Installatio n Instructions

C o o k t o p





























E30GC64ESS

E36GC65ESS

E46GC66ESS

E46GC67ESS

5995426250















2 Safety

IMPORTANT SAFETY INSTRUCTIONS

Safety Precautions

Do not attempt to install or operate your unit until you have read the safety precautions in this manual. Safety items throughout this manual are labeled with a Warning or Caution based on the risk type.

Definitions

! This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.

! WARNING

WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

! CAUTION

CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.

CAUTION

CAUTION used without the safety alert symbol indicates a potentially hazardous situation which, if not avoided, may result in property damage.

IMPORTANT

Indicates installation, operation or maintenance information which is important but not hazard related.

Safety 3

SAFETY PRECAUTIONS

!WARNING

Read all instructions before using the appliance.

Improper installation, adjustment, alteration, service, or maintenance can cause personal injury or property damage. Refer to these instructions and the accompanying Use & Care Manual. For assistance or additional information, consult a qualified installer, service agency, manufacturer (dealer), or the gas supplier.

For your safety:

-Do not obstruct the flow of combustion and ventilation air to the unit.

-Keep appliance area clear and free from combustible material, gasoline and other flammable vapors and liquids.

-Do not use or attempt to use this appliance in the event of a power failure.

This unit is designed as a cooking appliance. Never use it for warming or heating a room.

This appliance must not be used in combination with surface (countertop) ventilation systems. The use of an overhead hood or downdraft is recommended for ventilation.

This appliance must be installed with the gas pressure regulator supplied with it.

Disconnect the electrical supply before installing or servicing the appliance.

This appliance must be grounded. Connect only to a properly grounded electrical supply. Refer to “Electrical Requirements”.

Install or locate this appliance only in accordance with these installation instructions.

Use this appliance only for its intended use as described in this manual. Do not use corrosive chemicals or vapors in this appliance. This type of appliance is not designed for industrial or laboratory use.

As with any appliance, close supervision is necessary when used by children.

Do not operate this appliance if it has a damaged electrical cord, plug, conduit or wires, if it is not working properly, or if it has been damaged or dropped.

This appliance should be serviced only by qualified service personnel.

Some products, such as whole eggs, and sealed containers, such as closed glass jars, may explode and should not be heated on this cooktop.

4Safety

!WARNING

Based on safety considerations, the top burner flame should be adjusted so it does not extend beyond the edge of the cooking utensil.

Cooking utensils should not be used on the open top broiler section.

If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury, or death.

What to do if you smell gas:

- Do not try to light any appliance.

-Do not touch any electrical switch, do not use any phone in your building.

-Immediately call the gas supplier from a neighbor’s phone.

-Follow the gas supplier’s instructions.

-If you cannot reach your gas supplier, call thefire department.

For your safety:

-Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.

Installation of this appliance must be performed by a qualified installer, service agency or the gas supplier.

FindingInformation 5

READ AND SAVE THESE INSTRUCTIONS

NOTE

Installer: Leave instructions with owner.

Owner: Read your cooktop Use & Care Manual. It contains important safety information for operating this appliance. It also has many suggestions for getting the best results from your cooktop.

Read all instructions before installing the cooktop.

For your safety, please read and observe all safety instructions. This guide will help you anticipate all installation connections.

QUESTIONS?

For toll-free telephone support in the U.S. and Canada:

1-877- 4ELECTROLUX (1-877-435-3287)

For online support and Internet product information:

www.electroluxusa.com

Attach your sales receipt to this page for future reference.

©2005 Electrolux Home Products, Inc.

Post Office Box 212378, Augusta, Georgia 30917, USA All rights reserved. Printed in the USA

6 FindingInformation

TABLE OF CONTENTS



Safety ...................................................................

2

Definitions ..........................................................

2

Important Safety Instructions ..............................

2

Safety Precautions .............................................

3

Finding Information ...........................................

5

Please Read And Save This Guide ...................

5

Questions? ........................................................

5

Table Of Contents ..............................................

6

Preparing for Installation ..................................

7

Verifying Package Contents ...............................

7

Cabinet/Counterop Preparation .........................

7

Making the Gas/Electric Connection ..............

10

Requirements ..................................................

10

Installation ........................................................

12

Installing the Cooktop .......................................

12

Connecting the Gas .........................................

12

Gas and Electric Requirements Table ..............

13

Installing the Burner Components ....................

14

Making the Electrical Connection .....................

15

Operation ...........................................................

16

Verifying the Operation ....................................

16
