SPARE PARTS CATALOGUE
CATALOGO RICAMBI
STANDARD CABINETS
FRIGORIFERI STANDAR
FREEZER 1400LT
Code Model Ref. Page Description Eng.Ch.
727286 REX142FF a 2,5,6 MASS 1430L 2 FULL D. -15/-22°C DIG. A304 00-17
727287 REX142GF c 3,5,6 2-GLASS DR FREEZER 1430L -20-15°C, DIGIT 00-01
727288 REX144HF f 3,5,6 4x½-DR FREEZER 1430L -22/-15°C, DIG-CL.6 00-01
727297 RE4142FF d 2,5,6 2-DR FREEZER 1430L -22/-15°,DIG,S/S 430 00-17
727366 REX142FFG b 2,5,6 2-DR FREEZER 1430L -22/-15°C, DIGITAL-UK 00-19
727378 RE4142FFG e 2,5,6 2-DR FREEZER 1430L -22/-15°C,DIG,S/S-UK 00-19
728709 REK142FF a 2,5,6 2-DOOR FREEZER 1430L -22/-15°C, DIGITAL 00-16
Index and pages
Cabinet and door/Armadio e porta 2,3,4
Cooling unit assembly/Gruppo refrigerante 5......
Control panel/Pannello comandi 6... ..
Spare parts list/Lista ricambi 7......
Rev.4
From Ser. Nr.43510001
Up to Ser. Nr....
Ed. 2015/03/25 Page: 1
Doc No: 560112
22
23
3
18
19
14
15
21
17
16
6
20
12
9a
12a
12b
1
2
3
4
6
7
8
9
10
13
13a
11
6
full doors
From Ser. Nr.43510001
Up to Ser. Nr....
560122 porta intera
Ed. 2015/03/25 Page: 2
Doc No: 560112
Glass doors
9a
12
12a
12b
1a
1a
1
1
2
3
35
36
41
43
38
119
40
42
17
44
39
37
16
45
46
49
48
50
47
4
6
7
8
9
10
13
13a
11
6
6
From Ser. Nr.43510001
Up to Ser. Nr....
560112 porta vetro
Ed. 2015/03/25 Page: 3
Doc No: 560112
Half doors
22
23
3
20
1
2
3
4
6
7
8
9
10
13b
13a
11
28
29
31
33
34
32
17
30
21
17
24
26
27
26
27
25
24
25
12
12a
12a
12b
From Ser. Nr.43510001
Up to Ser. Nr....
Ed. 2015/03/25 Page: 4
560112 mezze porte
Doc No: 560112
54
55
56
59
61
58/58a
80/80a
57
62
52
60
52a
52b
52c
53
51
78
78a
73
77
64/64a
67
67a
67b
79
70a
69
68
70
74
76
75
63
82
82a
71
66
108
108
72
65
65b
66a
72a
65a
83
094573
094571
094572
094569
094570
Refer to TB N°VTX2015-03
Cooling
From Ser. Nr.43510001
Up to Ser. Nr....
Ed. 2015/03/25 Page: 5
560112 gruppo freezer
Doc No: 560112
99
113
118
103
103
104
104
110
106
106
105
117
108
100
109
102
107
117
112
Panel
From Ser. Nr.43510001
Up to Ser. Nr....
560112 pannello di controllo
Ed. 2015/03/25 Page: 6
Doc No: 560112
STANDARD CABINETS
Pos Code Factory code Description Descrizione Ref/notes
1 093243 541R050.. Foot Piedino
1a 093244 518R026.. Back foot glass door Piedino anteriore porta vetro c
2 093245 2175552.. Screw ( use by x foot) Vite per plastica per piedino
3 093246 5187086.. Screw M8X20 ( use by x bracket) Vite M8x20 per ss. staffa sup/inf
4 093394 502R175.. Side support Staffa supporto anchi
6 093249 501R382.. Front/back Rack Cremagliera anteriore/posteriore
7 093250 501R479.. Left support Guida Sx
8 093251 501R481.. Right support Guida Dx
9 093252 514R106.. Grid 2/1rilsan Griglia 2/1 rilsan
9a 093397 514R117.. Central grid Griglia centrale
10 093253 514R122.. Bottom grid rilsan Griglia di fondo rilsan
11 093490 501R621.. Rack rupport Supporto centrale cremagliere
12 093545 832R092.. Orrizzontal frame Cornice orrizzontale
12a 093255 832R091.. Vertical frame Cornice verticale
12b 093399 832R094.. Vertical frame central support Cornice verticale montante
13 093400 617R0680.. Heating cable frame 28,95 W Cavo riscaldante cornice 28,95 W
13b 093402 617R077.. Heating cable frame 40,5 W 1/2 doors Cavo riscaldante cornice 40,5 W f
13a 093401 617R069.. Heating cable frame 15,98 W Cavo riscaldante cornice 15,98 W
14 093309 835R243.. Gasket, hinge, and door Porta con guarnizione,cerniera bt a,b
14 093312 835R245.. Gasket, hinge, and door A430 Porta con guarnizione , cerni.A430 d,e
15 093311 835R242.. Door (left) A304 Porta 304 bt a,b
15 093310 835R244.. Door (left) A430 Porta 430 d,e
16 094152 548R080.. Gasket door ( gl/) Guarnizione porta pv/pc
17 082219 8357040.. Hinge door Cerniera porta
18 081654 5447006.. Door bush Boccola per porta
19 093341 833R216..
