Dell™ S2240L/S2340L Monitor User's Guide
About Your Monitor
Setting Up the Monitor
Operating the Monitor
Troubleshooting
Appendix
Notes, Cautions, Warnings
NOTE: A NOTE indicates important information that helps you make better use of your computer.
CAUTION: A CAUTION indicates potential damage to hardware or loss of data if instructions are not followed.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
Information in this document is subject to change without notice. © 2012 Dell Inc. All rights reserved.
Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.
Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Inc.; Microsoft and Windows are either trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. ENERGY STAR is a registered trademark of the U.S. Environmental Protection Agency. As an ENERGY STAR partner, Dell Inc. has determined that this product meets the ENERGY STAR guidelines for energy efficiency.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.
Model S2240Lc/S2340Lc
November 2012 Rev. A01
Back to Contents Page
About Your Monitor
Dell™ S2240L/S2340L Monitor User's Guide
Package Contents
Product Features
Identifying Parts and Controls
Monitor Specifications
Plug and Play Capability
LCD Monitor Quality & Pixel Policy
Maintenance Guidelines
Package Contents
Your monitor ships with all the components shown below. Ensure that you have received all the components and Contacting Dell™ if anything is missing.
NOTE: Some items may be optional and may not ship with your monitor. Some features or media may not be available in certain countries.
Monitor
Stand Riser
Stand Base
Velcro Strap
Power Cable
Adapter Cable
VGA Cable
Drivers and Documentation media Quick Setup Guide
Product Information Guide
Product Features
The Dell™ S2240L/S2340L flat panel display has an active matrix, Thin-Film Transistor, Liquid Crystal Display. The monitor's features include:
S2240L: 54.61 cm (21.5 inches) viewable area display. 1,920 x 1,080 resolution, plus full-screen support for lower resolutions.
S2340L: 58.42 cm (23.0 inches) viewable area display. 1,920 x 1,080 resolution, plus full-screen support for lower resolutions.
Wide viewing angle to allow viewing from a sitting or standing position, or while moving from side-to-side.
Removable pedestal.
Plug and play capability if supported by your system.
On-Screen Display (OSD) adjustments for ease of set-up and screen optimization.
Software and documentation media which includes an information file (INF), Image Color Matching File (ICM), and product documentation.
Dell Display Manager included (comes in the CD attached with the monitor).
Security lock slot.
Dell Display Manager functionality.
ENERGY STAR compliant.
EPEAT™ Silver compliant.
RoHS compliant.
Identifying Parts and Controls
Front View
1.
Function buttons (For more information, see Operating the Monitor)
2.
Power On/Off button
3. Power LED indicator
Back View
Label |
Description |
Use |
1 |
Regulatory rating label |
Lists the regulatory approvals. |
2 |
Audio Line-out |
Connect your speakers.* |
3 |
HDMI connector |
To connect your computer to the monitor using a HDMI cable. |
4 |
VGA connector |
To connect your computer to the monitor using a VGA cable. |
5 |
Adapter connector |
To connect the monitor power cable using a 12V DC adapter for transition. |
6 |
Security lock slot |
Use a security lock with the slot to help secure your monitor. |
7 |
Barcode serial number label |
Refer to this label if you need to contact Dell for technical support. |
8 |
Cable clip |
For cable management. |
9 |
Stand release button |
To release stand from monitor. |
* Headphone usage is not supported for the audio line-out connector.
Side View
Left view |
Right view |
Bottom View
Monitor Specifications
The following sections give you information about the various power management modes and pin assignments for the various connectors of your monitor.
Power Management Modes
If you have VESA's DPM compliance display card or software installed in your PC, the monitor automatically reduces its power consumption when not in use. This is referred to as Power Save Mode. If the computer detects input from keyboard, mouse, or other input devices, the monitor automatically resumes functioning. The following table shows the power consumption and signaling of this automatic power saving feature:
VESA Modes |
Horizontal Sync |
Vertical Sync |
Video |
Power Indicator |
Power Consumption |
|
Normal operation |
Active |
Active |
Active |
White |
23 |
W (Maximum) for S2240L |
|
|
|
|
|
18 |
W (Typical) for S2240L |
|
|
|
|
|
24 |
W (Maximum) for S2340L |
|
|
|
|
|
19 |
W (Typical) for S2340L |
Active-off mode |
Inactive |
Inactive |
Blank |
Amber |
Less than 0.5 W |
|
Switch off |
- |
- |
- |
Off |
Less than 0.5 W |
|
The OSD will only function in the normal operation mode. When any button except power button is pressed in Active-off mode, the following messages will be displayed:
Activate the computer and monitor to gain access to the OSD.
