SPARE PARTS CATALOGUE
ELECTROLUX PROFESSIONAL
Modular Platform
Viale Treviso, 15
33170 Pordenone - Italy
Fax: +39 0434-380577
PNC Model Ref. Notes
200 372 KCP/G1RU b Gas Pasta Cooker Rapid System 40L 400MM USA
200 373 KCP/G2RU d Gas Pasta Cooker 40+40L Rapid System 800MM USA
200 396 KCP/G1U a Gas Pasta Cooker 40L 400MM USA
200 397 KCP/G2U c Gas Pasta Cooker 40+40L 800MM USA
CATALOGO PARTI DI RICAMBIO
CUOCIPASTA GAS N900 USA
GAS PASTA COOKER N900 USA
Index Indice
Pag. 1 Frame Mobile
Pag. 2 Functional components Componenti funzionali
Pag. 3 Water system/Boiler Impianto acqua/Boiler
Pag. 4 - 5 - 6 - 7 Spare parts list Lista ricambi
Brand / Marchio : Zanussi
Factory code: 9PDX
Da Ser. Nr. / From ser. nr.:.....
Ed. 2015 06
Doc. Nr.:
2 - 25 602
4
21
9
2
3
8
37
36
22
23
24
7
18
29
26
27
25
28
35
38
6
17
34
33
1
7
3
1
1
4
5
1
13
15
13
14
12
32
31
11
19
16
18
28
18
29
27
111
17
12
2
2
2
2
39
Cuocipasta Gas N900
Gas Pasta Cooker N900
Da Ser. Nr. / From ser. nr.:.....
Doc. Nr.:
Page: 1
Ed. 2004 03
2 - 25 602
Cuocipasta Gas N900
Gas Pasta Cooker N900
Da Ser. Nr. / From ser. nr.:.....
Page: 2
Ed. 2007 12
Doc. Nr.:
2 - 25 602
106
113
110
108
116
115
117
112
107
111
109
11
127
105
103
10
101
122
102
O D E
O D E
102
102
102
103
103
102
102
106
12
125
123
119
118
120
102
103
103
102
121
115
11
102
116
10
126
100
115
Cuocipasta Gas N900
Gas Pasta Cooker N900
Da Ser. Nr. / From ser. nr.:.....
Page: 3
Ed. 2015 06
Doc. Nr.:
2 - 25 602
CUOCIPASTA GASN900 USA
GAS PASTA COOKER N900 USA
PNC Model Ref. Notes
200 372 KCP/G1RU b Gas Pasta Cooker Rapid System 40L 400MM USA
200 373 KCP/G2RU d Gas Pasta Cooker 40+40L Rapid System 800MM USA
200 396 KCP/G1U a Gas Pasta Cooker 40L 400MM USA
200 397 KCP/G2U c Gas Pasta Cooker 40+40L 800MM USA
Pos
Factory
Code
6 Dgt
Code
Descrizione Description
Ref. /
Notes
Pagina 1 Page 1
1 0835856900 0C0204 PIEDE FOOT
1A 0508898900 0C0122 PIASTRA DI RINFORZO PER PIEDE PLATE FOR FOOT
2 0529823703 0C0157 FIANCO DESTRO RIGHT SIDE PANEL
3 0529823803 0C0158 FIANCO SINISTRO LEFT SIDE PANEL
4 0527836002 0C0154 RINFORZO FIANCO DESTRO RIGHT SIDE PANEL STIFFENING
5 0527836102 0C0155 RINFORZO FIANCO SINISTRO LEFT SIDE PANEL STIFFENING
6 0147018088 0C1289 ADESIVO STRUTTURALE STRUCTURAL ADHESIVE TAPE
7 0529829301 0C0604 SCHIENALE 400mm BACK PANEL 400mm a b
7 0529829404 0C0162 SCHIENALE 800mm BACK PANEL 800mm c d
8 0870841103 0C0564 RIPIANO / VASCA 400 MM WORKTOP / TANK 400mm a b
8 0870846004 0C0571 RIPIANO / VASCA 800 MM WORKTOP / TANK 800mm c d
9 0831801800 0C0306 CRUSCOTTO 400mm CONTROL PANEL 400mm a b
9 0831801900 0C0305 CRUSCOTTO 800mm CONTROL PANEL 800mm c d
10 0527850500 0C0156 PIASTRA FISSAGGIO FIANCHI SIDE PANEL JOINTING PLATE
11 0529837800 0C0180 MANIGLIA SINISTRA LEFT HANDLE
12 0516860801 0C0138 CERNIERA HINGE, DOOR
13 0516860901 0C0139 CERNIERA HINGE, DOOR
