ELECTROLUX PROFESSIONAL
LAVAOGGETTI FRONTALE
FRONT LOADING DISHWASHER
WT830M / WT830H / WT850M
Code Type Ref. Pagina/
Page
506029 WT830M208U a 2 4 6 8
506030 WT830M240U b 2 4 6 8
506031 WT830H208U c 2 4 6 8
506032 WT830H240U d 2 4 6 8
506033 WT850M208U e 3 5 7 8
506034 WT850M240U f 3 5 7 8
CATALOGO PARTI DI RICAMBIO
SPARE PARTS CATALOGUE
Pagina/ Page Indice/ index
2 Vista generale (solo per “a,b,c,d”) / Main view (only for “a,b,c,d”)
3 Vista generale (solo per “e,f”) / Main view (only for “e,f”)
4 Componenti idraulici (solo per “a,b,c,d”) / Hydraulic components (only for “a,b,c,d”)
5 Componenti idraulici (solo per “e,f”) / Hydraulic components (only for “e,f”)
6 Circuito idraulico (solo per “a,b,c,d”) / Hydraulic circuit (only for “a,b,c,d”)
7 Circuito idraulico (solo per “e,f”) / Hydraulic circuit (only for “e,f”)
8 Componenti elettrici / Electrical components
9 - 17 Lista ricambi / Spare parts list
Marchio/ Brand:
Paese/ Country:
Z - E - A
Tutti/ All
Da Ser.Nr./From Ser.nr.: /620....
Page: 1
Ed. 2015-07
Doc. Nr.: 6-81 004
159
136
137
158
167
162
161
160
168
166
165
164
ill. 681002p1A_A
Vista generale (solo per “a,b,c,d”) / Main view (only for “a,b,c,d”)
Da Ser.Nr./From Ser.nr.: /620....
Page: 2
Ed. 2011-12
Doc. Nr.: 6-81 004
210
205
233
224
209
204
202
201
223
221
226
227
228
208
207
206
257
239
238
240
254
256
250
251
249
252
203
235
211
242
259
253
223
234
222
225
236
237
258
267
266
265
264
268
255
261
260
262
ill. 681002p2A_A2
Vista generale (solo per “e,f”) / Main view (only for “e,f”)
Da Ser.Nr./From Ser.nr.: /620....
Page: 3
Ed. 2011-12
Doc. Nr.: 6-81 004
320
321
322
323
301
329
325
345
346
348
343
344
342
338
339
340
341
316
300
328
326
324
329
347
352
352
352
351
351
350
350
349
349
349
ill. 681002p3A_A
Componenti idraulici (solo per “a,b,c,d”) / Hydraulic components (only for “a,b,c,d”)
Da Ser.Nr./From Ser.nr.: /620....
Page: 4
Ed. 2006-04
Doc. Nr.: 6-81 004
425
429
445
446
448
447
444
443
442
420
421
422
423
438
439
440
441
416
400
402
401
427
426
424
428
426
424
429
400
442
445
446
447
444
443
425
416
452
452
452
452
452
452
451
451
450
450
450
450
451
449
449
449
449
449
449
448
ill. 681002p4A_A
Componenti idraulici (solo per “e,f”) / Hydraulic components (only for “e,f”)
Da Ser.Nr./From Ser.nr.: /620....
Doc. Nr.: 6-81 004
Page: 5
Ed. 2006-04
548
547
548
548
544
548
543
543
543
547
548
547
543
543
544
548
541
547
529
557
556
555
539
538
535
508
514
510
509
549
550
515
511
516
517
513
518
547
552
552
547
547
530
545
528
534
533
532
512
570
519
ill. 681002p5A_A2
Circuito idraulico (solo per “a,b,c,d”) / Hydraulic circuit (only for “a,b,c,d”)
Da Ser.Nr./From Ser.nr.: /620....
Doc. Nr.: 6-81 004
Page: 6
Ed. 2014-08
642
628
648
643
643
643
635
654
647
647
647
648
648
643
608
614
610
609
649
650
616
615
617
613
618
618
641
647
639
652
652
648
636
647
647
648
620
647
647
648
620
648
643
642
642
647
647
643
647
642
643
638
656
629
657
655
634
633
632
612
670
ill. 681002p6A_A2
Circuito idraulico (solo per “e,f”) / Hydraulic circuit (only for “e,f”)
Da Ser.Nr./From Ser.nr.: /620....
