Refrigeration Platform
ELECTROLUX
CRESCENT CUBER
115v 50 HZ
MODEL
KM-75A
AUXILIARY CODE
U - 1
The auxiliary code is the first two characters in the serial number. The first
character indicates the production year. Years progress or regress in alphabetical
order. The series of letters and skipped letters depend on UL listing, production,
and model. See the auxiliary code(s) and corresponding year(s) on the front cover.
The second character indicates significant part changes within the same year.
Base is "1" and this number advances for each change. If there is no significant
part change at the turn of the year, this number starts from "0."
MARKS LOCATED UNDER THE AUXILIARY CODE
- = Part deleted.
x = Part deleted and replaced by "o" part.
o = New part in place of "x" part.
FASTENER PART NUMBER
1
*
SCREWS
F S T 0 3 0 6 F 0
Special treatment (0 - 9)
Material *
1
Length (mm)
Nominal diameter (mm)
Description *
2
Fastener
NUTS & WASHERS
F W S P 0 5 S 0
Special treatment (0 - 9)
Material *
1
Nominal diameter (mm)
Description *
2
Fastener
Material
F: Steel
S: Austenitic stainless steel
M: Martensitic stainless steel
B: Copper alloy
P: Polycarbonate
N: Polyamide
V: PVC
A: ABS
X: Polyacetal
L: Aluminum
2
Description
*
First letter
S: Machine screw
T: Ta p p i ng sc r ew
M: Wood screw
B: Bolt
W: Washer
N: Nut
1
HA
MODEL
INDEX
NO.
: KM-75A
DESCRIPTION
TITLE
: A. ICE CUBER ASSY
MATERIAL OR
MODEL NUMBER
PART
NUMBER
REQ'D NUMBER
S-1,S-2S-3,T-0T-1,U-0 U-1
B ICE MAKING MECHANISM ASSY 118493A01 1 1 1 1
C MECHANICAL BIN SWITCH 369013A01 1 1 -
371151A01 1 1
D WATER CIRCUIT ASSY 253740A01 1 -
253740A02 1 1 1
E REFRIGERATION CIRCUIT 118496A01 1 1 1 1
F CONTROL BOX ASSY 252005A06 1 1 1 1
G LABEL LOCATION 254314S01 1 1 1 1
K ACCESSORIES 1 1 1 1
1 BODY ASSY 118012G01 1 1 1 -
119364G01 1
2 FRONT FRAME 250745-01 1 1 1 1
3 RAIL (L) 117628-01 1 1 1 -
119369P01 1
4 RAIL (R) 117629-01 1 1 1 -
119370P01 1
5 AIR GUARD 470302-02 1 1 1 1
6 GROMMET-PIPE (C) 470311-01 1 1 1 1
SANTOPRENE
(NATURAL)
7 GROMMET-PIPE (B) 470310-01 1 1 1 1
8 GROMMET-PIPE (A) 470309-01 1 1 1 1
9 FRONT PANEL 369014G01 1 1 1 1
10 COLLAR 471009P01 4 4 4 4
11 LOUVER 117635-01 1 1 1 1
12 AIR FILTER 250727G01 1 1 1 1
15 COVER - PIPE 368305-02 1 1 1 1
16 REAR COVER 368313-01 1 1 1 1
SANTOPRENE
(NATURAL)
SANTOPRENE
(NATURAL)
2
HA
MODEL
INDEX
NO.
: KM-75A
DESCRIPTION
TITLE
: A. ICE CUBER ASSY
MATERIAL OR
MODEL NUMBER
PART
NUMBER
REQ'D NUMBER
S-1,S-2S-3,T-0T-1,U-0 U-1
17 REAR PANEL 370654M03 1 1 1 1
18 POWER SUPPLY CORD
19 BUSHING SR-7K-2 420472-02 1 1 1 1
20 SEAL - OVERFLOW 4Y4321P01 1 1 1 1
21 CLAMP 427902-02 5 5 5 5
23 DOOR 369051G01 1 1 1 1
24 TOP PANEL 369005A09 1 1 1 1
KP-30B SJT#16AWG
P00004-01 1 1 1 1
3
4
HA
MODEL
INDEX
NO.
