From sr. Nr/ Da Ser. Nr.: 015
From status level / Da scatto: 07 Page: 1 Ed. 2016 02
Doc. Nr.: 875400F00
SPARE PARTS CATALOGUE
CATALOGO PARTI DI RICAMBIO
06 GN 1/1 GAS CONVECTION / STEAM OVEN
FORNO CONVEZIONE / VAPORE GAS 06 GN 1/1
PNC
Model
Ref
Group
Level
Page
Notes
236700
FCZ061GKG1
b1
FCZ
Level K
2…11
230V 50Hz STD
236710
FCZ061GKD1
c1
FCZ
Level K
2…11
230V 50Hz LPG
236800
FCZ061GKZA
d1
FCZ
Level K
2…11
230V 50Hz AUS
237700
FCZ061GTG
a
FCZ
Touch
2…11
230V 50Hz STD
237710
FCZ061GTD
b
FCZ
Touch
2…11
230V 50Hz LPG
237780
FCZ061GTW
q1
FCZ
Touch
2…11
230V 50Hz UK
237800
FCZ061GTZA
e1
FCZ
Touch
2…11
230V 50Hz AUS
238700
FCZ061GBG2
c
FCZ
Level B
2…11
230V 50Hz STD
238710
FCZ061GBD2
d
FCZ
Level B
2…11
230V 50Hz LPG
238720
FCZ061GBL2
e
FCZ
Level B
2…11
100V 50/60Hz JAP LPG
238800
FCZ061GBZA
f1
FCZ
Level B
2…11
230V 50Hz AUS
239700
FCZ061GCG2
f
FCZ
Level C
2…11
230V 50Hz STD
239710
FCZ061GCD2
g
FCZ
Level C
2…11
230V 50Hz LPG
239800
FCZ061GCZA
g1
FCZ
Level C
2…11
230V 50Hz AUS
239810
FCZ061GCGS
o1
FCZ
Level C
2…11
230V 50Hz no clean
266700
AOS061GKG1
v
AOS
Level K
2…11
230V 50Hz STD
266710
AOS061GKD1
z
AOS
Level K
2…11
230V 50Hz LPG
266750
AOS061GKP1
a1
AOS
Level K
2…11
120V 60Hz USA
266760
AOS061GKP1
p1
AOS
Level K
2…11
120V 60Hz USA
266800
AOS061GKTA
h1
AOS
Level K
2…11
230V 50Hz AUS
267700
AOS061GTG1
h
AOS
Touch
2…11
230V 50Hz STD
267710
AOS061GTD1
i
AOS
Touch
2…11
230V 50Hz LPG
267750
AOS061GTP1
l
AOS
Touch
2…11
120V 60Hz USA
267780
AOS061GTW1
m
AOS
Touch
2…11
230V 50Hz UK
267800
AOS061GTZA
i1
AOS
Touch
2…11
230V 50Hz AUS
268700
AOS061GBG2
n
AOS
Level B
2…11
230V 50Hz STD
268710
AOS061GBD2
o
AOS
Level B
2…11
230V 50Hz LPG
268780
Aos061GBW2
p
AOS
Level B
2…11
230V 50Hz UK
268800
AOS061GBZA
l1
AOS
Level B
2…11
230V 50Hz AUS
269700
AOS061GCG2
q
AOS
Level C
2…11
230V 50Hz STD
269710
AOS061GCD2
r
AOS
Level C
2…11
230V 50Hz LPG
269750
AOS061GCP1
u
AOS
Level C
2…11
120V 60Hz USA
269780
AOS061GCW2
t
AOS
Level C
2…11
230V 50Hz UK
269790
AOS061GCY2
s
AOS
Level C
2…11
230V 50Hz Bakery
269800
AOS061GCZA
m1
AOS
Level C
2…11
230V 50Hz AUS
269810
AOS061GCGS
n1
AOS
Level C
2…11
230V 50Hz no clean
Pag
Index
Indice
Note
2
3
4
5
6
7...11
Oven cabinet and door.