Page: 7
Ed. 2014-08
Doc. Nr.: 6-81 004
736
732
739
738
727
746
737
735
733
734
740
741
742
743
* Cablaggio/Wiring hardness: 790
750
751
727
747
727
727
742
747
745
739
746
744
ill. 681002p7A_B
Componenti elettrici / Electrical components
Da Ser.Nr./From Ser.nr.: /620....
Page: 8
Ed. 2007-11
Doc. Nr.: 6-81 004
LAVAOGGETTI FRONTALE WT830M / WT830H / WT850M
FRONT LOADING DISHWASHER WT830M / WT830H / WT850M
Pos. Cod.ric.
Part No.
101 0L0194 Piede; compl. Foot; compl. Up to Ser. Nr. 710
101 048579 Piede; compl. Foot; compl. From Ser. Nr. 711
101 048579 Piede; compl. Foot; compl. Up to Ser. Nr. 405
101 0L3203 Piede; compl. Foot; compl. From Ser. Nr. 406
102 049658 Pannello laterale; inferiore sx Side panel; lower, left
103 049659 Pannello laterale; inferiore dx Side panel; lower, right
104 049713 Pannello laterale; superiore sx Side panel; upper, left c,d
104 049660 Pannello laterale; superiore sx Side panel; upper, left a,b
105 049661 Pannello laterale; superiore dx Side panel; upper, right a,b
105 049714 Pannello laterale; superiore dx Side panel; upper, right c,d
106 049657 Pannello frontale Front panel
107 0L0246 Pannello comandi Control panel Up to Ser. Nr.: 811
107 0L1773 Pannello comandi Control panel From Ser. Nr.: 812
107 0L2020 Pannello comandi Control panel From Ser. Nr.: 906
108 0L0243 Membrana adesiva Stick membrane Up to Ser. Nr.: 905
108 0L1673 Membrana adesiva Stick membrane From Ser. Nr.: 906
109 049662 Schienale Back a,b - Up to Ser. Nr.: 905
109 0L2022 Schienale Back a,b - From Ser. Nr.: 906
109 049715 Schienale Back c,d - Up to Ser. Nr.: 905
109 0L2025 Schienale Back c,d - From Ser. Nr.: 906
110 049663 Coperchio Cover
111 0L0135 Frangiflutti Splashguard
121 049673 Filtro piano Filter plate
122 049674 Filtro Filter
123 0E5183 Filtro; cestello Filter; basket
124 075690 Porta teglie Tray support
125 049664 Cesto Basket
126 049692 Ruota Wheel
127 049689 Protezione pompa; dx,compl. Pump protection; right, compl.
133 0L0141 Porta; superiore; compl. Door; upper; compl. a,b
133 0L0142 Porta; superiore; compl Door; upper; compl. c,d
134 049672 Perno Pin
135 0L2650 Porta; compl Door; compl.
136 0L0595 Fermo leva sinistro Left lever stopped Up to Ser. Nr.: 142
137 0L0594 Fermo leva destro Right lever stopped Up to Ser. Nr.: 142
138 049627 Magnete Magnet Up to Ser. Nr.: 905
138 0L1001 Magnete Magnet From Ser. Nr.: 906
139 0L0380 Squadretta Square Up to Ser. Nr.: 142
139 0L2599 Squadretta Square From Ser. Nr.: 143
140 049621 Sensore Sensor
142 049680 Guida cesto dx; compl. Right guide; compl.
142 049681 Guida cesto sx; compl. Left guide; compl.
Descrizione Description Note / Notes
Pagina 2: Vista generale Page 2: Main view Only for “a,b,c,d”
Grassetto = variazioni
Bold Print = changes
Up to Ser. Nr.: 905
Da Ser.Nr./From Ser.nr.: /620....
Page: 9
Ed. 2011-12
Doc. Nr.: 6-81 004
LAVAOGGETTI FRONTALE WT830M / WT830H / WT850M
FRONT LOADING DISHWASHER WT830M / WT830H / WT850M
Pos. Cod.ric.
Part No.