14 0529837300 0C0179 PORTA SINISTRA LEFT DOOR
15 0529836800 0C0177 CONTROPORTA INNER DOOR OVEN
16 0830898200 0C0201 MAGNETE MAGNET, DOOR
17 0543821900 0L0113 GUARNIZIONE X CRUSCOTTO GASKET, CONTROL PANEL
18 0543821000 053816 GUARNIZIONE X MANOPOLA GASKET, KNOB
19 529866902 0C0565 PANNELLO FRONTALE 400mm FRONTAL PANEL 400mm a b
19 529867103 0C0568 PANNELLO FRONTALE 800mm FRONTAL PANEL 800mm c d
20 0831800802 0C0720 ISPEZIONE PILOTA PILOT INSPECTION
20a 0206260400 057382 CORNICE FRAME
20b 0275290025 057400 VETRINO SPIA INSPECTION GLASS
20c 0282217401 057402 GUARNIZIONE PER VETRINO GASKET, GLASS
21 0518801801 053342 MOLLA PER MARCHIO SPRING, LABEL
22 0506864501 004836 FILTRO FONDO BOTTOM FILTER
23 0514848300 054905 MOLLA PER FILTRO FONDO SPRING, FILTER
24 0528822601 0C0559 SGOCCIOLATOIO DRAINING BOARD
25 0548859100 0C0560 GHIERA PER COMMUTATORE RING, KNOB SWITCH
26 0548859001 0C0318 GHIERA PER REG. ENERGIA RING, KNOB ENERGY REGULATOR
Da Ser. Nr. / From ser. nr.:.....
Page: 4
Ed. 2004 03
Doc. Nr.:
2 - 25 602
CUOCIPASTA GASN900 USA
GAS PASTA COOKER N900 USA
PNC Model Ref. Notes
200 372 KCP/G1RU b Gas Pasta Cooker Rapid System 40L 400MM USA
200 373 KCP/G2RU d Gas Pasta Cooker 40+40L Rapid System 800MM USA
200 396 KCP/G1U a Gas Pasta Cooker 40L 400MM USA
200 397 KCP/G2U c Gas Pasta Cooker 40+40L 800MM USA
Pos
Factory
Code
27 0218912211 069567 MOLLETTA PER GHIERA RING, RING KNOB
28 0548856800 0C0257 MANOPOLA KNOB
29 0214590701 025245 MOLLETTA X MANOPOLA SPRING, KNOB
30 0510819707 0C0131 GRIGLIA CAMINO PICCOLO GRID, SMALL CHIMNEY a b
30 0510819801 0C0508 GRIGLIA CAMINO GRANDE GRID, LARGE CHIMNEY c d
31 0529837700 0C0463 MANIGLIA DESTRA RIGHT HANDLE c d
32 0529837201 0C0567 PORTA DESTRA RIGHT DOOR c d
33 0541810600 0C0187 TAPPO POSTERIORE RIPIANO STOPPER
34 0516860700 0C0137 PIASTRA GIUNZIONE APPARECC. JOINTING REAR PLATE
35 0830857503 056918 CESTO CUOCIPASTA TONDO 1/6 ROUND BASKET 1/6; PASTA COOKER
35 0830857403 056917 CESTO CUOCIPASTA TONDO 1/3 ROUND BASKET 1/3; PASTA COOKER
36 0830857104 056915 CESTO CUOCIPASTA GN1/3 BASKET GN1/3; PASTA COOKER
36 0830857204 056916 CESTO CUOCIPASTA GN1/2 BASKET GN1/2; PASTA COOKER
37 F927216 056920 CESTO CUOCIPASTA GN1/1 BASKET GN1/1; PASTA COOKER
38 F927219 056922 GRIGLIA DI FONDO FALSE BOTTOM, PASTA COOKER
39 0147098044 006083 SIGILLANTE ADESIVO, PORTE ADHESIVE SILICON, DOOR
6 Dgt
Code
Descrizione Description
Ref. /
Notes
Pagina 2 Page 2
51 0830816203 004847 BRUCIATORE BURNER
52 0514829700 054118 PORTAUGELLO INJECTOR HOLDER
53 0214105101 020997 CONTRODADO LOCK NUT
54 0506833401 054029 GUARNIZIONE GASKET
55 0830828001 054039 AERATORE AERATOR
56 0835863100 0C1398 VALVOLA GAS GAS VALVE
57 0830873200 002074 RACCORDO PIPE FITTING
58 0853859802 0C0562 RIBALTA 400mm MANIFOLD 400mm a b
