Refrigeration Platform
CATALOGO PARTI DI RICAMBIO
SPARE PARTS CATALOGUE
REFRIGERATI 600 LT
della gamma
BENEFIT o AU
STANDARD BENEFIT 600 L
Code AVV Type Ref. Page Brand
113219 600lt 0/+10 °C full door 304 AISI a 2-3-6-7 Zanussi
113220 600lt 0/+10 °C full door 60HZ 304 AISI b 2-3-6-7 Zanussi
113221 600lt -2/+10 °C full door 304 AISI c 2-3-6-7 Zanussi
113222 600lt 0/+10 °C full door 430 AISI d 2-3-6-7 Zanussi
113223 600lt -2/+10 °C full door 304 AISI Austria e 2-3-6-7 Zanussi
728596 600lt -2/+10 °C full door 304 AISI f 2-3-6-7 Alpeninox
726317 12 600lt -2/+10 °C full door 304 AISI g 2-3-6-7 Electrolux
728597 600lt 0/+10 °C full door 304 AISI h 2-3-6-7 Alpeninox
728598 600lt 0/+10 °C full door 430 AISI i 2-3-6-7 Alpeninox
728599 600lt 0/+10 °C full door 304 AISI l 2-3-6-7 Whirpool
726452 600lt 0/+10 °C full door 304 AISI m 2-3-6-7 to brand
726453 600lt 0/+10 °C full door 60HZ 304 AISI n 2-3-6-7 to brand
726454 600lt 0/+10 °C full door 430 AISI o 2-3-6-7 to brand
726455 07 600lt -2/+10 °C full door 304 AISI Austria p 2-3-6-7 to brand
728057 600lt 0/+10 °C full door 304 AISI q 2-3-6-7 to brand
728061 600lt 0/+10 °C full door 304 AISI r 2-3-6-7 to brand
728638 06 600 lt-2\+8 A430/430 fuul door s 2-3-6-7 NORDCAP
726473 600lt 0/+10 °C full door White 430 AISI t 2-3-6-7 to brand
726689 02 RS06RXH2x ½ DOOR DIGIT.REFRIG. 600L -2+10° A304 u 4-5-6-7 to brand
726965 00 RS06RX1FG 1-DOOR DIG.REF+WHEELS 600L -2+10°A304-UK v 2-3-6-7 to brand
note:
Nuova sonda evaporatore ser.numb. 51100001
New evaporator probe ser.numb. 51100001
Pag. Indice Index
2 Armadio Cabinet
3 Lista ricambi Spare parts list
4 Gruppo refrigerante Cooling unit
5 Lista ricambi Spare parts list
Marchio / Brand: Z-A-E
Paese / Country: Tutti / All
Da serial n° 34700001
Until to serial N° 74500001
Page: 1 Ed. 01-2004
Doc. Nr. 501100
Standard Benefit 600 L
21
5
3
1
19
17
2
10
22
26
14
6
27
12
8
11
18
4
Da serial n° 34700001
Until to serial N° 74500001
15
Page: 2
20
24 right
25 left
9
Ed .01-2004
7
16
23
MOB 5-01-1-00
13
Doc. Nr..501100
Standard Benefit 600 L
PNC REF PNC REF PNC REF PNC REF PNC REF
113219 a 728597 h 728061 r
113220 b 728598 i 726454 o
113221 c 728599 l 728638 s
113222 d 726452 m 726473 t
113223 e 726453 n 726689 u
728596 f 726455 p
726317 g 728057 q
Pos Code Descrizione Description Ref. / Notes
1 0A8329 Inserto per porta Insert for door
2 053342 Molla arresto marchio Spring for brand
3 082219 Cerniera per porta Hinge for door
4 082256 Staffa inferiore porta Lower bracket
5 082257 Staffa superiore porta Upper bracket
6 082263 Guida per griglia dx-sx Runner for shelf dx-sx a,b,c,e,f,g,h,l,m,n,p,q,r,v
6 082206 Guida per griglia dx-sx 430 Runner for shelf dx-sx 430 d,i,o,s,t
7 089735 Guarnizione per porta Gasket for door
8 083635 Griglia Shelf
9 083813 Baccinella raccogli conde. Basin
10 083838 Gancio di supp.cremaglie. Hook for Rack
11 083837 Gancio di supp.cremaglie. Hook for Rack
* 083839 Tappo per gancio Plug for hook
12 087646 Cremagliera anteriore Front rack a,b,c,e,f,g,h,l,m,n,p,q,r,v
12 087773 Cremagliera anteriore 430 Front rack 430 d,i,o,s,t
13 089740 Porta Door a,b,c,e,f,g,h,l,m,n,p,q,v
13 089740 Porta PVB Door white n- art. 899768900
13 089736 Porta 430 Door 430 d,i,o,s
