Draper VC300 Instructions Manual

Page 1
VACUUM CLEANER
STOCK No.59333 ■ PART No.VC300
01/2000
• INSTRUCTIONS •
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY TO ENSURE
THE SAFE AND EFFECTIVE USE OF THIS TOOL.
GENERAL INFORMATION
This manual describes the purpose for which this tool has been designed and contains all the necessary information to ensure its correct and safe use.We recommend that this manual is read before any operation of the machine, before performing any kind of adjustment to the machine, and prior to any maintenance tasks. By following all the general safety instructions contained in this manual, it will ensure both machine and operator safety, together with longer life of the tool itself.
All photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the machine.
Whilst every effort has been made to ensure accuracy of information contained in this manual,the Draper Tool policy of continuous improvement determines the right to make modifications without prior warning.
Page 2
-2 -
VACUUM CLEANER
STOCK No.59333 ■ PART No.VC300
CONTENTS:
Page No’s.
Specification.....................................................................................................3
Guarantee ........................................................................................................3
Power supply....................................................................................................4
General safety instructions...............................................................................5
Know your vacuum ...........................................................................................6
Operating instructions......................................................................................7
Maintenance.....................................................................................................8
Optional accessories ........................................................................................9
We Draper Tools Ltd. Hursley Road, Chandler’s Ford, Eastleigh, Hampshire. SO53 1YF. England.
Declare under our sole responsibility that the product:
Part Number:- VC300 Stock Number:- 59333 Description:- Vacuum Cleaner.
To which this declaration relates is in conformity with the following directive(s) 73/23 EEC and 89/336 with reference to EN60335-1:1988+A2:1988,
EN60335-2-2:1988+A2, A52:1990, EN50082-1:1992, EN55014:1987+A2:1990, EN60555-2:1987 & EN60555-3:1987.
DECLARATION OF CONFORMITY
01/2000
Page 3
- 3 -
The Draper Tools policy of continuous improvement determines the right to change specification without notice.
Part No....................................................................................................................VC300
Stock No...................................................................................................................59333
Voltage......................................................................................................................240V
Motor................................................................................................................300W max
Fan speed ...................................................................................20,500RPM (+/-600RPM)
Brush speed ........................................................................................6,100 (+/-600RPM)
Sound pressure level...........................................................................................89 (db)A
Dust capacity..........................................................................................................400 ml
Noise level ..........................................................................................................90 (db)A
NOTE: This vacuum is intended for dry pick-up only (do not attempt to vacuum liquids asbestos, burning cigarettes, ashes, etc).
SPECIFICATION
GUARANTEE
Draper machine tools have been carefully tested and inspected before shipment and are guaranteed to be free from defective materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the guarantee period is reduced to ninety days from the date of purchase.
Should the machine develop any fault please return the complete tool to your nearest authorised warranty repair agent or contact Draper Tools Limited, Chandler’s Ford, Eastleigh, Hampshire SO53 1YF. England. Telephone (023) 8026 6355 .
If upon inspection it is found that the fault occurring is due to defective materials or workmanship repairs will be carried out free of charge. This guarantee does not apply to normal wear and tear, nor does it cover any damage caused by misuse, careless or unsafe handling, alterations, accident, or repairs attempted by any personnel other than the authorised Draper warranty repair agent.
This guarantee applies in lieu of any other guarantee expressed or implied and variations of its terms are not authorised.
Your Draper guarantee is not effective unless you can produce upon request a dated receipt or invoice to verify your proof of purchase within the 12 month period.
Please note that this guarantee is an additional benefit and does not affect your statutory rights.
Draper Tools Limited.
Page 4
POWER SUPPLY
3 6 10 13
Extension cable length Wire Size mm
2
7.5m 0.75 0.75 1.0 1.25
15m 0.75 0.75 1.0 1.5
22.5m 0.75 0.75 1.0 1.5
30m 0.75 0.75 1.25 1.5
45m 0.75 1.25 1.5 2.5
Ampere rating
(on Name plate)
CONNECTING YOUR MACHINE TO THE POWER SUPPLY: (240V)
To eliminate the possibility of an electric shock your machine has been fitted with a BS approved, non rewireable moulded plug and cable which incorporates a fuse, the value of which is indicated on the pin face of the plug. Should the fuse need to be replaced an
approved BS1362 fuse must be used of the same rating, marked thus .
The fuse cover is detachable, never use the plug with the cover omitted.If a replacement fuse cover is required, ensure it is of the same colour as that visible on the pin face of the plug (i.e. red). Fuse covers are available from your Draper Tools stockist. If the fitted plug is not suitable, it should be cut off and destroyed. *The end of the cable should now be suitably prepared and the correct type of plug fitted. See below.
