PURE ENERGY
With nearly 40 years of audio research, development, engineering and manufacturing, Energy speakers continue to impress and
inspire with pure sound reproduction. We achieve this by adhering to three vital sound principles: flat on-axis frequency response
with wide bandwidth; wide, constant dispersion; and low distortion.
Delivering musical truth, these sonically accurate speakers effortlessly recreate concert and movie experiences, bringing your
favorite artists into your home.
Energy Veritas speakers are the true essence of audiophile sound and timeless beauty. This premier flagship line offers movie and
music aficionados the ultimate in audio quality, lasting value and unrivalled design.
Aluminum tweeters ensure clear, accurate highs, while Veritas woofers, complete with patented Ribbed Elliptical Surround™,
deliver tight and powerful bass. Boasting pristine high gloss piano black and piano rosenut finishes, each model features elegant
cabinetry suitable for any décor.
MUSIC TO THE EYES & EARS
Unique to Energy speakers, Veritas’ proprietary Convergent Source
Module (CSM) technology places tweeters and mid-woofers in close
proximity to act as a single source for coherent, seamless dispersion.
This extraordinary innovation provides accurate treble and midrange for
an incomparable sonic experience.
BEAUTY MEETS BEAST
Handcrafted and designed with a no-compromise mindset, Veritas speakers are known the world over for their impeccable accuracy
and stunning clarity. Infused with the latest advances in audio technology, these speakers are the ultimate combination of sound
and style.
Veritas floorstanding towers and bookshelf models are engineered to produce accurate sound and transform any environment into
a live soundstage.
Center channels are responsible for nearly 70 percent of a movie’s dialogue and sound. Energy Veritas speakers uncover every word
and detail from your favorite movies and music, delivering them to you in their truest, finest form.
BORN FOR POWER
Feel it in your soul. Whether it’s an enormous explosion, highly anticipated battle scene or intense drum solo, the high performing
Veritas surround speakers place you in the middle of all the action, while the V-SW10 subwoofer with Fiberglas™ cone and Ribbed
Elliptical Surround delivers pure excitement that will leave you yearning for more.
SMALL
WONDERS
The V-Mini and V-Mini Center are two speakers that prove diminutive size are capable of astounding performance.
®
Woofers featuring Kevlar
reproduction. The furniture-grade cabinetry offers unparalleled quality and workmanship.
cones perfectly complement the hyperbolic aluminum dome tweeters for pure, accurate
EXPERIENCE 5.1
We aspire to continuously deliver unforgettable sound performances by providing the Energy 5.1 home theater experience.
Comprised of five main speakers – left and right main speakers, a center channel speaker, left and right surround
speakers – and a subwoofer for deep-reaching bass, a 5.1 Energy home theater system will envelop you in audiophile
quality sound.
Find the perfect combination of Veritas speakers to transform your surround sound listening experiences into powerfully
moving moments.
5.1 SYSTEMS
V-6.3 System
V-5.1 System
V-6.2 System
V-MINI System
SpecificationS V-6.3 V-6. 2 V - 5.1 V-5.2- c
Speaker System
Frequency Response 31Hz - 25kHz +/- 3dB 33Hz-25kHz ± 3dB 50Hz-25kHz ± 3dB 48Hz-25kHz ± 3dB
Recommended Amplier
Power
Sensitivity 93.5dB 92dB 90dB 93.5dB
Impedance 8 ohms nominal; 4 ohms minimum 8 ohms nominal; 4 ohms minimum 8 ohms nominal; 4 ohms minimum 8 ohms nominal; 4 ohms minimum
Tweeter
Midrange
Woofers
Crossover Poin ts 800Hz, 2.5kHz 700Hz, 1.9kHz 2.5kHz 2.2kHz
Inputs Dual 5-way nickel -plated binding posts Dual 5-way nickel -plated binding posts Dual 5-way nickel -plated binding posts Dual 5-way nickel -plated binding posts
Height 42.52" (108cm) 40. 24" (102.2cm) 13.15" (33.4cm) 7.6" (19.3cm)
Width 7.76" (19.7cm) 7.76" (19.7cm) 6.5" (16.5cm) 19.49" (49. 5cm)