13 099216 Porta con maniglia in plastica Door with plastic handle r
14 087648 Cremagliera posteriore Back rack a,b,c,e,f,g,h,l,m,n,p,q,r,v
14 087774 Cremagliera posteriore 430 Back rack 430 d,i,o,s,t
15 089140 Piedino Foot
15 0A9562 Piedino Foot s, t
16 087658 Sifone scarico acqua Discharge pipe
17 089890 Cruscotto completo Panel complete a,b,m,n,r
17 089891 Cruscotto completo Panel complete c,e,p
17 089892 Cruscotto completo Panel complete d,o
17 089893 Cruscotto completo Panel complete f
17 089894 Cruscotto completo Panel complete g,v
17 089895 Cruscotto completo Panel complete h,q
17 089896 Cruscotto completo Panel complete i
17 089897 Cruscotto completo Panel complete l
17 099568 Cruscotto completo Panel complete s
17 099421 Cruscotto 304 aisi Panel 304 aisi g,l,c,e,f,m,n,v
17 099569 Cruscotto 430 aisi Panel 430 aisi s,d, i, o
17 * Cruscotto White aisi Panel White aisi t - art. 899769200
18 0A8856 Boccola per porta Bush for door
19 0A8053 Serratura Lock
20 083814 Resistenza bacinella Heating element ptc a,b,c,e,f,g,h,l,m,n,p,q,r,s,v
21 089753 Chiusura posteriore Back panel
22 089898 Cavo riscaldante Heating cable
* 089899 Adesivo per cruscotto Sticker for panel a,b,c,e,d
* 089900 Adesivo per cruscotto Sticker for panel f,h,i,l
23 080803 Bacinella raccolta condensa Water tray condenser d,i,o,t
24 082534 Guida dx per bacinella Right guide for trey condenser d,i,o,t
25 082533 Guida sinistra per bacinella Left guide for trey condenser d,i,o,t
26 089901 Riscontro verticale Vertical frame
27 089902 Riscontro orrizzontale Horizontal
28 087110 Ruota con freno derby z540g5125 Whell with brake v
29 087111 Ruota derby z140g5125 Whell v
* Componenti disponibili a richiesta / Component available upon request
Da serial n° 34700001
Until to serial N° 74500001
Page:3
Ed. 01-2004
Doc. Nr.501100
Standard Benefit 600 L
127
104
120
123
125
116
126
112
110
114
115
115
111
113
109
105
101
121
121
119
117
122
123
100
Da serial n° 34700001
Until to serial N° 74500001
108
124
Page: 4
102
106
107
103
Ed .01-2004
119
120
Doc. Nr..501100
118
Standard Benefit 600 L
PNC REF PNC REF PNC REF PNC REF PNC REF
113219 a 728597 h 728061 r
113220 b 728598 i 726454 o
113221 c 728599 l 728638 s
113222 d 726452 m 726473 t
113223 e 726453 n 726689 u
728596 f 726455 p
726317 g 728057 q
Pos Code Descrizione Description Ref. / Notes
Pagina 4 Page 4
100 089140 Piedino Foot
101 091239 Riscontro verticale Vertical frame
102 089902 Riscontro orizzzontale Orrizontal frame
103 082350 Staffa inferiore porta Lower bracket
104 082257 Staffa superiore porta Upper bracket
105 082374 Staffa centrale Central bracket
106 083813 Bacinella Tray
107 083814 Resistenza baccinella Heating element ptc
108 087658 Sifone scarico acqua Discharge pipe
109 091240 Traversa centrale Central support
110 091241 Riscontro traversa Frame or central support
111 085988 Cremagliera anteriore Front rack
112 087648 Cremagliera posteriore Back rack
113 082263 Guida per griglia dx-sx Runner for shelf right- left
114 083635 Griglia Shelf
115 090210 Gancio di supp.cremagliera Hook for Rack
116 090214 Gancio di supp.cremagliera Hook for Rack
117 089759 Porta superiore Upper door
118 089760 Porta inferiore Lower door
119 0A9741 Guarnizione per porta Gasket door
