source problems . . . . . . . . . . . 18 Connecting the dial-up modem . . . . . . . . . . . . . . . . . . . . . . 18 Connecting to a broadband modem or network . . . . . . . . 19 Starting your notebook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Waking up your notebook . . . . . . . . . . . . . . . . . . . . . . . 21 Turning off your notebook . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Restarting (rebooting) your notebook . . . . . . . . . . . . . . . . . 22 Using the status indicators . . . . . . . . . . . . . . . . . . . . . . . . . . 23 Using the keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Key types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 System key combinations . . . . . . . . . . . . . . . . . . . . . . . . 27
i
Contents
Using the EZ Pad touchpad . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Adjusting brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 Adjusting the volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 Turning your wireless radio on or off . . . . . . . . . . . . . . . . . 33 IEEE 802.11 wireless network radio . . . . . . . . . . . . . . . . 34
Chapter 4: Using Drives and Accessories. . . . . 35
Using the CD or DVD drive . . . . . . . . . . . . . . . . . . . . . . . . . . 36 Identifying drive types . . . . . . . . . . . . . . . . . . . . . . . . . . 36 Using a CD or DVD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 Using the memory card reader . . . . . . . . . . . . . . . . . . . . . . 38 Memory card types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39 Inserting a memory card . . . . . . . . . . . . . . . . . . . . . . . . 39 Using a memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . 39 Removing a memory card . . . . . . . . . . . . . . . . . . . . . . . 39 Adding and removing an Express Card . . . . . . . . . . . . . . . . 40 Installing a printer or other peripheral device . . . . . . . . . . 41 Connecting a USB device . . . . . . . . . . . . . . . . . . . . . . . . 41 Viewing the display on a projector or monitor . . . . . . . . . . 42 Adjusting the display properties . . . . . . . . . . . . . . . . . . 42 Using the projector or monitor for a presentation . . . . 44 Ordering accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Chapter 5: Managing Power. . . . . . . . . . . . . . . 47
Monitoring the battery charge . . . . . . . . . . . . . . . . . . . . . . . 48 Recharging the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48 Changing the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49 Replacing the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . 49 Recalibrating the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 Getting the most from your battery . . . . . . . . . . . . . . . . . . 51 Maximizing battery performance . . . . . . . . . . . . . . . . . . 51 Conserving battery power . . . . . . . . . . . . . . . . . . . . . . . 51 Using alternate power sources . . . . . . . . . . . . . . . . . . . 52 Changing power modes . . . . . . . . . . . . . . . . . . . . . . . . . 52 Changing notebook power settings . . . . . . . . . . . . . . . . . . . 54 Changing the power plan . . . . . . . . . . . . . . . . . . . . . . . . 54 Changing advanced settings . . . . . . . . . . . . . . . . . . . . . 55
ii
www.gateway.com |
|
Chapter 6: Traveling with Your Notebook |
. . . 57 |
Packing your notebook . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 58 |
Traveling by air . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 58 |
Dial-up modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 58 |
Radio frequency wireless connections . . . . . . . . . . . . . |
. . . . 59 |
Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 59 |
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 60 |
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 61 |
Additional tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 61 |
Chapter 7: Maintaining Your Notebook . . . . . 63 |
|
Caring for your notebook . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 64 |
Cleaning your notebook . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 65 |
Cleaning the exterior . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 65 |
Cleaning the keyboard . . . . . . . . . . . . . . . . . . . . . . |
. . . . 66 |
Cleaning the notebook screen . . . . . . . . . . . . . . . . |
. . . . 66 |
Maintaining the battery . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 66 |
Storing batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 67 |
Cleaning CDs or DVDs . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 68 |
Recovering your system . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 68 |
Recovering pre-installed software and drivers . . . |
. . . . 69 |
Using Microsoft System Restore . . . . . . . . . . . . . . |
. . . . 75 |
Recovering your system to its factory condition |
. . . . . 78 |
Recovering your system using the Windows DVD |
. . . . 79 |
Chapter 8: Upgrading Your Notebook. . . . . |
. . 81 |
Preventing static electricity discharge . . . . . . . . . . . . . |
. . . . 82 |
Adding or replacing memory modules . . . . . . . . . . . . |
. . . . 83 |
Replacing the hard drive kit . . . . . . . . . . . . . . . . . . . . . |