*WARNING:
A plug with bare flexible wires exposed is hazardous if engaged in a live power socket outlet.
WARNING:THIS APPLIANCE IS DOUBLE INSULATED.
Blue – Neutral, Brown – Live. As these colours may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The wire which is coloured blue must be connected to the terminal which is marked with the letter ‘N’ or coloured black or blue. The wire which is coloured brown must be connected to the terminal which is marked with the letter ‘L’ or coloured red or brown.
CONNECTING YOUR MACHINE TO THE POWER SUPPLY (110V)
To eliminate the possibility of an electric shock your machine has been fitted with a BS approved, rewireable plug and cable. If the fitted plug is not suitable, it should be removed, the end of the cable should be suitably prepared and the correct type of plug fitted. See below.
WARNING:THIS APPLIANCE IS DOUBLE INSULATED.
Single phase 110 volt machines must be connected using the relevant coding and matching the colour of the flexible cable to that of the plug. The procedure is as follows:
1. Connect brown coloured core to plug terminal marked letter ‘L’ (live).
2. Connect blue colour core to plug terminal marked letter ‘N’ (neutral).
- 4 -
Page 5
- 5 -
GENERAL SAFETY INSTRUCTIONS FOR POWER TOOLS
1. KNOW YOUR POWER TOOL
Read and understand the owner's manual and labels affixed to the tool. Learn its application and limitations as well as the specific potential hazards peculiar to this tool.
2. KEEP WORK AREA CLEAN
Cluttered areas and benches invite accidents. Floors must not be slippery due to oil or sawdust.
3. AVOID DANGEROUS ENVIRONMENTS
Do not use power tools in damp or wet locations, or expose them to rain. Keep work area well lit. Provide adequate space surrounding the work area. Do not use in environments with a potentially explosive atmosphere.
4. KEEP CHILDREN AWAY
All visitors should be kept a safe distance from work area.
5. STORED TOOLS
When not being used, all tools should be stored in a dry, locked cupboard or out of the reach of children.
6. WEAR PROPER CLOTHING
Do not wear loose clothing,neckties or jewellery (rings, wristwatches) to catch in moving parts. NONSLIP footwear is recommended.Wear protective hair covering to contain long hair.Roll long sleeves above the elbow.
7. USE SAFETY GOGGLES (Head Protection)
Wear CE approved safety goggles at all times. Normal spectacles only have impact resistant lenses, they are NOT safety glasses. Also, use face or dust mask if application is dusty and ear protectors (plugs or muffs) during extended periods of operation.
8. NOISE LEVELS
Some types of machines may have high noise levels when working. In such cases ear protection must be worn.
9. VIBRATION LEVELS
Hand held power tools produce different vibration levels. You should always refer to the specifications and relevant Health and Safety guide.
10. DUST EXTRACTION
If your tool is fitted with a dust extraction fitting, always ensure that it is connected and being used with a dust extractor.Vacuum cleaners can be used if suitable for the material being extracted.
11. PROTECT YOURSELF FROM ELECTRIC SHOCK
When working with power tools, avoid contact with any earthed items (e.g. pipes, radiators, hobs and refrigerators,etc.). If you are using a power tool in extreme conditions (e.g. high humidity or generating metal dust), always use an RCD (residual current device) at the power socket.
12. STAY ALERT
Always watch what you are doing and use common sense. Do not operate a power tool when you are tired or under the influence of alcohol or drugs.
13. WHEN WORKING OUT OF DOORS
Only use extension leads designed for that purpose.
14. ACCESS TO MAINS SOCKET
If a stationary machine is fitted with a moulded plug and cable, the machine should not be positioned so that access to the mains socket is restricted.
15. DISCONNECT POWER TO THE TOOL
When not in use, before servicing and when changing accessories such as cutters, etc.
16. AVOID ACCIDENTAL STARTING
Make sure the switch is in the OFF position before plugging the machine into the power supply.
17. NEVER LEAVE MACHINE RUNNING UNATTENDED
Turn power off. Do not leave machine until it comes to a complete stop.
18. DO NOT ABUSE THE CORD
Never carry the tool by the power cable or pull it from the socket. Keep the power cable away from heat, oil and sharp edges.
19. NEVER STAND ON TOOL
Serious injury could occur if the tool is tipped or if the cutting tool is accidentally contacted. Do not store materials above or near the tool, so that it is necessary to stand on the tool to reach them.
20. CHECK DAMAGED PARTS
Check for damage to parts, breakage of parts, mountings and any other conditions that may affect its operation. A guard or other part that is damaged should be properly repaired or replaced.
21. KEEP GUARDS IN PLACE
And in working order.
22. MAINTAIN TOOLS WITH CARE
Keep tools sharp and clean for the best and safest performance. Follow instructions for lubricating and changing accessories. All extension cables must be checked at regular intervals and replaced if damaged. Always keep the hand grips on the tool clean,dry and free of oil and grease.