120 082219 Cerniera per porta Hinge for door
121 0A8856 Boccola per porta Bush for door
122 0A8529 Tappo chiusura serratura Plug for lock
123 0A8053 Serratura Lock
124 089952 Cavo riscaldante Heating cable
125 099421 Cruscotto Panel
126 053342 Molla arresto marchio Brand plate retainig spring
127 091242 Chiusura posteriore Back panel
* Componenti disponibili a richiesta / Component available upon request
Da serial n° 34700001
Until to serial N° 74500001
Page:5
Ed. 01-2004
Doc. Nr.501100
Standard Benefit 600 L
51
52
73
72
54
56
53
71
57
55
58
59
78
69
66
64
77
80
67
75
62
60
E
68
63
61
L
T
N
79
76
c
fn
°C
set
65
Da serial n° 34700001
Until to serial N° 74500001
0
1
74
Page: 6
Ed .01-2004
Doc. Nr..501100
Standard Benefit 600 L
PNC REF PNC REF PNC REF PNC REF PNC REF
113219 a 728597 h 728061 r
113220 b 728598 i 726454 o
113221 c 728599 l 728638 s
113222 d 726452 m 726473 t
113223 e 726453 n 726689 u
728596 f 726455 p
726317 g 728057 q
Pos Code Descrizione Description Ref. / Notes
51 088378 Ass. scambiatore Heat exchange c,e,f,g,p,s,u,v
51 087652 Ass. scambiatore Heat exchange a,b,d,h,i,l,m,n,o,q,r,,t
52 0A8764 Condensatore di spunto Electric starter capacitor a,c,d,e,f,g,h,i,l,m,o,p,q,r,s,t,u,v
53 0A8171 Valvola di carica Discharge valve
54 0A9350 Ventilatore condensatore Motor ventilator for condenser
55 084078 Filtro deidratatore Filter
56 089755 Protezione ventola Fan protection
57 082230 Ventola per condensatore Fan for condenser a,c,d,e,f,g,h,i,l,m,o,p,q,r,s,t,u,v
57 085532 Ventola per condensatore Fan for condenser b,n
58 087653 Condensatore Condenser
59 087067 Morsettiera Clamp
60 088374 Ventilatore cella Motor verntilator for evaporator
61 087654 Sonda cella Cell probe a,b,d,h,i,l,m,n,o,q,r,t
61 088405 Sonda cella Cell probe c,e,f,g,p,u,v
61 099570 Sonda cella Cell probe s
62 0A9671 Termostato di sicurezza Security thermostat c,e,f,g,p,s,u,v
63 088375 Protezione ventola Fan protection for evaporator
64 089175 Interruttore luminoso Swicth
65 089903 Termoregolatore id 961 Thermoregulator id 961 a,b,d,h,i,l,m,n,o,q,r,s,t
65 089904 Termoregolatore id 974 Thermoregulator id 974 c,e,f,g,p,u,v
66 087657 Prolunga di scarico Pipe for discharge
67 099570 Sonda evaporatore Evaporator probe c,e,f,g,p,u,v from ser.nub.51100001
68 Resistenza elettrica per EVS 40 Heating element for EVS 40 c,e,f,g,p,s,v Alias code : 170201
(eco refrigeration)
69 088373 Evaporatore evs 40 Evaporator evs 40
71 085876 Compressore GL 60 TB Compressor GL 60 TB a,c,d,e,f,g,h,i,l,m,o,p,q,r,s,t,u,v
71 087744 Compressore Compressor b,n
72 085875 Protettore per compressore Electric protection for compress. a,c,d,e,f,g,h,i,l,m,o,p,q,r,s,t,v
73 084286 Rele per compressore Relè for compressor a,c,d,e,f,g,h,i,l,m,o,p,q,r,s,t,v
74 087485 Micro porta Swicth for door
75 087650 Sifone di scarico Discharge pipe
76 088376 Ventola evap. Fan evap.
77 089756 Piletta di scarico con dado Discharge pipe condenser with nut
78 089905 Guarnizione per mascherina Gasket
79 099997 Bacinella /coperchio evaporatore Cover /basin evapoartor
* Componenti disponibili a richiesta / Component available upon request
Da serial n° 34700001
Until to serial N° 74500001
Page:7
Ed. 01-2004
Doc. Nr.501100