. . . . 86 |
Chapter 9: Troubleshooting . . . . . . . . . . . . . |
. . 89 |
Safety guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 90 |
First steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 90 |
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 91 |
Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 91 |
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 91 |
CD drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 91 |
iii
Contents
Diskette drive (external) . . . . . . . . . . . . . . . . . . . . . . . . . 92 Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92 DVD drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94 Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95 Express cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95 File management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96 Hard drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96 Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97 Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98 Media Center . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99 Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102 Memory card reader . . . . . . . . . . . . . . . . . . . . . . . . . . . 102 Modem (cable or DSL) . . . . . . . . . . . . . . . . . . . . . . . . . . 102 Modem (dial-up) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103 Mouse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106 Networks (wired) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107 Networks (wireless) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108 Passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110 Pointing device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111 Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111 Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112 Sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113 Status indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113 Touchpad or pointing device . . . . . . . . . . . . . . . . . . . . 114 Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Telephone support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114 Before calling Gateway Customer Care . . . . . . . . . . . . 114
Appendix A: Legal Information . . . . . . . . . . . . . 117
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
iv
CHAPTER1
•About this guide
•Accessing your online User Guide
•Gateway contact information
•Microsoft Certificate of Authenticity
•For more information
1
CHAPTER 1: About This Reference
This guide includes information and maintenance instructions that are specific to your model of Gateway notebook. For all other notebook information, see your online User Guide.
In addition to this guide, your online User Guide has been included on your hard drive. Your User Guide is an in-depth, easy-to-read manual that includes information on the following topics:
•Help and technical support
•Using and customizing Windows and other software
•Using the Internet
•Protecting your files
•Playing and recording media
•Networking
To access your online User Guide:
•Click (Start), All Programs, then click Gateway Documentation.
2
www.gateway.com
Important
The labels shown in this section are for informational purposes only. Label information varies by model, features ordered, and location.
The label on the bottom of your notebook contains information that identifies your notebook model and its features. Gateway Customer Care will need this information if you call for assistance.
Online Support:
Tech Support Phone:
Hours:
Model:
S/No:
Microsoft Certificate of
Authenticity
The Microsoft Certificate of Authenticity label found on the bottom of your notebook includes the product key code for your operating system.
For more information about your notebook, visit Gateway’s Support page at www.gateway.com or the Web address shown on your notebook’s label. The Support page also has links to additional Gateway documentation and detailed specifications.
3
CHAPTER 1: About This Reference
4
CHAPTER2
•Front
•Left
•Right
•Back
•Bottom
•Keyboard area
5
CHAPTER 2: Checking Out Your Notebook
LCD panel release latch
Speaker |
Microphone Headphone Power Battery |
Speaker |
|||||
|
jack jack |
indicator charge |
|
||||
|
|
|
|
|
|
indicator |
|
|
|
|
|
|
|
|
|
Component |
Icon |
Description |
|
||||
|
|
|
|
|
|
||
LCD panel release |
Press to open the LCD panel. |
|
|||||
latch |
|
|
|
|
|
|
|
Speakers |
|
|
|
|
Provide audio output when headphones or |
||
|
|
|
|
|
amplified speakers are not plugged in. |
||
|
|
|
|
|
|
||
Microphone jack |
|
|
|
Plug a microphone into this jack. |
|
||
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Headphone jack |
Plugamplifiedspeakers orheadphones into this |
||||||
|
|
|
|
|
jack. The built-in speakers are turned off when |
||
|
|
|
|
|
speakers or headphones are plugged into this |
||
|
|
|
|
|
jack. |
|
|
|
|
|
|
|
|
|
|
Power indicator |
|
|
■ |
LED on - Notebook is on. |
|
||
|
|
||||||
|
|
|
|
|
■ |
LED blinking - Notebook is in Sleep or Hybrid |
|
|
|
|
|
|
|
Sleep mode. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
■ |
LED off - Notebook is off. |
|
|
|
|
|
|
|
|
|
Battery charge indicator
■LED blue - Battery is fully charged.