20 082257 5057238.. Upper stirrup door Staffa superiore porta
21 093271 541R053.. Hole hinge plug Tappo per cerniere
22 093574 835R248.. Weel Ruota rotante b,e
23 093575 835R249.. Brake weel Ruota rotante con freno b,e
24 093343 880R642.. Support half door a430 Traversa per 1/2 porte a430
25 093272 832R100.. Support half door frame Cornice per traversa
26 093275 501R518.. Upper rack 1/2 doors a304 Cremagliera ant. 1/2 porte sup.
27 093276 501R516.. Lower rack 1/2 doors a304 Cremagliera ant. 1/2 porte 304 inf.
28 093585 835R254.. Upper half door a304 Ass.1/2 porta superiore
29 093519 835R255.. Lower half door a304 Ass.1/2 porta inferiore
30 093273 548R071.. Half door gasket Guarnizione magnetica 1/2 porte
31 093392 546R211.. Half door bush Boccola per cerniera 1/2 porte
32 093301 833R219.. Lower hinge assembly Ass. cerniera inferiore
33 093344 505R124.. Central hinge door Cerniera centrale
34 093345 833R209.. Serratura Serratura
35 093313 880R576.. Glass door assembled Ass. porta vetro completa c
36 093459 879R158.. Glass door BT Porta vetro bt c
37 093535 546R224.. Upper right plug door GL Tappo sup. dx pv c
38 093536 546R223.. Upper left plug door GL Tappo sup. sx pv c
39 093537 546R225.. Lower right plug door GL Tappo inf. dx pv c
40 093538 546R222.. Lower left plug door GL Tappo inf. sx pv c
41 093349 505R127.. Upper hinge GL Staffa superiore pv c
Lower stirrup door Staffa inferiore porta
FREEZER 1400LT
From Ser. Nr.43510001
Up to Ser. Nr....
Ed. 2015/03/25 Page: 7
Doc No: 560112
STANDARD CABINETS
Pos Code Factory code Description Descrizione Ref/notes
42 093301 833R219.. Lower bracket (reversible) Ass. staffa inf.( reversibile) pv c
43 093320 835R281.. Upper hinge GL Ass cerniera sup pv c
45 094484 835R268.. Light support assembly Ass. lampada completo c
46 093350 661R010.. Neon 28W Lampada 28W c
47 093258 546R226.. Protection light Frontale lampada c
48 093351 501R495.. Plug of clousure Tappo chiusura luce c
49 093352 546R232.. Wiring stopper Ferma cavo c
50 093321 501R502.. Stopper light Fermo lampada c
51 * 502R543.. Electrical wiring support Supporto impianto elettrico
* * 880R628.. Cooling unit gr 0.34 404A Modulo gruppo gr 0.34 404A c
* * 880R545.. Cooling unit gr 0.29 404A Modulo gruppo gr 0.29 404A a,f,d
* * 880R675.. Cooling unit (conveyor 3 holes)gr 0.34 Modulo gruppo (conveyor 3 holes)gr0.34 b,e
52 093424 684R056.. Compressor (NT2192GK) 220/50hz Compressore (NT2192GK) 220/50 a,c,d,f
52 093403 684R055.. Compressor (NT2212GK) 220/50hz Compressore (NT2212GK) 220/50 b,e
52a * * Start relay Relè avviamento
52b * * Protector Protettore
52c * * Start capacitor Condensatore di avviamento
53 * * Rubber compressor Fissaggio compressore
54 093404 830R050.. Condenser Condensatore 25X21,65
55 084780 5117046.. Ventola 254-34 Ventola 254-34
56 092651 5467075.. Fan protection Protezione ventola
57 094574 515R130.. Evaporation water pipe Serpentina evap. acqua di conden.