Water system
Boiler
Electrical components
Accessories
Spare parts list
Cella forno e porta
Impianto idraulico
Boiler
Componenti elettrici
Accessori
Lista ricambi
Brand/Marchio: All
Factory code: 9PDD
From sr. Nr/ Da Ser. Nr.: 015
From status level / Da scatto: 07 Page: 2 Ed. 2016 02
Doc. Nr.: 875400F00
From sr. Nr/ Da Ser. Nr.: 015
From status level / Da scatto: 07 Page: 3 Ed. 2016 02
Doc. Nr.: 875400F00
From sr. Nr/ Da Ser. Nr.: 015
From status level / Da scatto: 07 Page: 4 Ed. 2016 02
Doc. Nr.: 875400F00
GAS
POS. A1
CELLA/CAVITY
POS. A1
BOILER
POS. A2
CELLA/CAVITY
POS. A2
BOILER
G20 0C4630 (FUCSIA/FUCHSIA) 0C4630 (FUCSIA/FUCHSIA) 0C2445 (ø 6) 0C2445 (ø 6)
G25 0C4630 (FUCSIA/FUCHSIA) 0C4630 (FUCSIA/FUCHSIA) 0C5235 (ø 6,75) 0C5235 (ø 6,75)
G30 0C4630 (FUCSIA/FUCHSIA) 0C4630 (FUCSIA/FUCHSIA) 0C4383 (ø 5.25) 0C4384 (ø 4,75)
LPG 0C4630 (FUCSIA/FUCHSIA) 0C4630 (FUCSIA/FUCHSIA) 0C2442 (ø 5.5) 0C4385 (ø 5)
DIAFRAMMA/DIAPHRAGM
AERATORE/AERATOR
From sr. Nr/ Da Ser. Nr.: 015
From status level / Da scatto: 07 Page: 5 Ed. 2016 02
Doc. Nr.: 875400F00
From sr. Nr/ Da Ser. Nr.: 015
From status level / Da scatto: 07 Page: 6 Ed. 2016 02
Doc. Nr.: 875400F00
From sr. Nr/ Da Ser. Nr.: 015
From status level / Da scatto: 07 Page: 7 Ed. 2016 02
Doc. Nr.: 875400F00
06 GN 1/1 GAS CONVECTION / STEAMER OVEN
FORNO CONVEZIONE / VAPORE GAS 06 GN 1/1
Pos
Factory
Code
6DGT
Code
Descrizione
Description
Ref./Note
Pagina 2
Page 2
1
0530891500
0C6179
COPERCHIO
COVER
1
0530891700
0C6181
COPERCHIO
COVER
For Level C ,K
2
0530890800
0C6173
FIANCO DX
RIGHT SIDE PANEL
3
0530892600
0C6189
SCHIENALE
BACK PANEL
4
0530893200
0C6195
FIANCO SX
LEFT SIDE PANEL
5
0831850900
0C4892
PIEDINO
FOOT
From 2008/01
up to 2012/18
5
0831842202
0C4233
PIEDINO
FOOT
Up to 2007/52
from 2012/19
6
0806847803
0C4234
CERNIERA SUPERIORE
UPPER HINGE
7
0806861600
0C4235
CERNIERA INFERIORE
LOWER HINGE
8
0873869802
0C6395
VETRO INTERNO
INNER GLASS
9
0878863808
0C4962
PORTA COMPLETA (NO VETRO EST)
COMPLETE DOOR (NO EXT GLASS)
-
0518806205
0C6051
MOLLA FERMAVETRO INTERNO
SPRING FOR INTERNAL GLASS
10
0806859202
0C4478
PROFILO DX-SX
RIGHT AND LEFT TRIM
11
0574817203
0C6558
VETRO ESTERNO
EXTERNAL GLASS
for Group AOS
11
0574818301
0C4942
VETRO ESTERNO
EXTERNAL GLASS
for Group FCZ
12
0543839700
0C4088
GUARNIZIONE FLANGIA SPILLONE
GASKET
13
0543828001
006976
AMMORTIZZATORE
DAMPER
14
0806822000
007007
CERNIERA VETRO INTERNO
HINGE, INNER GLASS
15
0835871801
0C4089
GR.CHIUSURA A SCATTO 'HRS'
CLOSING MECHANISM
16
0510824200
0C4237
SUPPORTO GR.CHIUSURA
SUPPORTO
17
0548871501
0C4090
MANIGLIA CHIUSURA A SCATTO
DOOR HANDLE
18
0516896401
0C4238
DADO FISSAGGIO
NUT FOR DOOR CATCHER
19
0546822600
0C4091
TAPPO PER MANIGLIA 'HRS'