■LED purple - Battery is charging.
■LED blinking red - Battery charge is very low.
■LED solid red - Battery is malfunctioning. Important: This LED only lights up when your notebook is connected to AC power or the battery charge is very low.
6
www.gateway.com
|
Ventilation fan |
USB ports |
Express Card |
Memory card |
|
|
|
|
slot |
reader |
|
|
|
|
|
||
|
|
|
|
|
|
Component |
Icon |
Description |
|
|
|
|
|
|
|||
Ventilation fan |
|
Helps cool internal components. |
|||
|
|
Warning: Do not work with the notebook |
|||
|
|
resting on your lap. If the air vents are blocked, |
|||
|
|
the notebook may become hot enough to harm |
|||
|
|
your skin. |
|
|
|
|
|
Caution: Do not block or insert objects into |
|||
|
|
these slots. If these slots are blocked, your |
|||
|
|
notebookmayoverheatresultinginunexpected |
|||
|
|
shutdown or permanent damage to the |
|||
|
|
notebook. |
|
|
|
|
|
Caution: Provide adequate space around your |
|||
|
|
notebook so air vents are not obstructed. Do |
|||
|
|
not use the notebook on a bed, sofa, rug, or |
|||
|
|
other similar surface. |
|
|
|
USB ports |
|
Plug USB devices (such as a diskette drive, flash |
|||
|
|
drive, printer, scanner, camera, keyboard, or |
|||
|
|
||||
|
|
mouse) into these ports. |
|
||
|
|
|
|||
Express Card slot |
|
Insert one Type 54 Express Card into this slot. |
|||
|
|
For more information, see “Adding and |
|||
|
|
removing an Express Card” on page 40. |
|||
Memory card |
|
Insert a memory card from a digital camera, |
|||
reader |
|
MP3 player, PDA, or cellular telephone into the |
|||
|
|
memory card reader. For more information, see |
|||
|
|
“Using the memory card reader” on page 38. |
|||
|
|
The memory card reader supports Memory |
|||
|
|
Stick®, Memory Stick Pro®, Mini Secure |
|||
|
|
Digital®, MultiMediaCard™, |
|
||
|
|
RS-MultiMediaCard™, and Secure Digital™ |
|||
|
|
cards. |
|
|
|
|
|
|
|
|
|
7
CHAPTER 2: Checking Out Your Notebook
CD or DVD drive |
Ethernet |
Modem Monitor port |
|
jack |
jack |
Component |
Icon |
Description |
|||||
|
|
|
|
|
|
|
|
CD or DVD drive |
|
|
|
|
|
|
Insert CDs or DVDs into this drive. For more |
|
|
|
|
|
|
|
information, see “Using the CD or DVD drive” on |
|
|
|
|
|
|
|
page 36. To determine the type of drive in your |
|
|
|
|
|
|
|
notebook, examinethedrivetray’splasticcover |
|
|
|
|
|
|
|
and compare the logo to those listed in |
|
|
|
|
|
|
|
“Identifying drive types” on page 36. |
Ethernet jack |
|
|
|
|
|
|
Plug an Ethernet network cable into this jack. |
|
|
|
|
|
|
|
The other end of the cable can be plugged into |
|
|
|
|
|
|
|
a cable modem, DSL modem, or an Ethernet |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
network jack. For more information, see |
|
|
|
|
|
|
|
“Connecting to a broadband modem or |
|
|
|
|
|
|
|
network” on page 19. |
|
|
|
|
|
|
|
|
Modem jack |
|
|
|
|
|
|
Plug a dial-up modem cable into this jack. For |
|
|
|
|
|
|
|
more information, see “Connecting the dial-up |
|
|
|
|
|
|
|
modem” on page 18. |
Monitor port |
|
|
|
|
|
|
Plug an analog VGA monitor or projector into |
|
|
|
|
|
|
|
this port. For more information, see “Viewing |
|
|
|
|
|
|
|
the display on a projector or monitor” on |
|
|
|
|
|
|
|
page 42. |
|
|
|
|
|
|
|
|
8
www.gateway.com
Power connector |
|
|
|
|
|
|
Kensington lock slot |
|
