INSPIRON

SETUP GUIDE

INSPIRON

SETUP GUIDE

Model P03T        Type P03T001

Notes, Cautions, and Warnings

NOTE: A NOTE indicates important information that helps you make better use of your computer.

CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.

WARNING: A WARNING indicates a potential for property damage, personal injury, or death.

If you purchased a Dell™ n Series computer, any references in this document to Microsoft® Windows® operating systems are not applicable.

__________________

Information in this document is subject to change without notice. © 2009 Dell Inc. All rights reserved.

Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell, the DELL logo, YOURS IS HERE, Dell On Call, and DellConnect are trademarks of Dell Inc.; Intel, Celeron, and Pentium are registered trademarks of Intel Corporation in the U.S. and other countries; Microsoft, Windows, Windows Vista, and the Windows Vista start button logo are either trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries; Bluetooth is a registered trademark owned by Bluetooth SIG, Inc. and is used by Dell under license.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.

August 2009      P/N V0K33      Rev. A00

Contents

Setting Up Your Inspiron Laptop 5

Before Setting Up Your Computer

5

Connect the AC Adapter

6

Connect the Network Cable (Optional)

7

Press the Power Button

8

Set Up Microsoft Windows

9

Install the SIM (Optional)

10

Enable or Disable Wireless (Optional)

12

Connect to the Internet (Optional)

14

Using Your Inspiron Laptop 18

Right Side Features 18 Left Side Features 20 Computer Base Features 22 Touch Pad Gestures 24 Media Controls 26

Display Features 28 Removing and Replacing the Battery 30 Software Features 32 Dell Dock 35

Solving Problems 36

Beep Codes 36 Network Problems 37 Power Problems 38 Memory Problems 40 Lockups and Software Problems 40

Using Support Tools 43

Dell Support Center 43 System Messages 44 Hardware Troubleshooter 45 Dell Diagnostics 45

3

Contents

Restoring Your Operating System 49

System Restore 50 Dell Factory Image Restore 51 Operating System Reinstallation 53

Getting Help 55

Technical Support and Customer

Service 56 DellConnect 56 Online Services 57 Automated Order-Status Service 58 Product Information 58

Returning Items for Repair Under

Warranty or for Credit 59 Before You Call 60 Contacting Dell 61

Finding More Information and

Resources 62 Basic Specifications 64 Appendix 70

Macrovision Product Notice 70

Information for NOM, or Official

Mexican Standard (only for Mexico) 71

Index 72

4

Setting Up Your Inspiron Laptop

This section provides information about setting up your Inspiron11 laptop.

Before Setting Up Your Computer

When positioning your computer, ensure that you allow easy access to a power source, adequate ventilation, and a level surface to place your computer.

Restricting airflow around your Inspiron laptop may cause it to overheat. To prevent overheating ensure that you leave at least 10.2 cm (4 inches) at the back of the computer and a minimum of 5.1 cm (2 inches) on all other

sides. You should never place your computer in an enclosed space, such as a cabinet or drawer when it is powered on.

WARNING: Do not block, push objects into, or allow dust to accumulate in the air vents. Do not store your Dellcomputer in a low-airflow environment, such as a closed briefcase, while it is powered on. Restricting the airflow can damage the computer or cause a fire. The computer turns on the fan when the computer gets hot. Fan noise is normal and does not indicate a problem with the fan or the computer.

CAUTION: Placing or stacking heavy or sharp objects on the computer may result in permanent damage to the computer.

INSPIRON

5

Setting Up Your Inspiron Laptop

Connect the AC Adapter

Connect the AC adapter to the computer and then plug it into an electrical outlet or surge protector.

WARNING: The AC adapter works with electrical outlets worldwide. However, power connectors and power strips vary among countries. Using an incompatible cable or improperly connecting the cable to a power strip or electrical outlet may cause fire or permanent damage to your computer.

6

Setting Up Your Inspiron Laptop

Connect the Network Cable (Optional)

To use a wired network connection, connect the network cable.

7

Setting Up Your Inspiron Laptop

Press the Power Button

8

Setting Up Your Inspiron Laptop

Set Up Microsoft Windows

Your Dell computer is preconfigured with Microsoft Windows operating system. To set up Windows for the first time, follow the instructions on the screen. These steps are mandatory and may take some time to complete. The Windows setup screens will take you through several procedures including accepting license agreements, setting preferences, and setting up an Internet connection.

CAUTION: Do not interrupt the operating system’s setup process. Doing so may render your computer unusable and you will need to reinstall the operating system.

NOTE: For optimal performance of your computer, it is recommended that you download and install the latest BIOS and drivers for your computer available on the Dell Support website at support.dell.com.

9

Setting Up Your Inspiron Laptop

Install the SIM (Optional)

Installing a Subscriber Identity Module (SIM) card allows you to browse the Internet, check e-mail, and connect to a Virtual Private Network. To access these features, you must be within the network of your cellular service provider.

NOTE: Installing a SIM is not required if you are using an EVDO card to access the Internet.



2

1 battery bay



2SIM card

3SIM card slot

1

3

10

Setting Up Your Inspiron Laptop

To install the SIM:

1.Turn off your computer.

2.Remove the battery (see “Removing and Replacing the Battery” on 30).

3.In the battery bay, slide the SIM into the SIM card slot.