149 0L0622 Ass.me guida dx;PW1H Right assembly guide;PW1H c,d - Up to Ser. Nr.: 142
149 0L2624 Ass.me guida dx;PW1H Right assembly guide;PW1H c,d - From Ser. Nr.: 143
149 0L0623 Ass.me guida sx;PW1H Left assembly guide;PW1H c,d - Up to Ser. Nr.: 142
149 0L2623 Ass.me guida sx;PW1H Left assembly guide;PW1H c,d - From Ser. Nr.: 143
149 0L0624 Ass.me guida dx;PW1 Right assembly guide;PW1 a,b - Up to Ser. Nr.: 142
149 0L2617 Ass.me guida dx;PW1 Right assembly guide;PW1 a,b - From Ser. Nr.: 143
149 0L0625 Ass.me guida sx;PW1 Left assembly guide;PW1 a,b - Up to Ser. Nr.: 142
149 0L2616 Ass.me guida sx;PW1 Left assembly guide;PW1 a,b - From Ser. Nr.: 143
150 049685 Perno Pin Up to Ser. Nr.: 142
150 0L2612 Perno Pin From Ser. Nr.: 143
150 0L2749 Leva + Dado + Perno Lever + Nut + Pin a,b - From Ser. Nr.: 223
150 0L2750 Leva + Dado + Perno Lever + Nut + Pin c,d - From Ser. Nr.: 223
151 0L0037 Fermo porta dx; compl Right door-stop; compl. Up to Ser. Nr.: 142
151 0L2620 Fermo porta dx; compl Right door-stop; compl. From Ser. Nr.: 143
151 0L0036 Fermo porta sx; compl Left door-stop; compl. Up to Ser. Nr.: 142
151 0L2619 Fermo porta sx; compl Left door-stop; compl. From Ser. Nr.: 143
152 049688 Leva appoggio porta Lever Up to Ser. Nr.: 142
153 0L0626 Guida porta sx Left door drive Up to Ser. Nr.: 142
153 0L2609 Guida porta sx Left door drive From Ser. Nr.: 143
153 0L0627 Guida porta dx Right door drive Up to Ser. Nr.: 142
153 0L2610 Guida porta dx Right door drive From Ser. Nr.: 143
154 049731 Leva per porta Lever c,d - Up to Ser. Nr.: 142
154 0L2622 Leva per porta Lever c,d - From Ser. Nr.: 143
154 0L2750 Leva + Dado + Perno Lever + Nut + Pin c,d - From Ser. Nr.: 223
154 0L0034 Leva per porta Lever a,b - Up to Ser. Nr.: 142
154 0L2613 Leva per porta Lever a,b - From Ser. Nr.: 143
154 0L2749 Leva + Dado + Perno Lever + Nut + Pin a,b - From Ser. Nr.: 223
155 049683 Tirante per porta Door drawrod a,b - Up to Ser. Nr.: 142
155 0L2618 Tirante per porta Door drawrod a,b - From Ser. Nr.: 143
155 049730 Tirante per porta Door drawrod c,d - Up to Ser. Nr.: 142
155 0L2625 Tirante per porta Door drawrod c,d - From Ser. Nr.: 143
156 027023 Anello di sicurezza Clamp ring
157 049868 Paraspruzzi Splashguard
158 0L1149 Cinghia contenimento stoviglie Rubber band
159 0L0411 Tappo per schienale Back panel cover Up to Ser. Nr.: 905
159 0L2023 Tappo per schienale Back panel cover From Ser. Nr.: 906
160 0L2608 Supporto guida scorrevole SX Left sliding drive support From Ser. Nr.: 143
160 0L2611 Supporto guida scorrevole DX Right sliding drive support From Ser. Nr.: 143
161 0L2604 Labirinto guida porta Door drive labyrinth From Ser. Nr.: 143
162 0L2605 Chiavistello sinistro blocco porta Left door locking latch From Ser. Nr.: 143
162 0L2606 Chiavistello destro blocco porta Right door locking latch From Ser. Nr.: 143
164 0L2607 Ammortizzatore idraulico Hydraulic damper a,b,e,f - From Ser. Nr.: 143
Descrizione Description Note / Notes
Grassetto = variazioni
Bold Print = changes
Up to Ser. Nr.: 222
Up to Ser. Nr.: 222
Up to Ser. Nr.: 222
Da Ser.Nr./From Ser.nr.: /620....
Page: 10
Ed. 2012-05
Doc. Nr.: 6-81 004
LAVAOGGETTI FRONTALE WT830M / WT830H / WT850M
FRONT LOADING DISHWASHER WT830M / WT830H / WT850M
Pos. Cod.ric.
Part No.