DOOR COVER HANDLE
20
0806859900
0C4092
NASELLO SINGOLO SCATTO
DOOR CATCHER
21
0699603700
049627
MAGNETE
MAGNET
22
0543841300
0C4094
VASCHETTA RACC.CONDENSA
DOOR DRAIN TRAY
23
0543833900
0C1496
GUARNIZIONE CELLA-PORTA
GASKET
-
0147098067
003926
SIGILLANTE (RED)
RED SEALANT
24
0831846804
0C4502
PARETE DI ASPIRAZIONE
SUCTION WALL
26
0518808600
0C1740
FILTRO FONDO
FILTER
27
0654600000
049621
INTERRUTTORE MAGNETICO
MAGNETIC SWITCH
28
0831831001
0C4240
SPILLONE CURVO MULTIPOINT
MEAT PROBE MULTI POINT
for Level Touch, p1
28
0831830700
0C4241
SPILL. CURVO SINGOLO PUNTO
MEAT PROBE SINGLE POINT
for Level B e C,K
29
0518816600
0C4822
SUPPORTO SPILLONE
MEAT PROBE SUPPORT
30
0856814000
0C4242
BACINELLA SNODABILE
DRAIN TRAY
31
0806858800
0C4243
TUBO PER CONDENSA 1/1
DRAIN TUBE
32
0516855300
006991
DADO SONDA CELLA
NUT, CAVITY PROBE
33
0516809301
002701
TENUTA SONDA
PROBE GASKET
for Level Touch e B
34
0214105101
020997
CONTRODADO PORTAUGELLO
LOCK NUT
35
0508838701
002700
RONDELLA SONDA CELLA
WASHER
36
0543816300
002624
GUARN. PER TENUTA SONDA
GASKET
37
0516809400
002623
RACCORDO SONDA CELLA
CONNECTION, CAVITY PROBE
38
0518818000
0C8561
MOLLA PER CHIUSURA
SPRING
41
0806857201
0C4244
COND. SONDA LAMBDA
FLANGE TUBE
for level Touch
42
0543838300
0C4093
GUARNIZIONE BYPASS/LAMBDA
GASKET
44
0543841300
0C4094
GUARN. VASC. CONDENSA
GASKET
45
0806873000
0C6351
CONDOTTO FLANGIATO BY-PASS
DUCT, BYPASS PROBE
for Level B
46
0543828901
007005
GUARN. CONDOTTO ARIA-COP.
GASKET, DUCT
47
0611809000
0C5287
MOTORE
MOTOR
forl Level C,K
47
0611806001
006998
MOTORE
MOTOR
for Level Touch, B
47
0611806901
0C1882
MOTORE
MOTOR
for 100V, 120V models
48
0543816700
002873
O RING
O RING
49
0516808902
002699
CUSCINETTO
BEARING
50
0538815400
0C4138
FLANGIA FISS.TENUTA MOTORE
FLANGE
51
0835400C00
0C7029
VENTOLA
FAN
From sr. Nr/ Da Ser. Nr.: 015
From status level / Da scatto: 07 Page: 8 Ed. 2016 02
Doc. Nr.: 875400F00
06 GN 1/1 GAS CONVECTION / STEAMER OVEN
FORNO CONVEZIONE / VAPORE GAS 06 GN 1/1
Pos
Factory
Code
6DGT
Code
Descrizione
Description
Ref./Note
52
0831829303
0C4255
SCAMBIATORE
HEAT EXCHANGER
53
0543840500
0C4095
GUARNIZIONE
GASKET
54
0543831301
0C1132
GUARNIZIONE
GASKET
55
0527898900
0C4857
PIASTRA CHIUSURA
FLANGE
for Level C,K
56
0516892000
0C6296
PERNO SPILLONE
PROBE PIN
57
0856828301
0C4974
CONDOTTO UMIDIFICATORE
HUMIDIFIER PIPNG
for Level C ,K
58
0516887101
0C6228
DADO CONDOTTO
NUT HUMIDIFIER
for Level C,K
59
60
0543844600
0856810702
0C6200
0C4868
GUARNIZIONE CAMINO
ADATTATORE CAMINO
GASKET
ADPTER FOR CHIMNEY
For Australia models
61 * 0C6465
KIT SONDA LAMBDA
LAMBDA KIT
for level TOUCH
62
0835872002
0C4477
ASSIEME CHIUSURA PORTA
COMPLETE CLOSING MECH.