58 0853861502 0C0569 RIBALTA 800mm MANIFOLD 800mm c d
59 0830807000 002781 RACCORDO PIPE FITTING
60 0806825300 0C0704 CONDUTTURA GAS FLESSIBILE PIPE GAS, FLEXIBLE
61 0215073101 060325 BICONO DOUBLE CONE
62 0514829301 0A2125 DADO NUT
63 0830828100 054032 BRUCIATORE PILOTA PILOT BURNER
64 0330272401 052610 ELETTRODO; ACCENSIONE ELECTRODE
65 0214164101 057960 RACCORDO PIPE FITTING
66 0830852201 025031 TERMOCOPPIA THERMOCOUPLE
67 0515827401 053665 BICONO DOUBLE CONE
Da Ser. Nr. / From ser. nr.:.....
Page: 5
Ed. 2007 12
Doc. Nr.:
2 - 25 602
CUOCIPASTA GASN900 USA
GAS PASTA COOKER N900 USA
PNC Model Ref. Notes
200 372 KCP/G1RU b Gas Pasta Cooker Rapid System 40L 400MM USA
200 373 KCP/G2RU d Gas Pasta Cooker 40+40L Rapid System 800MM USA
200 396 KCP/G1U a Gas Pasta Cooker 40L 400MM USA
200 397 KCP/G2U c Gas Pasta Cooker 40+40L 800MM USA
Pos
Factory
Code
68 0517848901 0C0435 CONDUTTURA PILOTA PIPE, PILOT
69 0214164400 052125 RACCORDO PIPE FITTING
70 0215199700 052127 BICONO DOUBLE CONE
71 0624806600 006121 ACCENDITORE 120V IGNITER 120V
72 0638832401 002544 CAVO ELETTRODO SPARK PLUG CABLE
73 0830831400 054539 CONSENSO ACCENSIONE VALVOLA IGNITION VALVE
74 0639805900 059794 MORSETTIERA TERMINAL BOARD a c
74 0639812600 0C5568 MORSETTIERA TERMINAL BOARD b d
75 0452140500 057783 FUSIBILE FUSE a c
75 0652803300 0C1480 FUSIBILE FUSE b d
76 0648803001 058857 RELE’ RELAY
77 0624807900 0C0886 TRASFORMATORE TRANSFORMER
79 0648807500 0C1399 CONTATTORE CONTACTOR b d
80 0699801001 055016 REGOLATORE DI ENERGIA ENERGY REGULATOR
81 0641802400 059544 COMMUTATORE; 4 POS. SELECTOR; 4 POS.
82 0876800002 005010 LAMPADA SPIA VERDE PILOT LAMP; GREEN
83 0546811100 003704 MANOPOLA VALVOLA GAS KNOB GAS VALVE
84 0543820001 003705 GUARNIZIONE MANOPOLA VALVOLA GASKET, VALVE KNOB
85 - 006100 BOBINA VALVOLA SIT 60HZ COIL GAS VALVE SIT 60HZ
86 0835850200 006135 REGOLATORE DI PRESSIONE PRESSURE REGOLATOR
87 0835850300 006136 MOLLA BLU, 12,5...30mbar (5”...12”wc) BLUE SPRING, 12,5...30mbar (5”...12”wc)
6 Dgt
Code
Descrizione Description
Ref. /
Notes
88 0835850400 006137 VALVOLA SFERA VALVE
89 0516882500 0C4877 RACCORDO TERMOCOPPIA/VALVOLA PIPE FITTING THERMOCOUPLE/VALVE
Pagina 3 Page 3
100 0528876800 0C4151 COPERTURA ELETTROVALVOLA WATER VALVE PROTECTION since s/n 650
101 0696807000 0C4436 ELETTROVALVOLA MAGNETIC VALVE
102 0835823600 * FASCETTA HOSE CLAMP
103 0140068006 055445 TUBO GOMMA TELATO DIA.12mm HOSE, DIA.12mm
104 0544810601 0C2950 RACCORDO A 3 VIE CONNECTION, 3 WAY see PDX2005-04
105 0516863503 0C0721 GETTO ACQUA WATER TAP see PDX2006-09
106 0516812500 0C0690 CONTRODADO OTTONE LOCK NUT
107 0543826500 005921 GUARNIZIONE GASKET
108 0835849800 005919 VALVOLA SCARICO VALVE, DRAIN
109 0230645404 0C0722 MANICOTTO COUPLING
110 0806805000 004728 RACCORDO PIPE FITTING
Da Ser. Nr. / From ser. nr.:.....