NOTE: Dell S2240L/S2340L monitor is ENERGY STAR®-compliance.
*Zero power consumption in OFF mode can only be achieved by disconnecting the main cable from the monitor.
**Maximum power consumption with max luminance and contrast.
Pin Assignments
15-pin D-Sub connector
Pin Number
Monitor Side of the 15-pin Side Signal Cable
1 |
Video-Red |
2 |
Video-Green |
3 |
Video-Blue |
4 |
GND |
5 |
Self-test |
6 |
GND-R |
7 |
GND-G |
8 |
GND-B |
9 |
DDC +5V |
10 |
GND-sync |
11 |
GND |
12 |
DDC data |
13 |
H-sync |
14 |
V-sync |
15 |
DDC clock |
|
|
HDMI Connector
Pin Number |
24-pin Side of the Connected Signal Cable |
1 |
T.M.D.S. Data 2- |
2 |
T.M.D.S. Data 2 Shield |
3 |
T.M.D.S. Data 2+ |
4 |
T.M.D.S. Data 1+ |
5 |
T.M.D.S. Data 1 Shield |
6 |
T.M.D.S. Data 1- |
7 |
T.M.D.S. Data 0+ |
8 |
T.M.D.S. Data 0 Shield |
9 |
T.M.D.S. Data 0- |
10 |
T.M.D.S. Clock + |
11 |
T.M.D.S. Clock Shield |
12 |
T.M.D.S. Clock - |
13 |
CEC |
14 |
Reserved (N.C. on device) |
15 |
SCL |
16 |
SDA |
17 |
DDC/CEC Ground |
18 |
+5V Power |
19 |
Hot Plug Detect |
Plug and Play Capability
You can install the monitor in any Plug and Play compatible system. The monitor automatically provides the computer with its Extended Display Identification Data (EDID) using Display Data Channel (DDC) protocols so that the system can configure itself and optimize the monitor settings. Most monitor installations are automatic. You can select different settings if required.
Flat Panel Specifications
Model number
Screen type
Panel Type
Screen dimensions
Preset display area:
Horizontal
Vertical
Pixel pitch
Viewing angle
Horizontal
Vertical
Luminance output
Contrast ratio
Dynamic Contrast Ratio
Faceplate coating
Backlight
Response Time
Color Depth
Dell S2240L monitor
Active matrix - TFT LCD
IPS
54.61 cm (21.5 inches) (21.5-inch viewable image size)
476.06 mm (18.76 inches)
267.78 mm (11.85 inches)
0.248 mm
178 ° typical
178 ° typical
250 cd/m² (typical)
1,000 to 1 (typical)
8,000,000 to 1 (typical) *
Glare with hard-coating 3H
LED light bar system
14 ms(typical)
7 ms(typical) with Overdrive
16.7 mil colors
Dell S2340L monitor
Active matrix - TFT LCD
IPS
58.42 cm (23 inches) (23-inch wide viewable image size)
509.18 mm (20.05 inches)
286.41 mm (11.28 inches)
0.265 mm
178 ° typical
178 ° typical
250 cd/m² (typical)
1,000 to 1 (typical)
8,000,000 to 1 (typical) *
Glare with hard-coating 3H
LED light bar system
14 ms(typical)
7 ms(typical) with Overdrive
16.7 mil colors
Color Gamut |
82 % (typical) ** |
82 % (typical) ** |
|
|
|
*Based on estimation.