Depth 14.06" (35.7cm) 14.06" (35.7cm) 9.17" (23. 3cm) 9.17" (23.3 cm)
Weight 57 lbs / 25.9 kg 49.5 lbs / 22.5 kg 12 lbs / 5.5 kg 21.5 lbs / 9.8 kg
Finish Piano Black & Piano Rosenut Piano Black & Piano Rosenut Piano Black & Piano Rosenut Piano Black & Piano Rosenut
Included Accessories
3 way oorstanding loudspeaker with
shielded drivers, rear vented bass reex design
up to 250 watts RMS up to 225 watts RMS up to 175 watts RMS up to 200 watts RMS
One 1" tweeter with aluminum dome and
neodymium motor with heat sink
One chambered 5.25" midrange with kevlar
cone and Ribbed Elliptical Surround
Two 6.5" woofers with kevlar cones and
Ribbed Elliptical Surrounds
Spike kit, rubb er bumpers, high gloss black
base/plinth, por t plugs
2.5 way oorstanding loudspeaker with
shielded drivers, rear vented bass reex design
One 1" tweeter with aluminum dome and
neodymium motor with heat sink
N/A N/A N/A
Two 6.5" woofers with kevlar cones and
Ribbed Elliptical Surrounds
Spike kit, rubb er bumpers, high gloss black
base/plinth, por t plugs
2 way bookshelf loudspeaker with
shielded drivers, rear vented bass reex design
One 1" tweeter with aluminum dome and
neodymium motor with heat sink
One 5.25" woofer with kevlar cone and
Ribbed Elliptical Surround
Rubber bumpers, port plug, built-In 3/8-16
threaded inser t
2 way center channel loudspeaker with
shielded drivers, rear vented bass reex design
One 1" tweeter with aluminum dome and
neodymium motor with heat sink
Two 5.25" woofers with kevlar cone and
Ribbed Elliptical Surround
Port plug, rubber bumpers
V-S V-Mini V-Mini-c
SpecificationS V -S W10
Surround channel loudspeaker with switchable
bi/di-pole contro ls and volume attenuation
58Hz-25kHz ± 3dB 78Hz-25kHz ± 3dB 78Hz-25kHz ± 3dB
up to 125 watts RMS up to 150 watts RMS up to 150 watts RMS
89.5dB 90.5dB 93.5dB
8 ohms nominal; 4 ohms minimum 8 ohms nominal; 4 ohms minimum 8 ohms nominal; 4 ohms minimum
One 1" tweeter with aluminum dome and
neodymium motor with heat sink
Two 2" chambered midranges with aluminum
cones and neodymium motors
One 5.25" woofer with kevlar cone and Ribbed
Elliptical Surround
400Hz, 3k Hz 2.5kHz 2.5kHz
Single 5-way nickel-plated binding post Single 5-way nickel-plated binding post Single 5-way nickel-plated binding post
9.96" (25.3cm) 7. 48 " (19c m) 4.72" (12cm)
12.01" (30.5cm) 4.72" (12cm) 13.78" (35cm)
6.18" (15.7cm) 5. 51" (14c m) 5. 51" (14c m)
10 lbs / 4.6 kg 5 lbs / 2.3 kg 9 lbs / 4.1 kg
Piano Black High Gloss Black & Finished Rosenut High Gloss Black & Finished Rosenut
Rubber bumpers, built-in 3/8-16 threaded
insert
2 way bookshelf loudspeaker with shielded
drivers, rear vente d bass reex design
One 1" tweeter with aluminum dome and
neodymium motor
N/A N/A
One 4.5" woofer with kevlar cone and Ribbed
Elliptical Surround
Rubber bumpers, wall mount bracket Rubber bumpers
2 way center channel loudspeaker with
shielded drivers, rear vented bass reex design
One 1" tweeter with aluminum dome and
neodymium motor
Two 4.5" woofers with kevlar cone and Ribbed
Elliptical Surround
Speaker System
Frequency Response 23Hz-120Hz ± 3dB
Impedance 8 ohms nominal; 4 ohms minimum
Amplier Power Output 300 watts RMS, 1200 watts dynamic
Components
Variable Low Pass Filter 40Hz-120Hz @ 18dB/octave
Variable Phase Control -180 to +180
Power Mode Switc h On /Auto/O
Inputs Line in/sub in & speaker level in
Height 16.65" (42.3cm)
Width 14.57 " (37c m)
Depth 15. 55" (39.5cm)
Crossover Filter Switch Active / Bypass
Voice Coil Diameter 2" (50.8 cm)
Weight 40 lbs / 18.2 kg
Finish Piano Black
10" 300 watt powered subwoofer,
110 v
10" (25.4 cm) woven composite
Fiberglas™ cone with patente d
Ribbed Elliptical Surround
Energy is committed to providing the most sonically accurate sound experience to every home. As we continue to research and integrate new methods that complement
our existing technology, we welcome and value your comments, suggestions, and feedback. Please visit energy-speakers.com and share your thoughts with us.
We look forward to hearing from you.