Page: 6
Ed. 2007 12
Doc. Nr.:
see PDX2006-19
2 - 25 602
CUOCIPASTA GASN900 USA
GAS PASTA COOKER N900 USA
PNC Model Ref. Notes
200 372 KCP/G1RU b Gas Pasta Cooker Rapid System 40L 400MM USA
200 373 KCP/G2RU d Gas Pasta Cooker 40+40L Rapid System 800MM USA
200 396 KCP/G1U a Gas Pasta Cooker 40L 400MM USA
200 397 KCP/G2U c Gas Pasta Cooker 40+40L 800MM USA
Pos
115a 0806862100 0C4143 ESPANSIONE PRESSOSTATO EXPANSION CONTAINER since s/n 642
Factory
Code
111 0835821900 056887 IMPUGNATURA HANDLE
112 0853860801 0C0563 MANIGLIA SCARICO HANDLE, DRAIN
113 0544801101 056888 CONDUTTURA PIPE
114 0518602700 * FASCETTA HOSE CLAMP
115 0643813100 0C0872 PRESSOSTATO PRESSURE SWITCH
116 0544807800 0C0723 TUBO SILICONE HOOSE, SILICON, INNER
117 0527840302 0C0724 SUPPORTO X PRESSOSTATO SUPPORT, PRESSOSTAT
118 0617830100 0C1848 RESISTENZA/FUSIBILE 3000W/128°C HEATING ELEMENT/FUSE 3000W/128°C see PDX2005-03
119 0543800700 046213 GUARNIZIONE OR GASKET, O-RING b d
120 0873829403 0C0566 BOILER BOILER till s/n 702
0873882800 0C4222 BOILER CON SCARICO BOILER WITH DRAIN PIPE since s/n 702
121 0835848500 005902 VALVOLA DI SCARICO DRAIN VALVE since s/n 702
122 0516872000 0C1626 PORTAGOMMA RUBBER HOLDER
123 0516886300 0C3152 RIDUTTORE DI PORTATA D.0,95 WATER FEED REGULATOR see PDX2005-09
124 0806862800 0C4113 FILTRO PER ACQUA 3/4” WATER FILTER 3/4” since s/n 650
125 0856806400 0C3151 CONDIZ. MAGNETICO ACQUA WATER MAGNETIC CONDITIONER see PDX2005-08
126 0W00526600 0E5431 RACCORDO 1/2”-3/4” CONNECTION 1/2”-3/4”
127 0516872000 0C1626 PORTAGOMMA RUBBER HOLDER Up to 752…
127 0510828000 0C5564 PORTAGOMMA RUBBER HOLDER From 801…
6 Dgt
Code
Descrizione Description
Ref. /
Notes
see PDX2007-01
b d
see PDX2005-05
see PDX2007-10
see PDX2007-10
see PDX2007-02
** 633845100 0C8644 CABLAGGIO ELETTRICO WIRING HARNESS / EL. CABLES a
** 633832401 002544 CABLAGGIO ELETTRICO WIRING HARNESS / EL. CABLES b
** 633845200 0C6035 CABLAGGIO ELETTRICO WIRING HARNESS / EL. CABLES c
** 633802302 * CABLAGGIO ELETTRICO WIRING HARNESS / EL. CABLES d
Da Ser. Nr. / From ser. nr.:.....
Page: 7 Ed. 2015 06
Doc. Nr.:
2 - 25 602