164 0L2621 Ammortizzatore idraulico Hydraulic damper c,d - From Ser. Nr.: 143
164 0L2747 Ammortizzatore idraulico Hydraulic damper From Ser. Nr.: 223
165 0L2614 Perno attacco ammortizzatore Damper connection pin From Ser. Nr.: 143
166 0L2615 Supporto attacco ammortizzatore Damper connection support From Ser. Nr.: 143
167 0L2626 Piastrina Plate From Ser. Nr.: 143
168 0L2602 Rondella Washer From Ser. Nr.: 143
201 0L0194 Piede; compl. Foot; compl. Up to Ser. Nr. 710
201 048579 Piede; compl. Foot; compl. From Ser. Nr. 711
202 049658 Pannello laterale; inferiore sx Side panel; lower, left
203 049659 Pannello laterale; inferiore dx Side panel; lower, right
204 049660 Pannello laterale; superiore sx Side panel; upper, left
205 049661 Pannello laterale; superiore dx Side panel; upper, right
206 049705 Pannello frontale Front panel SX,PW2
207 0L0246 Pannello comandi Control panel Up to Ser. Nr.: 811
207 0L1773 Pannello comandi Control panel From Ser. Nr.: 812
207 0L2020 Pannello comandi Control panel From Ser. Nr.: 906
208 0L0243 Membrana adesiva Stick membrane Up to Ser. Nr.: 905
208 0L1673 Membrana adesiva Stick membrane From Ser. Nr.: 906
209 049707 Schienale;SX Back; Left Up to Ser. Nr.: 905
209 0L2027 Schienale;SX Back; Left From Ser. Nr.: 906
209 049706 Schienale;DX Back; Right Up to Ser. Nr.: 905
209 0L2026 Schienale;DX Back; Right From Ser. Nr.: 906
210 049708 Coperchio Cover
211 0L0136 Frangiflutti Splashguard
221 049699 Filtro piano Filter plate
222 049700 Filtro Filter
223 0E5183 Filtro; cestello Filter; basket
224 075690 Portateglie Tray support
225 049709 Cesto Basket
226 049692 Ruota Wheel
227 049689 Protezione pompa; dx,compl. Pump protection; right, compl.
228 049701 Protezione pompa; Sx,compl. Pump protection; left, compl.
233 0L0143 Porta; superiore; compl. Door; upper; compl.
234 049672 Perno Pin
235 0L2603 Porta; compl Door; compl.
236 0L0595 Fermo leva sinistro Left lever stopped Up to Ser. Nr.: 142
237 0L0594 Fermo leva destro Right lever stopped Up to Ser. Nr.: 142
238 049627 Magnete Magnet Up to Ser. Nr.: 905
238 0L1001 Magnete Magnet From Ser. Nr.: 906
239 0L0380 Squadretta Square Up to Ser. Nr.: 142
Descrizione Description Note / Notes
Pagina 3: Vista generale Page 3: Main view Only for e,f”
Grassetto = variazioni
Bold Print = changes
Up to Ser. Nr.: 222
Up to Ser. Nr.: 905
Da Ser.Nr./From Ser.nr.: /620....
Page: 11
Ed. 2012-05
Doc. Nr.: 6-81 004
LAVAOGGETTI FRONTALE WT830M / WT830H / WT850M
FRONT LOADING DISHWASHER WT830M / WT830H / WT850M
Pos. Cod.ric.
Part No.
239 0L2599 Squadretta Square From Ser. Nr.: 143
240 049621 Sensore Sensor
242 049680 Guida cesto dx; compl. Guide right; compl.
242 049681 Guida cesto sx; compl. Guide left; compl.
