Energy C-50, C-100, C-200, C-300, C-500 Owner's Manual

...

Download

C-300, C-500, C-C50,

OWNERS MANUAL

C-Series

C-50, C-100, C-200,

C-C100, C-R100

owners manual

IMPORTANT SAFETY INSTRUCTIONS – READ CAREFULLY!

We are proud to welcome you as an owner of ENERGY®Speaker Systems' C-Series.ENERGY sonic reproduction and represent the leading edge in speaker design and performance.The finest components and cabinet materials,combined with sophisticated manufacturing and quality control procedures,ensure many years of exceptional performance and listening pleasure.

Please take time to read all of the instructions contained in this manual to make certain your system is properly installed and set up for optimal sound reproduction. Be sure to unpack your system carefully. Retain the carton and all packing material for future use.

UNPACKING

Using a knife carefully cut the tape to open the package.Fold the carton flaps back and slide the speaker and packaging from the box.When removing the C-300 or C-500 floorstanding speaker,stand the box upright, cut the tape and slide the speaker from the box.Remove all inner packaging and parts.

IMPORTANT SAFETY INSTRUCTIONS

The C-Series floorstanding models C-300 or C-500 are designed to be used with spikes and feet for the speakers' bottom.It is important that these are installed properly as they provide stability and also add to the cosmetic look of the speakers.

CONTENTS:

4 - Self adhesive rubber bumpers 4 - Protective discs (C-300 or C-500 only) 4 - Spikes (C-300 or C-500 only) 4 - Nuts (C-300 or C-500 only) 1 - High gloss black plinth/base (C-300 or C-500 only)

BREAK-IN PROCEDURES

It is VITAL that your new C-Series speakers be allowed to break-in properly before you perform any precise set up procedures,system adjustments,and before you play them at higher volume levels.The best method of performing the break-in is to play a full range musical passage at a moderate level as long as possible.Utilizing the repeat function on your CD or DVD player can assist greatly.Optimum sound will not be achieved until approximately 100 hours of playing time.After break-in,the volume level can be increased.Do not play the speakers at high levels until the break-in process has been completed.The transducers need to “loosen up”,and until this occurs,damage can result to the transducers.

PLINTH/BASES

The C-300 or C-500 floorstanding speakers come out of the box with high gloss black plinth/bases attached to their bottom.The plinth/bases are removable if you so choose,by unscrewing the 4 round head machine bolts that attach the plinth/base to the cabinet. Care should be taken to not damage the speaker or plinth/base during removal.Plinth/bases ensure a larger surface area, and therefore provide greater stability to the speaker. Please see diagram 1.

Speakers are the result of extensive research into accurate

SPIKES

Spikes are included with every floorstanding speaker and are designed to decouple the speaker from the floor.With the speaker upside-down (be sure to protect the speaker surface when doing this),insert the spikes into the threaded insert in the plinth/base.Using the supplied wrench, tighten the nut on each spike,to ensure a sturdy and stable footing is established.The nuts also allow for the speaker balance to be fine tuned when the speaker is standing up,ensuring the speaker is level and plumb.If your flooring is hardwood or a hard surface like tile,laminate flooring,etc, the included protective discs are designed to be placed between the spike and the floor, with the padded side down, to protect your flooring. Simply lay the protective discs on the floor and position the speaker so the point of the spike fits into the hole in the top of the protective disc. If you have removed the plinth/base, spikes can be inserted directly into the threaded inserts in the bottom of the speaker.When using carpeting,ensure no wiring beneath the carpeting is pierced by the spike.

If you do not wish to use spikes or spikes with protective discs,self adhesive rubber bumpers are included, to protect hardwood or hard surface floors. DO NOT SLIDE THE SPEAKER WITH THE SPIKES INSTALLED,THIS WILL DAMAGE YOUR FLOORS AND YOUR SPEAKERS.Please see diagram 2.