**[S2240L/S2340L] color gamut (typical) is based on CIE1976 (82 %) and CIE1931 (72 %) test standards.
Resolution Specifications
Model number |
Dell S2240L monitor |
Dell S2340L monitor |
Scan range |
|
|
Horizontal |
30 kHz to 83 kHz (automatic) |
30 kHz to 83 kHz (automatic) |
Vertical |
56 Hz to 76 Hz (automatic) |
56 Hz to 76 Hz (automatic) |
Maximum preset resolution |
1,920 x 1,080 at 60 Hz |
1,920 x 1,080 at 60 Hz |
Electrical Specifications
Model number
Video input signals
Synchronization input signals
Dell S2240Lmonitor
Analog RGB: 0.7 Volts +/- 5 %, 75 ohm input impedance
Separate horizontal and vertical synchronizations, polarity-free TTL level, SOG (Composite SYNC on green)
|
input |
Delta adapter ADP-40DD B: 100 VAC to 240 VAC / 50 |
|
voltage / |
Hz to 60 Hz + 3 Hz / 1.5 A (Max.), Lite-On adapter |
AC/DC |
frequency |
PA-1041-71 : 100 VAC to 240 VAC / 50 Hz or 60 Hz + |
/ current |
3 Hz / 1.2 A (Max.) |
|
Adapter* |
output |
|
|
|
|
|
voltage / |
OUTPUT: 12 VDC / 3.33 A |
|
current |
|
Dell S2340L monitor
Analog RGB: 0.7 Volts +/- 5 %, 75 ohm input impedance
Separate horizontal and vertical synchronizations, polarity-free TTL level, SOG (Composite SYNC on green)
Delta adapter ADP-40DD B: 100 VAC to 240 VAC / 50 Hz to 60 Hz + 3 Hz / 1.5 A (Max.), Lite-On adapter PA-1041-71 : 100 VAC to 240 VAC / 50 Hz or 60 Hz + 3 Hz / 1.2 A (Max.)
OUTPUT: 12 VDC / 3.33 A
Inrush current |
120 V: 30 A (Max.) |
120 V: 30 A (Max.) |
|
240 V: 60 A (Max.) |
240 V: 60 A (Max.) |
||
|
* Qualified Compatible AC/DC adapters:
CAUTION: To avoid damage to the monitor, use only the adapter designed for this particular Dell monitor.
Manufacturer |
Model |
Polarity |
Delta |
ADP-40DD BA |
|
Lite-On |
PA-1041-71TP-LF |
|
|
This monitor comes equipped with a failsafe mechanism to shut down the monitor when a non-compliant power adapter is plugged in the DC socket. The following message will be displayed when the monitor has detected that a wrong power adapter is used.
To avoid damage to the unit, user is strongly advised to use the original power adapter that comes packaged together with the monitor.
Preset Display Modes
The following table lists the preset modes for which Dell guarantees image size and centering:
S2240L: |
|
|
|
|
Display Mode |
Horizontal Frequency |
Vertical Frequency |
Pixel Clock (MHz) |
Sync Polarity |
|
(kHz) |
(Hz) |
|
(Horizontal/Vertical) |
VESA, 720 x 400 |
31.5 |
70.0 |
28.3 |
-/+ |
VESA, 640 x 480 |
31.5 |
60.0 |
25.2 |
-/- |
VESA, 640 x 480 |
37.5 |
75.0 |
31.5 |
-/- |
VESA, 800 x 600 |
37.9 |
60.0 |
40.0 |
+/+ |
VESA, 800 x 600 |
46.9 |
75.0 |
49.5 |
+/+ |
VESA, 1,024 x 768 |
48.4 |
60.0 |
65.0 |
-/- |
VESA, 1,024 x 768 |
60.0 |
75.0 |
78.8 |
+/+ |
VESA, 1,152 x 864 |
67.5 |
75.0 |
108.0 |
+/+ |
VESA, 1,280 x 1,024 |
64.0 |
60.0 |
108.0 |
+/+ |
VESA, 1,280 x 1,024 |
80.0 |
75.0 |
135.0 |
+/+ |
VESA, 1,920 x 1,080 |
67.5 |
60.0 |
148.5 |
+/+ |
S2340L: |
|
|
|
|
Display Mode |
Horizontal Frequency |
Vertical Frequency |
Pixel Clock (MHz) |
Sync Polarity |
|
(kHz) |
(Hz) |
|
(Horizontal/Vertical) |
VESA, 720 x 400 |
31.5 |
70.0 |
28.3 |
-/+ |
VESA, 640 x 480 |
31.5 |
60.0 |
25.2 |
-/- |
VESA, 640 x 480 |
37.5 |
75.0 |
31.5 |
-/- |
VESA, 800 x 600 |
37.9 |
60.0 |
40.0 |
+/+ |
VESA, 800 x 600 |
46.9 |
75.0 |
49.5 |
+/+ |
VESA, 1,024 x 768 |
48.4 |
60.0 |
65.0 |
-/- |