|
|
|
|
|
|
|
Component |
Icon |
Description |
|||||
|
|
|
|
|
|
|
|
Power connector |
|
|
|
|
|
|
Plug the AC adapter cable into this connector. |
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
Kensington™ |
|
|
|
|
|
|
Secure your notebook to an object by |
lock slot |
|
|
|
|
|
|
connecting a Kensington cable lock to this slot. |
|
|
|
|
|
|
|
|
9
CHAPTER 2: Checking Out Your Notebook
Hard drive bay
Memory bay
Customer care/ |
|
|
|
|
|
|
system label |
|
|
|
|
|
Battery latch |
|
|
|
|
|
|
|
Battery lock |
|
|
|
|
|
|
|
|
|
|
|
|
Battery |
|
|
|
|
|
|
|
Component |
Icon |
|
Description |
|||
|
|
|
|
|
|
|
Battery lock |
|
|
|
|
|
Slide to unlock the battery. For more information, see |
|
|
|
|
|
|
“Changing the battery” on page 49. |
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
|
|
Customer |
|
|
|
|
|
Includes the Customer Care contact information. For |
Care label |
|
|
|
|
|
more information, see “Gateway contact information” |
|
|
|
|
|
|
on page 3. |
|
|
|
|
|
|
|
Memory bay |
|
|
|
|
|
Install a memory module into this bay. For more |
|
|
|
|
|
|
information, see “Adding or replacing memory |
|
|
|
|
|
|
modules” on page 83. |
|
|
|
|
|
|
|
Hard drive |
|
|
|
|
|
The hard drive is located in this bay. For more |
bay |
|
|
|
|
|
information, see “Replacing the hard drive kit” on |
|
|
|
|
|
|
page 86. |
|
|
|
|
|
|
|
Battery latch |
|
|
|
|
|
Slide to release the battery. For more information, see |
|
|
|
|
|
|
“Changing the battery” on page 49. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Battery |
|
|
|
|
|
Provides power when the notebook is not plugged |
|
|
|
|
|
|
into AC power. |
|
|
|
|
|
|
|
10
www.gateway.com
Power button
Keyboard
|
|
Touchpad Status indicators |
|
|
|
Component |
Icon |
Description |
|
|
|
Keyboard |
|
Provides all the features of a full-sized, computer |
|
|
keyboard. For more information, see “Using the |
|
|
keyboard” on page 25. |
Power button |
|
Press to turn the power on or off. You can also |
|
|
configure the power button for Sleep/Resume mode. |
|
|
For more informationon configuring the power button |
|
|
mode, see “Changing advanced settings” on page 55. |
|
|
|
Status |
|
Inform you when a drive is in use or when a button |
indicators |
|
has been pressed that affects how the keyboard is |
|
|
used. For more information, see “Using the status |
|
|
indicators” on page 23. |
Touchpad |
|
Provides all the functionality of a mouse. For more |
|
|
information, see “Using the EZ Pad touchpad” on |
|
|
page 29. |
|
|
|
11
CHAPTER 2: Checking Out Your Notebook
12
CHAPTER3
•Working safely and comfortably
•Connecting the AC adapter
•Connecting the dial-up modem
•Connecting to a broadband modem or network
•Starting your notebook
•Turning off your notebook
•Restarting (rebooting) your notebook
•Using the status indicators
•Using the keyboard
•Using the EZ Pad touchpad
•Adjusting brightness
•Adjusting the volume
•Turning your wireless radio on or off
13
CHAPTER 3: Setting Up and Getting Started
Before using your notebook, follow these general guidelines for setting up a safe and comfortable work area and avoiding discomfort and strain:
•Keep hands and arms parallel to the floor.
•Adjust the screen so it is perpendicular to your line of sight.
•Place your feet flat on the floor or on a footrest.