249 0L0624 Ass.me guida dx;PW2 Right assembly guide;PW2 Up to Ser. Nr.: 142
249 0L2617 Ass.me guida dx;PW2 Right assembly guide;PW2 From Ser. Nr.: 143
249 0L0625 Ass.me guida sx;PW2 Left assembly guide;PW2 Up to Ser. Nr.: 142
249 0L2616 Ass.me guida sx;PW2 Left assembly guide;PW2 From Ser. Nr.: 143
250 049685 Perno Pin Up to Ser. Nr.: 142
250 0L2612 Perno Pin From Ser. Nr.: 143
250 0L2749 Leva + Dado + Perno Lever + Nut + Pin From Ser. Nr.: 223
251 0L0037 Fermo porta dx; compl Right door-stop; compl. Up to Ser. Nr.: 142
251 0L2620 Fermo porta dx; compl Right door-stop; compl. From Ser. Nr.: 143
251 0L0036 Fermo porta sx; compl Left door-stop; compl. Up to Ser. Nr.: 142
251 0L2619 Fermo porta sx; compl Left door-stop; compl. From Ser. Nr.: 143
252 049688 Leva appoggio porta Lever Up to Ser. Nr.: 142
253 0L0626 Guida porta sx Left door drive
253 0L0627 Guida porta dx Right door drive
254 0L0034 Leva per porta Lever Up to Ser. Nr.: 142
254 0L2613 Leva per porta Lever From Ser. Nr.: 143
254 0L2749 Leva + Dado + Perno Lever + Nut + Pin From Ser. Nr.: 223
255 049683 Tirante per porta Tie-rod Up to Ser. Nr.: 142
255 0L2618 Tirante per porta Tie-rod From Ser. Nr.: 143
256 027023 Anello di sicurezza Clamp ring
257 049867 Paraspruzzi Splashguard
258 0L1149 Cinghia contenimento stoviglie Rubber band
259 0L0411 Tappo per schienale Back panel cover Up to Ser. Nr.: 905
259 0L2023 Tappo per schienale Back panel cover From Ser. Nr.: 906
260 0L2608 Supporto guida scorrevole SX Left sliding drive support From Ser. Nr.: 143
260 0L2611 Supporto guida scorrevole DX Right sliding drive support From Ser. Nr.: 143
261 0L2604 Labirinto guida porta Door drive labyrinth From Ser. Nr.: 143
262 0L2605 Chiavistello sinistro blocco porta Left door locking latch From Ser. Nr.: 143
262 0L2606 Chiavistello destro blocco porta Right door locking latch From Ser. Nr.: 143
264 0L2607 Ammortizzatore idraulico Hydraulic damper From Ser. Nr.: 143
265 0L2614 Perno attacco ammortizzatore Damper connection pin From Ser. Nr.: 143
266 0L2615 Supporto attacco ammortizzatore Damper connection support From Ser. Nr.: 143
267 0L2626 Piastrina Plate From Ser. Nr.: 143
268 0L2602 Rondella Washer From Ser. Nr.: 143
Descrizione Description Note / Notes
Grassetto = variazioni
Bold Print = changes
Up to Ser. Nr.: 222
Up to Ser. Nr.: 222
Pagina 4: Componenti idraulici Page 4: Hydraulic components Only for “a,b,c,d”
300 049726 Raccordo 3 vie; Connection 3 way;
301 049695 Supporto getti inferiore; DX Jets support; lower, Right
Da Ser.Nr./From Ser.nr.: /620....
Page: 12
Ed. 2012-05
Doc. Nr.: 6-81 004
LAVAOGGETTI FRONTALE WT830M / WT830H / WT850M
FRONT LOADING DISHWASHER WT830M / WT830H / WT850M
Pos. Cod.ric.
Part No.
316 0L1146 Pompa lavaggio; 208/240V 60Hz Wash pump; 208/240V 60Hz
320 0E5642 Manopola Knob
321 0E5643 Guida Guide
322 049676 Guarnizione Gasket
323 0E5645 Riduttore portata Bar
324 0L0621 Tubo; collegamento getti Pipe; jets connection c,d
324 0L0620 Tubo; collegamento getti Pipe; jets connection a,b
325 0L0695 Supporto getti superiore Jets support; upper
326 049694 Attacco Attack
328 049691 Rampe laterali; compl. Lateral ramp
329 0L1150 Tappo G 1/2" Plug G 1/2"
338 049675 Troppo pieno Overflow pipe
339 075624 Supporto scarico Support; drain
340 047192 Guarnizione;troppo pieno Gasket
341 066079 Ghiera Ring nut
342 048401 Mozzo Hub
343 0L0389 Getto lavaggio Wash jet
344 0E5640 Getto risciacquo Rinse jet
345 0E5639 Tappo Plug
346 0E5107 Ugello 9506 Nozzle 9506
347 048290 Perno; per getti risciaquo Pin; for rinse jets
348 048632 Rondella Washer
349 0L0193 Fascetta 40-60 Hose clamp 40-60
350 046853 Fascetta 68-85 Hose clamp 68-85
351 075609 Tubo gomma; 75X85 Hose; 75x85
352 045768 Tubo gomma; 45X55 Hose; 45x55
Descrizione Description Note / Notes
Grassetto = variazioni
Bold Print = changes
Pagina 5: Componenti idraulici Page 5: Hydraulic components Only for “e,f”
400 049726 Raccordo 3 vie Connection 3 way
401 049695 Supporto getti inferiore; DX Jets support; lower, Right
402 049704 Supporto getti inferiore; SX Jets support; lower, Left
416 0L1146 Pompa lavaggio; 208/240V 60HZ Wash pump; 208/240V 60HZ
420 0E5642 Manopola Knob
421 0E5643 Guida Guide
422 049676 Guarnizione Gasket
423 0E5645 Riduttore portata Bar
424 0L0620 Tubo; collegamento getti Pipe; jets connection
425 0L0695 Supporto getti superiore Jets support; upper
426 049694 Attacco Attack
427 049703 Rampe laterali;DX, compl. Lateral ramp; Right
428 049702 Rampe laterali;SX, compl. Lateral ramp; Left
429 0L1150 Tappo G 1/2" Plug G 1/2"
438 049675 Troppo pieno Overflow pipe
439 075624 Supporto scarico Support; drain
Da Ser.Nr./From Ser.nr.: /620....