MAGNETIC SHIELDING

While all C-Series speakers are magnetically shielded,stray magnetic fields can still exist. Placing your C-Series speakers on top or beside your CRT based television should not cause any interference.In the case where there is some minor discoloration,simply move the speaker forward or backwards or away from the television a few inches,this generally resolves the issue.Note:LCD, DLP and Plasma displays do not suffer from magnetic interference.

CONNECTING YOUR SPEAKERS

All of the models in the C-Series have the same high quality plated binding post connectors,so connection to each channel offers the same options.You should utilize high quality speaker cables,up to 12 gauge (AWG).The C-Series will accept a variety of connector types including spade lugs,banana jacks,or pin type connectors.The best connector in our opinion is the "Spade lug" as it provides more contact area with the terminal and allows the binding post to be tightened for a secure connection.Audiophiles and novices alike have preferences as to which connector type they favor, speak with your Authorized

ENERGY assured, plain speaker wire is more than acceptable,you can always upgrade your wires and/or connectors later on.

In the case where you wish to use banana type plugs, simply unscrew the binding post nut in a counter clock-wise fashion, until it comes completely off.Remove the plastic red or black insert and reconnect the binding post nut.The plastic insert is a mandatory security measure, as dictated by many local and federal government associations. Please see diagram 3.

To Connect your speaker system: Start at one speaker,and connect one channel at a time,starting with the front speakers.Always ensure that the entire A/V system is powered OFF before performing any connections.The positive and negative (red and black) sides of the speaker terminals MUST match the positive and negative (red and black) terminals of the receiver or amplifier. If they do not match, abnormal sound and a lack of bass response will result.After connecting the front speakers, connect the rest of the speakers to their appropriate channels of the receiver or amplifier.The three connection methods and their explanations include:

retailer as to which is the best for your Audio Video System.Rest

owners manual

TRADITIONAL CONNECTION METHOD (PLEASE SEE DIAGRAM 4)

1) Using your choice of speaker wire and termination method,connect the speaker cable (minding the positive and negative polarities),to the lower set of connectors.Ensure the terminals are tight.The gold “shorting straps”that connect the lower and upper connections must remain in place.

2) Repeat the procedure for the second speaker.

BI-WIRE METHOD (PLEASE SEE DIAGRAM 5)

This method involves using multiple cables and connectors,to access both sets of terminals on the C-Series loudspeakers simultaneously.The benefit of biwiring is to reduce noise,and reduce the likelihood of grounding problems,as you will have twice the thickness of cable between the amp and speakers as the traditional method would provide.For more details on the benefits of biwiring, please discuss this with your authorized ENERGY

NOTE:Before starting, remove the gold “shorting straps”, which connect the top and bottom set of input terminals.To remove the straps,loosen all of the connectors and pull the straps away from the binding posts.Make sure you put them in a safe place for future use.

1) Using your choice of speaker wire and termination method,connect one speaker cable from the amplifier (minding the positive and negative polarities) to the top set of connectors.Ensure the terminals are tight.

2) Next, connect the second cable, from the same channel of your amplifier to the lower set of terminals.

3) Repeat the procedure for the second speaker.

retailer.

BI-AMPLIFICATION METHOD

(Please see diagram 6)

This connection system involves the use of two separate two channel amplifiers to power one set of speakers.The idea is to have one stereo amplifier connected to one speaker,and another identical amplifier powering the second speaker.This is often referred to as “Vertical”Bi-amplification. It is the only method ENERGY

2) Next, connect the second cable, from the amplifier's other channel to the bottom set of terminals,again ensuring a tight connection.

3) Repeat Steps 1 and 2 for the second speaker using the second amplifier.

recommends.