•Although notebooks are sometimes called “laptops,” do not use your notebook while it rests on your unprotected lap. Notebook operating temperatures can become quite high, increasing the risk of burns to your legs. Instead, use a laptop desk to protect your legs.
•Do not use the notebook on any soft, conforming surface, such as your lap, a blanket, carpet, or a sofa. Soft surfaces can block your notebook’s ventilation openings, leading to overheating, permanent damage to your notebook, and fire danger. Instead, place your notebook on a rigid, hard surface, and make sure that you keep the ventilation openings on the sides clear.
Warning
Do not use your notebook on a soft surface, such as your lap, a blanket, carpet, or a sofa. You must keep your notebook’s ventilation openings clear of obstructions, or your notebook may overheat, increasing the risk of fire and personal injury.
Sunlight or bright indoor lighting should not reflect on the screen or shine directly into your eyes.
•Position the computer desk and screen so you can avoid glare on your screen and light shining directly into your eyes. Reduce glare by installing shades or curtains on windows, and by installing a glare screen filter.
•Use soft, indirect lighting in your work area. Do not use your notebook in a dark room.
•Avoid focusing your eyes on your screen for long periods of time. Every 10 or 15 minutes, look around the room, and try to focus on distant objects.
•Where feasible, keep your head vertical while looking at the screen. If you use an external keyboard, raise the notebook so the top of its screen is no higher than eye level.
14
www.gateway.com
When you are setting up your computer desk and chair, make sure that the desk isthe appropriate height and the chair helps you maintain good posture.
•Select a flat surface for your computer desk.
•Adjust the height of the computer desk so your hands and arms are positioned parallel to the floor when you use the keyboard and touchpad. If the desk is not adjustable or is too tall, consider using an adjustable chair to control your arm’s height above the keyboard.
•Use an adjustable chair that is comfortable, distributes your weight evenly, and keeps your body relaxed.
•Position your chair so the keyboard is at or slightly below the level of your elbow. This position lets your shoulders relax while you type.
•Adjust the chair height, adjust the forward tilt of the seat, or use a footrest to distribute your weight evenly on the chair and relieve pressure on the back of your thighs.
•Adjust the back of the chair so it supports the lower curve of your spine. You can use a pillow or cushion to provide extra back support.
•Avoid bending, arching, or angling your wrists. Make sure that they are in a relaxed position when you type.
•Do not slouch forward or lean far back. Sit with your back straight so your knees,hips, and elbowsform right angles when you work.
•Take breaks to stand and stretch your legs.
•Avoid twisting your torso or neck.
•Vary your activities to avoid excessive repetition.
•Take breaks to change your position, stretch your muscles, and relieve your eyes.
•Find ways to break up the work day, and schedule a variety of tasks.
15
CHAPTER 3: Setting Up and Getting Started
You can run your notebook using an AC adapter or your notebook’s battery. The battery was shipped to you partially charged. You should use the AC adapter right away to fully charge the battery. Allow three hours for the battery to fully charge.
Warning
Do not attempt to disassemble the AC adapter. The AC adapter has no user-replaceable or user-serviceable parts inside. The AC adapter has dangerous voltages that can cause serious injury or death. Contact Gateway about returning defective AC adapters.
Caution
Make sure that you use the AC adapter that came with your notebook or one of the same type purchased from Gateway. Replace the power cord if it becomes damaged. The replacement cord must be of the same type and voltage rating as the original cord or your notebook may be damaged.
Important
If the battery is not fully charged before you use your notebook on battery power for the first time, the battery life may be much shorter than you expect. If the battery life seems short even after being charged for three hours, the battery may need to be recalibrated. For information on recalibrating the battery, see “Recalibrating the battery” on page 50.
To connect the AC adapter:
1 Connect the power cord to the AC adapter.
16
www.gateway.com
2Connect the AC adapter to your notebook’s power connector.
3Plug the power cord into a wall outlet. The battery charge indicator turns on (see “Front” on page 6 for the location of the battery charge indicator). If the battery charge indicator does not turn on, complete the following steps until it turns on:
aUnplug the adapter from your notebook, then plug it back in.
bPress FN+F1 to toggle the status lights on and off.