Page: 13
Ed. 2011-12
Doc. Nr.: 6-81 004
LAVAOGGETTI FRONTALE WT830M / WT830H / WT850M
FRONT LOADING DISHWASHER WT830M / WT830H / WT850M
Pos. Cod.ric.
Part No.
440 047192 Guarnizione;troppo pieno Gasket
441 066079 Ghiera Ring nut
442 048401 Mozzo Hub
443 0L0389 Getto lavaggio Wash jet
444 0E5640 Getto risciacquo Rinse jet
445 0E5639 Tappo Plug
446 0E5107 Ugello 9506 Nozzle 9506
447 048290 Perno; per getti risciaquo Pin; for rinse jets
448 0E5638 Dado Nut
449 0L0193 Fascetta 40-60 Hose clamp 40-60
450 046853 Fascetta 68-85 Hose clamp 68-85
451 075609 Tubo gomma; 75X85 Hose; 75x85
452 045768 Tubo gomma; 45X55 Hose45x55
508 049459 Salto in aria; WRC AIR GAP
509 049828 Guarnizione Gasket
510 049480 Ghiera Ring nut
511 0L0082 Fascetta 7.3 / 7.8mm Clamp 7.3 / 7.8mm From Ser. 406
512 0L2560 Protezione ghiera Guard ring nut
513 048308 Trappola d’aria Air trap
514 049460 O ring O Ring
515 048883 Tubo 5x12 gomma Hose; 5x12 Up to Ser. 405
515 0K9162 Tubo 4x7 gomma Hose; 4x7 From to Ser. 406
516 049268 Dado M14x1.5 Nut; M14x1,5
517 068642 OR 2062x15.54 O Ring
518 046946 Fascetta 8-12 Clamp 8-12 Up to Ser. 405
518 046946 Fascetta 9.3 / 9.9 Clamp 9.3 / 9.9 From to Ser. 406
519 0L3273 Tubo corrugato Hellerman (HG-
528 083406 Condensatore per pompa risc. Rinse pump capacitor 5.0 ÏF
529 0L0569 Elettrovalvola Electric valve Up to Ser. Nr.: 222
529 0L2656 Elettrovalvola Electric valve From Ser. Nr.: 223
530 0L0365 Raccordo a 3 vie 3 way connection
532 0L1151 Boiler Boiler Up to Ser. Nr.: 905
532 0L1952 Boiler Boiler From Ser. Nr.: 906
532 0L1151 Boiler Boiler From Ser. Nr.: 018
533 048222 Fascetta 200-231 Hose clamp 200-231 Up to Ser. Nr.: 222
533 0TH122 Fascetta 200-220 Hose clamp 200-220 From Ser. Nr.: 223
534 0L1152 Coibentazione boiler Boiler insulation Up to Ser. Nr.: 222
535 0L0098 Trappola d'aria; boiler Air trap; boiler
538 0L1098
539 049679 Gomito; 90 GR Elbow; 90 degr
Descrizione Description Note / Notes
Pagina 6: Circuito idraulico Page 6: Hydraulic circuit Only for “a,b,c,d”
Conduit Hellerman (HG-SW13) From Ser. 406
SW13)
Pompa risciacquo;208/240V 60Hz
Rinse pump;208/240V 60Hz
Grassetto = variazioni
Bold Print = changes
Up to Ser. Nr.: 017
Da Ser.Nr./From Ser.nr.: /620....