Up to 6081…
62
0835402M00
*
ASSIEME CHIUSURA PORTA
COMPLETE CLOSING MECH.
From 6091…
63
0830400600
0C6572
MANIGLIA COMPLETA
COMPLETE DOOR HANDLE
for FCZ Group
63
0830400500
0C6569
MANIGLIA COMPLETA
COMPLETE DOOR HANDLE
for AOS Group
64
0830898902
0C6538
SENSORE TEMPERATURA
TEMP. PROBE
65
0830899101
0C6539
SENSORE TEMPERATURA
TEMP. PROBE
66
0543400900
0C7016
GUARNIZIONE PER TUBO
PIPE GASKET
67
0543816601
002692
TAPPO CARICO DISINCROST.
RECHARGE CAP FOR SCALER
68
0543843201
0C4965
GOMMINO CHIUSURA ING.DISIN
GASKET
Pagina 3
Page 3
100
0696808300
0C5516
ELETTROVALVOLA
WATER VALVE
for Level Touch,B
-
0544819400
0C5829
TUBO EPDM BLU
BLU PIPE EPDM
-
0835872300
0C5385
FASCETTA NORMACLAMP
NORMACLAMP
101
0543840600
0C4096
GUARNIZIONE FILTRO
GASKET
102
0549801800
0C2312
VALVOLA NON RITORNO
NOT RE-FLOW VALVE
103
0516879400
0C2313
RACCORDO ENTRATA ACQUA
PIPE FITTING
for Level Touch,B
105
0831811400
0C1155
ASSIEME FILTRO
FILTER
106
0516896101
0C4198
RACCORDO PORTAGOMMA
PIPE FITTING
107
0544809000
0C1117
VALVOLA NON RITORNO
NOT RE-FLOW VALVE
108
0516871900
0C1116
RACCORDO PER POMPA
CONNECTION, PUPM
109
0543832300
0C1935
O-RING
O-RING
110
0680801201
0C2341
POMPA
PUMP
110
0680801301
0C2342
POMPA
PUMP
for 60Hz models
116
0805400200
0C6202
ASS. COLLETTORE LAVAGGIO
CONNECTION
117
0806871100
0C6031
ASS. SUPP. GETTO LAVAGGIO
SUPPORT
118
0543841400
0C4201
GUARNIZIONE IN RAME
GASKET
119
0516898301
0C4467
CUSCINETTO GETTO ROTANTE
BEARING
120
0516896000
0C4202
DADO
NUT
121
0806873900
0C5503
GETTO ROTANTE
ROTATING WASHING JET
122
0518807100
007026
MOLLA
SPRING
123
0544808100
0C1151
TAPPO PER SERBATOIO BLU
BLUE CUP
124
0544808200
0C1152
TAPPO PER SERBATOIO ROSSO
RED CUP
125
0873857102
0C4426
SERBATOIO DETERGENTE-BRIL
TANK
126
0544808900
0C1154
PARATIA PER SERBATOIO ROSSO
RED BULKHEAD
127
0544808400
0C1153
PARATIA PER SERBATOIO BLU
BLUE BULKHEAD
129
0H22982600
007012
TUBO UMIDIFICATORE
HUMIDIFIER PIPE
for Level Touch, B
129
0856828600
0C4977
TUBO UMIDIFICATORE
HUMIDIFIER PIPE
for Level C,K
130
0696808800
0C6170
ELETTROVALVOLA
WATER VALVE
for Level B
130
0696808200
0C5515
ELETTROVALVOLA
WATER VALVE
for Level C,K
131
0831857200
0C6370
ASS. COLLETTORE LAVAGGIO
CONNECTION,C.S.
132
0696808600
0C6374
GRUPPO VALVOLE CLEANING
VALVE GROUP C.S.