4When you finish using your notebook for the first time, turn off your notebook and leave your notebook connected to AC power until the battery charge indicator turns blue.
Important
If the battery charge indicator does not turn blue after three hours, contact Gateway Customer Care at the location shown on the Customer Care label. For more information, see “Gateway contact information” on page 3.
17
CHAPTER 3: Setting Up and Getting Started
During a power surge, the voltage level of electricity coming into your notebook can increase to levels far above normal levels and cause data loss or system damage. Protect your notebook and peripheral devices by connecting them to a surge protector, which absorbs voltage surges and prevents them from reaching your notebook.
Warning
High voltages can enter your notebook through both the power cord and the modem connection. To protect your notebook and avoid electrical shock, use a surge protector. If you have a telephone modem, use a surge protector that has a modem jack. If you have a cable modem, use a surge protector that has an antenna/cable TV jack. During an electrical storm, unplug both the surge protector and the modem.
Your notebook has a built-in 56K modem that you can use to connect to a standard telephone line.
Warning
To reduce the risk of fire, use only No. 26 AWG or larger telecommunications line cord.
To connect the modem:
1Insert one end of the modem cable into the modem jack on your notebook.
2Insert the other end of the modem cable into a telephone wall jack.
Important
The modem will not work with digital or PBX telephone lines.
18
www.gateway.com
Your notebook has a network jack that you can use to connect to a cable or DSL modem or to a wired Ethernet network.
To connect to a cable or DSL modem or to a wired
Ethernet network:
1Insert one end of the network cable into the network jack on your notebook.
2Insert the other end of the network cable into a cable modem, DSL modem, or Ethernet network jack.
19
CHAPTER 3: Setting Up and Getting Started
Warning
Do not work with the notebook resting on your lap. If the air vents are blocked, the notebook may become hot enough to harm your skin.
Caution
Provide adequate space around your notebook so air vents are not obstructed. Do not use the notebook on a bed, sofa, rug, or other similar surface.
To start your notebook:
1Slide the latch on the front of your notebook, then lift the LCD panel.
2Press the power button located above the keyboard.
Power button
Tip
For more information about changing the power button mode, see “Changing advanced settings” on page 55.
3If you are starting your notebook for the first time, follow the on-screen instructions to select the language and time zone and to create your first user account.
4Attach and turn on any peripheral devices, such as printers, scanners, and speakers.
Tip
For more information about connecting peripheral devices, see “Installing a printer or other peripheral device” on page 41.
Tip
See the documentation that came with each device for its setup instructions.
20
www.gateway.com
5To open the main menu, click (Start). From that menu, you can run programs and search for files. For more information on using Windows, see “Using Windows” and “Customizing Windows” in your online
User Guide.
When you have not used your notebook for several minutes or if you close the LCD panel without turning off your notebook, it may enter a power-saving mode called Sleep. While in Sleep mode, the power indicator flashes. If your notebook is in Sleep mode, press the power button to “wake” it up.
Tip
For more information about Sleep mode, see “Changing power modes” on page 52.
Putting your notebook into Sleep mode is the easiest way to power down your notebook. Although it does not turn your notebook completely off, it turns off or slows down most system operations to save power. Sleep mode saves your desktop layout so the next time you restore power, the programs are laid out just as you left them. Waking your notebook from a Sleep state is much faster than turning on your notebook after it has been turned completely off.
Hibernate mode is an alternative to Sleep mode. In Hibernate mode, your notebook is turned completely off. When you wake your notebook from Hibernate mode, however, the programs that were running when your notebook entered Hibernate mode are running just as you left them.
To put your notebook to sleep:
•Click (Start), then click (power). The notebook saves your session and partially shuts down to save power.
-OR-
Press FN+F3.
Tip
You can change the Sleep mode from the standard Sleep mode (default) to Hybrid Sleep. For more information about Sleep mode, see “Changing power modes” on page 52.
21
CHAPTER 3: Setting Up and Getting Started
To put your notebook into hibernation:
•Click (Start), click the arrow next to the lock icon, then click Hibernate. The notebook saves your session and shuts down to save power.