4.Replace the battery (see “Removing and Replacing the Battery” on 30).

5.Turn on your computer.

To remove the SIM, press and eject the SIM.

11

Setting Up Your Inspiron Laptop

Enable or Disable Wireless (Optional)

12

Setting Up Your Inspiron Laptop

To enable wireless:

1.Ensure that your computer is turned on.

2.Press the wireless key on the keyboard. The Wireless Radio Control dialog box appears.

3.Select the options you want to enable.

4.Click OK.

To disable wireless:

1.Press the wireless key on the keyboard. The Wireless Radio Control dialog box appears.

2.Clear the options you want to disable.

3.Click OK.

NOTE: The Enable Flight Mode button allows you to quickly turn all of your wireless radios (Bluetooth, Mobile Broadband, and GPS) off, such as when you are asked to disable all wireless radios on an airplane flight.

13

Setting Up Your Inspiron Laptop

Connect to the Internet (Optional)

To connect to the Internet, you need an external modem or network connection and an Internet service provider (ISP).

If an external USB modem or WLAN adapter is not a part of your original order, you can purchase one from the Dell website at www.dell.com.

14

Setting Up a Wired Connection

If you are using a dial-up connection, connect the telephone line to the optional external USB modem and to the telephone wall connector before you set up your Internet connection.

If you are using a DSL or cable/satellite modem connection, contact your ISP or cellular telephone service for setup instructions.

To complete setting up your wired Internet connection, follow the instructions in “Setting Up Your Internet Connection” on page 16.

Setting Up a Wireless Connection

Before you can use your wireless Internet connection, you need to connect to your wireless router.

To set up your connection to a wireless router:

Windows Vista®

1.Ensure that wireless is enabled on your computer (see “Enable or Disable Wireless” on page 12).

2.Save and close any open files, and exit any open programs.

3.Click Start Connect To.

4.Follow the instructions on the screen to complete the setup.

Setting Up Your Inspiron Laptop

Windows® 7

1.Ensure that wireless is enabled on your computer (see “Enable or Disable Wireless” on page 12).

2.Save and close any open files, and exit any open programs.

3.Click Start Control PanelNetwork and Sharing CenterConnect to a network.

4.Follow the instructions on the screen to complete the setup.

15

Setting Up Your Inspiron Laptop

Setting Up Your Internet Connection

ISPs and ISP offerings vary by country. Contact your ISP for offerings available in your country.

If you cannot connect to the Internet but have successfully connected in the past, the ISP might have a service outage. Contact your ISP to check the service status, or try connecting again later.

Have your ISP information ready. If you do not have an ISP, the Connect to the Internet wizard can help you get one.

16

Windows Vista®

NOTE: The following instructions are applicable for the Windows default view, and may not apply if you set your computer to the Windows Classic view.

1.Save and close any open files, and exit any open programs.

2.Click Start Control Panel.

3.Click Network and InternetNetwork and Sharing CenterSet up a connection or NetworkConnect to the Internet.

The Connect to the Internet window appears.

NOTE: If you do not know which type of connection to select, click Help me choose or contact your ISP.

4.Follow the instructions on the screen and use the setup information provided by your ISP to complete the setup.

Setting Up Your Inspiron Laptop

Windows® 7

1.Save and close any open files, and exit any open programs.

2.Click Start Control PanelNetwork and Sharing CenterSet up a new connection or networkConnect to the Internet.

The Connect to the Internet window appears.

NOTE: If you do not know which type of connection to select, click Help me choose or contact your ISP.

3.Follow the instructions on the screen and use the setup information provided by your ISP to complete the setup.

17

INSPIRON

Using Your Inspiron Laptop

This section provides information about the features available on your Inspiron 11 laptop.

Right Side Features

1

2

3

4

5

6

18

Using Your Inspiron Laptop

1 3-in-1 Media Card Reader — Provides a fast and convenient way to view and share digital photos, music, videos, and documents stored on the following digital memory cards:

• Secure Digital (SD) memory card

• Memory Stick

• Secure Digital High Capacity (SDHC) card

• Memory Stick PRO

• Multi Media Card (MMC/MMC+)



2 Audio out/Headphone connector — Connects to a pair of headphones, or sends audio to a powered speaker or sound system.

3 Audio in/Microphone connector — Connects to a microphone or input signal for use with audio programs.

4 USB 2.0 connectors (2) — Connects to USB devices, such as a mouse, keyboard, printer, external drive, or MP3 player.

5 AC adapter connector — Connects to an AC adapter to power the computer and charge the battery.

6Security cable slot — Attaches a commercially available antitheft device to the computer.

NOTE: Before you buy an antitheft device, ensure that it works with the security cable slot on your computer.

19

Using Your Inspiron Laptop

Left Side Features

1

2

3

20

Using Your Inspiron Laptop

1 Network connector — Connects your computer to a network or a broadband device if you are using a wired network. The two lights next to the connector indicate status and activity for a wired network connection.

2 HDMI connector — Connects to a TV for both 5.1 audio and video signals. NOTE: When used with a monitor, only the video signal is read.

3 Power USB connector — Connects to USB devices that require more power, such as certain printers and bar code scanners. This connector supports a current load of up to 2 A.

21

Dell P03T, 1110, P03T001 User Manual

Using Your Inspiron Laptop

Computer Base Features

































1

2

3

4

22