For level Touch,B
132
0696400100
0C6373
GRUPPO VALVOLE CLEANING
VALVE GROUP C.S.
for Level Touch USA
132
0696400300
0C6406
GRUPPO VALVOLE CLEANING
VALVE GROUP C.S.
for Level C,K
132
0696400500
0C6408
GRUPPO VALVOLE CLEANING
VALVE GROUP C.S.
for Level C ,K USA
133
0546825100
0C6222
FORCELLA SICUREZZA
CLIP 134
0646817200
0C6217
PRESSOSTATO ATTACCO RAPIDO
CONNECTION FOR WASH ARM
135
0513805000
0C5426
STAFFA SUPPORTO SERBATOIO
SUPPORT PLATE
136 - 0C6467
KIT GANCIO SERBATOIO
KIT TANK HOOK
137 - 0C6375
KIT PARZIALIZZATORI DI FLUSSO
FLOW REDUCER KIT
From sr. Nr/ Da Ser. Nr.: 015
From status level / Da scatto: 07 Page: 9 Ed. 2016 02
Doc. Nr.: 875400F00
06 GN 1/1 GAS CONVECTION / STEAMER OVEN
FORNO CONVEZIONE / VAPORE GAS 06 GN 1/1
Pos
Factory
Code
6DGT
Code
Descrizione
Description
Ref./Note
138 - 061303
KIT O-RING +BUSSOLA
O-RING +BUSH KIT
139
0219035015
0C6421
ANELLO ELASTICO
ELASTIC RING
140
0505401R00
0C7924
PIASTRINA FISSAGGIO POMPE
FIXING PLAQUE
141
0544400C01
0C8348
VITE TTL
TTL SCREW
Up to 5151…
141
0544400C02
0CA348
VITE TTL
TTL SCREW
From 5161…
141a
0546400J00
0C9538
CAPPUCCIO DI PROTEZIONE
PROTECTION CAP
142
0543400R00
0C7925
PASSACAVO
WIRING BUSH
143
0546814600
0C2309
TUBO EXT
EXT. PIPE
144
0246530100
005382
GOMMINO
GASKET
145
0544819400
0C5829
TUBO EPDM BLU
EPDM PIPE
146
0686400100
0C8347
POMPA DEFOND PHOENIX
PHOENIX DEFOND PUMP
Up to 4441…
146
0686400201
0CA112
POMPA CEME
CEME PUMP
From 4451…
147
0835400L00
0C8683
GRUPPO ENTRATA ACQUA
GROUP WATER INLET
147
0835400M00
0C8684
GRUPPO ENTRATA ACQUA
GROUP WATER INLET
For level C,K
-
0831854100
0C5562
TUBO ACQUA WRAS
WATER INLET PIPE WRAS
-
0835870400
0C3464
RIDUTTORE DI PRESSIONE
WATER PRESSURE REDUCER
Pagina 4
Page 4
200
0878401A00
0C9666
KIT ASSIEME BOILER
BOILER ASS.Y KIT
for Level Touch, B
200
0878401700
-
KIT ASSIEME BOILER
BOILER ASS.Y KIT
q1
201
0560852803
0C4097
KIT ISOLAMENTO
KIT ISOLATION
for Level Touch, B
202
0543816601
002692
TAPPO
STOPPER
for Level Touch, B
203
0543817500
002634
GUARNIZIONE
GASKET
for Level Touch, B
204
0830890500
007033
SONDA DI LIVELLO
LEVEL PROBE
for Level Touch, B
205
0516868600
0C1063
RACCORDO
CONNECTION
for Level Touch, B
206
0696804201
0C0882
VALVOLA DI SCARICO 230V
DRAIN VALVE 230V
for Level Touch, B
206
0696808500
0C5518
VALVOLA DI SCARICO 240V
DRAIN VALVE 240V
for Level Touch,B 60Hz
207
0516868500
0C1062
MANICOTTO 1"-3/4"
CONNECTION 1"-3/4"
for Level Touch, B
208
0510828000
0C5564
RESCA D10 FILETT 1/4' GAS
PIPE CONNECTION
209
0516879600
0C4099
UGELLO 'ELPIS'1/4'FD3.5-3/8'M
NOZZLE
for Level Touch, B
210
0543842600
0C4872
TAPPO PER SENSORE
STOPPER FOR SENSOR
for Level Touch, B
211
0546821401
-
PANNELLO FRONTALE INFERIORE
PANEL
Level B,C,K
212
0543400000
0C7033
GUARNIZIONE PORTELLO
GASKET
for level TOUCH
213
0546815103
0C4532
PANNELLO FRONTALE INFERIORE
PANEL
for Level Touch
214
0873881200
0C4248
DOCCETTA
SHOWER
for Level Touch
up to 5201...
214
0875402G00
0CA407
DOCCETTA
SHOWER
for q1 and m
from 5211...