POSITIONING AND INSTALLING YOUR SPEAKERS

LEFT AND RIGHT MAIN SPEAKERS (C-50, C-100, C-200, C-300, C-500)

The main speakers are usually placed in the front of the room,on either side of the TV or video projector. They should be placed a minimum of 6 feet apart, and if the furniture placement allows,keep them at least 12 inches from all walls.To calculate the best placement, measure the distance between the speakers themselves and the listening position.Your distance from the speakers should be roughly 1.5 times the distance the speakers are apart from each other. For example: If the distance between each speaker and the listening position is 9 feet, then the speakers should be 6 feet apart from one another. This will provide excellent stereo separation and imaging for music playback. This is just a starting point,the room's acoustics and furniture placement will vary the placement of the speaker. Use your best judgment and experiment with speaker placement.Slight adjustments can provide significant improvements in performance.

C-50, C-100, C-200

The C-50,C-100, C-200 are designed to be used as a front left or right speaker,or as a rear channel speaker.When installing the C-50, C-100 or C-200 bookshelf speakers to a wall,there is an insert built into the back of the speaker,located above the input terminals.The threaded insert is designed specifically for the ENERGY your local authorized ENERGY

When the C-50, C-100 or C-200 are to be installed on a bookshelf or on a stand, please attach the 4 rubber bumpers to the bottom of the speaker, as this will protect both the mounting surface and the speaker from damage.Simply peel the bumper off its sheet and stick it in place on the bottom of the speaker, one bumper per corner.The rubber bumpers also help decouple the speaker from the bookshelf or stand. Please see diagram 8.

C-C50, C-C100

When the C-C50 or C-C100 is used as a center speaker,it is ideally placed as close to the center of the TV or video projector as possible.This is to ensure that voices and all sounds come from the performer's placement on screen.This may be on top,underneath, or on a shelf within a wall unit or other furniture. Use the position that provides the best sound quality,but keep in mind safety and room décor as well.The center channel works best when the front of the speaker is flush with the TV,or the shelf it rests on. If the center speaker is recessed in its placement, it will sound distant, and undefined in character. Please see diagram 9.

When the C-C50, C-C100 are to be installed on top of a television, in a cabinet or on a shelf,please attach the 4 rubber bumpers to the bottom of the speaker, as this will protect both the mounting surface and the speaker from damage. Simply peel the bumper off its sheet and stick one bumper in each corner on the speaker.Please see diagram 8.

Macromount™ bracket,which is available from

retailer. Please see diagram 7.

owners manual

C-R100

The rear speakers can vary greatly in position depending on the room layout, and the furniture placement.The ideal position is either on the side walls,or rear walls.

Side Wall:This position utilizes the rear walls of the room to reflect sound and create the "surround" effect. Rear Wall:This is generally used when the side wall position is not available to you, due to furniture placement or room dimensions. It is also used in a 6.1 or

7.1 surround configuration.

Both mounting positions have their advantages and disadvantages,the position offering the best coverage of the entire room should be chosen.The goal of the surround speakers during movie reproduction is to create an "atmosphere" around you.The rear channel speakers are ideally placed an equal distance from you as compared to the front speakers.But this is not always possible in a home environment.The C-R100 will emit sound from both sides of the speaker, and is best placed where it can use the walls to reflect the sound around the listeners.The best mounting position for a 5.1 system is the Side Wall position, as it makes use of the rooms' rear walls, and side walls.It will create a lifelike surround effect and make the room sound larger than it is.In this position,try to mount the speaker so that it is beside you or slightly behind you.The height should be above ear level, at approximately 2/3 of the height of the wall. 6 feet off of the ground is typically a good starting point, and the speaker should be 2 feet above your head when seated.These general guidelines should aid in positioning choices.Please see diagram 9.

You can also achieve excellent results in the rear position.Try not to place the speakers directly into a corner.Leave 2 or more feet between the edge of the cabinet and the side wall,so the sound can reflect into the room environment. The rear position is usually chosen when your room will not accommodate the side wall position due to unequal walls,a doorway, or a large opening, etc. It is recommended that the rear center (6.1 system) or dual rear surrounds (7.1) be placed at the same height as the other two rear surround speakers wherever possible.

FINE TUNING

Before beginning any fine tuning, please ensure all connections are properly made and your speakers have had the chance to break-in for a minimum of 100 hours.This will ensure the proper results are achieved.

