GB
GARDENA EasyCut 400/25
Translation of the original German operating instructions.
Please read the operating instructions carefully and observe the notes given. Use these operating instructions to familiarise yourself with the product, the proper use and the safety instructions.
For safety reasons, children and young people under the age of 16, as well as people not familiar with these operating instructions, may not use this product. Persons with reduced physical or mental abilities may use the product only if they are
supervised or instructed by a responsible person. Children must be supervised to ensure that they do not play with the product. Never operate the product when you are tired, ill or under the influence of alcohol, drugs or medicine.
v Keep these operating instructions in a safe place.
Contents: |
1. |
Area of application of your GARDENA Turbotrimmer. . . . |
12 |
|
2. |
Safety Instructions. . . . . . . . . . . . . . . . . .12 |
|
|
3. |
Assembly. . . . . . . . . . . . . . . . . . . . . 14 |
|
|
4. |
Operation. . . . . . . . . . . . . . . . . . . . . 15 |
|
|
5. |
Putting into Storage. . . . . . . . . . . . . . . . . |
17 |
|
6. |
Maintenance . . . . . . . . . . . . . . . . . . . .17 |
|
|
7. |
Troubleshooting.. . . . . . . . . . . . . . . . . . |
19 |
|
8. |
Technical Data. . . . . . . . . . . . . . . . . . . 20 |
|
|
9. |
Service / Warranty. . . . . . . . . . . . . . . . . |
20 |
1. Area of application of your GARDENA Turbotrimmer
Purpose: |
The GARDENA Turbotrimmer is designed for trimming and cutting |
|
areas of grass and lawns in private house and hobby gardens. |
|
The Turbotrimmer must not be used in public facilities, parks, |
|
sports grounds, next to roads or in agriculture or forestry. |
Please note: |
|
For safety reasons, the GARDENA Turbotrimmer must |
|
|
not be used for hedge trimming or for shredding for |
|
composting. |
|
|
2. Safety Instructions
v Please read the notes on safety on the Trimmer.
CAUTION!
vPlease read the operating instructions before using this tool.
DANGER! Risk of electric shock!
vKeep your Turbotrimmer away from water and rain!
360° |
DANGER!
Risk of injury to other people!
vKeep other people out
of the area where you are working.
12
DANGER!
Eye and ear injuries!
v Wear eye and hearing protection!
v If the cable of the unit is
damaged, the unit must be
unplugged from the mains immediately.
Check your Trimmer before each use
vAlways visually inspect your Trimmer before each use.
vCheck that the ventilation slots are not obstructed in any way.
Do not use the trimmer if it is damaged or if
its safety devices (pressure switch, safety cover) and / or the filament cassette are damaged or worn.
vNever bypass the safety devices.
vInspect the area to be cut before you begin work. Remove any foreign objects and look out for foreign objects (such as stones, pieces of wood, strings and wires) while you are working.
vIf you should come across an obstacle while cutting, turn off the Trimmer and unplug the mains plug. Remove the obstacle; inspect the trimmer for potential damage and arrange for it to be repaired if necessary.
vShould the trimmer begin to vibrate abnor mally, please take it out of operation and pull the mains plug. Inspect the trimmer for potential damage and arrange for it to be repaired, if necessary.
Use / responsibility
DANGER!
Tool does not stop immedi ately when turned off!
vKeep hands and feet away from the work area until the cutting filament is stationary!
The Trimmer can cause serious injuries.
vUse the Trimmer only for the purpose specified in these operating instructions.
You are responsible for safety in the work area (2 metre radius).
vEnsure that no other people (especially children) and animals are in close proximity to the danger area (15 metre radius).
In order to prevent injuries due to an accidental start-up of the device as a result of a damaged
start button, third parties must stay clear of the device upon plugging it in.
Unplug the mains plug after use and regularly inspect the trimmer, especially the filament cassette, for damage and arrange appropriate repair if necessary.
vAlways wear an eye shield or safety goggles!
vWear sturdy shoes and long trousers to protect your legs. Keep your fingers and feet away from the cutting filament – above all when starting work.
vAlways ensure that you have a secure foothold whilst working.
vKeep the extension cable away from the area you are cutting.