Page: 14
Ed. 2014-08
Doc. Nr.: 6-81 004
LAVAOGGETTI FRONTALE WT830M / WT830H / WT850M
FRONT LOADING DISHWASHER WT830M / WT830H / WT850M
Pos. Cod.ric.
Part No.
541 048834 Filtro Filter
543 048531 Tubo 19,5x12 Hose 19,5x12
544 049773 Tubo 26x38 Hose 26x38
545 049287 Tubo 25,5x32 Hose 25,5x32
547 048126 Fascetta 13-20 Hose clamp 13-20
548 047578 Fascetta 26-38 Hose clamp 26-38
549 0E5993 Fascetta 7,3-7,8 Hose clamp 7,3-7,8
550 0L0349 Assieme tappo brillantante Rinse aid plug assembly
552 049201 Guarnizione Gasket
555 049650 Parzializzatore Flow reducer
556 0L0479 Nipplo 3/4"-3/8" Nipple 3/4"-3/8"
557 0L0477 Portagomma ottone 3/8" G Brass fitting 3/8" G
570 0L2744
608 049459 Salto in aria; WRC AIR GAP
609 049828 Guarnizione Gasket
610 049480 Ghiera Ring nut
611 0L0082 Fascetta 7.3 / 7.8mm Clamp 7.3 / 7.8mm From Ser. 406
612 0L2560 Protezione ghiera Guard ring nut
613 048308 Trappola d’aria Air trap
614 049460 O ring O Ring
615 048883 Tubo 5x12 gomma Hose; 5x12 Up to Ser. 405
615 0K9162 Tubo 4x7 gomma Hose; 4x7 From Ser. 406
616 049268 Dado M14x1.5 Nut; M14x1,5
617 068642 OR 2062x15.54 O Ring
618 046946 Fascetta 8-12 Clamp 8-12 Up to Ser. 405
618 046946 Fascetta 9.3 / 9.9 Clamp 9.3 / 9.9 From to Ser. 406
619 0L3273 Tubo corrugato Hellerman (HG-
620 0L0365 Raccordo a 3 vie 3 way connection
628 083406 Condensatore per pompa risc. Rinse pump capacitor 5.0 ÏF
629 0L0569 Elettrovalvola Electric valve Up to Ser. Nr.: 222
629 0L2656 Elettrovalvola Electric valve From Ser. Nr.: 223
632 0L1151 Boiler Boiler Up to Ser. Nr.: 905
632 0L1952 Boiler Boiler From Ser. Nr.: 906
632 0L1151 Boiler Boiler From Ser. Nr.: 018
633 048222 Fascetta 200-231 Hose clamp 200-231 Up to Ser. Nr.: 222
633 0TH122 Fascetta 200-220 Hose clamp 200-220 From Ser. Nr.: 223
634 0L1152 Coibentazione boiler Boiler insulation Up to Ser. Nr.: 222
635 0L0098 Trappola d'aria; boiler Air trap; boiler
636 0L0210 Raccordo a "T" T connection
638 0L1098
Descrizione Description Note / Notes
Supporto pressostato Pressure switch plate
Pagina 7: Circuito idraulico Page 7: Hydraulic circuit Only for “e,f”
Conduit Hellerman (HG-SW13) From Ser. 406
SW13)
Pompa risciacquo;208/240V 60Hz
Rinse pump;208/240V 60Hz
Grassetto = variazioni
Bold Print = changes
From Ser. Nr.: 223
Up to Ser. Nr.: 017
Da Ser.Nr./From Ser.nr.: /620....
Page: 15
Ed. 2014-08
Doc. Nr.: 6-81 004
LAVAOGGETTI FRONTALE WT830M / WT830H / WT850M
FRONT LOADING DISHWASHER WT830M / WT830H / WT850M
Pos. Cod.ric.
Part No.