Your listening room is the final component of your audio system and will be the difference between mediocre sound and high quality sound. Reflections, which are a part of every recording and music playback, will have a major effect on your system's performance.If your room is too “live”,meaning there are many bare surfaces like glass windows,hard floors and thin furnishings,you might find the sound overly bright. If your room is “dead”, meaning there is thick pile carpeting, heavy furniture and a lot of wall coverings,you might find the sound lacks dynamic energy.To remedy these issues,small changes to your room should be considered as they generally lead to large improvements in sound quality.Most listening rooms must balance aesthetics and sound, but patience and small adjustments in positioning and settings can pay huge acoustic dividends.

The lower bass frequencies are typically the most influenced by your listening room. If you find the bass in your room to be uneven or exaggerated in certain frequencies,experimenting with placement of the front speakers or their orientation towards the listening position can alleviate some of these issues. The proximity of the speakers to room boundaries,like walls, will also affect the bass frequencies.If you find your system lacks bass,first check your connections to make sure your system is in phase,then experiment with placement.The further from the wall,the less overall bass output your system will have,but the bass will generally be better defined.If you position your speakers too close to a room boundary, the bass will typically be exaggerated and ill-defined.Adjusting your speakers to your room will generate the best results.

If you are experiencing issues with imaging, first ensure your speakers are in phase with each other. If this is the case and imaging is still an issue, moving the speakers closer together or toeing them in slightly (angling them towards the listening position) can aid in this respect.

MOUNTING YOUR C-R100 SPEAKERS

NOTE:The C-R100 features a very simple wall mounting system. Careful attention must be made to mount it securely as the speaker is heavy and damage to the product and/or injury could result from improper mounting. Please follow the directions carefully! Please see diagram 10.

1) Select the mounting position best suited for your room.

2) Place the wall mounting bracket against the wall in the desired mounting location and mark the center of the two holes with a pencil.This is where you need to insert the appropriate mounting hardware to securely fasten a load of 15 lbs.Hardware is not included with the speaker, as building materials vary greatly in different countries,but the recommended screw head size is a #8. Screw length is to be determined by the wall material.

3) If you are mounting directly to drywall,please ensure that you use the appropriate anchors,as screws into drywall itself will not provide a secure mount. Insert the anchors, and then hold the mounting bracket up to the wall.Insert the screws until tight.Try to locate into wall studs wherever possible.

4) Screw the included bolt into the insert in the back of the C-R100 speaker, located above the terminal cup.Hand tighten the bolt all the way,and then loosen a few turns counter clockwise.Place the two included rubber bumpers on the back of the speaker,on either side of the back label.

5) Hold the speaker upright,and insert the bolt head into the large hole.Let the speaker slide down into place.

When installing a surround sound system, all the above holds true. Calibration of your speaker distances,adjusting delays and balancing your levels with an SPL meter are necessary to extract the most out of your system.

CARE OF FINISH

The C-Series cabinets should be gently cleaned with only a damp cloth and warm water from time to time,in order to remove any dust or fingerprints.Do not use an abrasive cleaner,or any type of ammonia based cleaners,or window type cleaners.To remove the dust from the grille cloth, use the brush attachment on your vacuum cleaner or a slightly dampened sponge or dust free cloth. Do not touch the speaker cones directly or enter them in contact with water or cleaning materials,as this can cause irreparable damage.

DIAGRAMS/FIGURES/DIAGRAMAS

owners manual

DIAGRAMS/FIGURES/DIAGRAMAS

owners manual

5/6

DIAGRAMS/FIGURES/DIAGRAMAS

owners manual

SubwooferTV or Wall Unit

Center Channel

Front Speakers

Rear Speakers

owners manual

WARRANTY

GARANTIE

LIMITED WARRANTY POLICY IN THE UNITED STATES AND CANADA

ENERGY®warrants this product to the retail purchaser against any failure resulting

from original manufacturing defects in workmanship or materials.The warranty is in effect for a period of: Speaker Section-five (5) years,Subwoofer Section-one (1) year from date of purchase from an authorized ENERGY

dealer and is valid only if the

original dated bill of sale is presented when service is required. The warranty does not cover damage caused during shipment,by accident, misuse,

abuse,neglect, unauthorized product modification, failure to follow the instructions outlined in the owner’s manual,failure to perform routine maintenance,damage resulting from unauthorized repairs or claims based upon misrepresentations of the warranty by the seller.