: KM-75A
DESCRIPTION
TITLE
: B. ICE MAKING MECHANISM ASSY
MATERIAL OR
MODEL NUMBER
PART
NUMBER
REQ'D NUMBER
S-1,S-2S-3,T-0T-1,U-0 U-1
1 WATER TANK 117639-01 1 1 1 1
2 BRACKET - FLOAT SWITCH 368339-01 1 1 1 1
3 FLOAT SWITCH 4A3624-02 1 1 1 1
4 PUMP MOTOR PV-0511BHZ1 P00468-01 1 1 1 1
5 ELBOW 417703-01 1 1 1 1
6 CUBE GUIDE (A) 250742-01 2 2 2 2
7 CUBE GUIDE (C) 250740-01 1 1 1 1
8 BRACKET - ICE MAKING 117632-01 1 1 1 1
9 INSULATION - MECHANISM (A)
10 INSULATION - MECHANISM (B)
11 SOLENOID VALVE
12 WATER SUPPLY PIPE (A) 470306-01 1 1 1 1
13 ELBOW 470303-01 1 1 1 1
14 BYPASS PIPE 470308-01 1 1 1 1
15 WATER SUPPLY PIPE (B) 470307-01 1 1 1 1
16 TEE 470312-01 1 1 1 1
17 WATER SUPPLY TUBE 250743-03 1 1 1 1
18 SPRAY GUIDE 252052P03 1 1 1 1
19 SPRAY TUBE 250746-03 1 1 1 1
20 SPRAY TUBE CAP 3A2645-01 1 1 1 1
21 HOSE CLAMP 427443-04 2 2 2 2
22 HOSE CLAMP 427443-05 1 1 1 1
23 HOSE CLAMP 427443-06 1 1 1 1
24 SILICONE HOSE
25 SILICONE HOSE
26 CABLE TIE CV-100 7920-0002 8 8 8 8
27 HOSE CLAMP 427443-07 1 1 1 1
Only available as No.34.
Only available as No.34.
DSVP12N-2NSX-120AL3SR
FDC-90-02-115
L=300 14 DIA x 18 DIA
(CLEAR)
L=30 14 DIA x 18 DIA
(CLEAR)
368347-01 - - - -
368346-01 - - - -
4A3722-01 1 1 1 -
P00018-02 - 1
H11418300 1 1 1 1
H11418030 3 3 3 3
5
HA
MODEL
INDEX
NO.
: KM-75A
DESCRIPTION
TITLE
: B. ICE MAKING MECHANISM ASSY
MATERIAL OR
MODEL NUMBER
PART
NUMBER
REQ'D NUMBER
S-1,S-2S-3,T-0T-1,U-0 U-1
28 ORIFICE 4Y4194P02 1 1 1 1
29 INSULATION/MECHANISM (C)
30 INSULATION/MECHANISM (D)
31 PIPE/OVERFLOW 369038P03 1 1 1 1
32 SILICONE HOSE
33 INSULATION - PUMP
34 INSULATION - MECHANISM 256827P01 1
Only available as No.34.
Only available as No.34.
L=230 14 DIA x 18 DIA
(CLEAR)
Only available as No.34.
3Y2430Z01 - - - -
3Y2431Z01 - - - -
H11418230 1 1 1 1
472395Z01 - - -
6
7
HA
MODEL
INDEX
NO.
1 MECHANICAL SWITCH CASE 369019G01 1 1 -
2 DETECTOR 369020G01 1 1 -
: KM-75A
DESCRIPTION
TITLE
: C. MECHANICAL BIN SWITCH
MATERIAL OR
MODEL NUMBER
PART
NUMBER
371153G01 1 1
371152G01 1 1
REQ'D NUMBER
S-1,S-2S-3,T-0T-1,U-0 U-1
8
9
HA
MODEL
INDEX
NO.
: KM-75A
DESCRIPTION
TITLE
: D. WATER CIRCUIT ASSY
MATERIAL OR
MODEL NUMBER
PART
NUMBER
REQ'D NUMBER
S-1,S-2S-3,T-0T-1,U-0 U-1
1 WATER SUPPLY PIPE 369037G01 1 1 1 1
2 WATER VALVE V19, 1.2L/min P00464-01 1 1 1 1
3 RUBBER GASKET 413854-03 1 1 1 1
4 SOLENOID VALVE
5 DRAIN HOSE 470305-01 1 x1
5 DRAIN HOSE 370704R01 o1 1 1
6 HOSE - VALVE 470304-01 1 1 1 1
7 DRAIN FITTING 4Y1784G01 1 1 1 1
8 CABLE TIE CV-150 7920-0003 3 4 4 4
9 INSULATION/DRAIN 4Y4319Z01 1 1 1 1
10 HOSE CLAMP 427443-05 1 1 1 1
11 HOSE CLAMP 427443-06 1 1 1 1
12 CAP 472250P01 1 1 1
DSVP12N-2NSX-120AL3SR
FDC-90-02-115
EPDM (BLACK) OR
SANTOPRENE
(NATURAL)
SANTOPRENE
(NATURAL)
SANTOPRENE
(NATURAL)
4A3722-01 1 1 1 -
P00018-02 1
10
11
HA
MODEL
INDEX
NO.