VESA, 1,024 x 768 |
60.0 |
75.0 |
78.8 |
+/+ |
VESA, 1,152 x 864 |
67.5 |
75.0 |
108.0 |
+/+ |
VESA, 1,280 x 1,024 |
64.0 |
60.0 |
108.0 |
+/+ |
VESA, 1,280 x 1,024 |
80.0 |
75.0 |
135.0 |
+/+ |
VESA, 1,920 x 1,080 |
67.5 |
60.0 |
148.5 |
+/+ |
Physical Characteristics
The following table lists the monitor's physical characteristics:
Model Number |
Dell S2240L monitor |
Dell S2340L monitor |
|
Connector type |
D-subminiature, blue connector; |
D-subminiature, blue connector; |
|
HDMI |
HDMI |
||
|
|||
Signal cable type |
Analog: attachable, D-Sub, 15 pins, shipped |
Analog: attachable, D-Sub, 15 pins, shipped |
|
detached from the monitor |
detached from the monitor |
||
|
|||
Dimensions: (with stand) |
|
|
|
Height |
380.28 mm (14.97 inches) |
398.90 mm (15.70 inches) |
|
Width |
499.10 mm (19.65 inches) |
532.20 mm (20.95 inches) |
|
Depth |
175.80 mm (6.92 inches) |
175.80 mm (6.92 inches) |
|
Dimensions: (without stand) |
|
|
|
Height |
297.60 mm (11.72 inches) |
316.20 mm (12.45 inches) |
|
Width |
499.10 mm (19.65 inches) |
532.20 mm (20.95 inches) |
|
Depth |
37.80 mm (1.49 inches) |
37.80 mm (1.49 inches) |
|
Stand dimensions: |
|
|
|
Height |
137.10 mm (5.40 inches) |
137.10 mm (5.40 inches) |
Width
Depth
Weight:
Weight with packaging
Weight with stand assembly, cables, adapter, and dongle
Weight of stand assembly
175.80 mm (6.92 inches) |
|
175.80 mm (6.92 inches) |
175.80 mm (6.92 inches) |
|
175.80 mm (6.92 inches) |
4.60 kg (10.14 lb) |
|
4.95 kg (10.91 lb) |
|
||
3.69 kg (8.14 lb) |
|
3.91 kg (8.62 lb) |
0.60 kg (1.32 lb) |
|
0.60 kg (1.32 lb) |
Environmental Characteristics
The following table lists the environmental conditions for your monitor: |
|
||
Model Number |
Dell S2240L monitor |
Dell S2340L monitor |
|
Temperature |
|
|
|
Operating |
0 ° C to 40 ° C (32 ° F to 104 ° F) |
0 ° C to 40 ° C (32 ° F to 104 ° F) |
|
Non-operating |
Storage: -20 ° C to 60 ° C (-4 ° F to 140 ° F) |
Storage: -20 ° C to 60 ° C (-4 ° F to 140 ° F) |
|
|
Shipping: -20 ° C to 60 ° C (-4 ° F to 140 ° F) |
Shipping: -20 ° C to 60 ° C (-4 ° F to 140 ° F) |
|
Humidity |
|
|
|
Operating |
10 % to 80 % (non-condensing) |
10 % to 80 % (non-condensing) |
|
Non-operating |
Storage: 5 % to 90 % (non-condensing) |
Storage: 5 % to 90 % (non-condensing) |
|
|
Shipping: 5 % to 90 % (non-condensing) |
Shipping: 5 % to 90 % (non-condensing) |
|
Altitude |
|
|
|
Operating |
5,000 m (16,405 ft) max |
5,000 m (16,405 ft) max |
|
Non-operating |
12,192 m (40,000 ft) max |
12,192 m (40,000 ft) max |
|
Thermal dissipation |
78.43 BTU/hour (maximum) |
81.84 BTU/hour (maximum) |
|
61.38 BTU/hour (typical) |
64.79 BTU/hour (typical) |
||
|
|||
LCD Monitor Quality & Pixel Policy
During the LCD Monitor manufacturing process, it is not uncommon for one or more pixels to become fixed in an unchanging state. The visible result is a fixed pixel that appears as an extremely tiny dark or bright discolored spot. When the pixel remains permanently lit, it is known as a "bright dot". Wh en the pixel remains black, it is known as a "dark dot".
In almost every case, these fixed pixels are hard to see and do not detract from display quality or usability. A display with 1 to 5 fixed pixels is considered normal and within competitive standards. For more information, see Dell Support site at: support.dell.com.
Loading...