215
0543838200
0C4101
GUARNIZIONE BRUCIATORE LWZ
GASKET
216
0831827502
0C4289
BRUCIATORE
BURNER
217
0543838100
0C4102
GUARNIZIONE PER VENTILATORE
FAN GASKET
218
0538818602
0C4258
FLANGIA VENTILATORE
FAN FLANGE
219
0611808300
0C4103
VENTILATORE
FAN
220
0831846400
0C4461
CANDELINA DI ACC. E RIL.
IGNITION ROD
for Level Touch, B
220
0831846502
0C4462
CANDELINA DI ACC. E RIL.
IGNITION ROD
for Level C,K
221
0543816800
002874
ANELLO DI TENUTA OR
O-RING
for Level Touch, B
222
0518807600
0C1044
MOLLA
SPRING
for Level Touch, B
223
0835859601
0C1057
VALVOLA GAS
GAS VALVE
223
0835867200
0C1879
VALVOLA GAS
GAS VALVE
for USA Version
224
0543840600
0C4096
GUARNIZIONE
GASKET
225
0543841100
0C4104
GUARNIZIONE CANDELINA
ROD GASKET
226
0624810800
0C4260
CENTRALINA
IGNITION BOARD
227
0516847000
0C1058
DADO
NUT
228
0515801715
052671
BICONO X TUBO DA 16
SEAL
229
0624810600
0C4105
ACCENDITORE BRAHMA
IGNITION BOARD
230
0517877101
0C1054
CONDUTTURA L= 398MM
PIPE L= 398MM
for Level Touch, B
230
0517877001
0C1084
CONDUTTURA L= 330MM
PIPE L= 330MM
for Level Touch, B
231
0J89061403
0C3443
PORTELLO ISPEZIONE
INSPECTION COVER
for Level Touch
232
0527898700
0C4856
FLANGIA CHIUS. FORO BOILER
FLANGE
For Level C,K
233
0543842800
0C4963
GUARN. CHIUSURA FORO BOILER
GASKET
For Level C,K
From sr. Nr/ Da Ser. Nr.: 015
From status level / Da scatto: 07 Page: 10 Ed. 2016 02
Doc. Nr.: 875400F00
06 GN 1/1 GAS CONVECTION / STEAMER OVEN
FORNO CONVEZIONE / VAPORE GAS 06 GN 1/1
Pos
Factory
Code
6DGT
Code
Descrizione
Description
Ref./Note
234
235
0527878700
0543839200
0C6449
0C6450
FLANGIA CHIUS.FORO BOILER
GUARN.CHIUS.FORO BOILER
FLANGE
GASKET
for Level Touch, B
For Level Touch.B
236
0830899101
0C6539
SONDA BYPASS 1100 BIANCO
BYPASS PROBE 1100mm WHITE
for Level TOUCH, B
Pagina 5
Page 5
300
0806874001
0C5600
MANOPOLA
HANDLE
301
0214114900
051263
CONTRODADO
LOCK NUT
302
0508836400
002727
RONDELLA
DISK 303
0516807301
002662
BOCCOLA
BUSH
304
0548400400
0C6548
MEMBRANA TOUCH AOS MODELS
LAYER TOUCH AOS MODELS
for TOUCH AOS Group
304
0548400B00
0C6551
MEMBRANA TOUCH FCZ MODELS
LAYER TOUCH FCZ MODELS
for TOUCH FCZ Group
304
0548400D00
0C6552
MEMBRANA LIV.B AOS MODELS
LAYER LEV. B AOS MODELS
for Level B AOS Group
304
0675855001
0C4948
MEMBRANA LIV.B FCZ MODELS
LAYER LEV. B FCZ MODELS
for Level B FCZ Group
304
0548400H00
0C6555
MEMBRANA LIV.C AOS MODELS
LAYER LEV. C AOS MODELS
for Level C AOS Group
304
304
0675855102
0548401800
0C4949
0C8083
MEMBRANA LIV.C FCZ MODELS
MEMBRANA LV.C BAKERY MOD
LAYER LEV. C FCZ MODELS
LAYER LEV.C BAKERY MODELS
for Level C FCZ Group
for Level Bakery
304
0548401F00
0C8705
MEMBRANA LIV. TOUCH “K”
LAYER TOUCH “K”AOS MODELS
For Level Touch “K”
AOS Group
305
0873879301
0C6580
CRUSCOTTO LIV.TOUCH +
MEMBRANA
CONT.PANEL LEV. TOUCH + LAYER
for Level TOUCH AOS
305
0873895302
0C4898
CRUSCOTTO LIV. TOUCH (NO
MEMBR.)