: KM-75A
DESCRIPTION
TITLE
: E. REFRIGERATION CIRCUIT
MATERIAL OR
MODEL NUMBER
PART
NUMBER
REQ'D NUMBER
S-1,S-2S-3,T-0T-1,U-0 U-1
1 BASE 370284G01 1 1 1 1
2 COMPRESSOR
3 RUBBER GROMMET 01-245970 463983-01 4 4 4 4
4 BOLT 8x35 436206-03 2 2 2 2
5 CONDENSER P00030-01 1 1 1 1
6 SHROUD 3Y2364M01 1 1 1 1
7 BRACKET - FM 470291-01 1 1 1 1
8 FAN MOTOR M4Q045-CA27-04 P00466-01 1 1 1 1
9 FAN BLADE 200 DIA (22°) P00006-01 1 1 1 1
10 EVAPORATOR ASSY 252014G01 1 1 1 1
11 HOT GAS VALVE AMS-24B12HDU-1 3A2949-01 1 1 1 1
12 COPPER TUBE(A) - HI 368334-01 1 1 1 1
13 TEE 420041-03 1 1 1 1
14 COPPER TUBE(B) - HI 470297-01 1 1 1 1
15 STRAINER P00008-01 1 1 1 1
16 COPPER TUBE(C) - HI 471943M01 1 1 1 1
17 COPPER TUBE(D) - HI 470295-01 1 1 1 1
18 DRIER P00026-01 1 1 1 1
19 HEAT EXCHANGER 368326G01 1 1 1 1
20 COPPER TUBE - HOT GAS
21 INSULATION TUBE
22 THERMISTOR HOLDER 436455-01 1 1 1 1
23 THERMISTOR NBFC-36-H60-1 P00027-01 1 1 1 1
24 INSULATION - THERMISTOR 471010Z01 1 1 1 1
25 CABLE TIE CV-100 7920-0002 2 2 2 2
26 PUSH MOUNT TIE T30RSF 436156-01 1 1 1 1
27 EXPANSION VALVE HFE-5QHD-3 P00318-01 1 1 1 1
QA125K29CAU6-E0GS
COPPER TUBE - HOT GAS
370331G01
COPPER TUBE - HOT GAS
370331G01 L=1100
P00025-01 1 1 1 1
370331M01 1 1 1 1
H71020H11 1 1 1 1
12
HA
MODEL
INDEX
NO.
: KM-75A
DESCRIPTION
TITLE
: E. REFRIGERATION CIRCUIT
MATERIAL OR
MODEL NUMBER
PART
NUMBER
REQ'D NUMBER
S-1,S-2S-3,T-0T-1,U-0 U-1
28 INSULATION TUBE (A) L=200 H73858200 1 1 1 1
29 SEPARATOR 250749-03 2 2 2 2
30 COPPER TUBE - PROCESS(A)
31 STARTING RELAY MM5-E3CH 438849-01 1 1 1 1
32 MOTOR PROTECTOR MST00AKZ-9040 P00363-01 1 1 1 1
33 PROTECTOR COVER 01-242281 P00355-01 1 1 1 1
34 CLAMP 01-236384 438846-01 1 1 1 1
35 CLIP 01-246801 438847-01 1 1 1 1
36 GROMMET SLEEVE 01-245960 463984-01 2 2 2 2
37 EXPANSION VALVE COVER 369332Z01 1 1 1 1
38 COPPER TUBE - DRIER 471179M01 1 1 1 1
39 TEE 417394-01 1 1 1 1
40 PRESSURE SWITCH ACB-1UB29 463180-02 1 1 1 1
41 INSULATION TUBE
42 HOLDER - EXPV 451267-01 1 1 1 1
43 CLAMP 443461-01 1 1 1 1
44 CABLE TIE CV-200 7920-0010 2 2 2 2
COPPER TUBE - PROCESS(A)
471181G01
COPPER TUBE - PROCESS(A)
471181G01 L=100
471181M01 1 1 1 1
7762-1020 1 1 1 1
13
14
HA
MODEL
INDEX
NO.
: KM-75A
DESCRIPTION
TITLE
: F. CONTROL BOX ASSY
MATERIAL OR
MODEL NUMBER
PART
NUMBER
REQ'D NUMBER
S-1,S-2S-3,T-0T-1,U-0 U-1
1 CONTROL BOX 117624-01 1 1 1 1
2 TOGGLE SWITCH KND-203 P00033-01 1 1 1 1
3 FUSE HOLDER BF115 P00014-01 1 1 1 1
4 POWER RELAY G7L-1A-TUB 449000-01 1 1 1 1
5 TRANSFORMER 3A4395-01 1 1 1 1
6 CONTROLLER BOARD P301702 P00013-02 1 1 1 1
7 START CAPACITOR 100 F 160V
8 CABLE TIE CV-200 7920-0010 1 1 1 1
9 FUSE 125/250V 5A P00015-01 1 1 1 1
4Y1175-01 1 1 1 1
15