639 049679 Gomito; 90 GR Elbow; 90 degr
641 048834 Filtro Filter
642 049773 Tubo 19,5x12 Hose 19,5x12
643 048531 Tubo 26x38 Hose 26x38
647 048126 Fascetta 13-20 Hose clamp 13-20
648 047578 Fascetta 26-38 Hose clamp 26-38
649 0E5993 Fascetta 7,3-7,8 Hose clamp 7,3-7,8
650 0L0349 Assieme tappo brillantante Rinse aid plug assembly
652 049201 Guarnizione Gasket
654 049287 Tubo 25,5x32 Hose 25,5x32
655 049650 Parzializzatore Flow reducer
656 0L0479 Nipplo 3/4"-3/8" Nipple 3/4"-3/8"
657 0L0477 Portagomma ottone 3/8" G Brass fitting 3/8" G
670 0L2744
Descrizione Description Note / Notes
Supporto pressostato Pressure switch plate
Pagina 8: Componenti elettrici Page 8: Electrical components
Grassetto = variazioni
Bold Print = changes
From Ser. Nr.: 223
727 0E5037 OR 56.52X5.33 OR 56.52X5.33
732 049620 Pressostato Pressure switch
733 049303 Filtro RFI; trifase RFI filter; three phase
734 0L0111 Morsettiera Junction box
735 0L0430 Contattore; K3-18 A10 180 Contactor; K3-18 A10 180
736 0L0709 Interfaccia utente User interface Up to Ser. Nr.: 622
736 0L1240 Interfaccia utente User interface From Ser. Nr.: 623
Up to Ser. Nr.: 742
736 0L1566 Interfaccia utente User interface From Ser. Nr.: 743
Up to Ser. Nr.: 022
736 0L1973 Interfaccia utente User interface From Ser. Nr.: 023
737 0L2583 Scheda madre Main board
738 0L0366 Supporto; sonda di temp. Support; temp.sound
739 049643 Sonda di temperatura Temp.sound
740 0E5993 Fascetta elastica 7,8-8,3 Hose clamp 7,8-8,3
741 072393 Tubo gomma; L=2100 MM Hose
742 046376 OR 2037 O Ring
743 0E5942 Protezione Motor protection
744 0L1568 Copertura interfaccia utente User interface cover From Ser. Nr.: 743
745 0L0280 Premistoppa Stuffing box
746 0L1153 Resistenza sx; 6000W 208V
746 0L2499 Resistenza sx; 6000W 208V
746 0L2499 Resistenza sx; 6000W 208V
746 0L3338 Resistenza sx; 6000W 208V
747 0L1155 Resistenza dx; 6000W 208V
747 0L2500 Resistenza dx; 6000W 208V
747 0L2500 Resistenza dx; 6000W 208V
747 0L3339 Resistenza dx; 6000W 208V
Heating element left; 6000W 208V
Heating element left; 6000W 208V
Heating element left; 6000W 208V
Heating element left; 6000W 208V
Heating element right; 6000W 208V
Heating element right; 6000W 208V
Heating element right; 6000W 208V
Heating element right; 6000W 208V
a,c,e - Up to Ser. Nr.: 116
a,c,e - From Ser. Nr.: 117
a,c,e - Up to Ser. Nr.: 416
a,c,e - From Ser. Nr.: 417
a,c,e - Up to Ser. Nr.: 116
a,c,e - From Ser. Nr.: 117
a,c,e - Up to Ser. Nr.: 416
a,c,e - From Ser. Nr.: 417
Da Ser.Nr./From Ser.nr.: /620....
Page: 16
Ed. 2014-09
Doc. Nr.: 6-81 004
LAVAOGGETTI FRONTALE WT830M / WT830H / WT850M
FRONT LOADING DISHWASHER WT830M / WT830H / WT850M
Pos. Cod.ric.
Part No.
747 0L1156 Resistenza dx; 6000W 240V
750 0E6017 Interruttore automatico
750 0E6017 Interruttore automatico
751 0L1147 Interruttore bipolare Double-pole switch
790 0L1157 Cablaggio Wiring harness
790 0L1162 Cablaggio aggiuntivo Additional wiring harness e,f
Descrizione Description Note / Notes
Heating element right; 6000W 240V
Three-pole automatic switch Up to Ser. Nr: 5271
tripolare
Three-pole automatic switch From Ser. Nr: 5281
tripolare
Grassetto = variazioni
Bold Print = changes
b,d,f
Da Ser.Nr./From Ser.nr.: /620....
Page: 17
Ed. 2015-07
Doc. Nr.: 6-81 004
Loading...