To turn off your notebook:
•Click (Start), click the arrow next to the lock icon, then click Shut Down. The notebook turns off.
Important
If for some reason you cannot use the Shut Down option in Windows to turn off your notebook, press and hold the power button for about five seconds, then release it.
If your notebook does not respond to keyboard, touchpad, or mouse input, you may have to close programs that are not responding. If closing unresponsive programs does not restore your notebook to normal operation, you may have to restart (reboot) your notebook.
To close unresponsive programs on your notebook:
1Press CTRL+ALT+DEL.
2Click Start Task Manager. The Windows Task Manager dialog box opens.
3Click the program that is not responding.
4Click End Task.
5Click X in the top-right corner of the Windows Task Manager dialog box.
22
www.gateway.com
To restart your notebook:
•Click (Start), click the arrow next to the lock icon, then click Restart. The notebook turns off, then turns on again.
Important
If your notebook does not turn off immediately, complete the following steps until the notebook turns off:
1.Press and hold the power button for about five seconds, then release
it.
2.Unplug the power cord and remove the battery for more than 10 seconds.
Important
Status indicators vary by model and features ordered.
Important
If none of the indicators are on, you may need to press FN+F1 to toggle the status indicators on.
Status indicators inform you when a drive is being used or when a button has been pressed that affects how the keyboard is used. The status indicators are located below the touchpad.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Wireless network |
|
|
|
|
|
|
Hard drive |
||
|
|
|
|
|
|
Scroll |
|
lock |
|
|
|
Caps lock |
|
|
|
||||
|
|
|
|
|
|
|
|
||
|
|
|
|
Num |
|
lock |
|||
|
|
|
|
|
23
CHAPTER 3: Setting Up and Getting Started
Indicator |
Icon |
Description |
||
|
|
|
|
|
Wireless |
|
|
■ |
LED on - Wireless IEEE 802.11 radio is |
|
|
|||
network |
|
|
|
turned on. |
|
|
|
||
(optional) |
|
|
■ |
LED off - Wireless IEEE 802.11 radio is |
|
|
|
|
turned off. |
Caps lock |
|
|
■ |
LED on - Caps lock is turned on. |
|
|
A |
■ |
LED off - Caps lock is turned off. |
|
|
|
|
|
Num lock |
|
|
■ |
LED on - Numeric keypad is turned on. |
|
|
|||
|
|
1 |
■ |
LED off - Numeric keypad is turned off. |
|
|
|
|
|
Scroll lock |
|
|
■ |
LED on - Scroll lock is turned on. |
|
|
|
■ |
LED off - Scroll lock is turned off. |
|
|
|
|
|
Hard drive |
|
|
■ |
LED blinking - Hard drive is being |
|
|
|||
|
|
|
|
accessed. |
|
|
|
■ |
LED off - Hard drive is not being |
|
|
|
|
accessed. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Wireless network |
|
|
|
Hard drive |
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Caps |
lock |
|
Disc drive |
||
|
|
|
|
|
|
|
lock |
||
|
|
|
|
|
|
Num |
|||
|
|
|
|
|
|
|
|
|
|
Indicator |
Icon |
Description |
|||||||
|
|
|
|
|
|
|
|
|
|
Wireless |
|
|
|
|
■ |
LED on - Wireless IEEE 802.11 radio is |
|||
|
|
|
|
||||||
network |
|
|
|
|
|
turned on. |
|||
|
|
|
|
|
|||||
(optional) |
|
|
|
|
■ |
LED off - Wireless IEEE 802.11 radio is |
|||
|
|
|
|
|
|
turned off. |
|||
Caps lock |
|
|
|
|
■ |
LED on - Caps lock is turned on. |
|||
|
|
|
A |
■ |
LED off - Caps lock is turned off. |
||||
|
|
|
|
|
|
|
|
|
|
Num lock |
|
|
|
|
■ |
LED on - Numeric keypad is turned on. |
|||
|
|
|
|
||||||
|
|
1 |
|
■ |
LED off - Numeric keypad is turned off. |
||||
|
|
|
|
|
|
|
|
|
|
24