CONT.PANEL LEV. A (NO LAYER)
for Level A FCZ Ver.
305
0873880100
0C4250
CRUSCOTTO LIV. B (NO MEMBR.)
CONT.PANEL LEV. B (NO LAYER)
for Level B AOS Ver.
305
0873895402
0C4899
CRUSCOTTO LIV. B (NO MEMBR.)
CONT.PANEL LEV. B (NO LAYER)
for Level B FCZ Ver.
305
0873894000
0C4893
CRUSCOTTO LIV. C (NO MEMBR.)
CONT.PANEL LEV. C (NO LAYER)
for Level C AOS Ver.
305
0873895502
0C4900
CRUSCOTTO LIV. C (NO MEMBR.)
CONT.PANEL LEV. C (NO LAYER)
for Level C FCZ Ver.
-
0873879303
0C4249
FILTRO ARIA CRUSCOTTO
AIR FILTER CONTROL PANEL
305
0875401W00
0C8713
CRUSCOTTO LIV.TOUCH “K” CON
MEMBRANA
CONTROL PANEL TOUCH “K” WITH
LAYER
For Level Touch “K”
AOS Group
307
675400A00
0C6571
SCHEDA USER INTERFACE
LIV.TOUCH
USER INTERF. BOARD, LEV.
TOUCH
for Level TOUCH,K
up to 2441…
307
675400P01
0C8805
SCHEDA USER INTERFACE
LIV.TOUCH
USER INTERF. BOARD, LEV.
TOUCH
for Level TOUCH,K
from 2451…
up to 4481…
307
675400P03
0CA070
SCHEDA USER INTERFACE
LIV.TOUCH
USER INTERF. BOARD, LEV.
TOUCH
for Level TOUCH,K
from4491…
307
0675838802
0C0041
SCHEDA USER INTERFACE LIV. B
USER INTERF. BOARD, LEV. B
for Level B
307
0675854600
0C4891
SCHEDA USER INTERFACE LIV. C
USER INTERF. BOARD, LEV. C
for Level C
307
0675854602
0C7350
SCHEDA USER INT.LIV.C (1/2 VEL)
USER INT.BOARD LEV.C (1/2
SPEED)
For Level C (start s/n
120…)
308
0675400809
0C6570
SCHEDA POWER
MAIN POWER
for Level TOUCH,K
308
0675837808
0C0042
SCHEDA POWER
MAIN POWER
for Level B,C
-
0546814001
0C3750
DISTANZIALE ARCHETTO NYLON
PER SCHEDA POWER
SPACER NYLON FOR POWER
BOARD
309
0546824600
0C5833
PROLUNGA PULSANTE
PROLONG
-
0633847400
0C6564
CABLAGGIO USER - POWER
MAIN - USER CABLE
for TOUCH level,K
-
0638400P00
0C6565
CAVO ALIMENTAZIONE USER
SUPPLY CABLE USER
for TOUCH level,K
311
0652804500
0C1884
FUSIBILE OMEGA T 2.5A
FUSE OMEGA T 2.5A
for 120V models
311
0652803300
0C1480
FUSIBILE RAPIDO 6.30 A
FUSE FAST 6.3 A
for 120V models
311
0652803200
0C2953
FUSIBILE 5X20 2,5A T
FUSEOMEGA 5X20 2,5A T
for 100V,120V models
311
0652805200
0C2236
FUSIBILE 5X20 1,6A F
FUSEOMEGA 5X20 1,6A F
for 100V models
311
0652800701
058869
FUSIBILE 5X20 1,6A F
FUSEOMEGA 5X20 1,6A F
for 100V models
312
0652802100
0F0031
PORTAFUSIBILE
FUSE HOLDER
313
0646812200
007042
LIMITATORE, CELLA
LIMITER, CAVITY
313
0646810802
006314
LIMITATORE, CELLA
LIMITER, CAVITY
for 120V models
314
0508840801
002628
FLANGIA
FLANGE
315
0574804900
002627
VETRO
GLASS
316
0543842000
002626
GUARNIZIONE
GASKET
317
0660808300
0C4396
LAMPADA ALOGENA
HALOGEN LAMP
Up to 4361…
From sr. Nr/ Da Ser. Nr.: 015
From status level / Da scatto: 07 Page: 11 Ed. 2016 02
Doc. Nr.: 875400F00
06 GN 1/1 GAS CONVECTION / STEAMER OVEN