WARRANTY SERVICE

If you require service for your ENERGY®speaker(s) at any time during the warranty period, please contact:

1) the dealer from whom you purchased the product(s),

2) ENERGY NATIONAL SERVICE, 203 Eggert Road, Buffalo, N.Y.14215

Tel:716-896-9801 or

3) ENERGY

Avenue,Toronto,Ontario,Canada, M1X 1G5, Tel:416-321-1800.

4) Additional service centers can be found by checking the ENERGY

www.energy-speakers.com or, by calling either of the above numbers.

, a division of Audio Products International Corp.,3641 McNicoll

website:

GARANTIE AUX ÉTATS-UNIS ET AU CANADA

La société ENERGY®garantit cet appareil contre toute défectuosité attribuable aux pièces d’origine et à la main-d’oeuvre.Cette garantie est valide pendant une période de cinq (5) ans (enceinte) et d’un (1) an (extreme graves) à partir de la date d’achat auprès d’un revendeur ENERGY

agréé ; la garantie ne sera honorée que

sur présentation d’une pièce justificative de la date d’achat. La garantie ne couvre aucun dommage subi pendant le transport ou imputable à un

accident, à une utilisation impropre ou abusive, à la négligence,à une modification non autorisée,à la non-observance des instructions décrites dans le manuel de l’utilisateur ou des directives d’entretien, ni aucun dommage subi par suite de réparations non autorisées ou de réclamations fondées sur une mauvaise interprétation des conditions de la présente garantie par le revendeur.

SERVICE SOUS GARANTIE

Dans l’éventualité où une réparation deviendrait nécessaire pendant la période de couverture de la garantie,communiquez avec :

1) le revendeur auprès de qui l’appareil a été acheté,

2) ENERGY National Service, 203, Eggert Road, Buffalo,N.Y. 14215, tél. : 716-896-9801 ou

3) ENERGY 416-321-1800.

4) Pour connaître l'adresse de tous nos centres de service,consultez le site Web de ENERGY haut.

, 3641, avenue McNicoll, Toronto (Ontario),Canada, M1X 1G5, tél. :

à www.energy-speakers.com ou composez l’un des numéros indiqués plus

You will be responsible for transporting the speakers in adequate packaging to protect them from damage in transit and for the shipping costs to an authorized

ENERGY ENERGY by ENERGY ENERGY

service center or to ENERGY®. If the product is returned for repair to

in Toronto or Buffalo,the costs of the return shipment to you will be paid

, provided the repairs concerned fall within the Limited Warranty.The

Warranty is limited to repair or replacement of ENERGY®products.It does not cover any incidental or consequential damage of any kind. If the provisions in any advertisement, packing cartons or literature differ from those specified in this warranty, the terms of the Limited Warranty prevail.

Le propriétaire de l’appareil est responsable de son emballage et de tous frais d’expédition à un centre de service ENERGY Si l’appareil est expédié à ENERGY les frais de réexpédition seront assumés par ENERGY

agréé ou à ENERGY®.

à Toronto ou à Buffalo aux fins de réparation,

à la condition que les réparations effectuées soient couvertes par la garantie. La garantie est limitée à la réparation ou au remplacement des appareils fabriqués et distribués par ENERGY

. Elle ne couvre aucun dommage indirect ou consécutif de quelque nature que ce soit. Si les conditions accompagnant toute publicité, emballage ou documentation divergent de celles de la présente garantie,les conditions de la présente garantie prévaudront.