58 093406 501R417.. Stopper pipe Staffa ssaggio serpentina
58a 093260 543R093.. Stopper pipe Bloccetto ssaggio serpentina
59 093407 682R054.. Condenser ventialtor (VNT2540) Ventilatore condensatore(VNT2540)
60 * 858R066.. Heat exchanger Scambiatore a,c,d,f
60 093571 858R065.. Heat exchanger Scambiatore b,e
61 084078 8057298.. Dehidrator lter Filtro 40 gr
62 0A9459 8457085.. Compressor valve (charge or disch.) Valvola per compressore
63 093430 830R041.. Evaporator 4R 8T Evaporatore 4R 8T 2 circ. a,c,d,f
63 093408 830R043.. Evaporator 5R 8T Evaporatore 5R 8T 2 circ. b,e
64 093278 833R212.. Evaporator tray Vaschetta evaporatore
64a 093409 548R072.. Evaporator tray insulation Isolante per vaschetta evaporatore
65 093777 682R057.. Evaporator fan Ventilatore evaporatore me a,c,d,f
65a 094487 682R087.. Evaporator fan Ventilatore evaporatore ebm b,e
65b 093411 511R011.. Evaporator fan motor Ventola ventilatore evaporatore b,e
66 093326 501R524.. Fan support entry level Staffa motore entry level a,c,d,f
66a 093412 514R123.. Protection fan EBM Griglia EBM per ventilatore evap b,e
67 092174 646R068.. Cavity probe Sonda cella
67a 091061 546R075.. Probe protection Gabbietta per sonda
67b 093547 514R129.. Stopper/spring for heating cable Fermo per cavo riscaldante
68 093428 617R064.. Heating element with thermostat Resistenza con termost. 500w a,c,d,f
68 093413 617R063.. Heating element with thermostat Resistenza con termost. 750w b,e
69 093487 514R116.. Thermostat spring Molla per ssaggio termostati
70 093572 514R110.. Heating element spring 4R Molla per ssaggio resistenza 4R a,c,d,f
70 093548 514R109.. Heating element spring 5R Molla per ssaggio resistenza 5R b,e
70a 093414 501R386.. Air conveyor Deviatore aria up to 228100....
71 088557 6487271.. Contactor Teleruttore
FREEZER 1400LT
From Ser. Nr.43510001
Up to Ser. Nr....
Ed. 2015/03/25 Page: 8
Doc No: 560112
STANDARD CABINETS
Pos Code Factory code Description Descrizione Ref/notes
72 093573 501R449.. Evaporator convoyer 3 holes Convogliatore evap. 3 fori a,c,d,f
72a 093314 501R448.. Evaporator convoyer 2 holes Convogliatore evap. 2 fori b,e
73 093528 639R099.. Clamp Morsettiera
74 093261 835R241.. Evaporator cover Assieme Calotta
75 093262 14701R0.. Gasket cover ( neoprene 8x13,3) Neoprene espa. 8x13,3 nero (M4)
76 093245 2175552.. Cover screw Vite senza punta x plastica 7 -20
77 093263 546R197.. Pipe cover insulation Tamponcino per tubi
78 093976 546R267.. Wiring cover Copertura impianto elettrico
78a 094425 546R265.. Cover Coperchio copertura impianto elettrico
79 092257 694R005.. Electrical lter Filtro antidisturbo
80 093415 617R078.. Drain heating Resistenza scarico condensa
80a 093416 1100670.. Drain heating cable protection Guaina per resistenza scarico con.
82 093489 559R019.. Air blanketing Coibentazione carter
82a 093485 555R056.. Air blanketing (plus) Coibentazione carter aggiunta up to 228100....
83 084987 6947008.. Procon lter LC Filtro Procond tipo LC c
99 * 880R104.. Panel with termoregulator A304 Cruscotto con termoregolat. A304 a,b,f
99 * 880R106.. Panel with termoregulator A430 Cruscotto con termoregolat. A430 d,e
99 * 880R609.. Panel with termoregulator A304 GL Cruscotto con termor.. PV A304 c
100 509R130.. Panel 304 AISI Cruscotto A304 a,b,f,c
100 094436 509R131.. Panel 430 AISI Cruscotto A430 d,e
102 093609 832R101.. Hinge for panel dx Cerniera per cruscotto dx
103 093345 833R209.. Latch Serratura
104 087485 6407121.. Door switch Micro porta up to 228100....
104 094035 640R021.. Door switch Micro porta from 229100....
105 093532
105 093329 646R110.. Thermoregulator Gab/Mass GL Termoregolatore ir33 gab/mass PV c
106 093975 546R266.. Protection led-lamp Protezione
107 093354 501R375.. Bracket support Staffa ss. protez.trmoregolatore
108 0L0113 1400880.. Guarnizione Guarnizione
109 093268 755R039.. Stiker Membrana adesiva
110 092353 546R121.. Door switch protection Protezione micro c
112 093321 639R104.. Clamp Morsetto
113 093610 832R102.. Hinge for panel dx Cerniera per cruscotto dx
117 * 639R068.. Connector 3 ways right Connettore dritto 3 vie
117 * 639R069.. Connector 7 ways right Connettore dritto 7 vie
117 099740 * Connector 7 ways 90° Connettore 90° 7 vie
117 099741 * Connector 5 ways 90° Connettore 90° 5 vie
117 088998 * Connector 3 ways 90° Connettore 90° 3 vie
117 099743 * Connector 3 ways 90° small Connettore 90° 3 vie piccolo
117 099742 * Connector 2 ways 90° Connettore 90° 2 vie
117 091682 * Connector 4 ways 90° Connettore 90° 4 vie
117 091684 * Connector 5 ways 90° Connettore 90° 5 vie
* 093180 639R096.. UK plug converter Convertitore spina UK b,e
118 093270 624R014.. Light power GL Alimentatore PV c
119 093486 639R006.. Clamp one section Morsetto ad una via c
646R108.. Thermoregulator Gab/Mass Termoregolatore ir33 gab/mass a,b,d,e,f
FREEZER 1400LT
From Ser. Nr.43510001
Up to Ser. Nr....
Ed. 2015/03/25 Page: 9
Doc No: 560112
Loading...