FORNO CONVEZIONE / VAPORE GAS 06 GN 1/1
Pos
Factory
Code
6DGT
Code
Descrizione
Description
Ref./Note
317
0660400100
0C9877
LAMPADA ALOGENA
HALOGEN LAMP
From 4371…
318
0660806401
007055
PORTALAMPADA
LAMP HOLDER
319
0508896801
007081
FARFALLA
CLOSER
320
0680802300
0C5501
MOTORIDUTTORE
MOTOREDUCER
320
0680802400
0C5502
MOTORIDUTTORE
MOTOREDUCER
for 120V models
321
322
0543828600
007053
GUARNIZIONE
GASKET
323
0831828400
0C4252
CONDOTTO ARIA
DUCT, AIR
324
0624811000
0C4106
VENTILATORE
FAN
325
0694805900
0C4950
FILTRO ANTIDISTURBO
FILTER
326
0639804900
046357
MORSETTIERA
TERMINAL BOARD
327
0694604400
047541
CONDENSATORE 12.5 Mf
CAPACITOR 12.5 MF
for Level Touch, B
not for USA models
327
0694604400
047541
CONDENSATORE 60 Mf
CAPACITOR 60 MF
For 100V models
327
0694804601
0C4812
CONDENSATORE 60 Mf
CAPACITOR 60 MF
For 120V models
327
0694806000
0C5526
CONDENSATORE DA 8 MF
CAPACITOR 8 MF
for Level C,K
328
0624400100
0C6895
TRASFORMATORE
TRANSFORMER
328
0624807100
007046
TRASFORMATORE
TRANSFORMER
for 100V models
329
0648803001
058857
RELE
RELE
for Level Touch, B
329
0648808000
0C1883
RELE
RELE
for 120V,100V models
329
0648723800
088086
RELE
RELE
for 120V models
330
0624807002
007047
ALIMENT. SWITCHING LAMBDA
LAMBDA SWITCHING FEEDER
for Level Touch
331
0646812900
0C1147
LIMITATORE, BOILER
LIMITER, BOILER
331
0646810902
006433
LIMITATORE, BOILER
LIMITER, BOILER
for 120V models
332
0509803900
0C4459
RIFLETTORE
REFLECTOR
333
0652801900
004010
PORTAFUSIBILE
FUSE HOLDER
for 120V models
334
0624400002
0C6945
TRASFORMATORE
TRANSFORMER
for 120V models
336
337
0543843500
0638400Y00
0C5451
0C6566
GUARNIZIONE
PROLUNGA USB
GASKET
USB CABLE
FOR Touch Level
338
0546400200
0C6547
VASCHETTA USB
USB PLUG
for TOUCH level
339
0541400A00
0C6546
COPERTURA USB
USB COVER
for TOUCH level
340
341
0675858601
0648722900
0C8033
088267
TASTO ON-OFF(INTER.PRINCIPALE)
RELE’ SICUREZZA
ON-OFF (MAIN SWITCH)
SECURITY RELE
for TOUCH level
342
0831851002
0C4934
ASSIEME FILTRO CRUSCOTTO
ASS. FILTER CONTROL PANEL
343
0549400F00
0C9991
FILTRO CRUSCOTTO
FILTER CONTROL PANEL
Pagina 6
Page 6
400
0831850400
0C5018
PORTATEGLIE DX P60
TRAY SUPPORT DX P60
401
0831850500
0C5019
PORTATEGLIE SX P60
TRAY SUPPORT SX P60
402
0806872800
0C4961
SUPPORTO CON S.G.
SUPPORT S.G.
403
0511828100
0C5620
SUPPORTO
SUPPORT
SONDE DI TEMPERATURA
TEMPERATURE PROBES
0830898902
0C6538
SONDA CELLA 500mm ROSSA
CAVITY PROBE 500mm RED
0830899001
0C0325
SONDA BOILER 800mm AZZURRA
BOILER PROBE 800mm BLUE
for Level TOUCH, B
0830899101
0C6539
SONDA BYPASS 1100 BIANCO
BYPASS PROBE 1100mm WHITE
for Level TOUCH, B
Loading...