Take extra care when walking backwards. You may stumble!
Only work in the daylight or when visibility is good.
Interrupting work
vNever leave the Trimmer unattended where you are working.
vIf you stop work, unplug the mains plug and store your Trimmer in a safe place.
vIf you stop work in order to move to another work area, the trimmer must be switched off, wait until the work tool is stationary and then unplug the mains plug.
Always carry the trimmer at the additional handle.
Familiarise yourself with the surroundings
vFamiliarise yourself with the surroundings and look out for possible dangers which you may not hear due to machine noise.
vNever use the Trimmer when there is a risk of thunderstorms, when it is raining or in damp, wet areas.
Do not operate your Trimmer directly next to swimming pools or garden ponds.
Electrical safety
Check the power cord regularly for damage and signs of wear and tear.
Do not use your Trimmer if the power cord is damaged.
vIf the mains cord or extension cable is damaged while you are working, unplug the mains plug immediately.
Do not touch the cable until the mains plug is switched off.
GB
13
GB |
Supply lines must be lighter than: |
Warning! This machine produces an electro |
||
|
– common rubber lines (H 05 RNF), |
magnetical field during operation. This field may |
||
|
||||
|
if rubber-insulated; |
under some circumstances |
interfere with active |
|
|
– common PVC-coated lines (H 05 WF), |
or passive medical implants. To reduce the risk |
||
|
if insulated with PVC. |
of serious or fatal injury, we recommend persons |
||
|
Only connect the device to a mains circuit which |
with medical implants to consult |
their physician |
|
|
is equipped with a residual current device (RCD) |
and the medical implant manufacturer before |
||
with a maximum release current of 30 mA. |
operating this machine. Do not use the product |
|
when a thunderstorm is approaching. |
||
In Switzerland the use of a residual-current |
||
|
||
device is obligatory. |
|
3. Assembly
Assembling the trimmer:
1
2 ßR
4
3
7
9
8
CAUTION!
The trimmer may only be operated provided that the protective cover 0 is assembled.
1.Pull the lock 1 belonging to the additional handle 2, push in both
of the snap-fits 3 belonging to the additional handle 2 and, with
the grooves ßR pointing forwards, snap them into the holder 4.
2. From the front, push the plant
guard 8 into the upper groove 9 ßA1
ßA2 of the trimmer head 7.
In doing so, ensure that the installed bow can rotate freely (i. e. insert the bow with the kink pointing upwards).
3. |
Place the protective cover 0 on |
|
||
|
top of the trimmer head 7. |
0 |
||
4. |
Turn the protective cover 0 |
|||
|
||||
|
until it can be pushed over the |
|
||
|
trimmer head entirely (the two |
|
||
|
arrows ß, ß are directly across |
|
||
|
A1 |
A2 |
|
|
from each other).
5.Rotate the protective cover 0 anti-clockwise until it audibly engages.
14
4. Operation
DANGER!
Connecting the trimmer:
w e
t
q r
Risk of injury if the Turbotrimmer does not switch off when you release the start button.
vNever bypass the safety devices or switches (e. g. by tying the start button to the handle).
Risk of injury!
vUnplug the mains plug of the Turbotrimmer prior to each adjustment of the working position, to the shaft length, additional handle or plant guard!
1.Insert the loop of the extension cable q into the cable strain relief e from below through the handle w and pull tight.
2.Plug the plug r of the trimmer into the socket t of the extension cable q.
3.Plug the extension cable into a 230 V mains power supply.
Setting the working position:
GB
Working position 1: |
Working position 2: |
Standard trimming |
Trimming beneath obstacles |
Working position 1: |
|
For standard trimming. |
|
Working position 2:
1.Press the foot pedal z and lower the shaft downwards into the desired working position.
2.Release the foot pedal z and allow the shaft to engage.
z
CAUTION! Avoid contact between the ground and the trimmer head in working position 1 + 2.
15