23. USE RECOMMENDED ACCESSORIES
Consult the owners manual for recommended accessories. Follow the instructions that accompany the accessories. The use of improper accessories may cause hazards.
24. REMOVE ADJUSTING KEYS AND WRENCHES
Form a habit of checking to see that keys and adjusting wrenches are removed from the tool before turning it on.
25. SECURE WORK
Use clamps or a vice to hold work.This frees both hands to operate the tool.
26. DO NOT OVERREACH
Keep proper footing and balance at all times.
27. USE RIGHT TOOL
Do not force the tool or attachment to do a job for which it was not designed.
28. DO NOT FORCE TOOL
It will do the job better and safer at the rate for which it was designed.
29. DIRECTION OF FEED
Feed work into a blade or cutter against the direction of rotation of the blade or cutter only.
30. WHEN DRILLING OR SCREWING INTO WALLS
Always make sure there is no danger of hitting any hidden power cables, water or gas pipes in the wall.
WARNING
Please read the following instructions carefully, failure to do so could lead to serious personal injury.
IMPORTANT
Draper Tools Limited recommends that this machine should not be modified or used for any application other than that for which it was designed. If you are unsure of its relative applications do not hesitate to contact us in writing and we will advise you.
IMPORTANT NOTE Residual Risk. Although the safety instructions and operating manuals for our tools contain extensive
instructions on safe working with power tools, every power tool involves a certain residual risk which can not be completely excluded by safety mechanisms. Power tools must therefore always be operated with caution !
Page 6
-6 -
1. On/off switch
2. Power lead
3. Hand grip
4. Release button for dust container
5. Dust container with filter
6. Drive belt cover
7. Brush housing
GETTING TO KNOW YOUR
✚✌
✘✌
✙✌
✕✌
✛✌
✖✌
✗✌
Page 7
- 7 -
OPERATING INSTRUCTIONS
THE VC300 IS ASSEMBLED AND READY FOR USE
TO OPERATE
Connect the vacuum to the power supply. Hold the handle ✪✌ firmly, with your thumb slide the switch ✫✌forward to turn the vacuum on, and back to turn off.
REMO
VAL AND CLEANING OF FILTER
To remove the filter for cleaning depress the release button ✬✌ and remove the dust container ✭✌ carefully. Remove the dust filter
✮✌ so you do not disturb any dust collected.
Empty the contents of the dust container. To clean filter brush away any excess dust/dirt. If needed the filter can be washed with warm water. The filter must be dry before re-fitting it to the dust container.
W
ARNING
DO NOT OPERATE WITHOUT A FILTER FITTED.
Fig.1
✫✌
✪✌
✭✌
Fig.2
✮✌
✬✌
Page 8
-8 -
MAINTENANCE
REPLACING THE DRIVE BELT
IMPORTANT
Disconnect the vacuum from the power supply before replacing any parts.
1. Remove screw ✯✌to release front cover
✰✌. FIG.3.
2 Remove the two screws ✱✌ holding the brush
housing ✳✌ in place and remove. FIG.4.
3.Holding the brush ✴✌ in the centre, pull
the belt off the driveshaft and remove the brush with the bearings ✵✌ assembled. FIG.5..
4. Clean the brush if required. Slide a new belt ✶✌
onto the brush ✴✌and move it to a central position. FIG.6
5. Replace the brush ✴✌ complete with bearings
✵✌.
6. Place the belt over the driveshaft ✷✌ FIG.6. (The
belt should be twisted in a clockwise direction over the driveshaft ✷✌ as shown in FIG.7.)
7. Reassemble the brush housing ✳✌with screws
✱✌.
8. Replace the front cover ✰✌ and secure in place
with screw ✯✌.
✰✌
✭✌
Fig.5
✮✌
✬✌
✯✌
Fig.3
Fig.4
✶✌
✷✌
Fig.5
Fig.6
Fig.7
✱✌
✱✌
✳✌
✴✌
✵✌
✵✌
✷✌
Page 9
OPTIONAL ACCESSORIES
ACCESSORY KIT FOR VC300
PART No.AVC15 STOCK No.59334
- 9 -
Page 10
NOTES
-10 -
Page 11
NOTES
-11 -
Page 12
©Published by Draper Tools Ltd.
No part of this publication may be reproduced,
stored in a retrieval system or transmitted in
any form or by any means, electronic, mechanical
photocopying, recording or otherwise without prior
permission in writing from Draper Tools Ltd.
YOUR DRAPER STOCKIST
DRAPER TOOLS LIMITED,
Hursley Road, Chandler's Ford,
Eastleigh, Hants. SO53 1YF. England.
Tel: (023) 8026 6355.
